Montage- und Gebrauchsanweisung
für den Dunstabzug
Instruction on mounting and use of the cooker hood
JDU 1450
JDU 1230
JDU 1130
SDU 1130
1
D
2
5
4
A
1
3
5
C
2
A
1
4
2
3
3
B
C
Abb. 1 - Fig. 1
4
B
D
Abb. 2 - Fig. 2
5
E
2
1
G
2
1
E
3
Abb. 3 - Fig. 3
3
Abb. 4 - Fig. 4
F
3
1
2
Abb. 5 - Fig. 5
2
Öffnen
Open
Abb. 6 - Fig. 6
3
2
2
1
1
Abb. 7 - Fig. 7
2
2
E14
40W max
Abb. 8 - Fig. 8
3
Use
The hood may be used as follows:
Exhausting version
The appliance is fitted with 2 exhaust outlets:
one at the top A and the other at the back B
(Fig. 1).
To connect the pipe fit the coupling ring C in
the outlet selected.
Use cover D to close the unused outlet
(Fig. 1).
Remove the exhausting grid (Fig. 2).
Lever E: in position G (Fig. 3).
Refit the exhausting grid.
Choosing the exhausting pipe
The coupling ring C has a diameter of
120mm.
We suggest to use Ø 120 mm exhausting
pipe.
Recycling version
The air is purified by means of a charcoal
filter and recycled into the room through the
front grid.
Remove the exhausting grid (Fig. 2).
Lever E: in position F (Fig. 4).
Refit the exhausting grid.
Mounting the circular charcoal filter
(Fig. 5):
a. Position the circular charcoal filter so
that it covers the plastic grate which
protects the fan wheel and motor.
b. Check that the small tab (1) coincides
with the arrow (2) printed on the conveyor.
c. Turn in clockwise direction.
Installation
When installed, the hood must be not less
than 60 cm. above electric burners or 70
cm. above gas or mixed-fuel burners.
Warning!
— The hood cannot be connected to flues of
other appliances that run on energy
sources other than electricity.
— When the hood is used at the same time
of other appliances that run on energy
sources other than electricity, provision
must be made for an adequate supply of
air.
—No food must be cooked flambé
underneath the hood.
The use of an unprotected flame is
dangerous for the filters and could cause
fires.
Therefore, never use an open flame under
the hood. When frying foods, never leave
the pan alone because the cooking oil
could flare up.
— Please, keep to the provisions of official
directives regarding the question of fume
discharge.
— The manufacturers refuse to accept any
responsibility for damage to the hood or
its catching on fire because of failure to
observe the above instructions.
Suggestions for the installation and
use of the hood
— The horizontal sections of the pipe must
be slanted slightly upwards (about 10%)
to ensure an easy flow of the air outwards.
— The best performance of the unit is
obtained in the exhausting version,
therefore in the limits of the possibilities
it is advised to use this version.
— The best performances are obtained with
short pipes (max. 4 m) and with few
curves.
Electric connection
Before completing any connection, make
sure the house voltage corresponds with
the voltage indicated on the label affixed
inside the hood.
The hood is supplied with a standard plug;
connect it to a correspondingly standard
socket.
In the case is intended to connect the
appliance permanently to the mains after
having removed the plug supplied, must be
fitted a two-pole switch conforming to
regulations with an opening distance
between contacts of not less than 3mm.
The manufacturers are not liable for any
problems caused by the user’s failure to
observe the above instructions.
7
Fixing to the cabinet - Fig. 6
a. Make four holes at the bottom of the
cabinet .
b. Remove the exhausting grid (Fig. 2).
c. Remove the screws from the container
on the side of the conveyor.
d. Fit the four 4.2x35 screws supplied, from
inside the cabinet in the holes on the
appliance.
e. Refit the exhaust grid.
Using the hood
JDU 1230 - JDU 1450
The hood is provided with a 3-speed motor.
For the best performance, we recommend
using the low speeds in normal conditions
and the high speeds in particular cases of
strong odour and vapour concentration.
JDU 1130 - SDU 1130
The hood is provided with a 1-speed motor.
— We recommend starting up the hood a
few minutes before cooking and keeping
it running until all the odours have been
eliminated.
Maintenance
Before performing any maintenance
operation, disconnect the hood from the
electricity.
Grease filter
The hoods JDU 1230, JDU 1130 and SDU
1130 have a thin paper grease filter; the
hood JDU 1450 has a metal grease filter.
The metal grease filter lasts forever and
must be washed at least once a month
either by hand or in the dishwasher (60°C)
with suitable detergents.
Attention! When washed in a dishwasher,
the metal grease filter may discolour.
Let the filter dry without damaging it before
putting it back into place.
This paper grease filter must be replaced
every month.
To replace the filter, proceed as follows:
a. Slide the two side latches to release the
grid (Fig. 2,2 - Fig. 2,3).
b. Remove the grid completely , pull the
right side of the grid forward and unhook
it from the slots to which it is attached
(Fig. 2,5).
c. Remove the stops of the filter (Fig. 7,1 -
Fig. 7,2).
When the filters are washed, the grid should
also be cleaned with warm water and
biodegradable detergent.
Charcoal filter
This filter dissolves cooking odours.
The charcoal filter must never be washed.
It should be changed every 4 months in
normal use.
Mounting and replacing the charcoal
filter:
a. Disconnect the hood from the electricity.
b. Remove the exhausting grid (Fig. 2).
c. Pull-out the tab (1).
d. Turn the filter in the counterclockwise
direction (2).
To mount a new charcoal filter, see the
section in the paragraph Recycling
version - Mounting the circular
charcoal filter
e. Refit the exhaust grid.
Replacing the lamp
a. Disconnect the hood from the electricity.
b. Remove the exhaust grid (Fig. 2).
c. Always replace burnt-out lamps with
40Watt max. (E14).
d. Fit again the exhaust grid.
e. Before calling for repair service because
the hood fails to light up, make sure the
bulbs are screwed in tightly.
Cleaning
To clean the outside of the hood use a cloth
moistened with denatured alcohol or neutral
liquid detergents.
Never use products containing abrasive.
Attention
Failure to observe the rules for cleaning the
appliance and changing and cleaning the
filters may cause fires.
Therefore, we recommend observing these
instructions.
8
ELECTROLUX - ZANUSSI HAUSGERÄTE GMBH
Rennbahnstraße 72-74
D-60528 Frankfurt
LI08MA
