Juniper JUNOSE 11.1.0 - REV 4-29-2010, JUNOSe 11.1.0 User Manual

JUNOSe™ Software for E Series
Broadband Services Routers
Release Notes
Release 11.1.0
Juniper Networks, Inc.
1194 North Mathilda Avenue
Sunnyvale, CA 94089
USA
408-745-2000
www.juniper.net
Published: 2010-04-29
Juniper Networks, the Juniper Networks logo, JUNOS, NetScreen, ScreenOS, and Steel-Belted Radius are registered trademarks of Juniper Networks, Inc. in the United States and other countries. JUNOSe is a trademark of Juniper Networks, Inc. All other trademarks, service marks, registered trademarks, or registered service marks are the property of their respective owners.
Juniper Networks assumes no responsibility for any inaccuracies in this document. Juniper Networks reserves the right to change, modify, transfer, or otherwise revise this publication without notice.
Products made or sold by Juniper Networks (including the ERX310, ERX705, ERX710, ERX1410, ERX1440, M5, M7i, M10, M10i, M20, M40, M40e, M160, M320, and T320 routers, T640 routing node, and the JUNOS, JUNOSe, and SDX-300 software) or components thereof might be covered by one or more of the following patents that are owned by or licensed to Juniper Networks: U.S. Patent Nos. 5,473,599, 5,905,725, 5,909,440, 6,192,051, 6,333,650, 6,359,479, 6,406,312, 6,429,706, 6,459,579, 6,493,347, 6,538,518, 6,538,899, 6,552,918, 6,567,902, 6,578,186, and 6,590,785.
Copyright © 2010, Juniper Networks, Inc. All rights reserved. Printed in USA.
JUNOSe™ Software for E Series™ Broadband Services Routers Release Notes, Release 11.1.0 Writing: Subash Babu Asokan, Krupa Chandrashekar, Megha Shaseendran, Pallavi Madhusudhan, Namrata Mehta, Diane Florio, Brian Wesley Simmons, Fran Singer, Sairam V Editing: Ben Mann, Krishnaveni Venkatesan Cover Design: Edmonds Design
Revision History April 2010—FRS JUNOSe 11.1.0
The information in this document is current as of the date listed in the revision history.
Software License
The terms and conditions for using this software are described in the software license contained in the acknowledgment to your purchase order or, to the extent applicable, to any reseller agreement or end-user purchase agreement executed between you and Juniper Networks. By using this software, you indicate that you understand and agree to be bound by those terms and conditions.
Generally speaking, the software license restricts the manner in which you are permitted to use the software and may contain prohibitions against certain uses. The software license may state conditions under which the license is automatically terminated. You should consult the license for further details.
For complete product documentation, please see the Juniper Networks Web site at www.juniper.net/techpubs.
END USER LICENSE AGREEMENT
READ THIS END USER LICENSE AGREEMENT (“AGREEMENT”) BEFORE DOWNLOADING, INSTALLING, OR USING THE SOFTWARE. BY DOWNLOADING, INSTALLING, OR USING THE SOFTWARE OR OTHERWISE EXPRESSING YOUR AGREEMENT TO THE TERMS CONTAINED HEREIN, YOU (AS CUSTOMER OR IF YOU ARE NOT THE CUSTOMER, AS A REPRESENTATIVE/AGENT AUTHORIZED TO BIND THE CUSTOMER) CONSENT TO BE BOUND BY THIS AGREEMENT. IF YOU DO NOT OR CANNOT AGREE TO THE TERMS CONTAINED HEREIN, THEN (A) DO NOT DOWNLOAD, INSTALL, OR USE THE SOFTWARE, AND (B) YOU MAY CONTACT JUNIPER NETWORKS REGARDING LICENSE TERMS.
1. The Parties. The parties to this Agreement are (i) Juniper Networks, Inc. (if the Customer’s principal office is located in the Americas) or Juniper Networks (Cayman) Limited (if the Customer’s principal office is located outside the Americas) (such applicable entity being referred to herein as “Juniper”), and (ii) the person or organization that originally purchased from Juniper or an authorized Juniper reseller the applicable license(s) for use of the Software (“Customer”) (collectively, the “Parties”).
2. The Software. In this Agreement, “Software” means the program modules and features of the Juniper or Juniper-supplied software, for which Customer has paid the applicable license or support fees to Juniper or an authorized Juniper reseller, or which was embedded by Juniper in equipment which Customer purchased from Juniper or an authorized Juniper reseller. “Software” also includes updates, upgrades and new releases of such software. “Embedded Software” means Software which Juniper has embedded in or loaded onto the Juniper equipment and any updates, upgrades, additions or replacements which are subsequently embedded in or loaded onto the equipment.
3. License Grant. Subject to payment of the applicable fees and the limitations and restrictions set forth herein, Juniper grants to Customer a non-exclusive and non-transferable license, without right to sublicense, to use the Software, in executable form only, subject to the following use restrictions:
a. Customer shall use Embedded Software solely as embedded in, and for execution on, Juniper equipment originally purchased by Customer
from Juniper or an authorized Juniper reseller.
b. Customer shall use the Software on a single hardware chassis having a single processing unit, or as many chassis or processing units for which
Customer has paid the applicable license fees; provided, however, with respect to the Steel-Belted Radius or Odyssey Access Client software only, Customer shall use such Software on a single computer containing a single physical random access memory space and containing any number of processors. Use of the Steel-Belted Radius or IMS AAA software on multiple computers or virtual machines (e.g., Solaris zones) requires multiple licenses, regardless of whether such computers or virtualizations are physically contained on a single chassis.
c. Product purchase documents, paper or electronic user documentation, and/or the particular licenses purchased by Customer may specify limits
to Customer’s use of the Software. Such limits may restrict use to a maximum number of seats, registered endpoints, concurrent users, sessions, calls, connections, subscribers, clusters, nodes, realms, devices, links, ports or transactions, or require the purchase of separate licenses to use particular features, functionalities, services, applications, operations, or capabilities, or provide throughput, performance, configuration, bandwidth, interface, processing, temporal, or geographical limits. In addition, such limits may restrict the use of the Software to managing certain kinds of networks or require the Software to be used only in conjunction with other specific Software. Customer’s use of the Software shall be subject to all such limitations and purchase of all applicable licenses.
d. For any trial copy of the Software, Customer’s right to use the Software expires 30 days after download, installation or use of the Software.
Customer may operate the Software after the 30-day trial period only if Customer pays for a license to do so. Customer may not extend or create an additional trial period by re-installing the Software after the 30-day trial period.
e. The Global Enterprise Edition of the Steel-Belted Radius software may be used by Customer only to manage access to Customer’s enterprise
network. Specifically, service provider customers are expressly prohibited from using the Global Enterprise Edition of the Steel-Belted Radius software to support any commercial network access services.
The foregoing license is not transferable or assignable by Customer. No license is granted herein to any user who did not originally purchase the applicable license(s) for the Software from Juniper or an authorized Juniper reseller.
4. Use Prohibitions. Notwithstanding the foregoing, the license provided herein does not permit the Customer to, and Customer agrees not to and shall not: (a) modify, unbundle, reverse engineer, or create derivative works based on the Software; (b) make unauthorized copies of the Software (except as necessary for backup purposes); (c) rent, sell, transfer, or grant any rights in and to any copy of the Software, in any form, to any third party; (d) remove any proprietary notices, labels, or marks on or in any copy of the Software or any product in which the Software is embedded; (e) distribute any copy of the Software to any third party, including as may be embedded in Juniper equipment sold in the secondhand market; (f) use any ‘locked’ or key-restricted feature, function, service, application, operation, or capability without first purchasing the applicable license(s) and obtaining a valid key from Juniper, even if such feature, function, service, application, operation, or capability is enabled without a key; (g) distribute any key for the Software provided by Juniper to any third party; (h) use the Software in any manner that extends or is broader than the uses purchased by Customer from Juniper or an authorized Juniper reseller; (i) use Embedded Software on non-Juniper equipment; (j) use Embedded Software (or make it available for use) on Juniper equipment that the Customer did not originally purchase from Juniper or an authorized Juniper reseller; (k) disclose the results of testing or benchmarking of the Software to any third party without the prior written consent of Juniper; or (l) use the Software in any manner other than as expressly provided herein.
5. Audit. Customer shall maintain accurate records as necessary to verify compliance with this Agreement. Upon request by Juniper, Customer shall furnish such records to Juniper and certify its compliance with this Agreement.
6. Confidentiality. The Parties agree that aspects of the Software and associated documentation are the confidential property of Juniper. As such, Customer shall exercise all reasonable commercial efforts to maintain the Software and associated documentation in confidence, which at a minimum includes restricting access to the Software to Customer employees and contractors having a need to use the Software for Customer’s internal business purposes.
7. Ownership. Juniper and Juniper’s licensors, respectively, retain ownership of all right, title, and interest (including copyright) in and to the Software, associated documentation, and all copies of the Software. Nothing in this Agreement constitutes a transfer or conveyance of any right, title, or interest in the Software or associated documentation, or a sale of the Software, associated documentation, or copies of the Software.
8. Warranty, Limitation of Liability, Disclaimer of Warranty. The warranty applicable to the Software shall be as set forth in the warranty statement that accompanies the Software (the “Warranty Statement”). Nothing in this Agreement shall give rise to any obligation to support the Software. Support services may be purchased separately. Any such support shall be governed by a separate, written support services agree MAXIMUM EXTENT PERMITTED BY LAW, JUNIPER SHALL NOT BE LIABLE FOR ANY LOST PROFITS, LOSS OF DATA, OR COSTS OR PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES, OR FOR ANY SPECIAL, INDIRECT, OR CONSEQUENTIAL DAMAGES ARISING OUT OF THIS AGREEMENT, THE SOFTWARE, OR ANY JUNIPER OR JUNIPER-SUPPLIED SOFTWARE. IN NO EVENT SHALL JUNIPER BE LIABLE FOR DAMAGES ARISING FROM UNAUTHORIZED OR IMPROPER USE OF ANY JUNIPER OR JUNIPER-SUPPLIED SOFTWARE. EXCEPT AS EXPRESSLY PROVIDED IN THE WARRANTY STATEMENT TO THE EXTENT PERMITTED BY LAW, JUNIPER DISCLAIMS ANY AND ALL WARRANTIES IN AND TO THE SOFTWARE (WHETHER EXPRESS, IMPLIED, STATUTORY, OR OTHERWISE), INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, OR NONINFRINGEMENT. IN NO EVENT DOES JUNIPER WARRANT THAT THE SOFTWARE, OR ANY EQUIPMENT OR NETWORK RUNNING THE SOFTWARE, WILL OPERATE WITHOUT ERROR OR INTERRUPTION, OR WILL BE FREE OF VULNERABILITY TO INTRUSION OR ATTACK. In no event shall Juniper’s or its suppliers’ or licensors’ liability to Customer, whether in contract, tort (including negligence), breach of warranty, or otherwise, exceed the price paid by Customer for the Software that gave rise to the claim, or if the Software is embedded in another Juniper product, the price paid by Customer for such other product. Customer acknowledges and agrees that Juniper has set its prices and entered into this Agreement in reliance upon the disclaimers of warranty and the limitations of liability set forth herein, that the same reflect an allocation of risk between the Parties (including the risk that a contract remedy may fail of its essential purpose and cause consequential loss), and that the same form an essential basis of the bargain between the Parties.
9. Termi natio n. Any breach of this Agreement or failure by Customer to pay any applicable fees due shall result in automatic termination of the license granted herein. Upon such termination, Customer shall destroy or return to Juniper all copies of the Software and related documentation in Customer’s possession or control.
10. Taxes. All license fees payable under this agreement are exclusive of tax. Customer shall be responsible for paying Taxes arising from the purchase of the license, or importation or use of the Software. If applicable, valid exemption documentation for each taxing jurisdiction shall be provided to Juniper prior to invoicing, and Customer shall promptly notify Juniper if their exemption is revoked or modified. All payments made by Customer shall be net of any applicable withholding tax. Customer will provide reasonable assistance to Juniper in connection with such withholding taxes by promptly: providing Juniper with valid tax receipts and other required documentation showing Customer’s payment of any withholding taxes; completing appropriate applications that would reduce the amount of withholding tax to be paid; and notifying and assisting Juniper in any audit or tax proceeding related to transactions hereunder. Customer shall comply with all applicable tax laws and regulations, and Customer will promptly pay or reimburse Juniper for all costs and damages related to any liability incurred by Juniper as a result of Customer’s non-compliance or delay with its responsibilities herein. Customer’s obligations under this Section shall survive termination or expiration of this Agreement.
11 . Export. Customer agrees to comply with all applicable export laws and restrictions and regulations of any United States and any applicable foreign
agency or authority, and not to export or re-export the Software or any direct product thereof in violation of any such restrictions, laws or regulations, or without all necessary approvals. Customer shall be liable for any such violations. The version of the Software supplied to Customer may contain encryption or other capabilities restricting Customer’s ability to export the Software without an export license.
12. Commercial Computer Software. The Software is “commercial computer software” and is provided with restricted rights. Use, duplication, or disclosure by the United States government is subject to restrictions set forth in this Agreement and as provided in DFARS 227.7201 through
227.7202-4, FAR 12.212, FAR 27.405(b)(2), FAR 52.227-19, or FAR 52.227-14(ALT III) as applicable.
13. Interface Information. To the extent required by applicable law, and at Customer's written request, Juniper shall provide Customer with the interface information needed to achieve interoperability between the Software and another independently created program, on payment of applicable fee, if any. Customer shall observe strict obligations of confidentiality with respect to such information and shall use such information in compliance with any applicable terms and conditions upon which Juniper makes such information available.
14. Third Party Software. Any licensor of Juniper whose software is embedded in the Software and any supplier of Juniper whose products or technology are embedded in (or services are accessed by) the Software shall be a third party beneficiary with respect to this Agreement, and such licensor or vendor shall have the right to enforce this Agreement in its own name as if it were Juniper. In addition, certain third party software may be provided
with the Software and is subject to the accompanying license(s), if any, of its respective owner(s). To the extent portions of the Software are distributed under and subject to open source licenses obligating Juniper to make the source code for such portions publicly available (such as the GNU General Public License (“GPL”) or the GNU Library General Public License (“LGPL”)), Juniper will make such source code portions (including Juniper
ment. TO THE
modifications, as appropriate) available upon request for a period of up to three years from the date of distribution. Such request can be made in writing to Juniper Networks, Inc., 1194 N. Mathilda Ave., Sunnyvale, CA 94089, ATTN: General Counsel. You may obtain a copy of the GPL at
http://www.gnu.org/licenses/gpl.html, and a copy of the LGPL at http://www.gnu.org/licenses/lgpl.html.
15. Miscellaneous. This Agreement shall be governed by the laws of the State of California without reference to its conflicts of laws principles. The provisions of the U.N. Convention for the International Sale of Goods shall not apply to this Agreement. For any disputes arising under this Agreement, the Parties hereby consent to the personal and exclusive jurisdiction of, and venue in, the state and federal courts within Santa Clara County, California. This Agreement constitutes the entire and sole agreement between Juniper and the Customer with respect to the Software, and supersedes all prior and contemporaneous agreements relating to the Software, whether oral or written (including any inconsistent terms contained in a purchase order), except that the terms of a separate written agreement executed by an authorized Juniper representative and Customer shall govern to the extent such terms are inconsistent or conflict with terms contained herein. No modification to this Agreement nor any waiver of any rights hereunder shall be effective unless expressly assented to in writing by the party to be charged. If any portion of this Agreement is held invalid, the Parties agree that such invalidity shall not affect the validity of the remainder of this Agreement. This Agreement and associated documentation has been written in the English language, and the Parties agree that the English version will govern. (For Canada: Les parties aux présentés confirment leur volonté que cette convention de même que tous les documents y compris tout avis qui s'y rattaché, soient redigés en langue anglaise. (Translation: The parties confirm that this Agreement and all related documentation is and will be in the English language)).
Table of Contents
Release 11.1.0 1
Release Installation ..........................................................................................1
Upgrading to Release 5.3.0 or a Higher-Numbered Release.......................1
Upgrading from Release 5.1.1 or Lower-Numbered Releases to
Release 6.x.x or Higher-Numbered Releases ...................................... 2
Moving Line Modules Between Releases ....................................................2
SRP Module Memory Requirements ..........................................................3
Hardware and Software Compatibility.......................................................3
Requesting Technical Support .........................................................................3
Self-Help Online Tools and Resources........................................................3
Opening a Case with JTAC ......................................................................... 4
Release Overview............................................................................................. 4
Before You Start ........................................................................................ 5
Release Highlights............................................................................................7
Ethernet .................................................................................................... 8
ICR ............................................................................................................9
IP.............................................................................................................10
L2TP over MPLS ......................................................................................10
MLPPP.....................................................................................................10
MPLS ....................................................................................................... 10
Multiclass MLPPP.....................................................................................12
Packet Mirroring...................................................................................... 12
Policy Management .................................................................................13
SDX Software and SRC Software .............................................................13
SNMP ...................................................................................................... 14
System ....................................................................................................15
System Maximums .................................................................................. 15
Early Field Trial Features................................................................................ 16
DHCP ......................................................................................................16
Policy Management .................................................................................17
Unsupported Features .................................................................................... 17
E120 Router and E320 Router ................................................................. 17
Multicast..................................................................................................18
Policy Management .................................................................................18
Stateful SRP Switchover (High Availability) .............................................. 18
Release Software Protocols ............................................................................ 19
Core Routing Stack ..................................................................................19
Network Management Protocols..............................................................19
Routing Protocols .................................................................................... 19
Multiprotocol Label Switching (MPLS) ......................................................19
Layer 2 Protocols..................................................................................... 19
Security Protocols....................................................................................20
SRC Software and SDX Software Compatibility Matrix................................... 20
Known Behavior ............................................................................................21
Table of Contents v
JUNOSe 11.1.0 Release Notes
AAA......................................................................................................... 21
ATM.........................................................................................................21
BGP ......................................................................................................... 21
BGP/MPLS VPNs ......................................................................................22
B-RAS ......................................................................................................22
CLI........................................................................................................... 22
DHCP ......................................................................................................26
DHCP External Server.............................................................................. 26
Dynamic Interfaces .................................................................................27
Ethernet .................................................................................................. 28
Flash........................................................................................................29
GRE ......................................................................................................... 29
Hardware ................................................................................................29
HDLC....................................................................................................... 30
IP.............................................................................................................30
IPSec .......................................................................................................32
IS-IS.........................................................................................................32
L2TP........................................................................................................33
Line Module Redundancy ........................................................................33
MLPPP.....................................................................................................34
MPLS ....................................................................................................... 34
Multicast..................................................................................................34
Packet Mirroring...................................................................................... 35
Policy Management .................................................................................35
PPP..........................................................................................................37
PPPoE......................................................................................................37
QoS .........................................................................................................38
RADIUS ...................................................................................................38
SNMP ...................................................................................................... 39
SSH ......................................................................................................... 40
Stateful SRP Switchover (High Availability) .............................................. 40
Subscriber Interfaces ...............................................................................41
System ....................................................................................................41
System Logging ....................................................................................... 42
Tunneling ................................................................................................ 42
Known Problems and Limitations ..................................................................43
ANCP....................................................................................................... 43
ATM.........................................................................................................43
BFD ......................................................................................................... 45
Bridged Ethernet .....................................................................................45
CLI........................................................................................................... 45
DHCP ......................................................................................................45
DHCP External Server.............................................................................. 46
DoS Protection ........................................................................................ 46
Ethernet .................................................................................................. 47
File System..............................................................................................47
Forwarding ..............................................................................................47
ICR ..........................................................................................................48
IGMP ....................................................................................................... 49
IP.............................................................................................................50
IPSec .......................................................................................................51
IS-IS.........................................................................................................51
L2TP........................................................................................................51
MLD ........................................................................................................ 51
vi Table of Contents
Table of Contents
MLPPP.....................................................................................................52
Mobile IP ................................................................................................. 52
MPLS ....................................................................................................... 52
Multicast..................................................................................................53
Netflow.................................................................................................... 53
Policy Management .................................................................................54
PPPoE......................................................................................................55
QoS .........................................................................................................55
RSVP-TE .................................................................................................. 57
Service Manager ......................................................................................58
SNMP ...................................................................................................... 58
SONET..................................................................................................... 58
SRC Software and SDX Software ............................................................. 58
Stateful SRP Switchover (High Availability) and IP Tunnels......................59
Subscriber Management .......................................................................... 59
System ....................................................................................................60
System Logging ....................................................................................... 61
TCP ......................................................................................................... 61
Unified ISSU ............................................................................................ 61
Resolved Known Problems ............................................................................ 63
IP.............................................................................................................63
Errata.............................................................................................................64
Appendix A
System Maximums 65
ERX310, ERX7xx, and ERX14xx System Maximums.....................................66
General System Maximums ..................................................................... 66
Physical and Logical Density Maximums ................................................. 67
Link Layer Maximums ............................................................................. 70
Routing Protocol Maximums ................................................................... 75
Policy and QoS Maximums......................................................................79
Tunneling Maximums.............................................................................. 82
Subscriber Management Maximums........................................................84
E120 and E320 System Maximums ............................................................... 87
General System Maximums ..................................................................... 87
Physical and Logical Density Maximums ................................................. 88
Link Layer Maximums ............................................................................. 90
Routing Protocol Maximums ................................................................... 96
Policy and QoS Maximums......................................................................99
Tunneling Maximums............................................................................ 103
Subscriber Management Maximums......................................................105
Table of Contents
vii
JUNOSe 11.1.0 Release Notes
viii Table of Contents
Release 11.1.0
Release Installation
Complete procedures for installing the system software are available in JUNOSe System Basics Configuration Guide, Chapter 3, Installing JUNOSe Software.
New software releases are available for download from the Juniper Networks website at http://www.juniper.net/customers/support. You can use the downloaded image bundle to create your own software CDs.
Before upgrading to a new version of software, save your router’s running configuration to a .cnf file or .scr file. If you subsequently need to downgrade for any reason, you can restore the earlier software version.
NOTE: When you upgrade the software on a router that has a large number of
interfaces configured, the router might appear to be unresponsive for several minutes. This condition is normal; allow the process to continue uninterrupted.
Upgrading to Release 5.3.0 or a Higher-Numbered Release
When you upgrade from a lower-numbered release to Release 5.3.0 or a higher-numbered release, the higher release might not load if you issue the boot system command from Boot mode while the lower-numbered software is running on the router or if you insert a flash card running a higher-numbered release into a system running a lower numbered release. However, if you issue the boot system command from Global Configuration mode, the new software loads properly.
Release Installation 1
JUNOSe 11.1.0 Release Notes
Upgrading from Release 5.1.1 or Lower-Numbered Releases to Release 6.x.x or Higher-Numbered Releases
Release 5.1.1 or lower-numbered releases support application images only up to 172 MB. To install larger application images for Release 6.0.0 and higher-numbered releases, you must first install Release 5.1.2 (or a higher-numbered 5.x.x release). This enables the system to support application images greater than 172 MB. For example, you cannot go from Release 5.1.1 to Release 7.2.0 without first upgrading to Release 5.1.2. See the following table for compatibility of releases.
JUNOSe Release
5.1.1 or lower-numbered release
5.1.2 or higher-numbered release
7.2.0 or higher-numbered release
Highest Release Able to Load Cannot Load
5.3.5p0-2 or the highest-numbered 5.x.x release
No limitation Not applicable ~234 MB
No limitation Not applicable ~256 MB
6.x.x or higher-numbered release
Maximum Application Image
~172 MB
Your software upgrades may be available remotely through Telnet or FTP, or may be delivered on a new NVS card. Depending on how you access the software updates, there are two different procedures to follow. For more detailed information on installing software, and about NVS cards and SRP modules, see the following documents:
JUNOSe System Basics Configuration Guide, Chapter 6, Managing Modules
Upgrading NVS Cards on SRP Modules in ERX Hardware Guide, Chapter 8,
Maintaining ERX Routers
Upgrading NVS Cards on SRP Modules in E120 and E320 Hardware Guide, Chapter
8, Maintaining the Router
Moving Line Modules Between Releases
The Juniper Networks ERX1440 Broadband Services Router employs a 40-Gbps SRP module and a new midplane. Release 3.3.2 was the first software release to support the 40-Gbps SRP module and midplane. Before you can transfer a compatible line module from a Juniper Networks ERX705, ERX710, or ERX1410 Broadband Services Router to an ERX1440 router, you must first load Release 3.3.2 or a higher release onto the current router, and then reboot the router to load the release onto the line modules. If you then move any of those line modules to an ERX1440 router, that router is able to recognize the line module.
If you move a compatible line module from an ERX1440 router to an ERX705, ERX710, or ERX1410 router, the module loads properly in the new router regardless of the release.
2 Release Installation
SRP Module Memory Requirements
For Release 5.3.0 and higher-numbered software releases on ERX14xx models, ERX7xx models, and the Juniper Networks ERX310 Broadband Services Router, see ERX Module Guide, Table 1, ERX Module Combinations, for detailed information about memory requirements.
For Release 8.2.0 and higher-numbered software releases on Juniper Networks E120 and E320 Broadband Services Routers, see E120 and E320 Module Guide, Table 1, Modules and IOAs, for detailed information about memory requirements.
Hardware and Software Compatibility
For important information about hardware and software, see the document set as follows:
Combinations of line modules to achieve line rate performance are in JUNOSe
System Basics Configuration Guide, Chapter 6, Managing Modules.
Release 11.1.0
Compatibility of ERX router modules with software releases is in ERX Module
Guide, Table 1, ERX Module Combinations.
Layer 2 and layer 3 protocols and applications supported by ERX router
modules are in ERX Module Guide, Appendix A, Module Protocol Support.
Compatibility of E120 router and E320 router modules with software releases
is in E120 and E320 Module Guide, Table 1, Modules and IOAs.
Layer 2 and layer 3 protocols and applications supported by IOAs on the E120
router and the E320 router are in E120 and E320 Module Guide, Appendix A, IOA Protocol Support.
Requesting Technical Support
Technical product support is available through the Juniper Networks Technical Assistance Center (JTAC). If you are a customer with an active J-Care or JNASC support contract, or are covered under warranty, and need post-sales technical support, you can access our tools and resources online or open a case with JTAC.
JTAC Policies—For a complete understanding of our JTAC procedures and
policies, review the JTAC User Guide located at http://www.juniper.net/customers/support/downloads/710059.pdf
Product Warranties—For product warranty information, visit
http://www.juniper.net/support/warranty/
JTAC Hours of Operation—The JTAC centers have resources available 24 hours
a day, 7 days a week, 365 days a year.
Self-Help Online Tools and Resources
For quick and easy problem resolution, Juniper Networks has designed an online self-service portal called the Customer Support Center (CSC) that provides you with the following features:
Requesting Technical Support 3
JUNOSe 11.1.0 Release Notes
Find CSC offerings:
http://www.juniper.net/customers/support/
Search for known bugs:
http://www2.juniper.net/kb/
Find product documentation:
http://www.juniper.net/techpubs/
Find solutions and answer questions using our Knowledge Base:
http://kb.juniper.net/
Download the latest versions of software and review release notes:
http://www.juniper.net/customers/csc/software/
Search technical bulletins for relevant hardware and software notifications:
https://www.juniper.net/alerts/
Join and participate in the Juniper Networks Community Forum:
http://www.juniper.net/company/communities/
Open a case online in the CSC Case Manager:
http://www.juniper.net/cm/
To verify service entitlement by product serial number, use our Serial Number Entitlement (SNE) Tool located at https://tools.juniper.net/SerialNumberEntitlementSearch/
Opening a Case with JTAC
You can open a case with JTAC on the Web or by telephone.
Use the Case Manager tool in the CSC at
http://www.juniper.net/cm/
Call 1-888-314-JTAC
(1-888-314-5822 – toll free in the USA, Canada, and Mexico)
For international or direct-dial options in countries without toll-free numbers, visit http://www.juniper.net/support/requesting-support.html
Release Overview
These Release Notes cover Release 11.1.0 of the system software for the Juniper Networks E Series Broadband Services Routers and contain the following sections:
Release Highlights on page 7
Early Field Trial Features on page 16
Unsupported Features on page 17
Release Software Protocols on page 19
4 Release Overview
Before You Start
Release 11.1.0
SRC Software and SDX Software Compatibility Matrix on page 20
Known Behavior on page 21
Known Problems and Limitations on page 43
Resolved Known Problems on page 63
Errata on page 64
Appendix A, System Maximums on page 65
If the information in these Release Notes differs from the information found in the published documentation set, follow these Release Notes.
These Release Notes include information about the changes between Releases
11.0.0 and 11.1.0. Before you use your new software, read these Release Notes in their entirety, especially the section Known Problems and Limitations. You need the following documentation to fully understand all the features available in Release
11.1.0:
These 11.1.0 Release Notes, which describe changes between Release 11.0.0
and Release 11.1.0
The 11.0.0 Release Notes, which describe features available in Release 11.0.0
The 11.1.x documentation set, which provides detailed information about
features available in Release 11.1.0
The 11.1.x documentation set consists of several manuals and is available only in electronic format. You can print your own documentation using the PDF and HTML formats available at the Juniper Networks Technical Documentation Web site at www.juniper.net/techpubs. Refer to the following table to help you decide which document to use.
Task Document
Install the router ERX Hardware Guide
E120 and E320 Hardware Guide
Learn about modules ERX Module Guide
ERX End-of-Life Module Guide E120 and E320 Module Guide
Get up and running quickly E Series Installation Quick Start poster or ERX Quick Start
Guide E120 and E320 Quick Start Guide
Configure the router JUNOSe System Basics Configuration Guide
Configure physical layer interfaces JUNOSe Physical Layer Configuration Guide
Configure link layer interfaces JUNOSe Link Layer Configuration Guide
Release Overview 5
JUNOSe 11.1.0 Release Notes
Task Document
Configure line module redundancy, stateful SRP switchover, unified ISSU, VRRP, and interchassis redundancy (ICR)
Configure IP, IPv6 and Neighbor Discovery, and interior gateway protocols (RIP, OSPF, and IS-IS)
Configure IP routing services, including routing policies, NAT, J-Flow statistics, BFD, IPSec, digital certificates, and IP tunnels
Configure IP multicast routing and IPv6 multicast routing
Configure BGP, MPLS, Layer 2 service, and related applications
Configure policy management JUNOSe Policy Management Configuration Guide
Configure quality of service (QoS) JUNOSe Quality of Service Configuration Guide
Configure remote access JUNOSe Broadband Access Configuration Guide
Get specific information about commands
Monitor system events JUNOSe System Event Logging Reference Guide
Look up definitions of terms used in JUNOSe technical documentation
JUNOSe Service Availability Configuration Guide
JUNOSe IP, IPv6, and IGP Configuration Guide
JUNOSe IP Services Configuration Guide
JUNOSe Multicast Routing Configuration Guide
JUNOSe BGP and MPLS Configuration Guide
JUNOSe Command Reference Guide A to M JUNOSe Command Reference Guide N to Z
JUNOSe Glossary
6 Release Overview
Release Highlights
Release 11.1.0 includes the features described in this section.
Category Feature
Ethernet Support for Configuring 802.3ah OAM Link-Fault
Management on Ethernet Interfaces on page 8
ICR
IP
L2TP over MPLS
MLPPP
MPLS
Multiclass MLPPP
Packet Mirroring
Policy Management
SDX Software and SRC Software
SNMP
System
System Maximums
Support for Interchassis Redundancy (ICR) on ES2 10G
LM and the ES2 10G ADV LM on page 9
Support for Fast Reconnection of PPPoE Subscribers on
page 9
Support for Hardware Multicast Replication on ES2-S3
GE-20 IOA on page 10
Support for L2TP over MPLS with ES2 10G ADV LM as
Access Module on page 10
MLPPP Fragmentation and Reassembly Support on
OCx/STMx ATM IOAs on page 10
Support for Verifying Connectivity of Point-to-Multipoint
LSPs at Egress Nodes on page 10
Support for Troubleshooting MTU Failures in
Point-to-Point MPLS LSPs on page 11
Multiclass MLPPP Support on page 12
Support for Packet Mirroring Trigger on page 12
Support for HTTP Redirect on ES2 10G ADV LM on
page 13
Support for IPv6 HTTP Redirect on ES2 10G LM on
page 13
Support for CAM Classifier Size of 144-Bit on page 13
Transfer of Calling Station ID to PDP on page 13
Bulk Statistics Support for QoS Schema on page 14
Automatic Update of MAC Address Without SRP
Switchover After SRP IOA Hot-Swap on page 15
Increased Number of Active Service Sessions and Active
Subscriber Sessions on E120 and E320 Routers on page 15
Increased Number of L2TP Tunnels per Chassis on E120
and E320 Routers with SRP-320 and ES2 4G LM on page 16
Release 11.1.0
Release Highlights 7
JUNOSe 11.1.0 Release Notes
Ethernet
Support for Configuring 802.3ah OAM Link-Fault Management on Ethernet
Interfaces JUNOSe Software supports the IEEE 802.3ah standard for Operation,
Administration, and Maintenance (OAM). You can configure IEEE 802.3ah OAM on Ethernet point-to-point direct links or emulated point-to-point links.
You must enable link-fault management on an interface using the ethernet oam lfm command in Interface Configuration mode to be able to configure link detection settings.
JUNOSe Software supports the following OAM functionalities:
Discovery—Detects the devices in the network and their OAM capabilities.
This process is triggered automatically when you enable OAM on the interface.
Link monitoring—Detects and signifies link faults under various conditions
using the Event Notification OAM protocol data unit (PDU), and sends events to the remote OAM entity when problems are detected on the link.
Remote fault detection—Detects failure conditions that occur in the receive
path of the link and influences the state of the link based on the Event Notification OAM PDU received from the remote peer.
Remote loopback—Causes the interface of a local entity to receive and
respond to loopback requests from remote peers. Remote loopback mode ensures link quality between the router and a remote peer.
NOTE: Because the hysteresis mechanism is not available in JUNOSe Software
Release 11.1.0, an OAM session can terminate unexpectedly.
The following line module combinations on E Series routers support the
802.3ah OAM link-fault management feature:
ES2 4G line module combinations on the E120 router and the E320 router:
ES2 4G line modules with ES2-S1 GE-8 IOA
ES2 4G line modules with ES2-S1 GE-4 IOA
ES2 4G line modules with ES2-S1 10GE IOA
GE-2 and GE-HDE line module combinations on ERX14xx models, ERX7xx
In addition, the following log event categories have been added to support the OAM link-fault management feature:
8 Release Highlights
models, and the ERX310 router:
GE-2 and GE-HDE line modules with GE-2 SFP I/O module
GE-HDE line modules with GE-8 I/O module
Release 11.1.0
oam3ahAssociations
oam3ahEvents
oam3ahPdus
The following commands have been added to support configuration of OAM link-fault management:
ethernet oam lfm ethernet oam lfm pdu-lost-threshold
ethernet oam lfm high-threshold ethernet oam lfm pdu-transmit-interval
ethernet oam lfm link-monitor ethernet oam lfm remote-failure
ethernet oam lfm mode  ethernet oam lfm remote-loopback
The following commands have been added to support monitoring of OAM link-fault management:
ICR
show ethernet oam lfm discovery  show ethernet oam lfm status
show ethernet oam lfm statistics  show ethernet oam lfm summary
Change in existing behavior: New feature added as described here.
Support for Interchassis Redundancy (ICR) on ES2 10G LM and the ES2 10G
ADV LM On E120 and E320 routers, the ES2 10G LM and ES2 10G ADV LM now support
interchassis redundancy (ICR). ICR enables you to recover from router failure and minimize subscriber downtime, when the router or access interface on the edge router fails, by re-creating subscriber sessions on the backup router that were originally terminated on the failed router. ICR currently supports only PPPoE subscribers.
NOTE: The ES2 10G LM and ES2 10G ADV LM do not support fast reconnection of
PPPoE subscribers.
Change in existing behavior: Existing feature extended as described here. In lower-numbered releases, ICR was not supported on the ES2 10G LM and ES2 10G ADV LM.
Support for Fast Reconnection of PPPoE Subscribers
JUNOSe Software now supports the fast reconnection of PPPoE subscribers after an ICR failover, except when an administrator intentionally forces a failover.
After an ICR failover, when the new master router becomes active, the aggregation network forwards PPPoE data to the new master router. In lower-numbered releases, the new master router dropped these packets because a session did not exist for the PPPoE subscribers on the new master router.
Release Highlights 9
JUNOSe 11.1.0 Release Notes
IP
Now, when receiving traffic for non-existent PPPoE sessions, the router sends early termination requests by sending PPPoE Active Discovery Termination (PADT) packets to the clients instead of waiting for the client to reconnect after the PPPoE session expires. The clients respond by sending requests to log in again. Then, the new master router creates sessions for the PPPoE subscribers..
NOTE: The ES2 10G LM and ES2 10G ADV LM do not support fast reconnection of
PPPoE subscribers.
Change in existing behavior: New feature added as described here. In lower-numbered releases, the router drops the PPPoE packets because a session did not exist for the PPPoE subscribers. This is no longer the case.
Support for Hardware Multicast Replication on ES2-S3 GE-20 IOA
Logical port 20 on the ES2-S3 GE-20 IOA is reserved for the hardware multicast packet replication feature. You can now configure logical port 20 for hardware multicast replication on the ES2-S3 GE-20 IOA.
L2TP over MPLS
MLPPP
Change in existing behavior: Existing feature extended as described here. In lowered-numbered releases, logical port 20 could not be configured for hardware multicast replication on the ES2-S3 GE-20 IOA. This is no longer the case.
Support for L2TP over MPLS with ES2 10G ADV LM as Access Module
JUNOSe Software now supports configuration of L2TP over MPLS with an ES2 4G LM, ES2 10G LM, or ES2 10G ADV LM as the access module and an ES2 10G ADV LM as the uplink line module.
Change in existing behavior: Existing feature extended as described here.
MLPPP Fragmentation and Reassembly Support on OCx/STMx ATM IOAs
You can now configure MLPPP fragmentation and reassembly on the following module combinations on E120 routers and E320 routers:
ES2 4G LM with ES2-S1 OC3-8 STM1 ATM IOA
ES2 4G LM with ES2-S1 OC12-2 STM4 ATM IOA
Change in existing behavior: Existing feature extended as described here.
MPLS
Support for Verifying Connectivity of Point-to-Multipoint LSPs at Egress Nodes
You can now use the MPLS ping and trace features, available in routers other than E Series routers, to detect data plane failures at E Series routers that function as egress nodes of point-to-multipoint LSPs.
10 Release Highlights
The MPLS ping feature for egress nodes in point-to-multipoint LSPs is not supported on ES2 10G LM line modules, although these LMs support MPLS settings. This restriction occurs because ES2 10G LMs do not forward the received MPLS LSP ping packets to the SRP module on the router, which disables a response to be transmitted to the originator of the request.
As part of this feature, the mplsTraffic event log category has been enhanced to display point-to-multipoint MPLS ping and trace packets received at egress LSRs of point-to-multipoint LSPs.
Change in existing behavior: Existing feature extended as described here. In lower-numbered releases, E Series routers that were egress nodes of point-to-multipoint RSVP-TE MPLS LSPs could not respond to point-to-multipoint MPLS ping messages (echo requests) and, therefore, could not participate in verification of data-plane of point-to-multipoint RSVP-TE MPLS LSPs.
Support for Troubleshooting MTU Failures in Point-to-Point MPLS LSPs
You can now determine the label-switched router (LSR) in a point-to-point LSP at which packets are dropped from further transmission, when the size of the packet exceeds the maximum transmission (MTU) size, and troubleshoot MTU failures.
Release 11.1.0
You can use the data-size keyword with the trace mpls command for point-to-point LSPs in Privileged Exec and User Exec modes to specify the size of the MPLS ping messages (echo requests) in point-to-point LSPs associated with an IP or IPv6 address, a Martini circuit, an L3VPN IP or IPv6 prefix, an RSVP-TE tunnel, or a VPLS instance. You can specify a size in the range 0–6400 bytes; the default size is 100 bytes.
You can use the data-size keyword to determine whether MPLS packets with a particular size can be forwarded over an MPLS point-to-point LSP, when the size of the packet exceeds the MTU size at any of the LSRs that are nodes on the LSP. If you specify the packet size for MPLS echo requests, you can determine the exact LSR where the MTU size is exceeded and the MPLS packets are discarded. You can use this keyword to enable the pad TLV to be added to the MPLS LSP ping message (echo request), which results in future MPLS LSP ping echo requests to be of the same specified number of bytes.
The following commands have been enhanced to support specification of size of the MPLS ping message (echo request packet) to troubleshoot MTU problems in point-to-point MPLS LSPs:
trace mpls ip trace mpls rsvp tunnel
trace mpls l2transport trace mpls vpls
trace mpls l3vpn
Change in existing behavior: Existing feature extended as described here. In lower-numbered releases, you could not use the trace function of the MPLS ping feature to troubleshoot MTU problems in point-to-point MPLS LSPs.
Release Highlights 11
JUNOSe 11.1.0 Release Notes
Multiclass MLPPP
Multiclass MLPPP Support
Multiclass multilink PPP (MLPPP) enables you to fragment data packets of different priorities into multiple classes and to send high-priority packets between fragments of larger packets. When the MLPPP bundle consists of more than one multilink interface, multilink classes ensure that high-priority data packets are received in the sequence they were transmitted.
With multiclass MLPPP each traffic class is mapped to a separate multilink class. Multiclass MLPPP supports mapping of up to eight traffic classes. The default traffic class is the best-effort class. The multiclass MLPPP feature also supports fragmentation and reassembly on the multilink classes.
As part of this feature, the following SNMP MIB objects have been added to the Juniper Networks PPP MIB:
juniPppMlPppLinkConfigMultilinkMulticlass
Packet Mirroring
juniPppMlPppLinkConfigMultilinkMaxClasses
The following SNMP MIB objects have been added to the Juniper Networks PPP Profile MIB:
juniPppProfileMultilinkMulticlass
juniPppProfileMultilinkMaxClasses
The following commands have been added or enhanced to support multiclass MLPPP configuration and monitoring:
ppp multilink multiclass show ppp interface mlppp config
ppp multilink multiclass
fragmentation
ppp multilink multiclass reassembly show ppp interface mlppp statistics
ppp multilink multiclass traffic-class
show ppp interface mlppp full
Change in existing behavior: New feature added as described here.
Support for Packet Mirroring Trigger
You can now trigger packet mirroring for PPP and DHCP subscribers through the following new subscriber identification methods:
Agent Circuit ID
Agent Remote ID
DHCP Option 82
12 Release Highlights
Policy Management
Release 11.1.0
You can use the mirror-enable command to configure this feature through the CLI. The DHCP Option 82 identification method is used to trigger mirroring only for DHCP subscribers. The Agent Circuit ID and Agent Remote ID identification methods are used to trigger mirroring for both PPP and DHCP subscribers.
Change in existing behavior: New feature added as described here.
Support for HTTP Redirect on ES2 10G ADV LM
You can now create an exception rule within an IP policy classifier group for the ES2 10G ADV LM. The exception rule enables an application such as HTTP redirect to perform application-dependent action on the content of the packet. To create the exception rule, use the exception http-redirect command.
Change in existing behavior: Existing feature extended as described here. In lower-numbered releases, an IP policy with exception http-redirect as the action was not supported on the ES2 10G ADV LM.
Support for IPv6 HTTP Redirect on ES2 10G LM
You can now create an exception rule within an IPv6 policy classifier group for the ES2 10G LM. The exception rule enables an application such as HTTP redirect to perform application-dependent action on the content of the packet. To create the exception rule, use the exception http-redirect command.
Change in existing behavior: Existing feature extended as described here. In lower-numbered releases, the ES2 10G LM did not support an IPv6 policy with exception http-redirect.
Support for CAM Classifier Size of 144-Bit
You can now configure content-addressable memory (CAM) hardware classifier entries to be 144 bits for IPv6 policies on the ES2 10G LM or the ES2 10G Uplink LM. The number of 144-bit classifiers supported on the ES2 10G LM is 256K and on the ES2 10G Uplink LM is 128K.
Change in existing behavior: Existing feature extended as described here. In lower-numbered releases, the number of 144-bit classifiers supported on the ES2 10G LM was 128K and the number of 144-bit classifiers supported on the ES2 10G Uplink LM was 64K.
SDX Software and SRC Software
Transfer of Calling Station ID to PDP
JUNOSe Software now supports sending of the calling station ID to the Policy Decision Point (PDP) for a virtual router. To enable this, use the sscc option send-calling-station-id command in Global Configuration mode.
The following command has been modified in this release:
sscc option
Release Highlights 13
JUNOSe 11.1.0 Release Notes
SNMP
The output of the following command has been modified in this release:
show sscc option
Change in existing behavior: New feature added as described here.
Bulk Statistics Support for QoS Schema
The bulk statistics feature now supports the QoS schema, which enables service providers to receive QoS statistics on egress queues for various interface types. Service providers can use this feature to keep track of network congestion and oversubscription by monitoring the QoS statistics and configuration information for the egress interface queues on the router.
To enable bulk statistics to export egress queue-level statistics for subscriber interfaces, you can now use the bulkstats schema subtree qos command in Global Configuration mode. To enable the export of aggregate forwarded and dropped rates of traffic over each S-VLAN or ATM VP (virtual path), include the export-summarized-stats keyword.
The output of the show bulkstats command has been updated to display information about the QoS schema.
As part of this feature, the following new MIB objects have been added to the Juniper Networks Enterprise MIB to specify the attributes for the QoS schema:
rsAcctngAggDropRate rsAcctngQueueLength
rsAcctngAssuredRate rsAcctngQueueProfile
rsAcctngBurst rsAcctngRedDropBytes
rsAcctngByteAdjBytes rsAcctngRedDropPackets
rsAcctngByteAdjType rsAcctngRedEnabled
rsAcctngDropProfile rsAcctngSchedulerProfile
rsAcctngForwardedBytes rsAcctngShapingMode
rsAcctngForwardedPackets rsAcctngShapingRate
rsAcctngForwardedRate rsAcctngSharedShapingMode
rsAcctngGreenDropBytes rsAcctngSharedShapingRate
rsAcctngGreenDropPackets rsAcctngStatisticsProfile
rsAcctngParentChildWeight rsAcctngWeight
rsAcctngParentShapingRate rsAcctngYellowDropBytes
rsAcctngParentSharedShapRate rsAcctngYellowDropPackets
The following commands have been added or modified as part of this feature
bulkstats schema subtree qos show bulkstats
14 Release Highlights
System
Release 11.1.0
Change in existing behavior: Existing feature extended as described here. In lower-numbered releases, you obtained queue level statistics and configuration information for all logical interfaces using the QoS MIB. This feature has been enhanced to support the export of egress queue QoS statistics for various interface types.
Automatic Update of MAC Address Without SRP Switchover After SRP IOA
Hot-Swap On E120 and E320 routers, when you complete hot-swapping an SRP IOA, its
MAC address in the subnet is now automatically refreshed without rebooting the SRP or the chassis. Also, you can re-insert an SRP IOA that you had taken out previously to the same network without refreshing the MAC address of the SRP IOA.
If you have configured RADIUS server on an SRP IOA that you want to replace, you can perform either of the following actions to prevent loss of accounting or logout information:
System Maximums
Disable accounting and, when there is no subscriber login or logout
activity, hot-swap the SRP IOA.
Increase the timeout value of the RADIUS server configured depending on
the time used for IOA replacement. The maximum timeout value is 1000 seconds.
Change in existing behavior: Existing feature extended as described here. In lower-numbered releases, after you completed the hot-swap, you used the srp switch command to refresh the MAC address of the SRP IOA. Failure to refresh the MAC address resulted in MAC address conflict, which could cause disruption of applications or sessions running over the management port. This is no longer the case.
Increased Number of Active Service Sessions and Active Subscriber Sessions on
E120 and E320 Routers Beginning with JUNOSe Release 11.1.0, the number of active service sessions
and the number of active subscriber sessions on E120 and E320 routers have increased as follows:
For E120 routers, the number of active service sessions increased from
131,072 to 196,608 and the number of active subscriber sessions increased from 49,152 to 64,000.
For E320 routers, the number of active service sessions increased from
Change in existing behavior: Existing feature extended as described here.
131,072 to 262,144 and the number of active subscriber sessions increased from 49,152 to 96,000.
Release Highlights 15
JUNOSe 11.1.0 Release Notes
Early Field Trial Features
Increased Number of L2TP Tunnels per Chassis on E120 and E320 Routers
with SRP-320 and ES2 4G LM The number of L2TP tunnels per chassis on E120 and E320 routers with an
SRP-320 module and an ES2 4G LM has increased from 16,000 to 32,000
CAUTION: On E120 and E320 routers with an SRP-320 module, scaling the L2TP
tunnel to more than 16,000 is not supported if the chassis has an ES2 10G LM. The ES2 10G LM may reset if the L2TP tunnel is scaled to more than 16,000.
Change in existing behavior: New system maximums as described here.
The features described in this section are present in the code but have not yet been fully qualified by Juniper Networks. These features are available only for field test purposes in this release. If you use any of these features before they have been fully qualified, it is your responsibility to ensure that the feature operates correctly in your targeted configuration.
DHCP
Support for DHCP External Server, DHCP Local Server, DHCP Relay, and DHCP
Relay Proxy on POS Access Interfaces The following packet over SONET (POS) module combinations on E Series
routers now support configuration of the DHCP external server, DHCP local server, DHCP relay, and DHCP relay proxy applications, alone or in combination, when the POS module is the access interface:
POS module combinations on the E120 router and the E320 router:
ES2 4G LM with ES2-S1 OC12-2 STM4 POS IOA
ES2 4G LM with ES2-S1 OC48 STM16 POS IOA
POS module combinations on ERX14xx models, ERX7xx models, and the
ERX310 router:
OCx/STMx POS line module with OC3-4 I/O module
OCx/STMx POS line modules with OC12/STM4 I/O module
OC48 line module with OC48 FRAME APS I/O module
In the current release, this feature is available for early field test purposes only.
You can configure DHCP external server, DHCP local server, DHCP relay, and DHCP relay proxy on these POS modules in either a virtual router (VR) or a VPN routing and forwarding instance (VRF).
16 Early Field Trial Features
Release 11.1.0
As part of this feature, the pos keyword has been added to the existing ip dhcp-local limit command. To specify the maximum number of IP addresses
that the DHCP local server application can supply to all POS access interfaces or to a specific POS access interface, in the range 0–96000, use the ip dhcp-local limit command with the new pos keyword. For example:
! Set the IP address limit for all POS access interfaces to 1000 host1(config)#ip dhcp-local limit pos 1000 ! Set the IP address limit for the specified POS access interface to 2000 host1(config)#ip dhcp-local limit interface pos 5/0/0 2000 ! Restore the IP address limit for all POS access interfaces to the default value, ! 48000 host1(config)#no ip dhcp-local limit pos
To display the maximum number of IP address leases available for POS access interfaces, use the existing show ip dhcp-local limits command. For example:
host1#show ip dhcp-local limits
Policy Management
Support for CAM Classifier Size of Larger Than 144 Bits
Unsupported Features
The JUNOSe Release 11.1.x documentation set describes some features that are present in the code but that have not yet been fully qualified by Juniper Networks. If you use any of these features before they have been fully qualified, it is your responsibility to ensure that the feature operates correctly in your targeted configuration.
***************************************** DHCP Local Server Address Limits ATM Limit - 48000 VLAN Limit - 48000 POS Limit - 1000 Ethernet Limit - 48000
You can now configure content-addressable memory (CAM) hardware classifier entries to be greater than 144 bits for IPv6 policies on the ES2 10G LM or the ES2 10G Uplink LM. All different sizes of CAM classification entries like 144, 288, and 576 bits are supported. This feature is limited in this release to early field trial purposes only.
The following features are present but unsupported in this release.
E120 Router and E320 Router
The ES2 10G LM and ES2 10G Uplink LM do not support layer 2 statistics for
VLANs.
Unsupported Features 17
JUNOSe 11.1.0 Release Notes
Multicast
Subscriber Interfaces on the ES2 10G Uplink LM
You can configure dynamic subscriber interfaces and static subscriber interfaces on the ES2 10G Uplink LM using the CLI. However, configuring subscriber interfaces on the ES2 10G Uplink LM provides no benefit because access features such as per-subscriber QoS are unavailable on the module.
Unsupported IPv6 Data MDT Commands in CLI
The ipv6 pim data-mdt command and the show ipv6 pim data-mdt commands are unsupported in the current release.
The IPv6 PIM Data MDT Configuration mode is unsupported in this release. The following commands appear in IPv6 PIM Data MDT Configuration mode but are unsupported in the current release:
ipv6 pim join-filter mdt-data-timeout
ipv6 pim query-interval route map
mdt-data-delay tunnel group-address-pool
mdt-data-holdown tunnel source
Policy Management
External Parent Groups Unsupported on ES2 10G, ES2 10G Uplink, and ES2
10G ADV LMs External parent groups are not supported on the ES2 10G, ES2 10G Uplink, and
ES2 10G ADV LMs. If you create a policy that references an external parent group on these LMs, the system prevents you from attaching it to the LM interface and you receive an error message.
Stateful SRP Switchover (High Availability)
Stateful SRP Switchover for Certain Applications
The stateful SRP switchover feature has not been qualified for the following applications:
Remote Access
DHCP proxy client
L2TP dialout
18 Unsupported Features
Release Software Protocols
The following list identifies the major software protocols supported in this release. For detailed information about any protocol, see the configuration guides.
Core Routing Stack
Internet Protocol (IP) version 4 and version 6
Transmission Control Protocol (TCP) for IPv4
User Datagram Protocol (UDP) for IPv4 and IPv6
Network Management Protocols
Simple Network Management Protocol (SNMP) versions 1, 2c, and 3
Release 11.1.0
Routing Protocols
Border Gateway Protocol (BGP-4)
Distance Vector Multicast Routing Protocol (DVMRP)
Internet Group Membership Protocol (IGMP)
Intermediate System–to–Intermediate System (IS-IS)
Layer 2 Virtual Private Networks (L2VPNs)
Mobile IP
Open Shortest Path First (OSPF) version 2 and version 3
Protocol Independent Multicast Protocol (PIM), including PIM dense mode, PIM
sparse mode, PIM dense-sparse mode, and PIM source-specific multicast
Routing Information Protocol (RIP) version 2
Virtual Private LAN Service (VPLS)
Virtual Router Redundancy Protocol (VRRP)
Multiprotocol Label Switching (MPLS)
Border Gateway Protocol (BGP-4)
Label Distribution Protocol (LDP)
Resource ReSerVation Protocol – Traffic Engineering Extensions (RSVP-TE)
Layer 2 Protocols
Asynchronous Transfer Mode (ATM)
Bridged Ethernet
Release Software Protocols 19
JUNOSe 11.1.0 Release Notes
Bridged IP
Cisco High-Level Data Link Control (Cisco HDLC)
Ethernet
Extensible Authentication Protocol (EAP)
Frame Relay
Layer 2 Tunneling Protocol (L2TP)
Multilink Frame Relay (MLFR)
Multilink Point-to-Point Protocol (MLPPP)
Packet over SONET (POS)
Point-to-Point Protocol (PPP)
PPP over Ethernet (PPPoE)
Transparent bridging
Security Protocols
Internet Key Exchange (IKE)
Internet Security Association and Key Management Protocol (ISAKMP)
IP Authentication Header (AH)
IP Encapsulating Security Payload (ESP)
Network Address Translation (NAT)
SRC Software and SDX Software Compatibility Matrix
The SRC software offers the features of the SDX software on the C Series Controllers, a range of hardware platforms that use the Linux operating system. In contrast, the SDX software runs on Solaris workstations. The SRC software contains the features found in the associated SDX release plus additional features described in the SRC Release Notes.
The following table shows which versions of the SRC software and SDX software are compatible with specified versions of the JUNOSe Software.
SRC Software Release SDX Software Release Tested with JUNOSe Release
2.0.0 7.1.0 8.1.2, 8.2.2
2.1.0 Not applicable 9.1.0p0-1
3.0.0 Not applicable 9.0.0, 9.0.1, 9.1.1
3.1.0 Not applicable 9.2.0, 9.3.0, 10.0.0
20 SRC Software and SDX Software Compatibility Matrix
Known Behavior
AAA
Release 11.1.0
SRC Software Release SDX Software Release Tested with JUNOSe Release
3.2.0 Not applicable 10.1.0, 10.2.0, 10.3.0
For more detailed information about SRC software and SDX software compatibility with JUNOSe releases, see the SRC Release Notes.
This section briefly describes E Series router behavior and related issues. In some cases the behavior differs from non–E Series implementations; in others the behavior is included to emphasize how the router works.
Although you can use the max-sessions command to configure a maximum of
32,000 outstanding authentication/authorization requests to a RADIUS server, AAA internal limits prevent the actual number of outstanding authentication/authorization requests from exceeding 9600. These internal AAA limits apply only to authentication/authorization requests and not to accounting requests.
ATM
BGP
The JUNOSe Software does not support accounting for ATM 1483 subscribers.
The atm1483 keyword for the aaa accounting default command is present in the CLI, but it is not supported.
You cannot configure connection admission control (CAC) on an ATM interface
on which you have created a bulk-configured virtual circuit (VC) range for use by a dynamic ATM 1483 subinterface. Conversely, you cannot create a bulk-configured VC range on an ATM interface on which you have configured CAC. The router rejects these configurations, which causes them to fail.
Configuring CAC and bulk-configured VCs on the same ATM interface was supported in previous JUNOSe Software releases. As a result, If you are upgrading to the current JUNOSe release from a lower-numbered release, configurations that use CAC and bulk configuration on the same ATM interface continue to work. However, we recommend that you disable CAC on these ATM interfaces to ensure continued compatibility with future JUNOSe releases.
The E Series router does not include the link-local IPv6 address in the next-hop
field of an MP-BGP update message carrying IPv6 routing information over IPv4 transport. This behavior is compliant with RFC 2545 but might have interoperability issues with other implementations that depend on a link-local IPv6 address in the next-hop field on a directly connected external BGP peering.
Work-aro u n d: Enable EBGP multihop configuration on the remote (non–Juniper Networks) peer.
The following message might be displayed under certain conditions:
Known Behavior 21
JUNOSe 11.1.0 Release Notes
BGP/MPLS VPNs
bgpConnections (default,0.0.0.0): TCP error code xx (...) occurred while accepting inbound TCP connection
The message is generated when an unconfigured peer attempts to establish a TCP session with an E Series router and a valid route to the source address of the peer is absent from the router’s routing table.
If a valid route exists in the routing table, the following message is displayed when an unconfigured peer attempts to establish a TCP session with an E Series router; X.X.X.X is the source address of the unconfigured peer:
NOTICE 08/29/2001 16:50:11 bgpConnections (default,X.X.X.X): Inbound connection refused - no peer X.X.X.X configured in core
NAT does not function properly with secondary routing table lookup (fallback
global) or global export mapping on the VRF.
B-RAS
CLI
Pool groups are not supported; although the ip local pool group command
appears in the CLI, it is not supported.
If the router is under a heavy load, the show profile command might take
longer than usual to execute.
Work-aro u n d: You can either delay examination of profiles until the router is less busy, or save a copy of the profile to a text file off the router.
In Interface Configuration mode for a major interface, the CLI displays options
for protocols that are not supported by that interface type.
When you issue the reload command on an ERX310 router, the command
might display a warning message that erroneously indicates that a synchronizing operation will be performed. Any references to synchronization that appear in command output or system messages do not apply to the ERX310 router, which does not support SRP module redundancy.
The following commands have been deprecated in the JUNOSe Software and
might be removed completely in a future release. If a command has been deprecated for only a particular command mode, the table specifies any modes for which it is still available.
Deprecated Command Command Mode Preferred Command
aaa accounting interval Global Configuration aaa service accounting
cablelength short Controller Configuration
channel-group description Controller Configuration
channel-group shutdown Controller Configuration
22 Known Behavior
interval and aaa user accounting interval
Release 11.1.0
Deprecated Command Command Mode Preferred Command
channel-group snmp trap link-status Controller Configuration
channel-group timeslots Controller Configuration
classifier-list Global Configuration ip classifier-list
clock rate Interface Configuration
color Policy List Configuration color in Classifier Group
Configuration mode
controller e1 Global Configuration
controller t1 Global Configuration
description Interface Configuration
ip description
Still available in Controller Configuration and VRF Configuration modes
fdl Controller Configuration
fdl carrier Controller Configuration
fdl string Controller Configuration
fdl transmit Controller Configuration
filter Policy List Configuration filter in Classifier Group
Configuration mode
forward next-hop Policy List Configuration forward next-hop in
Classifier Group Configuration mode
forward next-interface Policy List Configuration forward interface in
Classifier Group Configuration mode
hostname Domain Map Tunnel
client-name
Configuration
Still available in Global Configuration mode
hssi description Interface Configuration
hssi force dte acknowledge Interface Configuration
hssi internal-clock Interface Configuration
ignore dcd Interface Configuration
ignore link-state-signals Interface Configuration
[ no ] ike cr
l Global Configuration [ no ] ipsec crl
interface hssi Global Configuration
invert tx clock Global Configuration
ip dhcp-local cable-modem Global Configuration set dhcp-relay with the
strings docsis and pktc in the server-string mapping specification
Known Behavior 23
JUNOSe 11.1.0 Release Notes
Deprecated Command Command Mode Preferred Command
ip mirror Global Configuration ip policy secure-input and
ip policy secure-output; for E120 and E320 routers, you must use these commands because the ip mirror command has been removed from the CLI for those routers.
ip policy local-input Interface Configuration,
Profile Configuration
[ no ] ipsec isakmp-policy rule Global Configuration [ no ] ipsec ike-policy-rule
ipv6 policy local-input Interface Configuration,
Profile Configuration
j1 Controller Configuration
license l2tp-session Global Configuration None
lineCoding Controller Configuration
log Policy List Configuration log in Classifier Group
log severity debug dhcpLocalProtocolDecode
loopback Domain Map Configuration
loopback remote { remote line fdl ansi | remote line fdl bellcore | remote line inband remote payload [ fdl ] [ ansi ] }
mark Policy List Configuration mark in Classifier Group
mark-de Policy List Configuration mark-de in Classifier Group
mark-exp Policy List Configuration mark-exp in Classifier Group
mark-user-priority Policy List Configuration mark-user-priority in
mpls ldp discovery transport-address
mpls topology-driven-lsp ip-interfaces
[ no ] next-hop Policy List Configuration forward next-hop in
[ no ] next-interface Policy List Configuration forward interface in
Global Configuration log severity debug
Still available in Controller Configuration and Interface Configuration modes
Controller Configuration
Interface Configuration This command has no effect
Global Configuration ldp ip-forwarding
None
None
Configuration mode
dhcpCapture
local-interface
Configuration mode
Configuration mode
Configuration mode
Classifier Group Configuration mode
in Interface Configuration mode. Now available in Global Configuration mode.
Classifier Group Configuration mode
Classifier Group Configuration mode
24 Known Behavior
Release 11.1.0
Deprecated Command Command Mode Preferred Command
nrzi-encoding Interface Configuration
no ospf enable Router Configuration ospf shutdown
policy-list Global Configuration ip policy-list
radius disconnect client Global Configuration
subscriber disconnect
The RADIUS Disconnect Configuration mode has been removed from the CLI.
rate-limit-profile Policy List Configuration rate-limit-profile in Classifier
Group Configuration mode
remote-loopback Controller Configuration
show controllers t1/e1 User Exec, Privileged Exec
show controllers t1 remote User Exec, Privileged Exec
show ike certificates User Exec, Privileged Exec show ipsec certificates
show ike configuration User Exec, Privileged Exec show ipsec ike-configuration
show ike identity User Exec, Privileged Exec show ipsec identity
show ike policy-rule User Exec, Privileged Exec show ipsec ike-policy-rule
show ike sa User Exec, Privileged Exec show ipsec ike-sa
show ip dhcp-external binding Privileged Exec show dhcp binding
show ip dhcp-external binding-id Privileged Exec show dhcp binding
show ip dhcp-local binding Privileged Exec show dhcp binding
show ip dynamic-interface-prefix Privileged Exec, User Exec None
show ip mirror interface Privileged Exec show secure policy-list
show license l2tp-session User Exec, Privileged Exec None
t1 lineCoding Controller Configuration None. This command never
had any effect.
traffic-class Policy List Configuration traffic-class in Classifier
Group Configuration mode
tunnel mpls label-dist Interface Configuration,
None
Tunnel Profile Configuration
tunnel mpls autoroute announce bgp
Interface Configuration, Tunnel Profile Configuration
None
unframed Controller Configuration
user-packet-class Policy List Configuration user-packet-class in
Classifier Group Configuration mode
virtual-router Domain Map Configuration
router-name
Still available in Privileged Exec and Global Configuration modes
yellow Controller Configuration
Known Behavior 25
JUNOSe 11.1.0 Release Notes
DHCP
The router displays a notice when you issue the command manually. If the command is in a script, the router automatically maps the deprecated command to the preferred command. If the deprecated command no longer has a function, then that command has no effect when you run a script containing the command.
The show configuration command normally takes a long time to finish for
extremely large configurations. If you specify a search string (with the begin, exclude, or include options) with the command for a string that is not present
in the configuration, then the CLI session appears to be busy for a prolonged period. The CLI filtering feature for show commands does not speed up execution of the command.
Configuring authentication on the DHCP local server requires that you first
disable the DHCP local server for standalone mode. Doing so removes your entire DHCP local server configuration. Therefore, if you want to configure authentication, do so before you have otherwise configured the DHCP local server.
DHCP External Server
When you upgrade from a release numbered lower than Release 7.1.0, all
DHCP host routes previously stored in NVS are deleted. After the upgrade, DHCP clients must reacquire their IP addresses, which results in the new host routes being correctly stored in NVS.
If you are using DHCP external server and a burst of client releases occurs
during a unified ISSU, some of the client releases might not be processed. [Defect ID 180178]
When the DHCP relay agent application and the DHCP external server
application are configured in the same virtual router, using the ip dhcp-external server-sync command on an unnumbered IP interface does not
function as expected. When you issue the ip dhcp-external server-sync command in this configuration to create subscriber state information based on lease renewals when the external DHCP server and the router are unsynchronized, the router does not forward the ACK request from the DHCP server to the client because there is no route. [Defect ID 88562]
When a bound DHCP client on a dynamic subscriber interface extends its IP
address lease by restarting the DHCP discovery process on its primary IP interface instead of by initiating the DHCP renewal process on its dynamic subscriber interface, the default behavior of the DHCP external server application to preserve the client’s dynamic subscriber interface was changed in the following JUNOSe releases to delete and re-create the client’s dynamic subscriber interface:
Release 7.2.4p0-4 and all higher-numbered 7.2.x releases and patch
Release 7.3.4 and all higher-numbered 7.3.x releases and patch releases
Release 8.0.4 and all higher-numbered 8.0.x releases and patch releases
26 Known Behavior
releases
Release 11.1.0
Release 8.1.2 and all higher-numbered 8.1.x releases and patch releases
Release 8.2.3 and all 8.2.3 patch releases
Release 9.0.0 and all 9.0.0 patch releases
Release 9.0.1 and all 9.0.1 patch releases
Release 9.1.0 and all 9.1.0 patch releases
If you are upgrading the JUNOSe Software on the router from any of these releases, you must explicitly issue the ip dhcp-external recreate-subscriber-interface command to configure the router to continue to delete and re-create the DHCP client’s dynamic subscriber interface.
NOTE: The DHCP external server application is unsupported in JUNOSe Release
8.2.1 and JUNOSe Release 8.2.2.
DHCP external server may not be able to bind all DHCP clients when all of the
following conditions exist:
DHCP external server and either DHCP relay or relay proxy are configured
in separate virtual routers on an E320 router.
The client-facing and server-facing interfaces for DHCP external server and
either DHCP relay or relay proxy are configured on the same ES2 4G LM.
DHCP external server is configured to create dynamic subscriber
interfaces.
When these three conditions exist simultaneously, the ES2 4G LM may not be able to successfully process all DHCP packets. Although all clients may get bounded in DHCP relay or relay proxy, some clients may not get bounded in DHCP external server. (In a production environment it is highly unlikely for conditions 1 and 2 to exist because stand-alone DHCP external server is normally configured for a DHCP relay in a different chassis.)
Work-aro u n d: You can eliminate this issue by modifying any one of these conditions. For example, this issue does not exist with any of the following configuration modifications:
Configure DHCP external server and either DHCP relay or relay proxy in
the same virtual router.
Configure the client-facing and server-facing interfaces for DHCP external
Configure the client-facing and server-facing interfaces for DHCP external
Dynamic Interfaces
Dynamic IPv6 interfaces over static PPP interfaces are not supported.
server and either DHCP relay or relay proxy on the same ES2 10G LM instead of the same ES2 4G LM.
server and either DHCP relay or relay proxy on separate ES2 4G LMs.
Known Behavior 27
JUNOSe 11.1.0 Release Notes
Ethernet
The hashing algorithm that selects the LAG member link is associated with the
IP address of the subscriber client to support QoS. Consequently, a particular flow is always hashed to the same link. When a member link is removed from a LAG bundle, traffic rate is disrupted and traffic flow is reduced. When the link goes down and then comes back up, the traffic flow is automatically redistributed.
When counting bits per second on a Fast Ethernet or Gigabit Ethernet interface,
an E Series router includes 12 bytes for interpacket gap, 7 bytes for preamble, and 1 byte for start frame delimiter, for a total of 20 bytes (160 bits) per packet more than some non–E Series routers. This value therefore shows the total bandwidth utilization on the interface, including both data and overhead.
To bridge unicast known-DA packets at line rate on both 2-Gbps ports of the
GE-2 line module or the GE-HDE module when paired with the GE-2 SFP I/O module, the minimum packet size must be at least 144 bytes.
When installed in the ERX1440 router, the GE-2 module delivers full bandwidth of 4 GB per line module (2 GB at the ingress and 2 GB at the egress) only when installed in slot 2 or slot 4, and when the SRP-40G+ module is used in the router. When installed in any other ERX1440 slot, the GE-2 module delivers a maximum bandwidth of 2 GB per line module (1 GB maximum at the ingress and 1 GB maximum at the egress). Therefore, of the maximum 24 possible ports for the module in an ERX1440 chassis (that is, two ports in each of 12 slots), full bandwidth is delivered only on a maximum of four ports (those in slots 2 and 4).
When installed in the ERX1440 router, the GE-HDE line module delivers full bandwidth of 4 GB per line module (2 GB at the ingress and 2 GB at the egress) only when installed in slot 2 or slot 4, and when the SRP-40G+ module is used in the router. When installed in any other ERX1440 slot, the GE-HDE module delivers a maximum bandwidth of 2 GB per line module (1 GB maximum at the ingress and 1 GB maximum at the egress). Therefore, of the maximum 96 possible ports for the module in an ERX1440 chassis (that is, 8 ports in each of 12 slots), full bandwidth is delivered only on a maximum of 16 ports (those in slots 2 and 4).
When the GE-2 line module or the GE-HDE line module is installed in either the ERX1440 router or the ERX310 router and both ports are active, line rate performance is achieved only with packets that are 174 bytes or larger. The line module might not achieve line rate with packets that are smaller than 174 bytes.
Support for the 0x9200 S-VLAN Ethertype has been removed. You can no
longer specify the 9200 option with the svlan ethertype command.
When you upgrade to Release 7.1.0 or higher-numbered release, the software automatically transfers existing configurations that use the 0x9200 Ethertype to the 0x88a8 Ethertype.
The show interface gigabitEthernet command output does not display the
following line of output for Gigabit Ethernet modules that do not support SFPs, such as the GE Single Mode I/O module and GE I/O Multi Mode I/O modules:
28 Known Behavior
Flash
GRE
Release 11.1.0
Primary/Secondary link signal detected Primary/Secondary link signal not detected
Flash cards manufactured by Wintec are present on some currently deployed
routers. When you upgrade the JUNOSe Software on such routers, the firmware on the flash card controller is automatically updated during diagnostics. During this reboot, the software runs an integrity check on the file system to verify that the firmware update did not corrupt the contents of the flash card. This integrity check is an expected side effect of the enhanced firmware available in this release. The integrity check does not indicate a problem with the flash card or its contents.
When you shut down the only outgoing IP interface to the IP destinations of
GRE/IP tunnels, the tunnels remain in the up state rather than transitioning to down. As a consequence, all IP routes that use these tunnels as next hops also remain in the routing table.
Hardware
SRP modules with only 1 GB of memory do not work reliably in ERX7xx and
ERX14xx routers running JUNOSe Release 8.1.0 or higher, and may experience system resets due to an out of memory condition. However, the ERX310 router still supports 1 GB of memory in the SRP-SE10 module.
Work-aro u n d: Upgrade your SRP module memory to 2 GB for all ERX7xx and ERX14xx routers running JUNOSe Release 8.1.0 or higher.
Do not include a not protocol clause in any classifier control list for policies
attached to an interface on an ES2 10G Uplink LM. The not protocol functionality is not available for this module.
The ES2 10G LM and the ES2 10G Uplink LM do not support VLAN statistics in
the current release.
PCMCIA NVS Card Caution
CAUTION: Before you insert or remove PCMCIA NVS (flash) cards from a running
router, we strongly recommend that you halt the SRP module or shut down the router. Failure to do this can result in file corruption in one or both cards.
The 4XOC3 APS MULTIMODE and 4XOC3 APS SINGLE MODE I/O modules are
incompatible with the following versions of the OCx/STMx ATM and OCx/STMx POS line modules:
OCx/STMx ATM line modules with assembly numbers 350-00039-xx,
OCx/STMx POS line modules with assembly number 350-10039-xx
350-80039-xx, and 350-90039-xx
Known Behavior 29
JUNOSe 11.1.0 Release Notes
HDLC
When you configure 1:5 line module redundancy by using either the 4XOC3
APS MULTIMODE or 4XOC3 APS SINGLE MODE I/O module, the spare R-Mid OCX I/O module you install must have assembly number 350-00094-01 Rev. A01 or later. Spare R-Mid OCX I/O modules with an earlier assembly number are not supported for 1:5 redundancy configurations that use either the 4XOC3 APS MULTIMODE or 4XOC3 APS SINGLE MODE I/O module.
There is a very small chance that some line modules can have an improperly
modified keying block that prevents the module from proper seating in the top slot of an older ERX7xx chassis or a preproduction ERX310 chassis. For example, this problem has been observed for an OCx/STMx module in slot 2 of an early-test ERX310 chassis.
Work-aro u n d: Remove the keying block to insert the module into the top slot, or insert the module into a different slot.
By design, on the cOC12/STM4 module you cannot delete a serial interface
while data for the interface is still enqueued. The enqueued data can drain only when the interface is operationally up. Therefore you must ensure that the interface is operationally up before you delete it. For example, if you have issued the shutdown command for the interface before you try to delete the interface, issue the no shutdown command, then delete the interface.
IP
When you upgrade from certain releases to JUNOSe Release 9.2.0p1-0 or
higher-numbered releases, descriptions configured for IP interfaces or IP subinterfaces are not retained across the upgrade when the descriptions are shorter than 9 characters in length. Additionally, VRF descriptions are not retained across the upgrade when the combined length of the VRF description and the VRF name is shorter than 9 characters. This behavior is seen during upgrades using a reload, stateful SRP switchover, or unified ISSU. Upgrades from the following releases are affected by this behavior:
7.x.x
8.0.x
8.1.x, 8.2.x, and 9.x.x builds created before July 23, 2008
Examples of descriptions that are not retained across the upgrade:
host1(config-if)#ip description 12345678
host1(config)#ip vrf 123 host1(config-vrf)#description 45678
Examples of descriptions that are retained across the upgrade:
host1(config-if)#ip description longdescription
host1(config)#ip vrf longername host1(config-vrf)#description 45678
30 Known Behavior
Release 11.1.0
host1(config)#ip vrf 123 host1(config-vrf)#description longdescription
Work-aro u n d: Before you upgrade from an affected release to JUNOSe Release
9.2.0p1-0 or higher-numbered releases, ensure that you do the following:
Change IP interface and subinterface descriptions to 9 or more characters.
Change VRF descriptions, VRF names, or both so that the combination of
associated VRF names and descriptions consists of 9 or more characters.
The ip tcp adjust-mss command, which modifies the maximum segment size
for TCP SYN packets traveling through the interface, is not supported on the ES2 10G LM or ES2 10G Uplink LM.
If you have enabled ipInterface logging at a priority of debug, the
acknowledgment that an interface has been deleted from the line modules can return to the SRP module after the layers beneath IP have deleted their interfaces. Consequently, the original name of the interface cannot be resolved or displayed in the log, and the system instead displays the ifIndex of the IP interface. This behavior has no functional effect other than that the log is misleading. However, previous log events indicate that the interface deletion was beginning.
When you want to use a configuration script to configure IP shared interfaces
that reference a physical interface, you must issue the service show configuration format 2 command before you generate the script. If the default show configuration format (format 1) is enabled instead, the generated script
cannot properly configure the IP shared interfaces because they are created before the physical interfaces. To properly configure the shared interfaces in this event, run the generated format 1 script twice.
When you issue the show ip forwarding-table command for a particular slot, it
is normal and appropriate behavior when the Status field indicates Valid while the Load Errors field is increasing daily for that VR. The Load Errors field records any failed routing table distribution attempt as an error. Attempts can fail for many reasons during normal operation; a failed attempt does not necessarily indicate a problem. It is normal to see many load errors per day. If the Status field indicates Invalid, then the routing table distribution has failed constantly for that VR and a real problem exists. You might occasionally see a status of Updating. However, if the Status field always indicates Updating, then again the routing table distribution has failed constantly for that VR, and a real problem exists.
The enhancement to the CLI to support unnumbered reference to any kind of
interface rather than just loopback interfaces has consequences such as the following: [Defect ID 47743]
If the references to shared interfaces appear in the show configuration
output before the configuration for the interfaces they refer to, trying to restore such a configuration with a script generated from show configuration generates errors like the following:
% Error, line 3929:
Known Behavior 31
JUNOSe 11.1.0 Release Notes
IPSec
host1(config-if)#ip share-interface FastEthernet 3/0.2 % No such interface
Unnumbered interfaces that refer to nonloopback interfaces (for example,
ip unnumbered fastEthernet 3/0.2) and that appear in the show configuration output before the interface referred to might generate
similar no such interface errors.
Work-aro u n d: Run the script twice.
When you shut down the only outgoing IP interface to the IP destinations of
IPSec tunnels, the tunnels remain in the up state rather than transitioning to down. As a consequence, all IP routes that use these tunnels as next hops also remain in the routing table. You can use dead keepalive detection (DPD) to avoid this situation. DPD must be active, which requires both IPSec tunnel endpoints to support DPD.
IS-IS
During a warm restart after a system failover, the SRP module can take several
minutes to resume the normal exchange of UDP/IP packets to applications. During this restart time, the E Series router does not send or receive dead peer detection (DPD) keepalives, which are used to verify connectivity between the router and its peers. The length of the restart time depends on the number of interfaces—if the restart time is too long, remote peers might determine that the connection from them to the E Series router is broken and then shut down an IPSec tunnel that has DPD enabled. In the worst case, all IPSec tunnels might be shut down. [Defect ID 65132]
When IS-IS is configured on a static PPP interface, the IS-IS neighbor does not
come up if you remove the IP address from the interface and then add the IP address back to the interface.
Work-aro u n d: When you remove and add back the IP address, you must also remove the IS-IS configuration from the interface and then add the configuration back to the interface by issuing the no router isis and router isis commands.
When you run IS-IS on back-to-back virtual routers (VRs) in an
IS-IS-over-bridged-Ethernet configuration and do not configure different IS-IS priority levels on each VR, a situation can occur in which both VRs elect themselves as the designated intermediate system (DIS) for the same network segment.
This situation occurs because the router uses the same MAC address on all bridged Ethernet interfaces by default. When both VRs have the same (that is, the default) IS-IS priority level, the router must use the MAC address assigned to each interface to determine which router becomes the DIS. Because each interface in an IS-IS-over-bridged-Ethernet configuration uses the same MAC address, however, the router cannot properly designate the DIS for the network segment. As a result, both VRs elect themselves as the DIS for the same network segment, and the configuration fails. [Defect ID 72367]
32 Known Behavior
L2TP
Release 11.1.0
Work-aro u n d: To ensure proper election of the DIS when you configure IS-IS over bridged Ethernet for back-to-back VRs, we recommend that you use the isis network point-to-point command in Interface Configuration mode to configure IS-IS to operate using point-to-point (P2P) connections on a broadcast circuit when only two routers (or, in this case, two VRs) are on the circuit. Issuing this command tears down the current existing IS-IS adjacency in that link and reestablishes a new adjacency.
L2TP peer resynchronization enables an L2TP failed endpoint to resynchronize
with its peer non-failed endpoint. The JUNOSe Software supports failover protocol and silent failover peer resynchronization methods. If you configure the silent failover method, you must keep the following considerations in mind:
PPP keepalives—To ensure resynchronization of the session database, PPP
keepalives must be enabled on the L2TP data path. Without PPP keepalives, silent failover might disconnect an established session if there is no user traffic during failover recovery.
Asymmetric routes on different line modules—Asymmetric routes whose
receive and transmit paths use I/O paths on different line modules can result in improperly handled line module control packets. If your network does include this type of asymmetric route, tunnels using these routes might fail to recover properly.
NAT dynamic translation generation affects the LNS session creation time.
When NAT dynamic translations and LNS sessions are created simultaneously, NAT dominates the CPU cycles of the tunnel-service module, resulting in a delay in the LNS session creation rate. The LNS session creation rate returns to its normal rate when NAT dynamic translations are no longer being generated. [Defect ID 53191]
Work-aro u n d: When signaling performance must be optimal, avoid the simultaneous configuration of NAT and LNS.
If you create an L2TP destination profile profileName, establish tunnels with the
profile, and then remove the profile, you cannot subsequently create another destination profile using that same profileName until all the tunnels drain from the previous instance of this destination profile. If you do not wait, the E Series router displays a message similar to the following:
l2tp: Discarding incoming sccrq from vr default, remote address 192.168.100.1 ­no destination profile.
If you do not want to wait for the tunnels to drain, use a different name for the destination profile. [Defect ID 32973]
Line Module Redundancy
On E120 routers and E320 routers, redundant IOAs have a temperature sensor,
and the show environment all command lists the temperature of IOAs in their associated slots.
Known Behavior 33
JUNOSe 11.1.0 Release Notes
MLPPP
On ERX routers, redundant I/O modules do not have a temperature sensor. Therefore, the show environment all command output lists the primary I/O module temperature in the slot of the line module that is responsible for the I/O module.
When you install an ES2-S1 Redundancy IOA with a hardware revision number
of -02 or less in slot 0 or slot 11 of the E320 router or in slot 0 or the E120 router, do not install an OCx/STMx ATM IOA or an OCx/STMx POS IOA in the lower (E320) or left (E120) adapter bay of slot 1 or slot 12. When the spare line module is controlling another slot and you revert back to the primary line module, the ATM or POS IOAs can become unusable or cause the line module to reset. [Defect ID 69760]
Work-aro u n d: This problem is not present for ES2-S1 Redundancy IOAs with a hardware revision number of -03 or higher.
Do not configure both MLPPP fragmentation (with the ppp fragmentation
command) and IP fragmentation of L2TP packets (with the ip mtu command) on the same interface. Instead, you must choose only one of the fragmentation configurations by setting it to the necessary value and set the other fragmentation configuration to the maximum allowable value.
MPLS
Multicast
Martini circuits configured on the ES2 10G LM act as true layer 2 tunnels,
without modifying the layer 2 headers. For this reason, Martini VLAN retagging is not currently supported.
If you are upgrading to Release 7.1.0 or a higher-numbered release from a
release numbered lower than Release 7.1.0, and have inter-AS option B or C configurations, you must explicitly configure MPLS on all inter-AS links, as in the following example:
host1#configure terminal host1(config)#interface fastEthernet 2/0 host1(config-if)#ip address ... host1(config-if)#mpls
If you do not explicitly configure MPLS on the links, the inter-AS feature will not work properly.
The ip dipe sg-cache-miss and ipv6 dipe commands are not intended or
supported for customer use, although they are visible in the User Exec and Privileged Exec modes respectively. These commands are intended to be used in a Juniper Networks internal lab environment for testing without a traffic generator.
Do not configure a multicast group with more than 10,219 outgoing interfaces
(OIFS) on the same ES2 10G LM. [Defect ID 81768]
34 Known Behavior
Packet Mirroring
Release 11.1.0
The ES2 10G LM supports the packet mirroring feature when the module is
paired with the ES2-S2 10GE PR IOA, the ES2-S1 GE-8 IOA, or the ES2-S3 GE-20 IOA. When you use the ES2 10G LM with these IOAs, CLI-based interface-specific mirroring is not supported.
When both interface-specific mirroring and user-specific mirroring are
configured on the same interface, the interface-specific secure policies take precedence. The interface-specific secure policies, which you manually attach using the CLI, override and remove any existing secure polices that were attached by a trigger action. If the interface-specific secure polices are subsequently deleted, the original trigger-based secure policies are not restored.
Typically, when configuring packet mirroring, you configure a static route to
reach the analyzer device through the analyzer port. If the analyzer port is an IP-over-Ethernet interface, you must also configure a static Address Resolution Protocol (ARP) entry to reach the analyzer device. However, because only a single static ARP entry can be installed for a given address at any given time, when you are using equal-cost multipath (ECMP) links to connect to the analyzer device, the static ARP configuration does not provide failover if the link being selected fails or is disconnected. Therefore, to provide continued connectivity if the link fails when using ECMP, enable the ip proxy-arp unrestricted command on the next-hop router for each ECMP interface. As a result, when the link fails, the router sends an ARP request to identify the MAC address of the analyzer device and gets a response over the new link.
Policy Management
The ES2 10G LM does not support the deprecated next-hop command.
You cannot configure classifier lists that reference multiple fields for a VLAN
policy list on the ES2 10G Uplink LM or the ES2 10G LM, with the exception of traffic-class and color. The system incorrectly classifies VLAN policies that classify using multiple fields. For example, an invalid policy list that references multiple fields uses both color and user-packet-class, or one classifier list using color and another using user-packet-class.
In rare cases, some policy configurations that use CAM hardware classifiers
from releases earlier than Release 7.1.0 can fail because they exceed the total hardware classifier entry size of 128 bits that was introduced in Release 7.1.0. For more information and examples of previous configurations, see JUNOSe
Policy Management Configuration Guide, Chapter 8, Policy Resources.
Multiple Forwarding Solution Rules for a Single Classifier List in a Policy
Before Release 5.2.0, it was possible to configure a policy with multiple rules that specified forwarding solutions where all of these rules were associated with a single classifier list. This typically was a configuration error, but the CLI accepted it. Beginning with Release 5.2.0, the CLI no longer accepts this configuration.
Multiple forwarding rules behavior for releases numbered lower than
Release 5.2.0:
Known Behavior 35
JUNOSe 11.1.0 Release Notes
If multiple forward or filter rules were configured to reference the
same classifier list in a single policy, then all rules except the first rule
configured were marked as eclipsed in the show policy command
display. Next-interface and next-hop rules were treated in the same
manner. The eclipsed rules were not applied.
If a policy were configured with one rule from the [forward, filter] pair
and one rule from the [next-hop, next-interface] pair, and if both rules
referenced the same classifier list, then no visible eclipsed marking
occurred. However, these two rules were mutually exclusive, and only
one of them defined the forwarding behavior. The rule action that was
applied was in the order (from highest to lowest preference): next
interface, filter, next hop, forward. The applied rule was the rule whose
behavior was seen by forwarded packets.
For example, if a policy had both a next-interface and a filter rule, then
the next interface was applied. If a policy had a next-hop and a filter
rule, then the filter rule was applied.
Multiple forwarding rules behavior for Release 5.2.0 and higher-numbered
releases:
Beginning with Release 5.2.0, the multiple rules behavior is designed so that when a forwarding solution conflict occurs within a policy, such as those described earlier, the second forwarding solution overwrites the preceding solution. That is, the last forwarding rule configured for the given classifier list within a policy is the forwarding behavior that is used. Also, a warning message is now displayed when this type of conflict occurs.
Example 1—In this example, the filter rule action overwrites the forward rule, and is therefore applied.
host1(config)#policy-list wstPolicyList host1(config-policy-list)#forward classifier-group svaleClacl1 host1(config-policy-list)#filter classifier-group svaleClacl1 WARNING: This rule has replaced a previously configured rule. host1(config-policy-list)#exit host1(config)#
Example 2—In this example, three forwarding solution conflicts result in rules being overwritten. The filter rule is the last rule configured, and is therefore applied.
host1(config)#policy-list bostTwo host1(config-policy-list)#forward classifier-group clacl5 host1(config-policy-list)#next-hop 1.1.1.1 classifier-group clacl5 WARNING: This rule has replaced a previously configured rule. host1(config-policy-list)#next-interface atm 1/0.0 classifier-group clacl5 WARNING: This rule has replaced a previously configured rule. host1(config-policy-list)#filter classifier-group clacl5 WARNING: This rule has replaced a previously configured rule. host1(config-policy-list)#exit host1(config)#
36 Known Behavior
Release 11.1.0
NOTE: When you upgrade the nonvolatile memory to Release 5.2.0 or later, the
upgrade removes eclipsed rules and rules whose behavior was not applied in the previous release. This removal ensures that the postupgrade forwarding behavior is the same as the preupgrade behavior.
NOTE: If you upgrade to Release 5.2.0 or later and then configure your router
using a script generated before Release 5.2.0, the postupgrade and preupgrade forwarding behaviors might not be the same. The new Release 5.2.0 configuration behavior is applied—the last policy rule configured for a given classifier list that specifies a forwarding behavior is the only rule remaining.
In JUNOSe Release 11.0.0 and higher-numbered releases, you must specify at
least one option by which the router defines a packet flow in order to configure classifier control lists (CLACLs) for policy lists to be attached to VLAN interfaces. Although a carriage return, <cr>, is displayed when you type a question mark (?) after entering the vlan classifier list classifierName command without defining any other keyword or CLACL option, an error message is displayed when you press Enter to configure the VLAN CLACL with only the name. The error message states that a VLAN classifier list cannot be configured without any classification criteria, such as color, traffic class, user packet class, or user priority. You must specify at least one keyword or option to configure VLAN CLACL successfully. [Defect ID 184139].
PPP
PPPoE
In JUNOSe releases earlier than Release 11.0.0, you could configure all CLACLs (except those CLACLs that were attached to IP interfaces) without specifying an option or a keyword. Because the policy management application treats only one default classifier group (configured with an * in the policy list) as a valid setting, this functionality change ensures that only one classifier that matches all packets can be present in a VLAN policy list definition.
The GE-2 line module does not support dynamic IP interfaces over static PPP
interfaces when the PPPoE subinterface is also static. The OC3/STM1 GE/FE line module does not support dynamic IP interfaces over static PPP interfaces when the ATM interface column is also static.
On the ES2 4G LM, ES2 10G LM, and ES2 10G Uplink LM, data packets for
PPPoE are not counted at the PPPoE interface. Instead, PPPoE data packets are counted at the PPP interface that sits on the PPPoE interface. Use the show ppp interface command to display the data packets. Control packets for PPPoE are counted at the PPPoE interface; use the show pppoe interface command to display the control packets.
Known Behavior 37
JUNOSe 11.1.0 Release Notes
QoS
In JUNOSe Releases 7.1.x, 7.2.x, and 7.3.x, you can attach a QoS profile to
Ethernet interfaces that are configured in a link aggregation group (LAG) interface. However, beginning with JUNOSe Release 8.0.1, you can attach a QoS profile directly to the LAG interface. As of JUNOSe Release 8.0.1, the software restricts you from attaching a QoS profile to any Ethernet interfaces that are members of a LAG. [Defect ID 84632]
Work-aro u n d: Prior to upgrading from JUNOSe Releases 7.1.x, 7.2.x, or 7.3.x to JUNOSe Release 8.0.x or higher-numbered releases, remove the QoS profile from the Ethernet interface. When you have successfully upgraded to JUNOSe Release 8.0.x or higher-numbered releases, reattach the QoS profile to the LAG interface.
In Release 7.2.0 and higher-numbered releases, you can configure the simple
shared shaper to select scheduler nodes in a named traffic-class group as active constituents.
RADIUS
By default, simple implicit shared shapers activate scheduler nodes in named traffic-class groups. The implicit constituent selection process is now the same for both simple and compound shared shapers.
This is a change in default behavior. For releases before Release 7.2.0, you could not configure scheduler nodes as active constituents of the simple shared shaper, except for the best-effort node.
To recover the default behavior available before Release 7.2.0, or to select active constituents that are different, use simple explicit shared shapers to select best-effort nodes only.
When you are configuring compound shared shaping using explicit
constituents and you explicitly specify both a scheduler node and a queue stacked above the node as constituents of the shared shaper, the system selects the scheduler node (but not the queue) as the constituent.
JUNOSe Software provides extended commands for configuring the formats of
the RADIUS NAS-Port attribute (attribute 5) and the RADIUS Calling-Station-ID attribute (attribute 31) when the physical port value is greater than 7.
When the physical port value is greater than 7:
An incorrectly configured NAS-Port attribute format results if you use either
the radius nas-port-format 0ssssppp or radius nas-port-format ssss0ppp command.
An incorrectly configured Calling-Station-ID attribute results if you use
Work-aro u n d: Use the following commands on routers that have line modules with more than 7 physical ports:
38 Known Behavior
either the radius calling-station-format fixed-format command or the radius calling-station-format fixed-format-adapter-embedded
command.
SNMP
Release 11.1.0
To configure the NAS-Port attribute format, use the radius nas-port-format
extended [ atm | ethernet ] command.
To configure the Calling-Station-ID attribute format, use the radius
calling-station-format fixed-format-adapter-new-field command.
SNMP MIBs
Information about all the SNMP MIBs (both standard and proprietary) that the router supports in this release is available in the MIB directory in the SW_Image_CD-2 folder of the JUNOSe Software image bundle, which you downloaded from the Juniper Networks website, that contains the release file for E120 and E320 routers. .
Some Juniper Networks SNMPv1-formatted traps contain an incorrect object
identifier (OID) in the SNMPv1-Trap-PDU enterprise field. An SNMPv2 trap is typically identified by an OID that ends in the form ...x.y.z.0.n. This OID appears, in full, as the value of the snmpTrapOID.0 object in the varbind list of an SNMPv2-formatted trap. In the corresponding SNMPv1-formatted trap, this OID is broken down into subcomponents that fill the SNMPv1-Trap-PDU enterprise field (...x.y.z) and specific trap number field (n); the zero is unused.
The SNMPv1-formatted versions of the following Juniper Networks traps incorrectly contain ...x.y.z.0 in the SNMPv1-Trap-PDU enterprise field. That is, a zero is mistakenly appended to the correct enterprise OID value.
Trap Name Expected Enterprise OID Enterprise OID Sent by SNMP Agent
junidApsEventSwitchover .1.3.6.1.4.1.4874.3.2.2.1.2 .1.3.6.1.4.1.4874.3.2.2.1.2.0
junidApsEventModeMismatch .1.3.6.1.4.1.4874.3.2.2.1.2 .1.3.6.1.4.1.4874.3.2.2.1.2.0
junidApsEventChannelMismatch .1.3.6.1.4.1.4874.3.2.2.1.2 .1.3.6.1.4.1.4874.3.2.2.1.2.0
junidApsEventPSBF .1.3.6.1.4.1.4874.3.2.2.1.2 .1.3.6.1.4.1.4874.3.2.2.1.2.0
junidApsEventFEPLF .1.3.6.1.4.1.4874.3.2.2.1.2 .1.3.6.1.4.1.4874.3.2.2.1.2.0
juniAddressPoolHighAddrUtil .1.3.6.1.4.1.4874.2.2.21.3 .1.3.6.1.4.1.4874.2.2.21.3.0
juniAddressPoolAbatedAddrUtil .1.3.6.1.4.1.4874.2.2.21.3 .1.3.6.1.4.1.4874.2.2.21.3.0
juniAddressPoolNoAddresses .1.3.6.1.4.1.4874.2.2.21.3 .1.3.6.1.4.1.4874.2.2.21.3.0
juniDhcpLocalServerPoolHighAddrUtil .1.3.6.1.4.1.4874.2.2.22.3 .1.3.6.1.4.1.4874.2.2.22.3.0
juniDhcpLocalServerPoolAbatedAddrUtil .1.3.6.1.4.1.4874.2.2.22.3 .1.3.6.1.4.1.4874.2.2.22.3.0
juniDhcpLocalServerPoolNoAddresses .1.3.6.1.4.1.4874.2.2.22.3 .1.3.6.1.4.1.4874.2.2.22.3.0
pimNeighborLoss .1.3.6.1.3.61.1 .1.3.6.1.3.61.1.0
Work-aro u n d: Use the OIDs that the SNMP agent sends.
Known Behavior 39
JUNOSe 11.1.0 Release Notes
SSH
If the SRP module restarts when SSH is configured in a VR other than default,
SSH can sometimes become disabled. This happens if SSH attempts to bind with a VR before the VR comes back up after the restart. In this event, a warning message is generated to alert you to the fact that SSH is disabled in that VR. You must manually re-enable SSH either by accessing the console VTY or creating a Telnet session to the router.
Stateful SRP Switchover (High Availability)
Additional processing is required to maintain and mirror the necessary state
information that enables subscriber sessions to stay up across an SRP failover. As a result, the performance of other control plane functions is reduced. Specifically, call setup rates are lower than in previous releases.
NOTE: Rapid call setup rates are most important following an outage that causes
all subscribers to drop, because many of the dropped subscribers will immediately attempt to reconnect. This type of outage occurs far less frequently with stateful SRP switchover.
We have ongoing development activities to characterize and improve call setup rates in future releases.
Stateful SRP switchover remains inactive for 20 minutes after an initial
cold-start or cold-restart of the router. This delay enables the system to reach a stable configuration before starting stateful SRP switchover.
If you want to override the 20-minute timer, turn high availability off by using the mode file-system-synchronization command, and then on again by using the mode high-availability command.
When IP tunnels are configured on a router enabled for stateful SRP
switchover, and the Service Module (SM) carrying these tunnels is reloaded, stateful SRP switchover transitions to the pending state. Stateful SRP switchover remains in the pending state for 10 minutes following the successful reloading of the SM. This amount of time allows for IP tunnel relocation and for the tunnels to become operational again on the SM. If an SRP switchover occurs while in the pending state, the router performs a cold restart.
Work-aro u n d: None.
After a stateful SRP switchover, each layer of the interface columns must
reconstruct its interfaces from the mirrored information. While the interfaces are being reconstructed the SRP module cannot send or receive frames, including the protocol frames that signal graceful restart behavior with OSPF and IS-IS peers. If the configured hold time is too short, peers might mistakenly declare the adjacency down during the time in which the graceful restart is taking place. [Defect ID 65132]
Work-aro u n d: Increase the hold time to provide sufficient time for interface synchronization before the peers declare the adjacency down.
40 Known Behavior
Release 11.1.0
For OSPF, use the ip ospf dead-interval command to set the hold time.
We recommend that you use Bidirectional Forwarding Detection (BFD) with a longer OSPF dead interval to achieve fast failure detection.
For IS-IS, use the isis hello-interval and isis hello-multiplier commands
to set the hold time.
We recommend the following hold times for each protocol, based on the number of interfaces.
Subscriber Interfaces
System
Recommended Hold Time
Interface Count
16000 or less 80 seconds 50 seconds
16001 to 32000 87 seconds 55 seconds
32001 to 48000 90 seconds 70 seconds
MAC address validation is not supported on either of the following:
Packet-triggered subscriber interfaces that are created dynamically
Packet-triggered subscriber interfaces that are managed on the primary IP
for OSPF
Recommended Hold Time for IS-IS
interface
A packet-triggered subscriber interface is created when the router receives a packet with an IP source address that does not match any entries in the demultiplexer table. When the router detects an unmatched packet, it generates a trigger event that determines whether to create a dynamic subscriber interface or configure an existing interface. To configure packet detection on the router, use the ip auto-detect ip-subscriber command.
ERX routers display different behavior from E120 routers and E320 routers
when reporting modules as inactive.
ERX routers report a module as inactive when either:
The I/O module is not present
The primary line module is fully booted and ready to resume operation. In
E120 routers and E320 routers report a module as inactive when either:
The primary line module has no IOAs.
The primary line module has IOAs, but they have failed diagnostics.
The standby line module has taken over for the primary line module, and
this case, the standby is currently providing services.
has control of the IOAs.
Known Behavior 41
JUNOSe 11.1.0 Release Notes
Because E120 and E320 routers can accommodate up to two IOAs per slot, at least one IOA must be online. If the second IOA fails, the line module is still online, but does not use both IOAs. You can ensure that every module is up and active in the system and not in a failed state by issuing the show version all command.
In a router with a redundancy group that does not span quadrants (for
example, a three-slot redundancy group that spans slots 0, 1, and 2 in an ERX1410 chassis), the potential bandwidth of the redundant module is erroneously included in the quadrant bandwidth calculation. The show utilization command might indicate that the bandwidth is exceeded for modules in that group. [Defect ID 31034]
When you copy the running configuration to NVS, the E Series router verifies
whether it has available space equal to at least twice the size of the .cnf file. If the space is insufficient, you cannot complete the copy. [Defect ID 40655]
Work-aro u n d: Make sufficient space on the NVS by deleting .rel or .cnf files.
System Logging
Tunneling
You cannot delete the ipInterface log after you delete the corresponding IP
interface. This does not prevent you from adding filters to other interfaces, nor does it prevent you from adding a filter to the same interface if you re-create it after deletion. [Defect ID 34842/45063]
Work-aro u n d: Remove the filter before you remove the interface. Alternatively, if you remove the interface first, then you must remove all filters associated with all IP interfaces.
If you enable engineering logs and set the control network logs to a level of
notice or lower (down from the default of error), you might see erroneous controlNetwork log messages like the following that are generated because SNMP polling on line modules (correctly) detects no fabric: [Defect ID 43168]
NOTICE 09/01/2002 18:47:52 CEST controlNetwork (slot 11): Control Bus Master slave error 0x5 while accessing slot
When you configure the GE-2 line module, the GE-HDE line module, or the
ES2-S1 GE-4 IOA to operate as a shared tunnel-server module, the available bandwidth for tunnel services is limited to 0.5 Gbps per module.
In releases numbered lower than Release 7.3.0, a dynamic tunnel-server port
was located on port 8 of the GE-HDE line module and GE-8 I/O module.
In Release 7.3.0 and higher-numbered releases, the dynamic tunnel-server port is located on port 9. When you upgrade to Release 7.3.0, any existing tunnel-server port configurations move from port 8 to port 9.
42 Known Behavior
Known Problems and Limitations
This section identifies the known problems and limitations in this release. For more information about known problems that were discovered at customer sites, you can log in to the JUNOSe Knowledge Base at https://www2.juniper.net/kb/, enter the defect ID number in the Search by Keyword field, and click Search.
ANCP
On an E320 router that has established 3000 ANCP adjacencies with a client
and traffic is initiated, the following behavior occurs sporadically: All existing Telnet sessions are disconnected and no new Telnet sessions can be established for several minutes. [Defect ID 83872]
ATM
The line module resets when you issue the show nbma arp command after
you have configured NBMA interfaces on an ATM line module. [Defect ID 88491]
Release 11.1.0
When 16,000 PPPoA interfaces are configured on an OCx/STMx ATM line
module paired with an OC3-4 I/O module in an ERX14xx model, ERX7xx model, or ERX310 router, Ping traffic passing through the line module on the restarting router experiences an outage of 103 seconds, which is beyond the maximum limit, after a unified ISSU from JUNOSe Release 9.2.0p1-0 to
9.3.0b0-12. This outage does not occur when the same configuration is applied on a Gigabit Ethernet interface. [Defect ID 179794]
When you reload an ATM line module that is configured with NBMA circuits as
passive OSPF interfaces and that has established OSPF adjacencies and IBGP peers (configured on Gigabit Ethernet interfaces), the transmission of OSPF hello packets might be affected until all the NBMA interfaces have initialized. [Defect ID 46157]
Work-aro u n d: Either remove the passive OSPF interface statements on the NBMA interfaces, or statically configure the OSPF cost on the NBMA interfaces.
When a mirror rule that triggers on username is employed for packet mirroring
of dynamic IP subscribers over ATM, removal of the rule does not disable packet mirroring. [Defect ID 175356]
Work-aro u n d: Use a mirror rule that triggers on account session ID rather than on username.
The ATM peak cell rate (PCR) does not appear in the L2TP Calling Number AVP
for the first PPP session when the ATM shaping parameters were configured by RADIUS return attributes. [Defect ID 60933]
When you issue the no atm atm1483 auto-configure upperInterfaceType
lockout-time command in Profile Configuration mode, the lockout time range
does not revert to the default values. [Defect ID 66544]
When one or more ATM1483 attributes appears in a profile, the show
configuration include-defaults command fails to display the default values for
all possible ATM1483 attributes. [Defect ID 67157]
Known Problems and Limitations 43
JUNOSe 11.1.0 Release Notes
The output of the show atm arp command displays only 4096 entries when
the line module is configured with more than 4096 NBMA ARP entries. [Defect ID 68849]
When you use the no-authenticate keyword with the subscriber command to
prevent subscriber authentication so that the subscriber information can be used for DHCP option 82, suboption 2, the SRP module can reset. This issue does not occur when you use the no-authenticate keyword with the subscriber command as a way to perform a RADIUS configuration. [Defect ID 69865]
When you perform an snmpWalk on the juniAtmSubIfVccTable, a response is
received for only a few of the total configured ATM subinterfaces when both of the following are true: the router has a line module that has some ATM-related configuration and the line module is in the disabled state. [Defect ID 80020]
The baseline interface atm command fails for a VCD assigned by the router to
F4 OAM circuits. [Defect ID 174482]
Unified ISSU is not supported when ILMI is configured on ATM interfaces.
[Defect ID 176007/177297/177122]
ATM line modules reset after unified ISSU completes at the LAC when an
MLPPP bundle with three links are tunneled to the LNS. [Defect ID 178821]
For PPPoE, the AAL5 inPacket Discards counter might increment erroneously
during call setup when a packet is passed directly to PPPoE for negotiation rather than being discarded. [Defect ID 51757]
Work-aro u n d: Incremental InPacketDiscards during call setup do not necessarily indicate a problem. However, we recommend you investigate an excessive count because that might indicate a connection that cannot be successfully brought up for some reason, such as RADIUS denials or improper configuration.
The inPacketOctetDiscards counter in the output of the show atm vc atm
interface vcd command includes both inBytesDropped and inBytesUnknownProtocol statistics. The inBytesUnknownProtocol stxatistics should be displayed by a separate counter.
At the major interface level, the inPacketDiscards counter includes both inPacketsDropped and inPacketUnknownProtocol statistics. The inPacketUnknownProtocol statistics should be displayed by a separate counter. [Defect ID 44286]
When you configure an ATM PVC where PCR = SCR and maximum burst size
is zero, the CLI returns an error indicating the burst size is invalid and it does not create the VC. [Defect ID 58357]
Work-aro u n d: Configure a CBR or a UBR plus PCR to create the circuit with the same parameters, depending on the desired priority for the traffic. CBR has a high priority and UBR plus PCR has a medium priority.
44 Known Problems and Limitations
BFD
Bridged Ethernet
CLI
Release 11.1.0
After you have shut down the interface to the next hop (for the route that is
used to establish the BFD session), output for the show bfd session command erroneously indicates the shutdown interface as Management Interface (FastEthernet 6/0). [Defect ID 174271]
The CLI erroneously permits you to configure bridge1483 encapsulation over
AAL5MUX IP even though that configuration is not supported. [Defect ID 35013]
When you issue a run show ppp command, the CLI changes the configuration
level of the command line to Global Configuration mode rather than remaining at the level from which you issued the command. [Defect ID 52165]
DHCP
Work-aro u n d: Reissue the commands necessary to reenter the desired mode.
The logout subscribers all command may not log out all of the DHCP
subscribers. Although the bindings and DHCP addresses are cleared, the show subscribers summary command may display some of the DHCP subscribers.
[Defect ID 180176]
Work-aro u n d: Try using the dhcp delete-binding all command. If this does not clear the subscribers, you may want to reload the line module to avoid further issues.
DHCP packets are not forwarded to the DHCP server over dynamically created
interfaces when all of the following are true: [Defect ID 180343]
DHCP relay or DHCP relay proxy is configured on the router.
The client-facing interfaces are created dynamically using bridged Ethernet
over static ATM PVCs.
The ip auto-detect ip-subscriber command is configured to enable packet
detection (packet triggering) and to trigger creation of dynamic subscriber interfaces.
Known Problems and Limitations 45
JUNOSe 11.1.0 Release Notes
DHCP External Server
Work-aro u n d: To avoid this defect, do all of the following:
Do not use the ip auto-detect ip-subscriber command to enable packet
triggering and to create dynamic subscriber interfaces
Ensure that DHCP external server is configured in the virtual router.
Ensure that the set dhcp relay inhibit-access-route-creation command is
configured in the virtual router to prevent DHCP relay from installing host routes by default.
With the unique client ID option enabled, when two clients with the same MAC
address or client ID are on an interface (where one client is connected over a router and relay and the other client is connected directly), sending a release request from one of the clients might terminate another client. [Defect ID 179759]
DoS Protection
The DHCP renew counter and release counter (displayed with the show ip
dhcp-external statistics command) are doubled rather than incremented for
each renew and release sent. [Defect ID 78802]
When DHCP clients on an S-VLAN over bridged Ethernet stack configuration
send a decline message to a router that has DHCP relay and DHCP external server configured in the same VR, the clients bindings are not removed from the DHCP external server. [Defect ID 87086]
When DHCP relay and DHCP external server are configured in the same VR
with server-sync enabled, bindings are not created in the DHCP external server when DHCP clients on an ATM bulk configuration interface stack and dynamic VLAN over Ethernet stack sends a renew message. [Defect ID 87087]
DHCP NAK packets are sent from a different VLAN than the one on which the
renew request is received on a router that is configured with dynamic VLANs, DHCP local server, and automatically created dynamic subscriber interfaces. This behavior occurs only after a link flap has taken place. [Defect ID 87062]
A Telnet session closes when sending ipLocalBGP protocol traffic at a rate in
the range 4096–4200 packets per second (pps) with suspicious control flow detection enabled. [Defect ID 81974]
Work-aro u n d: When the traffic drops below 4096 pps, open a new Telnet session.
46 Known Problems and Limitations
Ethernet
File System
Release 11.1.0
When autonegotiation is enabled on Gigabit Ethernet interfaces with the speed
automatically negotiate command, issuing the link selection command logs
out subscribers. [Defect ID 87185]
Work-aro u n d: Use the following commands to enable auto link selection (GE port redundancy) and to switch from one port to the other port:
(config-if)#no link selection (config-if)#link failover force
When the primary SRP module is running JUNOSe Release 7.2.0 or
higher-numbered release and the standby SRP module is running a release numbered lower than Release 7.2.0 (as in a downgrade situation), you cannot display the files for the standby SRP module. [Defect ID 74104]
Forwarding
The DoS protection egress rate is not accurate for the ES2 10G LM or the ES2
10G Uplink LM. [Defect ID 86925]
When performing MAC validation to match subscriber demux entries with ARP
host entries, the ES2 10G LM does an exact match, rather than a longest prefix match. The subscriber demux entry source address must be a /32 value matching the IP address of an ARP entry in order to validate the MAC address against that ARP entry. [Defect ID 79641]
When PPPoE over LAG is configured on an interface, and you re-execute the
PPPoE-over-LAG configuration before you delete the previous configuration, the ES2 10G LM line module resets. [Defect ID 179639]
Work-aro u n d: Before you can re-execute the PPPoE-over-LAG configuration, delete the existing PPPoE-over-LAG configuration.
VPLS forwarding does not function properly when any of the following
conditions occur: [Defect ID 79856]
MLPPP interfaces are used
L2TP is used with sequence numbers enabled
GRE is used with sequence numbers enabled
Specifying S-VLAN ranges that partially overlap does not work. [Defect ID
81918]
For example, the following configuration fails because S-VLAN 22 falls within the previously specified S-VLAN range of 21–23.
host1(config-if)#vlan bulk-config BulkDHCPCnfg1 svlan-range 21 23 401 426 host1(config-if)#vlan bulk-config BulkDHCPCnfg1 svlan-range 21 23 427 712 host1(config-if)#vlan bulk-config BulkCezarCnfg2 svlan-range 22 22 101 110
Known Problems and Limitations 47
JUNOSe 11.1.0 Release Notes
Work-aro u n d: You can do either of the following to avoid this problem.
Specify each S-VLAN within the partially overlapping range as individual
S-VLANs, as in the following example:
host1(config-if)#vlan bulk-config BulkDHCPCnfg1 svlan-range 21 21 401 426 host1(config-if)#vlan bulk-config BulkDHCPCnfg1 svlan-range 22 22 401 426 host1(config-if)#vlan bulk-config BulkDHCPCnfg1 svlan-range 23 23 401 426 host1(config-if)#vlan bulk-config BulkDHCPCnfg1 svlan-range 21 21 427 712 host1(config-if)#vlan bulk-config BulkDHCPCnfg1 svlan-range 22 22 427 712 host1(config-if)#vlan bulk-config BulkDHCPCnfg1 svlan-range 23 23 427 712 host1(config-if)#vlan bulk-config BulkCezarCnfg2 svlan-range 22 22 101 110
Use fully overlapping ranges rather than partially overlapping ranges, as in
the following example:
host1(config-if)#vlan bulk-config BulkDHCPCnfg1 svlan-range 21 23 401 426 host1(config-if)#vlan bulk-config BulkDHCPCnfg1 svlan-range 21 23 427 712 host1(config-if)#vlan bulk-config BulkCezarCnfg2 svlan-range 21 23 101 110
ICR
When you attach certain hierarchical policies to subinterfaces as input policies,
secondary input policies, and output policies, incoming traffic loss can occur when the number of subinterfaces to which the policies are attached exceeds
4600. [Defect ID 86741]
Ethernet statistics are incorrectly displayed for virtual port 8 of the ES2-S1 GE-8
IOA when that module is paired with the ES2 10G LM or the ES2 10G Uplink LM. [Defect ID 174784]
The ES2 10G LM does not support framed routes configured for dynamic
subscriber interfaces. [Defect ID 83154]
A memory leak of about two percent can occur on the ES2 10G LM and result
in a module reset when a large number of successive SRP switchovers take place with active DHCP clients. [Defect ID 86245]
On the ES2 10G LM, a VLAN ID of 0 assigned to an interface can prevent
packets from being properly forwarded. [Defect ID 176125]
If you saved the running configuration of the router as a script file (.scr) and
execute the script to apply the settings on the router, ICR partition configuration commands in the .scr file might fail to add group members to the partition. This problem happens when the subscriber configuration in the .scr file is placed before the ICR partition configuration. However, this problem does not occur if you used a system configuration (.cnf) file to set up the router. [Defect ID 183913]
48 Known Problems and Limitations
Release 11.1.0
Work-aro u n d: To correct this problem and enable ICR partitions to be created correctly, make sure that you add the ICR partition configuration before the subscriber interface configuration in the .scr file. You can perform this reordering by modifying the .scr file to place the commands that configure subinterfaces for ICR partitions before the commands used for VLAN-based or S-VLAN-based grouping of subscribers.
When you configure ICR settings using a CLI macro, ICR commands are run in
quick succession. Sometimes, in such a scenario, the active SRP module resets if the event that causes the change of state of the VRRP instance reaches the ICR application before the ICR partition has been created. [Defect ID 184095]
Work-aro u n d: To avoid this problem, add an additional delay of one second using the sleep command in the macro, before the ip vrrp vrid enable command that is written in the macro to enable VRRP instance.
For example, consider a macro that contains the following commands:
IGMP
ip vrrp vrid enable ip vrrp vrid icr-partition partitionId
Modify the macro, as follows, to add a delay of one second before the VRRP instance ID is enabled on the router and a delay of another second before the ICR partition that corresponds to the VRRP instance is created:
sleep 1 ip vrrp vrid enable sleep 1 ip vrrp vrid icr-partition partitionId
IGMPv3 proxy is not supported. [Defect ID 46038]
The E Series router IGMPv3 proxy does not operate correctly in the presence of
IGMPv2 queriers. [Defect ID 46039/46045]
Work-aro u n d: If an IGMPv2 router is present on the network, do not configure version 3 with the ip igmp-proxy version command on that network interface. (Version 2 is the default.)
The default value for the IGMPv3 proxy unsolicited report interval timer should
be 1 second rather than 10 seconds (the value for v2). [Defect ID 46040]
When more than about 100,000 mapped OIF entries are configured on a
virtual router, issuing the no virtual router command for this and other virtual routers does not delete all the virtual routers within the deletion timeout interval (3 minutes). The virtual routers do eventually delete after this timeout. [Defect ID 63882]
The E Series router does not log a warning when it receives an IGMPv2 query
but is not configured to use IGMPv2 on the interface. [Defect ID 46046]
Known Problems and Limitations 49
JUNOSe 11.1.0 Release Notes
IP
The ES2 4G LM can reset during a unified ISSU after you issue the issu start
command on a router configured with 8000 dynamic VCs and 8000 packet-triggered dynamic subscriber interfaces. [Defect ID 86761]
If you have a large configuration on a hybrid module combination (OC3/STM-1
GE/FE line module with the OC3-2 GE APS I/O module), boot from NVS, and issue the slot erase command before booting has completed, the line module resets. [Defect ID 64104]
Work-aro u n d: To recover from the error, issue the slot reload command anytime after the module begins to reset.
Deleting a VRF with 32,000 static subscriber interfaces fails to complete.
[Defect ID 82670]
Work-aro u n d: Use a macro to delete all static subscriber interfaces before you delete a VRF.
IP interface statistics become inconsistent when a slot is reset, because some
traffic (such as control traffic) might be destined for the SRP module and is therefore counted elsewhere. [Defect ID 26697]
The ip route permanent command does not work properly. [Defect ID 34303]
Work-aro u n d: Issue the ip alwaysup command to prevent the route from
being removed from the IP routing table after the interface is shut down.
Traffic statistics for dynamic subscriber interfaces associated with Mobile IP
subscribers are not maintained as the subscribers move between Mobile IP nodes. Consequently the reported interface statistics are only the values accumulated since the last time a mobile node moved. [Defect ID 174509]
When a router configured with PIM on a virtual router undergoes multiple
warm restarts, the router subsequently hangs when an IP profile is configured. [Defect ID 176470]
Logical port 20 on the ES2-S3 GE-20 IOA is reserved for the hardware multicast
packet replication feature. Logical port 20 and the hardware multicast replication feature are not supported on the ES2-S3 GE-20 IOA in this release. [Defect ID 84727]
When you change the demultiplexer type on a primary interface that has 1024
demultiplexer table entries, the ICC ping threshold times out due to the removal of the old entries and the addition of the new ones. [Defect ID 182218]
After an SRP stateful switchover completes on an ERX1410 router configured
with a single VPN routing and forwarding instance (VRF) and Network Address Translation (NAT), the SRP module that becomes active after the switchover resets. [Defect ID 180058]
50 Known Problems and Limitations
IPSec
Release 11.1.0
When the LAC–to–LNS data path runs over an MPLS tunnel and the MPLS
tunnel originates or terminates at the LAC on an ES2 10G LM or an ES2 10G Uplink LM, the L2TP data traffic that originated or terminated at the LAC is discarded. [Defect ID 87260]
In a network where you use the tunnel signalling command to specify that the
security parameters and keys are configured manually for IPSec tunnels between VRs, the line modules reset when you delete and then re-create the IPSec tunnels. If you attempt to configure the tunnels again after the modules come back up, the line modules reset again.
Work-aro u n d: Configure the IPSec tunnels to use ISASKMP/IKE to negotiate SA and establish keys. [Defect ID 178304]
IPSec tunnels created over Fast Ethernet interfaces fail to come up. [Defect ID
179256]
IS-IS
L2TP
MLD
Work-aro u n d: After you create the tunnel, bounce the tunnel interface by issuing the shutdown/no shutdown command sequence. The tunnel comes up successfully.
On a router configured with IS-IS and BFD, using the redundancy force srp
command to force an SRP switchover sometimes brings down IS-IS and BFD. [Defect ID 179287]
IS-IS graceful restart (nonstop forwarding) does not work on the broadcast
interface when the restarting router is the designated intermediate system (DIS). Graceful restart works properly when the restarting router is not the DIS. [Defect ID 61496]
After a unified ISSU completes on a router functioning as an L2TP access
concentrator (LAC), traffic outages occur on the L2TP network server (LNS)-facing interface at the LAC in a configuration with 16,000 or 32,000 L2TP sessions over 500 tunnels. [Defect ID 180147]
MLDv2 proxy is not supported. [Defect ID 46038]
The E Series router MLDv2 proxy does not operate correctly in the presence of
MLDv1 queriers. [Defect ID 46039/46045]
Work-aro u n d: If an MLDv1 router is present on the network, configure version 1 with the ipv6 mld-proxy version command on that network interface. (Version 2 is the default.)
The default value for the MLDv2 proxy unsolicited report interval timer should
be 1 second rather than 10 seconds (the value for v1). [Defect ID 46040]
Known Problems and Limitations 51
JUNOSe 11.1.0 Release Notes
MLPPP
The E Series router does not log a warning when it receives an MLDv1 query
but is not configured to use MLDv1 on the interface. [Defect ID 46046]
Failure to meet all of the following conditions for fragmented packets can result
in an incorrect operation during packet classification of the resulting reassembled packet: [Defect ID 50111]
The initial fragment of a packet must either contain the entire MLPPP
packet or be greater than 128 bytes.
The fragment size of the peer must not be lower than 128 bytes.
The initial fragment of a packet must be larger than subsequent fragments
of that packet.
Mobile IP
The clear ip mobile binding nai @realm command does not work. [Defect ID
178652]
Work-aro u n d: Use the following version of the command instead:
clear ip mobile binding nai
The @realm variable and the @ keyword alone do not work for the show ip
user@realm
mobile binding command. [Defect ID 178653]
Work-aro u n d: You can use the user@realm syntax instead to display the
binding for a specific user, as in this example:
host1#show ip mobile binding nai xyz@example.com
Alternatively, you can display the entire Mobile IP binding table by issuing the show ip mobile binding command without additional options.
The setup rate for Mobile IP client sessions decreases when you repeatedly
bring a large number of sessions down and back up. [Defect ID 178760]
When mobility bindings are present and you delete the Mobile IP home agent
with the no virtual router command, Mobile IP sends a RADIUS Acct-Stop message with no accounting statistics for the subscribers. [Defect ID 179081]
Work-aro u n d: Issue the clear ip mobile binding all command before you issue the no virtual router command. The clear command clears all the MIP subscribers and sends a RADIUS Acct-Stop message with the appropriate accounting statistics for the subscribers.
MPLS
When MPLS and IS-IS are configured on Ethernet interfaces, you cannot delete
the interface after the IP address is removed. This issue is not a problem on Ethernet VLAN interfaces. [Defect ID 66813]
52 Known Problems and Limitations
Release 11.1.0
Work-aro u n d: Issue the no mpls command to disable MPLS, then delete the interface.
You cannot use an underscore character (_) in an MPLS tunnel name. [Defect
ID 31291]
If LSPs are announced into IS-IS, then the IS-IS routes cannot be used for
multicast RPF checks, because LSPs are unidirectional. [Defect ID 28526]
Work-aro u n d: Configure static RPF routes with native hops when LSPs are autoroute announced to IGPs.
When the IPv4 explicit null label appears anywhere other than at the bottom of
the label stack, TTL expiration for this label is not handled correctly. As a result, the traceroute command does not work correctly for LSPs that have the IPv4 explicit null label anywhere other than at the bottom of the label stack. [Defect ID 76037]
Multicast
When you upgrade the router to JUNOSe Release 7.1.0 or a higher-numbered
release from a release numbered lower than Release 7.1.0, remote ATM layer 2 over MPLS circuits (also known as MPLS shim interfaces) that use Martini encapsulation are erroneously signaled with the control word attribute setting “Control word is not preferred by default”. Because control words are required for these MPLS shim interfaces, these circuits should instead be signaled with the setting “Control word is preferred by default”. [Defect ID 87048]
Work-aro u n d: To reinstate the proper setting (“Control word is preferred by default”), remove the MPLS shim interface from the ATM subinterface and then reconfigure it.
When you issue a traceroute or trace mpls command to trace the paths of
router packets over MPLS interfaces on an ES2 10G LM or ES2 10G Uplink LM, the results include an extra unknown host. [Defect ID 174537]
When you configure more than 10,219 outgoing interfaces (OIFs) on the same
ES2 10G LM in a single multicast group, the configuration of the multicast group’s OIF membership from the SRP module to the line module exceeds the size of a single message and is sent in fragments. Because of this fragmentation, the ES2 10G LM generates the following error message: [Defect ID 81768]
pc: 0x9e5c88: -> fatalPanic(void) offset: 0x8
Netflow
Flow sampling stops after a cold switchover on a router that is configured with
16 VRs and 32 interfaces per VR, when all flows are passing through the configuration (32 flows per VR). [Defect ID 74477]
Work-aro u n d: After the cold switchover is completed, reissue the ip flow-sampling-mode packet-interval 10 command on each VR, even though
the command is present in the configuration.
Known Problems and Limitations 53
JUNOSe 11.1.0 Release Notes
Policy Management
The OC3/STM1 GE/FE line module might reset after sending Ethernet traffic
into a VPLS network in a test environment when Ethernet packets are flooded to remote VPLS bridges. [Defect ID 74540]
On the E320 router, redirecting a large configuration with thousands of
interfaces to a script file can take a long time, perhaps exceeding a half-hour depending on the configuration. [Defect ID 80429]
When you attach a policy to an interface and the policy contains a classifier
rule that is unsupported for that interface, the CLI generates a message and the policy is applied. However, if an existing policy is already attached to that interface, then support for the new policy is not checked and the invalid policy is applied to the interface without warning. The results of this attachment are not predictable. [Defect ID 83562]
If you have removed the last rule in a policy list, the router generates a warning
only after you exit Policy List Configuration mode. If you have removed the last policy rule and then added a classifier group before you exit Policy List Configuration mode, the router does not generate a warning about removing the last rule. [Defect ID 83834]
When an MD-Port-Number value greater than 65,535 is sent to an E120 or
E320 router by means of a COA request, the value that is displayed in the UDP header of mirrored packets is the actual value minus 65,536. For example, an MD-Port-Number of 65,540 is displayed in the mirrored packet as 4. [Defect ID 84712]
On the E120 and E320 routers, when a mirror rule is deleted after a CoA
request is sent with Juniper-LI-Action set to No-Action, the existing mirroring session is not disabled. [Defect ID 84826]
No logs are created if you use the policy-list option with the log severity
severityValue policyMgrPacketLog policy-list policyListName command when logging policyMgrPacketLog events. [Defect ID 87203]
When you reload the slot holding a GE-2 or GE-HDE line module and you have
configured more than about 2000 policies with rate limiting on that module, the drop count becomes more than expected. This unexpected drop count does not occur when you create the same configuration after you reload the router to the factory-default configuration. [Defect ID 175696]
On E320 line modules that support secure policies, the SRP module enables
you to configure more than 1022 secure policies per module. [Defect ID 175756]
Work-aro u n d: To avoid potential performance issues, we recommend that you do not configure more than 1022 secure policies per module.
Unified in-service software upgrade (unified ISSU) is not supported on an E120
or E320 router if a hierarchical policy is attached to an external parent group. [Defect ID 177478]
54 Known Problems and Limitations
Release 11.1.0
When you modify a rate-limit profile in Global Configuration mode after the
system is in a scaled state, changes to the rate-limit profile fail owing to lack of adequate policy resources. However, the changed value of the rate-limit profile is displayed in the output of the show rate-limit profile command. [Defect ID 79342]
Work-aro u n d: To avoid this problem, do not update the rate-limit profile in Global Configuration mode in a scaled environment.
When you enter the no ip policy-parameter hierarchical parameterName
command or no ipv6 policy-parameter hierarchical parameterName command for a hierarchical policy-parameter type in Interface Configuration mode, the explicit reference of the parameter is removed successfully from the interface. However, the Referenced by interfaces field in the output of the show policy-parameter command does not change from the previously configured value to implicit. [Defect ID 183957]
Work-aro u n d: To correct this problem, remove the entire interface configuration.
PPPoE
QoS
The E Series router erroneously accepts a PADI with a payload length of 0
instead of rejecting it and incrementing the PPPoE Invalid PAD packet length counter. [Defect ID 48356]
You cannot paste a load-rebalance command string that uses the percent
option into a console or Telnet session from show configuration output because the output displays the % sign rather than the percent keyword that was submitted with the command and the percent sign is not recognized by the CLI. [Defect ID 81705]
The router cannot resolve inconsistent requests caused by two QoS profiles
that modify the same scheduler property inconsistently. [Defect ID 61485]
Work-aro u n d: Avoid using two QoS profiles that modify the same scheduler property inconsistently, such as setting different values for the shaping rate for the same S-VLAN node.
When you perform an SNMP walk of the juniQosQueueStatistics MIB, a timeout
of up to 5 minutes ensues, during which the SRP module CPU utilization goes to 100 percent. [Defect ID 62252]
The compound shared shaping feature does not work properly on egress
forwarding ASIC 2 (EFA2)-based ATM line modules when the shared shaper is queue-controlled as opposed to node-controlled. In a node-controlled configuration, in which you configure the shared-shaping rate on the best-effort scheduler node for the logical interface, integration of the EFA2 and ATM segmentation and reassembly (SAR) schedulers functions properly. However, in a queue-controlled configuration, in which you configure the shared-shaping rate on the best-effort queue for the logical interface, integration of the EFA2 and ATM SAR schedulers does not function properly. [Defect ID 69167]
Known Problems and Limitations 55
JUNOSe 11.1.0 Release Notes
Work-aro u n d: Use node-controlled compound shared shaping configured on the best-effort scheduler node with EFA2-based ATM line modules.
Egress strict-priority packets may experience high latency on OC3/STM1 ATM
interfaces associated with the LM if you have shaped the port rate to more than
148.5 Mbps. [Defect ID 80378]
Work-aro u n d: To ensure low strict-priority latency, shape the port rate to no more than 148.5 Mbps.
An error message regarding the qos-parameter instance
QosParameterDefinition is erroneously generated on an ERX1440 router when it is configured for L2C and QoS RAM and receives TLV 144 (DSL Type). The parameter instantiation actually functions properly. [Defect ID 80620]
The CLI erroneously enables you to configure a QoS profile with the ethernet
node group command. [Defect ID 80861]
The dynamic shaping rate calculated by the simple shared shaper can vary
because of the variation in the enqueue rate of the constituent queues. Even when the offered load is constant, the mechanism that calculates the enqueue rate introduces a slight variation, introducing a slight variation in the calculated dynamic shaping rate. [Defect ID 80938]
On a router that has both an ES2 10G LM and an ES2 4G LM installed, the byte
count reported by the show fabric-queue egress-slot command is incorrect. The reported packet count is correct. [Defect ID 80965]
On the E120 and E320 routers, you cannot attach QoS profiles to L2TP tunnels
by means of the CLI because the CLI does not pass the router ID to QoS. [Defect ID 81516]
PPP sessions may be dropped if you change the shaping rate in a QoS profile
that affects thousands of circuits while QoS traffic affected by the profile is being forwarded. [Defect ID 82950]
Work-aro u n d: Do not change the shaping rate in a QoS profile that affects thousands of circuits while QoS traffic is using the profile.
Egress traffic may be dropped on OC12/STM4 ATM interfaces if you have
shaped the port rate to more than 542 Mbps. [Defect ID 83785]
Work-aro u n d: Do not exceed a shaped port rate of 542 Mbps.
Incorrect output is sent to the CLI the first time you enter Global Configuration
mode or issue the show subscribers command after viewing the VLAN subinterface over which a subscriber is connected. [Defect ID 84507]
When QoS resources such as failure nodes and statistics bins are exhausted
because of insufficient memory available on the line module, the failures are properly logged, but additional log messages are generated every 10 minutes that report zero failures. [Defect ID 85105]
56 Known Problems and Limitations
Release 11.1.0
The no qos-parameter-define definition command does not delete the
specified QoS parameter definition. [Defect ID 176844]
Work-aro u n d: Remove the interface and add the desired QoS parameters when you re-create the interface instead of deleting the definition.
When 32,000 subscribers with 128,000 QoS queues are brought up on an ES2
10G or ES2 10G ADV LM, the LM resets if you modify the QoS profile that contains the best-effort IP or VLAN node rule, which references a scheduler profile configured with shared shaping rate, to a scheduler profile configured with legacy shaping rate. [Defect ID 183291]
Work-aro u n d: To avoid this problem, apply shared shaping on the best-effort queue, instead of on the best-effort node.
Simple shared shaping does not function correctly when it is used for 32,000
subscribers on an ES2 10G ADV LM. However, when you change the shaper to compound shared shaping, it works properly. Also, simple shared shaping does not function correctly for 16,000 subscribers on an ES2 10G ADV LM. [Defect ID 183512]
RSVP-TE
When you configure an E120 or E320 router with an ES2 10G ADV LM as a LAC
on one side of an L2TP tunnel and as a LNS to receive packets from the LAC on the other side of the tunnel, use RADIUS servers for authentication of subscribers on both sides of the tunnel, and attempt to bring up 16,000 subscribers on the L2TP tunnel, the LM that has subscribers on the LAC side of the tunnel resets when approximately 8000 logged-in subscribers are logged out and try to reestablish the connection. [Defect ID 184118]
After stateful SRP switchover, forwarding of VPN traffic might not resume if the
core interface that carries an MPLS base tunnel with LDP over RSVP-TE flaps (constantly goes up and down). [Defect ID 182019]
Known Problems and Limitations 57
JUNOSe 11.1.0 Release Notes
Service Manager
After you activate an independent IPv6 service and issue either of the following
commands on the default virtual router or any other virtual router, except the one on which the subscriber session is active, no output is displayed in the CLI interface: [Defect ID 181929]
show service-management subscriber-session subscriberName interface
interfaceType interfaceSpecifier
show service-management subscriber-session subscriberName interface
interfaceType interfaceSpecifier service-session serviceName
This problem also occurs when a subscriber is authenticated using a RADIUS server for a combined IPv4 and IPv6 service in a dual stack.
Work-aro u n d: To avoid this problem, use the show service-management owner-session ownerName ownerId command to display subscriber session information based on the session owner, instead of the show service-management subscriber-session subscriberName interface
interfaceType command to display details on subscriber sessions.
SNMP
When you configure the router with an address pool that has two IP address
ranges, only the range that you configured first is available via the MIB. [Defect ID 61232]
SONET
You cannot use the highest sensitivity bit-error rate setting (a value of 9)
associated with APS/MSP alarm when you issue the threshold sd-ber command to configure a cOCx/STMx line module with cOC12-APS-capable IOAs. [Defect ID 72861]
Work-aro u n d: Use only a value in the range 5–8 when you issue the threshold sd-ber command for this module combination, as in the following example:
host1(config)#controller sonet 2/1 host1(config-controll)#aps group boston host1(config-controll)#aps protect host1(config-controller)#threshold sd-ber 6
SRC Software and SDX Software
The SRC client does not prevent you from changing the name of the router
while the client is connected to the SAE, resulting in SAE issues such as lost IP addresses and stale users. [Defect ID 77102]
Work-aro u n d: To change the router name while the SRC client is connected to the SAE, shut down the SRC client, change the name, then re-enable the SRC client.
When multiple IPv6 interfaces are configured with policies attached from SRC,
only some of the IPv6 interfaces have the policies attached. [Defect ID 179498]
58 Known Problems and Limitations
Changing the SSCC status (enable/disable) while IPv6 interfaces are configured
might cause the SRP to reset. [Defect ID 179537]
Stateful SRP Switchover (High Availability) and IP Tunnels
When you issue show commands as soon as the CLI is available after a stateful
SRP switchover, the commands can hang until the warm restart is completed. [Defect ID 85306]
A packet loss sometimes occurs during stateful SRP switchover when you use
the ping command on a router that is configured for OSPF graceful restart, and is connected to a helper router in the OSPF IPv6 broadcast network and another helper router in the OSPF IPv6 backbone area. [Defect ID 181470]
ERX7xx model, ERX14xx model, or ERX310 router:
When you use the ping command with the IPv6 address of the helper
router in the multicast area as the destination address and the
loopback address of the helper router in the backbone area as the
source address, a packet loss of 2 seconds occurs for the first stateful
SRP switchover. However, no packet loss occurs for successive stateful
SRP switchovers.
Release 11.1.0
Subscriber Management
When a dynamic GRE tunnel interface for Mobile IP relocates between SM
When a subscriber has subscribed for a service, service session accounting
When you use the ping command with the IPv6 address of the helper
router in the broadcast network as the destination address and no
source address when stateful SRP switchover is performed the first
time, an identical packet loss occurs. In this case too, no packet loss
occurs during subsequent switchovers.
E120 router or E320 router
When you use the ping command with the IPv6 address of the helper
router in the broadcast network as the destination address and the
loopback address of the helper router in the backbone area as the
source address, no packet loss occurs.
When you use the ping command with the IPv6 address of the helper
router in the multicast area as the destination address and no source
address, a packet loss of 1–2 seconds sometimes occurs during stateful
SRP switchovers.
modules because the original SM reloads, Mobile IP deletes the relocated tunnel interface. [Defect ID 178399]
records always contains a default Acct-Terminate-Cause value of 10. This value remains unchanged even after you use the terminate-code command to configure a custom mapping between application terminate reasons and RADIUS Acct-Terminate-Cause attributes. [Defect ID 181043]
Dynamic subscriber interfaces continue to remain in the down or not present
operational state in either of the following scenarios: [Defect ID 81269]
Known Problems and Limitations 59
JUNOSe 11.1.0 Release Notes
If you configured a dynamic interface column, such as a dynamic bridged
Ethernet interface, dynamic VLAN interface, or an ATM interface, and when any one of the following conditions is satisfied:
The major interface is bounced (shut down and reenabled)
The major interface is shut down, which cause the dynamic VLAN
interfaces to be removed
The physical link goes down and comes back up
The line module is removed and reinserted
If you configured a static interface column and removed the major
interface
These scenarios might occur if you administratively issue the shutdown and no shutdown commands on the major interface in which the dynamic interface column is configured.
System
Work-aro u n d: Use the no interface ip ipAddress command to remove the dynamic subscriber interfaces. Although you can use the dhcp delete-binding command to remove the DHCP binding and the dynamic subscriber interfaces, the DHCP client does not detect the binding removal and retains the lease.
You cannot use a configuration script to boot the E320 router. [Defect ID
80304]
If you hot swap an IOA and then remove it again before that IOA’s OK or FAIL
LED is illuminated, the associated line module can reset. [Defect ID 177313/177267]
Work-aro u n d: Ensure that you firmly insert the IOA into the chassis when you hot swap IOAs. Do not attempt a second hot swap of an IOA that has not indicated that it completed the first hot swap cycle. You can remove the IOA when either its OK or FAIL LED is illuminated.
If your router is in Manual Commit mode, then you must issue the write
memory command before you perform an SRP module switch or a manual
reload. You must do this even when you have made no changes to the system configuration and the file systems are synchronized. [Defect ID 44469]
When you configure, delete, or reconfigure an IPv4 prefix object, the VRRP
states and priorities of interfaces of virtual routers are displayed incorrectly in the output of the show ip vrrp command. This problem occurs when both the following conditions are satisfied: [Defect ID 186258]
Alternatively enabling and disabling the priority of a virtual router ID from
The master router also operates as the IP address owner
60 Known Problems and Limitations
changing in response to the object state change using the ip vrrp track and no ip vrrp track commands
System Logging
TCP
Release 11.1.0
The show configuration category management syslog virtual-router default
command incorrectly displays logs for multiple syslog destinations when you add a log to only one syslog destination. The show log configuration command shows the correct configuration. [Defect ID 84082]
The SRP module resets in any of the following circumstances on an E320
router that has a line module configured with 5000 ANCP adjacencies: [Defect ID 176916]
When you issue the issu initialization command from the console and
then reload the line module from a Telnet session.
When the client that has the 5000 ANCP clients resets or an intermediate
switch resets.
Unified ISSU
When you reload the line module.
ATM line modules might reset after a unified ISSU when you attempt to add
memory to a VLAN subinterface in a large bridged Ethernet configuration. [Defect ID 178798]
Under certain conditions, a unified ISSU from JUNOSe Release 9.2.0p1-0 to the
current release fails, and causes the SRP module and the ES2 4G LM to reset. [Defect ID 179975]
When any of the subsystems is excluded for a JUNOSe release, a unified ISSU
to that release fails to apply conversion code to all of the line modules. As a result, the line modules reset when they come up with that release. [Defect ID 179595]
Work-aro u n d: To prevent the exclusion of a subsystem file from the release, do the following before you upgrade to a new JUNOSe release that supports unified ISSU:
1. Issue the show subsystems file fileName.rel command, where fileName is the name of the software release file, to determine whether any of the subsystem files are excluded from the release.
2. For each subsystem file that is excluded, issue the no exclude-subsystem subsystemName command to remove the exclusion for the specified subsystem file.
If you copied the software release to the router before removing the subsystem file from the exclusion list, you must copy the release to the router again to ensure that all subsystem files are included in the release.
Unified ISSU is not supported with 8000 bridged Ethernet interfaces on an
OC3/STM1 GE/FE ATM line module. [Defect ID 178811/178797/ 179547]
Known Problems and Limitations 61
JUNOSe 11.1.0 Release Notes
During the unified ISSU operation, if you modify the router configuration after
the initialization phase of the process is completed and before you issue the issu start command to commence the upgrade phase of the unified ISSU process, the unified ISSU procedure completes successfully and the stateful SRP switchover process begins to synchronize between the active and standby SRP modules. When the synchronization process is in progress, the standby SRP module reloads for the second time. After the second reload of the standby SRP module ends, the synchronization process also ends properly.
Although the standby SRP module reloads for the second time when it is synchronized with the upgraded release, normal router operations, such as handling of subscriber sessions and forwarding of traffic, remain unaffected. [Defect ID 185517]
62 Known Problems and Limitations
Resolved Known Problems
Release 11.1.0 is based on Release 11.0.0 and incorporates all problem resolutions found in that release. The following problems were reported open in Release 11.0.0 and have been resolved in this release, or have been resolved since the 11.0.0 release. For more information about particular resolved problems, you can log in to the JUNOSe Knowledge Base at https://www2.juniper.net/kb/, enter the defect ID number in the Search by Keyword field, and click Search.
IP
After you remove a virtual router configured with an SRC client, which is
enabled to support policies on IPv6 interfaces, the primary SRP module on an E320 router resets. Also, if you perform a warm restart of an ERX1440 router that contains a virtual router, which is configured to support policies on L2TP interfaces, the primary SRP module resets. [Defect 184120]
Although the IP access-internal route is deleted from the routing table after you
issue the shutdown command on a major PPP interface, or after you issue the logout subscribers all command and the subscribers try to log in again,
logging in of PPP subscribers fails. This problem occurs because the AAA server that authenticates subscribers responds with a message that access is denied owing to detection of duplicate addresses. Also, the
address detected
that you can view from the output of the show log command. [Defect ID 185109]
Release 11.1.0
access denied: duplicate
message is recorded in the aaaUserAccess event log category
Resolved Known Problems 63
JUNOSe 11.1.0 Release Notes
Errata
This section identifies errors found in the JUNOSe documentation. These errors are corrected in subsequent releases of the affected documentation.
The Policy and QoS Maximums (for E120 and E320 routers) table in JUNOSe
Release Notes, Appendix A, System Maximums for Releases 9.x, 10.x, and 11.0.x
incorrectly states that the maximum number of policy classification (CLACL) entries for the ES2 10G Uplink LM is 131,171.
The correct limit for CLACL entries for the ES2 10G Uplink LM in these releases is 65,535.
64 Errata
Appendix A
System Maximums
This appendix presents current system maximums for various E Series hardware configurations. An E Series router does not simultaneously support all maximum configurations.
For some entries, early field trial (EFT) values are presented in addition to supported values. These values have not been fully qualified by Juniper Networks and are mentioned only for field test purposes in this release. EFT values are enclosed within parentheses with an EFT designation; for example, (96,000 EFT).
Modules referred to in the tables are identified by their physical label. For module specifications, including their identifying labels, see ERX Module Guide, Table 1, Module Combinations and E120 and E320 Module Guide, Table 1, Modules and IOAs.
System Maximums for ERX310, ERX7xx, and ERX14xx
General router values General System Maximums on page 66
Physical layer values Physical and Logical Density Maximums on page 67
Link layer values Link Layer Maximums on page 70
Routing protocol and performance values Routing Protocol Maximums on page 75
Policy and QoS values Policy and QoS Maximums on page 79
Tunneling values Tunneling Maximums on page 82
Subscriber management values Subscriber Management Maximums on page 84
Section
System Maximums for E120 and E320 Routers
General router values General System Maximums on page 87
Physical layer values Physical and Logical Density Maximums on page 88
Link layer values Link Layer Maximums on page 90
Routing protocol and performance values Routing Protocol Maximums on page 96
Policy and QoS values Policy and QoS Maximums on page 99
Tunneling values Tunneling Maximums on page 103
Subscriber management values Subscriber Management Maximums on page 105
Section
65
JUNOSe 11.1.0 Release Notes
ERX310, ERX7xx, and ERX14xx System Maximums
The following tables provide system maximums for the ERX310, ERX7xx, and ERX14xx routers.
General System Maximums
Table 1 lists some general system maximums for the ERX routers.
Table 1: General System Maximums
ERX705 and
Feature ERX310
Fabric size 10 Gbps 5 or 10 Gbps 10 Gbps 40 Gbps
Chassis per 7-foot rack 14 6 3 3
NTP clients 1000 1000 1000 1000
NTP servers 300 300 300 300
Sessions per chassis (simultaneous Telnet + FTP + SSH, in any combination)
Virtual routers per chassis 1000 1000 1000 1000
Virtual routers per line module ASIC 1000 1000 1000 1000
ICR Partitions per chassis 640 640 640 640
ICR Partitions per line module 64 64 64 64
30 30 30 30
ERX710
ERX1410 ERX1440
66 ERX310, ERX7xx, and ERX14xx System Maximums
Physical and Logical Density Maximums
Table 2 lists physical and logical density maximums for the ERX routers. The following notes are referred to in Table 2:
1. Wire rate indicates the port density that supports maximum (wire-rate) performance. Oversubscribed indicates the port density possible when you are willing to accept less than wire-rate performance by oversubscribing the available fabric bandwidth. The ERX310 and ERX1440 routers do not support oversubscription; port densities for these models indicate wire-rate performance.
2. When you pair the GE-2 or GE-HDE line module with the GE-2 SFP I/O module on the ERX1440 router, you can terminate up to 24 Gigabit Ethernet interfaces. Slots 2 and 4 on the ERX1440 router support two Gigabit Ethernet interfaces at wire rate; the remaining 10 slots support one Gigabit Ethernet interface at wire rate. On the ERX310 router, all four ports (active and redundant) are at wire rate.
Appendix A: System Maximums
For more information about bandwidth and line-rate considerations for the GE-2 line module or the GE-HDE line module and their corresponding I/O modules on E Series routers, see JUNOSe Physical Layer Configuration Guide, Chapter 5, Configuring Ethernet Interfaces.
3. When you pair the GE-HDE line module with the GE-8 I/O module on the ERX1440 router, you can terminate up to 96 Gigabit Ethernet interfaces. Slots 2 and 4 on the ERX1440 router support two Gigabit Ethernet interfaces at wire rate; the remaining 10 slots support one Gigabit Ethernet interface at wire rate. On the ERX310 router, only two Gigabit Ethernet interfaces per slot are at wire rate; therefore, only four Gigabit Ethernet interfaces are at wire rate for the entire router.
For more information about bandwidth and line-rate considerations for the GE-HDE line module and the GE-8 I/O module on E Series routers, see JUNOSe Physical Layer Configuration Guide, Chapter 5, Configuring Ethernet Interfaces.
4. The OC3/STM-1 GE/FE line module and OC3-2 GE APS I/O module combination does not support line rate for Gigabit Ethernet interfaces.
Table 2: Physical and Logical Density Maximums
Feature ERX310
Physical density wire rate/oversubscribed
(See Note 1 on page 67.)
Channelized OC3 ports per chassis (cOC3 STM1 FO I/O modules)
Channelized OC12 ports per chassis (cOC12 STM4 FO I/O modules)
Channelized T3 ports per chassis (CT3/T3 12 I/O modules)
E3 (unchannelized) ports per chassis (CT3/T3 12 I/O modules)
8 16/20 32/48 48
2 4/5 4/12 12
24 48/60 96/144 144
24 48/60 96/144 144
ERX705 and ERX710
ERX1410 ERX1440
ERX310, ERX7xx, and ERX14xx System Maximums 67
JUNOSe 11.1.0 Release Notes
Table 2: Physical and Logical Density Maximums (continued)
Feature ERX310
Fast Ethernet (10/100) ports per chassis (FE-8 I/O and FE-8 SFP I/O modules)
Gigabit Ethernet ports per chassis (GE I/O modules)
Gigabit Ethernet ports per chassis (GE-2 SFP I/O modules)
(See Note 2 on page 67.)
Gigabit Ethernet ports per chassis (GE-8 I/O modules)
(See Note 3 on page 67.)
Gigabit Ethernet ports per chassis (OC3-2 GE APS I/O module)
(See Note 4 on page 67.)
OC3/STM-1 ATM ports per chassis (OC3-4 I/O modules)
OC3/STM-1 ATM ports per chassis (OC3-2 GE APS I/O module)
OC3/STM-1 POS ports per chassis (OC3-4 I/O modules)
OC12/STM-4 ATM ports per chassis (OC12 STM4 I/O modules)
OC12/STM-4 POS ports per chassis (OC12 STM4 I/O modules)
OC48/STM16 POS ports per chassis (OC48 FRAME I/O modules); ERX1440 router only
T3 (unchannelized) ports per chassis (4xDS3 ATM I/O modules)
T3 (unchannelized) ports per chassis (CT3/T3 12 I/O modules)
ERX705 and ERX710 ERX1410 ERX1440
16 32/40 32/96 96
2 4/5 4/12 12
4 14/24
4/16 14/96
2 4/5 4/12 12
8 16/20 32/48 48
4 10 24 24
8 16/20 16/48 48
2 4/5 8/12 12
2 4/5 4/12 12
–––2
8 16/20 32/48 48
24 48/60 96/144 144
Logical density per chassis
Logical E1s per chassis 504 1260 3024 3024
Logical E3s per chassis 24 60 144 144
Logical fractional E1s (DS0) per chassis 4000 10,000 24,000 24,000
Logical fractional T1s (DS0) per chassis 4000 10,000 24,000 24,000
Logical OC3/STM1 per chassis 8 20 48 48
Logical OC12/STM4 per chassis 2 5 12 12
Logical OC48/STM16 per chassis (ERX1440 router only)
Logical T1s per chassis 672 1680 4032 4032
Logical T3s per chassis 24 60 144 144
68 ERX310, ERX7xx, and ERX14xx System Maximums
–––2
Appendix A: System Maximums
Table 2: Physical and Logical Density Maximums (continued)
ERX705 and
Feature ERX310
Logical density per module combination (specified line module and all supported I/O modules)
Logical E1s per cOCx/STMx F0 line module 252
63 per OC3/STM1
Logical E3s per COCX-F3 line module 12 12 12 12
Logical fractional E1s (DS0) per cOCx/STMx F0 line module
Logical fractional T1s (DS0) per cOCx/STMx F0 line module
Logical fractional T1s (DS0) per CT3/T3-F0 line module 1992
Logical fractional T3s (DS3) per COCX-F3 line module 12 12 12 12
Logical T1s per cOCx/STMx F0 line module 336
Logical T1s per CT3/T3-F0 line module 336
Logical T3s per COCX-F3 line module 12 12 12 12
Logical T3s per cOCx/STMx F0 line module 12
Logical T3s per CT3/T3-F0 12 12 12 12
Logical T3s per OCx/STMx/DS3-ATM line module with 4xDS3 ATM I/O module
2000
500 per OC3/STM1
2000
500 per OC3/STM1
166 per T3
84 per OC3/STM1
28 per T3
3 per OC3/STM1
4444
ERX710 ERX1410 ERX1440
252
63 per OC3/STM1
2000
500 per OC3/STM1
2000
500 per OC3/STM1
1992
166 per T3
336
84 per OC3/STM1
336
28 per T3
12
3 per OC3/STM1
252
63 per OC3/STM1
2000
500 per OC3/STM1
2000
500 per OC3/STM1
1992
166 per T3
336
84 per OC3/STM1
336
28 per T3
12
3 per OC3/STM1
252
63 per OC3/STM1
2000
500 per OC3/STM1
2000
500 per OC3/STM1
1992
166 per T3
336
84 per OC3/STM1
336
28 per T3
12
3 per OC3/STM1
ERX310, ERX7xx, and ERX14xx System Maximums 69
JUNOSe 11.1.0 Release Notes
Link Layer Maximums
Table 3 lists link layer maximums for the ERX routers. The following notes are referred to in Table 3:
1. The ERX1440 router supports a maximum of 48,000 interface columns of all types combined. You can use either all dynamic interfaces or a combination of dynamic and static interfaces to achieve this maximum. For bridged Ethernet, IP network, and PPP interfaces, the ERX1440 router supports a maximum of 32,000 static major interfaces. Although the ERX1440 router supports a maximum of 48,000 static major interfaces for PPPoE, the PPPoE static limit is enforced at the subinterface level, which has a limit of 32,000.
The ERX705, ERX710, and ERX1410 routers support a maximum of 32,000 interfaces of all types combined; the ERX310 router supports a maximum of 16,000 interfaces of all types combined. For these routers, the interfaces can be any combination of dynamic or static.
The JUNOSe Software supports up to 10,000 PPP interfaces with EAP authentication negotiation configured. Performance and scalability is unchanged when EAP is not configured.
2. The total maximum number of Ethernet subinterfaces that can be active at any one time on an ERX310 router, an ERX7xx router, or an ERX14xx router is limited by the number of slots per chassis. Of this total, you can configure all single-tagged VLAN subinterfaces, all double-tagged S-VLAN subinterfaces, or a combination of both VLAN subinterfaces and S-VLAN subinterfaces to achieve this maximum.
Table 3: Link Layer Maximums
ERX705 and
Feature ERX310
ARP entries per line module
Dynamic ARP entries 32,768 32,768 32,768 32,768
Static ARP entries 32,768 32,768 32,768 32,768
Total ARP entries 32,768 32,768 32,768 32,768
ATM bulk configuration VC ranges per chassis 300 300 300 300
ATM bulk configuration VC ranges per line module 300 300 300 300
ERX710 ERX1410 ERX1440
ATM bulk configuration total VCs per chassis 64,000 160,000 384,000 384,000
ATM bulk configuration total VCs per line module
OCx/STMx/DS3-ATM 32,000 32,000 32,000 32,000
OC3/STM1 GE/FE 32,000 32,000 32,000 32,000
70 ERX310, ERX7xx, and ERX14xx System Maximums
Appendix A: System Maximums
Table 3: Link Layer Maximums (continued)
ERX705 and
Feature ERX310
ATM bulk configuration overriding profile assignments per chassis
ATM VCs per chassis (active/configured) 16,000/32,000 32,000/64,000 32,000/64,000 48,000/96,000
ATM VCs per line module
OCx/STMx/DS3-ATM (active/configured) 8000/16,000 8000/16,000 8000/16,000 8000/16,000
OC3/STM1 GE/FE (active/configured) 8000/16,000 8000/16,000 8000/16,000 8000/16,000
ATM V Cs pe r por t
OCx/STMx/DS3-ATM (active/configured) 8000/16,000 8000/16,000 8000/16,000 8000/16,000
OC3/STM1 GE/FE (active/configured) 8000/16,000 8000/16,000 8000/16,000 8000/16,000
100 100 100 100
ERX710 ERX1410 ERX1440
ATM VC classes per chassis 100 100 100 100
ATM VP/VC addresses per line module
OCx/STMx/DS3-ATM 20-bit 20-bit 20-bit 20-bit
OC3/STM1 GE/FE 20-bit 20-bit 20-bit 20-bit
ATM VP tunnels per port, all supported modules 256 256 256 256
Bridged Ethernet interfaces per chassis
(See Note 1 on page 70.)
Bridged Ethernet interfaces per line module
OCx/STMx/DS3-ATM 8192 8192 8192 8192
OC3/STM-1 GE/FE 8192 8192 8192 8192
Dynamic interfaces
Active autosensed dynamic interface columns per chassis over static or dynamic (bulk) ATM1483 subinterfaces
16,000 32,000 32,000 48,000
16,000 32,000 32,000 48,000
Ethernet 802.3ad Link Aggregation
Links per LAG (bundle) 8888
LAGs (bundles) per chassis 64 64 64 64
Ethernet S-VLANs per chassis
(See Note 2 on page 70.)
32,768 81,920 96,000 96,000
ERX310, ERX7xx, and ERX14xx System Maximums 71
JUNOSe 11.1.0 Release Notes
Table 3: Link Layer Maximums (continued)
ERX705 and
Feature ERX310
Ethernet S-VLANs per I/O module
FE-8 I/O and FE-8 SFP I/O 16,384 16,384 16,384 16,384
GE I/O 16,384 16,384 16,384 16,384
GE-2 SFP I/O 16,384 16,384
GE-8 I/O 16,384 16,384
OC3-2 GE APS I/O 16,384 16,384 16,384 16,384
ERX710 ERX1410 ERX1440
Ethernet VLANs per chassis
(See Note 2 on page 70.)
Ethernet VLANs per I/O module (no more than 4096 VLANs per por t)
FE-8 I/O and FE-8 SFP I/O 8192 8192 8192 8192
GE I/O 4096 4096 4096 4096
GE-2 SFP I/O 8192 8192
GE-8 I/O 16,384 16,384
OC3-2 GE APS I/O 4096 4096 4096 4096
Ethernet VLAN bulk configuration VLAN ranges per chassis
Ethernet VLAN bulk configuration VLAN ranges per line module
Ethernet VLAN overriding profile assignments per chassis
Ethernet VRRP VRIDs per line module ASIC 800 800 800 800
32,768 81,920 96,000 96,000
300 300 300 300
300 300 300 300
200 200 200 200
Frame Relay virtual circuits per chassis 2000 5000 12,000 12,000
Frame Relay virtual circuits per line module
COCX-F3 1000 1000 1000 1000
cOCx/STMx F0 1000 1000 1000 1000
OC48 (ERX1440 router only) –––1000
Frame Relay virtual circuits per port
COCX-F3 1000 1000 1000 1000
cOCx/STMx F0 1000 1000 1000 1000
OC48 (ERX1440 router only) –––1000
72 ERX310, ERX7xx, and ERX14xx System Maximums
Appendix A: System Maximums
Table 3: Link Layer Maximums (continued)
ERX705 and
Feature ERX310
HDLC interfaces per chassis 4000 10,000 24,000 24,000
HDLC interfaces per line module
COCX-F3 12121212
cOCx/STMx F0 2000 2000 2000 2000
CT3/T3 F0 1992 1992 1992 1992
OCx/STMx/DS-3 ATM 8000 8000 8000 8000
OCx/STMx POS 4444
OC48 (ERX1440 router only) –––1
MLFR bundles per chassis 5000 5000 5000 5000
ERX710 ERX1410 ERX1440
MLFR bundles per line module Bundles per line module are limited only by the
availability of interface columns on the module. Because a bundle requires at least one interface column, the number of bundles cannot exceed the number of interface columns.
MLPPP bundles per chassis 12,000 12,000 12,000 12,000
MLPPP bundles per line module The maximum number of MLPPP bundles supported per line
module is the lesser of the maximum number of MLPPP bundles supported per chassis or of the maximum number of interfaces supported on the line module. For more information, see the JUNOSe Link Layer Configuration Guide.
PPP interfaces per chassis
(See Note 1 on page 70.)
PPP interfaces per line module
COCX-F3 12121212
cOCx/STMx FO 2000 2000 2000 2000
GE/FE 8000 8000 8000 8000
GE-2 8000 8000
GE-HDE 8000 8000
OCx/STMx/DS-3 ATM 8000 8000 8000 8000
OC3/STM-1 GE/FE 8000 8000 8000 8000
OCx/STMx POS 4444
OC48 (ERX1440 router only) –––1
16,000 32,000 32,000 48,000
ERX310, ERX7xx, and ERX14xx System Maximums 73
JUNOSe 11.1.0 Release Notes
Table 3: Link Layer Maximums (continued)
ERX705 and
Feature ERX310
PPP packet logging
Aggregate dynamic and static PPP interfaces for which you can log PPP packets per chassis
PPPoE service name tables
PPPoE service name tables per chassis 16161616
Service name tags per PPPoE service name table (including one empty service name tag)
PPPoE subinterfaces
Subinterfaces per chassis
(See Note 1 on page 70.)
Subinterfaces per GE/FE line module 8000 8000 8000 8000
Subinterfaces per GE-2 line module 8000 8000
Subinterfaces per GE-HDE line module 8000 8000
Subinterfaces per OCx/STMx/DS-3 ATM line module 8000 8000 8000 8000
Subinterfaces per OC3/STM-1 GE/FE line module 8000 8000 8000 8000
32 32 32 32
17 17 17 17
16,000 32,000 32,000 48,000
ERX710 ERX1410 ERX1440
Transparent bridging and VPLS
Bridge groups or VPLS instances per chassis 1024 1024 1024 1024
Bridge interfaces per line module in bridge groups or VPLS instances
Bridge interfaces per chassis in bridge groups or VPLS instances
Learned MAC address entries combined for all bridge groups and VPLS instances on a chassis
8000 8000 8000 8000
16,000 32,000 32,000 32,000
64,000 64,000 64,000 64,000
74 ERX310, ERX7xx, and ERX14xx System Maximums
Routing Protocol Maximums
Table 4 lists routing protocol maximums for the ERX routers. The following notes are referred to in Table 4:
1. The total set of FTEs can be shared by interfaces, next hops, ECMP sets, VRs, and VRFs. Next-hop FTEs identify the next hop on multiaccess media, such as ATM multipoint, Ethernet, or bridged Ethernet. Each VR or VRF consumes three entries. Each interface, next hop, and ECMP set consumes a single entry. One FTE is reserved for internal use, and the system software limits the number of FTEs used by interfaces to a maximum of 32,000. The remaining FTEs can be shared across the other types.
2. The ERX1440 router supports a maximum of 48,000 interfaces of all types combined. You can use either all dynamic interfaces or a combination of dynamic and static interfaces to achieve this maximum. The ERX1440 router supports a maximum of 32,000 static PPP/PPPoE interfaces and a maximum of 36,500 static IP network interfaces. Bridged Ethernet does not enforce a limit so IP interfaces created on Bridged Ethernet can scale to the IP maximum of 36,500.
Appendix A: System Maximums
The ERX705, ERX710, and ERX1410 routers support a maximum of 32,000 IP network interfaces; the ERX310 router supports a maximum of 16,000 IP network interfaces. For all these models, the interfaces can be any combination of dynamic or static.
3. These values are subject to limitations on available SRP module memory, which varies according to your router configuration.
4. Depending on your configuration, the router may support more routing table entries or fewer routing table entries than this value. In any case, you can choose to limit the number of routes that can be added to the routing table on a per-VR or per-VRF basis by means of the maximum routes command.
5. The maximum number of ANCP adjacencies can be scaled over a maximum of 100 virtual routers. Fewer ANCP adjacencies can be scaled in configurations with more than 100 virtual routers.
6. This maximum is not valid for Frame Relay. The Frame Relay maximum is 1000 circuits over MPLS per line module, because only 1000 Frame Relay DLCIs are permitted per line module.
7. On the ERX1440 router, you can achieve 32,767 total Martini circuits over ATM or Ethernet interfaces. For all routers, the total Martini can be any combination of external inter-router circuits and internal circuits (local cross-connects).
8. There is no per-VR limit; all multicast routes can be on a single VR or present across multiple VRs.
9. The maximum number of interfaces can be achieved by any combination; for example, two streams each being replicated to 32,768 interfaces; 16,384 streams each being replicated four times; or any other combination.
ERX310, ERX7xx, and ERX14xx System Maximums 75
JUNOSe 11.1.0 Release Notes
10. Dynamic values represent typical limits that vary depending on configuration details and actual dynamic behavior. For dynamic values only, multiple server modules (SMs) in a chassis can improve the values as long as the multiple server modules are online and the number of virtual routers configured with NAT is greater than or equal to the number of server modules. If a server module fails, the load is redistributed to the remaining server modules, with a consequent reduction in aggregate capacity.
11. Static and dynamic translations occupy the same table; therefore, the number of static translation entries present in the table reduces the room for dynamic entries.
Table 4: Routing Protocol Maximums
ERX705 and
Feature ERX310
BFD
Sessions per line module 50 50 50 50
ERX710 ERX1410 ERX1440
ECMP maximum paths to a destination
BGP, IS-IS, MPLS, OSPF, RIP 16 16 16 16
IPv4 forwarding table entries
(See Note 1 on page 75.)
Chassis with only ASIC modules 1,048,576 1,048,576 1,048,576 1,048,576
IP network interfaces (IPv4 and IPv6)
Per chassis
(See Note 2 on page 75.)
Per line module ASIC 8000 8000 8000 8000
IPv4 routing protocol scaling and peering densities
(See Note 3 on page 75.)
Routing table entries
(See Note 4 on page 75.)
ANCP Adjacency Scaling
(See Note 5 on page 75.)
BGP-4 peering sessions 1000 1000 1000 1000
BGP-4 routes (NLRI) 1,500,000 1,500,000 1,500,000 1,500,000
IP next hops (egress FECs) on router with ASIC modules (used to represent the IP addresses of next-hop routers on Ethernet interfaces)
MPLS next hops (egress FECs) on router with ASIC modules only
MPLS forwarding entries 64,000 64,000 64,000 64,000
16,000 32,000 32,000 48,000
500,000 500,000 500,000 500,000
5000 5000 5000 5000
1,000,000 1,000,000 1,000,000 1,000,000
500,000 500,000 500,000 500,000
76 ERX310, ERX7xx, and ERX14xx System Maximums
Appendix A: System Maximums
Table 4: Routing Protocol Maximums (continued)
ERX705 and
Feature ERX310
IS-IS adjacencies 150 150 150 150
IS-IS routes 20,000 20,000 20,000 20,000
MPLS LDP LSPs 10,000 10,000 10,000 10,000
MPLS RSVP-TE LSPs 10,000 10,000 10,000 10,000
OSPF adjacencies 1000 1000 1000 1000
OSPF routes 25,000 25,000 25,000 25,000
ERX710 ERX1410 ERX1440
IPv6 routing table entries
(See Note 3 on page 75.)
J-Flow statistics
J-Flow–enabled VRs and VRFs, in any combination 16 16 16 16
Sampled interfaces per VR or VRF 32323232
Total sampled Interfaces per chassis 512 512 512 512
Martini circuits for layer 2 services over MPLS
Total Martini circuits per line module
(See Note 6 on page 75.)
Total Martini circuits per chassis
(See Note 7 on page 75.)
External Martini circuits per chassis 16,000 16,000 16,000 32,767
Internal Martini circuits (local cross-connects) per chassis 16,000 16,000 16,000 32,767
Mobile IP bindings per chassis 48,000
Multicast routes (IPv4 and IPv6)
Forwarding entries [(S,G) pairs] per chassis
(See Note 8 on page 75.)
Outgoing interfaces per chassis
(See Note 9 on page 75.)
50,000 50,000 50,000 50,000
8000 8000 8000 8000
16,000 16,000 16,000 32,767
16,384 16,384 16,384 16,384
65,536 65,536 65,536 65,536
Network Address Translation (NAT)
Static translations (simple or extended) per chassis 96,000 96,000 96,000 96,000
Dynamic simple translations (NAT) per SM
(See Notes 10 and 11 on page 76.)
Dynamic extended translations (NAPT) per SM
(See Notes 10 and 11 on page 76.)
400,000 400,000 400,000 400,000
200,000 200,000 200,000 200,000
ERX310, ERX7xx, and ERX14xx System Maximums 77
JUNOSe 11.1.0 Release Notes
Table 4: Routing Protocol Maximums (continued)
ERX705 and
Feature ERX310
Response Time Reporter simultaneous operations per VR
VRRP VRIDs per line module ASIC See Ethernet VRRP VRIDs per line module ASIC on page 72.
500 500 500 500
ERX710 ERX1410 ERX1440
78 ERX310, ERX7xx, and ERX14xx System Maximums
Policy and QoS Maximums
Table 5 lists policy and QoS maximums for the ERX routers. The following notes are referred to in Table 5:
1. The OC48 line module supports only 131,071 entries. The GE-2 and GE-HDE line modules support only 65,535 entries.
2. For line modules other than the GE-2, GE-HDE, and OC48/STM16 line modules, the router supports two sizes of policies: 8127 policies, each with a maximum of 32 classifiers, and 16,255 policies, each with a maximum of 16 classifiers. A combination of the two sizes of policies is also supported, in which case the total number of policies is between 8127 and 16,255, depending on the actual configuration.
3. The GE-2, GE-HDE, and OC48/STM16 line modules support CAM classifiers instead of hardware policy assignments. For most configurations, each classifier entry in a policy consumes one CAM entry. However, a policy that has only the default classifier consumes no CAM resources. Policies that use CAM hardware classifiers consume one interface attachment resource, regardless of the number of classifier entries in a policy.
Appendix A: System Maximums
Table 5: Policy and QoS Maximums
ERX705 and
Feature ERX310
QoS queues per ASIC line module 49,000 49,000 49,000 49,000
QoS profiles configurable per chassis 1000 1000 1000 1000
QoS profile attachments per chassis 96,000 96,000 96,000 96,000
QoS profile attachments per ASIC line module 16,000 16,000 16,000 16,000
QoS shapers per line module 64,000 64,000 64,000 64,000
Classification rules per policy 512 512 512 512
Policy classification (CLACL) entries per line module
(See Note 1 on page 79.)
Unique hardware policy assignments per line module for modules other than the GE-2, GE-HDE, and OC48/STM16
(See Note 2 on page 79.)
256,000 256,000 256,000 256,000
8127/16,255 8127/16,255 8127/16,255 8127/16,255
ERX710 ERX1410 ERX1440
ERX310, ERX7xx, and ERX14xx System Maximums 79
JUNOSe 11.1.0 Release Notes
Table 5: Policy and QoS Maximums (continued)
ERX705 and
Feature ERX310
CAM entries
(See Note 3 on page 79.)
GE-2 64,000 64,000
GE-HDE 64,000 64,000
OC48/STM16 128,000
Policy egress interface attachments per ASIC line module
Combined IP and IPv6 interface attachments 8191 8191 8191 8191
Combined ATM, Frame Relay, GRE, L2TP (LNS only), MPLS, and VLAN interface attachments
8191 8191 8191 8191
ERX710 ERX1410 ERX1440
Policy ingress interface attachments per ASIC line module
Combined IP and IPv6 interface attachments on GE-2, GE-HDE, and OC-48/STM16 line modules
Combined IP and IPv6 interface attachments on all other line modules
Combined ATM, Frame Relay, GRE, L2TP (LNS only), MPLS, and VLAN interface attachments
Rate limiters
Egress per ASIC line module 24,575 24,575 24,575 24,575
Ingress per ASIC line module 24,575 24,575 24,575 24,575
Policy statistics blocks
Egress per ASIC line module 256,000 256,000 256,000 256,000
Ingress per ASIC line module 256,000 256,000 256,000 256,000
Parent groups per ASIC line module
Egress and Ingress 8191 8191 8191 8191
GE-2, GE-HDE, and OC3/OC12 ATM line modules (Egress and Ingress)
16,383 16,383
16,000 16,000 16,000 16,000
8191 8191 8191 8191
24,575 24,575 24,575 24,575
All other ASIC line modules (Egress and Ingress) 8191 8191 8191 8191
Software lookup blocks
Per ASIC line module 16,383 16,383 16,383 16,383
80 ERX310, ERX7xx, and ERX14xx System Maximums
Appendix A: System Maximums
Table 5: Policy and QoS Maximums (continued)
ERX705 and
Feature ERX310
Secure policies (for packet mirroring)
Per ASIC line module 1022 1022 1022 1022
Per chassis 2400 2400 2400 2400
ERX710 ERX1410 ERX1440
ERX310, ERX7xx, and ERX14xx System Maximums 81
JUNOSe 11.1.0 Release Notes
Tunneling Maximums
Table 6: Tunneling Maximums
Table 6 lists tunneling maximums for the ERX routers. The following notes are referred to in Table 6:
1. The SM supports any combination of DVMRP, GRE, and L2TP tunnels up to a maximum of 8000 tunnels; however, no more than 4000 tunnels can be DVMRP or GRE tunnels in any combination. The ISM supports any combination of DVMRP, GRE, and L2TP tunnels over IPSec, up to a maximum of 5000 tunnels; however, no more than 4000 tunnels can be DVMRP or GRE tunnels.
2. You can have no more than 8000 L2TP/IPSec sessions per chassis.
3. For more information about supported L2TP sessions and tunnels, see JUNOSe Broadband Access Configuration Guide, Chapter 11, L2TP Overview.
ERX705 and
Feature ERX310
DVMRP (IP-in-IP) tunnels per chassis 4000 4000 4000 4000
DVMRP (IP-in-IP) tunnels per line module
(See Note 1 on page 82.)
GE-2 with shared tunnel-server ports provisioned 4000 4000
GE-HDE with shared tunnel-server ports provisioned 4000 4000
IPSec Service Module (DVMRP/IPSec tunnels) 4000 4000 4000 4000
Service Module (SM) 4000 4000 4000 4000
GRE tunnels per chassis 4000 4000 4000 4000
GRE tunnels per line module
(See Note 1 on page 82.)
GE-2 with shared tunnel-server ports provisioned 4000 4000
GE-HDE with shared tunnel-server ports provisioned 4000 4000
IPSec Service Module (GRE/IPSec tunnels) 4000 4000 4000 4000
Service Module (SM) 4000 4000 4000 4000
ERX710 ERX1410 ERX1440
IPSec manual secure tunnels per chassis 256 256 256 256
IPSec transform sets per chassis 1000 1000 1000 1000
IPSec transforms per transform set 6666
IPSec tunnels per chassis 10,000 10,000 10,000 20,000
82 ERX310, ERX7xx, and ERX14xx System Maximums
Appendix A: System Maximums
Table 6: Tunneling Maximums (continued)
ERX705 and
Feature ERX310
IPSec tunnels per IPSec Ser vice Module 5000 5000 5000 5000
ERX710 ERX1410 ERX1440
L2TP sessions per chassis
(See Notes 2 and 3 on page 82.)
L2TP sessions per line module
(See Notes 1 and 3 on page 82.)
GE-2 with shared tunnel-server ports provisioned 8000 8000
GE-HDE with shared tunnel-server ports provisioned 8000 8000
IPSec Service Module (ISM; L2TP/IPSec sessions) 5000 5000 5000 5000
Service Module (SM) 16,000 16,000 16,000 16,000
L2TP tunnels per chassis 8000 8000 8000 8000
L2TP tunnels per line module
(See Notes 1 and 3 on page 82.)
GE-2 with shared tunnel-server ports provisioned 8000 8000
GE-HDE with shared tunnel-server ports provisioned 8000 8000
IPSec Service Module (L2TP/IPSec tunnels) 5000 5000 5000 5000
Service Module 8000 8000 8000 8000
16,000 16,000 16,000 32,000
ERX310, ERX7xx, and ERX14xx System Maximums 83
JUNOSe 11.1.0 Release Notes
Subscriber Management Maximums
Table 7 lists subscriber management maximums for the ERX routers. The following notes are referred to in Table 7:
1. DHCP relay proxy maintains a list of active DHCP clients up to a maximum of 100,000 clients per chassis for all virtual routers. DHCP relay does not maintain a list of DHCP clients.
DHCP relay proxy is notified of DHCP client deletions and subsequently deletes the client’s host routes. In contrast, DHCP relay is not notified of DHCP client deletions, so the host routes for deleted clients remain in DHCP relay until you permanently delete them with the set dhcp relay discard-access-routes command. A maximum of 100,000 host routes for DHCP clients can be stored for all DHCP relay and DHCP relay proxy instances (that is, for all virtual routers).
2. The ERX1440 router supports a maximum of 48,000 interface columns of all types combined. You can use either all dynamic interfaces or a combination of dynamic and static interfaces to achieve this maximum. For bridged Ethernet, IP network, and PPP interfaces, the ERX1440 router supports a maximum of 32,000 static major interfaces. Although the ERX1440 router supports a maximum of 48,000 static major interfaces for PPPoE, the PPPoE static limit is enforced at the subinterface level, which has a limit of 32,000.
The ERX705, ERX710, and ERX1410 routers support a maximum of 32,000 interfaces of all types combined; the ERX310 router supports a maximum of 16,000 interfaces of all types combined. For these routers, the interfaces can be any combination of dynamic or static.
The JUNOSe Software supports up to 10,000 PPP interfaces with EAP authentication negotiation configured. Performance and scalability is unchanged when EAP is not configured.
3. For DHCPv6 local server, up to 32,000 subscribers and clients are supported on PPP/ATM and PPPoE/ATM with dynamic interfaces. Interface flapping tests have been qualified for 8000 subscribers and interfaces.
Table 7: Subscriber Management Maximums
ERX705 and
Feature ERX310
DHCP external ser ver clients (per chassis for all virtual routers; and per virtual router)
(See Note 1 on page 84.)
DHCP local server
(See Note 2 on page 84.)
Client bindings per chassis 96,000 96,000 96,000 96,000
Client interfaces per chassis 16,000 32,000 32,000 48,000
Local address pools per virtual router 4000 4000 4000 4000
IP addresses per local address pool 32,000 32,000 32,000 32,000
100,000 100,000 100,000 100,000
ERX710
ERX1410 ERX1440
84 ERX310, ERX7xx, and ERX14xx System Maximums
Table 7: Subscriber Management Maximums (continued)
Feature ERX310
DHCPv6 local server
Clients
(See Note 3 on page 84.)
DHCP relay and relay proxy client
(See Notes 1 and 2 on page 84.)
DHCP client host routes for DHCP relay and DHCP relay proxy combined (per chassis for all virtual routers; and per virtual router)
DHCP relay proxy clients (per chassis for all virtual routers; and per virtual router)
Interfaces (per chassis for all virtual routers; and per virtual router)
32,000 32,000 32,000 32,000
100,000 100,000 100,000 100,000
100,000 100,000 100,000 100,000
16,000 32,000 32,000 48,000
Appendix A: System Maximums
ERX705 and ERX710 ERX1410 ERX1440
Local authentication server
Local user databases per chassis 100 100 100 100
Users per local user database 100 100 100 100
Users for all local user databases 100 100 100 100
RADIUS requests
Concurrent RADIUS authentication requests 4000 4000 4000 32,000
Concurrent RADIUS accounting requests 4000 4000 4000 96,000
RADIUS route-download server downloaded routes per chassis
Service Manager
Service definitions 2048 2048 2048 2048
Service sessions (active) 131,072 131,072 131,072 131,072
Active subscriber sessions 16,000 32,000 32,000 48,000
SRC Software and SDX Software
COPS client instances 200 200 200 200
SRC clients 200 200 200 200
SRC interfaces 16,000 32,000 32,000 48,000
32,000 32,000 32,000 32,000
ERX310, ERX7xx, and ERX14xx System Maximums 85
JUNOSe 11.1.0 Release Notes
Table 7: Subscriber Management Maximums (continued)
ERX705 and
Feature ERX310
Subscriber interfaces
(See Note 2 on page 84.)
Dynamic subscriber interfaces per chassis 16,000 32,000 32,000 48,000
Dynamic subscriber interfaces per line module 8000 8000 8000 8000
Static subscriber interfaces per chassis 16,000 32,000 32,000 48,000
Static subscriber interfaces per line module 8000 8000 8000 8000
ERX710 ERX1410 ERX1440
86 ERX310, ERX7xx, and ERX14xx System Maximums
E120 and E320 System Maximums
The following tables provide system maximums for the E120 router and the E320 router.
General System Maximums
Table 8 lists some general system maximums for the E120 router and the E320 router. The following notes are referred to in Table 8:
1. The maximum number applies to any combination of VRs and VRFs. The number of VRs and VRFs that you can configure depends on your configuration. You cannot achieve the maximum number if each VR and VRF instance is running a routing protocol.
2. The maximum of 3000 VRs and VRFs can be achieved only with the SRP-120 and SRP-320 modules, which have 4 GB of memory. The limits cannot be achieved with the SRP-100 module, which has 2 GB of memory.
Appendix A: System Maximums
Table 8: General System Maximums
Feature E120 E320
Fabric size 120 Gbps 100 Gbps/320 Gbps
Chassis per 7-foot rack 6 3
NTP clients 1000 1000
NTP servers 300 300
Sessions per chassis (simultaneous Telnet + FTP + SSH, in any combination)
Virtual routers and VRFs per chassis, combined
(See Notes 1 and 2 on page 87.)
Virtual routers and VRFs per line module, combined
(See Notes 1 and 2 on page 87.)
ICR Partitions per chassis 640 640
ICR Partitions per line module 64 64
30 30
3000 3000
3000 3000
E120 and E320 System Maximums 87
JUNOSe 11.1.0 Release Notes
Physical and Logical Density Maximums
Table 9 lists physical and logical density maximums for the E120 router and the E320 router. The following notes are referred to in Table 9:
1. Wire rate indicates the port density that supports maximum (wire-rate) performance. Oversubscribed indicates the port density possible if you are willing to accept less than wire-rate performance by oversubscribing the available fabric bandwidth.
2. With a 120 Gbps configuration on the E120 router, you can install up to 6 combinations of ES2 10G Uplink LMs, ES2 10G LMs, or ES2 10G ADV LMs in slots numbered 0-5. You can install a maximum of 6 active ports and 6 redundant ports at any time.
With a 100 Gbps fabric configuration on the E320 router, you must install the ES2 10G Uplink LM, the ES2 10G LM, or the ES2 10G ADV LM in either of the E320 router turbo slots (2 and 4). When the ES2 10G Uplink LM, the ES2 10G LM, or the ES2 10G ADV LM is installed in slot 2 or slot 4, you cannot install another line module in slot 3 or slot 5. In this case, you can only install the ES2 4G LM in slots 0–1 and 6–11; therefore, the maximum number of ports and the forwarding performance per chassis is reduced for the IOAs that pair with the ES2 4G LM.
With a 320 Gbps fabric configuration on the E320 router, you can install up to 12 combinations of ES2 10G Uplink LMs, ES2 10G LMs, or ES2 10G ADV LMs in slots numbered 0-5 and 11-16. You can install a maximum of 12 active ports and 12 redundant ports at any time.
Table 9: Physical and Logical Density Maximums
Feature E120 E320
Physical density wire rate/oversubscribed
(See Note 1 on page 88.)
10-Gigabit Ethernet ports per chassis (ES2-S1 10GE IOA)
10-Gigabit Ethernet ports per chassis (ES2-S2 10GE PR IOA)
(See Note 2 on page 88.)
Gigabit Ethernet ports per chassis (ES2-S1 GE-4 IOAs)
Gigabit Ethernet ports per chassis (ES2-S1 GE-8 IOAs)
(See Note 2 on page 88.)
Gigabit Ethernet ports per chassis (ES2-S3 GE-20 IOA)
(See Note 2 on page 88.)
OC3/STM-1 ATM ports per chassis (ES2-S1 OC3-8 STM1 ATM IOAs)
OC12/STM-4 ATM ports per chassis (ES2-S1 OC12-2 STM4 ATM IOAs)
612
6 + 6 12 + 12
24 48
96 192
120 240
96 192
24 48
88 E120 and E320 System Maximums
Table 9: Physical and Logical Density Maximums (continued)
Feature E120 E320
OC12/STM-4 POS ports per chassis
24 48
(ES2-S1 OC12-2 STM4 POS IOAs)
OC48/STM16 ports per chassis
6 12
(ES2-S1 OC48 STM16 POS IOAs)
Logical density per chassis
Logical OC3/STM1 per chassis 96 192
Logical OC12/STM4 per chassis 24 48
Logical OC48/STM16 per chassis 6 12
Appendix A: System Maximums
E120 and E320 System Maximums 89
JUNOSe 11.1.0 Release Notes
Link Layer Maximums
Table 10 lists link layer maximums for the E120 router and the E320 router. The following notes are referred to in Table 10:
1. On the ES2 10G LM, ES2 10G ADV LM, or ES2 10 G Uplink LM, you can have configurations with up to 100,000 static entries that support 100,000 DHCP relay proxy clients. You can have an additional 28,000 static or dynamic entries for network resources, such as RADIUS and DHCP servers. However, the total number of dynamic entries in the ARP table is still restricted to a maximum of 32,768 per line module.
2. On the E120 router, the SRP-120 and the SRP-320 support a maximum of 64,000 interfaces.
On the E320 router, the SRP-320 supports a maximum of 96,000 interfaces. The SRP-100 supports a maximum of 64,000 interfaces.
3. The E120 router supports a maximum of 64,000 interface columns of all types combined. The E320 router supports a maximum of 96,000 interface columns of all types combined. You can use all dynamic interfaces, or all static interfaces, or a combination of dynamic and static interfaces to achieve this maximum.
The JUNOSe Software supports up to 10,000 PPP interfaces with EAP authentication negotiation configured. Performance and scalability is unchanged when EAP is not configured.
4. The E120 router supports a maximum of 64,000 Ethernet subinterfaces that can be active at any one time. The E320 router supports a maximum of 96,000 Ethernet subinterfaces that can be active at any one time. Of this total, you can configure all single-tagged VLAN subinterfaces, all double-tagged S-VLAN subinterfaces, or a combination of both VLAN subinterfaces and S-VLAN subinterfaces to achieve this maximum.
5. The E120 router and the E320 router support 16,384 VLAN subinterfaces per slot on the ES2 4G LM and the ES2 10G LM, and 32,768 VLAN subinterfaces per slot on the ES2 10G ADV LM. On the E120 router, a maximum of 64,000 VLAN subinterfaces is supported per chassis. On the E320 router, a maximum of 96,000 VLAN subinterfaces is supported per chassis. You can use all dynamic interfaces, or all static interfaces, or a combination of dynamic and static interfaces to achieve this maximum.
6. For all LMs, no more than 16,384 S-VLANs are supported per port. The ES2 10G ADV LM supports 32,768 S-VLANs per module. All other LMs support only 16,384 S-VLANs per module.
7. For all LMs, no more than 4096 VLANs are supported per port. The ES2 10G ADV LM supports 32,768 VLANs per module. All other LMs support only 16,384 VLANs per module.
8. No more than 8192 VLAN major interfaces are supported per line module.
90 E120 and E320 System Maximums
Table 10: Link Layer Maximums
Feature E120 E320
ARP entries per line module
Dynamic entries per LM 32,768 32,768
Static entries per ES2 4G LM 32,768 32,768
Static entries per ES2 10G LM, ES2 10G ADV LM, or ES2
128,000 128,000
10G Uplink LM
(See Note 1 on page 90.)
Total entries per ES2 4G LM 32,768 32,768
Total entries per ES2 10G LM, ES2 10G ADV LM, or ES2
128,000 128,000
10G Uplink LM
(See Note 1 on page 90.)
ATM bulk configuration VC ranges per chassis 300 1025
Appendix A: System Maximums
ATM bulk configuration VC ranges per line module 300 1025
ATM bulk configuration total VCs per chassis 192,000 384,000
ATM bulk configuration total VCs per line module
ES2 4G LM and OCx/STMx ATM IOA 32,000 32,000
ATM bulk configuration overriding profile assignments
100 100
per chassis
ATM VCs per chassis
64,000 96,000
(See Note 2 on page 90.)
ATM VCs per line module
ES2 4G LM and OCx/STMx ATM IOA 16,000 16,000
ATM V Cs pe r por t
ES2 4G LM and OCx/STMx ATM IOA 16,000 16,000
ATM VC classes per chassis 100 100
ATM VP/VC addresses per line module
ES2 4G LM and OCx/STMx ATM IOA 24-bit 24-bit
E120 and E320 System Maximums 91
JUNOSe 11.1.0 Release Notes
Table 10: Link Layer Maximums (continued)
Feature E120 E320
ATM VP tunnels per port, all supported modules
256 256
Bridged Ethernet interfaces per chassis
(See Notes 2 and 3 on page 90.)
Bridged Ethernet interfaces per line module (OCx/STMx ATM)
Dynamic interfaces
Active autosensed dynamic interface columns per chassis over static or dynamic (bulk) ATM1483 subinterfaces
(See Note 2 on page 90.)
Ethernet 802.3ad Link Aggregation
Links per LAG (bundle) 8 8
LAGs (bundles) per chassis 64 64
Ethernet S-VLANs per chassis
(See Notes 2, 4, and 5 on page 90.)
Ethernet S-VLANs per IOA
(See Note 6 on page 90.)
ES2-S1 GE-4 IOA (with ES2 4G LM)
ES2-S1 GE-8 IOA (with ES2 4G LM or ES2 10G LM)
ES2-S1 GE-8 IOA (with ES2 4G LM, ES2 10G LM, or ES2 10G ADV LM)
ES2-S1 GE-8 IOA (with ES2 10G ADV LM)
ES2-S1 10GE IOA (with ES2 4G LM)
ES2-S2 10GE PR IOA (with ES2 10G LM or ES2 10G Uplink LM)
ES2-S2 10GE PR IOA (with ES2 10G ADV LM)
ES2-S3 GE-20 IOA (with ES2 10G LM)
ES2-S3 GE-20 IOA (with ES2 10G ADV LM)
64,000 96,000
16,000 16,000
64,000 96,000
64,000 96,000
16,384 16,384
16,384 16,384
16,384 16,384
32,768 32,768
16,384 16,384
16,384 16,384
32,768 32,768
16,384 16,384
32,768 32,768
92 E120 and E320 System Maximums
