JVC AV-14F43, AV-20N43, AV-21D43 User Manual
COLOUR TELEVISION
INSTRUCTIONS
Thank you for buying this JVC
colour television.
To make sure you understand how to
use your new TV, please read this
manual thoroughly before you begin.
AV-14F43
AV-20N43
AV-21D43
Contents
Safety precautions 2
Preparation 3
1 Confirm which remote control you have
2 Inserting the batteries
3
Connecting the aerial and external devices
4 Connecting the power cord
5 SETUP TOUR
...................................
........................
..............................................
......
...
Basic operation 7
Remote control buttons and functions 8
ECO SENSOR button
PICTURE MODE button
COLOUR SYSTEM button
SOUND SYSTEM button
DISPLAY button
RETURN + button
CHANNEL SCAN button
MUTING button
OFF TIMER button
I/II button
PICTURE BOOSTER button
.....................................................
.....................................
.................................
.............................
...............................
.............................................
..........................................
................................
.............................................
.........................................
.........................
10
10
Using the TV’s menus 11
Basic operation
ON TIMER
...........................................................
INPUT
AUTO SHUTOFF
CHILD LOCK
BLUE BACK
AI ECO DISPLAY
SETUP TOUR
LANGUAGE
AUTO CH PRESET
MANUAL CH PRESET
..............................................................
SKIP
Picture Adjustments
........................................
.....................................................
..........................................
.................................................
..................................................
..........................................
...............................................
..................................................
.......................................
..................................
................................
11
12
12
13
13
13
13
14
14
14
15
16
16
Using the buttons on the TV 17
Troubleshooting 19
Specifications 20
3
3
4
6
6
8
8
8
8
9
9
9
9
9
LCT1209-001A-H
0802-NIC-JET
© 2002 VICTOR COMPANY OF JAPAN, LIMITED
Safety precautions
WARNING
• To prevent fire or shock hazard, do not expose the TV to rain or moisture.
CAUTION
• Operate only from the power source indicated on the rear of the TV.
• Avoid damaging the power cord and mains plug. When you unplug the TV, pull it out by
the mains plug. Do not pull on the power cord.
• Never block or cover the cabinet openings for
ventilation. Never install the TV where good
ventilation is unattainable. When installing
this TV, leave spaces for ventilation around
the TV more than the minimum distances
shown in the diagram.
• Do not allow objects or liquid into the
cabinet openings.
• In the event of a fault, unplug the TV and call a service technician. Do not attempt to
repair it by yourself or remove the rear cover.
• The surface of the TV screen is easily damaged. Be very careful with it when handling
the TV. Should the TV screen become soiled, wipe it with a soft dry cloth. Never rub it
forcefully. Never use any cleaner or detergent on it.
• When you don’t use this TV for a long period of time, be sure to unplug it.
10 cm 15 cm
10 cm
15 cm
2
Preparation
1 Confirm which remote control you have
Your TV comes with one of the three remote controls shown below. Functions you can
operate differ depending on the type of remote control.
RM-C368GY
ECO
SENSOR
COLOUR
TV/VIDEO
I/II
OFF
TIMER
CHANNEL
SCAN
DISPLAY
BOOSTER
SYSTEM
POWER
SOUND
123
456
789
RETURN
+
0-/
MENU
MODE
MUTING
--
CHANNEL
REMOTE CONTROL UNIT
RM-C368GY
2 Inserting the batteries
Correctly insert two batteries, observing the , and
. polarities and inserting the . end first.
CAUTION:
Follow the cautions printed on the batteries.
Notes:
• Use AA/R6/UM-3 dry cell batteries.
• If the remote control does not work properly, fit new
batteries.
The supplied batteries are for testing, not regular use.
VOLUME
3
Preparation
3 Connecting the aerial and external devices
• For further details, refer to the manuals provided with the devices you are connecting.
• Connecting cables are not supplied.
• The front and rear AUDIO/VIDEO input jacks are directly connected so that input to either jack
is output through both. You cannot provide input to both the front and rear jacks at the same
time. Disconnect one input, or use one of the jacks as an output jack only (for monitoring or
recording).
• The rod aerial is supplied with the AV-14F43.
■ Connecting the aerial and VCR
Connecting the aerial
To install rod aerial:
Install into the top-rear aerial holder. Once installed, it cannot be removed.
VHF/UHF outdoor aerial
VIDEO
AUDIO
IN
OUT
Indoor aerial
Rod aerial
• Illustration of AV-14F43.
Connecting the aerial and VCR
VHF/UHF outdoor aerial
4
1
2
To RF
output
To aerial input
To video
output
VIDEO
AUDIO
IN
OUT
3
To audio
output
VCR
• Illustration of AV-14F43.
Preparation
■ Connecting other external devices
VIDEO
• Illustration of AV-21D43.
AUDIO
IN
OUT
To audio
output
VCR (for playing)
VCR (for recording)
To audio
input
To video
output
To audio
output
To video
output
To video
input
Camcorder
or
TV game
• Illustration of AV-21D43.
VIDEO AUDIO
IN
MENU
Headphones
• Use the headphones with a stereo mini jack (3.5 mm in diameter). When you connect the
headphones, the TV speakers go off.
5
Preparation
4 Connecting the power cord
Connect the power cord to the AC outlet.
Operate only from the power source indicated on the rear of the TV.
5 SETUP TOUR
When the TV is first turned on it enters the SETUP TOUR mode, and the JVC logo is
displayed. Follow the instructions on the on-screen display to perform the SETUP TOUR.
• In case of resetting that the reason for such as removal, you can set the SETUP TOUR
function on the “MENU 3” menu. For details, see page 14.
1 Press the Main power button
on the TV.
The POWER lamp or POWER/ON
TIMER lamp lights. After the JVC
logo has been displayed, the TV
automatically switches to the
language setting mode.
SETUP TOUR
SETUP TOUR
LANGUAGE
ENGLISH
EXIT BY
OPERATE BY -+
NEXT
DISPLAY
DISPLAY
button
MENU –/+
buttons
POWER lamp Main power button
CHANNEL
SCAN
DISPLAY
CHANNEL
RETURN+
MENU
0-/
VOLUME
--
MUTING
MENU /
buttons
2 Press the MENU M buttons to select the on-screen language.
3 Press the MENU y button.
The AUTO PROGRAMMING function will start and the indicator blinks.
SETUP TOUR
NOW PROGRAMMING
STOP BY -+
• To stop the AUTO PROGRAMMING function, press the MENU m buttons.
When all the TV channels that can be received on your TV have been preset, the
display goes out and the AUTO PROGRAMMING function operation is completed.
• If a TV channel you want to view is not set to the channel, set it with the MANUAL CH
PRESET function. For details, see page 15.
6
