Jura Capresso F9 User Manual
Impressa F9
Fully Automatic
Coffee & Espresso Center
with Claris Water Care System
Operating Instructions
and Warranty
Customer Service 1-800-220-5701
63942R
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions
should always be followed, including the following:
1. Read all instructions.
2. Do not touch hot surfaces. Use handles or knobs.
3. To protect against fire, electric shock and personal injury,
do not immerse cord, plugs or appliance in water or
other liquids.
4. Close supervision is necessary when any appliance is
used by or near children.
5. Unplug from outlet when not in use and before cleaning.
Allow it to cool before putting on or taking off parts, and
before cleaning the appliance.
6. Do not operate any appliance with a damaged cord or
plug or after the appliance malfunctions, or has been
damaged in any manner. Return appliance to the nearest
authorized service facility for examination, repair or
adjustment.
7. The use of accessory attachments not recommended by
the appliance manufacturer may result in fire, electric
shock, or personal injury.
8. Do not use outdoors.
9. Do not let the cord hang over the edge of a table or
counter, or touch hot surfaces.
10. Do not place on or near a hot gas or electric burner, or in
a heated oven.
11. Always attach plug to appliance first, then plug cord into
wall outlet. To disconnect, turn any control to “off” then
remove plug from wall outlet.
12. Do not use appliance for other than intended use.
13. Use extreme caution when disposing hot steam.
14. For household use only.
SAVE THESE INSTRUCTIONS
SPECIAL CORD SET
INSTRUCTIONS
Regarding your cord set:
A. A short power-supply cord (or detachable power-supply
cord) is to be provided to reduce risks resulting from
becoming entangled in or tripping over a longer cord.
B. Longer detachable power-supply or extension cords are
available and may be used if care is exercised in their use.
C. If a long detachable power-supply cord or extension cord
is used,
1) The marked electrical rating of the detachable powersupply cord or extension cord should be at least as
great as the electrical rating of the appliance,
2) If the appliance is of the grounded type, the extension cord should be a rounding type 3-wire cord, and
3) The longer cord should be arranged so that it will not
drape over the counter-top or table-top where it can be
pulled on by children or tripped over.
2.
NOTICE: Your Impressa F9 has a 3-prong grounded plug. To
reduce the risk of electrical shock this plug will fit in an outlet
only one way. If the plug does not fit in the outlet contact a
qualified electrician. DO NOT modify the plug in any way.
CAUTION
This appliance is for household use. Any servicing other than
cleaning and user maintenance should be performed by an
authorized service representative.
• Do not immerse base in water or try to disassemble.
• To reduce the risk of fire or electric shock, do not remove
the base. No user serviceable parts inside. Repair should
be done by authorized service personnel only.
• Check voltage to be sure that the voltage indicated on the
name plate agrees with your voltage.
• Never use warm or hot water to fill the water container!
Use cold water only!
• Keep your hands and the cord away from hot parts of the
appliance during operation.
• Never clean with scouring powders or hard implements.
JURA-CAPRESSO
Jura was founded in 1931 in Switzerland.
Capresso was founded in 1994 in the USA.
Both companies have joined forces in the US to
bring you the best Fully Automatic Coffee
Centers available anywhere. With innovative and
user-friendly features, high quality materials,
clear instructions and superb customer service,
we are sure you will experience the best coffee,
espresso, cappuccino or latte you have ever
had. We hope you will enjoy your new Fully
Automatic Coffee Center and will recommend it
to your friends. For more information about our
products visit our website www.capresso.com.
Michael Kramm, President
3.
8
7
6
5a
5
4
3
2
Fig. 1
9
10
11
12
13
14
1. Height-Adjustable Coffee Spout
2. Operating Buttons (See Fig. 3)
3. Removable Water Tank
4. Low Water Flotation Device (See Fig. 8.4)
5. Claris Water Care Cartridge (Not Installed)
5a. Service Plug
6. Lid for Water Tank
7. Ground Coffee Funnel
8. Lid for Ground Coffee Funnel
9. Lid for Bean Container
10. Touch-screen control display (See Fig. 5)
11. Steam / Hot Water Buttons (See Fig. 4)
12. Dual Frother Plus
13. Stainless Steel Removable Grid
14. Removable Drawer
15. Measuring Scoop
16. Two Cleaning Tablets (white)
17. Water Hardness Indicator Strip
18. Claris Water Cartridge (unpacked)
1
15 16 17 18
4.
Fig. 2
19. Used Coffee Container
20. Tray
13. Grid
14. Drawer
a b
c d
e f
Operating
Buttons
a. On/Off
b. Rinse
PRESS MAINT.)
(
c. 1-Cup
d. 2-Cup
e. Programming
f. Pre-Ground Coffee
a b
a. Hot Water
b. Steam
SELECT PRODUCT
a b c d e f g
a. BIG CUP
b. COFFEE
c. ESPRESSO
d. ST@RT
e. MILD
f. NORMAL
g. STRONG
Fig. 3
Fig. 7
Fig. 8
Fig. 4
4
Fig. 9
Fig. 5
Fig. 10 Fig. 11
Fig. 6
5.
Fig. 12
Fig. 13 Fig. 14
a b c
Tip Metal Cylinder Clip-on Connector
Dual Frother Plus
6.
Fig. 15
Fig. 16
I
MPRESIA F9
Frothing:
down
a. Metal Tube
b. Chrome Sleeve
c. Steam Nozzle
a
b
Steaming:
up
c
Fig. 17
Fig. 21
Fig. 18
Fig. 19 Fig. 20
Fig. 22 Fig. 23
Fig. 24
7.
Table of Contents
Page
Important Safeguards / Jura-Capresso...............................2
Illustrations.......................................................................4–7
1. Product Registration......................................................9
2. Customer Service ..........................................................9
WELCOME TO THE IMPRESSA F9 ...........................9
3.
a. A Word about "Crema Coffee"...............................10
b. Pressure Brewing ...................................................10
c. Different Coffee Drinks...........................................10
d. Coffee Facts...........................................................10
4. Please Don't / Please Do ............................................10
5. Factory Settings ..........................................................11
PREPARING MACHINE FOR THE FIRST TIME........11
6.
7. Adding Coffee Beans ..................................................12
8. Adjusting the Grinder ..................................................12
9. DAILY PREPARATION................................................13
10. Grinding and Brewing..................................................13
a. Selecting Cup Size and Strength...........................13
11. Using Pre-Ground Coffee............................................13
12. Using Hot Water ..........................................................14
FROTHING, STEAMING, HEATING...........................14
13.
14. Heating and Frothing Milk ...........................................14
15. Cleaning the Dual Frother Plus ...................................15
CLARIS WATER CARTRIDGE ...................................15
16.
a. Installing and Activating the Claris Cartridge ........16
b. Replacing the Claris Cartridge...............................16
17. Adjusting the Water Hardness.....................................17
Page
18.
PROGRAMMING ........................................................17
a. Programming AROMA............................................18
b. Programming Temperature ....................................18
c. Programming Water Quantity (Cup Sizes).............18
d. Programming the 1-Cup Button ............................19
e. Programming Steam Portion .................................19
f. Programming Hot Water Portion............................19
g. Setting the Time.....................................................20
h. Setting Auto-On Time ............................................20
i. Setting Auto Shut-Off.............................................20
j. Setting Language...................................................21
k. Looking Up Cup Counter.......................................21
CARE AND MAINTENANCE......................................21
19.
a. Fill Water ................................................................21
b. Empty Tray / Empty Grounds.................................21
c Fill Beans................................................................21
d. Stones and Beans..................................................22
e. General Cleaning Instructions................................22
f. Emptying System Before Transport.......................22
AUTOMATIC CLEANING CYCLES............................22
20.
a. Cleaning with Special Tablet..................................22
b. Decalcifying Procedure ..........................................23
21. Tips for Better Coffee..................................................24
22. Supplies.......................................................................24
LIMITED WARRANTY ................................................24
23.
24. Troubleshooting...........................................................25
Address Information ..........................................................27
8.
1. PRODUCT REGISTRATION
Please read the enclosed product registration form now. Fill it
out and mail or fax it to us within two weeks after purchasing
your machine or register online through our website:
www.capresso.com.
Important: This registration is part of your
warranty (chapter 23).
2. CUSTOMER SERVICE
Thank you for choosing this Jura-Capresso product. Please
study these operating instructions carefully before using your
new machine. We highly recommend viewing the enclosed
video. For further information please call our special
TOLL FREE number: 1-800-220-5701, Mon-Fri 9AM – 9PM &
Sat 9AM – 5PM Eastern Standard Time. If you call at any other
time please leave a message with your telephone number and
when we can call you back. You can also send us a
FAX at:
201-767-9684 or EMAIL us at contact@capresso.com
3. WELCOME TO THE IMPRESSA F9
This fully automatic coffee center is completely programmable
and extremely user friendly. The Impressa F9 is made of the
finest materials and features a unique sensor touch panel. The
chrome plated metal front with its heavy duty die-cast coffee
spout, the stainless steel grid and the elegant cup illumination
make it the center piece of any contemporary kitchen. The
Impressa F9 can prepare one or two cups of crema coffee at a
time. The two-step pressure brewing system – well known in
commercial applications – was adapted and refined by Jura
coffee specialists and is the trademark of each Jura-Capresso
coffee center. This Pre-Brew Aroma-System (chapter 10) ensures
optimal coffee extraction and will finish every cup with a rich
layer of "crema" – proof for perfectly pressure brewed coffee. By
touching one of three cup symbols and one of three bean symbols you choose the cup size and the coffee strength you want.
Touch the
ST@RT button and the F9 will grind and brew your
personal cup of coffee. The integrated solid steel conical burr
grinder grinds beans to the preferred fineness. A separate funnel
lets you use pre-ground coffee. All coffee, water and steam
functions are programmable to your own personal taste. Make
any size cup of coffee between 1 and 16 oz. The Dual Frother
Plus* lets you froth and steam milk for delicious cappuccinos
and lattes. The frother can be programmed to produce steam up
to 60 seconds. Need more steam? Just push the steam button
again for another 60 seconds of steam. The stainless steel lined
ThermoBlock prevents water from coming in contact with aluminum and allows you to brew coffee immediately after frothing
(no purging). The hot water function lets you prepare tea and
other beverages in seconds. All important functions such as
water level, bean container, used coffee container and water filter
are monitored automatically. You can even program the machine
to turn itself on and off. You can change the language and can
check how many cups of coffee you made. Please watch the
enclosed video and study this instruction manual before you use
the machine on a daily basis. You will get so much more out of
your IMPRESSA F9. Enjoy!
* If you prepare many cappuccinos or lattes at a time we recommend
the fast and precise frothXpress PLUS system (separately available).
This system replaces the Dual Frother Plus and lets you fill cup after
cup with the desired amount of hot milk and milk froth automatically.
For details visit our website www.capresso.com and watch the videos
about the frothXpress Plus system (Super Automatics, Impressa S9).
9.
Loading...
