TWIN WATER DANCING SPEAKER
TWIN WATER DANCING SPEAKER
with Bluetooth® Wireless Technology
with Bluetooth® Wireless Technology
2016.06.29
08:44:34 +08'00'
2016.06.2
8 20:51:03
+08'00'
Owner's Manual
PLEASE READ BEFORE OPERATING THIS EQUIPMENT.
Model: CMA3584
Size: 148.5(W) x 210(H)mm (A5)
32280058500031
GENERAL WARNINGS
1. Read all instructions very carefully before use.
2. This unit is designed for adult use only. Always keep away from children.
( 41- 104 ) only. If unit freezes,
3. This unit is designed for indoor use within temperature 5-40
place it in room temperature
4. If the unit is broken and/or liquid leaks,discard the unit immediately.
until the liquid defrosts before powering on the unit.
°C °C
2016.06.29
08:44:43 +08'00'
FCC NOTICE
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide resonable protection
against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a
equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different
connected.
-- Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Any Changes or modifications not expressly approved by the party responsible for compliance could void
the user's authority to operate the equipment.
The device has been evaluated to meet general RF exposure requirement. The device can be used in
portable exposure condition without restriction.
FCC WARNING:
To assure continued compliance, follow the attached installation instructions and only shielded
cables when connecting to other devices. Modifications not authorized by the manufacturer may void
user's authority to operate this device.
from that to which the receiver is
particular installation. If this
2
DC5V
AUX
OFF/ON
BATTERY RECHARGE
The unit has a built-in Li-ion rechargeable battery, recharge it before first time use or
when the battery power is consumed (Tone sound will hearing from the speaker every
30 seconds) as below:
Connect the Micro USB Plug from the USB
z
Connection Cable to the Micro USB Port
on the rear of unit.
Connect the full size USB Plug to the USB Port on the Personal Computer or any
z
USB Charger having DC 5V output as the figure below.
During charging, the Red Indicator on the rear of the Main Speaker will
z
When
finished, it will
To Micro USB Port
USB Connection Cable
turn off.
Main Speaker
illuminate.
2016.0
6.29
08:44:
49
+08'00'
PC
To USB Port on PC or USB Charger
Notes:
Your battery will last longer if you follo
wing these simple guidelines for charging
and storingit.
A. Recharge and store the battery within the temperature range of 5 ~ 35
°C°C
(40°F~95°F).
B. Do not overcharge (longer than 24 hours). Excessive charging or
discharging may shorten the battery's life.
C. Battery life naturally shortens slowly over time.
D. The rechargeable battery incorporated in this product is not user replaceable.
3
DC5V
AUX
OFF/ON
SPEAKER
DC5V
AUX
OFF/ON
SPEAKER
LOCATION OF CONTROLS
Main Speaker
Front View Rear View
Right Speaker
123
/
/
DC 5V
DC 5V
DC 5V
AUX
AUXAUX
OFF/ON
OFF/ONOFF/ON
45678
SPEAKERSPEAKERSPEAKER
Front View Rear View
1. / Button
2. Button
3. / Button
4. Micro USB Port (For Charging Only)
5. AUX (IN) Jack
9
6. Right Speaker Connection Jack
7. Power ON/OFF Switch
8. Indicators
9. SPEAKER
Connection Jack
2016.06.29
08:44:56 +08'00'
SPEAKER CONNECTIONS
Before use, connect one side of the Speaker Connection Cable to the SPEAKER
Connection Jack on the rear of Right Speaker.
Right Speaker Connection Jack on the Main Speaker as the figures below:
Main Speaker
Connect the other side to the
Right Speaker
Speaker Connection Cable
4
OPERATION
BT (BLUETOOTH) PAIRING:
BT (BLUETOOTH) PAIRING:
In the first time use or re-pairing the unit to a new BT Device, pairing as below:
1. Connect the Right Speaker to Main Speaker as the previous procedures.
2. Slide the Power ON/OFF Switch on the rear of Main Speaker to ON position,
the Blue Indicator will illuminate and blink.
3. Power on the external BT Device and enter to searching mode. Start
pairing as the on screen instructions on the external BT Device. After
paired, the Blue Indicator will stop blinking. (For details pairing procedures,
please refer to the user’s manual of your BT Device).
Notes:
z
When the external BT Device searched the unit,ourmodelnumber
will appear on the display of external BT Device.
CMA3584CMA3584
“
Pairing code "0000" or "1234" may need to enter.
z
IMPORTANT:
Make sure the Audio Connection Cable has not been inserted into the
AUX (IN) Jack on the Main Speaker. Otherwise, BT will not function.
”
2016.06.29
08:45:02 +08'00'
Normal operation after pairing:
1. Turn on the BT function of the external BT Device.
2. Slide the Power ON/OFF Switch on the rear of Main Speaker to ON position
to power on the unit,
seconds until BT auto paired. (The Blue Indicator stop blinking).
3. Play the music in the paired BT Device as usual.
4. During playback:
Press and hold the / or / Buttons to adjust volume level.
z
Or, adjust the volume level of the paired BT Device as usual.
z Press the (Play/Pause) Button to pause; press again to resume.
z Press and release the
Or, press the or Buttons on the paired BT Device repeatedly to
skip tracks.
5.
When finished listening, slide the Power ON/OFF Switch to OFF position to
shut off
the unit.
the Blue Indicator will illuminate and blink. Wait a few
or
/
Buttons repeatedly to skip tracks.
/
5
AUX IN
To listen the music from the external Audio Player such like MP3 Player, Discman...etc.
1. Slide the Power ON/OFF Switch on the rear of Main Speaker to ON position
to power on the unit,
2. Insert one end of the Audio Connection Cable to the Line Out; AUX Out or Phones
Jack on the external Audio Player.
3. Insert the other end of the Audio Connection Cable to the AUX (IN) Jack on the rear
of Main Speaker. The unit will turn to AUX (IN) mode automatically.
4. Plays the music in theconnected Audio Player as usual. (Make surethe volume level
the connected audio player is turned to high level. ( Otherwise, sound is weak. )
of
5. During playback:
z Press the (Play/Pause) Button to pause; press again to resume.
Press and hold the / or / Buttons to adjust volume level.
z
Or, adjust the volume level of the connected Audio Player as usual.
6. When finished listening, slide the Power ON/OFF Switch to OFF position to shut off
the unit.
the Blue Indicator will illuminate and blink.
2016.0
6.29
08:45:
09
+08'00'
Can't power on
No sound or sound
weak
TROUBLESHOOTING
Power of built-in battery
consumed
Volume of the unit was
set to minimum position
Volume of
paired/connected
device is in low volume
level
Recharge the battery.
Increase the volume level by
press and hold the Button
Rise the volume level of the
paired BT Device or connected
Audio Player.
/
6
SPECIFICATIONS
Power Source
Maximum Play Time
BT Effective Range
Audio Power
Impedance of
Speakers
Built-in DC
rechargeable
Micro USB Port
Approximate 2 hours after fully charged
Up to 30 feet in open area
2 W x 2 (Total 4W, RMS)
4 ohm, 3W x 2
battery. Recharge by DC
ACCESSORIES
1 x User’s Manual
1 x USB Connection Cable only)(For charge
1 x Speakers Connection Cable
3.7V, 1000mAH (3.7WH) Li-polymer
through
5V
2016.06.29
08:45:16 +08'00'
SPECIFICATIONS AND ACCESSORIES ARE SUBJECT TO CHANGEWITHOUT NOTICE
7
LIMITED WARRANTY
Craig warrants this product to be free from manufacturing defects in material and
workmanship under normal use for a period of 90 days from date of purchase. If service
is required, please return the product to the store where it was purchased for exchange;
or, pack the unit in the original packing material with all accessories if applicable, a copy
of your sales receipt and a Cashier’s check or Money Order for $10.00 (to cover shipping
and handling costs) payable to Craig Electronics Inc. For consumers in Canada, please
make sure that the cashier check or money order is redeemable through a U.S. bank.
Ship your product freight pre-paid. Your unit will be repaired, replaced or if the unit can
not be repaired or replaced, a refund will be forwarded to you within four weeks of receipt
of your unit. Please ship your unit to:
Craig Electronics Inc.
1160 NW 163 Drive
Miami, Fl 33169
This warranty is void if the product has been: a) Used in a commercial application or
rental. b) Damaged through misuse, negligence, or abuse. c) Modified or repaired by
anyone other than an authorized Craig service center. d) Damaged because it is
improperly connected to any other equipment.
Note: This warranty does not cover: a) Ordinary adjustments as outlined in the Owner’s
Manual which can be performed by the customer. b) Damage to equipment not properly
connected to the product. c) Any cost incurred in shipping the product for repair. d)
Damage to the product not used in the USA.
This warranty is not transferable and only applies to the original purchase. Any implied
warranties, including the warranty of merchantability, are limited in duration to the period
of this expressed warranty and no warranty whether expressed or implied shall apply to
the product thereafter.
Under no circumstance shall Craig be liable for any loss or consequential damage arising
out of the use of this product. This warranty gives specific legal rights. However , you may
have other rights which may vary from state to state. Some states do not allow limitations
on implied warranties or exclusion of consequential damage. Therefore, these
restrictions may not apply to you.
2016.06.29
08:45:23 +08'00'
To Obtain Service on your Product
email:service@craigelectronics.com
Printed in China CMA3584_WC_E0CL1_B0US
