Juniper J2320, J2350, J4350, J6350 Specifications

J SERIES SERVICES

J SERIES SERVICES

J2320, J2350, J4350, and J6350

ROUTERS

J2320, J2350, J4350, and J6350

DATASHEET

Product Overview

Juniper Networks J Series
Services Routers extend enterprise
applications and deliver reliable
connectivity to remote offi ces
with a powerful blend of high­performance network protection and
advanced services. J Series Services
Routers leverage the modular
JUNOS Software and Juniper’s rich
product and partner portfolio to
consolidate market leading security,
application optimization, and voice
capabilities onto a single, easy to
manage platform. Our innovative
security approach inseparably
integrates routing and fi rewalls for
exceptional performance. Available
options, including integrated
Juniper Networks WX application
acceleration and integrated voice
gateway technology from Avaya,
make the J Series the ideal choice
for closing the distance between
central resources and remote
locations.

Product Description

Enterprises are faced with a number of challenges and opportunities by converging
voice, video and data to one network. This consolidation of network elements reduces
cost by easing deployment of SIP enabled VoIP, real-time high-defi nition Telepresence
and standardizing on a consistent infrastructure network operating system like Juniper
Networks
interactions with suppliers, and employee productivity. This mission-critical multi­media network must be always on and always available. To accomplish this, fully
integrated stateful security is a key requirement, not merely forwarding packets without
regard to the intended application or individual user session. JUNOS Software provides
the high-performance networking infrastructure that helps enterprises implement key
initiatives that:

• Integrates routing, fi rewalling and vpn into one best in class secure router. By

• Minimizes the cost of installing and operating a network by deploying J Series. With

Whether you have an enterprise network or a service provider looking for customer
premise equipment for an MPLS or IP network, the J Series offers a mix of features that
excel at both. By leveraging JUNOS, the J Series can be deployed at medium to large
sites and the wide range of interfaces scales the bandwidth as necessary for today’s real
time communications

®

JUNOS® Software. These new technologies improve; customer relations,

securing an enterprise’s mission critical information and protecting the network from
vulnerabilities and attack, the J Series offers a combination of features that increases
productivity and reduces costs. With JUNOS release 9.6, the J Series enhances these
features with Unifi ed Threat Management, consisting of antivirus, antispam, Web
fi ltering and intrusion prevention system. These advanced security features can
eliminate a standalone appliance and be applied with a software key.

the modular, protected mode design of JUNOS Software and the rigorous JUNOS
development and testing process, there are fewer system process failures. The single
code source of JUNOS makes the qualifi cation of new releases across the network
much simpler. In addition, superior confi guration management reduces human errors
that could lead to network downtime.

1

Table 1: Key Hardware Features of the J Series Services Routers

PRODUCT DESCRIPTION

J2320 • Support for T1, E1, Synchronous Serial, ISDN Basic Rate Interface, ADSL2/ADSL2+, G.SHDSL, and Gigabit

J2350 • Support for T1, E1, Synchronous Serial, ISDN BRI, ADSL/2/2+, G.SHDSL, and Gigabit Ethernet interfaces

Ethernet interfaces

• Support for integrated IP telephony using the Avaya IG550 Integrated Gateway

• Support for application acceleration using the Juniper Networks ISM200 Integrated Services Module

• 4 xed Gigabit Ethernet LAN ports, and 3 PIM slots

• 512 MB DRAM default, expandable to 1 GB DRAM

• 512 MB compact ash default, upgradeable to 1 GB

• Hardware encryption acceleration (optional)

• Full UTM; antivirus, antispam, Web ltering, intrusion prevention system (with high memory version)

• Unied Access Control (UAC) and content ltering

• Support for integrated IP telephony using the Avaya IG550 Integrated Gateway

• Support for application acceleration using the Juniper Networks ISM200 Integrated Services Module

• 4 xed Gigabit Ethernet LAN ports, and 5 PIM slots

• 512 MB DRAM default, expandable to 1 GB DRAM

• 512 MB compact ash default, upgradeable to 1 GB

• Hardware encryption acceleration (optional)

• DC version available

• NEBS-compliant models available

• Full UTM; antivirus, antispam, Web ltering, intrusion prevention system (with high memory version)

• Unied Access Control (UAC) and content ltering

J4350 • Support for T1, E1, Fast Ethernet, Synchronous Serial, ISDN BRI, ADSL2/ADSL2+, G.SHDSL, DS3, E3, Gigabit

J6350 • Support for T1, E1, Fast Ethernet, Synchronous Serial, ISDN BRI, ADSL2/ADSL2+, G.SHDSL, DS3, E3, Gigabit

Ethernet interfaces

• Support for integrated IP telephony using the Avaya IG550 Integrated Gateway

• Support for application acceleration using the Juniper Networks ISM200 Integrated Services Module

• 4 xed Gigabit Ethernet LAN ports, 4 PIM slots, and 2 EPIM/PIM slots

• DC version available

• 512 MB or 1 GB DRAM default, expandable to 2 GB DRAM

• 512 MB compact ash default, upgradeable to 1 GB

• Hardware encryption acceleration (optional)

• NEBS-compliant models available

• Full UTM; antivirus, antispam, Web ltering, intrusion prevention system (with high memory version)

• Unied Access Control (UAC) and content ltering

Ethernet interfaces

• Support for integrated IP telephony using the Avaya IG550 Integrated Gateway

• Support for application acceleration using the Juniper Networks ISM200 Integrated Services Module

• 4 xed Gigabit Ethernet LAN ports, 2 PIM slots, and 4 EPIM/PIM slots

• DC version available

• 1 GB DRAM default, expandable to 2 GB DRAM

• 512 MB compact ash default, upgradeable to 1 GB

• Hardware encryption acceleration standard

• NEBS-compliant models available

• Redundant AC or DC power supplies

• Full UTM; antivirus, antispam, Web ltering, intrusion prevention system (with high memory version)

• Unied Access Control (UAC) and content ltering

2

Features and Benefits

Secure Routing

Should you use a router and a firewall to secure your network?
By building the branch J Series Services Routers with best-in­class routing and firewall capabilities in one product, enterprises
don’t have to make that choice. Why forward traffic if it’s not
legitimate?

J Series for the branch checks the traffic to see if it is legitimate,
and only forwards it on when it is. This reduces the load on
the network, allocates bandwidth for all other mission-critical
applications, and secures the network from hacking.

The main purpose of a secure router is to provide firewall

protection and apply policies. The rewall (zone) functionality
inspects trafc ows and state to ensure that originating and

returning information in a session is expected and permitted for
a particular zone. The security policy determines if the session
can originate in one zone and traverse to another zone. This
architectural choice receives packets from a wide variety of
clients and servers and keeps track of every session, of every
application, and of every user. It allows the enterprise to make
sure that only legitimate traffic is on its network and that traffic

is owing in the expected direction.

“Untrust” Zone

INTERNET

High Availability

Active/StandbyActive/Standby

INTERNETINTERNET

Active

J Series

EX Series EX Series

Active

EX Series

By using the Web interface or CLI, enterprises can create a

series of security policies that will control the traffic from within
and in between zones by defining policies. At the broadest
level, all types of traffic can be allowed from any source in
security zones to any destination in all other zones without any
scheduling restrictions. At the narrowest level, policies can be
created that allow only one kind of traffic between a specified
host in one zone and another specified host in another zone
during a scheduled time period.

Standby

J Series

Active

J SeriesJ Series

EX Series

Figure 2: High availability

Failure

Failure

EX Series

EX Series

Active

J SeriesJ Series

EX Series

Active/ActiveActive/Active

INTERNETINTERNET

Active

J SeriesJ Series

EX Series

“Trust” Zone

Intranet

“Guest” Zone

“DMZ” Zone

Figure 1: Firewalls, zones and policies

To ease the configuration of a firewall, J Series for the branch
uses two features—“zones” and “policies.” While these can be
user defined, the default shipping configuration contains, at a
minimum, a trust and an untrust zone. The trust zone is used
for configuration and attaching the LAN to the branch J Series
routers. The untrust zone is used for the WAN or Internet
interface. To simplify installation and make configuration easier,
a default policy is in place that allows traffic originating from the

trust zone to ow to the untrust zone. This policy blocks all trafc

originating from the untrust zone to the trust zone. A traditional

router forwards all trafc without regard to a rewall (session
awareness) or policy (origination and destination of a session).

High Availability

JUNOS Services Redundancy Protocol (JSRP) is a core feature

of the J Series for the branch. JSRP enables a pair of security
systems to be easily integrated into a high availability network
architecture, with redundant physical connections between
the systems and the adjacent network switches. With link
redundancy, Juniper Networks can address many common
causes of system failures, such as a physical port going bad
or a cable getting disconnected, to ensure that a connection
is available, without having to fail over the entire system. This

is consistent with a typical active/standby nature of routing

resiliency protocols.

When J Series routers for the branch are configured as an

active/active pair, trafc and conguration will be mirrored

automatically to provide active firewall and VPN session
maintenance in case of a failure. The J Series will now
synchronize both configuration and runtime information.
As a result, during failover, synchronization of the following

information is shared: connection/session state and ow

information, IPsec security associations, Network Address

Translation (NAT) trafc, address book information, conguration
changes, and more. In contrast to the typical router active/

standby resiliency protocols such as Virtual Router Redundancy

3

Protocol (VRRP), all dynamic ow and session information is

lost and must be reestablished in the event of a failover. Some
or all applications sessions will have to restart depending on the
convergence time of the links or nodes. By maintaining state,
not only is the session preserved, but security is intact. In an

unstable network, this active/active conguration also mitigates
link apping affecting session performance.

Session-Based Forwarding Without the Performance Hit

In order to optimize the throughput and latency of the combined
router and firewall, JUNOS implements session-based
forwarding, an innovation that combines the session state
information of a traditional firewall and the next-hop forwarding
of a classic router into a single operation. With JUNOS, a
session that is permitted by the forwarding policy is added to
the forwarding table along with a pointer to the next-hop route.
Established sessions have a single table lookup to verify that
the session has been permitted and to find the next hop. This
efficient algorithm improves throughput and lowers latency
for session traffic when compared with a classic router that
performs multiple table lookups to verify session information and
then to find a next-hop route.

Figure 3 shows the session-based forwarding algorithm. When

a new session is established, the session-based architecture
within JUNOS verifies that the session is allowed by the
forwarding policies. If the session is allowed, JUNOS will look
up the next-hop route in the routing table. It then inserts the
session and the next-hop route into the session and forwarding
table and forwards the packet. Subsequent packets for the
established session require a single table lookup in the session
and forwarding table, and are forwarded to the egress interface.

Session Initial

Packet Processing

Forwarding Table

Ingress

Interface

Session and

Figure 3: Session-based forwarding algorithm

Security Policy Evaluation

and Next-Hop Lookup

Table

Update

Disallowed by

Policy: Dropped

Forwarding for

Permitted Traffic

Egress

Interface

SMALL OFFICE

Mobile

SRX210

DSL

LARGE OFFICE

EX4200 EX3200

EX4200-24T

J4350

Cellular

J6350

FIXED MOBILE SITE

(Mobile – 3G)

POP

PBX

SRX210

Wireless

Service Provider
SIP Softswitch

PSTN

EX3200-24P

POP

Voice (AMI)

Data (B8ZS)

Channelized T-1

Clear channel T-1

J2350

Fax

INTERNET

Service Provider
SIP Softswitch

PSTN

POP

SRX210

Fax

HQ BRANCH

4

BRANCH

Figure 4: The distributed enterprise

Product Options

Juniper Networks J2320, J2350, J4350, and J6350 Services
Routers offer a number of options in terms of LAN and WAN

ports, hardware encryption acceleration, power supplies, DRAM,
compact ash, and feature licenses.

LAN Ports

All J2320, J2350, J4350, and J6350 Services Routers ship with

four xed 10/100/1000 Ethernet ports. You can add more modular

LAN interfaces by ordering the appropriate PIMs, Enhanced PIMs

(EPIMs), or Universal PIMs (UPIMs). For more information, see

the J Series WAN and LAN modules Ordering Information section

on page 14.

WAN Ports

All J2320, J2350, J4350, and J6350 Services Routers ship without
fixed WAN ports. The customer can add modular WAN interfaces

by ordering the appropriate PIMs. For more information, see the

J Series WAN and LAN Modules Part Numbers in the Ordering

Information section on page 14.

Hardware Encryption Acceleration

The J2320, J2350, and J4350 are available with optional hardware
encryption acceleration. All J6350 models include hardware
encryption acceleration by default. If you purchase a J2320,
J2350, or J4350 without hardware encryption, you can add it later
by ordering the appropriate encryption card.

Power Supply

All J2350, J4350, and J6350 Services Routers ship with either a

DC power supply or an AC power supply and include a region­specic power cord. (The J2320 is available with AC power only.)
The J6350 supports a second redundant AC or DC power supply,
which can be added by ordering SSG-PS-DC or SSG-PS-AC. The

region-specic AC power cable for SSG-PS-AC must be ordered

separately.

DRAM

The J2320 and J2350 are upgradeable to a maximum of 1
GB DRAM. The J2320 and J2350 models without hardware
encryption acceleration (J2320-JB-SC and J2350-JB-SC) come
with 512 MB DRAM. All other models come with 1 GB of DRAM.

All J4350 models are upgradeable to a maximum of 2 GB
DRAM. The J4350 model that ships without hardware encryption
acceleration (J-4350-JB-SC) ships with 512 MB of DRAM. All
other J4350 models ship with 1 GB of DRAM.

All J6350 Services Routers ship with 1 GB of DRAM and are
upgradeable to 2 GB of DRAM. Order and install two additional
JXX50-MEM-512M-S DIMMs.

Note that when upgrading DRAM, DIMMs should always be
installed in pairs; for example, to upgrade to 1 GB DRAM, order
two JXX50-MEM-512M-S DIMMs. To upgrade to 2 GB DRAM,
order four JXX50-MEM-512M-S DIMMs.

With JUNOS Release 9.1 and later, all J Series Services Routers
(J2320, J2350, J4350, J6350) must run at least 512 MB of DRAM.

Compact Flash

All J2320, J2350, J4350, and J6350 Services Routers ship with

512 MB of primary compact ash. You can replace that with a
larger compact ash by ordering one either JX-CF-512M-S (for
512 MB) or JX-CF-1G-S (for 1 GB).

Table 2: J4350 and J6350 Supported Memory Configurations

TOTAL MEMORY DIMM 0 DIMM 1 DIMM 2 DIMM 3

512 MB 512 MB

512 MB 256 MB – 256 MB –

1 GB 256 MB 256 MB 256 MB 256 MB

1 GB 512 MB – 512 MB –

2 GB 512 MB 512 MB 512 MB 512 MB

5

Specifications

Protocols

• IPv4, IPv6, ISO Connectionless Network Service (CLNS)

Routing and Multicast

• Static routes

• RIPv2

• OSPF

• BGP

• BGP Router Reector

• IS-IS

• Multicast ((Internet Group Management Protocol (IGMPv3),
PIM, Session Description Protocol (SDP), Distance Vector
Multicast Routing Protocol (DVMRP), source-specic))

• MPLS

IP Address Management

• Static

• Dynamic Host Conguration Protocol (DHCP) (client
and server)

• DHCP relay

Encapsulations

• Ethernet (MAC and tagged)

• Point-to-Point Protocol (PPP) (synchronous)

– Multilink Point-to-Point Protocol (MLPPP)

• Frame Relay

– Multilink Frame Relay (MLFR) (FRF.15, FRF.16)

• High-Level Data Link Control (HDLC)

• Serial (RS-232, RS-449, X.21, V.35, EIA-530)

• 802.1q VLAN support

• Point-to-Point Protocol over Ethernet (PPPoE)

Traffic Management

• Marking, policing, and shaping

• Class-based queuing with prioritization

• Weighted random early detection (WRED)

• Queuing based on VLAN, data-link connection identier (DLCI),

interface, bundles, or filters

Security

• Firewall, zones, screens, policies

• Stateful rewall, ACL lters

• Denial of service (DoS) and distributed denial of service (DDoS)
protections (anomaly-based)

• Prevent replay attack; Anti-Replay

• Unied Access Control Dynamic Remote

• Unied Threat Management - Licensed on high memory

products only

2

– Antivirus, antispam, Web filtering, IPS

Voice Transport

• FRF.12

• Link fragmentation and interleaving (LFI)

• Compressed Real-Time Transport Protocol (CRTP)

1

High Availability

• VRRP

• Stateful failover and dual box clustering via JSRP
– Redundant power (optional)

IPv6

• OSPFv3

• IPv6 Multicast Listener Discovery (MLD)

• BGP

• Quality of service (QoS)

SLA and Measurement

• Real-time performance monitoring (RPM)

• Top talkers (sessions, packets, bandwidth usage)

• J-Flow ow monitoring and accounting services

Logging and Monitoring

• Syslog

• Traceroute

Administration

• Juniper Networks Network and Security Manager support

• Juniper Networks STRM Series Security Threat Response

Managers support

• Juniper Networks Advanced Insight Solutions support

• External administrator database (RADIUS, LDAP, SecureID)

• Auto conguration

• Conguration rollback

• Rescue conguration with button

• Commit conrm for changes

• Auto record for diagnostics

• Software upgrades

• J-Web

Operating System

All J Series Services Routers ship with the worldwide version
of JUNOS Software, which has standard encryption, as opposed

to the US and Canada version, which has strong encryption. You

can download the strong encryption version at no charge so
long as you can certify eligibility. The download is available from

Juniper’s Customer Support Center Web site: www.juniper.net/
customers/csc/software/.

Feature Licenses

Licenses are required for advanced functionality on the J Series

Services Routers. To run the Advanced BGP features, order
Advanced BGP (JX-BGP-ADV-LTU). Each license is good for one

chassis.

On the high memory versions of the J Series, you can run Unified
Threat Management consisting of antivirus, antispam, Web
filtering and IPS. These licenses are good for one chassis and
available as single features, bundles, single year and multi year
ordering options.

1

BGP Route Reflector see ordering information.

2

Unified Threat Management is only supported on high memory versions of J Series and requires a license. See ordering information.

6

J2320

J2350

J4350

J6350

Product Comparison

SPECIFICATION J2320 J2350 J4350 J6350

Maximum Performance and Capacity

JUNOS Software version tested JUNOS 9.6 JUNOS 9.6 JUNOS 9.6 JUNOS 9.6

Firewall performance (large packets) 600 Mbps 750 Mbps 2 Gbps 3.5 Gbps

Firewall performance (IMIX) 400 Mbps 500 Mbps 600 Mbps 1 Gbps

Firewall + routing PPS (64 Byte) 150 Kpps 175 Kpps 225 Kpps 400 Kpps

AES256+SHA-1/3DES+SHA-1 VPN
performance

IPsec VPN Tunnels 512 MB / GB DRAM

IPS (intrusion prevention system) 115 Mbps 130 Mbps 250 Mbps 500 Mbps

Antivirus 25 Mbps 30 Mbps 65 Mbps 130 Mbps

Connections per second 5,000 5,000 10,000 20,000

Maximum concurrent sessions
DRAM options

Maximum security policies 2048 (1 GB DRAM) 2048 (1 GB DRAM) 5192 (1 GB DRAM) 10384 (2 GB DRAM)

Maximum users supported Unrestricted Unrestricted Unrestricted Unrestricted

Network Connectivity

Fixed I/O 24 x 10/100/1000BASE-T 4 x 10/100/1000BASE-T 4 x 10/100/1000BASE-T 4 x 10/100/1000BASE-T

I/O slots 3 x PIM 5 x PIM 4 x PIM +

Services and Routing Engine slots N/A N/A N/A N/A

ExpressCard slot (3G WAN) N/A N/A N/A N/A

WAN/LAN interface options See ordering

Optional maximum number of PoE ports N/A N/A N/A N/A

USB 2 2 2 2

Routing

BGP instances 32 32 32 64

BGP peers 512 MB / 1 GB DRAM

BGP routes 512 MB / 1 GB DRAM

OSPF instances 512 MB / 1 GB DRAM

OSPF routes 512 MB / 1 GB DRAM

RIP v1/v2 instances 512 MB / 1 GB DRAM

125 Mbps 150 Mbps 400 Mbps 900 Mbps

256 / 512

64 K / 128K

512 MB / 1 GB DRAM

information

64 / 64

64 K / 400 K

32 / 32

5 K / 10 K

32 / 32

512 MB / GB DRAM

256 / 512

64 K / 128K

512 MB / 1 GB DRAM

See ordering

information

512 MB / 1 GB DRAM

64 / 64

512 MB / 1 GB DRAM

64 K / 400 K

512 MB / 1 GB DRAM

32 / 32

512 MB / 1 GB DRAM

5 K / 10 K

512 MB / 1 GB DRAM

32 / 32

512 MB / GB DRAM

256 / 512

64 K / 128 K

512 MB / 1 GB DRAM

2 x EPIM/PIM

See ordering

information

512 MB / 1 GB DRAM

64 / 64

512 MB / 1 GB DRAM

64 K / 400 K

512 MB / 1 GB DRAM

32 / 32

512 MB / 1 GB DRAM

5 K / 10 K

512 MB / 1 GB DRAM

32 / 32

1 GB / 2 GB DRAM

512 MB / 1 GB DRAM

1 GB / 2 GB DRAM

1 GB / 2 GB DRAM

1 GB / 2 GB DRAM

1 GB / 2 GB DRAM

1 GB / 2 GB DRAM

512 / 1024

256 K / 256 K

2 x PIM +

4 x EPIM/PIM

See ordering

information

64 / 64

400 K / 1000 K

64 / 64

10 K / 20 K

64 / 64

7

Product Comparison (continued)

SPECIFICATION J2320 J2350 J4350 J6350

Routing (continued)

RIP v2 routes 512 MB / 1 GB DRAM

Static routes 512 MB / 1 GB DRAM

Source-based routing Yes Yes Yes Yes

Policy-based routing Yes Yes Yes Yes

Equal-cost multipath (ECMP) Yes Yes Yes Yes

Reverse path forwarding (RPF) Yes Yes Yes Yes

5 K / 10 K

5 K / 10 K

MPLS

Layer 2 VPN (VPLS) Yes Yes Yes Yes

Layer 3 VPN Yes Yes Yes Yes

LDP Yes Yes Yes Yes

RSVP Yes Yes Yes Yes

Circuit Cross-connect (CCC) Yes Yes Yes Yes

Translational Cross-connect (TCC) Yes Yes Yes Yes

Multicast

IGMP (v1, v2, v3) Yes Yes Yes Yes

PIM SM Yes Yes Yes Yes

PIM source-specific multicast (SSM) Yes Yes Yes Yes

Multicast inside IPsec tunnel Yes Yes Yes Yes

IPsec VPN

Concurrent VPN tunnels 256 / 512

Tunnel interfaces 256 / 512

DES (56-bit), 3DES (168-bit) and
AES (256-bit)

MD-5 and SHA-1 authentication Yes Yes Yes Yes

Manual key, Internet Key Exchange (IKE),
public key infrastructure (PKI) (X.509)

Perfect forward secrecy (DH Groups) 1,2,5 1,2,5 1,2,5 1,2,5

Prevent replay attack Yes Yes Yes Yes

Dynamic remote access VPN Yes Yes Yes No

IPsec NAT traversal Yes Yes Yes Yes

Redundant VPN gateways Yes Yes Yes Yes

(512 MB / 1 GB DRAM)

(512 MB / 1 GB DRAM)

Yes Yes Yes Yes

Yes Yes Yes Yes

User Authentication and Access Control

Third-party user authentication RADIUS, RSA SecureID,

RADIUS accounting Yes Yes Yes Yes

XAUTH VPN, Web-based, 802.X
authentication

PKI certificate requests (PKCS 7 and
PKCS 10)

Certificate Authorities supported VeriSign, Entrust,

LDAP

Yes Yes Yes Yes

Yes Yes Yes Yes

Microsoft, RSA Keon,

iPLanet, (Netscape),

Baltimore,

DoD PKI

Virtualization

Maximum number of security zones 40 40 50 60

Maximum number of virtual routers 25 25 30 60

Maximum number of VLANs 256 256 512 1024

512 MB / 1 GB DRAM

5 K / 10 K

512 MB / 1 GB DRAM

5 K / 10 K

256 / 512

(512 MB / 1 GB DRAM)

256 / 512

(512 MB / 1 GB DRAM)

RADIUS, RSA SecureID,

LDAP

VeriSign, Entrust,

Microsoft, RSA Keon,

iPLanet, (Netscape),

Baltimore,

DoD PKI

512 MB / 1 GB DRAM

5 K / 10 K

512 MB / 1 GB DRAM

5 K / 10 K

256 / 512

(512 MB / 1 GB DRAM)

256 / 512

(512 MB / 1 GB DRAM)

RADIUS, RSA SecureID,

LDAP

VeriSign, Entrust,

Microsoft, RSA Keon,

iPLanet, (Netscape),

Baltimore,

DoD PKI

1 GB / 2 GB DRAM

10 K / 20 K

1 GB / 2 GB DRAM

10 K / 20 K

512 / 1024

(1 GB / 2 GB DRAM)

512 / 1024

(1 GB / 2 GB DRAM)

RADIUS, RSA SecureID,

LDAP

VeriSign, Entrust,

Microsoft, RSA Keon,

iPLanet, (Netscape),

Baltimore,

DoD PKI

8

Product Comparison (continued)

SPECIFICATION J2320 J2350 J4350 J6350

Encapsulations

PPP/MLPPP Yes Yes Yes Yes

MLPPP maximum physical interfaces 6 10 12 12

Frame Relay Yes Yes Yes Yes

MLFR (FRF .15, FRF .16) Yes Yes Yes Yes

MLFR maximum physical interfaces 6 10 12 12

HDLC Yes Yes Yes Yes

Address Translation

Source NAT with Port Address Translation
(PAT)

Static NAT Yes Yes Yes Yes

Destination NAT with PAT Yes Yes Yes Yes

IP Address Assignment

Static Yes Yes Yes Yes

DHCP, PPPoE client Yes Yes Yes Yes

Internal DHCP server Yes Yes Yes Yes

DHCP relay Yes Yes Yes Yes

L2 Switching

VLAN 802.1Q Yes Yes Yes Yes

Link Aggregation 802.3ad/LACP Yes Yes Yes Yes

Jumbo Frame (9216 Byte) Yes Yes Yes Yes

Spanning Tree Protocol (STP) 802.1D, RSTP

802.1w, MSTP 802.1s

Authentication 802.1x Port based and
multiple supplicant

Traffic Management Quality of Service (QoS)

Guaranteed bandwidth Yes Yes Yes Yes

Maximum bandwidth Yes Yes Yes Yes

Ingress traffic policing Yes Yes Yes Yes

Priority-bandwidth utilization Yes Yes Yes Yes

DiffServ marking Yes Yes Yes Yes

High Availability

Active/active—L3 mode Yes Yes Yes Yes

Active/passive—L3 mode Yes Yes Yes Yes

Configuration synchronization Yes Yes Yes Yes

VRRP Yes Yes Yes Yes

Session synchronization for firewall and VPN Yes Yes Yes Yes

Session failover for routing change Yes Yes Yes Yes

Device failure detection Yes Yes Yes Yes

Link failure detection Yes Yes Yes Yes

Firewall

Network attack detection Yes Yes Yes Yes

DoS and DDos protection Yes Yes Yes Yes

TCP reassembly for fragmented packet
protection

Brute force attack mitigation Yes Yes Yes Yes

SYN cookie protection Yes Yes Yes Yes

Zone-based IP spoofing Yes Yes Yes Yes

Malformed packet protection Yes Yes Yes Yes

Yes Yes Yes Yes

Yes Yes Yes Yes

Yes Yes Yes Yes

Yes Yes Yes Yes

9

Product Comparison (continued)

SPECIFICATION J2320 J2350 J4350 J6350

Unified Threat Management

Intrusion Prevention System (IPS) Yes Yes Yes Yes

Protocol anomaly detection Yes Yes Yes Yes

Stateful protocol signatures Yes Yes Yes Yes

Intrusion prevention system (IPS) attack
pattern obfuscation

Customer signatures creation Yes Yes Yes Yes

Frequency of updates Daily and emergency Daily and emergency Daily and emergency Daily and emergency

Antivirus

Express AV (packet-based AV) No Yes Yes Yes

File-based antivirus Yes Yes Yes Yes

Signature database Yes Yes Yes Yes

Protocols scanned POP3, HTTP, SMTP,

Antispyware Yes Yes Yes Yes

Antiadware Yes Yes Yes Yes

Antikeylogger Yes Yes Yes Yes

Antispam Yes Yes Yes Yes

Integrated Web filtering Yes Yes Yes Yes

Redirect Web filtering Yes Yes Yes Yes

Content filtering Yes Yes Yes Yes

Based on MIME type, file extension, and

protocol commands

System Management

Web UI Yes Yes Yes Yes

Command-line interface Yes Yes Yes Yes

Network and Security Manager Yes Yes Yes Yes

STRM Series Yes Yes Yes Yes

Flash and Memory

Memory minimum and maximum (DRAM) 512 MB, 1 GB 512 MB, 1 GB 512 MB, 2 GB 1 GB, 2 GB

Memory slots 4 DIMM 4 DIMM 4 DIMM 4 DIMM

Standard and Maximum Flash memory 512MB / 1GB 512MB / 1GB 512MB / 1GB 512MB / 1GB

USB port for external storage Yes Yes Yes Yes

Dimensions and Power

Dimensions (W x H x D) 17.5 x 1.75 x 15.1 in

Weight 15 lb (6.8 kg)

No interface modules,

Rack mountable Yes, 1 RU Yes, 1.5 RU Yes, 2 RU Yes, 2 RU

Power supply (AC) 100–240 VAC, 275 W 100–240 VAC, 300 W 100–240 VAC, 350 W 100–240 VAC, 420 W

Average power consumption 80 W 80 W 143 W 166 W

Input frequency 47-63 Hz 47-63 Hz 47-63 Hz 47-63 Hz

Maximum current consumption 3.2 A @ 100 VAC 3.5 A @ 100 VAC 5.7 A @ 100 VAC 5.7 A @ 100 VAC

Maximum inrush current 30 A 32 A 32 A 42 A

Yes Yes Yes Yes

IMAP, FTP

Yes Yes Yes Yes

(445 x 44 x 383 mm)

16.6 lb (7.6 kg)

3 interface modules

POP3, HTTP, SMTP,

IMAP, FTP

17.5 x 1.75 x 15.1 in

(445 x 44 x 383 mm)

16 lb (7.3 kg)

No interface modules,

19 lb (8.6 kg)

5 interface modules

POP3, HTTP, SMTP,

IMAP, FTP

17.5 x 3.5 x 21.5 in

(445 x 89 x 546 mm)

23 lb (10.4 kg)

No interface modules,

25.3 lb (11.5 kg)

6 interface modules

POP3, HTTP, SMTP,

IMAP, FTP

17.5 x 3.5 x 21.5 in

(445 x 89 x 546 mm)

25 lb (11.3 kg)

No interface modules,

1 power supply

30.7 lb (13.9 kg)

6 interface modules,

2 power supplies

10

Product Comparison (continued)

SPECIFICATION J2320 J2350 J4350 J6350

Dimensions and Power (continued)

Average heat dissipation 273 BTU/hour 273 BTU/hour 488 BTU/hour 566 BTU/hour

Maximum heat dissipation 1091 BTU/hour 1195 BTU/hour 1070 BTU/hour 1145 BTU/hour

Power supply (DC) NA -48 to -60 VDC, 300 W -48 to -60 VDC, 420 W -48 to -60 VDC, 420 W

Redundant power supply (hot swappable) No No No Yes

Acoustic noise level
(Note: Per ISO 7779 Standard)

Environment

Operational temperature 32° to 122° F

Nonoperational temperature 4° to 158° F

Humidity 10–90% noncondensing 10–90% noncondensing 10–90% noncondensing 10–90% noncondensing

Mean time between failures
(Telcordia model)

Certifications and Network Homologation

USA

Safety certifications UL 60950-1 UL 60950-1 UL 60950-1 UL 60950-1

EMC certifications FCC Class B FCC Class B

Network homologation TIA-968 TIA-968 TIA-968 TIA-966

Canada

Safety certifications CSA 60950-1 CSA 60950-1 CSA 60950-1 CSA 60950-1

EMC certifications ICES class B ICES class B

Network homologation CS-03 CS-03 CS-03 CS-03

Australia

Safety certifications AS / NZS 60950-1 AS / NZS 60950-1 AS / NZS 60950-1 AS / NZS 60950-1

EMC certifications AS / NZS CISPR22

Network homologation AS / ACIF S 002, S 016, S

New Zealand

Safety certifications AS / NZS 60950-1 AS / NZS 60950-1 AS / NZS 60950-1 AS / NZS 60950-1

EMC certifications AS / NZS CISPR22

Network homologation PTC 217, PTC 273 PTC 217, PTC 273 PTC 217, PTC 273 PTC 217, PTC 273

Japan

Safety certifications CB Scheme CB Scheme CB Scheme CB Scheme

EMC certifications VCCI Class B VCCI Class B

Network homologation Certicate for Technical

European Union

Safety certifications EN 60950-1 EN 60950-1 EN 60950-1 EN 60950-1

EMC certifications EN 55022 Class B, EN

Network homologation CTR 12 / 13, CTR 21,

40.0 dB 59.2 dB 59.3 dB 61.2 dB

(0° to 50° C)

(-20° to 70° C)

7.2 years 6.8 years 7.6 years 12 years with redundant

Class B

043.1, S043.2

Class B

Conditions

300386

DoC

32° to 122° F

(0° to 50° C)

4° to 158° F

(-20° to 70° C)

10

10

AS / NZS CISPR22 Class

AS / ACIF S 002, S 016, S

AS / NZS CISPR22 Class

Certicate for Technical

EN 55022 Class B10, EN

CTR 12 / 13, CTR 21,

10

B

043.1, S043.2

10

B

Conditions

300386

DoC

10

32° to 122° F

(0° to 50° C)

4° to 158° F

(-20° to 70° C)

FCC Class A FCC Class A

ICES class A ICES class A

AS / NZS CISPR22

Class A

AS / ACIF S 002, S 016, S

043.1, S043.2

AS / NZS CISPR22

Class A

VCCI Class A VCCI Class A

Certicate for Technical

Conditions

EN 55022 Class A, EN

300386

CTR 12 / 13, CTR 21,

DoC

AS / NZS CISPR22

AS / ACIF S 002, S 016, S

AS / NZS CISPR22

Certicate for Technical

EN 55022 Class A, EN

CTR 12 / 13, CTR 21,

32° to 122° F

(0° to 50° C)

4° to 158° F

(-20° to 70° C)

power

Class A

043.1, S043.2

Class A

Conditions

300386

DoC

Performance-Enabling Services and Support

Juniper Networks is the leader in performance-enabling services and support, which are designed to accelerate, extend, and optimize
your high-performance network. Our services allow you to bring revenue-generating capabilities online faster so you can realize bigger
productivity gains, faster rollouts of new business models and ventures, and greater market reach, while generating higher levels of
customer satisfaction. At the same time, Juniper Networks ensures operational excellence by optimizing your network to maintain

required levels of performance, reliability, and availability. For more details, please visit www.juniper.net/products-services.

11

Ordering Information

The following tables outline part numbers for J6350, J4350, J2350, and J2320 base systems and options; associated WAN and LAN
modules; and additional accessories.

J6350 Base Systems and Options

MODEL NUMBER DESCRIPTION

J6350 Base System

J-6350-JB J6350, Hw-encryption, high memory (1 GB DRAM,

512 MB Flash), 0 PIM cards, 1 AC PSU, w/JUNOS

J-6350-JB-DC J6350, 512 MB CF, 1 GB RAM, Hw-encryption,

0 PIM cards, 1 DC PSU

J-6350-JB-DC-N-TAA J6350, 512 MB CF, 1 GB RAM, Hw-encryption,

0 PIM cards, 1 DC PSU, w/JUNOS - NEBS and TAA

compliant

J-6350-JB-N-TAA J6350, 512 MB CF, 1 GB RAM, Hw-encryption,

0 PIM cards, 1 AC PSU, w/JUNOS - NEBS and TAA

compliant

J6350 Options

Redundant Power Supply

SSG-PS-DC DC power supply

SSG-PS-AC AC power supply

Region-Specific AC Power Cables for SSG-PS-AC

CBL-JX-PWR-AU Australia

CBL-JX-PWR-CH China

CBL-JX-PWR-EU Europe

CBL-JX-PWR-IT Italy

CBL-JX-PWR-JP Japan

CBL-JX-PWR-UK United Kingdom

CBL-JX-PWR-US USA

Additional DRAM

JXX50-MEM-512M-S 2 GB (2 x JXX50-MEM-512M-S, added to default)

Primary Compact Flash (Replaces default)

JX-CF-512M-S 512 MB

JX-CF-1G-S 1 GB

Additional Software Feature Licenses

JX-BGP-ADV-LTU Advanced BGP

JX-JFlow-LTU J-Flow Accounting

J6350-K-AV One year subscription for Juniper-Kaspersky AV

updates

J6350-K-AV-3 Three year subscription for Juniper-Kaspersky AV

updates

J6350-S2-AS One year subscription for Juniper-Sophos

Antispam

J6350-S2-AS-3 Three year subscription for Juniper-Sophos

Antispam

J6350-W-WF One year subscription for Juniper-Websense

Integrated Web Filtering

J6350-W-WF-3 Three year subscription for Juniper-Websense

Integrated Web Filtering

J6350-IDP One year subscription for IDP updates

J6350-IDP-3 Three year subscription for IDP updates

J6350-SMB2-CS One year security subscription for Enterprise -

includes Kaspersky AV, WF, Sophos AS,
and IDP

J6350-SMB2-CS-3 Three year security subscription for Enterprise -

includes Kaspersky AV, WF, Sophos AS,
and IDP

Interface Modules (Various choices; see page 14)

J4350 Base Systems and Options

MODEL NUMBER DESCRIPTION

J4350 Base System

J-4350-JB J4350, Hw-encryption, high-memory (1 GB DRAM,

512 MB Flash), 0 PIM cards, AC PSU, w/JUNOS

J-4350-JB-DC J4350, 512 MB CF, 1 GB RAM, Hw-encryption,

0 PIM cards, DC PSU

J-4350-JB-SC J4350, software encryption, low memory, (512 MB

DRAM, 512 MB Flash) 0 PIM cards, AC PSU, w/
JUNOS, Software Crypto

J-4350-JB-SC-DC J4350, software encryption, low memory, (512 MB

DRAM, 512 MB Flash) 0 PIM cards, DC PSU, w/
JUNOS, Software Crypto

J-4350-JB-DC-N-TAA J4350, 256 MB CF, 1GB RAM, Hw-encryption,

0 PIM cards, DC PSU, NEBS, w/JUNOS - NEBS and

TAA compliant

J-4350-JB-N-TAA J4350, 256 MB CF, 1GB RAM, Hw-encryption,

0 PIM cards, AC PSU, w/JUNOS - NEBS and TAA

compliant

J4350 Options

Additional DRAM for J4350 without encryption acceleration (DRAM
upgrades must be installed in matching pairs)

JXX50-MEM-256M-S 512 MB (JXX50-MEM-256M-S, added

to default)

JXX50-MEM-512M-S • 1 GB (2 x JXX50-MEM-512M-S, replaces default)

• 2 GB (4 x JXX50-MEM-512M-S, replaces default)

Additional DRAM for J4350 with encryption acceleration (DRAM upgrades
must be installed in matching pairs)

JXX50-MEM-512M-S 2 GB (4 x JXX50-MEM-512M-S, replaces default)

Primary Compact Flash (Replaces default)

JX-CF-512M-S 512 MB

JX-CF-1G-S 1 GB

Additional Software Feature Licenses

JX-BGP-ADV-LTU Advanced BGP

JX-JFlow-LTU J-Flow Accounting

J4350-K-AV One year subscription for Juniper-Kaspersky AV

updates

J4350-K-AV-3 Three year subscription for Juniper-Kaspersky AV

updates

J4350-S2-AS One year subscription for Juniper Antispam

J4350-S2-AS-3 Three year subscription for Juniper Antispam

J4350-W-WF One year subscription for Juniper-Websense

Integrated Web Filtering

J4350-W-WF-3 Three year subscription for Juniper-Websense

Integrated Web Filtering

J4350-IDP One year subscription for IDP updates

J4350-IDP-3 Three year subscription for IDP updates

J4350-SMB2-CS One year security subscription for Enterprise -

includes Kaspersky AV, WF, Sophos AS
and IDP

J4350-SMB2-CS-3 Three year security subscription for Enterprise -

includes Kaspersky AV, WF, Sophos AS
and IDP

Interface Modules (Various choices; see page 14)

JXH-HC2-S Cryptographic Acceleration Module, to be used

with J2350-JB-SC only

12

J2350 Base Systems and Options

MODEL NUMBER DESCRIPTION

J2350 Base System

J2350-JB-SC J2350, JUNOS, base memory (512 MB), 5 PIM slots,

J2350-JB-SC-DC J2350, JUNOS, base memory (512 MB DRAM,

J2350-JH J2350, JUNOS, high memory (1 GB DRAM,

J2350-JH-DC J2350, JUNOS, high memory (1 GB), 5 PIM slots,

J2350-JB-SC-DC­N-TAA

J2350-JB-SC-TAA J2350, JUNOS, base memory (512 MB), 5 PIM

J2350-JH-DC-N-TAA J2350, JUNOS, high memory (1 GB), 5 PIM slots,

J2350-JH-TAA J2350, JUNOS, high memory (1 GB), 5 PIM slots,

J2350 Options

Additional DRAM for J2350 without encryption acceleration (DRAM
upgrades must be installed in matching pairs)

JXX50-MEM-512M-S 1 GB (2 x JXX50-MEM-512M-S, replaces default)

Primary Compact Flash (Replaces default)

JX-CF-512M-S 512 MB

JX-CF-1G-S 1 GB

Additional Software Feature Licenses

JX-BGP-ADV-LTU Advanced BGP

JX-JFlow-LTU J-Flow Accounting

J2350-K-AV One year subscription for Juniper-Kaspersky AV

J2350-K-AV-3 Three year subscription for Juniper-Kaspersky AV

J2350-S2-AS One year subscription for Juniper-Sophos

J2350-S2-AS-3 Three year subscription for Juniper-Sophos

J2350-W-WF One year subscription for Juniper-Websense

J2350-W-WF-3 Three year subscription for Juniper-Websense

J2350-IDP One year subscription for IDP updates

J2350-IDP-3 Three year subscription for IDP updates

J2350-SMB2-CS One year security subscription for Enterprise -

J2350-SMB2-CS-3 Three year security subscription for Enterprise -

Interface Modules (Various choices; see page 14)

JXH-HC2-S Cryptographic Acceleration Module, to be used

SW security, AC power supply, 19” rack mount

512 MB Flash), 5 PIM slots, SW encryption, DC
power supply, 19” rack mount

512 MB Flash), 3 PIM slots, HW encryption, AC
power supply, 19” rack mount

HW Crypto, DC power supply, fan lter, 19” rack

mount

J2350, JUNOS, base memory (512 MB), 5 PIM slots,
SW Crypto, DC power supply, fan lter, NEBS, TAA,
19” rack mount

slots, SW Crypto, AC power supply, TAA, 19” rack

mount

HW Crypto, DC power supply, fan lter, NEBS, TAA,
19” rack mount

HW Crypto, AC power supply, TAA, 19” rack mount

updates

updates

Antispam

Antispam

Integrated Web Filtering

Integrated Web Filtering

includes Kaspersky AV, WF, Sophos AS
and IDP

includes Kaspersky AV, WF, Sophos AS
and IDP

with J2350-JB-SC only

J2320 Base Systems and Options

MODEL NUMBER DESCRIPTION

J2320 Base System

J2320-JB-SC J2320, JUNOS, base memory (512 MB DRAM,

512 MB Flash), 3 PIM slots, SW security, AC power
supply, 19” rack mount

J2320-JB-SC-TAA J2320, JUNOS, base memory (512 MB DRAM,

512 MB Flash), 3 PIM slots, SW security, AC power
supply, TAA 19” rack mount

J2320-JH J2320, JUNOS, high memory (1 GB DRAM,

512 MB Flash), 3 PIM slots, Hw-encryption,
AC power supply, 19” rack mount

J2320 Options

Additional DRAM for J2320 without encryption acceleration (DRAM
upgrades must be installed in matching pairs)

J-MEM-512M-S 1 GB (2 x J-MEM-512M-S replaces default)

Primary Compact Flash (Replaces default)

JX-CF-512M-S 512 MB

JX-CF-1G-S 1 GB

Additional Software Feature Licenses

JX-BGP-ADV-LTU Advanced BGP

JX-JFlow-LTU J-Flow Accounting

J2320-K-AV One year subscription for Juniper-Kaspersky

AV updates

J2320-K-AV-3 Three year subscription for Juniper-Kaspersky

AV updates

J2320-S2-AS One year subscription for Juniper -Sophos

Antispam

J2320-S2-AS-3 Three year subscription for Juniper -Sophos

Antispam

J2320-W-WF One year subscription for Juniper-Websense

Integrated Web Filtering

J2320-W-WF-3 Three year subscription for Juniper-Websense

Integrated Web Filtering

J2320-IDP One year subscription for IDP updates

J2320-IDP-3 Three year subscription for IDP updates

J2320-SMB2-CS One year security subscription for Enterprise -

includes Kaspersky AV, WF, Sophos AS
and IDP

J2320-SMB2-CS-3 Three year security subscription for Enterprise -

includes Kaspersky AV, WF, Sophos AS
and IDP

Interface Modules (Various choices; see page 14)

JXH-HC2-S Cryptographic Acceleration Module, to be used

with J2320-JB-SC only

13

WAN and LAN Module Part Numbers

PART NUMBER DESCRIPTION SUPPORTED ON J2320, J2350 SUPPORTED ON J4350, J6350

Physical Interface Module (PIM)

JX-1DS3-S 1-Port DS3 PIM No Yes

JX-1E3-S 1-Port E3 PIM No Yes

JX-2T1-RJ48-S 2-Port T1 PIM Yes Yes

JX-2E1-RJ48-S 2-Port E1 PIM Yes Yes

JX-2CT1E1-RJ45-S 2-Port Channelized T1/E1 PIM Yes Yes

JX-2Serial-1SL-S 2-Port Synchronous Serial PIM Yes Yes

JX-2FE-TX-S 2-Port FE PIM No Yes

JX-4BRI-S-S 4-Port ISDN BRI – S Interface Yes Yes

JX-4BRI-U-S 4-Port ISDN BRI – U Interface Yes Yes

JX-1ADSL-A-S 1-Port ADSL Annex A PIM Yes Yes

JX-1ADSL-B-S 1-Port ADSL Annex B PIM Yes Yes

JX-2SHDSL-S 2-Port 2-wire or 1-Port 4-wire

G.SHDSL Interface

JX-1DS3-S 1-Port DS3 PIM No Yes

Enhanced Physical Interface Module (EPIM)

JXE-1GE-TX-S 1-Port Gigabit Copper EPIM No Yes

JXE-1GE-SFP-S 1-Port Gigabit SFP EPIM No Yes

JXE-4FE-TX-S 4-Port FE EPIM No Yes

Universal Physical Interface Module (UPIM)

JXU-6GE-SFP-S 6-Port SFP Gigabit Ethernet

Universal PIM, SFPs sold separately

JXU-8GE-TX-S 8-Port Gigabit Ethernet 10/100/1000

Copper Universal PIM

JXU-16GE-TX-S 16-Port Gigabit Ethernet 10/100/1000

Copper Universal PIM

JXU-1SFP-S 1-Port SFP 100 Mbps or Gigabit

Ethernet Universal PIM (SFP sold

separately)

Yes Yes

Yes Yes

Yes Yes

Yes Yes

Yes Yes

Integrated Services Modules PIM

INTEGRATED SERVICES
MODULE PIM

JX-ISM-200-WXC ISM200 Integrated Services Module JUNOS 9.1 JUNOS 9.1

DESCRIPTION

J2320/J2350 J4350/J6350

MINIMUM JUNOS SOFTWARE

Avaya Telephony Gateway Modules and Telephony Interface Modules

AVAYA
PART NUMBER

700406978 TGM550 - Media Gateway Module JUNOS 9.1 JUNOS 9.1

700396138 TIM510 T1/E1 Media Module JUNOS 9.1 JUNOS 9.1

700396146 TIM514 Analog 4+4 Media Module JUNOS 9.1 JUNOS 9.1

700396153 TIM 521 BRI Media Module JUNOS 9.1 JUNOS 9.1

700436645 TGM550-20 Media Gateway Module JUNOS 9.1 JUNOS 9.1

700436652 TGM550-10 Media Gateway Module JUNOS 9.1 JUNOS 9.1

700426786 TIM508 Analog 8FXS Media Module JUNOS 9.1 JUNOS 9.1

700426794 TIM516 Analog 16FXS Media Module JUNOS 9.1 JUNOS 9.1

700426786 TIM518 Analog 8FXS+8FXO Media Module JUNOS 9.1 JUNOS 9.1

*Avaya Telephony Gateway Modules and Telephony Interface Modules are available through Avaya resellers and partners.

DESCRIPTION

J2320/J2350 J4350/J6350

14

MINIMUM JUNOS SOFTWARE

Small Form Pluggable (SFP) Modules

The one-port 100 Mbps or Gigabit Ethernet Universal PIM and the six-port SFP Gigabit Ethernet Universal PIM require an SPF module
to provide the physical interface. The SFP must be ordered separately from the UPIM.

PART NUMBER DESCRIPTION

JX-SFP-1GE-LX SFP 1000BASE-LX Gigabit Optical Transceiver SFP Module

JX-SFP-1GE-SX SFP 1000BASE-SX Gigabit Optical Transceiver SFP Module

JX-SFP-1GE-T SFP 1000BASE-T Gigabit Copper Transceiver SFP Module

JX-SFP-1FE-FX SFP 100BASE-FX Optical Transceiver Module (JXU-1SFP-S only)

Serial Interface Cables

The two-port Serial PIM requires separate purchase of serial cables.

PART NUMBER CABLE TYPE LENGTH CONNECTOR TYPE

JX-CBL-EIA530-DCE EIA530 cable (DCE) 10 ft (3 m) Female

JX-CBL-EIA530-DTE EIA530 cable (DTE) 10 ft (3 m) Male

JX-CBL-RS232-DCE RS232 cable (DCE) 10 ft (3 m) Female

JX-CBL-RS232-DTE RS232 cable (DTE) 10 ft (3 m) Male

JX-CBL-RS449-DCE RS449 cable (DTE) 10 ft (3 m) Female

JX-CBL-RS449-DTE RS449 cable (DTE) 10 ft (3 m) Male

JX-CBL-V35-DCE V.35 cable (DTE) 10 ft (3 m) Female

JX-CBL-V35-DTE V.35 cable (DTE) 10 ft (3 m) Male

JX-CBL-X21-DCE X.21 cable (DCE) 10 ft (3 m) Female

JX-CBL-X21-DTE X.21 cable (DTE) 10 ft (3 m) Male

15

About Juniper Networks

Juniper Networks, Inc. is the leader in high-performance networking. Juniper offers a high-performance network infrastructure
that creates a responsive and trusted environment for accelerating the deployment of services and applications over a single network.
This fuels high-performance businesses. Additional information can be found at www.juniper.net.

Corporate and Sales Headquarters

Juniper Networks, Inc.

1194 North Mathilda Avenue
Sunny vale, CA 94089 USA
Phone: 888.JUNIPER (888.586.4737)
or 408.745.20 00
Fax: [phone]

APAC Headquarters

Juniper Networks (Hong Kong)
26/F, Cityplaza One
1111 King’s Road
Taikoo Shing, Hong Kong
Phone: [phone]
Fax: [phone]

To purchase Juniper Networks solutions, please

contact your Juniper Networks representative

at 1-866-298-6428 or authorized reseller.

1000 206-003-E N Sept 20 09 Printed on recycled paper.

16

EMEA Headquarters

Juniper Networks Irel and
Airside Business Park

Swords, County Dublin, Ireland
Phone: [phone]
Fax: [phone]

Copy right 2009 Juniper Netw orks, Inc. All rights

reserved. Juniper Networks, the Juniper Networks
logo, JUNOS, NetScreen, and ScreenOS are
registered tr ademar ks of Juniper Networks, Inc.
in the United State s and other countries. JUNOSe
is a trademark of Juniper Networks, Inc. All other
trademarks, serv ice marks, registered marks, or
registered service marks are the property of their
respective owners . Juniper Networ ks assumes
no responsibility for any inaccuracies in this
document. Juniper Netw orks re serves the right to
change, modif y, transfer, or other wise revise this
publication without notice.
