JVC LCT1823-001A-A, 0305TNH-II-IM User Manual

Plasma Display Users Guide

For Model: PD-42X776

Illustration of PD-42X776 and RM-C14G

Important Note:

In the spaces below, enter the model and serial number of your television (located at the rear of the television cabinet). Staple your sales receipt or invoice to the inside cover of this guide. Keep this user’s guide in a convenient place for future reference. Keep the carton and original packaging for future use.

Model Number:

Serial Number:

LCT1823-001A-A

0305TNH-II-IM

Important Safety Precautions

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: To reduce the risk of electric shock. Do not

remove cover (or back). No user serviceable parts inside. Refer servicing to qualified service personnel.

The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

WARNING: TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS TV SET

TO RAIN OR MOISTURE.

CAUTION: TO INSURE PERSONAL SAFETY, OBSERVE THE FOLLOWING RULES

REGARDING THE USE OF THIS UNIT.

1. Operate only from the power source specified on the unit.

2. Avoid damaging the AC plug and power cord.

3. Avoid Improper installation and never position the unit where good ventilation is unattainable.

4. Do not allow objects or liquid into the cabinet openings.

5. In the event of trouble, unplug the unit and call a service technician. Do not attempt to repair it yourself or remove the rear cover.

Changes or modifications not approved by JVC could void the warranty.

* When you don’t use this TV set for a long period of time, be sure to disconnect both the

power plug from the AC outlet and antenna for your safety.

* To prevent electric shock do not use this polarized plug with an extension cord, receptacle or

other outlet unless the blades can be fully inserted to prevent blade exposure.

This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.

IMPORTANT SAFETY INSTRUCTIONS

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus

(including amplifiers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has

two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10) Protect the power cord from being walked on or pinched particularly at plugs, convenience

receptacles, and the point where they exit from the apparatus.

11) Only use attachments/accessories specified by the manufacturer.

12) Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with

the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13) Unplug this apparatus during lightning storms or when unused for long periods of time.

14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has

been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

15) Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on the apparatus.

16) Avoid improper installation and never position the unit where good ventilation is impossible. When

installing this TV, distance recommendations must be maintained between the set and the wall, as well as inside a tightly enclosed area or piece of furniture. Keep to the minimum distance guidelines shown for safe operation.

8 inch/200 mm

6 inch/150 mm

POWER

2 inch/50 mm

6 inch/150 mm

2 inch/50 mm

17) Cautions for installation

— Do not tilt the TV towards the left or right, or towards the back.

— Install the TV in a corner on the floor so as to keep cords out of the way. — The TV will generate a slight amount of heat during operation. Ensure that sufficient space is

available around the TV to allow satisfactory cooling.

FCC Notice:

Note: This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

– Reorient or relocate the receiving antenna.

– Increase the separation between the equipment and receiver.

– Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

– Consult the dealer or an experienced radio/TV technician for help.

Warnings

Screen Burn-in

A characteristic of Plasma Display Panels (PDPs) is that displaying the same image for a long time causes a part of the image to stay on the screen (this is called phosphor burn-in).

Avoid burn-in as follows.

IMAGE SHIFT

The picture displayed on the screen is shifted up, down and to the left and right at regular intervals. In order to prevent burn-in, set this function to FAST or STD. (Refer to page 47.) Even if the IMAGE SHIFT function is turned off, the picture will shift to the left or right when the channel or input is changed. This is only when the ASPECT function is in REGULAR mode.

VIDEO STATUS

The VIDEO STATUS function is initially set to DYNAMIC. Unless the TV is being watched in an extremely bright room, it is recommended to change the VIDEO STATUS setting to standard, theater or game. Doing so will reduce the chance of PDP burn-in and extend the life of the PDP. (Refer to page 66).

❑ Do not display static images or characters for long periods of time.

TV on

XYZ XYZ

For example...

• Reduce PICTURE and BRIGHT on the PICTURE ADJUST menu (page 56) when viewing.

❑ Do not view for long periods of time in the REGULAR mode (page 70).

Screen size is normally chosen to ensure that the picture is displayed on the entire screen. After viewing in the REGULAR mode in which black bands may occur at the left and right of the screen, it is recommended to change to the PANORAMA mode to display the picture on the entire screen.

TV on

For example...

❑ Do not view for long periods of time using the TWIN function (page 62) or INDEX

function (page 62).

TV off

Warnings

If Burn-in has occurred

If burn-in occurs, try the BURN-IN IMAGE REDUCER function (page 58). If burn-in is minimal it may gradually become less noticeable.

Note: Once burn-in occurs it will never disappear completely.

Point defects

PDPs use collections of fine pixels to display images. While there is no problem with more than

99.99% of these pixels, please understand that a very small number of pixels may not light or

may light all the time.

Do not install the TV near electronic equipment that is susceptible to electromagnetic waves

It may cause interference in images, sound, etc. In particular, keep video equipment away from this product.

Effect on infrared devices

There may be interference while using infrared devices such as infrared cordless headphones.

The phenomenon described below is not a malfunction.

If the television is used at a location above an altitude of 2,000 m, a buzzing noise and image distortion may occur. This phenomenon is peculiar to PDP (Plasma Display Panel), and could occur with any television using PDP. It is not a malfunction.

Caring for the Cabinet

Normally, light dusting with a soft, non-scratching duster will keep your TV clean.

If you wish to wipe down the television, first unplug it. Then wipe gently with a soft cloth, slightly moistened with water. You can add a few drops of mild liquid detergent to the water to help remove spots of oily dirt.

DO NOT allow liquid to enter the TV through the ventilation slots.

DO NOT use strong or abrasive cleaners on the TV.

DO NOT spray liquids or cleaners directly on the TV’s surface.

DO NOT rub or scrub the TV harshly. Wipe the set gently with a soft cloth.

Caring for the Screen

When it gets dirty, wipe it gently with a soft cloth.

Do not apply alcohol, organic solvents (like acetone), acidic or alkaline cleansers to the screen. These will remove the coating layer and cause discolorations.

Table of Contents

Important Safety Precautions . 2

Warnings . . . . . . . . . . . . 5

Quick Setup . . . . . . . . . . . 9

Unpacking your TV . . . . . . . . . . . . 9

TV Models . . . . . . . . . . . . . . . . 10

TV Remote Control . . . . . . . . . . . 11

Getting Started . . . . . . . . . . . . . 12

The Remote Control . . . . . . . . . . 13

Connecting Your Devices . . . . . . . 14

Interactive Plug In Menu . . . . . . . . 27

Remote Programming . . . . . 30

Setting CATV, VCR and DVD Codes . . . 30

CATV or Satellite Codes . . . . . . . . 30

VCR Codes . . . . . . . . . . . . . . 31

DVD Codes . . . . . . . . . . . . . . 32

Search Codes . . . . . . . . . . . . . 33

Onscreen Menus . . . . . . . . 34

Using the Guide . . . . . . . . . . . . . 34

Onscreen Menu System . . . . . . . . . 35

Initial Setup . . . . . . . . . . 37

Auto Tuner Setup . . . . . . . . . . . . 37

Channel Summary . . . . . . . . . . . . 38

V-Chip . . . . . . . . . . . . . . . . . . 40

Set Lock Code . . . . . . . . . . . . . 46

Auto Demo . . . . . . . . . . . . . . . 47

Image Shift . . . . . . . . . . . . . 47

Language . . . . . . . . . . . . . . . . 47

Closed Caption . . . . . . . . . . . . . 48

Auto Shut Off . . . . . . . . . . . . . . 50

XDS ID . . . . . . . . . . . . . . . . . 50

Noise Muting . . . . . . . . . . . . . . 51

Front Panel Lock . . . . . . . . . . . . 51

V1 Smart Input . . . . . . . . . . . 52

Video Input Label . . . . . . . . . . 52

Position Adjustment . . . . . . . . . . . 53

Power Indicator . . . . . . . . . . . . . 53

Video-1 Monitor Out . . . . . . . . . . 53

TV Speaker . . . . . . . . . . . . 54

Audio Out . . . . . . . . . . . . . . 54

Digital-In . . . . . . . . . . . . . . . . . 54

Digital-In Audio . . . . . . . . . . . . . 55

Center CH Input . . . . . . . . . . . . . 55

Picture Adjust . . . . . . . . . 56

Picture Settings . . . . . . . . . . . . . 56

Adjust Picture Settings . . . . . . . . . 56

Color Temperature . . . . . . . . . . . . 56

Digital Noise Clear . . . . . . . . . . . . 57

Color Management . . . . . . . . . . 57

Dynamic Gamma . . . . . . . . . . 57

Burn-In Image Reducer . . . . . . . . 58

Reset . . . . . . . . . . . . . . . . . . 58

Sound Adjust . . . . . . . . . 59

Sound Settings . . . . . . . . . . . . . 59

Adjust Sound Settings . . . . . . . . . 59

Reset . . . . . . . . . . . . . . . . 59

Clock Timers . . . . . . . . . . 60

Set Clock . . . . . . . . . . . . . . . . 60

On/Off Timer . . . . . . . . . . . . . . . 61

Button Functions . . . . . . . 62

Multi Screen Function . . . . . . . . . . 62

Index . . . . . . . . . . . . . . . . . . 62

Twin . . . . . . . . . . . . . . . . . 62

Freeze . . . . . . . . . . . . . . . . . . 63

Swap . . . . . . . . . . . . . . . . . 63

Select . . . . . . . . . . . . . . . . . . 63

Power . . . . . . . . . . . . . . . . . . 64

Number Buttons . . . . . . . . . . . . . 64

Tune . . . . . . . . . . . . . . . 64

Input . . . . . . . . . . . . . . . . . . . 64

TheaterPro D6500K . . . . . . . . . . . 64

Return+/TV . . . . . . . . . . . . . . . 65

Sound . . . . . . . . . . . . . . . . . . 65

Muting . . . . . . . . . . . . . . . . . . 66

Video Status . . . . . . . . . . . . . . . 66

Sleep Timer . . . . . . . . . . . . . . . 67

ML/MTS . . . . . . . . . . . . . . . . . 67

Display . . . . . . . . . . . . . . . . . 68

C.C. . . . . . . . . . . . . . . . . . . . 68

Channel +/- . . . . . . . . . . . . . 68

Volume +/- . . . . . . . . . . . . . 68

Favorite . . . . . . . . . . . . . . . . . 69

Aspect . . . . . . . . . . . . . . . . . 70

Aspect Ratios . . . . . . . . . . . . . 70

Menu . . . . . . . . . . . . . . . . . . 71

OK . . . . . . . . . . . . . . . . . . . 71

Back . . . . . . . . . . . . . . . . . . . 71

TV/CATV Slide Switch . . . . . . . . . . 72

VCR/DVD Slide Switch . . . . . . . . . 72

VCR Buttons . . . . . . . . . . . . . . . 72

DVD Buttons . . . . . . . . . . . . . . . 72

Light . . . . . . . . . . . . . . . . . . . 72

Table of Contents

Digital Setup . . . . . . . . . 73

Digital Setup . . . . . . . . . . . . . 73

Antenna Level . . . . . . . . . . . . . 73

Digital Sound . . . . . . . . . . . . . 74

Aspect Ratio . . . . . . . . . . . . . 74

Cable Card Application . . . . . . . . . 75

i.LINK Auto Play . . . . . . . . . . . 75

Software Update . . . . . . . . . . . 75

Digital Button Functions . . . 76

Digital CH D/A (Digital/Analog) . . . . . 76

Sub Channel . . . . . . . . . . . . . 76

i.LINK Menu . . . . . . . . . . . . . . . 77

Controller . . . . . . . . . . . . . 77

Device . . . . . . . . . . . . . . 78

Timer . . . . . . . . . . . . . . . 79

Reservation . . . . . . . . . . . . . . 79

Timer Edit . . . . . . . . . . . . . . 80

Guide . . . . . . . . . . . . . . . 81

OSD Information . . . . . . 82

Weak Signal . . . . . . . . . . . . . 82

No Program . . . . . . . . . . . . . 8

Cable Card Information . . . . 83

Cable Card Connection . . . . . . . . 83

Appendices . . . . . . . . . . 84

Troubleshooting . . . . . . . . . . . . . 84

Warranty . . . . . . . . . . . . . . 86

Specifications . . . . . . . . . . . . . 88

Notes . . . . . . . . . . . . . . . . . 89

Quick Setup Unpacking your TV

Thank you for your purchase of a JVC Color Television. Before you begin setting up your new television, please check to make sure you have all of the following items.

POWER

CATV VCR DVD

ASPECT

MULTI SCREEN

INDEX

SELECT

TWIN

SLEEP

FREEZE

SWAP

ML/MTS

DISPLAY

INPUT

123

D/A

456

i.LINK MENU

789

RETURN+

TIMER

TUNE

THEATER

VIDEO

SUB

FAVORITE

CHANNEL

PRO

STATUS

SUB

NATURAL CINEMA

SOUND

LIGHT

C.C.

MUTING

GUIDE

VOL VOL

POWER PROGRAM/LED

AA/R06-size batteries

(used to check

operation)

RF Cable × 2

BACK

VCR CHANNEL

VCR DVD

PREV NEXT

POWER

TV VCR

REW

FFPLAY

REC PAUSE

STOP

OPEN CLOSE

STILL PAUSE

RM-C14G

Remote control

2-WAY SPLITTER

Two Way Splitter x 1

Power cord

Quick Setup TV Models

CHANNEL

VOLUME

INPUT

POWER

Note: Before you connect your TV to another device, please refer to the proper diagrams for

your specific TV and remote.

Front

POWER PROGRAM/LED

POWER button

POWER

PC INPUT

CHANNELVOLUME

OPERATE

S-VIDEO VIDEO

OVER

L/MONO-AUDIO-R

INPUT

INPUT-4

Upgrade use only This SD card is used only for upgrade.

You can't use this for other purposes.

POWER

Rear

AUDIO

(ANALOG)

R L

R AUDIO L VIDEO

Pr Pb Y

CENTER CHANNEL INPUT

INPUT-2

INPUT-1

INPUT-3

R AUDIO L VIDEO

• AUDIO IN (ANALOG) and CENTER CHANNEL INPUT are for DVI.

Underneath

OPTICAL OUT

i.LINK IN/OUT

S400 (TS)

Digital Audio

U.S. Patent Nos. 4,631,603 ; 4,577,216; 4,819,098 ; 4,907,093 ; and 6,516,132.

CABLE CARD

VIDEO

DIGITAL

HDMI

ATSC /DIGITAL CABLE IN

AUDIO

AV COMPULINK

Licenced by BBE Sound, Inc.under USP4638258, 5510752 and 5736897. BBE and BBE symbol are registered trademarks of BBE Sound, Inc.

Sous licence de BBE Sound, Inc., sous les brevets USP4638258, 5510752 et 5736897. BBE et le symbole BBE sont des marques déposées de BBE Sound, Inc.

Licenciado de BBE Sound, Inc. sobre el numero USP4638258. 5510752 y 5736897. BBE y el simbolo de BBE son marcas registradas de BBE Sound, Inc.

Manufactured under license from Dolby Laboratories. "Dolby" and the double-D symbol are trademarks of Dolby Laboratories.

OVER

S-VIDEO

MONITOR/ REC OUT

Pr Pb Y

When the rear cover is removed, follow "CAUTION AT DISASSEMBLY" procedure in the service manual before plugging the TV's power cord into an AC outlet. Failure to follow the procedure will result in PERMANENT damage to some of the television features.

DÉBRANCHEZ LE CORDON DE LA PRISE DE COURANT C. A. AVANT DE RETIRER LE COUVERCLE ARRIÈRE.

Une fois le couvercle arrière déposé suivez la procédure « ATTENTION LORS DU DÉMONTAGE » décrite dans la manuel de service avant de brancher

75Ω

le cordon du téléviseur dans une prise c.a.

(VHF/UHF)

L'omission de suivre la procédure causera des dommages PERMANENTS à certaines fonctions du téléviseur.

AUDIO

OUT

UNPLUG THE POWER CORD FROM AC OUTLET BEFORE REMOVING THE REAR COVER

LC21898-001A

Quick Setup TV Remote Control

CATV VCR DVD

MULTI SCREEN

INDEX

TWIN

FREEZE

SWAP

INPUT

123

D/A

456

i.LINK MENU

789

TIMER

TUNE

THEATER

FAVORITE

PRO

SOUND

C.C.

MUTING

OPEN CLOSE

VOL VOL

VCR CHANNEL

PREV NEXT

REW

REC PAUSE

STOP

RM-C14G

ASPECT

SELECT

ML/MTS

VIDEO

STATUS

NATURAL CINEMA

VCR DVD

POWER

STILL PAUSE

POWER

SLEEP

DISPLAY

RETURN+

SUB

CHANNEL

SUB

LIGHT

GUIDE

BACK

TV VCR

FFPLAY

RM-C14G

• For information on remote control buttons, see pages 62 - 72 and 76 - 81.

• i.LINK MENU, TIMER, SUB CHANNEL, FAVORITE and GUIDE buttons are for digital channels. If your TV is connected to an ATSC antenna or Digital Cable, you can use these buttons.

Quick Setup Getting Started

Getting Started

These quick setup pages will provide you, in three easy steps, with the basic information you need to begin using your new television right away.

If you have questions, or for more detailed information on any of these steps, please consult other sections of this manual.

Step 1 - Using the stand

This TV comes with a Table Top Stand already attached.

This stand can be used to adjust the direction of the TV screen 20° to the left or right.

Rotate the TV left or right

While holding the bottom of the stand with one hand, use your other hand to hold the edge of the panel and slowly adjust the direction of the TV stand.

P O W

E R

P R O

G R A M

/L E D

Quick Setup Getting Started

Step 2 – The Remote Control

Before you can operate your remote control, you first need to install the batteries (included).

Slide the cover on the back of the remote down towards the bottom of the remote control. Insert two batteries (included) carefully noting the “+” and “–” markings, placing the “–” end in the unit first. Slide the cover back into place.

When you change the batteries, try to complete the task within three minutes. If you take longer than three minutes, the remote control codes for your VCR, DVD, and/or cable box/satellite receiver may have to be reset. See pages 30 - 33.

Key Feature Buttons

The four key feature buttons at the center of the remote can be used for basic operation of the television. The top and bottom buttons will scan forward and back through the available channels. To move rapidly through the channels using JVC’s Hyperscan feature, press and hold CH+ or CH –. The channels will zip by at a rate of five channels per second. The right and left buttons will turn the volume up or down. These buttons are also marked with four arrows and are used with JVC’s onscreen menu system. To use the onscreen menus, press the M

ENU button.

MUTING

VOL VOL

GUIDE

BACK

Basic Operation

Turn the television on and off by pressing the POWER button at the top right corner of the remote. If this is the first time you are turning on the TV, the interactive plug-in menu appears.

• Make sure the TV/CATV switch is set to TV. Move the switch to CATV only if you need to operate a cable box.

• Slide the VCR/DVD selector switch to VCR to control a VCR. Slide to DVD to control a DVD player. Please see pages 30 to 33 for instructions on programming your remote control to operate a cable box, VCR or DVD player.

POWER

CATV

VCR DVD

Quick Setup Connections

Step 3 – Connecting Your Devices

To make these connections, you will use plugs like the ones illustrated below.

S-Video Cable

Component Cables

Composite Cables

Audio Cables

Used to make video connections with S-Video VCRs, Camcorders and DVD players.

Notes:

• These connections are examples.

• After you are finished connecting your devices, plug the power cord into the nearest power outlet and turn on the TV.

• If you follow these diagrams and the television does not work properly, contact your local cable operator.

• To connect a DVD player, see VCR Connection. A DVD player is optional

• If you have a satellite television system, refer to the satellite TV manual.

Used to connect audio/video devices like VCRs, DVD players, stereo amplifiers, game consoles, etc.

No VCR Connection

Cable or Antenna

Output

OUT OUT

ATSC /DIGITAL CABLE IN

TV Underneath Panel

Two-way Splitter

(Attachment)

Coaxial Cable (Attachment)

75Ω

(VHF/UHF)

Quick Setup Connections

VCR Connection

Notes:

• Green, blue and red are the most common colors for DVD cables. Some models may vary colors. Please consult the user’s manual for your DVD player for more information.

• Be careful not to confuse the red DVD cable with the red audio cable. It is best to complete one set of connections (DVD or audio output) before starting the other to avoid accidentally switching the cables.

• You may also connect the DVD player to Input 1.

Diagram #1

Cable or Antenna

Output

Two-Way Splitter

(Attachment)

Coaxial Cable

(Attachment)

ATSC /DIGITAL CABLE IN

Television Underneath Panel

OUT OUT

VCR

75Ω

(VHF/UHF)

OUT

R L V

OUT

INPUT-3

R AUDIO L VIDEO

Television Rear Panel

INPUT-1

R AUDIO L VIDEO

OVER

S-VIDEO

OVER

S-VIDEO

Pr Pb Y

Y P

AUDIO OUT

R L

OUT

DVD Player (OPTIONAL)

Note:

• If this connection setup does not work for you, try the connection setup on page 16.

Green

Blue

Red

Quick Setup Connections

Diagram #2

Cable or Antenna

Output

Two-Way Splitter

(Attachment)

Coaxial Cable

(Attachment)

Television Underneath Panel

OUT OUT

ATSC /DIGITAL CABLE IN

VCR

75Ω

(VHF/UHF)

OUT

R L V

OUT

INPUT-3

R AUDIO L VIDEO

Television Rear Panel

INPUT-1

R AUDIO L VIDEO

OVER

S-VIDEO

OVER

S-VIDEO

Pr Pb Y

AUDIO OUT

R L

DVD Player (OPTIONAL)

Y P PR

Green

Blue

Red

OUT

Quick Setup Connections

Connecting to Monitor/Recording Output Terminal

Television Rear Panel

R AUDIO L VIDEO

OVER

S-VIDEO

AUDIO

OUT

MONITOR/ REC OUT

VCR

R L V

OUT

Notes:

• When you make this connection, set the Video-1 Monitor Out menu to ON. See page 53.

• If you are receiving ATSC/Digital Cable signal, it can be outputted to the S-Video output terminal or Video (composite video) terminal.

• If you are receiving Analog TV signal, it can not be outputted to the S-Video output terminal.

• No signal will be outputted through the S-Video output terminal when you are not viewing images coming from the composite video input terminal.

• No signal will be outputted through the Monitor/Recording output terminal when you are viewing images from the component video input.

OUT

Quick Setup Connections

Connecting to JVC AV Compu Link

JVC’s AV CompuLink feature makes playing video tapes or DVDs totally automatic. Simply insert a pre-recorded tape into your JVC brand VCR or DVD into your JVC DVD player and the device will automatically turn on and begin playback. At the same time, using the AV CompuLink, the VCR or DVD player sends a signal to the television telling it to turn on and switch to the proper video input.

• The AV CompuLink cable may be included with the JVC AV CompuLink unit you wish to connect. If it is not, contact JVC Parts Department at (800)-882-2345, or www.jvcservice.com for part # EWP 805-012.

• AV CompuLink can only be used with JVC brand products.

AV CompuLink Cable

To Connect: Plug one end of the AV compu link cable into the AV COMPU LINK INPUT on your VCR, DVD, or other compu link device. Plug the other end of the AV compu link cable into the AV COMPU LINK underneath the TV.

Note:

• The AV compu link cable has a male 3.5 mm (mono) plug on each end.

VCR

VIDEO

DIGITAL

TV Underneath Panel

HDMI

AUDIO

DIGITAL

AV COMPULINK

OUT

V L R

AV CompuLink

OUT

Notes:

• In order for the VCR playback to begin automatically, the recording tabs must be removed from the VHS tape. If the tab is in place, automatic switching will occur when you push the VCR’s PLAY button.

• If your JVC brand VCR has “A code/B code remote control switching” (see your VCR’s instruction book), using VCR A code will switch the TV to input 1.

• Refer to your DVD instruction book for detailed connection information.

• To connect a JVC HiFi receiver or amplifier for a completely automated home theater, see the receiver connection instructions for detailed connection information.

• AV CompuLink is compatible with select AV CompuLink receivers.

Quick Setup Connections

Connecting to a Camcorder

You may connect a camcorder, game console or other equipment to your television by using the front input jacks (Input 4) located under the front panel door. To access, push on the door to open it. You can also connect these using the television’s rear input jacks, using the same instructions.

POWER

PC INPUT

CHANNELVOLUME

OPERATE

S-VIDEO VIDEO

OVER

INPUT

L/MONO-AUDIO-R

INPUT-4

POWER

TV front Panel

CAMCORDER

1) Connect a yellow composite cable from the camcorder VIDEO OUT, into the VIDEO IN on

the front of the TV, OR connect an S-Video cable from the front of the TV to the camcorder.

2) Connect a white composite cable from the camcorder LEFT AUDIO OUT, into the

LEFT AUDIO IN on the front of the TV.

3) Connect a red composite cable from the camcorder RIGHT AUDIO OUT, into the

RIGHT AUDIO IN on the front of the TV.

Note:

• If your camcorder is a mono sound model it will have only one AUDIO OUT. Connect it to the LEFT AUDIO IN on the front of the TV.

Connecting to an External Amplifier

TV Rear Panel

AUDIO

OUT

MONITOR/ REC OUT

R AUDIO L VIDEO

OVER

S-VIDEO

1) Connect a white composite cable from the LEFT AUDIO OUTPUT on the back of the TV to

the LEFT AUDIO INPUT on the amplifier.

2) Connect a red composite cable from the RIGHT AUDIO OUTPUT on the back of the TV to

the RIGHT AUDIO INPUT on the amplifier.

Notes:

• Refer to your amplifier’s manual for more information.

• You can use AUDIO OUTPUT for your home theater system.

Speaker Speake

Amplifier

Quick Setup Connections

Connecting to an amplifier using your optical output

You can connect an amplifier that has an optical digital input terminal by using an optical digital cable from the optical output. The signal that is output can be PCM or Dolby Digital.

Television Underneath Panel

OPTICAL OUT

Digital Audio

1) Connect the optical cable from underneath the television to the back of the amplifier.

Notes:

• This terminal can only output digital audio.

• In order to use the optical output connection, select PCM or Dolby Digital on Digital Sound in the Digital Setup Menu. See page 74.

• Refer to your owners manual on using your amplifier.

Amplifier

Quick Setup Connections

Connecting to a Digital TV Receiver

By connecting a Digital TV Receiver, high definition pictures can be displayed on your TV in their digital form.

DTV Decoder

TV Rear Panel

AUDIO OUTDIGITAL OUT

AUDIO

(ANALOG)

R L

VIDEO

DIGITAL

TV Underneath Panel

HDMI to DVI Cable

After the connections have been made,

tighten the screw to secure the cables.

1) Connect the HDMI to DVI Cable from the DIGITAL OUT on the back of your DTV decoder, to the DIGITAL-IN underneath your television.

2) Connect a red cable from the DTV decoder RIGHT AUDIO OUT, to the RIGHT AUDIO DIGITAL-IN on the back of your television.

3) Connect a white cable from the DTV decoder LEFT AUDIO OUT, to the LEFT AUDIO DIGITAL-IN on the back of your television.

• The digital-in terminal is not compatible with the picture signal of a personal computer.

• Use a HDMI to DVI cable (commercially available) in order to digitally connect the television

with a DTV decoder.

HDMI

AUDIO

DIGITAL

AV COMPULINK

CENTER CHANNEL INPUT

Notes:

• If 480p signals (640x480 or 720x480) are displayed on the screen, the horizontal balance

may be slightly shifted. Access the “DIGITAL-IN” in the initial setup menu to adjust it. (Refer to page 54.)

• When you do the above connection, set DIGITAL-IN AUDIO in the Initial Setup menu to

ANALOG. See "DIGITAL-IN AUDIO", page 55.

Quick Setup Connections

Connecting to a HDMI Compatible Device

By connecting a HDMI compatible device, high definition pictures can be displayed on your TV in their digital form. Some HDMI devices can include DVD players, D-VHS or any HDMI compatible device.

HDMI (High Definition Multimedia Interface) is the first industry supported, uncompressed, all digital audio/video interface. HDMI provides and interface between any audio/video source, such as a set-top box, DVD player, A/V receiver or an audio and/or video monitor, such as a digital television (DTV).

HDMI Compatible Device

DIGITAL OUT

AUDIO OUT

HDMI Cable

VIDEO

AUDIO

DIGITAL

AV COMPULINK

HDMI

TV Underneath Panel

1) Connect the HDMI Cable from the DIGITAL OUT on the back of your DTV or HDMI device, to the DIGITAL-IN underneath your television.

Notes:

• When you do the above connection, set DIGITAL-IN AUDIO in the Initial Setup menu to

DIGITAL. See "DIGITAL-IN AUDIO", page 55.

• Some decoders may not respond depending on the equipment that you have connected

when it is connected to the HDMI.

• If the HDMI output device signal is changed (for example, 480i/60Hz is changed to

480p/60Hz), the screen may turn green and there may be some distortion for a short time until the signal becomes stable.

Quick Setup Connections

Connecting to an AV Receiver using your television's V1 Smart Input

By connecting your AV Receiver to your television's V1 Smart Input, you can watch picture sources from many different devices, without having to change or use the other input connections on your TV. This allows you to free up the other input connections so you can connect more devices to your television.

AV Receiver

MONITOR

OUT

MONITOR OUT

TV Rear Panel

INPUT-1

R AUDIO L VIDEO

OVER

S-VIDEO

Pr Pb Y

1) Connect an S-Video Cable from the AV Receiver's MONITOR OUT, to the S-Video INPUT-1 on the back of your TV.

2) Connect a Yellow Component Cable from the AV Receiver's MONITOR OUT, into the VIDEO INPUT-1 on the back of your TV.

3) Connect a Green Component Cable from the AV Receiver's Y MONITOR OUT, into the Y VIDEO INPUT-1 on the back of your TV.

4) Connect a Blue Component Cable from the AV Receiver's PB MONITOR OUT, into the PR VIDEO INPUT-1 on the back of your TV.

5) Connect a Red Component Cable from the AV Receiver's P

B MONITOR OUT, into the PR

VIDEO INPUT-1 on the back of your TV.

Notes:

• Please refer to your AV Receiver instruction manual for more information on connecting your

speakers and other devices like a DVD player.

• Use your AV Receiver's remote to switch to the different devices you have connected.

• Some AV Receiver's may not respond when the V1 Smart Input function is turned on.

• If you have video connections for each input device connected to your AV Receiver, you

should not connect them using both S-Video and Composite connection at the same time when you are using V1 input as the V1 Smart Input. In this case we recommend using the S-Video connection.

Quick Setup Connections

Connecting to the computer

This TV can be used as a computer screen. Use a commercially available D-SUB cable to connect the TV's PC INPUT terminal to the computer's analog RGB output terminal. If you want to listen to the sound from the computer, use a commercially available RCA cable to connect the INPUT-4 audio input terminal to the computer's audio output terminal. When the sound from the computer is mono, connect to the L/MONO of INPUT-4.

POWER

PC INPUT

CHANNELVOLUME

OPERATE

S-VIDEO VIDEO

OVER

L/MONO-AUDIO-R

INPUT

INPUT-4

POWER

Notes:

• Refer to your computer manual for a detailed explanation of the connections concerning your computer.

• Make sure that the connectors are facing the correct way when connecting.

• After connecting, tighten the two screws to fix

the connectors in place.

Looking at the images from a computer

After starting the computer, press the INPUT button to choose INPUT-4. You can listen to the sound when the sound from the computer is connected to the INPUT-4 AUDIO input terminal.

Notes:

• When the sound from the computer is connected to INPUT-4 by choosing external input INPUT-4, the sound from the computer can be listened to, but the images from the computer cannot be seen.

Quick Setup Connections

Table of signals for each type of computer

Resolution

640 x 480 (VGA)

1024 x 768 (XGA)

Vertical Frequency (Hz)

60.0

Horizontal Frequency (kHz)

31.5

48.4

• Only the above formats are supported.

• Even with the above formats at 60 Hz, some problems may be experienced depending on the quality of the synchronous signal. (Depending on the quality, some pictures may not be displayed correctly).

• Apple Macintosh* computers are not supported.

When a picture is not displayed

With some computers, some problems can be solved by changing the settings. Check the computer's refresh rate and set it to 60Hz. Computers that cannot set the refresh rate to 60 Hz, can not be used with this TV. Refer to the computer's instruction manual.

*Apple Macintosh is a registered trademark of Apple Computer, Inc.

Quick Setup Connections

Connecting an i.LINK compatible device to the back of your television

i.LINK is a digital serial interface that allows devices equipped with an i.LINK connector to exchange digital video signals, digital audio signals and device control signals bi-directionally over a single cable. (For example, a JVC D-VHS VCR).

i.LINK refers to the IEEE1394-1995 industry specification and extensions thereof. The logo is used for products compliant with the i.LINK standard.

This projection television uses a four-pin i.LINK connector to input and output MPEG2 video signals, audio signals and control signals.

TV Underneath Panel

OPTICAL OUT

Digital Audio

i.LINK IN/OUT

S400 (TS)

i.LINK Compatible Device

1) Connect the i.LINK cable from underneath the TV to the back of the i.LINK compatible device.

Notes:

• Use only the S400 i.LINK cable when connection your devices.

• See page 78 on how to select the i.LINK device.

• Refer to your owners manual on using your i.LINK device.

• When recording or playing back video with an i.LINK device, if you perform the Auto Tuner

Setup, the video signal you are recording or playing back may stop or you may not be able to perform the Digital Auto Tuner Setup.

• Your television can connect with i.LINK D-VHS decks and HD-Camcorders (JVC brand only).

If you connect other brand devices, with i.LINK cable, they will not work.

• It can play only the recorded contents in Digital Mode.

• Use only tapes bearing the DVHS (SVHS) mark for recording.

Quick Setup Plug-In Menu

Step 4 – The Interactive Plug In Menu

When you turn your television on for the first time the interactive plug-in menu will appear. The plug-in menu helps you to get your TV ready to use by letting you set your preferences for:

• The language in which you want the onscreen menus to appear.

• Setting the TV’s clock to the correct time so your timer functions will work properly. You can

choose “AUTO” or “MANUAL” for setting the clock.

• The auto tuner setup of which channels you wish to receive.

We recommend you complete the interactive plug-in items before you start using your television.

Notes:

• The interactive plug-in menu setting does not appear if your TV has been turned on before.

In this case use the onscreen menus to perform these settings. See pages 47, 60, 37.

• If you press the Menu button while setting up the interactive plug-in menu, it will skip over it.

Language

After the “JVC INTERACTIVE PLUG IN MENU” has been displayed, the TV automatically switches to the LANGUAGE settings. You can choose to view your onscreen menus in three languages: English, French (Français) or Spanish (Español).

LANGUAGE/LANGUE/IDIOMA

ENGLISH

SELECT OPERATE EXIT

√®

To choose a language:

(English, Français or Español)

†

To NEXT (To set clock)

(To be continued...)

Quick Setup Plug-In Menu

Auto Clock Set

Before you use any of your TV’s timer functions, you must first set the clock. You may precisely set your clock using the XDS time signal broadcast by most public analog broadcasting stations. If you do not have this in your area, you will have to set the clock manually. See manual clock set below. To set the clock using the XDS signal:

√®

SET CLOCK

MODE

TIME

TIME ZONE

DATE/YEAR

D.S.T.

SELECT OPERATE EXIT

AUTO

: --

ATLANTIC

JAN/01/05

Notes:

• D.S.T. can be used when it is set to ON in the SET CLOCK menu.

• Only when the MODE is set to AUTO, the Daylight Savings Time feature automatically adjusts your TV’s clock for Daylight Savings. The clock will move forward one hour at 2:00 am on the first Sunday in April. The clock will move back one hour at 2:00 am on the last Sunday in October.

• You will have to reset the clock after a power interruption. You must set the clock before operating any timer functions.

Manual Clock Set

To choose AUTO

†

To TIME ZONE

√®

To select your time zone: (Atlantic, Eastern, Central, Mountain, Pacific, Alaska or Hawaii)

†

To move to D.S.T. (Daylight Savings Time)

√®

To turn D.S.T. ON or OFF

†

To NEXT (To Auto Tuner Setup)

To set your clock manually (without using the XDS signal), choose MANUAL. If you choose AUTO, see auto clock set above.

√®

SET CLOCK

MODE TIME TIME ZONE DATE/YEAR D.S.T.

START CLOCK

SELECT OPERATE EXIT

MANUAL

: -ATLANTIC JAN/01/05

To choose MANUAL

†

√®

†

To minute

√®

†

To TIME ZONE

√®

Central, Mountain, Pacific, Alaska or Hawaii)

†

To DATE/YEAR

√®

†

To day

√®

†

To year

√®

†

To move to D.S.T. (Daylight Savings Time)

√®

†

To START CLOCK

To TIME

To set the hour

To set the minute

To select your time zone: (Atlantic, Eastern,

To set the month

To set the day

To set the year

To turn D.S.T. ON or OFF

Note:

• You will have to reset the clock after a power interruption. You must set the clock before operating any timer functions.

(To be continued...)

Quick Setup Plug-In Menu

Auto Tuner Setup

In auto tuner setup, the TV automatically scans through all available channels, memorizing the active ones and skipping over blank ones or channels with weak signals. This means when you scan (using the C two tuner modes to choose from, ANALOG or DIGITAL.

HANNEL +/– buttons) you will receive only clear, active channels. There are

AUTO TUNER SETUP

IN ANALOG

IN DIGITAL TUNER MODE

START

SELECT OPERATE EXIT

ATSC

√®

you skip Analog Auto Tuner Setup)

AIRTUNER MODE

π†

√®

when you skip Digital Auto Tuner Setup)

†

After Analog Auto Tuner Setup is finished, Digital Auto Tuner Setup starts.

To choose CABLE or AIR (or SKIP when

To TUNER MODE (IN DIGITAL)

To choose ATSC or Digital Cable (or SKIP

To START

NOW

Now Programming...

PROGRAMMING !

When the setup is finished, "THANK YOU ! SETUP IS NOW COMPLETE" is displayed. Your quick setup is now complete. You can now begin watching your television, or you can continue on in this guide for more information on programming your remote control, or using the JVC onscreen menu system to customize your television viewing experience.

Notes:

• If you want to cancel the Auto Tuner Setup, press the MENU button.

• Noise muting will not work during Auto Tuner Setup.

• If you choose SKIP, it finished without doing the Auto Tuner Setup.

Cable Box and Satellite Users: After your auto tuner setup is complete, you may, (depending on the type of hookup), have only 1 channel, usually 3 or 4 in the auto tuner memory. This is normal.

STOP

The Quick Setup is complete

Remote Programming

Setting the CATV, VCR and DVD Codes

You can program your remote to operate your cable box, satellite receiver, VCR or DVD player by using the instructions and codes listed below. If the equipment does not respond to any of the codes listed below or to the code search function, use the remote control supplied by the manufacturer.

Cable Box or Satellite Codes

The remote control is programmed with cable box and satellite codes for power on/off, channel up/down, and 10 key operation.

1) Find the cable box or satellite brand from the list of codes shown below.

2) Slide the 2-way selector switch to “CATV”.

3) Press and hold down the DISPLAY button, then enter the first code number listed with the 10 key pad.

4) Release the DISPLAY button, and confirm the operation of the cable box/satellite receiver.

• If your cable or satellite box does not respond to the first code, try the others listed. If it does

not respond to any code, try the search codes function, on page 33.

Cable Box Codes

ABC Archer Cableview Citizen Curtis Diamond Eagle Eastern GC Brand Gemini General

Instrument/Jerrold

Hamlin

Hitachi

Macom

Magnavox Memorex

Movietime Oak Panasonic

Paragon

Philips

Pioneer Pulsar

024 032, 025 051, 032 022, 051 058, 059 024, 032, 025 029 034 032, 051 022, 043 065, 024, 025,

026, 027, 020, 021, 022, 057, 023, 072, 074 040, 041, 042, 045, 058, 064 049, 024

049, 050, 051, 054

033 030 032, 051 039, 037, 048 055, 056, 060,

071, 073 063

028, 029, 030, 052, 053, 031, 069

047, 062 051, 032

Cable Box Codes

Puser RCA Realistic Regal

Regency Rembrandt

Samsung Scientific Atlanta SLMark Sprucer Stargate

Telecaption Teleview Texscan

To co m

Toshiba Unika

Universal

Videoway Viewstar Zenith Zenith/Drake

Satellite

032 061, 070 032 058, 064, 040,

041, 042, 045, 068 034

037, 032, 051, 038

051 057, 058, 059 051, 047 051, 056 032, 051

067 047, 051 044 035, 036, 066,

074

050, 048 032, 025

022, 032 052 029, 030 063, 046 046

Digital Satellite Systems

Echostar (Dish Network)

Express VU

G.E. G.I.

Gradiente Hitachi

HNS (Hughes)

Magnavox 102, 103

Panasonic Philips

Primestar

Proscan RCA Sony Star Choice Toshiba

Uniden

Codes

100, 113, 114, 115

100, 113

106 108, 120, 121,

122

112 104, 111

104

105 102, 103, 116

108

106, 109, 110 106, 109, 110

107 104, 108 101, 104, 117,

118 , 11 9

102, 103

Remote Programming

VCR Codes

The remote control is programmed with VCR codes for power on/off, play, stop, fast-forward, rewind, pause, record, channel up/down operation.

1) Find the VCR brand from the list of codes shown below.

2) Slide the first 2-way selector switch to “TV” and the other 2-way selector switch to “VCR”.

3) Press and hold down the D key pad.

4) Release the D

ISPLAY button, and confirm the operation of the VCR.

• If your VCR does not respond to the first code, try the others listed. If it does not respond to

any of the codes, try the search codes function on page 33.

• After you program your remote, some VCR buttons may not work properly. If so, use the

VCR’s remote.

• To record, hold down the R

ISPLAY button, then enter the first code number listed with the 10

EC button on the remote and press PLAY.

VCR

Admiral Aiwa Akai

Audio Dynamic Bell & Howell Broksonic Canon CCE Citizen Craig Curtis Mathes

Daewoo

DBX Dimensia Emerson

Fisher

Funai

G.E. Go Video

Goldstar Gradiente

Hitachi

Instant Replay Jensen JVC

Kenwood

LG 064

LXI 027, 064, 058,

Magnavox

Codes

035 027, 032, 095 029, 072, 073,

074 003, 005 063, 071 020, 026, 094 023, 025 043 064 063, 029, 064 045, 024, 027,

093 043, 059, 024,

092 003, 004, 005 045, 093

043, 026, 077, 061, 025, 042, 020, 076

063, 066, 067, 065, 071, 091

027, 026, 020, 000

033, 045, 024 037, 051, 049,

050, 089 064 083, 084, 081,

000, 001 023, 045, 058,

093, 027, 081

024, 023 003

003, 004, 005, 000, 001, 002, 006, 007

003, 004, 064, 005

065, 066, 063, 067

031, 023, 024, 086

VCR VCR

Marantz Marta Memorex MGA

Minolta Mitsubishi

Multitech NEC

Olympic Optimus

Orion Panasonic

Penney

Pentax

Philco

Philips

Pioneer

Proscan

Quasar

Radio Shack

RCA

Realistic 024, 063, 036,

Codes

003, 004, 005 064 024, 067 038, 040, 047,

048, 041, 042 058, 045, 093 038, 040, 047,

048, 041, 042, 078, 090

047, 027, 062 003, 004, 005,

000 024, 023

028, 021, 035, 064 026, 020

023, 024, 021, 022

024, 058, 045, 063, 003, 004, 005, 093

058, 005, 045, 093

031, 024, 027, 023, 026, 020, 043

031, 023, 024, 086

023 045, 058, 023,

024, 031, 046, 059, 060, 093, 033, 087

021, 022, 023, 024

033, 024, 063, 036, 067, 040, 027

033, 045, 058, 023, 024, 031, 046, 059, 060, 083, 084, 085, 087, 093, 096

067, 040, 027

Samsung

Samtron Sansui

Sanyo

Scott

Sears

Sharp

Shintom 075 Signature 2000

Singer Sony

SV 2000 Sylvania

Symphonic Tashiro Tatung Tea c

Technics

Teknika

Thomson 033, 096 Toshiba Vector Research Wards

Yamaha

Zenith 044, 082, 064,

Codes

037, 060, 062, 033, 089

089 003, 026, 020,

052 063, 067, 091,

071 059, 060, 062,

067, 038, 040, 047, 048, 026, 020

063, 064, 065, 066, 058

035, 036, 080, 088

027, 035

075 028, 029, 030,

053, 054, 055 027 031, 023, 024,

027 027, 081

064 003, 004, 005 003, 004, 027,

005 021, 022, 023,

024 024, 027, 070

059, 046, 079 005 035, 036, 067,

044, 064 063, 003, 004,

005

094

Remote Programming

DVD Codes

The remote control is programmed with DVD codes for power on/off, play, stop, fast-forward, rewind, previous/next chapter, tray open/close, and still/pause operation.

1) Find the DVD player brand from the list of codes shown below.

2) Slide the first 2-way selector switch to “TV” and the other 2-way selector switch to “DVD”.

3) Press and hold down the D key pad.

4) Release the DISPLAY button, and confirm the operation of the DVD player.

• If your DVD player does not respond to the first code, try the others listed. If it does not

respond to any of the codes, try the search codes function on page 33.

• After you program your remote, some DVD buttons may not work properly. If so, use the

DVD player’s remote.

ISPLAY button, then enter the first code number listed with the 10

Aiwa 043 Apex 040, 054,

Bose 058 Denon 020, 037

Funai 038 Go–Video 032 Harman

Kardon Hitachi 031 JVC 000 Kenwood 035, 020 KLH 051 Konka 039 Koss 050

055

053

DVD Player DVD Player

Mintek 057 Mitsubishi 025

Next Base 056 Onkyo 041, 052

Oritron 044 Panasonic 020 Philips 023, 036

Pioneer 022 Polk Audio 036 Raite 033 RCA 021, 026

Sampo 034 Samsung 030

Sharp 028 Silvania 038

SMC 048 Sony 024, 045,

Technics 020 Thomson 021 Toshiba 023

Venturer 051 Vialta 050 Wave 042 Yamaha 020, 049 Zenith 027, 032

CodesDVD Player Codes Codes

046, 047

Remote Programming

Search Codes

Cable/Satellite Search Codes Function

1) Slide the first 2-Way Mode Selector switch to CATV.

2) Press the P

3) Press the POWER button on the remote, and see if the cable or satellite box responds.

4) If there was a response, press RETURN+. The codes are now set. If there was no response, repeat Step 3. If you repeat Step 3 a total of 80 times without a response, use the remote control that came with your equipment.

5) Press RETURN+ to exit.

VCR/DVD Search Codes Function

1) Slide the first 2-way selector switch to “TV” and the other 2-way selector switch to “VCR” or “DVD”.

2) Press the VCR or DVD P release.

3) Press the VCR or DVD POWER button, and see if the VCR or DVD responds.

4) If there was a response, press RETURN+. The codes are now set. If there was no response, repeat Step 3. If you repeat Step 3 a total of 80 times for the VCR (40 times for the DVD player), and there is no response, use the remote control that came with your equipment.

5) Press R

OWER and RETURN+ buttons. Hold for at least three seconds and release.

OWER and RETURN+ buttons. Hold for at least three seconds and

ETURN+ to exit.

Onscreen Menus

Using the Guide

Certain symbols are used throughout this guide to help you learn about the features of your new television. The ones you will see most frequently are:

π†

Up and Down arrows mean press the CH+ or CH– buttons. Pressing the CH+ or CH–

buttons let you:

• Move vertically in a main menu screen

• Move through a submenu screen

• Move to the next letter, number, or other choice in a submenu

• Back up to correct an error

• Scan through TV channels (when not in a menu screen)

√®

Left and right arrows mean press the VOLUME+ or VOLUME- buttons to move left or right

to:

• Select a highlighted menu item

• Select an item in a submenu

• Select numbers in certain menu options

• Turn the volume up or down (when not in a menu screen)

The “press button” icon means you should press the button named on your remote

control. (Button names appear in S

The “helping arrow” icon points to the highlighted or selected item in a menu.

To bring up the onscreen menu, press the MENU button on the remote control. The item that appears in green is the one currently selected. If you use the Menu button on the TV’s front panel instead of the remote, an additional menu screen showing INPUT, VIDEO STATUS and ASPECT will appear between INITIAL SETUP and PICTURE ADJUST. The “interactive plug-in menu” will appear the first time the TV is plugged in.

MALL CAPITAL LETTERS.)

PREVIOUS AUTO TUNER SETUP CHANNEL SUMMARY V-CHIP SET LOCK CODE AUTO DEMO

SELECT OPERATE EXIT

INITIAL SETUP

OFF

(4/5)

Note:

• Menus shown in this book are illustrations, not exact replications of the television’s onscreen displays.

Onscreen Menus

The Onscreen Menu System

Your television comes with JVC’s onscreen menu system. The onscreen menus let you make adjustments to your television’s operation simply and quickly. Examples of the onscreen menus are shown on the next page. Detailed explanations on using each menu follow later in this guide. For information about the interactive plug-in Menu, see pages 27 - 29.

The Onscreen Menu System

To open the onscreen menu system, press the MENU button on the remote control. You navigate within the onscreen menus by using the four directional arrow buttons on the remote control. (These buttons are also the C will not operate when the onscreen menu is active).

The selected feature and option on a menu screen are highlighted in a different color.

H +/– and VOL +/– buttons. Channel and volume functions

Selected Option (Green)

To move to a different feature use the π† arrows to move up or down the list. When you press the up arrow at the top of the list or the down arrow at the bottom, the next menu screen will appear. Use the arrows √ ® to select an option from the highlighted feature. Pressing MENU on the remote control will close the onscreen menu system and return you to normal television viewing.

Each menu and its features will be discussed in the following pages of this guide.

Notes:

• If you do not press any buttons for a few seconds, the onscreen menu will automatically shut off.

• Button names in this guide are shown in S

• Menus may appear in different sizes onscreen depending on the aspect ratio selected.

• Some menu items may not appear in menu screens when certain aspect ratios or inputs are selected.

LANGUAGE CLOSED CAPTION

ENG. FRAN. ESP.

MALL CAPITAL LETTERS.

Selected Option (Blue)

Onscreen Menus

Press the MENU button

TO INITIAL SETUP 03

INITIAL SETUP

PREVIOUS AUTO TUNER SETUP CHANNEL SUMMARY V-CHIP SET LOCK CODE AUTO DEMO

NEXT PAGE SELECT OPERATE EXIT

OFF

INITIAL SETUP 04

INITIAL SETUP

PREVIOUS DIGITAL SETUP

NEXT PAGE SELECT OPERATE EXIT

INITIAL SETUP 05

PICTURE ADJUST

TINT COLOR PICTURE BRIGHT DETAIL COLOR TEMPERATURE

NEXT PAGE SELECT OPERATE

STANDARD 00 00 00 00 00

HIGH

PICTURE ADJUST 01

CLOCK / TIMERS

PREVIOUS SET CLOCK ON / OFF TIMER

(4/5)

NEXT PAGE SELECT OPERATE EXIT

CLOCK/TIMERS

SOUND ADJUST

PREVIOUS BASS

TREBLE

BALANCE

RESET

(5/5)

NEXT PAGE SELECT OPERATE EXIT

SOUND ADJUST

PICTURE ADJUST

PREVIOUS STANDARD DIG. NOISE CLEAR COLOR MANAGEMENT DYNAMIC GAMMA BURN-IN IMAGE REDUCER

RESET

(1/2)

EXIT

SELECT OPERATE EXIT

PICTURE ADJUST 02

PREVIOUS VIDEO-1MONITOR OUT TV SPEAKER AUDIO OUT DIGITAL-IN DIGITAL-IN AUDIO CENTER CH INPUT

SELECT OPERATE EXIT

INITIAL SETUP

OFF

VARI

SIZE1

DIGITAL

OFF

(1/5)

INITIAL SETUP 01

INITIAL SETUP

PREVIOUS NOISE MUTING FRONT PANEL LOCK V1 SMART INPUT VIDEO INPUT LABEL POSITION ADJUSTMENT POWER INDICATOR

NEXT PAGE SELECT OPERATE EXIT

OFF

LOW

(2/5)

INITIAL SETUP 02

INITIAL SETUP

OFF OFF OFF

IMAGE SHIFT LANGUAGE CLOSED CAPTION AUTO SHUT OFF XDS ID

(2/2)

SELECT OPERATE EXIT

ENG. FRAN. ESP.

OFF

(3/5)

INITIAL SETUP 03

TO INITIAL SETUP 04

Notes:

• The DIGITAL-IN menu can only be displayed when a 480p picture signal is input to the digital-in terminal and the picture is being displayed on the screen.

• When the Menu button on the TV side panel is pressed, the FRONT PANEL CONTROL menu between INITIAL SETUP 05 and PICTURE ADJUST 01 will appear.

• Regarding the digital setup menu, see page 73.

Initial Setup

Auto Tuner Setup

The auto tuner setup function is described on page 29 as the interactive plug-in menu. If you need to run the auto tuner setup again, follow the steps below.

Press the M

π†

√®

π†

√®

π†

√®

Programming will take approximately 2 to 4 minutes. The auto tuner is finished when the message PROGRAMMING OVER! appears onscreen.

To AUTO TUNER SETUP To operate To TUNER MODE (IN ANALOG) To choose CABLE, AIR or SKIP To TUNER MODE (IN DIGITAL) To choose ATSC, DIGITAL CABLE or SKIP

Press the OK button to start

ENU button

AUTO TUNER SETUP

IN ANALOG

IN DIGITAL TUNER MODE

PRESS OK TO START

SELECT OPERATE EXIT

AIRTUNER MODE

ATSC

Press the Menu button when finished

Initial Setup

Channel Summary

Channel summary allows you to customize the line-up of channels received by your TV. Regarding analog channels, you can add or delete channels from the line-up or prevent any unauthorized viewers from watching any or all 191 channels. Regarding digital channels, the only channels that will appear are the ones that are broadcasting.

Press the M

π†

√®

To CHANNEL SUMMARY

To operate

ENU button

The Channel summary screen will now be displayed with the channels set to scan marked with an “√”. Regarding analog channels, you can delete channels from the scan by removing the “√”. If any channels were missed during auto tuner setup and you wish to add them, you may by placing an “√” next to the channel number.

• Digital channels can not be added to the channel summary if the auto tuner setup did not find them.

π† √® To the SCAN column

Press the OK button to include or delete from

scan

Press the MENU button when finished

Note:

• The number of a digital channel may change, depending on the time of some broadcastings. If this channel existed and now had disappeared, the lock channel or scanned channel by the channel summary for that channel will be cancelled.

Analog Channels

CHANNEL SUMMARY

CHNO.

SCAN CHNO. SCANID ID 01 02

MTV 03 04

A&E 05

SELECT OPERATE EXIT

06 07 08 09 10

Digital Channels

Channel Summary Digital

CH No.

Scan

Station Name

D01

D02

D10-1

D10-2

D12345

Operate

FOX

ABC

CNN

NBC

BOX

NHK

BACK

Back

Note:

• When the Cable Card is not inserted into the Cabe Card Slot:

If you are watching analog

channels, the above screen appears.

If you are watching digital

channels, the below screen appears.

• When the Cable Card is inserted into the Cabe Card Slot:

Below screen appears Both analog and digital

channels are listed, but the background video is not displayed.

HBO

Exit

Initial Setup

How to set the channel label. (This is only for analog broadcasting.)

Press the M

π†

√®

π†

Press the OK button to enter

√®

π†

...continue to follow these directions for all four

Press the OK button to finish

Your characters are now set

Press the MENU button when finished

If you want to reset the characters you set:

Press the MENU button

π†

√®

π†

Press the O

π†

Press the OK button to finish

Your characters are now reset

To CHANNEL SUMMARY To operate To the ID column

To select the character you want To move to the next space

spaces

To CHANNEL SUMMARY To operate To the ID column

To select RESET

ENU button

K button to enter

CHANNEL 09

RESET

SELECT OPERATE EXIT

PRESS TO FINISH

Notes:

• You can use characters for: Alphabet, numbers, marks and spaces.

• It is possible to set the maximum of 40 channel labels.

• If you try to set more than the 40 maximum, the message "MEMORY OVERFLOW" will appear.

You can block access to a channel by activating the channel lock.

Press the M

π†

To CHANNEL SUMMARY

√®

To operate

π† √® To the Lock Column ( )

Press the ZERO button to lock or unlock that channel

Press the MENU button when finished

ENU button

Initial Setup

Channel Guard Message

When a viewer attempts to watch a guarded channel, the following message appears:

To watch a channel that you have locked, enter the Lock Code using the 10 key pad. If the wrong code is entered, the message “INVALID LOCK CODE!” will flash on the screen.

The channel cannot be accessed until the correct code is entered.

Notes:

• Once a channel has been unlocked, it will remain unlocked until the television is turned off.

• See also “Set Lock Code”, page 46.

V-Chip

Your TV is equipped with V-Chip technology which enables you to block channels or content that you feel to be inappropriate for children, based on US and Canada rating guidelines. V-Chip has no effect on video signals from a DVD discs, VCR tapes or Camcorder connection.

Note: Some programs, and movies are broadcast without a ratings signal. Even if you set up V-CHIP ratings limits, these programs will not be blocked. See page 41 for information on how to block unrated programs.

Note (for Canadian viewers): The V-Chip function is based on specifications designed for the United States and therefore may not work properly in Canada.

THIS CHANNEL IS LOCKED BY CHANNEL GUARD. PLEASE ENTER LOCK CODE BY 10 KEY PAD TO UNLOCK IT.

NO. - - - -

You can customize the V-Chip settings of your television to match your personal tastes. The V-Chip menu below is the starting point for your V-Chip settings

You can use US V-Chip settings (for programming broadcast from the United States), Canadian V-Chip settings (for programming broadcast from Canada), and movie ratings. You may use any or all of the settings (US V-Chip, Canada V-Chip, Movie ratings). Descriptions for setting each of the three V-Chip formats appear in the next six pages along with descriptions of the rating categories.

To access the rating categories:

Press the M

π†

√®

To V-CHIP To operate (Lock icon will appear)

Press ZERO to access the V-Chip menu

√®

To turn V-Chip ON or OFF (V-Chip must be

ENU button

V-CHIP V-CHIP SET US TV RATINGS SET MOVIE RATINGS SET CANADIAN RATINGS ENG SET CANADIAN RATINGS FRE UNRATED

OFF

VIEW

turned ON for rating settings to operate)

π†

To move to SET US TV RATINGS,

SELECT OPERATE EXIT

SET MOVIE RATINGS, or SET CANADIAN RATINGS (see following pages for descriptions of each item)

Initial Setup

Unrated Programs

Unrated programming refers to any programming which does not contain a rating signal. Programming on television stations which do not broadcast rating signals will be placed in the “Unrated Programming” category.

Examples of Unrated programs:

• Emergency Bulletins • Locally Originated Programming

• News • Political Programs

• Public Service Announcements • Religious Programs

• Sports • Weather

• Some Commercials

Note:

• TV programs or movies that do not have rating signals will be blocked if the unrated category is set to BLOCK.

Directions to Block Unrated Programs

You can block programs that are not rated.

Press the MENU button

π†

√®

To V-CHIP To operate (The lock icon appears)

Press ZERO to access V-Chip setup options

π†

√®

To UNRATED To VIEW or BLOCK

Press MENU when done

V-CHIP V-CHIP SET US TV RATINGS SET MOVIE RATINGS SET CANADIAN RATINGS ENG SET CANADIAN RATINGS FRE UNRATED

SELECT OPERATE EXIT

OFF

VIEW

Initial Setup

US V-Chip Ratings

U.S. PARENTAL RATING SYSTEMS Programs with the following ratings are appropriate for children.

❒ TV Y is Appropriate for All Children

Programs are created for very young viewers and should be suitable for all ages, including children ages 2 - 6.

❒ TV Y7 is for Older Children

Most parents would find such programs suitable for children 7 and above. These programs may contain some mild fantasy violence or comedic violence, which children should be able to discern from reality.

Programs with the following ratings are designed for the entire audience. ❒ TV G stands for General Audience

Most parents would find these programs suitable for all age groups. They contain little or no violence, no strong language, and little or no sexual dialog or situations.

❒ TV PG Parental Guidance Suggested

May contain some, but not much, strong language, limited violence, and some suggestive sexual dialog or situations. It is recommended that parents watch these programs first, or with their children.

❒ TV 14 Parents Strongly Cautioned

Programs contain some material that may be unsuitable for children under the age of 14 including possible intense violence, sexual situations, strong coarse language, or intensely suggestive dialog. Parents are cautioned against unattended viewing by children under 14.

❒ TV MA Mature Audiences Only

These programs are specifically for adults and may be unsuitable for anyone under 17 years of age. TV MA programs may have extensive V, S, L, or D.

Viewing Guidelines

In addition to the ratings categories explained above, information on specific kinds of content are also supplied with the V-Chip rating. These types of content may also be blocked. The content types are:

• V/FV is for VIOLENCE/FANTASY VIOLENCE

• S stands for SEXUAL CONTENT

• L stands for strong LANGUAGE

• D stands for suggestive DIALOG

Setting US V-Chip Ratings

Initial Setup

Press the MENU button

π†

√®

To V-CHIP To operate (lock icon appears)

Press ZERO to access the V-Chip menu

√®

π†

√®

To turn V-Chip ON or OFF To move to SET US TV RATINGS

To operate

V-CHIP V-CHIP SET US TV RATINGS SET MOVIE RATINGS SET CANADIAN RATINGS ENG SET CANADIAN RATINGS FRE UNRATED

SELECT OPERATE EXIT

OFF

VIEW

Directions to set US V-Chip Ratings

Line up the cursor in the column (TV PG, TV G, etc.) with the content row (V/FV, S, etc.) and press the feature on or off. An item is locked if the icon appears instead of a “—”.

For example. To block viewing of all TV 14 shows, move the cursor to the top row of that column and add a lock icon. Once you’ve put a lock on the top row, everything in that column is automatically locked.

π† √®

Press the MENU button when finished

Note:

• If you want to change the setup, move the cursor to

π† or √®

to move the cursor to the correct location. Press OK to turn the locking

To the TV 14 Column

Press the OK button to lock

the top column and change the lock icon to “—” by pressing OK again. You may then select individual categories to block.

SET US TV RATINGS

TVMATV14TVPGTVGTVY7TV

V/FV S L D

SELECT OPERATE

EXIT

Initial Setup

Movies Ratings

❒ NR – Not Rated

This is a film which has no rating. In many cases these films were imported from countries which do not use the MPAA ratings system. Other NR films may be from amateur producers who didn’t intend to have their film widely released.

NR (Not Rated) Programming may contain all types of programming including children’s programming, foreign programs, or adult material.

❒ G – General Audience

In the opinion of the review board, these films contain nothing in the way of sexual content, violence, or language that would be unsuitable for audiences of any age.

❒ PG – Parental Guidance

Parental Guidance means the movie may contain some contents such as mild violence, some brief nudity, and strong language. The contents are not deemed intense.

❒ PG-13 – Parents Strongly Cautioned

Parents with children under 13 are cautioned that the content of movies with this rating may include more explicit sexual, language, and violence content than movies rated PG.

❒ R – Restricted

These films contain material that is explicit in nature and is not recommended for unsupervised children under the age of 17.

❒ NC-17 – No One Under 17

These movies contain content which most parents would feel is too adult for their children to view. Content can consist of strong language, nudity, violence, and suggestive or explicit subject matter.

❒ X – No One under 18

Inappropriate material for anyone under 18.

Directions to set Movie (MPAA) Ratings

Press the MENU button

π†

√®

Press Z

π†

√®

To V-CHIP To operate (Lock icon appears)

ERO to access V-Chip setup options

To SET MOVIE RATINGS To enter movies menu

For example:

To block viewing of X and NC-17 rated from shows:

π† √®

Press the M

To the X Column

Press the OK button to lock

To the NC-17 Column

Press the OK button to lock

ENU button to finish

SET MOVIE RATINGS

SELECT OPERATE

EXIT

Initial Setup

Canadian V-Chip Ratings

❒ E – Exempt

Exempt programming includes: news, sports, documentaries and other information programming, talk shows, music videos, and variety programming.

❒ C – Programming Intended for Children

Violence Guidelines: There will be no realistic scenes of violence. Depictions of aggressive behavior will be infrequent and limited to portrayals that are clearly imaginary, comedic or unrealistic in nature.

❒ C8+ – Programming Intended for Children 8 and Over

Violence Guidelines: Any realistic depictions of violence will be infrequent, discreet, of low intensity and will show the consequences of the acts. There will be no offensive language, nudity or sexual content.

❒ G – General Audience

Programming will contain little violence and will be sensitive to themes which could affect younger children.

❒ PG – Parental Guidance

Programming intended for a general audience, but which may not be suitable for younger children. Parents may consider some content not appropriate for children aged 8-13.

❒ 14+ – 14 Years and Older

Parents are strongly cautioned to exercise discretion in permitting viewing by pre-teens and early teens. Programming may contain mature themes and scenes of intense violence.

❒ 18+ – Adult

Material intended for mature audiences only.

Directions to set Canadian V-Chip Ratings

Press the MENU button

π†

√®

To V-CHIP To operate (lock icon appears)

Press ZERO to access V-Chip setup options

π†

√®

To SET CANADIAN RATINGS ENG (for English) To enter ratings menu

For example:

To block viewing of programming rated 14+ and 18+:

√®

Press the M

To the 18+ Column Press the OK button to lock

To the 14+ Column

Press the OK button to lock

ENU button to finish

SET CANADIAN RATINGS ENG

14+

18+

SELECT OPERATE

EXIT

Note:

• For instructions on “SET CANADIAN RATINGS FRE (in French)”, please see page 45 in the French side of this user’s guide.

Initial Setup

Set Lock Code

Channel guard and V-Chip settings are protected by a four-digit lock code. Your TV comes preset with a lock code of “0000”. You may change the code to any four-digit number you wish. To change the lock code, follow the steps below.

Press the M

π†

√®

To SET LOCK CODE

To operate (lock icon appears)

Press Z

ENU button

ERO to access the lock code

SET LOCK CODE

LOCK CODE

0000

The first digit will be highlighted

√®

To select the number

π†

To move to the next digit

SELECT OPERATE EXIT

PRESS TO FINISH

Continue to follow these directions for all four numbers

Press the OK button to finish (your lock code is now set)

Press the Menu button when finished

When a viewer attempts to watch a blocked channel, this message appears:

THIS PROGRAMMING EXCEEDS YOUR RATING LIMITS. PLEASE ENTER LOCK CODE BY 10 KEY PAD TO UNLOCK IT. NO. - - - -

The channel will remain blocked until the correct lock code is entered (see above for information on setting your lock code).

Notes:

• After a power interruption you must reset the lock code.

• Write your lock code number down and keep it hidden from potential viewers.

• If you forget the lock code, a new code may be set using the steps listed above.

Auto Demo

This function lets you preview the Dynamic Gamma demo.

Initial Setup

Press the MENU button

π†

To AUTO DEMO

√®

To turn AUTO DEMO ON or OFF

Notes:

PREVIOUS AUTO TUNER SETUP CHANNEL SUMMARY V-CHIP SET LOCK CODE AUTO DEMO

INITIAL SETUP

• Auto demo starts 2 seconds after it is set to ON.

• To stop auto demo, press the M select auto demo by pressing the and turn it off by pressing the

ACK button to finish.

the B

ENU button, and

π†

buttons,

√®

buttons. Press

NEXT PAGE SELECT OPERATE EXIT

Image Shift

The picture displayed on the screen is shifted up, down and to the left and right at regular intervals. In order to prevent burn-in, set this function to FAST or STANDARD.

Press the M

π†

To IMAGE SHIFT

√®

π†

To enter

To select the mode “STD (STANDARD)”,

“FAST” or “OFF”

Press the M

OFF: IMAGE SHIFT is turned off.

STD: The picture is shifted every 30 minutes.

FAST: The picture is shifted every 10 minutes.

ENU button

ENU button when finished

PREVIOUS IMAGE SHIFT LANGUAGE CLOSED CAPTION AUTO SHUT OFF XDS ID

SELECT OPERATE EXIT

INITIAL SETUP

ENG. FRAN. ESP.

OFF

(4/5)

OFF

(3/5)

Language

The language function is described on page 27 as the interactive plug-in menu. If you need to choose the language again, follow the steps below.

Press the Menu button

π†

√®

To LANGUAGE

To choose a language: ENG. (English), FRAN.

(French) or ESP. (Spanish)

Press the MENU button when finished

PREVIOUS IMAGE SHIFT LANGUAGE CLOSED CAPTION AUTO SHUT OFF XDS ID

SELECT OPERATE EXIT

INITIAL SETUP

ENG. FRAN. ESP.

OFF

(3/5)

Initial Setup

Closed Caption

Many broadcasts now include an onscreen display of dialog called closed captions. Some broadcasts may also include displays of additional information in text form. Your television can access and display this information using the closed caption feature. To activate the closed caption feature, follow the steps below. There are three methods. When you are watching analog channels, you can perform Analog Setting of closed caption. When you are watching digital channels, you can perform Digital Auto Setting or Digital Manual Setting.

Analog Setting

Press the MENU button

π†

√®

π†

√®

π†

√®

To CLOSED CAPTION

To enter

To MODE

To select CAPTION or TEXT in MODE

To CAPTION or TEXT

To select a caption (CC1 to CC4) or text

channel (T1 to T4)

Press the OK button to save

Press the MENU button when finished

Digital Auto Setting

Press the MENU button

π†

√®

π†

√®

Auto: Shows closed caption a priority for

Advanced: Shows only the digital closed

Basic: Shows only the analog closed

π†

√®

π†

√® √®

π†

Press the OK button to save

The font/type and color are set automatically.

Press the M

To CLOSED CAPTION

To enter

To Type

To select Auto, Advanced or Basic

digital channels over analog channels. It is set automatically.

caption.

To Service

To select 1, 2, 3, 4, 5 or 6

To Appearance

To enter To select Auto

To Set

ENU button when finished

CLOSED CAPTION

AUTO

TEXTMODE

Exit

Auto

Exit

CAPTION TEXT

PRESS TO FINISH

SELECT OPERATE EXIT

Digital Closed Caption

Preview

Closed Caption Sample

Type

Service

Appearance

Cancel Set

Select

Digital Closed Caption > Appearance

Preview

Closed Caption Sample

Appearance Mode

Font

Colors

Opacities

Cancel Set

Select

Operate

BACK

Back

BACK

Back

CC1

Note:

• If you want to cancel the settings, select cancel.

Digital Manual Setting

Press the M

π†

√®

π†

√®

π†

√®

π†

√® √®

π†

√®

π†

√®

To CLOSED CAPTION

To enter

To Type

To select Auto, Advanced or Basic

To Service

To select 1, 2, 3, 4, 5 or 6

To Appearance

To enter To select Manual

To Font

To enter

To select Font Size or Font Style

To select the setting you like Font Size: Auto, Standard, Large or Small Font Style: Auto, Serif Mono, Serif, Sanserif mono,

Sanserif, Casual, Cursive or Small Capital

π†

To Set

Press the OK button to save

π†

√®

π†

√®

To Colors

To enter

To select Text, Edge or Background

To select the setting you like Auto, White, Black, Red, Green, Blue,

Yellow, Magenta or Cyan

π†

To Set

Press the O

π†

To Opacities

√®

To enter

π†

To select Text/Edge or Background

√®

To select Auto, Transparent, Translucent, Solid or Flashing

π†

To Set

Press the OK button to save

ENU button

K button to save

Initial Setup

Digital Closed Caption > Appearance

Preview

Closed Caption Sample

Appearance Mode

Font

Colors

Opacities

Cancel Set

Select

Operate

Digital Closed Caption > Appearance

Preview

Closed Caption Sample

Font Size

Appearance Mode

Font Style

Font

Colors

Opacities

Cancel Set

Select

Operate

Digital Closed Caption > Appearance

Preview

Closed Caption Sample

Tex t

Appearance Mode

Edge

Font

Background

Colors

Opacities

Cancel Set

Select

Operate

Manual

BACK

Back

Standard

Manual

Auto

Cancel Set

BACK

Back

White

Manual

White

Back

Black

Cancel Set

BACK

Exit

Press the MENU button when finished

Notes:

• Closed caption subtitles are usually found on closed caption channel CC1. Some programs may include additional text information which is usually found on text channel T1. The other channels are available for future use.

• Closed captioning may not work correctly if the signal being received is weak or if you are playing a video tape.

• Most broadcasts containing closed captioning will display a notice at the start of the program.

• To select the mode, press the C.C. button. See page 68.

Initial Setup

Auto Shut Off

This function automatically shuts off your TV when there is no signal from the channel the TV is on.

Press the M

π†

To AUTO SHUT OFF

√®

To turn ON or OFF

Press the M

ENU button

ENU button when finished

PREVIOUS IMAGE SHIFT LANGUAGE CLOSED CAPTION AUTO SHUT OFF XDS ID

• If the channel that you have on does not receive a signal for more than one minute, the blinking text “NOT RECEIVING A SIGNAL” appears on the screen,

SELECT OPERATE EXIT

and starts the countdown. If no signal is being received within 10 minutes, the TV shuts itself off.

• When i.LINK is displayed, Auto Shut Off will not work.

XDS ID

XDS ID Display provides a channel’s call letters, the network’s name, and even a program name. The XDS ID information is provided by the broadcaster.

Press the MENU button

π†

To XDS ID

√®

To turn ON or OFF

Press the MENU button when finished

PREVIOUS IMAGE SHIFT LANGUAGE CLOSED CAPTION AUTO SHUT OFF XDS ID

SELECT OPERATE EXIT

INITIAL SETUP

ENG. FRAN. ESP.

INITIAL SETUP

ENG. FRAN. ESP.

OFF

(3/5)

OFF

(3/5)

Initial Setup

Noise Muting

This feature inserts a blank grey screen over channels which are not broadcasting or are too weak to be received clearly.

Press the M

π†

√®

To NOISE MUTING

To turn noise muting ON or OFF

Press the M

Note:

• Noise muting will not work during auto tuner setup or when you operate channel summary.

• Noise muting will not work when the digital TV or i.LINK is displayed.

Front Panel Lock

This allows you to lock the keys on the front of the TV, so that a child may not accidentally change your viewing preferences.

Press the MENU button

π†

To FRONT PANEL LOCK

√®

To turn ON or OFF

Press the MENU button when finished

You can turn off this feature in the following ways:

• Unplug the power cord, and plug it back in. Do this if your batteries die, or you lose your remote control.

• Use the remote control.

• Press the MENU button on the front of the TV for more than 3 seconds. In this case, the OSD for FRONT PANEL LOCK will appear.

Note:

• To turn ON/OFF the TV, press the power button for more than 3 seconds. This feature will remain ON.

ENU button

ENU button when finished

PREVIOUS NOISE MUTING FRONT PANEL LOCK V1 SMART INPUT VIDEO INPUT LABEL POSITION ADJUSTMENT POWER INDICATOR

SELECT OPERATE EXIT

PREVIOUS NOISE MUTING FRONT PANEL LOCK V1 SMART INPUT VIDEO INPUT LABEL POSITION ADJUSTMENT POWER INDICATOR

NEXT PAGE SELECT OPERATE EXIT

INITIAL SETUP

OFF

LOW

OFF

LOW

(2/5)

Initial Setup

V1 Smart Input

This feature is used if you have connected an AV Receiver to your television. By turning this feature on, your television can automatically detect the signal source from your components that are connected to your AV Receiver.

Press the M

π†

√®

To V1 SMART INPUT To turn ON or OFF

Press the MENU button when finished

Notes:

• If you do not have an AV Receiver connected to your television, turn this feature OFF. By doing so, you can take advantage of using AV CompuLink components with your television.

• Some AV Receivers may not work with this function.

Video Input Label

This function is used to label video input connections for the onscreen displays.

Press the MENU button

π†

√®

π†

√®

To VIDEO INPUT LABEL

To operate

To select the desired video input

To select the desired preset input label (see

chart below)

Press the OK button to save

Press the M

Preset Labels

VCR

DVD

DVHS

STB

SAT

AMP

GAME

CAM

DISC

ENU button

ENU button when finished

Select when...

You have a VCR connected to the video input

You have a DVD connected to the video input

You have a Digital VCR connected to the video input

You have a Set-top Box connected to the video input

You have a Satellite Receiver connected to the video input

You have an Amplifier connected to the video input

You have a Video Game connected to the video input

You have a Video Camera connected to the video input

You have a Video Disc player connected to the video input

PREVIOUS NOISE MUTING FRONT PANEL LOCK V1 SMART INPUT VIDEO INPUT LABEL POSITION ADJUSTMENT POWER INDICATOR

SELECT OPERATE EXIT

NOISE MUTING FRONT PANEL LOCK V1 SMART INPUT VIDEO INPUT LABEL POSITION ADJUSTMENT POWER INDICATOR

INITIAL SETUP

OFF

LOW

SELECT OPERATE EXIT

VIDEO-1 VIDEO-2 VIDEO-3 VIDEO-4 DIGITAL-IN

SELECT OPERATE EXIT

INITIAL SETUP

VIDEO INPUT LABEL

PRESS TO FINISH

OFF

LOW

VCR DVD

SAT

GAME

STB

(2/5)

Initial Setup

Position Adjustment

Position adjustment allows you to adjust the position of the picture on the screen vertically when the aspect is set to panorama, cinema, or full.

Press the M

π†

To POSITION ADJUSTMENT

√®

π†

To enter

√®

To adjust the position

ENU button

Press the MENU button to finish

Notes:

OPERATE

RESET EXIT

• To reset the adjustment to the center, press the OK button.

• When the arrow disappears, while you are adjusting the position, the position is at it’s maximum limit.

• If you select regular size with aspect or Multi Screen, position adjustment option is not seen.

• When you change the screen size, perform the position adjustment again.

• Position adjustment allows you to adjust the screen position vertically and horizontally when the aspect is set PANORAMA ZOOM or CINEMA ZOOM for 720p signals.

Power Indicator

Power indicator allows you to adjust the brightness of the power indicator

Press the MENU button

π†

To POWER INDICATOR

√®

To adjust POWER INDICATOR LOW, HIGH

or OFF

Note:

PREVIOUS NOISE MUTING FRONT PANEL LOCK V1 SMART INPUT VIDEO INPUT LABEL POSITION ADJUSTMENT POWER INDICATOR

SELECT OPERATE EXIT

• If you set a timer on the TV, the power indicator will light even if the TV is on stand by.

INITIAL SETUP

OFF

LOW

(2/5)

Video-1 Monitor Out

This function allows you to set whether the signal, which comes from VIDEO-1 input terminal, should be output from MONITOR OUT terminal. If you select it from MONITOR OUT, set it to "ON".

Press the MENU button

π†

To VIDEO-1 MONITOR OUT

√®

To select ON or OFF

Press the MENU button to finish

PREVIOUS VIDEO-1MONITOR OUT TV SPEAKER AUDIO OUT DIGITAL-IN DIGITAL-IN AUDIO CENTER CH INPUT

SELECT OPERATE EXIT

INITIAL SETUP

OFF

VARI

SIZE1

DIGITAL

OFF

(1/5)

Initial Setup

TV Speaker

If your TV is connected to a stereo system, you can turn off the TV speakers and listen to the audio through your stereo.

Press the M

π†

√®

To TV SPEAKER To turn the TV’s speakers ON or OFF

Press the MENU button when finished

Notes:

• Before you turn the TV speaker setting from OFF to ON, make sure that the TV volume level is low! If the TV volume is set too high, the sound level will be extremely loud.

• After a power interruption, the TV speaker settings will return to “ON”.

Audio Out

If your television is connected to an external speaker source, audio out gives you the option of controlling the volume level with your TV’s remote control.

Press the MENU button

π†

To AUDIO OUT

√®

To VARI or FIX

Press the M

VARI: Lets you adjust the volume of the external speakers using the V remote control.

FIX: The volume of the external speakers is adjusted using the audio device’s remote control.

ENU button

ENU button when finished

OLUME+/– buttons on your TV’s

PREVIOUS VIDEO-1MONITOR OUT TV SPEAKER AUDIO OUT DIGITAL-IN DIGITAL-IN AUDIO CENTER CH INPUT

SELECT OPERATE EXIT

PREVIOUS VIDEO-1MONITOR OUT TV SPEAKER AUDIO OUT DIGITAL-IN DIGITAL-IN AUDIO CENTER CH INPUT

SELECT OPERATE EXIT

INITIAL SETUP

OFF

VARI

SIZE1

DIGITAL

OFF

VARI

SIZE1

DIGITAL

OFF

(1/5)

Digital-In

The DIGITAL-IN option can only be displayed in the INITIAL SETUP menu when a 480p picture signal is being input to the DIGITAL-IN terminal. This option adjusts the position when a 480p picture signal is being displayed on the screen. There are two types of 480p picture signals: 640x480 and 720x480. If the displayed picture is slightly shifted, the position can be adjusted by selecting either SIZE1 or SIZE2.

Press the M

π†

To DIGITAL-IN

√®

To enter

√®

To select SIZE1 or SIZE2

Press the M

ENU button

ENU button to finish

PREVIOUS VIDEO-1MONITOR OUT TV SPEAKER AUDIO OUT DIGITAL-IN DIGITAL-IN AUDIO CENTER CH INPUT

SELECT OPERATE EXIT

INITIAL SETUP

OFF

VARI

SIZE1

DIGITAL

OFF

(1/5)

Note:

The DIGITAL-IN menu can only be displayed when a 480p picture signal is input to the Digital-In terminal and the picture is being displayed on the screen.

Initial Setup

Digital-In Audio

This feature is used if you have a DTV or HDMI compatible component connected to your TV.

Press the M

π†

To DIGITAL-IN AUDIO

√®

To select “ANALOG” or “DIGITAL”

ENU button

Press the Menu button when ﬁ nished

Notes:

VIDEO-1MONITOR OUT TV SPEAKER AUDIO OUT DIGITAL-IN DIGITAL-IN AUDIO CENTER CH INPUT

SELECT OPERATE EXIT

• If your DTV or HDMI component is capable of digital audio and video, choose DIGITAL. If your DTV or HDMI component is capable of analog audio and digital video, choose ANALOG.

• Refer to your DTV or HDMI component’s instruction manual for more information.

• When you select DIGITAL, select PCM on Digital Sound in the Digital Setup menu. See page

74.

Center CH Input

When you are using a surround system, you can substitute the speaker of this television for the center speaker of your surround system. Set CENTER CH INPUT to ON when you use the speaker as the center speaker of your surround system. The volume differs when the TV is being utilized as the Center Channel Input versus when it is not.

Press the M

π†

To CENTER CH INPUT

√®

To adjust CENTER CH INPUT to ON or OFF

Press the MENU button when finished

Note:

• In order to use the CENTER CHANNEL SPEAKER feature, you need a video signal present as well as sound. Because of that we recommend using this feature for Home Theater setup only. If there is no video signal present, the TV will be muted.

• There are two different volume adjustment levels, one for regular TV and one for TV used as a CENTER CHANNEL. Please remember that when switching CENTER CHANNEL mode ON and OFF in TV menu.

ENU button

PREVIOUS VIDEO-1MONITOR OUT TV SPEAKER AUDIO OUT DIGITAL-IN DIGITAL-IN AUDIO CENTER CH INPUT

SELECT OPERATE EXIT

INITIAL SETUP

OFF

VARI

SIZE1

DIGITAL

OFF

VARI

SIZE1

DIGITAL

OFF

(1/5)

Picture Adjust

Picture Settings

These settings allow you to change and adjust the way the picture appears on your television.

TINT

Tint allows you to adjust the levels of red and green in your TV picture.

COLOR

The color function lets you make all the colors in the TV picture appear either more vivid or subtle.


Picture allows you to adjust the levels of black and white on the TV screen, giving you a darker or brighter picture overall.

BRIGHT

You can adjust the overall brightness of the TV picture with the Bright control.

DETAIL

The Detail feature adjusts the level of fine detail displayed in the picture.

Adjust the Picture Settings

Press the MENU button

π† To TINT, COLOR, PICTURE, BRIGHT or

DETAIL

√ ®

To enter

TINT

√ ®

To adjust the setting

π†

To move to the next setting

+02

PICTURE ADJUST

PREVIOUS TINT COLOR PICTURE BRIGHT DETAIL COLOR TEMPERATURE

SELECT OPERATE

Press the MENU button when finished

Color Temperature

You can decide how strong or dull the colors appear on the TV screen.

Press the M

π†

To COLOR TEMPERATURE

√®

To enter

COLOR TEMPERATURE LOW HIGH

√®

To set LOW or HIGH

Press the MENU button when finished

ENU button

PICTURE ADJUST

PREVIOUS TINT COLOR PICTURE BRIGHT DETAIL COLOR TEMPERATURE

SELECT OPERATE

00 00 00 00 00

STANDARD

HIGH

(1/2)

EXIT

STANDARD 00 00 00 00 00

HIGH

(1/2)

EXIT

Picture Adjust

Digital Noise Clear

With digital noise clear, this helps take our static or noise from a channel that may not be coming in clearly.

Press the M

π†

To DIG. NOISE CLEAR

√®

To enter

π†

To select the mode “LOW”, “HIGH” or “OFF”

Press the M

Color Management

This TV supports the COLOR MANAGEMENT function to ensure dull colors are compensated to produce natural hues.

Press the MENU button

π†

To COLOR MANAGEMENT

√®

To enter

π†

To select the mode “ON" or "OFF"

Press the M

Dynamic Gamma

JVC's Dynamic Gamma Circuitry (DGC makes it easier to see dark areas when a picture has many dark areas, and makes it easier to see the bright areas when a picture has many bright areas. DGC is turned on, DGC analyzes and adjusts the total level of picture brightness balance, especially in dark areas where the level of greyscale is often lost, turning completely to black DGC automatically enhances the detail in these dark areas providing a more dynamic image with ﬁ ner detail, so the optimum picture settings are automatically set for each picture. Normally use with DGC on.

Press the MENU button

π†

To DYNAMIC GAMMA

√®

To enter

π†

To turn ON or OFF

Press the MENU button when finished

ENU button

ENU button when finished

DIG. NOISE CLEAR

COLOR MANAGEMENT

DYNAMIC GAMMA

OFF

LOW

HIGH

OFF

Picture Adjust

Burn-in Image Reducer

When burn-in is minimal, burn-in and residual images may be softened with the BURN-IN IMAGE REDUCER function.

Press the M

π†

To BURN-IN IMAGE REDUCER

√®

To enter

REDUCING BURN-IN. PLEASE WAIT

Burn-in will be reduced by displaying snow on the screen for approximately 55 seconds, and white for approximately 5 seconds in sequence. Leave the television in this state for some time (more than a few hours).

Press the M

Reset

Reset resets all picture adjustments (tint, color, picture, bright, detail, color temperature, dig. noise clear, color management and dynamic gamma) at once to the default settings.

Press the MENU button

π†

To RESET

√®

To enter

The onscreen menu disappears for a moment,

Press the M

and then the settings are reset to the default setting for all the picture adjustments.

ENU button

ENU button to bring back to the normal screen.

PICTURE ADJUST

PREVIOUS STANDARD DIG. NOISE CLEAR COLOR MANAGEMENT DYNAMIC GAMMA BURN-IN IMAGE REDUCER

RESET

ENU button when finished

NEXT PAGE SELECT OPERATE EXIT

OFF

(2/2)

Sound Adjust

Sound Settings

These settings allow you to change and adjust the sound on your television.

You can increase or decrease the level of low-frequency sound in the TV’s audio with

BASS –

TREBLE –

BALANCE –

Adjust the Sound Settings

Press the MENU button

π† To BASS, TREBLE or BALANCE

√ ®

π†

Press the MENU button when finished

Note:

• You can reset the sound adjustments (BASS, TREBLE and BALANCE) you set at once as

• You can adjust BALANCE only when A.H.S. is off. See page 65.

the bass adjustment.

Use treble to adjust the level of high-frequency sound in your TV’s audio.

Adjust the level of sound between the TV’s left and right speakers with the

balance setting.

To adjust the setting

To move to the next setting

the default setting when you select reset. See page 58.

SOUND ADJUST

PREVIOUS BASS TREBLE BALANCE

RESET

NEXT PAGE SELECT OPERATE EXIT

00 00 00

Reset

Reset resets all Sound Adjustments (Bass, Treble and Balance) at once to the default settings. See page 58 on how to use reset.

Clock/Timers

Set Clock

The set clock function is described on page 28 as the interactive plug-in menu. You can choose to set the clock automatically or manually. If you need to set the clock again, follow the steps below.

Press the M

π†

To SET CLOCK

√®

To enter

When you set the clock automatically, choose AUTO by pressing the

π†

√®

π†

√®

To TIME ZONE

To select your time zone

ATLANTIC

To D.S.T. (daylight savings time)

To turn D.S.T. ON or OFF

Press OK to finish

Press the MENU button when finished

When you set the clock manually, choose MANUAL by pressing the

π†

√®

π†

√®

π†

√®

To move to the hours

To set the hours

To move to minutes

To set the minutes

To TIME ZONE

To select your time zone:

(Atlantic, Eastern, Central, Mountain, Pacific,

Alaska or Hawaii)

π†

To DATE/YEAR

√®

To set the month

π†

To day

√®

To set the day

π†

To year

√®

To set the year

π†

To D.S.T. (daylight savings time)

√®

To turn D.S.T. ON or OFF

Press OK to start clock

ENU button

HAWAII

√

or ® arrows.

EASTERN

ALASKA

CENTRAL

PACIFIC

MOUNTAIN

√

or ® arrows.

SET CLOCK

MODE

TIME

TIME ZONE

DATE/YEAR

D.S.T.

SELECT OPERATE EXIT

SET CLOCK

MODE TIME TIME ZONE DATE/YEAR D.S.T.

SELECT OPERATE EXIT

PRESS TO FINISH

PRESS TO START CLOCK

AUTO

: --

ATLANTIC

JAN/01/05

MANUAL

: --

ATLANTIC

JAN/01/05

THANK YOU !!

Press the MENU button when finished

Notes:

• D.S.T. can be used when it is set to ON in the SET CLOCK menu.

• Only when the MODE set to AUTO, the Daylight Savings Time feature automatically adjusts your TV’s clock for Daylight Savings. The clock will move forward one hour at 2:00 am on the first Sunday in April. The clock will move back one hour at 2:00 am on the last Sunday in October.

• You will have to reset the clock after a power interruption. You must set the clock before operating any timer functions.

Clock/Timers

On/Off Timer

The on/off timer lets you program your television to turn itself on or off. You can use it as an alarm to wake up, to help you remember important programs, or as a decoy when you’re not home.

Press the M

π†

√® √®

To ON/OFF TIMER

To operate (begins with ON TIME)

To set the hour (AM/PM) you want the TV to

turn on

†

To move to minutes

√®

To set the minutes

†

To accept ON TIME and move to OFF TIME (the time the TV will turn off). Set the

OFF TIME the same way as ON TIME

†

To accept OFF TIME and move to CHANNEL

√®

To select channel

†

To ON VOLUME

√®

To set the volume level

†

To move to MODE

√®

Choose ONCE or EVERYDAY

†

To ON/OFF TIMER

√®

Choose YES to accept the timer setting, choose NO if you don’t wish to accept

Press the OK button to finish

Press the MENU button to exit the menu

ENU button

ON/OFF TIMER ON TIME OFF TIME CHANNEL ON VOLUME MODE ON/OFF TIMER

SELECT OPERATE EXIT

PRESS TO FINISH

7:00 PM

10:00 PM

CURRENT

EVERYDAY

Notes:

• The on/off time cannot be set to locked or guarded channels.

• In order for the on/off timer to work, the clock must be set.

• After a power interruption, the timer settings must be reset.

Button Functions

Multi Screen Function

Your television has two kinds of screen: TWIN (2 channels) and INDEX (12 channels).

Note: After you press any multiscreen button, if you press the menu button, only the picture

adjust screen will appear.

Index

This allows you to quickly look at up to 12 channels at a time so that you can decide which one to watch.

Notes:

• Only RF input signal will be displayed.

• You can watch the channel added in channel summary. See page 38.

Twin

Activate the split-screen option by pressing Twin on the remote control. The channel (or input) you were watching before pressing Twin will appear on the left, the new channel will appear on the right. The sound will continue to come from the main screen channel (or input). To turn split-screen off and return to normal television viewing, press TWIN again or press

ACK button.

the B

MAIN SCREEN


SPLIT SCREEN


V-1

Notes:

• If the signal that you are watching is coming from the HDMI input, you cannot enter the TWIN mode

• Main Screen and Split Screen will not display the same channel or input at the same time.

• You can enter the TWIN mode when the screen is in NORMAL or INDEX mode.

• Split-screen functions will not work with locked channels or channels blocked by V-Chip

ratings limits. A grey screen will display instead.

• With split screen, the picture from the component terminal and DIGITAL-IN terminal will

not be displayed.

• The aspect of MAIN CHANNEL PICTURE becomes 16:9 when you input the picture of

480p from the component terminal and DIGITAL-IN terminal.

• After you press the Select button, and select SPLIT SCREEN when you press the OK button, select normal screen. If you don’t operate, the MAIN CHANNEL SCREEN will be automatically selected about 8 seconds later.

• Aspect does not work in Twin mode.

• When you press the M

ENU button in Twin mode, it appears only as Picture Adjust menu.

• When it is PC output, Main and Split screen will not be displayed.

Button Functions

Freeze

Pressing the FREEZE button causes the screen to change to the split-screen display with the still picture displayed on the right. In order to return to the normal display, press the F once again.

Note: When the screen is in freeze mode, if you do not operate it within 15 minutes, this function will cancel out.

Swap

You can exchange the channel (or input) displayed in the split screen window for the main screen image by pressing the SWAP button.

Note:

• It will only work in TWIN mode.

Select

With SELECT, you can select the picture (channel) while viewing SPLIT screen. When you

ELECT button, the channel number on the top will be highlighted. Each press of SELECT

press S will shift the channel.

REEZE button

Button Functions

Power

Turns the TV on or off.

Press the P

Number Buttons - 10Key Pad

Use the number buttons on the remote control to move directly to a specific channel. For example, to move to channel 12:

0 (Zero)

1 (One)

2 (Two)

Tune

Lets you decide the input channel and select it. After you press the number buttons on the remote, press the TUNE button. For example, to move to channel 12:

1 (One)

2 (Two)

Press the TUNE button

Input

Selects the signal input source for the television: VIDEO-1, 2, 3, 4, DIGITAL-IN or i.LINK for video devices like VCRs, DVD players or camcorders.

Press the INPUT button

By every press of the INPUT button, you can change the input mode.

Notes:

• When you return to TV mode, press the RETURN +/TV button or direct 10 key pad or CHANNEL +/– button.

• You can also access the FRONT CONTROL PANEL screen by using the M the side of the TV instead of the remote control. It appears between INITIAL SETUP and PICTURE ADJUST screen, and it has INPUT, VIDEO STATUS and ASPECT menus. Choose INPUT by pressing MENU† on the side panel and choose a mode by using the CHANNEL+/- buttons ( √ OPERATE ® ).

• i.LINK can be selected only when you have an i.LINK device connected.

• If you have a PC connected to the TV, select VIDEO-4.

OWER button

ENU button on

TheaterPro D6500K

The TheaterPro D6500K color temperature technology function makes sure that the video you watch is set to the standard color temperature, so that what you see is as true to what the film to video editors intended it to be.

Press the THEATERPRO button

Button Functions

Return +/TV

The RETURN+/TV button has three functions:

Return - Returns to the channel viewed just before the channel currently onscreen.

Return+ - Lets you program a specific channel to return to while scanning through the

TV - Returns to the TV mode.

Press the R

channels using the CH+ and CH– buttons.

ETURN+/TV and hold for three seconds

RETURN CHANNEL

PROGRAMMED!

The channel currently active has been programmed as your return+ channel. Now scan

through the channels using the CHANNEL+/– buttons.

Press the RETURN+/TV

You will return to your programmed channel.

• To cancel your return+ channel, press and hold the R

ETURN+ button for three seconds. The

message “RETURN CHANNEL CANCELLED!” will appear.

• Return+ works only with the Channel+/– buttons. Pressing any number key will cancel return+.

Sound

By pressing the SOUND button, you can change the A.H.S. (Advanced Hyper Surround) mode, BBE, SMART SOUND and A.H.B (Active Hyper Bass) on or off.

A.H.S. - Adds a more spacious surround sound. Music gives basic effect and movie for more

BBE - BBE High Definition Sound restores clarity and presence for better speech intelligibility

SMART SOUND - Decreases high sound levels, giving a regulated sound level.

A.H.B. - You can reinforce the bass sound to maintain rich, full bass at low volumes, and enjoy

Press the S

π†

√®

Press the MENU when finished

effect.

and musical realism.

a clear sound with boosted bass.

OUND button

To select A.H.S., BBE, SMART SOUND or A.H.B.

To choose the setting

SOUND EFFECT A.H.S. BBE SMART SOUND A.H.B.

OPERATE EXIT

SELECT

MOVIE MUSIC OFF

ON OFF

ON OFF ON OFF

Manufactured under license from BBE Sound, Inc. Licensed by BBE Sound, Inc. under USP4638258, 5510752 and 5736897. BBE and BBE symbol are registered trademarks of BBE Sound, Inc.

Note: Smart Sound may become an unnatural effect, depending on the signal source.

Button Functions

Muting

The MUTING button instantly turns the volume down completely when you press it. Press

UTING and the volume level will instantly go to zero. To restore the volume to its previous

M level, press M

Video Status

The VIDEO STATUS button gives you a choice of four TV picture display settings, including a display of your own preferences.

Standard - Resets the picture display to the factory settings.

Dynamic - Gives a vivid picture with better contrast when viewing in

Theater - Gives a rich, film-like look to video when viewing in a

Game - Used for when you are playing video games connected to

Press the V By every press of the VIDEO STATUS button, you change the mode.

Note:

• You can also change the mode by pressing the π† buttons.

• You can also access the FRONT CONTROL PANEL screen by using the MENU button on the side of the TV instead of the remote control. It appears between INITIAL SETUP and PICTURE ADJUST screen, and it has INPUT, VIDEO STATUS and ASPECT menus. Choose VIDEO STATUS by pressing M CHANNEL +/- buttons ( √ OPERATE ® ).

UTING again.

a brightly lit room.

dimly lit room.

your TV.

IDEO STATUS button

ENU

†

VIDEO STATUS

STANDARD

DYNAMIC THEATER

GAME

on the side panel and choose a mode by using the

Natural Cinema

Natural cinema corrects the problem of blurred edges which may occur when viewing a program originally shot on film (such as motion pictures) or animation. If you notice blurring at the edges of these programs, press N conversion errors that occur when film, which is shot at 24 frames-per-second, is broadcast at the television rate of 30 frames-per-second.

Press the NATURAL CINEMA button

Notes: The natural cinema mode is automatically set to “AUTO” in the

following cases:

• Turning on or off

• Changing the channel or input mode

• Using multi-screen functions

• If you are in PC mode, Natural Cinema can not be used

ATURAL CINEMA and set it to AUTO. Natural Cinema helps correct

NATURAL CINEMA

AUTO

OFF

Button Functions

Sleep Timer

The Sleep Timer can turn the TV off for you after you fall asleep. Program it to work in intervals of 15 minutes, for a total time of up to 180 minutes.

Press the S

LEEP button

0 15 30 45 60 75 90 105 120 135 150 165 180

Sleep Timer Message

20 seconds before the automatic shutoff, this message will appear:

GOOD NIGHT!!

PUSH SLEEP TIMER BUTTON

You then have 20 seconds to press the SLEEP button to

delay the shut off for another 15 minutes.

TO EXTEND

ML/MTS

MTS technology allows several audio signals to be broadcast in analog at once, giving you a choice in what you wish to hear with a TV program. In addition to mono or stereo sound, an MTS broadcast may also include a second audio program (SAP).

Press the ML/MTS button

By every press of the ML/MTS button, you change

the mode

ON AIR

MTS

STEREO

SAP

MONO

Notes:

• When you are receiving a digital broadcast, if there are other languages, you can change the language by pressing the M

• Keep the TV in stereo mode to get the best sound quality. The sound will work in stereo mode even if a certain broadcast is in mono sound only.

• Choose the mono setting to reduce excessive noise on a certain channel or broadcast.

• Selecting SAP will allow you to hear an alternative soundtrack, if one is available.

• MTS unavailable if your television’s Input source is in input 1, 2, 3 or 4 mode, as described on page 64.

• ML/MTS will not work when you are using the Digital-In.

• You can also change the mode by pressing the

L/MTS button.

π†

buttons.

Button Functions

Display

The display screen shows the current status of timers, inputs and XDS ID.

Press the D

ISPLAY button

The screen to the right shows the following information:

The current channel or AV input (Channel 05)

•

• The current time (12:20 pm)

• Sleep timer status/minutes remaining (The Sleep Timer is off)

• On/off timer status (Set to turn on everyday at 7: 00 PM, off at 10:00 PM)

• Each Press of the DISPLAY button changes the display mode:

05 KLVX PBS JAZZ FESTIVAL NOW SLEEP TIMER ON/OFF TIMER ON TIME OFF TIME

Display Time Channel Off

Display - Full screen shown above

Time - Shows the current time only

Channel - Shows the current channel

Off - Turns display off

Notes:

• You may also turn off the display at any step by pressing M

• If the clock, sleep timer or on/off timer are not set, the display screen will show: “CLOCK NOT SET”, “SLEEP TIMER OFF”, and “ON/OFF TIMER OFF” respectively.

ENU.

C.C. (Closed Caption)

Use the C.C. (Closed Caption) button to select the mode of closed caption.

Press the C.C. button

Notes:

• SMART CAPTION will appear when you press the M only on channels where the broadcast contains closed captioning.

• When you select ON, it will be the mode selected in the Closed Caption Menu.

• See page 48 when you set the caption/text mode.

• You can also change the mode by pressing the

• If you are in PC mode, C.C. can not be used

UTING button,

π†

buttons.

CLOSED CAPTION

SMART CAPTION

12:20 PM

OFF

EVERYDAY

7:00 PM

10:00 PM

OFF

Channel +/–

Use these buttons to move up or down all the available channels your TV is able to receive.

Volume +/–

Use these buttons to raise or lower the TV’s volume level.

Button Functions

Favorite

The Favorite button allows you to select your favorite channels easily. First, you must register the channels that you like. See how to register below.

Press the F

π†

To select the channel you want to watch

Press the OK button

Press the channel number you want to register

Press the FAVORITE button for three seconds

Notes:

• Both analog and digital channels can be registered. The digital channels have a "D" in front of the channel number.

• The maximum number of channels you can register is 24.

• If you have registered the maximum number of channels, and try to register more channels, the oldest channel you registered will be deleted.

• Sub channels can not be registered.

• The newest channel you registered will appear at the top of the list.

• Regarding digital channels, see pages 76 - 81.

AVORITE button

The favorite channel list will appear.

It will change to the channel you have selected.

The channel program will change.

The channel will be registered in the favorite channel list.

D103

D107

101 102

FAVORITE

CBS FOX

PBS2

> HBO ABC

Delete the favorite channel

Press the FAVORITE button

π†

√®

To enter

Press the OK button

Press the FAVORITE button when finished

Note:

• Before pressing the F you can return to the deleted channel.

The favorite channel list will appear.

To select the channel you want to delete

The channel was deleted.

AVORITE button when you are finished, press the

√®

button again, and

Button Functions

Aspect

This feature will help you adjust the picture you are watching to give you the best possible picture quality.

Aspect Ratios

PANORAMA - With this ratio a normal

4:3 aspect picture is stretched to fit the dimensions of the 16:9 aspect screen.

CINEMA - This ratio “zooms in” on the center part of a 4:3 aspect picture, blowing it up to fill the 16:9 screen.

FULL - This is the ratio to use when watching 16:9 High-Definition broadcasts.

PANORAMA ZOOM - This ratio stretches the High-Definition 16:9 aspect image to eliminate the black side bars.

REGULAR - The regular ratio is used when you want to watch a 4:3 broadcast or recorded program without modifying the original picture to fit the dimensions of your 16:9 screen. The 4:3 picture will fill the screen from top to bottom, while black bars will appear to fill up the remaining space along the picture’s sides. The 4:3 picture will be centered within the boundaries of the 16:9 screen.

CINEMA ZOOM - This ratio stretches the High-Definition 16:9 aspect image to eliminate the black surrounding bars.

Button Functions

Aspect Ratios (Continued)

Press the ASPECT button

• By pressing the A

When you change the aspect ratios, it is different from their broadcast or recorded program.

SPECT button, you can change the size.

HD (720p)NTSC, 480i, 480p

ASPECT

PANORAMA

CINEMA

FULL

REGULAR

Notes:

• You can also choose the size by pressing the

• When you change the aspect ratio or signal, reset the picture position to center.

• You can also access the FRONT PANEL CONTROL screen by using the MENU button on the side of the TV instead of the remote control. It appears between INITIAL SETUP and PICTURE ADJUST screen, and it has INPUT, VIDEO STATUS and ASPECT menus. Choose ASPECT by pressing Menu† on the side panel and choose a mode by using the CHANNEL +/- buttons (

√

OPERATE ® ).

PANORAMA ZOOM

π† buttons.

ASPECT

CINEMA ZOOM

FULL

The MENU button allows you to access JVC’s onscreen menu system. Press MENU to activate the onscreen menu system.

• See individual topics like “Sound Adjust” for specific information on using menus.

This button confirms your selection when you are in one of the onscreen menus.

Back

This button allows you to go back in the menu to change a selection or correct a mistake.

Button Functions

TV/CATV Slide Switch

Use either the television’s own tuner or a cable box to select channels. Set this switch to TV to operate the television’s built-in tuner. Move the switch to CATV to operate a cable box.

Note:

• See page 30 for information on programming your remote for cable box operation.

VCR/DVD Slide Switch

You can control a VCR or DVD player with the buttons on the lower part of the remote control. Move the slide switch to VCR or DVD to operate.

Notes:

• The remote is preset with the code 000 to control JVC-brand VCR’s. For any other manufacturer’s brand VCR, please see the code chart and instructions on page 31.

• The remote is preset with the code 000 to control JVC-brand DVD players. For any other manufacturer’s brand DVD player, please see the code chart and instructions on page 32.

VCR Buttons

You can use this remote control to operate the basic functions of your VCR. These functions include: play, record, rewind, fast-forward, stop, pause, channel scan, TV/VCR, power on and power off.

Move the selector switch to VCR to operate.

• The remote is preset with the code 000 to control JVC-brand VCR’s. For any other manufacturer’s brand VCR, please see the code chart and instructions on page 31.

DVD Buttons

You can also use this remote control to operate the basic functions of your DVD player. These functions include: play, rewind, fast-forward, stop, still/pause, previous/next, tray open/close, power on and power off.

Move the selector switch to DVD to operate.

• The remote is preset with the code 000 to control JVC-brand DVD players. For any other manufacturer’s brand DVD player, please see the code chart and instructions on page 32.

Light

All remote control buttons are illuminated, except for the TV/CATV slide switch, VCR/DVD slide switch and Light button. Press the LIGHT button to turn the illumination on for 4 seconds.

Digital Setup

Use this function when you are receiving a digital broadcast.

Press the M

π†

√®

To DIGITAL SETUP

To enter

The onscreen will appear

Notes:

• Software Update will only appear when the SD Card is inserted.

• If you are watching an analog channel, you can still access the digital setup menu at anytime, while you are doing this, the background screen will turn blank. In this case, the tuner will switch to digital, since you are accessing the digital setup menu.

Antenna Level

Confirms the present antenna level.

Press the MENU button

π†

√®

π†

√®

Note:

• If you are watching an analog channel or a signal from your i.Link device, antenna level will

To DIGITAL SETUP

To enter

To Antenna Level

To enter

not appear.

ENU button

Digital Setup

Antenna Level

Digital Sound

Aspect Ratio

Cable Card Application

i.LINK Auto Play

Software Update

Select

BACK

Back

BACK

Back

Operate

Antenna Level

Exit

PCM

4:3

OFF

Exit

Digital Setup

Digital Sound

You can select the optical digital sound output, either PCM or Dolby Digital when your TV is connected to an amplifier that has Dolby Digital decoder. If you select Dolby Digital, you can enjoy listening in 5.1ch sound when watching digital broadcasts.

Press the M

π†

√®

π†

√®

Notes:

• If your amplifier does not have Dolby Digital decoder, select PCM. If you don't select PCM, it

• For connecting an amplifier using the optical output, see page 20.

To DIGITAL SETUP

To enter

To Digital Sound

To select PCM or DOLBY DIGITAL

Press the M

cannot output the sound from the speakers.

ENU button

ENU button when finished

Manufactured under license from Dolby Laboratories. "Dolby", and the double-D symbol are trademarks of Dolby Laboratories.

Aspect Ratio

You can select the aspect mode for ATSC from 4:3 or 16:9.

Press the MENU button

π†

√®

π†

√®

Press the MENU button when finished

Notes:

• Set the mode to 4:3 or 16:9 before you record a program using the ATSC MONITOR OUT.

• Make sure the mode you choose is the same as the TV’s aspect ratio when the recorded

To DIGITAL SETUP

To enter

To Aspect Ratio

To select 4:3 or 16:9

program is played back, so that you can obtain a good picture quality, free from any unatural distortions.

Digital Setup

Cable Card Application

Press the MENU button

π†

√®

π†

√®

Press the OK button

The application will perform

i.LINK Auto Play

When playing a D-VHS tape, you can set it to the i.LINK input automatically, or manually.

Press the MENU button

π†

√®

π†

√®

ON: Set to i.LINK input automatically OFF: Select the input manually

Press the M

To DIGITAL SETUP

To enter

To Cable Card Application

To enter

To DIGITAL SETUP

To enter

To i.LINK Auto Play

To select ON or OFF

ENU button when finished

Software Update

At first, insert the SD(Multi-media) card into the memory card slot. This function will appear only when you insert an SD Card.

Press the M

π†

To DIGITAL SETUP

√®

To enter

π†

To Software Update

√®

To enter

π†

Checks the card if it needs an update or not

Press the MENU button when finished

ENU button

Digital Button Functions

Digital CH D/A (Digital/Analog)

The D/A button changes the analog and digital channel. Each time you press the D/A button, you can switch back and forth the analog and digital channels. Digital channels have a "D" in front of the channel number.

Note:

• If the cable card is inserted into the TV, you cannot use the D/A button. You can select a digital channel only.

Press the D/A button

To watch digital channels

For example, to move to channel D23:

Press 2 (Two)

Press 3 (Three)

Press the T

Sub Channel

The main channel sometimes has minor channels (Sub Channels). By using the SUB button, you can select a sub channel easily.

For example, to move to sub channel 123-45:

Press 1 (One)

Press 2 (Two)

Press 3 (Three)

Press the SUB button

Press 4 (Four)

Press 5 (Five)

Press the TUNE button

UNE button

Note:

• If there are more than 2 major channels, select the digital channel by using the π† buttons and then press the OK button.

Digital Button Functions

i.LINK Menu

i.LINK has two menus - Controller and Device.

By connecting a D-VHS VCR with an i.LINK cable, you can set the timer easily.

Notes:

• The i.LINK/Timer function will only work when you are receiving digital programming only.

• As for the connection of a D-VHS VCR with the i.LINK cable, see page 26.

• When operating the i.LINK, don't insert or disconnect the i.LINK cable.

Controller

You can operate a D-VHS VCR connected with an i.LINK cable by using this controller.

Notes:

• If the i.LINK is not connected, the Controller OSD will not appear. The OSD of device on page 78 will appear.

• Some controller operations may differ from your D-VHS VCR operations.

Press the i.LINK MENU button

i.LINK

D-VHS1

Device

√®

π†

To select the key you want to operate

Press the OK button

Controller

STOP 00:00:00

POWER

Digital Button Functions

Device

To operate, select a device.

i.LINK

Controller Renumber

Device

D-VHS1

HM-DH30000U

D-VHS2

HM-DH40000U

HD-MOVIE 1

GR-HD1

π†

To select your device connecting with i.LINK

Press the OK button

Notes:

• If you do not select the device, you cannot use the i.LINK timer functions.

• When one device is selected and you select controller, you will move to the Controller onscreen.

• The devices listed on the device onscreen are only D-VHS and HD-MOVIE that have i.LINK, which can be recognized on this television. However, you can not record programs to HDMOVIE.

• If you disconnect one device, it will be removed from the list. Then, select Renumber to rearrange the list in the new order.

Page 2/3

JVC

Digital Button Functions

Timer

You can set the two timers: Record and view. The timer starts the recording or turns to the channel you set for it automatically.

Reservation

Press the T

π†

To New Reservation

Press the O

†

To Timer Mode

√®

To select Rec or View

†

To Channel

√®

To select the channel you want to set the timer for

†

To Date

√®

To select the date

†

To Start Time

√®

To set the start time

†

To End Time

√®

To set end time

†

To Weekly/Daily

√®

To select Once, Weekly, Daily(Sun.-Sat.), Daily(Mon.-Sat.) or Daily(Mon.-Fri.)

†

To Rec to i.LINK

√®

To select ON or OFF

†

To Set Timer

Press the OK button

If you set the Rec on timer mode, set recording is added in front of the program

title.

If you set the View on timer mode, set viewing is added in front of the program

title.

Notes:

• In order for the timer setting to work, you must set the clock on your television. See page

60.

• When you want to edit the timer settings, see Timer Edit on page 80.

IMER button

K button

New Reservation

Timer Mode

0. New Reservation

New Reservation

80-3 PBS1DTV

Sep. 11 (Wed) 6:00PM - 6:30PM Once

335-1 KDVRet Retailer News Channel

i.LINK

Sep. 11 (Wed) 6:00PM - 7:00PM Mon - Fri

335-1 KDVRet Regular Schedule

Sep. 18 (Wed) 5:00PM - 6:00PM Daily

35-1 PBPBPB

i.LINK

Sep. 18 (Wed) 8:00PM - 8:30PM Weekly

Channel

Date

Start Time

End Time

Weekly/Daily

Rec to i.LINK

Cancel

Sept. 10 (Wed) 4:55PMTimer

Set Timer

Page 1/3

Sep. 10 (wed)

5:00PM

6:00PM

Weekly

Rec

35-1

Digital Button Functions

Timer Edit

When you want to confirm the timer you set or edited, or delete the timer setting, use this function.

Timer Edition

Press the TIMER button

π†

To select the timer list you want to edit

Press the O

√®

π†

To change the setting you want to edit

†

To Set Timer

Press the OK button

K button

Timer Edit

Timer Mode

0. New Reservation

i.LINK

Channel

Date

New Reservation

Start Time

80-3 PBS1DTV

End Time

Sep. 11 (Wed) 6:00PM - 6:30PM Once

335-1 KDVRet Retailer News Channel

Weekly/Daily

Sep. 11 (Wed) 6:00PM - 7:00PM Mon - Fri

Rec to i.LINK

335-1 KDVRet Regular Schedule

Sep. 18 (Wed) 5:00PM - 6:00PM Daily

35-1 PBPBPB

Sep. 18 (Wed) 8:00PM - 8:30PM Weekly

Cancel

Sept. 10 (Wed) 4:55PMTimer

Set Timer

Rec

35-1

Page 1/3

Sep. 10 (wed)

5:00PM

6:00PM

Weekly

Delete

Timer Deletion

Press the TIMER button

π†

To select the timer list you want to delete

Press the OK button

π†

To Delete

Press the OK button

Digital Button Functions

Cancel the timer recording

When you record a digital program now, you can cancel the recording.

Press the T

π†

To select the timer list you want to cancel

the recording

Press the OK button

The message "Do you want to

IMER button

0. New Reservation

New Reservation

80-3 PBS1DTV

Do you want to terminate current program?

Sept. 11 (Wed) 6:00PM - 6:30PM Once

335-1 KDVRet Retailer News Channel

i.LINK

Sept. 11 (Wed) 6:00PM - 7:00PM Mon - Fri

No Yes

Sep. 10 (Wed) 4:55PMTimer

Page 1/1

terminate current program ?" will appear.

√®

To select

YES: Cancel the recording NO: Continue the recording

Press the OK button

Guide

You can view the program from the GUIDE.

Notes:

• The GUIDE function will only work when you are receiving digital programming only.

• The GUIDE will not show the correct time and date if you have not performed the set clock function on your television. See page 60.

OSD Information

Weak Signal

This OSD warning appears when the digital channel that you have selected is too weak to receive or no signal is being detected for that channel.

Weak Signal

No Program

If the TV channel you selected, or were watching is not receiving a signal, "NO PROGRAM" appears on the television screen. It appears when that channel is not receiving a signal and you have the Noise Muting function OFF and you have a single screen. It moves automatically every two seconds to prevent the screen from burn-in.

Note:

• Even if "NO PROGRAM" appears on the screen, your timer functions and auto shut off functions that you set, are still active.

Cable Card Information

Cable card offers information when a cable card is inserted into the CABLE CARD slot underneath the television.

Notes:

• Please contact your local cable company regarding detailed information.

• When the cable card is inserted into the cable card slot, if you turned the power off, the fan will continue to rotate because the program information is being renewed. This is normal.

Cable Card Connection

CABLE CARD

ATSC /DIGITAL CABLE IN

CABLE CARD

Note for inserting Cable Card:

• When you are watching a digital program, and if a weather or government emergency occurs, the following may occur automatically regardless of what channel you were watching: the channel may change, the screen will disappear or important text will appear on the screen. The information is transmitted from EAS (Emergency Alert System), Firmware Upgrade of Cable Card or compulsory HTML.

Troubleshooting

Refer to the table below to check the condition. If you think that there is a problem, contact the JVC Service Center where you purchased the television.

PROBLEMS CHECK

There is no power

• See if the power cord became unplugged.

• Check for a blown fuse or circuit breaker or a power outage.

There is no picture or sound

Remote control is not operating properly or at all

You cannot select a certain channel

The power turns off by itself

It does not operate correctly

The clock is wrong

The color quality is poor

There are lines across the picture

The picture is spotted

There are double pictures (ghosts)

Picture is snowy (image noise)

• The antenna could be disconnected.

• The input mode could be set improperly. See page 64.

• The tuner (Auto Tuner Setup) could be set improperly. See page 37.

• The TV station may be having difficulties. Check to see if other stations are working.

• Check to see that the batteries are still working and properly installed.

• Make sure the remote has a clear sight path to the TV.

• Check that the TV/CATV switch is in the proper position.

• You may be too far from the TV. You must be within 23 feet (7 meters).

• Make sure the channels have been programmed. See "Channel Summary", page 39.

• Check to see if the channel is locked. See "Channel Summary - Lock" page 40.

• Make sure the set did not become unplugged.

• Perhaps the On/Off Timer is set. See page 61.

• Check to see if the Sleep Timer was set. See page 67.

• This television is operated by a microprocessor. It is possible that external noise or interference is causing the problem. If the television does not function correctly, remove the electrical plug from the wall outlet and wait a while before inserting it into the wall outlet again and operating the television.

• The power was interrupted and the clock was not reset. See page 60.

• Tint and Color may be improperly adjusted. See page 56.

• The Video Status mode may be turned to the wrong setting. See page 66.

• There could be interference from another electrical appliance, such as a computer, another TV or VCR. Move any such appliances further away from the TV.

• There could be interference from a high-wattage appliance, like a hairdryer or vacuum, operating nearby. Move the antenna away from the appliance or change to a coaxial cable connection which is less prone to interference.

• A building or passing airplane can reflect the original signal and produce a second, slightly delayed one. Adjust your antenna position.

• Your antenna may be damaged, disconnected or turned. Check the antenna connection. If the antenna is damaged, replace it.

Screen is 80% black

Stereo or bilingual programs can't be heard

• The Closed Caption Text mode is on. Turn it off in the Closed Caption Menu, page 48.

• Make sure the MTS settings are correct. See page 67.

Troubleshooting

PROBLEMS CHECK

There is no sound from the TV's speaker

Static electricity

• The Center CH Input may be turned on. See page 55.

• The TV Speaker option may be turned off. See page 54.

• It is normal to feel static electricity if you brush or touch the screen.

You hear occasional crackling sounds

The AUTO DEMO finished automatically

It does not operate correctly

• It is normal for the TV to make crackling sounds when first turned on or off. Unless the sound or picture become abnormal, this is fine.

• The TV recieved a signal from the AV CompuLink

• The On Timer that you programmed has started.

• The channel that the AUTO DEMO is using is a channel that is blocked by V-Chip.

• The Auto Shut Off that you programed has occured.

• Press the CHANNEL- and VOLUME- buttons on the front panel of the TV simultaneously for a few seconds. The Digital Tuner will be reset. If this does not reset it correctly, unplug the power cord and plug it back in.

The following are not malfunctions.

• The television may make a creaking sound if the temperature of the room or the temperature of the inside of the television changes. If there is no problem with the screen or sound, then there is no need to worry.

• Although the picture may be temporarily disturbed and noise may be seen on the screen if

the power is turned on immediately after it has been turned off, this is not a malfunction.

• If the television is used at a location above 2,000 m, a buzzing noise and image distortion

may occur. This phenomenon is peculiar to PDP (Plasma Display Panel), and could occur with any television using PDP. It is not a malfunction.

868788

Specifications

Model

Reception Format

Reception Range

Power Source

Power Consumption

Screen Size 42 inch / 107.5 cm measured diagonally, 16:9 ratio

Audio Output 10W + 10W

Speakers 6.6 cm round x 4

Antenna Terminal

(VHF/UHF,

ATSC/DIGITAL

CABLE IN)

External Input Jacks

Component Input

Jack

S-Video Input Jacks

Monitor/Recording

Output

Audio Output Jacks

(VARI/FIX)

Optical Output

Digital Audio

i.LINK In/Out Jack

AV CompuLink III

Jack

PC Input Jack

Digital–In

Dimensions (inch/cm)

W X H X D

Weight (lbs / kg)

Accessories

NTSC, BTSC System (Multi-Channel Sound)

VHF 2 to 13, UHF 14 to 69 CATV 135 Sub, Mid, Super, Hyper and Ultra bands (191 channel frequency synthesizer system)

• Reception of channel A-5 ("95" of the TV set's on-screen cable channel numbers) is not recommended for your TV set.

75 ohms (VHF/UHF)(F-type connector)

Audio: 500 mVrms (-4dBs) high impedance

Y: 1Vp-p positive, 75 ohms (negative sync provided)

C: 0.286 Vp-p (burst signal), 75 ohms

Y: 1Vp-p positive, 75 ohms (negative sync provided)

FIX: 500mVrms (-4dBs) Low impedance (400 Hz when modulated 100%)

Analog RGB D-SUB (15 pin) x 1

• PC signal is available. Refer to page 25 for details on the signals which can be input.

HDMI jack x 1 Note: The Digital–In terminal is not compatible with picture signals of a personal computer

41 1/4 x 31 1/8 x 12 7/8 / 104.5 x 78.9 x 32.5 (with the stand) 41 1/4 x 28 3/4 x 4 3/8 / 104.5 x 72.9 x 11 (without the stand)

VARI: More than 0 1000mVrms (+2.2dBs)

IEEE1394 compliant DTCP digital copy protection compatible

Refer to "unpacking your TV", page 9

PD-42X776

Plasma ScreenType

ATSC Terrestrial, Digital Cable

AC 120V, 60 Hz

390W

Video: 1 Vp-p, 75 ohms

Pb/Pr: 0.7 Vp-p 75 ohms

Video: 1Vp-p, 75ohms

C: 0.286 Vp-p (burst signal), 75 ohms

Audio: 250mVrms (-10dBs)

Fs-18dB Low Impedance

Digital Out (optical) x 1

TS IN/OUT (4-pin, S400) x 2

3.5 mm mini jack X 1

106.7 / 48.5 (with the stand)

83.9 / 38.1 (without the stand)

Specifications subject to change without notice.

• The open source software is embedded in this product. For more information, please go to:

http://software.jvc.com/opensource/Inx/DP/04_AtscCC/download.html.

Notes

JVC COMPANY OF AMERICA

Division of JVC Americas Corp.

1700 Valley Road

Wayne, New Jersey, 07470

JVC CANADA, INC.

21 Finchdene Square Scarborough, Ontario

Canada, M1X 1A7

JVC LCT1823-001A-A, 0305TNH-II-IM User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
