USING EXTENSION DOCUMENTS

JUNE 2008

Device extensions allow you to modify how a DSM parses logs, which is useful for resolving parsing issues. However, before you define a device extension, you must build an extension document. This document provides information on defining an extension document including:

• About Extension Document s

• Understanding Extension Document Elements

• Creating Extension Documents

• Device Type IDs

This document assumes an advanced knowledge of XML coding.

About Extension Documents

The extension document is specified in Extensible Markup Language (XML) format. You can create and edit the document using any common word processing application. You can create multiple extension documents and associate an extension document to various device types. Using an extension document, you can resolve parsing issues, such as:

• Fixing an event that has missing or incorrect fields (for example, if the

username is not being parsed).

• Completing the parsing of an event when the DSM to which it is attached fails to

produce a result. Any new events produced by the device extension are associated to the device that failed to parse the original payload. This action prevents these events from appearing as un-parsed in the STRM interface.

XML format allows for a simplification of the extension document’s organization, and verifies the extension document’s contents. Using this format requires that all regular expressions be contained in character data (CDATA) sections to prevent the special characters that are needed by regular expressions from interfering with the markup format. For example:

Where (tcp|udp|icmp|gre) is the actual regular expression pattern.

Release 2008.2

The extension document allows you to parse a device’s payload. Within the extension document you can include statements of varying degrees of complexity, as required to parse the desired information.

Understanding Extension Document Elements

Patterns Rather than associating a regular expression directly with a particular field name,

This section explains the two main divisions of the extension document:

• Patterns

• Match Groups

patterns (

patterns) are declared separately at the top of the extension document

and can be subsequently referenced multiple times within the file.

Table 1 Pattern Parameters

Parameter Description

(Required)

case-insensitive

(Optional)

trim-whitespace

(Optional)

Specify a regular string that is unique within the extension document.

Specify if you wish the pattern to ignore character case when doing a match, for example abc is the same as ABC.

If not specified, this parameter defaults to false. Specify if you wish the pattern to ignore white space and

carriage returns. If the CDATA sections are split onto different lines, this parameter ensures that any extra spaces and carriage returns are not interpreted as part of the pattern.

If not specified, this parameter defaults to false.

Match Groups A match group (match-group) is a set of patterns used for parsing or modifying

Release 2008.2

one or more types of events. A matcher is an entity within a match group that is parsed (for example, EventName) and is paired with the appropriate pattern and group for parsing. Any number of match groups may appear in the extension document.

Table 2 Match Group Parameters

Parameter Description

order

(Required)

description (Optional)

Specify an integer greater than zero to specify the order in which the match groups are executed. It must be unique within the extension document.

Specify a description for the match group, which can be any str ing. This information may appear in the logs.

If not specified, this parameter defaults to empty.

Understanding Extension Document Elements 3

Table 2 Match Group Parameters (continued)

Parameter Description

device-typeid-override

(Optional)

Specify a different device’s QID. Allows the particular match group to search in the specified device for the event type. It must be a valid device type ID, represented as an integer. A list of device type IDs is presented in

If not specified, this parameter defaults to the device type of the device to which the extension is attached.

Table 6.

Match groups can have up to three different types of entities:

• Matcher (matcher)

• Single-Event Modifier (event-match-single)

• Multi-Event Modifier (event-match-multiple)

Matcher (matcher)

A matcher entity is a field that is parsed (for example, EventName) and is paired with the appropriate pattern and group for parsing. Matchers have an associated order, so if multiple matchers are specified for the same field name, the matchers are executed in the order presented until a successful parse is found or a failure occurs.

Table 3 Matcher Entity Parameters

Parameter Description

field

(Required)

pattern-id

(Required)

order

(Required)

Specify the field to which you wish the pattern to apply, for example, EventName, or SourceIp. See list of valid field names.

Specify the pattern you wish to use when parsing the field out of the payload. This value must match (including case) the ID parameter of the pattern previously defined in a pattern ID parameter (

Specify the order that you wish this pattern to attempt among matchers assigned to the same field. If there are two matchers assigned to the EventName field, the one with the lowest order is attempted first.

Table 4 for a

Table 1).

Release 2008.2

Table 3 Matcher Entity Parameters (continued)

Parameter Description

capture-group

(Optional)

Specify capture group(s), as denoted in the regular expression inside parenthesis ( ). These captures are indexed starting at one and processed from left to right in the pattern. The capture-group field must be a positive integer less than or equal to the number of capture groups contained in the pattern. The default value is zero, which will be the entire match.

For example, you can define a single pattern for a source IP address and port; where the SourceIp matcher may use a capture group of 1, and the SourcePort matcher may use a capture group of 2, but only one pattern needs to be defined.

This field has a dual purpose when combined with the

enable-substitutions parameter.

enable-substitutions

(Optional)

Specify this Boolean parameter as true when a field cannot be adequately represented with a straight group capture.

You can combine multiple groups together with extra text to form a value. This parameter enables that behavior.

This parameter changes the meaning of the capture-group parameter. The capture-group parameter creates the new value, and group substitutions are specified using \x where x is a group number from 1 to 9. You may use groups multiple times, and any free-form text can also be inserted into the value. For example, if you need to form a value out of group 1, followed by an underscore, followed by group 2, an @, and then group 1 again, the appropriate capture-group syntax is:

capture-group=”\1_\2@\1”

In another example, a MAC address is separated by colons, but STRM assumes that MAC addresses are hyphen separated. The syntax to parse and capture the individual portions is:

capture-group=”\1:\2:\3:\4:\5:\6”

If no groups are specified in the capture-group when substitutions are enabled, a direct text replacement occurs.

Default is false.

Release 2008.2

Understanding Extension Document Elements 5

Table 4 provides a list of valid field names for use in the matcher field parameter (see Table 3).

Table 4 Matcher Field Names

Field Name Description

EventName (Required)

Specify the event name to be retrieved from the QID to identify the event.

EventCategory Specify an event category for any event with a category

not handled by an event-match-single entity or an event-match-multiple entity.

Combined with EventName, EventCategory is used to

search for the event in the QID. SourceIp Specify the source IP address for the message. SourcePort Specify the source port for the message. SourceIpPreNAT Specify the source IP address for the message before

Network Address Translation (NAT) occurs. SourceIpPostNAT Specify the source IP address for the message after NAT

occurs. SourceMAC Specify the source MAC address fo r the message. SourcePortPreNAT Specify the source port for the message before NAT

occurs. SourcePortPostNAT Specify the source port for the message after NAT occurs. DestinationIp Specify the destination IP address for the message. DestinationPort Specify the destination port for the message. DestinationIpPreNAT Specify the destination IP address for the message before

NAT occurs. DestinationIpPostNAT Specify the destination IP address for the message after

NAT occurs. DestinationPortPreNAT Specify the destination port for the message before NAT

occurs. DestinationPortPostNAT Specify the destination port for the message after NAT

occurs. DestinationMAC Specify the destination MAC address for the message. DeviceTime Specify the time that the event was sent, according to the

device (this is NOT the time that the event arrived).

STRM detects timestamps in the following formats:

• Valid syslog timestamp in the form of mm dd hh:mm:ss,

for example:

Jan 13 12:33:10

• Current locale timestamp

Any other formats will not properly convert.

Release 2008.2

Table 4 Matcher Field Names (continued)

Field Name Description

Protocol Specify the protocol associated with th e eve n t; fo r

example, TCP, UDP, or ICMP. If a protocol is not properly parsed out of a message, ports

that were parsed may not appear in STRM (it only displays

ports for port-based protocols). UserName Specify the user name associated with the event. HostName Specify the host name associated with the event. This field

is usually only associated with identity events. GroupName Specify the group name associated with the event. This

field is usually only associated with identity events. NetBIOSName Specify the NetBIOS name associated with the event. This

field is usually only associated with identity events.

Single-Event Modifier (event-match-single) Single-event modifier (event-match-single) matches (and subsequently

modifies) exactly one type of event, as specified by the required, case-sensitive EventName parameter. This entity allows mutation of successful events by changing the device event category, severity, or the method for sending identity events.

When events matching this event name are parsed, the device category, severity, and identity properties are imposed upon the resulting event. An event-match-single entity consists of three optional properties:

Table 5 Single-Event Modifier Parameters

Parameter Description

device-event-category Specify a new category for searching in the QID for the

event. This is an optimizing parameter, since some devices have the same category for all events.

severity Specify the severity of the event. This parameter must

be an integer value between 1 and 10. If a severity of less than 1 or greater than 10 is

specified, the system defaults to 5. If not specified, the default is whatever is found in the

QID.

Release 2008.2

Creating Extension Documents 7

Table 5 Single-Event Modifier Parameters (continued)

Parameter Description

send-identity Specifies the sending of identity change information

from the event. Choose one of the following options:

• UseDSMResults – If the DSM returns an identity

event, the event is passed on. If the DSM does not return an identity event, the DSM does not create or modify the identity information.

This is the default value if no value is specified.

• SendIfAbsent – If the DSM creates identity

information, the identity event is passed through unaffected. If no identity event is produced by the DSM, but there is enough information in the event to create an identity event, an event is generated with all the relevant fields set.

• OverrideAndAlwaysSend – Ignores any identity

event returned by the DSM and creates a new identity event, if there is enough information.

• OverrideAndNeverSend – Suppress any identity

information returned by the DSM.

Creating Extension Documents

Multi-Event Modifier (event-match-multiple)

The multi-event modifier (event-match-multiple) matches a range of event types (and subsequently modifies) as specified by the and the

capture-group-index parameter.

pattern-id parameter

Note: This match is not run against the payload, but is run against the results of the EventName matcher previously parsed out of the payload.

This entity allows mutation of successful events by changing the device event category, severity, or the method the event uses to send identity events. The

capture-group-index must be an integer value (substitutions are not

supported) and pattern-ID must reference an existing pattern entity. All other properties are identical to their counterparts in the single-event modifier

This section provides you with information on creating extension documents including:

• Writing a Complete Extension Document

• Uploading Extension Documents

• Solving Specific Parsing Issues

Release 2008.2

Writing a Complete

Extension Document

The example of an extension document included in this section provides information on how to parse one particular type of Cisco FWSM so that events are not sent with an incorrect event name. For example, if you wish to resolve the word

session, which is embedded in the middle of the event name:

Nov 17 09:28:26 129.15.126.6 %FWSM-session-0-302015: Built UDP connection for faddr 38.116.157.195/80 gaddr

129.15.127.254/31696 laddr 10.194.2.196/2157 duration 0:00:00 bytes 57498 (TCP FINs)

This condition causes the DSM to not recognize any events and all the events are un-parsed and associated with the generic logger.

Although only a portion of the text string ( entire text string (

%FWSM-session-0-302015) identifies the event as coming from

302015) is used for the QID search, the

a Cisco FWSM. Since the entire text string is invalid, the DSM assumes that the event is invalid.

A FWSM device has a large number of event types, many with unique formats. The following extension document example, indicates how to parse one event type.

The pattern IDs do not have to match the field names that they are parsing. Even though the following example duplicates the pattern, the

SourceIp field and the

SourceIpPreNAT field could use the ex act same pa ttern i n this case (thi s may no t

be true in all FWSM events).

<?xml version="1.0" encoding="UTF-8"?> <device-extension xmlns="event_parsing/device_extension">

<match-group order="1" description="FWSM Test" device-type-id-override="6" xmlns=""> <matcher field="EventName" order="1" pattern-id="EventNameFWSM" capture-group="1"/> <matcher field="SourceIp" order="1" pattern-id="SourceIp" capture-group="1" /> <matcher field="SourcePort" order="1" pattern-id="SourceIp" capture-group="2" /> <matcher field="SourceIpPreNAT" order="1" pattern-id="SourceIpPreNAT" capture-group="1" /> <matcher field="SourceIpPostNAT" order="1" pattern-id="SourceIpPostNAT" capture-group="1" /> <matcher field="SourcePortPreNAT" order="1" pattern-id="SourceIpPreNAT" capture-group="2" /> <matcher field="SourcePortPostNAT" order="1" pattern-id="SourceIpPostNAT" capture-group="2" /> <matcher field="DestinationIp" order="1" pattern-id="DestinationIp" capture-group="1" />

Release 2008.2

Creating Extension Documents 9

<event-match-multiple pattern-id="EventNameId" capture-group-index="1" device-event-category="Cisco Firewall"/> </match-group>

</device-extension>

The above extension document example demonstrates some of the basic aspects of parsing:

• IP addresses

• Ports

• Protocol

• Multiple fields using the same pattern with different groups

This example parses all FWSM events that follow the specified pattern, although the fields that are parsed may not be present in those events (if the events include different content).

The information that was necessar y to create this configuration that was not available from the event:

• The event name is only the last six digits (302015) of the

%FWSM-session-0-302015 portion of the event.

• The FWSM has a hard-coded device type category of Cisco Firewall.

• The FWSM uses the Cisco Pix QID and therefore includes the

device-type-id-override="6" parameter in the match group (the Pix

firewall’s device type ID is 6, see Table 6).

If the QID information is not specified or is unavailable, you can modify the event mapping using the Event Viewer. For more information, see the Modifying Event Mapping section in the STRM Users Guide.

An event name and a device event category is required when looking for the event in the QID. This device event category is a grouping parameter within the database that helps define like events within a device. The

event-match-multiple at the

end of the match group includes hard-coding of the category. The

event-match-multiple uses the EventNameId pattern on the parsed event

name to match up to six digits. This pattern is not run against the full payload, just that portion parsed as the EventName field.

The EventName pattern references the FWSM events contain the

%FWSM portion. The pattern in the example matches

%FWSM portion of the events; all Cisco

%FWSM followed by any number (zero or more) of letters and dashes. This pattern

match resolves the word

session that is embedded in the middle of the event

name that needs to removed. The event severity (according to Cisco), followed by

Release 2008.2

a dash and then the true event name as expected by STRM. The only string with a capture group (that is, bounded by parenthesis) is this pattern of digits

(\d{1,3}\.\d{1,3}\.\d{1,3}\.\d{1,3}).

The IP addresses and ports for the event all follow the same basic pattern: an IP address followed by a slash followed by the numeric port number. This pattern parses two pieces of data (the IP address and the port), and specifies different capture groups in the matcher section.

Thus, the IP address/port patterns are four sets of one to three digits, separated by periods followed by a slash and the port number. The IP address section is in a group, as is the port number (but not the slash). As was previously mentioned, the matcher sections for these fields reference the same pattern name, but a different capture group (the IP address is group 1 and the port is group 2).

The protocol is a common pattern that searches the payload for the first instance of TCP, UDP, ICMP, or GRE (the pattern is marked with the case-insensitive parameter so that any occurrence matches).

Uploading Extension

Documents

Note: You must search for the protocol when writing extension documents, as STRM may not display port numbers if the event is not based on a port-based protocol. See

Converting a Protocol for an example of how to search for a protocol.

Although a second protocol pattern does not occur in the event being used as an example, there is a second protocol pattern defined with an order of two. If the lowest-ordered protocol pattern does not match, the next one is attempted (and so on). The second protocol pattern also demonstrates the concept of a direct substitution; there are no match groups in the pattern, but with the enable-substitutions parameter enabled, the text TCP can be used in place of protocol=6.

Multiple extension documents can be created, uploaded, and associated to various device types. Extension documents can be stored anywhere prior to uploading to STRM. When you select an extension document for uploading, STRM validates the document against the internal XSD. STRM also verifies the validity of the document before uploading to the system. For more information about device extensions, see Managing Sensor Devices Guide.

Release 2008.2

Creating Extension Documents 11

Solving Specific

Parsing Issues

This section provides you with XML examples that can be used when resolving specific parsing issues that may arise:

• Converting a Protocol

• Making a Single Substitution

• Generating Colon-Separated MAC Address

• Combining IP Address and Port

• Modifying an Event Category

• Modifying Multiple Event Categories

• Suppressing Identity Change Events

Converting a Protocol

The following example shows a typical protocol conversion that searches for TCP, UDP, ICMP or GRE anywhere in the payload, surrounded by any word boundary (for example, tab, space, end-of-line). Also, character case is ignored:

Making a Single Substitution

The following is an example of a straight substitution that parses the source IP address, and then overrides the result and sets the IP address to 10.100.100.100, ignoring the IP address in the payload. The example assumes that the source IP address matches something similar to SrcAddress=10.3.111.33 followed by a comma:

<pattern id="SourceIp_AuthenOK" xmlns=""> <![CDATA[SrcAddress=(\d{1,3}\.\d{1,3}\.\d{1,3}\.\d{1,3}),]]></pattern

Generating Colon-Separated MAC Address

STRM detects MAC ad dresses in a colon-se parated form. Since all devices do not use this form, the following example shows how to correct that situation:

In the above example SourceMAC=12-34-56-78-90-AB is converted to a MAC address of

12:34:56:78:90:AB.

Release 2008.2

If the dashes are removed from the pattern, the pattern converts a MAC address with no separators. If spaces are inserted, the pattern converts a space-separated MAC address, and so on.

Combining IP Address and Port

Typically an IP address and port are combined in one field, separated by a colon or a slash. The following example uses multiple capture groups with one pattern:

pattern id="SourceIPColonPort" xmlns=""><! [CDATA[Source=(\d{1,3}\.\d{1,3}\.\d{1,3}\.\d{1,3}):([\d]{1,5})]]></pattern>

Modifying an Event Category

A device event category may be hard-coded, or the severity needs to be adjusted. The following example adjusts the severity for a single event type:

<event-match-single event-name="TheEvent" device-event-category="Actual Category" severity="6" send-identity="UseDSMResults" />

Modifying Multiple Event Categories

The following example is similar to the above single event example, except that this example matches all event codes starting with

7 and followed by one to five

digits:

<event-match-multiple pattern-id="EventNameId" capture-group-index="1" device-event-category="Actual Category" severity="6" send-identity="UseDSMResults"/>

Suppressing Identity Change Events

A DSM may unnecessarily send identity change events. The following is two examples; one is a method of how to suppress identity change events from being sent from a single event type. The other is a method of how to suppress identity change events from being sent from a group of events.

// Never send identity for the event with an EventName of “Authen OK” <event-match-single event-name="Authen OK" device-event-category="ACS" severity="6" send-identity="OverrideAndNeverSend" />

// Never send any identity for an event with an event name starting with 7, followed by one to five other digits: <pattern id="EventNameId" xmlns=""><![CDATA[(7\d{1,5})]]></pattern>

<event-match-multiple pattern-id="EventNameId" capture-group-index="1" device-event-category="Cisco Firewall" severity="7" send-identity="OverrideAndNeverSend"/>

Release 2008.2

Device Type IDs 13

Device Type IDs Table 6 lists the Device Type IDs that can be used in a match-group statement:

Table 6 Device Type ID Numbers

ID Device Description

2 Snort Snort Open Source IDS 3 CheckPoint CheckPoint Firewall-1 Devices via syslog 4 GenericFirewall Configurable Firewall Filter 5 NetScreenFirewall NetScreen Firewall Appliance 6 Pix Cisco PIX Firewall 7 GenericAuthServer Configurable Authentication message filter 8 SOAP Webservice-based messages 9 Dragon Ente rasys Dragon IDS 10 Apache Open Source Apache Webserver 11 LinuxServer Linux login messages 12 WindowsAuthServer Windows Security Event Log 13 IIS Windows IIS Webserver logs 14 Iptables Linux iptables Firewall 15 Proventia ISS Proventia Device 16 Classify Q1Labs Classify Engine 17 NetScreenIDP NetScreen IDP 18 EventCRE Event CRE 19 UnityOne Tipping Point UnityOne 20 IOS Cisco IOS 21 Contivity Nortel Contivity VPN Switch 22 ARN Nortel BayRS 15.x 23 VpnConcentrator VPN 3000 Concentrator 24 Solaris Solaris Login Messages 25 IntruShield McAfee IntruShield Network IPS Appliance 26 CSA Cisco CSA 28 Enterasys Enterasys Matrix E1 Switch 29 Sendmail Solaris Sendmail 30 IDS Cisco IDS 31 Cisco FWSM Cisco FWSM 33 SiteProtector ISS SiteProtector 35 Cyberguard Cyberguard 36 JuniperSA Juniper Secure Access 37 Contivityv2 Nortel Contivity VPN Switch

Release 2008.2

Table 6 Device Type ID Numbers (continued)

ID Device Description

38 TopLayerIPS TopLayer IPS 39 Generic Generic DSM 40 Tripwire Tripwire 41 ASA Cisco ASA 42 Niksun Niksun 43 Sidewinder Secure Computing - Sidewinder 45 NetscreenNSM Netscreen NSM 46 WebProxy Squid WebProxy 47 IpAngel Lucid IpAngel 48 OracleDbAudit Oracle Database Audit Records 49 BigIP F5 Networks BigIP 50 SolarisDhcpd Solaris DHCP Transaction Logs 55 ArrayVPN A rray VPN 56 CiscoCatOS Cisco CatOS 57 ProFTPD ProFTPD server 58 LinuxDHCPServer Linux DHCP Server 59 InfranetController Juniper Infranet Controller 60 PDSN Sprint PoC PDSN 61 RNC Sprint PoC RNC 62 BTS Sprint PoC BTS 63 ACS Cisco ACS 64 JuniperRouter Juniper Router 65 Sprint Sprint PoC 66 CallManager Cisco Call Manager 67 GenericLog Generic Log DSM+C46 68 Nseries Enterasys N Series Router/Switch 70 ExtremeWare ExtremeWare 7.7 71 Sidewinder Secure Computing - Sidewinder 73 FortiGuard Fortinet FortiGuard 75 SymantecAV Symantec Anti Virus 78 SonicWall SonicWall Firewall 79 Vericept Vericept Conten t 36 0 80 WindowsAgent Q1 Windows Agent Syslog 82 SymantecFirewall Symantec Firewall 83 JuniperSBR Juniper Steel-Belted Radius 85 IBM AIX IBM AIX 5L Operating System

Release 2008.2

Device Type IDs 15

Table 6 Device Type ID Numbers (continued)

ID Device Description

86 metainfo Meta IP metainfo Meta IP 87 SymantecSystemCenter Symantec System Center JDBC/WinAgent 90 Cisco ACS Cisco ACS 91 Sentinel Enterasys Sentinel 92 CounterACT Forescount CounterACt 93 McAfee ePO McAfee ePolicy Orchestrator 94 Cisco CSA-syslog Cisco CSA using syslog 95 Cisco NAC Cisco NAC Appliance 96 TippingPointx505 3com Tippingpoint x5 series 97 MicrosoftDHCP Microsoft DHCP server 98 MicrosoftIAS Microsoft IAS server 99 MicrosoftExchange Microsoft Exchange server 100 TrendISVW Trend Interscan Virus wall 101 MsSQL Microsoft SQL Server 102 AppleOSX Apple OSX system/fw events 103 Bluecoat Bluecoat SG Appliance 104 Firewall6000 Nortel Switched Firewall 6000 105 Q1Labs QRadar Q1Labs QRadar 106 3Com 8800 Series Switch 3Com 8800 Series Switch 107 Nortel VPN Gateway Nortel VPN Gateway 108 NortelTPS Nortel Threat Protection Intrusion Sensor 109 Vis Host Events Vis New Host, Port, Vuln Notifications 110 NortelNAS Nortel Application Switch 111 JuniperDX Juniper DX accelerator 112 SNAREReflector SNARE Reflector 113 Cisco 12000 Series Cisco 12000 Series 114 Cisco 6500 Series Cisco 6500 Series 115 Cisco 7600 Series Cisco 7600 Series 116 Cisco CRS Series Cisco CRS Series 117 Cisco ISR Series Cisco ISR Series 118 Juniper M Series Juniper M Series 119 Third Brigade Third Brigade Deep Security Manager 120 Firewall5100 Nortel Switched Firewall 5100 121 JunOS JunOS 122 Juniper MX Series Juniper MX Series 123 Juniper T Series Juniper T Series

Release 2008.2

Copyright © 2008 Juniper Networks, Inc. All rights reserved. Juniper Networks and the Juniper Net works logo ar e regi stere d tr adema rks of Juniper Net works Inc. in the United States and other countries. All other trademarks, service marks, registered trademarks, or registered service marks in this document are the property of Juniper Networks or their respective owners. All specifications are subject to change without notice. Juniper Networks assumes no responsibility for any inaccuracies in this document or for any obligation to update information in th is document. Juniper Networks reserves the right to change, modify, transfer, or otherwise revise this publication without notice.

Part Number 530-025629-01

Juniper NETWORKS STRM - TECHNICAL NOTE REV 6-2008, STRM User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
