PARTS LIST
CONTENTS
V29BF10ENS
V29BF10EP
V29BF10EE
!
USING PW BOARD & REMO T E CONTRO L UNIT
･･･････ ････････････････････････････････ ･････････････ ･･
! EXPLODED VIEW PARTS LIST ･･･････ ･････････････ ････････････････････････････････ ･･･････････････････ ･･･18
!
EXPLODED VIEW
!
PRINTED WIRING BOARD PARTS L IST
･･･････ ･････････････････････････ ･･･････ ･････････････ ････････････････････････････････ ････
[ AV29BF10ENS]
"
MAIN PW BOARD ASS'Y
"
CRT SOCKET PW BOARD ASS'Y ････････････････････ ････････････ ･･･････ ･････････････ ･･･････････････････ ･･･････ 22
" FRONT CONTROL PW BOARD ASS’Y･･･････ ･････････････ ････････････ ･･･････ ･････････････ ･･･････････････････ ･･･ 22
" FRONT AV + HEADPHONE JACK PW BOARD ASS’Y･･･････ ･････････････ ････････････ ･･･････ ･････････････ ･････････
･･･････ ･････････････ ････････････ ･･･････ ･････････････ ･･･････････････････ ･････････････ ･･
[ AV29BF10EPS]
" MAIN PW BOARD ASS'Y･･･････ ･････････････ ････････････ ･･･････ ･････････････ ･･･････････････････ ･････････････ ･･
[ AV29BF10EES]
"
MAIN PW BOARD ASS'Y･･･････ ･････････････ ････････････ ･･･････ ･････････････ ･･･････････････････ ･････････････ ･･ 25
" CRT SOCKET PW BOARD ASS’Y ･･･････ ･････････････ ････････････ ･･･････ ･････････････ ･･･････････････････ ･･･････ 27
!
PAC KING / PACKIN G PARTS L IST ･･･････ ･････････････ ･･･････････････････ ･････････････ ････････････ ･･････ 28
17
19
20
22
23
USING PW BOARD & REMOTE CONTROL UNIT
Model
PW B AS S ' Y
MAIN PWB
CRT SOCKET PW B
FR O NT CONTRO L P WB VE-20083267
FR O NT AV + HEADPHO NE
JACK PWB
REMOTE CONTROL UNIT
AV29BF10ENS AV29BF10EPS AV29BF10EES
VE-20082209 VE-20083311 VE-20082155
VE-20062535
VE-20083088
VE-30015781
(RM-C85)
VE-20072781
No. 51936
17
A
V29BF10ENS
A
A
V29BF10EPS
V29BF10EES
EXPLODED VIEW PA RTS LIST
[ SILVER model : AV29BF10ENS, AV29BF10EES, AV29BF10EPS]
!
Ref.No. Part No. Part Name Description
!
V01 VE -2 00852 73 CR T KIT (29” ) AK 33J In c. DY, PC MA GNE T, WE DGE, DEG CO IL (VE -300129 71)
!
1 VE -3 00129 71 DE G COI L
!
2 VE -3 00152 31 RO TA TION COI L
3 VE -3 50000 13 SP RI NG ON/OF F SWI TCH
!
4 VE -20 05993 0 BU TT ON ON/OF F
5 VE -20 00360 5 PI N (FR ONT A V DOO R) (X 2)
!
6 VE -40 00002 6 EJ EC TOR C LIP -CLAP
!
7 VE -20 08120 4 CO NT ROL P ANE L DOOR
!
8 VE -2 00824 32 FR ON T PAN EL
!
9 VE -2 00812 12 LE NS LED
!
10 VE-2 0082371 BUTTON FUNCTION
11 VE-4 0009351 SPONGE (X2)
12 VE-3 0001950 SPEAKER 8R 15W (77x128) (X2)
13 VE-3 0001947 TWEETER 8R 15W (CLOSED) (X2)
!
14 VE-2 0059055 BACK COVER
15 VE-3 5000216 SCREW 3.9X19 (X8)
!
16 VE-2 0084842 BACK DOOR
17 VE-3 5000217 SCREW 3.5X9.5 (X4)
18 VE-4 0009154 LOGO JVC
18
No. 51936
A
A
S
A
S
EXPLODED VIEW
17
!
16
V29BF10ENS
V29BF10EP
V29BF10EE
!
14
15
MAIN PWB
!
!
V01
!
2
FR O NT AV +
HEADPHONE JACK
PWB
11
!
8
12
13
!
6
1
11
12
13
!
10
FRONT
CONTROL
!
9
18
!
3
4
5
!
7
PWB
No. 51936
19
A
V29BF10ENS
PRINTED WIRING BOARD PARTS LIST
[ AV29BF10ENS ]
MAIN P.W. BOARD ASS’Y (VE-20082209)
!
Symbol No. Part No. Part Name Description
RESISTOR
R100 VE-30001259 WW RES. 5W 1R J
R102 VE-30001132 MO RES. 2W 0.22R J
R106 VE-30000767 CF RES. 1/4W 68R J
R109 VE-30000913 MF RES. 1/4W 2K J
R111 VE-30000718 CF RES. 1/4W 4.7K J
R114 VE-30000729 CF RES. 1/4W 470K J
R118 VE-30001257 MG RES. 1/2W 4.7M J
R128 VE-30000513 CF RES. 1/4W 130K J
R131 VE-30000770 CF RES. 1/4W 680R J
R132 VE-30000770 CF RES. 1/4W 680R J
R14 VE-30000481 CF RES. 1/4W 1M J
R142 VE-30000536 CF RES. 1/4W 150K J
R144 VE-30006758 MO RES. 1W 0.82R J
R145 VE-30000477 CF RES. 1/4W 100K J
R15 VE-30000541 CF RES. 1/4W 1.5M J
R152 VE-30001132 MO RES. 2W 0.22R J
R153 VE-30001174 MO RES. 2W 0.47R J
R157 VE-30000712 CF RES. 1/4W 470R J
R161 VE-30006755 MO RES. 2W 4.7R J
R17 VE-30000660 CF RES. 1/4W 3.3K J
R236 VE-30000792 CF RES. 1/4W 75R J
R278 VE-30000633 CF RES. 1/4W 27K J
R294 VE-30000554 CF RES. 1/4W 180R J
R300 VE-30000583 CF RES. 1/4W 220R J
R302 VE-30000583 CF RES. 1/4W 220R J
R303 VE-30000655 CF RES. 1/4W 330R J
R304 VE-30000655 CF RES. 1/4W 330R J
R323 VE-30000706 CF RES. 1/4W 47R J
R329 VE-30000460 CF RES. 1/4W 100R G
R332 VE-30000471 CF RES. 1/4W 10K J
R365 VE-30000748 CF RES. 1/4W 5.6K J
R366 VE-30000760 CF RES. 1/4W 6.2K J
R369 VE-30000775 CF RES. 1/4W 6.8K J
R405 VE-30000452 CF RES. 1/4W 10R J
R411 VE-30000452 CF RES. 1/4W 10R J
R500 VE-30000500 CF RES. 1/4W 12K J
R516 VE-30000531 CF RES. 1/4W 15K J
R537 VE-30000560 CF RES. 1/4W 1.8K J
R538 VE-30000560 CF RES. 1/4W 1.8K J
R571 VE-30000752 CF RES. 1/4W 56K J
R590 VE-30000723 CF RES. 1/4W 47K J
R598 VE-30000723 CF RES. 1/4W 47K J
R599 VE-30000723 CF RES. 1/4W 47K J
R601 VE-30001138 MO RES. 1W 2.7K J
R603 VE-30001138 MO RES. 1W 2.7K J
R604 VE-30001244 FUSE RES. 1/2W 0.47R J
!
R605 VE-30000628 CF RES. 1/4W 2.7K J
!
R606 VE-30001244 FUSE RES. 1/2W 0.47R J
R607 VE-30000554 CF RES. 1/4W 180R J
!
R612 VE-30001232 FUSE RES. 1/4W 2.7R J
R614 VE-30015721 MO RES. 5W 2.2K J
R615 VE-30000848 MF RES. 1/4W 1K F
!
R617 VE-30001215 FUSE RES. 1W 1R J
R623 VE-30001134 MO RES. 2W 2.2R J
R625 VE-30001162 MO RES. 1W 390R J
R627 VE-30001088 MO RES. 1W 1R J
R651 VE-30001245 FUSE RES. 1/4W 0.47R J
!
!
R652 VE-30001245 FUSE RES. 1/4W 0.47R J
R657 VE-30000993 MF RES. 1/4W 51K J
R658 VE-30007202 MF RES. 1/4W 56K F
R659 VE-30000865 MF RES. 1/4W 1.2K J
R670 VE-30015721 MO RES. 5W 2.2K J
R7 VE-30001155 MO RES. 2W 33K J
R709 VE-30000466 CF RES. 1/4W 1K J
R711 VE-30000459 CF RES. 1/4W 100R J
R712 VE-30000466 CF RES. 1/4W 1K J
R713 VE-30000466 CF RES. 1/4W 1K J
R714 VE-30000466 CF RES. 1/4W 1K J
R719 VE-30000734 CF RES. 1/4W 4.7R J
R720 VE-30000734 CF RES. 1/4W 4.7R J
R748 VE-30000670 CF RES. 1/4W 330K J
R8 VE-30001155 MO RES. 2W 33K J
CAPACITOR
C1 VE-30000352 EL CAP. 100UF 16V M
C100 VE-3 0000094 MKT CAP. 220N F AC275V M
!
!
Symbol No. Part No. Part Name Description
CAPACITOR
!
C101 VE-3 0007858 MKT CAP. 470N F AC275V M (P=22. 5MM)
!
C105 VE-30000153 MKP CAP. 330NF 400V J
C107 VE-30000353 EL CAP. 100UF 25V M
C11 VE-30006748 EL CAP. 4.7UF 350V M
C110 VE-30000387 EL CAP. 33UF 50V M
C111 VE-30000266 CER CAP. 560PF 50V J SL
C112 VE-30000092 MKT CAP. 220NF 63V J
C114 VE-30000161 MKP CAP. 47NF 630V J
C115 VE-30007308 CER CAP. 220PF 1KV K (PULSE)
C116 VE-30013690 EL CAP. 220UF 450V M 105°C
C117 VE-30006940 CER CAP. 2.7NF 1KV K B
C118 VE-30007308 CER CAP. 220PF 1KV K (PULSE)
C119 VE-30000440 CER CAP. 2.2NF 4KV M
C12 VE-30006748 EL CAP. 4.7UF 350V M
C122 VE-30000071 MKT CAP. 10NF 63V J
C123 VE-30007308 CER CAP. 220PF 1KV K (PULSE)
C124 VE-30007308 CER CAP. 220PF 1KV K (PULSE)
C126 VE-30007308 CER CAP. 220PF 1KV K (PULSE)
C127 VE-30000406 EL CAP. 47UF 250V M (HR)
C130 VE-30000295 CER CAP. 100NF 50V Z F
C137 VE-30000383 EL CAP. 2200UF 25V M
C138 VE-30000383 EL CAP. 2200UF 25V M
C14 VE-30000436 CER CAP. 10NF 1KV ZE
C142 VE-30000295 CER CAP. 100NF 50V Z F
C143 VE-30000359 EL CAP. 1000UF 16V M
C144 VE-30000360 EL CAP. 1000UF 25V M
C147 VE-30000375 EL CAP. 220UF 16V M
C149 VE-30000375 EL CAP. 220UF 16V M
C15 VE-30000436 CER CAP. 10NF 1KV ZE
C150 VE-30000375 EL CAP. 220UF 16V M
C152 VE-30000295 CER CAP. 100NF 50V Z F
C153 VE-30000295 CER CAP. 100NF 50V Z F
C155 VE-30007308 CER CAP. 220PF 1KV K (PULSE)
C16 VE-30000436 CER CAP. 10NF 1KV ZE
C164 VE-30000411 EL CAP. 4700UF 16V M
C166 VE-3 0000438 CER CAP. 2.2N F 2KV
C167 VE-3 0007708 CER CAP. 1NF 1KV K (PU LSE)
C17 VE-3 0000433 CER CAP. 1NF 1KV M B
C173 VE-30000367 EL CAP. 1UF 250V M
C180 VE-3 0000076 MKT CAP. 100N F AC275V M
!
C119 VE-30000440 CER CAP. 2.2NF 4KV M
!
!
C181 VE-30000440 CER CAP. 2.2NF 4KV M
C19 VE-30000335 CER CAP. 47NF 50V Z F
C217 VE-30000355 EL CAP. 100UF 50V M
C219 VE-30000345 EL CAP. 10UF 50V M
C22 VE-30000290 CER CAP. 10NF 50V Z F
C23 VE-30000146 MKP CAP. 220NF 250V M
C255 VE-30010571 EL CAP. 10UF 16V M
C257 VE-30000109 MKT CAP. 470NF 63V J
C260 VE-30000074 MKT CAP. 100NF 63V J
C262 VE-30000384 EL CAP. 2.2UF 50V M
C265 VE-3 0000283 CER CAP. 1NF 5 0V K B
C275 VE-30000362 EL CAP. 1UF 50V M
C283 VE-30000384 EL CAP. 2.2UF 50V M
C323 VE-30010571 EL CAP. 10UF 16V M
C326 VE-30000298 CER CAP. 1.5NF 50V K B
C355 VE-30000106 MKT CAP. 47NF 100V J
C356 VE-30000407 EL CAP. 470UF 16V M
C368 VE-30000330 CER CAP. 4.7NF 50V K B
C516 VE-30000345 EL CAP. 10UF 50V M
C532 VE-30000400 EL CAP. 47UF 50V M
C533 VE-30000400 EL CAP. 47UF 50V M
C535 VE-30000400 EL CAP. 47UF 50V M
C536 VE-30000400 EL CAP. 47UF 50V M
C600 VE-30000360 EL CAP. 1000UF 25V M
C601 VE-30000075 MKT CAP. 100NF 250V K (DC)
C603 VE-30000351 EL CAP. 10UF 350V M
C604 VE-30000075 MKT CAP. 100NF 250V K (DC)
C605 VE-30000409 EL CAP. 470UF 25V M
C606 VE-30000071 MKT CAP. 10NF 63V J
C607 VE-30000402 EL CAP. 47UF 100V M
C608 VE-30000406 EL CAP. 47UF 250V M (HR)
C611 VE-30000151 MKP CAP. 3.3NF 2KV %3.5
C612 VE-30000131 MKP CAP. 100NF 250V J
C615 VE-30000134 MKP CAP. 11NF 2000V %3.5
C616 VE-30000137 MKP CAP. 15NF 630V J
C617 VE-30000172 MKP CAP. 680NF 250V J (P=15)
C618 VE-30000172 MKP CAP. 680NF 250V J (P=15)
20
No. 51936
A
[ AV29BF10ENS ]
V29BF10ENS
Symbol No. Part No. Part Name Description
!
CAPACITOR
C621 VE-30000360 EL CAP. 1000UF 25V M
C623 VE-30000296 CER CAP. 100NF 100V Z F
C635 VE-30000350 EL CAP. 10UF 250V M
C636 VE-30000444 CER CAP. 470PF 1KV KB
C637 VE-30000444 CER CAP. 470PF 1KV KB
C638 VE-30000287 CER CAP. 10NF 50V K B
C639 VE-30000365 EL CAP. 1UF 160V M
C640 VE-30000197 CER CAP. 120PF 50V J SL
C642 VE-30000316 CER CAP. 220NF 25V Z F
C643 VE-30000074 MKT CAP. 100NF 63V J
C644 VE-30000074 MKT CAP. 100NF 63V J
C701 VE-30000345 EL CAP. 10UF 50V M
C711 VE-30000407 EL CAP. 470UF 16V M
C740 VE-30000393 EL CAP. 3.3UF 50V M
C741 VE-30000345 EL CAP. 10UF 50V M
C742 VE-30000345 EL CAP. 10UF 50V M
C744 VE-30000345 EL CAP. 10UF 50V M
C749 VE-30000345 EL CAP. 10UF 50V M
C760 VE-30000393 EL CAP. 3.3UF 50V M
C762 VE-30000362 EL CAP. 1UF 50V M
C763 VE-30000362 EL CAP. 1UF 50V M
C764 VE-30000074 MKT CAP. 100NF 63V J
C767 VE-30000409 EL CAP. 470UF 25V M
C768 VE-30000074 MKT CAP. 100NF 63V J
C770 VE-30000409 EL CAP. 470UF 25V M
C776 VE-30000371 EL CAP. 22UF 50V M
C780 VE-30000371 EL CAP. 22UF 50V M
C863 VE-30009208 CER CAP. 470PF 1KV K (PULSE)
C865 VE-3 0000283 CER CAP. 1NF 50V K B
C866 VE-30000407 EL CAP. 470UF 16V M
TRANSF
!
TR101 VE-30016154 SMPS TRF
TR600 VE-30002090 LINE DRIVER
!
TR60 1 VE-3 0014072 FBT TRF
COIL
L1 VE-30015576 TRF DFOCUS COIL 50HZ E25
L102 VE-3 0015617 TRF PFC 200U H
!
L200 VE-30001979 FIXED COIL 1UH Q45 M-A
L201 VE-30006712 FERRITE BEAD 3.5X4.7X0.8
L202 VE-30006712 FERRITE BEAD 3.5X4.7X0.8
L212 VE-30001992 FIXED COIL 10UH Q65 K-A
L225 VE-30013413 FERRITE BEAD
L226 VE-30013413 FERRITE BEAD
L227 VE-30013413 FERRITE BEAD
L228 VE-30013413 FERRITE BEAD
L507 VE-30001987 FIXED COIL 4.7UH Q70 K-A
L600 VE-30002031 FIXED COIL INJECTION 15MH
L601 VE-30002028 FIXED COIL BRIDGE 1.9MH
L603 VE-30007771 FIXED COIL 100UH
L700 VE-30001996 FIXED COIL 22UH Q40 K
L701 VE-30001996 FIXED COIL 22UH Q40 K
L702 VE-30001996 FIXED COIL 22UH Q40 K
L704 VE-30001996 FIXED COIL 22UH Q40 K
L708 VE-30001996 FIXED COIL 22UH Q40 K
L715 VE-30001996 FIXED COIL 22UH Q40 K
DIODE
D10 VE-30001291 DIODE
D105 VE-30001284 DIODE
D11 VE-30001291 DIODE
D117 VE-30001315 DIODE
D118 VE-30009366 DIODE
D119 VE-30001333 DIODE
D128 VE-30001284 DIODE
D129 VE-30001318 DIODE
D131 VE-30001284 DIODE
!
D132 VE-30007758 BRIDGE DIODE
D136 VE-30001368 ZENER DIODE
D140 VE-30001318 DIODE
D141 VE-30001318 DIODE
D209 VE-30001284 DIODE
Symbol No. Part No. Part Name Description
!
DIODE
D600 VE-30001318 DIODE
D601 VE-30001318 DIODE
D603 VE-30001299 DIODE
D604 VE-30001299 DIODE
D607 VE-30001284 DIODE
D608 VE-30001284 DIODE
D609 VE-30001284 DIODE
D610 VE-30001318 DIODE
D611 VE-30007681 DIODE
D612 VE-30007678 DIODE
D615 VE-30001377 ZENER DIODE
D622 VE-30001318 DIODE
D7 VE-30001291 DIODE
D8 VE-30001291 DIODE
D9 VE-30001291 DIODE
TRANSISTOR
Q100 VE-30001386 TR
Q101 VE-30001454 TR
Q102 VE-30016755 TR
Q103 VE-30001454 TR
Q105 VE-30001454 TR
Q106 VE-30001428 TR
Q107 VE-30001384 TR
Q4 VE-30006693 TR
Q600 VE-30001435 TR
Q604 VE-30001429 TR
Q605 VE-30001455 TR
IC
!
IC100 VE-30015087 IC
IC101 VE-30001668 IC
IC102 VE-30001622 IC
IC103 VE-30001500 IC
IC106 VE-30011968 IC
IC107 VE-30011970 IC
IC116 VE-30001506 IC
IC200 VE-30012090 IC
IC201 VE-30001619 IC
IC203 VE-30013685 IC
IC500 VE-30011957 IC (MYCOM)
IC502 VE-20082263 IC (MEMORY)
IC503 VE-30001665 IC
IC600 VE-30007793 IC
IC601 VE-30001506 IC
IC700 VE-30001664 IC
IC701 VE-30007794 IC
OTHERS
CON1 0 VE-3 0001891 RCA JACK
CON1 0 VE-3 0001892 RCA JACK
CON1 0 VE-3 0001893 RCA JACK
CON10 VE-30001900 HEADPHONE JACK
!
F100 VE-20000849 FUSE 3.15A
!
J118 VE-30001244 FUSE RES.
J203 VE-30006712 FERRITE BEAD
L107 VE-30002104 LINE FILTER
!
L108 VE-30002104 LINE FILTER
!
L602 VE-30015221 LINEARITY COIL
!
PL101 VE-30001792 CONN.MALE 2P MOLEX
RL100 VE-30002183 RELAY
TH100 VE-30001270 PTC
!
TU200 VE-30009637 TUNER
X500 VE-30006662 XTAL
X700 VE-30001756 XTAL
Z200 VE-3 0013163 SAW FILTER
Z201 VE-3 0014261 SAW FILTER
No. 51936
21
A
V29BF10ENS
[ AV29BF10ENS ]
CRT SOCKET PWB BOARD ASSY ( VE-2006 2535)
Symbol No. Part No. Part Name Description
!
RESISTOR
R900 VE-30000788 CF RES. 1/4W 6.8M J
R906 VE-30000535 CF RES. 1/2W 150K J
R909 VE-30000525 CF RES. 1/2W 1.5K J
R910 VE-30000525 CF RES. 1/2W 1.5K J
R911 VE-30001125 MO RES. 2W 2.2K J
R913 VE-30000525 CF RES. 1/2W 1.5K J
R914 VE-30001084 MO RES. 1W 1K J
R915 VE-30000580 CF RES. 1/4W 22R J
R916 VE-30001170 MO RES. 1W 4.7K J
R917 VE-30001230 FUSE RES. 1/2W 27R J
!
R921 VE-30000599 CF RES. 1/4W 220K J
R922 VE-30000590 CF RES. 1/4W 2.2K J
CAPACITOR
C902 VE-30000415 EL CAP. 4.7UF 250V M
C905 VE-30000234 CER CAP. 270PF 50V J SL
C909 VE-30000385 EL CAP. 2.2UF 250V M
DIODE
D901 VE-30001329 DIODE
D903 VE-30001329 DIODE
D904 VE-30001329 DIODE
D909 VE-30001344 ZENER DIODE
TRANSISTOR
Q900 VE-30001427 TR
IC
IC900 VE-30008721 IC
OTHERS
PL900 VE-30001856 CRT SOCKET
!
SG900 VE-30000428 SPARK GAP
SG901 VE-30000428 SPARK GAP
SG902 VE-30000428 SPARK GAP
SG903 VE-30000428 SPARK GAP
SG904 VE-30000428 SPARK GAP
FRONT CONTROL PW BOARD ASSY(VE-20083267)
!
Symbol No. Part No. Part Name Description
OTHERS
LD102 VE-30001279 LED RED/GREEN
MD101 VE-30001670 PREAMPLIFIER
S101 VE-30002181 SWITCH TACT
S102 VE-30002181 SWITCH TACT
S103 VE-30002181 SWITCH TACT
S104 VE-30002181 SWITCH TACT
S105 VE-30002181 SWITCH TACT
FRONT AV + HEADPHONE JACK PW BOARD
ASSY (VE-20083088)
Symbol No. Part No. Part Name Description
!
RESISTOR
R107 VE-30000594 CF RES. 1/4W 22K J
R108 VE-30000982 MF RES. 1/4W 4.7K J
R109 VE-30000594 CF RES. 1/4W 22K J
R110 VE-30000452 CF RES. 1/4W 10R J
R113 VE-30000744 CF RES. 1/4W 560R J
R114 VE-30000744 CF RES. 1/4W 560R J
R116 VE-30001159 MO RES. 1W 0.33R J
CAPACITOR
C103 VE-30000213 CER CAP. 180PF 50V J CH
!
C104 VE-30000213 CER CAP. 180PF 50V J CH
!
C106 VE-30000190 CER CAP. 100PF 50V J CH
COIL
L104 VE-30010964 FERRITE BEAT
OTHERS
T103 VE-30001962 FERRITE
T104 VE-30001963 FERRITE
T107 VE-30001963 FERRITE
22
No. 51936
A
S
PRINTED WIRING BOARD PARTS LIST
[ AV29BF10EPS ]
MAIN P.W. BOARD AS S’ Y (VE-20083311)
Symbol No. Part No. Part Name Description
!
RESISTOR
R100 VE-30001259 WW RES. 5W 1R J
R102 VE-30001132 MO RES. 2W 0.22R J
R106 VE-30000767 CF RES. 1/4W 68R J
R109 VE-30000913 MF RES. 1/4W 2K J
R111 VE-30000718 CF RES. 1/4W 4.7K J
R114 VE-30000729 CF RES. 1/4W 470K J
R118 VE-30001257 MG RES. 1/2W 4.7M J
!
R128 VE-30000513 CF RES. 1/4W 130K J
R131 VE-30000770 CF RES. 1/4W 680R J
R132 VE-30000770 CF RES. 1/4W 680R J
R14 VE-30000481 CF RES. 1/4W 1M J
R142 VE-30000536 CF RES. 1/4W 150K J
R144 VE-30006758 MO RES. 1W 0.82R J
R145 VE-30000477 CF RES. 1/4W 100K J
R152 VE-30001132 MO RES. 2W 0.22R J
R153 VE-30001174 MO RES. 2W 0.47R J
R157 VE-30000712 CF RES. 1/4W 470R J
R161 VE-30006755 MO RES. 2W 4.7R J
R17 VE-30000660 CF RES. 1/4W 3.3K J
R236 VE-30000792 CF RES. 1/4W 75R J
R294 VE-30000554 CF RES. 1/4W 180R J
R300 VE-30000583 CF RES. 1/4W 220R J
R302 VE-30000583 CF RES. 1/4W 220R J
R303 VE-30000655 CF RES. 1/4W 330R J
R304 VE-30000655 CF RES. 1/4W 330R J
R329 VE-30000460 CF RES. 1/4W 100R G
R332 VE-30000471 CF RES. 1/4W 10K J
R344 VE-30000723 CF RES. 1/4W 47K J
R365 VE-30000748 CF RES. 1/4W 5.6K J
R366 VE-30000760 CF RES. 1/4W 6.2K J
R369 VE-30000775 CF RES. 1/4W 6.8K J
R405 VE-30000452 CF RES. 1/4W 10R J
R411 VE-30000452 CF RES. 1/4W 10R J
R432 VE-30000541 CF RES. 1/4W 1.5M J
R500 VE-30000500 CF RES. 1/4W 12K J
R516 VE-30000531 CF RES. 1/4W 15K J
R537 VE-30000560 CF RES. 1/4W 1.8K J
R538 VE-30000560 CF RES. 1/4W 1.8K J
R570 VE-30000633 CF RES. 1/4W 27K J
R571 VE-30000752 CF RES. 1/4W 56K J
R574 VE-30000706 CF RES. 1/4W 47R J
R601 VE-30001138 MO RES. 1W 2.7K J
R603 VE-30001138 MO RES. 1W 2.7K J
R604 VE-30001244 FUSE RES. 1/2W 0.47R J
!
R605 VE-30000628 CF RES. 1/4W 2.7K J
!
R606 VE-30001244 FUSE RES. 1/2W 0.47R J
R607 VE-30000554 CF RES. 1/4W 180R J
R612 VE-30001232 FUSE RES. 1/4W 2.7R J
!
R614 VE-30015721 MO RES. 5W 2.2K J
R615 VE-30000848 MF RES. 1/4W 1K F
!
R617 VE-30001215 FUSE RES. 1W 1R J
R623 VE-30001134 MO RES. 2W 2.2R J
R625 VE-30001162 MO RES. 1W 390R J
R627 VE-30001088 MO RES. 1W 1R J
!
R651 VE-30001245 FUSE RES. 1/4W 0.47R J
!
R652 VE-30001245 FUSE RES. 1/4W 0.47R J
R657 VE-30000993 MF RES. 1/4W 51K J
R658 VE-30007202 MF RES. 1/4W 56K F
R659 VE-30000865 MF RES. 1/4W 1.2K J
R670 VE-30015721 MO RES. 5W 2.2K J
R7 VE-30001155 MO RES. 2W 33K J
R709 VE-30000466 CF RES. 1/4W 1K J
R711 VE-30000459 CF RES. 1/4W 100R J
R712 VE-30000466 CF RES. 1/4W 1K J
R713 VE-30000466 CF RES. 1/4W 1K J
R714 VE-30000466 CF RES. 1/4W 1K J
R719 VE-30000734 CF RES. 1/4W 4.7R J
R720 VE-30000734 CF RES. 1/4W 4.7R J
R748 VE-30000670 CF RES. 1/4W 330K J
R8 VE-30001155 MO RES. 2W 33K J
CAPACITOR
!
C100 VE-3 0000094 MKT CAP. 220N F AC275V M
!
C101 VE-3 0007858 MKT CAP. 470N F AC275V M(P=22.5 MM)
!
C105 VE-30000153 MKP CAP. 330NF 400V J
C107 VE-30000353 EL CAP. 100UF 25V M
V29BF10EP
Symbol No. Part No. Part Name Description
!
CAPACITOR
C11 VE-30006748 EL CAP. 4.7UF 350V M
C110 VE-30000387 EL CAP. 33UF 50V M
C111 VE-30000266 CER CAP. 560PF 50V J SL
C114 VE-30000161 MKP CAP. 47NF 630V J
C115 VE-30007308 CER CAP. 220PF 1KV K (PULSE)
C116 VE-30013690 EL CAP. 220UF 450V M 105°C
C117 VE-30006940 CER CAP. 2.7NF 1KV K B
C118 VE-30007308 CER CAP. 220PF 1KV K (PULSE)
C119 VE-30000440 CER CAP. 2.2NF 4KV M
C12 VE-30006748 EL CAP. 4.7UF 350V M
C122 VE-30000071 MKT CAP. 10NF 63V J
C123 VE-30007308 CER CAP. 220PF 1KV K (PULSE)
C124 VE-30007308 CER CAP. 220PF 1KV K (PULSE)
C126 VE-30007308 CER CAP. 220PF 1KV K (PULSE)
C127 VE-30000406 EL CAP. 47UF 250V M (HR)
C130 VE-30000295 CER CAP. 100NF 50V Z F
C137 VE-30000383 EL CAP. 2200UF 25V M
C138 VE-30000383 EL CAP. 2200UF 25V M
C14 VE-30000436 CER CAP. 10NF 1KV ZE
C142 VE-30000295 CER CAP. 100NF 50V Z F
C143 VE-30000359 EL CAP. 1000UF 16V M
C144 VE-30000360 EL CAP. 1000UF 25V M
C147 VE-30000375 EL CAP. 220UF 16V M
C148 VE-30000400 EL CAP. 47UF 50V M
C149 VE-30000375 EL CAP. 220UF 16V M
C15 VE-30000436 CER CAP. 10NF 1KV ZE
C150 VE-30000375 EL CAP. 220UF 16V M
C152 VE-30000295 CER CAP. 100NF 50V Z F
C153 VE-30000295 CER CAP. 100NF 50V Z F
C155 VE-30007308 CER CAP. 220PF 1KV K (PULSE)
C16 VE-30000436 CER CAP. 10NF 1KV ZE
C164 VE-30000411 EL CAP. 4700UF 16V M
C173 VE-30000367 EL CAP. 1UF 250V M
!
C180 VE-3 0000076 MKT CAP. 100N F AC275V M
!
C119 VE-30000440 CER CAP. 2.2NF 4KV M
C181 VE-30000440 CER CAP. 2.2NF 4KV M
!
C182 VE-3 0007708 CER CAP. 1NF 1KV K (PU LSE)
C19 VE-30000335 CER CAP. 47NF 50V Z F
C217 VE-30000355 EL CAP. 100UF 50V M
C219 VE-30000345 EL CAP. 10UF 50V M
C22 VE-30000290 CER CAP. 10NF 50V Z F
C23 VE-30000146 MKP CAP. 220NF 250V M
C255 VE-30010571 EL CAP. 10UF 16V M
C262 VE-30000384 EL CAP. 2.2UF 50V M
C265 VE-3 0000283 CER CAP. 1NF 50V K B
C274 VE-30000352 EL CAP. 100UF 16V M
C275 VE-30000362 EL CAP. 1UF 50V M
C280 VE-30000092 MKT CAP. 220NF 63V J
C283 VE-30000384 EL CAP. 2.2UF 50V M
C285 VE-30000092 MKT CAP. 220NF 63V J
C306 VE-30000352 EL CAP. 100UF 16V M
C323 VE-30010571 EL CAP. 10UF 16V M
C326 VE-30000298 CER CAP. 1.5NF 50V K B
C355 VE-30000106 MKT CAP. 47NF 100V J
C356 VE-30000407 EL CAP. 470UF 16V M
C363 VE-30000352 EL CAP. 100UF 16V M
C364 VE-30000352 EL CAP. 100UF 16V M
C365 VE-30000352 EL CAP. 100UF 16V M
C502 VE-30000074 MKT CAP. 100NF 63V J
C516 VE-30000345 EL CAP. 10UF 50V M
C520 VE-30000352 EL CAP. 100UF 16V M
C534 VE-30000109 MKT CAP. 470NF 63V J
C540 VE-3 0007708 CER CAP. 1NF 1KV K (PU LSE)
C600 VE-30000360 EL CAP. 1000UF 25V M
C603 VE-30000351 EL CAP. 10UF 350V M
C605 VE-30000409 EL CAP. 470UF 25V M
C606 VE-30000071 MKT CAP. 10NF 63V J
C607 VE-30000402 EL CAP. 47UF 100V M
C608 VE-30000406 EL CAP. 47UF 250V M (HR)
C611 VE-30000151 MKP CAP. 3.3NF 2KV %3.5
C612 VE-30000131 MKP CAP. 100NF 250V J
C615 VE-30000134 MKP CAP. 11NF 2000V %3.5
C616 VE-30000137 MKP CAP. 15NF 630V J
C617 VE-30000172 MKP CAP. 680NF 250V J (P=15)
C618 VE-30000172 MKP CAP. 680NF 250V J (P=15)
C621 VE-30000360 EL CAP. 1000UF 25V M
C623 VE-30000296 CER CAP. 100NF 100V Z F
C626 VE-30000092 MKT CAP. 220NF 63V J
No. 51936
23
A
V29BF10EPS
[ AV29BF10EPS ]
Symbol No. Part No. Part Name Description
!
CAPACITOR
C635 VE-30000350 EL CAP. 10UF 250V M
C636 VE-30000444 CER CAP. 470PF 1KV KB
C637 VE-30000444 CER CAP. 470PF 1KV KB
C638 VE-30000287 CER CAP. 10NF 50V K B
C639 VE-30000365 EL CAP. 1UF 160V M
C640 VE-30000197 CER CAP. 120PF 50V J SL
C642 VE-30000316 CER CAP. 220NF 25V Z F
C700 VE-30000352 EL CAP. 100UF 16V M
C701 VE-30000345 EL CAP. 10UF 50V M
C711 VE-30000407 EL CAP. 470UF 16V M
C740 VE-30000393 EL CAP. 3.3UF 50V M
C741 VE-30000345 EL CAP. 10UF 50V M
C742 VE-30000345 EL CAP. 10UF 50V M
C744 VE-30000345 EL CAP. 10UF 50V M
C749 VE-30000345 EL CAP. 10UF 50V M
C759 VE-30000352 EL CAP. 100UF 16V M
C760 VE-30000393 EL CAP. 3.3UF 50V M
C762 VE-30000362 EL CAP. 1UF 50V M
C763 VE-30000362 EL CAP. 1UF 50V M
C767 VE-30000409 EL CAP. 470UF 25V M
C770 VE-30000409 EL CAP. 470UF 25V M
C776 VE-30000371 EL CAP. 22UF 50V M
C780 VE-30000371 EL CAP. 22UF 50V M
C863 VE-30009208 CER CAP. 470PF 1KV K (PULSE)
C865 VE-3 0000283 CER CAP. 1NF 50V K B
C866 VE-30000407 EL CAP. 470UF 16V M
C900 VE-30000075 MKT CAP. 100NF 250V K (DC)
C901 VE-3 0000433 CER CAP. 1NF 1KV M B
C903 VE-3 0000438 CER CAP. 2.2N F 2KV
C907 VE-30000075 MKT CAP. 100NF 250V K (DC)
TRANSF
TR101 VE-30016154 SMPS TRF
!
TR600 VE-30002090 LINE DRIVER
!
TR60 1 VE-3 0014072 FBT TRF
COIL
L1 VE-30015576 TRF DFOCUS COIL 50HZ E25
!
L102 VE-3 0015617 TRF PFC 200U H
L103 VE-30001996 FIXED COIL 22UH Q40 K
L103 VE-30010964 FERRITE BEAT
L200 VE-30001979 FIXED COIL 1UH Q45 M-A
L201 VE-30006712 FERRITE BEAD 3.5X4.7X0.8
L202 VE-30006712 FERRITE BEAD 3.5X4.7X0.8
L212 VE-30001992 FIXED COIL 10UH Q65 K-A
L225 VE-30013413 FERRITE BEAD
L226 VE-30013413 FERRITE BEAD
L227 VE-30013413 FERRITE BEAD
L228 VE-30013413 FERRITE BEAD
L507 VE-30001987 FIXED COIL 4.7UH Q70 K-A
L600 VE-30002031 FIXED COIL INJECTION 15MH
L601 VE-30002028 FIXED COIL BRIDGE 1.9MH
L603 VE-30007771 FIXED COIL 100UH
DIODE
D10 VE-30001291 DIODE
D106 VE-30001284 DIODE
D11 VE-30001291 DIODE
D118 VE-30009366 DIODE
D119 VE-30001333 DIODE
D123 VE-30001344 ZENER DIODE
D127 VE-30001315 DIODE
D129 VE-30001318 DIODE
D132 VE-30007758 BRIDGE DIODE
!
D133 VE-30001315 DIODE
D136 VE-30001368 ZENER DIODE
D139 VE-30001284 DIODE
D140 VE-30001318 DIODE
D141 VE-30001318 DIODE
D600 VE-30001318 DIODE
D601 VE-30001318 DIODE
D603 VE-30001299 DIODE
D604 VE-30001299 DIODE
D610 VE-30001318 DIODE
D612 VE-30007678 DIODE
D615 VE-30001377 ZENER DIODE
Symbol No. Part No. Part Name Description
!
DIODE
D622 VE-30001318 DIODE
D7 VE-30001291 DIODE
D8 VE-30001291 DIODE
D9 VE-30001291 DIODE
TRANSISTOR
Q100 VE-30001386 TR
Q102 VE-30016755 TR
Q106 VE-30001428 TR
Q107 VE-30001384 TR
Q3 VE-30001454 TR
Q4 VE-30006693 TR
Q600 VE-30001435 TR
Q604 VE-30001429 TR
Q605 VE-30001455 TR
IC
!
IC100 VE-30015087 IC
IC101 VE-30001668 IC
IC102 VE-30001622 IC
IC103 VE-30001500 IC
IC106 VE-30011968 IC
IC107 VE-30011970 IC
IC116 VE-30001506 IC
IC200 VE-30012090 IC
IC201 VE-30001619 IC
IC203 VE-30013685 IC
IC500 VE-30011957 IC (MYCOM)
IC502 VE-20083332 IC (SERVICE)
IC503 VE-30001665 IC
IC600 VE-30007793 IC
IC601 VE-30001506 IC
IC700 VE-30001664 IC
IC701 VE-30007794 IC
OTHERS
CON1 0 VE-3 0001891 RCA JACK
CON1 0 VE-3 0001892 RCA JACK
CON1 0 VE-3 0001893 RCA JACK
CON10 VE-30001900 HEADPHONE JACK
!
F100 VE-20000849 FUSE 3.15A
!
J118 VE-30001244 FUSE RES.
J203 VE-30006712 FERRITE BEAD
L107 VE-30002104 LINE FILTER
!
L108 VE-30002104 LINE FILTER
!
L602 VE-30015221 LINEARITY COIL
!
PL101 VE-30001792 CONN.MALE 2P MOLEX
RL100 VE-30002183 RELAY
TH100 VE-30001270 PTC
!
TU200 VE-30009637 TUNER
X500 VE-30006662 XTAL
X700 VE-30001756 XTAL
Z200 VE-3 0012545 SAW FILTER
Z201 VE-3 0001692 SAW FILTER
CRT SOCKET P.W. BOARD ASS’Y (VE- 20062535)
Refer t o PARTS LIST i n page 22 for this P.W. board.
FRONT CONTROL P.W . BOARD ASS’Y
(VE-20083267)
Refer t o PARTS LIST i n page 22 for this P.W. board.
FRONT AV + HEADPHONE JACK P.W. BOARD
ASS’Y (VE-20083088)
24
Refer t o PARTS LIST i n page 22 for this P.W. board.
No. 51936
A
S
PRINTED WIRING BOARD PARTS LIST
[ AV29BF10EES ]
MAIN P.W. BOARD ASS’Y (VE-20082155)
Symbol No. Part No. Part Name Description
!
RESISTOR
R100 VE-30001259 WW RES. 5W 1R J
R102 VE-30001132 MO RES. 2W 0.22R J
R106 VE-30000767 CF RES. 1/4W 68R J
R109 VE-30000913 MF RES. 1/4W 2K J
R113 VE-30000471 CF RES. 1/4W 10K J
R114 VE-30000729 CF RES. 1/4W 470K J
R118 VE-30001257 MG RES. 1/2W 4.7M J
!
R122 VE-30000459 CF RES. 1/4W 100R J
R128 VE-30000513 CF RES. 1/4W 130K J
R13 VE-30000633 CF RES. 1/4W 27K J
R130 VE-30000471 CF RES. 1/4W 10K J
R131 VE-30000770 CF RES. 1/4W 680R J
R132 VE-30000770 CF RES. 1/4W 680R J
R14 VE-30000481 CF RES. 1/4W 1M J
R142 VE-30000536 CF RES. 1/4W 150K J
R144 VE-30006758 MO RES. 1W 0.82R J
R15 VE-30000541 CF RES. 1/4W 1.5M J
R152 VE-30001132 MO RES. 2W 0.22R J
R153 VE-30001174 MO RES. 2W 0.47R J
R157 VE-30000712 CF RES. 1/4W 470R J
R161 VE-30006755 MO RES. 2W 4.7R J
R17 VE-30000660 CF RES. 1/4W 3.3K J
R206 VE-30000459 CF RES. 1/4W 100R J
R207 VE-30000459 CF RES. 1/4W 100R J
R236 VE-30000792 CF RES. 1/4W 75R J
R279 VE-30000471 CF RES. 1/4W 10K J
R294 VE-30000554 CF RES. 1/4W 180R J
R298 VE-30000471 CF RES. 1/4W 10K J
R300 VE-30000583 CF RES. 1/4W 220R J
R302 VE-30000583 CF RES. 1/4W 220R J
R303 VE-30000655 CF RES. 1/4W 330R J
R304 VE-30000655 CF RES. 1/4W 330R J
R309 VE-30000459 CF RES. 1/4W 100R J
R329 VE-30000460 CF RES. 1/4W 100R G
R331 VE-30000459 CF RES. 1/4W 100R J
R335 VE-30000459 CF RES. 1/4W 100R J
R344 VE-30000723 CF RES. 1/4W 47K J
R365 VE-30000748 CF RES. 1/4W 5.6K J
R366 VE-30000760 CF RES. 1/4W 6.2K J
R369 VE-30000775 CF RES. 1/4W 6.8K J
R405 VE-30000452 CF RES. 1/4W 10R J
R411 VE-30000452 CF RES. 1/4W 10R J
R500 VE-30000500 CF RES. 1/4W 12K J
R501 VE-30000471 CF RES. 1/4W 10K J
R505 VE-30000471 CF RES. 1/4W 10K J
R506 VE-30000471 CF RES. 1/4W 10K J
R513 VE-30000471 CF RES. 1/4W 10K J
R516 VE-30000531 CF RES. 1/4W 15K J
R530 VE-30000718 CF RES. 1/4W 4.7K J
R537 VE-30000560 CF RES. 1/4W 1.8K J
R538 VE-30000560 CF RES. 1/4W 1.8K J
R560 VE-30000459 CF RES. 1/4W 100R J
R561 VE-30000459 CF RES. 1/4W 100R J
R571 VE-30000752 CF RES. 1/4W 56K J
R574 VE-30000706 CF RES. 1/4W 47R J
R600 VE-30000459 CF RES. 1/4W 100R J
R601 VE-30001138 MO RES. 1W 2.7K J
R603 VE-30001138 MO RES. 1W 2.7K J
R604 VE-30001244 FUSE RES. 1/2W 0.47R J
!
R605 VE-30000628 CF RES. 1/4W 2.7K J
!
R606 VE-30001244 FUSE RES. 1/2W 0.47R J
R607 VE-30000554 CF RES. 1/4W 180R J
R611 VE-30000471 CF RES. 1/4W 10K J
R612 VE-30001232 FUSE RES. 1/4W 2.7R J
!
R614 VE-30015721 MO RES. 5W 2.2K J
R615 VE-30000848 MF RES. 1/4W 1K F
!
R617 VE-30001215 FUSE RES. 1W 1R J
R623 VE-30001134 MO RES. 2W 2.2R J
R625 VE-30001162 MO RES. 1W 390R J
R626 VE-30000471 CF RES. 1/4W 10K J
R627 VE-30001088 MO RES. 1W 1R J
R629 VE-30000471 CF RES. 1/4W 10K J
!
R651 VE-30001245 FUSE RES. 1/4W 0.47R J
R652 VE-30001245 FUSE RES. 1/4W 0.47R J
!
R657 VE-30000993 MF RES. 1/4W 51K J
R658 VE-30007202 MF RES. 1/4W 56K F
R659 VE-30000865 MF RES. 1/4W 1.2K J
R670 VE-30015721 MO RES. 5W 2.2K J
V29BF10EE
Symbol No. Part No. Part Name Description
!
RESISTOR
R7 VE-30001155 MO RES. 2W 33K J
R705 VE-30000459 CF RES. 1/4W 100R J
R709 VE-30000466 CF RES. 1/4W 1K J
R712 VE-30000466 CF RES. 1/4W 1K J
R713 VE-30000466 CF RES. 1/4W 1K J
R714 VE-30000466 CF RES. 1/4W 1K J
R719 VE-30000734 CF RES. 1/4W 4.7R J
R720 VE-30000734 CF RES. 1/4W 4.7R J
R748 VE-30000670 CF RES. 1/4W 330K J
R8 VE-30001155 MO RES. 2W 33K J
R907 VE-30000477 CF RES. 1/4W 100K J
R908 VE-30000477 CF RES. 1/4W 100K J
R912 VE-30000477 CF RES. 1/4W 100K J
CAPACITOR
C100 VE-3 0000094 MKT CAP. 220N F AC275V M
!
!
C101 VE-3 0007858 MKT CAP. 470N F AC275V M (P=22. 5MM)
!
C105 VE-30000153 MKP CAP. 330NF 400V J
C107 VE-30000353 EL CAP. 100UF 25V M
C11 VE-30006748 EL CAP. 4.7UF 350V M
C110 VE-30000387 EL CAP. 33UF 50V M
C111 VE-30000266 CER CAP. 560PF 50V J SL
C112 VE-30000092 MKT CAP. 220NF 63V J
C114 VE-30000161 MKP CAP. 47NF 630V J
C115 VE-30007308 CER CAP. 220PF 1KV K (PULSE)
C116 VE-30013690 EL CAP. 220UF 450V M 105°C
C117 VE-30006940 CER CAP. 2.7NF 1KV K B
C118 VE-30007308 CER CAP. 220PF 1KV K (PULSE)
C119 VE-30000440 CER CAP. 2.2NF 4KV M
C12 VE-30006748 EL CAP. 4.7UF 350V M
C122 VE-30000071 MKT CAP. 10NF 63V J
C123 VE-30007308 CER CAP. 220PF 1KV K (PULSE)
C124 VE-30007308 CER CAP. 220PF 1KV K (PULSE)
C126 VE-30007308 CER CAP. 220PF 1KV K (PULSE)
C127 VE-30000406 EL CAP. 47UF 250V M (HR)
C130 VE-30000295 CER CAP. 100NF 50V Z F
C137 VE-30000383 EL CAP. 2200UF 25V M
C138 VE-30000383 EL CAP. 2200UF 25V M
C14 VE-30000436 CER CAP. 10NF 1KV ZE
C142 VE-30000295 CER CAP. 100NF 50V Z F
C143 VE-30000359 EL CAP. 1000UF 16V M
C144 VE-30000360 EL CAP. 1000UF 25V M
C147 VE-30000375 EL CAP. 220UF 16V M
C149 VE-30000375 EL CAP. 220UF 16V M
C15 VE-30000436 CER CAP. 10NF 1KV ZE
C150 VE-30000375 EL CAP. 220UF 16V M
C152 VE-30000295 CER CAP. 100NF 50V Z F
C153 VE-30000295 CER CAP. 100NF 50V Z F
C155 VE-30007308 CER CAP. 220PF 1KV K (PULSE)
C16 VE-30000436 CER CAP. 10NF 1KV ZE
C164 VE-30000411 EL CAP. 4700UF 16V M
C17 VE-3 0000433 CER CAP. 1NF 1KV M B
C173 VE-30000367 EL CAP. 1UF 250V M
!
C180 VE-3 0000076 MKT CAP. 100N F AC275V M
!
C119 VE-30000440 CER CAP. 2.2NF 4KV M
C181 VE-30000440 CER CAP. 2.2NF 4KV M
!
C182 VE-3 0007708 CER CAP. 1NF 1KV K (PU LSE)
C217 VE-30000355 EL CAP. 100UF 50V M
C23 VE-30000146 MKP CAP. 220NF 250V M
C255 VE-30010571 EL CAP. 10UF 16V M
C262 VE-30000384 EL CAP. 2.2UF 50V M
C265 VE-3 0000283 CER CAP. 1NF 50V K B
C274 VE-30000352 EL CAP. 100UF 16V M
C275 VE-30000362 EL CAP. 1UF 50V M
C283 VE-30000384 EL CAP. 2.2UF 50V M
C304 VE-30000345 EL CAP. 10UF 50V M
C306 VE-30000352 EL CAP. 100UF 16V M
C323 VE-30010571 EL CAP. 10UF 16V M
C325 VE-30000345 EL CAP. 10UF 50V M
C326 VE-30000298 CER CAP. 1.5NF 50V K B
C355 VE-30000106 MKT CAP. 47NF 100V J
C356 VE-30000407 EL CAP. 470UF 16V M
C363 VE-30000352 EL CAP. 100UF 16V M
C364 VE-30000352 EL CAP. 100UF 16V M
C365 VE-30000352 EL CAP. 100UF 16V M
C368 VE-30000335 CER CAP. 47NF 50V Z F
No. 51936
25
A
V29BF10EES
Symbol No. Part No. Part Name Description
!
CAPACITOR
C502 VE-30000074 MKT CAP. 100NF 63V J
C520 VE-30000352 EL CAP. 100UF 16V M
C524 VE-30000290 CER CAP. 10NF 50V Z F
C525 VE-30000290 CER CAP. 10NF 50V Z F
C526 VE-30000290 CER CAP. 10NF 50V Z F
C527 VE-30000290 CER CAP. 10NF 50V Z F
C532 VE-30000400 EL CAP. 47UF 50V M
C533 VE-30000400 EL CAP. 47UF 50V M
C534 VE-30000109 MKT CAP. 470NF 63V J
C535 VE-30000400 EL CAP. 47UF 50V M
C536 VE-30000400 EL CAP. 47UF 50V M
C540 VE-3 0007708 CER CAP. 1NF 1KV K (PU LSE)
C600 VE-30000360 EL CAP. 1000UF 25V M
C601 VE-30000075 MKT CAP. 100NF 250V K (DC)
C603 VE-30000351 EL CAP. 10UF 350V M
C604 VE-30000075 MKT CAP. 100NF 250V K (DC)
C605 VE-30000409 EL CAP. 470UF 25V M
C606 VE-30000071 MKT CAP. 10NF 63V J
C607 VE-30000402 EL CAP. 47UF 100V M
C608 VE-30000406 EL CAP. 47UF 250V M (HR)
C611 VE-30000151 MKP CAP. 3.3NF 2KV %3.5
C612 VE-30000131 MKP CAP. 100NF 250V J
C615 VE-30000134 MKP CAP. 11NF 2000V %3.5
C616 VE-30000137 MKP CAP. 15NF 630V J
C617 VE-30000172 MKP CAP. 680NF 250V J (P=15)
C618 VE-3 0000172 MKP CAP. 680NF 250V J (P =15)
C621 VE-30000360 EL CAP. 1000UF 25V M
C623 VE-30000296 CER CAP. 100NF 100V Z F
C636 VE-30000444 CER CAP. 470PF 1KV KB
C637 VE-30000444 CER CAP. 470PF 1KV KB
C638 VE-30000287 CER CAP. 10NF 50V K B
C639 VE-3 0000365 EL C AP. 1UF 1 60V M
C640 VE-30000197 CER CAP. 120PF 50V J SL
C642 VE-30000316 CER CAP. 220NF 25V Z F
C700 VE-30000352 EL CAP. 100UF 16V M
C711 VE-30000407 EL CAP. 470UF 16V M
C740 VE-30000393 EL CAP. 3.3UF 50V M
C759 VE-30000352 EL CAP. 100UF 16V M
C760 VE-30000393 EL CAP. 3.3UF 50V M
C762 VE-30000362 EL CAP. 1UF 50V M
C763 VE-30000362 EL CAP. 1UF 50V M
C767 VE-30000409 EL CAP. 470UF 25V M
C770 VE-30000409 EL CAP. 470UF 25V M
C776 VE-30000371 EL CAP. 22UF 50V M
C780 VE-30000371 EL CAP. 22UF 50V M
C863 VE-30009208 CER CAP. 470PF 1KV K (PULSE)
C865 VE-3 0000283 CER CAP. 1NF 50V K B
C866 VE-30000407 EL CAP. 470UF 16V M
C903 VE-3 0000438 CER CAP. 2.2N F 2KV
C906 VE-30000350 EL CAP. 10UF 250V M
TRANSF
TR101 VE-30016154 SMPS TRF
!
TR600 VE-30002090 LINE DRIVER
!
TR60 1 VE-3 0014072 FBT TRF
COIL
L1 VE-30015576 TRF DFOCUS COIL 50HZ E25
L102 VE-3 0015617 TRF PFC 200U H
!
L103 VE-30001996 FIXED COIL 22UH Q40 K
L103 VE-30010964 FERRITE BEAT
L105 VE-30001992 FIXED COIL 10UH Q65 K-A
L200 VE-30001979 FIXED COIL 1UH Q45 M-A
L201 VE-30006712 FERRITE BEAD 3.5X4.7X0.8
L202 VE-30006712 FERRITE BEAD 3.5X4.7X0.8
L209 VE-30001992 FIXED COIL 10UH Q65 K-A
L210 VE-30001992 FIXED COIL 10UH Q65 K-A
L225 VE-30013413 FERRITE BEAD
L226 VE-30013413 FERRITE BEAD
L227 VE-30013413 FERRITE BEAD
L228 VE-30013413 FERRITE BEAD
L500 VE-30001992 FIXED COIL 10UH Q65 K-A
L501 VE-30001992 FIXED COIL 10UH Q65 K-A
L502 VE-30001992 FIXED COIL 10UH Q65 K-A
L503 VE-30001992 FIXED COIL 10UH Q65 K-A
L504 VE-30001992 FIXED COIL 10UH Q65 K-A
Symbol No. Part No. Part Name Description
!
COIL
L507 VE-30001987 FIXED COIL 4.7UH Q70 K-A
L600 VE-30002031 FIXED COIL INJECTION 15MH
L601 VE-30002028 FIXED COIL BRIDGE 1.9MH
L603 VE-30007771 FIXED COIL 100UH
DIODE
D108 VE-30007681 DIODE
D111 VE-30001291 DIODE
D117 VE-30001315 DIODE
D118 VE-30009366 DIODE
D119 VE-30001333 DIODE
D129 VE-30001318 DIODE
D132 VE-30007758 BRIDGE DIODE
!
D136 VE-30001368 ZENER DIODE
D137 VE-30007681 DIODE
D140 VE-30001318 DIODE
D141 VE-30001318 DIODE
D600 VE-30001318 DIODE
D601 VE-30001318 DIODE
D603 VE-30001299 DIODE
D604 VE-30001299 DIODE
D610 VE-30001318 DIODE
D612 VE-30007678 DIODE
D613 VE-30001291 DIODE
D615 VE-30001377 ZENER DIODE
D622 VE-30001318 DIODE
D905 VE-30001284 DIODE
D906 VE-30001284 DIODE
D907 VE-30001284 DIODE
D908 VE-30001284 DIODE
TRANSISTOR
Q100 VE-30001386 TR
Q101 VE-30001454 TR
Q102 VE-30016755 TR
Q103 VE-30001454 TR
Q105 VE-30001454 TR
Q106 VE-30001428 TR
Q107 VE-30001384 TR
Q4 VE-30006693 TR
Q600 VE-30001435 TR
Q604 VE-30001429 TR
Q605 VE-30001455 TR
IC
!
IC100 VE-30015087 IC
IC101 VE-30001668 IC
IC102 VE-30001622 IC
IC103 VE-30001500 IC
IC106 VE-30011968 IC
IC107 VE-30011970 IC
IC116 VE-30001506 IC
IC200 VE-30012090 IC
IC201 VE-30001619 IC
IC203 VE-30013685 IC
IC500 VE-30011957 IC (MYCOM)
IC502 VE-20082153 IC (SERVICE)
IC503 VE-30001665 IC
IC600 VE-30007793 IC
IC601 VE-30001506 IC
IC700 VE-30001664 IC
IC701 VE-30007794 IC
OTHERS
CAB90 VE-30000190 CER CAP. 100PF 50V J CH
CON1 0 VE-3 0001891 RCA J ACK
CON1 0 VE-3 0001892 RCA JACK
CON1 0 VE-3 0001893 RCA JACK
CON10 VE-30001900 HEADPHONE JACK
DX906 VE-30000190 CER CAP. 100PF 50V J CH
!
F100 VE-20000849 FUSE 3.15A
!
J118 VE-30001244 FUSE RES.
J203 VE-30006712 FERRITE BEAD
L107 VE-30002104 LINE FILTER
!
26
No. 51936
A
S
!
Symbol No. Part No. Part Name Description
OTHERS
!
L108 VE-30002104 LINE FILTER
L602 VE-3 0015221 LINE ARITY COIL
!
PL101 VE-30001792 CONN.MALE 2P MOLEX
RL100 VE-30002183 RELAY
TH100 VE-30001270 PTC
!
TU200 VE-30009637 TUNER
X500 VE-30006662 XTAL
X700 VE-30001756 XTAL
Z200 VE-3 0012545 SAW FILTER
Z201 VE-3 0001692 SAW FILTER
CRT SOCKET PW BOARD ASSY ( VE-200 72781)
Symbol No. Part No. Part Name Description
!
RESISTOR
R900 VE-30000788 CF RES. 1/4W 6.8M J
R906 VE-30000535 CF RES. 1/2W 150K J
R909 VE-30000525 CF RES. 1/2W 1.5K J
R910 VE-30000525 CF RES. 1/2W 1.5K J
R911 VE-30001125 MO RES. 2W 2.2K J
R913 VE-30000525 CF RES. 1/2W 1.5K J
R914 VE-30001084 MO RES. 1W 1K J
R915 VE-30000580 CF RES. 1/4W 22R J
R916 VE-30001170 MO RES. 1W 4.7K J
!
R917 VE-30001230 FUSE RES. 1/2W 27R J
R921 VE-30000599 CF RES. 1/4W 220K J
R922 VE-30000590 CF RES. 1/4W 2.2K J
CAPACITOR
C902 VE-30000415 EL CAP. 4.7UF 250V M
C905 VE-30000234 CER CAP. 270PF 50V J SL
C909 VE-30000385 EL CAP. 2.2UF 250V M
DIODE
D901 VE-30001329 DIODE
D903 VE-30001329 DIODE
D904 VE-30001329 DIODE
D909 VE-30001344 ZENER DIODE
TRANSISTOR
Q900 VE-30001427 TR
IC
IC900 VE-30008721 IC
OTHERS
!
PL90 0 VE-3 0001855 CRT SOCKET
SG900 VE-30000428 SPARK GAP
SG901 VE-30000428 SPARK GAP
SG902 VE-30000428 SPARK GAP
SG903 VE-30000428 SPARK GAP
SG904 VE-30000428 SPARK GAP
V29BF10EE
FRONT CONTRO L P.W. BOARD AS S’Y
(VE-20083267)
Refer to PARTS LIST in page 22 for this P.W. board.
FRONT AV + HEADPHONE JACK P.W. BOARD
ASS’Y (VE-20083088)
Refer t o PARTS LIST i n page 22 for this P.W. board.
No. 51936
27
A
V29BF10ENS
A
A
V29BF10EPS
V29BF10EES
PACKING
3
2
4
5 6!7
1
8
2
PACKING PARTS LIST
!
Ref.No. Part No. Part Name Description
1 VE-5 0022390 F CA RTON BOX (AV2 9BF10ENS )
1 VE-5 0022788 F CA RTON BOX (AV2 9BF10EES )
1 VE-5 0022790 F CA RTON BOX (AV2 9BF10EPS )
2 VE-2 0048248 CU SHION ASS’Y 4 pcs in 1 s et
3 VE-5 0020732 PO LY BAG (1400*1000)
4 VE-7 0000587 PO LY BAG
5 VE-3 0015781 RE MOTE CONTROL UNIT (RM -C85)
!
6 VE-5 0022402 IN ST BOOK (AV29BF10ENS)
6 VE-5 0022857 IN ST BOOK (AV29BF10EES)
!
6 VE-5 0022856 IN ST BOOK (AV29BF10EPS)
!
7 BT-5 4013-2TK WARR ANTY CARD
8 VE-2 0084576 LA BEL (AV2 9BF10ENS )
8 VE-2 0083465 LA BEL (AV2 9BF10EES )
8 VE-2 0083482 LA BEL (AV2 9BF10EPS )
VICTOR COM PANY OF JAPAN, LIMITED
HOME AV NETWORK BUSINESS UNIT 12, 3-chome, Moriya-cho, Kanagawa-ku, Yokohama, Kanagawa-prefecture, 221-8528, Japan
28
No. 51936
VP 0203
DP8080
Loading...
