LT-Z26EX6
LT-Z32EX6
WIDE LCD PANEL TV INSTRUCTIONS
ENGLISH
© 2006 Victor Company of Japan, Limited
LT-Z26EX6
0706TKH-CR-MU GGT0128-001A-H-EN
1
2
3
4
I II
1
ENGLISH
ENGLISH
2
IMPORTANT! PREPARE USE
SETTINGS
TROUBLE?
Expanding the world of
beautiful images
Enjoy rich multi-media with JVC
VHF/UHF
Digital camera
Video camera
Game console
Personal
Audio components
VCR DVD player
DVD recorder
Computer
Contents
First things first!
Warning ············································ 3
Getting started
Names of all the parts ······················ 5
Basic connections ···························· 7
Initial settings ··································· 9
Editing channels ····························· 11
· Registering channels
Connecting external devices ·········· 13
Let’s try it out
Enjoying your new TV! ··················· 15
· TV / Teletext / Video / etc.
Watching TV ···································17
Viewing teletext ······························ 19
Watching videos / DVDs ················ 21
Try the advanced features
Useful functions ······························23
· Take a snapshot
· View and search in multi-picture mode
· “Sleep Timer” / “Channel Guard”
Just the way you like it
Customising your TV ······················ 27
Advanced picture adjustment ········· 29
·
Reduce noise / Watch a more natural picture
· Set the aspect ratio, etc.
When you have trouble
Troubleshooting ····························· 31
Technical information ····················· 35
“CH/CC” List ··································· 37
Specifications ································· 38
3
ENGLISH
ENGLISH
4
First things first!
IMPORTANT! PREPARE USE
SETTINGS
TROUBLE?
Warning
Follow this manual
regarding setup!
Connect only to a 110-240V, 50/60Hz
AC outlet.
Make enough room for
inserting and removing
the power plug!
Place the TV as
close to the outlet as
possible!
The main power supply for this TV is
controlled by inserting or removing the
power plug.
Never cut or damage
the power cord!
Please follow all the guidelines below
Do not allow the TV
to fall!
Do not rest your elbows on, or allow
children to hang from the TV.
There is a risk that the TV will fall and
cause injuries.
Never try to repair
the TV yourself!
If the problem cannot be solved in
“Troubleshooting” (P. 31), unplug
the power cord and contact your
retailer.
When attaching the TV to
the wall, use the optional
JVC wall mounting unit!
Consult a qualified technician.
See the included manual on mounting
procedures.
JVC assumes no responsibility for
damage due to improper mounting.
If the TV is damaged
or behaving strangely,
stop using it at once!
Unplug the power cord and contact
your retailer.
Never place anything on
the TV!
Placing liquids, naked
flames, cloths, paper,
etc. on the TV may
cause a fire.
Never expose to rain or
moisture!
To prevent fire or electric
shock, never allow
liquids to enter the unit.
Never insert objects into
the cabinet openings!
It may cause a fatal
electric shock. Take care
when children are near.
If the AC plug is not the
right shape, or the power
cord is not long enough,
use an appropriate plug
adapter or extension cable.
(Consult your retailer.)
Unplug the power cord
when going out!
The power buttons on
the remote control and
the TV unit cannot
completely turn off the
TV. (Make appropriate
arrangements for
bedridden people.)
For more details on installation, usage and safety
For more details on installation, usage and safety
Consult your retailer
Consult your retailer
Never dismantle the
rear panel!
It may cause an electric shock.
Never obstruct the
ventilation holes!
It may cause overheating or a fire.
Handle LCD panel
with care!
Use a soft, dry cloth when cleaning.
Never listen to
headphones at high
volume!
It may damage your hearing.
Hold the TV so as not to
scratch the screen!
Do not touch the screen when carrying the
TV.
Do not carry the
TV on your own!
In order to prevent accidents,
ensure that the TV is carried
by two or more people.
5
ENGLISH
ENGLISH
6
Getting started
TV/VIDEO
MENU/O
K
CHANNEL
VOLUME
IMPORTANT! PREPARE USE
SETTINGS
TROUBLE?
Names of all the parts
Remote control sensor
Power lamp
ON: Lit (Blue)
OFF: Unlit
Power lamp lights while
the TV is on.
“Power Lamp” (P. 28)
Remove the terminal cover
Press to
remove.
Cable cover
If the cover cannot be closed due to the cables being in the way
Do not force the cover to close (leave it open).
Connecting terminals on the back of the TV Connecting External devices (P. 13)
Press to
remove.
Check accessories
Remote control
(RM-C1835)
“AA/R06” Batteries
For confirming
the TV works
Switch between
TV / AV devices
Display on-screen
menu / set
Change channel / page
Volume
Power On / Off
To headphones (P. 13)
LT-Z26EX6LT-Z32EX6
Cable cover
Mute
Return to channel
you want to view
Return to TV
/ Watch video, etc. (P. 21)
Channel information
(P. 17)
Change channel / page
When watching TV / Video
Change the aspect ratio (P. 17)
Turn on “Cinema Surround” (P. 17)
Take a snapshot of the
screen (P. 23)
View in multi-picture
mode (P. 23)
Insert the batteries
Use two “AA/R06” dry cell batteries.
Insert the batteries from the - end, making
sure the + and - polarities are correct.
Power On / Off
Switch between
“VCR / TV / DVD”
Change channel / page
To teletext (P. 19)
Display on-screen menu (P. 27)
Select and
confirm settings in menus
To previous screen
Volume
When viewing teletext (P. 19)
Hold the current page
Bookmark pages
Reveal hidden pages
Switch briefly
between teletext and TV
Enlarge the text
To index page
7
ENGLISH
ENGLISH
8
IMPORTANT! PREPARE USE
SETTINGS
TROUBLE?
Basic connections
Please read the user manuals of each device carefully before setup.
It is necessary to connect an aerial to watch TV.
Connect with other devices “Connecting external devices” (P. 13)
Connect the aerial
AERIAL
After all the connections have been made, insert the plug into an AC outlet.
Connect a VCR / DVD recorder
(Y)
(Pr)
(Pb)
VIDEO-1
(R)
(L)
VCR / DVD recorder
After all the connections have been made, insert the plug into an AC outlet.
If both composite and S-VIDEO cables are connected, S-VIDEO will be enable.
AERIAL
Power requirements
Connect the power cord only to a 110-240V,
50/60Hz AC outlet.
When attaching the TV to the wall, use the
optional JVC wall mounting unit
Consult a qualified technician.
See the included manual on mounting procedures.
JVC assumes no responsibility for damage due to
improper mounting.
200mm × 200mm mount which conforms to VESA
standards.
Care when setting
Installation requirements
To avoid overheating, ensure the unit has ample
room.
200mm
50mm150mm 150mm 50mm
Tidying the cables
To remove the cable cover, refer to back of the cover.
9
ENGLISH
ENGLISH
10
Langua
ge
>
Group-1
Group-2
Group-3
Group-4
Group-5
Teletext Language
01
AV
PR
02
03
04
05
06
07
08
09
CH/CC
CH
21
CH
22
CH
23
CH
24
CH
25
CC
02
CC
CC
04
CC
05
03
> Edit
ID
CH
>
14%
Auto Program
28
IMPORTANT! PREPARE USE
SETTINGS
TROUBLE?
Initial settings
Set the menu language, installation location and automatically register the TV channels.
These channels can be edited later in “Editing channels” (P. 11).
1
2
Begin
Shown only when
powering on for the first time.
The power on the unit can also be used.
Select a language
1 select
2 set
To the previous screen
Exit
If the “JVC” logo does not appear or
if you wish to make changes later
“Language”, “Teletext language” and
“Auto Program” (P. 28)
For the teletext language group
“Language group for teletext”
(P. 35)
If the characters are unreadable.
“Language group for teletext”
(P. 35)
TV
MENU
3
Select the teletext language group
select
Automatically register channels
4
BACK
Check what was registered
5
Confirm
Edit channels
⁄ in “Editing channels” (P. 11)
6
11
ENGLISH
ENGLISH
12
Set Up
Set Up
Auto Program
Video-3 Setting
AI Volume
HDMI Setting
PC Position
Video
Off
Video
Teletext Language
Edit/Manual
Video-1 Setting
Language
01
AV
PR
02
03
04
05
06
07
08
09
CH/CC
CH
21
CH
22
CH
23
CH
24
CH
25
CC
02
CC
CC
04
CC
05
03
> Edit
ID
01
AV
PR
02
03
04
05
06
07
08
09
CH/CC
CH
21
CH
22
CH
23
CH
24
CH
25
CC
02
CC
03
CC
04
CC
05
>Edit
ID
> Edit
01
AV
PR
02
03
04
05
06
07
08
09
CH/CC
ID
CH
21
CH
22
CH
23
CH
24
CH
25
CC
03
CC
04
CC
05
01
AV
PR
02
03
04
05
06
07
08
09
CH/CC
CH
21
CH
22
CH
23
CH
24
CH
25
CC
02
CC
03
CC
04
CC
05
A
>Edit
ID
01
AV
PR
02
03
04
05
06
07
08
09
CH/CC
ID
CH
21
CH
22
CH
23
CH
24
CH
25
CC
02
CC
03
CC
04
CC
05
JVC
>Edit
01
AV
PR
02
03
04
05
06
07
08
09
CH/CC
CH
21
CH
22
CH
23
CH
24
CH
25
CC
02
CC
CC
03
CC
04
>Edit
ID
>Edit
01
AV
PR
02
03
04
05
06
07
08
09
CH/CC
ID
CH
21
CH
22
CH
23
CH
24
CH
25
CC
02
CC
CC
03
CC
04
12
>
01
AV
PR
02
03
04
05
06
07
CH/CC
CH
22
CH
23
CH
24
CH
25
CC
02
CC
03
CC
04
Edit
ID
>
11
10
PR
12
13
14
15
16
17
CH/CC
CH
02 (B/G
)
CC
06
Manual
ID
>Manual
11
10
PR
12
13
14
15
16
17
CH/CC
ID
CH
08 (B/G
)
CC
06
>
11
10
PR
12
13
14
15
16
17
CH/CC
CH
08
CC
06
Edit
ID
>
Manual
11
10
PR
12
13
14
15
16
CH/CC
ID
CH
08 (I
)
CC
06
IMPORTANT! PREPARE USE
SETTINGS
TROUBLE?
Editing channels
Edit the channels registered with “Auto Program” in “Initial settings” (P. 9).
When coming from “Initial settings” (P. 9), skip to ⁄.
Display the menu bar
1
Move a
channel’s
position
MOVE
1 Begin 2 Select a destination 3 Finish
select
move out move in
To the previous
screen
Exit
2
Select “Set Up”
1 select
2 next
Edit a
channel
name
ID
1 Begin 2 Enter a channel name
1 enter the first
character
2
next column
set
Select “Edit / Manual”
3
4
5
Select a row
Edit
1 select
2 next
select
Insert a
channel
INSERT
Delete a
channel
DELETE
1 Begin
1 Delete
2 Select a “CH / CC” 3 Enter a number
select
“CH/CC” List (P. 37)
Receives the
broadcast
signal.
Finish
6
1 Begin
2
Beginning channel search
From high
frequencies
Register a
new channel
MANUAL
· Registering channels
3 Set
If you can not receive the
channel you want to view,
press 3 to change the sound
system.
“Sound system in your
country or region” (P. 35)
From low
frequencies
or
Auto-search begins,
and the nearest
frequency is imported.
Repeat the previous
steps until the
Adjust
Channel fine tuning
desired channel is
displayed
/
If the picture or sound is unnatural
select a system
13
ENGLISH
ENGLISH
14
IMPORTANT! PREPARE USE
SETTINGS
TROUBLE?
Connecting external devices
You can connect many different devices to the rear panel of the TV.
Please read the user manuals of each device before setting up.
(Connecting cables are not supplied with this TV.)
PC
To “VIDEO-3” R/L
“Technical information” (P. 35)
Set-top box / Digital
broadcast tuner
(Y)
(Pr)
(Pb)
(R)
(L)
PC IN
VIDEO-3
VCR / DVD / other devices
: signal direction
VIDEO-1
Output Input
Use Component signal
“Switch between video and
component signal” (P. 22)
Use S-VIDEO
“Using S-VIDEO” (P. 22)
VIDEO-2
Output Input
Use S-VIDEO
“Using S-VIDEO” (P. 22)
Watching videos
·
Composite signal /
Component signal
/ S-VIDEO
· Sound L / R
Watching videos
·
Composite signal /
S-VIDEO
· Sound L / R
Game consoles
Video camera
VCR / DVD recorder
VCR / DVD recorder
Amplifier
(L) (R)
Headphones
Headphone
(R) (L)
(Pr)
(R)
(R)
(R)
(Y)
(Pb)
(L)
(L)
(L)
VIDEO-2
VIDEO-1
IN HDMI
OUT
HDMI
IN HDMI
DVD player
(HDMI compatible)
VIDEO-3
Output Input
Use Component signal
“Switch between video and
component signal” (P. 22)
HDMI
Output Input
“HDMI Setting” (P. 28)
Watching DVDs
·
Composite signal /
Component signal
· Sound L / R
Connecting
HDMI devices
· HDMI signal
(P. 36)
OUT
Video and sound signal of a TV channel
you are viewing outputs from this
terminal
Output
·
Composite signal /
S-VIDEO
· Sound L / R
“Using OUT terminal”. (P. 22)
Connect a “DVI” device to
“HDMI” (P. 36)
15
ENGLISH
ENGLISH
16
Let’s try it out
IMPORTANT! PREPARE USE
SETTINGS
TROUBLE?
Enjoying your new TV!
PAGE
17
Watching TV
View channel information
Change the aspect ratio
Enjoy “Cinema Surround”
Register your favourite channels
TV mode TV and Text mode
PAGE
19
Text mode
Viewing teletext
Enlarge the text
To the index page
Hold the current page
Switch briefly between teletext and TV
Bookmark your favourite pages
Reveal hidden pages
Personal preferences
PAGE
27
Adjust the picture
PAGE
Watching
21
· TV / Teletext / Video / etc.
videos / DVDs
Watch high quality video (S-VIDEO)
Switch between video and component signal
PC position adjustment
Adjust the sound
Advanced settings
(sleep-timer / channel guard, etc.)
Basic settings
(channel settings, etc.)
17
ENGLISH
ENGLISH
18
1
16 : 9 Zoom
HighCinema Surround
AV
02
03
04
05
06
07
08
09
PR List
01
Auto
Panoramic
Panoramic
14:9 Zoom
16:9 Zoom
16:9 Zoom Subtitle
Full
Zoom
Regular
CHANN
EL
VOLUME
MENU/O
K
TV/VIDEO
CHANNEL
Return Plus
Programmed!
23
34
Return Plus
Canceled!
IMPORTANT! PREPARE USE
SETTINGS
TROUBLE?
Watching TV
Mute
Volume
Power on
1
Press again to turn the screen off
The blue
power lamp
on the TV lights
and put the TV into standby mode.
Select a channel
2
Move up or down a channel
Switch between mono / stereo /
bilingual broadcasting
“Stereo / t·u” ( P. 28)
Note
To completely turn off the TV, unplug
the AC plug.
E.g.
1 :
15 :
up
down
Channel
information
DISPLAY
Select a page
Change the aspect
ratio
ZOOM
Enjoy ambient
PR List
Channels
registered in
“Initial settings” will
appear here.
select
1 select
2 set
High
Low
Channel information
(No indication)
1 select
Select and view a channel
2 view
When set to “Auto”, the aspect ratio
will turn to the ratio obtained from
the information the TV received.
Without receiving aspect information,
it will be the setting in “Auto” of
Move the picture with
1 or 4 while this bar is
displayed
: For stereo sound
: For stereo sound (when the sound distorts in “High” mode)
“Zoom” (P. 30)
Not available in 1080i (1125i) /
720p (750p) signals.
In PC mode, “Regular” and “Full” can
be selected.
sound
CINEMA SURROUND
Mono
: For mono sound (emulates a stereo-like sound)
Off
: Turns off “Cinema Surround”
Basic operations using the side buttons
2
Volume
Power on
Change
the channel
1
Always return to
the channel you
want to view
RETURN PLUS
Return to the
last channel you
were viewing
RETURN
Registered as return channel
While the channel
is displayed
Hold down
for 3 seconds
Recall the return channel
Current channel Last channel
Cancel
While the channel
is displayed
Hold down
for 3 seconds
19
ENGLISH
ENGLISH
20
IMPORTANT! PREPARE USE
SETTINGS
TROUBLE?
Viewing teletext
This TV can display TV broadcasts and teletext on the same channel in two windows.
1
Enter a teletext page
2
Move up or down a page
up
down
When watching TV
TV
TEXT
TEXT
Hold the
current page
HOLD
Reveal
hidden pages
REVEAL
Hold the current page
Release
Press “ ” again
Display hidden information
(answers to quizzes, etc.)
Bookmark
your favourite
page
LIST MODE
View sub-pages
to
sub-page
Display your
favourites list
1
Select a coloured button to save your page to
(RED) (GREEN) (YELLOW) (BLUE)
2
Enter the number of the page to save
3
Save
4
Recall your favourite page
Press the coloured button as in step 2
.....
Enlarge
the text
SIZE
To the
index page
INDEX
Switch briefly
from teletext
to TV
CANCEL
Double the size of the
displayed text
Returns to page “100”
or a previously designated page
Leave the current page open,
while you switch to watch TV
Useful when running a page search.
21
ENGLISH
ENGLISH
22
Set Up
Set Up
Auto Program
Video-3 Setting
HDMI Setting
Video
Off
PC Position
Teletext Language
Edit/Manual
Video-1 Setting
AI Volume
Language
Video
Video
1
2
3
4
5
Video-1
Video-2
Video-3
HDMI
PC
AV Select
0
01
Set Up
Video
Off
Video
PC Position
Auto Program
Video-3 Setting
HDMI Setting
Teletext Language
Edit/Manual
Video-1 Setting
AI Volume
Language
PC Position
>
>
Set Up
IMPORTANT! PREPARE USE
SETTINGS
TROUBLE?
Watching videos / DVDs
Select the video source
1
1 select
2 watch
Operate the connected device and play a video
2
Operate JVC VCRs and other devices
DVD players
1
VCRs and DVD recorders
2
3
Some models of JVC devices cannot be operated with this remote control.
Turn on the device
Select a channel (VCR mode)
Rewind / Playback / Fast-forward
Stop / Pause
Record / Display DVD top menu
Select a chapter (DVD mode)
Switch between video and component signal
Display the menu bar
1
Select “Set Up”
2
Select “Video-1 Setting” or “Video-3 Setting”
3
Change settings
4
Using S-VIDEO
If both composite and S-VIDEO cables are connected, S-VIDEO will be enable.
1 select
2 next
1 select
1 select
2 set
Video
Component
: For normal
video signal
: For component
video signal
1
Select “Set Up”
2
PC position adjustment
Display the menu bar
Select “PC Position”
1 select
2 next
Shown only when “PC” is selected.
1 adjust
Reset position
1 select
2 next
Component and PC signals does not output from this terminal.
When you are viewing video signal, no signal will output through the S-VIDEO terminal.
HDMI inputs does not output from this terminal.
Using OUT terminal
3
2 set
23
ENGLISH
ENGLISH
24
Try the advanced features
Features
>
Off
Sleep Timer
Sleep Timer
Channel Guard
Appearance
Blue Back
Favourite Setting
Type A
On
Child Lock
On
Auto Shutoff
On
Power Lamp On
Features
Sleep Timer
Channel Guard
Appearance
Blue Back
Favourite Setting
Type A
On
Child Lock
On
Auto Shutoff
On
Power Lamp On
Features
>
Set ID No.
>
>
Channel Guard
01
AV
PR
02
03
04
05
06
07
08
09
CH/C
C
ID
CH
21
CH
22
CH
23
CH
24
CH
25
CC
02
CC
03
CC
04
CC
05
>>
01
AV
PR
02
03
04
05
06
07
CH/CC
ID
CH
21
CH
22
CH
23
CH
24
CH
25
CC
02
CC
03
Channel Guard
IMPORTANT! PREPARE USE
SETTINGS
TROUBLE?
Useful functions
Watch in
multi-picture
mode
MULTI-PICTURE
Select the number
of screens
Selecting “ ” returns to normal viewing mode
Not available in PC mode.
1 select
2 set
Watch in dual-picture mode
E.g. You can watch TV and video at the same time.
(For wide aspect ratio signals)
Main Sub
Main
Sub
Switch between the
sound sources
Change the channel
(Main)
(Sub)
Select a channel in 12-screen mode
All registered channels are displayed as still images.
1 select a
channel
Main
Only the selected frame
has a moving picture.
Move up or down a page
Not available for HDMI input.
2 watch
Current programme
Set a time
for the TV to
turn itself off
SLEEP TIMER
Stop
children from
watching
specific
channels
CHANNEL GUARD
1
2
3
4
Cancel
Remaining time
After steps 1 and 2 above
Set the time to “0” in step 4
You can confirm the remaining time at step
4, after repeating this process.
3
4
5
6
1 select “Features”
2 next
1 select “Sleep Timer”
2 next
1 select a time in minutes
2 set
select
“Channel Guard”
1 enter an “ID No.”
(a secret number of your choice)
2 to the next column
3 set
select a channel to lock
Lock more channels
Repeat steps 5 and 6
Take
snapshots
of the screen
FREEZE
Cancel
Press “ ” again, or change the channel
Still picture
Not available when the SUB-PICTURE is displayed,
or when in PC mode.
You cannot save or export the snapshot.
· Take a snapshot
· View and search in multi-picture mode
· “Sleep Timer” / “Channel Guard”
7
Release a channel
View a locked channel
Press “ ” again in step 6
Use the numerical buttons to enter the channel number.
When n appears, press “ ” and enter your “ID No.”.
(If you forget your “ID No.”, check it in step 4.)
25
ENGLISH
ENGLISH
26
Set 1 - 4?
Programmed!
Favourite 1 - 4?
1
12
>
1
PR 01
2
PR 03
4
PR 07
3
PR
05
Favourite Setting
>
1
PR 01
2
PR 03
4
PR 07
3
Favourite Setting
On
12
12
On
On
IMPORTANT! PREPARE USE
SETTINGS
TROUBLE?
Useful functions
(continued)
Register a
channel to a
button
FAVOURITE
CHANNEL
While the channel
is displayed
1
Hold down
for 3 seconds
Press the number
to register it on
2
Disappears after a
few seconds
Recall the favourite channel
1
Press the number
you registered
2
Customisations (P. 28) to the picture of a
favourite channel get saved as well.
Check your favourite channels
Press “ ” and confirm that the channels you
have registered have a d beside them
Delete a favourite channel
Displays a
blue screen
and mute
the sound
when the
signal is
weak
BLUE BACK
Set the
power to
turn off if
no signal is
received and
no operation
is performed
AUTO
SHUTOFF
“MENU” “ ” “Features” “Blue Back”
1 select
2 set
When the signal is weak
or absent
“MENU” “ ” “Features” “Auto Shutoff”
When no signal is received
and no operation is performed
for about 15 minuites
Displays a blue screen and
mute the sound
1 select
2 set
The power turns off
Off
: Function is
turned off
Off
: Function is
turned off
On
: Displays a
blue screen
On
: Set the power
to turn off
“MENU” “ ” “Features”
“Favourite Setting”
1
delete
2
select
Prevent
sudden in
crease or
decrease of
sound when
changing
channels
“MENU” “ ” “Set Up” “AI Volume”
1 select
2 set
Off
: Function is
turned off
On
: Set to prevent
sudden increase
or decrease of
sound
AI VOLUME
27
ENGLISH
ENGLISH
28
Just the way you like it
Standard
Picture Mode
Standard
Back Light
Features
White Balance
Tint
Colour
Sharp
Bright
Contrast
Cool
Picture Mode
Standard
IMPORTANT! PREPARE USE
SETTINGS
TROUBLE?
Customising your TV
To the previous
screen
Exit
The menu disappears
after one minute of
inactivity.
1
2
3
4
Display the menu bar
Select a menu
1 select
2 next
Select an item
select
Adjust / Configure
1 adjust /
select
2 set
When adjusting
with the sliding-bar
Move
When selecting
from presets
The item will change.
Some items have a
sub-menu.
Sound
Features
Set Up
Items
1 adjust
2 set
1 select
2 set
Selected menu’s title
Menu Item Adjustments / Configurations
Picture Mode
Back Light
Contrast
Bright
Sharp
Colour
Tint
White Balance
Features
Stereo / t · u
Bass
Sound
Treble
Balance
Cinema Surround
Tone Correction
Sleep Timer
Channel Guard
Appearance
Features
Blue Back
Child Lock
Auto Shutoff
Favourite Setting
Power Lamp
Auto Program
Edit / Manual
Language
Video-1 Setting
Set Up
Video-3 Setting
AI Volume
Teletext Language
HDMI Setting
PC Position
Other settings · Change the aspect ratio “ZOOM” (P. 17)
· Turn on “Cinema Surround” “CINEMA SURROUND” (P. 17)
Picture mode (Bright / Standard / Soft)
Backlight brightness (Darker Brighter)
Contrast (Lower Higher)
Brightness (Darker Brighter)
Sharpness (Softer Sharper)
Colour (Lighter Deeper)
Tint (Reddish Greenish) Only NTSC
Colour temperature (Warm / Mid / Cool)
Finer picture adjustments (P. 29)
Mode / Language (v : MONO / s : STEREO / t : SUB1 / u : SUB2 / MONO) (P. 36)
Low tones (Weaker Stronger)
High tones (Weaker Stronger)
Speaker balance (Left Stronger Right Stronger)
Ambience level (High / Low / Mono / Off)
Make the sound more clear (On / Off)
Timer for turning off the TV (P. 24)
Stops children from watching specific channels (P. 24)
Format for displaying the channel number and menu screen.
(Type A / Type B)
Displays a blue screen and mute the sound
when the signal is weak or absent (P. 26)
Disables the front control buttons of the TV
Set the power to turn off if no signal is received and no operation is performed
for about 15 minuites. (P. 26)
Clear favourite channel settings (P. 25)
Lights power lamp (P. 5) while the TV is on (On / Off)
Automatically registers channels (P. 10, ⁄)
Change registered channels or add new ones (P. 11)
Select a language for on-screen menus (P. 10, Ÿ)
For use with video players and other devices (P. 22)
For use with video players and other devices (P. 22)
Prevent sudden increase or decrease of sound when changing channels (P. 26)
Select a language for Teletext programmes (P. 10, !)
HDMI : Size (1 / 2 / Auto)
Audio (Digital / Analogue / Auto)
PC position adjustment (P. 21)
29
ENGLISH
ENGLISH
30
Super DigiPure
Auto
Picture Mode
Standard
Back Light
Features
White Balance
Tint
Colour
Sharp
Bright
Contrast
Cool
>
Super DigiPure
Pull Down
Colour Management
Picture Management
Smart Picture
MPEG Noise Reduction
Off
Auto
On
On
Off
Off
Colour System
Zoom
Features
Auto
>>
Sub
Main
Auto
PAL
Colour System
Auto
Panoramic
Panoramic
14:9 Zoom
16:9 Zoom
16:9 Zoom Subtitle
Full
Zoom
Regular
>
>
Auto
On
On
On
On
IMPORTANT! PREPARE USE
SETTINGS
TROUBLE?
Advanced picture adjustment
By default, the TV automatically adjusts itself for the best picture.
1
Display the menu bar
Super
DigiPure
For
natural-looking
outlines
Off
: Function is
turned off
Min Max Auto
:
When the picture
loses sharpness
: When
noise appears
: Automatically
adjusts
To the previous
screen
Exit
The menu disappears
after one minute of
inactivity.
2
3
4
5
6
Select “Picture”
Select “Features”
Select an item
E.g. “Super DigiPure”
Change settings
E.g. “Super DigiPure”
Finish
1 select
2 next
1 select
2 next
1 select
2 next
select
Pull Down
Colour
Management
Management
Smart
MPEG Noise
Reduction
Colour
System
For smooth
cinema film
For
natural-looking
pictures
Fix
bright / dark
pictures
Fix
brightness of
white areas
To reduce
MPEG video
noise
When
there is no
colour
Off
: Function is
turned off
Off
: Function is
turned off
Off
: Function is
turned off
Off
: Function is
turned off
Off
: Function is
turned off
On Auto
: Function is
always on
On
: Maintain a natural
colour balance
On
: Make it easier to view
bright / dark pictures
On
: Make it easier to view
white areas
On
: When noise appers
: Automatically
adjusts
Not available when
“Picture Mode” is set
to “Bright” (P. 28).
1 Select the screen to change settings on
Main
: Main picture
Sub
: Sub-picture in
MULTI-PICTURE mode (P. 23)
2 Select the colour system
PAL
For colour system in your country or region.
“Colour system in your country or region” (P. 35)
SECAM NTSC 3.58 NTSC 4.43 Auto
· Reduce noise / Watch a more natural picture
· Set the aspect ratio, etc.
Zoom
Change the
aspect ratio
Select a default aspect ratio for Auto in “Zoom” (P. 17)
Panoramic
16 : 9 4 : 3 14 : 9
Regular 14:9 Zoom
31
ENGLISH
ENGLISH
32
When you have trouble
IMPORTANT! PREPARE USE
SETTINGS
TROUBLE?
Troubleshooting
Severe noise or
snow
Is the TV connected correctly to
the aerial?
Change the direction of the aerial.
Is the aerial or its cable
damaged?
Consult your retailer
Patterns, stripes
or noise
Is the aerial receiving interference
from high-voltage power lines or
wireless transmitters?
Consult your retailer
Are connected devices too close
to the TV?
Insert the minimum distance
between the aerial and the
cause of interference until no
interference
I can’t turn it on!
Is the power cord connected to the AC outlet
correctly?
Problem Actions
Remote control
stops working
Basics Screen Picture
Front control buttons
does not work
Aspect ratio changes
unintentionally
PC screen alignment
is off
Poor picture quality
Unplug TV, several minutes later plug it in again.
Switch “Child Lock” to “Off”.
Press “ ” to return to your settings.
Adjust the “PC position”.
Unnatural colour >>> Adjust “Colour” and “Back Light”.
Check your “Colour System”. If “Auto”
is selected, select the specific colour
system manually.
Noise >>> Set to the following functions.
Picture Mode : Standard
Super DigiPure : Max
Dull picture >>> Set to the following functions.
Picture Mode : Bright
Super DigiPure : Min
page
–
28
17
21
28
30
28
30
28
30
Ghosting
(Doubling of images)
Are you receiving interference
from signals reflected off
mountains or buildings?
Adjust the direction of your
aerial, or change to a
good-quality directional aerial
The remote
control doesn’t
work!
Are the batteries flat?
Are you more than 7 meters away
from the TV?
Is the “MODE (VCR / TV / DVD)” set to “TV”?
When viewing teletext, the TV menu bar does not appear.
Depending on the stability of the signal, there may be a time
lag when changing channels.
Strange picture
when using an external
device
Blue screen appears
on the screen
If the top of the image is distorted, check the video signal
quality itself.
If movement appears unnatural when receiving a signal from
a DVD player, etc. with 625p (progressive-scanning), change
the output setting of the external device to 625i (interlacescanning).
Switch “Blue Back” to “Off”.
–
–
26
33
ENGLISH
ENGLISH
34
IMPORTANT! PREPARE USE
SETTINGS
TROUBLE?
Troubleshooting (continued)
Sound
Problem Actions
Adjust the “Bass” and “Treble”.
Poor sound
Wrong screen size 28
No picture, no sound –
No sound
If receiving a poor signal in “Stereo / t·u”, switch to “Mono”.
Adjust the channel reception using “Manual”.
Switch “Size” in “HDMI Setting” to “1” or “2”.
Use the cable marked with HDMI logo.
Check if the device is compliant with HDMI.
Switch “Audio” in “HDMI Setting” to “Digital” or “Auto” for
HDMI devices, or “Analogue” or “Auto” for DVI devices.
page
28
28
11
28
–
Problem Actions
Screen
Black or white dots
appear on the screen
LCD panels use fine dots (“pixels”) to display images.
While more than 99.99% of these pixels function properly,
a very small number of pixels may not light, or may light all
the time.
Please understand that this is not a malfunction.
OUT terminal
No picture, no sound 22
Some inputs does not output from OUT terminal
page
–
Green and distorted
screen
Some functions do not
work
FunctionsHDMI
Some inputs cannot
be selected in the
sub-picture
Wait a little for the signal to stabilize when switching the
signal format for an “HDMI” device.
It is not a malfunction. Some functions (dark background) in
the menu do not work depending on the situation.
“VIDEO-1 (Component signal)”, “VIDEO-3 (Component
signal)”, “HDMI” inputs and PC mode cannot be selected in
the sub-picture.
–
–
–
35
ENGLISH
ENGLISH
36
IMPORTANT! PREPARE USE
SETTINGS
TROUBLE?
Technical information
Group Languages
Group-1 Turkish, Hungarian, English, German, French, Italian, Spanish, Portuguese, Greek, Swedish, Finnish
Group-2
Group-3
Group-4 Arabic, Czech, Slovak. Hungarian, English, German, French, Italian, Spanish, Portuguese, Swedish, Finnish
Group-5 Farsi, Czech, Slovak, Hungarian, English, German, French, Italian, Spanish, Portuguese, Swedish, Finnish
If the characters are unreadable. Select different teletext language group.
Polish, Serbian, Croatian, Slovenian, Czech, Slovak, Rumanian, Hungarian, German, French, Italian, Swedish, Finnish
Russian, Bulgarian, Lettish, Lithuanian, Estonian, Ukrainian, Serbian, Croatian, Slovenian, Czech, Slovak, English, German
Language group for teletext
Colour system in your country or region
Area Country or Region System
Bahrain, Kuwait, Oman, Qatar, United Arab Emirates, Yemen, etc. Indonesia, Malaysia, Singapore,
Thailand, India, etc.
Asia, Middle East
Europe
Oceania
Africa
China, Vietnam, etc.
Hong Kong, etc.
Islamic Republic of Iran, Lebanon, Saudi Arabia, etc.
Philippines, Taiwan, Myanmar, etc.
Russia, etc.
Czech Republic, Poland, etc.
UK, etc.
Australia, New Zealand, etc.
Republic of South Africa, etc.
Nigeria, etc.
Egypt, Morocco, etc.
PAL
SECAM
NTSC
SECAM
PALGermany, Holland, Belgium, etc.
PAL
PAL
SECAM
Monoaural sound
Use this function when stereo sound or bilingual sound is hard to hear.
Set “Stereo / t · u” to “MONO” (P. 28)
PC Signals that can be displayed
*Macintosh* computers are not supported.
(Macintosh is a registered trademark of
Apple Computer, Inc.)
If the signal doesn’t appear, check that the vertical
frequency on the PC is set to “60Hz”.
Resolution
Vertical frequency (Hz) 60.0 60.0
640 x 480 (VGA)
1024 x 768 (XGA)
Connect “DVI” devices
Connect a “DVI“ device to “HDMI” using “DVI-HDMI” conversion cable. Connect analogue sound output of the DVI
device to L and R terminals in IN HDMI.
Set “Audio” in “HDMI Setting” to “Analogue” or “Auto” (P. 28)
Sound system in your country or region
Area Country or Region System
Bahrain, Kuwait, Oman, Qatar, United Arab Emirates, Yemen, etc. Indonesia, Malaysia, Singapore,
Thailand, India, etc.
Asia, Middle East
Europe
Oceania
Africa
China, Vietnam, etc.
Hong Kong, etc.
Islamic Republic of Iran, Lebanon, Saudi Arabia, etc.
Philippines, Taiwan, Myanmar, etc.
Russia, etc.
Czech Republic, Poland, etc.
Germany, Holland, Belgium, etc. B/G
UK, etc.
Australia, New Zealand, etc.
Republic of South Africa, etc.
Nigeria, etc.
Egypt, Morocco, etc.
B/G
D/K
B/G
D/K
B/G
B/G
I
M
I
I
37
ENGLISH
ENGLISH
38
IMPORTANT! PREPARE USE
SETTINGS
TROUBLE?
“CH/CC” List
Specifications
To use the INSERT function (P. 11), find the “CH/CC” number corresponding to the TV’s Channel number from this
table.
US: The US channel numbers are the channel numbers used in the United States, Philippines, etc.
CCIR: The CCIR channel numbers are the channel numbers used in the Middle East, Southeast Asia, etc.
OIRT: The OIRT channel numbers are the channel numbers used in Eastern Europe, Russia, Vietnam, etc.
AUSTRALIA: The AUSTRALIA channel numbers are the channel numbers used in Australia, etc.
CH
CH 02 US-02 E2 R1 AU-0
CH 03 US-03 E3 AU-1
CH 04 US-04 E4 R2 AU-2
CH 05 US-05 E5 R6 AU-6
CH 06 US-06 E6 R7 AU-7
CH 07 US-07 E7 R8 AU-8
CH 08 US-08 E8 R9 AU-9
CH 09 US-09 E9
CH 10 US-10 E10 R10 AU-10
CH 11 US-11 E11 R11 AU-11
CH 12 US-12 E12 R12
CH 13 US-13
CH 14 US-14, W+29
CH 15 US-15, W+30
CH 16 US-16, W+31
CH 17 US-17, W+32
CH 18 US-18, W+33
CH 19 US-19, W+34
CH 20 US-20, W+35
CH 21 US-21, W+36 E21
CH 22 US-22, W+37 E22
CH 23 US-23, W+38 E23
CH 24 US-24, W+39 E24
CH 25 US-25, W+40 E25
CH 26 US-26, W+41 E26
CH 27 US-27, W+42 E27
CH 28 US-28, W+43 E28
CH 29 US-29, W+44 E29
CH 30 US-30, W+45 E30
CH 31 US-31, W+46 E31
CH 32 US-32, W+47 E32
CH 33 US-33, W+48 E33
CH 34 US-34, W+49 E34
CH 35 US-35, W+50 E35
CH 36 US-36, W+51 E36
CH 37 US-37, W+52 E37
CH 38 US-38, W+53 E38
CH 39 US-39, W+54 E39
CH 40 US-40, W+55 E40
CH 41 US-41, W+56 E41
CH 42 US-42, W+57 E42
CH 43 US-43, W+58 E43
CH 44 US-44, W+59 E44
CH 45 US-45, W+60 E45
CH 46 US-46, W+61 E46
CH 47 US-47, W+62 E47
CH 48 US-48, W+63 E48
CH 49 US-49, W+64 E49
CH 50 US-50, W+65 E50
CH 51 US-51, W+66 E51
CH 52 US-52, W+67 E52
CH 53 US-53, W+68 E53
CH 54 US-54, W+69 E54
CH 55 US-55, W+70 E55
CH 56 US-56, W+71 E56
CH 57 US-57, W+72 E57
CH 58 US-58, W+73 E58
CH 59 US-59, W+74 E59
CH 60 US-60, W+75 E60
CH 61 US-61, W+76 E61
CH 62 US-62, W+77 E62
CH 63 US-63, W+78 E63
CH 64 US-64, W+79 E64
CH 65 US-65, W+80 E65
CH 66 US-66, W+81 E66
CH 67 US-67, W+82 E67
CH 68 US-68, W+83 E68
CH 69 US-69, W+84 E69
US CCIR OIRT AUSTRALIA
Channel
CC
CC 01 S-1 AU-5
CC 02 S-2
CC 03 S-3
CC 04 S-4
CC 05 S-5
CC 06 S-6 AU-5A
CC 07 S-7
CC 08 S-8
CC 09 S-9
CC 10 S-10
CC 11 S-11
CC 12 S-12
CC 13 S-13
CC 14 A S-14
CC 15 B S-15
CC 16 C S-16
CC 17 D S-17
CC 18 E S-18
CC 19 F S-19
CC 20 G S-20
CC 21 H S-21
CC 22 I S-22
CC 23 J S-23
CC 24 K S-24
CC 25 L S-25
CC 26 M S-26
CC 27 N S-27
CC 28 O S-28
CC 29 P S-29
CC 30 Q S-30
CC 31 R S-31
CC 32 S S-32
CC 33 T S-33
CC 34 U S-34
CC 35 V S-35
CC 36 W S-36
CC 37 W+1 S-37
CC 38 W+2 S-38
CC 39 W+3 S-39
CC 40 W+4 S-40
CC 41 W+5 S-41
CC 42 W+6
CC 43 W+7
CC 44 W+8
CC 45 W+9
CC 46 W+10
CC 47 W+11
CC 48 W+12
CC 49 W+13
CC 50 W+14
CC 51 W+15
CC 52 W+16
CC 53 W+17
CC 54 W+18
CC 55 W+19
CC 56 W+20
CC 57 W+21
CC 58 W+22
CC 59 W+23
CC 60 W+24
CC 61 W+25
CC 62 W+26
CC 63 W+27
CC 64 W+28
CC 75 X
CC 76 Y R3
CC 77 Z R4 AU-3
CC 78 Z+1 R5
CC 79 Z+2 AU-4
CC 95 A-5
CC 96 A-4
CC 97 A-3
CC 98 A-2
CC 99
US CCIR OIRT AUSTRALIA
A-1
Channel
Main unit
Broadcasting systems B / G / I / D / K / K1 / M (See “Technical information”, P. 35)
Colour systems PAL, SECAM, NTSC 3.58/4.43MHz
Channels and frequencies
Sound-multiplex systems NICAM (I / B / G / D / K), A2 (B / G / D / K)
Teletext systems FLOF (Fastext), WST (standard system)
Power requirements AC 110 V - 240 V, 50/60Hz
Audio output (
Speakers (15 cm x 5.5 cm) oblique x 2 (12 cm x 5 cm) oblique x 2
Power consumption
[standby]
Screen size
(visible area size measured diagonally)
Dimensions (W x H x D: mm)
[without stand]
Weights
[without stand]
Accessories (See “Check accessories”, P. 5)
Model LT-Z32EX6 LT-Z26EX6
VHF low channel (VL) = 46.25 to 140.25 MHz
VHF high channel (VH) = 147.25 to 423.25 MHz
UHF channel (U) = 431.25 to 863.25 MHz
· Receives cable channels in mid band (X to Z+2, S1 to S10), super band (S11 to
S20) and hyper band (S21 to S41).
Rated power output
) 10 W + 10 W
120 W
[0.5 W]
113 W
[0.5 W]
81 cm 66 cm
800 x 588.8 x 267.8
[800 x 545 x 137.7]
17 kg
[15 kg]
672 x 518.5 x 244
[672 x 471 x 137.7]
14 kg
[12 kg]
Terminals / Connectors
Terminal name Terminal type Signal type (IN)
Composite video, S-video,
Analogue component
(576i (625i) / 480i (525i),
Progressive : 576p (625p) / 480p (525p)
HD : 1080i (1125i), 720p (750p)
AUDIO L / R
Composite video, S-video,
AUDIO L / R
Composite video,
Analogue component
(576i (625i) / 480i (525i),
Progressive : 576p (625p) / 480p (525p)
HD : 1080i (1125i), 720p (750p)
AUDIO L / R
HDMI
(576i (625i) / 480i (525i) /
576p (625p) / 480p (525p),
1080i (1125i), 720p (750p))
Input terminals
VIDEO-1
VIDEO-2
VIDEO-3
RCA connectors x 6
S-VIDEO connector x 1
RCA connectors x 3
S-VIDEO connector x 1
RCA connectors x 6
HDMI HDMI connector x 1
IN HDMI RCA connectors x 2 AUDIO L / R
PC INPUT D-SUB (15 pins) x 1 Analogue PC signal (P. 36)
Output
terminals
MONITOR
OUT
Headphone
RCA connectors x 3
S-VIDEO connector x 1
Stereo mini-jack x 1
(3.5 mm in diameter)
We may change the design and specifications without notice.
Signal type (OUT)
,
,
Composite video,
S-video,
Audio L / R
Headphone
output
Notes
Loading...
