JVC AV-2568TEE/CSK, AV-2569TEE/CSK Service Manual

SERVICE MANUAL

COLOUR TELEVISION

52033D200310

BASIC CHASSIS

AV-2568TEE/CSK
AV-2569TEE/CSK

Supplementary

We have changed the production country for some parts. As a result, some parts number have been changed.
Therefore, this service manual describes only these parts number.
For others, please use the service manual for AV-2568TEE, AV-2568TEE/C (No.52033, Aug. 2002) (No.52033B,
2002/12).

OUTLINE

CH

Since the production country was changed, we have issued the SERVICE MANUAL for AV-2568TEE/CSK, AV­2569TEE/CSK.

HOW TO IDENTIFY MODELS

“AV-2568TEECSK” and “AV-2569TEECSK” are added to the serial No. under at the Rating label.

MODEL

SERIAL No.

Indicated

AV-2568TEE
AV-2569TEE

AV-2568TEECSK
AV-2569TEECSK

COPYRIGHT © 2003 VICTOR COMPANY OF JAPAN, LIMITED

No.52033D

2003/10

DIFFERENCE LIST

USING P.W. BOARD (Page 3-41)

P.W.B ASS'Y Name AV-2568TEE AV-2568TEE/C AV-2568TEE/CSK DESCRIPTION

MAIN P.W.B SCH-1097A-H2 SCH-1 127A-H2 SCH-1603A-H2 Non compatible

P.W.B ASS'Y Name AV-2568TEE AV-2568TEE/C AV-2569TEE/CSK DESCRIPTION

MAIN P.W.B SCH-1097A-H2 SCH-1 127A-H2 SCH-1604A-H2 Non compatible
CRT SOCKET P.W.B --- --- SCH-3602A-H2 Addition

EXPLODED VIEW PARTS LIST (l) (Page 3-41)

PARTS No.

 Ref. No.

AV-2568TEE AV-2568TEE/C

18 GG10133-019D-H GG10133-029C-H GG10133-029C-HK FRONT CABINET

EXPLODED VIEW PARTS LIST (ll) (Page 3-42)

PARTS No.

 Ref. No.

AV-2568TEE AV-2568TEE/C

AV-2568TEE/CSK
AV-2569TEE/CSK

AV-2568TEE/CSK
AV-2569TEE/CSK

PARTS NAME DESCRIPTION

PARTS NAME DESCRIPTION

 V01 A60LVY196X A59QDC580X A59QDC580X09ND PICTURE TUBE(ITC)
 DY01 QQD0078-002 QQD0089-001 --- DEF YOKE

7 A75034-B ← --- PC MAGNET
8 CE40764-00A ← --- WEDGE ASSY

 14 GG10134-001B-H ← GG10134-001B-HK REAR COVER

PACKING PARTS LIST (Page 3-59)

 Ref. No.

AV-2568TEE AV-2568TEE/C AV-2569TEE/CSK

 6 LCT1178-001A-H ← LCT1519-001A-H INST BOOK

1 1 GG20025-003A-H ← LC21271-001A-H CORNER LABEL

PARTS No.

PARTS NAME DESCRIPTION

1-2 (No.52033D)

PRINTED WIRING BOARD PARTS LIST [AV-2568TEE/CSK]



MAIN P.W. BOARD ASS'Y (SCH-1603A-H2)



Ref No. Part No. Part Name Description Local

IC1130 M52342SP IC
IC1401 AN5522 IC
IC1480 UPC358G2-XE IC
IC1602 NJW1138M-W IC
IC1650 AN5277 IC
IC1701 TDA9365N23S0874 IC
IC1702 AT24C08-21WS3 IC (SERVICE)
IC1760 GP1UM281QK IR DETECT UNIT 38kHz
IC1801 MM1492AF IC
IC1901 STR-F6709A/F7 IC
IC1951 SE135N IC
IC1972 R1141Q331B-X IC
IC1974 AN80T36 IC

Q1101 2SC5083/L-P/-T TRANSISTOR
Q1102 UN2212-X DIGI TRANSISTOR
Q1104 2SB709A/QR/-X TRANSISTOR
Q1105 UN2212-X DIGI TRANSISTOR
Q1106 UN2212-X DIGI TRANSISTOR
Q1108 2SD601A/QR/-X TRANSISTOR
Q1109 2SB709A/QR/-X TRANSISTOR
Q1110 UN2212-X D IGI TRANSISTOR
Q1111 2SD601A/QR/-X TRANSISTOR
Q1130 2SB709A/QR/-X TRANSISTOR
Q1131 UN2212-X DIGI TRANSISTOR
Q1132 2SD601A/QR/-X TRANSISTOR
Q1133 2SB709A/QR/-X TRANSISTOR
Q1134 UN2212-X DIGI TRANSISTOR
Q1135 UN2212-X DIGI TRANSISTOR
Q1136 2SD601A/QR/-X TRANSISTOR
Q1137 2SD601A/QR/-X TRANSISTOR
Q1138 UN2212-X DIGI TRANSISTOR
Q1301 2SB709A/QR/-X TRANSISTOR
Q1302 2SB709A/QR/-X TRANSISTOR
Q1350 STC344-T TRANSISTOR
Q1351 2SA1321-T SI TRANSISTOR
Q1352 2SB709A/QR/-X TRANSISTOR
Q1360 STC344-T TRANSISTOR
Q1361 2SA1321-T SI TRANSISTOR
Q1370 STC344-T TRANSISTOR
Q1371 2SA1321-T SI TRANSISTOR
Q1374 2SD601A/QR/-X TRANSISTOR
Q1375 2SD601A/QR/-X TRANSISTOR
Q1376 2SD601A/QR/-X TRANSISTOR
Q1480 2SD1408/OY/-LB POW TRANSISTOR
Q1521 2SC2655/Y/-T TRANSISTOR



Q1522 2SD2645-YD TRANSISTOR H.OUT
Q1591 2SA1208/ST/Z1-T TRANSISTOR
Q1592 UN2212-X DIGI TRANSISTOR
Q1660 2SD601A/QR/-X TRANSISTOR
Q1661 2SD601A/QR/-X TRANSISTOR
Q1683 2SB709A/QR/-X TRANSISTOR
Q1684 2SB709A/QR/-X TRANSISTOR
Q1685 DTC323TK-X DIGI TRANSISTOR
Q1686 DTC323TK-X DIGI TRANSISTOR
Q1701 2SB709A/QR/-X TRANSISTOR
Q1702 2SB709A/QR/-X TRANSISTOR
Q1703 FMC2A-X D.TRANSISTOR
Q1720 2SB709A/QR/-X TRANSISTOR
Q1770 2SB709A/QR/-X TRANSISTOR
Q1801 DTC323TK-X DIGI TRANSISTOR
Q1802 DTC323TK-X DIGI TRANSISTOR
Q1803 2SB709A/QR/-X TRANSISTOR
Q1804 2SC1740S/QR/-T TRANSISTOR
Q1860 2SD601A/QR/-X TRANSISTOR
Q1861 2SB709A/QR/-X TRANSISTOR
Q1862 2SB709A/QR/-X TRANSISTOR
Q1952 2SD601A/QR/-X TRANSISTOR
Q1953 2SD601A/QR/-X TRANSISTOR
Q1954 2SD601A/QR/-X TRANSISTOR

D1101 1SS268-X SI DIODE
D1350 1SS244-T2 SI DIODE
D1352 RGP10J-5025-T3 SI DIODE
D1353 MA111-X SI DIODE
D1354 MA111-X SI DIODE
D1355 MA111-X SI DIODE
D1356 MA111-X SI DIODE
D1357 MA111-X SI DIODE
D1358 MA111-X SI DIODE
D1360 1SS244-T2 SI DIODE
D1370 1SS244-T2 SI DIODE
D1372 MA3075/M/-X Z DIODE
D1373 MA111-X SI DIODE

Ref No. Part No. Part Name Description Local

D1374 MA111-X SI DIODE
D1375 MTZJ5.6B-T2 Z DIODE
D1376 MTZJ5.6B-T2 Z DIODE
D1377 MTZJ5.6B-T2 Z DIODE
D1401 RGP10J-5025-T3 SI DIODE
D1402 MTZJ75-T2 Z DIODE
D1405 1N4003-T2 SI DIODE
D1408 MA111-X SI DIODE
D1480 MTZJ4.3A-T2 Z DIODE
D1521 RH3G-F1 SI DIODE
D1522 31DF6N-FC5 FR DIODE
D1523 RGP10J-5025-T3 SI DIODE
D1541 RGP10J-5025-T3 SI DIODE
D1550 MA111-X SI DIODE
D1551 RGP10J-5025-T3 SI DIODE
D1553 RGP10J-5025-T3 SI DIODE
D1554 RGP10J-5025-T3 SI DIODE
D1592 MA3075/H/-X CHIP ZENER DIODE
D1652 MA3330/L/-X Z DIODE
D1653 MA3330/L/-X Z DIODE
D1655 MA111-X SI DIODE
D1682 MA111-X SI DIODE
D1702 MA3024-X CHIP ZENER DIODE
D1703 MA3051/M/-X Z DIODE
D1704 MA3033-X CHIP ZENER DIODE
D1730 MA111-X SI DIODE
D1731 MA111-X SI DIODE
D1732 MA111-X SI DIODE
D1733 MA111-X SI DIODE
D1760 SLR-342VR-T16 LED POWER
D1770 MA111-X SI DIODE
D1771 P1241-04 PHOTO CONDUCTOR
D1801 MA3120/M/-X Z DIODE
D1802 MA3120/M/-X Z DIODE
D1807 MA3100/M/-X Z DIODE
D1808 MA3100/M/-X Z DIODE
D1901 GSIB460 BRIDGE DIODE
D1903 MTZJ12C-T2 Z DIODE
D1904 EG01C-T2 SI DIODE
D1906 EG01C-T2 SI DIODE
D1907 MA3150/M/-X Z DIODE
D1908 MTZJ27B-T2 Z DIODE
D1909 MA111-X SI DIODE
D1910 MA111-X SI DIODE
D1911 RGP10J-TS-T3 SI DIODE
D1912 1SS133-T2 DIODE
D1914 ERC30-02L38 SI DIODE
D1952 ERC30-02L38 SI DIODE
D1953 RGP10J-5025-T3 SI DIODE
D1954 RGP30B-F1 SI DIODE
D1956 31DF6N-FC5 FR DIODE
D1964 MA3330/L/-X Z DIODE
D1965 1SS133-T2 DIODE
D1966 MA3068/M/-X Z DIODE
D1968 MA111-X SI DIODE
D1969 MA111-X SI DIODE
D1971 MA111-X SI DIODE

C1001 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1002 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1003 QFV71HJ-104Z MF CAPACITOR 0.1uF 50V J
C1004 QETN1CM-477Z E CAPACITOR 470uF 16V M
C1005 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1006 QETN1CM-336Z E CAPACITOR 33uF 16V M
C1007 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1101 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1102 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1103 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1104 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1105 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1106 NDC21HJ-180X C CAPACITOR 18pF 50V J
C1107 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1109 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1130 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1131 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1132 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1133 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1134 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1135 QETN1AM-477Z E CAPACITOR 470uF 10V M
C1136 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1137 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1138 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1139 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1140 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1141 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1142 NCB31HK-103X C CAPACITOR 0.01uF 50V K

(No.52033D)1-3



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

C1143 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1144 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C1308 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1310 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
C1350 NDC21HJ-471X C CAPACITOR 470pF 50V J
C1351 NDC31HJ-681X C CAPACITOR 680pF 50V J
C1352 QETN2EM-475Z E CAPACITOR 4.7uF 250V M
C1353 QETN1HM-107Z E CAPACITOR 100uF 50V M
C1354 QETN1HM-105Z E CAPACITOR 1uF 50V M
C1355 QETN1HM-105Z E CAPACITOR 1uF 50V M
C1360 NDC21HJ-471X C CAPACITOR 470pF 50V J
C1361 NDC31HJ-681X C CAPACITOR 680pF 50V J
C1370 NDC21HJ-471X C CAPACITOR 470pF 50V J
C1371 NDC31HJ-821X C CAPACITOR 820pF 50V J
C1372 NRSA63J-273X MG RESISTOR 27k
C1374 QCZ0364-222 C CAPACITOR 2200pF
C1375 QETN1CM-477Z E CAPACITOR 470uF 16V M
C1401 QETN1HM-105Z E CAPACITOR 1uF 50V M
C1402 QCB31HK-682Z C CAPACITOR 6800pF 50V K
C1403 QEHR1VM-227Z E CAPACITOR 220uF 35V M
C1406 QFLC2AJ-683Z M CAPACITOR 0.068uF 100V J
C1407 QCS32HJ-180Z C CAPACITOR 18pF 500V J
C1408 QFV71HJ-184Z MF CAPACITOR 0.18uF 50V J
C1411 NCF21HZ-334X C CAPACIT O R 0.33uF 50V Z
C1412 NCF21HZ-334X C CAPACIT O R 0.33uF 50V Z
C1413 QFLC2AJ-563Z M CAPACITOR 0.056uF 100V J
C1422 QEHQ1VM-108 E CAPACITOR 1000uF 35V M
C1480 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1483 QEZ0195-475Z BP E CAPACITOR 4.7uF 50V M
C1485 QETN1HM-226Z E CAPACITOR 22uF 50V M
C1521 QETN1VM-476Z E CAPACITOR 47uF 35V M
C1522 QFLC1HJ-332Z M CAPACITOR 3300pF 50V J
C1523 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J
C1524 QFZ0200-512 MPP CAPACITOR 5100pF 1.5kV H
C1525 QFZ0196-113 MPP CAPACITOR 0.011uF 1.5kV H
C1526 QFP32GJ-223 PP CAPACITOR 0.022uF 400V J
C1527 QFZ0197-184 MPP CAPACITOR 0.18uF 250V J
C1528 QFZ0199-224 MPP CAPACITOR 0.22uF
C1529 QENC2AM-225Z BP E CAPACITOR 2.2uF 100V M
C1530 QCB32HK-561Z C CAPACITOR 560pF 500V K
C1531 QEHR1EM-108Z E CAPACITOR 1000uF 25V M
C1533 QEHR1EM-108Z E CAPACITOR 1000uF 25V M
C1535 QCB32HK-101Z C CAPACITOR 100pF 500V K
C1536 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C1540 QFV71HJ-104Z MF CAPACITOR 0.1uF 50V J
C1541 QETN2EM-226Z E CAPACITOR 22uF 250V M
C1542 QETN2EM-226Z E CAPACITOR 22uF 250V M
C1550 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1591 QETN1AM-107Z E CAPACITOR 100uF 10V M
C1592 QETM2CM-227 E CAPACITOR 220uF 160V M
C1593 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1625 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1626 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1628 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1629 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C1630 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1631 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C1632 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1633 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1634 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1635 QETN1HM-107Z E CAPACITOR 100uF 50V M
C1636 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1637 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1638 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C1639 NCF21CZ-105X C CAPACIT O R 1uF 16V Z
C1640 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1641 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C1642 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1644 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1645 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1650 QEHR1HM-106Z E CAPACITOR 10uF 50V M
C1651 QEHR1VM-476Z E CAPACITOR 47uF 35V M
C1652 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1655 QEHQ1VM-108 E CAPACITOR 1000uF 35V M
C1656 QEHQ1VM-108 E CAPACITOR 1000uF 35V M
C1659 NCF21HZ-224X C CAPACIT O R 0.22uF 50V Z
C1660 NCF21HZ-224X C CAPACIT O R 0.22uF 50V Z
C1661 NCF21HZ-224X C CAPACIT O R 0.22uF 50V Z
C1662 QEHR1VM-227Z E CAPACITOR 220uF 35V M
C1663 NCF21HZ-224X C CAPACIT O R 0.22uF 50V Z
C1681 QETN1CM-227Z E CAPACITOR 220uF 16V M
C1682 QETN1CM-227Z E CAPACITOR 220uF 16V M
C1683 QETN1CM-336Z E CAPACITOR 33uF 16V M
C1684 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1685 NRSA63J-0R0X MG RESISTOR 0
C1686 NRSA63J-0R0X MG RESISTOR 0
C1701 QETN1CM-227Z E CAPACITOR 220uF 16V M
C1702 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1703 NDC31HJ-330X C CAPACITOR 33pF 50V J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

C1704 NDC31HJ-330X C CAPACITOR 33pF 50V J
C1705 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1706 NCB21EK-224X C CAPACITOR 0.22uF 25V K
C1707 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1709 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1710 NCB21EK-224X C CAPACITOR 0.22uF 25V K
C1711 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1713 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1714 QETN1CM-476Z E CAPACITOR 47uF 16V M
C1720 QETN1CM-476Z E CAPACITOR 47uF 16V M
C1725 NCB31HK-681X C CAPACITOR 680pF 50V K
C1730 NCB21EK-224X C CAPACITOR 0.22uF 25V K
C1731 NCB21EK-224X C CAPACITOR 0.22uF 25V K
C1732 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1733 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1734 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1735 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1736 QETN1HM-105Z E CAPACITOR 1uF 50V M
C1737 QETN1HM-105Z E CAPACITOR 1uF 50V M
C1738 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1739 NFV41CJ-104X MPPS CAPACITOR 0.1uF 16V J
C1740 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C1741 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1742 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1743 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1744 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1745 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C1746 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C1747 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C1748 QETN1CM-476Z E CAPACITOR 47uF 16V M
C1749 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1751 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1752 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1753 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1760 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1761 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1770 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1801 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1802 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1803 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1804 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1805 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1807 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C1808 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C1810 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C1811 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1812 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C1813 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1814 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1815 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C1817 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C1819 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1820 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C1821 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C1822 QETN1CM-477Z E CAPACITOR 470uF 16V M
C1823 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1824 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1825 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1826 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1827 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1829 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1830 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1831 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1833 QETN1HM-226Z E CAPACITOR 22uF 50V M
C1834 NDC31HJ-181X C CAPACITOR 180pF 50V J



C1901 QFZ9072-104 MM CAPACITOR 0.1uF AC250V K



C1902 QFZ9072-473 MM CAPACITOR 0.047uF AC250V K



C1903 QCZ9015-102Z C CAPACITOR 1000pF AC250V Z



C1904 QCZ9015-102Z C CAPACITOR 1000pF AC250V Z



C1905 QCZ9015-102Z C CAPACITOR 1000pF AC250V Z



C1906 QFZ9072-224 MM CAPACITOR 0.22uF AC250V K
C1907 QEZ0633-337 E CAPACITOR 330uF
C1908 QFZ0209-222 MPP CAPACIT O R 2200pF 6A H
C1910 NDC31HJ-471X C CAPACITOR 470pF 50V J
C1911 QEHR1EM-227Z E CAPACITOR 220uF 25V M
C1914 QETN1EM-227Z E CAPACITOR 220uF 25V M
C1915 QFLC1HJ-152Z M CAPACITOR 1500pF 50V J
C1916 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1952 QCB32HK-471Z C CAPACITOR 470pF 500V K
C1953 QEHQ1VM-108 E CAPACITOR 1000uF 35V M
C1954 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1955 QCB32HK-471Z C CAPACITOR 470pF 500V K
C1956 QETN1VM-227Z E CAPACITOR 220uF 35V M
C1957 QCB32HK-471Z C CAPACITOR 470pF 500V K
C1958 QEHQ1EM-228 E CAPACITOR 2200uF 25V M
C1959 QCZ0364-561 C CAPACIT O R 560pF 2kV K
C1960 QEZ0203-227 E CAPACITOR 220uF 160V M
C1961 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C1962 QETN1HM-106Z E CAPACITOR 10uF 50V M

1-4 (No.52033D)



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

C1964 QETN1CM-476Z E CAPACITOR 47uF 16V M
C1965 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C1968 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1972 QEHR1VM-108Z E CAPACITOR 1000uF 35V M
C1973 QEHR1CM-107Z E CAPACITOR 100uF 16V M
C1974 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1975 QEHR1CM-227Z E CAPACITOR 220uF 16V M
C1976 QEHR1CM-107Z E CAPACITOR 100uF 16V M
C1977 QEHR1AM-477Z E CAPACITOR 470uF 10V M
C1978 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1980 QETN1CM-107Z E CAPACITOR 100uF 16V M



C1991 QCZ9079-102 C CAPACITOR 1000pF AC250V M



C1992 QCZ9079-102 C CAPACITOR 1000pF AC250V M



C1993 QCZ9079-102 C CAPACITOR 1000pF AC250V M
R1001 NRSA63J-221X MG RESISTOR 220Ω 1/16W J

R1002 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1003 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J
R1004 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1005 QQR1114-001Z FERRITE BEADS
R1006 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J
R1007 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R1101 NRSA63J-100X MG RESISTOR 10
R1102 NRSA63J-682X MG RESISTOR 6.8k
R1103 NRSA63J-272X MG RESISTOR 2.7kΩ 1/16W J
R1104 NRSA63J-181X MG RESISTOR 180Ω 1/16W J
R1105 NRSA63J-220X MG RESISTOR 22Ω 1/16W J
R1106 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1107 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R1108 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R1109 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R1111 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1112 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1117 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1119 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1120 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R1130 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R1131 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R1132 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R1133 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J
R1134 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J
R1135 NRSA63J-561X MG RESISTOR 560Ω 1/16W J
R1136 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R1137 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1138 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R1139 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R1140 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J
R1141 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J
R1142 NRSA63J-561X MG RESISTOR 560Ω 1/16W J
R1143 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R1144 NRSA63J-220X MG RESISTOR 22Ω 1/16W J
R1145 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R1146 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1147 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1148 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R1149 NRSA63J-471X MG RESISTOR 470
R1155 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R1301 NRSA63J-222X MG RESISTOR 2.2k
R1302 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R1303 NRSA63J-562X MG RESISTOR 5.6k
R1304 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R1305 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R1306 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J
R1351 NRSA63J-151X MG RESISTOR 150Ω 1/16W J
R1352 QRL029J-123 OMF RESISTOR 12k
R1353 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J
R1354 NRSA63J-331X MG RESISTOR 330
R1355 NRSA63J-101X MG RESISTOR 100
R1356 QRE121J-102Y C RESISTOR 1k
R1357 QRZ0107-152Z C RESISTOR 1.5k
R1358 QRE121J-182Y C RESISTOR 1.8k
R1359 QRE121J-471Y C RESISTOR 470
R1361 NRSA63J-151X MG RESISTOR 150
R1362 QRL029J-123 OMF RESISTOR 12k
R1363 NRSA63J-182X MG RESISTOR 1.8k
R1364 NRSA63J-331X MG RESISTOR 330
R1365 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1366 QRE121J-102Y C RESISTOR 1k
R1367 QRZ0107-152Z C RESISTOR 1.5kΩ 1/2W K
R1368 NRSA63J-202X MG RESISTOR 2k



R1369 QRZ9017-150 FUSI RESISTOR 15Ω 1/4W J
R1370 NRSA63J-151X MG RESISTOR 150
R1371 QRL029J-123 OMF RESISTOR 12kΩ 2W J
R1372 NRSA63J-182X MG RESISTOR 1.8k
R1373 NRSA63J-331X MG RESISTOR 330Ω 1/16W J
R1374 NRSA63J-101X MG RESISTOR 100
R1375 QRE121J-102Y C RESISTOR 1k
R1376 QRZ0107-152Z C RESISTOR 1.5kΩ 1/2W K
R1377 NRSA63J-330X MG RESISTOR 33Ω 1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/2W J

Ω

1/2W K

Ω

1/2W J

Ω

1/2W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/2W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/2W J

2W J

2W J

R1378 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R1379 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R1383 QRE121J-394Y C RESISTOR 390kΩ 1/2W J
R1384 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1385 QRE141J-393Y C RESISTOR 39kΩ 1/4W J
R1386 QRE141J-103Y C RESISTOR 10kΩ 1/4W J
R1401 NRSA63J-224X MG RESISTOR 220kΩ 1/16W J
R1403 NRSA63J-0R0X MG RESISTOR 0
R1405 NRSA63J-682X MG RESISTOR 6.8k
R1406 NRSA63J-123X MG RESISTOR 12kΩ 1/16W J
R1408 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J
R1410 NRSA63J-123X MG RESISTOR 12kΩ 1/16W J
R1411 QRG01GJ-221 OMF RESISTOR 220Ω 1W J
R1412 QRE121J-1R0Y C RESISTOR 1Ω 1/2W J
R1413 QRX01GJ-2R7 MF RESISTOR 2.7
R1414 QRE121J-8R2Y C RESISTOR 8.2
R1425 NRSA63J-683X MG RESISTOR 68kΩ 1/16W J
R1480 QRE121J-681Y C RESISTOR 680Ω 1/2W J
R1481 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R1482 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J
R1483 NRSA63J-823X MG RESISTOR 82kΩ 1/16W J
R1484 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J
R1485 NRSA63J-562X MG RESISTOR 5.6k
R1486 NRSA63J-272X MG RESISTOR 2.7k
R1487 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R1489 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J
R1490 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1491 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J
R1492 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J
R1493 QRE121J-333Y C RESISTOR 33kΩ 1/2W J
R1494 QRL039J-470 OMF RESISTOR 47Ω 3W J
R1521 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1522 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1524 QRL039J-820 OMF RESISTOR 82Ω 3W J
R1526 QRL029J-271 OMF RESISTOR 270Ω 2W J
R1527 QRL039J-103 OMF RESISTOR 10kΩ 3W J
R1528 QRX029J-R47 MF RESISTOR 0.47Ω 2W J
R1529 QRX029J-R47 MF RESISTOR 0.47Ω 2W J
R1531 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J



R1532 QRZ9017-4R7 FUSI RESISTOR 4.7Ω 1/4W J



R1540 QRL039J-470 OMF RESISTOR 47Ω 3W J
R1541 QRE121J-124Y C RESISTOR 120kΩ 1/2W J
R1542 QRE121J-124Y C RESISTOR 120kΩ 1/2W J
R1543 QRE121J-471Y C RESISTOR 470Ω 1/2W J
R1545 QRE121J-220Y C RESISTOR 22Ω 1/2W J
R1546 QRE121J-822Y C RESISTOR 8.2kΩ 1/2W J
R1591 QRE121J-472Y C RESISTOR 4.7kΩ 1/2W J
R1592 QRZ0221-3R9 UNF RESISTOR 3.9
R1593 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R1594 QRE121J-183Y C RESISTOR 18kΩ 1/2W J
R1595 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R1621 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R1622 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R1624 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1625 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1626 NRSA63J-102X MG RESISTOR 1k
R1627 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1650 NRSA63J-103X MG RESISTOR 10k
R1651 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J
R1654 NRSA63J-103X MG RESISTOR 10k
R1655 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J
R1658 QRE121J-2R2Y C RESISTOR 2.2Ω 1/2W J
R1659 QRE121J-2R2Y C RESISTOR 2.2Ω 1/2W J
R1660 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1661 NRSA63J-683X MG RESISTOR 68k
R1662 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R1663 NRSA63J-103X MG RESISTOR 10k
R1664 NRSA63J-222X MG RESISTOR 2.2k
R1686 NRSA63J-102X MG RESISTOR 1k
R1687 NRSA63J-103X MG RESISTOR 10k
R1688 NRSA63J-273X MG RESISTOR 27k
R1690 NRSA63J-104X MG RESISTOR 100k
R1698 NRSA63J-104X MG RESISTOR 100k
R1699 NRSA63J-104X MG RESISTOR 100k
R1701 NRSA63J-101X MG RESISTOR 100
R1702 NRSA63J-101X MG RESISTOR 100
R1703 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1704 NRSA63J-102X MG RESISTOR 1k
R1705 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1707 NRSA63J-472X MG RESISTOR 4.7k
R1708 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R1709 NRSA63J-472X MG RESISTOR 4.7k
R1710 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R1711 NRSA63J-101X MG RESISTOR 100
R1712 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1713 NRSA63J-101X MG RESISTOR 100
R1714 NRSA63J-101X MG RESISTOR 100
R1715 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1716 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/2W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

1W J

Ω

(No.52033D)1-5



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

R1717 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1718 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1719 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1720 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1721 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1722 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1723 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1724 NRSA63J-221X MG RESISTOR 220
R1725 NRSA63J-103X MG RESISTOR 10k
R1726 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R1727 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R1728 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1729 NRSA63J-470X MG RESISTOR 47Ω 1/16W J
R1730 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R1731 NRSA63J-101X MG RESISTOR 100
R1732 NRSA02F-393X MG RESISTOR 39k
R1733 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J
R1734 NRSA63J-391X MG RESISTOR 390Ω 1/16W J
R1735 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R1736 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R1737 NRSA63J-272X MG RESISTOR 2.7kΩ 1/16W J
R1738 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1739 NRSA63J-101X MG RESISTOR 100
R1740 NRSA63J-101X MG RESISTOR 100
R1741 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1742 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R1743 NRSA63J-681X MG RESISTOR 680Ω 1/16W J
R1744 NRSA63J-561X MG RESISTOR 560Ω 1/16W J
R1745 NRSA63J-105X MG RESISTOR 1MΩ 1/16W J
R1746 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R1747 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1748 NRSA02J-475X MG RESISTOR 4.7MΩ 1/10W J
R1749 NRSA02J-475X MG RESISTOR 4.7MΩ 1/10W J
R1750 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R1755 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1756 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1757 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R1758 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R1760 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J
R1770 QRE121J-271Y C RESISTOR 270Ω 1/2W J
R1771 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1772 QRE121J-271Y C RESISTOR 270Ω 1/2W J
R1773 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1775 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R1776 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J
R1777 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J
R1779 NRSA63J-272X MG RESISTOR 2.7kΩ 1/16W J
R1780 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R1781 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J
R1782 NRSA63J-181X MG RESISTOR 180Ω 1/16W J
R1783 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1784 NRSA63J-331X MG RESISTOR 330Ω 1/16W J
R1785 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R1803 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R1804 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R1805 NRSA63J-750X MG RESISTOR 75
R1806 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R1807 NRSA63J-750X MG RESISTOR 75
R1808 NRSA63J-823X MG RESISTOR 82kΩ 1/16W J
R1809 NRSA63J-391X MG RESISTOR 390
R1810 NRSA63J-823X MG RESISTOR 82kΩ 1/16W J
R1811 NRSA63J-391X MG RESISTOR 390Ω 1/16W J
R1812 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R1813 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R1815 NRSA63J-101X MG RESISTOR 100
R1818 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R1820 NRSA63J-101X MG RESISTOR 100
R1821 NRSA63J-222X MG RESISTOR 2.2k
R1823 NRSA63J-101X MG RESISTOR 100
R1824 NRSA63J-222X MG RESISTOR 2.2k
R1826 NRSA63J-101X MG RESISTOR 100
R1829 NRSA63J-750X MG RESISTOR 75
R1830 NRSA63J-222X MG RESISTOR 2.2k
R1831 NRSA63J-222X MG RESISTOR 2.2k
R1832 NRSA63J-122X MG RESISTOR 1.2k
R1833 NRSA63J-102X MG RESISTOR 1k
R1834 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J
R1835 NRSA63J-562X MG RESISTOR 5.6k
R1836 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R1837 NRSA63J-101X MG RESISTOR 100
R1838 QRK126J-121X UNF C RESISTOR 120Ω 1/2W J
R1839 QRE121J-221Y C RESISTOR 220
R1840 QRE121J-221Y C RESISTOR 220Ω 1/2W J
R1841 NRSA63J-0R0X MG RESISTOR 0
R1842 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R1843 NRSA63J-821X MG RESISTOR 820
R1844 NRSA63J-222X MG RESISTOR 2.2k
R1845 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1846 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/10W F

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/2W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

R1847 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1848 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R1849 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1880 NRSA63J-202X MG RESISTOR 2kΩ 1/16W J
R1881 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1882 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R1883 NRSA63J-181X MG RESISTOR 180Ω 1/16W J
R1902 QRF154K-2R2 UNF WW RESISTOR 2.2
R1904 QRE121J-681Y C RESISTOR 680
R1905 QRM034J-R15 MP RESISTOR 0.15Ω 3W J
R1907 NRSA63J-563X MG RESISTOR 56kΩ 1/16W J
R1908 QRL039J-333 OMF RESISTOR 33kΩ 3W J
R1909 QRE121J-474Y C RESISTOR 470kΩ 1/2W J
R1910 QRE121J-472Y C RESISTOR 4.7kΩ 1/2W J
R1911 QRE121J-332Y C RESISTOR 3.3k
R1912 NRSA63J-152X MG RESISTOR 1.5k
R1913 QRX01GJ-3R9 MF RESISTOR 3.9Ω 1W J



R1915 QRZ0111-474 C RESISTOR 470kΩ 1/2W K
R1952 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R1953 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1957 QRE121J-6R8Y C RESISTOR 6.8Ω 1/2W J
R1960 NRSA63J-391X MG RESISTOR 390Ω 1/16W J
R1961 QRL029J-223 OMF RESISTOR 22k
R1962 NRSA63J-561X MG RESISTOR 560
R1963 QRE121J-103Y C RESISTOR 10kΩ 1/2W J
R1964 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R1965 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R1966 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J
R1967 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R1970 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J
R1971 NRSA63J-183X MG RESISTOR 18kΩ 1/16W J
R1972 NRSA63J-391X MG RESISTOR 390Ω 1/16W J



R1991 QRZ9046-825Z C RESISTOR 8.2MΩ 1/2W K
L1001 CE42050-001Z BEADS CORE

L1002 CE42050-001Z BEADS CORE
L1101 QQLZ014-R82 COIL 0.82uH 100mA L
L1104 QQL244K-180Z PEAKING COIL 18uH K
L1480 QQR1138-001 CHOKE COIL
L1523 QQR1137-005 LINEARITY COIL
L1524 QQLZ034-140 HEATER CHO KE 14uH
L1540 QQL244J-5R6Z COIL 5.6uH J
L1701 QQL244K-100Z PEAKING COIL 10uH K
L1702 QQL244K-100Z PEAKING COIL 10uH K
L1731 QQL244J-5R6Z COIL 5.6uH J
L1951 QQLZ034-460 HEATER CHO KE 46uH
L1953 QQL244J-5R6Z COIL 5.6uH J
L1954 QQL244J-5R6Z COIL 5.6uH J



T1521 QQR1229-001 DRIVE TRANSF



T1901 QQS0165-001 SW TRANSF
CF1106 QAX0639-001Z C TRAP 4.500MHz

CF1130 QAX0642-001Z C FILTER 4.500MHz
CF1140 QAX0695-001Z C FILTER 5.500MHz
CF1141 QAX0696-001Z C FILTER 6.000MHz
CF1142 QAX0697-001Z C FILTER 6.500MHz
CN1001 QGA2501C5-04Z CONNECTOR W-B (1-4)
CN100A QJC001-032003 CONNECTOR ASSY
CN100C QGA2501C5-06Z CONNECTOR W-B (1-6)
CN100D WJQ0003-002A E-SH C WIRE B-B
CN100S QGA2501C5-05Z CONNECTOR W-B (1-5)
CN100T QJL001-065631 SIN CL B-B WIRE
CN100U CHGC04-400 CONNECTOR ASSY
CN10HV QGZ5004C1-04 CONNECTOR (1-4)
CN10PW QGA7901F1-02 CONNECTOR W-B (1-2)
CN1DEG QGZ5004C1-02 CONNECTOR (1-2)



CP1951 ICP-N75-Y IC PROTECTOR 2.7A



CP1952 ICP-N50-Y IC PROTECTOR 2.0A



CP1953 ICP-N75-Y IC PROTECTOR 2.7A



F1901 QMF51E2-4R0J4 FUSE 4A AC250V
HS1401 LC31696-001A HEAT SINK
HS1480 CM42862-A0A HEAT SINK ASSY
HS1522 LC31215-001A HEAT SINK/FE-P/
HS1650 LC30145-003A HEAT SINK/AL-F/
HS1901 CEHT12N-026PS HEAT SINK
HS1974 LC31334-002A HEAT SINK/AL-F/
J1770 QNS0155-001 3.5 JACK HEADPHONE
J1771 QNN0282-003 PIN JACK V IN
J1772 QNN0282-002 PIN JACK L IN
J1773 QNN0282-001 PIN JACK R IN
J1801 QNN0349-001 PIN JACK S/V/L/R IN
J1802 QNN0349-002 PIN JACK V/L/R IN
J1803 QNN0348-001 PIN JACK L/R IN
J1804 QNN0349-001 PIN JACK V/L/R OUT
K1104 QQR1113-001Z FERRITE BEADS
K1105 QQR1113-001Z FERRITE BEADS
K1106 QQR1113-001Z FERRITE BEADS
K1701 QQR1113-001Z FERRITE BEADS
K1901 QQR1113-001Z FERRITE BEADS

Ω

15W K

Ω

1/2W J

Ω

1/2W J

Ω

1/16W J

Ω

Ω

1/16W J

2W J

1-6 (No.52033D)



Ref No. Part No. Part Name Description Local

K1902 QQR1114-001Z FERRITE BEADS
K1903 QQR1114-001Z FERRITE BEADS
K1951 QQR1113-001Z FERRITE BEADS
K1953 QQR1113-001Z FERRITE BEADS
K1954 QQR1113-001Z FERRITE BEADS
K1955 QQR1214-001Y FERRITE BEADS



LF1901 QQR0673-004 LINE FILTER



LF1902 QQR1035-002 LINE FILTER



PC1901 PC123F2 PHOTO COUPLER



RY1901 QSK0092-001 RELAY
S1780 QSW0619-003Z TACT SWITCH MENU
S1781 QSW0619-003Z TACT SWITCH CH­S1782 QSW0619-003Z TACT SWITCH CH+
S1783 QSW0619-003Z TACT SWITCH VOL­S1784 QSW0619-003Z TACT SWITCH VOL+



S1901 QSW0846-001 PUSH SWITCH POWER
SF1101 QAX0325-001 SAW FILTER
SF1102 QAX0731-001 SAW FILTER



SK1351 QNZ0537-001 CRT SOCKET



TH1901 QAD0134-4R5 POSISTOR 4.5
TU1001 QAU0185-005 TUNER



VA1901 QAF0052-621 VAR ISTOR 620V
X1701 QAX0737-001 CRYSTAL 12.000MHz

Ω

(No.52033D)1-7

PRINTED WIRING BOARD PARTS LIST [AV-2569TEE/CSK]



MAIN P.W. BOARD ASS'Y (SCH-1604A-H2)



Ref No. Part No. Part Name Description Local

IC1130 M52342SP IC
IC1401 AN5522 IC
IC1480 UPC358G2-XE IC
IC1602 NJW1138M-W IC
IC1650 AN5277 IC
IC1701 TDA9365N23S0874 IC
IC1702 AT24C08-21WS3 IC (SERVICE)
IC1760 GP1UM281QK IR DETECT UNIT 38kHz
IC1801 MM1492AF IC
IC1901 STR-F6709A/F7 IC
IC1951 SE135N IC
IC1972 R1141Q331B-X IC
IC1974 AN80T36 IC

Q1101 2SC5083/L-P/-T TRANSISTOR
Q1102 UN2212-X DIGI TRANSISTOR
Q1104 2SB709A/QR/-X TRANSISTOR
Q1105 UN2212-X DIGI TRANSISTOR
Q1106 UN2212-X DIGI TRANSISTOR
Q1108 2SD601A/QR/-X TRANSISTOR
Q1109 2SB709A/QR/-X TRANSISTOR
Q1110 UN2212-X DIGI TRANSISTOR
Q1111 2SD601A/QR/-X TRANSISTOR
Q1130 2SB709A/QR/-X TRANSISTOR
Q1131 UN2212-X DIGI TRANSISTOR
Q1132 2SD601A/QR/-X TRANSISTOR
Q1133 2SB709A/QR/-X TRANSISTOR
Q1134 UN2212-X DIGI TRANSISTOR
Q1135 UN2212-X DIGI TRANSISTOR
Q1136 2SD601A/QR/-X TRANSISTOR
Q1137 2SD601A/QR/-X TRANSISTOR
Q1138 UN2212-X DIGI TRANSISTOR
Q1301 2SB709A/QR/-X TRANSISTOR
Q1302 2SB709A/QR/-X TRANSISTOR
Q1480 2SD1408/OY/-LB POW TRANSISTOR
Q1521 2SC2655/Y/-T TRANSISTOR



Q1522 2SD2645-YD TRANSISTOR H.OUT
Q1591 2SA1208/ST/Z1-T TRANSISTOR
Q1592 UN2212-X DIGI TRANSISTOR
Q1660 2SD601A/QR/-X TRANSISTOR
Q1661 2SD601A/QR/-X TRANSISTOR
Q1683 2SB709A/QR/-X TRANSISTOR
Q1684 2SB709A/QR/-X TRANSISTOR
Q1685 DTC323TK-X DIGI TRANSISTOR
Q1686 DTC323TK-X DIGI TRANSISTOR
Q1701 2SB709A/QR/-X TRANSISTOR
Q1702 2SB709A/QR/-X TRANSISTOR
Q1703 FMC2A-X D.TRANSISTOR
Q1720 2SB709A/QR/-X TRANSISTOR
Q1770 2SB709A/QR/-X TRANSISTOR
Q1801 DTC323TK-X DIGI TRANSISTOR
Q1802 DTC323TK-X DIGI TRANSISTOR
Q1803 2SB709A/QR/-X TRANSISTOR
Q1804 2SC1740S/QR/-T TRANSISTOR
Q1860 2SD601A/QR/-X TRANSISTOR
Q1861 2SB709A/QR/-X TRANSISTOR
Q1862 2SB709A/QR/-X TRANSISTOR
Q1952 2SD601A/QR/-X TRANSISTOR
Q1953 2SD601A/QR/-X TRANSISTOR
Q1954 2SD601A/QR/-X TRANSISTOR

D1101 1SS268-X SI DIODE
D1375 MTZJ5.6B-T2 Z DIODE
D1376 MTZJ5.6B-T2 Z DIODE
D1377 MTZJ5.6B-T2 Z DIODE
D1401 RGP10J-5025-T3 SI DIODE
D1402 MTZJ75-T2 Z DIODE
D1405 1N4003-T2 SI DIODE
D1408 MA111-X SI DIODE
D1480 MTZJ4.3A-T2 Z DIODE
D1521 RH3G-F1 SI DIODE
D1522 31DF6N-FC5 FR DIODE
D1523 RGP10J-5025-T3 SI DIODE
D1541 RGP10J-5025-T3 SI DIODE
D1550 MA111-X SI DIODE
D1551 RGP10J-5025-T3 SI DIODE
D1553 RGP10J-5025-T3 SI DIODE
D1554 RGP10J-5025-T3 SI DIODE
D1592 MA3075/H/-X CHIP ZENER DIODE
D1652 MA3330/L/-X Z DIODE
D1653 MA3330/L/-X Z DIODE
D1655 MA111-X SI DIODE
D1682 MA111-X SI DIODE
D1702 MA3024-X CHIP ZENER DIODE

Ref No. Part No. Part Name Description Local

D1703 MA3051/M/-X Z DIODE
D1704 MA3033-X CHIP ZENER DIODE
D1730 MA111-X SI DIODE
D1731 MA111-X SI DIODE
D1732 MA111-X SI DIODE
D1733 MA111-X SI DIODE
D1760 SLR-342VR-T16 LED POWER
D1770 MA111-X SI DIODE
D1771 P1241-04 PHOT O CONDUCTOR
D1801 MA3120/M/-X Z DIODE
D1802 MA3120/M/-X Z DIODE
D1807 MA3100/M/-X Z DIODE
D1808 MA3100/M/-X Z DIODE
D1901 GSIB46 0 BRIDGE DIODE
D1903 MTZJ12C-T2 Z DIODE
D1904 EG01C-T2 SI DIODE
D1906 EG01C-T2 SI DIODE
D1907 MA3150/M/-X Z DIODE
D1908 MTZJ27B-T2 Z DIODE
D1909 MA111-X SI DIODE
D1910 MA111-X SI DIODE
D1911 RGP10J-TS-T3 SI DIODE
D1912 1SS133-T2 DIODE
D1914 ERC30-02L38 SI DIODE
D1952 ERC30-02L38 SI DIODE
D1953 RGP10J-5025-T3 SI DIODE
D1954 RGP30B-F1 SI DIODE
D1956 31DF6N-FC5 FR DIODE
D1964 MA3330/L/-X Z DIODE
D1965 1SS133-T2 DIODE
D1966 MA3068/M/-X Z DIODE
D1968 MA111-X SI DIODE
D1969 MA111-X SI DIODE
D1971 MA111-X SI DIODE

C1001 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1002 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1003 QFV71HJ-104Z MF CAPACITOR 0.1uF 50V J
C1004 QETN1CM-477Z E CAPACITOR 470uF 16V M
C1005 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1006 QETN1CM-336Z E CAPACITOR 33uF 16V M
C1007 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1101 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1102 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1103 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1104 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1105 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1106 NDC21HJ-180X C CAPACITOR 18pF 50V J
C1107 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1109 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1130 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1131 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1132 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1133 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1134 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1135 QETN1AM-477Z E CAPACITOR 470uF 10V M
C1136 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1137 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1138 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1139 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1140 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1141 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1142 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1143 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1144 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C1308 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1310 NRSA63J-0R0X MG RESISTOR 0
C1401 QETN1HM-105Z E CAPACITOR 1uF 50V M
C1402 QCB31HK-682Z C CAPACITOR 6800pF 50V K
C1403 QEHR1VM-227Z E CAPACITOR 220uF 35V M
C1406 QFLC2AJ-683Z M CAPACITOR 0.068uF 100V J
C1407 QCS32HJ-180Z C CAPACITOR 18pF 500V J
C1408 QFV71HJ-184Z MF CAPACITOR 0.18uF 50V J
C1411 NCF21HZ-334X C CAPACITOR 0.33uF 50V Z
C1412 NCF21HZ-334X C CAPACITOR 0.33uF 50V Z
C1413 QFLC2AJ-563Z M CAPACITOR 0.056uF 100V J
C1422 QEHQ1VM-108 E CAPACITOR 1000uF 35V M
C1480 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1483 QEZ0195-475Z BP E CAPACITOR 4.7uF 50V M
C1485 QETN1HM-226Z E CAPACITOR 22uF 50V M
C1521 QETN1VM-476Z E CAPACITOR 47uF 35V M
C1522 QFLC1HJ-332Z M CAPACITOR 3300pF 50V J
C1523 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J
C1524 QFZ0200-512 MPP CAPACITOR 5100pF 1.5kV H
C1525 QFZ0196-113 MPP CAPACITOR 0.011uF 1.5kV H
C1526 QFP32GJ-223 PP CAPACITOR 0.022uF 400V J

Ω

1/16W J

1-8 (No.52033D)



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

C1527 QFZ0197-184 MPP CAPACITOR 0.18uF 250V J
C1528 QFZ0199-224 MPP CAPA CITOR 0.22uF
C1529 QENC2AM-225Z BP E CAPACITOR 2.2uF 100V M
C1530 QCB32HK-561Z C CAPACITOR 560pF 500V K
C1531 QEHR1EM-108Z E CAPACITOR 1000uF 25V M
C1533 QEHR1EM-108Z E CAPACITOR 1000uF 25V M
C1535 QCB32HK-101Z C CAPACITOR 100pF 500V K
C1536 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C1540 QFV71HJ-104Z MF CAPACITOR 0.1uF 50V J
C1541 QETN2EM-226Z E CAPACITOR 22uF 250V M
C1542 QETN2EM-226Z E CAPACITOR 22uF 250V M
C1550 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1591 QETN1AM-107Z E CAPACITOR 100uF 10V M
C1592 QETM2CM-227 E CAPACITOR 220uF 160V M
C1593 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1625 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1626 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1628 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1629 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C1630 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1631 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C1632 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1633 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1634 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1635 QETN1HM-107Z E CAPACITOR 100uF 50V M
C1636 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1637 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1638 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C1639 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C1640 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1641 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C1642 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1644 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1645 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1650 QEHR1HM-106Z E CAPACITOR 10uF 50V M
C1651 QEHR1VM-476Z E CAPACITOR 47uF 35V M
C1652 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1655 QEHQ1VM-108 E CAPACITOR 1000uF 35V M
C1656 QEHQ1VM-108 E CAPACITOR 1000uF 35V M
C1659 NCF21HZ-224X C CAPACITOR 0.22uF 50V Z
C1660 NCF21HZ-224X C CAPACITOR 0.22uF 50V Z
C1661 NCF21HZ-224X C CAPACITOR 0.22uF 50V Z
C1662 QEHR1VM-227Z E CAPACITOR 220uF 35V M
C1663 NCF21HZ-224X C CAPACITOR 0.22uF 50V Z
C1681 QETN1CM-227Z E CAPACITOR 220uF 16V M
C1682 QETN1CM-227Z E CAPACITOR 220uF 16V M
C1683 QETN1CM-336Z E CAPACITOR 33uF 16V M
C1684 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1685 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
C1686 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
C1701 QETN1CM-227Z E CAPACITOR 220uF 16V M
C1702 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1703 NDC31HJ-330X C CAPACITOR 33pF 50V J
C1704 NDC31HJ-330X C CAPACITOR 33pF 50V J
C1705 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1706 NCB21EK-224X C CAPACITOR 0.22uF 25V K
C1707 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1709 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1710 NCB21EK-224X C CAPACITOR 0.22uF 25V K
C1711 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1713 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1714 QETN1CM-476Z E CAPACITOR 47uF 16V M
C1720 QETN1CM-476Z E CAPACITOR 47uF 16V M
C1725 NCB31HK-681X C CAPACITOR 680pF 50V K
C1730 NCB21EK-224X C CAPACITOR 0.22uF 25V K
C1731 NCB21EK-224X C CAPACITOR 0.22uF 25V K
C1732 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1733 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1734 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1735 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1736 QETN1HM-105Z E CAPACITOR 1uF 50V M
C1737 QETN1HM-105Z E CAPACITOR 1uF 50V M
C1738 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1739 NFV41CJ-104X MPPS CAPACITO R 0.1uF 16V J
C1740 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C1741 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1742 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1743 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1744 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1745 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C1746 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C1747 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C1748 QETN1CM-476Z E CAPACITOR 47uF 16V M
C1749 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1751 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1752 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1753 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1760 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1761 QETN1CM-107Z E CAPACITOR 100uF 16V M

C1770 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1801 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1802 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1803 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1804 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1805 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1807 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C1808 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C1810 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C1811 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1812 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C1813 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1814 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1815 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C1817 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C1819 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1820 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C1821 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C1822 QETN1CM-477Z E CAPACITOR 470uF 16V M
C1823 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1824 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1825 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1826 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1827 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1829 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1830 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1831 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1833 QETN1HM-226Z E CAPACITOR 22uF 50V M
C1834 NDC31HJ-181X C CAPACITOR 180pF 50V J



C1901 QFZ9072-104 MM CAPACITOR 0.1uF AC250V K



C1902 QFZ9072-473 MM CAPACITOR 0.047uF AC250V K



C1903 QCZ9015-102Z C CAPACITOR 1000pF AC250V Z



C1904 QCZ9015-102Z C CAPACITOR 1000pF AC250V Z



C1905 QCZ9015-102Z C CAPACITOR 1000pF AC250V Z



C1906 QFZ9072-224 MM CAPACITOR 0.22uF AC250V K
C1907 QEZ0633-337 E CAPACITOR 330uF
C1908 QFZ0209-222 MPP CAPACITOR 2200pF 6A H
C1910 NDC31HJ-471X C CAPACITOR 470pF 50V J
C1911 QEHR1EM-227Z E CAPACITOR 220uF 25V M
C1914 QETN1EM-227Z E CAPACITOR 220uF 25V M
C1915 QFLC1HJ-152Z M CAPACITOR 1500pF 50V J
C1916 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1952 QCB32HK-471Z C CAPACITOR 470pF 500V K
C1953 QEHQ1VM-108 E CAPACITOR 1000uF 35V M
C1954 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1955 QCB32HK-471Z C CAPACITOR 470pF 500V K
C1956 QETN1VM-227Z E CAPACITOR 220uF 35V M
C1957 QCB32HK-471Z C CAPACITOR 470pF 500V K
C1958 QEHQ1EM-228 E CAPACITOR 2200uF 25V M
C1959 QCZ0364-561 C CAPACITOR 560pF 2kV K
C1960 QEZ0203-227 E CAPACITOR 220uF 160V M
C1961 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C1962 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1964 QETN1CM-476Z E CAPACITOR 47uF 16V M
C1965 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C1968 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1972 QEHR1VM-108Z E CAPACITOR 1000uF 35V M
C1973 QEHR1CM-107Z E CAPACITOR 100uF 16V M
C1974 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1975 QEHR1CM-227Z E CAPACITOR 220uF 16V M
C1976 QEHR1CM-107Z E CAPACITOR 100uF 16V M
C1977 QEHR1AM-477Z E CAPACITOR 470uF 10V M
C1978 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1980 QETN1CM-107Z E CAPACITOR 100uF 16V M



C1991 QCZ9079-102 C CAPACITOR 1000pF AC250V M



C1992 QCZ9079-102 C CAPACITOR 1000pF AC250V M



C1993 QCZ9079-102 C CAPACITOR 1000pF AC250V M
R1001 NRSA63J-221X MG RESISTOR 220Ω 1/16W J

R1002 NRSA63J-221X MG RESISTOR 220
R1003 NRSA63J-392X MG RESISTOR 3.9k
R1004 NRSA63J-221X MG RESISTOR 220
R1005 QQR1114-001Z FERRITE BEADS
R1006 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J
R1007 NRSA63J-750X MG RESISTOR 75
R1101 NRSA63J-100X MG RESISTOR 10
R1102 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J
R1103 NRSA63J-272X MG RESISTOR 2.7k
R1104 NRSA63J-181X MG RESISTOR 180Ω 1/16W J
R1105 NRSA63J-220X MG RESISTOR 22
R1106 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1107 NRSA63J-472X MG RESISTOR 4.7k
R1108 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R1109 NRSA63J-222X MG RESISTOR 2.2k
R1111 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1112 NRSA63J-103X MG RESISTOR 10k
R1117 NRSA63J-102X MG RESISTOR 1k
R1119 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1120 NRSA63J-471X MG RESISTOR 470Ω 1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

(No.52033D)1-9



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

R1130 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R1131 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R1132 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R1133 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J
R1134 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J
R1135 NRSA63J-561X MG RESISTOR 560Ω 1/16W J
R1136 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R1137 NRSA63J-103X MG RESISTOR 10k
R1138 NRSA63J-471X MG RESISTOR 470
R1139 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R1140 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J
R1141 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J
R1142 NRSA63J-561X MG RESISTOR 560Ω 1/16W J
R1143 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R1144 NRSA63J-220X MG RESISTOR 22
R1145 NRSA63J-821X MG RESISTOR 820
R1146 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1147 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1148 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R1149 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R1155 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R1301 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R1302 NRSA63J-222X MG RESISTOR 2.2k
R1303 NRSA63J-562X MG RESISTOR 5.6k
R1304 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R1305 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R1306 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J
R1401 NRSA63J-224X MG RESISTOR 220kΩ 1/16W J
R1403 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R1405 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J
R1406 NRSA63J-123X MG RESISTOR 12kΩ 1/16W J
R1408 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J
R1410 NRSA63J-123X MG RESISTOR 12kΩ 1/16W J
R1411 QRG01GJ-221 OMF RESISTOR 220Ω 1W J
R1412 QRE121J-1R0Y C RESISTOR 1Ω 1/2W J
R1413 QRX01GJ-2R7 MF RESISTOR 2.7Ω 1W J
R1414 QRE121J-8R2Y C RESISTOR 8.2Ω 1/2W J
R1425 NRSA63J-683X MG RESISTOR 68kΩ 1/16W J
R1480 QRE121J-681Y C RESISTOR 680Ω 1/2W J
R1481 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R1482 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J
R1483 NRSA63J-823X MG RESISTOR 82kΩ 1/16W J
R1484 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J
R1485 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J
R1486 NRSA63J-272X MG RESISTOR 2.7kΩ 1/16W J
R1487 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R1489 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J
R1490 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1491 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J
R1492 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J
R1493 QRE121J-333Y C RESISTOR 33kΩ 1/2W J
R1494 QRL039J-470 OMF RESISTOR 47Ω 3W J
R1521 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1522 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1524 QRL039J-820 OMF RESISTOR 82Ω 3W J
R1526 QRL029J-271 OMF RESISTOR 270
R1527 QRL039J-103 OMF RESISTOR 10kΩ 3W J
R1528 QRX029J-R47 MF RESISTOR 0.47
R1529 QRX029J-R47 MF RESISTOR 0.47Ω 2W J
R1531 NRSA63J-222X MG RESISTOR 2.2k



R1532 QRZ9017-4R7 FUSI RESISTOR 4.7Ω 1/4W J



R1540 QRL039J-470 OMF RESISTOR 47Ω 3W J
R1541 QRE121J-124Y C RESISTOR 120kΩ 1/2W J
R1542 QRE121J-124Y C RESISTOR 120kΩ 1/2W J
R1543 QRE121J-471Y C RESISTOR 470
R1545 QRE121J-220Y C RESISTOR 22Ω 1/2W J
R1546 QRE121J-822Y C RESISTOR 8.2k
R1591 QRE121J-472Y C RESISTOR 4.7k
R1592 QRZ0221-3R9 UNF RESISTOR 3.9
R1593 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R1594 QRE121J-183Y C RESISTOR 18k
R1595 NRSA63J-222X MG RESISTOR 2.2k
R1621 NRSA63J-0R0X MG RESISTOR 0
R1622 NRSA63J-0R0X MG RESISTOR 0
R1624 NRSA63J-101X MG RESISTOR 100
R1625 NRSA63J-101X MG RESISTOR 100
R1626 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1627 NRSA63J-102X MG RESISTOR 1k
R1650 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1651 NRSA63J-822X MG RESISTOR 8.2k
R1654 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1655 NRSA63J-822X MG RESISTOR 8.2k
R1658 QRE121J-2R2Y C RESISTOR 2.2Ω 1/2W J
R1659 QRE121J-2R2Y C RESISTOR 2.2
R1660 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1661 NRSA63J-683X MG RESISTOR 68k
R1662 NRSA63J-333X MG RESISTOR 33k
R1663 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1664 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω
Ω

Ω

1/16W J

Ω

1/2W J

Ω

1/2W J

Ω

1/2W J

Ω

1/2W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/2W J

Ω

1/16W J

Ω

1/16W J

2W J
2W J

R1686 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1687 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1688 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J
R1690 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R1698 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R1699 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R1701 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1702 NRSA63J-101X MG RESISTOR 100
R1703 NRSA63J-101X MG RESISTOR 100
R1704 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1705 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1707 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R1708 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R1709 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R1710 NRSA63J-472X MG RESISTOR 4.7k
R1711 NRSA63J-101X MG RESISTOR 100
R1712 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1713 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1714 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1715 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1716 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1717 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1718 NRSA63J-221X MG RESISTOR 220
R1719 NRSA63J-221X MG RESISTOR 220
R1720 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1721 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1722 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1723 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1724 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1725 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1726 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R1727 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R1728 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1729 NRSA63J-470X MG RESISTOR 47Ω 1/16W J
R1730 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R1731 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1732 NRSA02F-393X MG RESISTOR 39kΩ 1/10W F
R1733 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J
R1734 NRSA63J-391X MG RESISTOR 390Ω 1/16W J
R1735 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R1736 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R1737 NRSA63J-272X MG RESISTOR 2.7kΩ 1/16W J
R1738 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1739 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1740 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1741 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1742 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R1743 NRSA63J-681X MG RESISTOR 680Ω 1/16W J
R1744 NRSA63J-561X MG RESISTOR 560Ω 1/16W J
R1745 NRSA63J-105X MG RESISTOR 1MΩ 1/16W J
R1746 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R1747 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1748 NRSA02J-475X MG RESISTOR 4.7MΩ 1/10W J
R1749 NRSA02J-475X MG RESISTOR 4.7MΩ 1/10W J
R1750 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R1755 NRSA63J-101X MG RESISTOR 100
R1756 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1757 NRSA63J-222X MG RESISTOR 2.2k
R1758 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R1760 NRSA63J-682X MG RESISTOR 6.8k
R1770 QRE121J-271Y C RESISTOR 270Ω 1/2W J
R1771 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1772 QRE121J-271Y C RESISTOR 270Ω 1/2W J
R1773 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1775 NRSA63J-332X MG RESISTOR 3.3k
R1776 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J
R1777 NRSA63J-682X MG RESISTOR 6.8k

Ω

R1779 NRSA63J-272X MG RESISTOR 2.7k
R1780 NRSA63J-471X MG RESISTOR 470
R1781 NRSA63J-122X MG RESISTOR 1.2k
R1782 NRSA63J-181X MG RESISTOR 180
R1783 NRSA63J-221X MG RESISTOR 220
R1784 NRSA63J-331X MG RESISTOR 330
R1785 NRSA63J-471X MG RESISTOR 470
R1803 NRSA63J-333X MG RESISTOR 33k
R1804 NRSA63J-750X MG RESISTOR 75
R1805 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R1806 NRSA63J-750X MG RESISTOR 75
R1807 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R1808 NRSA63J-823X MG RESISTOR 82k
R1809 NRSA63J-391X MG RESISTOR 390Ω 1/16W J
R1810 NRSA63J-823X MG RESISTOR 82k
R1811 NRSA63J-391X MG RESISTOR 390Ω 1/16W J
R1812 NRSA63J-104X MG RESISTOR 100k
R1813 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R1815 NRSA63J-101X MG RESISTOR 100
R1818 NRSA63J-222X MG RESISTOR 2.2k
R1820 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1821 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

1-10 (No.52033D)



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

R1823 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1824 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R1826 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1829 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R1830 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R1831 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R1832 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J
R1833 NRSA63J-102X MG RESISTOR 1k
R1834 NRSA63J-562X MG RESISTOR 5.6k
R1835 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J
R1836 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R1837 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1838 QRK126J-121X UNF C RESISTOR 120Ω 1/2W J
R1839 QRE121J-221Y C RESISTOR 220Ω 1/2W J
R1840 QRE121J-221Y C RESISTOR 220
R1841 NRSA63J-0R0X MG RESISTOR 0
R1842 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R1843 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R1844 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R1845 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1846 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R1847 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1848 NRSA63J-471X MG RESISTOR 470
R1849 NRSA63J-221X MG RESISTOR 220
R1880 NRSA63J-202X MG RESISTOR 2kΩ 1/16W J
R1881 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1882 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R1883 NRSA63J-181X MG RESISTOR 180Ω 1/16W J
R1902 QRF154K-2R2 UNF WW RESISTOR 2.2Ω 15W K
R1904 QRE121J-681Y C RESISTOR 680Ω 1/2W J
R1905 QRM034J-R15 MP RESISTOR 0.15Ω 3W J
R1907 NRSA63J-563X MG RESISTOR 56kΩ 1/16W J
R1908 QRL039J-333 OMF RESISTOR 33kΩ 3W J
R1909 QRE121J-474Y C RESISTOR 470kΩ 1/2W J
R1910 QRE121J-472Y C RESISTOR 4.7kΩ 1/2W J
R1911 QRE121J-332Y C RESISTOR 3.3kΩ 1/2W J
R1912 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J
R1913 QRX01GJ-3R9 MF RESISTOR 3.9Ω 1W J



R1915 QRZ0111-474 C RESISTOR 470kΩ 1/2W K
R1952 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R1953 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1957 QRE121J-6R8Y C RESISTOR 6.8Ω 1/2W J
R1960 NRSA63J-391X MG RESISTOR 390Ω 1/16W J
R1961 QRL029J-223 OMF RESISTOR 22kΩ 2W J
R1962 NRSA63J-561X MG RESISTOR 560Ω 1/16W J
R1963 QRE121J-103Y C RESISTOR 10kΩ 1/2W J
R1964 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R1965 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R1966 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J
R1967 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R1970 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J
R1971 NRSA63J-183X MG RESISTOR 18kΩ 1/16W J
R1972 NRSA63J-391X MG RESISTOR 390Ω 1/16W J



R1991 QRZ9046-825Z C RESISTOR 8.2MΩ 1/2W K
L1001 CE42050-001Z BEADS CORE

L1002 CE42050-001Z BEADS CORE
L1101 QQLZ014-R82 COIL 0.82uH 100mA L
L1104 QQL244K-180Z PEAKING COIL 18uH K
L1480 QQR1138-001 CHOKE COIL
L1523 QQR1137-005 LINEARITY COIL
L1524 QQLZ034-140 HEATER CHOKE 14uH
L1540 QQL244J-5R6Z COIL 5.6uH J
L1701 QQL244K-100Z PEAKING COIL 10uH K
L1702 QQL244K-100Z PEAKING COIL 10uH K
L1731 QQL244J-5R6Z COIL 5.6uH J
L1951 QQLZ034-460 HEATER CHOKE 46uH
L1953 QQL244J-5R6Z COIL 5.6uH J
L1954 QQL244J-5R6Z COIL 5.6uH J



T1521 QQR1229-001 DRIVE TRANSF



T1901 QQS0165-001 SW TRANSF
CF1106 QAX0639-001Z C TRAP 4.500MHz

CF1130 QAX0642-001Z C FILTER 4.500MHz
CF1140 QAX0695-001Z C FILTER 5.500MHz
CF1141 QAX0696-001Z C FILTER 6.000MHz
CF1142 QAX0697-001Z C FILTER 6.500MHz
CN1001 QGA2501C5-04Z CONNECTOR W-B (1-4)
CN100A QJC001-032003 CONNECTOR ASSY
CN100C QGA2501C5-06Z CONNECTOR W-B (1-6)
CN100D WJQ0003-002A E-SH C WIRE B-B
CN100S QGA2501C5-05Z CONNECTOR W-B (1-5)
CN100T QJK002-065631 SIN CR C-B WIRE
CN100U CHHB04-400U-GS 4P DB WIRE ASSY
CN10HV Q GZ5004C1-04 CONNECTOR (1-4)
CN10PW QGA7901F1-02 CONNECTOR W-B (1-2)
CN1DEG QGZ5004C1-02 CONNECTOR (1-2)



CP1951 ICP-N75-Y IC PROTECTOR 2.7A



CP1952 ICP-N50-Y IC PROTECTOR 2.0A

Ω

1/16W J

Ω

1/16W J

Ω

1/2W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J



CP1953 ICP-N75-Y IC PROTECTOR 2.7A



F1901 QMF51E2-4R0J4 FUSE 4A AC250V
HS1401 LC31696-001A HEAT SINK
HS1480 CM42862-A0A HEAT SINK ASSY
HS1522 LC31215-001A HEAT SINK/FE-P/
HS1650 LC30145-003A HEAT SINK/AL-F/
HS1901 CEHT12N-026PS HEAT SINK
HS1974 LC31334-002A HEAT SINK/AL-F/
J1770 QNS0155-001 3.5 JACK HEADPHONE
J1771 QNN0282-003 PIN JACK V IN
J1772 QNN0282-002 PIN JACK L IN
J1773 QNN0282-001 PIN JACK R IN
J1801 QNN0349-001 PIN JACK S/V/L/R IN
J1802 QNN0349-002 PIN JACK V/L/R IN
J1803 QNN0348-001 PIN JACK L/R IN
J1804 QNN0349-001 PIN JACK V/L/R OUT
K1104 QQR1113-001Z FERRITE BEADS
K1105 QQR1113-001Z FERRITE BEADS
K1106 QQR1113-001Z FERRITE BEADS
K1701 QQR1113-001Z FERRITE BEADS
K1901 QQR1113-001Z FERRITE BEADS
K1902 QQR1114-001Z FERRITE BEADS
K1903 QQR1114-001Z FERRITE BEADS
K1951 QQR1113-001Z FERRITE BEADS
K1953 QQR1113-001Z FERRITE BEADS
K1954 QQR1113-001Z FERRITE BEADS
K1955 QQR1214-001Y FERRITE BEADS



LF1901 QQR0673-004 LINE FILTER



LF1902 QQR1035-002 LINE FILTER



PC1901 PC123F2 PHOTO COUPLER



RY1901 QSK0092-001 RELAY
S1780 QSW0619-003Z TACT SWITCH MENU
S1781 QSW0619-003Z TACT SWITCH CH­S1782 QSW0619-003Z TACT SWITCH CH+
S1783 QSW0619-003Z TACT SWITCH VOL­S1784 QSW0619-003Z TACT SWITCH VOL+



S1901 QSW0846-001 PUSH SWITCH POWER
SF1101 QAX0325-001 SAW FILTER
SF1102 QAX0731-001 SAW FILTER



TH1901 QAD0134-4R5 POSISTOR 4.5
TU1001 QAU0185-005 TUNER



VA1901 QAF0052-621 VAR ISTOR 620V
X1701 QAX0737-001 CRYSTAL 12.000MHz

Ω

CRT SOCKET P.W. BOARD ASS'Y (SCH-3602A-H2)



Ref No. Part No. Part Name Description Local

Q3350 STC344-T TRANSISTOR
Q3351 2SA1321-T SI TRANSISTOR
Q3352 2SA1309A/QR/ TRANSISTOR
Q3360 STC344-T TRANSISTOR
Q3361 2SA1321-T SI TRANSISTOR
Q3370 STC344-T TRANSISTOR
Q3371 2SA1321-T SI TRANSISTOR
Q3374 2SC3311A/QR/ TRANSISTOR
Q3375 2SC3311A/QR/ TRANSISTOR
Q3376 2SC3311A/QR/ TRANSISTOR

D3350 1SS244-T2 SI DIODE
D3352 RGP10J-5025-T3 SI DIODE
D3353 MA165 SI DIODE
D3354 MA165 SI DIODE
D3355 MA165 SI DIODE
D3356 MA165 SI DIODE
D3357 MA165 SI DIODE
D3358 MA165 SI DIODE
D3360 1SS244-T2 SI DIODE
D3370 1SS244-T2 SI DIODE
D3372 MA4075/M/-T2 Z DIODE
D3373 MA165 SI DIODE
D3374 MA165 SI DIODE

C3350 QCS31HJ-471 C CAPACITOR 470pF 50V J
C3351 QCS31HJ-681 C CAPACITOR 680pF 50V J
C3352 QETM2EM-475 E CAPACITOR 4.7uF 250V M
C3353 QETM1HM-107 E CAPACITOR 100uF 50V M
C3354 QETM1HM-105 E CAPACITOR 1uF 50V M
C3355 QETM1HM-105 E CAPACITOR 1uF 50V M
C3360 QCS31HJ-471 C CAPACITOR 470pF 50V J
C3361 QCS31HJ-681 C CAPACITOR 680pF 50V J
C3370 QCS31HJ-471 C CAPACITOR 470pF 50V J
C3371 QCS31HJ-821 C CAPACITOR 820pF 50V J
C3372 QRE142J-273 C RESISTOR 27k
C3374 QCZ0364-222 C CAPACITOR 2200pF
C3375 QETM1CM-477 E CAPACITOR 470uF 16V M

Ω

1/4W J

(No.52033D)1-11



Ref No. Part No. Part Name Description Local

R3351 QRE142J-151 C RESISTOR 150Ω 1/4W J
R3352 QRL029J-123 OMF RESISTOR 12kΩ 2W J
R3353 QRE142J-182 C RESISTOR 1.8kΩ 1/4W J
R3354 QRE142J-331 C RESISTOR 330Ω 1/4W J
R3355 QRE142J-101 C RESISTOR 100Ω 1/4W J
R3356 QRE122J-102 C RESISTOR 1kΩ 1/2W J
R3357 QRZ0111-152 C RESISTOR 1.5k
R3358 QRE122J-182 C RESISTOR 1.8k
R3359 QRE122J-471 C RESISTOR 470Ω 1/2W J
R3361 QRE142J-151 C RESISTOR 150Ω 1/4W J
R3362 QRL029J-123 OMF RESISTOR 12kΩ 2W J
R3363 QRE142J-182 C RESISTOR 1.8kΩ 1/4W J
R3364 QRE142J-331 C RESISTOR 330Ω 1/4W J
R3365 QRE142J-101 C RESISTOR 100
R3366 QRE122J-102 C RESISTOR 1k
R3367 QRZ0111-152 C RESISTOR 1.5kΩ 1/2W K
R3368 QRE142J-202 C RESISTOR 2kΩ 1/4W J



R3369 QRZ9017-150 FUSI RESISTOR 15Ω 1/4W J
R3370 QRE142J-151 C RESISTOR 150Ω 1/4W J
R3371 QRL029J-123 OMF RESISTOR 12kΩ 2W J
R3372 QRE142J-182 C RESISTOR 1.8kΩ 1/4W J
R3373 QRE142J-331 C RESISTOR 330
R3374 QRE142J-101 C RESISTOR 100
R3375 QRE122J-102 C RESISTOR 1kΩ 1/2W J
R3376 QRZ0111-152 C RESISTOR 1.5kΩ 1/2W K
R3377 QRE142J-330 C RESISTOR 33Ω 1/4W J
R3378 QRE142J-223 C RESISTOR 22kΩ 1/4W J
R3379 QRE142J-104 C RESISTOR 100kΩ 1/4W J
R3383 QRE122J-394 C RESISTOR 390kΩ 1/2W J
R3384 QRE142J-103 C RESISTOR 10kΩ 1/4W J
R3385 QRE142J-393 C RESISTOR 39kΩ 1/4W J
R3386 QRE142J-103 C RESISTOR 10kΩ 1/4W J

L3350 CH41005-H-05C FORMING BUS WIR
L3351 CH41005-H-05C FORMING BUS WIR
L3352 CH41005-H-05C FORMING BUS WIR
L3353 CH41005-H-05C FORMING BUS WIR

CN300T QGA2501C5-05 CONNECTOR W-B (1-5)
CN300U QGA2501C5-04 CONNECTOR W-B (1-4)
CN30E1 CHGT0015-0A CONNECTOR ASSY



SK3351 QNZ0537-001 CRT SOCKET

Ω

1/2W K

Ω

1/2W J

Ω

1/4W J

Ω

1/2W J

Ω

1/4W J

Ω

1/4W J

VICTOR COMPANY OF JAPAN, LIMITED

AV & MULTIMEDIA COMPANY VIDEO DISPLAY CATEGORY 12, 3-chome, Moriya-cho, kanagawa-ku, Yokohama, kanagawa-prefecture, 221-8528, Japan

(No.52033D)

Printed in Japan

WPC
