JVC AV-21MS26, AV-21BS26, AV-21MX56, AV-21MX16, AV-21BX16B User Manual
...
COLOUR TELEVISION EQUALIZER • CINEMA SURROUND • COMPONENT INPUT
Contents
AV-29BS26 AV-21BS26
AV-29BX16 AV-21BX16
AV-29MS26 AV-21BX16B
AV-29MX16 AV-21MS26
AV-29MX56 AV-21MX16
AV-29MX76 AV-21MX56
AV-29SS26 AV-21MX76
AV-29SX56
AV-29SX76
AV-25MS26
AV-25MX16
AV-25MX56
Knowing your TV’s features .......................................................3
Remote control buttons and basic functions ..............................4
TV buttons and functions ............................................................6
Setting up your TV ......................................................................7
Basic setting for picture ..............................................................9
Advanced setting for picture ..................................................... 11
Original features for picture ......................................................12
Basic setting for sound .............................................................14
Advanced setting for sound ......................................................15
DVD Menu ................................................................................16
Customized setting ...................................................................17
TV channel presetting ..............................................................19
Additional preparation ..............................................................22
Troubleshooting ........................................................................23
Specifi cations .............................................................Back cover
AV-25MX76
INSTRUCTIONS
GGT0116-001A-H
Thank you for buying this JVC colour television.
To make sure you understand how to use your new TV, please read this manual thoroughly before you begin.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE
CAUTION: TO ENSURE PERSONAL SAFETY, OBSERVE THE
1 Operate only from the power source indicated on the rear of the TV.
2 Avoid damaging the power cord and mains plug. When unplugging the
TV, grasp the mains plug. Do not pull on the power cord.
3 Never block or cover the ventilation openings.
Never install the TV where good ventilation is unattainable.
When installing this TV, leave spaces for ventilation around the TV of
more than the minimum distances as shown.
4 Do not allow objects or liquid into the cabinet openings.
5 In the event of a fault, unplug the unit and call a service technician.
Do not attempt to repair it yourself or remove the rear cover.
6 The surface of the TV screen is easily damaged. Be very careful with it
when handling the TV. Should the TV screen become soiled, wipe it with
a soft dry cloth. Never rub it forcefully. Never use any cleaner or detergent
on it.
THIS APPLIANCE TO RAIN OR MOISTURE.
FOLLOWING RULES REGARDING THE USE OF THIS TV.
15 cm
10 cm 10 cm
15 cm
7 This TV can be turned on/off power by connecting/disconnecting the AC
plug into AC outlet. While this TV is being installed, enough space should
be reserved for connection/disconnecting the AC plug into AC outlet by
hand.
8 The apparatus shall not be exposed to dripping or splashing and that
no objects fi lled with liquids, such as vases, shall be placed on the
apparatus.
WARNING: <AV-21M, AV-25M, AV-29M, AV-21B, AV-29B Series>
YOU CAN DETACH THE PROTECT SHEET ON THE TOP
THE FRONT BUTTON DOOR OF THE TV SHOULD BE
AND BOTTOM OF FRONT FRAME IF YOU NEEDED.
PULLED OUT FROM ITS BOTTOM. DO NOT PRESS THE
UPPER PART, OR YOUR FINGER MAY BE PINCHED.
PULL PULL
✓
2
Knowing your TV’s features
Main features
DVD MENU Just connect DVD player to the television. The television will detect DVD signal and display
MaxxBass MaxxBass enhances bass sound that cannot be reproduced by normal speakers to be
EXIT
PIP (Picture In Picture) You can view two screens ( Main picture and Sub picture ) at the same time.
TELETEXT You can view teletext programmes which are broadcasted by some TV channels. Teletext
FAVORITE CH (Channel) You can register up to four favorite channels for quick recall with one press.
A2/NICAM
1
(STEREO / I.II)
AI ECO SENSOR TV detects the brightness of your room and automatically adjust the picture brightness to
ECO MODE You can adjust TV screen contrast according to the brightness of your room to suitable
2
3
5
AI VOLUME TV adjusts the volume automatically to the same level for all TV channels to avoid sudden
4
TINT You can adjust TINT setting for all colour systems, including PAL.
Confi rm your TV’s functions
Some functions written in this instruction manual may not be available for your TV.
Please see the chart below and check the functions that are equipped for your TV’s model number.
The model number is indicated at the rear of your TV. When you press a button concerned to a function that is not available
for your TV, it does not work and the logo “Ø” appears on the screen.
NO.
Function
1
2,3
PIP control buttons (Green label)
4,3
TELETEXT control buttons (Black label)
PICTURE TILT
—
MaxxBass
—
5
AI ECO SENSOR
5
ECO MODE
(STEREO/I
picture on the screen automatically and you can adjust pictures and sound while you are
watching DVD as your desire. When disconnect DVD player, the television will display the
previous channel.
heard by our ears.
programme is an infromation in text form.
You can listen the stereo sound or billingal sound from TV programme broadcasting by A2
or NICAM Sound-multiplex system.
a suitable level for a better eyecare.
level for a better eyecare.
change of the volume when selecting different TV channels or selecting Video Mode.
■
II)
Model No.
AV-29BS26
AV-29BX16
AV-29MX16
AV-29MS26
AV-29SS26
AV-29MX56
AV-29SX56
AV-29MX76
AV-29SX76
AV-25MS26
AV-25MX16
AV-25MX56
AV-25MX76
AV-21BS26
AV-21BX16
AV-21BX16B
AV-21MS26
AV-21MX16
AV-21MX56
AV-21MX76
O—— O — — O———O — O———
——— — O O ——OO— — ——OO
O—— O — O O——OO — O——O
O O O O O O ————— — ————
——O O O O OOOO—— OOOO
——O O O O OOOO—— OOOO
O O — — — — ———— O O ————
3
Remote control buttons and basic functions
No. Press To
POWER Turn on or off the TV from standby mode.
1
MENU/OK Display menu and confi rm selected function.
2
5 / ∞ / 2 / 3 Select and adjust menu function.
3
CHANNEL -/+ Select the desired channel number.
4
VOLUME -/+ Adjust the volume level.
5
TV/VIDEO
6
EXIT
MUTING Turn off the volume.
7
DISPLAY
8
/BACK
0~9, -/-- Select the programme number. For two digits programme number, press -/--, then press the
9
RETURN+ a) Return to the frequently view channel with one touch.
!
FAVORITE
"
CHANNEL
(colour buttons: red,
green, yellow, blue)
4
Select TV or video terminal input.
On the other hand, you can use this button to EXIT from the menu.
Press this button again to resume the volume.
Display the programme number or video terminal number, stereo/bilingual broadcast system and
PR list (channel list) on the screen.
You can select the channel using the PR list.
1 Press the DISPLAY button once to display the PR list.
2 Press 5 / ∞ / 2 / 3 buttons to choose a channel, then press the MENU/OK button.
You can confi rm the favorite channels in the PR list. The channels set to favorite channels are
indicated with coloured mark.
On the other hand, you can use this button to return to the previous menu.
number button.
1 Choose the channel you want to register.
2 Press and hold RETURN+ button until “RETURN PLUS PROGRAMMED!” appears.
To cancel, press and hold RETURN+ button until “RETURN PLUS CANCELED!” appears.
b) Return to the previously viewed channel, if you have not set or have cancelled the Return
channel as above.
Register and recall 4 favorite channels.
1. Choose the TV channel you want to register then press and hold a colour button until
“PROGRAMMED! ■" appears.
2. To register other favorite channels, repeat step 1.
To recall the favorite channel, press the corresponding colour button.
When the TV is in Text function or MENU mode, the favorite channel function is not available.
When the TV is in PIP function, the favorite channel function cannot register but can recall the
favorite channel.
1
"
8
2
!
4
6
EXIT
3
7
9
5
Remote control buttons and basic functions (continued)
How to operate menus and menus locations
To Operation Note
Display the MENU
Choose a Top
menu
Choose a 2nd
menu
Display the 3rd
menu
Return to the
previous menu
Choose the setting
of a function
Adjust the effect
level of a function
Display the sub
menu of a function.
Press the MENU/OK button 2.
PICTURE MENU is displayed on
fi rst press.
Press 2/3 buttons 3 to choose
a menu title when the cursor is
pointing at MENU.
Press 5/∞ buttons 3 to choose a
2nd menu title.
Press 5/∞ buttons 3 to choose a
2nd menu title. Then press MENU/
OK button 2.
Press the DISPLAY/BACK button
8.
Press 5/∞ buttons 3 to choose
a function. Then press the 2/3
buttons 3 to change the setting.
Press 5/∞ buttons 3 to choose
a function. Then press the 2/3
buttons 3 to adjust the effect
level.
Press the 5/ ∞ buttons 3 to
choose a function. Then press
MENU/OK button 2 to display
the sub menu.
The following chart shows locations of functions in menus. In this manual,
location of a function is described as follows:
MENU
Top menu
2nd menu
Top menu 3rd menuMENU 2nd menu
Note: Some functions have the 4th menus as the sub-menus.
To exit the MENU,
press the DISPLAY/
BACK button 8 or
choose EXIT menu
or TV/VIDEO/EXIT
button 6.
—
Press ∞ button 3
to display the next
functions.
—
Press the TV/ VIDEO/
EXIT button 6 to exit
from the menu.
—
Top menu 2nd menu Location 3nd menu Location
PICTURE PICTURE MODE P.9 – –
MENU
SOUND
FEATURES DVD MENU P.16
INSTALL AUTO PROGRAM P.19 ––
PICTURE SETTING P.10 CONTRAST P.10
WHITE BALANCE P.10 – –
VNR P.17 – –
I■II
STEREO/
AI VOLUME P.15 ––
SOUND MODE P.14 ––
EQUALIZER P.15 ––
BALANCE P.14 ––
CINEMA SURROUND
MaxxBass P.15 ––
ON TIMER P.17 PR P.17
OFF TIMER P.17 ––
CHILD LOCK P.17 ––
COMPRESS (16:9)
AI ECO SENSOR/
ECO MODE
EDIT/MANUAL P.19 DELETE, MOVE,
COLOUR SYSTEM P.9 ––
LANGUAGE P.17 LANGUAGE P.17
TEXT LANGUAGE P.13 TEXT LANGUAGE P.13
VIDEO-2 SETTING P.18 ––
BLUE BACK P.11 ––
PICTURE TILT P.11 ––
BEEP P.18 ––
P. 1 5 ––
P.15 ––
P.11 ––
P.11 ––
BRIGHT P.10
SHARP P.10
COLOUR P.10
TINT P.10
AUTO SIGNAL DETECT
DVD PICTURE MODE
DVD THEATER STATUS
DVD SOUND MODE
ON TIMER P.17
MANUAL, INSERT
P.16
P.16
P.16
P.16
P.19P.20
5
TV buttons and functions
The illustrations shown below is for AV-21BS26 and AV-29SS26 only, which are used for explanation purpose.
Your TV may not look exactly the same as illustrated.
Front of the TV
AV-29SS26
TV/VIDEO
MENU/OK
CHANNEL
VOLUME
AV-21BS26
VR
IN (VIDEO-3)
Rear of the TV
AV-29SS26
#/-0/.%.4
6)$%/
6)$%/
/54054
).054
).054
3
/6%2
6
9
6
6
,22,
,
#
"
-/./
-/./
#
2
2
6
L / MONO
POWER
RVL/MONO
IN(VIDEO-3)
POWER
VOLUME
CHANNEL
MENU
OK
No. Button/terminal Description Page
L (main power)
1
POWER lamp Indicate the TV’s status. –
2
Press to turn on or turn off the TV’s main power. –
No colour : TV’s main power is being turned off.
Red : TV’s main power is being turned on.
Blink :
While the TV is in turn on mode , OFF TIMER function is in used.
Note: When you turn off the power switch while TV is in standby mode,
While the TV is in standby mode, ON TIMER funciton is in used.
the power lamp will go off in 10 -15 seconds.
When you operate the TV, POWER Lamp will be blink.
ECO sensor –
3
Remote control sensor –
4
TV/VIDEO
5
VOLUME -/+ Press to adjust the volume level. –
6
CHANNEL -/+
7
MENU/OK Press to display the menu. –
8
IN (VIDEO-3) Video and audio input jacks for VIDEO-3 mode. 22
9
!
"
OUTPUT Video and audio output jacks. (The component video
#
COMPONENT
$
(VIDEO-2) INPUT
Press to select TV or Video terminal input or exit from menu.
Press to select the desired channel (Both of RF and Video input.)
Headphone jack. 22
Aerial socket. 7
signal cannot be output.)
Video or component video, and audio input jacks for VIDEO-2
mode. You can select the input signal by setting the “VIDEO-2
SETTING” function (see page 18).
VIDEO-1 INPUT
%
Video or S-VIDEO, and audio input jacks for VIDEO-1 mode. 7
How to operate the menus with the TV button
TV button
Work as same as the button on
the remote control unit
Note
MENU MENU/OK button To display main menu and exit menu after
fi nish setting.
CHANNEL -/+ ∞/5 button To select menu function.
VOLUME -/+ 2/3 button To choose a Top menu and adjust the
desired menu function.
–
–
22
22
Setting up your TV
CAUTION
• Turn off the equipment including the TV before connecting.
1 Connecting the aerial cable.
VHF/UHF outdoor aerial
2 Connecting the main plug to the AC outlet.
75-ohm coaxial cable (not supplied)
If you connect a VCR, connect the aerial output jack of your VCR and
the aerial jack on the TV with aerial cable. Then connect the output
jacks of your VCR and the VIDEO-1 input jacks of the TV with the
video cable (or S-VIDEO cable if available) and audio cables. For
details, see the manual of your VCR.
Rear of TV
AV-21BS26
VCR
VHF/UHF outdoor aerial
COMPONENT
VIDEO-1
(VIDEO-2)
OUTPUT
INPUT
INPUT
S
OVER
V
Y
V
/
V
L
LRRL
B
C
/
/
MONO
MONO
C
R
R
The illustration shown is just a sample. It may not be same as your TV.
3 Inserting batteries into the remote control.
Insert two batteries by following the + and - polarities
and inserting the - end fi rst.
CAUTION:
Follow the cautions printed on the batteries.
Notes:
• Use AA/R6/UM-3 dry cell batteries.
• If the remote control does not work properly, fi t
new batteries. The supplied batteries are for testing,
not regular use.
4 Turn on the TV by pressing the main power button.
JVC logo appears on the screen.
JVC logo will appear on the screen again at the phase of “SETUP
TOUR RESTART?” function. Then the initial setting can be performed
according to page 8.
Note:
While in the INSTALL menu with the cursor pointing at INSTALL, pressing
the blue button will also display the JVC logo.
7
Setting up your TV (continued)
5 Making the initial settings
Set up your TV by pressing MENU/OK button or waiting for 15 seconds, then operate the TV by following the steps
When turn on the TV at
the next time
below:
LANGUAGE TEXT LANGUAGE
ENGLISH
кмллдав
FRANÇAIS
MENU : OK
DISPLAY : BACK
TV/VIDEO : EXIT
• Press 5/∞ button to
select your desired
language*.
TEXT LANGUAGE
GROUP–1
GROUP–2
GROUP–3
GROUP–4
MENU : OK
DISPLAY : BACK
TV/VIDEO : EXIT
• Press 5/∞ button to
select your desired
Teletext language
group*. For details,
see page 13.
(For BS26/MS26/
SS26/MX76/SX76
series only)
AUTO PROGRAM
22%
MENU : OK
• TV will start searching
for the channels.
To stop AUTO
PROGRAM, press
MENU/OK button.
EDIT
PR CH/CC
AV
■
1 CH 04
■
2 CH 76
■
3 CH 78
■
4 CH 05
5 CH 28
6 CH 10
MENU : OK
MOVE
3
■
INSERT
■
DELETE
■
MANUAL
• To complete the initial
setting, press the
MENU/OK button. To
edit the channel list,
see page 19.
AUTO PROGRAM
SETUP TOUR RESTART?
■
: YES
MENU : NO
• “SETUP TOUR
RESTART?” will be
displayed.
Press the MENU/OK
button to cancel
the SETUP TOUR
RESTART function.
If you want to make
initial settings again
when the next time
you turn on the TV,
press the Red button
to activate the SETUP
TOUR RESTART
function.
* If the TEXT function is available for your TV and the LANGUAGE shown follow as ENGLISH/кмллдав/ / /FRANÇAIS, you
can select the TEXT LANGUAGE group from GROUP-1 to GROUP-4.
If the TEXT function is available for your TV and the LANGUAGE shown follow as ENGLISH/кмллдав/
/MELAYU/INDONESIA,
you can select the TEXT LANGUAGE group from GROUP-1 to GROUP-3.
8
Loading...
