Page 1

JunosE™ Software for E Series™ Broadband Services Routers

System Event Logging Reference Guide

Release

11.3.x

Published: 2010-10-04

Page 2

Juniper Networks, Inc. 1194 North Mathilda Avenue Sunnyvale, California 94089 USA 408-745-2000 www.juniper.net

Juniper Networks, Junos, Steel-Belted Radius, NetScreen, and ScreenOS are registered trademarks of Juniper Networks, Inc. in the United States and other countries. The Juniper Networks Logo, the Junos logo, and JunosE are trademarks of Juniper Networks, Inc. All other trademarks, service marks, registered trademarks, or registered service marks are the property of their respective owners.

Juniper Networks assumes no responsibility for any inaccuracies in this document. Juniper Networks reserves the right to change, modify, transfer, or otherwise revise this publication without notice.

Products made or sold by Juniper Networks or components thereof might be covered by one or more of the following patents that are owned by or licensed to Juniper Networks: U.S. Patent Nos. 5,473,599, 5,905,725, 5,909,440, 6,192,051, 6,333,650, 6,359,479, 6,406,312, 6,429,706, 6,459,579, 6,493,347, 6,538,518, 6,538,899, 6,552,918, 6,567,902, 6,578,186, and 6,590,785.

JunosE™ Software for E Series™ Broadband Services Routers System Event Logging Reference Guide

Writing: Krupa Chandrashekar, Subash BabuAsokan, MarkBarnard, DianeFlorio, Bruce Gillham, Sarah Lesway-Ball, BrianWesley Simmons, Fran Singer Editing: Benjamin Mann, Alana Calapai Illustration: Nathaniel Woodward Cover Design: Edmonds Design

Revision History October 2010—FRS JunosE 11.3.x

The information in this document is current as of the date listed in the revision history.

YEAR 2000 NOTICE

Juniper Networks hardware and software products are Year 2000 compliant. The Junos OS has no known time-related limitations through the year 2038. However, the NTP application is known to have some difficulty in the year 2036.

Page 3

END USER LICENSE AGREEMENT

READ THIS END USER LICENSE AGREEMENT (“AGREEMENT”) BEFORE DOWNLOADING, INSTALLING, OR USING THE SOFTWARE.

BY DOWNLOADING, INSTALLING, OR USING THE SOFTWARE OR OTHERWISE EXPRESSING YOUR AGREEMENT TO THE TERMS CONTAINED HEREIN, YOU (AS CUSTOMER OR IF YOU ARE NOT THE CUSTOMER, AS A REPRESENTATIVE/AGENT AUTHORIZED TO BIND THE CUSTOMER) CONSENT TO BE BOUND BY THISAGREEMENT. IF YOU DO NOTOR CANNOT AGREE TOTHE TERMS CONTAINED HEREIN, THEN (A) DO NOT DOWNLOAD, INSTALL, OR USE THE SOFTWARE, AND (B) YOU MAY CONTACT JUNIPER NETWORKS REGARDING LICENSE TERMS.

1. The Parties. The parties to this Agreement are (i) Juniper Networks, Inc. (if the Customer’s principal office is located in the Americas) or Juniper Networks(Cayman)Limited(if the Customer ’sprincipal office is locatedoutside the Americas) (such applicable entity beingreferred to herein as“Juniper”), and (ii)the person ororganizationthat originally purchased from Juniperor anauthorized Juniper reseller theapplicable license(s) for use of the Software (“Customer”) (collectively, the “Parties”).

2. The Software. In this Agreement, “Software” means the program modules and features of the Juniper or Juniper-supplied software, for which Customer has paid the applicable license or support fees to Juniper or an authorized Juniper reseller, or which was embedded by Juniper in equipment which Customer purchased from Juniper or an authorized Juniper reseller. “Software” also includes updates, upgrades and new releases of such software. “Embedded Software” means Software which Juniper has embedded in or loaded onto the Juniper equipment and any updates, upgrades, additions or replacements which are subsequently embedded in or loaded onto the equipment.

3. License Grant. Subject to payment of the applicablefees and the limitations and restrictions set forthherein, Junipergrants to Customer a non-exclusive and non-transferable license, without right to sublicense, to use the Software, in executable form only, subject to the following use restrictions:

a. Customer shall use Embedded Software solely as embedded in, and for execution on, Juniper equipment originally purchased by Customer from Juniper or an authorized Juniper reseller.

b. Customer shall use the Software on a single hardware chassis having a single processing unit, or as many chassis or processing units for which Customer has paid the applicable license fees; provided, however, with respect to the Steel-Belted Radius or Odyssey Access Client software only, Customer shall use such Software on a single computer containing a single physical random access memory space and containing any number of processors. Use of the Steel-Belted Radius or IMS AAA software on multiple computers or virtual machines (e.g., Solaris zones) requires multiple licenses, regardless of whether such computers or virtualizations are physically contained on a single chassis.

c. Product purchase documents, paper or electronic user documentation, and/or the particular licenses purchased by Customer may specify limitstoCustomer’suse ofthe Software. Such limitsmayrestrictuse toa maximum numberof seats, registered endpoints, concurrent users, sessions, calls, connections, subscribers, clusters, nodes, realms, devices, links, ports or transactions, or require the purchase of separate licenses to use particular features, functionalities, services, applications, operations, or capabilities, or provide throughput, performance, configuration, bandwidth, interface, processing, temporal, or geographical limits. In addition, such limits may restrict the use of the Software to managing certain kinds of networks or require the Software to be used only in conjunction with other specific Software. Customer’s use of the Software shall be subject to all such limitations and purchase of all applicable licenses.

d. For any trial copy of the Software, Customer’s right to use the Software expires 30 days after download, installation or use of the Software. Customer may operate the Software after the 30-day trial period only if Customer pays for a license to do so. Customer may not extend or create an additional trial period by re-installing the Software after the 30-day trial period.

e. The Global Enterprise Edition of the Steel-Belted Radius software may be used by Customer only to manage access to Customer’s enterprise network. Specifically, service provider customers are expressly prohibited from using the Global Enterprise Edition of the Steel-Belted Radius software to support any commercial network access services.

The foregoing license is not transferable or assignable by Customer. No license is granted herein to any user who did not originally purchase the applicable license(s) for the Software from Juniper or an authorized Juniper reseller.

4. Use Prohibitions. Notwithstanding the foregoing, the license provided herein does not permit the Customer to, and Customer agrees not to and shall not: (a) modify, unbundle, reverse engineer, or create derivative works based on the Software; (b) make unauthorized copies of the Software (except as necessary for backup purposes); (c) rent, sell, transfer, or grant any rights in and to any copy of the Software,in anyform, to anythird party;(d) remove anyproprietarynotices, labels, or marks onor inany copy ofthe Software orany product in which the Software is embedded; (e) distribute any copy of the Software to any third party, including as may be embedded in Juniper equipment sold in thesecondhandmarket;(f) use any‘locked’ or key-restricted feature,function, service, application, operation,or capability without first purchasing the applicable license(s) and obtaining a valid key from Juniper, even if such feature, function, service, application, operation, or capability is enabled without a key; (g) distribute any key for the Software provided by Juniper to any third party; (h) use the

Page 4

Software in any manner that extends or is broader than the uses purchased by Customer from Juniper or an authorized Juniper reseller; (i) use Embedded Software on non-Juniper equipment; (j) use Embedded Software (or make it available for use) on Juniper equipment that the Customer did not originally purchase from Juniper or an authorized Juniper reseller; (k) disclose the results of testing or benchmarking of the Software to any third party without the prior written consent of Juniper; or (l) use the Software in any manner other than as expressly provided herein.

5. Audit. Customer shall maintain accurate records as necessary to verify compliance with this Agreement. Upon request by Juniper, Customer shall furnish such records to Juniper and certify its compliance with this Agreement.

6. Confidentiality. The Parties agree that aspects of the Software and associated documentation are the confidential property of Juniper. As such, Customer shall exerciseall reasonable commercial efforts to maintain the Software and associated documentation in confidence, which at a minimum includes restricting access to the Software to Customer employees and contractors having a need to use the Software for Customer’s internal business purposes.

7. Ownership. Juniper and Juniper’s licensors, respectively, retain ownership of all right, title, and interest (including copyright) in and to the Software, associated documentation, and all copies of the Software. Nothing in this Agreement constitutes a transfer or conveyance of any right, title, or interest in the Software or associated documentation, or a sale of the Software, associated documentation, or copies of the Software.

8. Warranty, Limitation of Liability, Disclaimer of Warranty. The warranty applicable to the Software shall be as set forth in the warranty statementthataccompaniesthe Software(the “Warranty Statement”). Nothing inthis Agreement shall giverise to anyobligation tosupport the Software. Support services may be purchased separately. Any such support shall be governed by a separate, written support services agreement. TO THE MAXIMUM EXTENT PERMITTED BY LAW, JUNIPER SHALL NOT BE LIABLE FOR ANY LOST PROFITS, LOSS OF DATA, OR COSTS ORPROCUREMENT OFSUBSTITUTE GOODSOR SERVICES,OR FORANYSPECIAL,INDIRECT, OR CONSEQUENTIALDAMAGES ARISING OUTOF THIS AGREEMENT,THE SOFTWARE,OR ANY JUNIPEROR JUNIPER-SUPPLIED SOFTWARE. IN NOEVENT SHALL JUNIPER BE LIABLE FOR DAMAGES ARISING FROM UNAUTHORIZED OR IMPROPER USE OF ANY JUNIPER OR JUNIPER-SUPPLIED SOFTWARE. EXCEPT AS EXPRESSLY PROVIDED IN THE WARRANTY STATEMENT TO THE EXTENT PERMITTED BY LAW, JUNIPER DISCLAIMS ANY AND ALL WARRANTIES IN AND TO THE SOFTWARE (WHETHER EXPRESS, IMPLIED, STATUTORY, OR OTHERWISE), INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, OR NONINFRINGEMENT. IN NO EVENT DOES JUNIPER WARRANT THAT THE SOFTWARE, OR ANY EQUIPMENT OR NETWORK RUNNING THE SOFTWARE, WILL OPERATE WITHOUT ERROR OR INTERRUPTION, OR WILL BE FREE OF VULNERABILITY TO INTRUSION OR ATTACK. In no event shall Juniper’s or its suppliers’ or licensors’ liability to Customer, whether in contract, tort (including negligence), breach of warranty, or otherwise, exceed the price paid by Customer for the Software that gave rise to the claim, or if the Software is embedded in another Juniper product, the price paid by Customer for such other product. Customer acknowledges and agrees that Juniper has set its prices and entered into this Agreement in reliance upon the disclaimers of warranty and the limitations of liability set forth herein, that the same reflect an allocation of risk between the Parties (including the risk that a contract remedy may fail of its essential purpose and cause consequential loss), and that the same form an essential basis of the bargain between the Parties.

9. Termination. Any breach of this Agreement or failure by Customer to pay any applicable fees due shall result in automatic termination of the license granted herein. Upon such termination, Customer shall destroy or return to Juniper all copies of the Software and related documentation in Customer’s possession or control.

10. Taxes. All license fees payable under this agreement are exclusive of tax. Customer shall be responsible for paying Taxes arising from the purchase of the license, or importation or use of the Software. If applicable, valid exemption documentation for each taxing jurisdiction shall be provided to Juniper prior to invoicing, and Customer shall promptly notify Juniper if their exemption is revoked or modified. All payments made by Customer shall be net of any applicable withholding tax. Customer will provide reasonable assistance to Juniper in connection with such withholding taxes by promptly: providing Juniper with valid tax receipts and other required documentation showing Customer’s payment of any withholding taxes; completing appropriate applications that would reduce the amount of withholding tax to be paid; and notifying and assisting Juniper in any audit or tax proceeding related to transactions hereunder. Customer shall comply with all applicable tax laws and regulations, and Customer will promptly pay or reimburse Juniper for all costs and damages related to any liability incurred by Juniper as a result of Customer’s non-compliance or delay with its responsibilities herein. Customer’s obligations under this Section shall survive termination or expiration of this Agreement.

11. Export. Customer agrees to comply with all applicable export laws and restrictions and regulations of any United States and any applicable foreign agency or authority, and not to export or re-export the Software or any direct product thereof in violation of any such restrictions, laws or regulations, or without all necessary approvals. Customer shall be liable for any such violations. The version of the Software supplied to Customer may contain encryption or other capabilities restricting Customer’s ability to export the Software without an export license.

Page 5

12. Commercial Computer Software. The Software is “commercial computer software” and is provided with restricted rights. Use, duplication, or disclosure by the United States government is subject to restrictions set forth in this Agreement and as provided in DFARS

227.7201 through 227.7202-4, FAR 12.212, FAR 27.405(b)(2), FAR 52.227-19, or FAR 52.227-14(ALT III) as applicable.

13. Interface Information. To the extent required by applicable law, and at Customer's written request, Juniper shall provide Customer with the interface information needed to achieve interoperability between the Software and another independently created program, on payment of applicable fee, if any. Customer shall observe strict obligations of confidentiality with respect to such information and shall use such information in compliance with any applicable terms and conditions upon which Juniper makes such information available.

14. Third Party Software. Any licensor of Juniper whose software is embedded in the Software andany supplier ofJuniper whose products or technology are embedded in (or services are accessed by) the Software shall be a third party beneficiary with respect to this Agreement, and such licensor or vendor shall have the right to enforce this Agreement in its own name as if itwere Juniper. In addition, certain third party software may be provided with the Software and is subject to the accompanying license(s), if any, of its respective owner(s). To the extent portions of the Software are distributed under and subject to open source licenses obligating Juniper to make the source code for such portions publicly available (such as the GNU General Public License (“GPL”) or the GNU Library General Public License (“LGPL”)), Juniper will make such source code portions (including Juniper modifications, as appropriate) available upon request for a period of up to three years from the date of distribution. Such request can be made in writing to Juniper Networks, Inc., 1194 N. Mathilda Ave., Sunnyvale, CA 94089, ATTN: General Counsel. You may obtain a copy of the GPL at http://www.gnu.org/licenses/gpl.html, and a copy of the LGPL

at http://www.gnu.org/licenses/lgpl.html .

15. Miscellaneous. This Agreement shall be governed by the laws of the State of California without reference to its conflicts of laws principles. The provisions of the U.N. Convention for the International Sale of Goods shall not apply to this Agreement. For any disputes arising under this Agreement, the Parties hereby consent to the personal and exclusive jurisdiction of, and venue in, the state and federal courts within Santa Clara County, California. This Agreement constitutes the entire and sole agreement between Juniper and the Customer with respect to the Software, and supersedes all prior and contemporaneous agreements relating to the Software, whether oral or written (including any inconsistent terms contained in a purchase order), except that the terms of a separate written agreement executed by an authorized Juniper representative and Customer shall govern to the extent such terms are inconsistent or conflict with terms contained herein. No modification to this Agreement nor any waiver of any rights hereunder shall be effective unless expressly assented to in writing by the party to be charged. If any portion of this Agreement is held invalid, the Parties agree that such invalidity shall not affect the validity of the remainder of this Agreement. This Agreement and associated documentation has been written in the English language, and the Parties agree that the English version will govern. (For Canada: Les parties aux présentés confirment leur volonté que cette convention de même que tous les documents y compris tout avis qui s'y rattaché, soient redigés en langue anglaise. (Translation: The parties confirm that this Agreement and all related documentation is and will be in the English language)).

Page 6

Page 7

Abbreviated Table of Contents

About the Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxi

Part 1 Chapters

Chapter 1 System Logging Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Chapter 2 Event Categories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Part 2 Event Categories

Chapter 3 A Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Chapter 4 B Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Chapter 5 C Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Chapter 6 D Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Chapter 7 E Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Chapter 8 F Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Chapter 9 G and H Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

Chapter 10 I Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Chapter 11 L Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123

Chapter 12 M Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139

Chapter 13 N Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159

Chapter 14 O Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163

Chapter 15 P Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 187

Chapter 16 Q Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 207

Chapter 17 R Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 209

Chapter 18 S Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 223

Chapter 19 T Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 239

Chapter 20 U Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 247

Chapter 21 V Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 249

Part 3 Index

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 255

Page 8

JunosE 11.3.x System Event Logging Reference Guide

Page 9

Table of Contents

About the Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxi

E Series and JunosE Documentation and Release Notes . . . . . . . . . . . . . . . . . . . . xxi

Audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxi

E Series and JunosE Text and Syntax Conventions . . . . . . . . . . . . . . . . . . . . . . . . xxi

Obtaining Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxiii

Documentation Feedback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxiii

Requesting Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxiii

Self-Help Online Tools and Resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxiv

Opening a Case with JTAC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxiv

Part 1 Chapters

Chapter 1 System Logging Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Overview of System Logging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Log Severity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Log Verbosity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Persistent Logs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Logging Platform Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Configuring Event Logging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Configuring Log Severity for Individual and Systemwide Logs . . . . . . . . . . . . . . . . 10

Configuring Log Verbosity for Individual Logs or All Logs . . . . . . . . . . . . . . . . . . . . 14

Setting the Timestamp for Log Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Configuring Log Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Turning Off Log Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Monitoring Logging System Events . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Chapter 2 Event Categories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Part 2 Event Categories

Chapter 3 A Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

aaaAtm1483Cfg . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

aaaEngineGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

aaaQosCfg . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

aaaServerGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

aaaUserAccess . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

addressServerGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

ar1AaaServerGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

atm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

atm1483 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

atm1483VcClass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

atmAal5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Page 10

JunosE 11.3.x System Event Logging Reference Guide

atmVcClass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

auditIpsec . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Chapter 4 B Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

bfdAdaptivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

bfdEvents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

bfdGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

bfdSession . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

bgpConnections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

bgpDampening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

bgpEvents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

bgpGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

bgpGracefulRestart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

bgpIpv6NextHops . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

bgpKeepAlives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

bgpMessages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

bgpNeighborChanges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

bgpNextHops . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

bgpRoutes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

bridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

bridgeEngine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

bridgingMgr . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

bulkStats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Chapter 5 C Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

cacGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

cacIntf . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

cliCommand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

cliGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

connectionManager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

cops . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

copsPr . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

coreDump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

ctreeLog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Chapter 6 D Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

dcm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

dcmEngineGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

debounceEvents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

debounceGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

dhcpCapture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

dhcpExternal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

dhcpExternalEngine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

dhcpGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

dhcpIssuLog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

dhcpLocalClients . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

dhcpLocalGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

dhcpLocalHighAvailability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

dhcpLocalPool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

dhcpLocalProtocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Page 11

Table of Contents

dhcpOfferLog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

dhcpPbeGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

dhcpProxyGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

dhcpRelayGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

dhcpRelayNvWriterGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

dhcpv6Client . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

dhcpv6DemuxGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

dhcpv6LsGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

dismanEventMgr . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

dnsGeneralLog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

dosProtection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

ds1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

ds3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

dvmrpGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

dvmrpGracefulRestart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

dvmrpMcastTable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

dvmrpProbeRcv . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

dvmrpProbeSent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

dvmrpRtTable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Chapter 7 E Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

ethernetStateSession . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Chapter 8 F Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

fileSystem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

flowInspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

flowInspectionEngine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

flowServicesFirewallAlert . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

flowServicesFirewallAudit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

frameRelay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

fsAgent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

ft1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

ftpClient . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

ftpServer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Chapter 9 G and H Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

gplaan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

ha . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

hdlc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

hotfixGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

httpServer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

Chapter 10 I Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

icImageFixServer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

icmpTraffic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

icmpv6Traffic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

icrPartitionManager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

igmpGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

igmpGracefulRestart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Page 12

JunosE 11.3.x System Event Logging Reference Guide

igmpGroupState . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

ikeCertificateMgr . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

ikeEnrollment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94

ikepki . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94

interModuleCommunication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

ipAccessList . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

ipEngine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

ipEngineering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

ipflowstats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

ipflowstatsEngine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

ipGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

ipIfCreator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100

ipInterface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100

ipNhopTrackerGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

ipProfileMgr . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

ipRoutePolicy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102

ipRouteTable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102

ipsecIdDb . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

ipsecP1Throttler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

ipsecXcfgSM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104

ipSubscriberMgr . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104

ipTraffic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105

ipTunnel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105

ipv6AccessList . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106

ipv6General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

ipv6Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108

ipv6ProfileMgr . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108

ipv6RouteTable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109

ipv6Traffic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110

ipv6Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110

isisAdjChange . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

isisAdjPackets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112

isisBfdEvents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112

isisChecksumErr . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113

isisGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113

isisHelloGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114

isisHelloPackets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114

isisIpv6Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115

isisLdpEvents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116

isisLocalUpdate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116

isisMplsTeAdvertisements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

isisMplsTeEvents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

isisNsfEvents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118

isisProtocolErr . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118

isisSnpPackets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119

isisSpfEvents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119

isisSpfStatistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

isisSpfTriggers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

isisUpdatePackets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

Page 13

Table of Contents

isVoice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

itm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122

Chapter 11 L Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123

l2cGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124

l2cKeepAlive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124

l2cPacket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125

l2tp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125

l2tpDialoutGenerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126

l2tpDisconnectCause . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126

l2tpIpLowerBinding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127

l2tpStateMachine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127

lasv6General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128

ldpConnect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128

ldpGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129

ldpGracefulRestart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129

ldpHelloMessages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130

ldpHelloMgr . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130

ldpInterface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131

ldpMessages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132

ldpPeer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132

ldpShimInterface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133

ldpSocket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133

ldpTimer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134

ldpVpls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135

ldpWorker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135

localAddressServerGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136

localAuthServer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136

localEnableAuthServer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137

localLinePassword . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137

Chapter 12 M Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139

macroData . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140

macroSchedular . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140

mgtmGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141

mgtmGracefulRestart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142

mgtmv6General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142

mgtmv6GracefulRestart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143

mldGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144

mldGracefulRestart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145

mldGroupState . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145

mmcd . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146

mobileIpv4HaBinding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146

mobileIpv4HaEng . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147

mobileIpv4HaEvent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147

mobileIpv4HaLog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148

mplsFwdTable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148

mplsGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149

mplsHighAvailability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149

mplsMajorInterface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150

Page 14

JunosE 11.3.x System Event Logging Reference Guide

mplsMinorInterface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151

mplsRouter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152

mplsShimInterface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152

mplsTraffic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153

mrInfoLog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153

mrInfoRcvdLog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154

mrInfoSentLog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154

mtraceLog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155

mtraceRcvdLog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155

mtraceSentLog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156

multicastTraffic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156

Chapter 13 N Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159

nameResolverLog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159

nfsClient . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159

noneAaaAddrServer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160

noneAaaServer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160

ntpGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161

Chapter 14 O Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163

oam3ahAssociations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 164

oam3ahEvents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 164

oam3ahPdus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165

os . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165

ospfElectDr . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 166

ospfGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167

ospfHelloPktsRcvd . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168

ospfHelloPktsSent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169

ospfInterface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170

ospfLdpEvents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170

ospfLsa . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171

ospfNeighbor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171

ospfPktsRcvd . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172

ospfPktsSent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172

ospfRestart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173

ospfRoute . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174

ospfSpfExt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174

ospfSpfInter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175

ospfSpfIntra . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175

ospfTeDatabase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 176

ospfTeSpf . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 176

ospfv3ElectDr . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177

ospfv3General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178

ospfv3HelloPktsRcvd . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179

ospfv3HelloPktsSent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179

ospfv3Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180

ospfV3Lsa . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 181

ospfv3Neighbor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 181

ospfv3PktsRcvd . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 182

ospfv3PktsSent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 183

Page 15

Table of Contents

ospfv3Route . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 183

ospfV3SpfExt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 184

ospfV3SpfInter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 184

ospfV3SpfIntra . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 185

Chapter 15 P Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 187

pimAutoRPRcvdLog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 188

pimAutoRPSentLog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 189

pimBsrRcvdLog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 189

pimBsrSentLog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 190

pimGracefulRestartLog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 191

pimHelloRcvdLog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 191

pimHelloSentLog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 192

pimIpv6AutoRPRcvdLog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 192

pimIpv6AutoRPSentLog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193

pimIpv6BsrRcvdLog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 194

pimIpv6BsrSentLog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 195

pimIpv6GracefulRestartLog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 195

pimIpv6HelloRcvdLog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 196

pimIpv6HelloSentLog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 197

pimIpv6PktsRcvdLog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 197

pimIpv6PktsSentLog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 198

pimPktsRcvdLog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 199

pimPktsSentLog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 199

pimsmGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200

pimsmMvpn . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200

policyMgrAttachment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201

policyMgrGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201

policyMgrPacketLog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 202

ppp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 202

pppoe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 203

pppoeControlPacket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 204

pppPacket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 204

pppStateMachine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 205

profileMgr . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 206

Chapter 16 Q Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 207

qm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 207

qos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 207

qosAttachment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 208

Chapter 17 R Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 209

radiusAttributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 209

radiusClient . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 210

radiusCoAAttributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 210

radiusDisconnectGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 211

radiusRelayGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 211

radiusSendAttributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 212

remOps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 213

resourceThresholdTrap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 213

Page 16

JunosE 11.3.x System Event Logging Reference Guide

ripBfd . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 214

ripGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 214

ripRoute . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 215

ripRtTable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 216

routeDownloader . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 216

routerLog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 217

rsvpAsyncMgr . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 217

rsvpBfd . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 218

rsvpGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 218

rsvpGracefulRestart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 219

rsvpInterface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 219

rsvpTunnel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 220

Chapter 18 S Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 223

security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 224

serviceability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 224

serviceMgr . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 225

serviceMgrClientSession . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 225

serviceMgrDcm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 226

serviceMgrMacroManager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 226

serviceMgrPerformance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 227

serviceMgrServiceDef . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 227

serviceMgrServiceInstance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 228

serviceMgrServiceSession . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 228

serviceMgrSubscriberSession . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 229

slep . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 229

snmp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 230

snmpIfMib . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 230

snmpPduAudit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 231

snmpSetPduAudit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 231

snmpTrap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 232

sonet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 232

sonetPath . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 233

sonetVT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 233

ssccDetailPm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 234

ssccDetailSsc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 234

ssccGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 235

ssccLacGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 235

ssh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 236

stTunnel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 237

stTunnelEngine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 237

system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 238

Chapter 19 T Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 239

tacacsPlusServer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 239

tcpGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 240

tcpTraffic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 240

tcpv6Traffic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 241

telnet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 242

telnetClient . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 242

Page 17

Table of Contents

tftpClient . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 243

trackerEvents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 243

trackerGeneral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 244

tsm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 244

Chapter 20 U Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 247

udpTraffic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 247

udpv6Traffic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 248

Chapter 21 V Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 249

vrrp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 249

vrrpTracking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 250

vsm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 250

vsmEngine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 251

Part 3 Index

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 255

Page 18

JunosE 11.3.x System Event Logging Reference Guide

Page 19

List of Tables

About the Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxi

Table 1: Notice Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxii

Table 2: Text and Syntax Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxii

Part 1 Chapters

Chapter 1 System Logging Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Table 3: Log Severity Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Page 20

JunosE 11.3.x System Event Logging Reference Guide

Page 21

About the Documentation

•

E Series and JunosE Documentation and Release Notes on page xxi

•

Audience on page xxi

•

E Series and JunosE Text and Syntax Conventions on page xxi

•

Obtaining Documentation on page xxiii

•

Documentation Feedback on page xxiii

•

Requesting Technical Support on page xxiii

E Series and JunosE Documentation and Release Notes

For a list of related JunosE documentation, see

http://www.juniper.net/techpubs/software/index.html .

If the information in the latest release notes differs from the information in the documentation, follow the JunosE Release Notes.

To obtain the most current version of all Juniper Networks®technical documentation, see the product documentation page on the Juniper Networks website at

http://www.juniper.net/techpubs/.

Audience

This guide is intended for experienced system and network specialists working with Juniper Networks E SeriesBroadband Services Routers in an Internetaccessenvironment.

E Series and JunosE Text and Syntax Conventions

Table 1 on page xxii defines notice icons used in this documentation.

Page 22

JunosE 11.3.x System Event Logging Reference Guide

Table 1: Notice Icons

Table 2 on page xxii defines text and syntax conventions that we use throughout the E Series and JunosE documentation.

DescriptionMeaningIcon

Indicates important features or instructions.Informational note

Indicates a situation that might result in loss of data or hardware damage.Caution

Alerts you to the risk of personal injury or death.Warning

Alerts you to the risk of personal injury from a laser.Laser warning

Table 2: Text and Syntax Conventions

Representscommandsand keywordsin text.Bold text like this

Fixed-width text like this

Italic text like this

Plus sign (+) linking key names

Syntax Conventions in the Command Reference Guide

Representsinformationas displayedon your terminal’s screen.

•

Emphasizes words.

•

Identifies variables.

•

Identifies chapter, appendix, and book

names.

keys simultaneously.

ExamplesDescriptionConvention

•

Issue the clock source command.

•

Specify the keyword exp-msg.

host1(config)#traffic class low-loss1Represents text that the user must type.Bold text like this

host1#show ip ospf 2

Routing Process OSPF 2 with Router ID 5.5.0.250

Router is an Area Border Router (ABR)

•

There are two levels of access: user and privileged.

•

clusterId, ipAddress.

•

Appendix A, System Specifications

Press Ctrl + b.Indicates that you must press two or more

terminal lengthRepresents keywords.Plain text like this

mask, accessListNameRepresents variables.Italic text like this

Page 23

Table 2: Text and Syntax Conventions (continued)

About the Documentation

ExamplesDescriptionConvention

| (pipe symbol)

or variable to the left or to the right of this symbol. (The keyword or variable can be either optional or required.)

[ ]* (brackets and asterisk)

that can be entered more than once.

Represent required keywords or variables.{ } (braces)

Obtaining Documentation

To obtain the most current version of all Juniper Networks technical documentation, see the Technical Documentation page on the Juniper Networks Web site at

http://www.juniper.net/.

To download complete sets of technical documentation to create your own documentation CD-ROMs or DVD-ROMs, see the Portable Libraries page at

http://www.juniper.net/techpubs/resources/index.html

diagnostic | lineRepresents a choice to select one keyword

[ internal | external ]Represent optional keywords or variables.[ ] (brackets)

[ level1 | level2 | l1 ]*Represent optional keywords or variables

{ permit | deny } { in | out }

{ clusterId | ipAddress }

Copies of the Management Information Bases (MIBs) for a particular software release are available for download in the software image bundle from the Juniper Networks Web site athttp://www.juniper.net/.

Documentation Feedback

We encourage you to provide feedback, comments, and suggestions so that we can improve the documentation to better meet your needs. Send your comments to

techpubs-comments@juniper.net, or fill out the documentation feedback form at

https://www.juniper.net/cgi-bin/docbugreport/. If you are using e-mail, be sure to include

the following information with your comments:

•

Document or topic name

•

URL or page number

•

Software release version

Requesting Technical Support

Technical productsupport isavailable through theJuniper NetworksTechnical Assistance Center (JTAC). If you are a customer with an active J-Care or JNASC support contract,

Page 24

JunosE 11.3.x System Event Logging Reference Guide

or are covered under warranty, and need post-sales technical support, you can access our tools and resources online or open a case with JTAC.

•

JTAC policies—For a complete understanding of our JTAC procedures and policies, review the JTAC User Guide located at

http://www.juniper.net/us/en/local/pdf/resource-guides/7100059-en.pdf .

•

Product warranties—For product warranty information, visit

http://www.juniper.net/support/warranty/ .

•

JTAC hours of operation—The JTAC centers have resources available 24 hours a day, 7 days a week, 365 days a year.

Self-Help Online Tools and Resources

For quick and easy problem resolution, Juniper Networks has designed an online self-service portal called the Customer Support Center (CSC) that provides you with the following features:

•

Find CSC offerings: http://www.juniper.net/customers/support/

•

Search for known bugs: http://www2.juniper.net/kb/

•

Find product documentation: http://www.juniper.net/techpubs/

•

Find solutions and answer questions using our Knowledge Base: http://kb.juniper.net/

•

Download the latest versions of software and review release notes:

http://www.juniper.net/customers/csc/software/

•

Search technical bulletins for relevant hardware and software notifications:

https://www.juniper.net/alerts/

•

Join and participate in the Juniper Networks Community Forum:

http://www.juniper.net/company/communities/

•

Open a case online in the CSC Case Management tool: http://www.juniper.net/cm/

To verifyservice entitlement by product serial number, use our SerialNumber Entitlement (SNE) Tool: https://tools.juniper.net/SerialNumberEntitlementSearch/

Opening a Case with JTAC

You can open a case with JTAC on the Web or by telephone.

•

Use the Case Management tool in the CSC at http://www.juniper.net/cm/ .

•

Call 1-888-314-JTAC (1-888-314-5822 toll-free in the USA, Canada, and Mexico).

For international or direct-dial options in countries without toll-free numbers, see

http://www.juniper.net/support/requesting-support.html .

Page 25

PART 1

Chapters

•

System Logging Overview on page 3

•

Event Categories on page 21

Page 26

JunosE 11.3.x System Event Logging Reference Guide

Page 27

CHAPTER 1

System Logging Overview

E Series Broadband Services Routers enable you to log system events to discover and isolate problems with your system. This chapter explains how to use the command-line interface (CLI) to monitor your system’s log configuration and stay informed about all system events that you want to track.

This chapter contains the following sections:

•

Overview of System Logging on page 3

•

Logging Platform Considerations on page 4

•

Configuring Event Logging on page 5

•

Configuring Log Severity for Individual and Systemwide Logs on page 10

•

Configuring Log Verbosity for Individual Logs or All Logs on page 14

•

Setting the Timestamp for Log Messages on page 14

•

Configuring Log Filters on page 15

•

Turning Off Log Filters on page 16

•

Monitoring Logging System Events on page 17

Overview of System Logging

System events are classified into event categories. Using the CLI, you can determine which event categories to log. To fully utilize the logging facility, you need to understand log severity and log verbosity.

Log Severity

Log severity is a level that is assigned to an event or log message. Log severity levels apply to event categories, such as bulkStats, bgpRoutes, or atm1483.

The minimum severity of a log message for an individual category is described either by a severity number in the range 0–7 or a descriptive priority term, such as emergency or debug. The lower the severity number is, the higher the priority. See Table 3 on page 4.

NOTE: Not every event category supports every severity level. For a list of event categories and the severity levels that each category supports, see “Event Categories” on page 21.

Page 28

JunosE 11.3.x System Event Logging Reference Guide

Table 3: Log Severity Descriptions

System ResponseSeverityNameSeverity Number

System unusable; shelf resetEmergency0

Immediate action needed; card resetAlert1

Critical conditions exist; interface is downCritical2

Error conditions; nonrecoverable software errorError3

Warning conditions; recoverable software errorWarning4

Log Verbosity

Persistent Logs

Notice5

Info6

Normal but significant conditions; nonerror, low-verbosity information

Informational messages; nonerror, medium-verbosity information

Debug messages; nonerror, high-verbosity informationDebug7

The verbosity level determines theamount of information that appears in each message. You can assign the verbosity level for the log category. Verbosity levels can be any of the following:

•

Low—Terse

•

Medium—Moderate

•

High—Verbose

NOTE: Many event categories provide only low-verbosity detail regardless

of the verbosity setting.

Log messages can survive a system reboot. After a reboot, the system rebuilds the list of log messages. However, if the system detects any problems or has gone through a power cycle, the buffer is reset, and the log messages from the previous session are lost.

Log messages are not synchronized between primary and redundant SRP modules. During a switchover from a primary to a redundant SRP module, existing log messages are not transferred to the redundant SRP module.

Logging Platform Considerations

System logs are supported on all E Series routers.

Page 29

For information about the modules supported on E Series routers:

•

See the ERXModule Guide for modulessupportedon ERX7xxmodels, ERX14xx models, and the Juniper Networks ERX310 Broadband Services Router.

•

See the E120 and E320 Module Guide for modules supported on the Juniper Networks E120 and E320 Broadband Services Routers.

Configuring Event Logging

By default, event logging is enabled and has default settings. This section explains how to change settings to customize event logging to fit your needs.

•

Set a baseline for when the system begins logging messages.

host1#baseline log 11:12:55 April 30 2002

•

Set the log severity.

host1(config)#log severity warning

Chapter 1: System Logging Overview

•

Remove the limit on the number of buffers available for an event category.

host1(config)#log unlimit qos

•

Set the log verbosity.

host1(config)#log verbosity low

•

Log messages to a specified destination.

host1(config)#log destination syslog 10.10.9.5 include ospfGeneral

mplsGeneral os

•

Select fields to be added to logs.

host1(config)#log fields timestamp instance no-calling-task

•

Enable logs destined for a console to be displayed at the current console device.

host1#log here

The next sectionsexplain how to configure individual and systemwide logs, how to format timestamps for log messages, and how to configure log filters.

baseline log • Use to set a baseline for logging events. Only log messages timestamped after the

baseline appear when you enter the show log data delta command.

• To use the current system time, do not enter any options.

• To set a specific time, use the following syntax:

Hour:Minute[:Second]—Current time in 24-hour format. Seconds are optional.

• utc—Enter this keyword to indicate that the time entered is in universal coordinated

time (UTC), rather than local time.

• To set a specific date, use the following syntax:

Month Day Year—You must spell out the name of the month.

Page 30

JunosE 11.3.x System Event Logging Reference Guide

• last-reset—Causes the system to display log messages generated since the last time

the system was reset

• Examples

host1#baseline log 11:12:55 April 30 2002 host1#baseline log last-reset

• There is no no version.

• See baseline log.

log destination • Use to log messages to the specified destination, including system log, console, and

nv-file (nonvolatile storage).

NOTE: You can display traffic logs—such as ipTraffic, icmpTraffic,

tcpTraffic, and udpTraffic—only through the show log data command or from the SRP module console. You cannot redirect traffic logs elsewhere, such as to a system log or nonvolatile storage file, or to a Telnet session.

• Use the severity keyword to limit the messages logged based on priority level.

• The following information applies to logging messages to system log servers.

• You can have multiple system log servers, but must configure logging to each one

separately.

• A particular message within a specified event category is logged to a particular

system log server only if the priority of the message is greater than or equal to both the priority of the event category and the priority of that system log server.

• If you log messages to a system log server, you can also specify:

• facility—Specifies a facility ID on the system log destination host. The range is

0–7, representing the logging facilities local0–local7.

• include—Logs only the listed categories to system log; no other categories are

logged unless specifically included by issuing this command again.

• exclude—Logs all categories to system log except the listed categories; all other

categories are logged unless specifically excluded by issuing this command again.

• Issuing an include command after an exclude command (or vice versa) overrides

the earlier command. Therefore, you cannot enter a command including certain categories and then follow it with a commandexcludingothers. Similarly,you cannot enter a command excluding certain categories and then follow it with a command including others.

• You can issue successive include commands or successive exclude commands; in

this case, the successive commands expand the list of included or excluded categories.

Page 31

Chapter 1: System Logging Overview

• Example 1—The first command causes only the osfpGeneral, mplsGeneral, and os

event categoriesto be logged to system log at 10.10.9.5. Thesecond command reverses this inclusion and restores the logging of all event categories.

host1(config)#log destination syslog 10.10.9.5 include ospfGeneral

mplsGeneral os

host1(config)#no log destination syslog 10.10.9.5

• Example 2—The first command again causes only the osfpGeneral, mplsGeneral, and

os event categories to be logged to system log at 10.10.9.5. The second command reversesthe inclusion ofospfGeneral and os. The mplsGeneral category isstill included and is thus the only category logged.

host1(config)#log destination syslog 10.10.9.5 include ospfGeneral mplsGeneral os host1(config)#no log destination syslog 10.10.9.5 include ospfGeneral os

• Example 3—The first command causes the isisGeneral, ipRoutePolicy, and ipTraffic

event categories to be excluded from logging to system log at 10.1.2.3. The second command reverses this exclusion and restores the logging of all event categories.

host1(config)#logdestinationsyslog10.1.2.3exclude isisGeneral ipRoutePolicy ipTraffic host1(config)#no log destination syslog 10.1.2.3 exclude

• Example 4—The first command again causes the isisGeneral, ipRoutePolicy, and

ipTraffic event categories to be excluded from logging to system log at 10.1.2.3. The second command reverses the exclusion of ipRoutePolicyand ipTraffic. The isisGeneral category is still excluded; all other events are logged.

host1(config)#log destination syslog 10.1.2.3 exclude isisGeneral

ipRoutePolicy ipTraffic

host1(config)#no log destination syslog 10.1.2.3 exclude isisGeneral

• Example 5—The first command causes the isisGeneral event category to be excluded

from logging to system log at 10.1.2.3. The second command causes ospfGeneral to also be excluded from logging.

host1(config)#log destination syslog 10.1.2.3 exclude isisGeneral host1(config)#log destination syslog 10.1.2.3 exclude ospfGeneral

• Example 6—The first command causes the isisGeneral event category to be excluded

from logging to systemlogat 10.1.2.3; all othereventsare logged. The second command overrides the first and causes the exclusion of all events except ospfGeneral.

host1(config)#log destination syslog 10.1.2.3 exclude isisGeneral host1(config)#log destination syslog 10.1.2.3 include ospfGeneral

• Use the no version to reverse the effects of previous commands or restore the default,

which is to log all event categories.

• See log destination.

log destination syslog

source

• Use to specify a source interface type and location for events logged to system log at

the specified IP address.

• Overrides the actual source interface type and location. The IP address associated

with thespecified source interface is used as thesource address for subsequent system log messages.

Page 32

JunosE 11.3.x System Event Logging Reference Guide

• Example

host1(config)#log destination syslog 10.1.2.3 source atm 0/1

• Use the no version to restore the actual source interface type and location.

• See log destination syslog source.

log engineering • Use to enable engineering logs.

• Provides troubleshooting information to assist you when contacting Juniper Networks

Technical Assistance Center (JTAC).

• Example

host1(config)#log engineering

• Use the no form of this command to disable engineering logs.

• See log engineering.

log fields • Use to select fields to be added to all logs. These fields include a timestamp for the

message, an instance identifier, and the name of the internal software application that created the message.

• Example

host1(config)#log fields timestamp instance no-calling-task

• Use the no version to restore the default log field settings.

• See log fields.

log here • Use to enable logs destined for a console to be displayed at the current console.

• By default, the local console automatically receives all log messages if console is a

destination. The exception is the cliCommand log, whose log events do not appear on the console.

• By default, Telnet consoles do not receive log messages.

• Example

host1#log here

• Use the no version to disable logs destined for a console from being displayed on this

console.

• See log here.

Page 33

Chapter 1: System Logging Overview

log severity • Use to set the severity level for systemwide logs (that is, when you do not specify an

individual event category) or for a specific event category. For a list of severity values, see Table 3 on page 4.

NOTE: Assigning a log severity to an individual event category changes its

state to Assigned. You cannot change the severity of that event category using systemwide level commands until you return the event category to its default, unassigned state with the no log severity command.

• If you do not specify a category, the severity value changes for all categories except

individual categories for which you previously set a specific severity level. See “Configuring Log Severity for Individual and Systemwide Logs” on page 10 for details.

• Each event category has itsown defaultseverity value. For most categories,the default

is Error.

• To disable all default level log messages, use the off keyword without specifying an

event category.

• To disable individual level log messages, use the off keyword and specify the event

category that you want to disable.

• Example

host1(config)#log severity warning

• Use the no version toreturn the systemwide (whenassigned) or default severity values

to event categories.

• Use the no version with an* (asterisk) to return all event categories (modified either

systemwide or individually) to their default severity setting. For example:

host1(config)#no log severity *

• See log severity.

log unlimit • Use to remove the limit on the number of outstanding buffers for an event category,

such as when the system is dropping logs of a particular category.

• Example

host1(config)#log unlimit qos

• Use the no version to return to the default value.

• See log unlimit.

log verbosity • Use to set the verbosity level for a selected category or for all categories.

• If you do not specify a category, then the verbosity level is set for all categories.

• The default verbosity setting for all logs is low.

• Example

host1(config)#log verbosity low

Page 34

JunosE 11.3.x System Event Logging Reference Guide

• Use the no version to return to the default verbosity (low) for the selected category.

• See log verbosity.

Configuring Log Severity for Individual and Systemwide Logs

You can change the severity setting for individual logs and the systemwide value.

When working with log severities, keep the following in mind:

•

All log event categories have a default. However, the default values can vary for each category. For example, most event categories havea default severity of Error. However, some event categories may have a default severity of Notice, Warning, Info, and so on.

•

Log event categories have two states—unassigned (default) and assigned. How a log event category reacts to the log severity command depends on its current state.

•

You can change log severities for event categoriesata systemwidelevelor anindividual level. Systemwide changes are those that modify a large number of unassigned event categories at one time; for example, the command log severity debug off. Individual changes are those that indicate an explicit event category that you want to change; for example, the command log severity notice clicommand.

•

Changes to log event categories at an individual level take precedence over those made at the systemwide level.

•

Changes to log event categories at the systemwide level take precedence over the default.

•

Assigning a log severity to an individual event category changes its state to Assigned. This means that you cannot change the severity of that event category using systemwide level commands until you return the event category to its default, unassigned state by using the no log severity eventCategory command.

•

To return all logs, systemwide and individual, to their default, unassigned severity level, use the no log severity * command.

•

To see whether individual or systemwide severity and verbosity settings are in effect, use the show log configuration command.

Example The following example demonstrates the effects of event category state in regard to

using systemwide commands:

1. In Configuration mode and having made no changes to the severity settings of any

event categories, view the log configuration:

host1(config)#run show log config log destination console severity WARNING log destination nv-file severity CRITICAL log destination syslog 10.10.4.240 facility 7 severity DEBUG no log engineering log fields timestamp instance no-calling-task no log here

Warning: Logging to this terminal is disabled no log severity

Page 35

Chapter 1: System Logging Overview

category severity verbosity filters notes

-------------------- -------- --------- ------- ----aaaAtm1483Cfg ERROR low aaaEngineGeneral ERROR low aaaServerGeneral ERROR low aaaUserAccess ERROR low addressServerGeneral ERROR low ar1AaaServerGeneral ERROR low atm ERROR low atm1483 ERROR low atmAal5 ERROR low

Notice that the atm event category has a default severity of Error.

2. Change all event categories to Warning, systemwide, and view the log configuration:

host1(config)#log severity warning host1(config)#run show log config log destination console severity WARNING log destination nv-file severity CRITICAL log destination syslog 10.10.4.240 facility 7 severity DEBUG no log engineering log fields timestamp instance no-calling-task no log here

Warning: Logging to this terminal is disabled log severity WARNING

category severity verbosity filters notes

-------------------- -------- --------- ------- ----aaaAtm1483Cfg WARNING low 1 aaaEngineGeneral WARNING low 1 aaaServerGeneral WARNING low 1 aaaUserAccess WARNING low 1 addressServerGeneral WARNING low 1 ar1AaaServerGeneral WARNING low 1 atm WARNING low 1 atm1483 WARNING low 1 atmAal5 WARNING low 1

3. Change the atm category to have a log severity of Emergency and view the log

configuration:

host1(config)#log severity emergency atm host1(config)#run show log config log destination console severity WARNING log destination nv-file severity CRITICAL log destination syslog 10.10.4.240 facility 7 severity DEBUG no log engineering log fields timestamp instance no-calling-task no log here

Warning: Logging to this terminal is disabled log severity WARNING

category severity verbosity filters notes

Page 36

JunosE 11.3.x System Event Logging Reference Guide

ar1AaaServerGeneral WARNING low 1 atm EMERGENCY low 2 atm1483 WARNING low 1 atmAal5 WARNING low 1

4. Change all event categories to Alert, systemwide, and view the log configuration:

host1(config)#log severity alert host1(config)#run show log config log destination console severity WARNING log destination nv-file severity CRITICAL log destination syslog 10.10.4.240 facility 7 severity DEBUG no log engineering log fields timestamp instance no-calling-task no log here

Warning: Logging to this terminal is disabled log severity ALERT

category severity verbosity filters notes

-------------------- -------- --------- ------- ----aaaAtm1483Cfg ALERT low 1 aaaEngineGeneral ALERT low 1 aaaServerGeneral ALERT low 1 aaaUserAccess ALERT low 1 addressServerGeneral ALERT low 1 ar1AaaServerGeneral ALERT low 1 atm EMERGENCY low 2 atm1483 ALERT low 1 atmAal5 ALERT low 1

Notice that the atm event category that you individually assigned in Step 3 does not change.

5. Turn off log notification, systemwide, and view the log configuration:

host1(config)#log severity off host1(config)#run show log config log destination console severity WARNING log destination nv-file severity CRITICAL log destination syslog 10.10.4.240 facility 7 severity DEBUG no log engineering log fields timestamp instance no-calling-task no log here

Warning: Logging to this terminal is disabled log severity OFF

category severity verbosity filters notes

-------------------- --------- --------- ------- ----aaaAtm1483Cfg OFF low 1 aaaEngineGeneral OFF low 1 aaaServerGeneral OFF low 1 aaaUserAccess OFF low 1 addressServerGeneral OFF low 1 ar1AaaServerGeneral OFF low 1 atm EMERGENCY low 2 atm1483 OFF low 1 atmAal5 OFF low 1

Notice that the atm event category does not change.

Page 37

Chapter 1: System Logging Overview

6. Remove the assignedstatus ofthe atmevent category and view the log configuration:

host1(config)#no log severity atm host1(config)#run show log config log destination console severity WARNING log destination nv-file severity CRITICAL log destination syslog 10.10.4.240 facility 7 severity DEBUG no log engineering log fields timestamp instance no-calling-task no log here

Warning: Logging to this terminal is disabled log severity OFF

category severity verbosity filters notes

-------------------- -------- --------- ------- ----aaaAtm1483Cfg OFF low 1 aaaEngineGeneral OFF low 1 aaaServerGeneral OFF low 1 aaaUserAccess OFF low 1 addressServerGeneral OFF low 1 ar1AaaServerGeneral OFF low 1 atm OFF low 1 atm1483 OFF low 1 atmAal5 OFF low 1

Notice that the atm event category follows the systemwide severity level of OFF. The systemwide setting takes precedence over the atm event category default of Error.

7. Change all event categories, systemwide, to their default/unassigned levels, and view

the log configuration:

host1(config)#no log severity *

Please wait....

Warning: Logging to this terminal is disabled no log severity

category severity verbosity filters notes

Page 38

JunosE 11.3.x System Event Logging Reference Guide

Configuring Log Verbosity for Individual Logs or All Logs

The default verbosity setting for all logs is low. To change the logging verbosity of an individual log, specify a category when you enter the log verbosity command. To change the log verbosity of every log, do not specify an event category when you enter the log verbosity command. However, after you enter the log verbosity command without specifying aparticular event category, all logsare set to thenew verbosity.No log verbosity overrides are saved.

Example The following example sets all log categories to verbosity medium, and then it sets the

verbosity level for ds3 events to high.

host1(config)#log verbosity medium host1(config)#log verbosity high ds3

Setting the Timestamp for Log Messages

You can use the service timestamps command to format timestamps for log messages. By default, log messages display universal coordinated time (UTC) without the time zone.

The following examples illustrate how you can change the timestamp on log messages.

•

Set the time zone to eastern daylight time (EDT), 5 hours behind UTC, and display the local time on the log messages.

host1(config)#clock timezone EDT -5

•

Display UTC, but no time zone, on the log messages.

host1(config)#service timestamps log datetime host1#exit host1#show log data category cliCommand severity info *********************************************************** NOTICE 05/14/2001 18:24:49 cliCommand: "configure terminal", console NOTICE 05/14/2001 18:24:45 cliCommand: "service timestamps log datetime", console ***********************************************************

•

Display UTC and the time zone on the log messages.

host1#configure terminal host1(config)#service timestamps log datetime show-timezone host1(config)#exit host1#show log data category cliCommand severity info *********************************************************** NOTICE 05/14/2001 18:28:45 UTC EDT cliCommand: "configure terminal", console NOTICE 05/14/2001 18:28:42 UTC EDT cliCommand: "service timestamps log datetime show-timezone", console ***********************************************************

•

Display no timestamp on the log messages.

host1#configure terminal host1(config)#no service timestamps

Page 39

host1#exit host1#show log data category cliCommand severity info *********************************************************** NOTICE 134 cliCommand: "configure terminal", console NOTICE 133 cliCommand: "no service timestamps", console ***********************************************************

service timestamps • Use to format timestamps for log messages.

• For information about setting local times and time zones, see JunosE System Basics

Configuration Guide.

• The show log data command displays the logdata with the current timestampformat.

• The show log data nv-file command displays the log data with the timestamp format

in effect at the time the log record was written.

• Use the no version to remove timestamps from log messages.

• See service timestamps.

Chapter 1: System Logging Overview

Configuring Log Filters

Many event categories contain filters so you can further refine the type of information that the system logs. For example, when logging BGP connections, you can limit the information logged to a specific access class, peer, route map, or virtual router.

You define filters when you set the log severity for an event category. The online Help shows the options you can set for each filter.

NOTE: You can use the packet flow monitoring feature to create user-defined

classification parameters that specify the packet data that is logged. See Packet Tagging Overview.

The following example createsa filter that logs BGPconnection information at thedebug severity level on traffic that matches access list ListOne, and is incoming traffic to virtual router default.

host1(config)# log severity debug bgpevents ? access-class Select an access list for the filter in Select import/in direction for the filter out Select export/out direction for the filter peer Select a peer IP address for the filter route-map Select a route map for the filter router Identify an instance of a virtual router <cr> host1(config)# log severity debug bgpevents access-class ? WORD The access list host1(config)# log severity debug bgpevents access-class ListOne ? filtering-router Identify virtual router where access-class/route-map are defined in Select import/in direction for the filter out Select export/out direction for the filter route-map Select a route map for the filter <cr>

Page 40

JunosE 11.3.x System Event Logging Reference Guide

host1(config)# log severity debug bgpevents access-class ListOne route-map ? WORD The route map host1(config)# log severity debug bgpevents access-class ListOne route-map default ? filtering-router Identify virtual router where access-class/route-map are defined in Select import/in direction for the filter out Select export/out direction for the filter <cr> host1(config)# log severity debug bgpevents access-class ListOne route-map default in

The next example limits the logging of PPP debug events to traffic to or from the POS interface in slot 2/0.

host1(config)#log severity debug ppp ? atm Specify an ATM PPP interface fastEthernet Specify a fastEthernet interface gigabitEthernet Specify a gigabitEthernet interface mlppp Specify an MLPPP network interface pos Specify a POS PPP interface serial Specify a serial PPP interface <cr> host1(config)#log severity debug ppp pos 2/0

To obtain a list of the filters available in each event category, see “Event Categories” on page 21 .

Turning Off Log Filters

You can turn off filters in three ways:

•

To turn off all filters:

To turn off all filters for anevent category, use the no version ofthe log severity command along with the category name. For example:

To turn off a specific filter, use the no version of the log severity command that you used to add the filter. For example:

no log filters • Use to turn off log filters.

• To turn off all filters for an event category, specify the category name.

Turn off all filters

Turn off all filters for an event category

Turn off a specific filter

host1(config)#no log filters

host1(config)#no log severity bgpEvents filters

host1(config)#no log severity bgpEvents peer 10.0.0.2 10.0.0.1

• Example

host1(config)#no log filters

Page 41

• To turn off a specific filter, use the no version of the log severity command that you

used to add the filter.

• See no log filters.

Monitoring Logging System Events

Use the show log configuration command to display your log configuration. Use the show log data command to display system events on your screen.

You can use theoutput filteringfeature of the show command to include or exclude lines of outputbasedon atextstring you specify. Seeshow Commands in JunosE System Basics Configuration Guide for details.

show log configuration • Use to show the logging configuration on your system.

• Example 1—Factory defaults are set

host1#show log configuration log destination console severity WARNING log destination nv-file severity CRITICAL no log engineering log fields timestamp instance no-calling-task no log severity

Chapter 1: System Logging Overview

category severity verbosity filters

------------------------- -------- --------- ------NameResolverLog ERROR low aaaAtm1483Cfg ERROR low aaaEngineGeneral ERROR low aaaServerGeneral ERROR low addressServerGeneral ERROR low atm ERROR low atm1483 ERROR low atmAal5 ERROR low bgpConnections ERROR low ... cliCommand NOTICE low controlNetworkSlave ERROR low cops ERROR low ... udpTraffic ERROR low

• Example 2—Individual log udpTraffic is set to warning

host1#(config)#log severity warning udpTraffic host1##show log configuration log destination console severity WARNING log destination nv-file severity CRITICAL no log engineering log fields timestamp instance no-calling-task no log severity

category severity verbosity filters

------------------------- -------- --------- ------NameResolverLog ERROR low aaaAtm1483Cfg ERROR low aaaEngineGeneral ERROR low aaaServerGeneral ERROR low

Page 42

JunosE 11.3.x System Event Logging Reference Guide

addressServerGeneral ERROR low atm ERROR low atm1483 ERROR low atmAal5 ERROR low bgpConnections ERROR low ... cliCommand NOTICE low controlNetworkSlave ERROR low cops ERROR low ... udpTraffic WARNING* low

* Default severity setting is overridden by the individual log severity setting.

• Example 3—Log severity is set to alert

host1#(config)#log severity alert host1#show log configuration log destination console severity WARNING log destination nv-file severity CRITICAL no log engineering log fields timestamp instance no-calling-task log severity ALERT

category severity verbosity filters

------------------------- -------- --------- ------NameResolverLog ALERT# low aaaAtm1483Cfg ALERT# low aaaEngineGeneral ALERT# low aaaServerGeneral ALERT# low addressServerGeneral ALERT# low atm ALERT# low atm1483 ALERT# low atmAal5 ALERT# low bgpConnections ALERT# low ... cliCommand ALERT# low controlNetworkSlave ALERT# low cops ALERT# low ... udpTraffic ALERT# low

* Default severity setting is overridden by the system-wide severity setting.

• Example 4—Individual log atm is set to severity warning

host1#(config)#log severity warning atm host1#show log configuration log destination console severity WARNING log destination nv-file severity CRITICAL no log engineering log fields timestamp instance no-calling-task log severity ALERT

category severity verbosity filters

------------------------- -------- --------- ------NameResolverLog ALERT# low aaaAtm1483Cfg ALERT# low aaaEngineGeneral ALERT# low aaaServerGeneral ALERT# low

Page 43

addressServerGeneral ALERT# low atm WARNING* low atm1483 ALERT# low atmAal5 ALERT# low bgpConnections ALERT# low ... cliCommand ALERT# low controlNetworkSlave ALERT# low cops ALERT# low ... udpTraffic ALERT# low

* Default severity setting is overridden by the system-wide severity setting.

* Default severity setting is overridden by the individual log severity setting.

• See show log configuration.

show log data • Use to display system events.

• Use keywords to select which events are displayed:

Chapter 1: System Logging Overview

• category—Limits the display to a single log event category. See the CLI online Help

for available categories.

• Example

host1#show log data category os

• delta—Limits the display to events that occurred after the time set with the log

baseline command.

• nv-file—Displays the information that is currently logged to nonvolatile storage.

• Example

host1# show log data nv-file logFile.temp: The system cannot find the file specified. ALERT 09/12/2000 21:29:17 os: ASSERTION FAILED: file mplsNvs2.cc, line 789 ALERT 09/20/2000 02:18:06 os: ASSERTION FAILED: file osPool.cc, line 819 ALERT 09/20/2000 02:26:35 os: ASSERTION FAILED: file osPool.cc, line 819 ALERT 09/20/2000 02:44:33 os: ASSERTION FAILED: file osPool.cc, line 819 ALERT 09/20/2000 04:56:35 os: ASSERTION FAILED: file osPool.cc, line 819 ALERT 09/27/2000 03:10:25 os: ASSERTION FAILED: file /sw0/sc/nvs/include/../nvMapBackend.h, line 235 ALERT 10/02/2000 04:05:42 os: ASSERTION FAILED: file osHeap.cc, line 439 ALERT 10/02/2000 04:08:04 os: ASSERTION FAILED: file osMessageQueue.cc, line 42, rip1 ALERT 10/12/2000 03:43:38 os: PANIC: file osSemaphore.cc, line 54 ALERT 11/01/2000 02:03:49 os: ASSERTION FAILED: file cliCommand.cc, line 195

• severity—Displays events that have a specific severity level.

• Example

Page 44

JunosE 11.3.x System Event Logging Reference Guide

host1# show log data severity notice NOTICE 01/10/2001 00:59:50 os: config -- using running NOTICE 01/10/2001 00:59:52 os: srp application, build date: 0x3a437424 (FRI DEC 22 2000 15:32:52 UTC) NOTICE 01/10/2001 00:59:52 os: last reset: user reboot, reason: not specified NOTICE 01/10/2001 00:59:52 os: OsIsrRegistrar: 0xb NOTICE 01/10/2001 00:59:52 os: OsIsrRegistrar: 0xa NOTICE 01/10/2001 00:59:52 os: OsIsrRegistrar: 0x2

• By combining keywords, you can further limit the information displayed. See the CLI

online Help for information about the keywords available at each level.

host1#show log data nv-file severity alert

• See show log data.

Page 45

CHAPTER 2

Event Categories

This chapter lists each event category in the system software. To help you determine the severity level to set when troubleshooting, the log strategy for each event category is included. The log strategy shows the type of information logged for each severity level. In addition, this chapter includes the filters available in each event category.

Page 46

JunosE 11.3.x System Event Logging Reference Guide

Page 47

PART 2

Event Categories

•

A Commands on page 25

•

B Commands on page 33

•

C Commands on page 49

•

D Commands on page 55

•

E Commands on page 75

•

F Commands on page 77

•

G and H Commands on page 83

•

I Commands on page 87

•

L Commands on page 123

•

M Commands on page 139

•

N Commands on page 159

•

O Commands on page 163

•

P Commands on page 187

•

Q Commands on page 207

•

R Commands on page 209

•

S Commands on page 223

•

T Commands on page 239

•

U Commands on page 247

•

V Commands on page 249

Page 48

JunosE 11.3.x System Event Logging Reference Guide

Page 49

CHAPTER 3

A Commands

•

aaaAtm1483Cfg on page 25

•

aaaEngineGeneral on page 26

•

aaaQosCfg on page 26

•

aaaServerGeneral on page 27

•

aaaUserAccess on page 27

•

addressServerGeneral on page 28

•

ar1AaaServerGeneral on page 28

•

atm on page 29

•

atm1483 on page 29

•

atm1483VcClass on page 30

•

atmAal5 on page 31

•

atmVcClass on page 31

•

auditIpsec on page 32

aaaAtm1483Cfg

Description AAA ATM 1483 subinterface configuration

Emergency None

Alert None

Critical None

Error None

Warning Log Illegal service category traffic parameter received from AAA; unable to modify circuit

Notice Log None

Info None

traffic parameters using those received from AAA

Page 50

JunosE 11.3.x System Event Logging Reference Guide

Debug Notification from AAA indicating that an ATM 1483subinterface configurationis available;

ATM 1483 processing configuration received from AAA; unable to get ATM 1483 subinterface information; number of ATM 1483 configuration entries is out of range

Filter None

aaaEngineGeneral

Description AAA engine general

Emergency None

Alert None

Critical None

Error None

Warning Log None

Notice Log Control flow and key events, less verbose than debug

aaaQosCfg

Description AAA QoS configuration logs

Emergency None

Info None

Debug Control flow and key events

Filter None

Alert None

Critical None

Error None

Warning Log None

Notice Log None

Info None

Page 51

Debug AAA QoS configuration tracking

Filter None

aaaServerGeneral

Description AAA server general

Emergency None

Alert None

Critical None

Error Subscriber count exceeds license plus grace; internal attachment errors

Warning Log Subscriber count exceeds license; cannot grow internal memory pools; accounting

Chapter 3: A Commands

messagefailures;the Framed-IPv6-PrefixRADIUS attribute isused for bothIPv6 Neighbor Discovery router advertisements and DHCPv6 Prefix Delegation;Notify duplicate event ignored for profileHandle: profileHandle issu in progress; Notify duplicate event ignored for profileHandle: profileHandle unable to allocate memory

Notice Log Authentication failures resulting from memory allocation failures

Debug Authentication failures resulting from reasons other than memory allocation failures;

Filter None

aaaUserAccess

Description AAA user access

Emergency None

Alert None

Info None

status of authentication; accounting and address assignment requests sent to local (internal) servers; duplicate accountingmessagefailures;EAP challenge received; memory allocation failure for tunnel definition table and profile; failed to insert tunnel attribute and tunnel tag table; container size exceeded: creating new; found unexpected tunnel table; dsl-forum atrribute type parse error: limited data or overflow; Duplicate prefix event received for profileHandle: profileHandle

Critical None

Page 52

JunosE 11.3.x System Event Logging Reference Guide

Error None

Warning Log None

Notice Log None

Info User is granted or denied access

Debug None

Filter None

addressServerGeneral

Description Address server general

Emergency None

Alert None

Critical None

Error None

Warning Log Address server request failure (for example, configured address server is not available)

Notice Log None

Info None

Debug None

Filter None

ar1AaaServerGeneral

Description Platform-dependent AAA server

Emergency None

Alert None

Critical None

Error Internal (NVS) errors for limit configuration per interface

Page 53

atm

Chapter 3: A Commands

Warning Log None

Notice Log None

Info None

Debug Interface information insufficient to identify the user’s interface location

Filter None

Description ATM interface

Emergency None

Alert None

Critical None

Error Unable to reenable ILMI administrative state after UNI version change

Warning Log Error gettinglocationof underlying physical interface; errorbinding orunbinding tophysical

interface; error allocating memory for new interface; error setting system identifier; error adding or configuring an interface; error getting capabilities of interface; error getting maximum VPI/VCI for interface; error getting maximum virtual circuit descriptor for interface;unable to store orallocate memoryfor F4OAM circuit data;unable to configure F4 OAM circuit for interface

Notice Log Interfacepool expanded by anincremental number of entries; reportretry delay inseconds

when waiting for the underlying physical interface to be created; unable to allocate a message to sendan interfaceup ordown notification; unable toadd orconfigureinterface

Info Dropping interface up, down, or not present notification due to removal of interface;

discarding F4 OAM circuits when interface does not support F4 OAM

Debug None

Filter None

atm1483

Description ATM 1483 data service

Emergency None

Page 54

JunosE 11.3.x System Event Logging Reference Guide

Alert None

Critical None

Error Error applying static map entry for a newly created circuit of an NBMA interface; unable

to configure interfaces on ATM interface; unable to determine interface location for ATM AAL5 interface;unable to determinemaximum interface configurationcount for interface; unable to configure interface on ATM interface

Warning Log Error gettinglocationof underlying AAL5or ATM interface; error binding to AAL5 interface;

error opening a circuit for an NBMA interface; attempting to associate a static map to an underlying ATM interface that does not exist; error restoring circuits from NVS; error removing static map entry; NVS entry not found for static map entry; error storing static map entry in NVS; error expanding interface pool, interface binding pool, or subscriber pool

Notice Log Interface pool, interface binding pool, or subscriber pool expanded by an incremental

number of entries; unable to allocate a message to send a subinterface up or down notification

Info Dropping subinterface up or down notification due to removal of subinterface; configure

Debug None

Filter None

atm1483VcClass

Description Application of attributes configured in a virtual circuit (VC) class to PVCs

Emergency None

Alert None

Critical None

Error In routers with high availability enabled, failure to mirror the VC modification or failure

Warning Log Failure to find the PVCs associated with this VC class; failure to apply the VC class

interfaces on ATM interface; elapsed time for downloading interfaces; elapsed time for ATM AAL5 present notification; maximum interface count per call

to associate the VC modification with the standby SRP module

attributes to the appropriate PVCs; the log message displays a brief description of the failure

Notice Log None

Page 55

atmAal5

Chapter 3: A Commands

Info None

Debug None

Filter None

Description ATM Adaptation Layer 5

Emergency None

Alert None

Critical None

Error None

Warning Log Error getting location of underlying ATM interface; error binding to ATM interface; unable

Notice Log Interfacepool expanded by anincremental number of entries; reportretry delay inseconds

atmVcClass

Description Information on VC class operational errors

Emergency None

to expand interface pool; error creating interface; unable to set administrative status of interface

when waitingfor the underlyingATM interfaceto be created; unable to allocate a message to send an interface up or down notification

Info Dropping interface up or down notification due to removal of interface

Debug None

Filter None

Alert None

Critical None

Error Resource failure errors, such as error allocating memory for adding a VC class; internal

software errors; error processing a VC class association; when using SNMP, unable to set a VC class state from not in service to in service, or vice-versa; unable to find an

Page 56

JunosE 11.3.x System Event Logging Reference Guide

existing VC class in the internal data structure; unable to complete processing after a high availability switchover

Warning Log None

Notice Log None

Info None

Debug Unable to update mirrored storage for a high availability switchover

Filter None

auditIpsec

Description IKE SA negotiations

Emergency None

Alert None

Critical None

Error None

Warning Log None

Notice Log Information about IKE SA negotiation payloads

Info None

Debug None

Filter None

Page 57

CHAPTER 4

B Commands

•

bfdAdaptivity on page 33

•

bfdEvents on page 34

•

bfdGeneral on page 34

•

bfdSession on page 35

•

bgpConnections on page 35

•

bgpDampening on page 36

•

bgpEvents on page 37

•

bgpGeneral on page 38

•

bgpGracefulRestart on page 38

•

bgpIpv6NextHops on page 39

•

bgpKeepAlives on page 40

•

bgpMessages on page 41

•

bgpNeighborChanges on page 42

•

bgpNextHops on page 42

•

bgpRoutes on page 43

•

bridge on page 46

•

bridgeEngine on page 46

•

bridgingMgr on page 47

•

bulkStats on page 47

bfdAdaptivity

Description BFD adaptivity events

Emergency None

Alert None

Critical None

Error None

Page 58

JunosE 11.3.x System Event Logging Reference Guide

Warning Log None

Notice Log None

Info BFD session adaptivity events

Debug BFD session adaptivity events

Filter None

bfdEvents

Description BFD Events

Emergency None

Alert None

Warning Log None

Notice Log None

bfdGeneral

Description BFD general events

Emergency None

Critical None

Error None

Info BFD session state changes

Debug None

Filter None

Alert None

Critical None

Error None

Warning Log None

Page 59

Notice Log BFD enabled/disabled on an interface from a client

bfdSession

Description BFD session events

Emergency None

Chapter 4: B Commands

Info None

Debug None

Filter None

Alert None

Critical None

Error None

Warning Log Unknown BFD session

Notice Log Session state changes

Info Session parameter changes

Debug None

Filter None

bgpConnections

Description BGP TCP/IP connection activity

Emergency None

Alert None

Critical None

Error Error setting password for specified peer; error binding to update-source address for

specified peer

Warning Log TCP error occurred while receiving data

Page 60

JunosE 11.3.x System Event Logging Reference Guide

Notice Log Outbound TCP connection initiated, completed, or failed; inbound TCP connection

accepted, refused, or failed; TCP connection closed by peer

Info None

Debug TCP connection is ready to send; data received on TCP connection; notification message

sent; could not send notification message due to flow control—will retry later; error while sending notification message; keepalive messagesent; could not send keepalive message due to flow control—will retry later; error while sending keepalive message; message other than notification or keepalive sent; could not send other message than notification or keepalive due to flow control—will retry later; error while sending other message than notification or keepalive

Filter 1 access-class—This filter is not currently supported

Filter 2 peer—See description of the bgpRoutes peer filter for information about this filter

Filter 3 route-map—This filter is not currently supported

Filter 4 router—See description of the bgpRoutes router filter for information about this filter

Filter 5 in—This filter is not currently supported

Filter 6 out—This filter is not currently supported

bgpDampening

Description BGP dampening

Emergency None

Alert None

Critical None

Error None

Warning Log None

Notice Log Route is suppressedby route-flap dampening; routeis nolonger suppressed by route-flap

dampening

Info None

Debug None

Page 61

bgpEvents

Description BGP finite state machine (FSM) events and transitions

Emergency None

Chapter 4: B Commands

Filter 1 access-class—This filter is not currently supported

Filter 2 peer—See description of the bgpRoutes peer filter for information about this filter

Filter 3 route-map—This filter is not currently supported

Filter 4 router—See description of the bgpRoutes router filter for information about this filter

Filter 5 in—This filter is not currently supported

Filter 6 out—This filter is not currently supported

Alert None

Critical None

Error Event occurred that was not expected for current state

Warning Log None

Notice Log One of the following events occurred: start, stop, inbound-connection-arrived,

outbound-connection-complete,connection-error, connection-closed, start-timer-expired, connect-timer-expired, hold-timer-expired, keep-alive-timer-expired, open-received, update-received, keep-alive-received, notification-received, route-refresh, route-refresh-cisco

Info None

Debug None

Filter 1 access-class—This filter is not currently supported

Filter 2 peer—See description of the bgpRoutes peer filter for information about this filter

Filter 3 route-map—This filter is not currently supported

Filter 4 router—See description of the bgpRoutes router filter for information about this filter

Filter 5 in—This filter is not currently supported

Page 62

JunosE 11.3.x System Event Logging Reference Guide

Filter 6 out—This filter is not currently supported

bgpGeneral

Description BGP general information

Emergency None

Alert None

Critical None

Error None

Warning Log None

Notice Log BGP IPv4 route-target-signaling address family enabled or disabled; making local route

to multihomed site less preferred (local-preference <> ) because down bit is set

Info None

Debug Setting local preference to <> for redistributed route of layer2 site

Filter 1 access-class—This filter is not currently supported

Filter 2 peer—See description of the bgpRoutes peer filter for information about this filter

Filter 3 route-map—This filter is not currently supported

Filter 4 router—See description of the bgpRoutes router filter for information about this filter

Filter 5 in—This filter is not currently supported

Filter 6 out—This filter is not currently supported

bgpGracefulRestart

Description BGP Graceful Restart Feature log

Emergency None

Alert None

Critical None

Page 63

Chapter 4: B Commands

Error None

Warning Log None

Notice Log Log BGP performed or did not perform a graceful restart; router supports or does not

support non-stop forwarding; router is capable of switching gracefully, deferring, or resuming best path selection decision process; BGP routes allowed or prevented from being downloaded to line cards; graceful-restart timer expiration; marking or removing stale routes; waiting to receive end-of-rib marker from peer; received end-of-rib marker from all peers

Info None

Debug Standby SRP will wait for BGP convergence on next restart

Filter 1 access-class—This filter is not currently supported

Filter 2 peer—This filter is not currently supported

Filter 3 route-map—This filter is not currently supported

Filter 4 router—See description of the bgpRoutes router filter for information about this filter

Filter 5 in—This filter is not currently supported

Filter 6 out—This filter is not currently supported

bgpIpv6NextHops

Description BGP indirect next-hops for IPv6 NLRI

Emergency None

Alert None

Critical None

Error Errors in BGP IPv6 next hop events and state transitions

Warning Log None

Notice Log State transitions of BGP IPv6 next hops

Info None

Page 64

JunosE 11.3.x System Event Logging Reference Guide

Debug BGP IPv6 indirect next-hop events

Filter 1 router—See description of the bgpRoutes router filter for information about this filter

Filter 2 remote-ipv6-address—Matches on the IPv6 address of the BGP indirect next-hop

bgpKeepAlives

Description BGP keepalive messages

Emergency None

Alert None

Critical None

Error None

Warning Log Keepalive message received with unexpected additional data after header

Notice Log Keepalive message received; keepalive message sent

Info None

Debug None

Filter 1 access-class—This filter is not currently supported

Filter 2 peer—See description of the bgpRoutes peer filter for information about this filter

Filter 3 route-map—This filter is not currently supported

Filter 4 router—See description of the bgpRoutes router filter for information about this filter

Filter 5 in—Matches on traffic coming into the router

Filter 6 out—Matches on traffic going out of the router

NOTE: Send messages are logged to the bgpKeepAlives log when a message is added to the send queue. A debug message is logged in to the bgpConnections log when the message is actually passed to TCP.

Page 65

bgpMessages

Description BGP protocol messages

Emergency None

Critical None

Warning Log Unknown message type received; invalid field in received message; notification message

Chapter 4: B Commands

Alert None

Error None

received or sent; invalid capability length in received ORF capability; invalid capability value in received ORF capability; invalid ORF in received ORF capability; ORF entries exceeded maximum limit in received prefix list

Notice Log Open message receivedor sent; update message received or sent;route-refresh message

received or sent; route-refresh-cisco message received or sent; received ORF capability; received route refresh message with ORF entries

Info None

Debug Keepalive message received or sent (Full decode of message logged if verbosity is high)

NOTE: Send messages are logged to the bgpMessages log when a message is added to the send queue. A debug message is logged to the bgpConnections log when the message is actually passed to TCP.

Filter 1 access-class—This filter is not currently supported

Filter 2 peer—See description of the bgpRoutes peer filter for information about this filter

Filter 3 route-map—This filter is not currently supported

Filter 4 router—See description of the bgpRoutes router filter for information about this filter

Filter 5 in—Matches on traffic coming into the router

Filter 6 out—Matches on traffic going out of the router

Page 66

JunosE 11.3.x System Event Logging Reference Guide

bgpNeighborChanges

Description BGP neighbor change

Emergency None

Alert None

Critical None

Error None

Warning Log None

Notice Log A peer has entered into or left the established state; reason for a session going idle

Info None

Debug None

Filter 2 peer—See description of the bgpRoutes peer filter for information about this filter

Filter 3 route-map—This filter is not currently supported

Filter 4 router—See description of the bgpRoutes router filter for information about this filter

Filter 5 in—This filter is not currently supported

Filter 6 out—This filter is not currently supported

bgpNextHops

Description VPN and non-VPN BGP indirect next hops

Emergency None

Filter 1 access-class—This filter is not currently supported

Alert None

Critical None

Error Errors in BGP next hop events and state transitions

Warning Log None

Page 67

Chapter 4: B Commands

Notice Log State transitions of BGP next hops

Info None

Debug BGP indirect next-hop events

Filter 1 access-class—This filter is not currently supported

Filter 2 peer—See description of the bgpRoutes peer filter for information about this filter

Filter 3 route-map—This filter is not currently supported

Filter 4 router—See description of the bgpRoutes router filter for information about this filter

Filter 5 in—Matches on traffic coming into the router

Filter 6 out—Matches on traffic going out of the router

bgpRoutes

Description BGP routing table updates

Emergency None

Warning Log Failure to add, remove, or modify BGP route in IP forwarding table

Notice Log BGP route added to, removed from, or modified in the IP forwarding table; aggregate

Alert None

Critical None

Error None

route added to, removed from, or modified in Loc-RIB; network route added to, removed from, or modified in Loc-RIB; best route for internal peers for a given prefix became available; bestroute for internal peersfor a given prefix isno longer available,has changed, or has become available; best route for external peers for a given prefix is no longer available, has changed, or has become available; MPLS base tunnel used to reach an indirect next-hop came upor went down;MPLSstackedtunnel for label came up;indirect next-hop became reachable or unreachable; direct next-hop for an indirect next-hop changed; MPLS tunnel for Inter-AS label came up or went down; route added to L2VPN instance; route deleted from L2VPN instance; route modified for L2VPN instance; -VE device for multihomed local layer 2 site 1 changed from peer to peer2

Info None

Page 68

JunosE 11.3.x System Event Logging Reference Guide

Debug Redistributed route added to, removed from, or modified in Loc-RIB; advertisement for

a given prefix received; withdraw for a given prefix received; local route-target-filtering route added to or removed from prefix in addressFamily

Filter 1 access-class accessClassName [ route-map routeMapName routeMapOptions |

filtering-router filteringRouterName filteringRouterOptions | in | out ]

• access-class—Logs events for traffic that matches a specific access class

• accessClassName —Name of the access class for which you want to log events

• route-map—Logs events for traffic that matches a specific route map

• routeMapName—Name of route map for which you want to log events

• routeMapOptions—In the following format—filtering-router filteringRouterName

filteringRouterOptions | in | out

• filtering-router—Logs events only if the access class or route map are defined on a

specific virtual router

• filteringRouterName—Virtual router where the access class or route map or both are

defined

• filteringRouterOptions—in | out

• in—Matches on traffic coming into the access class, route map, or virtual router

• out—Matches on traffic sent out of the access class, route map, or virtual router

Filter 2 peer peerIpAddress | peerIpv6Address

[ access-class accessClassName accessClassOptions | route-map routeMapName routeMapOptions | filtering-router filteringRouterName filteringRouterOptions | in | out ]

• peer—Logs events for traffic that matches a specific peer

• peerIpAddress—IP address of the peer for which you want to log events

• peerIpv6Address—IPv6 address of the peer for which you want to log events

• access-class—Logs events for traffic that matches a specific access class

• accessClassName—Name of the access class for which you want to log events

• accessClassOptions—In the following format—filtering-router filteringRouterName

filteringRouterOptions | in | out

• route-map—Logs events for traffic that matches a specific route map

• routeMapName—Name of route map for which you want to log events

• routeMapOptions—In the following format—filtering-router filteringRouterName

filteringRouterOptions | in | out

• filtering-router—Logs events only if the peer, access class or route map are defined on

a specific virtual router

Page 69

• filteringRouterName—Virtual router where the peer, access class or route map or both

are defined

• filteringRouterOptions—in | out

• in—Matches on traffic coming into the peer, access class, route map, or virtual router

• out—Matches on traffic sent out of the peer, access class, route map, or virtual router

Filter 3 route-map routeMapName

[ filtering-router filteringRouterName filteringRouterOptions | in | out ]

• route-map—Logs events for traffic that matches a specific route map

• routeMapName—Name of route map for which you want to log events

• filtering-router—Logs events only if the route map is defined on a specific virtual router

• filteringRouterName—Virtual router where the route map is defined

• filteringRouterOptions—in | out

• in—Matches on traffic coming into the route map or virtual router

Chapter 4: B Commands

• out—Matches on traffic sent out of the route map or virtual router

Filter 4 router virtualRouterName [ access-class accessClassName accessClassOptions |

route-map routeMapName routeMapOptions | filtering-router filteringRouterName filteringRouterOptions | peer peerIpAddress peerOptions | in | out ]

• router—Logs events for traffic on a specific virtual router

• virtualRouterName—Name of virtual router

• access-class—Logs events for traffic that matches a specific access class on the

specified router

• accessClassName—Name of the access class for which you want to log events

• accessClassOptions—In the following format—route-map routeMapName

routeMapOptions | virtual-router virtualRouterName virtualRouterOptions | in | out

• route-map—Logs events for traffic that matches a specific route map

• routeMapName—Name of route map for which you want to log events

• routeMapOptions—In the following format—virtual-router virtualRouterName

virtualRouterOptions | in | out

• filtering-router—Logs events only ifthe access classor route map is defined on a specific

virtual router

• filteringRouterName—Virtual router where the access class or route map is defined

• filteringRouterOptions—In the following format—in | out

• peer—Logs events for traffic that matches a specific peer

• peerIpAddress—Address of the peer for which you want to log events

Page 70

JunosE 11.3.x System Event Logging Reference Guide

• peerOptions—In the following format—access-class accessClassName

accessClassOptions | filtering-router filteringRouterName filteringRouterOptions | route-map routeMapName routeMapOptions | in | out

• in—Matches on traffic coming into the virtual router, access class, or route map

• out—Matches on traffic sent out of the virtual router, access class, or route map

Filter 5 in—Matches on traffic coming into the router

Filter 6 out—Matches on traffic going out of the router

bridge

Description Bridge group configuration

Emergency None

Alert None

Warning Log Bridge resources (maximum interfaces, memory exhaustion)

Notice Log Bridge group interface location availability, operation status, and MTU changes

bridgeEngine

Description Bridge engine configuration

Emergency None

Critical None

Error Bridge interface, learning, aging, and static MAC address errors

Info Bridge group state changes (start, shutdown); bridge interface, learning, aging, andstatic

MAC address modifications

Debug Verbosebridge interface, learning, aging, and static MAC address configuration and status

Filter None

Alert None

Critical None

Error Bridge engine, bridge agent, and bridge interface errors

Page 71

Warning Log Bridge engine resources (maximum interfaces, memory exhaustion)

Notice Log Slot status; bridge interface location availability

bridgingMgr

Description Bridging manager configuration

Emergency None

Chapter 4: B Commands

Info Bridge engine and bridge agent state changes (create, start, stop delete); bridge engine,

bridge agent, and bridge interface modifications

Debug Verbose bridge engine, bridge agent, and bridge interface configuration and status

Filter None

Warning Log Bridging manager resources (maximum bridge groups, maximum subscriber policies,

bulkStats

Alert None

Critical None

Error Bridge mode, bridge group, and subscriber policy errors

memory exhaustion)

Notice Log None

Info Bridging manager operation state changes (init, start, shutdown); bridge mode, bridge

group, and subscriber policy modifications

Debug Verbose bridge mode, bridge group, and subscriber policy configuration and status

Filter None

Description Bulk statistics collector

Emergency None

Alert None

Critical None

Page 72

JunosE 11.3.x System Event Logging Reference Guide

Error None

Warning Log Operational failures, such as failed transfer–reverting to secondary receiver, file full, file

creation failure, file deletion failure

Notice Log File full or file nearly full conditions, preparing to send an SNMP trap

Info Status of user configuration commands

Debug Tracks performance progress of bulkstats application

Filter None

Page 73

CHAPTER 5

C Commands

•

cacGeneral on page 49

•

cacIntf on page 50

•

cliCommand on page 50

•

cliGeneral on page 51

•

connectionManager on page 51

•

cops on page 52

•

copsPr on page 52

•

coreDump on page 53

•

ctreeLog on page 53

cacGeneral

Description CAC general purpose

Emergency None

Alert None

Critical None

Error None

Warning Log Unusual conditions in IGP/CAC interaction

Notice Log None

Info None

Debug General debugging info

Filter None

Page 74

JunosE 11.3.x System Event Logging Reference Guide

cacIntf

Description CAC interface events

Emergency None

Alert None

Critical None

Error None

Warning Log Unusual or failure situations in interface processing

Notice Log None

Info None

cliCommand

Description CLI commands

Emergency None

Debug Interface level debugging info

Filter interface interfaceType interfaceSpecifier

• interface—Logs events for a specific interface

• interfaceType—Type of interface on which you want to log events

• interfaceSpecifier—Location of interface in the appropriate format

NOTE: For information about interface types and specifiers, see Interface Types and Specifiers in JunosE Command Reference Guide.

Alert None

Critical None

Error None

Warning Log None

Page 75

cliGeneral

Description CLI general log

Chapter 5: C Commands

Notice Log All successful CLI configuration commands

Info All unsuccessful CLI configuration commands; all nonconfiguration commands

Debug None

Filter None

Emergency None

Alert None

Critical None

Error None

Warning Log CLI command mode from prior release no longer exists; the overridden privilege level

Notice Log None

Info None

Debug None

Filter None

connectionManager

Description Logging various conditions in the component that manages the chassis fabric.

Emergency None

Alert None

Critical 10G and 5G SRP modules only—Detection that the FPGAs have not been loaded (results

command will be discarded

in an SRP [and chassis] reset)

Error 10G and 5G SRP modules only—That there is not enough bandwidth for a particular

board in the system, that connections could not be added in the fabric due to resource limitations (such as memory), that a board was just removed and the resource will not

Page 76

JunosE 11.3.x System Event Logging Reference Guide

be needed when this condition is detected momentarily, or that a connection cannot be closed or a multicast destination cannot be dropped.

Warning Log Cannot connect to a particular source or destination address (board may have just been

removed)

Notice Log A connectionthat previously could not be closedhas now closed; a multicast destination

that previously could not be dropped has now been dropped

Info Various logs to indicate events and transitions for low level diagnosis

Debug Various logs to indicate events and transitions for low level diagnosis

Filter None

cops

Description Common Open Policy Service (COPS) protocol

Emergency None

Alert None

Critical None

Error COPS message with bad header, version, length, or client

Warning Log Unexpected socket event

Notice Log COPS layer enabled or disabled; socket remotely closed

Info None

Debug COPS session instantiation or removal; COPS connection or socket creation or deletion;

keepalive value

Filter None

copsPr

Description COPS-PR general log

Emergency None

Alert None

Page 77

Warning Log Outstanding COPS-PR pool allocations while attempting to shut down SSC client;

coreDump

Chapter 5: C Commands

Critical None

Error Error decoding COPS-PR messages received from the SDX program

temporary resource allocations while sending COPS-PR messages to SDX program

Notice Log None

Info None

Debug None

Filter None

Description Core dump events

Emergency None

Alert None

Critical None

Error Connection errors; file open errors; write failures; core dump failures; transfer errors

Warning Log Core dumpconfigurationchanges due tocoredump monitor;coredump monitor memory

allocation errors

Notice Log Successful line cardcore dump; coredump attempts; core dumpprogression; core dump

monitor checks; core dump monitor transfer completions; core dump monitor dump file deletion

Info None

Debug lcLoader creation; dump request receipt; core dump monitor start; core dump monitor

stop

Filter None

ctreeLog

Description For internal maintenance of IP routes

Emergency None

Page 78

JunosE 11.3.x System Event Logging Reference Guide

Alert None

Critical None

Error Failure in insertion, deletion, and update of IP routes in internal data structure used to

maintain the routes

Warning Log None

Notice Log None

Info None

Debug Creation or deletion of an internal data structure

Filter None

Page 79

CHAPTER 6

D Commands

•

dcm on page 56

•

dcmEngineGeneral on page 56

•

debounceEvents on page 57

•

debounceGeneral on page 57

•

dhcpCapture on page 58

•

dhcpExternal on page 58

•

dhcpExternalEngine on page 59

•

dhcpGeneral on page 59

•

dhcpIssuLog on page 60

•

dhcpLocalClients on page 60

•

dhcpLocalGeneral on page 61

•

dhcpLocalHighAvailability on page 61

•

dhcpLocalPool on page 62

•

dhcpLocalProtocol on page 62

•

dhcpOfferLog on page 63

•

dhcpPbeGeneral on page 64

•

dhcpProxyGeneral on page 64

•

dhcpRelayGeneral on page 65

•

dhcpRelayNvWriterGeneral on page 65

•

dhcpv6Client on page 66

•

dhcpv6DemuxGeneral on page 66

•

dhcpv6LsGeneral on page 67

•

dismanEventMgr on page 67

•

dnsGeneralLog on page 68

•

dosProtection on page 68

•

ds1 on page 69

•

ds3 on page 69

•

dvmrpGeneral on page 70

Page 80

JunosE 11.3.x System Event Logging Reference Guide

•

dvmrpGracefulRestart on page 71

•

dvmrpMcastTable on page 72

•

dvmrpProbeRcv on page 72

•

dvmrpProbeSent on page 73

•

dvmrpRtTable on page 73

dcm

Description Dynamic Configuration Manager

Emergency None

Alert None

Critical None

Error None

Warning Log None

Notice Log None

Info None

Debug Schedule engine event; status of dynamic interface creation; receipt of teardown signal

Filter None

dcmEngineGeneral

Description DCM engine general

Emergency None

Alert None

Critical None

for a dynamic interface; no interface adapterto propagate teardown; creation of dynamic PPP interface failed; creation of dynamic PPPoE interface failed

Error None

Warning Log None

Notice Log None

Page 81

Info None

Debug Giving notify credits to line module; receipt of request buffer from line module; starting

Filter None

debounceEvents

Description Events causing changes to the upper-layer link status based on Ethernet debounce

Emergency None

Alert Debounce preempted; link stabilized to operational up or down status

Critical None

Chapter 6: D Commands

line module communication session; Ack/Nack dynamic interface creation request

configuration

Error None

Warning Log None

Notice Log Events causing finite state machine transitions

Info Events not causing finite state machine transitions

Debug None

Filter None

debounceGeneral

Description Ethernet debounce configuration status log

Emergency None

Alert None

Critical None

Error Error in enabling or disabling the debounce timer on the Ethernet interface

Warning Log None

Notice Log Debounce timer enabled or disabled on the Ethernet interface

Page 82

JunosE 11.3.x System Event Logging Reference Guide

Info None

Debug None

Filter None

dhcpCapture

Description DHCP packet capture

Emergency None

Alert None

Critical None

Error Configuration errors

Warning Log Processing errors (resource exhaustion)

Notice Log None

dhcpExternal

Description DHCP external

Emergency None

Critical None

Info Logged DHCP packets, configured by the ip dhcp-capture command (specify high

verbosity for detail)

Debug Configuration change details; DHCP discover, offer, request, decline, and ACK/NAK

packets on a per-interface basis

Filter None

Alert None

Error Configuration errors; client processing errors (invalid data)

Warning Log Client processing errors (resource exhaustion)

Notice Log Configuration changes

Page 83

Info None

Debug Configuration change details; client events

Filter None

dhcpExternalEngine

Description DHCP external engine

Emergency None

Alert None

Critical None

Error Configuration errors; client processing errors (invalid data)

Chapter 6: D Commands

Warning Log None

Notice Log None

dhcpGeneral

Description DHCP general

Emergency None

Info System events (line cards online/offline)

Debug Configuration change details; client events

Filter None

Alert Rvn8

Critical None

Error None

Warning Log None

Notice Log None

Info None

Page 84

JunosE 11.3.x System Event Logging Reference Guide

Debug DHCP message received

Filter None

dhcpIssuLog

Description DHCP ISSU information

Emergency None

Alert None

Critical None

Error Error recreating DHCP ISSU IC shadow and its data structures, followed by an ISSU halt

Warning Log Buffering capacity exceeded between DHCP engine and the driver/ISSU shadow driver

Notice Log None

Info None

Debug Normal operation: packet processing events, creation and deletion of DHCP common

Filter None

dhcpLocalClients

Description DHCP local server clients

Emergency None

Alert None

Critical None

Error Cannot find the client’s interface; cannot find the client to expire the lease or remove it

objects during ISSU

from the database; trying to expire client’s lease or remove it from database with bad IP address; requested MAC address does not match the available address; cannot allocate SDX subscriber information

Warning Log Cannot find the DHCP instancefor the client with an expired lease; cannot find theDHCP

instance to release the client IP address; secondary DNSwithout primaryDNS configured, using DHCP values; secondary NetBIOS Name Server (NBNS) without primary NBNS configured, using DHCP values

Page 85

Notice Log None

Info None

Debug Removing stale offers to clients and stale clients; adding and removing clients; expiring

Filter None

dhcpLocalGeneral

Description General DHCP local server

Emergency None

Alert None

Chapter 6: D Commands

client’s lease; client’s transactions with DHCP local server

Critical None

Error Memory allocation failure; cannot find interface location for the UID

Warning Log No DHCP instance to process the received packet; hard limits reached; packet discarded

due to no resources

Notice Log DHCP local server not configured; client’s session failed to start

Info Client per-interface limit exceeded; client per-interface exceeded condition abated

Debug Any log message that indicates the status of the general operation of the DHCP local

server; NVS actions; grace period lease state; configuration changes

Filter None

dhcpLocalHighAvailability

NOTE: This category replaces the dhcpLocalServerGeneral category.

Description DHCP local high availability

Emergency None

Alert None

Page 86

JunosE 11.3.x System Event Logging Reference Guide

Critical None

Error Out of resources errors; nonrecoverable software errors during client restoration or

mirroring, pool creation/modification; recoverable software errors during modification of existing client

Warning Log Recoverable software errors during client, server or pool configuration; out of resources

on new client, server, or pool configuration; timer configuration problems

Notice Log Normal recovery following SRP switch

Info None

Debug Normal client, server, pool processing

Filter None

dhcpLocalPool

Description DHCP local address pool, including normal, linked, and shared pools

Emergency None

Alert Local pool IP address is exhausted (address limit violation)

Critical Higher limit of address pool utilization reached

Error None

Warning Log Lower limitof address pool utilization reached; invalid DHCP localaddress pool attributes

Notice Log None

Debug DHCP local address pool resolution; address allocation

Filter None

Info None

dhcpLocalProtocol

Description DHCP local server protocol

Emergency None

Page 87

Chapter 6: D Commands

Alert None

Critical None

Error Cannot find interface; remote client bind add failed; client failed to decline IP address;

client failed to decline a null offered IP address; delete remote client entry failed

Warning Log AAA not responding; SDX program not responding; rediscovering with no IP address

allocated; a renewal is received on the line module for an unknown client; secondary DNS without primary DNS configured, using DHCP values; secondary NetBIOS Name Server (NBNS) without primary NBNS configured, using DHCP values; duplicate MAC address detected

Notice Log None

Info None

Debug Received packet; transmit packet; authentication status; DHCP local server state

dhcpOfferLog

Description DHCP offer selection process log

Emergency None

transitions

Filter interface interfaceType interfaceSpecifier

• interface—Logs events for a specific interface

• interfaceType—Type of interface for which you want to log events

• interfaceSpecifier—Location of interface in the appropriate format

NOTE: For information about interface types and specifiers, see Interface Types and Specifiers in JunosE Command Reference Guide.

Alert None

Critical None

Error None

Warning Log None

Page 88

JunosE 11.3.x System Event Logging Reference Guide

Notice Log None

Info None

Debug Status of the offer selection process

Filter None

dhcpPbeGeneral

Description DHCP Proxy Backend Log

Emergency None

Alert None

Critical None

Error Heap exhaustion

Warning Log Failure to send a DHCP message to a client

Notice Log Failure to restore client after reboot or interface change; failure to allocate memory from

Info None

Debug Status of task and DHCP operations

Filter None

dhcpProxyGeneral

Description DHCP Proxy general

Emergency None

Alert None

Critical None

task-controlled pools

Error None

Warning Log None

Page 89

Notice Log None

Info None

Debug Control flow and key events

Filter None

dhcpRelayGeneral

Description DHCP Relay general

Emergency None

Alert None

Critical None

Chapter 6: D Commands

Error None

Warning Log None

Notice Log Warm start recovery problems (high availability and unified ISSU)

Info None

Debug Control flow andkey events, packets that are transmitted using the layer 2 unicastfeature,

status and changes to DHCP relay agent information option and suboptions

Filter None

dhcpRelayNvWriterGeneral

Description DHCP host route preservation

Emergency None

Alert None

Critical None

Error Out of memory conditions

Warning Log Unexpected unified ISSU signal, removing all NVS and routing table entries at startup,

removing routing table entries at startup due to inconsistencies

Page 90

JunosE 11.3.x System Event Logging Reference Guide

Notice Log Removing or adding entries on start up due to inconsistencies

Info None

Debug Receiving unified ISSU signal, construction of the writer, saving to NVS, removing router,

removing routes, adding routes

Filter None

dhcpv6Client

Description DHCPv6 internal test client events

Emergency None

Alert None

Critical None

Error Problems communicating with IPv6; invalid message types received; out-of-memory

conditions; serious DHCPv6 protocol state errors; internal errors

Warning Log Minor DHCPv6 protocol errors

Notice Log None

Info None

Debug None

Filter None

dhcpv6DemuxGeneral

Description DHCPv6 packet demultiplexer events

Emergency None

Alert None

Critical None

Error UDP transmit errors, out-of-memory conditions, internal errors

Warning Log Invalid DHCPv6 packet type received

Page 91

Notice Log None

Info None

Debug None

Filter None

dhcpv6LsGeneral

Description DHCPv6 local server events

Emergency None

Alert None

Critical None

Chapter 6: D Commands

Error Failure to create server (bad router or out of memory)

Warning Log Attempt to remove a nonexistent server

Notice Log Failure to create server (IPv6 not licensed); cold/warm restart of DHCPv6 local server;

Info None

Debug Server bind, creation, deletion, unbind, and restoration of bindings post warm SRP

Filter None

dismanEventMgr

Description Distributed management event manager

Emergency None

Alert None

before/after restoring client bindings;

switchover; Prefix Allocation Notification: designated prefix is already in use by another client

Critical None

Error Configuration errors; Sampling, testing and setting errors

Page 92

JunosE 11.3.x System Event Logging Reference Guide

Warning Log Limit maximums reached

Notice Log Trigger values reached

Info Application started; traps activated; sampling information provided

Debug None

Filter None

dnsGeneralLog

Description DNS general

Emergency None

Alert None

Critical None

Warning Log Failure to post a message to DNS about the query response from DNS server

Notice Log None

Debug Dump DNS response packet; trace DNS query submission; trace DNS response parsing

dosProtection

Description DoS general

Emergency None

Error None

Info None

and processing; trace dropped queriesif router isshutting down or DNS disabled invirtual router; trace DNS cache cleanup

Filter None

Alert None

Critical Suspicious control flows exceed threshold for specific line module; possible distributed

DoS attack

Page 93

ds1

Chapter 6: D Commands

Error Control flow changed to suspicious.

Warning Log Flow table overflow, protocol (or priority) has transitioned to suspicious

Notice Log Suspicious control flow returned to nonsuspicious protocol (or priority) has transitioned

from suspicious

Info Suspicious control flow deleted

Debug None

Filter None

Description DS1 layer

ds3

Emergency None

Alert None

Critical None

Error None

Warning Log Interface creation or binding failure

Notice Log Failureto bringline module application online; dropped interfacestatechange notification

due to lack of resources; discarded stale line module notification

Info Dropped interface state change notification for unknown or removed interface

Debug None

Filter None

Description DS3 layer

Emergency None

Alert None

Critical None

Page 94

JunosE 11.3.x System Event Logging Reference Guide

Error None

Warning Log Failure to create or bind interface

Notice Log Failureto bringline module application online; dropped interfacestatechange notification

due to lack of resources; discarded stale line module notification

Info Dropped interface state change notification for unknown or removed interface

Debug None

Filter None

dvmrpGeneral

Description DVMRP general

Emergency None

Alert None

Critical None

Error Memory allocation errors; bad parameters (internal errors); designated forwarder errors

(two for same interface, DoNotForward by no designated forwarder); processing prune errors; graft errors; internal errors; catastrophic RT table errors; management interaction errors; NVS errors

Warning Log Unable to add local route; routeHogCheck; routeLimit

Notice Log Route expiration; pruneProcessing (send or receive); graftAck processing; source group

(SG) state information; deletion of an output interface; nbrQuickDelete; nbrReset; nbrTimeOut; error adding neighbor on Route Report Reception

Info Designatedforwarderelection information; sending graft;timer expired for MulticastEntry;

attempting to log duplicate accept filter; external route deleted or added

Debug Local address creation or deletion; information about accept filters; dvmrpInterface

creation or deletion; sgTimeout information; noMoreOifs info; sg creation information; multicastForwarding enabled or disabled; DvmrpInit; dvmrpEnable/Disable;rpfCallback

Filter 1 interface interfaceType interfaceSpecifier

• interface—Logs events for a specific interface

• interfaceType—Type of interface for which you want to log events

Page 95

Chapter 6: D Commands

• interfaceSpecifier—Location of interface in the appropriate format

NOTE: For information about interface types and specifiers, see Interface

Types and Specifiers in JunosE Command Reference Guide.

Filter 2 router virtualRouterName [ interface interfaceType interfaceSpecifier ]

• router—Logs events for a specific virtual router

• virtualRouterName—Name of virtual router for which you want to log events

• interface—Logs events on a specific interface on the virtual router

• interfaceType—Type of interface for which you want to log events

• interfaceSpecifier—Location of interface in the appropriate format

dvmrpGracefulRestart

Description DVMRP graceful restart

Emergency None

Alert None

Critical None

Error None

Warning Log None

Notice Log DVMRP graceful restart complete

Info None

NOTE: For information about interface types and specifiers, see Interface Types and Specifiers in JunosE Command Reference Guide.

Debug None

Filter None

Page 96

JunosE 11.3.x System Event Logging Reference Guide

dvmrpMcastTable

Description DVMRP multicast table messages

Emergency None

Alert None

Critical None

Error Error removing MulticastEntry; adding duplicate MulticastEntry; adding nonexistent

MulticastEntry; attempting to send prune to nonexistent neighbor; error deleting MulticastEntry; error adding outgoing interfaces

Warning Log Deleting MulticastEntry with no SG state found; attempting to create MulticastEntry, but

unable to do so

Notice Log Creating MulticastEntry

Info rePruning; delOif; add outgoing interface; not adding outgoing interface for some reason;

Debug None

Filter 1 interface—See description of the dvmrpGeneral interface filterfor information aboutthis

Filter 2 router—See description of the dvmrpGeneral router filter for information about this filter

dvmrpProbeRcv

Description DVMRP probe received

Emergency None

Alert None

Critical None

creating sgoiflist; pruneDelayCallback; prune; deleting MulticastEntry

filter

Error None

Warning Log None

Notice Log procProbe new neighbor

Page 97

Info None

Debug Processing probe (verified has our address in packet); display probe

Filter 1 interface—See description of the dvmrpGeneral interface filterfor information aboutthis

Filter 2 router—See description of the dvmrpGeneral router filter for information about this filter

dvmrpProbeSent

Description DVMRP probe sent

Emergency None

Alert None

Chapter 6: D Commands

filter

Critical None

Warning Log None

Notice Log None

Debug Send probe

Filter 1 interface—See description of the dvmrpGeneral interface filterfor information aboutthis

Filter 2 router—See description of the dvmrpGeneral router filter for information about this filter

dvmrpRtTable

Description DVMRP Routing Table

Emergency None

Error None

Info None

filter

Alert None

Critical None

Page 98

JunosE 11.3.x System Event Logging Reference Guide

Error Route error; router report error; error replacing route after applying accept filter; internal

errors

Warning Log Unable to create new route; deleting routing table

Notice Log Error in report packet; adding or replacing local route; ignoring poison on upstream user

interface (USIF); deleting all dependent neighbors

Info Processing report; added route from report;declaring ourselves as designated forwarder;

route update

Debug Delete route; insert route

Filter 1 interface—See description of the dvmrpGeneral interface filterfor information aboutthis

filter

Filter 2 router—See description of the dvmrpGeneral router filter for information about this filter

Page 99

CHAPTER 7

E Commands

•

ethernet on page 75

•

ethernetStateSession on page 75

ethernet

Description Ethernet layer

Emergency None

Alert None

Critical None

Error None

Warning Log Cannot configure Ethernet interface successfully; memory pool depleted

Notice Log No pool space; can bring interface up

Info Hardware present or not present notification

Debug Interface created or deleted

Filter None

ethernetStateSession

Description Configuration of the Fast Ethernet management port on the SRP IOA on the E320 router

or the E120 router

Emergency None

Alert None

Critical None

Page 100

JunosE 11.3.x System Event Logging Reference Guide

Error Configuration errors for duplex mode and speed settings on the Fast Ethernet

management port

Warning Log Configuration did not occur for duplex mode andspeed on the Fast Ethernet management

port

Notice Log None

Info None

Debug None

Filter None

Juniper JUNOSE SOFTWARE FOR E SERIES 11.3.X - SYSTEM EVENT LOGGING REFERENCE GUIDE 2010-10-04, JUNOSE 11.3 Reference Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
