JVC 0405AIMMDWJEM, GVT0142-008A User Manual

COMPACT COMPONENT SYSTEM

FS-Y1

Consists of CA-FSY1 and SP-FSY1

INSTRUCTIONS

GVT0142-008A

[B]

Warnings, cautions and others

IMPORTANT for the U.K.

DO NOT cut off the mains plug from this equipment. If the plug

fitted is not suitable for the power points in your home or the cable is too short to reach a power point, then obtain an appropriate safety approved extension lead or consult your dealer.

BE SURE to replace the fuse only with an identical approved type, as originally fitted.

If nonetheless the mains plug is cut off ensure to remove the fuse and dispose of the plug immediately, to avoid a possible shock hazard by inadvertent connection to the mains supply.

If this product is not supplied fitted with a mains plug then follow the instructions given below:

IMPORTANT: DO NOT make any connection to the terminal which is marked

with the letter E or by the safety earth symbol or coloured green or green-and-yellow.

The wires in the mains lead on this product are coloured in accordance with the following code:

Blue: Neutral Brown: Live

As these colours may not correspond with the coloured markings identifying the terminals in your plug proceed as follows:

The wire which is coloured blue must be connected to the terminal which is marked with the letter N or coloured black.

The wire which is coloured brown must be connected to the terminal which is marked with the letter L or coloured red.

IF IN DOUBT - CONSULT A COMPETENT ELECTRICIAN.

CAUTION

To reduce the risk of electrical shocks, fire, etc.:

1. Do not remove screws, covers or cabinet.

2. Do not expose this appliance to rain or moisture.

CAUTION — STANDBY/ON button!

Disconnect the mains plug to shut the power off completely (the STANDBY lamp goes off). The STANDBY/ON not disconnect the mains line.

• When the system is on standby, the STANDBY lamp lights red.

• When the system is turned on, the STANDBY lamp lights green.

The power can be remote controlled.

button in any position does

CAUTION

• Do not block the ventilation openings or holes. (If the ventilation openings or holes are blocked by a newspaper or cloth, etc., the heat may not be able to get out.)

• Do not place any naked flame sources, such as lighted candles, on the apparatus.

• When discarding batteries, environmental problems must be considered and local rules or laws governing the disposal of these batteries must be followed strictly.

• Do not expose this apparatus to rain, moisture, dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.

G-1

IMPORTANT FOR LASER PRODUCTS

1. CLASS 1 LASER PRODUCT

2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave all servicing to qualified service personnel.

3. CAUTION: Visible and invisible laser radiation when open and interlock failed or defeated. Avoid direct exposure to beam.

4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED INSIDE THE UNIT.

Caution: Proper Ventilation

To avoid risk of electric shock and fire, and to prevent damage, locate the apparatus as follows:

1. Front:No obstructions and open spacing.

2. Sides/Top/Back:No obstructions should be placed in the areas shown by the dimensions below.

3. Bottom:Place on the level surface. Maintain an adequate air path for ventilation by placing on a stand with a height of 10 cm or more.

Front view Side view

Wall or obstructions Wall or obstructions

1 cm 1 cm

15 cm

CA-FSY1 CA-FSY1

10 cm

15 cm

G-2

SAFETY INSTRUCTIONS

“SOME DOS AND DON’TS ON THE SAFE USE OF EQUIPMENT”

This equipment has been designed and manufactured to meet international safety standards but, like any electrical equipment, care must be taken if you are to obtain the best results and safety is to be assured.

Do read the operating instructions before you attempt to use the equipment.

Do ensure that all electrical connections (including the mains plug, extension leads and interconnections between pieces of equipment) are properly made and in accordance with the manufacturer’s instructions. Switch off and withdraw the mains plug when making or changing connections.

Do consult your dealer if you are ever in doubt about the installation, operation or safety of your equipment.

Do be careful with glass panels or doors on equipment.

DON’T continue to operate the equipment if you are in any doubt about it working normally, or if it is damaged in any way — switch off, withdraw the mains plug and consult your dealer.

DON’T remove any fixed cover as this may expose dangerous voltages.

DON’T leave equipment switched on when it is unattended unless it is specifically stated that it is designed for unattended operation or has a standby mode. Switch off using the switch on the equipment and make sure that your family know how to do this. Special arrangements may need to be made for infirm or handicapped people.

DON’T use equipment such as personal stereos or radios so that you are distracted from the requirements of traffic safety. It is illegal to watch television whilst driving.

DON’T listen to headphones at high volume as such use can permanently damage your hearing.

DON’T obstruct the ventilation of the equipment, for example with curtains or soft furnishings. Overheating will cause damage and shorten the life of the equipment.

DON’T use makeshift stands and NEVER fix legs with wood screws — to ensure complete safety always fit the manufacturer’s approved stand or legs with the fixings provided according to the instructions.

DON’T allow electrical equipment to be exposed to rain or moisture.

ABOVE ALL

—NEVER let anyone, especially children, push anything into holes, slots or any other opening in the case — this

could result in a fatal electrical shock.;

—NEVER guess or take chances with electrical equipment of any kind — it is better to be safe than sorry!

G-3

E43486-340B

IMPORTANT FOR LASER PRODUCTS

1. CLASS 1 LASER PRODUCT

2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave all servicing to qualified service personnel.

3. CAUTION: Visible and invisible laser radiation when open and interlock failed or defeated. Avoid direct exposure to beam.

4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED INSIDE THE UNIT.

Caution: Proper Ventilation

To avoid risk of electric shock and fire, and to prevent damage, locate the apparatus as follows:

1. Front:No obstructions and open spacing.

2. Sides/Top/Back:No obstructions should be placed in the areas shown by the dimensions below.

3. Bottom:Place on the level surface. Maintain an adequate air path for ventilation by placing on a stand with a height of 10 cm or more.

Front view Side view

Wall or obstructions Wall or obstructions

1 cm 1 cm

15 cm

CA-FSY1 CA-FSY1

10 cm

15 cm

G-2

SAFETY INSTRUCTIONS

“SOME DOS AND DON’TS ON THE SAFE USE OF EQUIPMENT”

Do read the operating instructions before you attempt to use the equipment.

Do consult your dealer if you are ever in doubt about the installation, operation or safety of your equipment.

Do be careful with glass panels or doors on equipment.

DON’T continue to operate the equipment if you are in any doubt about it working normally, or if it is damaged in any way — switch off, withdraw the mains plug and consult your dealer.

DON’T remove any fixed cover as this may expose dangerous voltages.

DON’T use equipment such as personal stereos or radios so that you are distracted from the requirements of traffic safety. It is illegal to watch television whilst driving.

DON’T listen to headphones at high volume as such use can permanently damage your hearing.

DON’T obstruct the ventilation of the equipment, for example with curtains or soft furnishings. Overheating will cause damage and shorten the life of the equipment.

DON’T allow electrical equipment to be exposed to rain or moisture.

ABOVE ALL

—NEVER let anyone, especially children, push anything into holes, slots or any other opening in the case — this

could result in a fatal electrical shock.;

—NEVER guess or take chances with electrical equipment of any kind — it is better to be safe than sorry!

G-3

E43486-340B

Introduction

About discs......................................................3

Description of parts .........................................5

Getting started

Using the remote control .................................6

Putting the batteries in the remote control .......... 6

Operating the TV using the remote control......... 7

Connecting up .................................................8

Basic operations

Playing discs .................................................12

Playback ........................................................... 12

To switch the display ........................................ 13

Select what you want to play by using

the number buttons.................................... 14

To stop playback............................................... 14

To pause playback............................................ 14

To advance picture frame-by-frame.................. 14

Fast reverse/Fast forward search ..................... 14

Playing back from a position 10 seconds

before (One Touch Replay) ....................... 15

Slow Motion Playback....................................... 15

Skip to the beginning of the selection ............... 15

To change the brightness of

the display window (DIMMER) .................. 16

Adjusting the volume ........................................ 16

Adjusting sound quality..................................... 16

Turning off the sound temporarily (MUTING) ... 16

Functions specific to DVD AUDIO.................27

Playing the Bonus Group...................................27

Browsable Still Pictures (B.S.P.) .......................27

Using the menu bar ....................................... 28

Preferences................................................... 29

Country/Area codes.......................................31

Listening to radio

Listening to a radio broadcast .......................32

Tuning in to a preset station .......................... 33

Using the RDS...............................................34

Using the RDS (Radio Data System) when

receiving FM stations...................................34

Convenient functions

Listening to the sound of other audio device

Setting the various timer................................38

Setting the built-in clock.....................................38

Setting the daily timer ........................................38

Auto Standby .....................................................39

Sleep Timer .......................................................40

Tray Lock.......................................................40

....38

Reference

Troubleshooting.............................................41

Language codes............................................ 42

Specifications ................................................43

Advanced operations

Playing audio/video files................................16

Resume Playback .........................................18

Select the scene to be played .......................19

Program Playback/Random Playback...........20

Repeat Playback ...........................................22

Other convenient functions............................24

Selecting the subtitles ....................................... 24

Selecting the audio language ........................... 24

Selecting a view angle...................................... 24

Enlarging the picture (ZOOM)........................... 25

Adjusting the picture quality (VFP) ................... 25

Creating realistic sound (3D PHONIC)............. 26

Adjusting playback level (DVD LEVEL) ............ 26

Enjoying better pictures (SCAN MODE) ........... 26

How to read this manual

• Operations are described by mainly using the remote control buttons. If there are the same marks on the main unit, the buttons on the main unit can also be used.

• The following marks tell you for which type of the discs the operation can be made.

• The illustrations and TV screens may be different between the actual case and the description.

• “VCD” is an abbreviation of “Video CD”.

• “SVCD” is an abbreviation of “Super Video CD”.

Special cautions

Notes on handling

7 Important cautions

Installation of the system

• Select a place which is level, dry and neither too hot nor too cold; between 5°C and 35°C.

• Leave sufficient distance between the system and the TV.

• Do not use the system in a place subject to vibration.

Power cord

• Do not handle the power cord with wet hands.

• A small amount of power is always consumed while the power cord is connected to the wall outlet.

• When unplugging the power cord from the wall outlet, always pull on the plug, not the power cord.

To prevent malfunctions of the system

• There are no user-serviceable parts inside. If anything goes wrong, unplug the power cord and consult your dealer.

• Do not insert any metallic object into the system.

• Do not use any non-standard shape disc (like a heart, flower or credit card, etc.) available on the market, because it may damage the system.

• Do not use a disc with tape, stickers, or paste on it, because it may damage the system.

Label sticker

Sticker

Note about copyright laws

Check the copyright laws in your country before recording from DVDs, VCDs, SVCDs, and CDs. Recording of copyrighted material may infringe copyright laws.

Note about copy guard system

DVDs are protected by copy guard system. When you connect the system to your VCR directly, the copy guard system activates and the picture may not be played back correctly.

7 Safety precautions

Avoid moisture, water and dust

Do not place the system in moist or dusty places.

Avoid high temperatures

Do not expose the system to direct sunlight and do not place it near a heating device.

When you are away

When away on travel or for other reasons for an extended period of time, disconnect the power cord plug from the wall outlet.

Do not block the vents

Blocking the vents may damage the system.

Paste

Care of the cabinet

When cleaning the system, use a soft cloth and follow the relevant instructions on the use of chemically-coated cloths. Do not use benzene, thinner or other organic solvents including disinfectants. These may cause deformation or discoloring.

If water gets inside the system

Turn the system off and disconnect the power cord plug from the wall outlet, then call the store where you made your purchase. Using the system in this condition may cause fire or electrical shock.

7 When condensation or water drops adhere to the

lens

In any of the following cases, condensation or water drops may adhere to the lens to prevent the system from working properly:

• Immediately after starting to heat the room

• When the system is installed in a steamy or damp space

• When the system is suddenly moved from a cold place to a warm space

In any of these cases, leave the system turned on for 1 or 2 hours before use.

Supplied accessories

Check to be sure you have all of the supplied accessories. The number in parentheses is the quantity of the pieces supplied. If anything is missing, contact your dealer immediately.

• Remote control (1)

• Batteries (2)

• FM antenna (1)

• AM loop antenna (1)

• Power cord (1)

• Composite video cord (1)

• Speaker cords (2)

• Manufactured under license from Dolby Laboratories. “Dolby”, “Pro Logic”, “MLP Lossless”, and the double-D symbol are trademarks of Dolby Laboratories.

• “DTS” and “DTS 2.0+DIGITAL OUT” are registered trademarks of Digital Theater Systems, Inc.

• This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

About discs

Playable disc types

This system has been designed to play back the following discs:

DVD VIDEO, DV D AUDIO, VC D, SVCD, CD This system can also play back the following discs:

• Finalized DVD-R/-RW discs recorded in the DVD VIDEO format.

• CD-R/RW discs recorded in the following formats

• Music CDs (finalized discs)

• VCDs

• SVCDs

• MP3/WMA/JPEG discs recorded in ISO 9660 (for

details, refer to “Notes on CD-R and CD-RW ”)

However, some discs may not be played back because of their disc characteristics, recording conditions, or damage or stain on them. Only sounds can be played back from the following discs:

MIX-MODE CD CD-G CD-EXTRA CD TEXT

Discs you can play:

Disc

Type

Mark (Logo)

DVD

VIDEO

DVD

AUDIO

VCD PAL

SVCD PAL

CD —

CD-R —

CD-RW —

Video

Format

PA L

—

Introduction

* Note on Region Code

DVD players and DVD VIDEOs have their own Region Code numbers. This system can only play back a DVD VIDEO recorded with the Region Code number and video format mentioned below. For your available Region Code, check the rear panel of your main unit. This system can play back only DVD VIDEOs whose Region Code numbers include “2”.

Examples:

If a DVD VIDEO with an improper Region Code number is loaded, “REGION CODE ERROR!” appears on the TV screen and playback cannot start.

• On some DVD VIDEOs, DVD AUDIOs, VCDs or SVCDs, their actual operation may be different from what is explained in this manual. This is due to the disc programming and disc structure, not a malfunction of this system.

Notes on DVD-R and DVD-RW

• This system can also play finalized DVD-Rs or DVDRWs recorded in DVD-Video format.

Notes on CD-R and CD-RW

• This system can also play CD-Rs or CD-RWs if MP3, WMA, and JPEG files are recorded on them with ISO 9660 format.

• This system supports “multi-session” discs (up to 20 sessions).

• This system cannot play “packet write” (UDF format) discs. Some discs may not be played back because of their disc characteristics, recording conditions, or damage or stain on them.

Discs that cannot be played back

• The following discs cannot be played back: DVD-ROM, DVD-RAM, DVD-R/-RW (recorded in VR

format), CD-ROM, CD-I (CD-I Ready), Photo CD, SACD, etc. Playing back these discs will generate noise and damage the speakers.

Damaged discs and discs in an extraordinary shape (other than a disc of 12 cm or 8 cm) cannot be played back.

Caution for DualDisc playback

The non-DVD side of a “DualDisc” does not comply with the “Compact Disc Digital Audio” standard. Therefore, the use of Non-DVD side of a DualDisc on this product may not be recommended.

is a trademark of DVD Format/Logo

Licensing Corporation.

About discs (continued)

Notes on all files

• The system can only recognize and play files with one of the following extensions, which can be in any combination of upper and lower case;

• MP3: “.MP3”, “.mp3”

• WMA: “.WMA” , “.wma”

• JPEG: “.JPG”, “.JPEG”, “.jpg”, “.jpeg”

• If a character other than single byte English characters is used in the file name of an MP3/WMA/JPEG file, the track/file name will not be displayed correctly.

• The system recognizes up to 150 tracks (files) per group, 99 groups per disc, and the total number of the tracks (files) that the system can play is 1 000.

• Some files may not be played back normally because of their disc characteristics or recording conditions.

For MP3/WMA files

• An off-the-shelf MP3 disc may be played in an order different from that indicated on the label attached to the disc.

• The system supports MP3/WMA files recorded with a bit rate of 32 – 320 kbps and a sampling frequency of 16 kHz, 22.05 kHz, 24 kHz (WMA only), 32 kHz, 44.1 kHz, or 48 kHz.

• If the tag information (album name, artist, and track title, etc.) is recorded on a disc, it appears in the file control display on the TV screen.

• We recommend to record each piece of material (song) at a sample rate of 44.1 kHz and at a data transfer rate of 128 (96 for WMA only) kbps.

• This system cannot play back files encoded with Multiple Bit Rate (MBR). (MBR is a format to encode a file content at several different bit rates.)

For JPEG files

• We recommend to record a file at 640 x 480 resolution.

• This system can play a baseline JPEG file, excluding monochromatic JPEG files.

• This system can play JPEG data taken with a digital camera conforming to the DCF (Design Rule for Camera File System) standard (when a function is applied such as the automatic rotation function of a digital camera, data goes beyond the DCF standard, so the image may not be displayed).

• If data has been processed, edited and restored with PC image editing software, the data may not be displayed.

• This system cannot play animations such as MOTION JPEG, or still images (TIFF etc.) other than JPEG, and image data with sound.

• An image with a resolution of more than 8 192 x 7 680 pixels cannot be displayed.

Disc structure

DVD VIDEO

A DVD VIDEO consists of “titles” and each title may be divided into “chapters”.

Title 1 Title 2

Chapter 1 Chapter 2 Chapter 3 Chapter 1 Chapter 2

DVD AUDIO

A DVD AUDIO consists of “groups” and each group may be divided into “tracks”. Some discs include a “bonus group” that requires a password for playing (page 27).

Group 1 Group 2

Track 1 Track 2 Track 3 Track 1 Track 2

VCD/SVCD/CD

VCD, SVCD and CD consist of “tracks”. In general, each track has its own track number. (On some discs, each track may also be further divided by indexes.)

Track 1 Track 2 Track 3 Track 4 Track 5

MP3/WMA [JPEG] discs

On an MP3/WMA [JPEG] disc, each still picture (material) is recorded as a track [file]. Tracks [Files] are usually grouped into a folder. Folders can also include other folders, creating hierarchical folder layers.

This unit simplifies the hierarchical construction of a disc and manages folders by “groups”.

Group 1 Group 2

Track 1

[File 1]

Track 2

[File 2]

Group 3 Group 4 Group 5

This product can recognize up to 1 000 tracks [files] in a disc. Also, the product can recognize up to 150 tracks [files] per group and up to 99 groups in a disc. Since the unit ignores the tracks [files] whose numbers are exceeding 150 and the groups whose numbers are exceeding 99, they cannot be played back.

• If there is any type of files other than MP3/WMA [JPEG] files in a folder, those files are also counted in the total file number.

Description of parts

The numbers represent the page numbers.

Front panel

Introduction

See “Display window” below.

Top of the unit

DIMMER 3D PHONICBASS/TREBLE

16 16

16 12 11

In the door

* Connect headphones (not supplied) with a stereo mini plug. If the headphones are connected, the

speakers and subwoofer will not produce any sound.

PHONES

32 32

15 14

PLAY

AM A UXFM

MULTI CONTROL UPDOWN

PAUSE

Display window

18 26 27 27 13

PRGM. AL L SLEEP AHB PRO 3D PHONICA. STANDBYA-B 12 31RANDOM

Rear panel

RESUME

21 17, 22 38 40 39 34, 3632 26

AM EXT AM LOOP

AUX

FM75

PCM/

COAXIAL

STREAM

ANTENNA

DVD OPTICAL

DIGITAL OUT

SUB-

WOOFER

OUT

COMPONENT

YPBP

Ω

BONUS B.S.P.ST AUTO RDS TA NEWS INFOPROGRESSIVESVCDVD-A

SPEAKERS

VIDEO

VIDEO OUT

CAUTION:

SPEAKER IMPEDANCE

4Ω-16Ω

S-VIDEO

These holes discharge heat generated inside the unit.

Do not cover up these holes.

11 11

Using the remote control

The numbers represent the page numbers.

13, 16 12

Putting the batteries in the remote control

15, 17

15, 32

19, 28

29 24

27 38, 39 38, 39

16 35, 36

FM AM

PTY SELECT PTY SEARCH TA/News/Info

RDS

DISPLAY

16 7, 13,

14, 16 16

15, 32

12, 17

14 19

28 24

25, 26

7, 15

Batteries

If the range or effectiveness of the remote control decreases, replace the batteries. Use two R6 (SUM-3)/AA(15F) type dry-cell batteries.

CAUTION

•Do

not use a used battery and a new battery

together.

• Do not use different types of batteries at the same time.

• Take out the batteries if the remote control is not to be used for a long time. Otherwise it may cause a leakage.

Remote control operation

When operating the remote control, point it towards the front panel of the main unit. If the remote control is operated from a direction that is extremely oblique or when there is an obstacle in the way, signals may not be transmitted.

If the remote control sensor is exposed to a strong light such as direct sunlight, correct operation may not be carried out.

Introduction

Getting started

This page is for when operating your TV using the remote control of this product.

Operating the TV using the remote control

Manufacturer

JVC 01 Nordmende

Akai 02, 05 Okano 09 Blaupunkt 03 Orion 15 Daewoo 10, 31, 32 Panasonic 16, 17 Fenner 04, 31, 32 Philips 10

Fisher 05 Saba

Grundig 06 Sanyo 05 Hitachi 07, 08 Schneider 02, 05 Inno-Hit 09 Sharp 20 Irradio 02, 05 Sony 21 – 25

Magnavox 10 Telefunken

Mitsubishi 11, 33 Thomson

Miver 03 Toshiba 29 Nokia 12, 34

NOTE

Manufacturer’s codes may be changed without notice. You may not be able to operate a TV produced by the manufacturer shown above.

Code

Manufacturer

Code

13, 14, 18, 26 – 28

13, 14, 18, 26–28, 30

5 Release TV.

For TV operation

Setting the manufacturer's code

1 Slide the remote control mode

selector to the TV side.

2 Keep pressing down TV.

NOTE

Keep pressing down TV until Step 4 is complete.

3 Press ENTER. 4 Press number buttons (1-9, 0).

Ex.:

For a Hitachi TV: Press 0, then 7. For a Toshiba TV: Press 2, then 9.

If there are more than one manufacturer’s codes, try them in turn and select the one that causes the product to work properly.

Operate the remote control by pointing it towards the TV.

Turn ON/OFF the power.

Change channels.

Adjust volume.

100+

Alternates between the previously selected channel and the current channel.

Switch TV and video input.

*1 Make sure to slide the remote control mode

selector to the TV side in advance.

NOTE

When the batteries are replaced, perform the manufacturer's code setting again.

Select channels.

)

Connecting up

–

Do not turn on the power until the connection is complete

Connecting antennas

–

Connection

onnecting AM loop antenna (supplied

1 Set up the AM loop antenna.

Connecting FM antenna (supplied)

Main unit

(rear panel)

FM antenna

FM75Ω

COAXIAL

Put the antenna up straight in the direction where the best radio reception can be obtained, and fix by using tape.

2 Connect antenna cords.

Main unit

(rear panel)

AM EXT AM LOOP

How to insert antenna cords

Connect two antenna cords as described above.

If the antenna cord is covered with vinyl on the tip, twist and pull the vinyl off and remove.

7 When good radio reception cannot be

obtained with the supplied antenna or when using a communal antenna

3 Turn the AM loop antenna to the direction of the

best radio reception. Locate the AM loop antenna as far away from the main unit as possible.

• Do not locate the AM loop antenna on a metallic table or close to a TV, personal computer, etc. Otherwise it may result in bad radio reception.

7 When good radio reception cannot be

obtained with the supplied AM loop antenna

Electric wire: 3 - 5 m (commercially available)

Electric wire

Twist

AM loop antenna

AM EXT AM LOOP

Main unit

(rear panel)

Put up an electric wire extending horizontally, preferably at a high place such as above a window or outdoors.

Connect the AM loop antenna cords together.

Communal antenna terminal

Outdoor FM antenna (commercially available)

Coaxial cable (commercially available)

Main unit

(rear panel)

FM75Ω

COAXIAL

Antenna cord (not supplied)

Converter (sold separately: compatible with 300 Ω/ 75 Ω)

Depending on the radio reception conditions, an FM feeder antenna (sold separately: compatible with 300 Ω) can be used. In the case, a converter (not supplied) is required.

For details of connecting a separately sold antenna, refer to the user guide for the antenna or converter.

When positioning the antenna, listen to an actual radio program (refer to “Listening to a radio broadcast” on page 32).

Connecting up Connection

Getting started

Connecting speakers

There is no difference between the left and right speakers.

Speaker terminal

Speaker cord

Without

black line

With black

line

Right speaker

(rear panel)

(supplied)

SPEAKERS

Main unit

(rear panel)

Speaker cord (supplied)

Without black line

Left speaker

(rear panel)

CAUTION

• DO NOT connect more than one speaker to one speaker terminal.

• The speakers of this product are magnetically shielded, but color irregularities may occur on the TV depending on how the speakers are installed. Keep in mind the following.

1. Turn off the main power of your TV before

installing the speakers. Wait for about 30 minutes before turning on the TV again.

2. If color irregularity occurs in pictures, keep a

distance of more than 10 cm between the TV and the speakers.

With black line

NOTE

• Impedance of speaker that can be connected to the main unit is within a range of 4

• In order to have a sufficient cooling effect, leave a space of more than 1 cm between the main unit and the speakers or other objects.

Speaker grille can be detached.

Ω

to 16 Ω.

Speaker grille

+ 35 hidden pages

JVC 0405AIMMDWJEM, GVT0142-008A User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

INSTRUCTIONS

Warnings, cautions and others

Table of contents

Special cautions

About discs

Description of parts

Using the remote control
