JVC AV-21D43/BBT Service Manual

SERVICE MANUAL

COLOUR TELEVISION

52036B20051

BASIC CHASSIS

AV-21D43/BBT

Supplementary

The following items for the AV-21D43/BBT was changed partly from AV-21D43/BK.
Therefore, this service manual describes only the items which differ from those of the AV-21D43/BK service
manual.
For details other than those described in this manual, please refer to the AV-21D43/BK service manual
(No.52036, Aug. 2002).

OUTLINE

CG

Since the production place was changed, we have issued the SERVICE MANUAL for AV-21D43/BBT.

HOW TO IDENTIFY MODELS

"AV-21D43BBT" is added at the bottom of the Rating label.

AV-21D43

Indicated

AV-21D43BBT

COPYRIGHT © 2005 Victor Company of Japan, Limited

No.52036B

2005/1

DIFFERENCE LIST

USING P.W. BOARD (Page 39)

P.W.B ASS'Y Name AV-21D43/BK AV-21D43/BBT DESCRIPTION

MAIN PWB SCG-1435A SCG-1514A-H2 Non compatible

EXPLODED VIEW PARTS LIST -1 (Page 40)

Ref. No.

L01 QQW0006-001 QQW0088-001 DEG COIL

1 LC11129-021A-H LC11129-021C-H FRONT CABINET

2 CM48125-009 GG40023-001A-H JVC MARK

4 GG30019-001B-H GG30019-003A-H POWER KNOB

5 CM30861-069 CM35235-003-H SPRING

6 GG20006-001A-H GG20006-003A-H CONTROL KNOB

8 A48457-1 A48457-3-H SPRING

9 CHGB0016-0B-N CHGB0016-0B-FH BRAIDED ASSY

11 QAL0627-001 CE40764-00A WEDGE ASSY

14 QMPR010-200-E2 QMPR410-165-K2 POWER CORD

16 GG10130-005A-H GG10130-014A-H REAR COVER

19 GG20029-008A-H GG20024-001B-H RATING LABEL

AV-21D43/BK AV-21D43/BBT

Part No.

PART NAME DESCRIPTION

PACKING PARTS LIST (Page 45)

Ref. No.

1 GG10195-003A-H GG10056-065B-H PACKING CASE

2 CM47385-00A GG20025-003A-H CORNER LABEL 2pcs in 1set

4 CP30697-005-H GG30097-003A-H POLY BAG

6 QPA02503505 GG30096-001A-H POLY BAG

AV-21D43/BK AV-21D43/BBT

Part No.

PART NAME DESCRIPTION

1-2 (No.52036B)

PRINTED WIRING BOARD PARTS LIST



MAIN P.W. BOARD ASS'Y (SCG-1514A-H2)



Ref No. Part No. Part Name Description Local

IC1301 NN5198K IC
IC1421 AN5539-LF IC
IC1651 LA4287 IC
IC1652 SI-5003X-X IC
IC1701 MN1873287JM IC
IC1702 AT24C08-21D43BK IC (SERVICE)
IC1703 L78LR05E-MA IC
IC1704 GP1UM281QK IR DETECT UNIT 38kHz
IC1921 STR-G6653 IC
IC1941 SE115N-LF12 IC
IC1971 BA51W12ST-V5 IC

Q1102 2SC5083/L-P/-T TRANSISTOR
Q1161 2SD601A/QR/-X TRANSISTOR
Q1301 2SB709A/QR/-X TRANSISTOR
Q1302 2SD601A/QR/-X TRANSISTOR
Q1351 STC344-T TRANSISTOR
Q1352 STC344-T TRANSISTOR
Q1353 STC344-T TRANSISTOR
Q1401 DTC124ESA-T DIGI TRANSISTOR
Q1402 2SD601A/QR/-X TRANSISTOR
Q1521 2SK3065-W SI TRANSISTOR



Q1522 2SC5388-CA POW TRANSISTOR H.OUT
Q1523 2SD601A/QR/-X TRANSISTOR
Q1524 2SD601A/QR/-X TRANSISTOR
Q1571 2SA1208/ST/Z1-T TRANSISTOR
Q1572 2SD601A/QR/-X TRANSISTOR
Q1651 2SB709A/QR/-X TRANSISTOR
Q1652 DTC323TK-X DIGI TRANSISTOR
Q1654 2SD601A/QR/-X TRANSISTOR
Q1655 2SD601A/QR/-X TRANSISTOR
Q1702 2SD601A/QR/-X TRANSISTOR
Q1703 2SD601A/QR/-X TRANSISTOR
Q1708 UN2212-X DIGI TRANSISTOR
Q1709 2SB709A/QR/-X TRANSISTOR
Q1710 UN2212-X DIGI TRANSISTOR
Q1803 2SC1815/YG/-T TRANSISTOR
Q1804 2SD601A/QR/-X TRANSISTOR
Q1941 2SD601A/QR/-X TRANSISTOR
Q1943 UN2211-X TRANSISTOR
Q1974 2SA966/OY/-T TRANSISTOR
Q1975 UN2212-X DIGI TRANSISTOR

D1001 MA3330/L/-X Z DIODE
D1301 MA3091/M/-X Z DIODE
D1302 MA3091/M/-X Z DIODE
D1305 RB100A-T2 SI DIODE
D1306 1SR124-400A-T2 SI DIODE
D1341 MA111-X SI DIODE
D1342 MA111-X SI DIODE
D1421 MA3360/M/-X Z DIODE
D1422 MA3360/M/-X Z DIODE
D1423 1SR124-400A-T2 SI DIODE
D1424 MA111-X SI DIODE
D1425 MA111-X SI DIODE
D1427 MA3270/H/-X Z DIODE
D1551 RGP10J-TS-T3 SI DIODE
D1552 RH1S-T3 SI DIODE
D1553 MA3091/M/-X Z DIODE
D1554 MA111-X SI DIODE
D1555 1SR124-400A-T2 SI DIODE
D1571 MA3075/M/-X Z DIODE
D1581 MA3200/M/-X Z DIODE
D1582 RGP10J-TS-T3 SI DIODE
D1651 MA111-X SI DIODE
D1652 MA111-X SI DIODE
D1653 MTZJ18A-T2 Z DIODE
D1701 MA111-X SI DIODE
D1704 LH22440-T16 LED POWER(RED)
D1705 SLR-342MG-T16 LED (GREEN)
D1706 MA111-X SI DIODE
D1707 MA111-X SI DIODE
D1731 MA111-X SI DIODE
D1921 RGP10J-TS-T3 SI DIODE
D1922 MA111-X SI DIODE
D1923 MA111-X SI DIODE
D1924 MA111-X SI DIODE
D1926 MA3056/M/-X Z DIODE
D1927 MA3068/M/-X Z DIODE
D1929 RD12E/B2/-T5 Z DIODE
D1930 EG1A-T3 SI DIODE
D1932 MA111-X SI DIODE
D1933 RD27E/B2/-T5 Z DIODE
D1941 RU3AM-LFC4 SI DIODE

Ref No. Part No. Part Name Description Local

D1942 RU3YX-LFC4 SI DIODE
D1943 RGP10J-TS-T3 SI DIODE
D1945 MA3075/H/-X Z DIODE
D1982 MA111-X SI DIODE
D1983 MA111-X SI DIODE

C1001 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1002 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C1004 QETN1CM-477Z E CAPACITOR 470uF 16V M
C1005 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C1008 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1103 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1104 NCB21HK-472X C CAPACITOR 4700pF 50V K
C1105 NCB21HK-472X C CAPACITOR 4700pF 50V K
C1106 NCB21HK-472X C CAPACITOR 4700pF 50V K
C1107 NCB21HK-472X C CAPACITOR 4700pF 50V K
C1110 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
C1112 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1113 NCB21HK-472X C CAPACITOR 4700pF 50V K
C1115 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C1116 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C1117 QFVF1HJ-224Z MF CAPACITOR 0.22uF 50V J
C1119 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C1120 NDC21HJ-121X C CAPACITOR 120pF 50V J
C1121 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C1122 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C1161 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C1162 NCB21HK-152X C CAPACITOR 1500pF 50V K
C1164 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C1165 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C1166 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1301 NCB21HK-681X C CAPACITOR 680pF 50V K
C1302 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1303 NDC21HJ-100X C CAPACITOR 10pF 50V J
C1304 QFVF1HJ-474Z MF CAPACITOR 0.47uF 50V J
C1305 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C1306 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C1307 QETN1CM-477Z E CAPACITOR 470uF 16V M
C1308 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1309 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C1310 NDC21HJ-221X C CAPACITOR 220pF 50V J
C1311 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C1312 QENC1HM-474Z BP E CAPACITOR 0.47uF 50V M
C1313 QETN1HM-335Z E CAPACITOR 3.3uF 50V M
C1314 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C1315 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1316 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1317 NCB21HK-473X C CAPACITOR 0.047uF 50V K
C1321 NDC21HJ-120X C CAPACITOR 12pF 50V J
C1322 NCB21HK-273X C CAPACITOR 0.027uF 50V K
C1323 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C1324 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1325 QENC1HM-106Z BP E CAPACITOR 10uF 50V M
C1326 NCS21HJ-221X C CAPACITOR 220pF 50V J
C1341 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1351 QCZ0121-102 C CAPACITOR 1000pF 3KV Z
C1354 NDC21HJ-271X C CAPACITOR 270pF 50V J
C1355 NDC21HJ-221X C CAPACITOR 220pF 50V J
C1356 NDC21HJ-331X C CAPACITOR 330pF 50V J
C1357 QETN1AM-477Z E CAPACITOR 470uF 10V M
C1365 QENC1HM-105Z BP E CAPACITOR 1uF 50V M
C1366 QENC1HM-105Z BP E CAPACITOR 1uF 50V M
C1367 QENC1HM-105Z BP E CAPACITOR 1uF 50V M
C1401 QFVF1HJ-474Z MF CAPACITOR 0.47uF 50V J
C1402 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C1422 QETN1HM-105Z E CAPACITOR 1uF 50V M
C1423 QCS32HJ-180Z C CAPACITOR 18pF 500V J
C1424 QFLC2AJ-103Z M CAPACITOR 0.01uF 100V J
C1426 QFLC1HJ-102Z M CAPACITOR 1000pF 50V J
C1427 QETN1VM-107Z E CAPACITOR 100uF 35V M
C1428 QEHR1VM-107Z E CAPACITOR 100uF 35V M
C1429 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1430 QFN32AJ-472Z M CAPACITOR 4700pF 100V J
C1433 QEHR1HM-475Z E CAPACITOR 4.7uF 50V M
C1435 QETM1EM-228 E CAPACITOR 2200uF 25V M
C1436 QFVF1HJ-334Z MF CAPACITOR 0.33uF 50V J
C1501 QETN1HM-476Z E CAPACITOR 47uF 50V M
C1502 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C1503 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1504 QETN1CM-227Z E CAPACITOR 220uF 16V M
C1523 QEHR1VM-476Z E CAPACITOR 47uF 35V M
C1525 QFZ0200-103 MPP CAPACITOR 0.01uF 1.5kV H
C1526 QEHR1EM-337Z E CAPACITOR 330uF 25V M
C1527 QFZ0199-224 MPP CAPACITOR 0.22uF 250V J
C1528 QETN2EM-475Z E CAPACITOR 4.7uF 250V M
C1531 QEZ0203-107 E CAPACITOR 100uF 160V M

(No.52036B)1-3



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

C1552 QETM1VM-108 E CAPACITOR 1000uF 35V M
C1554 QETN2EM-475Z E CAPACITOR 4.7uF 250V M
C1555 QFLC2AJ-104Z M CAPACITOR 0.1uF 100V J
C1571 QETN1AM-107Z E CAPACITOR 100uF 10V M
C1572 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1581 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C1582 QFZ0199-224 MPP CAPACITOR 0.22uF 250V J
C1651 QTNC1HM-105Z E CAPACITOR 1uF 50V M
C1652 QEHR1HM-106Z E CAPACITOR 10uF 50V M
C1653 QEHR1HM-106Z E CAPACITOR 10uF 50V M
C1654 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1655 QEHQ1VM-228 E CAPACITOR 2200uF 35V M
C1656 QEHR1EM-477Z E CAPACITOR 470uF 25V M
C1658 QETN1HM-226Z E CAPACITOR 22uF 50V M
C1659 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1663 QEHR1HM-106Z E CAPACITOR 10uF 50V M
C1664 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1665 QEHR1HM-105Z E CAPACITOR 1uF 50V M
C1701 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1705 QETN1CM-477Z E CAPACITOR 470uF 16V M
C1706 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1707 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C1708 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1709 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C1710 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1711 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C1712 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C1713 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C1714 NDC21HJ-330X C CAPACITOR 33pF 50V J
C1715 NDC21HJ-330X C CAPACITOR 33pF 50V J
C1716 NDC21HJ-181X C CAPACITOR 180pF 50V J
C1717 NDC21HJ-181X C CAPACITOR 180pF 50V J
C1718 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C1719 QETN1HM-105Z E CAPACITOR 1uF 50V M
C1720 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C1721 NCB21HK-333X C CAPACITOR 0.033uF 50V K
C1722 NDC21HJ-101X C CAPACITOR 100pF 50V J
C1724 NDC21HJ-560X C CAPACITOR 56pF 50V J
C1728 NDC21HJ-181X C CAPACITOR 180pF 50V J
C1729 NDC21HJ-181X C CAPACITOR 180pF 50V J
C1730 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C1738 QETN1HM-226Z E CAPACITOR 22uF 50V M
C1744 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C1805 QETN1CM-227Z E CAPACITOR 220uF 16V M
C1806 QETN1CM-477Z E CAPACITOR 470uF 16V M
C1811 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1841 NCB21HK-152X C CAPACITOR 1500pF 50V K



C1901 QFZ9075-104 MPP CAPACITOR 0.1uF AC275V M



C1904 QCZ9082-222Z C CAPACITOR 2200pF AC250V M



C1905 QCZ9082-222Z C CAPACITOR 2200pF AC250V M



C1907 QCZ9082-222Z C CAPACITOR 2200pF AC250V M
C1909 QEZ0476-127 E CAPACITOR 120uF



C1910 QFZ9075-473 MPP CAPACITOR 0.047uF AC275V M
C1922 QFLC1HJ-471Z M CAPACITOR 470pF 50V J
C1924 QETN1VM-107Z E CAPACITOR 100uF 35V M
C1926 QFLC1HJ-332Z M CAPACITOR 3300pF 50V J
C1928 NCB21HK-473X C CAPACITOR 0.047uF 50V K
C1929 QFP32GJ-223Z PP CAPACITOR 0.022uF 400V J
C1930 QCZ0122-561 C CAPACITOR 560pF 2kV K
C1931 QCZ0325-151 C CAPACITOR 150pF 2kV K
C1932 QCZ0325-151 C CAPACITOR 150pF 2kV K
C1941 QCZ0122-561 C CAPACITOR 560pF 2kV K
C1942 QEZ0420-107 E CAPACITOR 100uF 150V M
C1945 QEHR1CM-108Z E CAPACITOR 1000uF 16V M
C1946 QEHR1CM-477Z E CAPACITOR 470uF 16V M
C1948 QEHR1VM-108Z E CAPACITOR 1000uF 35V M
C1949 NDC21HJ-471X C CAPACITOR 470pF 50V J
C1950 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1971 QETN1HM-226Z E CAPACITOR 22uF 50V M
C1976 QETN1HM-105Z E CAPACITOR 1uF 50V M
C1977 QETN1CM-477Z E CAPACITOR 470uF 16V M
C1978 QETN1CM-227Z E CAPACITOR 220uF 16V M
C1979 QETN1CM-107Z E CAPACITOR 100uF 16V M



C1991 QCZ9079-471 C CAPACITOR 470pF AC250V K



C1992 QCZ9079-471 C CAPACITOR 470pF AC250V K



C1993 QCZ9079-102 C CAPACITOR 1000pF AC250V M

Ω

R1002 NRSA02J-221X MG RESISTOR 220
R1003 NRSA02J-221X MG RESISTOR 220Ω 1/10W J
R1004 NRSA02J-563X MG RESISTOR 56k
R1102 NRSA02J-750X MG RESISTOR 75Ω 1/10W J
R1103 NRSA02J-100X MG RESISTOR 10
R1109 NRSA02J-682X MG RESISTOR 6.8kΩ 1/10W J
R1110 NRSA02J-272X MG RESISTOR 2.7k
R1111 N RSA 02J-181X MG RESISTOR 180Ω 1/10W J
R1112 NRSA02J-100X MG RESISTOR 10
R1113 NRSA02J-101X MG RESISTOR 100
R1120 NRSA02J-391X MG RESISTOR 390Ω 1/10W J
R1121 NRSA02J-221X MG RESISTOR 220Ω 1/10W J

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

R1159 NRSA02J-184X MG RESISTOR 180kΩ 1/10W J
R1161 NRSA02J-102X MG RESISTOR 1kΩ 1/10W J
R1162 NRSA02J-122X MG RESISTOR 1.2kΩ 1/10W J
R1163 NRSA02J-222X MG RESISTOR 2.2kΩ 1/10W J
R1164 NRSA02J-221X MG RESISTOR 220Ω 1/10W J
R1165 NRSA02J-220X MG RESISTOR 22Ω 1/10W J
R1166 NRSA02J-821X MG RESISTOR 820Ω 1/10W J
R1301 NRSA02J-221X MG RESISTOR 220
R1302 NRSA02J-472X MG RESISTOR 4.7k
R1303 NRSA02J-101X MG RESISTOR 100Ω 1/10W J
R1304 NRSA02J-101X MG RESISTOR 100Ω 1/10W J
R1305 NRSA02J-101X MG RESISTOR 100Ω 1/10W J
R1306 NRSA02J-221X MG RESISTOR 220Ω 1/10W J
R1307 NRSA02J-122X MG RESISTOR 1.2kΩ 1/10W J
R1308 NRSA02J-182X MG RESISTOR 1.8k
R1312 NRSA02J-0R0X MG RESISTOR 0
R1313 NRSA02J-102X MG RESISTOR 1kΩ 1/10W J
R1314 NRSA02J-102X MG RESISTOR 1kΩ 1/10W J
R1321 NRSA02J-152X MG RESISTOR 1.5kΩ 1/10W J
R1322 NRSA02J-272X MG RESISTOR 2.7kΩ 1/10W J
R1323 NRSA02J-103X MG RESISTOR 10kΩ 1/10W J
R1324 NRSA02J-102X MG RESISTOR 1kΩ 1/10W J
R1326 NRSA02J-101X MG RESISTOR 100
R1327 NRSA02J-475X MG RESISTOR 4.7M
R1341 NRSA02J-332X MG RESISTOR 3.3kΩ 1/10W J
R1347 NRSA02J-392X MG RESISTOR 3.9kΩ 1/10W J
R1349 NRSA02J-472X MG RESISTOR 4.7kΩ 1/10W J
R1351 NRSA02J-151X MG RESISTOR 150Ω 1/10W J
R1352 NRSA02J-151X MG RESISTOR 150Ω 1/10W J
R1353 NRSA02J-151X MG RESISTOR 150Ω 1/10W J
R1354 NRSA02J-331X MG RESISTOR 330Ω 1/10W J
R1355 NRSA02J-331X MG RESISTOR 330Ω 1/10W J
R1356 NRSA02J-331X MG RESISTOR 330Ω 1/10W J
R1357 NRSA02J-101X MG RESISTOR 100Ω 1/10W J
R1358 NRSA02J-101X MG RESISTOR 100Ω 1/10W J
R1359 NRSA02J-101X MG RESISTOR 100Ω 1/10W J
R1360 QRZ0107-152Z C RESISTOR 1.5kΩ 1/2W K
R1361 QRZ0107-152Z C RESISTOR 1.5kΩ 1/2W K
R1362 QRZ0107-152Z C RESISTOR 1.5kΩ 1/2W K
R1363 QRL029J-123 OMF RESISTOR 12kΩ 2W J
R1364 QRL029J-123 OMF RESISTOR 12kΩ 2W J
R1365 QRL029J-123 OMF RESISTOR 12kΩ 2W J
R1366 NRSA02J-182X MG RESISTOR 1.8kΩ 1/10W J
R1367 NRSA02J-182X MG RESISTOR 1.8kΩ 1/10W J
R1368 NRSA02J-182X MG RESISTOR 1.8kΩ 1/10W J
R1372 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
R1374 NRSA02J-682X MG RESISTOR 6.8kΩ 1/10W J
R1401 NRSA02J-103X MG RESISTOR 10kΩ 1/10W J
R1421 NRSA02J-122X MG RESISTOR 1.2kΩ 1/10W J
R1422 NRSA02J-122X MG RESISTOR 1.2kΩ 1/10W J
R1423 NRSA02J-331X MG RESISTOR 330Ω 1/10W J
R1424 NRSA02J-101X MG RESISTOR 100Ω 1/10W J
R1425 NRSA02J-471X MG RESISTOR 470Ω 1/10W J
R1426 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
R1429 NRSA02J-103X MG RESISTOR 10kΩ 1/10W J
R1430 NRSA02J-823X MG RESISTOR 82k
R1431 NRSA02J-103X MG RESISTOR 10kΩ 1/10W J
R1432 QRE121J-2R7Y C RESISTOR 2.7
R1433 QRE121J-2R7Y C RESISTOR 2.7Ω 1/2W J
R1436 NRSA02J-823X MG RESISTOR 82k
R1440 QRE121J-471Y C RESISTOR 470Ω 1/2W J
R1441 NRSA02J-822X MG RESISTOR 8.2kΩ 1/10W J
R1442 NRSA02J-103X MG RESISTOR 10kΩ 1/10W J
R1443 QRE121J-1R0Y C RESISTOR 1Ω 1/2W J
R1453 NRSA02J-272X MG RESISTOR 2.7k
R1501 QRE121J-101Y C RESISTOR 100Ω 1/2W J
R1502 NRSA02J-0R0X MG RESISTOR 0
R1503 NRSA02J-682X MG RESISTOR 6.8k
R1521 NRSA02J-681X MG RESISTOR 680
R1522 NRSA02J-103X MG RESISTOR 10k
R1524 QRL02EJ-820X OMF RESISTOR 82
R1525 QRL02EJ-820X OMF RESISTOR 82
R1526 QRE121J-270Y C RESISTOR 27
R1530 QRE121J-223Y C RESISTOR 22k
R1531 NRSA02J-103X MG RESISTOR 10k
R1532 NCB21HK-103X C CAPACITOR 0.01uF 50V K
R1533 NRSA02J-332X MG RESISTOR 3.3k
R1534 NRSA02J-332X MG RESISTOR 3.3k



R1551 QRZ9011-1R0 FUSI RESISTOR 1Ω 1/2W J
R1552 QRJ146J-2R2X UNF C RESISTOR 2.2
R1554 QRE121J-821Y C RESISTOR 820Ω 1/2W J
R1571 QRE121J-222Y C RESISTOR 2.2k
R1573 QRT02EJ-1R5X MF RESISTOR 1.5Ω 2W J
R1574 QRT02EJ-1R5X MF RESISTOR 1.5
R1576 QRE121J-223Y C RESISTOR 22kΩ 1/2W J
R1577 NRSA02J-392X MG RESISTOR 3.9k
R1578 NRSA02J-103X MG RESISTOR 10k
R1581 QRE121J-182Y C RESISTOR 1.8kΩ 1/2W J
R1582 NRSA02J-223X MG RESISTOR 22kΩ 1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/2W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

2W J

Ω

2W J

Ω

1/2W J

Ω

1/2W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/4W J

Ω

1/2W J

Ω

2W J

Ω

1/10W J

Ω

1/10W J

1-4 (No.52036B)



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

R1583 NRSA02J-393X MG RESISTOR 39kΩ 1/10W J
R1651 NRSA02J-103X MG RESISTOR 10kΩ 1/10W J
R1652 NRSA02J-102X MG RESISTOR 1kΩ 1/10W J
R1653 QRE121J-1R0Y C RESISTOR 1Ω 1/2W J
R1654 QRX029J-4R7 MF RESISTOR 4.7Ω 2W J
R1656 NRSA02J-123X MG RESISTOR 12kΩ 1/10W J
R1657 NRSA02J-391X MG RESISTOR 390Ω 1/10W J
R1658 NRSA02J-102X MG RESISTOR 1k
R1659 NRSA02J-102X MG RESISTOR 1k
R1660 NRSA02J-103X MG RESISTOR 10kΩ 1/10W J
R1661 QRE121J-271Y C RESISTOR 270Ω 1/2W J
R1662 QRE121J-271Y C RESISTOR 270Ω 1/2W J
R1664 NRSA02J-221X MG RESISTOR 220Ω 1/10W J
R1665 NRSA02J-103X MG RESISTOR 10kΩ 1/10W J
R1701 NRSA02J-562X MG RESISTOR 5.6k
R1702 NRSA02J-682X MG RESISTOR 6.8k
R1703 NRSA02J-392X MG RESISTOR 3.9kΩ 1/10W J
R1704 NRSA02J-221X MG RESISTOR 220Ω 1/10W J
R1705 NRSA02J-221X MG RESISTOR 220Ω 1/10W J
R1706 NRSA02J-561X MG RESISTOR 560Ω 1/10W J
R1707 NRSA02J-561X MG RESISTOR 560Ω 1/10W J
R1708 NRSA02J-102X MG RESISTOR 1kΩ 1/10W J
R1709 NRSA02J-472X MG RESISTOR 4.7k
R1710 NRSA02J-472X MG RESISTOR 4.7k
R1711 NRSA02J-472X MG RESISTOR 4.7kΩ 1/10W J
R1712 NRSA02J-472X MG RESISTOR 4.7kΩ 1/10W J
R1713 NRSA02J-472X MG RESISTOR 4.7kΩ 1/10W J
R1714 NRSA02J-472X MG RESISTOR 4.7kΩ 1/10W J
R1715 NRSA02J-221X MG RESISTOR 220Ω 1/10W J
R1716 NRSA02J-221X MG RESISTOR 220Ω 1/10W J
R1718 NRSA02J-561X MG RESISTOR 560Ω 1/10W J
R1719 NRSA02J-102X MG RESISTOR 1kΩ 1/10W J
R1720 NRSA02J-472X MG RESISTOR 4.7kΩ 1/10W J
R1721 NRSA02J-103X MG RESISTOR 10kΩ 1/10W J



R1723 QRZ9023-270 FUSIBLE RESISTOR 27Ω 2W J
R1725 NRSA02J-102X MG RESISTOR 1kΩ 1/10W J
R1726 NRSA02J-472X MG RESISTOR 4.7kΩ 1/10W J
R1727 NRSA02J-153X MG RESISTOR 15kΩ 1/10W J
R1728 NRSA02J-102X MG RESISTOR 1kΩ 1/10W J
R1729 NRSA02J-102X MG RESISTOR 1kΩ 1/10W J
R1730 NRSA02J-103X MG RESISTOR 10kΩ 1/10W J
R1731 NRSA02J-472X MG RESISTOR 4.7kΩ 1/10W J
R1736 NRSA02J-823X MG RESISTOR 82kΩ 1/10W J
R1737 NRSA02J-104X MG RESISTOR 100kΩ 1/10W J
R1738 NRSA02J-103X MG RESISTOR 10kΩ 1/10W J
R1739 NRSA02J-103X MG RESISTOR 10kΩ 1/10W J
R1740 NRSA02J-392X MG RESISTOR 3.9kΩ 1/10W J
R1741 NRSA02J-561X MG RESISTOR 560Ω 1/10W J
R1742 NRSA02J-563X MG RESISTOR 56kΩ 1/10W J
R1746 NRSA02J-103X MG RESISTOR 10kΩ 1/10W J
R1747 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
R1748 NRSA02J-223X MG RESISTOR 22kΩ 1/10W J
R1749 NRSA02J-472X MG RESISTOR 4.7kΩ 1/10W J
R1771 NRSA02J-222X MG RESISTOR 2.2kΩ 1/10W J
R1772 NRSA02J-821X MG RESISTOR 820Ω 1/10W J
R1773 NRSA02J-122X MG RESISTOR 1.2k
R1791 NRSA02J-221X MG RESISTOR 220Ω 1/10W J
R1792 NRSA02J-221X MG RESISTOR 220
R1793 NRSA02J-221X MG RESISTOR 220Ω 1/10W J
R1794 NRSA02J-221X MG RESISTOR 220
R1795 NRSA02J-221X MG RESISTOR 220Ω 1/10W J
R1796 NRSA02J-103X MG RESISTOR 10kΩ 1/10W J
R1797 NRSA02J-153X MG RESISTOR 15kΩ 1/10W J
R1802 NRSA02J-750X MG RESISTOR 75Ω 1/10W J
R1806 QRE121J-271Y C RESISTOR 270
R1807 NRSA02J-680X MG RESISTOR 68Ω 1/10W J
R1810 QRG01GJ-560 OMF RESISTOR 56
R1811 NRSA02J-221X MG RESISTOR 220
R1815 QRE121J-181Y C RESISTOR 180
R1816 NRSA02J-681X MG RESISTOR 680
R1817 NRSA02J-472X MG RESISTOR 4.7k
R1901 QRF104K-3R9 UNF WW RESISTOR 3.9
R1903 QRL02EJ-683X OMF RESISTOR 68k
R1921 QRE121J-681Y C RESISTOR 680
R1922 QRT029J-1R2 MF RESISTOR 1.2
R1923 QRM059J-R22 MP RESISTOR 0.22
R1926 NRSA02J-222X MG RESISTOR 2.2kΩ 1/10W J
R1928 QRL03EJ-563X OMF RESISTOR 56k
R1929 QRE121J-822Y C RESISTOR 8.2kΩ 1/2W J
R1932 QRE121J-564Y C RESISTOR 560k
R1933 QRE121J-220Y C RESISTOR 22Ω 1/2W J
R1934 NRSA02J-333X MG RESISTOR 33k
R1936 QRG01GJ-561 OMF RESISTOR 560Ω 1W J
R1941 QRE121J-821Y C RESISTOR 820
R1942 NRSA02J-122X MG RESISTOR 1.2kΩ 1/10W J
R1943 NRSA02J-473X MG RESISTOR 47k
R1944 NRSA02J-103X MG RESISTOR 10k
R1974 NRSA02J-222X MG RESISTOR 2.2kΩ 1/10W J
R1976 NRSA02J-102X MG RESISTOR 1kΩ 1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/2W J

Ω

Ω

1/10W J

Ω

1/2W J

Ω

1/10W J

Ω

1/10W J

Ω

10W K

Ω

Ω

1/2W J

Ω
Ω

Ω

Ω

1/2W J

Ω

1/10W J

Ω

1/2W J

Ω

1/10W J

Ω

1/10W J

1W J

2W J

2W J
5W J

3W J

R1977 QRE121J-122Y C RESISTOR 1.2kΩ 1/2W J
R1978 NRSA02J-473X MG RESISTOR 47kΩ 1/10W J
R1979 QRT02EJ-1R2X MF RESISTOR 1.2Ω 2W J
R1980 QRL02EJ-103X OMF RESISTOR 10kΩ 2W J



R1991 QRZ0057-825 C RESISTOR 8.2MΩ 1W J

L1001 QQL244K-8R2Z PEAKING COIL 8.2uH K
L1101 QQLZ014-2R2 COIL 2.2uH 130mA K
L1103 QQL244K-8R2Z PEAKING COIL 8.2uH K
L1523 QQL342J-2R2Z COIL 2.2uH J
L1551 QQLZ034-430 HEATER CHOKE 43uH
L1701 QQL244J-5R6Z COIL 5.6uH J
L1941 QQL26AK-820Z CHOKE COIL 82uH K
L1942 QQL26AK-820Z CHOKE COIL 82uH K
L1943 QQL26AK-820Z CHOKE COIL 82uH K



T1921 QQS0239-001 SW TRANSF

CF1161 QAX0694-001Z C FILTER 5.742MHz
CF1162 QAX0694-001Z C FILTER 5.742MHz
CN100T QJL001-053820 SIN CL B-B WIRE
CN100U CHGC04-400 CONNECTOR ASSY
CN10E1 CHGT0015-0A CONNECTOR ASSY
CN10HV QGZ5004C1-04 CONNECTOR (1-4)
CN1DEG QGZ5004C1-02 CONNECTOR (1-2)



CP1981 ICP-N75-Y IC PROTECTOR 2.7A



CP1982 ICP-N75-Y IC PROTECTOR 2.7A



F1901 QMF51E2-3R15J4 FUSE 3.15A AC250V
J1002 QNN0384-001 PIN JACK
J1003 CEMN065-001 PIN JACK
J1004 CEMN065-002 PIN JACK
J1005 QNS0165-001 3.5 JACK
K1001 QQR0621-002Z FERRITE BEADS
K1351 QQR0621-002Z FERRITE BEADS
K1421 QQR0582-001Z FERRITE BEADS
K1921 QQR1113-001Z FERRITE BEADS
K1922 QQR1113-001Z FERRITE BEADS
K1923 QQR1114-001Z FERRITE BEADS
K1924 QQR1113-001Z FERRITE BEADS
K1941 QQR1113-001Z FERRITE BEADS
K1942 QQR1113-001Z FERRITE BEADS
K1943 QQR1113-001Z FERRITE BEADS



LF1901 QQR0527-002 LINE FILTER
PC1701 P1241-04 PHOTO CONDUCTOR



PC1921 PC123F2 PHOTO COUPLER
S1701 QSW0619-003Z TACT SWITCH VOL+
S1702 QSW0619-003Z TACT SWITCH VOL­S1703 QSW0619-003Z TACT SWITCH CH+
S1704 QSW0619-003Z TACT SWITCH CH­S1705 QSW0619-003Z TACT SWITCH MENU



S1901 QSW0750-001 PUSH SWITCH POWER SW
SF1102 QAX0666-002 SAW FILTER
SF1122 QAX0325-001 SAW FILTER



SK1351 CE42446-001 CRT SOCKET
TH1901 QAD0119-9R0 P THERMISTOR 9
TU1001 QAU0186-002 TUNER



VA1901 QAF0052-621 VARISTOR 620V
X1301 QAX0705-001Z CRYSTAL 4.433619MHz
X1302 CE41651-001Z CRYSTAL
X1701 QAX0685-001 C RESONATOR 12.0MHz

Ω

(No.52036B)1-5

SECTION 1

PRECAUTION

Please refer to "AV-21D43/BK (No.52036)" about this section.

SECTION 2

SPECIFIC SERVICE INSTRUCTIONS

Please refer to "AV-21D43/BK (No.52036)" about this section.

SECTION 3

DISASSEMBLY

Please refer to "AV-21D43/BK (No.52036)" about this section.

SECTION 4

ADJUSTMENT

Please refer to "AV-21D43/BK (No.52036)" about this section.

SECTION 5

TROUBLESHOOTING

Please refer to "AV-21D43/BK (No.52036)" about this section.

Victor Company of Japan, Limited
AV & MULTIMEDIA COMPANY VIDEO DISPLAY CATEGORY 12, 3-chome, Moriya-cho, kanagawa-ku, Yokohama, kanagawa-prefecture, 221-8528, Japan

(No.52036B)

Printed in Japan

VPT
