JVC AV-14F43/BK, AV-20N43/BK, AV-21D43/BK Parts List

A

V-21D43

A

A

V-20N43

V-14F43

PARTS LIST

CAUTION

! The parts identified by the ! symbol are important for the safety. W henever replacing these parts, be sure to use specified ones to secure

the safety .

! The parts not indicated in this Parts List and those which are filled with lines 　　
! P. W. Board Ass'y will not be supplied, but those which are filled with the Parts No. in the Parts No. columns will be supplied.

ABBREVIATIONS OF RESISTORS, CAPACITORS AND TOLERANCES

RESISTORS CAPACITORS

C R Carbon Resistor C CAP. Ceramic Capacitor

F R Fusible Resistor E CAP. Electrolytic Capacitor

P R Plate Resistor M CAP. Mylar Capacitor

in the Parts No. columns will not be supplied.

V R

HV R High Voltage Resistor MF CAP. Metalized Film Capacitor

MF R Metal Film Resistor MM CAP. Metalized Mylar Capacitor

MG R Metal Glazed Resistor MP CAP. Metalized Polystyrol C apacitor

MP R Metal Plate R esistor PP CAP. Polypropylene Capacitor

OM R Metal Oxide Film Resistor

CMF R Coating Metal Film Resistor TF CAP. Thin Film Capacitor

UNF R Non-Flammable R esistor MPP CAP. Metalized Polypropylene Capacitor

CH V R Chip Variable Resistor TAN. CAP. Tantalum Capacitor

CH MG R Chip Metal Glazed Resistor CH C CAP. Chip Ceramic Capacitor

COMP. R Composition Resistor BP E CAP. Bi-Polar Electr olytic C apacitor

LPTC R

Variable Resisto

Linear Positive Temperature Coefficient
Resistor

r

HV CAP. High Voltage Capacitor

PS CAP

.

CH AL E CAP. Chip Aluminum Electrolytic Capacitor

CH AL BP CAP.

CH TAN. E CAP.

Polystyrol Capacitor

Chip Aluminum Bi-Polar Capacitor

Chip Tantalum Electrolytic Capacitor

CH AL BP E CAP.

Chip Tantalum Bi-Polar Electrolytic Capacitor

TOLERANCES

FGJ KMNRHZP

±1% ±2% ±5% ±10% ±20% ±30%

+30%

-10%

No.52036

+50%

-10%

+80%

-20%

+100%

-0%

37

A

V-21D43

A

A

V-20N43
V-14F43

CONTENTS

! USING PW BOARD & REMOTE CONTROL UNIT････････････････････････････････････････････････ 39

! REMOTE CONTROL UNIT PARTS LIST ････････････････････････････････････････････････････････ 39

[ AV-21D43

/BK

]

! EXPLODED VIEW PARTS LIST････････････････････････････････････････････････････････････････ 40

!!!! EXPLODED VIEW･････････････････････････････････････････････････････････････････････････ 40,41

! PRINTED WIRING BOARD PARTS LIST

MAIN PW BOARD ASS’Y (With CRT SOCKET PW BOARD)

"

･･････････････････････････････････････････ 42

! PACKING ･･･････････････････････････････････････････････････････････････････････････････････ 45

! PACKING PARTS LIST ･･･････････････････････････････････････････････････････････････････････ 45

[ AV-20N43

/BK

]

! EXPLODED VIEW PARTS LIST ･･･････････････････････････････････････････････････････････････ 46

!!!! EXPLODED VIEW･････････････････････････････････････････････････････････････････････････ 46,47

! PRINTED WIRING BOARD PARTS LIST

MAIN PW BOARD ASS’Y (With CRT SOCKET PW BOARD)

"

･･････････････････････････････････････････ 48

! PACKING ･･･････････････････････････････････････････････････････････････････････････････････ 51

! PACKING PARTS LIST ･･･････････････････････････････････････････････････････････････････････ 51

[ AV-14F43

/BK

]

! EXPLODED VIEW PARTS LIST････････････････････････････････････････････････････････････････ 52

!!!! EXPLODED VIEW･････････････････････････････････････････････････････････････････････････ 52,53

! PRINTED WIRING BOARD PARTS LIST

MAIN PW BOARD ASS’Y (With CRT SOCKET PW BOARD)

"

･･････････････････････････････････････････ 54

! PACKING ･･･････････････････････････････････････････････････････････････････････････････････ 57

! PACKING PARTS LIST ･･･････････････････････････････････････････････････････････････････････ 57

38

No.52036

A

A

A

USING P.W. BOARD & REMOTE CONTROL UNIT

V-21D43
V-20N43

V-14F43

P.W.B ASS’Y

MAIN PWB

(With CRT SOCKET PWB)

REMOTE CONTROL UNIT

Model

AV-21D43

SCG-1435A SCG-1434A SCG-1433A

RM-C368GY-1H

/BK

AV-20N43

/BK

AV-14F43

REMOTE CONTROL UNIT PARTS LIST

[ AV-21D43/BK ] [ AV-20N43/BK ] [ AV-14F43/BK ]

! Ref.No. Part No. Part Name Description

1 25-1168F BATTERY COVER

(RM-C368GY-1H)

/BK

1

No.52036

39

A

V-21D43

EXPLODED VIEW PARTS LIST

[ AV-21D43/BK ]

! Ref.No. Part No. Part Name Description

! 1 LC11129-021A-H FRONT CABINET

2 CM48125-009 JVC MARK

! 3 GG30020-001A-H REMOCON WINDOW
! 4 GG30019-001B-H POWER KNOB

5 CM30861-069 SPRING

! 6 GG20006-001A-H CONTROL KNOB

7 GG30021-002A-H LED LENS

! V01 A51LMV10X PICTURE TUBE
! DY01 CE20336-00A DEF YOKE
! L01 QQW0006-001 DEG COIL
! T1522 QQH0069-001 F.B.TRANSF.

8 A48457-1 SPRING
9 CHGB0016-0B-N BRAIDED ASSY
10 A75034-B PC MAGNET or CE42378-00B
11 CE40764-00A WEDGE ASSY (x4)

12 CM36623-B01-H CHASSIS RAIL (x2)
13 QAS0086-001 SPEAKER (x2)SP01

! 14 QMPR010-200-E2 POWER CORD or QMPR010-200-K2
! 15 CM47005-A01-H POWER CORD CLAMP
! 16 GG10130-005A-H REAR COVER

17 QYSBSFG4016Z TAP SCREW (x7)
18 QYSBSF3010Z TAP SCREW

! 19 GG20024-001B-H RATING LABEL

EXPLODED VIEW

FRONT VIEW

!

1

!

6

2

!

3

!

4

5

7

40

No. 52036

A

EXPLODED VIEW

!

V01

L01

!

!

DY01

11

8

9

CRT SOCKET PWB

(Within MAIN PWB)

V-21D43

13

!

T1522

13

14

!

16

!

15

!

12

10

12

MAIN PWB

!

19

18

17

(×7)

No. 52036

41

A

V-21D43

[ AV-21D43/BK ]

PRINTED WIRING BOARD PARTS LIST

MAIN P.W. BOARD ASS’Y (SCG-1435A)

! Symbol No. Part No. Part Name Description

RESISTOR

R1002 NRSA02J-221X MG R 220Ω 1/10W J
R1003 NRSA02J-221X MG R 220
R1004 NRSA02J-563X MG R 56k
R1102 NRSA02J-750X MG R 75Ω 1/10W J
R1103 NRSA02J-100X MG R 10
R1109 NRSA02J-682X MG R 6.8kΩ 1/10W J
R1110 NRSA02J-272X MG R 2.7kΩ 1/10W J
R1111 NRSA02J-181X MG R 180
R1112 NRSA02J-100X MG R 10Ω 1/10W J
R1113 NRSA02J-101X MG R 100
R1114 NRSA02J-472X MG R 4.7k
R1115 NRSA02J-222X MG R 2.2kΩ 1/10W J
R1117 NRSA02J-0R0X MG R 0.0Ω 1/10W J
R1118 NRSA02J-222X MG R 2.2k
R1120 NRSA02J-391X MG R 390Ω 1/10W J
R1121 NRSA02J-221X MG R 220Ω 1/10W J
R1159 NRSA02J-184X MG R 180k
R1161 NRSA02J-102X MG R 1kΩ 1/10W J
R1162 NRSA02J-122X MG R 1.2kΩ 1/10W J
R1163 NRSA02J-222X MG R 2.2k
R1164 NRSA02J-221X MG R 220Ω 1/10W J
R1165 NRSA02J-220X MG R 22Ω 1/10W J
R1166 NRSA02J-821X MG R 820
R1301 NRSA02J-221X MG R 220Ω 1/10W J
R1302 NRSA02J-472X MG R 4.7kΩ 1/10W J
R1303 NRSA02J-101X MG R 100
R1304 NRSA02J-101X MG R 100Ω 1/10W J
R1305 NRSA02J-101X MG R 100Ω 1/10W J
R1306 NRSA02J-221X MG R 220
R1307 NRSA02J-122X MG R 1.2kΩ 1/10W J
R1308 NRSA02J-182X MG R 1.8kΩ 1/10W J
R1312 NRSA02J-0R0X MG R 0.0
R1313 NRSA02J-102X MG R 1kΩ 1/10W J
R1314 NRSA02J-102X MG R 1kΩ 1/10W J
R1321 NRSA02J-152X MG R 1.5k
R1322 NRSA02J-272X MG R 2.7kΩ 1/10W J
R1323 NRSA02J-103X MG R 10kΩ 1/10W J
R1324 NRSA02J-102X MG R 1k
R1326 NRSA02J-101X MG R 100Ω 1/10W J
R1327 NRSA02J-475X MG R 4.7MΩ 1/10W J
R1341 NRSA02J-332X MG R 3.3k
R1347 NRSA02J-392X MG R 3.9kΩ 1/10W J
R1349 NRSA02J-472X MG R 4.7kΩ 1/10W J
R1351 NRSA02J-151X MG R 150
R1352 NRSA02J-151X MG R 150Ω 1/10W J
R1353 NRSA02J-151X MG R 150Ω 1/10W J
R1354 NRSA02J-331X MG R 330
R1355 NRSA02J-331X MG R 330Ω 1/10W J
R1356 NRSA02J-331X MG R 330Ω 1/10W J
R1357 NRSA02J-101X MG R 100
R1358 NRSA02J-101X MG R 100Ω 1/10W J
R1359 NRSA02J-101X MG R 100Ω 1/10W J
R1360 QRZ0107-152Z C R 1.5k
R1361 QRZ0107-152Z C R 1.5kΩ 1/2W K
R1362 QRZ0107-152Z C R 1.5kΩ 1/2W K
R1363 QRL029J-123 OM R 12k
R1364 QRL029J-123 OM R 12kΩ 2W J
R1365 QRL029J-123 OM R 12kΩ 2W J
R1366 NRSA02J-182X MG R 1.8k
R1367 NRSA02J-182X MG R 1.8kΩ 1/10W J
R1368 NRSA02J-182X MG R 1.8kΩ 1/10W J
R1372 NRSA02J-0R0X MG R 0.0
R1374 NRSA02J-682X MG R 6.8kΩ 1/10W J
R1401 NRSA02J-103X MG R 10kΩ 1/10W J
R1421 NRSA02J-122X MG R 1.2k
R1422 NRSA02J-122X MG R 1.2kΩ 1/10W J
R1423 NRSA02J-331X MG R 330Ω 1/10W J
R1424 NRSA02J-101X MG R 100
R1425 NRSA02J-471X MG R 470Ω 1/10W J
R1426 NRSA02J-0R0X MG R 0.0Ω 1/10W J
R1429 NRSA02J-103X MG R 10k
R1430 NRSA02J-823X MG R 82kΩ 1/10W J
R1431 NRSA02J-103X MG R 10kΩ 1/10W J
R1432 QRE121J-2R7Y C R 2.7
R1433 QRE121J-2R7Y C R 2.7Ω 1/2W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/2W K

Ω

2W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/2W J

! Symbol No. Part No. Part Name Description

RESISTOR

R1436 NRSA02J-823X MG R 82kΩ 1/10W J
R1440 QRE121J-471Y C R 470
R1441 NRSA02J-822X MG R 8.2k
R1442 NRSA02J-103X MG R 10kΩ 1/10W J
R1443 QRE121J-1R0Y C R 1.0
R1453 NRSA02J-272X MG R 2.7kΩ 1/10W J
R1501 QRE121J-101Y C R 100
R1502 NRSA02J-0R0X MG R 0.0
R1503 NRSA02J-682X MG R 6.8kΩ 1/10W J
R1521 NRSA02J-681X MG R 680Ω 1/10W J
R1522 NRSA02J-103X MG R 10k
R1524 QRL02EJ-820X OM R 82
R1525 QRL02EJ-820X OM R 82
R1526 QRE121J-270Y C R 27
R1530 QRE121J-223Y C R 22kΩ 1/2W J
R1531 NRSA02J-103X MG R 10k
R1532 NCB31HK-103X C CAP. 0.01
R1533 NRSA02J-332X MG R 3.3k
R1534 NRSA02J-332X MG R 3.3kΩ 1/10W J

! R1551 QRZ9011-1R0 F R 1.0

R1552 QRJ146J-2R2X C R 2.2Ω 1/4W J
R1554 QRE121J-821Y C R 820Ω 1/2W J
R1571 QRE121J-222Y C R 2.2k
R1573 QRT02EJ-1R5X MF R 1.5Ω 2W J
R1574 QRT02EJ-1R5X MF R 1.5Ω 2W J
R1576 QRE121J-223Y C R 22k
R1577 NRSA02J-392X MG R 3.9kΩ 1/10W J
R1578 NRSA02J-103X MG R 10kΩ 1/10W J
R1581 QRE121J-182Y C R 1.8k
R1582 NRSA02J-223X MG R 22kΩ 1/10W J
R1583 NRSA02J-393X MG R 39kΩ 1/10W J
R1651 NRSA02J-103X MG R 10k
R1652 NRSA02J-102X MG R 1kΩ 1/10W J
R1653 QRE121J-1R0Y C R 1.0Ω 1/2W J
R1654 QRX029J-4R7 MF R 4.7
R1656 NRSA02J-123X MG R 12kΩ 1/10W J
R1657 NRSA02J-391X MG R 390Ω 1/10W J
R1658 NRSA02J-102X MG R 1k
R1659 NRSA02J-102X MG R 1kΩ 1/10W J
R1660 NRSA02J-103X MG R 10kΩ 1/10W J
R1661 QRE121J-271Y C R 270
R1662 QRE121J-271Y C R 270Ω 1/2W J
R1664 NRSA02J-221X MG R 220Ω 1/10W J
R1665 NRSA02J-103X MG R 10k
R1701 NRSA02J-562X MG R 5.6kΩ 1/10W J
R1702 NRSA02J-682X MG R 6.8kΩ 1/10W J
R1703 NRSA02J-392X MG R 3.9k
R1704 NRSA02J-221X MG R 220Ω 1/10W J
R1705 NRSA02J-221X MG R 220Ω 1/10W J
R1706 NRSA02J-561X MG R 560
R1707 NRSA02J-561X MG R 560Ω 1/10W J
R1708 NRSA02J-102X MG R 1kΩ 1/10W J
R1709 NRSA02J-472X MG R 4.7k
R1710 NRSA02J-472X MG R 4.7kΩ 1/10W J
R1711 NRSA02J-472X MG R 4.7kΩ 1/10W J
R1712 NRSA02J-472X MG R 4.7k
R1713 NRSA02J-472X MG R 4.7kΩ 1/10W J
R1714 NRSA02J-472X MG R 4.7kΩ 1/10W J
R1715 NRSA02J-221X MG R 220
R1716 NRSA02J-221X MG R 220Ω 1/10W J
R1718 NRSA02J-561X MG R 560Ω 1/10W J
R1719 NRSA02J-102X MG R 1k
R1720 NRSA02J-472X MG R 4.7kΩ 1/10W J
R1721 NRSA02J-103X MG R 10kΩ 1/10W J

! R1723 QRZ9023-270 F R 27

R1725 NRSA02J-102X MG R 1kΩ 1/10W J
R1726 NRSA02J-472X MG R 4.7kΩ 1/10W J
R1727 NRSA02J-153X MG R 15k
R1728 NRSA02J-102X MG R 1kΩ 1/10W J
R1729 NRSA02J-102X MG R 1kΩ 1/10W J
R1730 NRSA02J-103X MG R 10k
R1731 NRSA02J-472X MG R 4.7kΩ 1/10W J
R1736 NRSA02J-823X MG R 82kΩ 1/10W J
R1737 NRSA02J-104X MG R 100k
R1738 NRSA02J-103X MG R 10kΩ 1/10W J

Ω

1/2W J

Ω

1/10W J

Ω

1/2W J

Ω

1/2W J

Ω

1/10W J

Ω

1/10W J

Ω

2W J

Ω

2W J

Ω

1/2W J

Ω

1/10W J

µ

F 50V K

Ω

1/10W J

Ω

1/2W J

Ω

1/2W J

Ω

1/2W J

Ω

1/2W J

1/10W J

Ω

Ω

2W J

Ω

1/10W J

Ω

1/2W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

2W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

42

No. 52036

A

V-21D43

! Symbol No. Part No. Part Name Description

RESISTOR

R1739 NRSA02J-103X MG R 10kΩ 1/10W J
R1740 NRSA02J-392X MG R 3.9k
R1741 NRSA02J-561X MG R 560
R1742 NRSA02J-563X MG R 56k
R1746 NRSA02J-103X MG R 10k
R1747 NRSA02J-0R0X MG R 0.0Ω 1/10W J
R1748 NRSA02J-223X MG R 22k
R1749 NRSA02J-472X MG R 4.7k
R1771 NRSA02J-222X MG R 2.2kΩ 1/10W J
R1772 NRSA02J-821X MG R 820Ω 1/10W J
R1773 NRSA02J-122X MG R 1.2k
R1797 NRSA02J-153X MG R 15k
R1796 NRSA02J-103X MG R 10k
R1791 NRSA02J-221X MG R 220
R1792 NRSA02J-221X MG R 220Ω 1/10W J
R1793 NRSA02J-221X MG R 220Ω 1/10W J
R1794 NRSA02J-221X MG R 220
R1795 NRSA02J-221X MG R 220
R1802 NRSA02J-750X MG R 75Ω 1/10W J
R1806 QRE121J-271Y C R 270
R1807 NRSA02J-680X MG R 68Ω 1/10W J
R1810 QRG01GJ-560 OM R 56Ω 1W J
R1811 NRSA02J-221X MG R 220
R1815 QRE121J-181Y C R 180Ω 1/2W J
R1816 NRSA02J-681X MG R 680Ω 1/10W J
R1817 NRSA02J-472X MG R 4.7k

! R1901 QRF104K-3R9 UNF R 3.9Ω 10W K

R1903 QRL02EJ-683X OM R 68kΩ 2W J
R1921 QRE121J-681Y C R 680
R1922 QRT029J-1R2 MF R 1.2Ω 2W J
R1923 QRM059J-R22 MP R 0.22Ω 5W J
R1926 NRSA02J-222X MG R 2.2k
R1928 QRL03EJ-563X OM R 56kΩ 3W J
R1929 QRE121J-822Y C R 8.2kΩ 1/2W J
R1932 QRE121J-564Y C R 560k
R1933 QRE121J-220Y C R 22
R1934 NRSA02J-333X MG R 33kΩ 1/10W J
R1936 QRG01GJ-561 OM R 560
R1941 QRE121J-821Y C R 820Ω 1/2W J
R1942 NRSA02J-122X MG R 1.2kΩ 1/10W J
R1943 NRSA02J-473X MG R 47k
R1944 NRSA02J-103X MG R 10kΩ 1/10W J
R1974 NRSA02J-222X MG R 2.2kΩ 1/10W J
R1976 NRSA02J-102X MG R 1k
R1977 QRE121J-122Y C R 1.2kΩ 1/2W J
R1978 NRSA02J-473X MG R 47kΩ 1/10W J
R1979 QRT02EJ-1R2X MF R 1.2
R1980 QRL02EJ-103X OM R 10kΩ 2W J

! R1991 QRZ0057-825 C R 8.2MΩ 1W J

CAPACITOR

C1001 QETN1HM-106Z E CAP. 10µF 50V M
C1002 NCB31HK-103X C CAP. 0.01µF 50V K
C1004 QETN1CM-477Z E CAP. 470µF 16V M
C1005 QFV71HJ-104Z MF CAP. 0.1
C1008 QETN1HM-475Z E CAP. 4.7µF 50V M
C1103 QETN1EM-476Z E CAP. 47µF 25V M
C1104 NCB31HK-472X C CAP. 4700pF 50V K
C1105 NCB31HK-472X C CAP. 4700pF 50V K
C1106 NCB31HK-472X C CAP. 4700pF 50V K
C1107 NCB31HK-472X C CAP. 4700pF 50V K
C1109 NCB31HK-472X C CAP. 4700pF 50V K
C1110 NRSA02J-0R0X MG R 0.0
C1112 QETN1EM-476Z E CAP. 47µF 25V M
C1113 NCB31HK-472X C CAP. 4700pF 50V K
C1115 NCB31HK-103X C CAP. 0.01
C1116 NCB31HK-103X C CAP. 0.01
C1117 QFV71HJ-224Z MF CAP. 0.22µF 50V J
C1119 QETN1HM-474Z E CAP. 0.47µF 50V M
C1120 NDC31HJ-121X C CAP. 120pF 50V J
C1121 NCB31HK-103X C CAP. 0.01
C1122 NCB31HK-103X C CAP. 0.01µF 50V K
C1161 NCB31HK-103X C CAP. 0.01µF 50V K
C1162 NCB31HK-152X C CAP. 1500pF 50V K
C1164 NCB31HK-103X C CAP. 0.01
C1165 NCB31HK-103X C CAP. 0.01µF 50V K
C1166 NCB21HK-104X C CAP. 0.1µF 50V K
C1301 NCB21HK-123X C CAP. 0.012

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/2W J

Ω

1/10W J

Ω

1/10W J

Ω

1/2W J

Ω

1/10W J

Ω

1/2W J

Ω

1/2W J

Ω

1W J

Ω

1/10W J

Ω

1/10W J

Ω

2W J

µ

F 50V J

Ω

1/10W J

µ

F 50V K

µ

F 50V K

µ

F 50V K

µ

F 50V K

µ

F 50V K

! Symbol No. Part No. Part Name Description

CAPACITOR

C1302 QETN1HM-475Z E CAP. 4.7µF 50V M
C1303 NDC31HJ-100X C CAP. 10pF 50V J
C1304 QFV71HJ-474Z MF CAP. 0.47
C1305 QETN1HM-474Z E CAP. 0.47µF 50V M
C1306 NCB31HK-103X C CAP. 0.01
C1307 QETN1CM-477Z E CAP. 470µF 16V M
C1308 QETN1CM-107Z E CAP. 100
C1309 NCB31HK-103X C CAP. 0.01µF 50V K
C1310 NDC31HJ-221X C CAP. 220pF 50V J
C1311 NCB31HK-103X C CAP. 0.01
C1312 QENC1HM-474Z E CAP. 0.47
C1313 QETN1HM-335Z E CAP. 3.3
C1314 NCB31HK-103X C CAP. 0.01
C1315 QETN1CM-107Z E CAP. 100µF 16V M
C1316 QETN1HM-106Z E CAP. 10µF 50V M
C1317 NCB31EK-473X C CAP. 0.047
C1321 NDC31HJ-120X C CAP. 12pF 50V J
C1322 NCB21HK-273X C CAP. 0.027
C1323 QETN1HM-474Z E CAP. 0.47
C1324 QETN1HM-106Z E CAP. 10
C1325 QENC1HM-106Z BP E CAP. 10µF 50V M
C1326 NCS21HJ-221X C CAP. 220pF 50V J
C1341 QETN1HM-106Z E CAP. 10
C1351 QCZ0121-102 C CAP. 1000pF 3kV Z
C1354 NDC31HJ-271X C CAP. 270pF 50V J
C1355 NDC31HJ-221X C CAP. 220pF 50V J
C1356 NDC31HJ-331X C CAP. 330pF 50V J
C1357 QETN1AM-477Z E CAP. 470
C1365 QENC1HM-105Z E CAP. 1µF 50V M
C1366 QENC1HM-105Z E CAP. 1µF 50V M
C1367 QENC1HM-105Z E CAP. 1
C1401 QFV71HJ-474Z MF CAP. 0.47µF 50V J
C1402 QFV71HJ-104Z MF CAP. 0.1µF 50V J
C1422 QETN1HM-105Z E CAP. 1
C1423 QCS32HJ-180Z C CAP. 18pF 500V J
C1424 QFLC2AJ-103Z M CAP. 0.01
C1426 QFLC1HJ-102Z M CAP. 1000pF 50V J
C1427 QETN1VM-107Z E CAP. 100
C1428 QEHR1VM-107Z E CAP. 100
C1429 QETN1HM-106Z E CAP. 10µF 50V M
C1430 QFLC2AJ-472Z M CAP. 4700pF 100V J
C1433 QEHR1HM-475Z E CAP. 4.7
C1435 QETM1EM-228 E CAP. 2200
C1436 QFV71HJ-334Z MF CAP. 0.33µF 50V J
C1501 QETN1HM-476Z E CAP. 47µF 50V M
C1502 NCB31HK-103X C CAP. 0.01
C1503 QETN1HM-106Z E CAP. 10µF 50V M
C1504 QETN1CM-227Z E CAP. 220µF 16V M
C1523 QTMN1VM-476Z E CAP. 47

! C1525 QFZ0200-103 MPP CAP. 0.01µF1.5kVH±3%

C1526 QTMN1EM-337Z E CAP. 330

! C1527 QFZ0199-224 MPP CAP. 0.22

C1528 QETN2EM-475Z E CAP. 4.7µF 250V M
C1531 QEZ0203-107 E CAP. 100µF 160V M
C1552 QETM1VM-108 E CAP. 1000
C1554 QETN2EM-475Z E CAP. 4.7µF 250V M
C1555 QFLC2AJ-104Z M CAP. 0.1µF 100V J
C1571 QETN1AM-107Z E CAP. 100
C1572 QETN1EM-476Z E CAP. 47µF 25V M
C1581 QFV71HJ-104Z MF CAP. 0.1µF 50V J
C1582 QFZ0199-224 MPP CAP. 0.22
C1651 QTNC1HM-105Z E CAP. 1µF 50V M
C1652 QEHR1HM-106Z E CAP. 10µF 50V M
C1653 QEHR1HM-106Z E CAP. 10
C1654 NCB21HK-104X C CAP. 0.1µF 50V K
C1655 QEHQ1VM-228 E CAP. 2200µF 35V M
C1656 QEHR1EM-477Z E CAP. 470
C1658 QETN1HM-226Z E CAP. 22µF 50V M
C1659 QETN1CM-107Z E CAP. 100µF 16V M
C1663 QEHR1HM-106Z E CAP. 10
C1664 NCB21HK-104X C CAP. 0.1µF 50V K
C1665 QEHR1HM-105Z E CAP. 1µF 50V M
C1701 QETN1HM-106Z E CAP. 10
C1705 QETN1CM-477Z E CAP. 470µF 16V M
C1706 NCB21EK-104X C CAP. 0.1µF 25V K
C1707 NCB31HK-103X C CAP. 0.01
C1708 QETN1EM-476Z E CAP. 47µF 25V M
C1709 NCB31HK-103X C CAP. 0.01µF 50V K
C1710 QETN1CM-107Z E CAP. 100

µ

F 50V J

µ

F 50V K

µ

F 16V M

µ

F 50V K

µ

F 50V M

µ

F 50V M

µ

F 50V K

µ

F 25V K

µ

F 50V K

µ

F 50V M

µ

F 50V M

µ

F 50V M

µ

F 10V M

µ

F 50V M

µ

F 50V M

µ

F 100V J

µ

F 35V M

µ

F 35V M

µ

F 50V M

µ

F 25V M

µ

F 50V K

µ

F 35V M

µ

F 25V M

µ

F 250V J

µ

F 35V M

µ

F 10V M

µ

F 250V J

µ

F 50V M

µ

F 25V M

µ

F 50V M

µ

F 50V M

µ

F 50V K

µ

F 16V M

No. 52036

43

A

V-21D43

! Symbol No. Part No. Part Name Description

CAPACITOR

C1711 NCB31HK-103X C CAP. 0.01µF 50V K
C1712 NCB31HK-103X C CAP. 0.01
C1713 NCB31HK-103X C CAP. 0.01
C1714 NDC31HJ-330X C CAP. 33pF 50V J
C1715 NDC31HJ-330X C CAP. 33pF 50V J
C1716 NDC31HJ-181X C CAP. 180pF 50V J
C1717 NDC31HJ-181X C CAP. 180pF 50V J
C1718 NCB31HK-103X C CAP. 0.01
C1719 QETN1HM-105Z E CAP. 1µF 50V M
C1720 NCB31HK-103X C CAP. 0.01
C1721 NCB21HK-333X C CAP. 0.033
C1722 NDC31HJ-101X C CAP. 100pF 50V J
C1724 NDC31HJ-560X C CAP. 56pF 50V J
C1728 NDC31HJ-181X C CAP. 180pF 50V J
C1729 NDC31HJ-181X C CAP. 180pF 50V J
C1730 NCB31HK-103X C CAP. 0.01
C1738 QETN1HM-226Z E CAP. 22µF 50V M
C1744 NCB31HK-103X C CAP. 0.01
C1805 QETN1CM-227Z E CAP. 220
C1806 QETN1CM-477Z E CAP. 470µF 16V M
C1811 QETN1HM-106Z E CAP. 10µF 50V M
C1841 NCB31HK-152X C CAP. 1500pF 50V K

! C1901 QFZ9075-104 MPP CAP. 0.1
! OR QFZ9040-104 MF CAP. 0.1µFAC275V M
! C1904 QCZ9078-222 C CAP. 2200pFAC250V M
! C1905 QCZ9078-222 C CAP. 2200pFAC250V M
! C1907 QCZ9078-222 C CAP. 2200pFAC250V M
! C1909 QEZ0476-127 E CAP. 120
! OR QEZ0199-127 E CAP. 120
! C1910 QFZ9075-473 MPP CAP. 0.047µFAC275V M
! OR QFZ9040-473 MF CAP. 0.047µFAC275V M

C1922 QFLC1HJ-471Z M CAP. 470pF 50V J
C1924 QETN1VM-107Z E CAP. 100
C1926 QFLC1HJ-332Z M CAP. 3300pF 50V J
C1928 NCB21HK-473X C CAP. 0.047

! C1929 QFP32GJ-223Z PP CAP. 0.022µF 400V J

C1930 QCZ0325-561 C CAP. 560pF 2kV K
C1931 QCZ0325-151 C CAP. 150pF 2kV K
C1932 QCZ0325-151 C CAP. 150pF 2kV K
C1941 QCZ0122-561 C CAP. 560pF 2kV K
C1942 QEZ0420-107 E CAP. 100
C1945 QEHR1CM-108Z E CAP. 1000µF 16V M
C1946 QEHR1CM-477Z E CAP. 470µF 16V M
C1948 QEHR1VM-108Z E CAP. 1000
C1949 NDC31HJ-471X C CAP. 470pF 50V J
C1950 NCB21HK-104X C CAP. 0.1
C1971 QETN1HM-226Z E CAP. 22µF 50V M
C1976 QETN1HM-105Z E CAP. 1
C1977 QETN1CM-477Z E CAP. 470µF 16V M
C1978 QETN1CM-227Z E CAP. 220µF 16V M
C1979 QETN1CM-107Z E CAP. 100

! C1991 QCZ9079-471 C CAP. 470pFAC250V K
! C1992 QCZ9079-471 C CAP. 470pFAC250V K
! C1993 QCZ9079-102 C CAP. 1000pFAC250V M

TRANSFORMER

! T1522 QQH0069-001 F.B.TRANSF.
! T1921 QQS0050-001 SW TRANSF. or QQS0056-001

COIL

L1001 QQL244K-8R2Z COIL 8.2µH K
L1101 QQLZ014-2R2 INDUCTOR
L1103 QQL244K-8R2Z COIL 8.2
L1351 IM-BW BUS WIRE
L1352 IM-BW BUS WIRE
L1353 IM-BW BUS WIRE
L1354 IM-BW BUS WIRE
L1523 QQL342J-2R2Z INDUCTOR
L1551 QQLZ034-430 INDUCTOR
L1701 QQL244J-5R6Z COIL 5.6
L1941 QQL26AK-820Z COIL 82µH K
L1942 QQL26AK-820Z COIL 82µH K
L1943 QQL26AK-820Z COIL 82

DIODE

D1001 MA3330/L/-X ZENER DIODE
D1102 MA859-T2 SI.DIODE
D1301 MA3091/M/-X ZENER DIODE

µ

F 50V K

µ

F 50V K

µ

F 50V K

µ

F 50V K

µ

F 50V K

µ

F 50V K

µ

F 50V K

µ

F 16V M

µ

FAC275V M

µ

F 400V M

µ

F 400V M

µ

F 35V M

µ

F 50V K

µ

F 160V M

µ

F 35V M

µ

F 50V K

µ

F 50V M

µ

F 16V M

µ

H K

µ

H J

µ

H K

! Symbol No. Part No. Part Name Description

DIODE

D1302 MA3091/M/-X ZENER DIODE
D1305 RB100A-T2 SB DIODE
D1306 1SR124-400A-T2 SI.DIODE
D1341 MA111-X SI.DIODE
D1342 MA111-X SI.DIODE
D1421 MA3360/M/-X ZENER DIODE
D1422 MA3360/M/-X ZENER DIODE
D1423 1SR124-400A-T2 SI.DIODE
D1424 MA111-X SI.DIODE
D1425 MA111-X SI.DIODE
D1427 MA3270/H/-X ZENER DIODE
D1551 RGP10J-TS-T3 SI.DIODE
D1552 RH1S-T3 SI.DIODE
D1553 MA3091/M/-X ZENER DIODE
D1554 MA111-X SI.DIODE
D1555 1SR124-400A-T2 SI.DIODE
D1571 MA3075/M/-X ZENER DIODE
D1581 MA3200/M/-X ZENER DIODE
D1582 RGP10J-TS-T3 SI.DIODE
D1651 MA111-X SI.DIODE
D1652 MA111-X SI.DIODE
D1653 MTZJ18A-T2 ZENER DIODE
D1701 MA111-X SI.DIODE
D1704 L-132XID-T16 LED
D1705 SLR-342MG-T16 LED
D1706 MA111-X SI.DIODE
D1707 MA111-X SI.DIODE
D1731 MA111-X SI.DIODE

! D1901 G2SBA60 BRIDGE DIODE

D1902 IM-BW BUS WIRE
D1921 RGP10J-TS-T3 SI.DIODE
D1922 MA111-X SI.DIODE
D1923 MA111-X SI.DIODE
D1924 MA111-X SI.DIODE
D1926 MA3056/M/-X ZENER DIODE
D1927 MA3068/M/-X ZENER DIODE
D1929 RD12E/B2/-T5 ZENER DIODE
D1930 EG1A-T3 SI.DIODE
D1932 MA111-X SI.DIODE
D1933 RD27E/B2/-T5 ZENER DIODE
D1941 RU3AM-LFC4 SI.DIODE
D1942 RU3YX-LFC4 SI.DIODE
D1943 RGP10J-TS-T3 SI.DIODE
D1945 MA3075/H/-X ZENER DIODE
D1982 MA111-X SI.DIODE
D1983 MA111-X SI.DIODE

TRANSISTOR

Q1102 2SC5083/L-P/-T SI.TRANSISTOR
Q1103 UN2212-X DIGI.TRANSISTOR
Q1161 2SD601A/QR/-X SI.TRANSISTOR
Q1301 2SB709A/QR/-X SI.TRANSISTOR
Q1302 2SD601A/QR/-X SI.TRANSISTOR
Q1351 2SC3271F SI.TRANSISTOR
Q1352 2SC3271F SI.TRANSISTOR
Q1353 2SC3271F SI.TRANSISTOR
Q1401 DTC124ESA-T DIGI.TRANSISTOR
Q1402 2SD601A/QR/-X SI.TRANSISTOR
Q1521 2SK3065-W MOS FET

! Q1522 2SC5388-CA POWER TRANSISTOR H.OUT

Q1523 2SD601A/QR/-X SI.TRANSISTOR
Q1524 2SD601A/QR/-X SI.TRANSISTOR
Q1571 2SA1208/ST/Z1-T SI.TRANSISTOR
Q1572 2SD601A/QR/-X SI.TRANSISTOR
Q1651 2SB709A/QR/-X SI.TRANSISTOR
Q1652 DTC323TK-X DIGI.TRANSISTOR
Q1654 2SD601A/QR/-X SI.TRANSISTOR
Q1655 2SD601A/QR/-X SI.TRANSISTOR
Q1702 2SD601A/QR/-X SI.TRANSISTOR
Q1703 2SD601A/QR/-X SI.TRANSISTOR
Q1708 UN2212-X DIGI.TRANSISTOR
Q1709 2SB709A/QR/-X SI.TRANSISTOR
Q1710 UN2212-X DIGI.TRANSISTOR
Q1803 2SC1815/YG/-T SI.TRANSISTOR
Q1804 2SD601A/QR/-X SI.TRANSISTOR
Q1941 2SD601A/QR/-X SI.TRANSISTOR
Q1943 UN2211-X DIGI.TRANSISTOR
Q1974 2SA966/OY/-T SI.TRANSISTOR
Q1975 UN2212-X DIGI.TRANSISTOR

IC

IC1301 NN5198K IC
IC1421 AN5539-LF IC

44

No. 52036

A

! Symbol No. Part No. Part Name Description

IC

IC1651 LA4287 IC
IC1652 SI-5003X-X IC
IC1701 MN1873287JM IC
IC1702 AT24C08-21D43BK IC (SERVICE)
IC1703 L78LR05E-MA IC
IC1704 PIC-28143SY IR DETECT UNIT
IC1921 STR-G6653 IC
IC1941 SE115N-LF12 IC
IC1971 BA51W12ST-V5 IC

OTHERS

LC30114-001C-H LED HOLDER

CF1161 QAX0694-001Z C FILTER
CF1162 QAX0694-001Z C FILTER
CP1701 IM-BW BUS WIRE

! CP1981 ICP-N75-Y I.C.PROTECT
! CP1982 ICP-N75-Y I.C.PROTECT
! F1901 QMF51E2-3R15J4 FUSE 3.15A

FC1901 CEMG002-001Z FUSE CLIP
J1002 QNN0384-001 PIN JACK
J1003 CEMN065-001 PIN JACK or QNN0281-003
J1004 CEMN065-002 PIN JACK or QNN0281-002
J1005 QNS0165-001 3.5 JACK
K1001 QQR0621-002Z FERRITE BEADS
K1351 QQR0621-002Z FERRITE BEADS
K1421 QQR0582-001Z FERRITE BEADS
K1701 IM-BW BUS WIRE
K1703 IM-BW BUS WIRE
K1704 IM-BW BUS WIRE
K1921 QQR1113-001Z FERRITE BEADS
K1922 QQR1113-001Z FERRITE BEADS
K1923 QQR1114-001Z FERRITE BEADS
K1924 QQR1113-001Z FERRITE BEADS
K1941 QQR1113-001Z FERRITE BEADS
K1942 QQR1113-001Z FERRITE BEADS
K1943 QQR1113-001Z FERRITE BEADS

! LF1901 QQR0527-002 LINE FILTER

PC1701 P1241-04 PHOTO CONDUCTOR

! PC1921 PC123F2 IC(PHOTO COUPLE or TLP721F(D4-GR)

SF1102 QAX0594-001 SAW FILTER
SF1122 QAX0325-001 SAW FILTER

! SK1351 CE42446-001 CRT SOCKET

S1701 QSW0619-003Z TACT SWITCH VOL+
S1702 QSW0619-003Z TACT SWITCH VOL­S1703 QSW0619-003Z TACT SWITCH CH+
S1704 QSW0619-003Z TACT SWITCH CH­S1705 QSW0619-003Z TACT SWITCH MENU

! S1901 QSW0750-001 PUSH SWITCH POWER SW
! TH1901 QAD0119-9R0 THERMISTOR or QAD0121-9R0

TU1001 QAU0186-002 TUNER

! VA1901 QAF0052-621 VARISTOR or ERZV10V621CS

X1301 QAX0500-001Z CRYSTAL
X1302 CE42690-001Z CRYSTAL
X1701 FCR12.0M2S CRYSTAL

CM35921-B02 CDS HOLDER

PACKING

3

4

2

PACKING PARTS LIST

V-21D43

5

6

7 8

3

1

[ AV-21D43

! Ref.No. Part No. Part Name Description

! 7 LCT1209-001A-H INST BOOK

No. 52036

1 GG10056-065A-H PACKING CASE
2 CM47385-00A POS,SERIAL LABEL
3 GG10131-001B-H CUSHION ASSY 4pcs in 1set
4 CP30697-005-H POLY BAG or CP30697-003-H
5 RM-C368GY-1H REMOCON UNIT
6 QPA02503505 POLY BAG

8 ATEAB001-00A MATCHING BOX

/BK

]

45

A

V-20N43

EXPLODED VIEW PARTS LIST

[ AV-20N43

! Ref.No. Part No. Part Name Description

! 1 LC10438-032A-H FRONT CABINET

2 CM48006-007-C JVC MARK

! 3 LC30664-001B-H REMOCON WINDOW
! 4 LC20318-003A-H CONTROL KNOB

5 LC30665-001A-H REMOCON LENS

! V01 A48LSD095X PICTURE TUBE
! DY01 QQD0034-001 DEF YOKE
! L01 QQW0061-001 DEG COIL
! T1522 QQH0073-001 F.B.TRANSF.
! 6 LC30663-003A-H POWER KNOB

7 A48457-1 SPRING
8 WJY0008-002A E-BRAIDED ASSY
9 A75034-B PC MAGNET or CE42378-00B

10 CE40764-00A WEDGE ASSY (x3)
11 CM36623-B01-H CHASSIS RAIL (x2)
12 CEBSS12D-07KJ2 SPEAKER (x2) SP01

! 13 QMPR010-200-E2 POWER CORD or QMPR010-200-K2
! 14 CM47005-A01-H POWER CORD CLAMP
! 15 LC10448-002B-H REAR COVER

16 QYSBSFG4016Z TAP SCREW (x6)
17 QYSBSF3010Z TAP SCREW

! 18 GG20024-001B-H RATING LABEL

/BK

]

EXPLODED VIEW

FRONT VIEW

2

!

3

!

4

5

!

1

46

No. 52036

A

EXPLODED VIEW

V-20N43

12

V01

!

L01

!

14

!

10

DY01

11

!

7

8

9

CRT SOCKET PWB

(Within MAIN PWB)

11

!

6

12

!

T1522

MAIN PWB

15

!

13

!

!

18

17

16

(×6)

No. 52036

47

A

V-20N43

[ AV-20N43/BK ]

PRINTED WIRING BOARD PARTS LIST

MAIN P.W. BOARD ASS’Y (SCG-1434A)

! Symbol No. Part No. Part Name Description

RESISTOR

R1002 NRSA02J-221X MG R 220Ω 1/10W J
R1003 NRSA02J-221X MG R 220
R1004 NRSA02J-563X MG R 56k
R1102 NRSA02J-750X MG R 75Ω 1/10W J
R1103 NRSA02J-100X MG R 10
R1109 NRSA02J-682X MG R 6.8kΩ 1/10W J
R1110 NRSA02J-272X MG R 2.7kΩ 1/10W J
R1111 NRSA02J-181X MG R 180
R1112 NRSA02J-100X MG R 10Ω 1/10W J
R1113 NRSA02J-101X MG R 100
R1114 NRSA02J-472X MG R 4.7k
R1115 NRSA02J-222X MG R 2.2kΩ 1/10W J
R1117 NRSA02J-0R0X MG R 0.0Ω 1/10W J
R1118 NRSA02J-222X MG R 2.2k
R1120 NRSA02J-391X MG R 390Ω 1/10W J
R1121 NRSA02J-221X MG R 220Ω 1/10W J
R1159 NRSA02J-184X MG R 180k
R1161 NRSA02J-102X MG R 1kΩ 1/10W J
R1162 NRSA02J-122X MG R 1.2kΩ 1/10W J
R1163 NRSA02J-222X MG R 2.2k
R1164 NRSA02J-221X MG R 220Ω 1/10W J
R1165 NRSA02J-220X MG R 22Ω 1/10W J
R1166 NRSA02J-821X MG R 820
R1301 NRSA02J-221X MG R 220Ω 1/10W J
R1302 NRSA02J-472X MG R 4.7kΩ 1/10W J
R1303 NRSA02J-101X MG R 100
R1304 NRSA02J-101X MG R 100Ω 1/10W J
R1305 NRSA02J-101X MG R 100Ω 1/10W J
R1306 NRSA02J-221X MG R 220
R1307 NRSA02J-122X MG R 1.2kΩ 1/10W J
R1308 NRSA02J-182X MG R 1.8kΩ 1/10W J
R1312 NRSA02J-0R0X MG R 0.0
R1313 NRSA02J-102X MG R 1kΩ 1/10W J
R1314 NRSA02J-102X MG R 1kΩ 1/10W J
R1321 NRSA02J-152X MG R 1.5k
R1322 NRSA02J-272X MG R 2.7kΩ 1/10W J
R1323 NRSA02J-103X MG R 10kΩ 1/10W J
R1324 NRSA02J-102X MG R 1k
R1326 NRSA02J-101X MG R 100Ω 1/10W J
R1327 NRSA02J-475X MG R 4.7MΩ 1/10W J
R1341 NRSA02J-332X MG R 3.3k
R1347 NRSA02J-392X MG R 3.9kΩ 1/10W J
R1349 NRSA02J-472X MG R 4.7kΩ 1/10W J
R1351 NRSA02J-151X MG R 150
R1352 NRSA02J-151X MG R 150Ω 1/10W J
R1353 NRSA02J-151X MG R 150Ω 1/10W J
R1354 NRSA02J-331X MG R 330
R1355 NRSA02J-331X MG R 330Ω 1/10W J
R1356 NRSA02J-331X MG R 330Ω 1/10W J
R1357 NRSA02J-101X MG R 100
R1358 NRSA02J-101X MG R 100Ω 1/10W J
R1359 NRSA02J-101X MG R 100Ω 1/10W J
R1360 QRZ0107-152Z C R 1.5k
R1361 QRZ0107-152Z C R 1.5kΩ 1/2W K
R1362 QRZ0107-152Z C R 1.5kΩ 1/2W K
R1363 QRL029J-123 OM R 12k
R1364 QRL029J-123 OM R 12kΩ 2W J
R1365 QRL029J-123 OM R 12kΩ 2W J
R1366 NRSA02J-182X MG R 1.8k
R1367 NRSA02J-182X MG R 1.8kΩ 1/10W J
R1368 NRSA02J-182X MG R 1.8kΩ 1/10W J
R1372 NRSA02J-0R0X MG R 0.0
R1374 NRSA02J-682X MG R 6.8kΩ 1/10W J
R1401 NRSA02J-103X MG R 10kΩ 1/10W J
R1421 NRSA02J-122X MG R 1.2k
R1422 NRSA02J-122X MG R 1.2kΩ 1/10W J
R1423 NRSA02J-331X MG R 330Ω 1/10W J
R1424 NRSA02J-101X MG R 100
R1425 NRSA02J-471X MG R 470Ω 1/10W J
R1426 NRSA02J-0R0X MG R 0.0Ω 1/10W J
R1429 NRSA02J-103X MG R 10k
R1430 NRSA02J-823X MG R 82kΩ 1/10W J
R1431 NRSA02J-103X MG R 10kΩ 1/10W J
R1432 QRE121J-2R7Y C R 2.7

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/2W K

Ω

2W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/2W J

! Symbol No. Part No. Part Name Description

RESISTOR

R1433 QRE121J-2R7Y C R 2.7Ω 1/2W J
R1436 NRSA02J-823X MG R 82kΩ 1/10W J
R1440 QRE121J-471Y C R 470Ω 1/2W J
R1441 NRSA02J-822X MG R 8.2k
R1442 NRSA02J-103X MG R 10k
R1443 QRE121J-1R0Y C R 1.0Ω 1/2W J
R1453 NRSA02J-272X MG R 2.7k
R1501 QRE121J-101Y C R 100
R1502 NRSA02J-0R0X MG R 0.0Ω 1/10W J
R1503 NRSA02J-682X MG R 6.8k
R1521 NRSA02J-681X MG R 680Ω 1/10W J
R1522 NRSA02J-103X MG R 10k
R1524 QRL02EJ-820X OM R 82
R1525 QRL02EJ-820X OM R 82Ω 2W J
R1526 QRE121J-270Y C R 27Ω 1/2W J
R1530 QRE121J-223Y C R 22k
R1531 NRSA02J-472X MG R 4.7k
R1532 NCB31HK-103X C CAP. 0.01µF 50V K
R1533 NRSA02J-332X MG R 3.3k
R1534 NRSA02J-332X MG R 3.3kΩ 1/10W J

! R1551 QRZ9011-1R0 F R 1.0 Ω 1/2W J

R1552 QRJ146J-2R2X C R 2.2
R1554 QRE121J-681Y C R 680Ω 1/2W J
R1571 QRE121J-222Y C R 2.2kΩ 1/2W J
R1573 QRT02EJ-1R5X MF R 1.5
R1574 QRT02EJ-1R5X MF R 1.5Ω 2W J
R1576 QRE121J-223Y C R 22kΩ 1/2W J
R1577 NRSA02J-392X MG R 3.9k
R1578 NRSA02J-103X MG R 10kΩ 1/10W J
R1581 QRE121J-182Y C R 1.8kΩ 1/2W J
R1582 NRSA02J-273X MG R 27k
R1583 NRSA02J-393X MG R 39k
R1651 NRSA02J-103X MG R 10kΩ 1/10W J
R1652 NRSA02J-821X MG R 820
R1653 QRE121J-1R0Y C R 1.0Ω 1/2W J
R1654 QRX029J-4R7 MF R 4.7Ω 2W J
R1656 NRSA02J-123X MG R 12k
R1657 NRSA02J-391X MG R 390Ω 1/10W J
R1658 NRSA02J-102X MG R 1kΩ 1/10W J
R1659 NRSA02J-102X MG R 1k
R1660 NRSA02J-103X MG R 10kΩ 1/10W J
R1661 QRE121J-271Y C R 270Ω 1/2W J
R1662 QRE121J-271Y C R 270
R1664 NRSA02J-221X MG R 220Ω 1/10W J
R1665 NRSA02J-103X MG R 10kΩ 1/10W J
R1701 NRSA02J-562X MG R 5.6k
R1702 NRSA02J-682X MG R 6.8kΩ 1/10W J
R1703 NRSA02J-392X MG R 3.9kΩ 1/10W J
R1704 NRSA02J-221X MG R 220
R1705 NRSA02J-221X MG R 220Ω 1/10W J
R1706 NRSA02J-561X MG R 560Ω 1/10W J
R1707 NRSA02J-561X MG R 560
R1708 NRSA02J-102X MG R 1kΩ 1/10W J
R1709 NRSA02J-472X MG R 4.7kΩ 1/10W J
R1710 NRSA02J-472X MG R 4.7k
R1711 NRSA02J-472X MG R 4.7kΩ 1/10W J
R1712 NRSA02J-472X MG R 4.7kΩ 1/10W J
R1713 NRSA02J-472X MG R 4.7k
R1714 NRSA02J-472X MG R 4.7kΩ 1/10W J
R1715 NRSA02J-221X MG R 220Ω 1/10W J
R1716 NRSA02J-221X MG R 220
R1718 NRSA02J-561X MG R 560Ω 1/10W J
R1719 NRSA02J-102X MG R 1kΩ 1/10W J
R1720 NRSA02J-472X MG R 4.7k
R1721 NRSA02J-103X MG R 10kΩ 1/10W J

! R1723 QRZ9023-270 F R 27 Ω 2W J

R1725 NRSA02J-102X MG R 1k
R1726 NRSA02J-472X MG R 4.7kΩ 1/10W J
R1727 NRSA02J-153X MG R 15kΩ 1/10W J
R1728 NRSA02J-102X MG R 1k
R1729 NRSA02J-102X MG R 1kΩ 1/10W J
R1730 NRSA02J-103X MG R 10kΩ 1/10W J
R1731 NRSA02J-472X MG R 4.7k
R1736 NRSA02J-823X MG R 82kΩ 1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/2W J

Ω

1/10W J

Ω

1/10W J

Ω

2W J

Ω

1/2W J

Ω

1/10W J

Ω

1/10W J

Ω

1/4W J

Ω

2W J

Ω

1/10W J

Ω

1/10W J
1/10W J

Ω

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/2W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

48

No. 52036

A

V-20N43

! Symbol No. Part No. Part Name Description

RESISTOR

R1737 NRSA02J-104X MG R 100kΩ 1/10W J
R1738 NRSA02J-103X MG R 10k
R1739 NRSA02J-103X MG R 10k
R1740 NRSA02J-392X MG R 3.9k
R1741 NRSA02J-561X MG R 560
R1742 NRSA02J-563X MG R 56kΩ 1/10W J
R1746 NRSA02J-103X MG R 10k
R1747 NRSA02J-0R0X MG R 0.0
R1748 NRSA02J-223X MG R 22kΩ 1/10W J
R1749 NRSA02J-472X MG R 4.7kΩ 1/10W J
R1771 NRSA02J-222X MG R 2.2k
R1772 NRSA02J-821X MG R 820
R1773 NRSA02J-122X MG R 1.2k
R1797 NRSA02J-153X MG R 15k
R1796 NRSA02J-103X MG R 10kΩ 1/10W J
R1791 NRSA02J-221X MG R 220Ω 1/10W J
R1792 NRSA02J-221X MG R 220
R1793 NRSA02J-221X MG R 220
R1794 NRSA02J-221X MG R 220Ω 1/10W J
R1795 NRSA02J-221X MG R 220
R1802 NRSA02J-750X MG R 75Ω 1/10W J
R1806 QRE121J-271Y C R 270Ω 1/2W J
R1807 NRSA02J-680X MG R 68
R1810 QRG01GJ-560 OM R 56Ω 1W J
R1811 NRSA02J-221X MG R 220Ω 1/10W J
R1815 QRE121J-181Y C R 180
R1816 NRSA02J-681X MG R 680Ω 1/10W J
R1817 NRSA02J-472X MG R 4.7kΩ 1/10W J

! R1901 QRF104K-3R9 UNF R 3.9

R1903 QRL02EJ-683X OM R 68kΩ 2W J
R1921 QRE121J-681Y C R 680Ω 1/2W J
R1922 QRT029J-1R2 MF R 1.2
R1923 QRM059J-R22 MP R 0.22Ω 5W J
R1926 NRSA02J-222X MG R 2.2kΩ 1/10W J
R1928 QRL03EJ-563X OM R 56k
R1929 QRE121J-822Y C R 8.2k
R1932 QRE121J-564Y C R 560kΩ 1/2W J
R1933 QRE121J-220Y C R 22
R1934 NRSA02J-333X MG R 33kΩ 1/10W J
R1936 QRG01GJ-561 OM R 560Ω 1W J
R1941 QRE121J-821Y C R 820
R1942 NRSA02J-122X MG R 1.2kΩ 1/10W J
R1943 NRSA02J-473X MG R 47kΩ 1/10W J
R1944 NRSA02J-103X MG R 10k
R1974 NRSA02J-222X MG R 2.2kΩ 1/10W J
R1976 NRSA02J-102X MG R 1kΩ 1/10W J
R1977 QRE121J-122Y C R 1.2k
R1978 NRSA02J-473X MG R 47kΩ 1/10W J
R1979 QRT02EJ-1R2X MF R 1.2Ω 2W J
R1980 QRL02EJ-103X OM R 10k

! R1991 QRZ0057-825 C R 8.2MΩ 1W J

CAPACITOR

C1001 QETN1HM-106Z E CAP. 10µF 50V M
C1002 NCB31HK-103X C CAP. 0.01
C1004 QETN1CM-477Z E CAP. 470µF 16V M
C1005 QFV71HJ-104Z MF CAP. 0.1µF 50V J
C1008 QETN1HM-475Z E CAP. 4.7
C1103 QETN1EM-476Z E CAP. 47µF 25V M
C1104 NCB31HK-472X C CAP. 4700pF 50V K
C1105 NCB31HK-472X C CAP. 4700pF 50V K
C1106 NCB31HK-472X C CAP. 4700pF 50V K
C1107 NCB31HK-472X C CAP. 4700pF 50V K
C1109 NCB31HK-472X C CAP. 4700pF 50V K
C1110 NRSA02J-0R0X MG R 0.0
C1112 QETN1EM-476Z E CAP. 47
C1113 NCB31HK-472X C CAP. 4700pF 50V K
C1115 NCB31HK-103X C CAP. 0.01
C1116 NCB31HK-103X C CAP. 0.01µF 50V K
C1117 QFV71HJ-224Z MF CAP. 0.22
C1119 QETN1HM-474Z E CAP. 0.47µF 50V M
C1120 NDC31HJ-121X C CAP. 120pF 50V J
C1121 NCB31HK-103X C CAP. 0.01
C1122 NCB31HK-103X C CAP. 0.01
C1161 NCB31HK-103X C CAP. 0.01µF 50V K
C1162 NCB31HK-681X C CAP. 680pF 50V K
C1164 NCB31HK-103X C CAP. 0.01

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/2W J

Ω

10W K

Ω

2W J

Ω

3W J

Ω

1/2W J

Ω

1/2W J

Ω

1/2W J

Ω

1/10W J

Ω

1/2W J

Ω

2W J

µ

F 50V K

µ

F 50V M

Ω

1/10W J

µ

F 25V M

µ

F 50V K

µ

F 50V J

µ

F 50V K

µ

F 50V K

µ

F 50V K

! Symbol No. Part No. Part Name Description

CAPACITOR

C1165 NCB31HK-103X C CAP. 0.01µF 50V K
C1166 NCB21HK-104X C CAP. 0.1
C1301 NCB21HK-123X C CAP. 0.012
C1302 QETN1HM-475Z E CAP. 4.7
C1303 NDC31HJ-100X C CAP. 10pF 50V J
C1304 QFV71HJ-474Z MF CAP. 0.47
C1305 QETN1HM-474Z E CAP. 0.47
C1306 NCB31HK-103X C CAP. 0.01µF 50V K
C1307 QETN1CM-477Z E CAP. 470
C1308 QETN1CM-107Z E CAP. 100
C1309 NCB31HK-103X C CAP. 0.01µF 50V K
C1310 NDC31HJ-221X C CAP. 220pF 50V J
C1311 NCB31HK-103X C CAP. 0.01
C1312 QENC1HM-474Z E CAP. 0.47µF 50V M
C1313 QETN1HM-335Z E CAP. 3.3µF 50V M
C1314 NCB31HK-103X C CAP. 0.01
C1315 QETN1CM-107Z E CAP. 100
C1316 QETN1HM-106Z E CAP. 10µF 50V M
C1317 NCB31EK-473X C CAP. 0.047
C1321 NDC31HJ-120X C CAP. 12pF 50V J
C1322 NCB21HK-273X C CAP. 0.027
C1323 QETN1HM-474Z E CAP. 0.47µF 50V M
C1324 QETN1HM-106Z E CAP. 10
C1325 QENC1HM-106Z BP E CAP. 10µF 50V M
C1326 NCS21HJ-221X C CAP. 220pF 50V J
C1341 QETN1HM-106Z E CAP. 10
C1351 QCZ0121-102 C CAP. 1000pF 3kV Z
C1354 NDC31HJ-271X C CAP. 270pF 50V J
C1355 NDC31HJ-221X C CAP. 220pF 50V J
C1356 NDC31HJ-331X C CAP. 330pF 50V J
C1357 QETN1AM-477Z E CAP. 470
C1365 QENC1HM-105Z E CAP. 1µF 50V M
C1366 QENC1HM-105Z E CAP. 1µF 50V M
C1367 QENC1HM-105Z E CAP. 1
C1401 QFV71HJ-474Z MF CAP. 0.47µF 50V J
C1402 QFV71HJ-104Z MF CAP. 0.1µF 50V J
C1422 QETN1HM-105Z E CAP. 1
C1423 QCS32HJ-180Z C CAP. 18pF 500V J
C1424 QFLC2AJ-103Z M CAP. 0.01
C1426 QFLC1HJ-102Z M CAP. 1000pF 50V J
C1427 QETN1VM-107Z E CAP. 100
C1428 QEHR1VM-107Z E CAP. 100
C1429 QETN1HM-106Z E CAP. 10µF 50V M
C1430 QFLC2AJ-472Z M CAP. 4700pF 100V J
C1433 QEHR1HM-475Z E CAP. 4.7
C1435 QETM1EM-228 E CAP. 2200
C1436 QFV71HJ-334Z MF CAP. 0.33µF 50V J
C1501 QETN1HM-476Z E CAP. 47µF 50V M
C1502 NCB31HK-103X C CAP. 0.01
C1503 QETN1HM-106Z E CAP. 10µF 50V M
C1504 QETN1CM-227Z E CAP. 220µF 16V M
C1523 QTMN1VM-476Z E CAP. 47

! C1525 QFZ0200-962 MPP CAP. 9600pF1.5kVH±3%

C1526 QTMN1EM-337Z E CAP. 330

! C1527 QFZ0199-274 MPP CAP. 0.27

C1528 QETN2EM-475Z E CAP. 4.7µF 250V M
C1531 QEZ0203-107 E CAP. 100µF 160V M
C1552 QETM1VM-108 E CAP. 1000
C1554 QETN2EM-475Z E CAP. 4.7µF 250V M
C1555 QFLC2AJ-104Z M CAP. 0.1µF 100V J
C1571 QETN1AM-107Z E CAP. 100
C1572 QETN1EM-476Z E CAP. 47µF 25V M
C1581 QFV71HJ-104Z MF CAP. 0.1µF 50V J

! C1582 QFZ0199-224 MPP CAP. 0.22

C1651 QTNC1HM-105Z E CAP. 1µF 50V M
C1652 QEHR1HM-106Z E CAP. 10µF 50V M
C1653 QFV71HJ-474Z MF CAP. 0.47
C1654 NCB21HK-104X C CAP. 0.1µF 50V K
C1655 QEHQ1VM-228 E CAP. 2200µF 35V M
C1656 QEHR1EM-477Z E CAP. 470
C1658 QETN1HM-226Z E CAP. 22µF 50V M
C1659 QETN1CM-107Z E CAP. 100µF 16V M
C1663 QEHR1HM-106Z E CAP. 10
C1664 NCB21HK-104X C CAP. 0.1µF 50V K
C1665 QEHR1HM-105Z E CAP. 1µF 50V M
C1701 QETN1HM-106Z E CAP. 10
C1705 QETN1CM-477Z E CAP. 470µF 16V M
C1706 NCB21EK-104X C CAP. 0.1µF 25V K

µ

F 50V K

µ

F 50V K

µ

F 50V M

µ

F 50V J

µ

F 50V M

µ

F 16V M

µ

F 16V M

µ

F 50V K

µ

F 50V K

µ

F 16V M

µ

F 25V K

µ

F 50V K

µ

F 50V M

µ

F 50V M

µ

F 10V M

µ

F 50V M

µ

F 50V M

µ

F 100V J

µ

F 35V M

µ

F 35V M

µ

F 50V M

µ

F 25V M

µ

F 50V K

µ

F 35V M

µ

F 25V M

µ

F 250V J

µ

F 35V M

µ

F 10V M

µ

F 250V J

µ

F 50V J

µ

F 25V M

µ

F 50V M

µ

F 50V M

No. 52036

49

A

V-20N43

! Symbol No. Part No. Part Name Description

CAPACITOR

C1707 NCB31HK-103X C CAP. 0.01µF 50V K
C1708 QETN1EM-476Z E CAP. 47µF 25V M
C1709 NCB31HK-103X C CAP. 0.01
C1710 QETN1CM-107Z E CAP. 100
C1711 NCB31HK-103X C CAP. 0.01µF 50V K
C1712 NCB31HK-103X C CAP. 0.01
C1713 NCB31HK-103X C CAP. 0.01
C1714 NDC31HJ-330X C CAP. 33pF 50V J
C1715 NDC31HJ-330X C CAP. 33pF 50V J
C1716 NDC31HJ-181X C CAP. 180pF 50V J
C1717 NDC31HJ-181X C CAP. 180pF 50V J
C1718 NCB31HK-103X C CAP. 0.01
C1719 QETN1HM-105Z E CAP. 1
C1720 NCB31HK-103X C CAP. 0.01µF 50V K
C1721 NCB21HK-333X C CAP. 0.033
C1722 NDC31HJ-101X C CAP. 100pF 50V J
C1724 NDC31HJ-560X C CAP. 56pF 50V J
C1728 NDC31HJ-181X C CAP. 180pF 50V J
C1729 NDC31HJ-181X C CAP. 180pF 50V J
C1730 NCB31HK-103X C CAP. 0.01
C1738 QETN1HM-226Z E CAP. 22µF 50V M
C1744 NCB31HK-103X C CAP. 0.01µF 50V K
C1805 QETN1CM-227Z E CAP. 220
C1806 QETN1CM-477Z E CAP. 470µF 16V M
C1811 QETN1HM-106Z E CAP. 10µF 50V M
C1841 NCB31HK-152X C CAP. 1500pF 50V K

! C1901 QFZ9075-104 MPP CAP. 0.1
! OR QFZ9040-104 MF CAP. 0.1µFAC275V M
! C1904 QCZ9078-222 C CAP. 2200pFAC250V M
! C1905 QCZ9078-222 C CAP. 2200pFAC250V M
! C1907 QCZ9078-222 C CAP. 2200pFAC250V M
! C1909 QEZ0199-127 E CAP. 120
! C1910 QFZ9075-473 MPP CAP. 0.047
! OR QFZ9040-473 MF CAP. 0.047µFAC275V M

C1922 QFLC1HJ-471Z M CAP. 470pF 50V J
C1924 QETN1VM-107Z E CAP. 100
C1926 QFLC1HJ-332Z M CAP. 3300pF 50V J
C1928 NCB21HK-473X C CAP. 0.047
C1929 QFP32GJ-223Z PP CAP. 0.022µF 400V J
C1930 QCZ0325-561 C CAP. 560pF 2kV K
C1931 QCZ0325-151 C CAP. 150pF 2kV K
C1932 QCZ0325-151 C CAP. 150pF 2kV K
C1941 QCZ0122-561 C CAP. 560pF 2kV K
C1942 QEZ0420-107 E CAP. 100
C1945 QEHR1CM-108Z E CAP. 1000
C1946 QEHR1CM-477Z E CAP. 470µF 16V M
C1948 QEHR1VM-108Z E CAP. 1000µF 35V M
C1949 NDC31HJ-471X C CAP. 470pF 50V J
C1950 NCB21HK-104X C CAP. 0.1
C1971 QETN1HM-226Z E CAP. 22µF 50V M
C1976 QETN1HM-105Z E CAP. 1µF 50V M
C1977 QETN1CM-477Z E CAP. 470
C1978 QETN1CM-227Z E CAP. 220µF 16V M
C1979 QETN1CM-107Z E CAP. 100µF 16V M

! C1991 QCZ9079-471 C CAP. 470pFAC250V K
! C1992 QCZ9079-471 C CAP. 470pFAC250V K
! C1993 QCZ9079-102 C CAP. 1000pFAC250V M

TRANSFORMER

! T1522 QQH0073-001 F.B.TRANSF.
! T1921 QQS0050-001 SW TRANSF. or QQS0056-001

COIL

L1001 QQL244K-8R2Z COIL 8.2µH K
L1101 QQLZ014-2R2 INDUCTOR
L1103 QQL244K-8R2Z COIL 8.2
L1351 IM-BW BUS WIRE
L1352 IM-BW BUS WIRE
L1353 IM-BW BUS WIRE
L1354 IM-BW BUS WIRE
L1523 QQL342J-2R2Z INDUCTOR
L1551 QQLZ034-500 INDUCTOR
L1701 QQL244J-5R6Z COIL 5.6
L1941 QQL26AK-820Z COIL 82
L1942 QQL26AK-820Z COIL 82µH K
L1943 QQL26AK-820Z COIL 82µH K

DIODE

D1001 MA3330/L/-X ZENER DIODE

µ

F 50V K

µ

F 16V M

µ

F 50V K

µ

F 50V K

µ

F 50V K

µ

F 50V M

µ

F 50V K

µ

F 50V K

µ

F 16V M

µ

FAC275V M

µ

F 400V M

µ

FAC275V M

µ

F 35V M

µ

F 50V K

µ

F 160V M

µ

F 16V M

µ

F 50V K

µ

F 16V M

µ

H K

µ

H J

µ

H K

! Symbol No. Part No. Part Name Description

DIODE

D1102 MA859-T2 SI.DIODE
D1301 MA3091/M/-X ZENER DIODE
D1302 MA3091/M/-X ZENER DIODE
D1305 RB100A-T2 SB DIODE
D1306 1SR124-400A-T2 SI.DIODE
D1341 MA111-X SI.DIODE
D1342 MA111-X SI.DIODE
D1421 MA3360/M/-X ZENER DIODE
D1422 MA3360/M/-X ZENER DIODE
D1423 1SR124-400A-T2 SI.DIODE
D1424 MA111-X SI.DIODE
D1425 MA111-X SI.DIODE
D1427 MA3270/H/-X ZENER DIODE
D1551 RGP10J-TS-T3 SI.DIODE
D1552 RH1S-T3 SI.DIODE
D1553 MA3091/M/-X ZENER DIODE
D1554 MA111-X SI.DIODE
D1555 1SR124-400A-T2 SI.DIODE
D1571 MA3075/M/-X ZENER DIODE
D1581 MA3200/M/-X ZENER DIODE
D1582 RGP10J-TS-T3 SI.DIODE
D1651 MA111-X SI.DIODE
D1652 MA111-X SI.DIODE
D1653 MTZJ18A-T2 ZENER DIODE
D1701 MA111-X SI.DIODE
D1704 L-132XID-T16 LED
D1705 SLR-342MG-T16 LED
D1706 MA111-X SI.DIODE
D1707 MA111-X SI.DIODE
D1731 MA111-X SI.DIODE

! D1901 G2SBA60 BRIDGE DIODE

D1902 IM-BW BUS WIRE
D1921 RGP10J-TS-T3 SI.DIODE
D1922 MA111-X SI.DIODE
D1923 MA111-X SI.DIODE
D1924 MA111-X SI.DIODE
D1926 MA3056/M/-X ZENER DIODE
D1927 MA3068/M/-X ZENER DIODE
D1929 RD12E/B2/-T5 ZENER DIODE
D1930 EG1A-T3 SI.DIODE
D1932 MA111-X SI.DIODE
D1933 RD27E/B2/-T5 ZENER DIODE
D1941 RU3AM-LFC4 SI.DIODE
D1942 RU3YX-LFC4 SI.DIODE
D1943 RGP10J-TS-T3 SI.DIODE
D1945 MA3075/H/-X ZENER DIODE
D1982 MA111-X SI.DIODE
D1983 MA111-X SI.DIODE

TRANSISTOR

Q1102 2SC5083/L-P/-T SI.TRANSISTOR
Q1103 UN2212-X DIGI.TRANSISTOR
Q1161 2SD601A/QR/-X SI.TRANSISTOR
Q1301 2SB709A/QR/-X SI.TRANSISTOR
Q1302 2SD601A/QR/-X SI.TRANSISTOR
Q1351 2SC3271F SI.TRANSISTOR
Q1352 2SC3271F SI.TRANSISTOR
Q1353 2SC3271F SI.TRANSISTOR
Q1401 DTC124ESA-T DIGI.TRANSISTOR
Q1402 2SD601A/QR/-X SI.TRANSISTOR
Q1521 2SK3065-W MOS FET

! Q1522 2SC5388-CA POWER TRANSISTOR H.OUT

Q1523 2SD601A/QR/-X SI.TRANSISTOR
Q1524 2SD601A/QR/-X SI.TRANSISTOR
Q1571 2SA1208/ST/Z1-T SI.TRANSISTOR
Q1572 2SD601A/QR/-X SI.TRANSISTOR
Q1651 2SB709A/QR/-X SI.TRANSISTOR
Q1652 DTC323TK-X DIGI.TRANSISTOR
Q1654 2SD601A/QR/-X SI.TRANSISTOR
Q1655 2SD601A/QR/-X SI.TRANSISTOR
Q1702 2SD601A/QR/-X SI.TRANSISTOR
Q1703 2SD601A/QR/-X SI.TRANSISTOR
Q1708 UN2212-X DIGI.TRANSISTOR
Q1709 2SB709A/QR/-X SI.TRANSISTOR
Q1710 UN2212-X DIGI.TRANSISTOR
Q1803 2SC1815/YG/-T SI.TRANSISTOR
Q1804 2SD601A/QR/-X SI.TRANSISTOR
Q1941 2SD601A/QR/-X SI.TRANSISTOR
Q1943 UN2211-X DIGI.TRANSISTOR
Q1974 2SA966/OY/-T SI.TRANSISTOR
Q1975 UN2212-X DIGI.TRANSISTOR

IC

IC1301 NN5198K IC

50

No. 52036

A

! Symbol No. Part No. Part Name Description

IC

IC1421 AN5539-LF IC
IC1651 LA4287 IC
IC1652 SI-5003X-X IC
IC1701 MN1873287JM IC
IC1702 AT24C08-21D43BK IC (SERVICE)
IC1703 L78LR05E-MA IC
IC1704 PIC-28143SY IR DETECT UNIT
IC1921 STR-G6653 IC
IC1941 SE115N-LF12 IC
IC1971 BA51W12ST-V5 IC

OTHERS

LC30114-001C-H LED HOLDER

CF1161 QAX0694-001Z C FILTER
CF1162 QAX0694-001Z C FILTER
CP1701 IM-BW BUS WIRE

! CP1981 ICP-N75-Y I.C.PROTECT
! CP1982 ICP-N75-Y I.C.PROTECT
! F1901 QMF51E2-3R15J4 FUSE 3.15A

FC1901 CEMG002-001Z FUSE CLIP
J1002 QNN0384-001 PIN JACK
J1003 CEMN065-001 PIN JACK or QNN0281-003
J1004 CEMN065-002 PIN JACK or QNN0281-002
J1005 QNS0165-001 3.5 JACK
K1001 QQR0621-002Z FERRITE BEADS
K1351 QQR0621-002Z FERRITE BEADS
K1421 QQR0582-001Z FERRITE BEADS
K1701 IM-BW BUS WIRE
K1703 IM-BW BUS WIRE
K1704 IM-BW BUS WIRE
K1921 QQR1113-001Z FERRITE BEADS
K1922 QQR1113-001Z FERRITE BEADS
K1923 QQR1114-001Z FERRITE BEADS
K1924 QQR1113-001Z FERRITE BEADS
K1941 QQR1113-001Z FERRITE BEADS
K1942 QQR1113-001Z FERRITE BEADS
K1943 QQR1113-001Z FERRITE BEADS

! LF1901 QQR0527-002 LINE FILTER

PC1701 P1241-04 PHOTO CONDUCTOR

! PC1921 PC123F2 IC(PHOTO COUPLE or TLP721F(D4-GR)

S1701 QSW0619-003Z TACT SWITCH VOL+
S1702 QSW0619-003Z TACT SWITCH VOL­S1703 QSW0619-003Z TACT SWITCH CH+
S1704 QSW0619-003Z TACT SWITCH CH­S1705 QSW0619-003Z TACT SWITCH MENU

! S1901 QSW0750-001 PUSH SWITCH POWER SW

SF1102 QAX0594-001 SAW FILTER
SF1122 QAX0325-001 SAW FILTER

! SK1351 CE42446-001 CRT SOCKET
! TH1901 QAD0119-9R0 THERMISTOR

TU1001 QAU0186-002 TUNER

! VA1901 QAF0052-621 VARISTOR or ERZV10V621CS

X1301 QAX0500-001Z CRYSTAL
X1302 CE42690-001Z CRYSTAL
X1701 FCR12.0M2S CRYSTAL

CM35921-B02 CDS HOLDER

PACKING

4

2

V-20N43

3

5

3

6

7

8

3

1

PACKING PARTS LIST

[ AV-20N43/BK ]

! Ref.No. Part No. Part Name Description

1 GG10056-064A-H PACKING CASE
2 CM47385-00B-H POS,SERIAL LABEL
3 LC10469-001B CHUSION ASSY 4pcs in 1set
4 CP30697-005-H POLY BAG or CP30967-005-H
5 RM-C368GY-1H REMOCON UNIT
6 QPA02503505 POLY BAG

! 7 LCT1209-001A-H INST BOOK

8 ATEAB001-00A MATCHING BOX

No. 52036

51

A

V-14F43

]

EXPLODED VIEW PARTS LIST

[ AV-14F43/BK

! Ref.No. Part No. Part Name Description

! 1 LC10831-030A-H FRONT CABINET

2 CM46880-002-H JVC MARK

! 3 LC30617-001C-H REMOCON WINDOW
! 4 LC30616-004A-H POWER KNOB

5 CM30861-069 SPRING

! 6 LC20292-004A-H CONTROL KNOB

7 LC30618-001B-H LED LENS

! V01 A34AGT13X PICTURE TUBE
! DY01 QQD0046-001 DEF YOKE
! L01 QQW0093-001 DEG COIL
! T1522 QQH0072-001 F.B.TRANSF.

8 A48457-1 SPRING
9 CHGB0016-0A-N BRAIDED ASSY
10 CE40305-00B PC MAGNET
11 CE42153-00AJ1 WEDGE ASSY (x3)

12 QAS0054-001 SPEAKER SP01 (x2)

! 13 CM48144-002-H PB STOPPER
! 14 QMPR010-200-E2 POWER CORD or QMPR010-200-K2
! 15 CM47005-A01-H POWER CORD CLAMP
! 16 CM12961-D01-VH REAR COVER

17 QYSBSFG4016Z TAP SCREW (x4)
18 QYSBSF3010Z TAP SCREW
19 QYSBSBG4012M TAP SCREW

! 20 GG20024-001B-H RATING LABEL

EXPLODED VIEW

FRONT VIEW

2

!

!

6

7

!

5

!

3

1

4

52

No. 52036

A

EXPLODED VIEW

!

!

L01

V01

V-14F43

8

14

!

!

DY01

15

11

!

10

9

CRT SOCKET PWB (Within MAIN PWB)

12

(××××2)

!

T1522

MAIN PWB

!

13

!

16

19

18

!

20

17

(××××4)

No. 52036

53

A

V-14F43

[ AV-14F43/BK ]

PRINTED WIRING BOARD PARTS LIST

MAIN P.W. BOARD ASS’Y (SCG-1433A)

! Symbol No. Part No. Part Name Description

RESISTOR

R1002 NRSA02J-221X MG R 220Ω 1/10W J
R1003 NRSA02J-221X MG R 220
R1004 NRSA02J-563X MG R 56k
R1102 NRSA02J-750X MG R 75Ω 1/10W J
R1103 NRSA02J-100X MG R 10
R1109 NRSA02J-682X MG R 6.8kΩ 1/10W J
R1110 NRSA02J-272X MG R 2.7kΩ 1/10W J
R1111 NRSA02J-181X MG R 180
R1112 NRSA02J-100X MG R 10Ω 1/10W J
R1113 NRSA02J-101X MG R 100
R1114 NRSA63J-472X MG R 4.7k
R1115 NRSA63J-222X MG R 2.2kΩ 1/16W J
R1117 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R1118 NRSA63J-222X MG R 2.2k
R1120 NRSA63J-391X MG R 390Ω 1/16W J
R1121 NRSA63J-221X MG R 220Ω 1/16W J
R1159 NRSA02J-184X MG R 180k
R1161 NRSA63J-102X MG R 1kΩ 1/16W J
R1162 NRSA63J-122X MG R 1.2kΩ 1/16W J
R1163 NRSA63J-222X MG R 2.2k
R1164 NRSA63J-221X MG R 220Ω 1/16W J
R1165 NRSA63J-220X MG R 22Ω 1/16W J
R1166 NRSA63J-821X MG R 820
R1301 NRSA02J-221X MG R 220Ω 1/10W J
R1302 NRSA02J-472X MG R 4.7kΩ 1/10W J
R1303 NRSA02J-101X MG R 100
R1304 NRSA02J-101X MG R 100Ω 1/10W J
R1305 NRSA02J-101X MG R 100Ω 1/10W J
R1306 NRSA02J-221X MG R 220
R1307 NRSA02J-122X MG R 1.2kΩ 1/10W J
R1308 NRSA02J-182X MG R 1.8kΩ 1/10W J
R1312 NRSA02J-0R0X MG R 0.0
R1313 NRSA02J-102X MG R 1kΩ 1/10W J
R1314 NRSA02J-102X MG R 1kΩ 1/10W J
R1321 NRSA02J-152X MG R 1.5k
R1322 NRSA02J-272X MG R 2.7kΩ 1/10W J
R1323 NRSA02J-103X MG R 10kΩ 1/10W J
R1324 NRSA02J-102X MG R 1k
R1326 NRSA02J-101X MG R 100Ω 1/10W J
R1327 NRSA02J-475X MG R 4.7MΩ 1/10W J
R1341 NRSA02J-332X MG R 3.3k
R1345 NRSA02J-151X MG R 150Ω 1/10W J
R1346 NRSA02J-151X MG R 150Ω 1/10W J
R1353 NRSA02J-151X MG R 150
R1354 NRSA02J-331X MG R 330Ω 1/10W J
R1355 NRSA02J-331X MG R 330Ω 1/10W J
R1356 NRSA02J-331X MG R 330
R1357 NRSA02J-101X MG R 100Ω 1/10W J
R1358 NRSA02J-101X MG R 100Ω 1/10W J
R1359 NRSA02J-101X MG R 100
R1360 QRZ0107-152Z C R 1.5kΩ 1/2W K
R1361 QRZ0107-152Z C R 1.5kΩ 1/2W K
R1362 QRZ0107-152Z C R 1.5k
R1363 QRL029J-123 OM R 12kΩ 2W J
R1364 QRL029J-123 OM R 12kΩ 2W J
R1365 QRL029J-123 OM R 12k
R1366 NRSA02J-182X MG R 1.8kΩ 1/10W J
R1367 NRSA02J-182X MG R 1.8kΩ 1/10W J
R1368 NRSA02J-182X MG R 1.8k
R1372 NRSA02J-0R0X MG R 0.0Ω 1/10W J
R1374 NRSA02J-682X MG R 6.8kΩ 1/10W J
R1401 NRSA02J-103X MG R 10k
R1421 NRSA02J-122X MG R 1.2kΩ 1/10W J
R1422 NRSA02J-122X MG R 1.2kΩ 1/10W J
R1423 NRSA02J-331X MG R 330
R1424 NRSA02J-101X MG R 100Ω 1/10W J
R1425 NRSA02J-471X MG R 470Ω 1/10W J
R1426 NRSA02J-0R0X MG R 0.0
R1429 NRSA02J-103X MG R 10kΩ 1/10W J
R1430 NRSA02J-823X MG R 82kΩ 1/10W J
R1431 NRSA02J-103X MG R 10k
R1432 QRE121J-3R9Y C R 3.9Ω 1/2W J
R1433 QRE121J-3R9Y C R 3.9Ω 1/2W J
R1436 NRSA02J-823X MG R 82k

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/16W J

Ω

1/16W J

Ω

1/10W J

Ω

1/16W J

Ω

1/16W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/2W K

Ω

2W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

! Symbol No. Part No. Part Name Description

RESISTOR

R1440 QRE121J-561Y C R 560Ω 1/2W J
R1441 NRSA02J-822X MG R 8.2kΩ 1/10W J
R1442 NRSA02J-103X MG R 10kΩ 1/10W J
R1443 QRE121J-1R0Y C R 1.0
R1453 NRSA02J-272X MG R 2.7k
R1501 QRE121J-101Y C R 100Ω 1/2W J
R1502 NRSA02J-0R0X MG R 0.0
R1503 NRSA02J-682X MG R 6.8k
R1521 NRSA02J-681X MG R 680Ω 1/10W J
R1522 NRSA02J-103X MG R 10k
R1524 QRL03EJ-680X OM R 68Ω 3W J
R1526 QRE121J-270Y C R 27
R1529 QRL039J-121 OM R 120
R1531 NRSA02J-472X MG R 4.7kΩ 1/10W J
R1532 NCB31HK-103X C CAP. 0.01µF 50V K
R1533 NRSA02J-332X MG R 3.3k
R1534 NRSA02J-332X MG R 3.3k

! R1551 QRZ9011-1R0 F R 1.0 Ω 1/2W J

R1552 QRJ146J-2R2X C R 2.2
R1554 QRE121J-182Y C R 1.8kΩ 1/2W J
R1571 QRE121J-272Y C R 2.7kΩ 1/2W J
R1573 QRT02EJ-1R5X MF R 1.5
R1574 QRT02EJ-2R7X MF R 2.7Ω 2W J
R1576 QRE121J-223Y C R 22kΩ 1/2W J
R1577 NRSA02J-562X MG R 5.6k
R1578 NRSA02J-103X MG R 10kΩ 1/10W J
R1581 QRE121J-182Y C R 1.8kΩ 1/2W J
R1582 NRSA02J-273X MG R 27k
R1583 NRSA02J-393X MG R 39kΩ 1/10W J
R1651 NRSA02J-103X MG R 10kΩ 1/10W J
R1652 NRSA02J-102X MG R 1k
R1653 QRE121J-1R0Y C R 1.0
R1654 QRX029J-4R7 MF R 4.7Ω 2W J
R1656 NRSA02J-123X MG R 12k
R1657 NRSA02J-391X MG R 390Ω 1/10W J
R1658 NRSA02J-102X MG R 1kΩ 1/10W J
R1659 NRSA02J-102X MG R 1k
R1660 NRSA02J-103X MG R 10kΩ 1/10W J
R1661 QRE121J-271Y C R 270Ω 1/2W J
R1662 QRE121J-271Y C R 270
R1664 NRSA02J-221X MG R 220Ω 1/10W J
R1665 NRSA02J-103X MG R 10kΩ 1/10W J
R1701 NRSA02J-562X MG R 5.6k
R1702 NRSA02J-682X MG R 6.8kΩ 1/10W J
R1703 NRSA02J-392X MG R 3.9kΩ 1/10W J
R1704 NRSA02J-221X MG R 220
R1705 NRSA02J-221X MG R 220Ω 1/10W J
R1706 NRSA02J-561X MG R 560Ω 1/10W J
R1707 NRSA02J-561X MG R 560
R1708 NRSA02J-102X MG R 1kΩ 1/10W J
R1709 NRSA02J-472X MG R 4.7kΩ 1/10W J
R1710 NRSA02J-472X MG R 4.7k
R1711 NRSA02J-472X MG R 4.7kΩ 1/10W J
R1712 NRSA02J-472X MG R 4.7kΩ 1/10W J
R1713 NRSA02J-472X MG R 4.7k
R1714 NRSA02J-472X MG R 4.7kΩ 1/10W J
R1715 NRSA02J-221X MG R 220Ω 1/10W J
R1716 NRSA02J-221X MG R 220
R1718 NRSA02J-561X MG R 560Ω 1/10W J
R1719 NRSA02J-102X MG R 1kΩ 1/10W J
R1720 NRSA02J-472X MG R 4.7k
R1721 NRSA02J-103X MG R 10kΩ 1/10W J

! R1723 QRZ9023-270 F R 27 Ω 2W J

R1725 NRSA02J-102X MG R 1k
R1726 NRSA02J-472X MG R 4.7kΩ 1/10W J
R1727 NRSA02J-153X MG R 15kΩ 1/10W J
R1728 NRSA02J-102X MG R 1k
R1729 NRSA02J-102X MG R 1kΩ 1/10W J
R1730 NRSA02J-103X MG R 10kΩ 1/10W J
R1731 NRSA02J-472X MG R 4.7k
R1736 NRSA02J-823X MG R 82kΩ 1/10W J
R1737 NRSA02J-104X MG R 100kΩ 1/10W J
R1738 NRSA02J-103X MG R 10k
R1739 NRSA02J-103X MG R 10kΩ 1/10W J

Ω

1/2W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/2W J

Ω

3W J

Ω

1/10W J

Ω

1/10W J

Ω

1/4W J

Ω

2W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

1/2W J

Ω

Ω

1/10W J

Ω

1/10W J

Ω

1/2W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

54

No. 52036

A

V-14F43

! Symbol No. Part No. Part Name Description

RESISTOR

R1740 NRSA02J-392X MG R 3.9kΩ 1/10W J
R1741 NRSA02J-561X MG R 560
R1742 NRSA02J-563X MG R 56kΩ 1/10W J
R1746 NRSA02J-103X MG R 10k
R1747 NRSA02J-0R0X MG R 0.0
R1748 NRSA02J-103X MG R 10kΩ 1/10W J
R1749 NRSA02J-472X MG R 4.7k
R1771 NRSA63J-222X MG R 2.2k
R1772 NRSA63J-821X MG R 820Ω 1/16W J
R1773 NRSA63J-122X MG R 1.2kΩ 1/16W J
R1797 NRSA63J-153X MG R 15k
R1796 NRSA63J-103X MG R 10k
R1791 NRSA63J-221X MG R 220Ω 1/16W J
R1792 NRSA63J-221X MG R 220
R1793 NRSA63J-221X MG R 220
R1794 NRSA63J-221X MG R 220
R1795 NRSA63J-221X MG R 220
R1802 NRSA02J-750X MG R 75Ω 1/10W J
R1806 QRE121J-271Y C R 270Ω 1/2W J
R1807 NRSA02J-680X MG R 68
R1810 QRG01GJ-560 OM R 56
R1811 NRSA02J-221X MG R 220Ω 1/10W J
R1815 QRE121J-181Y C R 180
R1816 NRSA02J-681X MG R 680Ω 1/10W J
R1817 NRSA02J-472X MG R 4.7kΩ 1/10W J

! R1901 QRF074K-4R7 UNF R 4.7

R1903 QRL02EJ-683X OM R 68kΩ 2W J
R1921 QRE121J-681Y C R 680Ω 1/2W J
R1922 QRT029J-1R2 MF R 1.2
R1923 QRM059J-R22 MP R 0.22Ω 5W J
R1926 NRSA02J-222X MG R 2.2kΩ 1/10W J
R1928 QRL03EJ-563X OM R 56k
R1929 QRE121J-822Y C R 8.2kΩ 1/2W J
R1932 QRE121J-564Y C R 560kΩ 1/2W J
R1933 QRE121J-220Y C R 22
R1934 NRSA02J-333X MG R 33k
R1936 QRG01GJ-561 OM R 560Ω 1W J
R1941 QRE121J-821Y C R 820
R1942 NRSA02J-122X MG R 1.2kΩ 1/10W J
R1943 NRSA02J-473X MG R 47kΩ 1/10W J
R1944 NRSA02J-103X MG R 10k
R1974 NRSA02J-222X MG R 2.2kΩ 1/10W J
R1976 NRSA02J-102X MG R 1kΩ 1/10W J
R1977 QRE121J-122Y C R 1.2k
R1978 NRSA02J-473X MG R 47kΩ 1/10W J
R1979 QRT02EJ-1R2X MF R 1.2Ω 2W J
R1980 QRL02EJ-103X OM R 10k
R1985 QRE121J-120Y C R 12Ω 1/2W J
R1986 NRSA02J-682X MG R 6.8kΩ 1/10W J
R1987 NRSA02J-473X MG R 47k
R1988 NRSA02J-182X MG R 1.8kΩ 1/10W J

! R1991 QRZ0057-825 C R 8.2MΩ 1W J

CAPACITOR

C1001 QETN1HM-106Z E CAP. 10µF 50V M
C1002 NCB31HK-103X C CAP. 0.01µF 50V K
C1004 QETN1CM-227Z E CAP. 220µF 16V M
C1005 QFV71HJ-104Z MF CAP. 0.1
C1008 QETN1HM-475Z E CAP. 4.7µF 50V M
C1103 QETN1EM-476Z E CAP. 47µF 25V M
C1104 NCB31HK-472X C CAP. 4700pF 50V K
C1105 NCB31HK-472X C CAP. 4700pF 50V K
C1106 NCB31HK-472X C CAP. 4700pF 50V K
C1107 NCB31HK-472X C CAP. 4700pF 50V K
C1109 NCB31HK-472X C CAP. 4700pF 50V K
C1110 NRSA02J-0R0X MG R 0.0
C1112 QETN1EM-476Z E CAP. 47µF 25V M
C1113 NCB31HK-472X C CAP. 4700pF 50V K
C1115 NCB31HK-103X C CAP. 0.01
C1116 NCB31HK-103X C CAP. 0.01
C1117 QFV71HJ-224Z MF CAP. 0.22µF 50V J
C1119 QETN1HM-474Z E CAP. 0.47µF 50V M
C1120 NDC31HJ-121X C CAP. 120pF 50V J
C1121 NCB31HK-103X C CAP. 0.01
C1122 NCB31HK-103X C CAP. 0.01µF 50V K
C1161 NCB31HK-103X C CAP. 0.01µF 50V K
C1162 NCB31HK-152X C CAP. 1500pF 50V K
C1164 NCB31HK-103X C CAP. 0.01

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/10W J

Ω

1W J

Ω

1/2W J

Ω

7W K

Ω

2W J

Ω

3W J

Ω

1/2W J

Ω

1/10W J

Ω

1/2W J

Ω

1/10W J

Ω

1/2W J

Ω

2W J

Ω

1/10W J

µ

F 50V J

Ω

1/10W J

µ

F 50V K

µ

F 50V K

µ

F 50V K

µ

F 50V K

! Symbol No. Part No. Part Name Description

CAPACITOR

C1165 NCB31HK-103X C CAP. 0.01µF 50V K
C1166 NCB31HK-104X C CAP. 0.1
C1301 NCB21HK-123X C CAP. 0.012
C1302 QETN1HM-475Z E CAP. 4.7
C1303 NDC31HJ-100X C CAP. 10pF 50V J
C1304 QFV71HJ-474Z MF CAP. 0.47
C1305 QETN1HM-474Z E CAP. 0.47
C1306 NCB31HK-103X C CAP. 0.01µF 50V K
C1307 QETN1CM-477Z E CAP. 470
C1308 QETN1CM-107Z E CAP. 100
C1309 NCB31HK-103X C CAP. 0.01µF 50V K
C1310 NDC31HJ-221X C CAP. 220pF 50V J
C1311 NCB31HK-103X C CAP. 0.01
C1312 QENC1HM-474Z E CAP. 0.47µF 50V M
C1313 QETN1HM-335Z E CAP. 3.3µF 50V M
C1314 NCB31HK-103X C CAP. 0.01
C1315 QETN1CM-107Z E CAP. 100
C1316 QETN1HM-106Z E CAP. 10µF 50V M
C1317 NCB31EK-473X C CAP. 0.047
C1321 NDC31HJ-120X C CAP. 12pF 50V J
C1322 NCB21HK-273X C CAP. 0.027
C1323 QETN1HM-474Z E CAP. 0.47µF 50V M
C1324 QETN1HM-106Z E CAP. 10
C1325 QENC1HM-106Z BP E CAP. 10µF 50V M
C1326 NCS21HJ-221X C CAP. 220pF 50V J
C1341 QETN1HM-106Z E CAP. 10
C1351 QCZ0121-102 C CAP. 1000pF 3kV Z
C1354 NDC31HJ-271X C CAP. 270pF 50V J
C1355 NDC31HJ-221X C CAP. 220pF 50V J
C1356 NDC31HJ-331X C CAP. 330pF 50V J
C1357 QETN1AM-477Z E CAP. 470
C1365 QENC1HM-105Z E CAP. 1µF 50V M
C1366 QENC1HM-105Z E CAP. 1µF 50V M
C1367 QENC1HM-105Z E CAP. 1
C1401 QFV71HJ-474Z MF CAP. 0.47µF 50V J
C1402 QFV71HJ-104Z MF CAP. 0.1µF 50V J
C1422 QETN1HM-105Z E CAP. 1
C1423 QCS32HJ-100Z C CAP. 10pF 500V J
C1424 QFLC2AJ-103Z M CAP. 0.01
C1426 QFLC1HJ-103Z M CAP. 0.01µF 50V J
C1427 QETN1VM-107Z E CAP. 100
C1428 QEHR1VM-107Z E CAP. 100µF 35V M
C1429 QETN1HM-106Z E CAP. 10µF 50V M
C1430 QFLC2AJ-272Z M CAP. 2700pF 100V J
C1433 QEHR1HM-475Z E CAP. 4.7
C1435 QETM1EM-228 E CAP. 2200µF 25V M
C1436 QFV71HJ-334Z MF CAP. 0.33µF 50V J
C1501 QETN1HM-476Z E CAP. 47
C1502 NCB31HK-103X C CAP. 0.01µF 50V K
C1503 QETN1HM-106Z E CAP. 10µF 50V M
C1504 QETN1CM-227Z E CAP. 220
C1523 QTMN1VM-476Z E CAP. 47µF 35V M

! C1525 QFZ0200-752 MPP CAP. 7500pF1.5kVH±3%

C1526 QTMN1EM-337Z E CAP. 330

! C1527 QFZ0199-224 MPP CAP. 0.22µF 250V J

C1531 QEZ0203-107 E CAP. 100µF 160V M
C1552 QETM1VM-108 E CAP. 1000
C1554 QETN2EM-475Z E CAP. 4.7µF 250V M
C1555 QFLC2AJ-104Z M CAP. 0.1µF 100V J
C1571 QETN1AM-107Z E CAP. 100
C1572 QETN1EM-476Z E CAP. 47µF 25V M
C1581 QFV71HJ-104Z MF CAP. 0.1µF 50V J

! C1582 QFZ0199-204 MPP CAP. 0.2

C1651 QTNC1HM-105Z E CAP. 1µF 50V M
C1652 QEHR1HM-106Z E CAP. 10µF 50V M
C1653 QEHR1HM-106Z E CAP. 10
C1654 NCB21HK-104X C CAP. 0.1µF 50V K
C1655 QEHQ1VM-228 E CAP. 2200µF 35V M
C1656 QEHR1EM-477Z E CAP. 470
C1658 QETN1HM-226Z E CAP. 22µF 50V M
C1659 QETN1CM-107Z E CAP. 100µF 16V M
C1663 QEHR1HM-106Z E CAP. 10
C1664 NCB21HK-104X C CAP. 0.1µF 50V K
C1665 QEHR1HM-105Z E CAP. 1µF 50V M
C1701 QETN1HM-106Z E CAP. 10
C1705 QETN1CM-477Z E CAP. 470µF 16V M
C1706 NCB21EK-104X C CAP. 0.1µF 25V K
C1707 NCB31HK-103X C CAP. 0.01
C1708 QETN1EM-476Z E CAP. 47µF 25V M

µ

F 50V K

µ

F 50V K

µ

F 50V M

µ

F 50V J

µ

F 50V M

µ

F 16V M

µ

F 16V M

µ

F 50V K

µ

F 50V K

µ

F 16V M

µ

F 25V K

µ

F 50V K

µ

F 50V M

µ

F 50V M

µ

F 10V M

µ

F 50V M

µ

F 50V M

µ

F 100V J

µ

F 35V M

µ

F 50V M

µ

F 50V M

µ

F 16V M

µ

F 25V M

µ

F 35V M

µ

F 10V M

µ

F 250V J

µ

F 50V M

µ

F 25V M

µ

F 50V M

µ

F 50V M

µ

F 50V K

No. 52036

55

A

V-14F43

! Symbol No. Part No. Part Name Description

CAPACITOR

C1709 NCB31HK-103X C CAP. 0.01µF 50V K
C1710 QETN1CM-107Z E CAP. 100
C1711 NCB31HK-103X C CAP. 0.01
C1712 NCB31HK-103X C CAP. 0.01
C1713 NCB31HK-103X C CAP. 0.01
C1714 NDC31HJ-330X C CAP. 33pF 50V J
C1715 NDC31HJ-330X C CAP. 33pF 50V J
C1716 NDC31HJ-181X C CAP. 180pF 50V J
C1717 NDC31HJ-181X C CAP. 180pF 50V J
C1718 NCB31HK-103X C CAP. 0.01
C1719 QETN1HM-105Z E CAP. 1
C1720 NCB31HK-103X C CAP. 0.01
C1721 NCB21HK-333X C CAP. 0.033µF 50V K
C1722 NDC31HJ-101X C CAP. 100pF 50V J
C1728 NDC31HJ-181X C CAP. 180pF 50V J
C1729 NDC31HJ-181X C CAP. 180pF 50V J
C1730 NCB31HK-103X C CAP. 0.01
C1738 QETN1HM-226Z E CAP. 22
C1744 NCB31HK-103X C CAP. 0.01µF 50V K
C1805 QETN1CM-227Z E CAP. 220
C1806 QETN1CM-477Z E CAP. 470
C1811 QETN1HM-106Z E CAP. 10
C1841 NCB31HK-152X C CAP. 1500pF 50V K

! C1901 QFZ9075-104 MPP CAP. 0.1
! OR QFZ9040-104 MF CAP. 0.1
! C1904 QCZ9082-222Z C CAP. 2200pFAC250V M
! C1905 QCZ9082-222Z C CAP. 2200pFAC250V M
! C1907 QCZ9082-222Z C CAP. 2200pFAC250V M
! C1909 QEZ0199-127 E CAP. 120
! C1910 QFZ9075-473 MPP CAP. 0.047µFAC275V M
! OR QFZ9040-473 MF CAP. 0.047

C1922 QFLC1HJ-471Z M CAP. 470pF 50V J
C1924 QETN1VM-107Z E CAP. 100
C1926 QFLC1HJ-332Z M CAP. 3300pF 50V J
C1928 NCB21HK-473X C CAP. 0.047

! C1929 QFP32GJ-223Z PP CAP. 0.022

C1930 QCZ0325-561 C CAP. 560pF 2kV K
C1931 QCZ0325-151 C CAP. 150pF 2kV K
C1932 QCZ0325-151 C CAP. 150pF 2kV K
C1941 QCZ0122-561 C CAP. 560pF 2kV K
C1942 QEZ0420-107 E CAP. 100
C1945 QEHR1CM-108Z E CAP. 1000µF 16V M
C1946 QEHR1CM-477Z E CAP. 470
C1948 QEHR1VM-108Z E CAP. 1000µF 35V M
C1949 NDC31HJ-471X C CAP. 470pF 50V J
C1950 NCB21HK-104X C CAP. 0.1
C1971 QETN1HM-226Z E CAP. 22
C1972 QETN1CM-107Z E CAP. 100µF 16V M
C1976 QETN1HM-105Z E CAP. 1µF 50V M
C1977 QETN1CM-477Z E CAP. 470
C1978 QETN1CM-227Z E CAP. 220µF 16V M
C1979 QETN1CM-107Z E CAP. 100µF 16V M

! C1991 QCZ9079-471 C CAP. 470pFAC250V K
! C1992 QCZ9079-471 C CAP. 470pFAC250V K
! C1993 QCZ9079-102 C CAP. 1000pFAC250V M

TRANSFORMER

! T1522 QQH0072-001 F.B.TRANSF.
! T1921 QQS0050-001 SW TRANSF. or QQS0056-001

COIL

L1001 QQL244K-8R2Z COIL 8.2µH K
L1101 QQLZ014-2R2 INDUCTOR
L1103 QQL244K-8R2Z COIL 8.2
L1351 IM-BW BUS WIRE
L1352 IM-BW BUS WIRE
L1353 IM-BW BUS WIRE
L1354 IM-BW BUS WIRE
L1523 QQL342J-2R2Z INDUCTOR
L1551 QQLZ034-670 INDUCTOR
L1701 QQL244J-5R6Z COIL 5.6
L1941 QQL26AK-820Z COIL 82
L1942 QQL26AK-820Z COIL 82µH K
L1943 QQL26AK-820Z COIL 82µH K

DIODE

D1001 MA3330/L/-X ZENER DIODE
D1102 MA859-T2 SI.DIODE
D1301 MA3091/M/-X ZENER DIODE

µ

F 16V M

µ

F 50V K

µ

F 50V K

µ

F 50V K

µ

F 50V K

µ

F 50V M

µ

F 50V K

µ

F 50V K

µ

F 50V M

µ

F 16V M

µ

F 16V M

µ

F 50V M

µ

FAC275V M

µ

FAC275V M

µ

F 400V M

µ

FAC275V M

µ

F 35V M

µ

F 50V K

µ

F 400V J

µ

F 160V M

µ

F 16V M

µ

F 50V K

µ

F 50V M

µ

F 16V M

µ

H K

µ

H J

µ

H K

! Symbol No. Part No. Part Name Description

DIODE

D1302 MA3091/M/-X ZENER DIODE
D1305 RB100A-T2 SB DIODE
D1306 1SR124-400A-T2 SI.DIODE
D1341 MA111-X SI.DIODE
D1342 MA111-X SI.DIODE
D1421 MA3360/M/-X ZENER DIODE
D1422 MA3360/M/-X ZENER DIODE
D1423 1SR124-400A-T2 SI.DIODE
D1424 MA111-X SI.DIODE
D1425 MA111-X SI.DIODE
D1427 MA3270/H/-X ZENER DIODE
D1551 RGP10J-TS-T3 SI.DIODE
D1552 RH1S-T3 SI.DIODE
D1553 MA3091/M/-X ZENER DIODE
D1554 MA111-X SI.DIODE
D1571 MA3075/M/-X ZENER DIODE
D1581 MA3200/M/-X ZENER DIODE
D1582 RGP10J-TS-T3 SI.DIODE
D1651 MA111-X SI.DIODE
D1652 MA111-X SI.DIODE
D1653 MTZJ18A-T2 ZENER DIODE
D1701 MA111-X SI.DIODE
D1704 L-132XID-T16 LED
D1705 SLR-342MG-T16 LED
D1706 MA111-X SI.DIODE
D1707 MA111-X SI.DIODE
D1731 MA111-X SI.DIODE

! D1901 G2SBA60 BRIDGE DIODE

D1902 IM-BW BUS WIRE
D1921 RGP10J-TS-T3 SI.DIODE
D1922 MA111-X SI.DIODE
D1923 MA111-X SI.DIODE
D1924 MA111-X SI.DIODE
D1926 MA3056/M/-X ZENER DIODE
D1927 MA3068/M/-X ZENER DIODE
D1929 RD12E/B2/-T5 ZENER DIODE
D1930 EG1A-T3 SI.DIODE
D1932 MA111-X SI.DIODE
D1933 RD27E/B2/-T5 ZENER DIODE
D1941 RU3AM-LFC4 SI.DIODE
D1942 RU3YX-LFC4 SI.DIODE
D1943 RGP10J-TS-T3 SI.DIODE
D1945 MA3075/H/-X ZENER DIODE
D1973 MA111-X SI.DIODE
D1974 MA111-X SI.DIODE
D1982 MA111-X SI.DIODE
D1983 MA111-X SI.DIODE

TRANSISTOR

Q1102 2SC5083/L-P/-T SI.TRANSISTOR
Q1103 UN2212-X DIGI.TRANSISTOR
Q1161 2SD601A/QR/-X SI.TRANSISTOR
Q1301 2SB709A/QR/-X SI.TRANSISTOR
Q1302 2SD601A/QR/-X SI.TRANSISTOR
Q1351 2SC4722/NP/ SI.TRANSISTOR
Q1352 2SC4722/NP/ SI.TRANSISTOR
Q1353 2SC4722/NP/ SI.TRANSISTOR
Q1401 DTC124ESA-T DIGI.TRANSISTOR
Q1402 2SD601A/QR/-X SI.TRANSISTOR
Q1521 2SK3065-W MOS FET

! Q1522 2SC5388-CA POWER TRANSISTOR H.OUT

Q1523 2SD601A/QR/-X SI.TRANSISTOR
Q1524 2SD601A/QR/-X SI.TRANSISTOR
Q1571 2SA1208/ST/Z1-T SI.TRANSISTOR
Q1572 2SD601A/QR/-X SI.TRANSISTOR
Q1651 2SB709A/QR/-X SI.TRANSISTOR
Q1652 DTC323TK-X DIGI.TRANSISTOR
Q1654 2SD601A/QR/-X SI.TRANSISTOR
Q1655 2SD601A/QR/-X SI.TRANSISTOR
Q1702 2SD601A/QR/-X SI.TRANSISTOR
Q1703 2SD601A/QR/-X SI.TRANSISTOR
Q1708 UN2212-X DIGI.TRANSISTOR
Q1709 2SB709A/QR/-X SI.TRANSISTOR
Q1710 UN2212-X DIGI.TRANSISTOR
Q1803 2SC1815/YG/-T SI.TRANSISTOR
Q1804 2SD601A/QR/-X SI.TRANSISTOR
Q1941 2SD601A/QR/-X SI.TRANSISTOR
Q1943 UN2211-X DIGI.TRANSISTOR
Q1973 2SD601A/QR/-X SI.TRANSISTOR
Q1974 2SA966/OY/-T SI.TRANSISTOR
Q1975 UN2212-X DIGI.TRANSISTOR

IC

IC1301 NN5198K IC

56

No. 52036

A

! Symbol No. Part No. Part Name Description

IC

IC1421 AN5539-LF IC
IC1651 LA4287 IC
IC1652 SI-5003X-X IC
IC1701 MN1873287JM IC
IC1702 AT24C08-21D43BK IC (SERVICE)
IC1703 L78LR05E-MA IC
IC1704 PIC-28143SY IR DETECT UNIT
IC1921 STR-G6653 IC
IC1941 SE115N-LF12 IC
IC1971 BA51W12ST-V5 IC

OTHERS

LC30114-001C-H LED HOLDER

CF1161 QAX0694-001Z C FILTER
CF1162 QAX0694-001Z C FILTER
CP1701 IM-BW BUS WIRE

! CP1981 ICP-N75-Y I.C.PROTECT
! CP1982 ICP-N75-Y I.C.PROTECT
! F1901 QMF51E2-3R15J4 FUSE 3.15A

FC1901 CEMG002-001Z FUSE CLIP
J1002 QNN0384-001 PIN JACK
J1003 CEMN065-001 PIN JACK or QNN0281-003
J1004 CEMN065-002 PIN JACK or QNN0281-002
J1005 QNS0165-001 3.5 JACK
K1001 QQR0621-002Z FERRITE BEADS
K1351 QQR0621-002Z FERRITE BEADS
K1421 QQR0582-001Z FERRITE BEADS
K1701 IM-BW BUS WIRE
K1703 IM-BW BUS WIRE
K1704 IM-BW BUS WIRE
K1921 QQR1113-001Z FERRITE BEADS
K1922 QQR1113-001Z FERRITE BEADS
K1923 QQR1114-001Z FERRITE BEADS
K1924 QQR1113-001Z FERRITE BEADS
K1941 QQR1113-001Z FERRITE BEADS
K1942 QQR1113-001Z FERRITE BEADS
K1943 QQR1113-001Z FERRITE BEADS

! LF1901 QQR1095-002 LINE FILTER or QQR0906-001

PC1701 P1241-04 PHOTO CONDUCTOR

! PC1921 PC123F2 IC(PHOTO COUPLE
! RY1971 QSK0061-002 RELAY

SF1102 QAX0666-002 SAW FILTER
SF1122 QAX0325-001 SAW FILTER

! SK1351 CE42554-001 C R T SOCKET

S1701 QSW0619-003Z TACT SWITCH VOL+
S1702 QSW0619-003Z TACT SWITCH VOL­S1703 QSW0619-003Z TACT SWITCH CH+
S1704 QSW0619-003Z TACT SWITCH CH­S1705 QSW0619-003Z TACT SWITCH MENU

! S1901 QSW0750-001 PUSH SWITCH POWER SW
! TH1901 QAD0119-9R0 THERMISTOR or QAD0121-9R0
! TU1001 QAU0186-001 TUNER
! VA1901 QAF0052-621 VARISTOR or ERZV10V621CS

X1301 QAX0500-001Z CRYSTAL
X1302 CE42690-001Z CRYSTAL
X1701 FCR12.0M2S CRYSTAL

CM35921-B02 CDS HOLDER

PACKING

3

4

2

V-14F43

5

3

6

!

!

8

7

9

3

1

2

PACKING PARTS LIST

[ AV-14F43

! Ref.No. Part No. Part Name Description

1 GG10056-066B-H PACKING CASE
2 GG20025-001A-H CORNER LABEL 2pcs in 1set
3 LC10833-002B-H CUSHION ASSY 4pcs in 1set
4 CP30697-004-H POLY BAG
5 RM-C368GY-1H REMOCON UNIT
6 QPA02503505P POLY BAG

! 7 LCT1209-001A-H INST BOOK
! 8 CM36447-00A-H ROD ANTENNA

9 ATEAB001-00A MATCHING BOX

No. 52036

/BK

]

57

A

V-14F43

Memo

58

No. 52036

A

Memo

V-14F43

No. 52036

59

VICTOR COMP ANY OF J APAN, LIMITED

HOME AV NETWORK BUSINESS UNIT 12, 3-chome, Moriya-cho, Kanagawa-ku, Yokohama, Kanagawa-prefecture, 221-8528, Japan

4

Printed in Japan
0208 WPC
