JVC AV-29W83/BK, AV-29W83/VT, AV-29W83B/VT, AV-29W93/BK, AV-29W93B/BK Parts List

AV-29W83 AV-29W93B AV-29W93 AV-29W83B

PARTS LIST

CAUTION

q The parts identified by the symbol are important for the safety . Whenever replacing these parts, be sure to use specified ones to secure the

safety .

q The parts not indicated in this Parts List and those which are filled with lines --- in the Parts No. columns will not be supplied . q P. W. Board Ass'y will not be supplied, but those which are filled with the Parts No. in the Parts No. columns will be supplied .

ABBREVIATIONS OF RESISTORS, CAPACITORS AND TOLERANCES

RESISTORS CAPACITORS

C R Carbon Resistor

F R Fusible Resistor

P R Plate Resistor

V R Variable Resistor

HV R High Voltage Resistor

MF R Metal Film Resistor

MG R Metal Glazed Resistor

MP R Metal Plate Resistor

OM R Metal Oxide Film Resistor

CMF R Coating Metal Film Resistor

UNF R Non-Flammable Resistor

CH V R Chip Variable Resistor

CH MG R Chip Metal Glazed Resistor

COMP. R Composition Resistor

LPTC R Linear Positive Temperature Coefficient Resistor

C CAP. Ceramic Capacitor

E CAP. Electrolytic Capacitor

M CAP. Mylar Capacitor

CH CAP. Chip Capacitor

HV CAP. High Voltage Capacitor

MF CAP. Metalized Film Capacitor

MM CAP. Metalized Mylar Capacitor

MP CAP. Metalized Polystyrol Capacitor

PP CAP. Polypropylene Capacitor

PS CAP. Polystyrol Capacitor

TF CAP. Thin Film Capacitor

MPP CAP. Metalized Polypropylene Capacitor

TAN. CAP. Tantalum Capacitor

CH C CAP. Chip Ceramic Capacitor

BP E CAP. Bi-Polar Electrolytic Capacitor

CH AL E CAP. Chip Aluminum Electrolytic Capacitor

CH AL BP CAP. Chip Aluminum Bi-Polar Capacitor

CH TAN. E CAP. Chip Tantalum Electrolytic Capacitor

CH AL BP E CAP. Chip Tantalum Bi-Polar Electrolytic Capacitor

RESISTORS

FGJKMNRHZP

±1% ±2% ±5% ±10% ±20% ±30%

No. 52070 41

+30% +50% +80% +100%

-10% -10% -20% 0%

AV-29W83 AV-29W93B AV-29W93 AV-29W83B

USING P.W. BOARD & REMOTE CONTROL UNIT

AV-29W83 AV-29W93B AV-29W93 AV-29W83B

P. W.B ASS’Y

MAIN PWB SCH-1118A-BK SCH-1119A-BK SCH-1120A-BK CRT SOCKET PWB SCH-3005A-BK FRONT CONTROL PWB SCH-8004A-BK REMOTE CONTROL UNIT RM-C1016-1H RM-C1011-1H RM-C1012-1H

P. W.B ASS’Y

MAIN PWB SCH-1312A-CK SCH-1310A-V2 CRT SOCKET PWB SCH-3301A-V2 FRONT CONTROL PWB SCH-8301A-V2 REMOTE CONTROL UNIT RM-C1015-1H RM-C1014-1H

Model

EXPLODED VIEW PARTS LIST-

!

Ref.No. Part No. Part Name Description Local

22 GG20028-001A-H OPERATION SHEET 23 GG30050-001B-H REMOCON LENS 24 GG30049-001B-H LED LENS 25 LC41037-003A-H JVC MARK 26 GG10189-008A-H FRONT CABINET ASS’Y Inc. No. 27, 28, 29, 30 [AV-29W83/BK] 26 GG10189-005A-H FRONT CABINET ASS’Y Inc. No. 27, 28, 29, 30 [AV-29W93/BK, AV-29W93B/BK] 26 GG10189-007A-HK FRONT CABINET ASS’Y Inc. No. 27, 28, 29, 30 [AV-29W83B/VT] 26 GG10189-009A-HK FRONT CABINET ASS’Y Inc. No. 27, 28, 29, 30 [AV-29W83/VT]

27 GG20027-008B-H DOOR [AV-29W83/BK] 27 GG20027-005B-H DOOR [AV-29W93/BK, AV-29W93B/BK] 27 GG20027-007B-H DOOR [AV-29W83B/VT, AV-29W83/VT] 28 CM48229-00A-C DOOR LATCH 29 GG30048-001B-H POWER KNOB 30 CM35235-003-H SPRING

AV-29W83/BK AV-29W93/BK AV-29W93B/BK

AV-29W83B/VT AV-29W83/VT

1

EXPLODED VIEW-1

26

22

28

25

23

24

27

30

29

No. 52070 43

AV-29W83 AV-29W93B AV-29W93 AV-29W83B

EXPLODED VIEW PARTS LIST-

!

Ref.No. Part No. Part Name Description Local

! V01 A68QCU257X PICTURE TUBE [AV-29W83/BK, AV-29W93/BK, AV-29W93B/BK] ! V01 A68QCU257X75K PICTURE TUBE (ITC) Inc. DEF YOKE [AV-29W83B/VT, AV-29W83/VT] ! L01 QQW0150-001 DEG COIL

DY01 QQD0057-001 DEFLECTION YOKE [AV-29W83/BK, AV-29W93/BK, AV-29W93B/BK]

! T1551 QQH0139-001 FBT Not including ANODE WIRE ASS’Y

1 LC11061-001A-H CHASSIS BASE 2LC11062-001D-H CONTROL BASE 3 LC11064-002A-H AV TERMINAL BOARD [AV-29W83/BK, AV-29W93/BK, AV-29W83/VT]

3 LC11064-005A-H AV TERMINAL BOARD [AV-29W93B/BK, AV-29W83B/VT] 4 QYSBSF3012M TAPPING SCREW (X4) 5 CHFD125-18BD FFC WIRE

! 6 QMPR420-165-K2 POWER CORD [AV-29W83/BK, AV-29W93/BK, AV-29W93B/BK] ! 6 QMPR400-200-JC POWER CORD [AV-29W83B/VT, AV-29W83/VT] ! 7 CM23167-A01-H POWER CORD CLAMP

8 LC30103-001B-H CHASSIS ADAPTER (X2) 9 GG20023-001B-H SP HOLDER (X4)

10 LC40226-003A-H SPACER (X4) 11 LC40317-002A-H TAPPING SCREW (X4) 12 QAS0114-001 SPEAKER (X2) 13 WJY0018-001A BRAIDED ASS’Y 14 CHGB0017-0C BRAIDED ASS’Y (SUB) (X2) 15 A48457-3-H SPRING 16 CE42568-00A PC MAGNET

! 17 GG10192-001B-H REAR COVER [AV-29W83/BK, AV-29W93/BK]

! 17 GG10192-004B-H REAR COVER [AV-29W93B ! 17 GG10192-003B-HK REAR COVER [AV-29W83B/VT] ! 17 GG10192-002B-HK REAR COVER [AV-29W83/VT]

18 QYSBSFG4016Z TAPPING SCREW (X16)

! 19 GG20024-001B-H RATING LABEL [AV-29W83/BK, AV-29W93/BK, AV-29W93B/BK] ! 19 GG20016-023A-E RATING LABEL [AV-29W83B/VT] ! 19 GG20016-022A-E RATING LABEL [AV-29W83/VT] ! 20 QNZ0369-001 ANODE WIRE ASS’Y

21 CE40764-00A WEDGE ASS’Y (X4)

2

/BK]

44 No. 52070

EXPLODED VIEW-2

AV-29W83 AV-29W93B AV-29W93 AV-29W83B

20

9

12

FRONT CABINET

9

V01

21

DY01

16

8

10

9

8

FRONT CONTROL PWB (1/2)

11

2

12

9

CRT SOCKET PWB

5

10

11

10

FRONT CONTROL PWB (2/2)

MAIN PWB

T1551

3

17

10

TWIN PORT BASS BLASTER UNIT (For AV-29W93B

/BK

, AV-29W83B

18

19

1

(For AV-29W93B AV-29W83B

/VT

only)

13

/VT

/BK

only)

,

7

6

14

4

15

!

L01

No. 52070 45

AV-29W93B AV-29W83B

EXPLODED VIEW PARTS LIST-3 [AV-29W93B

!

Ref.No. Part No. Part Name Description Local

31 GG10140-001C-H BASS TOP COVER [AV-29W93B/BK] 31 GG10140-001C-HK BASS TOP COVER [AV-29W83B/VT] 32 GG10141-001C-H BASS BOTTOM COVER [AV-29W83B/BK] 32 GG10141-001C-HK BASS BOTTOM COVER [AV-29W83B/VT] 33 QYSBSFG4016Z TAPPING SCREW (X13) 34 GG20007-001C-H BASS INT.DUCT R (X2) 35 GG20007-002C-H BASS INT.DUCT L (X2) 36 QYSBSFG4016Z TAPPING SCREW (X6)

37 GG30022-001A-H BASS DUCT R (X2) 38 LC40352-001A-H RUBBER SHEET (X4) 39 QAS0118-001 BASS SPEAKER 40 QYSBSFG4016Z TAPPING SCREW (X4) 41 LC41211-001A SOUND ABSORBER 42 GG40028-001A-H SEAL LABEL [AV-29W93B/BK]

/BK, AV-29W83B/VT]

EXPLODED VIEW-3 [AV-29W93B/BK ,AV-29W83B/VT]

38

33

38

33

37

36

34

35

41

40

39

42

40

35

32

36

37

34

31

46 No. 52070

AV-29W83

PRINTED WIRING BOARD PARTS LIST [AV-29W83/BK]

MAIN PW BOARD ASS’Y(SCH-1118A-BK)

! Symbol No. Part No. Part Name Description Local ! Symbol No. Part No. Part Name Description Local

RESISTOR

R1001 NRSA63J-221X MG R 220¸ 1/16W J R1002 NRSA63J-221X MG R 220¸ 1/16W J R1003 NRSA63J-392X MG R 3.9k¸ 1/16W J R1004 NRSA63J-221X MG R 220¸ 1/16W J R1005 NRSA63J-273X MG R 27k¸ 1/16W J R1006 NRSA63J-750X MG R 75¸ 1/16W J R1101 NRSA63J-100X MG R 10¸ 1/16W J R1102 NRSA63J-682X MG R 6.8k¸ 1/16W J

R1103 NRSA63J-272X MG R 2.7k¸ 1/16W J R1104 NRSA63J-181X MG R 180¸ 1/16W J R1105 NRSA63J-220X MG R 22¸ 1/16W J R1106 NRSA63J-101X MG R 100¸ 1/16W J R1107 NRSA63J-472X MG R 4.7k¸ 1/16W J R1108 NRSA63J-222X MG R 2.2k¸ 1/16W J R1109 NRSA63J-222X MG R 2.2k¸ 1/16W J R1111 NRSA63J-102X MG R 1k¸ 1/16W J

R1113 NRSA63J-102X MG R 1k¸ 1/16W J R1130 NRSA63J-472X MG R 4.7k¸ 1/16W J R1131 NRSA63J-471X MG R 470¸ 1/16W J R1132 NRSA63J-222X MG R 2.2k¸ 1/16W J R1133 NRSA63J-152X MG R 1.5k¸ 1/16W J R1134 NRSA63J-182X MG R 1.8k¸ 1/16W J R1135 NRSA63J-561X MG R 560¸ 1/16W J R1136 NRSA63J-472X MG R 4.7k¸ 1/16W J

R1137 NRSA63J-103X MG R 10k¸ 1/16W J R1138 NRSA63J-471X MG R 470¸ 1/16W J R1139 NRSA63J-222X MG R 2.2k¸ 1/16W J R1140 NRSA63J-152X MG R 1.5k¸ 1/16W J R1141 NRSA63J-182X MG R 1.8k¸ 1/16W J R1142 NRSA63J-561X MG R 560¸ 1/16W J R1143 NRSA63J-471X MG R 470¸ 1/16W J R1144 NRSA63J-220X MG R 22¸ 1/16W J

R1145 NRSA63J-821X MG R 820¸ 1/16W J R1146 NRSA63J-103X MG R 10k¸ 1/16W J R1147 NRSA63J-101X MG R 100¸ 1/16W J R1148 NRSA63J-332X MG R 3.3k¸ 1/16W J R1301 NRSA63J-222X MG R 2.2k¸ 1/16W J R1302 NRSA63J-222X MG R 2.2k¸ 1/16W J R1303 NRSA63J-562X MG R 5.6k¸ 1/16W J R1304 NRSA63J-222X MG R 2.2k¸ 1/16W J

R1305 NRSA63J-222X MG R 2.2k¸ 1/16W J R1306 NRSA63J-562X MG R 5.6k¸ 1/16W J R1307 NRSA63J-103X MG R 10k¸ 1/16W J R1308 NRSA63J-101X MG R 100¸ 1/16W J R1309 NRSA63J-473X MG R 47k¸ 1/16W J R1310 NRSA63J-473X MG R 47k¸ 1/16W J R1311 NRSA63J-123X MG R 12k¸ 1/16W J R1317 QRL029J-101 OM R 100¸ 2W J

R1401 NRSA63J-123X MG R 12k¸ 1/16W J R1403 NRSA63J-0R0X MG R 0.0¸ 1/16W J R1405 NRSA63J-682X MG R 6.8k¸ 1/16W J R1406 NRSA63J-472X MG R 4.7k¸ 1/16W J R1408 NRSA63J-682X MG R 6.8k¸ 1/16W J R1410 NRSA63J-472X MG R 4.7k¸ 1/16W J R1411 QRG01GJ-221 OM R 220¸ 1W J R1412 QRE121J-1R0Y C R 1¸ 1/2W J

R1413 QRX01GJ-1R2 MF R 1.2¸ 1W J R1414 QRE121J-2R2Y C R 2.2¸ 1/2W J R1425 NRSA63J-153X MG R 15k¸ 1/16W J R1478 NRSA63J-101X MG R 100¸ 1/16W J R1479 NRSA63J-101X MG R 100¸ 1/16W J R1480 QRE121J-681Y C R 680¸ 1/2W J R1481 NRSA63J-223X MG R 22k¸ 1/16W J R1482 NRSA63J-562X MG R 5.6k¸ 1/16W J

R1483 NRSA63J-823X MG R 82k¸ 1/16W J R1484 NRSA63J-562X MG R 5.6k¸ 1/16W J R1485 NRSA63J-123X MG R 12k¸ 1/16W J R1486 NRSA63J-272X MG R 2.7k¸ 1/16W J R1487 NRSA63J-333X MG R 33k¸ 1/16W J R1489 NRSA63J-122X MG R 1.2k¸ 1/16W J R1490 NRSA63J-102X MG R 1k¸ 1/16W J R1491 NRSA63J-562X MG R 5.6k¸ 1/16W J

RESISTOR

R1492 NRSA63J-822X MG R 8.2k¸ 1/16W J R1493 QRE121J-223Y C R 22k¸ 1/2W J R1494 QRL039J-330 OM R 33¸ 3W J R1521 NRSA63J-101X MG R 100¸ 1/16W J R1522 NRSA63J-102X MG R 1k¸ 1/16W J R1523 QRL039J-151 OM R 150¸ 3W J R1524 QRL039J-151 OM R 150¸ 3W J R1526 QRL029J-271 OM R 270¸ 2W J

R1527 QRL039J-103 OM R 10k¸ 3W J

! R1528 QRZ9021-1R0 F R 1¸ 1W J ! R1529 QRZ9021-1R0 F R 1¸ 1W J

R1531 NRSA63J-182X MG R 1.8k¸ 1/16W J

! R1532 QRZ9017-4R7 F R 4.7¸ 1/4W J

R1541 QRE121J-124Y C R 120k¸ 1/2W J R1542 QRE121J-124Y C R 120k¸ 1/2W J R1543 QRE121J-471Y C R 470¸ 1/2W J

R1545 QRE121J-220Y C R 22¸ 1/2W J R1546 QRE121J-822Y C R 8.2k¸ 1/2W J

! R1547 QRZ9011-4R7 F R 4.7¸ 1/2W J

R1561 QRL029J-220 OM R 22¸ 2W J R1562 QRE121J-123Y C R 12k¸ 1/2W J R1563 QRZ0056-103Z COMP. R 10k¸ 1/2W K R1591 QRA14CF-1202Y CMF R 12k¸ 1/4W F R1592 QRZ0225-2R2 UNF R 2.2¸ 2W

R1593 NRSA02F-332X MG R 3.3k¸ 1/10W F R1594 QRE121J-183Y C R 18k¸ 1/2W J R1595 NRSA63J-222X MG R 2.2k¸ 1/16W J R1621 NRSA63J-0R0X MG R 0.0¸ 1/16W J R1622 NRSA63J-0R0X MG R 0.0¸ 1/16W J R1623 NRSA63J-473X MG R 47k¸ 1/16W J R1624 NRSA63J-101X MG R 100¸ 1/16W J R1625 NRSA63J-101X MG R 100¸ 1/16W J

R1627 NRSA63J-102X MG R 1k¸ 1/16W J R1628 NRSA63J-103X MG R 10k¸ 1/16W J R1629 NRSA63J-102X MG R 1k¸ 1/16W J R1630 NRSA63J-102X MG R 1k¸ 1/16W J R1650 NRSA63J-103X MG R 10k¸ 1/16W J R1651 NRSA63J-103X MG R 10k¸ 1/16W J R1652 NRSA63J-103X MG R 10k¸ 1/16W J R1653 NRSA63J-104X MG R 100k¸ 1/16W J

R1654 NRSA63J-103X MG R 10k¸ 1/16W J R1655 NRSA63J-104X MG R 100k¸ 1/16W J R1656 QRE121J-2R2Y C R 2.2¸ 1/2W J R1657 QRE121J-2R2Y C R 2.2¸ 1/2W J R1660 NRSA63J-103X MG R 10k¸ 1/16W J R1661 NRSA63J-683X MG R 68k¸ 1/16W J R1662 NRSA63J-333X MG R 33k¸ 1/16W J R1663 NRSA63J-103X MG R 10k¸ 1/16W J

R1664 NRSA63J-222X MG R 2.2k¸ 1/16W J R1688 NRSA63J-273X MG R 27k¸ 1/16W J R1690 NRSA63J-104X MG R 100k¸ 1/16W J R1691 NRSA63J-102X MG R 1k¸ 1/16W J R1695 NRSA63J-153X MG R 15k¸ 1/16W J R1696 NRSA63J-0R0X MG R 0.0¸ 1/16W J R1701 NRSA63J-101X MG R 100¸ 1/16W J R1702 NRSA63J-101X MG R 100¸ 1/16W J

R1703 NRSA63J-101X MG R 100¸ 1/16W J R1704 NRSA63J-102X MG R 1k¸ 1/16W J R1705 NRSA63J-102X MG R 1k¸ 1/16W J R1706 NRSA63J-102X MG R 1k¸ 1/16W J R1707 NRSA63J-472X MG R 4.7k¸ 1/16W J R1708 NRSA63J-472X MG R 4.7k¸ 1/16W J R1709 NRSA63J-472X MG R 4.7k¸ 1/16W J R1710 NRSA63J-472X MG R 4.7k¸ 1/16W J

R1711 NRSA63J-101X MG R 100¸ 1/16W J R1712 NRSA63J-101X MG R 100¸ 1/16W J R1713 NRSA63J-101X MG R 100¸ 1/16W J R1714 NRSA63J-101X MG R 100¸ 1/16W J R1715 NRSA63J-101X MG R 100¸ 1/16W J R1716 NRSA63J-103X MG R 10k¸ 1/16W J R1717 NRSA63J-103X MG R 10k¸ 1/16W J R1718 NRSA63J-221X MG R 220¸ 1/16W J

AV-29W83

No. 52070 47

AV-29W83

! Symbol No. Part No. Part Name Description Local ! Symbol No. Part No. Part Name Description Local

RESISTOR

R1719 NRSA63J-221X MG R 220¸ 1/16W J R1720 NRSA63J-102X MG R 1k¸ 1/16W J R1721 NRSA63J-221X MG R 220¸ 1/16W J R1722 NRSA63J-221X MG R 220¸ 1/16W J R1723 NRSA63J-221X MG R 220¸ 1/16W J R1724 NRSA63J-221X MG R 220¸ 1/16W J R1725 NRSA63J-103X MG R 10k¸ 1/16W J R1726 NRSA63J-472X MG R 4.7k¸ 1/16W J

R1727 NRSA63J-104X MG R 100k¸ 1/16W J R1728 NRSA63J-103X MG R 10k¸ 1/16W J R1730 NRSA63J-223X MG R 22k¸ 1/16W J R1731 NRSA63J-101X MG R 100¸ 1/16W J R1732 NRSA02F-393X MG R 39k¸ 1/10W F R1733 NRSA63J-273X MG R 27k¸ 1/16W J R1734 NRSA63J-391X MG R 390¸ 1/16W J R1735 NRSA63J-104X MG R 100k¸ 1/16W J

R1736 NRSA63J-333X MG R 33k¸ 1/16W J R1737 NRSA63J-272X MG R 2.7k¸ 1/16W J R1738 NRSA63J-103X MG R 10k¸ 1/16W J R1739 NRSA63J-101X MG R 100¸ 1/16W J R1740 NRSA63J-101X MG R 100¸ 1/16W J R1741 NRSA63J-101X MG R 100¸ 1/16W J R1742 NRSA63J-0R0X MG R 0.0¸ 1/16W J R1744 NRSA63J-561X MG R 560¸ 1/16W J

R1745 NRSA63J-105X MG R 1M¸ 1/16W J R1746 NRSA63J-333X MG R 33k¸ 1/16W J R1747 NRSA63J-103X MG R 10k¸ 1/16W J R1748 NRSA02J-225X MG R 2.2M¸ 1/10W J R1749 NRSA02J-185X MG R 1.8M¸ 1/10W J R1750 NRSA63J-0R0X MG R 0.0¸ 1/16W J R1755 NRSA63J-101X MG R 100¸ 1/16W J R1756 NRSA63J-101X MG R 100¸ 1/16W J

R1757 NRSA63J-222X MG R 2.2k¸ 1/16W J R1758 NRSA63J-222X MG R 2.2k¸ 1/16W J R1790 NRSA63J-270X MG R 27¸ 1/16W J R1803 NRSA63J-333X MG R 33k¸ 1/16W J R1804 NRSA63J-750X MG R 75¸ 1/16W J R1805 NRSA63J-750X MG R 75¸ 1/16W J R1806 NRSA63J-750X MG R 75¸ 1/16W J R1807 NRSA63J-750X MG R 75¸ 1/16W J

R1808 NRSA63J-823X MG R 82k¸ 1/16W J R1809 NRSA63J-391X MG R 390¸ 1/16W J R1810 NRSA63J-823X MG R 82k¸ 1/16W J R1811 NRSA63J-391X MG R 390¸ 1/16W J R1812 NRSA63J-104X MG R 100k¸ 1/16W J R1813 NRSA63J-222X MG R 2.2k¸ 1/16W J R1815 NRSA63J-101X MG R 100¸ 1/16W J R1818 NRSA63J-222X MG R 2.2k¸ 1/16W J

R1820 NRSA63J-101X MG R 100¸ 1/16W J R1821 NRSA63J-222X MG R 2.2k¸ 1/16W J R1823 NRSA63J-101X MG R 100¸ 1/16W J R1824 NRSA63J-222X MG R 2.2k¸ 1/16W J R1826 NRSA63J-101X MG R 100¸ 1/16W J R1829 NRSA63J-750X MG R 75¸ 1/16W J R1830 NRSA63J-222X MG R 2.2k¸ 1/16W J R1831 NRSA63J-222X MG R 2.2k¸ 1/16W J

R1832 NRSA63J-391X MG R 390¸ 1/16W J R1833 NRSA63J-271X MG R 270¸ 1/16W J R1834 NRSA63J-562X MG R 5.6k¸ 1/16W J R1835 NRSA63J-562X MG R 5.6k¸ 1/16W J R1836 NRSA63J-750X MG R 75¸ 1/16W J R1837 NRSA63J-101X MG R 100¸ 1/16W J R1838 QRK126J-121X UNF R 120¸ 1/2W J R1839 QRE121J-221Y C R 220¸ 1/2W J

R1840 QRE121J-221Y C R 220¸ 1/2W J R1841 NRSA63J-0R0X MG R 0.0¸ 1/16W J R1842 NRSA63J-0R0X MG R 0.0¸ 1/16W J R1843 NRSA63J-821X MG R 820¸ 1/16W J R1844 NRSA63J-222X MG R 2.2k¸ 1/16W J R1845 NRSA63J-102X MG R 1k¸ 1/16W J R1846 NRSA63J-222X MG R 2.2k¸ 1/16W J R1847 NRSA63J-103X MG R 10k¸ 1/16W J

RESISTOR

R1848 NRSA63J-221X MG R 220¸ 1/16W J R1849 NRSA63J-471X MG R 470¸ 1/16W J R1850 QRE141J-0R0Y C R 0.0¸ 1/4W J R1880 NRSA63J-202X MG R 2k¸ 1/16W J R1881 NRSA63J-103X MG R 10k¸ 1/16W J R1882 NRSA63J-181X MG R 180¸ 1/16W J R1883 NRSA63J-471X MG R 470¸ 1/16W J R1902 QRF154K-2R2 UNF R 2.2¸ 15W K

R1903 QRL039J-393 OM R 39k¸ 3W J R1904 QRE121J-221Y C R 220¸ 1/2W J R1905 QRM034J-R10 MP R 0.1¸ 3W J R1906 QRE141J-1R5Y C R 1.5¸ 1/4W J R1908 NRSA63J-103X MG R 10k¸ 1/16W J R1911 QRE121J-152Y C R 1.5k¸ 1/2W J R1912 QRE121J-123Y C R 12k¸ 1/2W J

! R1913 QRZ9017-100 F R 10¸ 1/4W J

R1914 QRL039J-473 OM R 47k¸ 3W J R1915 NRSA63J-823X MG R 82k¸ 1/16W J R1916 NRSA63J-154X MG R 150k¸ 1/16W J R1951 QRE121J-223Y C R 22k¸ 1/2W J R1952 NRSA63J-222X MG R 2.2k¸ 1/16W J R1953 QRE121J-152Y C R 1.5k¸ 1/2W J R1954 QRE121J-150Y C R 15¸ 1/2W J R1955 QRG01GJ-330 OM R 33¸ 1W J

R1956 QRE121J-120Y C R 12¸ 1/2W J R1957 QRE121J-5R6Y C R 5.6¸ 1/2W J R1958 QRL039J-820 OM R 82¸ 3W J R1959 QRE121J-820Y C R 82¸ 1/2W J R1960 NRSA63J-391X MG R 390¸ 1/16W J R1961 QRL029J-223 OM R 22k¸ 2W J R1962 NRSA63J-681X MG R 680¸ 1/16W J R1963 QRE121J-332Y C R 3.3k¸ 1/2W J

R1964 NRSA63J-103X MG R 10k¸ 1/16W J R1965 NRSA63J-0R0X MG R 0.0¸ 1/16W J R1966 NRSA63J-223X MG R 22k¸ 1/16W J R1967 NRSA63J-473X MG R 47k¸ 1/16W J R1968 NRSA63J-331X MG R 330¸ 1/16W J R1969 QRT029J-1R5 MF R 1.5¸ 2W J R1970 NRSA63J-153X MG R 15k¸ 1/16W J R1971 NRSA63J-183X MG R 18k¸ 1/16W J

R1972 QRE121J-182Y C R 1.8k¸ 1/2W J R1973 QRE121J-332Y C R 3.3k¸ 1/2W J R1974 QRT029J-1R2 MF R 1.2¸ 2W J

! R1991 QRZ0057-825 C R 8.2M¸ 1W J

CAPACITOR

C1001 NCB31HK-103X C CAP. 0.01µF 50V K C1002 QETN1HM-106Z E CAP. 10µF 50V M C1003 QFV71HJ-104Z MF CAP. 0.1µF 50V J C1004 QETN1CM-477Z E CAP. 470µF 16V M C1005 NCB31HK-222X C CAP. 2200pF 50V K C1006 QETN1CM-336Z E CAP. 33µF 16V M C1007 NCB31HK-103X C CAP. 0.01µF 50V K C1101 NCB31HK-472X C CAP. 4700pF 50V K

C1102 NCB31HK-472X C CAP. 4700pF 50V K C1103 NCB31HK-472X C CAP. 4700pF 50V K C1104 NCB31HK-472X C CAP. 4700pF 50V K C1105 NCB31HK-472X C CAP. 4700pF 50V K C1106 NDC31HJ-180X C CAP. 18pF 50V J C1107 NCB31HK-103X C CAP. 0.01µF 50V K C1109 QETN1HM-106Z E CAP. 10µF 50V M C1130 NCB31HK-103X C CAP. 0.01µF 50V K

C1131 NCB31HK-103X C CAP. 0.01µF 50V K C1132 NCB31HK-103X C CAP. 0.01µF 50V K C1133 QETN1CM-107Z E CAP. 100µF 16V M C1134 NCB31HK-103X C CAP. 0.01µF 50V K C1135 QETN1EM-476Z E CAP. 47µF 25V M C1136 NCB31HK-103X C CAP. 0.01µF 50V K C1137 NCB31HK-103X C CAP. 0.01µF 50V K C1138 NCB31HK-103X C CAP. 0.01µF 50V K

48 No. 52070

AV-29W83

! Symbol No. Part No. Part Name Description Local ! Symbol No. Part No. Part Name Description Local

CAPACITOR

C1140 NCB31HK-103X C CAP. 0.01µF 50V K C1141 NCB31HK-103X C CAP. 0.01µF 50V K C1142 NCB31HK-103X C CAP. 0.01µF 50V K C1143 QETN1HM-106Z E CAP. 10µF 50V M C1144 NCB31HK-223X C CAP. 0.022µF 50V K C1301 NCB31CK-104X C CAP. 0.1µF 16V K C1302 NCB31CK-104X C CAP. 0.1µF 16V K C1304 NCB31HK-103X C CAP. 0.01µF 50V K

C1305 NCB31HK-103X C CAP. 0.01µF 50V K C1306 NCB31CK-104X C CAP. 0.1µF 16V K C1307 NDC31HJ-330X C CAP. 33pF 50V J C1308 NCB31HK-103X C CAP. 0.01µF 50V K C1315 QFLC1HJ-473Z M CAP. 0.047µF 50V J C1401 QETN1HM-336Z E CAP. 33µF 50V M C1402 QCB31HK-682Z C CAP. 6800pF 50V K C1403 QEHR1VM-107Z E CAP. 100µF 35V M

C1406 QFLC2AJ-683Z M CAP. 0.068µF 100V J C1407 QCS32HJ-180Z C CAP. 18pF 500V J C1411 NCF21HZ-334X C CAP. 0.33µF 50V Z C1412 NCF21HZ-334X C CAP. 0.33µF 50V Z C1413 QFLC2AJ-563Z M CAP. 0.056µF 100V J C1422 QEHQ1VM-108 E CAP. 1000µF 35V M C1471 QETN1HM-106Z E CAP. 10µF 50V M C1480 QETN1HM-106Z E CAP. 10µF 50V M

C1483 QEZ0195-475Z BP E CAP. 4.7µF 50V M C1485 QETN1HM-226Z E CAP. 22µF 50V M C1521 QETN1VM-476Z E CAP. 47µF 35V M C1522 QFLC1HJ-332Z M CAP. 3300pF 50V J C1523 QFLC1HJ-223Z M CAP. 0.022µF 50V J C1524 QFZ0196-382 MPP CAP. 3800pF 1.5kVH±3% C1525 QFZ0200-143 MPP CAP. 0.014µF 1.5kVH±3% C1526 QFP32JJ-223 PP CAP. 0.022µF 630V J

C1527 QFZ0199-224 MPP CAP. 0.22µFAC250V J C1528 QFZ0199-224 MPP CAP. 0.22µFAC250V J C1529 QENC2AM-225Z BP E CAP. 2.2µF 100V M C1530 QCB32HK-561Z C CAP. 560pF 500V K C1531 QEHR1EM-108Z E CAP. 1000µF 25V M C1532 QCB32HK-561Z C CAP. 560pF 500V K C1533 QEHR1EM-108Z E CAP. 1000µF 25V M C1534 QCB32HK-561Z C CAP. 560pF 500V K

C1536 QFLC1HJ-103Z M CAP. 0.01µF 50V J C1540 QFV71HJ-104Z MF CAP. 0.1µF 50V J C1541 QETN2EM-106Z E CAP. 10µF 250V M C1550 NCB31CK-104X C CAP. 0.1µF 16V K C1561 QFV21HJ-154Z MF CAP. 0.15µF 50V J C1566 QFZ0200-113 MPP CAP. 0.011µF 1.5kVH±3% C1591 QETN1CM-107Z E CAP. 100µF 16V M C1592 QETM2CM-227 E CAP. 220µF 160V M

C1593 QETN1EM-476Z E CAP. 47µF 25V M C1625 NCF21EZ-474X C CAP. 0.47µF 25V Z C1626 NCB31HK-333X CH C CAP. 0.033µF 50V K C1627 NCB31HK-473X CH C CAP. 0.047µF 50V K C1628 NCB31HK-223X C CAP. 0.022µF 50V K C1629 NCB31HK-222X C CAP. 2200pF 50V K C1630 NCB31HK-104X C CAP. 0.1µF 50V K C1631 QETN1HM-475Z E CAP. 4.7µF 50V M

C1632 QETN1HM-475Z E CAP. 4.7µF 50V M C1633 QETN1HM-475Z E CAP. 4.7µF 50V M C1634 QETN1HM-475Z E CAP. 4.7µF 50V M C1635 QETN1HM-475Z E CAP. 4.7µF 50V M C1636 QETN1HM-475Z E CAP. 4.7µF 50V M C1637 QETN1HM-475Z E CAP. 4.7µF 50V M C1638 QETN1HM-475Z E CAP. 4.7µF 50V M C1639 QETN1HM-107Z E CAP. 100µF 50V M

C1640 NCF21HZ-334X C CAP. 0.33µF 50V Z C1641 QETN1HM-475Z E CAP. 4.7µF 50V M C1643 NCB31HK-104X C CAP. 0.1µF 50V K C1644 NCB31HK-222X C CAP. 2200pF 50V K C1645 NCB31HK-104X C CAP. 0.1µF 50V K C1646 NCB31HK-104X C CAP. 0.1µF 50V K C1647 NCF21EZ-474X C CAP. 0.47µF 25V Z C1648 NCB31HK-153X C CAP. 0.015µF 50V K

CAPACITOR

C1649 NCB31HK-153X C CAP. 0.015µF 50V K C1650 NCF31AZ-105X C CAP. 1µF 10V Z C1651 QEHR1HM-107Z E CAP. 100µF 50V M C1652 QETN1HM-105Z E CAP. 1µF 50V M C1653 NCF21HZ-224X C CAP. 0.22µF 50V Z C1654 NCF21HZ-224X C CAP. 0.22µF 50V Z C1655 NCF21HZ-224X C CAP. 0.22µF 50V Z C1656 NCF21HZ-224X C CAP. 0.22µF 50V Z

C1662 QETN1HM-106Z E CAP. 10µF 50V M C1681 QETN1CM-227Z E CAP. 220µF 16V M C1682 QETN1CM-227Z E CAP. 220µF 16V M C1683 QETN1CM-336Z E CAP. 33µF 16V M C1684 QETN1HM-106Z E CAP. 10µF 50V M C1702 QETN1HM-106Z E CAP. 10µF 50V M C1703 NDC31HJ-330X C CAP. 33pF 50V J C1704 NDC31HJ-330X C CAP. 33pF 50V J

C1706 NCB21EK-224X C CAP. 0.22µF 25V K C1707 QETN1CM-107Z E CAP. 100µF 16V M C1709 QETN1CM-477Z E CAP. 470µF 16V M C1710 NCB21EK-224X C CAP. 0.22µF 25V K C1711 NCB31CK-104X C CAP. 0.1µF 16V K C1712 QETN1CM-476Z E CAP. 47µF 16V M C1713 NCB31CK-104X C CAP. 0.1µF 16V K C1720 QETN1EM-476Z E CAP. 47µF 25V M

C1725 NCB31HK-681X C CAP. 680pF 50V K C1729 QETN1CM-476Z E CAP. 47µF 16V M C1730 NCB21EK-224X C CAP. 0.22µF 25V K C1731 NCB21EK-224X C CAP. 0.22µF 25V K C1732 QETN1CM-107Z E CAP. 100µF 16V M C1733 NCB31CK-104X C CAP. 0.1µF 16V K C1734 NCB31HK-222X C CAP. 2200pF 50V K C1735 NCB31HK-222X C CAP. 2200pF 50V K

C1736 QETN1HM-105Z E CAP. 1µF 50V M C1737 QETN1HM-105Z E CAP. 1µF 50V M C1738 NCB31CK-104X C CAP. 0.1µF 16V K C1739 NFV41CJ-104X MPP CAP. 0.1µF 16V J C1740 QETN1HM-225Z E CAP. 2.2µF 50V M C1741 NCB31CK-104X C CAP. 0.1µF 16V K C1742 NCB31CK-104X C CAP. 0.1µF 16V K C1743 QETN1CM-107Z E CAP. 100µF 16V M

C1744 NCB31HK-222X C CAP. 2200pF 50V K C1745 NCB31HK-473X CH C CAP. 0.047µF 50V K C1747 NCB31HK-473X CH C CAP. 0.047µF 50V K C1749 QETN1HM-106Z E CAP. 10µF 50V M C1751 NCB21HK-104X C CAP. 0.1µF 50V K C1752 NCB21HK-104X C CAP. 0.1µF 50V K C1753 NCB21HK-104X C CAP. 0.1µF 50V K C1801 QETN1HM-106Z E CAP. 10µF 50V M

C1802 QETN1HM-106Z E CAP. 10µF 50V M C1803 QETN1HM-106Z E CAP. 10µF 50V M C1804 QETN1HM-106Z E CAP. 10µF 50V M C1805 NCB31CK-104X C CAP. 0.1µF 16V K C1807 NCF31AZ-105X C CAP. 1µF 10V Z C1808 NCF31AZ-105X C CAP. 1µF 10V Z C1810 NCF31AZ-105X C CAP. 1µF 10V Z C1811 NCB31CK-104X C CAP. 0.1µF 16V K

C1812 NCF31AZ-105X C CAP. 1µF 10V Z C1813 NCB31HK-103X C CAP. 0.01µF 50V K C1814 NCB31CK-104X C CAP. 0.1µF 16V K C1815 NCF31AZ-105X C CAP. 1µF 10V Z C1817 NCF31AZ-105X C CAP. 1µF 10V Z C1819 NCB31CK-104X C CAP. 0.1µF 16V K C1820 NCF31AZ-105X C CAP. 1µF 10V Z C1821 NCF31AZ-105X C CAP. 1µF 10V Z

C1822 QETN1CM-477Z E CAP. 470µF 16V M C1823 QETN1CM-107Z E CAP. 100µF 16V M C1824 QETN1CM-107Z E CAP. 100µF 16V M C1825 NCB31HK-103X C CAP. 0.01µF 50V K C1826 NCB31CK-104X C CAP. 0.1µF 16V K C1827 NCB31HK-103X C CAP. 0.01µF 50V K C1829 NCB31HK-103X C CAP. 0.01µF 50V K C1830 NCB31HK-103X C CAP. 0.01µF 50V K

AV-29W83

No. 52070 49

AV-29W83

! Symbol No. Part No. Part Name Description Local ! Symbol No. Part No. Part Name Description Local

CAPACITOR

C1831 NCB31HK-103X C CAP. 0.01µF 50V K C1833 QETN1HM-226Z E CAP. 22µF 50V M C1834 NDC31HJ-181X C CAP. 180pF 50V J

! C1902 QFZ9072-104 MM CAP. 0.1µF

C1903 QCZ9015-102Z C CAP. 1000pF AC250V Z C1904 QCZ9015-102Z C CAP. 1000pF AC250V Z C1905 QCZ9015-102Z C CAP. 1000pF AC250V Z C1907 QEZ0371-337 E CAP. 330µF 400V M

C1909 QCZ0325-102 C CAP. 1000pF 2000V K C1910 NDC31HJ-102X C CAP. 1000pF 50V J C1911 QETN1VM-107Z E CAP. 100µF 35V M C1913 QFLC1HJ-683Z M CAP. 0.068µF 50V J C1915 QCB32HK-222Z C CAP. 2200pF 500V K C1916 QETN1HM-475Z E CAP. 4.7µF 50V M C1917 QCB32HK-181Z C CAP. 180pF 500V K C1918 QCB32HK-103 C CAP. 0.01µF 500V K

C1919 QCZ0325-391 C CAP. 390pF 2000V K C1920 QCZ0122-471 C CAP. 470pF 2000V K C1921 QFN31HJ-473Z M CAP. 0.047µF 50V J C1922 QETN2AM-226Z E CAP. 22µF 100V M C1952 QCB32HK-471Z C CAP. 470pF 500V K C1953 QEHQ1VM-228 E CAP. 2200µF 35V M C1955 QCB32HK-471Z C CAP. 470pF 500V K C1956 QETN1VM-107Z E CAP. 100µF 35V M

C1957 QCB31HK-471Z C CAP. 470pF 50V K C1958 QEHR1CM-108Z E CAP. 1000µF 16V M C1959 QCZ0364-561 C CAP. 560pF C1960 QEZ0203-227 E CAP. 220µF 160V M C1961 QETN1CM-476Z E CAP. 47µF 16V M C1962 QETN1HM-106Z E CAP. 10µF 50V M C1963 QETN1CM-477Z E CAP. 470µF 16V M C1964 QETN1EM-476Z E CAP. 47µF 25V M

C1965 QETN1VM-476Z E CAP. 47µF 35V M C1966 QETN1CM-107Z E CAP. 100µF 16V M C1968 NCB31CK-104X C CAP. 0.1µF 16V K C1970 QETN1CM-107Z E CAP. 100µF 16V M C1972 QETN1EM-476Z E CAP. 47µF 25V M C1974 NCB31CK-104X C CAP. 0.1µF 16V K C1975 QETN1CM-227Z E CAP. 220µF 16V M C1977 QETN1EM-476Z E CAP. 47µF 25V M

C1978 NCB21HK-104X C CAP. 0.1µF 50V K C1980 QETN1CM-107Z E CAP. 100µF 16V M C1981 NCB31HK-102X C CAP. 1000pF 50V K C1982 QETN1CM-476Z E CAP. 47µF 16V M C1983 QETN1CM-227Z E CAP. 220µF 16V M

! C1991 QCZ9079-102 C CAP. 1000pF AC250V M ! C1992 QCZ9079-102 C CAP. 1000pF AC250V M ! C1993 QCZ9079-102 C CAP. 1000pF AC250V M

TRANSFORMER

T1521 QQR1229-001 DRIVE TRANSF

! T1551 QQH0139-001 FBT(HV WIRELESS)

T1561 QQR1153-001 DEF TRANSF

! T1901 QQS0110-001 SW TRANSF

COIL

L1001 QQL244K-8R2Z COIL 8.2µHK L1002 QQL244K-8R2Z COIL 8.2µHK L1101 QQLZ014-R82 COIL 0.82µH L1301 QQL244K-221Z PEAKING COIL 220µHK L1401 QQL26AK-220Z COIL 22µHK L1480 QQR1138-001 CHOKE COIL L1523 QQR1243-001 LINEARITY COIL L1541 QQL244K-220Z COIL 22µHK

L1561 QQLZ028-272 COIL 2700µH L1701 QQL244K-100Z COIL 10µHK L1702 QQL244K-100Z COIL 10µHK L1731 QQL244J-101Z COIL 100µHJ L1951 QQLZ034-460 COIL 46µH L1953 QQL244J-5R6Z COIL 5.6µHJ L1954 QQL26AK-820Z COIL 82µHK

DIODE

D1101 DAN235K-X SI. DIODE D1401 RGP10J-5025-T3 SI. DIODE D1402 MTZJ75-T2 ZENER DIODE D1405 1N4003-T2 SI. DIODE D1408 MA111-X SI. DIODE D1480 MTZJ4.3A-T2 ZENER DIODE D1521 RH3G-F1 SI. DIODE D1522 31DF6N-FC5 SI. DIODE

D1523 RGP10J-5025-T3 SI. DIODE D1541 RGP10J-5025-T3 SI. DIODE D1550 MA111-X SI. DIODE D1551 EU2-T3 SI. DIODE D1553 RGP10J-5025-T3 SI. DIODE D1554 RGP10J-5025-T3 SI. DIODE D1592 MA3075/H/-X ZENER DIODE D1652 MA3330/L/-X ZENER DIODE

D1653 MA3330/L/-X ZENER DIODE D1655 MA111-X SI. DIODE D1657 MA111-X SI. DIODE D1701 MA111-X SI. DIODE D1702 MA3020-X ZENER DIODE D1703 MA3036-X ZENER DIODE D1730 MA111-X SI. DIODE D1731 MA111-X SI. DIODE

D1732 MA111-X SI. DIODE D1733 MA111-X SI. DIODE D1801 MA3120/M/-X ZENER DIODE D1802 MA3120/M/-X ZENER DIODE D1901 GSIB460 BRIDGE DIODE D1902 MTZJ33B-T2 ZENER DIODE D1906 MTZJ27B-T2 ZENER DIODE D1907 MTZJ33B-T2 ZENER DIODE

D1908 MA3200/M/-X ZENER DIODE D1909 1SS133-T2 SI. DIODE D1911 RGP10J-5025-T3 SI. DIODE D1912 RGP10J-5025-T3 SI. DIODE D1913 RGP10M-5010-T3 SI. DIODE D1914 NRSA63J-0R0X MG R 0.0¸ 1/16W J D1915 MTZJ39B-T2 ZENER DIODE D1916 MTZJ15B-T2 ZENER DIODE

D1917 1SS133-T2 SI. DIODE D1919 1SS133-T2 SI. DIODE D1920 MTZJ15B-T2 ZENER DIODE D1950 RGP10J-5025-T3 SI. DIODE D1952 ERC30-02L38 SI. DIODE D1953 RGP10J-5025-T3 SI. DIODE D1954 RU30A-F1 SI. DIODE D1955 1SR35-400A-T2 SI. DIODE

D1956 31DF6N-FC5 SI. DIODE D1958 MTZJ5.1A-T2 ZENER DIODE D1960 MA111-X SI. DIODE D1964 MA3330/L/-X ZENER DIODE D1966 MA3047/L/-X ZENER DIODE D1968 MA111-X SI. DIODE D1969 MA111-X SI. DIODE D1970 MTZJ9.1B-T2 ZENER DIODE

D1971 NRSA02J-0R0X MG R 0.0¸ 1/10W J

TRANSISTOR

Q1101 2SC5083/L-P/-T TRANSISTOR Q1102 UN2212-X DIGI. TRANSISTOR Q1104 2SB709A/QR/-X TRANSISTOR Q1105 2SD601A/QR/-X TRANSISTOR Q1130 2SB709A/QR/-X TRANSISTOR Q1131 UN2212-X DIGI. TRANSISTOR Q1132 2SD601A/QR/-X TRANSISTOR Q1133 2SB709A/QR/-X TRANSISTOR

50 No. 52070

AV-29W83

! Symbol No. Part No. Part Name Description Local ! Symbol No. Part No. Part Name Description Local

TRANSISTOR

Q1134 UN2212-X DIGI. TRANSISTOR Q1135 UN2212-X DIGI. TRANSISTOR Q1136 2SD601A/QR/-X TRANSISTOR Q1137 2SD601A/QR/-X TRANSISTOR Q1301 2SB709A/QR/-X TRANSISTOR Q1302 2SB709A/QR/-X TRANSISTOR Q1303 UN2212-X DIGI. TRANSISTOR Q1304 2SD601A/QR/-X TRANSISTOR

Q1480 2SD1408/OY/-LB POWER TRANSISTOR Q1521 2SC2655/Y/-T TRANSISTOR Q1522 2SD2634-YD POWER TRANSISTOR Q1591 2SA1208/ST/Z1-T TRANSISTOR Q1592 UN2212-X DIGI. TRANSISTOR Q1660 2SD601A/QR/-X TRANSISTOR Q1661 2SD601A/QR/-X TRANSISTOR Q1683 2SB709A/QR/-X TRANSISTOR

Q1684 2SB709A/QR/-X TRANSISTOR Q1685 DTC323TK-X DIGI. TRANSISTOR Q1686 DTC323TK-X DIGI. TRANSISTOR Q1701 2SB709A/QR/-X TRANSISTOR Q1702 2SB709A/QR/-X TRANSISTOR Q1720 2SB709A/QR/-X TRANSISTOR Q1801 DTC323TK-X DIGI. TRANSISTOR Q1802 DTC323TK-X DIGI. TRANSISTOR

Q1803 2SB709A/QR/-X TRANSISTOR Q1804 2SC1740S/QR/-T TRANSISTOR Q1860 2SD601A/QR/-X TRANSISTOR Q1861 2SB709A/QR/-X TRANSISTOR Q1862 2SB709A/QR/-X TRANSISTOR Q1901 2SC3852A POWER TRANSISTOR Q1951 2SA1013/RO/-T TRANSISTOR Q1952 2SD601A/QR/-X TRANSISTOR

Q1953 2SD601A/QR/-X TRANSISTOR Q1954 2SD601A/QR/-X TRANSISTOR Q1955 2SD601A/QR/-X TRANSISTOR

IC

IC1130 M52342SP I.C(MONO-ANA) IC1301 TDA9181T/N1-X I.C(MONO-ANA) IC1401 LA78041 I.C(MONO-ANA) IC1461 JLC1562BF-X I.C(MONO-ANA) IC1480 UPC358G2-XE I.C(MONOLITHIC) IC1602 NJW1136G-X I.C(MONO-ANA) IC1650 AN5277 I.C(MONO-ANA) IC1701 TDA9386N22S0902 IC(MCU)

IC1702 AT24C08-21WS3 I.C(MEMORY-OTH) (SERVICE) IC1801 MM1492AF I.C(MONO-ANA) IC1901 STR-F6256S-F7 I.C(HYBRID) IC1951 SE135N I.C(HYBRID) IC1972 L88M33T-X I.C(MONO-ANA) IC1973 BA17812T I.C(MONO-ANA) IC1974 BA51W12ST-V5 I.C(MONO-ANA)

OTHERS

CF1130 QAX0694-001Z C FILTER CF1131 QAX0694-001Z C FILTER CF1140 QAX0695-001Z C FILTER

! CP1951 ICP-N75-Y IC PROTECTOR ! CP1952 ICP-N38-Y IC PROTECTOR ! CP1953 ICP-N38-Y IC PROTECTOR

J1801 QNN0349-001 PIN JACK J1802 QNN0349-002 PIN JACK

J1803 QNN0348-001 PIN JACK J1804 QNN0349-001 PIN JACK K1705 QQR1214-001Y FERRITE BEADS K1901 QQR1214-001Y FERRITE BEADS K1902 QQR1214-001Y FERRITE BEADS K1903 QQR1214-001Y FERRITE BEADS K1951 QQR1214-001Y FERRITE BEADS K1953 QQR1214-001Y FERRITE BEADS

OTHERS

K1954 QQR1214-001Y FERRITE BEADS K1955 QQR1214-001Y FERRITE BEADS

! LF1901 QQR1356-001 LINE FILTER ! PC1901 PC123F2 IC(PHOTO COUPLE) ! RY1901 QSK0061-001 RELAY

SF1101 QAX0325-001 SAW FILTER SF1102 QAX0731-001 SAW FILTER TH1901 QAD0134-4R5 P THERMISTOR

TU1001 QAU0185-005 TUNER W1010 NRSA63J-0R0X MG R 0.0¸ 1/16W J W1031 NRSA63J-0R0X MG R 0.0¸ 1/16W J W1239 NRSA63J-0R0X MG R 0.0¸ 1/16W J W1257 NRSA63J-0R0X MG R 0.0¸ 1/16W J W1273 NRSA63J-0R0X MG R 0.0¸ 1/16W J W1306 NRSA63J-0R0X MG R 0.0¸ 1/16W J W1307 NRSA63J-0R0X MG R 0.0¸ 1/16W J

W1309 NRSA63J-0R0X MG R 0.0¸ 1/16W J W1321 NRSA63J-0R0X MG R 0.0¸ 1/16W J W1325 NRSA63J-0R0X MG R 0.0¸ 1/16W J W1326 NRSA63J-0R0X MG R 0.0¸ 1/16W J W1333 QQR1113-001Z FERRITE BEADS W1334 NRSA63J-0R0X MG R 0.0¸ 1/16W J W1379 NRSA63J-0R0X MG R 0.0¸ 1/16W J W1386 NRSA63J-0R0X MG R 0.0¸ 1/16W J

W1395 NRSA63J-0R0X MG R 0.0¸ 1/16W J W1397 NRSA63J-0R0X MG R 0.0¸ 1/16W J W1402 QQR1113-001Z FERRITE BEADS W1405 NRSA63J-0R0X MG R 0.0¸ 1/16W J W1418 NRSA63J-0R0X MG R 0.0¸ 1/16W J W1423 NRSA63J-0R0X MG R 0.0¸ 1/16W J W1428 NRSA63J-0R0X MG R 0.0¸ 1/16W J W1430 NRSA63J-0R0X MG R 0.0¸ 1/16W J

W1431 QQR1113-001Z FERRITE BEADS X1701 QAX0737-001 CRYSTAL Y1001 NRSA63J-0R0X MG R 0.0¸ 1/16W J Y1003 NRSA63J-0R0X MG R 0.0¸ 1/16W J Y1601 NRSA63J-0R0X MG R 0.0¸ 1/16W J Y1602 NRSA63J-0R0X MG R 0.0¸ 1/16W J Y1603 NRSA63J-0R0X MG R 0.0¸ 1/16W J

CRT SOCKET PW BOARD ASS’Y (SCH-3005A-BK)

! Symbol No. Part No. Part Name Description Local

RESISTOR

R3101 NRSA63J-682X MG R 6.8k¸ 1/16W J R3102 NRSA63J-102X MG R 1k¸ 1/16W J R3103 NRSA63J-153X MG R 15k¸ 1/16W J R3104 NRSA63J-682X MG R 6.8k¸ 1/16W J R3105 NRSA63J-102X MG R 1k¸ 1/16W J R3106 NRSA63J-272X MG R 2.7k¸ 1/16W J R3107 NRSA63J-682X MG R 6.8k¸ 1/16W J R3108 NRSA63J-102X MG R 1k¸ 1/16W J

R3109 NRSA63J-562X MG R 5.6k¸ 1/16W J R3110 NRSA63J-101X MG R 100¸ 1/16W J R3111 NRSA63J-101X MG R 100¸ 1/16W J R3112 NRSA63J-101X MG R 100¸ 1/16W J R3113 NRSA63J-563X MG R 56k¸ 1/16W J R3120 QRE121J-101Y C R 100¸ 1/2W J R3121 NRSA63J-101X MG R 100¸ 1/16W J R3122 NRSA63J-101X MG R 100¸ 1/16W J

R3123 QRE121J-152Y C R 1.5k¸ 1/2W J R3124 NRSA63J-221X MG R 220¸ 1/16W J R3125 NRSA63J-101X MG R 100¸ 1/16W J R3126 NRSA63J-101X MG R 100¸ 1/16W J R3127 QRE121J-152Y C R 1.5k¸ 1/2W J R3128 NRSA63J-221X MG R 220¸ 1/16W J R3129 NRSA63J-101X MG R 100¸ 1/16W J R3130 NRSA63J-101X MG R 100¸ 1/16W J

AV-29W83

No. 52070 51

AV-29W83

! Symbol No. Part No. Part Name Description Local ! Symbol No. Part No. Part Name Description Local

RESISTOR

R3131 QRE121J-152Y C R 1.5k¸ 1/2W J R3132 NRSA63J-221X MG R 220¸ 1/16W J R3133 NRSA63J-470X MG R 47¸ 1/16W J R3136 NRSA63J-470X MG R 47¸ 1/16W J R3137 NRSA63J-470X MG R 47¸ 1/16W J R3138 QRL029J-223 OM R 22k¸ 2W J R3139 QRL029J-223 OM R 22k¸ 2W J R3140 QRZ0107-102Z C R 1k¸ 1W K

R3141 QRL029J-223 OM R 22k¸ 2W J R3143 QRL029J-223 OM R 22k¸ 2W J R3144 QRZ0107-102Z C R 1k¸ 1W K R3145 QRL029J-223 OM R 22k¸ 2W J R3146 QRL029J-223 OM R 22k¸ 2W J R3147 QRZ0107-102Z C R 1k¸ 1W K R3148 QRE121J-124Y C R 120k¸ 1/2W J R3149 QRE121J-102Y C R 1k¸ 1/2W J

R3151 QRE121J-124Y C R 120k¸ 1/2W J R3152 QRE121J-102Y C R 1k¸ 1/2W J R3153 QRE121J-124Y C R 120k¸ 1/2W J R3154 QRE121J-102Y C R 1k¸ 1/2W J R3155 QRE121J-474Y C R 470k¸ 1/2W J R3157 QRZ0107-474Z C R 470k¸ 1W K R3159 NRSA63J-184X MG R 180k¸ 1/16W J R3161 QRE121J-333Y C R 33k¸ 1/2W J

R3164 QRE121J-560Y C R 56¸ 1/2W J R3166 QRE121J-333Y C R 33k¸ 1/2W J R3167 NRSA63J-222X MG R 2.2k¸ 1/16W J R3168 NRSA63J-103X MG R 10k¸ 1/16W J R3170 NRSA63J-332X MG R 3.3k¸ 1/16W J R3171 NRSA63J-681X MG R 680¸ 1/16W J R3172 NRSA63J-0R0X MG R 0.0¸ 1/16W J R3173 NRSA63J-0R0X MG R 0.0¸ 1/16W J

R3174 NRSA63J-0R0X MG R 0.0¸ 1/16W J R3211 NRSA63J-0R0X MG R 0.0¸ 1/16W J R3212 NRSA63J-153X MG R 15k¸ 1/16W J R3213 NRSA63J-222X MG R 2.2k¸ 1/16W J R3214 NRSA63J-152X MG R 1.5k¸ 1/16W J R3215 NRSA63J-680X MG R 68¸ 1/16W J R3216 NRSA63J-221X MG R 220¸ 1/16W J

! R3217 QRJ146J-100X UNF R 10¸ 1/4W J

R3221 NRSA63J-470X MG R 47¸ 1/16W J R3222 NRSA63J-470X MG R 47¸ 1/16W J R3224 NRSA63J-122X MG R 1.2k¸ 1/16W J R3225 QRE121J-563Y C R 56k¸ 1/2W J R3226 QRE121J-563Y C R 56k¸ 1/2W J R3227 NRSA63J-122X MG R 1.2k¸ 1/16W J R3228 NRSA63J-390X MG R 39¸ 1/16W J R3229 QRE121J-2R7Y C R 2.7¸ 1/2W J

R3230 QRE121J-2R7Y C R 2.7¸ 1/2W J R3231 NRSA63J-390X MG R 39¸ 1/16W J R3232 QRE121J-121Y C R 120¸ 1/2W J R3233 QRL029J-391 OM R 390¸ 2W J R3251 NDC31HJ-331X C CAP. 330pF 50V J R3252 NRSA63J-222X MG R 2.2k¸ 1/16W J R3253 NRSA63J-101X MG R 100¸ 1/16W J R3254 NRSA63J-563X MG R 56k¸ 1/16W J

R3255 NRSA63J-223X MG R 22k¸ 1/16W J R3256 NRSA63J-681X MG R 680¸ 1/16W J R3257 NRSA63J-102X MG R 1k¸ 1/16W J R3258 NRSA63J-182X MG R 1.8k¸ 1/16W J R3259 NRSA63J-102X MG R 1k¸ 1/16W J R3260 NRSA63J-271X MG R 270¸ 1/16W J R3261 NRSA63J-101X MG R 100¸ 1/16W J R3262 NRSA63J-101X MG R 100¸ 1/16W J

R3263 NRSA63J-101X MG R 100¸ 1/16W J R3264 NRSA63J-222X MG R 2.2k¸ 1/16W J R3265 NRSA63J-102X MG R 1k¸ 1/16W J R3266 NRSA63J-103X MG R 10k¸ 1/16W J R3267 NRSA63J-102X MG R 1k¸ 1/16W J R3268 NRSA63J-222X MG R 2.2k¸ 1/16W J R3269 NRSA63J-102X MG R 1k¸ 1/16W J R3270 NRSA63J-103X MG R 10k¸ 1/16W J

RESISTOR

R3271 NRSA63J-102X MG R 1k¸ 1/16W J R3272 NRSA63J-222X MG R 2.2k¸ 1/16W J R3273 NRSA63J-102X MG R 1k¸ 1/16W J R3274 NRSA63J-103X MG R 10k¸ 1/16W J R3275 NRSA63J-102X MG R 1k¸ 1/16W J

CAPACITOR

C3101 QETN1CM-477Z E CAP. 470µF 16V M C3107 QETM2EM-106 E CAP. 10µF 250V M C3108 QETM2EM-476 E CAP. 47µF 250V M C3110 QCZ0131-222 C CAP. 2200pF 2000V K C3114 QCS31HJ-151Z C CAP. 150pF 50V J C3115 QETN1CM-476Z E CAP. 47µF 16V M C3116 NDC31HJ-561X C CAP. 560pF 50V J C3117 NCB31HK-471X C CAP. 470pF 50V K

C3118 NCB31HK-471X C CAP. 470pF 50V K C3119 QFLC1HJ-104Z M CAP. 0.1µF 50V J C3120 QETN1HM-105Z E CAP. 1µF 50V M C3121 NCB31HK-102X C CAP. 1000pF 50V K C3204 NDC31HJ-561X C CAP. 560pF 50V J C3205 QETN1HM-335Z E CAP. 3.3µF 50V M C3206 QETN1HM-106Z E CAP. 10µF 50V M C3207 QCS31HJ-5R0Z C CAP. 5.0pF 50V J

C3209 QETN1CM-107Z E CAP. 100µF 16V M C3211 NDC31HJ-391X C CAP. 390pF 50V J C3212 QCB32HK-472Z C CAP. 4700pF 500V K C3213 NDC31HJ-561X C CAP. 560pF 50V J C3214 QETN2CM-106Z E CAP. 10µF 160V M C3215 QCB32HK-472Z C CAP. 4700pF 500V K C3216 QETN2CM-106Z E CAP. 10µF 160V M C3217 QETN1AM-107Z E CAP. 100µF 10V M

C3218 QETN1AM-107Z E CAP. 100µF 10V M C3219 QETN1AM-337Z E CAP. 330µF 10V M C3220 QCS32HJ-680Z C CAP. 68pF 500V J C3251 QENC1HM-105Z BP E CAP. 1µF 50V M C3252 NDC31HJ-151X C CAP. 150pF 50V J C3253 NDC31HJ-560X C CAP. 56pF 50V J C3255 NCB31HK-104X C CAP. 0.1µF 50V K C3261 NDC31HJ-820X C CAP. 82pF 50V J

C3262 NDC31HJ-820X C CAP. 82pF 50V J C3263 NDC31HJ-820X C CAP. 82pF 50V J C3264 QETN1AM-107Z E CAP. 100µF 10V M C3265 QETN1AM-107Z E CAP. 100µF 10V M C3266 QETN1AM-107Z E CAP. 100µF 10V M C3267 QETN1CM-227Z E CAP. 220µF 16V M

COIL

L3121 QQL244J-5R6Z COIL 5.6µHJ L3122 QQLZ034-220 COIL 22µH L3251 QQL244K-150Z COIL 15µHK

DIODE

D3107 MA111-X SI. DIODE D3108 MA3075/H/-X ZENER DIODE D3109 MA3051/H/-X ZENER DIODE D3110 MA111-X SI. DIODE D3111 MA3051/H/-X ZENER DIODE D3112 MA111-X SI. DIODE D3113 MA3051/H/-X ZENER DIODE D3114 MA111-X SI. DIODE

D3119 1SS244-T2 SI. DIODE D3120 1SS244-T2 SI. DIODE D3121 1SS244-T2 SI. DIODE D3122 1SS244-T2 SI. DIODE D3123 1SS244-T2 SI. DIODE D3124 1N4003-T2 SI. DIODE D3125 1N4003-T2 SI. DIODE D3126 1N4003-T2 SI. DIODE

52 No. 52070

AV-29W83

FRONT CONTROL PW BOARD ASS’Y(SCH-8004A-BK)

! Symbol No. Part No. Part Name Description Local ! Symbol No. Part No. Part Name Description Local

DIODE

D3127 MA111-X SI. DIODE D3131 MTZJ75-T2 ZENER DIODE D3132 MA3043-X ZENER DIODE D3134 1SS244-T2 SI. DIODE D3136 MA111-X SI. DIODE D3138 MA111-X SI. DIODE D3141 MTZJ30A-T2 ZENER DIODE D3142 MTZJ30A-T2 ZENER DIODE

D3143 MTZJ30A-T2 ZENER DIODE D3201 NRSA63J-0R0X MG R 0.0¸ 1/16W J D3202 NRSA63J-0R0X MG R 0.0¸ 1/16W J D3203 RGP10J-5025-T3 SI. DIODE D3204 RGP10J-5025-T3 SI. DIODE

TRANSISTOR

Q3101 2SD601A/QR/-X TRANSISTOR Q3102 2SD601A/QR/-X TRANSISTOR Q3103 2SD601A/QR/-X TRANSISTOR Q3104 2SD601A/QR/-X TRANSISTOR Q3105 2SD601A/QR/-X TRANSISTOR Q3106 2SD601A/QR/-X TRANSISTOR Q3121 2SC1740S/QR/-T TRANSISTOR Q3122 2SA933AS/QR/-T TRANSISTOR

Q3123 2SC4075/DE/YA11 POWER TRANSISTOR Q3124 2SC1740S/QR/-T TRANSISTOR Q3125 2SC4075/DE/YA11 POWER TRANSISTOR Q3126 2SC1740S/QR/-T TRANSISTOR Q3127 2SC4075/DE/YA11 POWER TRANSISTOR Q3128 2SC1740S/QR/-T TRANSISTOR Q3129 2SC3334-T TRANSISTOR Q3130 2SA1321-T TRANSISTOR

Q3131 2SC3334-T TRANSISTOR Q3132 2SA1321-T TRANSISTOR Q3133 2SC3334-T TRANSISTOR Q3134 2SA1321-T TRANSISTOR Q3135 2SB709A/QR/-X TRANSISTOR Q3204 2SC1740S/QR/-T TRANSISTOR Q3205 2SC1740S/QR/-T TRANSISTOR Q3206 2SA933AS/QR/-T TRANSISTOR

Q3209 2SA1837 POWER TRANSISTOR Q3210 2SC4793 POWER TRANSISTOR Q3251 2SB709A/QR/-X TRANSISTOR Q3252 2SD601A/QR/-X TRANSISTOR Q3253 2SB709A/QR/-X TRANSISTOR Q3261 2SB709A/QR/-X TRANSISTOR Q3262 2SB709A/QR/-X TRANSISTOR Q3263 2SB709A/QR/-X TRANSISTOR

Q3264 2SD601A/QR/-X TRANSISTOR Q3265 2SD601A/QR/-X TRANSISTOR Q3266 2SD601A/QR/-X TRANSISTOR

OTHERS

CL3001 QZW0027-004 WIRE CLAMP DL3261 CE41925-001 DELAY LINE DL3262 CE41925-001 DELAY LINE DL3263 CE41925-001 DELAY LINE

! FR3201 QRZ9021-561 F R 560¸ 1W J

K3201 CE41492-001Z CHOKE COIL K3202 CE41492-001Z CHOKE COIL K3203 CE41492-001Z CHOKE COIL

K3204 CE41492-001Z CHOKE COIL K3205 QQR1113-001Z FERRITE BEADS K3206 QQR1113-001Z FERRITE BEADS K3207 QQR1113-001Z FERRITE BEADS K3208 QQR1113-001Z FERRITE BEADS SG3101 QAF0056-501Z SURGE ABSORBER SG3102 QAF0056-501Z SURGE ABSORBER

! SK3001 CE42670-001 CRT SOCKET

W3034 NRSA63J-0R0X MG R 0.0¸ 1/16W J

RESISTOR

R8482 NRSA63J-124X MG R 120k¸ 1/16W J R8483 NRSA63J-683X MG R 68k¸ 1/16W J R8484 NRSA63J-562X MG R 5.6k¸ 1/16W J R8485 NRSA63J-562X MG R 5.6k¸ 1/16W J R8486 NRSA63J-333X MG R 33k¸ 1/16W J R8487 NRSA63J-332X MG R 3.3k¸ 1/16W J R8488 NRSA63J-154X MG R 150k¸ 1/16W J R8489 NRSA63J-104X MG R 100k¸ 1/16W J

R8491 NRSA63J-0R0X MG R 0.0¸ 1/16W J R8492 NRSA63J-0R0X MG R 0.0¸ 1/16W J R8495 NRSA63J-152X MG R 1.5k¸ 1/16W J R8497 NRSA63J-562X MG R 5.6k¸ 1/16W J R8499 QRE121J-561Y C R 560¸ 1/2W J R8801 NRSA63J-332X MG R 3.3k¸ 1/16W J R8802 NRSA63J-392X MG R 3.9k¸ 1/16W J R8803 NRSA63J-682X MG R 6.8k¸ 1/16W J

R8805 NRSA63J-682X MG R 6.8k¸ 1/16W J R8807 NRSA63J-181X MG R 180¸ 1/16W J R8808 NRSA63J-221X MG R 220¸ 1/16W J R8809 NRSA63J-331X MG R 330¸ 1/16W J R8810 NRSA63J-471X MG R 470¸ 1/16W J R8811 NRSA63J-821X MG R 820¸ 1/16W J R8812 NRSA63J-122X MG R 1.2k¸ 1/16W J R8813 NRSA63J-471X MG R 470¸ 1/16W J

R8815 QRE121J-271Y C R 270¸ 1/2W J R8816 QRE121J-271Y C R 270¸ 1/2W J R8817 NRSA63J-102X MG R 1k¸ 1/16W J R8818 NRSA63J-102X MG R 1k¸ 1/16W J R8819 NRSA63J-272X MG R 2.7k¸ 1/16W J R8826 NRSA63J-0R0X MG R 0.0¸ 1/16W J R8830 NRSA63J-222X MG R 2.2k¸ 1/16W J R8831 NRSA63J-222X MG R 2.2k¸ 1/16W J

! R8901 QRZ0111-474 C R 470k¸ 1W K

CAPACITOR

C8481 NCB21EK-224X C CAP. 0.22µF 25V K C8482 NCB21EK-224X C CAP. 0.22µF 25V K C8483 NCB21EK-224X C CAP. 0.22µF 25V K C8484 NCB21EK-224X C CAP. 0.22µF 25V K C8485 QETN1EM-476Z E CAP. 47µF 25V M C8487 QFLC1HJ-103Z M CAP. 0.01µF 50V J C8660 QETM1VM-108 E CAP. 1000µF 35V M C8661 QETM1VM-108 E CAP. 1000µF 35V M

C8801 QETN1HM-106Z E CAP. 10µF 50V M C8802 QETN1CM-107Z E CAP. 100µF 16V M C8803 NCB31CK-104X C CAP. 0.1µF 16V K C8815 QETN1CM-107Z E CAP. 100µF 16V M

! C8901 QFZ9072-224 MM CAP. 0.22µF

COIL

L8401 QQL244K-820Z COIL 82µHK

DIODE

D8801 MA111-X SI. DIODE D8802 P1241-04 PHOTO CONDUCTOR D8803 SLR-342VR-T16 LED

TRANSISTOR

Q8481 2SC2412K/QR/-X TRANSISTOR Q8801 2SA1037AK/QR/-X TRANSISTOR

IC

IC8481 LA6515 I.C IC8801 GP1UM281QK IR DETECT UNIT

AV-29W83

No. 52070 53

AV-29W83

! Symbol No. Part No. Part Name Description Local ! Symbol No. Part No. Part Name Description Local

OTHERS

CM35921-005-H CDS HOLDER

! F8901 QMF51E2-4R0J4 FUSE

FC8901 CEMG002-001Z FUSE CLIP J8302 QNN0279-003 PIN JACK J8303 QNN0279-002 PIN JACK J8304 QNN0279-001 PIN JACK J8801 QNS0155-001 3.5 JACK

! LF8901 QQR1356-001 LINE FILTER

S8801 QSW0619-003Z TACT SWITCH CH+ S8802 QSW0619-003Z TACT SWITCH CHS8803 QSW0619-003Z TACT SWITCH MENU S8804 QSW0619-003Z TACT SWITCH TV/VIDEO S8805 QSW0619-003Z TACT SWITCH VOL+ S8806 QSW0619-003Z TACT SWITCH VOL-

! S8901 QSW0750-001 PUSH SWITCH POWER

! VA8901 QAF0052-621 VARISTOR

Y8401 NRSA63J-0R0X MG R 0.0¸ 1/16W J

CM36626-B01-H LED HOLDER

REMOTE CONTROL UNIT PARTS LIST (RM-C1016-1H)

! Ref.No Part No. Part Name Description Local

25-1168F BATTERY COVER

54 No. 52070

AV-29W93

PRINTED WIRING BOARD PARTS LIST [AV-29W93/BK]

MAIN PW BOARD ASS’Y(SCH-1119A-BK)

! Symbol No. Part No. Part Name Description Local ! Symbol No. Part No. Part Name Description Local

RESISTOR

R1001 NRSA63J-221X MG R 220¸ 1/16W J R1002 NRSA63J-221X MG R 220¸ 1/16W J R1003 NRSA63J-392X MG R 3.9k¸ 1/16W J R1004 NRSA63J-221X MG R 220¸ 1/16W J R1005 NRSA63J-273X MG R 27k¸ 1/16W J R1006 NRSA63J-750X MG R 75¸ 1/16W J R1101 NRSA63J-100X MG R 10¸ 1/16W J R1102 NRSA63J-682X MG R 6.8k¸ 1/16W J

R1103 NRSA63J-272X MG R 2.7k¸ 1/16W J R1104 NRSA63J-181X MG R 180¸ 1/16W J R1105 NRSA63J-220X MG R 22¸ 1/16W J R1106 NRSA63J-101X MG R 100¸ 1/16W J R1107 NRSA63J-472X MG R 4.7k¸ 1/16W J R1108 NRSA63J-222X MG R 2.2k¸ 1/16W J R1109 NRSA63J-222X MG R 2.2k¸ 1/16W J R1110 NRSA63J-222X MG R 2.2k¸ 1/16W J

R1111 NRSA63J-102X MG R 1k¸ 1/16W J R1113 NRSA63J-102X MG R 1k¸ 1/16W J R1114 NRSA63J-102X MG R 1k¸ 1/16W J R1115 NRSA63J-471X MG R 470¸ 1/16W J R1117 NRSA63J-103X MG R 10k¸ 1/16W J R1150 NRSA63J-331X MG R 330¸ 1/16W J R1151 NRSA63J-222X MG R 2.2k¸ 1/16W J R1152 NRSA63J-121X MG R 120¸ 1/16W J

R1153 NRSA63J-122X MG R 1.2k¸ 1/16W J R1154 NRSA63J-181X MG R 180¸ 1/16W J R1301 NRSA63J-222X MG R 2.2k¸ 1/16W J R1302 NRSA63J-222X MG R 2.2k¸ 1/16W J R1303 NRSA63J-562X MG R 5.6k¸ 1/16W J R1304 NRSA63J-222X MG R 2.2k¸ 1/16W J R1305 NRSA63J-222X MG R 2.2k¸ 1/16W J R1306 NRSA63J-562X MG R 5.6k¸ 1/16W J

R1307 NRSA63J-103X MG R 10k¸ 1/16W J R1308 NRSA63J-101X MG R 100¸ 1/16W J R1309 NRSA63J-473X MG R 47k¸ 1/16W J R1310 NRSA63J-473X MG R 47k¸ 1/16W J R1311 NRSA63J-123X MG R 12k¸ 1/16W J R1317 QRL029J-101 OM R 100¸ 2W J R1401 NRSA63J-123X MG R 12k¸ 1/16W J R1403 NRSA63J-0R0X MG R 0.0¸ 1/16W J

R1405 NRSA63J-682X MG R 6.8k¸ 1/16W J R1406 NRSA63J-472X MG R 4.7k¸ 1/16W J R1408 NRSA63J-682X MG R 6.8k¸ 1/16W J R1410 NRSA63J-472X MG R 4.7k¸ 1/16W J R1411 QRG01GJ-221 OM R 220¸ 1W J R1412 QRE121J-1R0Y C R 1¸ 1/2W J R1413 QRX01GJ-1R2 MF R 1.2¸ 1W J R1414 QRE121J-2R2Y C R 2.2¸ 1/2W J

R1425 NRSA63J-153X MG R 15k¸ 1/16W J R1478 NRSA63J-101X MG R 100¸ 1/16W J R1479 NRSA63J-101X MG R 100¸ 1/16W J R1480 QRE121J-681Y C R 680¸ 1/2W J R1481 NRSA63J-223X MG R 22k¸ 1/16W J R1482 NRSA63J-562X MG R 5.6k¸ 1/16W J R1483 NRSA63J-823X MG R 82k¸ 1/16W J R1484 NRSA63J-562X MG R 5.6k¸ 1/16W J

R1485 NRSA63J-123X MG R 12k¸ 1/16W J R1486 NRSA63J-272X MG R 2.7k¸ 1/16W J R1487 NRSA63J-333X MG R 33k¸ 1/16W J R1489 NRSA63J-122X MG R 1.2k¸ 1/16W J R1490 NRSA63J-102X MG R 1k¸ 1/16W J R1491 NRSA63J-562X MG R 5.6k¸ 1/16W J R1492 NRSA63J-822X MG R 8.2k¸ 1/16W J R1493 QRE121J-223Y C R 22k¸ 1/2W J

R1494 QRL039J-330 OM R 33¸ 3W J R1521 NRSA63J-101X MG R 100¸ 1/16W J R1522 NRSA63J-102X MG R 1k¸ 1/16W J R1523 QRL039J-151 OM R 150¸ 3W J R1524 QRL039J-151 OM R 150¸ 3W J R1526 QRL029J-271 OM R 270¸ 2W J R1527 QRL039J-103 OM R 10k¸ 3W J

! R1528 QRZ9021J-1R0 F R 1¸ 1W J

RESISTOR

! R1529 QRZ9021J-1R0 F R 1¸ 1W J

R1531 NRSA63J-182X MG R 1.8k¸ 1/16W J

! R1532 QRZ9017-4R7 F R 4.7¸ 1/4W J

R1541 QRE121J-124Y C R 120k¸ 1/2W J R1542 QRE121J-124Y C R 120k¸ 1/2W J R1543 QRE121J-471Y C R 470¸ 1/2W J R1545 QRE121J-220Y C R 22¸ 1/2W J R1546 QRE121J-822Y C R 8.2k¸ 1/2W J

! R1547 QRZ9011J-4R7 F R 4.7¸ 1/2W J

R1561 QRL029J-220 OM R 22¸ 2W J R1562 QRE121J-123Y C R 12k¸ 1/2W J R1563 QRZ0056-103Z COMP. R 10k¸ 1/2W K R1591 QRA14CF-1202Y CMF R 12k¸ 1/4W F R1592 QRZ0225-2R2 UNF R 2.2¸ 2W R1593 NRSA02F-332X MG R 3.3k¸ 1/10W F R1594 QRE121J-183Y C R 18k¸ 1/2W J

R1595 NRSA63J-222X MG R 2.2k¸ 1/16W J R1602 NRSA63J-271X MG R 270¸ 1/16W J R1603 NRSA63J-101X MG R 100¸ 1/16W J R1604 NRSA63J-101X MG R 100¸ 1/16W J R1621 NRSA63J-0R0X MG R 0.0¸ 1/16W J R1622 NRSA63J-0R0X MG R 0.0¸ 1/16W J R1623 NRSA63J-473X MG R 47k¸ 1/16W J R1624 NRSA63J-101X MG R 100¸ 1/16W J

R1625 NRSA63J-101X MG R 100¸ 1/16W J R1627 NRSA63J-102X MG R 1k¸ 1/16W J R1628 NRSA63J-103X MG R 10k¸ 1/16W J R1629 NRSA63J-102X MG R 1k¸ 1/16W J R1630 NRSA63J-102X MG R 1k¸ 1/16W J R1650 NRSA63J-103X MG R 10k¸ 1/16W J R1651 NRSA63J-103X MG R 10k¸ 1/16W J R1652 NRSA63J-103X MG R 10k¸ 1/16W J

R1653 NRSA63J-104X MG R 100k¸ 1/16W J R1654 NRSA63J-103X MG R 10k¸ 1/16W J R1655 NRSA63J-104X MG R 100k¸ 1/16W J R1656 QRE121J-2R2Y C R 2.2¸ 1/2W J R1657 QRE121J-2R2Y C R 2.2¸ 1/2W J R1660 NRSA63J-103X MG R 10k¸ 1/16W J R1661 NRSA63J-683X MG R 68k¸ 1/16W J R1662 NRSA63J-333X MG R 33k¸ 1/16W J

R1663 NRSA63J-103X MG R 10k¸ 1/16W J R1664 NRSA63J-222X MG R 2.2k¸ 1/16W J R1688 NRSA63J-273X MG R 27k¸ 1/16W J R1690 NRSA63J-104X MG R 100k¸ 1/16W J R1691 NRSA63J-102X MG R 1k¸ 1/16W J R1695 NRSA63J-153X MG R 15k¸ 1/16W J R1696 NRSA63J-0R0X MG R 0.0¸ 1/16W J R1701 NRSA63J-101X MG R 100¸ 1/16W J

R1702 NRSA63J-101X MG R 100¸ 1/16W J R1703 NRSA63J-101X MG R 100¸ 1/16W J R1704 NRSA63J-102X MG R 1k¸ 1/16W J R1705 NRSA63J-102X MG R 1k¸ 1/16W J R1706 NRSA63J-102X MG R 1k¸ 1/16W J R1707 NRSA63J-472X MG R 4.7k¸ 1/16W J R1708 NRSA63J-472X MG R 4.7k¸ 1/16W J R1709 NRSA63J-472X MG R 4.7k¸ 1/16W J

R1710 NRSA63J-472X MG R 4.7k¸ 1/16W J R1711 NRSA63J-101X MG R 100¸ 1/16W J R1712 NRSA63J-101X MG R 100¸ 1/16W J R1713 NRSA63J-101X MG R 100¸ 1/16W J R1714 NRSA63J-101X MG R 100¸ 1/16W J R1715 NRSA63J-101X MG R 100¸ 1/16W J R1716 NRSA63J-103X MG R 10k¸ 1/16W J R1717 NRSA63J-103X MG R 10k¸ 1/16W J

R1718 NRSA63J-221X MG R 220¸ 1/16W J R1719 NRSA63J-221X MG R 220¸ 1/16W J R1720 NRSA63J-102X MG R 1k¸ 1/16W J R1721 NRSA63J-221X MG R 220¸ 1/16W J R1722 NRSA63J-221X MG R 220¸ 1/16W J R1723 NRSA63J-221X MG R 220¸ 1/16W J R1724 NRSA63J-221X MG R 220¸ 1/16W J R1725 NRSA63J-103X MG R 10k¸ 1/16W J

AV-29W93

No. 52070 55

AV-29W93

! Symbol No. Part No. Part Name Description Local ! Symbol No. Part No. Part Name Description Local

RESISTOR

R1726 NRSA63J-472X MG R 4.7k¸ 1/16W J R1727 NRSA63J-104X MG R 100k¸ 1/16W J R1728 NRSA63J-103X MG R 10k¸ 1/16W J R1730 NRSA63J-223X MG R 22k¸ 1/16W J R1731 NRSA63J-101X MG R 100¸ 1/16W J R1732 NRSA02F-393X MG R 39k¸ 1/10W F R1733 NRSA63J-273X MG R 27k¸ 1/16W J R1734 NRSA63J-391X MG R 390¸ 1/16W J

R1735 NRSA63J-104X MG R 100k¸ 1/16W J R1736 NRSA63J-333X MG R 33k¸ 1/16W J R1737 NRSA63J-272X MG R 2.7k¸ 1/16W J R1738 NRSA63J-103X MG R 10k¸ 1/16W J R1739 NRSA63J-101X MG R 100¸ 1/16W J R1740 NRSA63J-101X MG R 100¸ 1/16W J R1741 NRSA63J-101X MG R 100¸ 1/16W J R1742 NRSA63J-0R0X MG R 0.0¸ 1/16W J

R1744 NRSA63J-561X MG R 560¸ 1/16W J R1745 NRSA63J-105X MG R 1M¸ 1/16W J R1746 NRSA63J-333X MG R 33k¸ 1/16W J R1747 NRSA63J-103X MG R 10k¸ 1/16W J R1748 NRSA02J-225X MG R 2.2M¸ 1/10W J R1749 NRSA02J-185X MG R 1.8M¸ 1/10W J R1750 NRSA63J-0R0X MG R 0.0¸ 1/16W J R1755 NRSA63J-101X MG R 100¸ 1/16W J

R1756 NRSA63J-101X MG R 100¸ 1/16W J R1757 NRSA63J-222X MG R 2.2k¸ 1/16W J R1758 NRSA63J-222X MG R 2.2k¸ 1/16W J R1790 NRSA63J-270X MG R 27¸ 1/16W J R1803 NRSA63J-333X MG R 33k¸ 1/16W J R1804 NRSA63J-750X MG R 75¸ 1/16W J R1805 NRSA63J-750X MG R 75¸ 1/16W J R1806 NRSA63J-750X MG R 75¸ 1/16W J

R1807 NRSA63J-750X MG R 75¸ 1/16W J R1808 NRSA63J-823X MG R 82k¸ 1/16W J R1809 NRSA63J-391X MG R 390¸ 1/16W J R1810 NRSA63J-823X MG R 82k¸ 1/16W J R1811 NRSA63J-391X MG R 390¸ 1/16W J R1812 NRSA63J-104X MG R 100k¸ 1/16W J R1813 NRSA63J-222X MG R 2.2k¸ 1/16W J R1815 NRSA63J-101X MG R 100¸ 1/16W J

R1818 NRSA63J-222X MG R 2.2k¸ 1/16W J R1820 NRSA63J-101X MG R 100¸ 1/16W J R1821 NRSA63J-222X MG R 2.2k¸ 1/16W J R1823 NRSA63J-101X MG R 100¸ 1/16W J R1824 NRSA63J-222X MG R 2.2k¸ 1/16W J R1826 NRSA63J-101X MG R 100¸ 1/16W J R1829 NRSA63J-750X MG R 75¸ 1/16W J R1830 NRSA63J-222X MG R 2.2k¸ 1/16W J

R1831 NRSA63J-222X MG R 2.2k¸ 1/16W J R1832 NRSA63J-391X MG R 390¸ 1/16W J R1833 NRSA63J-271X MG R 270¸ 1/16W J R1834 NRSA63J-562X MG R 5.6k¸ 1/16W J R1835 NRSA63J-562X MG R 5.6k¸ 1/16W J R1836 NRSA63J-750X MG R 75¸ 1/16W J R1837 NRSA63J-101X MG R 100¸ 1/16W J R1838 QRK126J-121X UNF R 120¸ 1/2W J

R1839 QRE121J-221Y C R 220¸ 1/2W J R1840 QRE121J-221Y C R 220¸ 1/2W J R1841 NRSA63J-0R0X MG R 0.0¸ 1/16W J R1842 NRSA63J-0R0X MG R 0.0¸ 1/16W J R1843 NRSA63J-821X MG R 820¸ 1/16W J R1844 NRSA63J-222X MG R 2.2k¸ 1/16W J R1845 NRSA63J-102X MG R 1k¸ 1/16W J R1846 NRSA63J-222X MG R 2.2k¸ 1/16W J

R1847 NRSA63J-103X MG R 10k¸ 1/16W J R1848 NRSA63J-221X MG R 220¸ 1/16W J R1849 NRSA63J-471X MG R 470¸ 1/16W J R1850 QRE141J-0R0Y C R 0.0¸ 1/4W J R1880 NRSA63J-202X MG R 2k¸ 1/16W J R1881 NRSA63J-103X MG R 10k¸ 1/16W J R1882 NRSA63J-181X MG R 180¸ 1/16W J R1883 NRSA63J-471X MG R 470¸ 1/16W J

RESISTOR

R1902 QRF154K-2R2 UNF R 2.2¸ 15W K R1903 QRL039J-393 OM R 39k¸ 3W J R1904 QRE121J-221Y C R 220¸ 1/2W J R1905 QRM034J-R10 MP R 0.1¸ 3W J R1906 QRE141J-1R5Y C R 1.5¸ 1/4W J R1908 NRSA63J-103X MG R 10k¸ 1/16W J R1911 QRE121J-152Y C R 1.5k¸ 1/2W J R1912 QRE121J-123Y C R 12k¸ 1/2W J

! R1913 QRZ9017-100 F R 10¸ 1/4W J

R1914 QRL039J-473 OM R 47k¸ 3W J R1915 NRSA63J-823X MG R 82k¸ 1/16W J R1916 NRSA63J-154X MG R 150k¸ 1/16W J R1951 QRE121J-223Y C R 22k¸ 1/2W J R1952 NRSA63J-222X MG R 2.2k¸ 1/16W J R1953 QRE121J-152Y C R 1.5k¸ 1/2W J R1954 QRE121J-150Y C R 15¸ 1/2W J

R1955 QRG01GJ-330 OM R 33¸ 1W J R1956 QRE121J-120Y C R 12¸ 1/2W J R1957 QRE121J-5R6Y C R 5.6¸ 1/2W J R1958 QRL039J-820 OM R 82¸ 3W J R1959 QRE121J-820Y C R 82¸ 1/2W J R1960 NRSA63J-391X MG R 390¸ 1/16W J R1961 QRL029J-223 OM R 22k¸ 2W J R1962 NRSA63J-681X MG R 680¸ 1/16W J

R1963 QRE121J-332Y C R 3.3k¸ 1/2W J R1964 NRSA63J-103X MG R 10k¸ 1/16W J R1965 NRSA63J-0R0X MG R 0.0¸ 1/16W J R1966 NRSA63J-223X MG R 22k¸ 1/16W J R1967 NRSA63J-473X MG R 47k¸ 1/16W J R1968 NRSA63J-331X MG R 330¸ 1/16W J R1969 QRT029J-1R5 MF R 1.5¸ 2W J R1970 NRSA63J-153X MG R 15k¸ 1/16W J

R1971 NRSA63J-183X MG R 18k¸ 1/16W J R1972 QRE121J-182Y C R 1.8k¸ 1/2W J R1973 QRE121J-332Y C R 3.3k¸ 1/2W J R1974 QRT029J-1R2 MF R 1.2¸ 2W J

! R1991 QRZ0057-825 C R 8.2M¸ 1W J

CAPACITOR

C1001 NCB31HK-103X C CAP. 0.01µF 50V K C1002 QETN1HM-106Z E CAP. 10µF 50V M C1003 QFV71HJ-104Z MF CAP. 0.1µF 50V J C1004 QETN1CM-477Z E CAP. 470µF 16V M C1005 NCB31HK-222X C CAP. 2200pF 50V K C1006 QETN1CM-336Z E CAP. 33µF 16V M C1007 NCB31HK-103X C CAP. 0.01µF 50V K C1101 NCB31HK-472X C CAP. 4700pF 50V K

C1102 NCB31HK-472X C CAP. 4700pF 50V K C1103 NCB31HK-472X C CAP. 4700pF 50V K C1104 NCB31HK-472X C CAP. 4700pF 50V K C1105 NCB31HK-472X C CAP. 4700pF 50V K C1106 NDC31HJ-180X C CAP. 18pF 50V J C1107 NCB31HK-103X C CAP. 0.01µF 50V K C1108 NCB31HK-472X C CAP. 4700pF 50V K C1109 QETN1HM-106Z E CAP. 10µF 50V M

C1150 NCB31HK-472X C CAP. 4700pF 50V K C1151 NCB31HK-472X C CAP. 4700pF 50V K C1301 NCB31CK-104X C CAP. 0.1µF 16V K C1302 NCB31CK-104X C CAP. 0.1µF 16V K C1304 NCB31HK-103X C CAP. 0.01µF 50V K C1305 NCB31HK-103X C CAP. 0.01µF 50V K C1306 NCB31CK-104X C CAP. 0.1µF 16V K C1307 NDC31HJ-330X C CAP. 33pF 50V J

C1308 NCB31HK-103X C CAP. 0.01µF 50V K C1315 QFLC1HJ-473Z M CAP. 0.047µF 50V J C1401 QETN1HM-336Z E CAP. 33µF 50V M C1402 QCB31HK-682Z C CAP. 6800pF 50V K C1403 QEHR1VM-107Z E CAP. 100µF 35V M C1406 QFLC2AJ-683Z M CAP. 0.068µF 100V J C1407 QCS32HJ-180Z C CAP. 18pF 500V J C1411 NCF21HZ-334X C CAP. 0.33µF 50V Z

56 No. 52070

AV-29W93

! Symbol No. Part No. Part Name Description Local ! Symbol No. Part No. Part Name Description Local

CAPACITOR

C1412 NCF21HZ-334X C CAP. 0.33µF 50V Z C1413 QFLC2AJ-563Z M CAP. 0.056µF 100V J C1422 QEHQ1VM-108 E CAP. 1000µF 35V M C1471 QETN1HM-106Z E CAP. 10µF 50V M C1480 QETN1HM-106Z E CAP. 10µF 50V M C1483 QEZ0195-475Z BP E CAP. 4.7µF 50V M C1485 QETN1HM-226Z E CAP. 22µF 50V M C1521 QETN1VM-476Z E CAP. 47µF 35V M

C1522 QFLC1HJ-332Z M CAP. 3300pF 50V J C1523 QFLC1HJ-223Z M CAP. 0.022µF 50V J C1524 QFZ0196-382 MPP CAP. 3800pF 1.5kVH±3% C1525 QFZ0200-143 MPP CAP. 0.014µF 1.5kVH±3% C1526 QFP32JJ-223 PP CAP. 0.022µF 630V J C1527 QFZ0199-224 MPP CAP. 0.22µFAC250V J C1528 QFZ0199-224 MPP CAP. 0.22µFAC250V J C1529 QENC2AM-225Z BP E CAP. 2.2µF 100V M

C1530 QCB32HK-561Z C CAP. 560pF 500V K C1531 QEHR1EM-108Z E CAP. 1000µF 25V M C1532 QCB32HK-561Z C CAP. 560pF 500V K C1533 QEHR1EM-108Z E CAP. 1000µF 25V M C1534 QCB32HK-561Z C CAP. 560pF 500V K C1536 QFLC1HJ-103Z M CAP. 0.01µF 50V J C1540 QFV71HJ-104Z MF CAP. 0.1µF 50V J C1541 QETN2EM-106Z E CAP. 10µF 250V M

C1550 NCB31CK-104X C CAP. 0.1µF 16V K C1561 QFV21HJ-154Z MF CAP. 0.15µF 50V J C1566 QFZ0200-113 MPP CAP. 0.011µF 1.5kVH±3% C1591 QETN1CM-107Z E CAP. 100µF 16V M C1592 QETM2CM-227 E CAP. 220µF 160V M C1593 QETN1EM-476Z E CAP. 47µF 25V M C1602 NCB31HK-103X C CAP. 0.01µF 50V K C1603 QETN1CM-107Z E CAP. 100µF 16V M

C1604 NCB31CK-104X C CAP. 0.1µF 16V K C1606 NDC31HJ-2R0X C CAP. 2pF 50V J C1607 NDC31HJ-2R0X C CAP. 2pF 50V J C1608 NCB31HK-103X C CAP. 0.01µF 50V K C1609 NCB31HK-103X C CAP. 0.01µF 50V K C1610 QETN1HM-106Z E CAP. 10µF 50V M C1611 NCB31CK-104X C CAP. 0.1µF 16V K C1612 QETN1HM-106Z E CAP. 10µF 50V M

C1613 NCB31CK-104X C CAP. 0.1µF 16V K C1615 QETN1HM-106Z E CAP. 10µF 50V M C1616 NCB31CK-104X C CAP. 0.1µF 16V K C1617 QETN1HM-106Z E CAP. 10µF 50V M C1618 NCB31CK-104X C CAP. 0.1µF 16V K C1619 QETN1HM-106Z E CAP. 10µF 50V M C1620 NCB31HK-102X C CAP. 1000pF 50V K C1621 NCB31HK-102X C CAP. 1000pF 50V K

C1625 NCF21EZ-474X C CAP. 0.47µF 25V Z C1626 NCB31HK-333X CH C CAP. 0.033µF 50V K C1627 NCB31HK-473X CH C CAP. 0.047µF 50V K C1628 NCB31HK-223X C CAP. 0.022µF 50V K C1629 NCB31HK-222X C CAP. 2200pF 50V K C1630 NCB31HK-104X C CAP. 0.1µF 50V K C1631 QETN1HM-475Z E CAP. 4.7µF 50V M C1632 QETN1HM-475Z E CAP. 4.7µF 50V M

C1633 QETN1HM-475Z E CAP. 4.7µF 50V M C1634 QETN1HM-475Z E CAP. 4.7µF 50V M C1635 QETN1HM-475Z E CAP. 4.7µF 50V M C1636 QETN1HM-475Z E CAP. 4.7µF 50V M C1637 QETN1HM-475Z E CAP. 4.7µF 50V M C1638 QETN1HM-475Z E CAP. 4.7µF 50V M C1639 QETN1HM-107Z E CAP. 100µF 50V M C1640 NCF21HZ-334X C CAP. 0.33µF 50V Z

C1641 QETN1HM-475Z E CAP. 4.7µF 50V M C1643 NCB31HK-104X C CAP. 0.1µF 50V K C1644 NCB31HK-222X C CAP. 2200pF 50V K C1645 NCB31HK-104X C CAP. 0.1µF 50V K C1646 NCB31HK-104X C CAP. 0.1µF 50V K C1647 NCF21EZ-474X C CAP. 0.47µF 25V Z C1648 NCB31HK-153X C CAP. 0.015µF 50V K C1649 NCB31HK-153X C CAP. 0.015µF 50V K

CAPACITOR

C1650 NCF31AZ-105X C CAP. 1µF 10V Z C1651 QEHR1HM-107Z E CAP. 100µF 50V M C1652 QETN1HM-105Z E CAP. 1µF 50V M C1653 NCF21HZ-224X C CAP. 0.22µF 50V Z C1654 NCF21HZ-224X C CAP. 0.22µF 50V Z C1655 NCF21HZ-224X C CAP. 0.22µF 50V Z C1656 NCF21HZ-224X C CAP. 0.22µF 50V Z C1662 QETN1HM-106Z E CAP. 10µF 50V M

C1681 QETN1CM-227Z E CAP. 220µF 16V M C1682 QETN1CM-227Z E CAP. 220µF 16V M C1683 QETN1CM-336Z E CAP. 33µF 16V M C1684 QETN1HM-106Z E CAP. 10µF 50V M C1702 QETN1HM-106Z E CAP. 10µF 50V M C1703 NDC31HJ-330X C CAP. 33pF 50V J C1704 NDC31HJ-330X C CAP. 33pF 50V J C1706 NCB21EK-224X C CAP. 0.22µF 25V K

C1707 QETN1CM-107Z E CAP. 100µF 16V M C1709 QETN1CM-477Z E CAP. 470µF 16V M C1710 NCB21EK-224X C CAP. 0.22µF 25V K C1711 NCB31CK-104X C CAP. 0.1µF 16V K C1712 QETN1CM-476Z E CAP. 47µF 16V M C1713 NCB31CK-104X C CAP. 0.1µF 16V K C1720 QETN1EM-476Z E CAP. 47µF 25V M C1725 NCB31HK-681X C CAP. 680pF 50V K

C1729 QETN1CM-476Z E CAP. 47µF 16V M C1730 NCB21EK-224X C CAP. 0.22µF 25V K C1731 NCB21EK-224X C CAP. 0.22µF 25V K C1732 QETN1CM-107Z E CAP. 100µF 16V M C1733 NCB31CK-104X C CAP. 0.1µF 16V K C1734 NCB31HK-222X C CAP. 2200pF 50V K C1735 NCB31HK-222X C CAP. 2200pF 50V K C1736 QETN1HM-105Z E CAP. 1µF 50V M

C1737 QETN1HM-105Z E CAP. 1µF 50V M C1738 NCB31CK-104X C CAP. 0.1µF 16V K C1739 NFV41CJ-104X MPP CAP. 0.1µF 16V J C1740 QETN1HM-225Z E CAP. 2.2µF 50V M C1741 NCB31CK-104X C CAP. 0.1µF 16V K C1742 NCB31CK-104X C CAP. 0.1µF 16V K C1743 QETN1CM-107Z E CAP. 100µF 16V M C1744 NCB31HK-222X C CAP. 2200pF 50V K

C1745 NCB31HK-473X CH C CAP. 0.047µF 50V K C1747 NCB31HK-473X CH C CAP. 0.047µF 50V K C1749 QETN1HM-106Z E CAP. 10µF 50V M C1751 NCB21HK-104X C CAP. 0.1µF 50V K C1752 NCB21HK-104X C CAP. 0.1µF 50V K C1753 NCB21HK-104X C CAP. 0.1µF 50V K C1801 QETN1HM-106Z E CAP. 10µF 50V M C1802 QETN1HM-106Z E CAP. 10µF 50V M

C1803 QETN1HM-106Z E CAP. 10µF 50V M C1804 QETN1HM-106Z E CAP. 10µF 50V M C1805 NCB31CK-104X C CAP. 0.1µF 16V K C1807 NCF31AZ-105X C CAP. 1µF 10V Z C1808 NCF31AZ-105X C CAP. 1µF 10V Z C1810 NCF31AZ-105X C CAP. 1µF 10V Z C1811 NCB31CK-104X C CAP. 0.1µF 16V K C1812 NCF31AZ-105X C CAP. 1µF 10V Z

C1813 NCB31HK-103X C CAP. 0.01µF 50V K C1814 NCB31CK-104X C CAP. 0.1µF 16V K C1815 NCF31AZ-105X C CAP. 1µF 10V Z C1817 NCF31AZ-105X C CAP. 1µF 10V Z C1819 NCB31CK-104X C CAP. 0.1µF 16V K C1820 NCF31AZ-105X C CAP. 1µF 10V Z C1821 NCF31AZ-105X C CAP. 1µF 10V Z C1822 QETN1CM-477Z E CAP. 470µF 16V M

C1823 QETN1CM-107Z E CAP. 100µF 16V M C1824 QETN1CM-107Z E CAP. 100µF 16V M C1825 NCB31HK-103X C CAP. 0.01µF 50V K C1826 NCB31CK-104X C CAP. 0.1µF 16V K C1827 NCB31HK-103X C CAP. 0.01µF 50V K C1829 NCB31HK-103X C CAP. 0.01µF 50V K C1830 NCB31HK-103X C CAP. 0.01µF 50V K C1831 NCB31HK-103X C CAP. 0.01µF 50V K

AV-29W93

No. 52070 57

AV-29W93

! Symbol No. Part No. Part Name Description Local ! Symbol No. Part No. Part Name Description Local

CAPACITOR

C1833 QETN1HM-226Z E CAP. 22µF 50V M C1834 NDC31HJ-181X C CAP. 180pF 50V J

! C1902 QFZ9072-104 MM CAP. 0.1µF

C1903 QCZ9015-102Z C CAP. 1000pF AC250V Z C1904 QCZ9015-102Z C CAP. 1000pF AC250V Z C1905 QCZ9015-102Z C CAP. 1000pF AC250V Z C1907 QEZ0371-337 E CAP. 330µF 400V M C1909 QCZ0325-102 C CAP. 1000pF 2000V K

C1910 NDC31HJ-102X C CAP. 1000pF 50V J C1911 QETN1VM-107Z E CAP. 100µF 35V M C1913 QFLC1HJ-683Z M CAP. 0.068µF 50V J C1915 QCB32HK-222Z C CAP. 2200pF 500V K C1916 QETN1HM-475Z E CAP. 4.7µF 50V M C1917 QCB32HK-181Z C CAP. 180pF 500V K C1918 QCB32HK-103 C CAP. 0.01µF 500V K C1919 QCZ0325-391 C CAP. 390pF 2000V K

C1920 QCZ0122-471 C CAP. 470pF 2000V K C1921 QFN31HJ-473Z M CAP. 0.047µF 50V J C1922 QETN2AM-226Z E CAP. 22µF 100V M C1952 QCB32HK-471Z C CAP. 470pF 500V K C1953 QEHQ1VM-228 E CAP. 2200µF 35V M C1955 QCB32HK-471Z C CAP. 470pF 500V K C1956 QETN1VM-107Z E CAP. 100µF 35V M C1957 QCB31HK-471Z C CAP. 470pF 50V K

C1958 QEHR1CM-108Z E CAP. 1000µF 16V M C1959 QCZ0364-561 C CAP. 560pF C1960 QEZ0203-227 E CAP. 220µF 160V M C1961 QETN1CM-476Z E CAP. 47µF 16V M C1962 QETN1HM-106Z E CAP. 10µF 50V M C1963 QETN1CM-477Z E CAP. 470µF 16V M C1964 QETN1EM-476Z E CAP. 47µF 25V M C1965 QETN1VM-476Z E CAP. 47µF 35V M

C1966 QETN1CM-107Z E CAP. 100µF 16V M C1968 NCB31CK-104X C CAP. 0.1µF 16V K C1970 QETN1CM-107Z E CAP. 100µF 16V M C1972 QETN1EM-476Z E CAP. 47µF 25V M C1974 NCB31CK-104X C CAP. 0.1µF 16V K C1975 QETN1CM-227Z E CAP. 220µF 16V M C1977 QETN1EM-476Z E CAP. 47µF 25V M C1978 NCB21HK-104X C CAP. 0.1µF 50V K

C1980 QETN1CM-107Z E CAP. 100µF 16V M C1981 NCB31HK-102X C CAP. 1000pF 50V K C1982 QETN1CM-476Z E CAP. 47µF 16V M C1983 QETN1CM-227Z E CAP. 220µF 16V M

! C1991 QCZ9079-102 C CAP. 1000pF AC250V M ! C1992 QCZ9079-102 C CAP. 1000pF AC250V M ! C1993 QCZ9079-102 C CAP. 1000pF AC250V M

TRANSFORMER

T1521 QQR1229-001 DRIVE TRANSF

! T1551 QQH0139-001 FBT(HV WIRELESS)

T1561 QQR1153-001 DEF TRANSF

! T1901 QQS0110-001 SW TRANSF

COIL

L1001 QQL244K-8R2Z COIL 8.2µHK L1002 QQL244K-8R2Z COIL 8.2µHK L1101 QQLZ014-R82 COIL 0.82µH L1102 QQL244K-180Z COIL 18µHK L1301 QQL244K-221Z PEAKING COIL 220µHK L1401 QQL26AK-220Z COIL 22µHK L1480 QQR1138-001 CHOKE COIL L1523 QQR1243-001 LINEARITY COIL

L1541 QQL244K-220Z COIL 22µHK L1561 QQLZ028-272 COIL 2700µH L1601 QQL244K-4R7Z COIL 4.7µHK L1701 QQL244K-100Z COIL 10µHK L1702 QQL244K-100Z COIL 10µHK L1731 QQL244J-101Z COIL 100µHJ L1951 QQLZ034-460 COIL 46µH L1953 QQL244J-5R6Z COIL 5.6µHJ

COIL

L1954 QQL26AK-820Z COIL 82µHK

DIODE

D1101 DAN235K-X SI. DIODE D1301 MTZJ5.1B-T2 ZENER DIODE D1401 RGP10J-5025-T3 SI. DIODE D1402 MTZJ75-T2 ZENER DIODE D1405 1N4003-T2 SI. DIODE D1408 MA111-X SI. DIODE D1480 MTZJ4.3A-T2 ZENER DIODE D1521 RH3G-F1 SI. DIODE

D1522 31DF6N-FC5 SI. DIODE D1523 RGP10J-5025-T3 SI. DIODE D1541 RGP10J-5025-T3 SI. DIODE D1550 MA111-X SI. DIODE D1551 EU2-T3 SI. DIODE D1553 RGP10J-5025-T3 SI. DIODE D1554 RGP10J-5025-T3 SI. DIODE D1592 MA3075/H/-X ZENER DIODE

D1652 MA3330/L/-X ZENER DIODE D1653 MA3330/L/-X ZENER DIODE D1655 MA111-X SI. DIODE D1657 MA111-X SI. DIODE D1701 MA111-X SI. DIODE D1702 MA3020-X ZENER DIODE D1703 MA3036-X ZENER DIODE D1730 MA111-X SI. DIODE

D1731 MA111-X SI. DIODE D1732 MA111-X SI. DIODE D1733 MA111-X SI. DIODE D1801 MA3120/M/-X ZENER DIODE D1802 MA3120/M/-X ZENER DIODE D1901 GSIB460 BRIDGE DIODE D1902 MTZJ33B-T2 ZENER DIODE D1906 MTZJ27B-T2 ZENER DIODE

D1907 MTZJ33B-T2 ZENER DIODE D1908 MA3200/M/-X ZENER DIODE D1909 1SS133-T2 SI. DIODE D1911 RGP10J-5025-T3 SI. DIODE D1912 RGP10J-5025-T3 SI. DIODE D1913 RGP10M-5010-T3 SI. DIODE D1914 NRSA63J-0R0X MG R 0.0¸ 1/16W J D1915 MTZJ39B-T2 ZENER DIODE

D1916 MTZJ15B-T2 ZENER DIODE D1917 1SS133-T2 SI. DIODE D1919 1SS133-T2 SI. DIODE D1920 MTZJ15B-T2 ZENER DIODE D1950 RGP10J-5025-T3 SI. DIODE D1952 ERC30-02L38 SI. DIODE D1953 RGP10J-5025-T3 SI. DIODE D1954 RU30A-F1 SI. DIODE

D1955 1SR35-400A-T2 SI. DIODE D1956 31DF6N-FC5 SI. DIODE D1958 MTZJ5.1A-T2 ZENER DIODE D1960 MA111-X SI. DIODE D1964 MA3330/L/-X ZENER DIODE D1966 MA3047/L/-X ZENER DIODE D1968 MA111-X SI. DIODE D1969 MA111-X SI. DIODE

D1970 MTZJ9.1B-T2 ZENER DIODE D1971 NRSA02J-0R0X MG R 0.0¸ 1/10W J

58 No. 52070

AV-29W93

! Symbol No. Part No. Part Name Description Local ! Symbol No. Part No. Part Name Description Local

TRANSISTOR

Q1101 2SC5083/L-P/-T TRANSISTOR Q1102 UN2212-X DIGI. TRANSISTOR Q1103 UN2212-X DIGI. TRANSISTOR Q1104 2SB709A/QR/-X TRANSISTOR Q1105 2SD601A/QR/-X TRANSISTOR Q1106 2SB709A/QR/-X TRANSISTOR Q1107 UN2212-X DIGI. TRANSISTOR Q1108 2SD601A/QR/-X TRANSISTOR

Q1109 UN2212-X DIGI. TRANSISTOR Q1110 UN2212-X DIGI. TRANSISTOR Q1150 2SD601A/QR/-X TRANSISTOR Q1301 2SB709A/QR/-X TRANSISTOR Q1302 2SB709A/QR/-X TRANSISTOR Q1303 UN2212-X DIGI. TRANSISTOR Q1304 2SD601A/QR/-X TRANSISTOR Q1480 2SD1408/OY/-LB POWER TRANSISTOR

Q1521 2SC2655/Y/-T TRANSISTOR Q1522 2SD2634-YD POWER TRANSISTOR Q1591 2SA1208/ST/Z1-T TRANSISTOR Q1592 UN2212-X DIGI. TRANSISTOR Q1660 2SD601A/QR/-X TRANSISTOR Q1661 2SD601A/QR/-X TRANSISTOR Q1683 2SB709A/QR/-X TRANSISTOR Q1684 2SB709A/QR/-X TRANSISTOR

Q1685 DTC323TK-X DIGI. TRANSISTOR Q1686 DTC323TK-X DIGI. TRANSISTOR Q1701 2SB709A/QR/-X TRANSISTOR Q1702 2SB709A/QR/-X TRANSISTOR Q1720 2SB709A/QR/-X TRANSISTOR Q1801 DTC323TK-X DIGI. TRANSISTOR Q1802 DTC323TK-X DIGI. TRANSISTOR Q1803 2SB709A/QR/-X TRANSISTOR

Q1804 2SC1740S/QR/-T TRANSISTOR Q1860 2SD601A/QR/-X TRANSISTOR Q1861 2SB709A/QR/-X TRANSISTOR Q1862 2SB709A/QR/-X TRANSISTOR Q1901 2SC3852A POWER TRANSISTOR Q1951 2SA1013/RO/-T TRANSISTOR Q1952 2SD601A/QR/-X TRANSISTOR Q1953 2SD601A/QR/-X TRANSISTOR

Q1954 2SD601A/QR/-X TRANSISTOR Q1955 2SD601A/QR/-X TRANSISTOR

OTHERS

K1705 QQR1214-001Y FERRITE BEADS K1901 QQR1214-001Y FERRITE BEADS K1902 QQR1214-001Y FERRITE BEADS K1903 QQR1214-001Y FERRITE BEADS K1951 QQR1214-001Y FERRITE BEADS K1953 QQR1214-001Y FERRITE BEADS K1954 QQR1214-001Y FERRITE BEADS K1955 QQR1214-001Y FERRITE BEADS

! LF1901 QQR1356-001 LINE FILTER ! PC1901 PC123F2 IC(PHOTO COUPLE) ! RY1901 QSK0061-001 RELAY

SF1101 QAX0663-001 SAW FILTER SF1102 QAX0731-001 SAW FILTER TH1901 QAD0145-2R3 P THERMISTOR TU1001 QAU0185-005 TUNER W1010 NRSA63J-0R0X MG R 0.0¸ 1/16W J

W1031 NRSA63J-0R0X MG R 0.0¸ 1/16W J W1239 NRSA63J-0R0X MG R 0.0¸ 1/16W J W1257 NRSA63J-0R0X MG R 0.0¸ 1/16W J W1306 NRSA63J-0R0X MG R 0.0¸ 1/16W J W1307 NRSA63J-0R0X MG R 0.0¸ 1/16W J W1309 NRSA63J-0R0X MG R 0.0¸ 1/16W J W1321 NRSA63J-0R0X MG R 0.0¸ 1/16W J W1325 NRSA63J-0R0X MG R 0.0¸ 1/16W J

W1326 NRSA63J-0R0X MG R 0.0¸ 1/16W J W1333 QQR1113-001Z FERRITE BEADS W1334 NRSA63J-0R0X MG R 0.0¸ 1/16W J W1379 NRSA63J-0R0X MG R 0.0¸ 1/16W J W1386 NRSA63J-0R0X MG R 0.0¸ 1/16W J W1395 NRSA63J-0R0X MG R 0.0¸ 1/16W J W1397 NRSA63J-0R0X MG R 0.0¸ 1/16W J W1402 QQR1113-001Z FERRITE BEADS

W1405 NRSA63J-0R0X MG R 0.0¸ 1/16W J W1418 NRSA63J-0R0X MG R 0.0¸ 1/16W J W1423 NRSA63J-0R0X MG R 0.0¸ 1/16W J W1428 NRSA63J-0R0X MG R 0.0¸ 1/16W J W1430 NRSA63J-0R0X MG R 0.0¸ 1/16W J W1431 QQR1113-001Z FERRITE BEADS X1601 CE42546-001Z X TAL X1701 QAX0737-001 CRYSTAL

Y1004 NRSA63J-0R0X MG R 0.0¸ 1/16W J Y1602 NRSA63J-0R0X MG R 0.0¸ 1/16W J Y1603 NRSA63J-0R0X MG R 0.0¸ 1/16W J

AV-29W93

IC

IC1301 TDA9181T/N1-X I.C(MONO ANA) IC1401 LA78041 I.C(MONO ANA) IC1461 JLC1562BF-X I C(DIGI-MOS) IC1480 UPC358G2-XE IC(MONOLITHIC) IC1601 MSP3417G-X I.C(MONO ANA) IC1602 NJW1136G-X I.C(MONO ANA) IC1650 AN5277 I.C(MONO ANA) IC1701 TDA9386N22S0902 IC(MCU)

IC1702 AT24C08-21WS3 I.C(MEMORY-OTH) (SERVICE) IC1801 MM1492AF I.C(MONO-ANA) IC1901 STR-F6256S-F7 I C(HYBRID) IC1951 SE135N I C(HYBRID) IC1972 L88M33T-X I.C(MONO-ANA) IC1973 BA17812T I.C(MONO-ANA) IC1974 BA51W12ST-V5 I.C(MONO-ANA)

OTHERS

CF1103 QAX0639-001Z C TRAP

! CP1951 ICP-N75-Y IC PROTECTOR ! CP1952 ICP-N38-Y IC PROTECTOR ! CP1953 ICP-N38-Y IC PROTECTOR

J1801 QNN0349-001 PIN JACK J1802 QNN0349-002 PIN JACK J1803 QNN0348-001 PIN JACK J1804 QNN0349-001 PIN JACK

CRT SOCKET PW BOARD ASS’Y (SCH-3005A-BK)

! Symbol No. Part No. Part Name Description Local

Refer to PARTS LIST in pages 51 - 53 for this PW BOARD

FRONT CONTROL PW BOARD ASS’Y (SCH-8004A-BK)

! Symbol No. Part No. Part Name Description Local

Refer to PARTS LIST in pages 53 - 54 for this PW BOARD

No. 52070 59

AV-29W93

! Symbol No. Part No. Part Name Description Local ! Symbol No. Part No. Part Name Description Local

REMOTE CONTROL UNIT PARTS LIST (RM-C1011-1H)

! Ref.No Part No. Part Name Description Local

25-1168F BATTERY COVER

60 No. 52070

AV-29W93B

PRINTED WIRING BOARD PARTS LIST [AV-29W93B/BK]

MAIN PW BOARD ASS’Y(SCH-1120A-BK)
