JURA 13613, J9TFT Operating Instructions
IMPRESSA J9.3 One Touch TFT Instructions for Use
The Instructions for Use has been awarded the seal of
approval by the independent German T echnical Inspection
Agency, TÜV SÜD, due to its easy-to-understand style, its
thoroughness and coverage of safety aspects.
Table of contents
Your IMPRESSA J9.3 One Touch TFT
Control elements 4
Important information 6
Proper use ......................................................................................................................................................6
For your safety ...............................................................................................................................................6
1 Preparing and using for the first time 9
JURA on the Internet .....................................................................................................................................9
Setting up the machine ...............................................................................................................................9
Filling the water tank ....................................................................................................................................9
Filling the bean container ............................................................................................................................9
First-time use ................................................................................................................................................10
Inserting and activating the filter ...............................................................................................................11
Determining and adjusting the water hardness .....................................................................................12
Adjusting the grinder ..................................................................................................................................14
2 Preparation 15
Ways of preparing a beverage ...................................................................................................................15
Espresso and coffee .....................................................................................................................................16
Preparing two speciality coffees ................................................................................................................16
Latte macchiato, cappuccino .....................................................................................................................17
Warm milk and milk foam ..........................................................................................................................18
Ground coffee ...............................................................................................................................................18
Permanently setting the amount of water for the cup size .................................................................19
Hot water ......................................................................................................................................................20
3 Daily operation 21
Switching on .................................................................................................................................................21
Daily maintenance .......................................................................................................................................21
Switching off ................................................................................................................................................22
4 Permanent settings in programming mode 23
Product settings ..........................................................................................................................................24
Maintenance settings .................................................................................................................................25
Energy-saving mode ..................................................................................................................................26
Automatic switch-off ..................................................................................................................................27
Unit for amount of water ...........................................................................................................................28
Restore factory settings .............................................................................................................................28
Language ......................................................................................................................................................29
Colour scheme .............................................................................................................................................30
Viewing information ...................................................................................................................................31
2
Table of contents
5 Maintenance 32
Rinsing the machine ...................................................................................................................................32
Rinsing the cappuccino frother ................................................................................................................33
Cleaning the cappuccino frother ..............................................................................................................33
Dismantling and rinsing the cappuccino frother ..................................................................................34
Changing the filter ......................................................................................................................................34
Cleaning the machine ................................................................................................................................36
Descaling the machine ..............................................................................................................................37
Cleaning the bean container .....................................................................................................................39
Descaling the water tank ...........................................................................................................................40
6 Display messages 41
7 Troubleshooting 42
8 Transport and environmentally friendly disposal 44
Transport / Emptying the system .............................................................................................................44
Disposal .........................................................................................................................................................44
9 Technical data 45
10 Index 46
11 JURA contact details / Legal information 48
Symbol description
Warnings
J CAUTION
J WARNING
CAUTION CAUTION draws your attention to potential damage to the machine.
Symbols used
T Prompt to take action. This symbol means that you are being prompted to
E Information and tips to make it even easier to use your IMPRESSA.
‘Espresso’
Always take note of any information marked with the words CAUTION or
WARNING and a warning sign. The signal word WARNING draws your attention
to potential serious injury, and the signal word CAUTION to potential minor
injury.
perform some action.
Display
3
Control elements
Control elements
1 Bean container cover
2 Water tank cover
3 Bean container with aroma preservation
cover
4 Water tank
5 Height-adjustable cappuccino frother
6 Coffee grounds container
7 Drip tray
8 Cup platform
9 Filler funnel for ground coffee
10 Storage compartment cover
11 Grinder adjustment switch
12 Hot-water nozzle
13 Measuring spoon for ground coffee
14 Height- and width-adjustable coffee spout
15 Power switch and mains cable
(side of machine)
4
Control elements
Top of the machine
1 Q On/Off button
2 g Rotary Switch
3 O P button (programming)
Front
4 Display
5 Buttons (button function depends on
what is shown in the display)
5
Important information
Important information
Proper use
For your safety
J
The machine is designed and intended for private domestic use. It
should only be used for coffee preparation and to heat milk and
water . Use for any other purpose will be deemed improper . JURA Elektroapparate AG cannot accept any responsibility for the consequences of improper use.
Before using the machine read these instructions for use thoroughly
and completely and comply with the instructions they contain. A
warranty service is not applicable for damage or defects caused by
non-compliance with the instructions for use. Keep these instructions for use close to the machine and pass them on to the next user .
Please carefully read and observe the important safety information
set out below.
To avoid danger of potentially fatal electric shock:
Never use a machine which is damaged or has a defective
U
mains cable.
In the event of signs of damage, for example if there is a smell
U
of burning, unplug the machine immediately from the mains
supply and contact JURA service.
If the mains cable of this machine is damaged, it must be
U
repaired either directly by JURA or by an authorised JURA service centre.
Make sure that the IMPRESSA and the mains cable are not
U
located close to hot surfaces.
Be careful to ensure that the mains cable is not trapped and
U
does not rub against sharp edges.
Never open and repair the machine yourself. Do not modify
U
the machine in any way that is not described in these instructions for use. The machine contains live parts. If opened, there
is a danger of potentially fatal injury. Repairs may only be car ried out by authorised JURA service centres, using original
spare parts and accessories.
To completely and safely disconnect the machine from the
U
power supply, first switch off the IMPRESSA using the On/Off
6
Important information
button and then at the power switch. Only then should you
remove the mains plug from the power socket.
There is a risk of scalds or burns on the spouts and the cappuccino
frother.
Place the machine out of the reach of children.
U
Do not touch any hot parts. Use the handles provided.
U
Ensure that the cappuccino frother is correctly fitted and
U
clean. If incorrectly fitted or if they become blocked, the cappuccino frother or its parts might come off.
A defective machine is not safe and could cause injury or fire. To
avoid damage and any associated risk of injury or fire:
Never allow the mains cable to loosely hang down. The mains
U
cable could pose a tripping hazard or become damaged.
Protect the IMPRESSA from environmental influences such as
U
rain, frost and direct sunlight.
Do not immerse the IMPRESSA, mains cable or connections in
U
water.
Do not put the IMPRESSA or any individual parts in the dish-
U
washer.
Switch your IMPRESSA off at the power switch before any
U
cleaning operation. Always wipe the IMPRESSA with a damp
cloth rather than a wet one, and protect it from prolonged
exposure to water splash.
Only connect the machine to the mains voltage in accordance
U
with the information on the rating plate. The rating plate is
located on the underside of your IMPRESSA. Further technical
data is provided in these instructions for use (see Chapter 9
‘Technical data’).
Please only use original JURA maintenance products. Use of
U
products that are not explicitly recommended by JURA could
damage the IMPRESSA.
Do not use any coffee beans treated with additives or caramel-
U
ised coffee beans.
Only fill the water tank with fresh, cold water.
U
Switch the machine off at the power switc h if you are going to
U
be absent for a longer period of time.
7
Important information
People, including children, who
do not have the physical, sensory or mental capabilities to use
U
the machine safely or
are inexperienced or lack knowledge in how to use the
U
machine safely
must be supervised by a responsible person when using it, or must
be instructed in how to use it correctly.
Safety when handling the CLARIS Blue filter cartridge:
Filter cartridges should be kept out of the reach of children.
U
Store filter cartridges in a dry place in the sealed packaging.
U
Protect cartridges from heat and direct sunlight.
U
Do not use damaged filter cartridges.
U
Do not open filter cartridges.
U
8
1 Preparing and using for the first time
1 Preparing and using for the first time
JURA on the Internet
Setting up the machine
Filling the water tank
CAUTION
Visit us on the Internet. You can do wnload short operating instructions for your machine from the JURA website (www.jura.com). You
will also find interesting and up-to-date information on your
IMPRESSA and on every aspect of coffee.
When setting up your IMPRESSA, please note the following:
Place the IMPRESSA on a horizontal surface that is not sensi-
U
tive to water.
Choose a spot for your IMPRESSA which prot ects the machine
U
against overheating. Ensure that the ventilation slots are not
covered.
To enjoy the per fect cup of coffee we recommend changing the
water every day.
Milk, sparkling mineral water or other liquids can damage the wat er
tank or the machine.
T Only fill the water tank with fresh, cold water.
T Open the water tank cover.
T Remove the water tank and rinse it with cold water.
T Fill the water tank with fresh, cold water and reinsert the
tank.
T Close the water tank cover.
Filling the bean container
CAUTION
The bean container has an aroma preservation cover . This will ensure
that your coffee beans retain their aroma for longer.
Coffee beans which have been treated with additives (e.g. sugar),
ground coffee or freeze-dried coffee will damage the grinder.
T Only use untreated coffee beans to fill the bean container.
T Open the bean container cover and remove the aroma pres-
ervation cover.
9
1 Preparing and using for the first time
First-time use
J
WARNING
T Remove any dirt or foreign objects from inside the bean
container.
T Fill the bean container with coffee beans, then close the
aroma preservation cover and the bean container cover.
If the machine is operated with a defective mains cable, there is a
danger of potentially fatal electric shock.
T Never use a machine which is damaged or has a defective
mains cable.
Precondition: The water tank and bean container have been filled.
T Insert the mains plug into a power socket.
3 T Switch on the IMPRESSA using the power switch on the
right-hand side of the machine.
Q T Press the On/Off button to switch the IMPRESSA on.
The JURA logo appears. The display then shows the languages you can choose from.
10
E To display more languages, press the
‘Next’ button (bottom
right).
T Press the button that corresponds to the language y ou want,
e.g.
‘English’.
‘Saved’ appears briefly on the display to confirm the setting.
‘Please press the Rotary Switch.’, the Rotary Switch lights up.
T Place a receptacle under the cappuccino frother.
k T Press the Rotary Switch.
‘System is filling.’, the system fills up with wa t er. The opera-
tion stops automatically.
‘Please press the Rotary Switch.’
1 Preparing and using for the first time
T Place a receptacle under the coffee spout.
k T Press the Rotary Switch.
‘Machine is rinsing.’, the machine rinses. The operation
stops automatically.
display. The IMPRESSA is now ready for use.
E The display shows the products you can prepare.
‘Please select product:’ appears on the
Inserting and activating
the filter
Your IMPRESSA no longer has to be descaled if you are using the
CLARIS Blue filter cartridge. If the water hardness is 10° dH or more,
we recommend using the filter cartridge.
E If you do not know the hardness of your water, you must find
this out first (see Chapter 1 ‘Preparing and using for the first
time – Determining the water hardness’).
E Per form the ‘inserting the filter’ operation without any inter-
ruptions. This will ensure that your IMPRESSA alwa ys produces
its best.
Precondition:
O T Press the P button.
g T Turn the Rotary Switch until the programme item
T Press the
T Press the ‘Active’ button.
T Press the
T Remove the filter cartridge extension from the Welcome
T Fit the filter extension on top of a CLARIS Blue filter cartridge.
T Remove and empty the water tank.
‘Please select product:’ is displayed.
‘Maintenance status (1/6)’
‘Maintenance settings (3/6)’ is displayed.
‘Filter’ button.
‘Filter’
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Insert filter’
Pack.
11
1 Preparing and using for the first time
T Open the filter holder and insert the filter cartridge into the
water tank, exerting slight pressure.
T Close the filter holder. It will click into place audibly.
E Af ter t wo months, the filter will cease to work. You can check
the elapsed time by referring to the date plate on the filter
holder in the water tank.
T Fill the water tank with fresh, cold water and reinsert the
tank.
T Place a receptacle (at least 500 ml) under the cappuccino
frother.
T Press the
‘Filter is being rinsed.’, water flows out of the cappuccino
frother.
E You can interrupt rinsing of the filter at any time by pressing
any button. Press the Rotary Switch k to continue rinsing of
the filter.
E The water may be slightly discoloured. This is not harmful to
health and does not affect the taste.
Rinsing of the filter stops automatically after approximately
500 ml. The machine heats up.
appears on the display. The filter is now activated.
‘Next’ button.
‘Please select product:’
Determining and
adjusting the water
hardness
12
E If you are using the CLARIS Blue filter cartridge and have acti-
vated it in programming mode, you will not be able to adjust
the water hardness.
The harder the water is, the more frequently the IMPRESSA needs to
be descaled. It is therefore important to adjust the water hardness.
The water hardness can be adjusted on a continuous scale between
1° dH and 30° dH.
1 Preparing and using for the first time
Determining the water
hardness
Adjusting the water
hardness
You can find out what the w at er hardness is by using the Aquadur®
test strip supplied as standard.
T Hold the test strip briefly (for 1 second) under flowing w ater.
Shake off the water.
T Wait for about one minute.
T You will then be able to read the degree of water hardness
from the discolouration of the Aquadur® test strip and the
description on the packaging.
You can now adjust the water hardness.
Precondition: ‘Please select product:’ is displayed.
O T Press the P button.
‘Maintenance status (1/6)’
g T Turn the Rotary Switch until the programme item
‘Maintenance settings (3/6)’ is displayed.
T Press the
‘Water hardness’ button.
‘Water hardness’
T Press the ‘ < ’ or ‘ > ’ button to set the water hardness.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display to confirm the setting.
‘Maintenance settings (3/6)’
O T Press the P button to exit programming mode.
‘Please select product:’
13
1 Preparing and using for the first time
Adjusting the grinder
CAUTION
You can adjust the grinder on a continuous scale to suit the degree
of roast of your coffee.
If you adjust the consistency of grind when the grinder is not operating, the grinder adjustment switch could be damaged.
T Only adjust the consistency of grind when the grinder is run-
ning.
The consistency of grind setting is correct if the coffee flows regularly from the coffee spout. In addition a fine, thick crema forms.
Example: Proceed as follows to change the consistency of grind
during the preparation of an espresso.
T Open the storage compartment cover.
T Place a cup under the coffee spout.
T Press the
The grinder starts up.
T Turn the grinder adjustment switch to the desired position
while the grinder is running.
The espresso is prepared and the consistency of grind is
adjusted.
T Close the storage compartment cover.
‘Espresso’ button.
‘Espresso’ is displayed.
14
2 Preparation
2 Preparation
E You can stop preparation of a speciality coffee, speciality cof-
fee with milk or hot water at any time. Just press any button.
E During the grinding operation you can select the coffee
strength of individual products by turning the Rotary
Switch g: ; (extra-mild), ;; (mild), ;;; (normal), ;;;; (strong)
or ;;;;; (extra-strong).
E During preparation, you can change the preset amount
of water by turning the Rotary Switch g or pressing the
and
‘ > ’ buttons.
E You can follow the current status of preparation on the display .
You can make permanent settings for all products in programming
mode (see Chapter 4 ‘Permanent settings in programming mode –
Product settings’).
‘ < ’
Ways of preparing a
beverage
Only some of the speciality coffees you can prepare are shown on
the display at any one time. As soon as you turn the Rotary Switch,
more speciality coffees are displayed in the product selector. The
product selector disappears automatically after 5 seconds if no
preparation is started.
The following speciality coffees are displayed as standard:
‘Espresso’
U
‘Coffee’
U
‘Cappuccino’
U
‘Latte macchiato’
U
‘Hot water’
U
‘1 portion milk’
U
Additional speciality coffees in the product selector:
‘Ristretto’
U
‘2 espressi’
U
‘2 coffees’
U
‘2 ristretti’
U
15
Loading...
