Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the
back of the manual (or month and year of purchase if product has no number). Keep this manual and the
receipt in a safe and dry place for future reference. 22d
57354
Visit our website at: http://www.harborfreight.com
Email our technical support at: productsupport@harborfreight.com
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright© 2022 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
To ol s re q u ir e d fo r as s e mb l y a n d s e r vi c e m a y n o t b e in c l ud e d .
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Specifications
Input
Output
Voltage
Wire Gauge 2 AWG (up to 6 ft.)
Internal Fuses 30 A x 6
Input Fuse Rating 180 A
Current 142.9 A (rated)
Continuous 1500W
Surge 3000W
Receptacles
Waveform Modified Sine Wave
Voltage Range 120VAC
Frequency 60 ±2Hz
Current 13.04 A
12 VDC Nominal
(11-15 VDC)
2 AC outlets,
2 USB ports
Ground Wire Gauge 8 AWG
No Load Current
(Switch on)
Maximum efficiency 90%
Full load efficiency >80%
Over voltage Shutdown 15.75 ±0.75 V
Low voltage alarm 10.5 ±0.5 V
Low voltage shutdown 10 ±0.5 V
Thermal Shutdown 149 ±9 °F
Note: Battery charge level, wire length and
other factors will effect performance.
<1.0A (at 12.5V)
WARNING SYMBOLS AND DEFINITIONS
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
Addresses practices not related to personal injury.
Page 2 For technical questions, please call 1-888-866-5797. Item 57354
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS–
This manual contains important instructions that shall be followed
during installation and maintenance of the Inverter.
IMPROPER INSTALLATION OR USE CAN RESULT IN SERIOUS INJURY, PROPERTY DAMAGE, OR DEATH.
General Precautions
1. People with pacemakers should consult their
physician(s) before use. Electromagnetic fields in
close proximity to heart pacemaker could cause
pacemaker interference or pacemaker failure.
Installation Precautions
1. DO NOT INSTALL THIS INVERTER INTO
A BUILDING’S ELECTRICAL SYSTEM.
This Inverter is a vehicular accessory.
It is not designed to be safely used in a building’s
electrical system and has not been evaluated to
meet building wiring codes. Improper application
may create a fire or electric shock hazard.
2. To allow proper cooling, install in indoor
well-ventilated area and do not cover
ventilation openings or cooling fins.
Do not install in engine compartment.
Especially avoid placing the Inverter on
carpets and rugs; they are not only flammable,
but they also obstruct vents underneath it.
2. The warnings, precautions, and instructions
discussed in this instruction manual cannot cover all
possible conditions and situations that may occur.
It must be understood by the operator that
common sense and caution are factors
which cannot be built into this product, but
must be supplied by the operator.
7. Keep Inverter dry and clean. Do not expose
to rain, snow, spray, bilge water or dust.
8. Use cables that are thick enough. The more power
(amps) or the longer the cables, the thicker they
need to be to prevent overheating and fire.
9. Install as close to DC source as possible, but
not in a closed area with vented lead-acid batteries.
Vented lead-acid batteries release explosive
hydrogen gas that can be ignited by the Inverter.
10. Mount Inverter horizontally.
11. Verify that installation surface has no hidden
utility lines before drilling or driving screws.
3. Keep combustible materials and gasses away
from the Inverter. The Inverter produces sparks
and heat during operation and can start a fire.
4. Connect to 12 VDC power supply only.
A power supply with lower voltage will
not operate the Inverter correctly, and
higher voltage could damage the Inverter.
5. Connect input polarity properly. Incorrect connection
will damage Inverter and void warranty.
6. Do not use in a marine application.
This Inverter is not intended to withstand the highly
corrosive conditions in marine applications and
would quickly be rendered inoperable or unsafe.
12. This product is not a toy.
Keep it out of reach of children.
13. Do not use with positive ground electrical systems.
(Most automobiles, trucks, and RV’s
have negative ground systems.)
14. The positive (+) battery on the Inverter must be the
last connection made, and must be connected before
the Inverter is turned on. There may be a small
spark during the final connection. This is normal.
15. Properly ground the Inverter’s case
as explained in this manual.
Page 3For technical questions, please call 1-888-866-5797.Item 57354
Battery Precautions
1. Wear splash-resistant ANSI-approved
safety goggles and electrically-insulated
gloves while working near batteries.
2. Charge, store, and maintain batteries
according to supplier’s instructions.
3. Locate batteries in a clean, well-ventilated area,
away from ignition sources and flammable materials.
Vented lead-acid batteries release
explosive hydrogen gas while charging.
Operation Precautions
1. Multiple outlet power strips with switches and circuit
breakers only interrupt power to the “hot” receptacle
terminals. The “neutral” terminals remain powered
with respect to the “ground” terminals.
So strip switch may be off,
but part of device may still be powered.
2. Inspect supply connections before use to ensure
they are tight and that insulation is not damaged.
4. Only connect similar batteries together.
Do not connect old and new batteries together,
flooded and gel cells together, or
batteries of different capacities together.
5. Use only 12 V batteries with this item.
6. Connect batteries in parallel ONLY
(negative terminals together to one cable;
positive terminals together to the other cable).
7. Install a properly rated fuse on the
positive output of the battery bank.
6. Do not attempt to power a device, or combination
of devices, that will require more than the
rated output of this Inverter. This may damage
the Inverter or the attached devices.
7. Appliances such as microwave ovens will
normally draw more than their rated current.
For example: A typical 600 watt microwave oven
will draw approximately 1,000 watts.
3. Do not use this Inverter to power sensitive devices
such as medical devices or plug-in computers.
Do not use in ignition protected areas.
4. Some rechargeable devices can damage the
Inverter. Check the temperature of the device
several times when it is charging. If the device
becomes extremely hot; turn the power off, remove
the device, and do not use with the Inverter again.
5. Check for breakage of parts and any other
condition that may affect the Inverter’s operation.
If damaged, have it repaired before use.
Service Precautions
1. DO NOT OPEN HOUSING.
Contains no user-serviceable parts.
Internal parts may be electrified,
even with Inverter off and
power disconnected.
2. Maintain labels and nameplates on the Inverter.
These carry important safety information.
If unreadable or missing, contact
Harbor Freight Tools for a replacement.
8. Do not attach a battery charger if the charger
carries a warning that dangerous voltages
are present at the battery terminals.
9. Some fluorescent lamps may not operate properly
with this type of Inverter.
If the bulb appears to be too bright, or fails to light,
do not use the lamp with this Inverter.
10. Some fans with synchronous motors may slightly
increase in speed when powered by the Inverter.
This is not harmful to the fan or to the Inverter.
11. Inverter will consume some power while on, even
without loads attached. Turn Inverter off after use.
3. Have your Inverter serviced by a qualified
repair person using only identical
replacement parts. This will ensure that
the safety of the Inverter is maintained.
4. Fuses must be replaced with fuses of
the same type and rating only.
SAVE THESE INSTRUCTIONS.
Page 4 For technical questions, please call 1-888-866-5797. Item 57354
Symbology
VAC
Double Insulated
Volts Alternating Current
Alternating Current Supply
Direct Current Supply
A
Ø
Amperes
Phase
Equipment Grounding Conductor
FCC
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Page 5For technical questions, please call 1-888-866-5797.Item 57354
Output waveform
Sine
Wave
Modified
Wave
(MSW)
1.
This Inverter’s output is a Modified Sine Wave.
Power from most electric utilities is a Sine Wave.
Note: Only multimeters identified as “TRUE RMS”
will read Modified Sine Wave voltage accurately.
Installation
Sine
2. Modified Sine Wave (MSW) power is suitable
for most AC devices and power supplies used in
electronic equipment, transformers, and motors.
Do not use to power sensitive devices such
as medical equipment or plug-in computers.
Some audio equipment may perform poorly
if run on Modified Sine Wave power.
3. Sine Wave Inverters provide power that is identical
to, or even better than, the power supplied by
your power company. Motors start easier and run
cooler under Sine Wave power. Certain devices,
such as laser printers, variable speed motors and
digital clocks, require sine wave power to operate
properly. Sine wave Inverters are typically more
expensive for their capacity than other Inverters.
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this document
including all text under subheadings therein before set up or use of this product.
This Inverter must only be connected to batteries with a output voltage of 12 volts DC.
Lower voltage will not operate the Inverter properly, and more voltage could damage the Inverter
or the device being powered. Do not use this Inverter with positive ground electrical systems.
The Inverter has a number of shut-down points,
for the safety of the operator, the Inverter, and the devices being used with it.
• If the DC input voltage drops too low,
the alarm on the Inverter will sound.
If the input voltage drops further, the Inverter will
shut down automatically to prevent permanent
battery damage. Recharge the battery soon.
• If the DC input voltage exceeds 15V
the Inverter will shut down automatically.
Note: Even though this Inverter has built-in mechanisms to minimize damage,
these situations should be avoided because they can still damage the Inverter or battery.
1. Place the Inverter on a dry, level, non-flammable,
stable surface. Make sure the Inverter has
adequate ventilation and is not in direct sunlight.
2. Connect one end of a ground wire (not included,
use at least recommended wire thickness from
specification chart) to the wing nut located on the
back of the Inverter. Then connect the other end
of the ground wire to a paint/rust free grounded
metal surface, such as the vehicle chassis.
• If the output load power rises higher
than the rating power of the Inverter;
the Inverter may shut down automatically.
• The Inverter may automatically shut down
if its internal temperature gets too high.
3. Battery Type Selection:
• Use only deep cycle lead-acid batteries with this
Inverter, such as 12 volt marine/RV deep-cycle
batteries. Do not use automotive, engine starting
(SLI), or maintenance-free wet cell batteries with
this Inverter; they are designed for repeated,
shallow discharge and will wear out quickly.
• Gel and AGM (Absorbed Glass Mat)
batteries can be used with this Inverter,
but they require special charging procedures.
Refer to battery supplier’s instructions.
Page 6 For technical questions, please call 1-888-866-5797. Item 57354
4. Battery capacity selection:
about 1 hour
Inverter
Output
500W 80 Ah 200 Ah
1000W 150 Ah 400 Ah
1500W 240 Ah 700 Ah
2000W 300 Ah 1000 Ah
3000W 450 Ah 1500 Ah
4000W 600 Ah 2000 Ah
5000W 750 Ah 2500 Ah
discharge time
(Minimum battery
capacity)
about 4 hour
discharge time
(Optimal battery
capacity)
Consult the chart above for approximate run time
at different battery capacities. If the battery
does not have a capacity this large individually,
use a bank of batteries as explained below.
5. Battery Bank assembly instructions:
a. Read the following safety rules before
assembling the battery bank:
• Connect batteries in parallel
(negative terminals together to one cable;
positive terminals together to the other cable)
as shown in Battery Bank Example ONLY.
• Do not connect 12V batteries in series
(from negative of one battery
to the positive of the next).
This connection can result in voltage high
enough to cause ELECTROCUTION.
• Wear splash-resistant ANSI-approved
safety goggles and electrically insulated
gloves while assembling battery bank.
• Only connect similar batteries together in a
battery bank. Do not connect old and new
batteries together, flooded and gel cells together,
or batteries of different capacities together.
• Connect all batteries in the battery bank together
using cables of the thickness recommended
on the specification chart or thicker.
Since amp draw on this low-voltage circuit will be
very high, thinner cables present a fire hazard.
• Locate battery bank in a clean,
well-ventilated area, away from ignition sources
and flammable materials. Batteries release
explosive hydrogen gas while charging.
• Charge, store, and maintain batteries
according to supplier’s instructions.
(To Negative (To Negative
Inverter Terminal)Inverter Terminal)
OUTPUTOUTPUT
12 V /
200* Ah
Lead- Acid
–
Battery
To Increase
Capacity, Connect
Additional
12 V / 200* Ah
–
Lead-Acid
Batteries Here
12 V /
200* Ah
Lead- Acid
–
Battery
+
+
+
OUTPUT OUTPUT
(To Positive (To Positive
Inverter Terminal)Inverter Terminal)
12 V / 400^ Ah Battery Bank Example
* 200 Ah batteries shown for illustration.
^ Bank Capacity = (single battery capacity) x (# of
batteries) 400 Ah capacity is for two, 200 Ah batteries.
b.
Connect the batteries in parallel as shown above.
Connect all of the positive terminals
to one another.
c. Then connect all the negative terminals
to one another.
d. Connect the negative and positive output cables
to opposite ends of the bank. Do not allow
the output cables to touch one another.
e. Test the voltages at the output cables to help
ensure that the battery bank is properly wired.
If the voltage is higher than 13 volts, then part
of the battery bank is likely connected in series
(a negative terminal of one battery attached to a
positive terminal of another) instead of in parallel.
Carefully examine the diagram and correct
the wiring before attaching to the Inverter.
6. Turn the Inverter’s Switch off.
7. Connect the output cables from the
battery bank to the Inverter.
Page 7For technical questions, please call 1-888-866-5797.Item 57354
Operating Instructions
1. Plug 120 VAC device(s) into the receptacles.
Switch all devices off. The devices must not use
more than the rated wattage during continuous
operation, otherwise they may overload the Inverter.
2. Turn the Inverter’s Switch on.
NOTE: Some rechargeable devices may
damage the Inverter or the device(s).
When first using a rechargeable device,
check the Inverter’s temperature for the first ten minutes.
If it becomes abnormally hot,
do not use the device with the Inverter.
3. Turn the device(s) on, one at a time.
If the alarm sounds, turn off the device(s).
Unplug the device(s) from the Inverter.
Check the wattage of the devices, if there were
multiple devices plugged in, discontinue use of
one or more. If a single device set the alarm off,
it is not appropriate for use with the Inverter.
4. If the Inverter is powered by a vehicle’s starting
battery, be careful not to discharge the battery
to the point that it will no longer start the engine.
If needed, operate the engine periodically to
maintain the battery’s charge. Do not operate
a vehicle’s engine in an enclosed space.
5. Inverter will consume some power while on, even
without loads attached. Turn Inverter off after use.
Page 8 For technical questions, please call 1-888-866-5797. Item 57354
Typical Device Power Consumption
Product Wattage
Laptop 50
Stereo 200
Mixer 200
Table Fan 200
TV-VCR 250
Plug-in computer 250
Small Refrigerator 350
Jigsaw 350
Note: The above chart is intended as a general guideline only, actual device wattage requirements will vary.
Some devices listed above may require a pure sine wave Inverter instead for proper operation.
Product Wattage
Belt Sander 350
3/8" Drill 350
Blender 350
Laser Printer 400
Food Processor 400
Reciprocating Saw 600
AC (5,000 BTU) 700
Vacuum 750
Product Wattage
Chest Freezer 800
Coffee Maker 850
Iron 1050
Mini Microwave 1200
Hair Dryer 1200
10" Saw 1350
Page 9For technical questions, please call 1-888-866-5797.Item 57354
Maintenance and Servicing
Procedures not specifically explained in this manual
must be performed only by a qualified technician.
TO PREVENT SERIOUS INJURY FROM ELECTRIC SHOCK:
Turn the Inverter off and disconnect its power supply before performing any
inspection, maintenance, or cleaning procedures.
TO PREVENT SERIOUS INJURY FROM INVERTER FAILURE:
Do not use damaged Inverter. If abnormal noise, vibration, or heating occurs,
have the problem corrected before further use.
Wear splash-resistant ANSI-approved safety goggles and
electrically insulated gloves while working near batteries.
1. BEFORE EACH USE, inspect the
general condition of the Inverter. Check for:
• loose hardware,
• damaged electrical wiring,
• cracked or broken parts, and
• any other condition that may
affect its safe operation.
2. AFTER USE, clean external surfaces of
the Inverter with clean, dry cloth.
3. Maintain batteries according to manufacturer’s
instructions. Check electrolyte level on all
batteries after charging and refill as needed.
Charge batteries according to manufacturer’s
recommendations ONLY; incorrect charging
may cause battery damage or explosion.
4. DO NOT OPEN HOUSING.
Contains no user-serviceable parts.
Internal parts may be electrified,
even with Inverter off and
power disconnected.
5. Store the Inverter in a clean, dry, safe location out
of reach of children and other unauthorized people.
6. Internal electronic components must be
disposed of properly or recycled.
Page 10 For technical questions, please call 1-888-866-5797. Item 57354
Troubleshooting
Problem Possible Causes Probable Solutions
Inverter shuts off
during use.
No output voltage. 1. Cords not connected properly.
Output voltage
is incorrect.
Could not drive load. 1. Load power is too large.
Motor-operated
device operates at
incorrect speed.
Television picture is full
of static or speakers
make a buzz.
1. Excessive load at output.
2. Internal temperature is too high.
2. Fuse on battery bank open.
3. Internal fuse(s) open.
4. Low input voltage.
5. Loose or corroded connection.
6. High input voltage.
Input voltage is too high or too low. Maintain input voltage at required level.
2. The AWG of the wire is too low.
3. Start power of an device is
up to twice the rated power.
Load is only inductive. Operate a lamp or heater at the same time
1. Television or radio interference.
2. Incompatible device.
1. Reduce load to less than rated power.
2. Let the Inverter cool down for at least 30 minutes.
Make sure that the fan is not blocked and
that the Inverter has sufficient ventilation.
1. Check and secure connections.
2. Check battery bank fuse and replace as needed.
3. Have technician check internal
fuses and replace as needed.
Only a qualified technician should open housing.
4. Recharge or replace battery.
5. Clean and tighten connection.
6. Remove charging source and make sure correct
battery is being used and connected correctly.
1. Lower load level.
2. Use appropriately-sized wire connections.
3. Reduce load, or change devices.
to provide a more balanced load.
1. Move Inverter away from antenna and/
or use a shielded antenna cable.
2. Contact device supplier to make sure that device
can operate on Modified Sine Wave Power.
Follow all safety precautions whenever diagnosing or servicing the Inverter.
Disconnect power supply before service.
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Replacement parts are not available for this product.
Page 11For technical questions, please call 1-888-866-5797.Item 57354
Limited 90 Day Warranty
Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards,
and warrants to the original purchaser that this product is free from defects in materials and workmanship for the
period of 90 days from the date of purchase. This warranty does not apply to damage due directly or indirectly,
to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper
installation, normal wear and tear, or to lack of maintenance. We shall in no event be liable for death, injuries
to persons or property, or for incidental, contingent, special or consequential damages arising from the use of
our product. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation of exclusion may not apply to you. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us with transportation charges
prepaid. Proof of purchase date and an explanation of the complaint must accompany the merchandise.
If our inspection verifies the defect, we will either repair or replace the product at our election or we may
elect to refund the purchase price if we cannot readily and quickly provide you with a replacement. We will
return repaired products at our expense, but if we determine there is no defect, or that the defect resulted
from causes not within the scope of our warranty, then you must bear the cost of returning the product.
This warranty gives you specific legal rights and you may also have other rights which vary from state to state.
26677 Agoura Road • Calabasas, CA 91302 • 1-888-866-5797
Loading...
