Audio Output (Fix)500 mV(rms)(-4dBs), low Impedance, (400 Hz when modulated 100 %), RCA pin jack × 2
Digital Audio Optical OutputDigital SPDIF × 1
Remote Control UnitRM-C1290G (AA/R6/UM-3 battery × 2)
Component Video
Analog
Digital
VHF Low
VHF High
UHF
CATV
Video IF
Sound IF
[Input-2]
S-video
[Input-1]
Video
Audio
CCIR (M)
ATSC terrestrial / Digital cable
02ch - 06ch : 54MHz - 88MHz
07ch - 13ch : 174MHz - 216MHz
14ch - 69ch : 470MHz - 806MHz
54MHz - 804MHz
Low Band : 02 - 06
High Band : 07 - 13
Mid Band : 14 - 22
Super Band : 23 - 36
Hyper Band : 37 - 64
Ultra Band : 65 - 94, 100 - 135
Sub Mid Band : 01, 96 - 99
45.75 MHz
41.25 MHz (4.5MHz)
(H: 55.4 cm × V: 41.8 cm)
RCA pin jack × 3
Y : 1V(p-p), 75 Ω, negative sync
Pb/Pr : 0.7 V(p-p), 75 Ω
Mini DIN 4-pin connector × 1
Y : 1 V(p-p), 75 Ω, negative sync
C : 0.286 V(p-p)(burst signal), 75 Ω
1 V(p-p), 75 Ω, negative sync, RCA pin jack × 2
500 mV(rms)(-4dBs), high impedance, RCA pin jack × 6
AV-27F577AV-32F577
Contents
87.7 cm × 69.9 cm × 56.5 cm
(34-5/8" × 27-5/8" × 22-1/4")
82.2 cm (32") Measured diagonally
(H: 65.6 cm × V : 49.6 cm)
Design & specifications are subject to change without notice.
1-2 (No.YA387)
Page 3
SECTION 1
PRECAUTION
1.1SAFETY PRECAUTIONS
(1) The design of this product contains special hardware, many
circuits and components specially for safety purposes. For
continued protection, no changes should be made to the original
design unless authorized in writing by the manufacturer.
Replacement parts must be identical to those used in the original
circuits. Service should be performed by qualified personnel only.
(2) Alterations of the design or circuitry of the products should not be
made. Any design alterations or additions will void the
manufacturer's warranty and will further relieve the manufacturer
of responsibility for personal injury or property damage resulting
therefrom.
(3) Many electrical and mechanical parts in the products have special
safety-related characteristics. These characteristics are often not
evident from visual inspection nor can the protection afforded by them
necessarily be obtained by using replacement components rated for
higher voltage, wattage, etc. Replacement parts which have these
special safety characteristics are identified in the parts list of Service
manual. Electrical components having such features are
identified by shading on the schematics and by ( ) on the
parts list in Service manual. The use of a substitute replacement
which does not have the same safety characteristics as the
recommended replacement part shown in the parts list of Service
manual may cause shock, fire, or other hazards.
(4) Use isolation transformer when hot chassis.
The chassis and any sub-chassis contained in some products are
connected to one side of the AC power line. An isolation
transformer of adequate capacity should be inserted between the
product and the AC power supply point while performing any
service on some products when the HOT chassis is exposed.
(5) Don't short between the LIVE side ground and ISOLATED (NEU-
TRAL) side ground or EARTH side ground when repairing.
Some model's power circuit is partly different in the GND. The difference of the GND is shown by the LIVE : ( ) side GND, the ISOLATED (NEUTRAL) : ( ) side GND and EARTH : ( ) side GND.
Don't short between the LIVE side GND and ISOLATED (NEUTRAL)
side GND or EARTH side GND and never measure the LIVE side
GND and ISOLATED (NEUTRAL) side GND or EARTH side GND at
the same time with a measuring apparatus (oscilloscope etc.). If
above note will not be kept, a fuse or any parts will be broken.
(6) If any repair has been made to the chassis, it is recommended that
the B1 setting should be checked or adjusted (See B1 POWER
SUPPLY check).
(7) The high voltage applied to the picture tube must conform with that
specified in Service manual. Excessive high voltage can cause an
increase in X-Ray emission, arcing and possible component
damage, therefore operation under excessive high voltage
conditions should be kept to a minimum, or should be prevented.
If severe arcing occurs, remove the AC power immediately and
determine the cause by visual inspection (incorrect installation,
cracked or melted high voltage harness, poor soldering, etc.). To
maintain the proper minimum level of soft X-Ray emission,
components in the high voltage circuitry including the picture tube
must be the exact replacements or alternatives approved by the
manufacturer of the complete product.
(8) Do not check high voltage by drawing an arc. Use a high voltage
meter or a high voltage probe with a VTVM. Discharge the picture
tube before attempting meter connection, by connecting a clip lead
to the ground frame and connecting the other end of the lead
through a 10k
(9) When service is required, observe the original lead dress. Extra
precaution should be given to assure correct lead dress in the high
voltage circuit area. Where a short circuit has occurred, those
components that indicate evidence of overheating should be
replaced. Always use the manufacturer's replacement
components.
Ω 2W resistor to the anode button.
(10) Isolation Check (Safety for Electrical Shock Hazard)
After re-assembling the product, always perform an isolation
check on the exposed metal parts of the cabinet (antenna
terminals, video/audio input and output terminals, Control knobs,
metal cabinet, screw heads, earphone jack, control shafts, etc.) to
be sure the product is safe to operate without danger of electrical
shock.
a) Dielectric Strength Test
The isolation between the AC primary circuit and all metal parts
exposed to the user, particularly any exposed metal part having a
return path to the chassis should withstand a voltage of 1100V AC
(r.m.s.) for a period of one second.
(. . . . Withstand a voltage of 1100V AC (r.m.s.) to an appliance rat-
ed up to 120V, and 3000V AC (r.m.s.) to an appliance rated 200V
or more, for a period of one second.) This method of test requires
a test equipment not generally found in the service trade.
b) Leakage Current Check
Plug the AC line cord directly into the AC outlet (do not use a line
isolation transformer during this check.). Using a "Leakage
Current Tester", measure the leakage current from each exposed
metal part of the cabinet, particularly any exposed metal part
having a return path to the chassis, to a known good earth ground
(water pipe, etc.). Any leakage current must not exceed 0.5mA AC
(r.m.s.).
However, in tropical area, this must not exceed 0.2mA AC (r.m.s.).
Alternate Check Method
Plug the AC line cord directly into the AC outlet (do not use a
line isolation transformer during this check.). Use an AC
voltmeter having 1000
following manner. Connect a 1500
a 0.15
µF AC-type capacitor between an exposed metal part
Ω per volt or more sensitivity in the
Ω 10W resistor paralleled by
and a known good earth ground (water pipe, etc.). Measure the
AC voltage across the resistor with the AC voltmeter. Move the
resistor connection to each exposed metal part, particularly any
exposed metal part having a return path to the chassis, and
measure the AC voltage across the resistor. Now, reverse the
plug in the AC outlet and repeat each measurement. Any
voltage measured must not exceed 0.75V AC (r.m.s.). This
corresponds to 0.5mA AC (r.m.s.).
However, in tropical area, this must not exceed 0.3V AC
(r.m.s.). This corresponds to 0.2mA AC (r.m.s.).
AC VOLTMETER
(HAVING 1000 /V,
OR MORE SENSITIVITY)
0.15 F AC-TYPE
PLACE THIS PROBE
1500 10W
(11) High voltage hold down circuit check.
GOOD EARTH GROUND
ON EACH EXPOSED
ME TAL PAR T
After repair of the high voltage hold down circuit, this circuit shall
be checked to operate correctly.See item "How to check the highvoltage hold down circuit".
This mark shows a fast
operating fuse, the
letters indicated below
show the rating.
A V
POWER CORD
REPLACEMENT WARNING.
Connecting the white line side of power
cord to "WHT" character side.
PWB
White line side
WHT
PW
(No.YA387)1-3
Page 4
SECTION 2
SPECIFIC SERVICE INSTRUCTIONS
2.1FEATURES
Built in ATSC (Advanced Television Systems Committee)
TUNER
This TV can receive Digital broadcasting (ATSC), Digital cable
and Analogue broadcasting.
SMART CAPTION
Smart caption will appear when you press the MUTING button,
only on channels where the broadcast contains CLOSED
CAPTION information.
SMART SOUND
Decreases high sound levels, giving a regulated sound level.
FLAT SQUARE CRT
It became legible from any position by CRT with few reflection
and reflect lumps on the flat screen.
DIGITAL COMB FILTER
By the 3D digital comb filter, the refreshed image can be seen.
VIDEO STATUS
Expression of a favorite screen can be chosen by the VIDEO
STATUS function.
COMPONENT INPUT
Since the component signal input terminal is equipped, it
reappears direct without deteriorating the signal from DVD.
V-CHIP
Since the V-CHIP is built in, it can choose, view and listen to a
healthy program.
MTS STEREO
The voice multiplex function of the MTS system is built in.
(MTS = Multi channel Television Sound system)
RETURN PLUS
You program a specific channel to return to while scanning
through the channels using the CH+ and CH - keys.
VIDEO INPUT LABEL
This function is used to label video input connections for the
onscreen displays.
A.H.S.
A.H.S. adds a more spacious surround sound. Music gives
basic effect and movie for more effect.
How to recognize from the appearance of the model concerned is written below. Please distinguish from several contents currently
printed on the rating label
28 V2_IN/Y_IN I Not used56 LEDO POWER / ON TIMER LED lndication [lighting : L]
Not used: X-ray detection (for protection) [Detection : H]
Pin
Pin nameI/OFunction
No.
MONITOR_OUT
48 DTVM_REQI Read request from DTV micom [Request : H]
O Not used
(No.YA387)1-5
Page 6
SECTION 3
DISASSEMBLY
3.1DISASSEMBLY PROCEDURE
CAUTION AT DISASSEMBLY:
• Be sure to perform the SYSTEM SETTEING, at the end of the procedure.
• Make sure that the power cord is disconnected from the outlet.
• Pay special attention not to break or damage the parts.
• When removing each board, remove the connectors as required. Taking notes of the connecting points (connector numbers) makes service procedure manageable.
• Make sure that there is no bent or stain on the connectors before inserting, and firmly insert the connectors.
3.1.1 REMOVING THE REAR COVER
(1) Disconnect the power plug.
(2) Remove the 12 screws [A].
(3) Withdraw the REAR COVER backward.
3.1.2 REMOVING THE AV TERMINAL BOARD
• Remove the REAR COVER.
(1) Remove the 4 screws [B].
(2) Withdraw the AV TERMINAL BOARD toward you.
3.1.3 REMOVING THE CHASSIS
• Remove the REAR COVER.
• Remove the AV TERMINAL BOARD.
(1) Slightly raise the both sides of CHASSIS by hand.
(2) Remove the 2 claws under the both side of the CHASSIS
from the front cabinet.
(3) Withdraw the CHASSIS backward.
(If necessary, remove the wire clamp, connectors etc.)
3.1.4 REMOVING THE SPEAKER [AV-27F577]
• Remove the REAR COVER.
(1) Remove the 4 screws [C].
(2) Remove the SPEAKER.
(3) Follow the same steps when removing the other hand
SPEAKER.
3.1.7 REMOVING THE FRONT CONTROL PWB
• Remove the REAR COVER.
• Remove the CHASSIS.
(1) Remove the 2 screws [G].
(2) Withdraw the FRONT CONTROL PWB toward you.
*If necessary, remove the wire clamp, connector etc.
3.1.8 REMOVING THE USB PWB
• Remove the REAR COVER.
• Remove the AV TERMINAL BOARD.
(1) Remove the 2 screws [H].
(2) Withdraw the USB PWB toward you.
*If necessary, remove the wire clamp, connector etc.
3.1.9 CHECKING THE CHASSIS
To check the PW Board from back side.
(1) Pull out the CHASSIS (refer to REMOVING THE CHASSIS).
(2) Erect the CHASSIS vertically with the HVT side facing up
so that you can easily check the back side of the PW board.
CAUTION :
• When erecting the CHASSIS, be careful so that there will be
no contacting with other PW Board.
• Before turning on power, make sure that the wire connector
is properly connected.
• When conducting a check with power supplied, be sure
to confirm that the CRT EARTH WIRE (BRAIDED ASS'Y)
is connected to the CRT SOCKET PWB.
3.1.5 REMOVING THE SPEAKER [AV-32F577]
• Remove the REAR COVER.
(1) Remove the 2 screws [D].
(2) Remove the SPEAKER with SPEAKER HOLDER.
(3) Remove the 2 screws [E].
(4) Remove the SPEAKER from the SPEAKER HOLDER.
(5) Follow the same steps when removing the other hand
SPEAKER.
NOTE :
When remove the 2 screws [D] of the SPEAKER, remove the
lower side screw first, and then remove the upper one.
3.1.6 REMOVING THE LED & POWER SW PWB
• Remove the REAR COVER.
• Remove the CHASSIS.
(1) Remove the 2 screws [F].
(2) Withdraw the LED & POWER SW PWB toward you.
*If necessary, remove the wire clamp, connector etc.
1-6 (No.YA387)
3.1.10 WIRE CLAMPING AND CABLE TYING
(1) Be sure to clamp the wire.
(2) Never remove the cable tie used for tying the wires together.
Should it be inadvertently removed, be sure to tie the wires
with a new cable tie.
Page 7
FRONT CABINET
CRT SOCKET
PWB
FRONT CONTROL PWB
Claw
AV TERMINAL BOARD
MAIN PWB
REAR
E
SPEKAER
SPEAKER
HOLDER
REAR COVER
LED&POWER SW PWB
<AV-27F577>
SPEKAER
C
<AV-32F577>
SPACER
D
CHASSIS
F
L/F PWB
G
AV SW PWB
H
USB PWB
AV TERMINAL BOARD
ATSC TUNER
MODULE PWB
B
POWER CORD
Fig.1
A
(No.YA387)1-7
Page 8
3.1.11 REMOVING THE CRT
NOTE:
• Replacement of the CRT should be performed by 2 or more
persons.
• After removing the REAR COVER, CHASSIS etc.,
(1) Putting the CRT change table on soft cloth, the CRT
change table should also be covered with such soft cloth
(shown in Fig. 2).
(2) While keeping the surface of CRT down, mount the TV set
on the CRT change table balanced will as shown in Fig. 2.
(3) Remove 4 screws marked by arrows with a box type screw-
driver as shown in Fig. 3.
NOTE:
Since the cabinet will drop when screws have been
removed, be sure to support the cabinet with hands.
(4) After 4 screws have been removed, put the cabinet slowly
on cloth (At this time, be carefully so as not to damage the
front
surface of the cabinet) shown in Fig. 4.
NOTE:
• The CRT should be assembled according to the
opposite sequence of its dismounting steps.
• The CRT change table should preferably be smaller
that the CRT surface, and its height be about 35cm.
CRT CHANGE TABLE
CLOTH
CRT
CHANGE
TABLE
Fig.2
CRT
Fig.3
APPROX.
35cm
BOX
TYPE
SCREW
DRIVER
CRT
CABINET
CRT
CHANGE TABLE
Fig.4
COATING OF SILICON GREASE FOR ELECTRICAL INSULATION ON THE CRT ANODE CAP SECTION.
Subsequent to replacement of the CRT and HV transformer or repair of the anode cap, etc. by dismounting them, be sure to coat
silicon grease for electrical insulation as shown in Fig.5.Wipe around the anode button with clean and dry cloth. (Fig.5)Coat silicon
grease on the section around the anode button. At this time, take care so that any silicon greases dose not sticks to the anode
button. (Fig.6)
Silicon grease product No. KS - 650N
CRT
Anode button
Approx.
20mm (Do not
coat grease on
this section
Silicon grease
should be coated
by 5mm or more
from the outside
diameter of anode
cap.
1-8 (No.YA387)
Silicon grease
coating
Fig.5
Anode button
(No sticking of
silicon grease)
Fig.6
Coating position
of silicon grease
Anode cap
Page 9
3.2MEMORY IC REPLACEMENT
• This model uses the memory IC.
• This memory IC stores data for proper operation of the video and drive circuits.
• When replacing, be sure to use an IC containing this (initial value) data.
3.2.1 MEMORY IC TABLE
Simbol Number of pins Mounting PWBMain content of data
IC702
8-pinMAIN PWBSetting value of Initial setting data is memorized.
3.2.2 MEMORY IC REPLACEMENT PROCEDURE
1. Power off
Switch off the power and disconnect the power plug.
2. Replace the memory IC
Be sure to use a memory IC written with the initial setting data.
3. Power on
Connect the power cord to the wall outlet and switch on the
power.
4. Receiving channel setting
Refer to the OPERATING INSTRUCTIONS (USER'S GUIDE)
and set the receive channels (Channels Preset) as described.
5. User settings
Check the user setting items according to the "FACTORY
SETTING ITEM" table.
Where these do not agree, refer to the OPERATING
INSTRUCTIONS (USER'S GUIDE) and set the items as
described.
6. SERVICE MODE setting
Verify what to set in the SERVICE MODE, and set whatever is
necessary(Fig.1) .
Refer to the SERVICE ADJUSTMENT for setting.
3.2.3 SERVICE MODE SETTING ITEMS
Service Menu
Service Menu
1.Digital Service
2.TV-Micro Service
3.Conver Service
4.Diagnostics
Press [2] key
Digital Service
Digital Service
1.Adjust
2.Memory Edit
3.Edit Config
4.All Reset
5.Select Channel Map
6.Clear Channel Map
7.Digital Tunig Test
Press [1] key
TV-Micro Service
TV-Micro Service
1.Adjust
2.White Balance
3.Memory Edit
Fig.1
Setting itemsSettingsItem No.
1. Digital Service
Audio system settingAdjustA001~A010
2. TV-Micro Service
Video system settingAdjustS001 - S045
Deflection system AdjustD001 - D033
Factory system settingFixedF001 - F003
(No.YA387)1-9
Page 10
3.2.4 SETTINGS OF FACTORY SHIPMENT
3.2.4.1BUTTON OPERATION3.2.4.2REMOTE CONTROL DIRECT OPERATION
Setting itemSetting position
POWEROff
CHANNELCABLE-02
VOLUME10
3.2.4.3REMOTE CONTROL MENU OPERATION
INPUTTV
CHANNELCABLE-02
VOLUME10
MUTINGOFF
DISPLAYOFF
SLEEP TIMEROFF
V. STATUSDYNAMIC
THEAT. PROOFF
C.C.OFF
MTSSTEREO
ASPECT4 : 3
SOUND
Setting itemSetting position
A.H.SOFF
Smart SoundOFF
(1) INITIAL SETUP
Setting itemSetting position
Noise MutingOn
LanguageEnglish
Front Panel LockOff
V-ChipOff
Set Lock Code0000
Closed Caption Auto(CC1/T1)
Auto Shut OffOff
(2) TUNER SETUP
Setting itemSetting position
Auto Tuner SetupUnnecessary to set
(3) EXTERNAL INPUT
Setting itemSetting position
Video Input LabelAll blank
(7) PICTURE ADJUST
Customers can adjust the picture setting of menu screen as their own like but the picture standard value during factory shipment is as below.
Setting itemTINTCOLORPICTUREBRIGHTDETAIL
STANDARD00000LOWON
DINAMIC00+140+10HIGHON
THEATER-3-3-10+10HIGHOFF
GAME0+7-100+7LOWON
(4) SOUND ADJUST
Setting itemSetting position
Bass0
Treble+2
Balance0
Optical OutPCM
Turn On VolumeCurrent
Volume Limit50
(5) CLOCK / TIMERS
Setting itemSetting position
Set ClockManual
On / Off TimerOff
(6) INTERACTIVE PLUG-IN MENU
Refer to the OPERATING INSTRUCTIONS (USER'S GUIDE).
COLOR TEMPERATURE
VSM
1-10 (No.YA387)
Page 11
3.3REPLACEMENT OF CHIP COMPONENT
3.3.1 CAUTIONS
(1) Avoid heating for more than 3 seconds.
(2) Do not rub the electrodes and the resist parts of the pattern.
(3) When removing a chip part, melt the solder adequately.
(4) Do not reuse a chip part after removing it.
3.3.2 SOLDERING IRON
(1) Use a high insulation soldering iron with a thin pointed end of it.
(2) A 30w soldering iron is recommended for easily removing parts.
3.3.3 REPLACEMENT STEPS
1. How to remove Chip parts
2. How to install Chip parts
[Resistors, capacitors, etc.]
(1) As shown in the figure, push the part with tweezers and
alternately melt the solder at each end.
(2) Shift with the tweezers and remove the chip part.
[Transistors, diodes, variable resistors, etc.]
(1) Apply extra solder to each lead.
SOLDER
SOLDER
[Resistors, capacitors, etc.]
(1) Apply solder to the pattern as indicated in the figure.
(2) Grasp the chip part with tweezers and place it on the
solder. Then heat and melt the solder at both ends of the
chip part.
[Transistors, diodes, variable resistors, etc.]
(1) Apply solder to the pattern as indicated in the figure.
(2) Grasp the chip part with tweezers and place it on the
solder.
(3) First solder lead A as indicated in the figure.
(2) As shown in the figure, push the part with tweezers and
alternately melt the solder at each lead. Shift and remove
the chip part.
NOTE :
After removing the part, remove remaining solder from the
pattern.
A
B
C
(4) Then solder leads B and C.
A
B
C
(No.YA387)1-11
Page 12
SECTION 4
ADJUSTMENT
4.1ADJUSTMENT PREPARATION
(1) There are 2 ways of adjusting this TV : One is with the
REMOTE CONTROL UNIT and the other is the
conventional method using adjustment parts and
components.
(2) The adjustment using the REMOTE CONTROL UNIT is
made on the basis of the initial setting values. The
setting values which adjust the screen to the optimum
condition can be different from the initial setting
values.
(3) Make sure that connection is correctly made AC to AC
power source.
(4) Turn on the power of the TV and measuring instruments for
warming up for at least 30 minutes before starting
adjustments.
(5) If the receive or input signal is not specified, use the most
appropriate signal for adjustment.
(6) Never touch the parts (such as variable resistors,
transformers and condensers) not shown in the adjustment
items of this service adjustment.
4.2PRESET SETTING BEFORE ADJUSTMENTS
Unless otherwise specified in the adjustment items, preset the
following functions with the REMOTE CONTROL UNIT.
ItemPreset value
VIDEO STATUSSTANDARD
PICTURE adjustmentAll 00
COLOR TEMPERATURELOW
VSMOFF
SOUND adjustmentAll 00
A.H.S.OFF
Smart SoundOFF
ASPECT4 : 3
4.3MEASURING INSTRUMENT AND FIXTURES
• DC voltmeter (or digital voltmeter)
• DC power supply
• Oscilloscope
• Signal generator (Pattern generator) [NTSC]
• TV audio multiplex signal generator
• Remote control unit
4.4ADJUSTMENT ITEMS
CHECK ITEM
• B1 VOLTAGE check
• HV POTENTIAL check
• X-RAY PROTECTOR OPERATION-1 check
• X-RAY PROTECTOR OPERATION-2 check
FOCUS
• FOCUS adjustment
DEFLECTION CIRCUIT [2.TV-Micro Service]
• V. SIZE / V. POSITION (4:3) adjustment
• V. SIZE / V. POSITION (16:9) adjustment
• H. POSITION / H. SIZE / SIDE PIN (4:3) adjustment
•
H. POSITION / H. SIZE / SIDE PIN (16:9) adjustment
VIDEO CIRCUIT [2.TV-Micro Service]
• WHITE BALANCE(High Light & Low Light) adjustment
• SUB BRIGHT adjustment
• SUB CONTRAST adjustment
• SUB COLOR adjustment
• SUB TINT adjustment
MTS CIRCUIT [1.Digital Service]
• MTS INPUT LEVEL adjustment
• MTS SEPARATION adjustment
1-12 (No.YA387)
Page 13
4.5ADJUSTMENT LOCATIONS
HVT
CEN TER
SW
FRONT
FRONT
FRONT
F
W
L/F PWB
F901
5A
LED & POWER SW PWB
POWER SW
SPEAKER
POWER LED
B
M
MEMORY IC
IC702
G
E
FRONT CONTROL PWB
CN600B
CN600B
ATSC TUNER
MODULE PWB
CN600G
F
CN600R
FRONT
W
DEG
DEG COIL
MAIN PWB
PW
POWER CORD
R
CN002
AV SW PWB
CRT SOCKET PWB
TP-R
TP-E
CN300E
CN300A
IC201
(SOLDER SIDE)
TP-B
TOP
CN1005
CN001
TUNER
DOWN
V CENTER
S421
1 : TP-E
2 : X-RAY2
3 : X-RAY1
4 : NC
5 : TP-91B
SW
UP
5
DEF. YOKE
HV
HVT
E1
S1
A
1
( )
(BRAIDED ASS'Y)
CRT EARTH
UPPER : FOCUS
LOWER : SCREEN
USB PWB
TOP
CN800L
FRONT
(No.YA387)1-13
Page 14
4.6SERVICE MODE
Service Menu
1.Digital Service
2.TV-Micro Service
3.Conver Service
4.Diagnostics
4.6.1 BASIC OPERATION OF SERVICE MODE
Operate the SERVICE MODE with the REMOTE CONTROL UNIT.
4.6.1.1HOW TO ENTER THE SERVICE MODE
(1) Set to "0 minutes" using the [SLEEP TIMER] key.
(2) While "0 minutes" is displayed, press the [VIDEO
STATUS] key and [DISPLAY] key simultaneously.
(3) Enter the SERVICE MODE (Fig.1)
SERVICE MENU SCREEN
Service Menu
1.Digital Service
2.TV-Micro Service
3.Conver Service
4.Diagnostics
4.6.1.4SERVICE MODE SELECT KEY LOCATION
[SLEEP TIMER] key
[POWER] key
[NUMBER
[MUTING] key
] key
Fig.1
4.6.1.2HOW TO EXIT THE SERVICE MODE
Press the [ MENU ] key to exit the SERVICE MODE.
4.6.1.3HOW TO STORE OF SETTING VALUE
When adjustment is completed, press the [MUTING] key to
memorize the adjustment value.
NOTE:
If not to do it, adjustment data is not memorized to the memory
IC. And if exit the adjustment mode before memorize the data,
the adjustment value which you change is canceled.
[DISPLAY] key
[MENU] key
[VOL-] key
[CH+] key
[BACK] key
[VOL+] key
[CH-] key
[VIDEO STATUS] key
1-14 (No.YA387)
Page 15
4.6.2 SERVICE MODE MENU FLOW CHART
TVM Memory Edit
Addr (H) 0000
0 1 2 3 4 5 6 7
04 01 06 58 FF FF FF FF
8 9 A B C D E F
11 29 00 00 01 FF FD FD
X240 Memory Edit
Addr (H) 0000
0 1 2 3 4 5 6 7
04 01 06 58 FF FF FF FF
8 9 A B C D E F
11 29 00 00 01 FF FD FD
4.Diagnostics
[Refer to SECTION 5]
1. Digital Service
Digital Service
1.Adjust
2.Memory Edit
3.Edit Config
4.All Reset
5.Select Channel Map
6.Clear Channel Map
7.Digital Tunig Test
A001- A010
1.Adjust
A001 IN LAVEL 137
NTSC 43-4:3 STANDARD L
3. Edit Config
2. Memory Edit
4. All Reset
DO NOT ADJUST
X240 Memory Edit
Addr (H) 0000
0 1 2 3 4 5 6 7
04 01 06 58 FF FF FF FF
8 9 A B C D E F
11 29 00 00 01 FF FD FD
SERVICE MENU
Service Menu
1.Digital Service
2.TV-Micro Service
3.Conver Service
4.Diagnostics
1. Adjust
S001 COLOR 137
NTSC 43-4:3 STANDARD L
S001- S045
S001 COLOR 137
NTSC 43-4:3 Standard L
D001 - D033
3.Conver Service [Not used]
2. TV-Micro Service
TV-Micro Service
1.Adjust
2.White Balance
3.Memory Edit
5. Select Channel Map 6. Clear Channel Map
7. Digital Tunig Test
2. White Balance
3. Memory Edit
D001 V FREQ 137
NTSC 43-4:3 Standard L
F001- F003
F001 137
NTSC 43-4:3 Standard L
BR 114
DRV R060B059
CUT R060G065B033
DO NOT ADJUST
TVM Memory Edit
Addr (H) 0000
0 1 2 3 4 5 6 7
04 01 06 58 FF FF FF FF
8 9 A B C D E F
11 29 00 00 01 FF FD FD
(No.YA387)1-15
Page 16
4.6.3 DESCRIPTION OF STATUS DISPLAY
X240 Memory Edit
Addr (H) 0000
0 1 2 3 4 5 6 7
04 01 06 58 FF FF FF FF
8 9 A B C D E F
11 29 00 00 01 FF FD FD
The status display on the upper part of the SERVICE MODE screen is common (to all models).
4.6.3.1DIGITAL SERVICE MODE
1. Adjust
(6) SETTING ITEM NO.
Setting item numbers are displayed. The setting item numbers
43-4:3: 4 : 3 (Input signal 4 : 3)
43-16:9: 16 : 9 (Input signal 4 : 3)
16-16:9: 16 : 9 (Input signal 16 : 9)
16-4:3: 4 : 3 (Input signal 16 : 9)
16-ZOOM : HD ZOOM (Input signal 16 : 9)
(3) VIDEO STATUS
State of the VIDEO STATUS is displayed.
STANDARD : STANDARD
DYNAMIC: DYNAMIC
THEATER: THEATER
GAME: GAME
WHITE BALANCE
• [SLEEP TIMER] key.
Switch to the next items.
S001 → D001 → F001 → S001
(7) SETTING VALUE (DATA)
The SETTING VALUE is displayed.
CHANGE OF SETTING VALUE (DATA)
• [VOL+] / [VOL-] key.
Change the setting values up/down.
MEMORY OF SETTING VALUE (DATA)
Changed setting value is memorized by pressing
[MUTING] key.
(4) WHITE BALANCE
State of the WHITE BALANCE is displayed.
H : HIGH
L: LOW
(5) SETTING ITEM NAME
Setting item name are displayed. For the setting item names
to be displayed, refer to "INITIAL SETTING VALUE OF
SERVICE MODE".
1-18 (No.YA387)
Page 19
2. White Balance
TVM Memory Edit
Addr (H) 0000
0 1 2 3 4 5 6 7
04 01 06 58 FF FF FF FF
8 9 A B C D E F
11 29 00 00 01 FF FD FD
White balance data is adjusted on this screen.
SETTING VALUE (DATA)
BRIGHTNESS
DRIVE
CUTOFF
BR 70
DRV R060B059
CUT R060G065B030
BRIGHTNESS
[VOL+] key: BRIGHT is up
[VOL-] key: BRIGHT is down
DRIVE
[2] key: DRIVE R is up
[5] key: DRIVE R is down
[3] key: DRIVE B is up
[6] key: DRIVE B is down
3. Memory Edit
Data in the EEPROM is edited on this screen. [Do not adjust]
CAUTION:
This mode is not used in the ADJUSTMENT. Press the
[BACK] key to return to the SERVICE MENU SCREEN.
MEMORY EDIT MODE
TVM Memory Edit
Addr (H) 0000
0 1 2 3 4 5 6 7
04 01 06 58 FF FF FF FF
8 9 A B C D E F
11 29 00 00 01 FF FD FD
CUTOFF
[1] key: HORIZONTAL LINE on
[4] key: HORIZONTAL LINE off
[7] key: CUTOFF G is up
[TUNE] key
: CUTOFF G is down
[8] key: CUTOFF R is up
[0] key: CUTOFF R is down
[9] key: CUTOFF B is up
[RETURN+] key: CUTOFF B is down
MEMORY OF SETTING VALUE (DATA)
Changed setting value is memorized by pressing [MUTING]
key.
(No.YA387)1-19
Page 20
4.7INITIAL SETTING VALUE OF SERVICE MODE
(1) Adjustment of the SERVICE MODE is made on the basis of the initial setting values ; however, the new setting values which set
the screen in its optimum condition may differ from the initial setting.
(2) Do not change the initial setting values of the setting items NOT LISTED IN ADJUSTMENT PROCEDURE.
(3) --- : This mark described in each table shows "Cannot adjust it."
(1) Receive the black and white signal. (color off)
(2) Connect the DC voltmeter to the 1-pin and 5-pin of
S1 connector.
(3) Confirm that the voltage is DC134.5V±2V.
(1) Receive any broadcast.
(2) Turn the SCREEN VR to make cut-off screen (black
screen).
(3) Connect the earth clip of HV voltmeter to chassis
GND.
(4) Connect the probe of HV voltmeter to CRT anode.
(5) Confirm that the voltage is within a value as shown
left table.
NOTE:
Remove the probe before removing the earth clip.
(1) Receive any broadcast.
(2) Apply DC 20V between the 1-pin and 3-pin of S1
connector.
(3) Increase the DC voltage slowly.
(4) Confirm that the screen picture disappeares until the
DC voltage as shown left table.
(5) Disconnect the power plug.
(6) Again connect the power plug.
(7) Turn the power switch to on.
(8) Make sure that the normal picture is displayed on the
screen.
(1) Receive any broadcast.
(2) Refer to the figure, connect the resistor between 2-
pin and 3-pin of S1 connector.
(3) Make sure that the screen picture disappeares.
(4) Disconnect the power plug.
(5) Remove the resistor.
(6) Again connect the power plug.
(7) Turn the power switch to on.
(8) Make sure that the normal picture is displayed on the
screen.
321
45
4.8.2 FOCUS
Item
Measuring
instrument
FOCUSSignal
generator
1-24 (No.YA387)
CONNECTOR
S1
HVT
4
Test pointAdjustment partDescription
FOCUS VR
[In HVT]
(1) Receive the crosshatch signal.
(2) While watching at the screen, adjust the FOCUS VR
so that the vertical and horizontal lines get the
thinnest and sharpest center horizontal line.
(3) Make sure that the picture is in focus even when the
screen gets darkened.
Page 25
4.8.3 DEFLECTION CIRCUIT [2.TV-Micro Service]
Item
V. SIZE /
V. POSITION
(4:3)
Measuring
instrument
Signal
generator
Remote
control unit
Test pointAdjustment partDescription
[1.Adjust]
D05: V PHASE
D07: V SIZE
D11: VS CORR
D13: V LIN
V. CENTER SW
(S421
[MAIN PWB]
Screen
size
V. SIZE /
V. POSITION
(16:9)
Signal
generator
size
100%
[1.Adjust]
D08: V SIZE+-
D14: V LIN+Remote
control unit
B
[B=B']
B'
Adjust point
Setting value
(1) Receive the crosshatch signal.
(2) Select the 2.TV-Micro Service from the SERVICE
MODE.
(3) Select the 1. Adjust.
(4) Select < D05 > (V PHASE).
(5) Confirm that the value of < D05 > is 0.
(6) Adjust V. CENTER SW to agree the vertical center
)
with the display center.
(7) Select < D07 > (V SIZE).
(8) Adjust < D07 > so that the vertical screen size becomes
92% of the vertical picture size.
(9) Press the [MUTING] key to memorize the set value.
NOTE:
• Bottom is to be located within the 85%-95% range.
• When vertical linearity is not even, adjust < D13 >
(V LIN) and < D11 > (VS CORR) to vertical linearity.
• V. SIZE / V. POSITION (4:3) adjustment should be finished.
(1) Receive the black and white signal (color off).
(2) Select the ASPECT to 16:9 mode.
(3) Select the 2.TV-Micro Service from the SERVICE
MODE.
(4) Select the 1. Adjust.
(5) Confirm that the width of V. BLANKING is equal to
adjustment value (B).
(6) If the value (B) is not correct, adjust < D08 > (V SIZE+-) and
< D14 > (V LIN+-) to be same to adjustment value (B).
(7) Press the [MUTING] key to memorize the set value.
NOTE :
• When you change the VERTICAL adjustment value of
the regular mode (4:3), review the adjustment of 16:9
mode again.
B
H. SIZE /
H. POSITION /
SIDE PIN
(4:3)
50 mm (27 inch models)
60 mm (32 inch models)
Signal
generator
Remote
control unit
Screen size
Picture size 100%
[1.Adjust]
D03: H POSI
D15: H SIZE
D23: EW PARA
D19: EWCR TOP
D21: EWCR BTM
• FORCUS adjustment should be finished.
• V. SIZE / V. POSITION adjustment should be finished.
(1) Receive the crosshatch signal.
(2) Select the 2.TV-Micro Service from the SERVICE MODE.
(3) Select the 1. Adjust.
(4) Select < D03 > (H POSI).
(5) Adjust < D03 > so that the left width and right width
of the crosshatch screen become equal.
(6) Select < D15 > (H SIZE).
(7) Adjust < D15 > so that the horizontal screen size becomes
90% of the horizontal picture size.
(8) Select < D23 > (EW PARA).
(9 ) Adjust < D23 > to vertical line at both side to become straight.
(10) If it is necessary, readjust step 3 to 9.
(11) Press the [MUTING] key to memorize the set value.
NOTE:
If it is not straight at the vertical upper and bottom corner
line, adjust the upper and bottom conrner pin by < D19 >
(EWCR TOP) and < D21 > (EWCR BTM).
(No.YA387)1-25
Page 26
Item
H. POSITION /
H. SIZE /
SIDE PIN
(16:9)
Measuring
instrument
Signal
generator
Remote
control unit
Screen size
Picture size 100%
Test pointAdjustment partDescription
[1.Adjust]
D16: H SIZE+D04: H POSI+D24: EW PARA+D20: EWCR T+D22: EWCR B+-
• FORCUS adjustment should be finished.
• V. SIZE / V. POSITION adjustment should be finished.
• H. SIZE / H. POSITION / SIDE PIN adjustment should
be finished. (Regular size(4:3)).
(1) Receive the crosshatch signal.
(2) Select the ASPECT to 16:9 mode.
(3) Select the 2.TV-Micro Service from the SERVICE
MODE.
(4) Select the 1. Adjust.
(5) Confirm both sides of crosshatch to be the
adjustment value 90%.
(6) If the value is not correct, adjust < D16 > (H SIZE+-)
and < D04 > (H POSI+-) so that the horizontal
screen size becomes 90% of the horizontal picture
size.
(7) Confirm the second vertical line from left and right to
be straight.
(8) If it is not straight, adjust to be straight by < D24 >
(EW PARA+-), < D20 > (EWCR T+-) and < D22 >
(EWCR B+-).
(9) Press the [MUTING] key to memorize the set value.
NOTE :
• Review the adjustment of 16:9 mode again when you
change the SIDE PIN adjustment value of regular
(4:3) mode.
1-26 (No.YA387)
Page 27
4.8.4 VIDEO CIRCUIT [2.TV-Micro Service]
Item
WHITE
BALANCE
Measuring
instrument
Signal
generator
Test pointAdjustment partDescription
(LOW LIGHT)
Remote
control unit
REMOTE CONTROL UNIT
H.LINE ON
1
H.LINE OFF
4
G CUTOFFB CUTOFF
7
G CUTOFFB CUTOFFR CUTOFF
TUNE
WHITE
BALANCE
2
5
R CUTOFF
8
0
Signal
generator
3
6
9
RETURN+
(HIGH LIGHT)
Remote
control unit
REMOTE CONTROL UNIT
B DRIVER DRIVE
1
4
2
5
3
B DRIVER DRIVE
6
[1.Adjust]
S01: BRIGHT
S11: R CUTOFF
S12: G CUTOFF
S13: B CUTOFF
[2.White Blance]
SCREEN VR [in HVT]
[1.Adjust]
S14: R DRIVE
S15: B DRIVE
[2.White Blance]
(1) Receive the black and white signal ( color off ).
(2) Set VIDEO STATUS to "STANDARD".
(3) Select COLOR TEMPERATURE to "LOW".
(4) Select the 2.TV-Micro Service from the SERVICE
MODE.
(5) Select the 1. Adjust.
(6) Set the initial setting value of < S11 > (R CUTOFF), < S12
> (G CUTOFF), < S13 > (B CUTOFF) and < S01 >
(BRIGHT).
(7) Return to the 2.TV-Micro Service MENU.
(8) Select the 2. White Balance.
(9) Display a single horizontal line by pressing the [1] key.
(10) Turn the SCREEN VR all the way to the left.
(11) Turn the SCREEN VR gradually to the right from the
left until either one of the red, blue or green colors
appears faintly.
(12) Adjust the two colors which did not appear until the
single horizontal line becomes white by using the [7]
to [0] keys, [TUNE] and [RETURN+].
(13) Turn the SCREEN VR until the single horizontal line
is displayed faintly.
(14) Press the [MUTING] key to memorize the set value.
(15) Press the [4] key to cancel the single horizontal line
mode.
(16) Adjust the BRIGHT level so that the black component
shines white slightly by the [VOL+] / [VOL-] key.
(17) Confirm that whether the color ingredient of R, G, or
B is visible to the black component, which shines
white slightly.
(18) When the color ingredient can be seen, two colors
other than a visible color are adjusted, and it is made
to look white.
(19) Press the [MUTING] key to memorize the set value.
• WHITE BALANCE(LOW LIGHT) adjustment should be
finished.
(1) Receive the black and white signal (color off).
(2) Set VIDEO STATUS to "STANDARD".
(3) Select COLOR TEMPERATURE to "LOW".
(4) Select the 2.TV-Micro Service from the SERVICE
MODE.
(5) Select the 1. Adjust.
(6) Set the initial setting value of < S14 > (R DRIVE) and
< S15 > (B DRIVE).
(7) Return to the 2.TV-Micro Service MENU.
(8) Select the 2. White Balance.
(9) Adjust the screen until it becomes white by using the
[2], [3], [5] and [6] keys.
(10) Press the [MUTING] key to memorize the set value.
7
TUNE
8
0
9
RETURN+
(No.YA387)1-27
Page 28
Item
Measuring
instrument
SUB BRIGHTRemote
control unit
SUB
CONTRAST
Remote
control unit
SUB COLORRemote
control unit
Signal
generator
Oscilloscope
Remote
control unit
W
Y
C
Test pointAdjustment partDescription
[1.Adjust]
S01: BRIGHT
• WHITE BALANCE adjustment should be finished.
(1) Receive any broadcast.
(2) Set VIDEO STATUS to "STANDARD".
(3) Select COLOR TEMPERATURE to "LOW".
(4) Select the 2.TV-Micro Service from the SERVICE
MODE.
(5) Select the 1. Adjust.
(6) Select < S01 > (BRIGHT).
(7) Set the initial setting value of < S01 >.
(8) If the brightness is not the best with the initial setting
value, make fine adjustment of < S01 > until you get
the optimum brightness.
(9) Press the [MUTING] key to memorize the set value.
[1.Adjust]
S02: PICTURE
• SUB BRIGHT adjustment should be finished.
(1) Receive any broadcast.
(2) Set VIDEO STATUS to "STANDARD".
(3) Select COLOR TEMPERATURE to "LOW".
(4) Select the 2.TV-Micro Service from the SERVICE
MODE.
(5) Select the 1. Adjust.
(6) Select < S02 > (PICTURE).
(7) Set the initial setting value of < S02 >.
(8) If the contrast is not the best with the initial setting
value, make fine adjustment of the < S02 > until you
get the optimum contrast.
(9) Press the [MUTING] key to memorize the set value.
[1.Adjust]
S03 : COLOR
[ Method of adjustment without measuring instrument ]
• SUB CONTRAST adjustment should be finished.
(1) Receive any broadcast.
(2) Set VIDEO STATUS to "STANDARD".
(3) Select COLOR TEMPERATURE to "LOW".
(4) Select the 2.TV-Micro Service from the SERVICE
MODE.
(5) Select the 1. Adjust.
(6) Select < S03 >(COLOR).
(7) Set the initial setting value of the < S03 >.
(8) If the color is not the best with the initial setting
values, make fine adjustment until you get the best
color.
(9) Press the [MUTING] key to memorize the set value.
TP-B
TP-E
[CRT SOCKET
PWB]
[1.Adjust]
S03 : COLOR
[ Method of adjustment using measuring instrument ]
• SUB CONTRAST adjustment should be finished.
(1) Input the full color bar signal includes the 75% white.
(2) Set VIDEO STATUS to "STANDARD".
(3) Select COLOR TEMPERATURE to "LOW".
(4) Select the 2.TV-Micro Service from the SERVICE
(7) Set the initial setting value of the < S03 >.
(8) Connect the oscilloscope between TP-B
(9) Adjust < S03 > and bring the voltage of (A) in the
)
(
illustration to +17V. (voltage difference between
white and blue).
0V
(A)
B
M
(
)
(10) Press the [MUTING] key to memorize the set value.
and TP-E.
1-28 (No.YA387)
Page 29
Item
Measuring
instrument
SUB TINTRemote
control unit
Signal
generator
Oscilloscope
Remote
control unit
W
Test pointAdjustment partDescription
TP-B
TP-E
[CRT SOCKET PWB]
Y
G
C
M
[1.Adjust]
S04 : TINT
[ Method of adjustment without measuring instrument ]
• SUB CONTRAST adjustment should be finished.
(1) Receive any broadcast.
(2) Set VIDEO STATUS to "STANDARD".
(3) Select COLOR TEMPERATURE to "LOW".
(4) Select the 2.TV-Micro Service from the SERVICE
MODE.
(5) Select the 1. Adjust.
(6) Select < S04 >(TINT).
(7) Set the initial setting value of the < S04 >.
(8) If the tint is not the best with the initial setting values,
make fine adjustment until you get the best tint.
(9) Press the [MUTING] key to memorize the set value.
[1.Adjust]
S04 : TINT
[ Method of adjustment using measuring instrument ]
• SUB CONTRAST adjustment should be finished.
(1) Input the full color bar signal includes the 75% white.
(2) Set VIDEO STATUS to "STANDARD".
(3) Select COLOR TEMPERATURE to "LOW".
(4) Select the 2.TV-Micro Service from the SERVICE
(7) Set the initial setting value of the < S04 >.
(8) Connect the oscilloscope between TP-B
and TP-E.
(9) Adjust < S04 > and bring the voltage of (B) in the
illustration to +17V. (voltage difference between
white and magenta).
(10) Press the [MUTING] key to memorize the set value.
4.8.5 MTS CIRCUIT [1.Digital Service]
Item
MTS INPUT
LEVEL
MTS
SEPARATION
Measuring
instrument
Remote
control unit
TV audio
multiplex
signal
Test pointAdjustment partDescription
R OUT
L OUT
[AUDIO OUT]
generator
Oscilloscope
Remote
control unit
L-Channel
signal waveform
1 cycle
[1.Adjust]
A01: IN LEVEL
[1.Adjust]
A02: LOW SEP
A03: HIGH SEP
R-Channel
crosstalk portion
Minimum
Input the stereo R signal
(3kHz) and change
(1) Receive any broadcast.
(2) Select the 1.Digital Service from the SERVICE
MODE.
(3) Select the 1.Adjust.
(4) Select the < A01 > (IN LEVEL).
(5) Set the initial setting value of < A01 >.
(6) Press the [MUTING] key to memorize the set value.
(1) Input the stereo L signal (300 Hz) from the TV audio
multiplex signal generator to the antenna terminal.
(2) Connect an oscilloscope to R OUT pin of the AUDIO
OUT, and display one cycle portion of the 300 Hz
signal.
(3) Select the 1.Digital Service from the SERVICE
MODE.
(4) Select the 1.Adjust.
(5) Select the < A02 > (LOW SEP).
(6) Set the initial setting value of < A02 >.
(7) Adjust the < A02 > so that the stroke element of the
300Hz signal will become minimum.
(8) Press the [MUTING] key to memorize the set value.
(9) Input the stereo R signal (3kHz) and change the
connection of the oscilloscope to L OUT pin of the
AUDIO OUT.
(10) Similarly adjust < A03 > (HIGH SEP).
(11) Press the [MUTING] key to memorize the set value.
(No.YA387)1-29
Page 30
SECTION 5
TROUBLESHOOTING
5.1SELF CHECK FEATURE
5.1.1 OUTLINE
This unit comes with the "Self check" feature, which checks the
operational state of the circuit and displays/saves it during
failure. Diagnosis is performed when power is turned on, and
information input to the main microcomputer is monitored at all
time. Failure detection is based on input state of I
various control lines connected to the main microcomputer.
5.1.2 HOW TO ENTER THE SELF CHECK MODE
(1) Set to "0 minutes" using the [SLEEP TIMER] key.
(2) While "0 minutes" is displayed, press the [VIDEO STATUS]
key and [DISPLAY] key simultaneously, then enter the
SERVICE MODE.
(3) Press the [4] key (4.Diagnostics) in the SERVICE MENU
SCREEN. (Fig.1)
(4) Press the [3] key (3.Self check) in the DIAGNOSTICS
MODE screen. (Fig.2)
(5) The SELF CHECK MODE screen is displayed. (Fig.3)
(6) Press the [VOL+] / [VOL-] key to switch between the first
page and the second page.
NOTE:
When a number key other than the [4] key is pressed in
the SERVICE MENU SCREEN, the other relevant
screen may be displayed.
This is not used in the SELF CHECK MODE. Press the
[BACK] key to return to the SERVICE MENU SCREEN.
5.1.3 HOW TO EXIT THE SELF CHECK MODE
TO SAVE FAILURE HISTORY:
Turn off the power by unplugging the AC power cord plug
when in the SELF CHECK MODE.
TO CLEAR (RESET) FAILURE HISTORY:
Turn off the power by pressing the key on the remote control
unit when in the SELF CHECK MODE.
2
C bus and the
Press [4] key
Press [3] key
SELF CHECK MODE SCREEN (Page 1)
Item
CHECK
Normality=OK
Abnormality=NG
Not used= ---
SERVICE
Service Menu
1.Digital Service
2.TV-Micro Service
3.Conver Service
4.Diagnostics
MENU SCREEN
Fig.1
Diagnostic MENU SCREEN
Diagnostic
1.I2C Bus Stop
2.Status Monitor
3.Self Check
4.Version
5.Save Config data to SD card
6.Load Config data
7.Boot from NFS
8.Debug Log
Fig.2
Self Check
X-RAY -- OCP -- LOB -- TIM OK
PHOTO -- HostLink OK
FAN ---
<> Previous/Next Page [BACK]Back [MENU]Exit
Press [VOL+] / [VOL-] key
5.1.4 FAILURE HISTORY
Failure history can be counted up to 9 times for each item. When
the number exceeds 9, display will remain as 9. Failure history
will be stored in the memory unless it has been deleted.
5.1.5 POINTS TO NOTE WHEN USING THE SELF CHECK
FEATURE
In addition to circuit failures (abnormal operation), the following
cases may also be diagnosed as "Abnormal" and displayed and
counted as "NG".
(1) Temporary defective transmissions across circuits due to
pulse interruptions
(2) Misalignment in the on/off timing of power for I
2
C bus
(VCC) when turning on/off the main power.
Diagnosis may be impeded if a large number of items are
displayed as "NG". As such, start Self check check only after 3
seconds in the case of receivers and 5 seconds in the case of
panels upon turning on the power. If recurrences are expected,
ensure to clear (reset) the failure history and record the new
diagnostic reults.
1-30 (No.YA387)
SELF CHECK MODE SCREEN (Page 2)
Item
CHECK
Normality=OK
Abnormality=NG
Not used= ---
Self Check
MTS OK RGB/DEF OK
TONE OK
AVSW OK A-EEPROM OK
CompSW -- ADC NG(9)
TUNER OK
AudioADC -- HDMI ---
<> Previous/Next Page [BACK]Back [MENU]Exit
Fig.3
Page 31
5.1.6 DETAILS
Self check is performed for the following items:
5.1.6.1PAGE 1 OF SCREEN
Detection itemDisplayDetection content
X-ray protectionX-RAYNot used.------
B1 over-current
protection
Low bias line short
protection
Timer (clock)TIMThe power frequency is changed as
Photo ditectPHOTONot used.------
DTVM and TVM
communication
Fan lockFANNot used.------
5.1.6.2PAGE 2 OF SCREEN
Detection itemDisplayDetection content
US audio multiplexing
decoder
Tone/volume controlTONESame as above.SDASame as above.
AV select switchAVSWSame as above.SDASame as above.
Component signal
select switch
A-D converter for
component signal
TunerTUNERSame as above.SDASame as above.
A-D converter for audio
Digital inputHDMINot used.------
RGB/Def processRGB/DEF Confirmation of reply of ACK signal
MemoryA-EEPROM Confirmation of reply of ACK signal
OCPNot used.------
LOBNot used.------
follows: 50Hz → 60Hz / 60Hz→50Hz.
[MAIN PWB]
IC201
HostlinkCommunication error between the
digital TV microcomputer and the TV
microcomputer is detected.
[MAIN PWB]
IC201
MTSConfirmation of reply of ACK signal
which uses I2C communication.
CompSW Not used.------
ADCConfirmation of reply of ACK signal
which uses I2C communication.
Audio ADC Not used.------
which uses I2C communication.
[MAIN PWB]
IC201
which uses I2C communication.
[MAIN PWB]
IC702
Diagnosis
signal (line)
AC_INDetection starts 3 seconds after the
power is turned on. Periodically check the
power frequency by counting the AC
pulse and monitor whether or not the
frequency is changed.
SDACheck communication errors by counting
the number of reset exception handling.
Diagnosis
signal (line)
SDAIf it checks whenever I2C communication
is performed and no reply of ACK signal
an error will be counted.
SDAIf it checks whenever I2C communication
is performed and no reply of ACK signal
an error will be counted.
SDAIf it checks whenever I2C communication
is performed and no reply of ACK signal
an error will be counted.
SDASame as above.
Detection timing
Detection timing
(No.YA387)1-31
Page 32
Victor Company of Japan, Limited
CRT Display Category 12, 3-chome, Moriya-cho, Kanagawa-ku, Yokohama-city, Kanagawa-prefecture, 221-8528, Japan
The components identified by thesymbol and shading are
critical for safety. For continued safety replace safety ciritical
components only with manufactures recommended parts.
2.SPECIFIED VOLTAGE AND WAVEFORM VALUES
The voltage and waveform values have been measured under the
following conditions.
(1)Input signal: Colour bar signal
(2)Setting positions of
each knob/button and
variable resistor
(3)Internal resistance of tester
(4)Oscilloscope sweeping time
(5)Voltage values
Since the voltage values of signal circuit vary to some extent
according to adjustments, use them as reference values.
Composition resistor 1/2 [W] is specified as 1/2S or Comp.
(2)Capacitors
Capacitance value
1 or higher: [pF]
less than 1
Withstand voltage
No indication: DC50[V]
Others: DC withstand voltage [V]
AC indicated
Electrolytic Capacitors
47/50[Example]: Capacitance value [µF]/withstand voltage[V]
: [kΩ]
: [MΩ]
: Carbon resistor
: Oxide metal film resistor
: Metal film resistor
: Metal plate resistor
: Uninflammable resistor
: Fusible resistor
: [µF]
: AC withstand voltage [V]
(7)Ground symbol
: LIVE side ground
: ISOLATED(NEUTRAL) side ground
: EARTH ground
: DIGITAL ground
5.NOTE FOR REPAIRING SERVICE
This model's power circuit is partly different in the GND. The
difference of the GND is shown by the LIVE : ( ) side GND and the
ISOLATED(NEUTRAL) : ( ) side GND. Therefore, care must be
taken for the following points.
(1)Do not touch the LIVE side GND or the LIVE side GND and the
ISOLATED(NEUTRAL) side GND simultaneously. if the above
caution is not respected, an electric shock may be caused.
Therefore, make sure that the power cord is surely removed from
the receptacle when, for example, the chassis is pulled out.
(2)Do not short between the LIVE side GND and ISOLATED(NEUTRAL
side GND or never measure with a measuring apparatus measure
with a measuring apparatus ( oscilloscope, etc.) the LIVE side GND
and ISOLATED(NEUTRAL) side GND at the same time.
If the above precaution is not respected, a fuse or any parts will be broken.
Since the circuit diagram is a standard one, the circuit and
circuit constants may be subject to change for improvement
without any notice.
NOTE
Due improvement in performance, some part numbers show
in the circuit diagram may not agree with those indicated in
the part list.
When ordering parts, please use the numbers that appear
in the Parts List.
3 1.3
4 0
5 0.6
6 1.2
7 5.9
8 0.9
Q001
S 3.2
D 5
G 3.3
Q002
S 3.2
D 5
G 3.3
Q003
S 3.3
D 5
G 3.3
Q004
S 3.3
D 5
G 3.3
Q005
E 0
C 0
B 3.2
Q352
E 8.4
C 8.9
B 9
Q671
E 0
C 7.8
B 0
Q681
E 0
C 0
B -0.7
Q682
E 9.9
C -0.8
B 10.3
Q683
E 0
C 0
B 0.1
Q684
E 0
C 0
B 0.6
Q701
E 3.7
C 2.5
B 3
Q730
E 0
C 1.8
B 3.8
CN001
1 0
2 32
3 4.9
4 4.9
5 4.9
6 0
7 0
8 0
9 0
10 0
11 0
12 0.2
13 2.5
14 4.9
15 8.9
16 8.9
17 0
18 0
19 0
20 3.3
21 3.2
22 3.2
23 3.2
24 3.2
25 0
26 0
27 3.3
28 3.3
29 1.2
30 1.2
31 1.2
32 1.2
33 2.6
34 2.6
35 2.6
36 0
37 0
38 0
IC421
1 2.6
2 27.6
3 2.6
4 0
5 15
6 28.1
7 2.7
IC911
1 129.8
2 0.1
3 0
4 18.3
5 1.7
IC921
1 134.6
2 12.9
3 0
Q501
E 0
C 64.3
B 0.3
Q511
E 0
C 133.8
B 0.1
Q531
E 0
C 9.9
B 0
Q532
E 9.9
C 0
B 9.9
Q541
E 4.5
C 0.5
B 3.9
Q542
E 4.5
C 0
B 3.9
Q543
E 0
C 14.3
B 0.6
Q951
E 0
C 0.1
B 1.4
Q971
E 134.6
C 0.1
B 134.2
PC921
1 14
2 12.9
3 1.7
4 16.6
DC (V
<AV SW PWB>
MODE
)
PIN NO.
IC5001
1 3.9
2 4.4
3 3.9
4 4.4
5 4.4
6 0
7 NC
8 3.9
9 4.4
10 0
11 0
12 4.4
13 0
14 4.8
15 3.9
16 4.4
17 3.9
18 4.4
19 4.4
20 0
21 NC
22 4.4
23 3.9
24 4.4
25 0
26 5
27 5
28 4.4
29 0
30 4.5
31 0
32 4.4
33 3.5
34 8.9
35 0
36 3.9
37 4.4
38 4.4
39 4.5
40 NC
41 4.4
42 NC
43 NC
44 0
45 NC
46 4.4
47 3.9
48 4.4
Q5001
E 2.8
C 8.9
B 3.4
Q5002
E 2.8
C 8.9
B 3.4
Q5003
E 2.8
C 8.9
B 3.4
Q5004
E 2.7
C 0
B 0
Q5005
E 2.3
C 0
B 1.7
Q5006
E 2.4
C 0
B 1.7
Q5007
E 3.4
C 0
B 2.8
Q5008
E 3.4
C 0
B 2.8
Q5009
E 3.4
C 0
B 2.8
Q5601
E 0
C 0
B -0.4
Q5602
E 0
C 0
B -0.4
Q5603
E 0.1
C -0.4
B 0
<CRT SOCKET PWB>
[P.2-19-P.2-20]
MODE
)
DC (V
PIN NO.
Q3103
E 3.3
C 11.9
B 0
Q3107
E 132.6
C 69.9
B 132.2
Q3108
E 4.5
C 69.5
B 5.1
Q3109
E 2.2
C 4.1
B 2.8
Q3304
E 1.5
C 160.5
B 2
Q3305
E 1.6
C 159.8
B 2
Q3306
E 1.6
C 156
B 2.1
Q3351
E 11.8
C -1
B 11.9
<LED & POWER SW PWB>
[P.2-23]
MODE
PIN NO.
IC7701
1 5
2 5
3 0
Q7701
E 5
C 5
B 0.2
<USB PWB>
[P.2-24]
MODE
PIN NO.
IC8501
1 0.1
2 4.9
3 0
DC (V
DC (V
DC (V
WAVEFORMS
)
)
)
(No.YA387)2-252-26(No.YA387)
MAIN PWB(1/2)
IC201-6
(0.5µs)
5 Vp-p
IC201-24
0.6 Vp-p
MAIN PWB(2/2)
IC421-1
0.7 Vp-p
Q511-C
1100 Vp-p
CRT SOCKET PWB
Q3304-C
105 Vp-p
(H)
(V)
(H)
(H)
IC201-13
IC201-39
IC421-3
Q543-B
0.08 Vp-p
Q3305-C
6 Vp-p
3 Vp-p
32 Vp-p
95 Vp-p
(H)
(H)
(H)
IC201-14
5 Vp-p
IC201-40
2.5 Vp-p
IC421-5
(V)
60 Vp-p
Q543-C
(V)
10 Vp-p
Q3306-C
(H)
(H)
(V)
(V)
(H)
IC201-18
2.9 Vp-p
IC201-41
3.5 Vp-p
IC421-6
T502-2
35 Vp-p
90 Vp-p
(H)
(H)
IC201-19
(V)
1.2 Vp-p
Q501-B
(V)
0.8 Vp-p
T502-4
30 Vp-p
(H)
(H)
IC201-22
(V)
0.7 Vp-p
Q501-C
120 Vp-p
T502-6
250 Vp-p
(H)
(H)
(H)
IC201-23
Q511-B
2.3 Vp-p
T502-8
(H)
1 Vp-p
(H)
(H)
75 Vp-p
120 Vp-p
Page 48
Victor Company of Japan, Limited
CRT Display Category 12, 3-chome, Moriya-cho, kanagawa-ku, Yokohama-city, kanagawa-prefecture, 221-8528, Japan
(No.YA387)
Printed in Japan
VPT
Page 49
PARTS LIST
CAUTION
J The parts identified by the symbol are important for the safety . Whenever replacing these parts, be sure to use specified ones to secure the
safety.
J The parts not indicated in this Parts List and those which are filled with lines --- in the Parts No. columns will not be supplied.
J P.W. BOARD Ass'y will not be supplied, but those which are filled with the Parts No. in the Parts No. columns will be supplied.
ABBREVIATIONS OF RESISTORS, CAPACITORS AND TOLERANCES
RESISTORSCAPACITORS
CRCarbon ResistorC CAP.Ceramic Capacitor
FRFusible ResistorE CAP.Electrolytic Capacitor
PRPlate ResistorM CAP.Mylar Capacitor
VRVariable ResistorCH CAP.Chip Capacitor
HV RHigh Voltage ResistorHV CAP.High Voltage Capacitor
MF RMetal Film ResistorMF CAP.Metalized Film Capacitor
OM RMetal Oxide Film ResistorPP CAP.Polypropylene Capacitor
CMF RCoating Metal Film ResistorPS CAP.Polystyrol Capacitor
UNF RNon-Flammable ResistorTF CAP.Thin Film Capacitor
CH V RChip Variable ResistorMPP CAP.Metalized Polypropylene Capacitor
CH MG RChip Metal Glazed ResistorTAN. CAP.Tantalum Capacitor
COMP. RComposition ResistorCH C CAP.Chip Ceramic Capacitor
LPTC RLinear Positive Temperature Coefficient ResistorBP E CAP.Bi-Polar Electrolytic Capacitor
CH AL E CAP.Chip Aluminum Electrolytic Capacitor
CH AL BP CAP.Chip Aluminum Bi-Polar Capacitor
CH TAN. E CAP.Chip Tantalum Electrolytic Capacitor
CH AL BP E CAP.Chip Tantalum Bi-Polar Electrolytic Capacitor
RESISTORS
FGJ KMNRHZ P
±1%±2%±5%±10%±20%±30%
+30%
-10%
+50%
-10%
+80%
-20%
+100%
-0%
(No.YA387)3-1
Page 50
CONTENTS
USING P.W. BOARD & REMOTE CONTROL UNIT ................................................................................................... 3-3
EXPLODED VIEW PARTS LIST -1 ............................................................................................................................. 3-4
PACKING PARTS LIST ............................................................................................................................................. 3-27
3-2(No.YA387)
Page 51
USING P.W. BOARD & REMOTE CONTROL UNIT
P.W.B ASS'Y name
MAIN P.W.BSGJ-1308A-M2SGJ-1302A-M2SGJ-1313A-M2SGJ-1301A-M2SGJ-1307A-M2
AV SW P.W.BSGJ-5301A-M2←←←←
FRONT CONTROL P.W.BSGJ-6301A-M2←←←←
LED&POWER SW P.W.BSGJ-7301A-M2←←←←
USB P.W.BSGJ-8302A-M2←←←←
L/F P.W.BSGJ-9302A-M2←SGJ-9301A-M2←←
Q0012SK1374-XMOS FET
Q0022SK1374-XMOS FET
Q0032SK1374-XMOS FET
Q0042SK1374-XMOS FET
Q005RT1N440C-XTRANSISTOR
Q3522SC3928A/QR/-XTRANSISTOR
Q5012SC4212/Z1/TRANSISTOR
C009NCB31HK-103XC CAPACITOR0.01uF 50V K
C101QENC1EM-475ZBP E CAPACITOR4.7uF 25V M
C102NCB31HK-562XC CAPACITOR5600pF 50V K
C103NCB31EK-123XC CAPACITOR0.012uF 25V K
C104NCB31CK-105XC CAPACITOR1uF 16V K
C105QETN1HM-475ZE CAPACITOR4.7uF 50V M
C106QETN1HM-106ZE CAPACITOR10uF 50V M
C107QETN1HM-475ZE CAPACITOR4.7uF 50V M
C108QETN1CM-107ZE CAPACITOR100uF 16V M
C109NCB31HK-103XC CAPACITOR0.01uF 50V K
C110QENC1EM-475ZBP E CAPACITOR4.7uF 25V M
C111QETN1HM-475ZE CAPACITOR4.7uF 50V M
C112QENC1EM-475ZBP E CAPACITOR4.7uF 25V M
C113NCB31HK-272XC CAPACITOR2700pF 50V K
C114NCB31HK-473XC CAPACITOR0.047uF 50V K
C115QETN1HM-335ZE CAPACITOR3.3uF 50V M
C116QENC1EM-475ZBP E CAPACITOR4.7uF 25V M
C117QETN1HM-106ZE CAPACITOR10uF 50V M
C118NCB31CK-105XC CAPACITOR1uF 16V K
C119NCB31HK-103XC CAPACITOR0.01uF 50V K
C120NCB31HK-103XC CAPACITOR0.01uF 50V K
C121NCB31HK-103XC CAPACITOR0.01uF 50V K
C202NCB21AK-105XC CAPACITOR1uF 10V K
C203NCB31HK-152XC CAPACITOR1500pF 50V K
C221QETN1HM-106ZE CAPACITOR10uF 50V M
C222NCB31CK-104XC CAPACITOR0.1uF 16V K
C237NCB31CK-104XC CAPACITOR0.1uF 16V K
C241NCB31HK-103XC CAPACITOR0.01uF 50V K
C242NCB21AK-225XC CAPACITOR2.2uF 10V K
C243QETN0JM-227ZE CAPACITOR220uF 6.3V M
C244NCB31HK-103XC CAPACITOR0.01uF 50V K
C281QFVF1HJ-474ZMF CAPACITOR0.47uF 50V J
C282QETN1CM-107ZE CAPACITOR100uF 16V M
C283NCB31HK-103XC CAPACITOR0.01uF 50V K
C284QETN1HM-225ZE CAPACITOR2.2uF 50V M
C285NCB31HK-103XC CAPACITOR0.01uF 50V K
C286NCB21CK-474XC CAPACITOR0.47uF 16V K
C287QETN1CM-107ZE CAPACITOR100uF 16V M
C288NCB31HK-103XC CAPACITOR0.01uF 50V K
C289NCB21AK-105XC CAPACITOR1uF 10V K
C290NCB21AK-105XC CAPACITOR1uF 10V K
C291NCB21AK-105XC CAPACITOR1uF 10V K
C301NCZ1064-225XC CAPACITOR2.2uF
C302NCB31EK-104XC CAPACITOR0.1uF 25V K
C352QETN1EM-476ZE CAPACITOR47uF 25V M
C354NCB31HK-103XC CAPACITOR0.01uF 50V K
C360NCB31HK-103XC CAPACITOR0.01uF 50V K
C391QETN1CM-107ZE CAPACITOR100uF 16V M
C392NCB31HK-103XC CAPACITOR0.01uF 50V K
C422QFN32AK-102ZM CAPACITOR1000pF 100V K
C424QETN1VM-107ZE CAPACITOR100uF 35V M
C425QETN1VM-477ZE CAPACITOR470uF 35V M
C427QETN1HM-225ZE CAPACITOR2.2uF 50V M
C428QETM1EM-228E CAPACITOR2200uF 25V M
C431QFLC2AK-563ZM CAPACITOR0.056uF 100V K
C433QETN1EM-476ZE CAPACITOR47uF 25V M
C435NCB31HK-183XC CAPACITOR0.018uF 50V K
C440QCS32HJ-100ZC CAPACITOR10pF 500V J
C501QCB32HK-151ZC CAPACITOR150pF 500V K
C502QCB32HK-331ZC CAPACITOR330pF 500V K
C503QEHR2CM-105ZE CAPACITOR1uF 160V M
C504QEZ0203-107E CAPACITOR100uF 160V M
C507QEM61HK-475ZE CAPACITOR4.7uF 50V K
C508QEM61HK-475ZE CAPACITOR4.7uF 50V K
C510QFZ0200-482MPP CAPACITOR4800pF 1.5kV H
C513QFZ0196-113MPP CAPACITOR0.011uF 1.5kV H
C514QFP32GJ-183PP CAPACITOR0.018uF 400V J
C515QFZ0197-404MPP CAPACITOR0.4uF 250V J
C516QCB32HK-561ZC CAPACITOR560pF 500V K
C521QETN2EM-106ZE CAPACITOR10uF 250V M
C523QEHR1VM-477ZE CAPACITOR470uF 35V M
C525QETN1VM-107ZE CAPACITOR100uF 35V M
C526QFV21HJ-824ZMF CAPACITOR0.82uF 50V J
C527QFLC2AJ-103ZM CAPACITOR0.01uF 100V J
C531QCB32HK-471ZC CAPACITOR470pF 500V K
C533QETN1HM-106ZE CAPACITOR10uF 50V M
C621QETN1HM-475ZE CAPACITOR4.7uF 50V M
3-6(No.YA387)
Page 55
Ref No.Part No.Part NameDescription Local
Ref No.Part No.Part NameDescription Local
C623NCB31HK-102XC CAPACITOR1000pF 50V K
C624NCB31CK-334XC CAPACITOR0.33uF 16V K
C625NCB31HK-822XC CAPACITOR8200pF 50V K
C627NCB31CK-105XC CAPACITOR1uF 16V K
C628NCB31CK-105XC CAPACITOR1uF 16V K
C629NCB31CK-105XC CAPACITOR1uF 16V K
C630NCB31CK-105XC CAPACITOR1uF 16V K
C631QETN1HM-475ZE CAPACITOR4.7uF 50V M
C633NCB31HK-102XC CAPACITOR1000pF 50V K
C634NCB31CK-334XC CAPACITOR0.33uF 16V K
C635QETN1CM-476ZE CAPACITOR47uF 16V M
C636QETN1HM-105ZE CAPACITOR1uF 50V M
C637NCB31CK-105XC CAPACITOR1uF 16V K
C638NCB31CK-105XC CAPACITOR1uF 16V K
C651QETN1HM-475ZE CAPACITOR4.7uF 50V M
C652QETN1HM-475ZE CAPACITOR4.7uF 50V M
C653NCB31HK-104XC CAPACITOR0.1uF 50V K
C654QETN1EM-477ZE CAPACITOR470uF 25V M
C655QETN1EM-108ZE CAPACITOR1000uF 25V M
C656NCB31HK-104XC CAPACITOR0.1uF 50V K
C661QETN1HM-475ZE CAPACITOR4.7uF 50V M
C662QETN1HM-475ZE CAPACITOR4.7uF 50V M
C663NCB31HK-104XC CAPACITOR0.1uF 50V K
C666NCB31HK-104XC CAPACITOR0.1uF 50V K
C671QETN1HM-106ZE CAPACITOR10uF 50V M
C683QETN1EM-107ZE CAPACITOR100uF 25V M
C684QETN1CM-476ZE CAPACITOR47uF 16V M
C701QETN1HM-106ZE CAPACITOR10uF 50V M
C702QETN1HM-106ZE CAPACITOR10uF 50V M
C703QETN1HM-106ZE CAPACITOR10uF 50V M
C704QETN1CM-107ZE CAPACITOR100uF 16V M
C705NCB31HK-103XC CAPACITOR0.01uF 50V K
C706NCB31HK-102XC CAPACITOR1000pF 50V K
C708NDC31HJ-220XC CAPACITOR22pF 50V J
C709NDC31HJ-220XC CAPACITOR22pF 50V J
C710NCB31HK-103XC CAPACITOR0.01uF 50V K
C711QETN1CM-107ZE CAPACITOR100uF 16V M
C712NCB31HK-103XC CAPACITOR0.01uF 50V K
C728NCB31HK-103XC CAPACITOR0.01uF 50V K
C730NCB31CK-104XC CAPACITOR0.1uF 16V K
C807NCB31CK-104XC CAPACITOR0.1uF 16V K
C851QETN1EM-477ZE CAPACITOR470uF 25V M
C852NCB31EK-104XC CAPACITOR0.1uF 25V K
C853QETN1CM-107ZE CAPACITOR100uF 16V M
C854QETN1EM-107ZE CAPACITOR100uF 25V M
C856QETN1CM-107ZE CAPACITOR100uF 16V M
C857QETN1CM-107ZE CAPACITOR100uF 16V M
C858QEZ0256-128E CAPACITOR1200uF 10V M
C861QETN0JM-107ZE CAPACITOR100uF 6.3V M
C865QETN0JM-107ZE CAPACITOR100uF 6.3V M
C866QETN0JM-107ZE CAPACITOR100uF 6.3V M
C868QETN1EM-477ZE CAPACITOR470uF 25V M
C869QCZ0397-106ZC CAPACITOR10uF 25V M
C871NCB31HK-103XC CAPACITOR0.01uF 50V K
C874NCB31EK-273XC CAPACITOR0.027uF 25V K
C876QEZ0256-128E CAPACITOR1200uF 10V M
C880NCB31HK-103XC CAPACITOR0.01uF 50V K
C905QCZ9054-102C CAPACITOR1000pF AC250V Z
C907QEZ0644-567E CAPACITOR560uF 200V K
C908QCZ9054-102C CAPACITOR1000pF AC250V Z
C912QCZ0340-222C CAPACITOR2200pF 2kV K
C913QFLC1HJ-471ZM CAPACITOR470pF 50V J
C914QETN1HM-107ZE CAPACITOR100uF 50V M
C916NDC31HJ-331XC CAPACITOR330pF 50V J
C917NCB31HK-182XC CAPACITOR1800pF 50V K
C918NCB31HK-104XC CAPACITOR0.1uF 50V K
C919QFP32GJ-103PP CAPACITOR0.01uF 400V J
C931QEZ0203-227E CAPACITOR220uF 160V M
C932QETN1CM-108ZE CAPACITOR1000uF 16V M
C933QETN1EM-108ZE CAPACITOR1000uF 25V M
C934NDC31HJ-221XC CAPACITOR220pF 50V J
C935QETN1VM-108ZE CAPACITOR1000uF 35V M
C937QCZ0340-102C CAPACITOR1000pF 2kV K
C938QETN1EM-227ZE CAPACITOR220uF 25V M
C939QCB32HK-152ZC CAPACITOR1500pF 500V K
C941QCB32HK-102ZC CAPACITOR1000pF 500V K
C942QEHR1HM-105ZE CAPACITOR1uF 50V M
C943QETN1CM-227ZE CAPACITOR220uF 16V M
C951QETN1EM-477ZE CAPACITOR470uF 25V M
C952QETN1CM-227ZE CAPACITOR220uF 16V M
C971QETN1CM-107ZE CAPACITOR100uF 16V M
C972QETN1EM-476ZE CAPACITOR47uF 25V M
L001QQL244K-6R8ZPEAKING COIL6.8uH K
L241QQL244K-220ZPEAKING COIL22uH K
L391QQL244K-220ZPEAKING COIL22uH K
L511QQR1165-001LINEARITY COIL
L512QQLZ036-821COIL820uH K
L521QQLZ026-360COIL36uH
L704QQL244K-220ZPEAKING COIL22uH K
L705QQL244K-220ZPEAKING COIL22uH K
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
Ω
Ω
Ω
1/2W J
Ω
1/2W J
Ω
1/2W J
Ω
1/2W J
Ω
1/2W J
Ω
Ω
Ω
1/16W J
Ω
1/10W D
Ω
1/10W D
Ω
1/16W J
1W J
2W J
2W J
2W J
3W J
L851QQR1401-001CHOKE COIL
L853QQL26AK-330ZCHOKE COIL33uH K
L854QQL26AK-470ZCHOKE COIL47uH K
L855QQL26AK-100ZCHOKE COIL10uH K
L860QQL28AK-150COIL15uH K
L861QQR1401-001CHOKE COIL
L931QQL26AK-470ZCHOKE COIL47uH K
L933QQL26AK-470ZCHOKE COIL47uH K
L937QQL26AK-470ZCHOKE COIL47uH K
L940QQR0582-001ZFERRITE BEADS
T501QQR1414-001DRIVE TRANSF
T921QQS0376-001SW TRANSF
CN001QGB1221J1-80CONNECTOR B-B (1-80)
CN002QGB1505J1-35CONNECTOR B-B (1-35)
CN00FQJB003-032213-ESIN ID C-B WIRE
CN00WWJK0200-004A-EE-SI C WIRE C-B
Q0012SK1374-XMOS FET
Q0022SK1374-XMOS FET
Q0032SK1374-XMOS FET
Q0042SK1374-XMOS FET
Q005RT1N440C-XTRANSISTOR
Q3522SC3928A/QR/-XTRANSISTOR
Q5012SC4212/Z1/TRANSISTOR
C009NCB31HK-103XC CAPACITOR0.01uF 50V K
C101QENC1EM-475ZBP E CAPACITOR4.7uF 25V M
C102NCB31HK-562XC CAPACITOR5600pF 50V K
C103NCB31EK-123XC CAPACITOR0.012uF 25V K
C104NCB31CK-105XC CAPACITOR1uF 16V K
C105QETN1HM-475ZE CAPACITOR4.7uF 50V M
C106QETN1HM-106ZE CAPACITOR10uF 50V M
C107QETN1HM-475ZE CAPACITOR4.7uF 50V M
C108QETN1CM-107ZE CAPACITOR100uF 16V M
C109NCB31HK-103XC CAPACITOR0.01uF 50V K
C110QENC1EM-475ZBP E CAPACITOR4.7uF 25V M
C111QETN1HM-475ZE CAPACITOR4.7uF 50V M
C112QENC1EM-475ZBP E CAPACITOR4.7uF 25V M
C113NCB31HK-272XC CAPACITOR2700pF 50V K
C114NCB31HK-473XC CAPACITOR0.047uF 50V K
C115QETN1HM-335ZE CAPACITOR3.3uF 50V M
C116QENC1EM-475ZBP E CAPACITOR4.7uF 25V M
C117QETN1HM-106ZE CAPACITOR10uF 50V M
C118NCB31CK-105XC CAPACITOR1uF 16V K
C119NCB31HK-103XC CAPACITOR0.01uF 50V K
C120NCB31HK-103XC CAPACITOR0.01uF 50V K
C121NCB31HK-103XC CAPACITOR0.01uF 50V K
C202NCB21AK-105XC CAPACITOR1uF 10V K
C203NCB31HK-152XC CAPACITOR1500pF 50V K
C221QETN1HM-106ZE CAPACITOR10uF 50V M
C222NCB31CK-104XC CAPACITOR0.1uF 16V K
C237NCB31CK-104XC CAPACITOR0.1uF 16V K
C241NCB31HK-103XC CAPACITOR0.01uF 50V K
C242NCB21AK-225XC CAPACITOR2.2uF 10V K
C243QETN0JM-227ZE CAPACITOR220uF 6.3V M
C244NCB31HK-103XC CAPACITOR0.01uF 50V K
C281QFVF1HJ-474ZMF CAPACITOR0.47uF 50V J
C282QETN1CM-107ZE CAPACITOR100uF 16V M
C283NCB31HK-103XC CAPACITOR0.01uF 50V K
C284QETN1HM-225ZE CAPACITOR2.2uF 50V M
C285NCB31HK-103XC CAPACITOR0.01uF 50V K
C286NCB21CK-474XC CAPACITOR0.47uF 16V K
C287QETN1CM-107ZE CAPACITOR100uF 16V M
C288NCB31HK-103XC CAPACITOR0.01uF 50V K
C289NCB21AK-105XC CAPACITOR1uF 10V K
C290NCB21AK-105XC CAPACITOR1uF 10V K
C291NCB21AK-105XC CAPACITOR1uF 10V K
C301NCZ1064-225XC CAPACITOR2.2uF
C302NCB31EK-104XC CAPACITOR0.1uF 25V K
C352QETN1EM-476ZE CAPACITOR47uF 25V M
C354NCB31HK-103XC CAPACITOR0.01uF 50V K
C360NCB31HK-103XC CAPACITOR0.01uF 50V K
C391QETN1CM-107ZE CAPACITOR100uF 16V M
C392NCB31HK-103XC CAPACITOR0.01uF 50V K
C422QFN32AK-102ZM CAPACITOR1000pF 100V K
C424QETN1VM-107ZE CAPACITOR100uF 35V M
C425QETN1VM-477ZE CAPACITOR470uF 35V M
C427QETN1HM-225ZE CAPACITOR2.2uF 50V M
C428QETM1EM-228E CAPACITOR2200uF 25V M
C431QFLC2AK-563ZM CAPACITOR0.056uF 100V K
C433QETN1EM-476ZE CAPACITOR47uF 25V M
C435NCB31HK-183XC CAPACITOR0.018uF 50V K
C440QCS32HJ-100ZC CAPACITOR10pF 500V J
C501QCB32HK-151ZC CAPACITOR150pF 500V K
C502QCB32HK-331ZC CAPACITOR330pF 500V K
C503QEHR2CM-105ZE CAPACITOR1uF 160V M
C504QEZ0203-107E CAPACITOR100uF 160V M
C507QEM61HK-475ZE CAPACITOR4.7uF 50V K
C508QEM61HK-475ZE CAPACITOR4.7uF 50V K
C510QFZ0200-482MPP CAPACITOR4800pF 1.5kV H
C513QFZ0196-113MPP CAPACITOR0.011uF 1.5kV H
C514QFP32GJ-183PP CAPACITOR0.018uF 400V J
C515QFZ0197-404MPP CAPACITOR0.4uF 250V J
C516QCB32HK-561ZC CAPACITOR560pF 500V K
C521QETN2EM-106ZE CAPACITOR10uF 250V M
C523QEHR1VM-477ZE CAPACITOR470uF 35V M
C525QETN1VM-107ZE CAPACITOR100uF 35V M
C526QFV21HJ-824ZMF CAPACITOR0.82uF 50V J
C527QFLC2AJ-103ZM CAPACITOR0.01uF 100V J
C531QCB32HK-471ZC CAPACITOR470pF 500V K
C533QETN1HM-106ZE CAPACITOR10uF 50V M
C621QETN1HM-475ZE CAPACITOR4.7uF 50V M
(No.YA387)3-11
Page 60
Ref No.Part No.Part NameDescription Local
Ref No.Part No.Part NameDescription Local
C623NCB31HK-102XC CAPACITOR1000pF 50V K
C624NCB31CK-334XC CAPACITOR0.33uF 16V K
C625NCB31HK-822XC CAPACITOR8200pF 50V K
C627NCB31CK-105XC CAPACITOR1uF 16V K
C628NCB31CK-105XC CAPACITOR1uF 16V K
C629NCB31CK-105XC CAPACITOR1uF 16V K
C630NCB31CK-105XC CAPACITOR1uF 16V K
C631QETN1HM-475ZE CAPACITOR4.7uF 50V M
C633NCB31HK-102XC CAPACITOR1000pF 50V K
C634NCB31CK-334XC CAPACITOR0.33uF 16V K
C635QETN1CM-476ZE CAPACITOR47uF 16V M
C636QETN1HM-105ZE CAPACITOR1uF 50V M
C637NCB31CK-105XC CAPACITOR1uF 16V K
C638NCB31CK-105XC CAPACITOR1uF 16V K
C651QETN1HM-475ZE CAPACITOR4.7uF 50V M
C652QETN1HM-475ZE CAPACITOR4.7uF 50V M
C653NCB31HK-104XC CAPACITOR0.1uF 50V K
C654QETN1EM-477ZE CAPACITOR470uF 25V M
C655QETN1EM-108ZE CAPACITOR1000uF 25V M
C656NCB31HK-104XC CAPACITOR0.1uF 50V K
C661QETN1HM-475ZE CAPACITOR4.7uF 50V M
C662QETN1HM-475ZE CAPACITOR4.7uF 50V M
C663NCB31HK-104XC CAPACITOR0.1uF 50V K
C666NCB31HK-104XC CAPACITOR0.1uF 50V K
C671QETN1HM-106ZE CAPACITOR10uF 50V M
C683QETN1EM-107ZE CAPACITOR100uF 25V M
C684QETN1CM-476ZE CAPACITOR47uF 16V M
C701QETN1HM-106ZE CAPACITOR10uF 50V M
C702QETN1HM-106ZE CAPACITOR10uF 50V M
C703QETN1HM-106ZE CAPACITOR10uF 50V M
C704QETN1CM-107ZE CAPACITOR100uF 16V M
C705NCB31HK-103XC CAPACITOR0.01uF 50V K
C706NCB31HK-102XC CAPACITOR1000pF 50V K
C708NDC31HJ-220XC CAPACITOR22pF 50V J
C709NDC31HJ-220XC CAPACITOR22pF 50V J
C710NCB31HK-103XC CAPACITOR0.01uF 50V K
C711QETN1CM-107ZE CAPACITOR100uF 16V M
C712NCB31HK-103XC CAPACITOR0.01uF 50V K
C728NCB31HK-103XC CAPACITOR0.01uF 50V K
C730NCB31CK-104XC CAPACITOR0.1uF 16V K
C807NCB31CK-104XC CAPACITOR0.1uF 16V K
C851QETN1EM-477ZE CAPACITOR470uF 25V M
C852NCB31EK-104XC CAPACITOR0.1uF 25V K
C853QETN1CM-107ZE CAPACITOR100uF 16V M
C854QETN1EM-107ZE CAPACITOR100uF 25V M
C856QETN1CM-107ZE CAPACITOR100uF 16V M
C857QETN1CM-107ZE CAPACITOR100uF 16V M
C858QEZ0256-128E CAPACITOR1200uF 10V M
C861QETN0JM-107ZE CAPACITOR100uF 6.3V M
C865QETN0JM-107ZE CAPACITOR100uF 6.3V M
C866QETN0JM-107ZE CAPACITOR100uF 6.3V M
C868QETN1EM-477ZE CAPACITOR470uF 25V M
C869QCZ0397-106ZC CAPACITOR10uF 25V M
C871NCB31HK-103XC CAPACITOR0.01uF 50V K
C874NCB31EK-273XC CAPACITOR0.027uF 25V K
C876QEZ0256-128E CAPACITOR1200uF 10V M
C880NCB31HK-103XC CAPACITOR0.01uF 50V K
C905QCZ9054-102C CAPACITOR1000pF AC250V Z
C907QEZ0644-567E CAPACITOR560uF 200V K
C908QCZ9054-102C CAPACITOR1000pF AC250V Z
C912QCZ0340-222C CAPACITOR2200pF 2kV K
C913QFLC1HJ-471ZM CAPACITOR470pF 50V J
C914QETN1HM-107ZE CAPACITOR100uF 50V M
C916NDC31HJ-331XC CAPACITOR330pF 50V J
C917NCB31HK-182XC CAPACITOR1800pF 50V K
C918NCB31HK-104XC CAPACITOR0.1uF 50V K
C919QFP32GJ-103PP CAPACITOR0.01uF 400V J
C931QEZ0203-227E CAPACITOR220uF 160V M
C932QETN1CM-108ZE CAPACITOR1000uF 16V M
C933QETN1EM-108ZE CAPACITOR1000uF 25V M
C934NDC31HJ-221XC CAPACITOR220pF 50V J
C935QETN1VM-108ZE CAPACITOR1000uF 35V M
C937QCZ0340-102C CAPACITOR1000pF 2kV K
C938QETN1EM-227ZE CAPACITOR220uF 25V M
C939QCB32HK-152ZC CAPACITOR1500pF 500V K
C941QCB32HK-102ZC CAPACITOR1000pF 500V K
C942QEHR1HM-105ZE CAPACITOR1uF 50V M
C943QETN1CM-227ZE CAPACITOR220uF 16V M
C951QETN1EM-477ZE CAPACITOR470uF 25V M
C952QETN1CM-227ZE CAPACITOR220uF 16V M
C971QETN1CM-107ZE CAPACITOR100uF 16V M
C972QETN1EM-476ZE CAPACITOR47uF 25V M
L001QQL244K-6R8ZPEAKING COIL6.8uH K
L241QQL244K-220ZPEAKING COIL22uH K
L391QQL244K-220ZPEAKING COIL22uH K
L511QQR1165-001LINEARITY COIL
L512QQLZ036-821COIL820uH K
L521QQLZ026-760COIL76uH
L704QQL244K-220ZPEAKING COIL22uH K
L705QQL244K-220ZPEAKING COIL22uH K
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1W J
Ω
2W J
Ω
2W J
Ω
1/2W J
Ω
1/2W J
Ω
1/2W J
Ω
1/2W J
Ω
1/2W J
Ω
2W J
Ω
3W J
Ω
1/16W J
Ω
1/10W D
Ω
1/10W D
Ω
1/16W J
L851QQR1401-001CHOKE COIL
L853QQL26AK-330ZCHOKE COIL33uH K
L854QQL26AK-470ZCHOKE COIL47uH K
L855QQL26AK-100ZCHOKE COIL10uH K
L860QQL28AK-150COIL15uH K
L861QQR1401-001CHOKE COIL
L931QQL26AK-470ZCHOKE COIL47uH K
L933QQL26AK-470ZCHOKE COIL47uH K
L937QQL26AK-470ZCHOKE COIL47uH K
L940QQR0582-001ZFERRITE BEADS
T501QQR1414-001DRIVE TRANSF
T921QQS0376-001SW TRANSF
CN001QGB1221J1-80CONNECTOR B-B (1-80)
CN002QGB1505J1-35CONNECTOR B-B (1-35)
CN00FQJB003-032213-ESIN ID C-B WIRE
CN00WWJK0200-004A-EE-SI C WIRE C-B
Q0012SK1374-XMOS FET
Q0022SK1374-XMOS FET
Q0032SK1374-XMOS FET
Q0042SK1374-XMOS FET
Q005RT1N440C-XTRANSISTOR
Q3522SC3928A/QR/-XTRANSISTOR
Q5012SC4212/Z1/TRANSISTOR
C009NCB31HK-103XC CAPACITOR0.01uF 50V K
C101QENC1EM-475ZBP E CAPACITOR4.7uF 25V M
C102NCB31HK-562XC CAPACITOR5600pF 50V K
C103NCB31EK-123XC CAPACITOR0.012uF 25V K
C104NCB31CK-105XC CAPACITOR1uF 16V K
C105QETN1HM-475ZE CAPACITOR4.7uF 50V M
C106QETN1HM-106ZE CAPACITOR10uF 50V M
C107QETN1HM-475ZE CAPACITOR4.7uF 50V M
C108QETN1CM-107ZE CAPACITOR100uF 16V M
C109NCB31HK-103XC CAPACITOR0.01uF 50V K
C110QENC1EM-475ZBP E CAPACITOR4.7uF 25V M
C111QETN1HM-475ZE CAPACITOR4.7uF 50V M
C112QENC1EM-475ZBP E CAPACITOR4.7uF 25V M
C113NCB31HK-272XC CAPACITOR2700pF 50V K
C114NCB31HK-473XC CAPACITOR0.047uF 50V K
C115QETN1HM-335ZE CAPACITOR3.3uF 50V M
C116QENC1EM-475ZBP E CAPACITOR4.7uF 25V M
C117QETN1HM-106ZE CAPACITOR10uF 50V M
C118NCB31CK-105XC CAPACITOR1uF 16V K
C119NCB31HK-103XC CAPACITOR0.01uF 50V K
C120NCB31HK-103XC CAPACITOR0.01uF 50V K
C121NCB31HK-103XC CAPACITOR0.01uF 50V K
C202NCB21AK-105XC CAPACITOR1uF 10V K
C203NCB31HK-152XC CAPACITOR1500pF 50V K
C221QETN1HM-106ZE CAPACITOR10uF 50V M
C222NCB31CK-104XC CAPACITOR0.1uF 16V K
C237NCB31CK-104XC CAPACITOR0.1uF 16V K
C241NCB31HK-103XC CAPACITOR0.01uF 50V K
C242NCB21AK-225XC CAPACITOR2.2uF 10V K
C243QETN0JM-227ZE CAPACITOR220uF 6.3V M
C244NCB31HK-103XC CAPACITOR0.01uF 50V K
C281QFVF1HJ-474ZMF CAPACITOR0.47uF 50V J
C282QETN1CM-107ZE CAPACITOR100uF 16V M
C283NCB31HK-103XC CAPACITOR0.01uF 50V K
C284QETN1HM-225ZE CAPACITOR2.2uF 50V M
C285NCB31HK-103XC CAPACITOR0.01uF 50V K
C286NCB21CK-474XC CAPACITOR0.47uF 16V K
C287QETN1CM-107ZE CAPACITOR100uF 16V M
C288NCB31HK-103XC CAPACITOR0.01uF 50V K
C289NCB21AK-105XC CAPACITOR1uF 10V K
C290NCB21AK-105XC CAPACITOR1uF 10V K
C291NCB21AK-105XC CAPACITOR1uF 10V K
C301NCZ1064-225XC CAPACITOR2.2uF
C302NCB31EK-104XC CAPACITOR0.1uF 25V K
C352QETN1EM-476ZE CAPACITOR47uF 25V M
C354NCB31HK-103XC CAPACITOR0.01uF 50V K
C360NCB31HK-103XC CAPACITOR0.01uF 50V K
C391QETN1CM-107ZE CAPACITOR100uF 16V M
C392NCB31HK-103XC CAPACITOR0.01uF 50V K
C422QFN32AK-102ZM CAPACITOR1000pF 100V K
C424QETN1VM-107ZE CAPACITOR100uF 35V M
C425QETN1VM-477ZE CAPACITOR470uF 35V M
C427QETN1HM-225ZE CAPACITOR2.2uF 50V M
C428QETM1EM-228E CAPACITOR2200uF 25V M
C431QFLC2AK-563ZM CAPACITOR0.056uF 100V K
C433QETN1EM-476ZE CAPACITOR47uF 25V M
C435NCB31HK-183XC CAPACITOR0.018uF 50V K
C440QCS32HJ-100ZC CAPACITOR10pF 500V J
C501QCB32HK-151ZC CAPACITOR150pF 500V K
C502QCB32HK-331ZC CAPACITOR330pF 500V K
C503QEHR2CM-105ZE CAPACITOR1uF 160V M
C504QEZ0203-107E CAPACITOR100uF 160V M
C507QEZ0195-475ZE CAPACITOR4.7uF 50V M
C510QFZ0200-382MPP CAPACITOR3800pF 1.5kV H
C513QFZ0198-133MPP CAPACITOR0.013uF 1.5kV H
C514QFP32JJ-183PP CAPACITOR0.018uF 630V J
C515QFZ0197-474MPP CAPACITOR0.47uF 250V J
C516QCB32HK-561ZC CAPACITOR560pF 500V K
C521QETN2EM-106ZE CAPACITOR10uF 250V M
C523QEHR1VM-108ZE CAPACITOR1000uF 35V M
C525QETN1VM-107ZE CAPACITOR100uF 35V M
C526QFV21HJ-824ZMF CAPACITOR0.82uF 50V J
C527QFLC2AJ-103ZM CAPACITOR0.01uF 100V J
C533QETN1HM-106ZE CAPACITOR10uF 50V M
C621QETN1HM-475ZE CAPACITOR4.7uF 50V M
C623NCB31HK-102XC CAPACITOR1000pF 50V K
C624NCB31CK-334XC CAPACITOR0.33uF 16V K
(No.YA387)3-15
Page 64
Ref No.Part No.Part NameDescription Local
Ref No.Part No.Part NameDescription Local
C625NCB31HK-822XC CAPACITOR8200pF 50V K
C627NCB31CK-105XC CAPACITOR1uF 16V K
C628NCB31CK-105XC CAPACITOR1uF 16V K
C629NCB31CK-105XC CAPACITOR1uF 16V K
C630NCB31CK-105XC CAPACITOR1uF 16V K
C631QETN1HM-475ZE CAPACITOR4.7uF 50V M
C633NCB31HK-102XC CAPACITOR1000pF 50V K
C634NCB31CK-334XC CAPACITOR0.33uF 16V K
C635QETN1CM-476ZE CAPACITOR47uF 16V M
C636QETN1HM-105ZE CAPACITOR1uF 50V M
C637NCB31CK-105XC CAPACITOR1uF 16V K
C638NCB31CK-105XC CAPACITOR1uF 16V K
C651QETN1HM-475ZE CAPACITOR4.7uF 50V M
C652QETN1HM-475ZE CAPACITOR4.7uF 50V M
C653NCB31HK-104XC CAPACITOR0.1uF 50V K
C654QETN1EM-477ZE CAPACITOR470uF 25V M
C655QETN1EM-108ZE CAPACITOR1000uF 25V M
C656NCB31HK-104XC CAPACITOR0.1uF 50V K
C661QETN1HM-475ZE CAPACITOR4.7uF 50V M
C662QETN1HM-475ZE CAPACITOR4.7uF 50V M
C663NCB31HK-104XC CAPACITOR0.1uF 50V K
C666NCB31HK-104XC CAPACITOR0.1uF 50V K
C671QETN1HM-106ZE CAPACITOR10uF 50V M
C683QETN1EM-107ZE CAPACITOR100uF 25V M
C684QETN1CM-476ZE CAPACITOR47uF 16V M
C701QETN1HM-106ZE CAPACITOR10uF 50V M
C702QETN1HM-106ZE CAPACITOR10uF 50V M
C703QETN1HM-106ZE CAPACITOR10uF 50V M
C704QETN1CM-107ZE CAPACITOR100uF 16V M
C705NCB31HK-103XC CAPACITOR0.01uF 50V K
C706NCB31HK-102XC CAPACITOR1000pF 50V K
C708NDC31HJ-220XC CAPACITOR22pF 50V J
C709NDC31HJ-220XC CAPACITOR22pF 50V J
C710NCB31HK-103XC CAPACITOR0.01uF 50V K
C711QETN1CM-107ZE CAPACITOR100uF 16V M
C712NCB31HK-103XC CAPACITOR0.01uF 50V K
C728NCB31HK-103XC CAPACITOR0.01uF 50V K
C730NCB31CK-104XC CAPACITOR0.1uF 16V K
C807NCB31CK-104XC CAPACITOR0.1uF 16V K
C851QETN1EM-477ZE CAPACITOR470uF 25V M
C852NCB31EK-104XC CAPACITOR0.1uF 25V K
C853QETN1CM-107ZE CAPACITOR100uF 16V M
C854QETN1EM-107ZE CAPACITOR100uF 25V M
C856QETN1CM-107ZE CAPACITOR100uF 16V M
C857QETN1CM-107ZE CAPACITOR100uF 16V M
C858QEZ0256-128E CAPACITOR1200uF 10V M
C861QETN0JM-107ZE CAPACITOR100uF 6.3V M
C865QETN0JM-107ZE CAPACITOR100uF 6.3V M
C866QETN0JM-107ZE CAPACITOR100uF 6.3V M
C868QETN1EM-477ZE CAPACITOR470uF 25V M
C869QCZ0397-106ZC CAPACITOR10uF 25V M
C871NCB31HK-103XC CAPACITOR0.01uF 50V K
C874NCB31EK-273XC CAPACITOR0.027uF 25V K
C876QEZ0256-128E CAPACITOR1200uF 10V M
C880NCB31HK-103XC CAPACITOR0.01uF 50V K
C905QCZ9054-102C CAPACITOR1000pF AC250V Z
C907QEZ0644-567E CAPACITOR560uF 200V K
C908QCZ9054-102C CAPACITOR1000pF AC250V Z
C912QCZ0340-222C CAPACITOR2200pF 2kV K
C913QFLC1HJ-471ZM CAPACITOR470pF 50V J
C914QETN1HM-107ZE CAPACITOR100uF 50V M
C916NDC31HJ-331XC CAPACITOR330pF 50V J
C917NCB31HK-182XC CAPACITOR1800pF 50V K
C918NCB31HK-104XC CAPACITOR0.1uF 50V K
C919QFP32GJ-103PP CAPACITOR0.01uF 400V J
C931QEZ0203-227E CAPACITOR220uF 160V M
C932QETN1CM-108ZE CAPACITOR1000uF 16V M
C933QETN1EM-108ZE CAPACITOR1000uF 25V M
C934NDC31HJ-221XC CAPACITOR220pF 50V J
C935QETN1VM-108ZE CAPACITOR1000uF 35V M
C937QCZ0340-102C CAPACITOR1000pF 2kV K
C938QETN1EM-227ZE CAPACITOR220uF 25V M
C939QCB32HK-152ZC CAPACITOR1500pF 500V K
C941QCB32HK-102ZC CAPACITOR1000pF 500V K
C942QEHR1HM-105ZE CAPACITOR1uF 50V M
C943QETN1CM-227ZE CAPACITOR220uF 16V M
C951QETN1EM-477ZE CAPACITOR470uF 25V M
C952QETN1CM-227ZE CAPACITOR220uF 16V M
C971QETN1CM-107ZE CAPACITOR100uF 16V M
C972QETN1EM-476ZE CAPACITOR47uF 25V M
L001QQL244K-6R8ZPEAKING COIL6.8uH K
L241QQL244K-220ZPEAKING COIL22uH K
L391QQL244K-220ZPEAKING COIL22uH K
L511QQR1027-003LINEARITY COIL
L512QQLZ036-821COIL820uH K
L521QQLZ018-340COIL34uH
L704QQL244K-220ZPEAKING COIL22uH K
L705QQL244K-220ZPEAKING COIL22uH K
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1W J
Ω
2W J
Ω
2W J
Ω
1/2W J
Ω
1/2W J
Ω
1/2W J
Ω
1/2W J
Ω
1/2W J
Ω
2W J
Ω
3W J
Ω
1/16W J
Ω
1/10W D
Ω
1/10W D
Ω
1/16W J
L851QQR1401-001CHOKE COIL
L853QQL26AK-330ZCHOKE COIL33uH K
L854QQL26AK-470ZCHOKE COIL47uH K
L855QQL26AK-100ZCHOKE COIL10uH K
L860QQL28AK-150COIL15uH K
L861QQR1401-001CHOKE COIL
L931QQL26AK-470ZCHOKE COIL47uH K
L933QQL26AK-470ZCHOKE COIL47uH K
L937QQL26AK-470ZCHOKE COIL47uH K
L940QQR0582-001ZFERRITE BEADS
T501QQR1414-001DRIVE TRANSF
T921QQS0376-001SW TRANSF
CN001QGB1221J1-80CONNECTOR B-B (1-80)
CN002QGB1505J1-35CONNECTOR B-B (1-35)
CN00FQJB003-032213-ESIN ID C-B WIRE
CN00WWJK0200-004A-EE-SI C WIRE C-B
Q0012SK1374-XMOS FET
Q0022SK1374-XMOS FET
Q0032SK1374-XMOS FET
Q0042SK1374-XMOS FET
Q005RT1N440C-XTRANSISTOR
Q3522SC3928A/QR/-XTRANSISTOR
Q5012SC4212/Z1/TRANSISTOR
C009NCB31HK-103XC CAPACITOR0.01uF 50V K
C101QENC1EM-475ZBP E CAPACITOR4.7uF 25V M
C102NCB31HK-562XC CAPACITOR5600pF 50V K
C103NCB31EK-123XC CAPACITOR0.012uF 25V K
C104NCB31CK-105XC CAPACITOR1uF 16V K
C105QETN1HM-475ZE CAPACITOR4.7uF 50V M
C106QETN1HM-106ZE CAPACITOR10uF 50V M
C107QETN1HM-475ZE CAPACITOR4.7uF 50V M
C108QETN1CM-107ZE CAPACITOR100uF 16V M
C109NCB31HK-103XC CAPACITOR0.01uF 50V K
C110QENC1EM-475ZBP E CAPACITOR4.7uF 25V M
C111QETN1HM-475ZE CAPACITOR4.7uF 50V M
C112QENC1EM-475ZBP E CAPACITOR4.7uF 25V M
C113NCB31HK-272XC CAPACITOR2700pF 50V K
C114NCB31HK-473XC CAPACITOR0.047uF 50V K
C115QETN1HM-335ZE CAPACITOR3.3uF 50V M
C116QENC1EM-475ZBP E CAPACITOR4.7uF 25V M
C117QETN1HM-106ZE CAPACITOR10uF 50V M
C118NCB31CK-105XC CAPACITOR1uF 16V K
C119NCB31HK-103XC CAPACITOR0.01uF 50V K
C120NCB31HK-103XC CAPACITOR0.01uF 50V K
C121NCB31HK-103XC CAPACITOR0.01uF 50V K
C202NCB21AK-105XC CAPACITOR1uF 10V K
C203NCB31HK-152XC CAPACITOR1500pF 50V K
C221QETN1HM-106ZE CAPACITOR10uF 50V M
C222NCB31CK-104XC CAPACITOR0.1uF 16V K
C237NCB31CK-104XC CAPACITOR0.1uF 16V K
C241NCB31HK-103XC CAPACITOR0.01uF 50V K
C242NCB21AK-225XC CAPACITOR2.2uF 10V K
C243QETN0JM-227ZE CAPACITOR220uF 6.3V M
C244NCB31HK-103XC CAPACITOR0.01uF 50V K
C281QFVF1HJ-474ZMF CAPACITOR0.47uF 50V J
C282QETN1CM-107ZE CAPACITOR100uF 16V M
C283NCB31HK-103XC CAPACITOR0.01uF 50V K
C284QETN1HM-225ZE CAPACITOR2.2uF 50V M
C285NCB31HK-103XC CAPACITOR0.01uF 50V K
C286NCB21CK-474XC CAPACITOR0.47uF 16V K
C287QETN1CM-107ZE CAPACITOR100uF 16V M
C288NCB31HK-103XC CAPACITOR0.01uF 50V K
C289NCB21AK-105XC CAPACITOR1uF 10V K
C290NCB21AK-105XC CAPACITOR1uF 10V K
C291NCB21AK-105XC CAPACITOR1uF 10V K
C301NCZ1064-225XC CAPACITOR2.2uF
C302NCB31EK-104XC CAPACITOR0.1uF 25V K
C352QETN1EM-476ZE CAPACITOR47uF 25V M
C354NCB31HK-103XC CAPACITOR0.01uF 50V K
C360NCB31HK-103XC CAPACITOR0.01uF 50V K
C391QETN1CM-107ZE CAPACITOR100uF 16V M
C392NCB31HK-103XC CAPACITOR0.01uF 50V K
C422QFN32AK-102ZM CAPACITOR1000pF 100V K
C424QETN1VM-107ZE CAPACITOR100uF 35V M
C425QETN1VM-477ZE CAPACITOR470uF 35V M
C427QETN1HM-225ZE CAPACITOR2.2uF 50V M
C428QETM1EM-228E CAPACITOR2200uF 25V M
C431QFLC2AK-563ZM CAPACITOR0.056uF 100V K
C433QETN1EM-476ZE CAPACITOR47uF 25V M
C435NCB31HK-183XC CAPACITOR0.018uF 50V K
C440QCS32HJ-100ZC CAPACITOR10pF 500V J
C501QCB32HK-151ZC CAPACITOR150pF 500V K
C502QCB32HK-331ZC CAPACITOR330pF 500V K
C503QEHR2CM-105ZE CAPACITOR1uF 160V M
C504QEZ0203-107E CAPACITOR100uF 160V M
C507QEZ0195-475ZE CAPACITOR4.7uF 50V M
C510QFZ0200-422MPP CAPACITOR4200pF 1.5kV H
C513QFZ0198-133MPP CAPACITOR0.013uF 1.5kV H
C514QFP32JJ-183PP CAPACITOR0.018uF 630V J
C515QFZ0197-474MPP CAPACITOR0.47uF 250V J
C516QCB32HK-561ZC CAPACITOR560pF 500V K
C521QETN2EM-106ZE CAPACITOR10uF 250V M
C523QEHR1VM-108ZE CAPACITOR1000uF 35V M
C525QETN1VM-107ZE CAPACITOR100uF 35V M
C526QFV21HJ-824ZMF CAPACITOR0.82uF 50V J
C527QFLC2AJ-103ZM CAPACITOR0.01uF 100V J
C533QETN1HM-106ZE CAPACITOR10uF 50V M
C621QETN1HM-475ZE CAPACITOR4.7uF 50V M
C623NCB31HK-102XC CAPACITOR1000pF 50V K
C624NCB31CK-334XC CAPACITOR0.33uF 16V K
(No.YA387)3-19
Page 68
Ref No.Part No.Part NameDescription Local
Ref No.Part No.Part NameDescription Local
C625NCB31HK-822XC CAPACITOR8200pF 50V K
C627NCB31CK-105XC CAPACITOR1uF 16V K
C628NCB31CK-105XC CAPACITOR1uF 16V K
C629NCB31CK-105XC CAPACITOR1uF 16V K
C630NCB31CK-105XC CAPACITOR1uF 16V K
C631QETN1HM-475ZE CAPACITOR4.7uF 50V M
C633NCB31HK-102XC CAPACITOR1000pF 50V K
C634NCB31CK-334XC CAPACITOR0.33uF 16V K
C635QETN1CM-476ZE CAPACITOR47uF 16V M
C636QETN1HM-105ZE CAPACITOR1uF 50V M
C637NCB31CK-105XC CAPACITOR1uF 16V K
C638NCB31CK-105XC CAPACITOR1uF 16V K
C651QETN1HM-475ZE CAPACITOR4.7uF 50V M
C652QETN1HM-475ZE CAPACITOR4.7uF 50V M
C653NCB31HK-104XC CAPACITOR0.1uF 50V K
C654QETN1EM-477ZE CAPACITOR470uF 25V M
C655QETN1EM-108ZE CAPACITOR1000uF 25V M
C656NCB31HK-104XC CAPACITOR0.1uF 50V K
C661QETN1HM-475ZE CAPACITOR4.7uF 50V M
C662QETN1HM-475ZE CAPACITOR4.7uF 50V M
C663NCB31HK-104XC CAPACITOR0.1uF 50V K
C666NCB31HK-104XC CAPACITOR0.1uF 50V K
C671QETN1HM-106ZE CAPACITOR10uF 50V M
C683QETN1EM-107ZE CAPACITOR100uF 25V M
C684QETN1CM-476ZE CAPACITOR47uF 16V M
C701QETN1HM-106ZE CAPACITOR10uF 50V M
C702QETN1HM-106ZE CAPACITOR10uF 50V M
C703QETN1HM-106ZE CAPACITOR10uF 50V M
C704QETN1CM-107ZE CAPACITOR100uF 16V M
C705NCB31HK-103XC CAPACITOR0.01uF 50V K
C706NCB31HK-102XC CAPACITOR1000pF 50V K
C708NDC31HJ-220XC CAPACITOR22pF 50V J
C709NDC31HJ-220XC CAPACITOR22pF 50V J
C710NCB31HK-103XC CAPACITOR0.01uF 50V K
C711QETN1CM-107ZE CAPACITOR100uF 16V M
C712NCB31HK-103XC CAPACITOR0.01uF 50V K
C728NCB31HK-103XC CAPACITOR0.01uF 50V K
C730NCB31CK-104XC CAPACITOR0.1uF 16V K
C807NCB31CK-104XC CAPACITOR0.1uF 16V K
C851QETN1EM-477ZE CAPACITOR470uF 25V M
C852NCB31EK-104XC CAPACITOR0.1uF 25V K
C853QETN1CM-107ZE CAPACITOR100uF 16V M
C854QETN1EM-107ZE CAPACITOR100uF 25V M
C856QETN1CM-107ZE CAPACITOR100uF 16V M
C857QETN1CM-107ZE CAPACITOR100uF 16V M
C858QEZ0256-128E CAPACITOR1200uF 10V M
C861QETN0JM-107ZE CAPACITOR100uF 6.3V M
C865QETN0JM-107ZE CAPACITOR100uF 6.3V M
C866QETN0JM-107ZE CAPACITOR100uF 6.3V M
C868QETN1EM-477ZE CAPACITOR470uF 25V M
C869QCZ0397-106ZC CAPACITOR10uF 25V M
C871NCB31HK-103XC CAPACITOR0.01uF 50V K
C874NCB31EK-273XC CAPACITOR0.027uF 25V K
C876QEZ0256-128E CAPACITOR1200uF 10V M
C880NCB31HK-103XC CAPACITOR0.01uF 50V K
C905QCZ9054-102C CAPACITOR1000pF AC250V Z
C907QEZ0644-567E CAPACITOR560uF 200V K
C908QCZ9054-102C CAPACITOR1000pF AC250V Z
C912QCZ0340-222C CAPACITOR2200pF 2kV K
C913QFLC1HJ-471ZM CAPACITOR470pF 50V J
C914QETN1HM-107ZE CAPACITOR100uF 50V M
C916NDC31HJ-331XC CAPACITOR330pF 50V J
C917NCB31HK-182XC CAPACITOR1800pF 50V K
C918NCB31HK-104XC CAPACITOR0.1uF 50V K
C919QFP32GJ-103PP CAPACITOR0.01uF 400V J
C931QEZ0203-227E CAPACITOR220uF 160V M
C932QETN1CM-108ZE CAPACITOR1000uF 16V M
C933QETN1EM-108ZE CAPACITOR1000uF 25V M
C934NDC31HJ-221XC CAPACITOR220pF 50V J
C935QETN1VM-108ZE CAPACITOR1000uF 35V M
C937QCZ0340-102C CAPACITOR1000pF 2kV K
C938QETN1EM-227ZE CAPACITOR220uF 25V M
C939QCB32HK-152ZC CAPACITOR1500pF 500V K
C941QCB32HK-102ZC CAPACITOR1000pF 500V K
C942QEHR1HM-105ZE CAPACITOR1uF 50V M
C943QETN1CM-227ZE CAPACITOR220uF 16V M
C951QETN1EM-477ZE CAPACITOR470uF 25V M
C952QETN1CM-227ZE CAPACITOR220uF 16V M
C971QETN1CM-107ZE CAPACITOR100uF 16V M
C972QETN1EM-476ZE CAPACITOR47uF 25V M
L001QQL244K-6R8ZPEAKING COIL6.8uH K
L241QQL244K-220ZPEAKING COIL22uH K
L391QQL244K-220ZPEAKING COIL22uH K
L511QQR1027-003LINEARITY COIL
L512QQLZ036-821COIL820uH K
L521QQLZ018-800COIL80uH
L704QQL244K-220ZPEAKING COIL22uH K
L705QQL244K-220ZPEAKING COIL22uH K
L851QQR1401-001CHOKE COIL
Ω
1/16W J
Ω
1/4W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/2W J
Ω
2W J
Ω
1/2W J
Ω
1/2W J
Ω
1/2W J
Ω
1/2W J
Ω
1/2W J
Ω
2W J
Ω
3W J
Ω
1/16W J
Ω
1/2W J
Ω
1/10W D
Ω
1/2W J
L853QQL26AK-330ZCHOKE COIL33uH K
L854QQL26AK-470ZCHOKE COIL47uH K
L855QQL26AK-100ZCHOKE COIL10uH K
L860QQL28AK-150COIL15uH K
L861QQR1401-001CHOKE COIL
L931QQL26AK-470ZCHOKE COIL47uH K
L933QQL26AK-470ZCHOKE COIL47uH K
L937QQL26AK-470ZCHOKE COIL47uH K
L940QQR0582-001ZFERRITE BEADS
T501QQR1414-001DRIVE TRANSF
T921QQS0376-001SW TRANSF
CN001QGB1221J1-80CONNECTOR B-B (1-80)
CN002QGB1505J1-35CONNECTOR B-B (1-35)
CN00FQJB003-032213-ESIN ID C-B WIRE
CN00WWJK0200-004A-EE-SI C WIRE C-B
Q0012SK1374-XMOS FET
Q0022SK1374-XMOS FET
Q0032SK1374-XMOS FET
Q0042SK1374-XMOS FET
Q005RT1N440C-XTRANSISTOR
Q3522SC3928A/QR/-XTRANSISTOR
Q5012SC4212/Z1/TRANSISTOR
C009NCB31HK-103XC CAPACITOR0.01uF 50V K
C101QENC1EM-475ZBP E CAPACITOR4.7uF 25V M
C102NCB31HK-562XC CAPACITOR5600pF 50V K
C103NCB31EK-123XC CAPACITOR0.012uF 25V K
C104NCB31CK-105XC CAPACITOR1uF 16V K
C105QETN1HM-475ZE CAPACITOR4.7uF 50V M
C106QETN1HM-106ZE CAPACITOR10uF 50V M
C107QETN1HM-475ZE CAPACITOR4.7uF 50V M
C108QETN1CM-107ZE CAPACITOR100uF 16V M
C109NCB31HK-103XC CAPACITOR0.01uF 50V K
C110QENC1EM-475ZBP E CAPACITOR4.7uF 25V M
C111QETN1HM-475ZE CAPACITOR4.7uF 50V M
C112QENC1EM-475ZBP E CAPACITOR4.7uF 25V M
C113NCB31HK-272XC CAPACITOR2700pF 50V K
C114NCB31HK-473XC CAPACITOR0.047uF 50V K
C115QETN1HM-335ZE CAPACITOR3.3uF 50V M
C116QENC1EM-475ZBP E CAPACITOR4.7uF 25V M
C117QETN1HM-106ZE CAPACITOR10uF 50V M
C118NCB31CK-105XC CAPACITOR1uF 16V K
C119NCB31HK-103XC CAPACITOR0.01uF 50V K
C120NCB31HK-103XC CAPACITOR0.01uF 50V K
C121NCB31HK-103XC CAPACITOR0.01uF 50V K
C202NCB21AK-105XC CAPACITOR1uF 10V K
C203NCB31HK-152XC CAPACITOR1500pF 50V K
C221QETN1HM-106ZE CAPACITOR10uF 50V M
C222NCB31CK-104XC CAPACITOR0.1uF 16V K
C237NCB31CK-104XC CAPACITOR0.1uF 16V K
C241NCB31HK-103XC CAPACITOR0.01uF 50V K
C242NCB21AK-225XC CAPACITOR2.2uF 10V K
C243QETN0JM-227ZE CAPACITOR220uF 6.3V M
C244NCB31HK-103XC CAPACITOR0.01uF 50V K
C281QFVF1HJ-474ZMF CAPACITOR0.47uF 50V J
C282QETN1CM-107ZE CAPACITOR100uF 16V M
C283NCB31HK-103XC CAPACITOR0.01uF 50V K
C284QETN1HM-225ZE CAPACITOR2.2uF 50V M
C285NCB31HK-103XC CAPACITOR0.01uF 50V K
C286NCB21CK-474XC CAPACITOR0.47uF 16V K
C287QETN1CM-107ZE CAPACITOR100uF 16V M
C288NCB31HK-103XC CAPACITOR0.01uF 50V K
C289NCB21AK-105XC CAPACITOR1uF 10V K
C290NCB21AK-105XC CAPACITOR1uF 10V K
C291NCB21AK-105XC CAPACITOR1uF 10V K
C301NCZ1064-225XC CAPACITOR2.2uF
C302NCB31EK-104XC CAPACITOR0.1uF 25V K
C352QETN1EM-476ZE CAPACITOR47uF 25V M
C354NCB31HK-103XC CAPACITOR0.01uF 50V K
C360NCB31HK-103XC CAPACITOR0.01uF 50V K
C391QETN1CM-107ZE CAPACITOR100uF 16V M
C392NCB31HK-103XC CAPACITOR0.01uF 50V K
C422QFN32AK-102ZM CAPACITOR1000pF 100V K
C424QETN1VM-107ZE CAPACITOR100uF 35V M
C425QETN1VM-477ZE CAPACITOR470uF 35V M
C427QETN1HM-225ZE CAPACITOR2.2uF 50V M
C428QETM1EM-228E CAPACITOR2200uF 25V M
C431QFLC2AK-563ZM CAPACITOR0.056uF 100V K
C433QETN1EM-476ZE CAPACITOR47uF 25V M
C435NCB31HK-183XC CAPACITOR0.018uF 50V K
C440QCS32HJ-100ZC CAPACITOR10pF 500V J
C501QCB32HK-151ZC CAPACITOR150pF 500V K
C502QCB32HK-331ZC CAPACITOR330pF 500V K
C503QEHR2CM-105ZE CAPACITOR1uF 160V M
C504QEZ0203-107E CAPACITOR100uF 160V M
C507QEZ0195-475ZE CAPACITOR4.7uF 50V M
C510QFZ0200-382MPP CAPACITOR3800pF 1.5kV H
C513QFZ0196-103MPP CAPACITOR0.01uF 1.5kV H
C514QFP32JJ-183PP CAPACITOR0.018uF 630V J
C515QFZ0197-404MPP CAPACITOR0.4uF 250V J
C516QCB32HK-561ZC CAPACITOR560pF 500V K
C521QETN2EM-106ZE CAPACITOR10uF 250V M
C523QEHR1VM-108ZE CAPACITOR1000uF 35V M
C525QETN1VM-107ZE CAPACITOR100uF 35V M
C526QFV21HJ-824ZMF CAPACITOR0.82uF 50V J
C527QFLC2AJ-103ZM CAPACITOR0.01uF 100V J
C533QETN1HM-106ZE CAPACITOR10uF 50V M
C621QETN1HM-475ZE CAPACITOR4.7uF 50V M
C623NCB31HK-102XC CAPACITOR1000pF 50V K
C624NCB31CK-334XC CAPACITOR0.33uF 16V K
(No.YA387)3-23
Page 72
Ref No.Part No.Part NameDescription Local
Ref No.Part No.Part NameDescription Local
C625NCB31HK-822XC CAPACITOR8200pF 50V K
C627NCB31CK-105XC CAPACITOR1uF 16V K
C628NCB31CK-105XC CAPACITOR1uF 16V K
C629NCB31CK-105XC CAPACITOR1uF 16V K
C630NCB31CK-105XC CAPACITOR1uF 16V K
C631QETN1HM-475ZE CAPACITOR4.7uF 50V M
C633NCB31HK-102XC CAPACITOR1000pF 50V K
C634NCB31CK-334XC CAPACITOR0.33uF 16V K
C635QETN1CM-476ZE CAPACITOR47uF 16V M
C636QETN1HM-105ZE CAPACITOR1uF 50V M
C637NCB31CK-105XC CAPACITOR1uF 16V K
C638NCB31CK-105XC CAPACITOR1uF 16V K
C651QETN1HM-475ZE CAPACITOR4.7uF 50V M
C652QETN1HM-475ZE CAPACITOR4.7uF 50V M
C653NCB31HK-104XC CAPACITOR0.1uF 50V K
C654QETN1EM-477ZE CAPACITOR470uF 25V M
C655QETN1EM-108ZE CAPACITOR1000uF 25V M
C656NCB31HK-104XC CAPACITOR0.1uF 50V K
C661QETN1HM-475ZE CAPACITOR4.7uF 50V M
C662QETN1HM-475ZE CAPACITOR4.7uF 50V M
C663NCB31HK-104XC CAPACITOR0.1uF 50V K
C666NCB31HK-104XC CAPACITOR0.1uF 50V K
C671QETN1HM-106ZE CAPACITOR10uF 50V M
C683QETN1EM-107ZE CAPACITOR100uF 25V M
C684QETN1CM-476ZE CAPACITOR47uF 16V M
C701QETN1HM-106ZE CAPACITOR10uF 50V M
C702QETN1HM-106ZE CAPACITOR10uF 50V M
C703QETN1HM-106ZE CAPACITOR10uF 50V M
C704QETN1CM-107ZE CAPACITOR100uF 16V M
C705NCB31HK-103XC CAPACITOR0.01uF 50V K
C706NCB31HK-102XC CAPACITOR1000pF 50V K
C708NDC31HJ-220XC CAPACITOR22pF 50V J
C709NDC31HJ-220XC CAPACITOR22pF 50V J
C710NCB31HK-103XC CAPACITOR0.01uF 50V K
C711QETN1CM-107ZE CAPACITOR100uF 16V M
C712NCB31HK-103XC CAPACITOR0.01uF 50V K
C728NCB31HK-103XC CAPACITOR0.01uF 50V K
C730NCB31CK-104XC CAPACITOR0.1uF 16V K
C807NCB31CK-104XC CAPACITOR0.1uF 16V K
C851QETN1EM-477ZE CAPACITOR470uF 25V M
C852NCB31EK-104XC CAPACITOR0.1uF 25V K
C853QETN1CM-107ZE CAPACITOR100uF 16V M
C854QETN1EM-107ZE CAPACITOR100uF 25V M
C856QETN1CM-107ZE CAPACITOR100uF 16V M
C857QETN1CM-107ZE CAPACITOR100uF 16V M
C858QEZ0256-128E CAPACITOR1200uF 10V M
C861QETN0JM-107ZE CAPACITOR100uF 6.3V M
C865QETN0JM-107ZE CAPACITOR100uF 6.3V M
C866QETN0JM-107ZE CAPACITOR100uF 6.3V M
C868QETN1EM-477ZE CAPACITOR470uF 25V M
C869QCZ0397-106ZC CAPACITOR10uF 25V M
C871NCB31HK-103XC CAPACITOR0.01uF 50V K
C874NCB31EK-273XC CAPACITOR0.027uF 25V K
C876QEZ0256-128E CAPACITOR1200uF 10V M
C880NCB31HK-103XC CAPACITOR0.01uF 50V K
C905QCZ9054-102C CAPACITOR1000pF AC250V Z
C907QEZ0644-567E CAPACITOR560uF 200V K
C908QCZ9054-102C CAPACITOR1000pF AC250V Z
C912QCZ0340-222C CAPACITOR2200pF 2kV K
C913QFLC1HJ-471ZM CAPACITOR470pF 50V J
C914QETN1HM-107ZE CAPACITOR100uF 50V M
C916NDC31HJ-331XC CAPACITOR330pF 50V J
C917NCB31HK-182XC CAPACITOR1800pF 50V K
C918NCB31HK-104XC CAPACITOR0.1uF 50V K
C919QFP32GJ-103PP CAPACITOR0.01uF 400V J
C931QEZ0203-227E CAPACITOR220uF 160V M
C932QETN1CM-108ZE CAPACITOR1000uF 16V M
C933QETN1EM-108ZE CAPACITOR1000uF 25V M
C934NDC31HJ-221XC CAPACITOR220pF 50V J
C935QETN1VM-108ZE CAPACITOR1000uF 35V M
C937QCZ0340-102C CAPACITOR1000pF 2kV K
C938QETN1EM-227ZE CAPACITOR220uF 25V M
C939QCB32HK-152ZC CAPACITOR1500pF 500V K
C941QCB32HK-102ZC CAPACITOR1000pF 500V K
C942QEHR1HM-105ZE CAPACITOR1uF 50V M
C943QETN1CM-227ZE CAPACITOR220uF 16V M
C951QETN1EM-477ZE CAPACITOR470uF 25V M
C952QETN1CM-227ZE CAPACITOR220uF 16V M
C971QETN1CM-107ZE CAPACITOR100uF 16V M
C972QETN1EM-476ZE CAPACITOR47uF 25V M
L001QQL244K-6R8ZPEAKING COIL6.8uH K
L241QQL244K-220ZPEAKING COIL22uH K
L391QQL244K-220ZPEAKING COIL22uH K
L511QQR1165-001LINEARITY COIL
L512QQLZ036-821COIL820uH K
L521QQLZ026-860COIL86uH
L704QQL244K-220ZPEAKING COIL22uH K
L705QQL244K-220ZPEAKING COIL22uH K
L851QQR1401-001CHOKE COIL
Ω
1/16W J
Ω
1/4W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/2W J
Ω
2W J
Ω
1/2W J
Ω
1/2W J
Ω
1/2W J
Ω
1/2W J
Ω
1/2W J
Ω
2W J
Ω
3W J
Ω
1/16W J
Ω
1/2W J
Ω
1/10W D
Ω
1/2W J
L853QQL26AK-330ZCHOKE COIL33uH K
L854QQL26AK-470ZCHOKE COIL47uH K
L855QQL26AK-100ZCHOKE COIL10uH K
L860QQL28AK-150COIL15uH K
L861QQR1401-001CHOKE COIL
L931QQL26AK-470ZCHOKE COIL47uH K
L933QQL26AK-470ZCHOKE COIL47uH K
L937QQL26AK-470ZCHOKE COIL47uH K
L940QQR0582-001ZFERRITE BEADS
T501QQR1414-001DRIVE TRANSF
T921QQS0376-001SW TRANSF
CN001QGB1221J1-80CONNECTOR B-B (1-80)
CN002QGB1505J1-35CONNECTOR B-B (1-35)
CN00FQJB003-032213-ESIN ID C-B WIRE
CN00WWJK0200-004A-EE-SI C WIRE C-B
CN300AWJA0029-002A-EE-SI ID WIRE
CN300EQJB003-074022-ESIN ID C-B WIRE
CN30E2QUB130-46A6AS-ESIN TWIST WIRE
CN30E4QUB130-46A6AS-ESIN TWIST WIRE
K3104QQR1114-001ZFERRITE BEADS
K3105QQR1114-001ZFERRITE BEADS
SK3001QNZ0536-002CRT SOCKET
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
2W J
Ω
2W J
Ω
1/2W K
Ω
1/2W K
AV SW P.W. BOARD ASS'Y (SGJ-5301A-M2)
REFER TO PARTS LIST IN PAGE 3-9 FOR THIS P.W. BOARD.
FRONT CONTROL P.W. BOARD ASS'Y (SGJ-6301A-M2)
REFER TO PARTS LIST IN PAGE 3-10 FOR THIS P.W. BOARD.
LED & POWER SW P.W. BOARD ASS'Y (SGJ-7301A-M2)
REFER TO PARTS LIST IN PAGE 3-10 FOR THIS P.W. BOARD.
USB P.W. BOARD ASS'Y (SGJ-8302A-M2)
REFER TO PARTS LIST IN PAGE 3-10 FOR THIS P.W. BOARD.
L/F P.W. BOARD ASS'Y (SGJ-9301A-M2)
REFER TO PARTS LIST IN PAGE 3-18 FOR THIS P.W. BOARD.
ATSC TUNER MODULE P.W. BOARD ASS'Y
(SSD-2302A-M2)
REFER TO PARTS LIST IN PAGE 3-10 FOR THIS P.W. BOARD.
3-26(No.YA387)
Page 75
REMOTE CONTROL UNIT PARTS LIST (RM-C1290G-1C)
Ref.No.Part No.Part NameDescriptionLocal
10030-0006800BATTERY COVER
PACKING
2
4
56789
3
1
2
PACKING PARTS LIST
Ref.No.Part No.Part NameDescriptionLocal
1LC10181-025C-APACKING CASEAV-27F577R,AV-27F577S
1LC10181-026C-APACKING CASEAV-32F577R,AV-32F577Y,AV-32F577Z
2LC10884-002B-ACUSHION ASSY4pcs in 1setAV-27F577R,AV-27F577S
2LC11049-002B-ACUSHION ASSY4pcs in 1setAV-32F577R,AV-32F577Y,AV-32F577Z
3GQ30092-005A-ALAMINATE FILM BAGAV-27F577R,AV-27F577S
3GQ30092-003A-ALAMINATE FILM BAGAV-32F577R,AV-32F577Y,AV-32F577Z
4QPA02503505POLY BAG25cm x 35cm
5RM-C1290G-1CREMOTE CONTROL UNIT
