JVC AV-27320/S/R, AV-27330/S/R, AV-27S33/S/R Parts List

A

V-27320

A

A

V-27330

V-27S33

PARTS LIST

CAUTION

! The parts identifi ed by th e ! sym bol ar e i m por t ant for t he s afe ty. W h enever rep l aci ng the se par ts, be sure t o use spec if ied o nes to se cure

the safety .

!

The parts n ot i nd ic ated i n this P ar ts L i st a nd tho se whic h ar e fil led with l i nes 　　 in the Parts No. columns will not be supplied.

! P. W. Board Ass'y will not be supplied, but those which are filled with the Parts No. in the Parts No. columns will be supplied.

ABBREVIATIONS OF RESISTOR S, CAP ACITORS AND TOLERANCES

RESISTORS CAPACITORS

C R Carbon Resistor C CAP. Ceramic Capacitor

F R Fusible Resistor E CAP. Electrolytic Capacitor

P R Plate Resistor M CAP. Mylar Capacitor

V R Variable Resisto

HV R High Voltage Resistor MF CAP. Metalized Film Capacitor

MF R Metal Film Resistor MM CAP. Metalized Mylar Capacitor

MG R Metal Glazed Resistor MP CAP. Metalize d Polystyrol Capacitor

MP R M etal Plate Resi s to r PP CA P. Po lyp ropyl en e Ca pa citor

OM R M etal Oxi de F ilm Resi stor PS CA P. Polyst yrol Capacitor

CMF R Coating Metal Film Resistor TF CAP. Thin Film Capacitor

UNF R Non-Fl am m abl e R esisto r MPP CAP . Metalize d Pol yprop ylene Cap acito r

CH V R Chip Variable Resistor TAN. CAP. Tantalum Capacitor

CH MG R Chip Metal Glazed Resistor CH C CAP. Chip Ceramic Capacitor

COMP . R Composi t io n Re sist or BP E C AP . Bi-Pola r E l ectrolytic C a pacit or

LP TC R

Linear P ositive T emperat ure Co eff icie nt
Resistor

r

HV CAP. High Voltage Capacitor

CH AL E CAP. Chip Aluminum Electrolytic Capacitor

CH AL BP CA P.

CH TAN. E CAP.

Chip A lum i num B i-Po l ar Cap acitor

Chip T ant alum Elec trol ytic Cap acitor

CH AL BP E CAP.

Chip T ant alum Bi-Po l ar El ectr o l yt ic C a pac itor

TOLERANCES

FGJ KMNRHZ P

±1% ±2% ±5% ±10 % ±20 % ±30 %

+30%

-10%

No.51937

+50%

-10%

+80%

-20%

+100 %

-0%

31

A

V-27320

A

A

V-27330
V-27S33

CONTENTS

! USING P.W. BOARD ･･･････････････････････････････････････････････ ･･････････････････････････ 33

AV-27320/S / AV-27320/R

!

EXPLODED VIEW PARTS LIST

!

EXPLODED VIEW

!

PRINTED WIRING BOARD PARTS LIST

" MAIN PW BOAR D AS S'Y ( SFE- 10 0 6A-M2) [AV-27320/S] ･･･････････････････････････････････････････････ ･･ 36

"

MAIN PW B OARD AS S'Y (SFE- 1 007 A-M2) [A V-2 732 0/R]

･･･････････････････････････････････････････････ ･････････････････････････････

･･･････････････････････････････････････････････ ･････････････････

･･･････････････････････････････････････････････ ･･

34

35

40

! REMOTE CONTROL UNIT PARTS LIST ･･･････････････････････････････････････････････ ･････････ 44

!

PACKING

!

PACKING PA RTS L I ST

････････････････････････････････ ･･･････････････ ････････････････････････････････ ････

･･･････････････････････････････････････････････ ･････････････････････････

45

45

AV-27330/S / AV-27330/R / AV-27S33/S / AV-27S33/R

!

EXPLODED VIEW PARTS LIST

!

EXPLODED VIEW

!

PRINTED WIRING BOARD PARTS LIST

" MAIN PW BOAR D AS S'Y ( SFE- 10 0 4A-M2) [AV-27330/S / AV -2 7S 33/S]･･･････････････ ･････････････････････････

"

MAIN PW B OARD AS S'Y (SFE- 1 005 A-M2) [A V-2 733 0/R / AV- 2 7S3 3/ R]

･･･････････････････････････････････････････････ ･････････････････････････････

! REMOTE CONTROL UNIT PARTS LIST ･･･････････････････････････････････････････････ ･････････ 56

! PACKING ････････････････････････････････ ･･･････････････ ････････････････････････････････････ 57

!

PACKING PA RTS L I ST

･･･････････････････････････････････････････････ ･････････････････････････

･･･････････････････････････････････････････････ ･････････････････

･･･････････････････････････････････････

46

47

48
52

57

32

No.51937

A

A

A

USING P.W. BOARD

V-27320
V-27330

V-27S33

P.W.B AS S'Y

Model

MAI N P.W .B REM OTE CO NT ROL UNIT

AV-2 73 20/S SFE-1006A-M2 RM-C205-1C

AV-2 73 20/R SFE-1007A-M2

AV-2 73 30/S SFE-1004A-M2 RM-C255-1H

AV-2 73 30/R SFE-1005A-M2

AV-2 7S 33 /S SFE-1004A-M2

AV-2 7S 33

/R

SFE-1005A-M2

No.51937

33

A

V-27320

EXPLODED VIEW PARTS LIST

AV-27320

Ref.No. Part No. Part Name Description

!

!!!!

V01 A68QDN891X001 ITC TUBE(C) Inc.DY.PC MAGNET.WEDGE[AV-27320/S]
V01 A68ADT25X01 ITC TUBE(C) Inc.DY.PC MAGNET.WEDGE[AV-27320/R]

!!!!

L01 CE41329-00DJB DEG COIL

!

T1521 QQH0129-001 H.V.TRANSF.

!

1 CHGB0015-0B BRAIDED WIRE
2 CHGB0016-0C BRAIDED WIRE(SUB)

!

3 LC30191-001C-A REMOCON LENS
4 LC30376-001A-A POWER KNOB Within MAIN PWB (CN10PW)

!

!

5 LC30271-001A-A PUSH KNOB

!

6 CEBSS09D-03KJ2 SPEAKER (X2)SP01, SP02

!

7 CM48144-001-A PWB STOPPER
8 LC10082-004A-A REAR COVER

!

9 QMPD390-200-JS POWER CORD or QMPD200-200-JC

!
!

10 LC20106-001D-A CORD CLAMP
11 QYSBSFG4016Z TAPPING SCREW (X7)
12 QYSBSB3010Z TAPPING SCREW (X3)

13 LC31139-001A-A RATING LABEL

!
!

14 LC10081-005B-A FRONT CABINET
15 CM48006-006-C JVC MARK

!

16 GQ30034-001B-A WARNING LABEL

AV-27320/R

/S /

34

No. 51937

A

EXPLODED VIEW

!

16

V01

2

!

V-27320

!

14

15

CRT SOCKET PWB
(Within MAIN PWB)

!

6

MAIN PWB

!

T1521

5

!

!

L01

!

1

!

!

3

4

!

6

!

8

7

NO TE :

13

!

Due to the difference of PICTURE
TU BE , the i llu st ra ti ons ar ound

DEF. YOKE differ slightly.

!

10

!

12

(×3)

9

11

(×7)

No. 51937

35

A

V-27320

AV-27320/S

PRINTED WIRING BOARD PARTS LIST

MAIN P.W. BOARD ASS’Y (SF E-1006A-M2)

!

Symbol No. Part No. Part Name Description

RESISTOR

R1003-04 NRSA63J-221X MG R 220Ω 1/16W J
R1005 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R1006 NRSA63J-223X MG R 22kΩ 1/16W J
R1008 NRSA63J-820X MG R 82Ω 1/16W J

R1101 NRSA63J-562X MG R 5.6kΩ 1/16W J
R1102 NRSA63J-182X MG R 1.8kΩ 1/16W J
R1103 QRE121J-101Y C R 100Ω 1/2W J
R1104 NRSA63J-180X MG R 18Ω 1/16W J

R1105 NRSA63J-270X MG R 27Ω 1/16W J
R1111-12 NRSA63J-154X MG R 150kΩ 1/16W J
R1113 NRSA63J-101X MG R 100Ω 1/16W J

R1115 NRSA63J-101X MG R 100Ω 1/16W J
R1116 NRSA63J-680X MG R 68Ω 1/16W J
R1117 NRSA63J-273X MG R 27kΩ 1/16W J
R1131 NRSA63J-102X MG R 1kΩ 1/16W J
R1132 NRSA63J-221X MG R 220Ω 1/16W J

R1133 NRSA63J-821X MG R 820Ω 1/16W J
R1134 NRSA63J-681X MG R 680Ω 1/16W J

R1135 NRSA63J-102X MG R 1kΩ 1/16W J
R1161 NRSA63J-332X MG R 3.3kΩ 1/16W J
R1163 NRSA63J-223X MG R 22kΩ 1/16W J
R1164 NRSA63J-102X MG R 1kΩ 1/16W J
R1165 NRSA63J-223X MG R 22kΩ 1/16W J

R1166 NRSA63J-103X MG R 10kΩ 1/16W J

R1167 NRSA63J-102X MG R 1kΩ 1/16W J
R1168 NRSA63J-101X MG R 100Ω 1/16W J

R1169 NRSA63J-561X MG R 560Ω 1/16W J
R1171 NRSA63J-103X MG R 10kΩ 1/16W J
R1201 NRSA63J-223X MG R 22kΩ 1/16W J
R1227 NRSA63J-104X MG R 100kΩ 1/16W J
R1251 NRSA63J-332X MG R 3.3kΩ 1/16W J

R1252 NRSA63J-103X MG R 10kΩ 1/16W J

R1253 NRSA63J-102X MG R 1kΩ 1/16W J
R1254 NRSA63J-181X MG R 180Ω 1/16W J
R1255-56 NRSA63J-152X MG R 1.5kΩ 1/16W J
R1257 NRSA63J-222X MG R 2.2kΩ 1/16W J
R1261-63 NRSA63J-101X MG R 100Ω 1/16W J
R1264 NRSA63J-821X MG R 820Ω 1/16W J

R1280 QRE141J-102Y C R 1kΩ 1/4W J
R1282 NRSA63J-222X MG R 2.2kΩ 1/16W J

R1283 NRSA63J-821X MG R 820Ω 1/16W J
R1285 NRSA63J-331X MG R 330Ω 1/16W J
R1286-87 NRSA63J-102X MG R 1kΩ 1/16W J
R1288 NRSA63J-0R0X MG R 0.0Ω 1/16W J

R1289 QRE141J-102Y C R 1kΩ 1/4W J
R1290 QRE141J-102Y C R 1kΩ 1/4W J
R1292 NRSA63J-222X MG R 2.2kΩ 1/16W J
R1293 NRSA63J-471X MG R 470Ω 1/16W J

R1295 NRSA63J-331X MG R 330Ω 1/16W J
R1296-97 NRSA63J-102X MG R 1kΩ 1/16W J
R1298 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R1299 QRE141J-102Y C R 1kΩ 1/4W J

R1301 NRSA63J-151X MG R 150Ω 1/16W J
R1302 QRL029J-123 OM R 12kΩ 2W J
R1303 QRZ0111-152 C R 1.5kΩ 1/2W K
R1304 NRSA63J-103X MG R 10kΩ 1/16W J

R1305 NRSA63J-331X MG R 330Ω 1/16W J
R1306 NRSA63J-101X MG R 100Ω 1/16W J
R1311 NRSA63J-151X MG R 150Ω 1/16W J

R1312 QRL029J-123 OM R 12kΩ 2W J
R1313 QRZ0111-152 C R 1.5kΩ 1/2W K
R1314 NRSA63J-103X MG R 10kΩ 1/16W J
R1315 NRSA63J-331X MG R 330Ω 1/16W J
R1316 NRSA63J-101X MG R 100Ω 1/16W J

!

Symbol No. Part No. Part Name Description

RESISTOR

R1321 NRSA63J-151X MG R 150Ω 1/16W J
R1322 QRL029J-123 OM R 12kΩ 2W J
R1323 QRZ0111-152 C R 1.5kΩ 1/2W K
R1324 NRSA63J-103X MG R 10kΩ 1/16W J

R1325 NRSA63J-331X MG R 330Ω 1/16W J
R1326 NRSA63J-101X MG R 100Ω 1/16W J
R1354 NRSA63J-331X MG R 330Ω 1/16W J
R1356 NRSA63J-123X MG R 12kΩ 1/16W J

R1359 NRSA63J-103X MG R 10kΩ 1/16W J
R1360 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R1364-66 NRSA63J-101X MG R 100Ω 1/16W J

R1401 NRSA63J-102X MG R 1kΩ 1/16W J
R1402 NRSA63J-472X MG R 4.7kΩ 1/16W J
R1403 NRSA63J-103X MG R 10kΩ 1/16W J
R1405 NRSA63J-103X MG R 10kΩ 1/16W J
R1407-08 QRE121J-681Y C R 680Ω 1/2W J

R1409 QRX01GJ-1R0 MF R 1.0Ω 1W J
R1411 NRSA63J-123X MG R 12kΩ 1/16W J

R1412 NRSA63J-153X MG R 15kΩ 1/16W J
R1414 NRSA63J-103X MG R 10kΩ 1/16W J
R1416 QRE121J-102Y C R 1kΩ 1/2W J
R1501 NRSA63J-472X MG R 4.7kΩ 1/16W J
R1502 NRSA63J-681X MG R 680Ω 1/16W J

R1504 NRSA63J-392X MG R 3.9kΩ 1/16W J

R1505 NRSA63J-154X MG R 150kΩ 1/16W J
R1506 NRSA63J-471X MG R 470Ω 1/16W J

R1507 NRSA63J-561X MG R 560Ω 1/16W J
R1508 NRSA63J-101X MG R 100Ω 1/16W J
R1509 NRSA63J-271X MG R 270Ω 1/16W J
R1510 QRE121J-103Y C R 10kΩ 1/2W J
R1511-12 QRG029J-182 OM R 1.8kΩ 2W J

R1521 QRE121J-220Y C R 22Ω 1/2W J

R1522 QRE121J-681Y C R 680Ω 1/2W J
R1523 QRL039J-152 OM R 1.5kΩ 3W J
R1524 QRE121J-224Y C R 220kΩ 1/2W J
R1525 QRE121J-184Y C R 180kΩ 1/2W J
R1526 QRK129J-150 C R 15Ω 1/2W J

!

R1527 QRX01GJ-1R0 MF R 1.0Ω 1W J
R1528 QRE121J-472Y C R 4.7kΩ 1/2W J

R1529 QRK126J-4R7X C R 4.7Ω 1/2W J

R1530 QRX029J-1R5 MF R 1.5Ω 2W J

!
!

R1531 NRZ0032-7151X MF R 7.15kΩ 1/10W±0.5%
R1533 NRZ0032-2941X MF R 2.94kΩ 1/10W±0.5%

!

R1541 QRE121J-683Y C R 68kΩ 1/2W J
R1614 QRL039J-100 OM R 10Ω 3W J

R1615-16 NRSA63J-123X MG R 12kΩ 1/16W J
R1617-18 NRSA63J-332X MG R 3.3kΩ 1/16W J
R1619-20 NRSA63J-471X MG R 470Ω 1/16W J

R1621 QRE121J-4R7Y C R 4.7Ω 1/2W J
R1622 QRE121J-4R7Y C R 4.7Ω 1/2W J
R1625 NRSA63J-333X MG R 33kΩ 1/16W J
R1627 NRSA63J-101X MG R 100Ω 1/16W J

R1651-52 NRSA63J-101X MG R 100Ω 1/16W J
R1653 NRSA63J-105X MG R 1MΩ 1/16W J
R1654 NRSA63J-104X MG R 100kΩ 1/16W J
R1655 NRSA63J-682X MG R 6.8kΩ 1/16W J

R1656 NRSA63J-123X MG R 12kΩ 1/16W J
R1657 NRSA63F-623X MG R 62kΩ 1/16W F
R1658 NRSA63J-332X MG R 3.3kΩ 1/16W J

R1659 NRSA63J-302X MG R 3kΩ 1/16W J
R1661 NRSA63J-392X MG R 3.9kΩ 1/16W J
R1662-63 NRSA63J-681X MG R 680Ω 1/16W J
R1664-65 NRSA63J-101X MG R 100Ω 1/16W J
R1681-82 NRSA63J-681X MG R 680Ω 1/16W J

36

No. 51937

A

AV-27320/S

V-27320

Symbol No. Part No. Part Name Description

!

RESISTOR

R1683-86 NRSA63J-223X MG R 22kΩ 1/16W J
R1687-88 NRSA63J-221X MG R 220Ω 1/16W J
R1691-92 NRSA63J-823X MG R 82kΩ 1/16W J
R1701-02 NRSA63J-102X MG R 1kΩ 1/16W J
R1703 NRSA63J-103X MG R 10kΩ 1/16W J
R1704-06 NRSA63J-472X MG R 4.7kΩ 1/16W J
R1707 NRSA63J-103X MG R 10kΩ 1/16W J

R1708-09 NRSA63J-101X MG R 100Ω 1/16W J

R1714 NRSA63J-823X MG R 82kΩ 1/16W J
R1718 NRSA63J-223X MG R 22kΩ 1/16W J
R1720 QRJ149J-1R0 C R 1.0Ω 1/4W J
R1721 NRSA63J-102X MG R 1kΩ 1/16W J
R1731-32 NRSA63J-101X MG R 100Ω 1/16W J

R1733-34 NRSA63J-472X MG R 4.7kΩ 1/16W J
R1739 NRSA63J-272X MG R 2.7kΩ 1/16W J
R1740 NRSA63J-101X MG R 100Ω 1/16W J

R1751-52 NRSA63J-102X MG R 1kΩ 1/16W J
R1753 NRSA63J-152X MG R 1.5kΩ 1/16W J
R1754 NRSA63J-272X MG R 2.7kΩ 1/16W J
R1755 NRSA63J-562X MG R 5.6kΩ 1/16W J

R1756 NRSA63J-122X MG R 1.2kΩ 1/16W J
R1757-58 NRSA63J-101X MG R 100Ω 1/16W J
R1764-67 NRSA63J-471X MG R 470Ω 1/16W J
R1768 NRSA63J-682X MG R 6.8kΩ 1/16W J

R1769 NRSA63J-102X MG R 1kΩ 1/16W J
R1770 NRSA63J-103X MG R 10kΩ 1/16W J
R1771 NRSA63J-153X MG R 15kΩ 1/16W J
R1772-75 NRSA63J-103X MG R 10kΩ 1/16W J

R1776-77 NRSA63J-101X MG R 100Ω 1/16W J
R1778 NRSA63J-103X MG R 10kΩ 1/16W J
R1801 NRSA63J-680X MG R 68Ω 1/16W J
R1803-04 NRSA63J-750X MG R 75Ω 1/16W J

R1805 NRSA63J-101X MG R 100Ω 1/16W J
R1821 NRSA63J-124X MG R 120kΩ 1/16W J

R1831-33 NRSA63J-750X MG R 75Ω 1/16W J
R1834-36 NRSA63J-101X MG R 100Ω 1/16W J
R1851-54 NRSA63J-101X MG R 100Ω 1/16W J
R1855 NRSA63J-153X MG R 15kΩ 1/16W J
R1856 NRSA63J-101X MG R 100Ω 1/16W J
R1857 NRSA63J-103X MG R 10kΩ 1/16W J

R1861 NRSA63J-101X MG R 100Ω 1/16W J
R1862 NRSA63J-104X MG R 100kΩ 1/16W J

R1863 NRSA63J-473X MG R 47kΩ 1/16W J
R1901 QRF074K-R47 UNF R 0.47Ω 7W K

!

R1902-03 QRE121J-473Y C R 47kΩ 1/2W J

!

R1904-05 QRT029J-R22 MF R 0.22Ω 2W J
R1906 QRE121J-2R2Y C R 2.2Ω 1/2W J

R1907 QRE121J-472Y C R 4.7kΩ 1/2W J

R1908 QRK126J-681X C R 680Ω 1/2W J
R1910 QRE121J-684Y C R 680kΩ 1/2W J

R1911 QRG01GJ-470 OM R 47Ω 1W J
R1921 QRE121J-100Y MF R 10Ω 1/2W J

!

R1922 NRSA63J-472X MG R 4.7kΩ 1/16W J
R1923 NRSA63J-473X MG R 47kΩ 1/16W J

!

R1924 QRX01GJ-1R0 MF R 1.0Ω 1W J
R1925 QRX01GJ-1R0 MF R 1.0Ω 1W J

!

R1926 QRT029J-1R2 MF R 1.2Ω 2W J

!

R1927 QRT029J-1R2 MF R 1.2Ω 2W J

!

R1928 QRE121J-272Y C R 2.7kΩ 1/2W J
R1929 QRE121J-223Y C R 22kΩ 1/2W J
R1930 QRE121J-473Y C R 47kΩ 1/2W J

R1932-33 NRSA63J-123X MG R 12kΩ 1/16W J
R1934 NRSA63J-273X MG R 27kΩ 1/16W J
R1935 NRSA63J-333X MG R 33kΩ 1/16W J

R1936 QRE121J-103Y C R 10kΩ 1/2W J
R1938-39 QRE121J-103Y C R 10kΩ 1/2W J
R1941 QRG029J-180 OM R 18 Ω 2W J
R1942 QRE121J-5R6Y C R 5.6Ω 1/2W J
R1943 QRE121J-820Y C R 82Ω 1/2W J

R1991 QRZ9041-275 C R 2.7MΩ 1/2W K

Symbol No. Part No. Part Name Description

!

CAPACITOR

C1001 QETN1HM-475Z E CAP. 4.7µF 50V M
C1002 NCB31HK-103X C CAP. 0.01µF 50V K
C1003 QETN1EM-476Z E CAP. 47µF 25V M
C1004 QETN1AM-227Z E CAP. 220µF 10V M
C1005 NCB31HK-103X C CAP. 0.01µF 50V K
C1101 -02 NCB31HK-103X C CAP. 0.01µF 50V K
C1104-05 NCB31HK-103X C CAP. 0.01µF 50V K

C1106 QETN1EM-476Z E CAP. 47µF 25V M

C1107 NCB31HK-103X C CAP. 0.01µF 50V K
C1113-14 NCB31HK-103X C CAP. 0.01µF 50V K
C1116 NCB31CK-224X C CAP. 0.22µF 16V K
C1117 QETN1EM-476Z E CAP. 47µF 25V M
C1118 NCB31HK-103X C CAP. 0.01µF 50V K

C1119 NDC31HJ-681X C CAP. 680pF 50V J
C1120 QETN1HM-474Z E CAP. 0.47µF 50V M

C1124 NCB31HK-103X C CAP. 0.01µF 50V K

C1131 NCB31HK-103X C CAP. 0.01µF 50V K
C1161-62 QETN1HM-106Z E CAP. 10µF 50V M
C1163-64 NDC31HJ-470X C CAP. 47pF 50V J

C1165-66 NCB31HK-103X C CAP. 0.01µF 50V K
C1202 QETN1HM-105Z E CAP. 1µF 50V M

C1203 NCB31HK-152X C CAP. 1500pF 50V K
C1221 QETN1HM-106Z E CAP. 10µF 50V M
C1222 NCB31HK-104X C CAP. 0.1µF 50V K

C1237 NCB31HK-103X C CAP. 0.01µF 50V K
C1241 NCB31HK-103X C CAP. 0.01µF 50V K
C1243 QETN1EM-476Z E CAP. 47µF 25V M
C1244 NCB31HK-103X C CAP. 0.01µF 50V K

C1247 QETN1HM-225Z E CAP. 2.2µF 50V M
C1252 NDC31HJ-101X C CAP. 100pF 50V J

C1253 NDC31HJ-470X C CAP. 47pF 50V J
C1254 NDC31HJ-181X C CAP. 180pF 50V J

C1261 NCB31HK-103X C CAP. 0.01µF 50V K
C1262 QETN1EM-476Z E CAP. 47µF 25V M
C1263-64 NCB31HK-103X C CAP. 0.01µF 50V K

C1265 QETN1HM-474Z E CAP. 0.47µF 50V M
C1266-67 NCB31HK-103X C CAP. 0.01µF 50V K
C1268 QETN1EM-476Z E CAP. 47µF 25V M
C1269 NCB31HK-103X C CAP. 0.01µF 50V K
C1270 QETN1EM-476Z E CAP. 47µF 25V M

C1272-73 NCB31HK-103X C CAP. 0.01µF 50V K
C1274 NDC31HJ-181X C CAP. 180pF 50V J

C1275 QETN1EM-476Z E CAP. 47µF 25V M
C1276-78 NCB31HK-103X C CAP. 0.01µF 50V K

C1283 NDC31HJ-330X C CAP. 33pF 50V J
C1285 QETN1EM-476Z E CAP. 47µF 25V M

C1293 NDC31HJ-150X C CAP. 15pF 50V J
C1295 QFLC1HJ-103Z M CAP. 0.01µF 50V J

C1302 NDC31HJ-331X C CAP. 330pF 50V J
C1312 NDC31HJ-271X C CAP. 270pF 50V J
C1322 NDC31HJ-271X C CAP. 270pF 50V J

C1341 QETN1EM-476Z E CAP. 47µF 25V M

!

C1343 QCZ0121-102 C CAP. 1000pF
C1352 QETN1EM-476Z E CAP. 47µF 25V M

C1354 NCB31HK-103X C CAP. 0.01µF 50V K
C1361 QETN1EM-476Z E CAP. 47µF 25V M

C1362 NCB31HK-103X C CAP. 0.01µF 50V K
C1401 QFV71HJ-474Z MF CAP. 0.47µF 50V J

C1402 NCB31HK-102X C CAP. 1000pF 50V K
C1403 QENC1CM-106Z E CAP. 10µF 16V M

C1404 NCB31HK-222X C CAP. 2200pF 50V K
C1405 QETN1HM-106Z E CAP. 10µF 50V M

C1406 NCB31HK-102X C CAP. 1000pF 50V K
C1407 QETN1VM-107Z E CAP. 100µF 35V M

C1408 QCS32HJ-100Z C CAP. 10pF 500V J
C1409-10 QFLC2AK-104Z M CAP. 0.1µF 100V K
C1411 QETM1VM-228 E CAP. 2200µF 35V M
C1412 QETN1HM-225Z E CAP. 2.2µF 50V M
C1501 QETN1EM-476Z E CAP. 47µF 25V M

C1502-03 NCB31HK-103X C CAP. 0.01µF 50V K
C1504 QETN1HM-225Z E CAP. 2.2µF 50V M
C1505 NCB31AK-474X C CAP. 0.47µF 10V K

3kV Z

No. 51937

37

A

V-27320

AV-27320/S

Symbol No. Part No. Part Name Description

!

CAPACITOR

C1506 QETN1EM-476Z E CAP. 47µF 25V M
C1507 NCB31HK-103X C CAP. 0.01µF 50V K

C1508 QCB32HK-151Z C CAP. 150pF 500V K
C1509 QCB32HK-331Z C CAP. 330pF 500V K

C1510 QETN2EM-225Z E CAP. 2.2µF 250V M
C1522 QFZ0198-133 MPP CAP. 0.013 µF1.5kVH±3%

!
!

C1523 QFZ0197-624 MPP CAP. 0.62µF 250V J
C1524 QCB32HK-561Z C CAP. 560pF 500V K

C1525 QEZ0203-107 E CAP. 100µF 160V M
C1526 QFLC1HJ-823Z M CAP. 0.082 µF 50V J

C1527 QETN2EM-106Z E CAP. 10µF 250V M
C1528 QETN1VM-477Z E CAP. 470µF 35V M
C1529 QETN1VM-476Z E CAP. 47µF 35V M
C1530 QFLC2AJ-103Z M CAP. 0.01µF 100V J
C1611-12 QETN1HM-106Z E CAP. 10µF 50V M
C1614 QETN1CM-477Z E CAP. 470µF 16V M

C1616 QETN1HM-106Z E CAP. 10µF 50V M
C1617 QETN1CM-227Z E CAP. 220µF 16V M

C1618 QETN1CM-107Z E CAP. 100µF 16V M
C1619 QETN1CM-477Z E CAP. 470µF 16V M
C1620 NCF31CZ-104X C CAP. 0.1µF 16V Z
C1622 QETN1HM-106Z E CAP. 10µF 50V M
C1623 QETN1CM-227Z E CAP. 220µF 16V M
C1624 QETN1HM-107Z E CAP. 100µF 50V M

C1625 QETN1CM-477Z E CAP. 470µF 16V M
C1626 NCF31CZ-104X C CAP. 0.1µF 16V Z

C1627 QETN1EM-476Z E CAP. 47µF 25V M
C1651 QENC1HM-475Z E CAP. 4.7µF 50V M
C1652 NCB31HK-104X C CAP. 0.1µF 50V K
C1653 QENC1HM-475Z E CAP. 4.7µF 50V M

C1654 NCB31HK-562X C CAP. 5600pF 50V K
C1655 NCB31HK-123X C CAP. 0.012 µF 50V K

C1656 QETN1HM-105Z E CAP. 1µF 50V M
C1657-58 QETN1HM-106Z E CAP. 10µF 50V M

C1659 QETN1HM-475Z E CAP. 4.7µF 50V M
C1660 QETN1EM-476Z E CAP. 47µF 25V M
C1661 NCB31HK-103X C CAP. 0.01µF 50V K
C1662 QENC1HM-475Z E CAP. 4.7µF 50V M
C1663 QETN1HM-475Z E CAP. 4.7µF 50V M
C1664 QENC1HM-475Z E CAP. 4.7µF 50V M

C1665 NCB31HK-272X C CAP. 2700pF 50V K
C1666 NCB31HK-473X C CAP. 0.047 µF 50V K
C1667 QETN1HM-335Z E CAP. 3.3µF 50V M

C1668 QENC1HM-475Z E CAP. 4.7µF 50V M
C1669 QETN1HM-106Z E CAP. 10µF 50V M
C1670 QETN1HM-105Z E CAP. 1µF 50V M
C1671-72 QETN1HM-106Z E CAP. 10µF 50V M
C1673 NCB31HK-223X C CAP. 0.022 µF 50V K

C1674 NCB31HK-472X C CAP. 4700pF 50V K
C1675 QENC1HM-475Z E CAP. 4.7µF 50V M
C1676 NCB31HK-104X C CAP. 0.1µF 50V K

C1677 NCB31HK-472X C CAP. 4700pF 50V K
C1681-84 QETN1HM-106Z E CAP. 10µF 50V M
C1687-88 QETN1HM-106Z E CAP. 10µF 50V M

C1701 NCB31HK-102X C CAP. 1000pF 50V K
C1702-03 QETN1HM-106Z E CAP. 10µF 50V M

C1704 QETN1EM-476Z E CAP. 47µF 25V M
C1705 NCB31HK-103X C CAP. 0.01µF 50V K

C1708-09 NDC31HJ-220X C CAP. 22pF 50V J
C1711 QETN1EM-476Z E CAP. 47µF 25V M

C1712 NCB31HK-103X C CAP. 0.01µF 50V K
C1716 QETN1HM-106Z E CAP. 10µF 50V M
C1751 QETN1EM-476Z E CAP. 47µF 25V M
C1801 QETN1HM-106Z E CAP. 10µF 50V M

C1803 QETN1HM-105Z E CAP. 1µF 50V M
C1804 QETN1HM-106Z E CAP. 10µF 50V M
C1807 NCB31HK-103X C CAP. 0.01µF 50V K

C1815 NCB31HK-103X C CAP. 0.01µF 50V K
C1831-33 NCB31HK-104X C CAP. 0.1µF 50V K
C1834 QETN1HM-106Z E CAP. 10µF 50V M
C1851-52 NCB31HK-103X C CAP. 0.01µF 50V K
C1853 QETN1HM-106Z E CAP. 10µF 50V M

Symbol No. Part No. Part Name Description

!

CAPACITOR

C1854-56 NCB31HK-103X C CAP. 0.01µF 50V K
C1857 QETN1HM-106Z E CAP. 10µF 50V M
C1858-60 NCB31HK-103X C CAP. 0.01µF 50V K
C1861 QETN1EM-476Z E CAP. 47µF 25V M
C1862 QETN1HM-106Z E CAP. 10µF 50V M
C1863-65 NCB31HK-103X C CAP. 0.01µF 50V K

!

C1901 QFZ9072-104 MF CAP. 0.1µFAC275V K
C1902 QFZ9072-104 MF CAP. 0.1µFAC275V K

!

C1903 QEZ0169-477 E CAP. 470µF 200V M
C1904 QCZ9054-102 C CAP. 1000pFAC250V Z

!
!

C1905 QCZ9054-102 C CAP . 1000pFAC250V Z
C1907 QETN1HM-476Z E CAP. 47µF 50V M

C1908 QCZ0340-102 C CAP. 1000pF 2kV K
C1909 NDC31HJ-102X C CAP. 1000pF 50V J
C1910 NDC31HJ-471X C CAP. 470pF 50V J
C1911 DFP32GJ-103Z PP CAP. 0.01pF 400V J

!

C1921 QETN1EM-477Z E CAP. 470µF 25V M

C1922 QETN1CM-107Z E CAP. 100µF 16V M
C1923 QEZ0203-107 E CAP. 100µF 160V M
C1924 QETN2CM-476Z E CAP. 47µF 160V M
C1925 QETN1CM-477Z E CAP. 470µF 16V M
C1926 QETN1CM-107Z E CAP. 100µF 16V M

C1927 QETN1CM-477Z E CAP. 470µF 16V M
C1929 QCZ0340-102 C CAP. 1000pF 2kV K

C1930-31 QCB32HK-102Z C CAP. 1000pF 500V K

C1932 QETN0JM-107Z E CAP. 100µF 6.3V M
C1933 QETN1VM-476Z E CAP. 47µF 35V M

C1935 QETN1CM-476Z E CAP. 47µF 16V M
C1940 NCB31HK-103X C CAP. 0.01µF 50V K
C1941-42 QETN1CM-107Z E CAP. 100µF 16V M
C1943 NCB31HK-103X C CAP. 0.01µF 50V K
C1944 QETN1CM-107Z E CAP. 100µF 16V M
C1945 NCB31HK-103X C CAP. 0.01µF 50V K

C1991 QCZ9074-103 C CAP. 0.01µFAC250V M

!

C1992 QCZ9074-103 C CAP. 0.01µFAC250V M

!

TRANSFORMER

T1111 QQR0907-001 I.F.TRANSFOMER
T1501 CE42034-002 H.DRIVE TRANSF.

!

T1521 QQH0129-001 H.V.TRANSF.

!

T1901 QQT0355-001 POWER TRANSF.
T1921 QQS0158-001 SWITCH.TRANSF.

!

COIL

L1101 QQLZ014-R39 PEAKING COIL
L1131 QQL244K-220Z PEAKING COIL
L1161 QQL244K-220Z PEAKING COIL

L1251 QQL244K-4R7Z COIL 4.7µH K
L1281 QQL244K-150Z COIL 15µH K
L1291 QQL244K-150Z COIL 15µH K
L1341 QQL03BJ-390Z COIL 39µH J

L1521 QQR1027-004 LINE FILTER

L1921-22 QQL26AK-470Z COIL 47µH K

DIODE

D1352 MTZJ9.1C-T2 ZENER DIODE
D1353 1SS133-T2 SI.DIODE
D1365 1SS133-T2 SI.DIODE
D1366 1SS133-T2 SI.DIODE

D1367 1SS133-T2 SI.DIODE
D1368 1SS133-T2 SI.DIODE
D1369 1SS133-T2 SI.DIODE
D1370 1SS133-T2 SI.DIODE

D1401 1SR35-400A-T2 SI.DIODE
D1402 MTZJ75-T2 ZENER DIODE
D1501 MTZJ3.3A-T2 ZENER DIODE
D1521 1SR35-400A-T2 SI.DIODE
D1522 RH1S-T3 SI.DIODE

D1523 1SR35-400A-T2 SI.DIODE
D1524 RGP10J-5025-T3 SI.DIODE
D1525 MTZJ5.6A-T2 ZENER DIODE

38

No. 51937

A

AV-27320/S

V-27320

Symbol No. Part No. Part Name Description

!

DIODE

D1526 MA4068N/Z1/-T2 ZENER DIODE
D1661 MTZJ9.1C-T2 ZENER DIODE
D1681-84 MTZJ9.1C-T2 ZENER DIODE
D1687-88 MTZJ9.1C-T2 ZENER DIODE

D1705 1SS133-T2 SI.DIODE
D1751 SLR-342VR3F L.E.D.
D1801 MTZJ9.1C-T2 ZENER DIODE
D1803-04 MTZJ9.1C-T2 ZENER DIODE

D1807 MTZJ9.1C-T2 ZENER DIODE
D1831-34 MTZJ9.1C-T2 ZENER DIODE

!

D1901 GSIB460-S1 DIODE
D1902 RGP10J-5025-T3 SI.DIODE
D1903 RGP10J-5025-T3 SI.DIODE
D1904 RGP10J-5025-T3 SI.DIODE

D1905 SARS01-T2 SI.DIODE
D1908 MTZJ15C-T2 ZENER DIODE

D1921-24 1SR35-400A-T2 SI.DIODE
D1925 1SS133-T2 SI.DIODE

D1926 RU3AM-LFC4 SI.DIODE
D1927 RU3YX-LFC4 SI.DIODE
D1928 RU3YX-LFC4 SI.DIODE
D1930 1SS133-T2 SI.DIODE
D1931 1SS133-T2 SI.DIODE

D1932 MTZJ33B-T2 ZENER DIODE

D1933 1N4002G-T2 SI.DIODE

TRANSISTOR

Q1001 DTC124EKA-X DIGI.TRANSISTOR
Q1101 2SC5083/L-P/-T SI.TRANSISTOR
Q1131 2SB709A/QR/-X SI.TRANSISTOR

Q1161 2SC2412K/QR/-X SI.TRANSISTOR
Q1251-52 2SD601A/QR/-X SI.TRANSISTOR
Q1281 2SB709A/QR/-X SI.TRANSISTOR
Q1282 2SD601A/QR/-X SI.TRANSISTOR
Q1283 2SB709A/QR/-X SI.TRANSISTOR

Q1291 2SB709A/QR/-X SI.TRANSISTOR
Q1292 2SD601A/QR/-X SI.TRANSISTOR
Q1293 2SB709A/QR/-X SI.TRANSISTOR
Q1301 2SC4544-LB SI.TRANSISTOR
Q1311 2SC4544-LB SI.TRANSISTOR

Q1321 2SC4544-LB SI.TRANSISTOR
Q1352 2SD601A/QR/-X SI.TRANSISTOR
Q1501 2SC4212/Z1/ SI.TRANSISTOR

Q1521 2SD2634-YD SI.TRANSISTOR H.OUT

!

Q1602 DTC124EKA-X DIGI.TRANSISTOR
Q1681 2SB709A/QR/-X SI.TRANSISTOR
Q1682 2SD601A/QR/-X SI.TRANSISTOR
Q1683 2SB709A/QR/-X SI.TRANSISTOR
Q1684 2SD601A/QR/-X SI.TRANSISTOR

Q1701 2SB709A/QR/-X SI.TRANSISTOR
Q1751 DTA124EKA-X DIGI.TRANSISTOR

Q1851 2SD601A/QR/-X SI.TRANSISTOR
Q1921 2SD1383K/AB/-X SI.TRANSISTOR

Q1922 2SC2785/JH/-T SI.TRANSISTOR
Q1923 2SA1037AK/QR/-X SI.TRANSISTOR
Q1924 2SA1208/ST/Z1-T SI.TRANSISTOR

IC

IC1101 M52342SP I.C(MONO-ANA)
IC1201 TM8812CSANG3PF2 I.C(M)
IC1251 TC90A49P I.C(DIGI-MOS)
IC1421 AN5522 I.C(MONO-ANA)

!
!

IC1602 LA4446 I.C(MONO-ANA)
IC1603 CXA2134Q-X I.C(M)
IC1702 AT24C04-27D303 I.C (SERVICE)
IC1703 S-80840CNY-T I.C(MONO-ANA)

IC1704 AN78L05-T I.C(MONO-ANA)
IC1751 GP1UM281QK IFR DETECT UNIT
IC1851 TA1218AN I.C(MONO-ANA)
IC1901 STR-G5624A/F8 I C
IC1921 AN7809F I.C(MONO-ANA)

IC1922 AN7805F I.C(MONO-ANA)

Symbol No. Part No. Part Name Description

!

OTHERS

CF1001 QAX0349-001 CERAMIC FILTER
CF1131 QAX0639-001Z CERAMIC FILTER
CF1161 QAX0642-001Z CERAMIC FILTER

CL1003 QZW0027-001 WIRE CLAMP

!

CN10PW QMPD390-200-JS POWER CORD or QMPD200-200-JC

!

F1901 QMF51N1-5R0-J5 FUSE 5.0A
FC1901 CEMG002-001Z FUSE CLIP (X2)

J1001 QNZ0531-001 AV JACK
J1002 QNN0348-001 PIN JACK
J1003 QNN0349-002 PIN JACK
J1005 CEMN065-001 PIN JACK
J1006 CEMN065-002 PIN JACK
J1007 CEMN072-003 PIN JACK

K1001 QQR0582-001Z BEADS CORE
K1101 QQR0582-001Z BEADS CORE
K1251 QQR0582-001Z BEADS CORE
K1253-54 QQR0582-001Z BEADS CORE
K1401 QQR0582-001Z BEADS CORE

K1701-02 QQR0582-001Z BEADS CORE
K1901-02 QQR0582-001Z BEADS CORE
K1921-23 QQR0582-001Z BEADS CORE
LF1901 QQR0527-003 LINE FILTER

!
!

TH1901 QAD0129-3R0 P.THERMISTOR

!

TU1001 QAU0275-001 TUNER

!

RY1901 QSK0085-001 RELAY

S1401 QSL4A13-C02 LEVER SWITCH
S1751 QSW0619-003Z PUSH SWITCH POWER

S1752 QSW0619-003Z PUSH SWITCH VOL+
S1753 QSW0619-003Z PUSH SWITCH VOL­S1754 QSW0619-003Z PUSH SWITCH CH+
S1755 QSW0619-003Z PUSH SWITCH CH-

S1756 QSW0619-003Z PUSH SWITCH MENU
SF1101 QAX0723-001 SAW FILTER

!

SK1351 QNZ0537-001 C.R.T.SOCKET
VA1901 ERZV10V621CS VARISTOR

!

W1602 QRX029J-3R3 MF R 3.3Ω 2W J
W1603 QRE141J-101Y C R 100Ω 1/4W J
W1605 QRE141J-101Y C R 100Ω 1/4W J

X1701 QAX0717-001Z CRYSTAL

LC30190-001B-A L.E.D.HOLDER

No. 51937

39
