JunosE™ Software for E Series

™

Broadband Services Routers

Release Notes

Release 10.3.2

Juniper Networks, Inc.

1194 North Mathilda Avenue

Sunnyvale, CA 94089

USA

408-745-2000

www.juniper.net

Published: 2010-09-29

Juniper Networks, Junos, Steel-Belted Radius, NetScreen, and ScreenOS are registered trademarks of Juniper Networks, Inc. in the United States and other countries. The Juniper Networks Logo, the Junos logo, and JunosE are trademarks of Juniper Networks, Inc. All other trademarks, service marks, registered trademarks, or registered service marks are the property of their respective owners.

Juniper Networks assumes no responsibility for any inaccuracies in this document. Juniper Networks reserves the right to change, modify, transfer, or otherwise revise this publication without notice.

Products made or sold by Juniper Networks (including the ERX310, ERX705, ERX710, ERX1410, ERX1440, M5, M7i, M10, M10i, M20, M40, M40e, M160, M320, and T320 routers, T640 routing node, and the Junos, JunosE, and SDX-300 software) or components thereof might be covered by one or more of the following patents that are owned by or licensed to Juniper Networks: U.S. Patent Nos. 5,473,599, 5,905,725, 5,909,440, 6,192,051, 6,333,650, 6,359,479, 6,406,312, 6,429,706, 6,459,579, 6,493,347, 6,538,518, 6,538,899, 6,552,918, 6,567,902, 6,578,186, and 6,590,785.

JunosE™ Software for E Series™ Broadband Services Routers Release Notes, Release 10.3.2 Writing: Subash Babu Asokan, Krupa Chandrashekar, Megha Shaseendran, Pallavi Madhusudhan, Namrata Mehta, Diane Florio, Brian Wesley Simmons, Fran Singer, Sairam V Editing: Ben Mann, Alana Calapai Cover Design: Edmonds Design

Revision History September 2010—FRS JunosE 10.3.2

The information in this document is current as of the date listed in the revision history.

Software License

The terms and conditions for using this software are described in the software license contained in the acknowledgment to your purchase order or, to the extent applicable, to any reseller agreement or end-user purchase agreement executed between you and Juniper Networks. By using this software, you indicate that you understand and agree to be bound by those terms and conditions.

Generally speaking, the software license restricts the manner in which you are permitted to use the software and may contain prohibitions against certain uses. The software license may state conditions under which the license is automatically terminated. You should consult the license for further details.

For complete product documentation, please see the Juniper Networks Web site at www.juniper.net/techpubs.

END USER LICENSE AGREEMENT

READ THIS END USER LICENSE AGREEMENT (“AGREEMENT”) BEFORE DOWNLOADING, INSTALLING, OR USING THE SOFTWARE. BY DOWNLOADING, INSTALLING, OR USING THE SOFTWARE OR OTHERWISE EXPRESSING YOUR AGREEMENT TO THE TERMS CONTAINED HEREIN, YOU (AS CUSTOMER OR IF YOU ARE NOT THE CUSTOMER, AS A REPRESENTATIVE/AGENT AUTHORIZED TO BIND THE CUSTOMER) CONSENT TO BE BOUND BY THIS AGREEMENT. IF YOU DO NOT OR CANNOT AGREE TO THE TERMS CONTAINED HEREIN, THEN (A) DO NOT DOWNLOAD, INSTALL, OR USE THE SOFTWARE, AND (B) YOU MAY CONTACT JUNIPER NETWORKS REGARDING LICENSE TERMS.

1. The Parties. The parties to this Agreement are (i) Juniper Networks, Inc. (if the Customer’s principal office is located in the Americas) or Juniper Networks (Cayman) Limited (if the Customer’s principal office is located outside the Americas) (such applicable entity being referred to herein as “Juniper”), and (ii) the person or organization that originally purchased from Juniper or an authorized Juniper reseller the applicable license(s) for use of the Software (“Customer”) (collectively, the “Parties”).

2. The Software. In this Agreement, “Software” means the program modules and features of the Juniper or Juniper-supplied software, for which Customer has paid the applicable license or support fees to Juniper or an authorized Juniper reseller, or which was embedded by Juniper in equipment which Customer purchased from Juniper or an authorized Juniper reseller. “Software” also includes updates, upgrades and new releases of such software. “Embedded Software” means Software which Juniper has embedded in or loaded onto the Juniper equipment and any updates, upgrades, additions or replacements which are subsequently embedded in or loaded onto the equipment.

3. License Grant. Subject to payment of the applicable fees and the limitations and restrictions set forth herein, Juniper grants to Customer a non-exclusive and non-transferable license, without right to sublicense, to use the Software, in executable form only, subject to the following use restrictions:

a. Customer shall use Embedded Software solely as embedded in, and for execution on, Juniper equipment originally purchased by Customer

from Juniper or an authorized Juniper reseller.

b. Customer shall use the Software on a single hardware chassis having a single processing unit, or as many chassis or processing units for which

Customer has paid the applicable license fees; provided, however, with respect to the Steel-Belted Radius or Odyssey Access Client software only, Customer shall use such Software on a single computer containing a single physical random access memory space and containing any number of processors. Use of the Steel-Belted Radius or IMS AAA software on multiple computers or virtual machines (e.g., Solaris zones) requires multiple licenses, regardless of whether such computers or virtualizations are physically contained on a single chassis.

c. Product purchase documents, paper or electronic user documentation, and/or the particular licenses purchased by Customer may specify limits

to Customer’s use of the Software. Such limits may restrict use to a maximum number of seats, registered endpoints, concurrent users, sessions, calls, connections, subscribers, clusters, nodes, realms, devices, links, ports or transactions, or require the purchase of separate licenses to use particular features, functionalities, services, applications, operations, or capabilities, or provide throughput, performance, configuration, bandwidth, interface, processing, temporal, or geographical limits. In addition, such limits may restrict the use of the Software to managing certain kinds of networks or require the Software to be used only in conjunction with other specific Software. Customer’s use of the Software shall be subject to all such limitations and purchase of all applicable licenses.

d. For any trial copy of the Software, Customer’s right to use the Software expires 30 days after download, installation or use of the Software.

Customer may operate the Software after the 30-day trial period only if Customer pays for a license to do so. Customer may not extend or create an additional trial period by re-installing the Software after the 30-day trial period.

e. The Global Enterprise Edition of the Steel-Belted Radius software may be used by Customer only to manage access to Customer’s enterprise

network. Specifically, service provider customers are expressly prohibited from using the Global Enterprise Edition of the Steel-Belted Radius software to support any commercial network access services.

The foregoing license is not transferable or assignable by Customer. No license is granted herein to any user who did not originally purchase the applicable license(s) for the Software from Juniper or an authorized Juniper reseller.

4. Use Prohibitions. Notwithstanding the foregoing, the license provided herein does not permit the Customer to, and Customer agrees not to and shall not: (a) modify, unbundle, reverse engineer, or create derivative works based on the Software; (b) make unauthorized copies of the Software (except as necessary for backup purposes); (c) rent, sell, transfer, or grant any rights in and to any copy of the Software, in any form, to any third party; (d) remove any proprietary notices, labels, or marks on or in any copy of the Software or any product in which the Software is embedded; (e) distribute any copy of the Software to any third party, including as may be embedded in Juniper equipment sold in the secondhand market; (f) use any ‘locked’ or key-restricted feature, function, service, application, operation, or capability without first purchasing the applicable license(s) and obtaining a valid key from Juniper, even if such feature, function, service, application, operation, or capability is enabled without a key; (g) distribute any key for the Software provided by Juniper to any third party; (h) use the Software in any manner that extends or is broader than the uses purchased by Customer from Juniper or an authorized Juniper reseller; (i) use Embedded Software on non-Juniper equipment; (j) use Embedded Software (or make it available for use) on Juniper equipment that the Customer did not originally purchase from Juniper or an authorized Juniper reseller; (k) disclose the results of testing or benchmarking of the Software to any third party without the prior written consent of Juniper; or (l) use the Software in any manner other than as expressly provided herein.

5. Audit. Customer shall maintain accurate records as necessary to verify compliance with this Agreement. Upon request by Juniper, Customer shall furnish such records to Juniper and certify its compliance with this Agreement.

6. Confidentiality. The Parties agree that aspects of the Software and associated documentation are the confidential property of Juniper. As such, Customer shall exercise all reasonable commercial efforts to maintain the Software and associated documentation in confidence, which at a minimum includes restricting access to the Software to Customer employees and contractors having a need to use the Software for Customer’s internal business purposes.

7. Ownership. Juniper and Juniper’s licensors, respectively, retain ownership of all right, title, and interest (including copyright) in and to the Software, associated documentation, and all copies of the Software. Nothing in this Agreement constitutes a transfer or conveyance of any right, title, or interest in the Software or associated documentation, or a sale of the Software, associated documentation, or copies of the Software.

8. Warranty, Limitation of Liability, Disclaimer of Warranty. The warranty applicable to the Software shall be as set forth in the warranty statement that accompanies the Software (the “Warranty Statement”). Nothing in this Agreement shall give rise to any obligation to support the Software. Support services may be purchased separately. Any such support shall be governed by a separate, written support services agree MAXIMUM EXTENT PERMITTED BY LAW, JUNIPER SHALL NOT BE LIABLE FOR ANY LOST PROFITS, LOSS OF DATA, OR COSTS OR PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES, OR FOR ANY SPECIAL, INDIRECT, OR CONSEQUENTIAL DAMAGES ARISING OUT OF THIS AGREEMENT, THE SOFTWARE, OR ANY JUNIPER OR JUNIPER-SUPPLIED SOFTWARE. IN NO EVENT SHALL JUNIPER BE LIABLE FOR DAMAGES ARISING FROM UNAUTHORIZED OR IMPROPER USE OF ANY JUNIPER OR JUNIPER-SUPPLIED SOFTWARE. EXCEPT AS EXPRESSLY PROVIDED IN THE WARRANTY STATEMENT TO THE EXTENT PERMITTED BY LAW, JUNIPER DISCLAIMS ANY AND ALL WARRANTIES IN AND TO THE SOFTWARE (WHETHER EXPRESS, IMPLIED, STATUTORY, OR OTHERWISE), INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, OR NONINFRINGEMENT. IN NO EVENT DOES JUNIPER WARRANT THAT THE SOFTWARE, OR ANY EQUIPMENT OR NETWORK RUNNING THE SOFTWARE, WILL OPERATE WITHOUT ERROR OR INTERRUPTION, OR WILL BE FREE OF VULNERABILITY TO INTRUSION OR ATTACK. In no event shall Juniper’s or its suppliers’ or licensors’ liability to Customer, whether in contract, tort (including negligence), breach of warranty, or otherwise, exceed the price paid by Customer for the Software that gave rise to the claim, or if the Software is embedded in another Juniper product, the price paid by Customer for such other product. Customer acknowledges and agrees that Juniper has set its prices and entered into this Agreement in reliance upon the disclaimers of warranty and the limitations of liability set forth herein, that the same reflect an allocation of risk between the Parties (including the risk that a contract remedy may fail of its essential purpose and cause consequential loss), and that the same form an essential basis of the bargain between the Parties.

9. Termi natio n. Any breach of this Agreement or failure by Customer to pay any applicable fees due shall result in automatic termination of the license granted herein. Upon such termination, Customer shall destroy or return to Juniper all copies of the Software and related documentation in Customer’s possession or control.

10. Taxes. All license fees payable under this agreement are exclusive of tax. Customer shall be responsible for paying Taxes arising from the purchase of the license, or importation or use of the Software. If applicable, valid exemption documentation for each taxing jurisdiction shall be provided to Juniper prior to invoicing, and Customer shall promptly notify Juniper if their exemption is revoked or modified. All payments made by Customer shall be net of any applicable withholding tax. Customer will provide reasonable assistance to Juniper in connection with such withholding taxes by promptly: providing Juniper with valid tax receipts and other required documentation showing Customer’s payment of any withholding taxes; completing appropriate applications that would reduce the amount of withholding tax to be paid; and notifying and assisting Juniper in any audit or tax proceeding related to transactions hereunder. Customer shall comply with all applicable tax laws and regulations, and Customer will promptly pay or reimburse Juniper for all costs and damages related to any liability incurred by Juniper as a result of Customer’s non-compliance or delay with its responsibilities herein. Customer’s obligations under this Section shall survive termination or expiration of this Agreement.

11 . Export. Customer agrees to comply with all applicable export laws and restrictions and regulations of any United States and any applicable foreign

agency or authority, and not to export or re-export the Software or any direct product thereof in violation of any such restrictions, laws or regulations, or without all necessary approvals. Customer shall be liable for any such violations. The version of the Software supplied to Customer may contain encryption or other capabilities restricting Customer’s ability to export the Software without an export license.

12. Commercial Computer Software. The Software is “commercial computer software” and is provided with restricted rights. Use, duplication, or disclosure by the United States government is subject to restrictions set forth in this Agreement and as provided in DFARS 227.7201 through

227.7202-4, FAR 12.212, FAR 27.405(b)(2), FAR 52.227-19, or FAR 52.227-14(ALT III) as applicable.

13. Interface Information. To the extent required by applicable law, and at Customer's written request, Juniper shall provide Customer with the interface information needed to achieve interoperability between the Software and another independently created program, on payment of applicable fee, if any. Customer shall observe strict obligations of confidentiality with respect to such information and shall use such information in compliance with any applicable terms and conditions upon which Juniper makes such information available.

14. Third Party Software. Any licensor of Juniper whose software is embedded in the Software and any supplier of Juniper whose products or technology are embedded in (or services are accessed by) the Software shall be a third party beneficiary with respect to this Agreement, and such licensor or vendor shall have the right to enforce this Agreement in its own name as if it were Juniper. In addition, certain third party software may be provided

with the Software and is subject to the accompanying license(s), if any, of its respective owner(s). To the extent portions of the Software are distributed under and subject to open source licenses obligating Juniper to make the source code for such portions publicly available (such as the GNU General Public License (“GPL”) or the GNU Library General Public License (“LGPL”)), Juniper will make such source code portions (including Juniper

ment. TO THE

modifications, as appropriate) available upon request for a period of up to three years from the date of distribution. Such request can be made in writing to Juniper Networks, Inc., 1194 N. Mathilda Ave., Sunnyvale, CA 94089, ATTN: General Counsel. You may obtain a copy of the GPL at

http://www.gnu.org/licenses/gpl.html, and a copy of the LGPL at http://www.gnu.org/licenses/lgpl.html.

15. Miscellaneous. This Agreement shall be governed by the laws of the State of California without reference to its conflicts of laws principles. The provisions of the U.N. Convention for the International Sale of Goods shall not apply to this Agreement. For any disputes arising under this Agreement, the Parties hereby consent to the personal and exclusive jurisdiction of, and venue in, the state and federal courts within Santa Clara County, California. This Agreement constitutes the entire and sole agreement between Juniper and the Customer with respect to the Software, and supersedes all prior and contemporaneous agreements relating to the Software, whether oral or written (including any inconsistent terms contained in a purchase order), except that the terms of a separate written agreement executed by an authorized Juniper representative and Customer shall govern to the extent such terms are inconsistent or conflict with terms contained herein. No modification to this Agreement nor any waiver of any rights hereunder shall be effective unless expressly assented to in writing by the party to be charged. If any portion of this Agreement is held invalid, the Parties agree that such invalidity shall not affect the validity of the remainder of this Agreement. This Agreement and associated documentation has been written in the English language, and the Parties agree that the English version will govern. (For Canada: Les parties aux présentés confirment leur volonté que cette convention de même que tous les documents y compris tout avis qui s'y rattaché, soient redigés en langue anglaise. (Translation: The parties confirm that this Agreement and all related documentation is and will be in the English language)).

Table of Contents

Release 10.3.2 1

Release Installation ..........................................................................................1

Upgrading to Release 5.3.0 or a Higher-Numbered Release.......................1

Upgrading from Release 5.1.1 or Lower-Numbered Releases to

Release 6.x.x or Higher-Numbered Releases ...................................... 2

Moving Line Modules Between Releases ....................................................2

SRP Module Memory Requirements ..........................................................3

Hardware and Software Compatibility.......................................................3

Requesting Technical Support .........................................................................3

Self-Help Online Tools and Resources........................................................4

Opening a Case with JTAC ......................................................................... 4

Release Overview............................................................................................. 5

Before You Start ........................................................................................ 5

Release Highlights............................................................................................7

IPv6...........................................................................................................7

Early Field Trial Features.................................................................................. 7

DHCP ........................................................................................................8

Unified ISSU .............................................................................................. 9

Unsupported Features ...................................................................................... 9

E120 Router and E320 Router ................................................................... 9

Multicast....................................................................................................9

Policy Management ...................................................................................9

Stateful SRP Switchover (High Availability) .............................................. 10

Release Software Protocols ............................................................................ 10

Core Routing Stack ..................................................................................10

Layer 2 Protocols..................................................................................... 10

Multiprotocol Label Switching (MPLS) ......................................................11

Network Management Protocols..............................................................11

Routing Protocols .................................................................................... 11

Security Protocols....................................................................................11

SRC Software and SDX Software Compatibility Matrix................................... 12

Known Behavior ............................................................................................12

AAA......................................................................................................... 12

ATM.........................................................................................................12

BGP ......................................................................................................... 13

BGP/MPLS VPNs ......................................................................................13

B-RAS ......................................................................................................13

CLI........................................................................................................... 14

DHCP ......................................................................................................17

DHCP External Server.............................................................................. 17

Dynamic Interfaces .................................................................................19

Ethernet .................................................................................................. 19

Flash........................................................................................................20

Forwarding ..............................................................................................20

Table of Contents  v

JunosE 10.3.2 Release Notes

GRE ......................................................................................................... 21

Hardware ................................................................................................21

HDLC....................................................................................................... 22

IP.............................................................................................................22

IPSec .......................................................................................................24

IS-IS.........................................................................................................24

L2TP........................................................................................................25

Line Module Redundancy ........................................................................25

MLPPP.....................................................................................................26

MPLS ....................................................................................................... 26

Multicast..................................................................................................26

Packet Mirroring...................................................................................... 27

Policy Management .................................................................................27

PPP..........................................................................................................29

PPPoE......................................................................................................29

QoS .........................................................................................................29

RADIUS ...................................................................................................30

SNMP ...................................................................................................... 31

SSH ......................................................................................................... 31

Stateful SRP Switchover (High Availability) .............................................. 32

Subscriber Interfaces ...............................................................................33

System ....................................................................................................33

System Logging ....................................................................................... 34

Tunneling ................................................................................................ 34

Known Problems and Limitations ..................................................................35

ANCP....................................................................................................... 35

ATM.........................................................................................................35

BFD ......................................................................................................... 37

Bridged Ethernet .....................................................................................37

CLI........................................................................................................... 37

DHCP ......................................................................................................37

DHCP External Server.............................................................................. 38

DoS Protection ........................................................................................ 38

Ethernet .................................................................................................. 38

File System..............................................................................................38

Forwarding ..............................................................................................39

ICR ..........................................................................................................40

IGMP ....................................................................................................... 41

IP.............................................................................................................41

IPSec .......................................................................................................42

IS-IS.........................................................................................................43

L2TP........................................................................................................43

MLD ........................................................................................................ 43

MLPPP.....................................................................................................43

Mobile IP ................................................................................................. 44

MPLS ....................................................................................................... 44

Multicast..................................................................................................45

Netflow.................................................................................................... 45

Policy Management .................................................................................45

PPPoE......................................................................................................47

QoS .........................................................................................................47

RSVP-TE .................................................................................................. 49

Service Manager ......................................................................................49

SNMP ...................................................................................................... 49

vi  Table of Contents

Table of Contents

SONET..................................................................................................... 49

SRC Software and SDX Software ............................................................. 50

Stateful SRP Switchover (High Availability) and IP Tunnels......................50

Subscriber Management .......................................................................... 51

System ....................................................................................................52

System Logging ....................................................................................... 52

TCP ......................................................................................................... 52

Unified ISSU ............................................................................................ 52

Resolved Known Problems ............................................................................ 54

ATM.........................................................................................................54

BGP ......................................................................................................... 54

Bridged Ethernet .....................................................................................54

DHCP ......................................................................................................54

DHCPv6 Server........................................................................................55

DoS Protection ........................................................................................ 55

Ethernet .................................................................................................. 55

Forwarding ..............................................................................................55

HTTP Server ............................................................................................ 55

IGMP ....................................................................................................... 55

IP.............................................................................................................56

IPv6.........................................................................................................56

L2TP........................................................................................................56

Line Module Redundancy ........................................................................56

MPLS ....................................................................................................... 56

OSPF ....................................................................................................... 56

Policy Management .................................................................................56

QoS .........................................................................................................56

RSVP-TE .................................................................................................. 57

SRC Software and SDX Software ............................................................. 57

SRP..........................................................................................................57

Errata.............................................................................................................58

Appendix A

System Maximums 69

ERX310, ERX7xx, and ERX14xx System Maximums.....................................70

General System Maximums ..................................................................... 70

Physical and Logical Density Maximums ................................................. 71

Link Layer Maximums ............................................................................. 74

Routing Protocol Maximums ................................................................... 79

Policy and QoS Maximums......................................................................83

Tunneling Maximums.............................................................................. 86

Subscriber Management Maximums........................................................88

E120 and E320 System Maximums ............................................................... 91

General System Maximums ..................................................................... 91

Physical and Logical Density Maximums ................................................. 92

Link Layer Maximums ............................................................................. 94

Routing Protocol Maximums ................................................................. 100

Policy and QoS Maximums....................................................................103

Tunneling Maximums............................................................................ 107

Subscriber Management Maximums......................................................109

Table of Contents

 vii

JunosE 10.3.2 Release Notes

viii  Table of Contents

Release 10.3.2

Release Installation

Complete procedures for installing the system software are available in JunosE System Basics Configuration Guide, Chapter 3, Installing JunosE Software.

New software releases are available for download from the Juniper Networks website at http://www.juniper.net/customers/support. You can use the downloaded image bundle to create your own software CDs.

Before upgrading to a new version of software, save your router’s running configuration to a .cnf file or .scr file. If you subsequently need to downgrade for any reason, you can restore the earlier software version.

NOTE: When you upgrade the software on a router that has a large number of

interfaces configured, the router might appear to be unresponsive for several minutes. This condition is normal; allow the process to continue uninterrupted.

Upgrading to Release 5.3.0 or a Higher-Numbered Release

When you upgrade from a lower-numbered release to Release 5.3.0 or a higher-numbered release, the higher release might not load if you issue the boot system command from Boot mode while the lower-numbered software is running on the router or if you insert a flash card running a higher-numbered release into a system running a lower numbered release. However, if you issue the boot system command from Global Configuration mode, the new software loads properly.

Release Installation  1

JunosE 10.3.2 Release Notes

Upgrading from Release 5.1.1 or Lower-Numbered Releases to Release 6.x.x or Higher-Numbered Releases

Release 5.1.1 or lower-numbered releases support application images only up to 172 MB. Your software upgrades or application images may be available remotely through Telnet or FTP, or may be delivered on a new NVS card. If you upgrade the JunosE Software using a new NVS card, we recommend you perform the upgrade in two stages: first to an intermediate release and then to the higher-numbered release you want to run. This restriction is not applicable if you upgrade your software remotely through Telnet or FTP.

To install larger application images for Release 6.0.0 and higher-numbered releases, you must first install Release 5.1.2 (or a higher-numbered 5.x.x release). This enables the system to support application images greater than 172 MB. For example, if you are upgrading the software using a new NVS card, you cannot go from Release 5.1.1 to Release 7.2.0 without first upgrading to Release 5.1.2.

See the following table for compatibility of releases.

JunosE Release

5.1.1 or lower-numbered release

5.1.2 or higher-numbered release

7.2.0 or higher-numbered release

For more detailed information on installing software, and about NVS cards and SRP modules, see the following documents:

 JunosE System Basics Configuration Guide, Chapter 6, Managing Modules

 Upgrading NVS Cards on SRP Modules in ERX Hardware Guide, Chapter 8,

Maintaining ERX Routers

 Upgrading NVS Cards on SRP Modules in E120 and E320 Hardware Guide, Chapter

8, Maintaining the Router

Moving Line Modules Between Releases

The Juniper Networks ERX1440 Broadband Services Router employs a 40-Gbps SRP module and a new midplane. Release 3.3.2 was the first software release to support the 40-Gbps SRP module and midplane. Before you can transfer a compatible line module from a Juniper Networks ERX705, ERX710, or ERX1410 Broadband Services Router to an ERX1440 router, you must first load Release 3.3.2 or a higher release onto the current router, and then reboot the router to load the release onto the line modules. If you then move any of those line modules to an ERX1440 router, that router is able to recognize the line module.

Highest Release Able to Load

5.3.5p0-2 or the highest-numbered 5.x.x release

No limitation Not applicable ~234 MB

No limitation Not applicable ~256 MB

Cannot Load

6.x.x or higher-numbered release

Maximum Application Image

~172 MB

If you move a compatible line module from an ERX1440 router to an ERX705, ERX710, or ERX1410 router, the module loads properly in the new router regardless of the release.

2  Release Installation

SRP Module Memory Requirements

For Release 5.3.0 and higher-numbered software releases on ERX14xx models, ERX7xx models, and the Juniper Networks ERX310 Broadband Services Router, see ERX Module Guide, Table 1, ERX Module Combinations, for detailed information about memory requirements.

For Release 8.2.0 and higher-numbered software releases on Juniper Networks E120 and E320 Broadband Services Routers, see E120 and E320 Module Guide, Table 1, Modules and IOAs, for detailed information about memory requirements.

Hardware and Software Compatibility

For important information about hardware and software, see the document set as follows:

 Combinations of line modules to achieve line rate performance are in JunosE

System Basics Configuration Guide, Chapter 6, Managing Modules.

Release 10.3.2

 Compatibility of ERX router modules with software releases is in ERX Module

Guide, Table 1, ERX Module Combinations.

 Layer 2 and layer 3 protocols and applications supported by ERX router

modules are in ERX Module Guide, Appendix A, Module Protocol Support.

 Compatibility of E120 router and E320 router modules with software releases is

in E120 and E320 Module Guide, Table 1, Modules and IOAs.

 Layer 2 and layer 3 protocols and applications supported by IOAs on the E120

router and the E320 router are in E120 and E320 Module Guide, Appendix A, IOA Protocol Support.

Requesting Technical Support

Technical product support is available through the Juniper Networks Technical Assistance Center (JTAC). If you are a customer with an active J-Care or JNASC support contract, or are covered under warranty, and need post-sales technical support, you can access our tools and resources online or open a case with JTAC.

 JTAC Policies—For a complete understanding of our JTAC procedures and

policies, review the JTAC User Guide located at http://www.juniper.net/customers/support/downloads/710059.pdf

 Product Warranties—For product warranty information, visit

http://www.juniper.net/support/warranty/

 JTAC Hours of Operation—The JTAC centers have resources available 24 hours

a day, 7 days a week, 365 days a year.

Requesting Technical Support  3

JunosE 10.3.2 Release Notes

Self-Help Online Tools and Resources

For quick and easy problem resolution, Juniper Networks has designed an online self-service portal called the Customer Support Center (CSC) that provides you with the following features:

 Find CSC offerings:

http://www.juniper.net/customers/support/

 Search for known bugs:

http://www2.juniper.net/kb/

 Find product documentation:

http://www.juniper.net/techpubs/

 Find solutions and answer questions using our Knowledge Base:

http://kb.juniper.net/

 Download the latest versions of software and review release notes:

http://www.juniper.net/customers/csc/software/

 Search technical bulletins for relevant hardware and software notifications:

https://www.juniper.net/alerts/

 Join and participate in the Juniper Networks Community Forum:

http://www.juniper.net/company/communities/

 Open a case online in the CSC Case Manager:

http://www.juniper.net/cm/

To verify service entitlement by product serial number, use our Serial Number Entitlement (SNE) Tool located at https://tools.juniper.net/SerialNumberEntitlementSearch/

Opening a Case with JTAC

You can open a case with JTAC on the Web or by telephone.

 Call 1-888-314-JTAC

(1-888-314-5822 – toll free in the USA, Canada, and Mexico)

For international or direct-dial options in countries without toll-free numbers, visit http://www.juniper.net/support/requesting-support.html

4  Requesting Technical Support

Release Overview

Release 10.3.2

These Release Notes cover Release 10.3.2 of the system software for the Juniper Networks E Series Broadband Services Routers and contain the following sections:

 Release Highlights on page 7

 Early Field Trial Features on page 7

 Unsupported Features on page 9

 Release Software Protocols on page 10

 SRC Software and SDX Software Compatibility Matrix on page 12

 Known Behavior on page 12

 Known Problems and Limitations on page 35

Before You Start

 Resolved Known Problems on page 54

 Errata on page 58

 Appendix A, System Maximums, on page 69

If the information in these Release Notes differs from the information found in the published documentation set, follow these Release Notes.

These Release Notes include information about the changes between Releases

10.3.1 and 10.3.2. Before you use your new software, read these Release Notes in their entirety, especially the section Known Problems and Limitations. You need the following documentation to fully understand all the features available in Release

10.3.2:

 These 10.3.2 Release Notes, which describe changes between Release 10.3.1

and Release 10.3.2

 The 10.3.1 Release Notes, which describe the features available in Release

10.3.1

 The 10.3.x documentation set, which provides detailed information about

features available in Release 10.3.0

Release Overview  5

JunosE 10.3.2 Release Notes

The 10.3.x documentation set consists of several manuals and is available only in electronic format. You can print your own documentation using the PDF and HTML formats available at the Juniper Networks Technical Documentation Web site at www.juniper.net/techpubs. Refer to the following table to help you decide which document to use.

Task Document

Install the router ERX Hardware Guide

E120 and E320 Hardware Guide

Learn about modules ERX Module Guide

ERX End-of-Life Module Guide E120 and E320 Module Guide

Get up and running quickly E Series Installation Quick Start poster or ERX Quick Start

Guide E120 and E320 Quick Start Guide

Configure the router JunosE System Basics Configuration Guide

Configure physical layer interfaces JunosE Physical Layer Configuration Guide

Configure link layer interfaces JunosE Link Layer Configuration Guide

Configure line module redundancy, stateful SRP switchover, unified ISSU, VRRP, and interchassis redundancy (ICR)

Configure IP, IPv6 and Neighbor Discovery, and interior gateway protocols (RIP, OSPF, and IS-IS)

Configure IP routing services, including routing policies, NAT, J-Flow statistics, BFD, IPSec, digital certificates, and IP tunnels

Configure IP multicast routing and IPv6 multicast routing

Configure BGP, MPLS, Layer 2 service, and related applications

Configure policy management JunosE Policy Management Configuration Guide

Configure quality of service (QoS) JunosE Quality of Service Configuration Guide

Configure remote access JunosE Broadband Access Configuration Guide

Get specific information about commands

Monitor system events JunosE System Event Logging Reference Guide

Look up definitions of terms used in JunosE technical documentation

JunosE Service Availability Configuration Guide

JunosE IP, IPv6, and IGP Configuration Guide

JunosE IP Services Configuration Guide

JunosE Multicast Routing Configuration Guide

JunosE BGP and MPLS Configuration Guide

JunosE Command Reference Guide A to M JunosE Command Reference Guide N to Z

JunosE Glossary

6  Release Overview

Release Highlights

IPv6

Release 10.3.2

Release 10.3.2 is a maintenance release and includes the feature described in this section.

Category Feature

IPv6  Support for IPv6 Neighbor Discovery Router

Advertisements with Service Modules on ERX Routers

 Support for IPv6 Neighbor Discovery Router Advertisements with Service

Modules on ERX Routers

Service line modules and IPSec service modules (collectively referred to as Service Modules) on ERX14xx models, ERX7xx models, and the ERX310 router now support IPv6 Neighbor Discovery router advertisements for dynamically configured interfaces. When a router is configured for IPv6, it uses router advertisements to announce its presence to other nodes connected to it. Hosts discover the addresses of their neighboring routers by listening for these advertisements.

In addition to configuring Neighbor Discovery through the CLI, you can also use IPv6 profiles and RADIUS to configure Neighbor Discovery route advertisements for dynamically configured interfaces. If both an IPv6 profile and RADIUS are configured for Neighbor Discovery router advertisement, the prefix value returned in RADIUS VSA 26-129 takes precedence over the prefix specified in the IPv6 profile configuration.

Change in existing behavior: Existing feature extended as described here. In lower-numbered releases, IPv6 Neighbor Discovery was supported only on Fast Ethernet, Gigabit Ethernet, OCx/STMx GE/FE, and OCx/STMx ATM line modules on ERX routers. In this release, ERX routers that contain SMs support IPv6 Neighbor Discovery router advertisements on dynamic interfaces.

Early Field Trial Features

The features described in this section are present in the code but have not yet been fully qualified by Juniper Networks. These features are available only for field test purposes in this release. If you use any of these features before they have been fully qualified, it is your responsibility to ensure that the feature operates correctly in your targeted configuration.

Release Highlights  7

JunosE 10.3.2 Release Notes

DHCP

 Support for DHCP External Server, DHCP Local Server, DHCP Relay, and DHCP

Relay Proxy on POS Access Interfaces The following packet over SONET (POS) module combinations on E Series

routers now support configuration of the DHCP external server, DHCP local server, DHCP relay, and DHCP relay proxy applications, alone or in combination, when the POS module is the access interface:

 POS module combinations on the E120 router and the E320 router:

 ES2 4G LM with ES2-S1 OC12-2 STM4 POS IOA

 ES2 4G LM with ES2-S1 OC48 STM16 POS IOA

 POS module combinations on ERX14xx models, ERX7xx models, and the

ERX310 router:

 OCx/STMx POS line module with OC3-4 I/O module

 OCx/STMx POS line modules with OC12/STM4 I/O module

 OC48 line module with OC48 FRAME APS I/O module

In the current release, this feature is available for early field test purposes only.

You can configure DHCP external server, DHCP local server, DHCP relay, and DHCP relay proxy on these POS modules in either a virtual router (VR) or a VPN routing and forwarding instance (VRF).

As part of this feature, the pos keyword has been added to the existing ip dhcp-local limit command. To specify the maximum number of IP addresses that the DHCP local server application can supply to all POS access interfaces or to a specific POS access interface, in the range 0–96000, use the ip dhcp-local limit command with the new pos keyword. For example:

! Set the IP address limit for all POS access interfaces to 1000 host1(config)#ip dhcp-local limit pos 1000 ! Set the IP address limit for the specified POS access interface to 2000 host1(config)#ip dhcp-local limit interface pos 5/0/0 2000 ! Restore the IP address limit for all POS access interfaces to the default value, ! 48000 host1(config)#no ip dhcp-local limit pos

To display the maximum number of IP address leases available for POS access interfaces, use the existing show ip dhcp-local limits command. For example:

host1#show ip dhcp-local limits

***************************************** DHCP Local Server Address Limits ATM Limit - 48000 VLAN Limit - 48000 POS Limit - 1000 Ethernet Limit - 48000

8  Early Field Trial Features

Unified ISSU

 Service Manager Support for Unified ISSU

Unsupported Features

The JunosE Release 10.3.x documentation set describes some features that are present in the code but that have not yet been fully qualified by Juniper Networks. If you use any of these features before they have been fully qualified, it is your responsibility to ensure that the feature operates correctly in your targeted configuration.

The following features are present but unsupported in this release.

Release 10.3.2

Service Manager support for unified ISSU is limited in this release to early field trial purposes only.

E120 Router and E320 Router

 The ES2 10G LM and ES2 10G Uplink LM do not support layer 2 statistics for

VLANs.

 Subscriber Interfaces on the ES2 10G Uplink LM

You can configure dynamic subscriber interfaces and static subscriber interfaces on the ES2 10G Uplink LM using the CLI. However, configuring subscriber interfaces on the ES2 10G Uplink LM provides no benefit because access features such as per-subscriber QoS are unavailable on the module.

Multicast

 Unsupported IPv6 Data MDT Commands in CLI

The ipv6 pim data-mdt command and the show ipv6 pim data-mdt command are unsupported in the current release.

The IPv6 PIM Data MDT Configuration mode is unsupported in this release. The following commands appear in IPv6 PIM Data MDT Configuration mode but are unsupported in the current release:

 ipv6 pim join-filter  mdt-data-timeout

 ipv6 pim query-interval  route map

 mdt-data-delay  tunnel group-address-pool

 mdt-data-holdown  tunnel source

Policy Management

 External Parent Groups Unsupported on ES2 10G, ES2 10G Uplink, and ES2

10G ADV LMs External parent groups are not supported on the ES2 10G, ES2 10G Uplink, and

ES2 10G ADV LMs. If you create a policy that references an external parent group on these LMs, the system prevents you from attaching it to the LM interface and you receive an error message.

Unsupported Features  9

JunosE 10.3.2 Release Notes

Stateful SRP Switchover (High Availability)

 Stateful SRP Switchover for Certain Applications

The stateful SRP switchover feature has not been qualified for the following applications:

Remote Access

 DHCP proxy client

 L2TP dialout

Release Software Protocols

The following list identifies the major software protocols supported in this release. For detailed information about any protocol, see the configuration guides.

Core Routing Stack

Layer 2 Protocols

 Internet Protocol (IP) version 4 and version 6

 Transmission Control Protocol (TCP) for IPv4

 User Datagram Protocol (UDP) for IPv4 and IPv6

 Asynchronous Transfer Mode (ATM)

 Bridged Ethernet

 Bridged IP

 Cisco High-Level Data Link Control (Cisco HDLC)

 Ethernet

 Extensible Authentication Protocol (EAP)

 Frame Relay

 Layer 2 Tunneling Protocol (L2TP)

 Multilink Frame Relay (MLFR)

 Multilink Point-to-Point Protocol (MLPPP)

 Packet over SONET (POS)

 Point-to-Point Protocol (PPP)

 PPP over Ethernet (PPPoE)

 Transparent bridging

10  Release Software Protocols

Multiprotocol Label Switching (MPLS)

 Border Gateway Protocol (BGP-4)

 Label Distribution Protocol (LDP)

 Resource ReSerVation Protocol – Traffic Engineering Extensions (RSVP-TE)

Network Management Protocols

 Simple Network Management Protocol (SNMP) versions 1, 2c, and 3

Routing Protocols

 Border Gateway Protocol (BGP-4)

 Distance Vector Multicast Routing Protocol (DVMRP)

Release 10.3.2

Security Protocols

 Internet Group Membership Protocol (IGMP)

 Intermediate System–to–Intermediate System (IS-IS)

 Layer 2 Virtual Private Networks (L2VPNs)

 Mobile IP

 Open Shortest Path First (OSPF) version 2 and version 3

 Protocol Independent Multicast Protocol (PIM), including PIM dense mode, PIM

sparse mode, PIM dense-sparse mode, and PIM source-specific multicast

 Routing Information Protocol (RIP) version 2

 Virtual Private LAN Service (VPLS)

 Virtual Router Redundancy Protocol (VRRP)

 Internet Key Exchange (IKE)

 Internet Security Association and Key Management Protocol (ISAKMP)

 IP Authentication Header (AH)

 IP Encapsulating Security Payload (ESP)

 Network Address Translation (NAT)

Release Software Protocols  11

JunosE 10.3.2 Release Notes

SRC Software and SDX Software Compatibility Matrix

The SRC software offers the features of the SDX software on the C Series Controllers, a range of hardware platforms that use the Linux operating system. In contrast, the SDX software runs on Solaris workstations. The SRC software contains the features found in the associated SDX release plus additional features described in the SRC Release Notes.

The following table shows which versions of the SRC software and SDX software are compatible with specified versions of the JunosE Software.

SRC Software Release SDX Software Release Tested with JunosE Release

2.0.0 7.1.0 8.1.2, 8.2.2

2.1.0 Not applicable 9.1.0p0-1

3.0.0 Not applicable 9.0.0, 9.0.1, 9.1.1

3.1.0 Not applicable 9.2.0, 9.3.0, 10.0.0

3.2.0 Not applicable 10.1.0, 10.2.0, 10.3.0

Known Behavior

AAA

ATM

For more detailed information about SRC software and SDX software compatibility with JunosE releases, see the SRC Release Notes.

This section briefly describes E Series router behavior and related issues. In some cases the behavior differs from non–E Series implementations; in others the behavior is included to emphasize how the router works.

 Although you can use the max-sessions command to configure a maximum of

32,000 outstanding authentication/authorization requests to a RADIUS server, AAA internal limits prevent the actual number of outstanding authentication/authorization requests from exceeding 9600. These internal AAA limits apply only to authentication/authorization requests and not to accounting requests.

 The JunosE Software does not support accounting for ATM 1483 subscribers.

The atm1483 keyword for the aaa accounting default command is present in the CLI, but it is not supported.

 You cannot configure connection admission control (CAC) on an ATM interface

on which you have created a bulk-configured virtual circuit (VC) range for use by a dynamic ATM 1483 subinterface. Conversely, you cannot create a bulk-configured VC range on an ATM interface on which you have configured CAC. The router rejects these configurations, which causes them to fail.

12  SRC Software and SDX Software Compatibility Matrix

BGP

Release 10.3.2

Configuring CAC and bulk-configured VCs on the same ATM interface was supported in previous JunosE Software releases. As a result, If you are upgrading to the current JunosE release from a lower-numbered release, configurations that use CAC and bulk configuration on the same ATM interface continue to work. However, we recommend that you disable CAC on these ATM interfaces to ensure continued compatibility with future JunosE releases.

 The E Series router does not include the link-local IPv6 address in the next-hop

field of an MP-BGP update message carrying IPv6 routing information over IPv4 transport. This behavior is compliant with RFC 2545 but might have interoperability issues with other implementations that depend on a link-local IPv6 address in the next-hop field on a directly connected external BGP peering.

Work-aro u n d: Enable EBGP multihop configuration on the remote (non–Juniper Networks) peer.

BGP/MPLS VPNs

B-RAS

 The following message might be displayed under certain conditions:

bgpConnections (default,0.0.0.0): TCP error code xx (...) occurred while accepting inbound TCP connection

The message is generated when an unconfigured peer attempts to establish a TCP session with an E Series router and a valid route to the source address of the peer is absent from the router’s routing table.

If a valid route exists in the routing table, the following message is displayed when an unconfigured peer attempts to establish a TCP session with an E Series router; X.X.X.X is the source address of the unconfigured peer:

NOTICE 08/29/2001 16:50:11 bgpConnections (default,X.X.X.X): Inbound connection refused - no peer X.X.X.X configured in core

 NAT does not function properly with secondary routing table lookup (fallback

global) or global export mapping on the VRF.

 Pool groups are not supported; although the ip local pool group command

appears in the CLI, it is not supported.

 If the router is under a heavy load, the show profile command might take

longer than usual to execute.

Work-aro u n d: You can either delay examination of profiles until the router is less busy, or save a copy of the profile to a text file off the router.

Known Behavior  13

JunosE 10.3.2 Release Notes

CLI

 In Interface Configuration mode for a major interface, the CLI displays options

for protocols that are not supported by that interface type.

 When you issue the reload command on an ERX310 router, the command

might display a warning message that erroneously indicates that a synchronizing operation will be performed. Any references to synchronization that appear in command output or system messages do not apply to the ERX310 router, which does not support SRP module redundancy.

 The following commands have been deprecated in the JunosE Software and

might be removed completely in a future release. If a command has been deprecated for only a particular command mode, the table specifies any modes for which it is still available.

Deprecated Command Command Mode Preferred Command

aaa accounting interval Global Configuration aaa service accounting

interval and aaa user accounting interval

cablelength short Controller Configuration

channel-group description Controller Configuration

channel-group shutdown Controller Configuration

channel-group snmp trap link-status Controller Configuration

channel-group timeslots Controller Configuration

classifier-list Global Configuration ip classifier-list

clock rate Interface Configuration

color Policy List Configuration color in Classifier Group

Configuration mode

controller e1 Global Configuration

controller t1 Global Configuration

description Interface Configuration

Still available in Controller Configuration and VRF Configuration modes

fdl Controller Configuration

fdl carrier Controller Configuration

fdl string Controller Configuration

fdl transmit Controller Configuration

filter Policy List Configuration filter in Classifier Group

forward next-hop Policy List Configuration forward next-hop in

forward next-interface Policy List Configuration forward interface in

ip description

Configuration mode

Classifier Group Configuration mode

14  Known Behavior

Release 10.3.2

Deprecated Command Command Mode Preferred Command

hostname Domain Map Tunnel

client-name

Configuration

Still available in Global Configuration mode

hssi description Interface Configuration

hssi force dte acknowledge Interface Configuration

hssi internal-clock Interface Configuration

ignore dcd Interface Configuration

ignore link-state-signals Interface Configuration

[ no ] ike cr

l Global Configuration [ no ] ipsec crl

interface hssi Global Configuration

invert tx clock Global Configuration

ip dhcp-local cable-modem Global Configuration set dhcp-relay with the

strings docsis and pktc in the server-string mapping specification

ip mirror Global Configuration ip policy secure-input and

ip policy secure-output; for E120 and E320 routers, you must use these commands because the ip mirror command has been removed from the CLI for those routers.

ip policy local-input Interface Configuration,

None

Profile Configuration

[ no ] ipsec isakmp-policy rule Global Configuration [ no ] ipsec ike-policy-rule

ipv6 policy local-input Interface Configuration,

None

Profile Configuration

j1 Controller Configuration

license l2tp-session Global Configuration None

lineCoding Controller Configuration

log Policy List Configuration log in Classifier Group

Configuration mode

log severity debug dhcpLocalProtocolDecode

loopback Domain Map Configuration

Global Configuration log severity debug

dhcpCapture

local-interface

Still available in Controller Configuration and Interface Configuration modes

loopback remote { remote line fdl

Controller Configuration ansi | remote line fdl bellcore | remote line inband remote payload [ fdl ] [ ansi ] }

mark Policy List Configuration mark in Classifier Group

Configuration mode

Known Behavior  15

JunosE 10.3.2 Release Notes

Deprecated Command Command Mode Preferred Command

mark-de Policy List Configuration mark-de in Classifier Group

Configuration mode

mark-exp Policy List Configuration mark-exp in Classifier Group

Configuration mode

mark-user-priority Policy List Configuration mark-user-priority in

Classifier Group Configuration mode

mpls ldp discovery transport-address

mpls topology-driven-lsp ip-interfaces

[ no ] next-hop Policy List Configuration forward next-hop in

[ no ] next-interface Policy List Configuration forward interface in

nrzi-encoding Interface Configuration

no ospf enable Router Configuration ospf shutdown

policy-list Global Configuration ip policy-list

radius disconnect client Global Configuration

rate-limit-profile Policy List Configuration rate-limit-profile in Classifier

remote-loopback Controller Configuration

show controllers t1/e1 User Exec, Privileged Exec

show controllers t1 remote User Exec, Privileged Exec

show ike certificates User Exec, Privileged Exec show ipsec certificates

show ike configuration User Exec, Privileged Exec show ipsec ike-configuration

show ike identity User Exec, Privileged Exec show ipsec identity

show ike policy-rule User Exec, Privileged Exec show ipsec ike-policy-rule

show ike sa User Exec, Privileged Exec show ipsec ike-sa

show ip dhcp-external binding Privileged Exec show dhcp binding

show ip dhcp-external binding-id Privileged Exec show dhcp binding

show ip dhcp-local binding Privileged Exec show dhcp binding

show ip dynamic-interface-prefix Privileged Exec, User Exec None

show ip mirror interface Privileged Exec show secure policy-list

show license l2tp-session User Exec, Privileged Exec None

t1 lineCoding Controller Configuration None. This command never

Interface Configuration This command has no effect

in Interface Configuration mode. Now available in Global Configuration mode.

Global Configuration ldp ip-forwarding

Classifier Group Configuration mode

subscriber disconnect

The RADIUS Disconnect

Configuration mode has

been removed from the CLI.

Group Configuration mode

had any effect.

16  Known Behavior

Release 10.3.2

Deprecated Command Command Mode Preferred Command

traffic-class Policy List Configuration traffic-class in Classifier

Group Configuration mode

tunnel mpls autoroute announce bgp

tunnel mpls label-dist Interface Configuration,

unframed Controller Configuration

user-packet-class Policy List Configuration user-packet-class in

virtual-router Domain Map Configuration

yellow Controller Configuration

Interface Configuration,

Tunnel Profile Configuration

Still available in Privileged

Exec and Global

Configuration modes

None

Classifier Group Configuration mode

router-name

DHCP

The router displays a notice when you issue the command manually. If the command is in a script, the router automatically maps the deprecated command to the preferred command. If the deprecated command no longer has a function, then that command has no effect when you run a script containing the command.

 The show configuration command normally takes a long time to finish for

extremely large configurations. If you specify a search string (with the begin, exclude, or include options) with the command for a string that is not present

in the configuration, then the CLI session appears to be busy for a prolonged period. The CLI filtering feature for show commands does not speed up execution of the command.

 Configuring authentication on the DHCP local server requires that you first

disable the DHCP local server for standalone mode. Doing so removes your entire DHCP local server configuration. Therefore, if you want to configure authentication, do so before you have otherwise configured the DHCP local server.

 When you upgrade from a release numbered lower than Release 7.1.0, all

DHCP host routes previously stored in NVS are deleted. After the upgrade, DHCP clients must reacquire their IP addresses, which results in the new host routes being correctly stored in NVS.

DHCP External Server

 If you are using DHCP external server and a burst of client releases occurs

during a unified ISSU, some of the client releases might not be processed. [Defect ID 180178]

Known Behavior  17

JunosE 10.3.2 Release Notes

 When the DHCP relay agent application and the DHCP external server

application are configured in the same virtual router, using the ip dhcp-external server-sync command on an unnumbered IP interface does not

function as expected. When you issue the ip dhcp-external server-sync command in this configuration to create subscriber state information based on lease renewals when the external DHCP server and the router are unsynchronized, the router does not forward the ACK request from the DHCP server to the client because there is no route. [Defect ID 88562]

 When a bound DHCP client on a dynamic subscriber interface extends its IP

address lease by restarting the DHCP discovery process on its primary IP interface instead of by initiating the DHCP renewal process on its dynamic subscriber interface, the default behavior of the DHCP external server application to preserve the client’s dynamic subscriber interface was changed in the following JunosE releases to delete and re-create the client’s dynamic subscriber interface:

 Release 7.2.4p0-4 and all higher-numbered 7.2.x releases and patch

releases

 Release 7.3.4 and all higher-numbered 7.3.x releases and patch releases

 Release 8.0.4 and all higher-numbered 8.0.x releases and patch releases

 Release 8.1.2 and all higher-numbered 8.1.x releases and patch releases

 Release 8.2.3 and all 8.2.3 patch releases

 Release 9.0.0 and all 9.0.0 patch releases

 Release 9.0.1 and all 9.0.1 patch releases

 Release 9.1.0 and all 9.1.0 patch releases

If you are upgrading the JunosE Software on the router from any of these releases, you must explicitly issue the ip dhcp-external recreate-subscriber-interface command to configure the router to continue to delete and re-create the DHCP client’s dynamic subscriber interface.

NOTE: The DHCP external server application is unsupported in JunosE Release

8.2.1 and JunosE Release 8.2.2.

 DHCP external server may not be able to bind all DHCP clients when all of the

following conditions exist:

 DHCP external server and either DHCP relay or relay proxy are configured

 The client-facing and server-facing interfaces for DHCP external server and

 DHCP external server is configured to create dynamic subscriber interfaces.

18  Known Behavior

in separate virtual routers on an E320 router.

either DHCP relay or relay proxy are configured on the same ES2 4G LM.

Release 10.3.2

When these three conditions exist simultaneously, the ES2 4G LM may not be able to successfully process all DHCP packets. Although all clients may get bounded in DHCP relay or relay proxy, some clients may not get bounded in DHCP external server. (In a production environment it is highly unlikely for conditions 1 and 2 to exist because stand-alone DHCP external server is normally configured for a DHCP relay in a different chassis.)

Work-aro u n d: You can eliminate this issue by modifying any one of these conditions. For example, this issue does not exist with any of the following configuration modifications:

 Configure DHCP external server and either DHCP relay or relay proxy in

the same virtual router.

 Configure the client-facing and server-facing interfaces for DHCP external

server and either DHCP relay or relay proxy on the same ES2 10G LM instead of the same ES2 4G LM.

Dynamic Interfaces

Ethernet

 Configure the client-facing and server-facing interfaces for DHCP external

server and either DHCP relay or relay proxy on separate ES2 4G LMs.

 Dynamic IPv6 interfaces over static PPP interfaces are not supported.

 The hashing algorithm that selects the LAG member link is associated with the

IP address of the subscriber client to support QoS. Consequently, a particular flow is always hashed to the same link. When a member link is removed from a LAG bundle, traffic rate is disrupted and traffic flow is reduced. When the link goes down and then comes back up, the traffic flow is automatically redistributed.

 When counting bits per second on a Fast Ethernet or Gigabit Ethernet interface,

an E Series router includes 12 bytes for interpacket gap, 7 bytes for preamble, and 1 byte for start frame delimiter, for a total of 20 bytes (160 bits) per packet more than some non–E Series routers. This value therefore shows the total bandwidth utilization on the interface, including both data and overhead.

 To bridge unicast known-DA packets at line rate on both 2-Gbps ports of the

GE-2 line module or the GE-HDE module when paired with the GE-2 SFP I/O module, the minimum packet size must be at least 144 bytes.

When installed in the ERX1440 router, the GE-2 module delivers full bandwidth of 4 GB per line module (2 GB at the ingress and 2 GB at the egress) only when installed in slot 2 or slot 4, and when the SRP-40G+ module is used in the router. When installed in any other ERX1440 slot, the GE-2 module delivers a maximum bandwidth of 2 GB per line module (1 GB maximum at the ingress and 1 GB maximum at the egress). Therefore, of the maximum 24 possible ports for the module in an ERX1440 chassis (that is, two ports in each of 12 slots), full bandwidth is delivered only on a maximum of four ports (those in slots 2 and 4).

Known Behavior  19

JunosE 10.3.2 Release Notes

When installed in the ERX1440 router, the GE-HDE line module delivers full bandwidth of 4 GB per line module (2 GB at the ingress and 2 GB at the egress) only when installed in slot 2 or slot 4, and when the SRP-40G+ module is used in the router. When installed in any other ERX1440 slot, the GE-HDE module delivers a maximum bandwidth of 2 GB per line module (1 GB maximum at the ingress and 1 GB maximum at the egress). Therefore, of the maximum 96 possible ports for the module in an ERX1440 chassis (that is, 8 ports in each of 12 slots), full bandwidth is delivered only on a maximum of 16 ports (those in slots 2 and 4).

When the GE-2 line module or the GE-HDE line module is installed in either the ERX1440 router or the ERX310 router and both ports are active, line rate performance is achieved only with packets that are 174 bytes or larger. The line module might not achieve line rate with packets that are smaller than 174 bytes.

 Support for the 0x9200 S-VLAN Ethertype has been removed. You can no

longer specify the 9200 option with the svlan ethertype command.

Flash

Forwarding

When you upgrade to Release 7.1.0 or higher-numbered release, the software automatically transfers existing configurations that use the 0x9200 Ethertype to the 0x88a8 Ethertype.

 The show interface gigabitEthernet command output does not display the

following line of output for Gigabit Ethernet modules that do not support SFPs, such as the GE Single Mode I/O module and GE I/O Multi Mode I/O modules:

Primary/Secondary link signal detected Primary/Secondary link signal not detected

 Flash cards manufactured by Wintec are present on some currently deployed

routers. When you upgrade the JunosE Software on such routers, the firmware on the flash card controller is automatically updated during diagnostics. During this reboot, the software runs an integrity check on the file system to verify that the firmware update did not corrupt the contents of the flash card. This integrity check is an expected side effect of the enhanced firmware available in this release. The integrity check does not indicate a problem with the flash card or its contents.

 The hashing algorithm that selects the LAG member link is associated with the

20  Known Behavior

GRE

Hardware

Release 10.3.2

 When you shut down the only outgoing IP interface to the IP destinations of

GRE/IP tunnels, the tunnels remain in the up state rather than transitioning to down. As a consequence, all IP routes that use these tunnels as next hops also remain in the routing table.

 SRP modules with only 1 GB of memory do not work reliably in ERX7xx and

ERX14xx routers running JunosE Release 8.1.0 or higher, and may experience system resets due to an out of memory condition. However, the ERX310 router still supports 1 GB of memory in the SRP-SE10 module.

Work-aro u n d: Upgrade your SRP module memory to 2 GB for all ERX7xx and ERX14xx routers running JunosE Release 8.1.0 or higher.

 Do not include a not protocol clause in any classifier control list for policies

attached to an interface on an ES2 10G Uplink LM. The not protocol functionality is not available for this module.

 The ES2 10G LM and the ES2 10G Uplink LM do not support VLAN statistics in

the current release.

 PCMCIA NVS Card Caution

CAUTION: Before you insert or remove PCMCIA NVS (flash) cards from a running

router, we strongly recommend that you halt the SRP module or shut down the router. Failure to do this can result in file corruption in one or both cards.

 The 4XOC3 APS MULTIMODE and 4XOC3 APS SINGLE MODE I/O modules are

incompatible with the following versions of the OCx/STMx ATM and OCx/STMx POS line modules:

 OCx/STMx ATM line modules with assembly numbers 350-00039-xx,

350-80039-xx, and 350-90039-xx

 OCx/STMx POS line modules with assembly number 350-10039-xx

 When you configure 1:5 line module redundancy by using either the 4XOC3

APS MULTIMODE or 4XOC3 APS SINGLE MODE I/O module, the spare R-Mid OCX I/O module you install must have assembly number 350-00094-01 Rev. A01 or later. Spare R-Mid OCX I/O modules with an earlier assembly number are not supported for 1:5 redundancy configurations that use either the 4XOC3 APS MULTIMODE or 4XOC3 APS SINGLE MODE I/O module.

 There is a very small chance that some line modules can have an improperly

modified keying block that prevents the module from proper seating in the top slot of an older ERX7xx chassis or a preproduction ERX310 chassis. For example, this problem has been observed for an OCx/STMx module in slot 2 of an early-test ERX310 chassis.

Work-aro u n d: Remove the keying block to insert the module into the top slot, or insert the module into a different slot.

Known Behavior  21

JunosE 10.3.2 Release Notes

HDLC

 By design, on the cOC12/STM4 module you cannot delete a serial interface

while data for the interface is still enqueued. The enqueued data can drain only when the interface is operationally up. Therefore you must ensure that the interface is operationally up before you delete it. For example, if you have issued the shutdown command for the interface before you try to delete the interface, issue the no shutdown command, then delete the interface.

 When you upgrade from certain releases to JunosE Release 9.2.0p1-0 or

higher-numbered releases, descriptions configured for IP interfaces or IP subinterfaces are not retained across the upgrade when the descriptions are shorter than 9 characters in length. Additionally, VRF descriptions are not retained across the upgrade when the combined length of the VRF description and the VRF name is shorter than 9 characters. This behavior is seen during upgrades using a reload, stateful SRP switchover, or unified ISSU. Upgrades from the following releases are affected by this behavior:

 7.x.x

 8.0.x

 8.1.x, 8.2.x, and 9.x.x builds created before July 23, 2008

Examples of descriptions that are not retained across the upgrade:

host1(config-if)#ip description 12345678

host1(config)#ip vrf 123 host1(config-vrf)#description 45678

Examples of descriptions that are retained across the upgrade:

host1(config-if)#ip description longdescription

host1(config)#ip vrf longername host1(config-vrf)#description 45678

host1(config)#ip vrf 123 host1(config-vrf)#description longdescription

Work-aro u n d: Before you upgrade from an affected release to JunosE Release

9.2.0p1-0 or higher-numbered releases, ensure that you do the following:

 Change IP interface and subinterface descriptions to 9 or more characters.

 Change VRF descriptions, VRF names, or both so that the combination of

 The ip tcp adjust-mss command, which modifies the maximum segment size

for TCP SYN packets traveling through the interface, is not supported on the ES2 10G LM or ES2 10G Uplink LM.

22  Known Behavior

associated VRF names and descriptions consists of 9 or more characters.

Release 10.3.2

 If you have enabled ipInterface logging at a priority of debug, the

acknowledgment that an interface has been deleted from the line modules can return to the SRP module after the layers beneath IP have deleted their interfaces. Consequently, the original name of the interface cannot be resolved or displayed in the log, and the system instead displays the ifIndex of the IP interface. This behavior has no functional effect other than that the log is misleading. However, previous log events indicate that the interface deletion was beginning.

 When you want to use a configuration script to configure IP shared interfaces

that reference a physical interface, you must issue the service show configuration format 2 command before you generate the script. If the default show configuration format (format 1) is enabled instead, the generated script

cannot properly configure the IP shared interfaces because they are created before the physical interfaces. To properly configure the shared interfaces in this event, run the generated format 1 script twice.

 When you issue the show ip forwarding-table command for a particular slot, it

is normal and appropriate behavior when the Status field indicates Valid while the Load Errors field is increasing daily for that VR. The Load Errors field records any failed routing table distribution attempt as an error. Attempts can fail for many reasons during normal operation; a failed attempt does not necessarily indicate a problem. It is normal to see many load errors per day. If the Status field indicates Invalid, then the routing table distribution has failed constantly for that VR and a real problem exists. You might occasionally see a status of Updating. However, if the Status field always indicates Updating, then again the routing table distribution has failed constantly for that VR, and a real problem exists.

 The enhancement to the CLI to support unnumbered reference to any kind of

interface rather than just loopback interfaces has consequences such as the following: [Defect ID 47743]

 If the references to shared interfaces appear in the show configuration

output before the configuration for the interfaces they refer to, trying to restore such a configuration with a script generated from show configuration generates errors like the following:

% Error, line 3929: host1(config-if)#ip share-interface FastEthernet 3/0.2 % No such interface

 Unnumbered interfaces that refer to nonloopback interfaces (for example,

ip unnumbered fastEthernet 3/0.2) and that appear in the show configuration output before the interface referred to might generate

similar no such interface errors.

Work-aro u n d: Run the script twice.

Known Behavior  23

JunosE 10.3.2 Release Notes

IPSec

 When you shut down the only outgoing IP interface to the IP destinations of

IPSec tunnels, the tunnels remain in the up state rather than transitioning to down. As a consequence, all IP routes that use these tunnels as next hops also remain in the routing table. You can use dead keepalive detection (DPD) to avoid this situation. DPD must be active, which requires both IPSec tunnel endpoints to support DPD.

 During a warm restart after a system failover, the SRP module can take several

minutes to resume the normal exchange of UDP/IP packets to applications. During this restart time, the E Series router does not send or receive dead peer detection (DPD) keepalives, which are used to verify connectivity between the router and its peers. The length of the restart time depends on the number of interfaces—if the restart time is too long, remote peers might determine that the connection from them to the E Series router is broken and then shut down an IPSec tunnel that has DPD enabled. In the worst case, all IPSec tunnels might be shut down. [Defect ID 65132]

IS-IS

 When IS-IS is configured on a static PPP interface, the IS-IS neighbor does not

come up if you remove the IP address from the interface and then add the IP address back to the interface.

Work-aro u n d: When you remove and add back the IP address, you must also remove the IS-IS configuration from the interface and then add the configuration back to the interface by issuing the no router isis and router isis commands.

 When you run IS-IS on back-to-back virtual routers (VRs) in an

IS-IS-over-bridged-Ethernet configuration and do not configure different IS-IS priority levels on each VR, a situation can occur in which both VRs elect themselves as the designated intermediate system (DIS) for the same network segment.

This situation occurs because the router uses the same MAC address on all bridged Ethernet interfaces by default. When both VRs have the same (that is, the default) IS-IS priority level, the router must use the MAC address assigned to each interface to determine which router becomes the DIS. Because each interface in an IS-IS-over-bridged-Ethernet configuration uses the same MAC address, however, the router cannot properly designate the DIS for the network segment. As a result, both VRs elect themselves as the DIS for the same network segment, and the configuration fails. [Defect ID 72367]

Work-aro u n d: To ensure proper election of the DIS when you configure IS-IS over bridged Ethernet for back-to-back VRs, we recommend that you use the isis network point-to-point command in Interface Configuration mode to configure IS-IS to operate using point-to-point (P2P) connections on a broadcast circuit when only two routers (or, in this case, two VRs) are on the circuit. Issuing this command tears down the current existing IS-IS adjacency in that link and reestablishes a new adjacency.

24  Known Behavior

L2TP

Release 10.3.2

 L2TP peer resynchronization enables an L2TP failed endpoint to resynchronize

with its peer non-failed endpoint. The JunosE Software supports failover protocol and silent failover peer resynchronization methods. If you configure the silent failover method, you must keep the following considerations in mind:

 PPP keepalives—To ensure resynchronization of the session database, PPP

keepalives must be enabled on the L2TP data path. Without PPP keepalives, silent failover might disconnect an established session if there is no user traffic during failover recovery.

 Asymmetric routes on different line modules—Asymmetric routes whose

receive and transmit paths use I/O paths on different line modules can result in improperly handled line module control packets. If your network does include this type of asymmetric route, tunnels using these routes might fail to recover properly.

 NAT dynamic translation generation affects the LNS session creation time.

 If you create an L2TP destination profile profileName, establish tunnels with the

Line Module Redundancy

 On E120 routers and E320 routers, redundant IOAs have a temperature sensor,

When NAT dynamic translations and LNS sessions are created simultaneously, NAT dominates the CPU cycles of the tunnel-service module, resulting in a delay in the LNS session creation rate. The LNS session creation rate returns to its normal rate when NAT dynamic translations are no longer being generated. [Defect ID 53191]

Work-aro u n d: When signaling performance must be optimal, avoid the simultaneous configuration of NAT and LNS.

profile, and then remove the profile, you cannot subsequently create another destination profile using that same profileName until all the tunnels drain from the previous instance of this destination profile. If you do not wait, the E Series router displays a message similar to the following:

l2tp: Discarding incoming sccrq from vr default, remote address 192.168.100.1 no destination profile.

If you do not want to wait for the tunnels to drain, use a different name for the destination profile. [Defect ID 32973]

and the show environment all command lists the temperature of IOAs in their associated slots.

On ERX routers, redundant I/O modules do not have a temperature sensor. Therefore, the show environment all command output lists the primary I/O module temperature in the slot of the line module that is responsible for the I/O module.

Known Behavior  25

JunosE 10.3.2 Release Notes

MLPPP

 When you install an ES2-S1 Redundancy IOA with a hardware revision number

of -02 or less in slot 0 or slot 11 of the E320 router or in slot 0 or the E120 router, do not install an OCx/STMx ATM IOA or an OCx/STMx POS IOA in the lower (E320) or left (E120) adapter bay of slot 1 or slot 12. When the spare line module is controlling another slot and you revert back to the primary line module, the ATM or POS IOAs can become unusable or cause the line module to reset. [Defect ID 69760]

Work-aro u n d: This problem is not present for ES2-S1 Redundancy IOAs with a hardware revision number of -03 or higher.

 Do not configure both MLPPP fragmentation (with the ppp fragmentation

command) and IP fragmentation of L2TP packets (with the ip mtu command) on the same interface. Instead, you must choose only one of the fragmentation configurations by setting it to the necessary value and set the other fragmentation configuration to the maximum allowable value.

MPLS

Multicast

 Martini circuits configured on the ES2 10G LM act as true layer 2 tunnels,

without modifying the layer 2 headers. For this reason, Martini VLAN retagging is not currently supported.

 If you are upgrading to Release 7.1.0 or a higher-numbered release from a

release numbered lower than Release 7.1.0, and have inter-AS option B or C configurations, you must explicitly configure MPLS on all inter-AS links, as in the following example:

host1#configure terminal host1(config)#interface fastEthernet 2/0 host1(config-if)#ip address ... host1(config-if)#mpls

If you do not explicitly configure MPLS on the links, the inter-AS feature will not work properly.

 The ip dipe sg-cache-miss and ipv6 dipe commands are not intended or

supported for customer use, although they are visible in the User Exec and Privileged Exec modes respectively. These commands are intended to be used in a Juniper Networks internal lab environment for testing without a traffic generator.

 Do not configure a multicast group with more than 10,219 outgoing interfaces

(OIFS) on the same ES2 10G LM. The configuration of the multicast group’s OIF membership from the SRP module to the line module exceeds the size of a single message and is sent in fragments. Because of this fragmentation, the ES2 10G LM generates the following error message: [Defect ID 81768]

pc: 0x9e5c88: -> fatalPanic(void) offset: 0x8

26  Known Behavior

Packet Mirroring

Release 10.3.2

 The ES2 10G LM supports the packet mirroring feature when the module is

paired with the ES2-S2 10GE PR IOA, the ES2-S1 GE-8 IOA, or the ES2-S3 GE-20 IOA. When you use the ES2 10G LM with these IOAs, CLI-based interface-specific mirroring is not supported.

 When both interface-specific mirroring and user-specific mirroring are

configured on the same interface, the interface-specific secure policies take precedence. The interface-specific secure policies, which you manually attach using the CLI, override and remove any existing secure polices that were attached by a trigger action. If the interface-specific secure polices are subsequently deleted, the original trigger-based secure policies are not restored.

 Typically, when configuring packet mirroring, you configure a static route to

reach the analyzer device through the analyzer port. If the analyzer port is an IP-over-Ethernet interface, you must also configure a static Address Resolution Protocol (ARP) entry to reach the analyzer device. However, because only a single static ARP entry can be installed for a given address at any given time, when you are using equal-cost multipath (ECMP) links to connect to the analyzer device, the static ARP configuration does not provide failover if the link being selected fails or is disconnected. Therefore, to provide continued connectivity if the link fails when using ECMP, enable the ip proxy-arp unrestricted command on the next-hop router for each ECMP interface. As a result, when the link fails, the router sends an ARP request to identify the MAC address of the analyzer device and gets a response over the new link.

Policy Management

 The ES2 10G LM does not support the deprecated next-hop command.

 You cannot configure classifier lists that reference multiple fields for a VLAN

policy list on the ES2 10G Uplink LM or the ES2 10G LM, with the exception of traffic-class and color. The system incorrectly classifies VLAN policies that classify using multiple fields. For example, an invalid policy list that references multiple fields uses both color and user-packet-class, or one classifier list using color and another using user-packet-class.

 In rare cases, some policy configurations that use CAM hardware classifiers

from releases earlier than Release 7.1.0 can fail because they exceed the total hardware classifier entry size of 128 bits that was introduced in Release 7.1.0. For more information and examples of previous configurations, see JunosE

Policy Management Configuration Guide, Chapter 8, Policy Resources.

Known Behavior  27

JunosE 10.3.2 Release Notes

 Multiple Forwarding Solution Rules for a Single Classifier List in a Policy

Before Release 5.2.0, it was possible to configure a policy with multiple rules that specified forwarding solutions where all of these rules were associated with a single classifier list. This typically was a configuration error, but the CLI accepted it. Beginning with Release 5.2.0, the CLI no longer accepts this configuration.

 Multiple forwarding rules behavior for releases numbered lower than

Release 5.2.0:

 If multiple forward or filter rules were configured to reference the same

classifier list in a single policy, then all rules except the first rule configured were marked as eclipsed in the show policy command display. Next-interface and next-hop rules were treated in the same manner. The eclipsed rules were not applied.

 If a policy were configured with one rule from the [forward, filter] pair

and one rule from the [next-hop, next-interface] pair, and if both rules referenced the same classifier list, then no visible eclipsed marking occurred. However, these two rules were mutually exclusive, and only one of them defined the forwarding behavior. The rule action that was applied was in the order (from highest to lowest preference): next interface, filter, next hop, forward. The applied rule was the rule whose behavior was seen by forwarded packets.

For example, if a policy had both a next-interface and a filter rule, then the next interface was applied. If a policy had a next-hop and a filter rule, then the filter rule was applied.

 Multiple forwarding rules behavior for Release 5.2.0 and higher-numbered

releases:

Beginning with Release 5.2.0, the multiple rules behavior is designed so that when a forwarding solution conflict occurs within a policy, such as those described earlier, the second forwarding solution overwrites the preceding solution. That is, the last forwarding rule configured for the given classifier list within a policy is the forwarding behavior that is used. Also, a warning message is now displayed when this type of conflict occurs.

Example 1—In this example, the filter rule action overwrites the forward rule, and is therefore applied.

host1(config)#policy-list wstPolicyList host1(config-policy-list)#forward classifier-group svaleClacl1 host1(config-policy-list)#filter classifier-group svaleClacl1 WARNING: This rule has replaced a previously configured rule. host1(config-policy-list)#exit host1(config)#

28  Known Behavior

Release 10.3.2

Example 2—In this example, three forwarding solution conflicts result in rules being overwritten. The filter rule is the last rule configured, and is therefore applied.

host1(config)#policy-list bostTwo host1(config-policy-list)#forward classifier-group clacl5 host1(config-policy-list)#next-hop 1.1.1.1 classifier-group clacl5 WARNING: This rule has replaced a previously configured rule. host1(config-policy-list)#next-interface atm 1/0.0 classifier-group clacl5 WARNING: This rule has replaced a previously configured rule. host1(config-policy-list)#filter classifier-group clacl5 WARNING: This rule has replaced a previously configured rule. host1(config-policy-list)#exit host1(config)#

NOTE: When you upgrade the nonvolatile memory to Release 5.2.0 or later, the

upgrade removes eclipsed rules and rules whose behavior was not applied in the previous release. This removal ensures that the postupgrade forwarding behavior is the same as the preupgrade behavior.

PPP

PPPoE

QoS

NOTE: If you upgrade to Release 5.2.0 or later and then configure your router

using a script generated before Release 5.2.0, the postupgrade and preupgrade forwarding behaviors might not be the same. The new Release 5.2.0 configuration behavior is applied—the last policy rule configured for a given classifier list that specifies a forwarding behavior is the only rule remaining.

 The GE-2 line module does not support dynamic IP interfaces over static PPP

interfaces when the PPPoE subinterface is also static. The OC3/STM1 GE/FE line module does not support dynamic IP interfaces over static PPP interfaces when the ATM interface column is also static.

 On the ES2 4G LM, ES2 10G LM, and ES2 10G Uplink LM, data packets for

PPPoE are not counted at the PPPoE interface. Instead, PPPoE data packets are counted at the PPP interface that sits on the PPPoE interface. Use the show ppp interface command to display the data packets. Control packets for PPPoE are counted at the PPPoE interface; use the show pppoe interface command to display the control packets.

 When you are configuring compound shared shaping using explicit constituents

and you explicitly specify both a scheduler node and a queue stacked above the node as constituents of the shared shaper, the system selects the scheduler node (but not the queue) as the constituent.

Known Behavior  29

JunosE 10.3.2 Release Notes

 In JunosE Releases 7.1.x, 7.2.x, and 7.3.x, you can attach a QoS profile to

Ethernet interfaces that are configured in a link aggregation group (LAG) interface. However, beginning with JunosE Release 8.0.1, you can attach a QoS profile directly to the LAG interface. As of JunosE Release 8.0.1, the software restricts you from attaching a QoS profile to any Ethernet interfaces that are members of a LAG. [Defect ID 84632]

Work-aro u n d: Prior to upgrading from JunosE Releases 7.1.x, 7.2.x, or 7.3.x to JunosE Release 8.0.x or higher-numbered releases, remove the QoS profile from the Ethernet interface. When you have successfully upgraded to JunosE Release 8.0.x or higher-numbered releases, reattach the QoS profile to the LAG interface.

 In Release 7.2.0 and higher-numbered releases, you can configure the simple

shared shaper to select scheduler nodes in a named traffic-class group as active constituents.

By default, simple implicit shared shapers activate scheduler nodes in named traffic-class groups. The implicit constituent selection process is now the same for both simple and compound shared shapers.

RADIUS

This is a change in default behavior. For releases before Release 7.2.0, you could not configure scheduler nodes as active constituents of the simple shared shaper, except for the best-effort node.

To recover the default behavior available before Release 7.2.0, or to select active constituents that are different, use simple explicit shared shapers to select best-effort nodes only.

 JunosE Software provides extended commands for configuring the formats of

the RADIUS NAS-Port attribute (attribute 5) and the RADIUS Calling-Station-ID attribute (attribute 31) when the physical port value is greater than 7.

When the physical port value is greater than 7:

 An incorrectly configured NAS-Port attribute format results if you use either

the radius nas-port-format 0ssssppp or radius nas-port-format ssss0ppp command.

 An incorrectly configured Calling-Station-ID attribute results if you use

either the radius calling-station-format fixed-format command or the radius calling-station-format fixed-format-adapter-embedded

command.

Work-aro u n d: Use the following commands on routers that have line modules with more than 7 physical ports:

 To configure the NAS-Port attribute format, use the radius nas-port-format

 To configure the Calling-Station-ID attribute format, use the radius

30  Known Behavior

extended [ atm | ethernet ] command.

calling-station-format fixed-format-adapter-new-field command.

SNMP

Release 10.3.2

 SNMP MIBs

Information about all the SNMP MIBs (both standard and proprietary) that the router supports in this release is available in the MIB directory in the SW_Image_CD-2 folder of the JunosE Software image bundle, which you downloaded from the Juniper Networks website, that contains the release file for E120 and E320 routers. .

 Some Juniper Networks SNMPv1-formatted traps contain an incorrect object

identifier (OID) in the SNMPv1-Trap-PDU enterprise field. An SNMPv2 trap is typically identified by an OID that ends in the form ...x.y.z.0.n. This OID appears, in full, as the value of the snmpTrapOID.0 object in the varbind list of an SNMPv2-formatted trap. In the corresponding SNMPv1-formatted trap, this OID is broken down into subcomponents that fill the SNMPv1-Trap-PDU enterprise field (...x.y.z) and specific trap number field (n); the zero is unused.

The SNMPv1-formatted versions of the following Juniper Networks traps incorrectly contain ...x.y.z.0 in the SNMPv1-Trap-PDU enterprise field. That is, a zero is mistakenly appended to the correct enterprise OID value

Trap Name Expected Enterprise OID Enterprise OID Sent by SNMP Agent

junidApsEventSwitchover .1.3.6.1.4.1.4874.3.2.2.1.2 .1.3.6.1.4.1.4874.3.2.2.1.2.0

junidApsEventModeMismatch .1.3.6.1.4.1.4874.3.2.2.1.2 .1.3.6.1.4.1.4874.3.2.2.1.2.0

junidApsEventChannelMismatch .1.3.6.1.4.1.4874.3.2.2.1.2 .1.3.6.1.4.1.4874.3.2.2.1.2.0

junidApsEventPSBF .1.3.6.1.4.1.4874.3.2.2.1.2 .1.3.6.1.4.1.4874.3.2.2.1.2.0

junidApsEventFEPLF .1.3.6.1.4.1.4874.3.2.2.1.2 .1.3.6.1.4.1.4874.3.2.2.1.2.0

juniAddressPoolHighAddrUtil .1.3.6.1.4.1.4874.2.2.21.3 .1.3.6.1.4.1.4874.2.2.21.3.0

juniAddressPoolAbatedAddrUtil .1.3.6.1.4.1.4874.2.2.21.3 .1.3.6.1.4.1.4874.2.2.21.3.0

juniAddressPoolNoAddresses .1.3.6.1.4.1.4874.2.2.21.3 .1.3.6.1.4.1.4874.2.2.21.3.0

juniDhcpLocalServerPoolHighAddrUtil .1.3.6.1.4.1.4874.2.2.22.3 .1.3.6.1.4.1.4874.2.2.22.3.0

juniDhcpLocalServerPoolAbatedAddrUtil .1.3.6.1.4.1.4874.2.2.22.3 .1.3.6.1.4.1.4874.2.2.22.3.0

juniDhcpLocalServerPoolNoAddresses .1.3.6.1.4.1.4874.2.2.22.3 .1.3.6.1.4.1.4874.2.2.22.3.0

pimNeighborLoss .1.3.6.1.3.61.1 .1.3.6.1.3.61.1.0

Work-aro u n d: Use the OIDs that the SNMP agent sends.

SSH

 If the SRP module restarts when SSH is configured in a VR other than default,

SSH can sometimes become disabled. This happens if SSH attempts to bind with a VR before the VR comes back up after the restart. In this event, a warning message is generated to alert you to the fact that SSH is disabled in that VR. You must manually re-enable SSH either by accessing the console VTY or creating a Telnet session to the router.

Known Behavior  31

JunosE 10.3.2 Release Notes

Stateful SRP Switchover (High Availability)

 Additional processing is required to maintain and mirror the necessary state

information that enables subscriber sessions to stay up across an SRP failover. As a result, the performance of other control plane functions is reduced. Specifically, call setup rates are lower than in previous releases.

NOTE: Rapid call setup rates are most important following an outage that causes all

subscribers to drop, because many of the dropped subscribers will immediately attempt to reconnect. This type of outage occurs far less frequently with stateful SRP switchover.

We have ongoing development activities to characterize and improve call setup rates in future releases.

 Stateful SRP switchover remains inactive for 20 minutes after an initial

cold-start or cold-restart of the router. This delay enables the system to reach a stable configuration before starting stateful SRP switchover.

If you want to override the 20-minute timer, turn high availability off by using the mode file-system-synchronization command, and then on again by using the mode high-availability command.

 After a stateful SRP switchover, each layer of the interface columns must

reconstruct its interfaces from the mirrored information. While the interfaces are being reconstructed the SRP module cannot send or receive frames, including the protocol frames that signal graceful restart behavior with OSPF and IS-IS peers. If the configured hold time is too short, peers might mistakenly declare the adjacency down during the time in which the graceful restart is taking place. [Defect ID 65132]

Work-aro u n d: Increase the hold time to provide sufficient time for interface synchronization before the peers declare the adjacency down.

 For OSPF, use the ip ospf dead-interval command to set the hold time. We

recommend that you use Bidirectional Forwarding Detection (BFD) with a longer OSPF dead interval to achieve fast failure detection.

 For IS-IS, use the isis hello-interval and isis hello-multiplier commands to

set the hold time.

We recommend the following hold times for each protocol, based on the number of interfaces.

Recommended Hold Time

Interface Count

16000 or less 80 seconds 50 seconds

16001 to 32000 87 seconds 55 seconds

32001 to 48000 90 seconds 70 seconds

for OSPF

Recommended Hold Time for IS-IS

32  Known Behavior

Subscriber Interfaces

Release 10.3.2

 When IP tunnels are configured on a router enabled for stateful SRP switchover,

and the Service Module (SM) carrying these tunnels is reloaded, stateful SRP switchover transitions to the pending state. Stateful SRP switchover remains in the pending state for 10 minutes following the successful reloading of the SM. This amount of time allows for IP tunnel relocation and for the tunnels to become operational again on the SM. If an SRP switchover occurs while in the pending state, the router performs a cold restart.

Work-aro u n d: None.

 MAC address validation is not supported on either of the following:

 Packet-triggered subscriber interfaces that are created dynamically

 Packet-triggered subscriber interfaces that are managed on the primary IP

interface

System

A packet-triggered subscriber interface is created when the router receives a packet with an IP source address that does not match any entries in the demultiplexer table. When the router detects an unmatched packet, it generates a trigger event that determines whether to create a dynamic subscriber interface or configure an existing interface. To configure packet detection on the router, use the ip auto-detect ip-subscriber command.

 ERX routers display different behavior from E120 routers and E320 routers

when reporting modules as inactive.

ERX routers report a module as inactive when either:

 The I/O module is not present

 The primary line module is fully booted and ready to resume operation. In

this case, the standby is currently providing services.

E120 routers and E320 routers report a module as inactive when either:

 The primary line module has no IOAs.

 The primary line module has IOAs, but they have failed diagnostics.

 The standby line module has taken over for the primary line module, and

has control of the IOAs.

Because E120 and E320 routers can accommodate up to two IOAs per slot, at least one IOA must be online. If the second IOA fails, the line module is still online, but does not use both IOAs. You can ensure that every module is up and active in the system and not in a failed state by issuing the show version all command.

Known Behavior  33

JunosE 10.3.2 Release Notes

 In a router with a redundancy group that does not span quadrants (for example,

a three-slot redundancy group that spans slots 0, 1, and 2 in an ERX1410 chassis), the potential bandwidth of the redundant module is erroneously included in the quadrant bandwidth calculation. The show utilization command might indicate that the bandwidth is exceeded for modules in that group. [Defect ID 31034]

 When you copy the running configuration to NVS, the E Series router verifies

whether it has available space equal to at least twice the size of the .cnf file. If the space is insufficient, you cannot complete the copy. [Defect ID 40655]

Work-aro u n d: Make sufficient space on the NVS by deleting .rel or .cnf files.

 You cannot delete the ipInterface log after you delete the corresponding IP

interface. This does not prevent you from adding filters to other interfaces, nor does it prevent you from adding a filter to the same interface if you re-create it after deletion. [Defect ID 34842/45063]

System Logging

Tunneling

Work-aro u n d: Remove the filter before you remove the interface. Alternatively, if you remove the interface first, then you must remove all filters associated with all IP interfaces.

 If you enable engineering logs and set the control network logs to a level of

notice or lower (down from the default of error), you might see erroneous controlNetwork log messages like the following that are generated because SNMP polling on line modules (correctly) detects no fabric: [Defect ID 43168]

NOTICE 09/01/2002 18:47:52 CEST controlNetwork (slot 11): Control Bus Master slave error 0x5 while accessing slot

 When you configure the GE-2 line module, the GE-HDE line module, or the

ES2-S1 GE-4 IOA to operate as a shared tunnel-server module, the available bandwidth for tunnel services is limited to 0.5 Gbps per module.

 In releases numbered lower than Release 7.3.0, a dynamic tunnel-server port

was located on port 8 of the GE-HDE line module and GE-8 I/O module.

In Release 7.3.0 and higher-numbered releases, the dynamic tunnel-server port is located on port 9. When you upgrade to Release 7.3.0, any existing tunnel-server port configurations move from port 8 to port 9.

34  Known Behavior

Known Problems and Limitations

This section identifies the known problems and limitations in this release. For more information about known problems that were discovered at customer sites, you can log in to the JunosE Knowledge Base at https://www2.juniper.net/kb/, enter the defect ID number in the Search by Keyword field, and click Search.

ANCP

 On an E320 router that has established 3000 ANCP adjacencies with a client

and traffic is initiated, the following behavior occurs sporadically: All existing Telnet sessions are disconnected and no new Telnet sessions can be established for several minutes. [Defect ID 83872]

ATM

 When 16,000 PPPoA interfaces are configured on an OCx/STMx ATM line

module paired with an OC3-4 I/O module in an ERX14xx model, ERX7xx model, or ERX310 router, Ping traffic passing through the line module on the restarting router experiences an outage of 103 seconds, which is beyond the maximum limit, after a unified ISSU from JunosE Release 9.2.0p1-0 to

9.3.0b0-12. This outage does not occur when the same configuration is applied on a Gigabit Ethernet interface. [Defect ID 179794]

Release 10.3.2

 When you reload an ATM line module that is configured with NBMA circuits as

passive OSPF interfaces and that has established OSPF adjacencies and IBGP peers (configured on Gigabit Ethernet interfaces), the transmission of OSPF hello packets might be affected until all the NBMA interfaces have initialized. [Defect ID 46157]

Work-aro u n d: Either remove the passive OSPF interface statements on the NBMA interfaces, or statically configure the OSPF cost on the NBMA interfaces.

 When a mirror rule that triggers on username is employed for packet mirroring

of dynamic IP subscribers over ATM, removal of the rule does not disable packet mirroring. [Defect ID 175356]

Work-aro u n d: Use a mirror rule that triggers on account session ID rather than on username.

 The ATM peak cell rate (PCR) does not appear in the L2TP Calling Number AVP

for the first PPP session when the ATM shaping parameters were configured by RADIUS return attributes. [Defect ID 60933]

 When you issue the no atm atm1483 auto-configure upperInterfaceType

lockout-time command in Profile Configuration mode, the lockout time range

does not revert to the default values. [Defect ID 66544]

 When one or more ATM1483 attributes appears in a profile, the show

configuration include-defaults command fails to display the default values for

all possible ATM1483 attributes. [Defect ID 67157]

 The output of the show atm arp command displays only 4096 entries when the

line module is configured with more than 4096 NBMA ARP entries. [Defect ID 68849]

Known Problems and Limitations  35

JunosE 10.3.2 Release Notes

 When you use the no-authenticate keyword with the subscriber command to

prevent subscriber authentication so that the subscriber information can be used for DHCP option 82, suboption 2, the SRP module can reset. This issue does not occur when you use the no-authenticate keyword with the subscriber command as a way to perform a RADIUS configuration. [Defect ID 69865]

 When you perform an snmpWalk on the juniAtmSubIfVccTable, a response is

received for only a few of the total configured ATM subinterfaces when both of the following are true: the router has a line module that has some ATM-related configuration and the line module is in the disabled state. [Defect ID 80020]

 The baseline interface atm command fails for a VCD assigned by the router to

F4 OAM circuits. [Defect ID 174482]

 Unified ISSU is not supported when ILMI is configured on ATM interfaces.

[Defect ID 176007/177297/177122]

 ATM line modules reset after unified ISSU completes at the LAC when an

MLPPP bundle with three links are tunneled to the LNS. [Defect ID 178821]

 For PPPoE, the AAL5 inPacket Discards counter might increment erroneously

during call setup when a packet is passed directly to PPPoE for negotiation rather than being discarded. [Defect ID 51757]

Work-aro u n d: Incremental InPacketDiscards during call setup do not necessarily indicate a problem. However, we recommend you investigate an excessive count because that might indicate a connection that cannot be successfully brought up for some reason, such as RADIUS denials or improper configuration.

 The inPacketOctetDiscards counter in the output of the show atm vc atm

interface vcd command includes both inBytesDropped and inBytesUnknownProtocol statistics. The inBytesUnknownProtocol statistics should be displayed by a separate counter.

At the major interface level, the inPacketDiscards counter includes both inPacketsDropped and inPacketUnknownProtocol statistics. The inPacketUnknownProtocol statistics should be displayed by a separate counter. [Defect ID 44286]

 When you configure an ATM PVC where PCR = SCR and maximum burst size

is zero, the CLI returns an error indicating the burst size is invalid and it does not create the VC. [Defect ID 58357]

Work-aro u n d: Configure a CBR or a UBR plus PCR to create the circuit with the same parameters, depending on the desired priority for the traffic. CBR has a high priority and UBR plus PCR has a medium priority.

 The line module resets when you issue the show nbma arp command after you

have configured NBMA interfaces on an ATM line module. [Defect ID 178031/88491]

36  Known Problems and Limitations

BFD

Bridged Ethernet

CLI

Release 10.3.2

 After you have shut down the interface to the next hop (for the route that is

used to establish the BFD session), output for the show bfd session command erroneously indicates the shutdown interface as Management Interface (FastEthernet 6/0). [Defect ID 174271]

 The CLI erroneously permits you to configure bridge1483 encapsulation over

AAL5MUX IP even though that configuration is not supported. [Defect ID 35013]

 When you issue a run show ppp command, the CLI changes the configuration

level of the command line to Global Configuration mode rather than remaining at the level from which you issued the command. [Defect ID 52165]

DHCP

Work-aro u n d: Reissue the commands necessary to reenter the desired mode.

 The logout subscribers all command may not log out all of the DHCP

subscribers. Although the bindings and DHCP addresses are cleared, the show subscribers summary command may display some of the DHCP subscribers.

[Defect ID 180176]

Work-aro u n d: Try using the dhcp delete-binding all command. If this does not clear the subscribers, you may want to reload the line module to avoid further issues.

 DHCP packets are not forwarded to the DHCP server over dynamically created

interfaces when all of the following are true: [Defect ID 180343]

 DHCP relay or DHCP relay proxy is configured on the router.

 The client-facing interfaces are created dynamically using bridged Ethernet

over static ATM PVCs.

 The ip auto-detect ip-subscriber command is configured to enable packet

detection (packet triggering) and to trigger creation of dynamic subscriber interfaces.

Work-aro u n d: To avoid this defect, do all of the following:

 Do not use the ip auto-detect ip-subscriber command to enable packet

 Ensure that DHCP external server is configured in the virtual router.

 Ensure that the set dhcp relay inhibit-access-route-creation command is

triggering and to create dynamic subscriber interfaces

configured in the virtual router to prevent DHCP relay from installing host routes by default.

Known Problems and Limitations  37

JunosE 10.3.2 Release Notes

DHCP External Server

 With the unique client ID option enabled, when two clients with the same MAC

address or client ID are on an interface (where one client is connected over a router and relay and the other client is connected directly), sending a release request from one of the clients might terminate another client. [Defect ID 179759]

 The DHCP renew counter and release counter (displayed with the show ip

dhcp-external statistics command) are doubled rather than incremented for

each renew and release sent. [Defect ID 78802]

 When DHCP clients on an S-VLAN over bridged Ethernet stack configuration

send a decline message to a router that has DHCP relay and DHCP external server configured in the same VR, the clients bindings are not removed from the DHCP external server. [Defect ID 87086]

 When DHCP relay and DHCP external server are configured in the same VR

with server-sync enabled, bindings are not created in the DHCP external server when DHCP clients on an ATM bulk configuration interface stack and dynamic VLAN over Ethernet stack sends a renew message. [Defect ID 87087]

DoS Protection

Ethernet

 DHCP NAK packets are sent from a different VLAN than the one on which the

renew request is received on a router that is configured with dynamic VLANs, DHCP local server, and automatically created dynamic subscriber interfaces. This behavior occurs only after a link flap has taken place. [Defect ID 87062]

 A Telnet session closes when sending ipLocalBGP protocol traffic at a rate in the

range 4096–4200 packets per second (pps) with suspicious control flow detection enabled. [Defect ID 81974]

Work-aro u n d: When the traffic drops below 4096 pps, open a new Telnet session.

 When autonegotiation is enabled on Gigabit Ethernet interfaces with the speed

automatically negotiate command, issuing the link selection command logs

out subscribers. [Defect ID 87185]

Work-aro u n d: Use the following commands to enable auto link selection (GE port redundancy) and to switch from one port to the other port:

(config-if)#no link selection (config-if)#link failover force

File System

 When the primary SRP module is running JunosE Release 7.2.0 or

higher-numbered release and the standby SRP module is running a release numbered lower than Release 7.2.0 (as in a downgrade situation), you cannot display the files for the standby SRP module. [Defect ID 74104]

38  Known Problems and Limitations

Forwarding

Release 10.3.2

 The DoS protection egress rate is not accurate for the ES2 10G LM or the ES2

10G Uplink LM. [Defect ID 86925]

 When performing MAC validation to match subscriber demux entries with ARP

host entries, the ES2 10G LM does an exact match, rather than a longest prefix match. The subscriber demux entry source address must be a /32 value matching the IP address of an ARP entry in order to validate the MAC address against that ARP entry. [Defect ID 79641]

 When PPPoE over LAG is configured on an interface, and you re-execute the

PPPoE-over-LAG configuration before you delete the previous configuration, the ES2 10G LM line module resets. [Defect ID 179639]

Work-aro u n d: Before you can re-execute the PPPoE-over-LAG configuration, delete the existing PPPoE-over-LAG configuration.

 VPLS forwarding does not function properly when any of the following

conditions occur: [Defect ID 79856]

 MLPPP interfaces are used

 L2TP is used with sequence numbers enabled

 GRE is used with sequence numbers enabled

 Specifying S-VLAN ranges that partially overlap does not work. [Defect ID

81886/81918]

For example, the following configuration fails because S-VLAN 22 falls within the previously specified S-VLAN range of 21–23.

host1(config-if)#vlan bulk-config BulkDHCPCnfg1 svlan-range 21 23 401 426 host1(config-if)#vlan bulk-config BulkDHCPCnfg1 svlan-range 21 23 427 712 host1(config-if)#vlan bulk-config BulkCezarCnfg2 svlan-range 22 22 101 110

Work-aro u n d: You can do either of the following to avoid this problem.

 Specify each S-VLAN within the partially overlapping range as individual

S-VLANs, as in the following example:

host1(config-if)#vlan bulk-config BulkDHCPCnfg1 svlan-range 21 21 401 426 host1(config-if)#vlan bulk-config BulkDHCPCnfg1 svlan-range 22 22 401 426 host1(config-if)#vlan bulk-config BulkDHCPCnfg1 svlan-range 23 23 401 426 host1(config-if)#vlan bulk-config BulkDHCPCnfg1 svlan-range 21 21 427 712 host1(config-if)#vlan bulk-config BulkDHCPCnfg1 svlan-range 22 22 427 712 host1(config-if)#vlan bulk-config BulkDHCPCnfg1 svlan-range 23 23 427 712 host1(config-if)#vlan bulk-config BulkCezarCnfg2 svlan-range 22 22 101 110

 Use fully overlapping ranges rather than partially overlapping ranges, as in

the following example:

Known Problems and Limitations  39

JunosE 10.3.2 Release Notes

 When you attach certain hierarchical policies to subinterfaces as input policies,

secondary input policies, and output policies, incoming traffic loss can occur when the number of subinterfaces to which the policies are attached exceeds

4600. [Defect ID 86741]

 Ethernet statistics are incorrectly displayed for virtual port 8 of the ES2-S1 GE-8

IOA when that module is paired with the ES2 10G LM or the ES2 10G Uplink LM. [Defect ID 174784]

 The ES2 10G LM does not support framed routes configured for dynamic

subscriber interfaces. [Defect ID 83154]

 A memory leak of about two percent can occur on the ES2 10G LM and result in

a module reset when a large number of successive SRP switchovers take place with active DHCP clients. [Defect ID 86245]

 On the ES2 10G LM, a VLAN ID of 0 assigned to an interface can prevent

packets from being properly forwarded. [Defect ID 176125]

ICR

 When you configure ICR settings using a CLI macro, ICR commands are run in

quick succession. Sometimes, in such a scenario, the active SRP module resets if the event that causes the change of state of the VRRP instance reaches the ICR application before the ICR partition has been created. [Defect ID 184095]

Work-aro u n d: To avoid this problem, add an additional delay of one second using the sleep command in the macro, before the ip vrrp vrid enable command that is written in the macro to enable VRRP instance.

For example, consider a macro that contains the following commands:

ip vrrp vrid enable ip vrrp vrid icr-partition partitionId

Modify the macro, as follows, to add a delay of one second before the VRRP instance ID is enabled on the router and a delay of another second before the ICR partition that corresponds to the VRRP instance is created:

sleep 1 ip vrrp vrid enable sleep 1 ip vrrp vrid icr-partition partitionId

40  Known Problems and Limitations

IGMP

Release 10.3.2

 If you saved the running configuration of the router as a script file (.scr) and

execute the script to apply the settings on the router, ICR partition configuration commands in the .scr file might fail to add group members to the partition. This problem happens when the subscriber configuration in the .scr file is placed before the ICR partition configuration. However, this problem does not occur if you used a system configuration (.cnf) file to set up the router. [Defect ID 183913]

Work-aro u n d: To correct this problem and enable ICR partitions to be created correctly, make sure that you add the ICR partition configuration before the subscriber interface configuration in the .scr file. You can perform this reordering by modifying the .scr file to place the commands that configure subinterfaces for ICR partitions before the commands used for VLAN-based or S-VLAN-based grouping of subscribers.

 IGMPv3 proxy is not supported. [Defect ID 46038]

 The E Series router IGMPv3 proxy does not operate correctly in the presence of

IGMPv2 queriers. [Defect ID 46039/46045]

Work-aro u n d: If an IGMPv2 router is present on the network, do not configure version 3 with the ip igmp-proxy version command on that network interface. (Version 2 is the default.)

 The default value for the IGMPv3 proxy unsolicited report interval timer should

be 1 second rather than 10 seconds (the value for v2). [Defect ID 46040]

 When more than about 100,000 mapped OIF entries are configured on a virtual

router, issuing the no virtual router command for this and other virtual routers does not delete all the virtual routers within the deletion timeout interval (3 minutes). The virtual routers do eventually delete after this timeout. [Defect ID 63882]

 The E Series router does not log a warning when it receives an IGMPv2 query

but is not configured to use IGMPv2 on the interface. [Defect ID 46046]

 The ES2 4G LM can reset during a unified ISSU after you issue the issu start

command on a router configured with 8000 dynamic VCs and 8000 packet-triggered dynamic subscriber interfaces. [Defect ID 86761]

 If you have a large configuration on a hybrid module combination (OC3/STM-1

GE/FE line module with the OC3-2 GE APS I/O module), boot from NVS, and issue the slot erase command before booting has completed, the line module resets. [Defect ID 64104]

Work-aro u n d: To recover from the error, issue the slot reload command anytime after the module begins to reset.

Known Problems and Limitations  41

JunosE 10.3.2 Release Notes

 Deleting a VRF with 32,000 static subscriber interfaces fails to complete.

[Defect ID 82670]

Work-aro u n d: Use a macro to delete all static subscriber interfaces before you delete a VRF.

 IP interface statistics become inconsistent when a slot is reset, because some

traffic (such as control traffic) might be destined for the SRP module and is therefore counted elsewhere. [Defect ID 26697]

 The ip route permanent command does not work properly. [Defect ID 34303]

Work-aro u n d: Issue the ip alwaysup command to prevent the route from being

removed from the IP routing table after the interface is shut down.

 Traffic statistics for dynamic subscriber interfaces associated with Mobile IP

subscribers are not maintained as the subscribers move between Mobile IP nodes. Consequently the reported interface statistics are only the values accumulated since the last time a mobile node moved. [Defect ID 174509]

IPSec

 When a router configured with PIM on a virtual router undergoes multiple

warm restarts, the router subsequently hangs when an IP profile is configured. [Defect ID 176470]

 Logical port 20 on the ES2-S3 GE-20 IOA is reserved for the hardware multicast

packet replication feature. Logical port 20 and the hardware multicast replication feature are not supported on the ES2-S3 GE-20 IOA in this release. [Defect ID 84727]

 When you change the demultiplexer type on a primary interface that has 1024

demultiplexer table entries, the ICC ping threshold times out due to the removal of the old entries and the addition of the new ones. [Defect ID 182218]

 After an SRP stateful switchover completes on an ERX1410 router configured

with a single VPN routing and forwarding instance (VRF) and Network Address Translation (NAT), the SRP module that becomes active after the switchover resets. [Defect ID 180058]

 In a network where you use the tunnel signalling command to specify that the

security parameters and keys are configured manually for IPSec tunnels between VRs, the line modules reset when you delete and then re-create the IPSec tunnels. If you attempt to configure the tunnels again after the modules come back up, the line modules reset again.

Work-aro u n d: Configure the IPSec tunnels to use ISASKMP/IKE to negotiate SA and establish keys. [Defect ID 178304]

 When the LAC–to–LNS data path runs over an MPLS tunnel and the MPLS

tunnel originates or terminates at the LAC on an ES2 10G LM or an ES2 10G Uplink LM, the L2TP data traffic that originated or terminated at the LAC is discarded. [Defect ID 87260]

42  Known Problems and Limitations

IS-IS

Release 10.3.2

 IPSec tunnels created over Fast Ethernet interfaces fail to come up. [Defect ID

179256]

Work-aro u n d: After you create the tunnel, bounce the tunnel interface by issuing the shutdown/no shutdown command sequence. The tunnel comes up successfully.

 On a router configured with IS-IS and BFD, using the redundancy force srp

command to force an SRP switchover sometimes brings down IS-IS and BFD. [Defect ID 179287]

 IS-IS graceful restart (nonstop forwarding) does not work on the broadcast

interface when the restarting router is the designated intermediate system (DIS). Graceful restart works properly when the restarting router is not the DIS. [Defect ID 61496]

L2TP

MLD

MLPPP

 After a unified ISSU completes on a router functioning as an L2TP access

concentrator (LAC), traffic outages occur on the L2TP network server (LNS)-facing interface at the LAC in a configuration with 16,000 or 32,000 L2TP sessions over 500 tunnels. [Defect ID 180147]

 MLDv2 proxy is not supported. [Defect ID 46038]

 The E Series router MLDv2 proxy does not operate correctly in the presence of

MLDv1 queriers. [Defect ID 46039/46045]

Work-aro u n d: If an MLDv1 router is present on the network, configure version 1 with the ipv6 mld-proxy version command on that network interface. (Version 2 is the default.)

 The default value for the MLDv2 proxy unsolicited report interval timer should

be 1 second rather than 10 seconds (the value for v1). [Defect ID 46040]

 The E Series router does not log a warning when it receives an MLDv1 query

but is not configured to use MLDv1 on the interface. [Defect ID 46046]

 Failure to meet all of the following conditions for fragmented packets can result

in an incorrect operation during packet classification of the resulting reassembled packet: [Defect ID 50111]

 The initial fragment of a packet must either contain the entire MLPPP

 The fragment size of the peer must not be lower than 128 bytes.

 The initial fragment of a packet must be larger than subsequent fragments

packet or be greater than 128 bytes.

of that packet.

Known Problems and Limitations  43

JunosE 10.3.2 Release Notes

Mobile IP

 The @realm variable and the @ keyword alone do not work for the show ip

mobile binding command. [Defect ID 178653]

Work-aro u n d: You can use the user@realm syntax instead to display the

binding for a specific user, as in this example:

host1#show ip mobile binding nai xyz@example.com

Alternatively, you can display the entire Mobile IP binding table by issuing the show ip mobile binding command without additional options.

 The clear ip mobile binding nai @realm command does not work. [Defect ID

178652]

Work-aro u n d: Use the following version of the command instead:

MPLS

clear ip mobile binding nai

 The setup rate for Mobile IP client sessions decreases when you repeatedly

user@realm

bring a large number of sessions down and back up. [Defect ID 178760]

 When mobility bindings are present and you delete the Mobile IP home agent

with the no virtual router command, Mobile IP sends a RADIUS Acct-Stop message with no accounting statistics for the subscribers. [Defect ID 179081]

Work-aro u n d: Issue the clear ip mobile binding all command before you issue the no virtual router command. The clear command clears all the MIP subscribers and sends a RADIUS Acct-Stop message with the appropriate accounting statistics for the subscribers.

 When MPLS and IS-IS are configured on Ethernet interfaces, you cannot delete

the interface after the IP address is removed. This issue is not a problem on Ethernet VLAN interfaces. [Defect ID 66813]

Work-aro u n d: Issue the no mpls command to disable MPLS, then delete the interface.

 You cannot use an underscore character (_) in an MPLS tunnel name. [Defect ID

31291]

 If LSPs are announced into IS-IS, then the IS-IS routes cannot be used for

multicast RPF checks, because LSPs are unidirectional. [Defect ID 28526]

Work-aro u n d: Configure static RPF routes with native hops when LSPs are autoroute announced to IGPs.

 When the IPv4 explicit null label appears anywhere other than at the bottom of

the label stack, TTL expiration for this label is not handled correctly. As a result, the traceroute command does not work correctly for LSPs that have the IPv4 explicit null label anywhere other than at the bottom of the label stack. [Defect ID 76037]

44  Known Problems and Limitations

Multicast

Release 10.3.2

 When you issue a traceroute or trace mpls command to trace the paths of

router packets over MPLS interfaces on an ES2 10G LM or ES2 10G Uplink LM, the results include an extra unknown host. [Defect ID 174537]

 When you upgrade the router to JunosE Release 7.1.0 or a higher-numbered

release from a release numbered lower than Release 7.1.0, remote ATM layer 2 over MPLS circuits (also known as MPLS shim interfaces) that use Martini encapsulation are erroneously signaled with the control word attribute setting “Control word is not preferred by default”. Because control words are required for these MPLS shim interfaces, these circuits should instead be signaled with the setting “Control word is preferred by default”. [Defect ID 87048]

Work-aro u n d: To reinstate the proper setting (“Control word is preferred by default”), remove the MPLS shim interface from the ATM subinterface and then reconfigure it.

 When you configure more than 10,219 outgoing interfaces (OIFs) on the same

ES2 10G LM in a single multicast group, the configuration of the multicast group’s OIF membership from the SRP module to the line module exceeds the size of a single message and is sent in fragments. Because of this fragmentation, the ES2 10G LM generates the following error message: [Defect ID 81768]

Netflow

Policy Management

pc: 0x9e5c88: -> fatalPanic(void) offset: 0x8

 Flow sampling stops after a cold switchover on a router that is configured with

16 VRs and 32 interfaces per VR, when all flows are passing through the configuration (32 flows per VR). [Defect ID 74477]

Work-aro u n d: After the cold switchover is completed, reissue the ip flow-sampling-mode packet-interval 10 command on each VR, even though

the command is present in the configuration.

 The OC3/STM1 GE/FE line module might reset after sending Ethernet traffic

into a VPLS network in a test environment when Ethernet packets are flooded to remote VPLS bridges. [Defect ID 74540]

 On the E320 router, redirecting a large configuration with thousands of

interfaces to a script file can take a long time, perhaps exceeding a half-hour depending on the configuration. [Defect ID 80429]

 When you modify a rate-limit profile in Global Configuration mode after the

system is in a scaled state, changes to the rate-limit profile fail owing to lack of adequate policy resources. However, the changed value of the rate-limit profile is displayed in the output of the show rate-limit profile command. [Defect ID 79342/184107]

Work-aro u n d: To avoid this problem, do not update the rate-limit profile in Global Configuration mode in a scaled environment.

Known Problems and Limitations  45

JunosE 10.3.2 Release Notes

 When you attach a policy to an interface and the policy contains a classifier rule

that is unsupported for that interface, the CLI generates a message and the policy is applied. However, if an existing policy is already attached to that interface, then support for the new policy is not checked and the invalid policy is applied to the interface without warning. The results of this attachment are not predictable. [Defect ID 83562]

 If you have removed the last rule in a policy list, the router generates a warning

only after you exit Policy List Configuration mode. If you have removed the last policy rule and then added a classifier group before you exit Policy List Configuration mode, the router does not generate a warning about removing the last rule. [Defect ID 83834]

 When an MD-Port-Number value greater than 65,535 is sent to an E120 or

E320 router by means of a COA request, the value that is displayed in the UDP header of mirrored packets is the actual value minus 65,536. For example, an MD-Port-Number of 65,540 is displayed in the mirrored packet as 4. [Defect ID 84712]

 On the E120 and E320 routers, when a mirror rule is deleted after a CoA

request is sent with Juniper-LI-Action set to No-Action, the existing mirroring session is not disabled. [Defect ID 84826]

 No logs are created if you use the policy-list option with the log severity

severityValue policyMgrPacketLog policy-list policyListName command when logging policyMgrPacketLog events. [Defect ID 87203]

 When you reload the slot holding a GE-2 or GE-HDE line module and you have

configured more than about 2000 policies with rate limiting on that module, the drop count becomes more than expected. This unexpected drop count does not occur when you create the same configuration after you reload the router to the factory-default configuration. [Defect ID 175696]

 Unified in-service software upgrade (unified ISSU) is not supported on an E120

or E320 router if a hierarchical policy is attached to an external parent group. [Defect ID 177478]

 On E320 line modules that support secure policies, the SRP module enables

you to configure more than 1022 secure policies per module. [Defect ID 175756/180360]

Work-aro u n d: To avoid potential performance issues, we recommend that you do not configure more than 1022 secure policies per module.

 When you enter the no ip policy-parameter hierarchical parameterName

command or no ipv6 policy-parameter hierarchical parameterName command for a hierarchical policy-parameter type in Interface Configuration mode, the explicit reference of the parameter is removed successfully from the interface. However, the Referenced by interfaces field in the output of the show policy-parameter command does not change from the previously configured value to implicit. [Defect ID 183957]

Work-aro u n d: To correct this problem, remove the entire interface configuration.

46  Known Problems and Limitations

PPPoE

QoS

Release 10.3.2

 The E Series router erroneously accepts a PADI with a payload length of 0

instead of rejecting it and incrementing the PPPoE Invalid PAD packet length counter. [Defect ID 48356]

 You cannot paste a load-rebalance command string that uses the percent

option into a console or Telnet session from show configuration output because the output displays the % sign rather than the percent keyword that was submitted with the command and the percent sign is not recognized by the CLI. [Defect ID 81705]

 The router cannot resolve inconsistent requests caused by two QoS profiles that

modify the same scheduler property inconsistently. [Defect ID 61485]

Work-aro u n d: Avoid using two QoS profiles that modify the same scheduler property inconsistently, such as setting different values for the shaping rate for the same S-VLAN node.

 Simple shared shaping does not function correctly when it is used for 32,000

subscribers on an ES2 10G ADV LM. However, when you change the shaper to compound shared shaping, it works properly. Also, simple shared shaping does not function correctly for 16,000 subscribers on an ES2 10G ADV LM. [Defect ID 183512]

 When you perform an SNMP walk of the juniQosQueueStatistics MIB, a timeout

of up to 5 minutes ensues, during which the SRP module CPU utilization goes to 100 percent. [Defect ID 62252]

 The compound shared shaping feature does not work properly on egress

forwarding ASIC 2 (EFA2)-based ATM line modules when the shared shaper is queue-controlled as opposed to node-controlled. In a node-controlled configuration, in which you configure the shared-shaping rate on the best-effort scheduler node for the logical interface, integration of the EFA2 and ATM segmentation and reassembly (SAR) schedulers functions properly. However, in a queue-controlled configuration, in which you configure the shared-shaping rate on the best-effort queue for the logical interface, integration of the EFA2 and ATM SAR schedulers does not function properly. [Defect ID 69167]

Work-aro u n d: Use node-controlled compound shared shaping configured on the best-effort scheduler node with EFA2-based ATM line modules.

 Egress strict-priority packets may experience high latency on OC3/STM1 ATM

interfaces associated with the LM if you have shaped the port rate to more than

148.5 Mbps. [Defect ID 80378]

Work-aro u n d: To ensure low strict-priority latency, shape the port rate to no more than 148.5 Mbps.

 An error message regarding the qos-parameter instance

QosParameterDefinition is erroneously generated on an ERX1440 router when it is configured for L2C and QoS RAM and receives TLV 144 (DSL Type). The parameter instantiation actually functions properly. [Defect ID 80620]

Known Problems and Limitations  47

JunosE 10.3.2 Release Notes

 The CLI erroneously enables you to configure a QoS profile with the ethernet

node group command. [Defect ID 80861]

 The dynamic shaping rate calculated by the simple shared shaper can vary

because of the variation in the enqueue rate of the constituent queues. Even when the offered load is constant, the mechanism that calculates the enqueue rate introduces a slight variation, introducing a slight variation in the calculated dynamic shaping rate. [Defect ID 80938]

 On a router that has both an ES2 10G LM and an ES2 4G LM installed, the byte

count reported by the show fabric-queue egress-slot command is incorrect. The reported packet count is correct. [Defect ID 80965]

 On the E120 and E320 routers, you cannot attach QoS profiles to L2TP tunnels

by means of the CLI because the CLI does not pass the router ID to QoS. [Defect ID 81516]

 PPP sessions may be dropped if you change the shaping rate in a QoS profile

that affects thousands of circuits while QoS traffic affected by the profile is being forwarded. [Defect ID 82950]

Work-aro u n d: Do not change the shaping rate in a QoS profile that affects thousands of circuits while QoS traffic is using the profile.

 Egress traffic may be dropped on OC12/STM4 ATM interfaces if you have

shaped the port rate to more than 542 Mbps. [Defect ID 83785]

Work-aro u n d: Do not exceed a shaped port rate of 542 Mbps.

 Incorrect output is sent to the CLI the first time you enter Global Configuration

mode or issue the show subscribers command after viewing the VLAN subinterface over which a subscriber is connected. [Defect ID 84507]

 When QoS resources such as failure nodes and statistics bins are exhausted

because of insufficient memory available on the line module, the failures are properly logged, but additional log messages are generated every 10 minutes that report zero failures. [Defect ID 85105]

 The no qos-parameter-define definition command does not delete the

specified QoS parameter definition. [Defect ID 176844]

Work-aro u n d: Remove the interface and add the desired QoS parameters when you re-create the interface instead of deleting the definition.

 When you configure an E120 or E320 router with an ES2 10G ADV LM as a LAC

on one side of an L2TP tunnel and as a LNS to receive packets from the LAC on the other side of the tunnel, use RADIUS servers for authentication of subscribers on both sides of the tunnel, and attempt to bring up 16,000 subscribers on the L2TP tunnel, the LM that has subscribers on the LAC side of the tunnel resets when approximately 8000 logged-in subscribers are logged out and try to reestablish the connection. [Defect ID 184118]

48  Known Problems and Limitations

RSVP-TE

Service Manager

Release 10.3.2

 When 32,000 subscribers with 128,000 QoS queues are brought up on an ES2

10G or ES2 10G ADV LM, the LM resets if you modify the QoS profile that contains the best-effort IP or VLAN node rule, which references a scheduler profile configured with shared shaping rate, to a scheduler profile configured with legacy shaping rate. [Defect ID 183291]

Work-aro u n d: To avoid this problem, apply shared shaping on the best-effort queue, instead of on the best-effort node.

 After a stateful SRP switchover, forwarding of VPN traffic might not resume if

the core interface that carries an MPLS base tunnel with LDP over RSVP-TE flaps (constantly goes up and down). [Defect ID 182019]

 After you activate an independent IPv6 service and issue either of the following

commands on the default virtual router or any other virtual router, except the one on which the subscriber session is active, no output is displayed in the CLI interface: [Defect ID 181929]

SNMP

SONET

 show service-management subscriber-session subscriberName interface

interfaceType interfaceSpecifier

 show service-management subscriber-session subscriberName interface

interfaceType interfaceSpecifier service-session serviceName

This problem also occurs when a subscriber is authenticated using a RADIUS server for a combined IPv4 and IPv6 service in a dual stack.

Work-aro u n d: To avoid this problem, use the show service-management owner-session ownerName ownerId command to display subscriber session information based on the session owner, instead of the show service-management subscriber-session subscriberName interface

interfaceType command to display details on subscriber sessions.

 When you configure the router with an address pool that has two IP address

ranges, only the range that you configured first is available via the MIB. [Defect ID 61232]

 After an SRP switchover in a dynamic PPPoA configuration, the following error

message is displayed: [Defect ID 69733]

ERROR 08/19/2005 20:17:32 ipProfileMgr: doDcmIpIntfCreate : Creation of IP interface/address failed with status: Reference to Unnumbered Interface ERROR 08/19/2005 20:17:32 ipProfileMgr: doDcmIpIntfCreate : Creation of IP interface/address failed with status: Reference to Unnumbered Interface

Known Problems and Limitations  49

JunosE 10.3.2 Release Notes

 You cannot use the highest sensitivity bit-error rate setting (a value of 9)

SRC Software and SDX Software

 The SRC client does not prevent you from changing the name of the router

associated with APS/MSP alarm when you issue the threshold sd-ber command to configure a cOCx/STMx line module with cOC12-APS-capable IOAs. [Defect ID 72861]

Work-aro u n d: Use only a value in the range 5–8 when you issue the threshold sd-ber command for this module combination, as in the following example:

host1(config)#controller sonet 2/1 host1(config-controll)#aps group boston host1(config-controll)#aps protect host1(config-controller)#threshold sd-ber 6

while the client is connected to the SAE, resulting in SAE issues such as lost IP addresses and stale users. [Defect ID 77102]

Work-aro u n d: To change the router name while the SRC client is connected to the SAE, shut down the SRC client, change the name, then re-enable the SRC client.

 When multiple IPv6 interfaces are configured with policies attached from SRC,

only some of the IPv6 interfaces have the policies attached. [Defect ID 179498]

 Changing the SSCC status (enable/disable) while IPv6 interfaces are configured

might cause the SRP to reset. [Defect ID 179537]

Stateful SRP Switchover (High Availability) and IP Tunnels

 When you issue show commands as soon as the CLI is available after a stateful

SRP switchover, the commands can hang until the warm restart is completed. [Defect ID 85306]

 A packet loss sometimes occurs during stateful SRP switchover when you use

the ping command on a router that is configured for OSPF graceful restart, and is connected to a helper router in the OSPF IPv6 broadcast network and another helper router in the OSPF IPv6 backbone area. [Defect ID 181470]

 ERX7xx model, ERX14xx model, or ERX310 router:

 When you use the ping command with the IPv6 address of the helper

router in the multicast area as the destination address and the loopback address of the helper router in the backbone area as the source address, a packet loss of 2 seconds occurs for the first stateful SRP switchover. However, no packet loss occurs for successive stateful SRP switchovers.

50  Known Problems and Limitations

 When you use the ping command with the IPv6 address of the helper

router in the broadcast network as the destination address and no source address when stateful SRP switchover is performed the first time, an identical packet loss occurs. In this case too, no packet loss occurs during subsequent switchovers.

Subscriber Management

 When a dynamic GRE tunnel interface for Mobile IP relocates between SM

Release 10.3.2

 E120 router or E320 router

 When you use the ping command with the IPv6 address of the helper

router in the broadcast network as the destination address and the loopback address of the helper router in the backbone area as the source address, no packet loss occurs.

 When you use the ping command with the IPv6 address of the helper

router in the multicast area as the destination address and no source address, a packet loss of 1–2 seconds sometimes occurs during stateful SRP switchovers.

modules because the original SM reloads, Mobile IP deletes the relocated tunnel interface. [Defect ID 178399]

 When a subscriber has subscribed for a service, service session accounting

records always contains a default Acct-Terminate-Cause value of 10. This value remains unchanged even after you use the terminate-code command to configure a custom mapping between application terminate reasons and RADIUS Acct-Terminate-Cause attributes. [Defect ID 181043]

 MAC address validation not working for IP auto-detect sessions. [Defect ID

86446]

 Dynamic subscriber interfaces continue to remain in the down or not present

operational state in either of the following scenarios: [Defect ID 81269]

 If you configured a dynamic interface column, such as a dynamic bridged

Ethernet interface, dynamic VLAN interface, or an ATM interface, and when any one of the following conditions is satisfied:

 The major interface is bounced (shut down and reenabled)

 The major interface is shut down, which cause the dynamic VLAN

interfaces to be removed

 The physical link goes down and comes back up

 The line module is removed and reinserted

 If you configured a static interface column and removed the major interface

These scenarios might occur if you administratively issue the shutdown and no shutdown commands on the major interface in which the dynamic interface

column is configured.

Work-aro u n d: Use the no interface ip ipAddress command to remove the dynamic subscriber interfaces. Although you can use the dhcp delete-binding command to remove the DHCP binding and the dynamic subscriber interfaces, the DHCP client does not detect the binding removal and retains the lease.

Known Problems and Limitations  51

JunosE 10.3.2 Release Notes

System

 You cannot use a configuration script to boot the E320 router. [Defect ID

80304]

 If you hot swap an IOA and then remove it again before that IOA’s OK or FAIL

LED is illuminated, the associated line module can reset. [Defect ID 177313/177267]

Work-aro u n d: Ensure that you firmly insert the IOA into the chassis when you hot swap IOAs. Do not attempt a second hot swap of an IOA that has not indicated that it completed the first hot swap cycle. You can remove the IOA when either its OK or FAIL LED is illuminated.

 If your router is in Manual Commit mode, then you must issue the write

memory command before you perform an SRP module switch or a manual

reload. You must do this even when you have made no changes to the system configuration and the file systems are synchronized. [Defect ID 44469]

System Logging

TCP

Unified ISSU

 The show configuration category management syslog virtual-router default

command incorrectly displays logs for multiple syslog destinations when you add a log to only one syslog destination. The show log configuration command shows the correct configuration. [Defect ID 84082]

 The SRP module resets in any of the following circumstances on an E320 router

that has a line module configured with 5000 ANCP adjacencies: [Defect ID 176916]

 When you issue the issu initialization command from the console and

then reload the line module from a Telnet session.

 When the client that has the 5000 ANCP clients resets or an intermediate

switch resets.

 When you reload the line module.

 ATM line modules might reset after a unified ISSU when you attempt to add

memory to a VLAN subinterface in a large bridged Ethernet configuration. [Defect ID 178798]

 Under certain conditions, a unified ISSU from JunosE Release 9.2.0p1-0 to the

current release fails, and causes the SRP module and the ES2 4G LM to reset. [Defect ID 179975]

 Unified ISSU is not supported with 8000 bridged Ethernet interfaces on an

OC3/STM1 GE/FE ATM line module. [Defect ID 178809/178811/178797/ 179547]

52  Known Problems and Limitations

Release 10.3.2

 When any of the subsystems is excluded for a JunosE release, a unified ISSU to

that release fails to apply conversion code to all of the line modules. As a result, the line modules reset when they come up with that release. [Defect ID 179595]

Work-aro u n d: To prevent the exclusion of a subsystem file from the release, do the following before you upgrade to a new JunosE release that supports unified ISSU:

1. Issue the show subsystems file fileName.rel command, where fileName is the name of the software release file, to determine whether any of the subsystem files are excluded from the release.

2. For each subsystem file that is excluded, issue the no exclude-subsystem subsystemName command to remove the exclusion for the specified subsystem file.

If you copied the software release to the router before removing the subsystem file from the exclusion list, you must copy the release to the router again to ensure that all subsystem files are included in the release.

 During the unified ISSU operation, if you modify the router configuration after

the initialization phase of the process is completed and before you issue the issu start command to commence the upgrade phase of the unified ISSU process, the unified ISSU procedure completes successfully and the stateful SRP switchover process begins to synchronize between the active and standby SRP modules. When the synchronization process is in progress, the standby SRP module reloads for the second time. After the second reload of the standby SRP module ends, the synchronization process also ends properly.

Although the standby SRP module reloads for the second time when it is synchronized with the upgraded release, normal router operations, such as handling of subscriber sessions and forwarding of traffic, remain unaffected. [Defect ID 185517]

Known Problems and Limitations  53

JunosE 10.3.2 Release Notes

Resolved Known Problems

ATM

BGP

The following problems were reported open in Release 10.3.1 and have been resolved in this release, or have been resolved since the 10.3.1p0-3 patch release. For more information about particular resolved problems, you can log in to the JunosE Knowledge Base at https://www2.juniper.net/kb/, enter the defect ID number in the Search by Keyword field, and click Search.

 While doing HA switchover after ISSU with NBMA configuration, the OC3-4A

line card crashes. [Defect ID 184745]

 Performance issues after upgrading ATM cards to EFA2 architecture. [Defect ID

90861]

 SRP reset type: processor exception 0x700 (program) task: bgp [Defect ID

90031]

Bridged Ethernet

DHCP

 LM10 reset type: exception 0x68616c74 (halt) [Defect ID 90100]

 New bridge subint in status "NotPresent" [Defect ID 90096]

 Line module crashes when performing SNMP set operation - file: ethernet.cc,

line: 2687, task: scheduler [Defect ID 90708]

 SRP module reset type: panic, file: dhcpRelay.cc, task: dhcpRelay_dhcpRe, lr:

DhcpRelay::PbeSession::addClient [Defect ID 90261]

 DHCP external server does not update the lease time when the client sends a

renew request. [Defect ID 90685]

 DHCP Proxy client stops DORA process due to stale FSM/CSM entries. [Defect

ID 90765]

 DHCP Relay does not follow the standard criteria to distinguish BOOTP/DHCP

messages. [Defect ID 90779]

 UnACKnowledged DHCP RENEW request in DHCP Proxy Client leaks FSM pool

memory. [Defect ID 90891]

54  Resolved Known Problems

DHCPv6 Server

DoS Protection

Ethernet

Release 10.3.2

 E320 routers do not discard DHCPv6 Solicit and Rebind messages. [Defect ID

90798]

 Output value of "lease timer" has HEX cases and DECIMAL cases, as seen in

dhcpv6LsGeneral. [Defect ID 90799]

 JunosE does not send an error notification Reply to a DHCPv6 Request sent on

link local unicast. [Defect ID 90800]

 The control-plane policer protocol configuration is misaligned after upgrade.

[Defect ID 89170]

 LM4: reset type: panic; task: scheduler; file: vsm.cc - Vsm::addAciData [Defect

ID 90723]

Forwarding

HTTP Server

 LM4 reset type: panic, file: thernetHF1072.cc, line: 204, task: scheduler,

Ethernet::autoConfigVlanReceive [Defect ID 90857]

 Dynamic VLAN sub-interfaces fail to be created after shutdown and modify

VLAN bulk-config vlan-range. [Defect ID 89962]

 VLAN bulk-config cannot be removed after certain CLI sequences. [Defect ID

90214]

 VLAN subinterfaces fail to be created when LAG major port is down. [Defect ID

90606]

 LM10A crash - SRA-2048 - file: ic1Detector.cc ,line: 1013 ,message:

Ic1Detector::requestRecovery executed forced IC crashes [Defect ID 90704]

 LM10: Memory leak on "luCodeBranch code branch representations" when

classifier-group "*" references a rate-limit-profile. [Defect ID 90737]

 Malformed HTTP POST request received by HTTP server might cause software

panic. [Defect ID 90834]

IGMP

 Multicast forwarding stops when OIF is flapped; IGMP state on OIF shows up

no groups learnt but queries and reports are counted. [Defect ID 90314]

Resolved Known Problems  55

JunosE 10.3.2 Release Notes

IPv6

L2TP

 Executing BFD last-resort also enables RTR last-resort. [Defect ID 89510]

 100% CPU utilization after issuing the show ip socket statistics det command.

[Defect ID 90751]

 Few PPP sessions drop due to "aaa duplicate check" failure, even though the

/32 route is not present in SRP routing table. [Defect ID 90806]

 IPv6 ND over dynamic interface does not work on ERX if it acts as LNS. [Defect

ID 88378]

 ERX does not respond to L2TP control packet during ISSU. [Defect ID 90336]

 NTT: E320:10-2-1p0-1 release has wrong MIB "Default SNMP ifType" of L2TP

Line Module Redundancy

 Line card redundancy is broken when a primary line card is STUCK IN

MPLS

 LM10U reset type panic file: aptationLayer.cc line: 3159

OSPF

 OSPF adjacency might flap when ISSU is performed with OSPF default Hello

 BNGSTL:11-0-0b1-5 reset type: exception 0x300 (data access: protection

Policy Management

 Policy might fail to attach during subscriber login on LM10A if massive policy

interface. [Defect ID 90881]

BOOTING state and the router is reloading. [Defect ID 90898]

Hw2MplsAdaptationLayer::setEgressDirectNextHopLabel [Defect ID 90732]

and Dead interval timers. [Defect ID 90562]

violation (read attempt)) task: ospf_msgQueue_14. [Defect ID 185096]

update is in progress. [Defect ID 90739]

QoS

 “qos-parameter” is not cleaned up properly during stress tests. [Defect ID

90326]

 Service-manager qos-parameter value when modified by CoA/service-manager

is not cleaned up. [Defect ID 90559]

56  Resolved Known Problems

RSVP-TE

 SRP module reset type: processor exception 0x300 (read attempts) task:

rsvp_msgQueue_1 pc: 0x4d0547f0 -> Rsvp::doEndPointsChange [Defect ID 90246]

SRC Software and SDX Software

 On an ERX router configured for a LAG interface, the show sae interfaces and

the show sae subscribers command outputs display NasPortID as the interface name of DSI interface created. [Defect ID 90208]

SRP

 standby SRP reset, type: panic, file: 1xCmBackplane.cc, line: 1211,

lr-Ar1CmSwcm::allocStreamId() [Defect ID 90718]

Release 10.3.2

Resolved Known Problems  57

JunosE 10.3.2 Release Notes

Errata

This section identifies errors found in the JunosE documentation. These errors are corrected in subsequent releases of the affected documentation.

 The JunosE documentation for Release 6.0.5 and higher-numbered releases

states that when you upgrade the JunosE Software from Release 5.1.1 or lower-numbered releases, you must perform the upgrade in two stages: first to an intermediate release and then to the higher-numbered release that you want to run. This statement is only partially correct; you must perform a two-stage upgrade only when you upgrade from a new NVS card. This restriction is not applicable if you upgrade your software remotely through Telnet or FTP.

The imprecise information appears in the following JunosE documents:

 The Upgrading to JunosE Software Release 6.x.x or Higher-Numbered Releases

from Release 5.1.1 or Lower-Numbered Releases special hardware notice

dated 31 March 2006

 The Upgrading to JunosE Software Release 6.x.x or Higher-Numbered Releases

from Release 5.1.1 or Lower-Numbered Releases section in the JunosE Release Notes for the following releases:

 Releases 6.0.5, 6.1.4, and 6.1.5

 Releases 7.1.2, 7.1.3, 7.1.4, 7.2.x, 7.3.x

 Releases 8.x, 9.x, 10.x, 11.0.x, and 11.1.x

 The Upgrading to JunosE Software Release 6.x.x or Higher-Numbered Releases

from Release 5.1.1 or Lower-Numbered Releases section in ERX Hardware Guide, Chapter 8, Maintaining ERX Routers for the following releases:

 Release 7.3.x

 Releases 8.x, 9.x, 10.x, 11.0.x, and 11.1.x

 The Upgrading to JunosE Software Release 6.x.x or Higher-Numbered Releases

from Release 5.1.1 or Lower-Numbered Releases section in the JunosE System Basics Configuration Guide, Chapter 3, Installing JunosE Software for the

following releases:

 Release 7.3.x

 Releases 8.x, 9.x, 10.x, 11.0.x, and 11.1.x

 The Resolved Known Problems section of the JunosE 10.2.2 Release Notes failed

to mention in the IP section that defect ID 90081, High CPU utilization, was fixed in that release.

58  Errata

Release 10.3.2

 The Link Layer Maximums table (for the E120 and E320 routers) in Appendix A,

System Maximums, of the JunosE Release Notes, for the following releases

incorrectly stated that the maximum number of Ethernet S-VLANs per ES2-S2 10GE PR IOA with an ES2 10G LM or ES2 10G Uplink LM was 32,768:

 Releases 10.2.0 and 10.2.1

 Release 10.3.0

The correct limit for Ethernet S-VLANs per ES2-S2 10GE PR IOA on these LMs in these releases is only 16,384. The increased scaling maximum of 32,768 Ethernet S-VLANs per ES2-S2 10GE PR IOA, in these releases, applies only to the ES2 10G ADV LM.

 The SRC Software and SDC Software section in the Subscriber Management

Maximums table (for the ERX310, ERX7xx, and ERX14xx routers) in Appendix A, System Maximums, of the JunosE Release Notes, for the following releases

incorrectly mentioned that the maximum number of SRC interfaces supported on all the ERX routers was 48,000.

 Release 9.0.3

 Release 9.1.3

 Releases 9.2.2 and 9.2.3

 Releases 9.3.1 and 9.3.2

 Releases 10.0.1 and 10.0.2

 Releases 10.1.0, 10.1.1, and 10.1.2

 Releases 10.2.0 and 10.2.1

 Release 10.3.0

The correct maximum number of SRC interfaces supported on the different ERX routers is as follows:

 16,000 interfaces on the ERX310 router

 32,000 interfaces on the ERX705 and ERX710 router

 32,000 interfaces on the ERX1410 router

 48,000 interfaces on the ERX1440 router

Errata  59

JunosE 10.3.2 Release Notes

 ERX Module Guide, Appendix A, Module Protocol Support incorrectly states that

IPv6 multicast is supported on the following line modules:

 cOCx FO line module with cOC3/STM1 modules

 cOCx FO line module with cOC12/STM4 FO I/O modules

 COCx-F3 line modules with CT3/T3 12 I/O modules

 OCx/STMx ATM line modules with 4xDS3 ATM I/O modules

 CT3/T3-FO line modules with CT3/T3 12 I/O modules

 The ERX Module Guide fails to include a Module Name Cross-Reference

Information appendix. See Appendix B, Module Name Cross-Reference Information, in the 10.3.1 Release Notes for a single table that lists the module

label name, software display name, and the model number for each module for ERX routers.

 E120 and E320 Module Guide, Appendix A, IOA Protocol Support incorrectly states

that IPv6 multicast is supported on the ES2-S1 Service IOA module. IPv6 multicast is not supported on this module.

 The Environmental Requirements and Cabling Recommendations sections in

Appendix B, Installation Guidelines and Requirements, of the E120 and E320 Hardware Guide fail to mention that, based on the optical fiber cables used, you

may need to increase the physical space provided for the chassis. The strain relief and bend radius requirements of the optical fiber cables may exceed the specified depth of the chassis and the cable-management bracket.

 In JunosE System Basics Configuration Guide, Chapter 4, Configuring SNMP, the

Monitoring Interface Tables section contains a topic whose heading is incorrect.

Although the title of that section is show snmp group, the information described in it relates to the show snmp interfaces command.

The correct heading for that section is show snmp interfaces. The field descriptions and usage guidelines for the show snmp group command are available in a separate section under the Viewing SNMP Status main section of the same chapter.

 The Monitoring Suspicious Control Flow section in JunosE System Basics

Configuration Guide, Chapter 7, Passwords and Security, incorrectly contains a

section titled show snmp interfaces. The discussion in this section is only about commands to monitor suspicious control flows, while the show snmp interfaces command is used to view SNMP status.

The show snmp interfaces command is described in detail in the Monitoring Interface Tables section in Chapter 4, Configuring SNMP. However, the heading of the subtopic in that section incorrectly reads show snmp group, while the description is about the usage of the show snmp interfaces command.

60  Errata

Release 10.3.2

 The Configuring VRRP section in JunosE System Basics Configuration Guide,

Chapter 1, Planning Your Network and the Before You Configure IP section in JunosE IP, IPv6, and IGP Configuration Guide, Chapter 1, Configuring IP

erroneously refer to the JunosE IP Services Configuration Guide. These references are corrected to refer to the JunosE Service Availability Configuration Guide.

 The Detecting Corrupt File Configurations section in JunosE System Basics

Configuration Guide, Chapter 5, Managing the System fails to mention that if you

check the running configuration for corruption manually when auto mode is enabled, a warning message appears:

host1(config)#service check-config running-configuration WARNING: This command will cause config monitor to switch into manual mode. Proceed with current command? [confirm]

If you confirm you want to check the running configuration in manual mode or ignore the warning message, then manual mode is enabled.

 In JunosE IP, IPv6, and IGP Configuration Guide, Chapter 2, Configuring IPv6, the

Before You Configure IPv6 section fails to list all the modules that support IPv6.

You can find complete lists of modules that support IPv6 in the following appendixes:

 E120 and E320 Module Guide, Appendix A, IOA Protocol Support

 ERX Module Guide, Appendix A, Module Protocol Support

 In the Monitoring IGMP section in JunosE Multicast Routing Configuration Guide,

Chapter 2, Configuring IGMP, the bulleted list of field descriptions and output example for the show ip igmp interface command incorrectly display the field name for the number of multicast groups that the interface has discovered as "Groups learned". The correct label for this field is "Groups learnt".

 In the Configuring Graceful Restart section in JunosE IP, IPv6, and IGP

Configuration Guide, Chapter 6, Configuring IS-IS, the default time for the

restarting router to wait for the LSP database to synchronize and to reset the overload bit is incorrectly mentioned as 30 seconds. The correct value is 100 seconds for both the instances.

 In the JunosE Service Availability Configuration Guide for Releases 10.3.0, 11.0.0,

and 11.1.0, the Notes column for the Multicast Routing rows under IPv4 Multicast Routing and under IPv6 Multicast Routing in the Application Support for Stateful SRP Switchover table of Chapter 3, Managing Stateful SRP Switchover, stated incorrectly that only static recovery is supported. The correct information is as follows:

Stateful SRP switchover. During switchover, the system mirrors the multicast queue so that IP can use the same queue without needing to recreate a different connection. The multicast queues are also preserved during the switchover and graceful restart period to ensure that multicast data continues to be forwarded using the previously learned multicast forwarding state.

NOTE: Before JunosE Release 10.3.0, the Application Support for Stateful SRP

Switchover table was located in the JunosE System Basics Configuration Guide.

Errata  61

JunosE 10.3.2 Release Notes

 The ICR Overview section in JunosE 10.3.x Service Availability Configuration

Guide, Chapter 6, Managing Interchassis Redundancy, does not accurately

describe how the ICR master partition functions. The following paragraph accurately describes how the ICR master partition functions:

The subscriber broadcasts a PPPoE Active Discovery Initiation (PADI) packet to both the master and backup router. Only the master router processes the packet and creates the subscriber session. When the master router fails, VRRP switchover occurs and the backup router becomes the new master router. PPPoE data that now shows up on the new master is dropped because a session was not created for the subscriber on the new master. Eventually, the PPP session on the client expires and the client session is re-created with the new master.

 The ICR Overview section in JunosE 10.3.x Service Availability Configuration

Guide, Chapter 6, Managing Interchassis Redundancy, does not accurately define

an ICR partition. The following sentence accurately defines the ICR partition:

An ICR partition is a set of S-VLANs (and CVLANs) associated with a unique VRRP instance.

 The note in the ICR Overview section in JunosE 10.3.x Service Availability

Configuration Guide, Chapter 6, Managing Interchassis Redundancy does not

accurately describe what service providers must do to enable subscriber traffic to reach all interfaces. The following note accurately describes what to do:

NOTE: While deploying ICR, service providers must ensure that the aggregation

layer between the E Series router and access node (DSLAM) provides a broadcast domain per VLAN or per S-VLAN between active and backup routers. In the case of a direct connect model the access node must provide the broadcast domain per VLAN or per S-VLAN between the active and backup routers or instead provide an Ethernet switch such as EX Series Ethernet Switch between the access node and E Series router.

 The ICR Scaling Considerations section in JunosE 10.3.x Service Availability

Configuration Guide, Chapter 6, Managing Interchassis Redundancy incorrectly

states that ICR supports 1:3 or 1:N subscriber redundancy.

ICR supports 1:1 subscriber redundancy only.

 The Example: Configuring ICR Partitions That Group Subscribers by S-VLAN ID

section in JunosE 10.3.x Service Availability Configuration Guide, Chapter 6, Managing Interchassis Redundancy incorrectly uses the control-subinterface

keyword in Step 4 of the procedures that describe how a master and backup ICR partition can be configured. The correct keyword is control-interface, which controls traffic on the range of subinterfaces of the master and backup partitions. The following example of the command used to control traffic on subinterface ranges of the master and backup partitions is correct:

host1 (config-if)#ip vrrp 1 icr-par tition svlan-range 100 110 control-interface

62  Errata

Release 10.3.2

 In JunosE Service Availability Configuration Guide, Chapter 4, Configuring a

Unified In-Service Software Upgrade, the DHCP Relay Server row in the

Application Support for Unified In-Service Software Upgrades table is incorrectly marked as unsupported for the unified ISSU operation. DHCP relay has supported unified ISSU since JunosE Release 9.2.0.

 The DHCP Affected Behaviors section in JunosE Service Availability Configuration

Guide, Chapter 4, Configuring a Unified In-Service Software Upgrade, incorrectly

contains the DHCP Relay and DHCP Relay Proxy Prevent Unified ISSU section, which indicates that the DHCP relay and DHCP relay proxy applications do not support unified ISSU.

Both the DHCP relay and relay proxy applications began supporting unified ISSU in JunosE Release 9.2.0. Therefore, you need not unconfigure these applications from all virtual routers to perform a unified ISSU operation for JunosE Release 9.2.0 and higher-numbered releases. DHCP relay proxy continues processing of DHCP release requests during the unified ISSU to maintain server-client synchronization.

 In the Graceful Restarts section in JunosE BGP and MPLS Configuration Guide,

Chapter 1, Configuring BGP Routing, the following corrections and additions

apply to the working of the BGP graceful restart feature:

 The bgp graceful-restart and neighbor graceful-restart command sections

incorrectly state that advertisement of the graceful restart capability is enabled by default. The correct default behavior of these commands is that BGP graceful restart is disabled, and advertisement of the graceful restart capability is also disabled, both globally and for specified peers or peer groups.

 The bgp graceful-restart command section incorrectly mentions that you

can use the default keyword to restore the default condition, which causes the sending of advertisements of the graceful restart capability to be sent. However, the correct command behavior is that if you use the default keyword with the bgp graceful-restart command, advertisements of the graceful restart capability are not sent.

 The neighbor graceful-restart command section fails to state that using

the no version of this command disables advertisement of the graceful restart capability for specified peers or peer groups only. The no form of this command does not affect global advertisement of the graceful restart capability.

 In the Aggregating Routes section in JunosE BGP and MPLS Configuration Guide,

Chapter 1, Configuring BGP Routing, the references to the router, “Snakes”, in

the description that precedes the “Configuring Aggregate Addresses” figure are incorrect. The correct references for this router are “SanJose”, which is the label used for this router in the figure.

Errata  63

JunosE 10.3.2 Release Notes

 In the Detecting Peer Reachability with BFD section in JunosE BGP and MPLS

Configuration Guide, Chapter 1, Configuring BGP Routing, the

neighbor-bfd-liveness-detection command subsection incorrectly states the following:

If you remove the BFD configuration while the BGP sessions and the BFD protocol session are up, then the BGP session may flap because the remote BGP speaker cannot detect why the BFD session went down.

The correct behavior of BGP sessions, when you remove the BFD configuration for the last client tied to a BFD session, is as follows:

If you remove the BFD configuration while the BGP sessions and the BFD protocol session are up, BFD moves to the Admin Down state and communicates the change to the peer to enable the client protocols to handle this transition in a seamless manner without going down. For the Admin Down state to work, the peer, which receives the Admin Down state notification, must have the capability to distinguish between administratively down state and real link down.

NOTE: The BFD Admin Down state is used to bring down a BFD session

administratively, to protect client applications from BFD configuration removal, license issues, and clearing of BFD sessions.

 The Number of CAM Entries Per Allocation and Free Entries section in Chapter 8,

Policy Resources of the JunosE Policy Management Configuration Guide

inadvertently omitted the following paragraph:

The block that is common to the variable-sized entries is not available for 144-bit CAM entries when you configure any 288-bit or 576-bit entries, even though you remove them later. It is also not available for any 288-bit or 576-bit entries when the 144-bit entries spill into this block, even though you remove the 144-bit entries later.

 In the JunosE documentation for Release 9.3.x, 10.x.x, and 11.0.x, the

descriptions about support for DSL line rate information retrieval from access nodes for transmission to the SRC software, and the sscc update-policy-request enable command introduced by this feature are erroneously omitted. This feature was introduced in JunosE Release 9.3.0.

The information on this functionality and associated command is missing from the following guides in the JunosE documentation set:

 JunosE Broadband Access Configuration Guide—Configuring the SRC Client

section in Chapter 1, Configuring Remote Access, and Monitoring SRC Client Conection Status section in Chapter 2, Monitoring and Troubleshooting Remote Access

 JunosE Command Reference Guide N to Z

See Appendix C, Transferring DSL Line Rate Information from an Access Node to SRC Software in the JunosE 10.3.1 Release Notes for detailed information.

64  Errata

 The Note in the timeout command section in JunosE Broadband Access

Configuration Guide, Chapter 1, Configuring Remote Access fails to mention that

the router uses the backoff algorithm only for subscriber AAA accounting messages except Acct-On messages.

 In the Creating Multicast VPNs Using Default MDT section in Chapter 3,

Configuring PIM for IPv4 Multicast of the JunosE Multicast Routing Configuration Guide, the command line configuration examples in Step 8, Step 9, and Step 10

are incorrect. The following steps present the correct information:

 Step 8: Configure the IP interface (Tv) in PE2:CE1 as a numbered or

unnumbered PIM sparse-mode interface. Use the same address as the loopback interface, Lp in the parent router, PE2.

host1(config)#virtual-router PE2:CE1 host1:PE2:CE1(config)#interface tunnel gre:MTI-21 host1:PE2:CE1(config-if)#ip address 2.2.2.2 255.255.255.255 host1:PE2:CE1(config-if)#ip pim sparse-mode host1:PE2:CE1(config-if)#exit host1:PE2:CE1#

Release 10.3.2

 Step 9: Configure the IP interface (Tv) in PE2:CE2 as a numbered or

unnumbered PIM sparse-mode interface. Use the same address as the loopback interface, Lp in the parent router, PE2.

host1(config)#virtual-router PE2:CE2 host1:PE2:CE2(config)#interface loopback 0 host1:PE2:CE2(config-if)#ip address 2.2.2.2 255.255.255.255 host1:PE2:CE2(config-if)#exit host1:PE2:CE2(config)# host1:PE2:CE2(config)#interface tunnel gre:MTI-22 host1:PE2:CE2(config-if)#ip unnumbered loopback 0 host1:PE2:CE2(config-if)#ip pim sparse-mode host1:PE2:CE2(config-if)#exit host1:PE2:CE2#

 Step 10: Configure the Tp interfaces in the parent router, PE2, as

unnumbered PIM sparse-mode interfaces tied to the loopback interface, Lp.

host1(config)#virtual-router PE2 host1: PE2(config)#interface tunnel gre:MTI-21.mdt host1:PE2(config-if)#ip unnumbered loopback 0 host1:PE2(config-if)#ip pim sparse-mode host1:PE2(config-if)#exit host1:PE2(config)# host1:PE2(config)#interface tunnel gre:MTI-22.mdt host1:PE2(config-if)#ip unnumbered loopback 0 host1:PE2(config-if)#ip pim sparse-mode host1:PE2(config-if)#exit host1:PE2(config)#

 The term "Tunnel-Service Module" used in the JunosE Broadband Access

Configuration Guide and the JunosE Physical Layer Configuration Guide is no

longer valid. Juniper Networks support for the Tunnel Service Module (TSM) ended on December 31, 2009. The term "Service Module" replaces any references to the TSM.

Errata  65

JunosE 10.3.2 Release Notes

 In the Monitoring MLD section in JunosE Multicast Routing Configuration Guide,

Chapter 6, Configuring Multicast Listener Discovery, the following corrections

apply to the commands used to monitor MLD configuration:

 The description of the bgp graceful-restart command in the JunosE Command

Reference A to M incorrectly states that graceful restart is enabled by default. It

also erroneously states that using the default keyword with the bgp graceful-restart command restores the default condition, wherein graceful

restart is enabled. The correct default behavior of BGP graceful restart is that it is disabled, which prevents the advertisement of all BGP graceful restart capabilities. This default behavior has been applicable since the time this command was introduced.

In addition, the Note in this command section inaccurately states that the E Series router supports graceful restart only as a receiving peer and not as a restarting peer. However, E Series routers have supported graceful restart as restarting peers, in addition to functioning as receiving peers, since JunosE Release 5.1.0.

 In the JunosE Command Reference Guide A to M, the description of the mpls ldp

graceful-restart reconnect-time command incorrectly states that the no

version restores the default value of 120 seconds. The correct default value is 140 seconds.

 The description of the neighbor graceful-restart command in the JunosE

Command Reference N to Z incorrectly states that graceful restart is enabled by

default. The correct default behavior is that graceful restart is disabled. This default behavior has been applicable since the time this command was introduced in JunosE Release 7.1.0.

 The syntax of the show icr-partitions command in the JunosE Command

Reference Guide N to Z incorrectly states the following:

show icr-partitions [ brief ] [ filter ]

The correct syntax for this command is as follows:

show icr-partitions [ backup | dormant | master | summary ] [ filter ]

where:

 backup—Displays the total number of backup ICR partitions configured on

the router

 dormant—Displays the total number of dormant ICR partitions configured

on the router

 master—Displays the total number of master ICR partitions configured on

 summary—Displays a summary of all ICR partitions configured on the

 filter—See Filtering show Commands in the Command Reference Guide

66  Errata

the router

router

Release 10.3.2

 The tables in the Interface Types and Specifiers section of Chapter 1, Command

Reference Topics, in the JunosE Command Reference Guide erroneously state that

the maximum number of PPPoE subinterfaces per Ethernet (GE/FE) line module is 4094. The correct number for an ERX router is 8000 and for an E120 or E320 router, it is 16,000.

 The JunosE Command Reference Guide N to Z omits the description of the show

memory-management protection command, beginning with JunosE Release

7.1.0 in which it was introduced.

The show memory-management protection command is available in Privileged Exec mode. You can use this command to display the information about memory management protection of the router.

The syntax for this command is:

show memory-management protection [detail] [filter]

The command can be used only in the support mode and is not user configurable.

 In the JunosE System Event Logging Reference Guide, for the radiusClient event

category, the Error field incorrectly includes the following errors:

 Internal allocation error of base RADIUS server table

 Invalid virtual router for user's context

These errors were never implemented in any version of JunosE Software.

Errata  67

JunosE 10.3.2 Release Notes

68  Errata

Appendix A

System Maximums

This appendix presents current system maximums for various E Series hardware configurations. An E Series router does not simultaneously support all maximum configurations.

For some entries, early field trial (EFT) values are presented in addition to supported values. These values have not been fully qualified by Juniper Networks and are mentioned only for field test purposes in this release. EFT values are enclosed within parentheses with an EFT designation; for example, (96,000 EFT).

Modules referred to in the tables are identified by their physical label. For module specifications, including their identifying labels, see ERX Module Guide, Table 1, Module Combinations and E120 and E320 Module Guide, Table 1, Modules and IOAs.

System Maximums for ERX310, ERX7xx, and ERX14xx

General router values General System Maximums on page 70

Physical layer values Physical and Logical Density Maximums on page 71

Link layer values Link Layer Maximums on page 74

Routing protocol and performance values Routing Protocol Maximums on page 79

Policy and QoS values Policy and QoS Maximums on page 83

Tunneling values Tunneling Maximums on page 86

Subscriber management values Subscriber Management Maximums on page 88

Section

System Maximums for E120 and E320 Routers

General router values General System Maximums on page 91

Physical layer values Physical and Logical Density Maximums on page 92

Link layer values Link Layer Maximums on page 94

Routing protocol and performance values Routing Protocol Maximums on page 100

Policy and QoS values Policy and QoS Maximums on page 103

Tunneling values Tunneling Maximums on page 107

Subscriber management values Subscriber Management Maximums on page 109

Section

 69

JunosE 10.3.2 Release Notes

ERX310, ERX7xx, and ERX14xx System Maximums

The following tables provide system maximums for the ERX310, ERX7xx, and ERX14xx routers.

General System Maximums

Table 1 lists some general system maximums for the ERX routers.

Table 1: General System Maximums

ERX705 and

Feature ERX310

Fabric size 10 Gbps 5 or 10 Gbps 10 Gbps 40 Gbps

Chassis per 7-foot rack 14 6 3 3

NTP clients 1000 1000 1000 1000

NTP servers 300 300 300 300

Sessions per chassis (simultaneous Telnet + FTP + SSH, in any combination)

Virtual routers per chassis 1000 1000 1000 1000

Virtual routers per line module ASIC 1000 1000 1000 1000

ICR Partitions per chassis 640 640 640 640

ICR Partitions per line module 64 64 64 64

30 30 30 30

ERX710

ERX1410 ERX1440

70  ERX310, ERX7xx, and ERX14xx System Maximums

Physical and Logical Density Maximums

Table 2 lists physical and logical density maximums for the ERX routers. The following notes are referred to in Table 2:

1. Wire rate indicates the port density that supports maximum (wire-rate) performance. Oversubscribed indicates the port density possible when you are willing to accept less than wire-rate performance by oversubscribing the available fabric bandwidth. The ERX310 and ERX1440 routers do not support oversubscription; port densities for these models indicate wire-rate performance.

2. When you pair the GE-2 or GE-HDE line module with the GE-2 SFP I/O module on the ERX1440 router, you can terminate up to 24 Gigabit Ethernet interfaces. Slots 2 and 4 on the ERX1440 router support two Gigabit Ethernet interfaces at wire rate; the remaining 10 slots support one Gigabit Ethernet interface at wire rate. On the ERX310 router, all four ports (active and redundant) are at wire rate.

Appendix A: System Maximums

For more information about bandwidth and line-rate considerations for the GE-2 line module or the GE-HDE line module and their corresponding I/O modules on E Series routers, see JunosE Physical Layer Configuration Guide, Chapter 5, Configuring Ethernet Interfaces.

3. When you pair the GE-HDE line module with the GE-8 I/O module on the ERX1440 router, you can terminate up to 96 Gigabit Ethernet interfaces. Slots 2 and 4 on the ERX1440 router support two Gigabit Ethernet interfaces at wire rate; the remaining 10 slots support one Gigabit Ethernet interface at wire rate. On the ERX310 router, only two Gigabit Ethernet interfaces per slot are at wire rate; therefore, only four Gigabit Ethernet interfaces are at wire rate for the entire router.

For more information about bandwidth and line-rate considerations for the GE-HDE line module and the GE-8 I/O module on E Series routers, see JunosE Physical Layer Configuration Guide, Chapter 5, Configuring Ethernet Interfaces.

4. The OC3/STM-1 GE/FE line module and OC3-2 GE APS I/O module combination does not support line rate for Gigabit Ethernet interfaces.

Table 2: Physical and Logical Density Maximums

Feature ERX310

Physical density wire rate/oversubscribed

(See Note 1 on page 71.)

Channelized OC3 ports per chassis (cOC3 STM1 FO I/O modules)

Channelized OC12 ports per chassis (cOC12 STM4 FO I/O modules)

Channelized T3 ports per chassis (CT3/T3 12 I/O modules)

E3 (unchannelized) ports per chassis (CT3/T3 12 I/O modules)

8 16/20 32/48 48

2 4/5 4/12 12

24 48/60 96/144 144

ERX705 and ERX710

ERX1410 ERX1440

ERX310, ERX7xx, and ERX14xx System Maximums  71

JunosE 10.3.2 Release Notes

Table 2: Physical and Logical Density Maximums (continued)

Feature ERX310

Fast Ethernet (10/100) ports per chassis (FE-8 I/O and FE-8 SFP I/O modules)

Gigabit Ethernet ports per chassis (GE I/O modules)

Gigabit Ethernet ports per chassis (GE-2 SFP I/O modules)

(See Note 2 on page 71.)

Gigabit Ethernet ports per chassis (GE-8 I/O modules)

(See Note 3 on page 71.)

Gigabit Ethernet ports per chassis (OC3-2 GE APS I/O module)

(See Note 4 on page 71.)

OC3/STM-1 ATM ports per chassis (OC3-4 I/O modules)

OC3/STM-1 ATM ports per chassis (OC3-2 GE APS I/O module)

OC3/STM-1 POS ports per chassis (OC3-4 I/O modules)

OC12/STM-4 ATM ports per chassis (OC12 STM4 I/O modules)

OC12/STM-4 POS ports per chassis (OC12 STM4 I/O modules)

OC48/STM16 POS ports per chassis (OC48 FRAME I/O modules); ERX1440 router only

T3 (unchannelized) ports per chassis (4xDS3 ATM I/O modules)

T3 (unchannelized) ports per chassis (CT3/T3 12 I/O modules)

ERX705 and ERX710 ERX1410 ERX1440

16 32/40 32/96 96

2 4/5 4/12 12

4 – – 14/24

4/16 – – 14/96

2 4/5 4/12 12

8 16/20 32/48 48

4 10 24 24

8 16/20 16/48 48

2 4/5 8/12 12

2 4/5 4/12 12

–––2

8 16/20 32/48 48

24 48/60 96/144 144

Logical density per chassis

Logical E1s per chassis 504 1260 3024 3024

Logical E3s per chassis 24 60 144 144

Logical fractional E1s (DS0) per chassis 4000 10,000 24,000 24,000

Logical fractional T1s (DS0) per chassis 4000 10,000 24,000 24,000

Logical OC3/STM1 per chassis 8 20 48 48

Logical OC12/STM4 per chassis 2 5 12 12

Logical OC48/STM16 per chassis (ERX1440 router only)

Logical T1s per chassis 672 1680 4032 4032

Logical T3s per chassis 24 60 144 144

72  ERX310, ERX7xx, and ERX14xx System Maximums

–––2

Appendix A: System Maximums

Table 2: Physical and Logical Density Maximums (continued)

ERX705 and

Feature ERX310

Logical density per module combination (specified line module and all supported I/O modules)

Logical E1s per cOCx/STMx F0 line module 252

63 per OC3/STM1

Logical E3s per COCX-F3 line module 12 12 12 12

Logical fractional E1s (DS0) per cOCx/STMx F0 line module

Logical fractional T1s (DS0) per cOCx/STMx F0 line module

Logical fractional T1s (DS0) per CT3/T3-F0 line module 1992

Logical fractional T3s (DS3) per COCX-F3 line module 12 12 12 12

Logical T1s per cOCx/STMx F0 line module 336

Logical T1s per CT3/T3-F0 line module 336

Logical T3s per COCX-F3 line module 12 12 12 12

Logical T3s per cOCx/STMx F0 line module 12

Logical T3s per CT3/T3-F0 12 12 12 12

Logical T3s per OCx/STMx/DS3-ATM line module with 4xDS3 ATM I/O module

2000

500 per OC3/STM1

2000

500 per OC3/STM1

166 per T3

84 per OC3/STM1

28 per T3

3 per OC3/STM1

4444

ERX710 ERX1410 ERX1440

252

63 per OC3/STM1

2000

500 per OC3/STM1

2000

500 per OC3/STM1

1992

166 per T3

336

84 per OC3/STM1

336

28 per T3

3 per OC3/STM1

252

63 per OC3/STM1

2000

500 per OC3/STM1

2000

500 per OC3/STM1

1992

166 per T3

336

84 per OC3/STM1

336

28 per T3

3 per OC3/STM1

252

63 per OC3/STM1

2000

500 per OC3/STM1

2000

500 per OC3/STM1

1992

166 per T3

336

84 per OC3/STM1

336

28 per T3

3 per OC3/STM1

ERX310, ERX7xx, and ERX14xx System Maximums  73

JunosE 10.3.2 Release Notes

Link Layer Maximums

Table 3 lists link layer maximums for the ERX routers. The following notes are referred to in Table 3:

1. The ERX1440 router supports a maximum of 48,000 interface columns of all types combined. You can use either all dynamic interfaces or a combination of dynamic and static interfaces to achieve this maximum. For bridged Ethernet, IP network, and PPP interfaces, the ERX1440 router supports a maximum of 32,000 static major interfaces. Although the ERX1440 router supports a maximum of 48,000 static major interfaces for PPPoE, the PPPoE static limit is enforced at the subinterface level, which has a limit of 32,000.

The ERX705, ERX710, and ERX1410 routers support a maximum of 32,000 interfaces of all types combined; the ERX310 router supports a maximum of 16,000 interfaces of all types combined. For these routers, the interfaces can be any combination of dynamic or static.

The JunosE Software supports up to 10,000 PPP interfaces with EAP authentication negotiation configured. Performance and scalability is unchanged when EAP is not configured.

2. The total maximum number of Ethernet subinterfaces that can be active at any one time on an ERX310 router, an ERX7xx router, or an ERX14xx router is limited by the number of slots per chassis. Of this total, you can configure all single-tagged VLAN subinterfaces, all double-tagged S-VLAN subinterfaces, or a combination of both VLAN subinterfaces and S-VLAN subinterfaces to achieve this maximum.

Table 3: Link Layer Maximums

ERX705 and

Feature ERX310

ARP entries per line module

Dynamic ARP entries 32,768 32,768 32,768 32,768

Static ARP entries 32,768 32,768 32,768 32,768

Total ARP entries 32,768 32,768 32,768 32,768

ATM bulk configuration VC ranges per chassis 300 300 300 300

ATM bulk configuration VC ranges per line module 300 300 300 300

ERX710 ERX1410 ERX1440

ATM bulk configuration total VCs per chassis 64,000 160,000 384,000 384,000

ATM bulk configuration total VCs per line module

OCx/STMx/DS3-ATM 32,000 32,000 32,000 32,000

OC3/STM1 GE/FE 32,000 32,000 32,000 32,000

74  ERX310, ERX7xx, and ERX14xx System Maximums

Appendix A: System Maximums

Table 3: Link Layer Maximums (continued)

ERX705 and

Feature ERX310

ATM bulk configuration overriding profile assignments per chassis

ATM VCs per chassis (active/configured) 16,000/32,000 32,000/64,000 32,000/64,000 48,000/96,000

ATM VCs per line module

OCx/STMx/DS3-ATM (active/configured) 8000/16,000 8000/16,000 8000/16,000 8000/16,000

OC3/STM1 GE/FE (active/configured) 8000/16,000 8000/16,000 8000/16,000 8000/16,000

ATM V Cs pe r por t

OCx/STMx/DS3-ATM (active/configured) 8000/16,000 8000/16,000 8000/16,000 8000/16,000

OC3/STM1 GE/FE (active/configured) 8000/16,000 8000/16,000 8000/16,000 8000/16,000

100 100 100 100

ERX710 ERX1410 ERX1440

ATM VC classes per chassis 100 100 100 100

ATM VP/VC addresses per line module

OCx/STMx/DS3-ATM 20-bit 20-bit 20-bit 20-bit

OC3/STM1 GE/FE 20-bit 20-bit 20-bit 20-bit

ATM VP tunnels per port, all supported modules 256 256 256 256

Bridged Ethernet interfaces per chassis

(See Note 1 on page 74.)

Bridged Ethernet interfaces per line module

OCx/STMx/DS3-ATM 8192 8192 8192 8192

OC3/STM-1 GE/FE 8192 8192 8192 8192

Dynamic interfaces

Active autosensed dynamic interface columns per chassis over static or dynamic (bulk) ATM1483 subinterfaces

16,000 32,000 32,000 48,000

Ethernet 802.3ad Link Aggregation

Links per LAG (bundle) 8888

LAGs (bundles) per chassis 64 64 64 64

Ethernet S-VLANs per chassis

(See Note 2 on page 74.)

32,768 81,920 96,000 96,000

ERX310, ERX7xx, and ERX14xx System Maximums  75

JunosE 10.3.2 Release Notes

Table 3: Link Layer Maximums (continued)

ERX705 and

Feature ERX310

Ethernet S-VLANs per I/O module

FE-8 I/O and FE-8 SFP I/O 16,384 16,384 16,384 16,384

GE I/O 16,384 16,384 16,384 16,384

GE-2 SFP I/O 16,384 – – 16,384

GE-8 I/O 16,384 – – 16,384

OC3-2 GE APS I/O 16,384 16,384 16,384 16,384

ERX710 ERX1410 ERX1440

Ethernet VLANs per chassis

(See Note 2 on page 74.)

Ethernet VLANs per I/O module (no more than 4096 VLANs per por t)

FE-8 I/O and FE-8 SFP I/O 8192 8192 8192 8192

GE I/O 4096 4096 4096 4096

GE-2 SFP I/O 8192 – – 8192

GE-8 I/O 16,384 – – 16,384

OC3-2 GE APS I/O 4096 4096 4096 4096

Ethernet VLAN bulk configuration VLAN ranges per chassis

Ethernet VLAN bulk configuration VLAN ranges per line module

Ethernet VLAN overriding profile assignments per chassis

Ethernet VRRP VRIDs per line module ASIC 800 800 800 800

32,768 81,920 96,000 96,000

300 300 300 300

200 200 200 200

Frame Relay virtual circuits per chassis 2000 5000 12,000 12,000

Frame Relay virtual circuits per line module

COCX-F3 1000 1000 1000 1000

cOCx/STMx F0 1000 1000 1000 1000

OC48 (ERX1440 router only) –––1000

Frame Relay virtual circuits per port

COCX-F3 1000 1000 1000 1000

cOCx/STMx F0 1000 1000 1000 1000

OC48 (ERX1440 router only) –––1000

76  ERX310, ERX7xx, and ERX14xx System Maximums

Appendix A: System Maximums

Table 3: Link Layer Maximums (continued)

ERX705 and

Feature ERX310

HDLC interfaces per chassis 4000 10,000 24,000 24,000

HDLC interfaces per line module

COCX-F3 12121212

cOCx/STMx F0 2000 2000 2000 2000

CT3/T3 F0 1992 1992 1992 1992

OCx/STMx/DS-3 ATM 8000 8000 8000 8000

OCx/STMx POS 4444

OC48 (ERX1440 router only) –––1

ERX710 ERX1410 ERX1440

MLFR bundles per chassis 5000 5000 5000 5000

MLFR bundles per line module Bundles per line module are limited only by the

availability of interface columns on the module. Because a bundle requires at least one interface column, the number of bundles cannot exceed the number of interface columns.

MLPPP bundles per chassis 12,000 12,000 12,000 12,000

MLPPP bundles per line module The maximum number of MLPPP bundles supported per line

module is the lesser of the maximum number of MLPPP bundles supported per chassis or of the maximum number of interfaces supported on the line module. For more information, see the JunosE Link Layer Configuration Guide.

PPP interfaces per chassis

(See Note 1 on page 74.)

PPP interfaces per line module

COCX-F3 12121212

cOCx/STMx FO 2000 2000 2000 2000

GE/FE 8000 8000 8000 8000

GE-2 8000 – – 8000

GE-HDE 8000 – – 8000

OCx/STMx/DS-3 ATM 8000 8000 8000 8000

OC3/STM-1 GE/FE 8000 8000 8000 8000

OCx/STMx POS 4444

OC48 (ERX1440 router only) –––1

16,000 32,000 32,000 48,000

ERX310, ERX7xx, and ERX14xx System Maximums  77

JunosE 10.3.2 Release Notes

Table 3: Link Layer Maximums (continued)

ERX705 and

Feature ERX310

PPP packet logging

Aggregate dynamic and static PPP interfaces for which you can log PPP packets per chassis

PPPoE service name tables

PPPoE service name tables per chassis 16161616

Service name tags per PPPoE service name table (including one empty service name tag)

PPPoE subinterfaces

Subinterfaces per chassis

(See Note 1 on page 74.)

Subinterfaces per GE/FE line module 8000 8000 8000 8000

Subinterfaces per GE-2 line module 8000 – – 8000

Subinterfaces per GE-HDE line module 8000 – – 8000

Subinterfaces per OCx/STMx/DS-3 ATM line module 8000 8000 8000 8000

Subinterfaces per OC3/STM-1 GE/FE line module 8000 8000 8000 8000

32 32 32 32

17 17 17 17

16,000 32,000 32,000 48,000

ERX710 ERX1410 ERX1440

Transparent bridging and VPLS

Bridge groups or VPLS instances per chassis 1024 1024 1024 1024

Bridge interfaces per line module in bridge groups or VPLS instances

Bridge interfaces per chassis in bridge groups or VPLS instances

Learned MAC address entries combined for all bridge groups and VPLS instances on a chassis

8000 8000 8000 8000

16,000 32,000 32,000 32,000

64,000 64,000 64,000 64,000

78  ERX310, ERX7xx, and ERX14xx System Maximums

Routing Protocol Maximums

Table 4 lists routing protocol maximums for the ERX routers. The following notes are referred to in Table 4:

1. The total set of FTEs can be shared by interfaces, next hops, ECMP sets, VRs, and VRFs. Next-hop FTEs identify the next hop on multiaccess media, such as ATM multipoint, Ethernet, or bridged Ethernet. Each VR or VRF consumes three entries. Each interface, next hop, and ECMP set consumes a single entry. One FTE is reserved for internal use, and the system software limits the number of FTEs used by interfaces to a maximum of 32,000. The remaining FTEs can be shared across the other types.

2. The ERX1440 router supports a maximum of 48,000 interfaces of all types combined. You can use either all dynamic interfaces or a combination of dynamic and static interfaces to achieve this maximum. The ERX1440 router supports a maximum of 32,000 static PPP/PPPoE interfaces and a maximum of 36,500 static IP network interfaces. Bridged Ethernet does not enforce a limit so IP interfaces created on Bridged Ethernet can scale to the IP maximum of 36,500.

Appendix A: System Maximums

The ERX705, ERX710, and ERX1410 routers support a maximum of 32,000 IP network interfaces; the ERX310 router supports a maximum of 16,000 IP network interfaces. For all these models, the interfaces can be any combination of dynamic or static.

3. These values are subject to limitations on available SRP module memory, which varies according to your router configuration.

4. Depending on your configuration, the router may support more routing table entries or fewer routing table entries than this value. In any case, you can choose to limit the number of routes that can be added to the routing table on a per-VR or per-VRF basis by means of the maximum routes command.

5. The maximum number of ANCP adjacencies can be scaled over a maximum of 100 virtual routers. Fewer ANCP adjacencies can be scaled in configurations with more than 100 virtual routers.

6. This maximum is not valid for Frame Relay. The Frame Relay maximum is 1000 circuits over MPLS per line module, because only 1000 Frame Relay DLCIs are permitted per line module.

7. On the ERX1440 router, you can achieve 32,767 total Martini circuits over ATM or Ethernet interfaces. For all routers, the total Martini can be any combination of external inter-router circuits and internal circuits (local cross-connects).

8. There is no per-VR limit; all multicast routes can be on a single VR or present across multiple VRs.

9. The maximum number of interfaces can be achieved by any combination; for example, two streams each being replicated to 32,768 interfaces; 16,384 streams each being replicated four times; or any other combination.

ERX310, ERX7xx, and ERX14xx System Maximums  79

JunosE 10.3.2 Release Notes

10. Dynamic values represent typical limits that vary depending on configuration details and actual dynamic behavior. For dynamic values only, multiple server modules (SMs) in a chassis can improve the values as long as the multiple server modules are online and the number of virtual routers configured with NAT is greater than or equal to the number of server modules. If a server module fails, the load is redistributed to the remaining server modules, with a consequent reduction in aggregate capacity.

11. Static and dynamic translations occupy the same table; therefore, the number of static translation entries present in the table reduces the room for dynamic entries.

Table 4: Routing Protocol Maximums

ERX705 and

Feature ERX310

BFD

Sessions per line module 50 50 50 50

ERX710 ERX1410 ERX1440

ECMP maximum paths to a destination

BGP, IS-IS, MPLS, OSPF, RIP 16 16 16 16

IPv4 forwarding table entries

(See Note 1 on page 79.)

Chassis with only ASIC modules 1,048,576 1,048,576 1,048,576 1,048,576

IP network interfaces (IPv4 and IPv6)

Per chassis

(See Note 2 on page 79.)

Per line module ASIC 8000 8000 8000 8000

IPv4 routing protocol scaling and peering densities

(See Note 3 on page 79.)

Routing table entries

(See Note 4 on page 79.)

ANCP Adjacency Scaling

(See Note 5 on page 79.)

BGP-4 peering sessions 1000 1000 1000 1000

BGP-4 routes (NLRI) 1,500,000 1,500,000 1,500,000 1,500,000

IP next hops (egress FECs) on router with ASIC modules (used to represent the IP addresses of next-hop routers on Ethernet interfaces)

MPLS next hops (egress FECs) on router with ASIC modules only

MPLS forwarding entries 64,000 64,000 64,000 64,000

16,000 32,000 32,000 48,000

500,000 500,000 500,000 500,000

5000 5000 5000 5000

1,000,000 1,000,000 1,000,000 1,000,000

500,000 500,000 500,000 500,000

80  ERX310, ERX7xx, and ERX14xx System Maximums

Appendix A: System Maximums

Table 4: Routing Protocol Maximums (continued)

ERX705 and

Feature ERX310

IS-IS adjacencies 150 150 150 150

IS-IS routes 20,000 20,000 20,000 20,000

MPLS LDP LSPs 10,000 10,000 10,000 10,000

MPLS RSVP-TE LSPs 10,000 10,000 10,000 10,000

OSPF adjacencies 1000 1000 1000 1000

OSPF routes 25,000 25,000 25,000 25,000

ERX710 ERX1410 ERX1440

IPv6 routing table entries

(See Note 3 on page 79.)

J-Flow statistics

J-Flow–enabled VRs and VRFs, in any combination 16 16 16 16

Sampled interfaces per VR or VRF 32323232

Total sampled Interfaces per chassis 512 512 512 512

Martini circuits for layer 2 services over MPLS

Total Martini circuits per line module

(See Note 6 on page 79.)

Total Martini circuits per chassis

(See Note 7 on page 79.)

External Martini circuits per chassis 16,000 16,000 16,000 32,767

Internal Martini circuits (local cross-connects) per chassis 16,000 16,000 16,000 32,767

Mobile IP bindings per chassis – – – 48,000

Multicast routes (IPv4 and IPv6)

Forwarding entries [(S,G) pairs] per chassis

(See Note 8 on page 79.)

Outgoing interfaces per chassis

(See Note 9 on page 79.)

50,000 50,000 50,000 50,000

8000 8000 8000 8000

16,000 16,000 16,000 32,767

16,384 16,384 16,384 16,384

65,536 65,536 65,536 65,536

Network Address Translation (NAT)

Static translations (simple or extended) per chassis 96,000 96,000 96,000 96,000

Dynamic simple translations (NAT) per SM

(See Notes 10 and 11 on page 80.)

Dynamic extended translations (NAPT) per SM

(See Notes 10 and 11 on page 80.)

400,000 400,000 400,000 400,000

200,000 200,000 200,000 200,000

ERX310, ERX7xx, and ERX14xx System Maximums  81

JunosE 10.3.2 Release Notes

Table 4: Routing Protocol Maximums (continued)

ERX705 and

Feature ERX310

Response Time Reporter simultaneous operations per VR

VRRP VRIDs per line module ASIC See Ethernet VRRP VRIDs per line module ASIC on page 76.

500 500 500 500

ERX710 ERX1410 ERX1440

82  ERX310, ERX7xx, and ERX14xx System Maximums

Policy and QoS Maximums

Table 5 lists policy and QoS maximums for the ERX routers. The following notes are referred to in Table 5:

1. The OC48 line module supports only 131,071 entries. The GE-2 and GE-HDE line modules support only 65,535 entries.

2. For line modules other than the GE-2, GE-HDE, and OC48/STM16 line modules, the router supports two sizes of policies: 8127 policies, each with a maximum of 32 classifiers, and 16,255 policies, each with a maximum of 16 classifiers. A combination of the two sizes of policies is also supported, in which case the total number of policies is between 8127 and 16,255, depending on the actual configuration.

3. The GE-2, GE-HDE, and OC48/STM16 line modules support CAM classifiers instead of hardware policy assignments. For most configurations, each classifier entry in a policy consumes one CAM entry. However, a policy that has only the default classifier consumes no CAM resources. Policies that use CAM hardware classifiers consume one interface attachment resource, regardless of the number of classifier entries in a policy.

Appendix A: System Maximums

Table 5: Policy and QoS Maximums

ERX705 and

Feature ERX310

QoS queues per ASIC line module 49,000 49,000 49,000 49,000

QoS profiles configurable per chassis 1000 1000 1000 1000

QoS profile attachments per chassis 96,000 96,000 96,000 96,000

QoS profile attachments per ASIC line module 16,000 16,000 16,000 16,000

QoS shapers per line module 64,000 64,000 64,000 64,000

Classification rules per policy 512 512 512 512

Policy classification (CLACL) entries per line module

(See Note 1 on page 83.)

Unique hardware policy assignments per line module for modules other than the GE-2, GE-HDE, and OC48/STM16

(See Note 2 on page 83.)

256,000 256,000 256,000 256,000

8127/16,255 8127/16,255 8127/16,255 8127/16,255

ERX710 ERX1410 ERX1440

ERX310, ERX7xx, and ERX14xx System Maximums  83

JunosE 10.3.2 Release Notes

Table 5: Policy and QoS Maximums (continued)

ERX705 and

Feature ERX310

CAM entries

(See Note 3 on page 83.)

GE-2 64,000 – – 64,000

GE-HDE 64,000 – – 64,000

OC48/STM16 – – – 128,000

Policy egress interface attachments per ASIC line module

Combined IP and IPv6 interface attachments 8191 8191 8191 8191

Combined ATM, Frame Relay, GRE, L2TP (LNS only), MPLS, and VLAN interface attachments

8191 8191 8191 8191

ERX710 ERX1410 ERX1440

Policy ingress interface attachments per ASIC line module

Combined IP and IPv6 interface attachments on GE-2, GE-HDE, and OC-48/STM16 line modules

Combined IP and IPv6 interface attachments on all other line modules

Combined ATM, Frame Relay, GRE, L2TP (LNS only), MPLS, and VLAN interface attachments

Rate limiters

Egress per ASIC line module 24,575 24,575 24,575 24,575

Ingress per ASIC line module 24,575 24,575 24,575 24,575

Policy statistics blocks

Egress per ASIC line module 256,000 256,000 256,000 256,000

Ingress per ASIC line module 256,000 256,000 256,000 256,000

Parent groups per ASIC line module

GE-2, GE-HDE, and OC3/OC12 ATM line modules (Egress and Ingress)

All other ASIC line modules (Egress and Ingress) 8191 8191 8191 8191

16,383 – – 16,383

16,000 16,000 16,000 16,000

8191 8191 8191 8191

24,575 24,575 24,575 24,575

Software lookup blocks

Per ASIC line module 16,383 16,383 16,383 16,383

84  ERX310, ERX7xx, and ERX14xx System Maximums

Appendix A: System Maximums

Table 5: Policy and QoS Maximums (continued)

ERX705 and

Feature ERX310

Secure policies (for packet mirroring)

Per ASIC line module 1022 1022 1022 1022

Per chassis 2400 2400 2400 2400

ERX710 ERX1410 ERX1440

ERX310, ERX7xx, and ERX14xx System Maximums  85

JunosE 10.3.2 Release Notes

Tunneling Maximums

Table 6: Tunneling Maximums

Table 6 lists tunneling maximums for the ERX routers. The following notes are referred to in Table 6:

1. The SM supports any combination of DVMRP, GRE, and L2TP tunnels up to a maximum of 8000 tunnels; however, no more than 4000 tunnels can be DVMRP or GRE tunnels in any combination. The ISM supports any combination of DVMRP, GRE, and L2TP tunnels over IPSec, up to a maximum of 5000 tunnels; however, no more than 4000 tunnels can be DVMRP or GRE tunnels.

2. You can have no more than 8000 L2TP/IPSec sessions per chassis.

3. For more information about supported L2TP sessions and tunnels, see JunosE Broadband Access Configuration Guide, Chapter 11, L2TP Overview.

ERX705 and

Feature ERX310

DVMRP (IP-in-IP) tunnels per chassis 4000 4000 4000 4000

DVMRP (IP-in-IP) tunnels per line module

(See Note 1 on page 86.)

GE-2 with shared tunnel-server ports provisioned 4000 – – 4000

GE-HDE with shared tunnel-server ports provisioned 4000 – – 4000

IPSec Service Module (DVMRP/IPSec tunnels) 4000 4000 4000 4000

Service Module (SM) 4000 4000 4000 4000

GRE tunnels per chassis 4000 4000 4000 4000

GRE tunnels per line module

(See Note 1 on page 86.)

GE-2 with shared tunnel-server ports provisioned 4000 – – 4000

GE-HDE with shared tunnel-server ports provisioned 4000 – – 4000

IPSec Service Module (GRE/IPSec tunnels) 4000 4000 4000 4000

Service Module (SM) 4000 4000 4000 4000

ERX710 ERX1410 ERX1440

IPSec manual secure tunnels per chassis 256 256 256 256

IPSec transform sets per chassis 1000 1000 1000 1000

IPSec transforms per transform set 6666

IPSec tunnels per chassis 10,000 10,000 10,000 20,000

86  ERX310, ERX7xx, and ERX14xx System Maximums

Appendix A: System Maximums

Table 6: Tunneling Maximums (continued)

ERX705 and

Feature ERX310

IPSec tunnels per IPSec Ser vice Module 5000 5000 5000 5000

ERX710 ERX1410 ERX1440

L2TP sessions per chassis

(See Notes 2 and 3 on page 86.)

L2TP sessions per line module

(See Notes 1 and 3 on page 86.)

GE-2 with shared tunnel-server ports provisioned 8000 – – 8000

GE-HDE with shared tunnel-server ports provisioned 8000 – – 8000

IPSec Service Module (ISM; L2TP/IPSec sessions) 5000 5000 5000 5000

Service Module (SM) 16,000 16,000 16,000 16,000

L2TP tunnels per chassis 8000 8000 8000 8000

L2TP tunnels per line module

(See Notes 1 and 3 on page 86.)

GE-2 with shared tunnel-server ports provisioned 8000 – – 8000

GE-HDE with shared tunnel-server ports provisioned 8000 – – 8000

IPSec Service Module (L2TP/IPSec tunnels) 5000 5000 5000 5000

Service Module 8000 8000 8000 8000

16,000 16,000 16,000 32,000

ERX310, ERX7xx, and ERX14xx System Maximums  87

JunosE 10.3.2 Release Notes

Subscriber Management Maximums

Table 7 lists subscriber management maximums for the ERX routers. The following notes are referred to in Table 7:

1. DHCP relay proxy maintains a list of active DHCP clients up to a maximum of 100,000 clients per chassis for all virtual routers. DHCP relay does not maintain a list of DHCP clients.

DHCP relay proxy is notified of DHCP client deletions and subsequently deletes the client’s host routes. In contrast, DHCP relay is not notified of DHCP client deletions, so the host routes for deleted clients remain in DHCP relay until you permanently delete them with the set dhcp relay discard-access-routes command. A maximum of 100,000 host routes for DHCP clients can be stored for all DHCP relay and DHCP relay proxy instances (that is, for all virtual routers).

2. The ERX1440 router supports a maximum of 48,000 interface columns of all types combined. You can use either all dynamic interfaces or a combination of dynamic and static interfaces to achieve this maximum. For bridged Ethernet, IP network, and PPP interfaces, the ERX1440 router supports a maximum of 32,000 static major interfaces. Although the ERX1440 router supports a maximum of 48,000 static major interfaces for PPPoE, the PPPoE static limit is enforced at the subinterface level, which has a limit of 32,000.

The JunosE Software supports up to 10,000 PPP interfaces with EAP authentication negotiation configured. Performance and scalability is unchanged when EAP is not configured.

3. For DHCPv6 local server, up to 32,000 subscribers and clients are supported on PPP/ATM and PPPoE/ATM with dynamic interfaces. Interface flapping tests have been qualified for 8000 subscribers and interfaces.

Table 7: Subscriber Management Maximums

ERX705 and

Feature ERX310

DHCP external ser ver clients (per chassis for all virtual routers; and per virtual router)

(See Note 1 on page 88.)

DHCP local server

(See Note 2 on page 88.)

Client bindings per chassis 96,000 96,000 96,000 96,000

Client interfaces per chassis 16,000 32,000 32,000 48,000

Local address pools per virtual router 4000 4000 4000 4000

IP addresses per local address pool 32,000 32,000 32,000 32,000

100,000 100,000 100,000 100,000

ERX710

ERX1410 ERX1440

88  ERX310, ERX7xx, and ERX14xx System Maximums

Table 7: Subscriber Management Maximums (continued)

Feature ERX310

DHCPv6 local server

Clients

(See Note 3 on page 88.)

DHCP relay and relay proxy client

(See Notes 1 and 2 on page 88.)

DHCP client host routes for DHCP relay and DHCP relay proxy combined (per chassis for all virtual routers; and per virtual router)

DHCP relay proxy clients (per chassis for all virtual routers; and per virtual router)

Interfaces (per chassis for all virtual routers; and per virtual router)

32,000 32,000 32,000 32,000

100,000 100,000 100,000 100,000

16,000 32,000 32,000 48,000

Appendix A: System Maximums

ERX705 and ERX710 ERX1410 ERX1440

Local authentication server

Local user databases per chassis 100 100 100 100

Users per local user database 100 100 100 100

Users for all local user databases 100 100 100 100

RADIUS requests

Concurrent RADIUS authentication requests 4000 4000 4000 32,000

Concurrent RADIUS accounting requests 4000 4000 4000 96,000

RADIUS route-download server downloaded routes per chassis

Service Manager

Service definitions 2048 2048 2048 2048

Service sessions (active) 131,072 131,072 131,072 131,072

Active subscriber sessions 16,000 32,000 32,000 48,000

SRC Software and SDX Software

COPS client instances 200 200 200 200

SRC clients 200 200 200 200

SRC interfaces 16,000 32,000 32,000 48,000

32,000 32,000 32,000 32,000

ERX310, ERX7xx, and ERX14xx System Maximums  89

JunosE 10.3.2 Release Notes

Table 7: Subscriber Management Maximums (continued)

ERX705 and

Feature ERX310

Subscriber interfaces

(See Note 2 on page 88.)

Dynamic subscriber interfaces per chassis 16,000 32,000 32,000 48,000

Dynamic subscriber interfaces per line module 8000 8000 8000 8000

Static subscriber interfaces per chassis 16,000 32,000 32,000 48,000

Static subscriber interfaces per line module 8000 8000 8000 8000

ERX710 ERX1410 ERX1440

90  ERX310, ERX7xx, and ERX14xx System Maximums

E120 and E320 System Maximums

The following tables provide system maximums for the E120 router and the E320 router.

General System Maximums

Table 8 lists some general system maximums for the E120 router and the E320 router. The following notes are referred to in Table 8:

1. The maximum number applies to any combination of VRs and VRFs. The number of VRs and VRFs that you can configure depends on your configuration. You cannot achieve the maximum number if each VR and VRF instance is running a routing protocol.

2. The maximum of 3000 VRs and VRFs can be achieved only with the SRP-120 and SRP-320 modules, which have 4 GB of memory. The limits cannot be achieved with the SRP-100 module, which has 2 GB of memory.

Appendix A: System Maximums

Table 8: General System Maximums

Feature E120 E320

Fabric size 120 Gbps 100 Gbps/320 Gbps

Chassis per 7-foot rack 6 3

NTP clients 1000 1000

NTP servers 300 300

Sessions per chassis (simultaneous Telnet + FTP + SSH, in any combination)

Virtual routers and VRFs per chassis, combined

(See Notes 1 and 2 on page 91.)

Virtual routers and VRFs per line module, combined

(See Notes 1 and 2 on page 91.)

ICR Partitions per chassis 640 640

ICR Partitions per line module 64 64

30 30

3000 3000

E120 and E320 System Maximums  91

JunosE 10.3.2 Release Notes

Physical and Logical Density Maximums

Table 9 lists physical and logical density maximums for the E120 router and the E320 router. The following notes are referred to in Table 9:

1. Wire rate indicates the port density that supports maximum (wire-rate) performance. Oversubscribed indicates the port density possible if you are willing to accept less than wire-rate performance by oversubscribing the available fabric bandwidth.

2. With a 120 Gbps configuration on the E120 router, you can install up to 6 combinations of ES2 10G Uplink LMs, ES2 10G LMs, or ES2 10G ADV LMs in slots numbered 0-5. You can install a maximum of 6 active ports and 6 redundant ports at any time.

With a 100 Gbps fabric configuration on the E320 router, you must install the ES2 10G Uplink LM, the ES2 10G LM, or the ES2 10G ADV LM in either of the E320 router turbo slots (2 and 4). When the ES2 10G Uplink LM, the ES2 10G LM, or the ES2 10G ADV LM is installed in slot 2 or slot 4, you cannot install another line module in slot 3 or slot 5. In this case, you can only install the ES2 4G LM in slots 0–1 and 6–11; therefore, the maximum number of ports and the forwarding performance per chassis is reduced for the IOAs that pair with the ES2 4G LM.

With a 320 Gbps fabric configuration on the E320 router, you can install up to 12 combinations of ES2 10G Uplink LMs, ES2 10G LMs, or ES2 10G ADV LMs in slots numbered 0-5 and 11-16. You can install a maximum of 12 active ports and 12 redundant ports at any time.

Table 9: Physical and Logical Density Maximums

Feature E120 E320

Physical density wire rate/oversubscribed

(See Note 1 on page 92.)

10-Gigabit Ethernet ports per chassis (ES2-S1 10GE IOA)

10-Gigabit Ethernet ports per chassis (ES2-S2 10GE PR IOA)

(See Note 2 on page 92.)

Gigabit Ethernet ports per chassis (ES2-S1 GE-4 IOAs)

Gigabit Ethernet ports per chassis (ES2-S1 GE-8 IOAs)

(See Note 2 on page 92.)

Gigabit Ethernet ports per chassis (ES2-S3 GE-20 IOA)

(See Note 2 on page 92.)

OC3/STM-1 ATM ports per chassis (ES2-S1 OC3-8 STM1 ATM IOAs)

OC12/STM-4 ATM ports per chassis (ES2-S1 OC12-2 STM4 ATM IOAs)

612

6 + 6 12 + 12

24 48

96 192

120 240

96 192

24 48

92  E120 and E320 System Maximums
