Juniper EX9204 Hardware Guide

EX9204 Switch Hardware Guide

Published

2020-12-15

Juniper Networks, Inc. 1133 Innovation Way Sunnyvale, California 94089 USA 408-745-2000 www.juniper.net

Juniper Networks, the Juniper Networks logo, Juniper, and Junos are registered trademarks of Juniper Networks, Inc. in the United States and other countries. All other trademarks, service marks, registered marks, or registered service marks are the property of their respective owners.

Juniper Networks assumes no responsibility for any inaccuracies in this document. Juniper Networks reserves the right to change, modify, transfer, or otherwise revise this publication without notice.

EX9204 Switch Hardware Guide

The information in this document is current as of the date on the title page.

YEAR 2000 NOTICE

Juniper Networks hardware and software products are Year 2000 compliant. Junos OS has no known time-related limitations through the year 2038. However, the NTP application is known to have some difficulty in the year 2036.

END USER LICENSE AGREEMENT

The Juniper Networks product that is the subject of this technical documentation consists of (or is intended for use with) Juniper Networks software. Use of such software is subject to the terms and conditions of the End User License Agreement (“EULA”) posted at https://support.juniper.net/support/eula/. By downloading, installing or using such software, you agree to the terms and conditions of that EULA.

About the Documentation | xiii

Documentation and Release Notes | xiii

Using the Examples in This Manual | xiii

Merging a Full Example | xiv

Merging a Snippet | xv

Documentation Conventions | xv

Documentation Feedback | xviii

Requesting Technical Support | xviii

Self-Help Online Tools and Resources | xix

Creating a Service Request with JTAC | xix

iii

Overview

EX9204 System Overview | 21

EX9204 Switch Hardware Overview | 21

Benefits of the EX9204 Switch | 22

Software | 22

Front and Rear Views of an EX9204 Switch | 22

Host Subsystem | 24

Line Cards | 24

Cooling System | 26

Power Supplies | 26

EX9204 Switch Configurations | 27

EX9204 Switch Hardware and CLI Terminology Mapping | 31

Chassis Physical Specifications of an EX9204 Switch | 35

Field-Replaceable Units in an EX9200 Switch | 37

EX9204 Chassis | 39

Understanding EX9204 Switch Component and Functionality Redundancy | 39

Craft Interface in an EX9200 Switch | 41

Host Subsystem LEDs | 43

Fan LEDs | 43

Power Supply (PEM) LEDs | 44

Switch Fabric LEDs and Control Buttons | 44

Line Card LEDs and Control Buttons | 45

Alarm LEDs and Alarm Cutoff Button | 45

Alarm Relay Contacts | 46

Midplane in an EX9200 Switch | 47

EX9204 Cooling System | 49

Fan Tray | 49

Airflow Direction in the EX9204 Switch Chassis | 50

EX9204 Power System | 51

AC Power Supply in an EX9204 Switch | 51

AC Power Supply Description | 52

AC Power Supply Configurations | 53

AC Power Supply Specifications for EX9204 Switches | 55

AC Power Supply LEDs in an EX9204 Switch | 55

AC Power Cord Specifications for an EX9204 Switch | 56

DC Power Supply in an EX9204 Switch | 59

DC Power Supply Description | 60

DC Power Supply Configurations | 61

DC Power Supply Specifications for EX9204 Switches | 62

DC Power Supply LEDs in an EX9204 Switch | 63

Power Requirements for EX9200 Switch Components | 64

EX9200 Host Subsystem | 65

Host Subsystem in an EX9200 Switch | 66

Routing Engine Module in an EX9200 Switch | 66

Routing Engine Module LEDs in an EX9200 Switch | 70

Switch Fabric Module in an EX9200 Switch | 72

Switch Fabric Module LEDs in an EX9200 Switch | 75

EX9200-SF3 Module in an EX9200 Switch | 76

EX9200-SF3 Components and Features | 77

EX9200-SF3 LEDs | 78

EX9200-SF3 Fabric Bandwidth Performance and Redundancy | 78

EX9200-SF3 Maximum Power Consumption per Ambient Temperature and CB Slot | 80

Interoperability with Existing Hardware | 81

EX9200-SF3 Unsupported Functions and Capabilities from Legacy Swith Fabric

Modules | 82

EX9200 Line Cards | 82

Line Card Model and Version Compatibility in an EX9200 Switch | 83

EX9200-2C-8XS Line Card | 86

Line Card Models | 86

Line Card Components | 87

EX9200-4QS Line Card | 88

Line Card Models | 88

Line Card Components | 89

EX9200-6QS Line Card | 89

Line Card Models | 89

Line Card Components | 90

EX9200-MPC Line Card | 92

Line Card Models | 92

Line Card Components | 93

EX9200-12QS Line Card | 95

Line Card Models | 96

Line Card Components | 97

EX9200-15C Line Card | 98

Line Card Models | 98

Line Card Components | 100

EX9200-15C Power Requirements | 100

EX9200-15C LEDs | 101

Cables and Connectors | 101

EX9200-32XS Line Card | 102

Line Card Models | 102

Line Card Components | 103

EX9200-40T Line Card | 103

Line Card Models | 103

Line Card Components | 104

EX9200-40F Line Card | 105

Line Card Models | 105

Line Card Components | 106

EX9200-40F-M Line Card | 106

Line Card Models | 106

Line Card Components | 107

EX9200-40XS Line Card | 108

Line Card Models | 108

Line Card Components | 109

Line Card LED in an EX9200 Switch | 110

Network Port LEDs on Line Cards in an EX9200 Switch | 110

Modular Interface Card LED in an EX9200 Switch | 111

Configuring Rate Selectability on an EX9200-12QS Line Card to Enable Different Port

Speeds | 112

Configuring Rate Selectability at the PIC Level | 112

Configuring Rate Selectability at the Port Level | 114

Site Planning, Preparation, and Specifications

Site Preparation Checklist for an EX9204 Switch | 118

EX9204 Site Guidelines and Requirements | 119

Environmental Requirements and Specifications for EX Series Switches | 120

General Site Guidelines | 125

Site Electrical Wiring Guidelines | 125

Clearance Requirements for Airflow and Hardware Maintenance for an EX9204 Switch | 126

Rack Requirements | 127

Cabinet Requirements | 128

Grounding Cable and Lug Specifications for EX9200 Switches | 130

Grounding Points Specifications for an EX9200 Switch | 130

Grounding Cable Lug Specifications for an EX9200 Switch | 131

Grounding Cable Specifications for an EX9200 Switch | 131

EX9200 Network Cable and Transceiver Planning | 132

Pluggable Transceivers Supported on EX9200 Switches | 132

Understanding EX Series Switches Fiber-Optic Cable Signal Loss, Attenuation, and

Dispersion | 133

Signal Loss in Multimode and Single-Mode Fiber-Optic Cable | 133

Attenuation and Dispersion in Fiber-Optic Cable | 134

Calculating the Fiber-Optic Cable Power Budget for EX Series Devices | 135

Calculating the Fiber-Optic Cable Power Margin for EX Series Devices | 135

EX9200 Management Cable Specifications and Pinouts | 137

Management Cable Specifications | 137

Console Port Connector Pinout Information | 138

USB Port Specifications for an EX Series Switch | 139

vii

RJ-45 Management Port Connector Pinout Information | 139

RJ-45 to DB-9 Serial Port Adapter Pinout Information | 140

Initial Installation and Configuration

Unpacking and Mounting the EX9204 Switch | 142

Unpacking the EX9200 Switch | 142

Parts Inventory (Packing List) for an EX9204 Switch | 144

Unpacking a Line Card Used in an EX9200 Switch | 146

Installing and Connecting an EX9204 Switch | 148

Installing a Mounting Shelf in a Rack or Cabinet for an EX9204 Switch | 149

Moving the Mounting Brackets for Center-Mounting an EX9200 Switch | 151

Mounting an EX9200 Switch on a Rack or Cabinet Using a Mechanical Lift | 153

Mounting an EX9204 Switch on a Rack or Cabinet Without Using a Mechanical Lift | 156

Connecting the EX9204 to Power | 158

Connect Earth Ground to an EX Series Switch | 159

Parts and Tools Required for Connecting an EX Series Switch to Earth Ground | 159

Special Instructions to Follow Before Connecting Earth Ground to an EX Series Switch | 164

Connecting Earth Ground to an EX Series Switch | 165

Connecting AC Power to an EX9204 Switch | 166

Powering On an AC-Powered EX9200 Switch | 168

Connecting DC Power to an EX9204 Switch | 170

Powering On a DC-Powered EX9200 Switch | 175

Connecting the EX9200 to External Devices | 177

Connecting an EX9200 Switch to a Network for Out-of-Band Management | 178

Connecting an EX9200 Switch to a Management Console or an Auxiliary Device | 179

Connecting the EX9200 Switch to an External Alarm-Reporting Device | 180

Connecting the EX9200 to the Network | 181

Install a Transceiver | 181

Connect a Fiber-Optic Cable | 184

Configuring Junos OS on the EX9200 | 185

viii

EX9200 Switch Default Configuration | 185

Connecting and Configuring an EX9200 Switch (CLI Procedure) | 186

Maintaining Components

Routine Maintenance Procedures for EX9200 Switches | 192

Maintaining the EX9200 Cooling System | 192

Removing a Fan Tray from an EX9200 Switch | 192

Installing a Fan Tray in an EX9200 Switch | 194

Maintaining the Fan Tray in EX9200 Switches | 196

Maintaining the Air Filter in EX9200 Switches | 199

Maintaining the EX9204 Power System | 199

Removing an AC Power Supply from an EX9204 Switch | 200

Installing an AC Power Supply in an EX9204 Switch | 201

Removing a DC Power Supply from an EX9204 Switch | 203

Installing a DC Power Supply in an EX9204 Switch | 205

Maintaining Power Supplies in EX9200 Switches | 207

Maintaining the EX9200 Host Subsystem | 208

Taking the Host Subsystem Offline in an EX9200 Switch | 209

Removing an RE Module from an EX9200 Switch | 209

Installing an RE Module in an EX9200 Switch | 211

Upgrading an EX9200-SF to an EX9200-SF2 | 214

Preparing the EX9200 Switch for an EX9200-SF2 Upgrade | 214

Powering Off the Switch | 214

Removing a Routing Engine from an EX9200-SF Module | 215

Replacing the EX9200-SF with the EX9200-SF2 | 215

Installing a Routing Engine into an EX9200-SF2 | 215

Powering On the Switch | 216

Completing the EX9200-SF2 Upgrade | 216

Upgrading to an EX9200-SF3 | 217

Preparing the EX9200 Switch for an EX9200-SF3 Upgrade | 218

Powering Off the Switch | 218

Removing a Routing Engine from an SF Module | 219

Replacing the EX9200-SF or EX9200-SF2 with the EX9200-SF3 | 219

Installing a Routing Engine into an EX9200-SF3 | 219

Powering On the Switch | 220

Completing the EX9200-SF3 Upgrade | 220

Removing an SF Module from an EX9200 Switch | 221

Installing an SF Module in an EX9200 Switch | 223

Maintaining the Host Subsystem in EX9200 Switches | 227

Maintaining the EX9200 Line Cards | 230

Handling and Storing Line Cards | 231

Holding a Line Card | 231

Storing a Line Card | 235

Maintaining Line Card Cables | 236

Unpacking a Line Card Used in an EX9200 Switch | 236

Removing a Line Card from an EX9200 Switch | 237

Installing a Line Card in an EX9200 Switch | 240

Removing a MIC from an EX9200-MPC Line Card | 242

Installing a MIC in an EX9200-MPC Line Card | 245

Maintaining a Transceiver | 250

Remove a Transceiver | 251

Install a Transceiver | 254

Maintaining Fiber-Optic Cables | 257

Connect a Fiber-Optic Cable | 257

Disconnect a Fiber-Optic Cable | 258

How to Handle Fiber-Optic Cables | 259

Removing an EX9204 from a Rack or Cabinet | 260

Powering Off an EX9200 Switch | 260

Removing an EX9200 Switch from a Rack or Cabinet Using a Mechanical Lift | 261

Removing an EX9204 Switch from a Rack or Cabinet Without Using a Mechanical Lift | 262

Troubleshooting Hardware

Troubleshooting EX9200 Components | 266

Troubleshooting the Cooling System in an EX9200 Switch | 266

Troubleshooting Power Supplies in an EX9200 Switch | 267

Troubleshooting Line Cards in EX9200 Switches | 268

Troubleshooting Traffic Drops on EX9200-6QS Line Cards | 271

Understand Alarm Types and Severity Levels on EX Series Switches | 271

Chassis Component Alarm Conditions on EX9200 Switches | 273

Backup Routing Engine Alarms | 278

Monitor System Log Messages | 280

Troubleshoot Temperature Alarms in EX Series Switches | 285

Contacting Customer Support and Returning the Chassis or Components

Returning an EX9204 Chassis or Components | 291

Returning an EX9200 Switch or Component for Repair or Replacement | 291

Locating the Serial Number on an EX9204 Switch or Component | 292

Listing the Switch and Components Details with the CLI | 292

Locating the Serial Number ID Label on an EX9200 Switch Chassis | 294

Locating Serial Number ID Labels on FRU Components | 295

Contact Customer Support to Obtain Return Material Authorization | 297

Packing an EX9200 Switch or Component | 298

Packing an EX9200 Switch | 298

Packing EX9200 Switch Components for Shipping | 299

Safety and Compliance Information

General Safety Guidelines and Warnings | 303

Definitions of Safety Warning Levels | 304

Qualified Personnel Warning | 307

Warning Statement for Norway and Sweden | 308

Fire Safety Requirements | 308

Fire Suppression | 308

Fire Suppression Equipment | 308

Installation Instructions Warning | 310

Chassis and Component Lifting Guidelines | 310

Restricted Access Warning | 312

Ramp Warning | 314

Rack-Mounting and Cabinet-Mounting Warnings | 315

Grounded Equipment Warning | 321

Radiation from Open Port Apertures Warning | 322

Laser and LED Safety Guidelines and Warnings | 323

General Laser Safety Guidelines | 323

Class 1 Laser Product Warning | 324

Class 1 LED Product Warning | 325

Laser Beam Warning | 326

Maintenance and Operational Safety Guidelines and Warnings | 326

Battery Handling Warning | 328

Jewelry Removal Warning | 329

Lightning Activity Warning | 331

Operating Temperature Warning | 332

Product Disposal Warning | 334

General Electrical Safety Guidelines and Warnings | 335

Action to Take After an Electrical Accident | 336

Prevention of Electrostatic Discharge Damage | 337

AC Power Electrical Safety Guidelines | 338

AC Power Disconnection Warning | 340

DC Power Disconnection Warning | 341

DC Power Electrical Safety Guidelines | 343

DC Power Grounding Requirements and Warning | 344

DC Power Wiring Sequence Warning | 346

DC Power Wiring Terminations Warning | 349

Multiple Power Supplies Disconnection Warning | 352

TN Power Warning | 353

xii

Agency Approvals and Compliance Statements for EX Series Switches | 353

Agency Approvals for EX Series Switches | 354

Battery Compliance Statement for Environmental Requirements for EX Series Switches | 355

Compliance Statements for Acoustic Noise for EX Series Switches | 355

Compliance Statements for EMC Requirements for EX Series Switches | 355

Canada | 356

Taiwan | 357

European Community | 357

Israel | 357

Japan | 357

Korea | 358

United States | 358

FCC Part 15 Statement | 358

Nonregulatory Environmental Standards | 359

About the Documentation

IN THIS SECTION

Documentation and Release Notes | xiii

Using the Examples in This Manual | xiii

Documentation Conventions | xv

Documentation Feedback | xviii

Requesting Technical Support | xviii

Use this guide to install hardware and perform initial software configuration, routine maintenance, and troubleshooting for the EX9204 switch. After completing the installation and basic configuration procedures covered in this guide, refer to the Junos OS documentation for information about further software configuration.

xiii

Documentation and Release Notes

To obtain the most current version of all Juniper Networks®technical documentation, see the product documentation page on the Juniper Networks website at https://www.juniper.net/documentation/.

If the information in the latest release notes differs from the information in the documentation, follow the product Release Notes.

Juniper Networks Books publishes books by Juniper Networks engineers and subject matter experts. These books go beyond the technical documentation to explore the nuances of network architecture, deployment, and administration. The current list can be viewed at https://www.juniper.net/books.

Using the Examples in This Manual

If you want to use the examples in this manual, you can use the load merge or the load merge relative command. These commands cause the software to merge the incoming configuration into the current candidate configuration. The example does not become active until you commit the candidate configuration.

If the example configuration contains the top level of the hierarchy (or multiple hierarchies), the example is a full example. In this case, use the load merge command.

If the example configuration does not start at the top level of the hierarchy, the example is a snippet. In this case, use the load merge relative command. These procedures are described in the following sections.

Merging a Full Example

To merge a full example, follow these steps:

1. From the HTML or PDF version of the manual, copy a configuration example into a text file, save the file with a name, and copy the file to a directory on your routing platform.

For example, copy the following configuration to a file and name the file ex-script.conf. Copy the ex-script.conf file to the /var/tmp directory on your routing platform.

system {

scripts {

commit {

file ex-script.xsl;

}

} } interfaces {

fxp0 {

disable; unit 0 {

family inet {

address 10.0.0.1/24;

}

} }

xiv

2. Merge the contents of the file into your routing platform configuration by issuing the load merge configuration mode command:

[edit] user@host# load merge /var/tmp/ex-script.conf load complete

Merging a Snippet

To merge a snippet, follow these steps:

1. From the HTML or PDF version of the manual, copy a configuration snippet into a text file, save the file with a name, and copy the file to a directory on your routing platform.

For example, copy the following snippet to a file and name the file ex-script-snippet.conf. Copy the ex-script-snippet.conf file to the /var/tmp directory on your routing platform.

commit {

file ex-script-snippet.xsl; }

2. Move to the hierarchy level that is relevant for this snippet by issuing the following configuration mode command:

[edit] user@host# edit system scripts [edit system scripts]

3. Merge the contents of the file into your routing platform configuration by issuing the load merge relative configuration mode command:

[edit system scripts] user@host# load merge relative /var/tmp/ex-script-snippet.conf load complete

For more information about the load command, see CLI Explorer.

Documentation Conventions

Table 1 on page xvi defines notice icons used in this guide.

Table 1: Notice Icons

xvi

DescriptionMeaningIcon

Indicates important features or instructions.Informational note

Caution

Indicates a situation that might result in loss of data or hardware damage.

Alerts you to the risk of personal injury or death.Warning

Alerts you to the risk of personal injury from a laser.Laser warning

Indicates helpful information.Tip

Alerts you to a recommended use or implementation.Best practice

Table 2 on page xvi defines the text and syntax conventions used in this guide.

Table 2: Text and Syntax Conventions

ExamplesDescriptionConvention

Fixed-width text like this

Italic text like this

Represents text that you type.Bold text like this

Represents output that appears on the terminal screen.

Introduces or emphasizes important

•

new terms.

Identifies guide names.

•

Identifies RFC and Internet draft

•

titles.

To enter configuration mode, type the configure command:

user@host> configure

user@host> show chassis alarms

No alarms currently active

A policy term is a named structure

•

that defines match conditions and actions.

Junos OS CLI User Guide

•

RFC 1997, BGP Communities

•

Attribute

Table 2: Text and Syntax Conventions (continued)

xvii

ExamplesDescriptionConvention

Italic text like this

Text like this

< > (angle brackets)

| (pipe symbol)

Represents variables (options for which you substitute a value) in commands or configuration statements.

Represents names of configuration statements, commands, files, and directories; configuration hierarchy levels; or labels on routing platform components.

variables.

Indicates a choice between the mutually exclusive keywords or variables on either side of the symbol. The set of choices is often enclosed in parentheses for clarity.

Configure the machine’s domain name:

[edit] root@# set system domain-name

domain-name

To configure a stub area, include

•

the stub statement at the [edit protocols ospf area area-id]

hierarchy level.

The console port is labeled

•

CONSOLE.

stub <default-metric metric>;Encloses optional keywords or

broadcast | multicast

(string1 | string2 | string3)

# (pound sign)

[ ] (square brackets)

Indention and braces ( { } )

; (semicolon)

GUI Conventions

Indicates a comment specified on the same line as the configuration statement to which it applies.

Encloses a variable for which you can substitute one or more values.

Identifies a level in the configuration hierarchy.

Identifies a leaf statement at a configuration hierarchy level.

rsvp { # Required for dynamic MPLS only

community name members [ community-ids ]

[edit] routing-options {

static {

route default {

nexthop address; retain;

}

Table 2: Text and Syntax Conventions (continued)

xviii

ExamplesDescriptionConvention

Bold text like this

> (bold right angle bracket)

Represents graphical user interface (GUI) items you click or select.

Separates levels in a hierarchy of menu selections.

In the Logical Interfaces box, select

•

All Interfaces.

To cancel the configuration, click

•

Cancel.

In the configuration editor hierarchy, select Protocols>Ospf.

Documentation Feedback

We encourage you to provide feedback so that we can improve our documentation. You can use either of the following methods:

Online feedback system—Click TechLibrary Feedback, on the lower right of any page on the Juniper

•

Networks TechLibrary site, and do one of the following:

Click the thumbs-up icon if the information on the page was helpful to you.

•

Click the thumbs-down icon if the information on the page was not helpful to you or if you have

•

suggestions for improvement, and use the pop-up form to provide feedback.

E-mail—Send your comments to techpubs-comments@juniper.net. Include the document or topic name,

•

URL or page number, and software version (if applicable).

Requesting Technical Support

Technical product support is available through the Juniper Networks Technical Assistance Center (JTAC). If you are a customer with an active Juniper Care or Partner Support Services support contract, or are

covered under warranty, and need post-sales technical support, you can access our tools and resources online or open a case with JTAC.

JTAC policies—For a complete understanding of our JTAC procedures and policies, review the JTAC User

•

Guide located at https://www.juniper.net/us/en/local/pdf/resource-guides/7100059-en.pdf.

Product warranties—For product warranty information, visit https://www.juniper.net/support/warranty/.

•

JTAC hours of operation—The JTAC centers have resources available 24 hours a day, 7 days a week,

•

365 days a year.

Self-Help Online Tools and Resources

For quick and easy problem resolution, Juniper Networks has designed an online self-service portal called the Customer Support Center (CSC) that provides you with the following features:

Find CSC offerings: https://www.juniper.net/customers/support/

•

Search for known bugs: https://prsearch.juniper.net/

•

xix

Find product documentation: https://www.juniper.net/documentation/

•

Find solutions and answer questions using our Knowledge Base: https://kb.juniper.net/

•

Download the latest versions of software and review release notes:

•

https://www.juniper.net/customers/csc/software/

Search technical bulletins for relevant hardware and software notifications:

•

https://kb.juniper.net/InfoCenter/

Join and participate in the Juniper Networks Community Forum:

•

https://www.juniper.net/company/communities/

Create a service request online: https://myjuniper.juniper.net

•

To verify service entitlement by product serial number, use our Serial Number Entitlement (SNE) Tool:

https://entitlementsearch.juniper.net/entitlementsearch/

Creating a Service Request with JTAC

You can create a service request with JTAC on the Web or by telephone.

Visit https://myjuniper.juniper.net.

•

Call 1-888-314-JTAC (1-888-314-5822 toll-free in the USA, Canada, and Mexico).

•

For international or direct-dial options in countries without toll-free numbers, see

https://support.juniper.net/support/requesting-support/.

CHAPTER

Overview

EX9204 System Overview | 21

EX9204 Chassis | 39

EX9204 Cooling System | 49

EX9204 Power System | 51

EX9200 Host Subsystem | 65

EX9200 Line Cards | 82

EX9204 System Overview

IN THIS SECTION

EX9204 Switch Hardware Overview | 21

EX9204 Switch Configurations | 27

EX9204 Switch Hardware and CLI Terminology Mapping | 31

Chassis Physical Specifications of an EX9204 Switch | 35

Field-Replaceable Units in an EX9200 Switch | 37

EX9204 Switch Hardware Overview

IN THIS SECTION

Benefits of the EX9204 Switch | 22

Software | 22

Front and Rear Views of an EX9204 Switch | 22

Host Subsystem | 24

Line Cards | 24

Cooling System | 26

Power Supplies | 26

Juniper Networks EX9204 Ethernet Switches provide high performance, scalable connectivity, and carrier-class reliability for high-density environments such as campus-aggregation and data-center networks. The EX9204 switch has a throughput of up to 1.6 terabits per second (Tbps) or up to 240 gigabits per second (Gbps) per slot full duplex.

You can manage EX9204 switches by using the same interfaces that you use for managing other devices running the Juniper Networks Junos operating system (Junos OS)—the CLI, the Network and Security Manager (NSM), and Junos Space.

Benefits of the EX9204 Switch

ESD

g022026

Air intake

ESD point

Craft interface panel

Front mounting

flange

SF1/LC0

Line cards

SF0

RE0

Simplified network architecture—EX9204 switches deliver a simple, secure, virtualized network environment that increases business agility. They are ideal for simplifying campus, data center, and combined campus and data center network environments by collapsing network layers. In a multichassis link aggregation (MC-LAG) configuration in the campus, you can use EX9204 switches to eliminate Spanning Tree Protocol (STP); they collapse the core and aggregation layers, thereby simplifying the network architecture and network operations. In a data center, you can use EX9204 switches to collapse core and aggregation layers. In combined campus and data center environments, EX9204 switches consolidate network layers to simplify the network architecture and operations.

Support for MACsec—EX9200-40F-M and EX9200-40XS line cards and EX9200-20F-MIC for EX9200-MPC line card supports IEEE 802.1AE MACsec with AES-256 bit encryption, ensuring link-layer data confidentiality, data integrity, and data origin authentication.

Software

Juniper Networks EX Series Ethernet Switches run Junos OS, which provides Layer 2 and Layer 3 switching, routing, and security services.

Front and Rear Views of an EX9204 Switch

The EX9204 switch is five rack units (5 U) in size. Nine EX9204 switches can fit in a standard 48 U rack. Each EX9204 switch is designed to optimize rack space and cabling. See Figure 1 on page 22,

Figure 2 on page 23, Figure 3 on page 23, and Figure 4 on page 24.

Figure 1: Front View of an EX9204 Switch

Figure 2: Rear View of an EX9204 Switch with AC Power Supplies (Low-Line Configuration)

PEM 3

PEM 2

PEM 1

PEM 0

AIR FILTER

FAN

TRAY

g004301

AC Power supplies

Fan tray

Air filter

Power supply exhaust

Protective earthing

Air exhaustESD point

ESD

Figure 3: Rear View of an EX9204 Switch with AC Power Supplies (High-Line Configuration)

Figure 4: Rear View of an EX9204 Switch with DC Power Supplies

PEM 3

PEM 2

PEM 1

PEM 0

AIR FI

TER

FAN

TRAY

g004351

DC Power supplies

Fan tray

Air filter

Power supply exhaust

Protective earthing

Air exhaustESD point

ESD

INPUTOK

PWROK

BKRON

INPUTOK

PWROK

BKRON

INPUTOK

PWROK

BKRON

INPUTOK

Host Subsystem

Switching and routing functionality, system management, and system control functions of an EX9204 switch are performed by the host subsystem. The host subsystem consists of a Routing Engine functioning together with a Switch Fabric.

An EX9204 is a 4-slot chassis that provides two dedicated slots—labeled 1 and 2—for line cards, one dedicated slot—labeled 0—for a host subsystem, and one multifunction slot—labeled 1|0—for either a line card or a host subsystem.

You can install either one or two host subsystems in an EX9204 switch. A base-configuration EX9204 switch has one host subsystem. A redundant-configuration EX9204 switch has a second host subsystem. For more information, see “EX9204 Switch Configurations” on page 27.

Line Cards

Line cards are field-replaceable units (FRUs) that you can install in the line card slots and in the multifunctional slot on the front of the switch chassis. All line cards are hot-removable and hot-insertable.

You can install up to three line cards in an EX9204 switch. Each EX9204 switch has two dedicated line card slots—labeled 1 and 2—and a multifunction slot—labeled 1|0—that you can use for either a line card or a host subsystem.

The line cards in EX9204 switches combine a Packet Forwarding Engine and Ethernet interfaces in a single assembly. Table 3 on page 25 lists the line cards available for EX9204 switches.

Table 3: Line Cards Available for EX9204 Switches

Additional InformationDescriptionModel

EX9200-2C-8XS

EX9200-4QS

EX9200-6QS

EX9200-MPC

EX9200-12QS

Ethernet ports and eight 10-Gigabit Ethernet ports

Ethernet ports

Ethernet ports and 24 10-Gigabit Ethernet ports

of the following MICs:

EX9200-10XS-MIC

•

EX9200-20F-MIC

•

EX9200-40T-MIC

•

Ethernet rate-selectable ports, each of which can house transceivers

“EX9200-2C-8XS Line Card” on page 86A line card with two 100-Gigabit

“EX9200-4QS Line Card” on page 88A line card with four 40-Gigabit

“EX9200-6QS Line Card” on page 89A line card with six 40-Gigabit

“EX9200-MPC Line Card” on page 92A modular line card that accepts any

“EX9200-12QS Line Card” on page 95A line card with six 40-Gigabit

EX9200-15C

EX9200-32XS

EX9200-40T

EX9200-40F

EX9200-40F-M

“EX9200-15C Line Card” on page 98line card with 15 rate-selectable

ports. All ports can operate at 10-Gbps, 25-Gbps, 40-Gbps, or 100-Gbps speeds

“EX9200-32XS Line Card” on page 102A line card with 32 10-Gigabit

Ethernet ports

“EX9200-40T Line Card” on page 103A line card with 40

10/100/1000BASE-T ports that support RJ-45 connectors

“EX9200-40F Line Card” on page 105A line card with 40 1-Gigabit

Ethernet ports

“EX9200-40F-M Line Card” on page 106A line card with 40 1-Gigabit

Ethernet ports with Media Access Control Security (MACsec) capability

Table 3: Line Cards Available for EX9204 Switches (continued)

Additional InformationDescriptionModel

EX9200-40XS

Ethernet ports with Media Access Control Security (MACsec) capability, each of which can house 10-gigabit small form-factor pluggable plus (SFP+) transceivers

“EX9200-40XS Line Card” on page 108A line card with 40 10-Gigabit

Cooling System

The cooling system in an EX9204 switch is a field-replaceable unit (FRU). It consists of a hot-removable and hot-insertable fan tray. The fan tray contains three fans. The fan tray installs vertically on the right back of the chassis and provides side-to-side chassis cooling. See “EX9204 Cooling System” on page 49.

Power Supplies

Power supplies for the EX9204 switch are fully redundant, load-sharing, and hot-removable and hot-insertable FRUs. Each EX9204 switch chassis can hold up to four AC or up to two DC power supplies.

Table 4 on page 26 shows the details of the power supplies available for EX9204 switches.

Table 4: Power Supplies Supported on EX9204 Switches

Output PowerInput VoltagePower Supply

1027 WLow-voltage line (100–120 VAC)2520 W AC

1590 WHigh-voltage line (200–240 VAC)

2400 W to 2600 W–40 VDC through –70 VDC2400 W DC

A base-configuration EX9204 switch ships with two low-line (100–120 VAC) AC power supplies or one high-line (200–240 VAC) AC power supply. An AC-powered, redundant-configuration EX9204 switch ships with four low-line (100–120 VAC) or two high-line (200–240 VAC) AC power supplies. See “AC

Power Supply in an EX9204 Switch” on page 51.

A DC-powered, redundant-configuration EX9204 switch ships with two DC power supplies. See “DC

Power Supply in an EX9204 Switch” on page 59.

CAUTION: Do not mix AC and DC power supplies in the same chassis.

EX9204 Switch Configurations

Table 5 on page 27 lists the three hardware configurations for an EX9204 switch—one base configuration

(AC) and two redundant configurations (AC and DC)—and the components included in each configuration.

Table 5: EX9204 Switch Hardware Configurations

First Junos OS ReleaseConfiguration ComponentsSwitch Configuration

EX9204-BASE3C-AC

EX9204-RED3C-AC

(redundant configuration with 2520 W AC power supplies)

EX9204-RED3C-DC

(redundant configuration with 2520 W DC power supplies)

Chassis with craft interface and midplane

•

One EX9200-SF3 module

•

One EX9200-RE2 module

•

One fan tray

•

Two 2520 W AC power supplies (low-line AC)

•

One 2520 W AC power supply (high-line AC)

•

Blank panels for empty power supply slots

•

Blank panels for line card slots

•

Chassis with craft interface and midplane

•

Two EX9200-SF3 modules

•

Two EX9200-RE2 modules

•

One fan tray

•

Four 2520 W AC power supplies (low-line AC)

•

Two 2520 W AC power supplies (high-line AC)

•

Blank panels for line card slots

•

Chassis with craft interface and midplane

•

Two EX9200-SF3 modules

•

Two EX9200-RE2 modules

•

One fan tray

•

Two 2520 W DC power supplies

•

Blank panels for line card slots

•

20.3R1

Table 5: EX9204 Switch Hardware Configurations (continued)

First Junos OS ReleaseConfiguration ComponentsSwitch Configuration

EX9204-BASE3B-AC

EX9204-AC-BND2

(comprises EX9204-BASE3B-AC and line card EX9200-32XS, shipped separately as two items)

EX9204-RED3B-AC

(redundant configuration with 2520 W AC power supplies)

Chassis with craft interface and midplane

•

One EX9200-SF2 module

•

One EX9200-RE2 module

•

One fan tray

•

Two 2520 W AC power supplies

•

Blank panels for empty power supply slots

•

Blank panels for line card slots

•

Chassis with craft interface and midplane

•

One EX9200-SF2 module

•

One EX9200-RE2 module

•

One fan tray

•

Two 2520 W AC power supplies

•

Blank panels for line card slots

•

Blank panels for empty power supply slots

•

Chassis with craft interface and midplane

•

Two EX9200-SF2 modules

•

Two EX9200-RE2 modules

•

One fan tray

•

Four 2520 W AC power supplies

•

Blank panels for line card slots

•

17.1R1

EX9204-RED3B-DC

(redundant configuration with 2520 W DC power supplies)

Chassis with craft interface and midplane

•

Two EX9200-SF2 modules

•

Two EX9200-RE2 modules

•

One fan tray

•

Four 2520 W DC power supplies

•

Blank panels for line card slots

•

17.1R1

Table 5: EX9204 Switch Hardware Configurations (continued)

First Junos OS ReleaseConfiguration ComponentsSwitch Configuration

EX9204-BASE3A-AC

EX9204-REDUND3A-AC

EX9204-AC-BND1

(comprises of EX9204-BASE3 and line card EX9200-32XS, shipped separtely as two items)

Chassis with craft interface and midplane

•

One EX9200-SF2 module

•

One EX9200-RE module

•

One fan tray

•

Two 2520 W AC power supplies

•

Blank panels for empty power supply slots

•

Blank panels for line card slots

•

Chassis with craft interface and midplane

•

Two EX9200-SF2 modules

•

Two EX9200-RE modules

•

One fan tray

•

Two 2520 W AC power supplies

•

Blank panels for empty power supply slots

•

Blank panels for line card slots

•

Chassis with craft interface and midplane

•

One EX9200-SF2 module

•

One EX9200-RE module

•

One fan tray

•

Two 2520 W AC power supplies

•

Blank panels for empty power supply slots

•

Blank panels for line card slots

•

14.1

EX9204-REDUND3A-DC

Chassis with craft interface and midplane

•

Two EX9200-SF2 modules

•

Two EX9200-RE modules

•

One fan tray

•

One air filter

•

Two 2400 W DC power supplies

•

Blank panels for line card slots

•

Blank panels for empty power supply slots

•

14.1

Table 5: EX9204 Switch Hardware Configurations (continued)

First Junos OS ReleaseConfiguration ComponentsSwitch Configuration

EX9204-BASE-AC

(base configuration with 2520 W AC power supplies)

EX9204-REDUND-AC

(redundant configuration with 2520 W AC power supplies)

Chassis with craft interface and midplane

•

One EX9200-SF module

•

One EX9200-RE module

•

One fan tray

•

One air filter

•

Two 2520 W AC power supplies

•

One cover panel for multifunctional module

•

Two cover panels for line card slots

•

Cover panels for empty power supply slots

•

Chassis with craft interface and midplane

•

Two EX9200-SF modules

•

Two EX9200-RE modules

•

One fan tray

•

One air filter

•

Four 2520 W AC power supplies

•

One cover panel for multifunctional module

•

Two cover panels for line card slots

•

Cover panels for empty power supply slots

•

12.3R2

EX9204-REDUND-DC

(redundant configuration with 2400 W DC power supplies)

Chassis with craft interface and midplane

•

Two EX9200-SF modules

•

Two EX9200-RE modules

•

One fan tray

•

One air filter

•

Two 2400 W DC power supplies

•

Two cover panels for line card slots

•

Cover panels for empty power supply slots

•

NOTE: You can install up to three line cards (in any combination) in the switch.

12.3R2

NOTE: Line cards are not part of the base or redundant configuration. You must order them

separately.

NOTE: Power cords and additional power supplies (AC or DC) must be purchased separately.

EX9204 Switch Hardware and CLI Terminology Mapping

This topic describes the hardware terms used in EX9204 switch documentation and the corresponding terms used in the Junos OS CLI. See Table 6 on page 31.

Table 6: CLI Equivalents of Terms Used in Documentation for EX9204 Switches

Hardware Item (CLI)

Midplane

PEM (n)

EX9204-BP

•

EX9204-BP3

•

One of the following:

PS 1.4-2.52 kW;

•

90-264 V AC in

DC 2.4 kW Power

•

Entry Module

n is a value in the range 0-3. The value corresponds to the power supply slot number.

Item in DocumentationValue (CLI)Description (CLI)

Switch chassis–EX9204Chassis

Switch midplane–One of the following:

Craft interface–Front Panel DisplayFPM Board

AC or DC power supply

Additional Information

“Chassis Physical Specifications of an EX9204 Switch” on page 35

Midplane in an EX9200

Switch

Craft Interface in an

EX9200 Switch

AC Power Supply in

•

an EX9204 Switch on page 51

DC Power Supply in

•

an EX9204 Switch on page 59

Table 6: CLI Equivalents of Terms Used in Documentation for EX9204 Switches (continued)

Hardware Item (CLI)

Routing Engine (n)

CB (n)

One of the following:

RE–S–EX9200

•

–1800X4

RE–S–EX9200

•

–2X00x6

One of the following:

EX9200–SCBE

•

EX9200–SF2

•

EX9200–SF3

•

0-1.

In base configuration, only one entry appears.

In redundant configuration, two entries appear; one for each Routing Engine module (RE module) installed in the chassis.

of 0-1.

Multiple line items appear in the CLI if more than one Switch Fabric modules (SF modules) is installed in the chassis.

Item in DocumentationValue (CLI)Description (CLI)

RE modulen is a value in the range

SF modulen is a value in the range

Additional Information

“Routing Engine Module in an EX9200 Switch” on page 66

“Switch Fabric Module in an EX9200 Switch” on page 72

CB0 and CB1 stand for SF modules.

Table 6: CLI Equivalents of Terms Used in Documentation for EX9204 Switches (continued)

Hardware Item (CLI)

FPC (n)

Abbreviated name of the line card.

One of the following:

EX9200-2C-8XS

•

EX9200 4x40G

•

QSFP

EX9200

•

24x10GE+6x40GE

EX9200-MPC

•

EX9200-12QS

•

EX9200-15C

•

EX9200 32x10G

•

SFP

EX9200 40x1G

•

Copper

EX9200-40x1G-SFP

•

EX9200-40FE

•

EX9200-40XS

•

n is a value in the range of 0-2. The value corresponds to the line card slot number in which the line card is installed.

Item in DocumentationValue (CLI)Description (CLI)

Line card (The switch does not have actual FPCs—the line cards are the FPC equivalents on the switch)

Additional Information

EX9200-2C-8XS Line

•

Card on page 86

EX9200-4QS Line

•

Card on page 88

EX9200-6QS Line

•

Card on page 89

EX9200-MPC Line

•

Card on page 92

EX9200-12QS Line

•

Card on page 95

EX9200-15C Line

•

Card on page 98

EX9200-32XS Line

•

Card on page 102

EX9200-40T Line

•

Card on page 103

EX9200-40F Line

•

Card on page 105

EX9200-40F-M Line

•

Card on page 106

EX9200-40XS Line

•

Card on page 108

Table 6: CLI Equivalents of Terms Used in Documentation for EX9204 Switches (continued)

Hardware Item (CLI)

MIC (n)

Abbreviated name of the Modular Interface Card (MIC).

One of the following if EX9200-MPC line card is installed:

10X10GE SFPP

•

20X1GE SFP

•

MACSEC

40x1GE RJ45

•

n is a value in the range 0-1.

Item in DocumentationValue (CLI)Description (CLI)

Line card

NOTE:

The switch does not have actual MICs except in the EX9200-MPC line card—the line cards are the MIC equivalents on the switch. EX9200-MPC is a modular line card that accepts any of the following MICs:

EX9200-10XS-MIC

•

EX9200-20F-MIC

•

EX9200-40T-MIC

•

Additional Information

EX9200-2C-8XS Line

•

Card on page 86

EX9200-4QS Line

•

Card on page 88

EX9200-6QS Line

•

Card on page 89

EX9200-MPC Line

•

Card on page 92

EX9200-12QS Line

•

Card on page 95

EX9200-15C Line

•

Card on page 98

EX9200-32XS Line

•

Card on page 102

EX9200-40T Line

•

Card on page 103

EX9200-40F Line

•

Card on page 105

EX9200-40F-M Line

•

Card on page 106

EX9200-40XS Line

•

Card on page 108

Table 6: CLI Equivalents of Terms Used in Documentation for EX9204 Switches (continued)

Hardware Item (CLI)

PIC (n)

Abbreviated name of the Physical Interface Card (PIC).

n is a value in the range 0-3.

Item in DocumentationValue (CLI)Description (CLI)

Line card (The switch does not have actual PICs.)

Additional Information

EX9200-2C-8XS Line

•

Card on page 86

EX9200-4QS Line

•

Card on page 88

EX9200-6QS Line

•

Card on page 89

EX9200-MPC Line

•

Card on page 92

EX9200-12QS Line

•

Card on page 95

EX9200-15C Line

•

Card on page 98

EX9200-32XS Line

•

Card on page 102

EX9200-40T Line

•

Card on page 103

EX9200-40F Line

•

Card on page 105

EX9200-40F-M Line

•

Card on page 106

EX9200-40XS Line

•

Card on page 108

Xcvr (n)

Abbreviated name of the transceiver.

Optical transceiversn is a value equivalent to the number of the port in which the transceiver is installed.

Fan tray–Enhanced Fan TrayFan tray

“Pluggable Transceivers Supported on EX9200 Switches” on page 132

“EX9204 Cooling System” on page 49

Chassis Physical Specifications of an EX9204 Switch

The EX9204 switch chassis is a rigid sheet-metal structure that houses the other switch components.

Table 7 on page 36 summarizes the physical specifications of the EX9204 switch chassis.

Table 7: Physical Specifications of the EX9204 Switch Chassis

DepthWidthHeightWeightDescription

Chassis

module

Switch Fabric module

craft interface (front-panel display), fan tray, and air filter:

52.0 lb (23.6 kg)

Maximum configuration: 128.0 lb (58.1 kg)

Routing Engine installed)

17.5 in. (44.5 cm)8.7 in. (22.1 cm)Chassis with midplane,

24.5 in. (62.2 cm) (from front to chassis rear)

7.75 in. (19.7 cm)11 in. (27.9 cm)1.25 in. (3.2 cm)2.4 lb (1.09 kg)Routing Engine

22 in. (55.9 cm)17 in. (43.2 cm)1.25 in. (3.2 cm)9.6 lb (4.4 kg) (with

21.2 in. (53.85 cm)15.7 in. (39.87 cm)1.2 in. (3.05 cm)13.6 lb (6.2 kg)EX9200-SF3

line card

card

23.3 in. (59.2 cm)1.76 in. (4.5 cm)6.5 in. (16.5 cm)4.2 lb (1.9 kg)Fan Tray

22.23 in. (56.5 cm)0.31 in. (0.8 cm)5.0 in. (12.7 cm)1.0 lb (0.5 kg)Air filter

4 in. (10.2 cm)14.5 in. (36.8 cm)1.75 in. (4.4 cm)6.6 lb (2.99 kg)AC power supply

4 in. (10.2 cm)14.5 in. (36.8 cm)1.75 in. (4.4 cm)6.2 lb (2.81 kg)DC power supply

22 in. (55.9 cm)17 in. (43.2 cm)1.25 in. (3.2 cm)19.4 lb (8.8 kg)EX9200-2C-8XS

22 in. (55.9 cm)17 in. (43.2 cm)1.25 in. (3.2 cm)16.8 lb (7.6 kg)EX9200-4QS line

22 in. (55.9 cm)17 in. (43.2 cm)1.25 in. (3.2 cm)21 lb (9.25 kg)EX9200-6QS line

22 in. (55.9 cm)17 in. (43.2 cm)1.25 in. (3.2 cm)15.96 lb (7.3 kg)EX9200-MPC line

7.86 in. (20 cm)6.67 in. (16.9 cm)1.25 in. (3.2 cm)1.54 lb (0.7 kg)EX9200-10XS-MIC

Table 7: Physical Specifications of the EX9204 Switch Chassis (continued)

card

DepthWidthHeightWeightDescription

7.86 in. (20 cm)6.67 in. (16.9 cm)1.25 in. (3.2 cm)1.2 lb (0.54 kg)EX9200-20F-MIC

22 in. (55.9 cm)13.36 in. (33.9 cm)1.25 in. (3.2 cm)1.9 lb (0.9 kg)EX9200-40T-MIC

22 in. (55.9 cm)17 in. (43.2 cm)1.25 in. (3.2 cm)15.7 lb (7.12 kg)EX9200-12QS line

21.2 in. (53.85 cm)15.7 in. (39.87 cm)1.2 in. (3.05 cm)20.4 lb (9.25 kg)EX9200-15C line

22 in. (55.9 cm)17 in. (43.2 cm)1.25 in. (3.2 cm)19.2 lb (8.7 kg)EX9200-32XS line

22 in. (55.9 cm)17 in. (43.2 cm)1.25 in. (3.2 cm)14.0 lb (6.6 kg)EX9200-40T line

22 in. (55.9 cm)17 in. (43.2 cm)1.25 in. (3.2 cm)14.8 lb (6.7 kg)EX9200-40F line

card

22 in. (55.9 cm)17 in. (43.2 cm)1.25 in. (3.2 cm)14.8 lb (6.7 kg)EX9200-40F-M

line card

22 in. (55.9 cm)17 in. (43.2 cm)1.25 in. (3.2 cm)17 lb (7.7 kg)EX9200-40XS line

card

You can mount an EX9204 switch on a standard 19-in. four-post rack or a standard 800-mm enclosed cabinet. You can mount up to eight EX9204 switches in a standard (48 rack unit (U)) rack.

Field-Replaceable Units in an EX9200 Switch

Field-replaceable units (FRUs) are switch components that you can replace at your site. The EX9200 switch uses the following types of FRUs:

Hot-insertable and hot-removable—You can remove and replace these components without powering

•

off the switch or disrupting the switching function.

Hot-pluggable—You can remove and replace these components without powering off the switch, but

•

the switching function is interrupted until you replace the component.

Table 8 on page 38 lists the FRUs for the EX9200 switch and their types.

Table 8: FRUs in an EX9200 Switch

TypeFRU

Hot-insertable and hot-removable.Power supplies

Hot-insertable and hot-removable.Fan tray and air filter

Routing Engine module (RE module)

Switch Fabric module (SF module)

Redundant configuration:

Primary RE module is hot-pluggable.

•

Backup RE module is hot-insertable and hot-removable.

•

Base configuration:

You must disable the switch before removing any RE module.

•

See “Taking the Host Subsystem Offline in an EX9200 Switch”

on page 209.

See “EX9204 Switch Configurations” on page 27, EX9208 Switch Configurations, and EX9214 Switch Configurations.

Redundant configuration:

Primary SF module is hot-pluggable.

•

Backup SF module is hot-insertable and hot-removable.

•

Base configuration:

You must disable the switch before removing any SF module.

•

See “Taking the Host Subsystem Offline in an EX9200 Switch”

on page 209.

Line cards

See “Pluggable Transceivers Supported on

EX9200 Switches” on page 132 for the Junos OS

release in which the transceivers were introduced.

See “EX9204 Switch Configurations” on page 27, EX9208 Switch Configurations, and EX9214 Switch Configurations.

Hot-insertable and hot-removable. We recommend that you take the line cards offline before removing them. See “Removing a

Line Card from an EX9200 Switch” on page 237.

Hot-insertable and hot-removable.SFP, SFP+, QSFP+, and CFP transceivers

NOTE: Line cards are not part of the base or redundant configuration. You must order them

separately.

NOTE: If you have a Juniper J-Care service contract, register any addition, change, or upgrade

of hardware components at

https://www.juniper.net/customers/support/tools/updateinstallbase/ . Failure to do so can

result in significant delays if you need replacement parts. This note does not apply if you replace existing components with the same type of component.

EX9204 Chassis

IN THIS SECTION

Understanding EX9204 Switch Component and Functionality Redundancy | 39

Craft Interface in an EX9200 Switch | 41

Midplane in an EX9200 Switch | 47

Understanding EX9204 Switch Component and Functionality Redundancy

The Juniper Networks EX9204 Ethernet Switches are available as fully redundant system. A redundant EX9204 switch configuration is designed so that no single point of failure can cause the entire switch to fail. See “EX9204 Switch Configurations” on page 27.

The following hardware components provide redundancy to an EX9204 switch:

Host Subsystem —The host subsystem consists of a Routing Engine functioning together with a Switch

•

Fabric. The host subsystem performs switching and routing functionality, system management, and system control functions of the switch. The switch can have one or two host subsystems. If two host subsystems are installed, one functions as the primary and the other functions as the backup. If the primary host subsystem (or either of its components) fails, the backup can take over as the primary. To

operate, each host subsystem requires a Routing Engine module (RE module) installed directly into in a Switch Fabric module (SF module).

If the Routing Engines are configured for graceful switchover, the backup Routing Engine automatically synchronizes its configuration and state with the primary Routing Engine. Any update to the primary Routing Engine state is replicated on the backup Routing Engine. If the backup Routing Engine assumes primary role, packet forwarding continues through the switch without interruption. See “Host Subsystem

in an EX9200 Switch” on page 66.

Power supplies—In the low-line (100 V) AC power configuration, the switch contains two or four AC

•

power supplies, located horizontally at the rear of the chassis in slots PEM0 through PEM3 (left to right). Each AC power supply provides power to all components in the switch. When two power supplies are present, they share power almost equally within a fully populated system. Four AC power supplies provide full power redundancy. If one power supply fails or is removed, the remaining power supplies instantly assume the entire electrical load without interruption. Two power supplies provide the maximum configuration with full power for as long as the switch is operational.

In the high-line (200 V) AC power configuration, the switch contains one or two AC power supplies located horizontally at the rear of the chassis in slots PEM0 and PEM2 (left to right). Each AC power supply provides power to all components in the switch. Each AC power supply provides power to all components in the switch. When two power supplies are present, they share power almost equally within a fully populated system. If one power supply fails or is removed, the remaining power supply assumes the entire electrical load without interruption. One power supply can provide the maximum configuration with full power for as long as the switch is operational.

See “AC Power Supply in an EX9204 Switch” on page 51.

In the DC configuration, the switch comes with two DC power supply preinstalled. one power supply is required to supply power to a fully configured switch and the second power supply provides full power redundancy. If one power supply fails or is removed, the second power supply instantly assume the entire electrical load without interruption. One power supply provides the maximum configuration with full power for as long as the switch is operational. See “DC Power Supply in an EX9204 Switch” on

page 59.

Cooling system—The cooling system in EX9204 switches consists of fan tray and air filter. The fan tray

•

contains three fans. Under normal operating conditions, the fans in the fan tray run at less than full speed. If one of the fans fails, the host subsystem increases the speed of the remaining fans to provide sufficient cooling for the switch indefinitely. See “EX9204 Cooling System” on page 49.

Craft Interface in an EX9200 Switch

g022028

IN THIS SECTION

Host Subsystem LEDs | 43

Fan LEDs | 43

Power Supply (PEM) LEDs | 44

Switch Fabric LEDs and Control Buttons | 44

Line Card LEDs and Control Buttons | 45

Alarm LEDs and Alarm Cutoff Button | 45

Alarm Relay Contacts | 46

The craft interface enables you to view status and troubleshooting information at a glance and to perform many system control functions. The craft interface is located on the front panel of the switch. It contains LEDs and on and off buttons for switch components, the alarm relay contacts, and an alarm cutoff button.

Figure 5 on page 41 shows the craft interface in an EX9204 switch. Figure 6 on page 42 shows the craft

interface in an EX9208 switch. Figure 7 on page 42 shows the craft interface in an EX9214 switch.

Figure 5: Craft Interface in an EX9204 Switch

5—1— Major alarm LEDHost subsystem LEDs

6—2— Alarm cutoff/lamp test buttonFan LEDs

7—3— Alarm relay contactsPower supply LEDs

Minor alarm LED

8—4— LEDs and control buttons for Switch Fabric and Line

cards

NOTE: You can install a line card or an SF module in the multifunctional slot labeled 1|0 in

g022004

1 2 3 4 5 6 7

8 9

EX9204 switches. The corresponding LED displays information depending on the hardware installed in that slot.

Figure 6: Craft Interface in an EX9208 Switch

6—1— Alarm cutoff/lamp test buttonHost subsystem LEDs

5—Major alarm LED

Figure 7: Craft Interface in an EX9214 Switch

7—2— Alarm relay contactsFan LEDs

8—3— Switch Fabric LEDs and control buttonsPower supply LEDs

9—4— Line card LEDs and control buttonsMinor alarm LED

6—1— Alarm cutoff/lamp test buttonPower supply LEDs

7—2— Alarm relay contactsFan LEDs

8—3— Line card LEDs and control buttonsHost subsystem LEDs

9—4— Switch Fabric/line card LED and control buttonMinor alarm LED

10—5— Switch Fabric LEDs and control buttonsMajor alarm LED

NOTE: You can install a line card or a Switch Fabric module (SF module) in slot nine—labeled 2

| 6. The corresponding LED displays information depending on the hardware installed in that

slot.

NOTE: At least one Switch Fabric module (SF module) with a Routing Engine module (RE module)

must be installed in the switch for the craft interface to obtain power.

The craft interface has the following components:

Host Subsystem LEDs

Each host subsystem (RE module with SF module) has three LEDs, located on the upper left of the craft interface, to indicate its status. The LEDs grouped with labels RE0 and RE1 show the status of the host subsystems installed in the switch. Table 9 on page 43 describes the functions of these LEDs.

Table 9: Host Subsystem LEDs on the Craft Interface

DescriptionStatusLabel

Host subsystem is functioning as the primary.GreenMASTER

Unlit

Host subsystem is either functioning as the backup or not installed.

Host subsystem is online and is functioning normally.GreenONLINE

Host subsystem is either offline or not installed.Unlit

Host subsystem is installed but Routing Engine is offline.RedOFFLINE

Host subsystem is not installed.Unlit

Fan LEDs

The fan LEDs are located on the top left of the craft interface. Table 10 on page 44 describes the functions of the fan LEDs.

Table 10: Fan LEDs on the Craft Interface

DescriptionStatusLabel

Fan is functioning normally.GreenOK

Fan is not installed.Unlit

Fan has failed.RedFAIL

Fan is not installed or functioning normally.Unlit

Power Supply (PEM) LEDs

Each power supply has two LEDs on the craft interface that indicate its status. The LEDs—labeled 0 through 3—are located on the craft interface next to the PEM label. Table 11 on page 44 describes the functions

of the power supply LEDs on the craft interface.

Table 11: Power Supply LEDs on the Craft Interface

DescriptionStatusLabel

Power supply is functioning normally.GreenOK

Power supply in not installed.Off

Power supply has failed.RedFAIL

Power supply is not installed or functioning normally.Off

Switch Fabric LEDs and Control Buttons

Each Switch Fabric module has two LEDs on the craft interface that indicates its status. The LEDs—OK and FAIL—are associated with control buttons and are located along the bottom of the craft interface. You can turn the SF modules on or off by pressing these buttons on the craft interface.

Table 12 on page 45 describes the status of the SF module LEDs.

Table 12: Switch Fabric Module LEDs on the Craft Interface

DescriptionStatusLabel

GreenOK

Unlit

On steadily—The SF module is functioning normally.

Blinking—The SF module is coming online or going offline.

The SF module is not online.Unlit

The SF module has failed.RedFAIL

The SF module is not installed or is not functioning normally.

Line Card LEDs and Control Buttons

Each line card has two LEDs—OK and FAIL—on the craft interface that indicates its status. The line card LEDs are associated with control buttons and are located along the bottom of the craft interface. You can turn a line card online or offline by using its control button on the craft interface. Table 13 on page 45 describes the function of the line card LEDs.

Table 13: Line Card LEDs on the Craft Interface

DescriptionStatusLabel

On steadily—Line card is functioning normally.GreenOK

Blinking—Line card is coming online or going offline.

Line card is not online.Unlit

Line card has failed.RedFAIL

Line card is not installed or functioning normally.Unlit

Alarm LEDs and Alarm Cutoff Button

Two large alarm LEDs are located at the upper right of the craft interface. The circular LED called major alarm LED glows to indicate a critical condition that can result in a system shutdown. The triangular LED called minor alarm LED glows to indicate a less severe condition (warning) that requires monitoring or maintenance. Both LEDs can be lit simultaneously.

A condition that causes an LED to be lit also activates the corresponding alarm relay contact on the craft

g022029

Craft Interface panel

Alarm

relay

contacts

interface.

The alarm cutoff/lamp test (ACO/LT) button, located next to the alarm LEDs, is a control button for alarms. You can press the ACO/LT button to deactivate major and minor alarms. Deactivating an alarm turns off both LEDs and deactivates the device attached to the corresponding alarm relay contact on the craft interface.

Table 14 on page 46 describes the alarm LEDs and the alarm cutoff/lamp test button.

Table 14: Alarm LEDs and Alarm Cutoff/Lamp Test Button

DescriptionStatusAlarm LEDs and Button

Red

Major alarm LED

Yellow

Minor alarm LED

–

Alarm cutoff/lamp test button

Indicates a critical condition that can cause the switch to stop functioning. Possible causes include component removal, failure, or overheating.

Indicates a serious but nonfatal error condition, such as warning for a maintenance or a significant increase in component temperature.

Deactivates major and minor alarms. Causes all LEDs on the craft interface to light (for testing) when pressed and held.

Alarm Relay Contacts

The craft interface has two alarm relay contacts for connecting the switch to external alarm devices. Whenever a system condition triggers either the critical (major alarm) or warning (minor alarm) alarm on the craft interface, the alarm relay contacts are also activated. The alarm relay contacts are located on the upper right of the craft interface.

Figure 8 on page 46 shows the alarm relay contacts in EX9200 switches.

Figure 8: Alarm Relay Contacts in EX9200 Switches

Midplane in an EX9200 Switch

ESD

g022027

Midplane

The midplane is located on the rear of the chassis and forms the rear of the card cage. The Switch Fabric modules (SF modules) and line cards are installed into the midplane from the front of the chassis, and the power supplies install into the midplane from the rear of the chassis. The cooling system components also connect to the midplane.

The midplane performs the following major functions:

Provides a data path—Data packets are transferred across the midplane between the line cards through

•

the Switch Fabric on the host subsystem.

Distributes power—The power supplies connect to the midplane, which distributes power to all the

•

switch components.

Provides a signal path—The midplane provides the signal path to the line cards, Switch Fabric, and other

•

system components for monitoring and control of the system.

Figure 9 on page 47 shows the midplane in an EX9204 switch. Figure 10 on page 48 shows the midplane

in an EX9208 switch. Figure 11 on page 48 shows the midplane in an EX9214 switch.

Figure 9: Midplane in an EX9204 Switch

Figure 10: Midplane in an EX9208 Switch

g022001

Midplane

g022043

Midplane

Figure 11: Midplane in an EX9214 Switch

EX9204 Cooling System

IN THIS SECTION

Fan Tray | 49

Airflow Direction in the EX9204 Switch Chassis | 50

The cooling system in an EX9204 switch consists of a fan tray and an air filter. The cooling system components work together to keep all switch components within the acceptable temperature range.

Fan Tray

The fan tray is a hot-insertable and hot-removable field-replaceable unit (FRU) and contains three fans. The fan tray and air filter install vertically in the rear of the switch. See Figure 12 on page 49 and

Figure 13 on page 50.

Figure 12: Fan Tray for an EX9204 Switch

Figure 13: Air Filter for an EX9204 Switch

Airflow Direction in the EX9204 Switch Chassis

The air intake to cool the chassis is located on the side of the chassis next to the air filter. Air is pulled through the chassis toward the fan tray, where it is exhausted out through the side of the chassis. The air intake to cool the power supplies is located in the front of the chassis above the craft interface. See

Figure 14 on page 50.

Figure 14: Airflow Through the EX9204 Switch Chassis

The host subsystem monitors the temperature of switch components. Under normal operating conditions, the fans in the fan tray run at less than full speed. If a fan fails or the ambient temperature rises above a threshold, the speed of the remaining fans is automatically adjusted to keep the temperature within the acceptable range. If the ambient maximum temperature specification is exceeded and the system cannot be adequately cooled, the Routing Engine shuts down the system by disabling output power from each power supply.

You cannot replace a single fan. If one or more fans fail, you must replace the entire fan tray.

EX9204 Power System

IN THIS SECTION

AC Power Supply in an EX9204 Switch | 51

AC Power Supply Specifications for EX9204 Switches | 55

AC Power Supply LEDs in an EX9204 Switch | 55

AC Power Cord Specifications for an EX9204 Switch | 56

DC Power Supply in an EX9204 Switch | 59

DC Power Supply Specifications for EX9204 Switches | 62

DC Power Supply LEDs in an EX9204 Switch | 63

Power Requirements for EX9200 Switch Components | 64

AC Power Supply in an EX9204 Switch

IN THIS SECTION

AC Power Supply Description | 52

AC Power Supply Configurations | 53

An EX9204 switch is configurable with one, two, or four AC power supplies. The power supplies connect to the midplane, which distributes the different output voltages produced by the power supplies to the switch components, depending on their voltage requirements. Each power supply is cooled by its own internal cooling system.

CAUTION: EX9204 switches use either AC or DC power supplies. Do not mix AC and

DC power supplies in a switch. The first type of power supply detected by the switch when initially powered on determines the type of power supply allowed by the switch. All installed power supplies of the other type are disabled by the switch. If you install a power supply of the other type while the switch is operating, the switch disables the power supply and generates an alarm.

This topic describes the AC power supplies in EX9204 switches:

AC Power Supply Description

The AC power supplies in EX9204 switches are hot-insertable and hot-removable field-replaceable units (FRUs).

You can install up to four AC power supplies in an EX9204 switch. Power supplies are installed in the rear of the chassis in slots PEM0 through PEM3 (left to right).

WARNING: The switch is installed in a restricted-access location. It has a separate

protective earthing terminal (sized for UNC 1/4-20 ground lugs) provided on the chassis in addition to the grounding pin of the power supply cord. This separate protective earthing terminal must be permanently connected to earth.

CAUTION: Before you begin installing the switch, ensure that a licensed electrician

has attached an appropriate grounding lug to the grounding cable that you supply. Using a grounding cable with an incorrectly attached lug can damage the switch.

Each AC power supply weighs approximately 6.6 lb (2.99 kg) and consists of one AC appliance inlet, an AC input switch, a fan, and LEDs to monitor the status of the power supply. See Figure 15 on page 53.

Figure 15: AC Power Supply for an EX9204 Switch

AC OK

DC OK

FAIL

Each power supply has its own fan and is cooled by its own internal cooling system.

EX9204 switches support 2520 W AC power supply. The AC power supply supports the low-line (100–120 VAC) and the high-line(200–240 VAC) AC power configurations.

Each AC power supply has a single AC appliance inlet located on the power supply that requires a dedicated AC power feed. We recommend that you use a customer site circuit breaker rated for 16.0 A @ 100 VAC or 16.0 A @ 200 VAC circuit breaker minimum for each AC power supply, or as required by local code. Doing so enables you to operate the switch in any configuration without upgrading the power infrastructure.

AC Power Supply Configurations

The EX9204 switch supports either the low-line (100–120 V) AC power configuration or the high-line (200–240 V) AC power configuration.

In the low-line (100–120 V) AC power configuration, the EX9204 switch contains either two AC power

•

supplies in base AC configuration, located horizontally at the rear of the chassis in slots PEM0 and PEM1 (left to right); or four AC power supplies in the redundant AC configuration, located in slots PEM0 through PEM3 (left to right). Each AC power supply provides power to all components in the switch.

The low-line configuration requires minimum two power supplies to provide the maximum configuration with full power for as long as the switch is operational. When only two power supplies are present, they share power almost equally within a fully populated system and removing one of the power supply will disturb switch functions. Four AC power supplies provide full power redundancy; if one power supply fails or is removed, the remaining power supplies assume the entire electrical load without interruption.

In the high-line (200–240 V) AC power configuration, the EX9204 switch contains either one power

•

supply in the base AC configuration, located horizontally in the slot PEM0; or two power supplies in the redundant AC configuration, located in slots PEM0 and PEM2 (left to right). In a high-line AC power configuration, each AC power supply provides power to all components in the switch.

In high-line configuration, one power supply provide the maximum configuration with full power for as long as the switch is operational. Two power supplies provide full power redundancy; if one power

supply fails or is removed, the remaining power supply assume the entire electrical load without interruption. The high-line configuration requires one power supply, with the second providing redundancy. See “AC Power Supply Specifications for EX9204 Switches” on page 55.

Ensure that you install sufficient number of power supplies to provide the power necessary for the line cards you install in the switch. See Power Requirements for EX9200 Switch Components to know the power required by each component in the switch and “AC Power Supply Specifications for EX9204 Switches” on

page 55 for the power supply specifications including the output power provided by the power supplies.

Table 15 on page 54 shows an example for power requirement calculation. To install three EX9200-32XS

line cards in the switch, the power required is 2300 W, calculated as shown in the table:

Table 15: Example—Power Required to Install Three EX9200-32XS Line Cards in an EX9204 Switch

Power RequiredComponent

410 WBase system

150 W1 SF module

90 W1 RE module

1650 W3 EX9200-32XS line cards

2300 WTotal

The output power provided by each low-voltage line power supply is 1167 W and the output power provided by each high-voltage line power supply is 2050 W.

Starting in Junos OS Release 18.4R1, on EX9204 switches, the enhanced AC PEM in the high-line power configuration supplies a power output of 2400 W. On Junos OS versions prior to 18.4R1, the PEM provided 2050 W of power output.

Therefore, to provide sufficient power to support three EX9200-32XS line cards, you must install at least two low-voltage line or high-voltage line power supplies in the switch.

SEE ALSO

AC Power Supply LEDs in an EX9204 Switch | 55

Installing an AC Power Supply in an EX9204 Switch | 201 Removing an AC Power Supply from an EX9204 Switch | 200

AC Power Supply Specifications for EX9204 Switches

Table 16 on page 55 lists the power supply specifications for an AC power supply used in EX9204 switches.

Table 16: AC Power Supply Specifications for an EX9204 Switch

SpecificationsItem

AC input voltage

AC input current rating

AC output power

Operating range:

Low-voltage line: 100–120 VAC

•

High-voltage line: 200–240 VAC

•

50–60 HzAC input line frequency

Low-voltage line: 16 A

•

High-voltage line: 15.1 A

•

Low-voltage line: 1167 W

•

High-voltage line: 2050 W

•

Table 17 on page 55 lists the AC power system specification for an EX9200 switch.

Table 17: AC Power System Specifications

High-LineLow-LineItem

1+12+2Redundancy

2050 W1167 WOutput power (maximum) per power supply

2050 W2334 WOutput power (maximum) per system

AC Power Supply LEDs in an EX9204 Switch

An AC power supply has three LEDs on its faceplate. These LEDs display information about the status of the AC power supply. The power supply status is also reflected in two LEDs on the craft interface. In addition, a power supply failure triggers the major alarm LED on the craft interface.

Table 18 on page 56 describes the LEDs on an AC power supply in an EX9204 switch.

Table 18: AC Power Supply LEDs on EX9204 Switches

DescriptionColorLED

GreenAC OK

Off

GreenDC OK

Off

RedPS FAIL

AC power input is within range. Power supply is functioning normally.

AC power input is below the range.Yellow

Indicates one of the following:

Power supply is disconnected from AC power

•

feed.

No AC power input.

•

DC power output generated by the power supply is within the normal operating ranges.

DC power output generated by the power supply is not within the normal operating ranges.

Power supply is not functioning normally and its output voltage is out of regulation limits. Check AC OK and DC OK LEDs for more information.

Power supply is functioning normally.Off

AC Power Cord Specifications for an EX9204 Switch

Each AC power supply has a single AC appliance inlet located on the power supply that requires a dedicated AC power feed. Most sites distribute power through a main conduit that leads to frame-mounted power distribution panels, one of which can be located at the top of the rack that houses the switch. An AC power cord connects each power supply to the power distribution panel.

You can order detachable AC power cords, each approximately 8 ft (2.44 m) long that supply AC power to the switch. The C19 appliance coupler end of the cord inserts into the AC appliance inlet coupler, type C20 (right angle) as described by International Electrotechnical Commission (IEC) standard 60320. The plug end of the power cord fits into the power source receptacle that is standard for your geographical location.

Table 19 on page 57 provides specifications and Figure 16 on page 58 depicts the plug on the AC power

cord provided for each country or region.

Table 19: AC Power Cord Specifications for an EX9204 Switch

Electrical SpecificationModel NumberCountry

Plug Type

SAA/3/15240 VAC, 50 Hz ACCBL-M-PWR-RA-AUAustralia

CH2-16P220 VAC, 50 Hz ACCBL-M-PWR-RA-CHChina

Switzerland, and United Kingdom)

CBL-M-PWR-RA-EUEurope (except Denmark, Italy,

CBL-PWR-RA-JP15Japan

CBL-M-PWR-RA-JP

CEE 7/7220 or 230 VAC,

50 Hz AC

CEI 23-16/VII230 VAC, 50 Hz ACCBL-M-PWR-RA-ITItaly

JIS 8303125 VAC, 50 or 60 Hz

NEMA L6-20P220 VAC, 50 or 60 Hz

NEMA 5-15P125 VAC, 60 Hz ACCBL-PWR-RA-US15North America

NEMA L5-15P125 VAC, 60 Hz ACCBL-PWR-RA-TWLK-US15

NEMA 6-20250 VAC, 60 Hz ACCBL-M-PWR-RA-US

NEMA L6-20P250 VAC, 60 Hz ACCBL-M-PWR-RA-TWLK-US

BS89/13240 VAC, 50 Hz ACCBL-M-PWR-RA-UKUnited Kingdom

Figure 16: AC Plug Types

WARNING: The AC power cord for the switch is intended for use with the switch

only and not for any other use.

WARNING:

Translation from Japanese: The attached power cable is only for this product. Do not use the cable for another product.

NOTE: In North America, AC power cords must not exceed 4.5 m (approximately 14.75 ft) in

length, to comply with National Electrical Code (NEC) Sections 400-8 (NFPA 75, 5-2.2) and 210-52, and Canadian Electrical Code (CEC) Section 4-010(3). You can order AC power cords that are in compliance.

WARNING: The switch is pluggable type A equipment installed in a restricted-access

location. It has a separate protective earthing terminal (sized for UNC 1/4-20 ground lugs) provided on the chassis in addition to the grounding pin of the power supply cord. This separate protective earthing terminal must be permanently connected to earth.

CAUTION: Power cords must not block access to switch components. We recommend

that you route all AC power cord cables through the power cord tray provided with the switch.

DC Power Supply in an EX9204 Switch

IN THIS SECTION

DC Power Supply Description | 60

DC Power Supply Configurations | 61

An EX9204 switch comes with two DC power supplies. The power supplies connect to the midplane, which distributes the different output voltages produced by the power supplies to the switch components, depending on their voltage requirements. Each power supply is cooled by its own internal cooling system.

CAUTION: EX9204 switches use either AC or DC power supplies. Do not mix AC and

This topic describes the DC power supplies in EX9204 switches:

DC Power Supply Description

The DC power supplies in EX9000 switches are hot-insertable and hot-removable field-replaceable units (FRUs).

You can install two DC power supplies in an EX9204 switch. Power supplies are installed in the rear of the chassis in slots PEM0 and PEM2 (left to right).

A DC power supply weighs approximately 6.2 lb (2.81 kg) and consists of one DC input (–48 VDC and return), one 70 A (–48 VDC) circuit breaker, a fan, and LEDs to monitor the status of the power supply. See Figure 17 on page 61.

Each DC power supply has a single DC input (–48 VDC and return) that requires a dedicated circuit breaker. We recommend that you provision 60 A or 75 A per feed, depending on the selected DIP switch setting. If you plan to operate a maximally configured DC-powered switch with DC power supplies, we recommend that you use a dedicated customer site circuit breaker rated for 70 A (–48 VDC) minimum, or as required by local code.

If you plan to operate a DC-powered switch at less than the maximum configuration, we recommend that you provision a circuit breaker according to respective National Electrical Code and customer site internal standards to maintain proper level of protection for the current specified above or each DC power supply rated for at least 125% of the continuous current that the system draws at –48 VDC.

Figure 17: DC Power Supply for an EX9204 Switch

DC Power Supply Configurations

In the DC power configuration, the EX9204 switch comes with two DC power supplies located at the rear of the chassis in slots PEM0 and PEM2 (left to right). One power supply provide the maximum configuration with full power for as long as the switch is operational. Two power supplies provide full redundancy; if one power supply fails or is removed, the redundant power supply takes over without interruption. . A single DC power supply provides power to all components and the second DC power supply provides redundancy. See “DC Power Supply Specifications for EX9204 Switches” on page 62.

NOTE: Move the input switch to 0 for 60 A input and position 1 for 70 A input.

NOTE: Do not set the input mode switch if the power supply is installed in the chassis. If the

power supply is already installed, you must remove it before setting the input mode switch.

Ensure that you install sufficient number of power supplies to provide the power necessary for the line cards you install in the switch. See Power Requirements for EX9200 Switch Components to know the power required by each component in the switch and “DC Power Supply Specifications for EX9204 Switches”

on page 62 for the power supply specifications including the output power provided by the power supplies.

Table 20 on page 62 shows an example for power requirement calculation. To install three EX9200-32XS

line cards in the switch, the power required is 2300 W, calculated as shown in the table:

Table 20: Example—Power Required to Install Three EX9200-32XS Line Cards in an EX9204 Switch

Power RequiredComponent

410 WBase system

150 W1 SF module

90 W1 RE module

1650 W3 EX9200-32XS line cards

2300 WTotal

The output power provided by each power supply is at least 2400 W.

Therefore, one DC power supply can provide sufficient power to support three EX9200-32XS line cards.

DC Power Supply Specifications for EX9204 Switches

Table 21 on page 62 lists the DC power supply specifications for EX9204 switches.

Table 21: DC Power Supply Specifications for an EX9204 Switch

SpecificationsItem

DC input voltage

DC input current rating

Operating range:

Minimum operating range: –40.5 VDC

•

Nominal operating range: –48 VDC

•

Operating voltage range: –40.5 VDC to –72 VDC

•

70 A (DIP=1)60 A (DIP=0)Maximum Input Current

2600 W2400 WMaximum output power

50 A @ –48 VDC normal operating voltage

54.2 A @ –48 VDC normal operating voltage

Table 22 on page 63 lists the power system specifications for EX9200 switches.

Table 22: Power System Specifications for an EX9200 Switch

SpecificationsItem

1+1Redundancy

70 A (DIP=1)60 A (DIP=0)Output power (maximum) per supply

2600 W2400 W

2600 W2400 WOutput power (maximum) per system

DC Power Supply LEDs in an EX9204 Switch

A DC power supply has three LEDs on its faceplate: POWER OK, BRKR ON, and INPUT OK LEDs. The power supply status is also reflected in two LEDs on the craft interface. In addition, a power supply failure triggers the major alarm LED on the craft interface.

NOTE: A host subsystem must be present for the POWER OK LED to be on.

Table 23 on page 63 describes the LEDs on a DC power supply in EX9204 switches.

Table 23: DC Power Supply LEDs in EX9204 Switches

DescriptionColorLED

Power supply is functioning normally.GreenPOWER OK

The main output voltage is out of range.Yellow

Off

GreenBRKR ON

Power supply is not functioning normally. Check the INPUT OK LED for more information.

DC power input is present and the DC power supply circuit breaker is turned on.

DC power supply circuit breaker is turned off.Off

Table 23: DC Power Supply LEDs in EX9204 Switches (continued)

DescriptionColorLED

GreenINPUT OK

Yellow

DC input is present and is connected in correct polarity.

DC input is present, but is not in valid operating range or connected in reverse polarity.

DC input to the power supply is not present.Off

Power Requirements for EX9200 Switch Components

Table 24 on page 64 lists the power requirements for different hardware components of EX9200 switches.

Table 24: EX9200 Switch Component Power Requirements

Reserved Power (watt)Typical Power (watt)Component

Base system

EX9204 switch: 410 W

•

EX9208 switch: 560 W

•

EX9214 switch: 1290 W

•

EX9204 switch: 410 W

•

EX9208 switch: 560 W

•

EX9214 switch: 1670 W

•

Redundant system

EX9204 switch: 690 W

•

EX9208 switch: 800 W

•

EX9214 switch: 1530 W

•

See “EX9200-SF3 Module in an EX9200 Switch” on page 76EX9200-SF3 Switch Fabric module

EX9204 switch: 690 W

•

EX9208 switch: 800 W

•

EX9214 switch: 1910 W

•

150 W150 WEX9200-SF Switch Fabric module

155 W155 WEX9200-SF2 Switch Fabric module

90 W90 WRouting Engine module (RE module)

610 W530 WEX9200-2C-8XS line card

520 W408 WEX9200-4QS line card

607 W511 WEX9200-6QS line card

534 W461 WEX9200-MPC line card

Table 24: EX9200 Switch Component Power Requirements (continued)

See “EX9200-15C Line Card” on page 98EX9200-15C line card

Reserved Power (watt)Typical Power (watt)Component

29.8 W29.8 WEX9200-10XS-MIC

37 W37 WEX9200-20F-MIC

41 W41 WEX9200-40T-MIC

545 W465 WEX9200-12QS line card

610 W550 WEX9200-32XS line card

239 W206 WEX9200-40T line card

EX9200 Host Subsystem

IN THIS SECTION

Host Subsystem in an EX9200 Switch | 66

Routing Engine Module in an EX9200 Switch | 66

Routing Engine Module LEDs in an EX9200 Switch | 70

Switch Fabric Module in an EX9200 Switch | 72

Switch Fabric Module LEDs in an EX9200 Switch | 75

239 W219 WEX9200-40F line card

239 W219 WEX9200-40F-M line card

545 W465 WEX9200-40XS line card

EX9200-SF3 Module in an EX9200 Switch | 76

Host Subsystem in an EX9200 Switch

Switching and routing functionality, system management, and system control functions of an EX9200 switch are performed by host subsystem. A host subsystem consists of a Routing Engine functioning together with a Switch Fabric.

You can install either one or two host subsystems in the front panel of an EX9204 or an EX9208 switch. A base configuration EX9204 and EX9208 switch has one host subsystem. A redundant configuration EX9204 and EX9208 switch has a second host subsystem.

You can install either two or three host subsystems in the front panel of an EX9214 switch. A base configuration EX9214 switch has two host subsystems. A redundant configuration EX9214 switch has a third host subsystem.

NOTE: In EX9204 and EX9208 switches, we recommend that you install two host subsystems

for redundant protection. If you install only one host subsystem, we recommend that you install it in slot 0. In EX9214 switches, we recommend that you install three host subsystems for redundant protection. If you install only two host subsystems, we recommend that you install it in slot 0 and 1.

Each host subsystem has LEDs in the craft interface that display its status. See Craft Interface in an EX9200 Switch.

SEE ALSO

Taking the Host Subsystem Offline in an EX9200 Switch | 209 Maintaining the Host Subsystem in EX9200 Switches | 227

Routing Engine Module in an EX9200 Switch

The Routing Engine module (RE module) is an Intel-based platform that runs Juniper Networks Junos operating system (Junos OS). Software processes that run on the RE module maintain the routing tables, manage the routing protocols used on the switch, control the router interfaces and some of the chassis components, and provide the interface for system management and user access to the switch.

In an EX9204, EX9208, or EX9214 switch, you can install one or two RE modules in the Switch Fabric modules (SF modules) that are installed in slots on the front panel of the switch. If you install two RE modules, one functions as the primary and the other functions as the backup. If the primary RE module

fails or is removed and the backup is configured appropriately, the backup takes over as the primary. The backup RE module is hot-insertable and hot-removable, whereas the primary RE module is only hot-insertable. See Figure 18 on page 68 and Figure 19 on page 69. A USB port on the RE module accepts a USB memory card that loads the Junos OS.

NOTE:

In EX9214 switches, you must install an RE module only in the SF modules installed in slots 7

•

and 8 labeled 0 and 1.

If you have installed only one RE module, you must power off the switch before removing the

•

RE module.

A base-configuration EX9204, EX9208, or EX9214 switch has only one RE module. See “EX9204 Switch

Configurations” on page 27, EX9208 Switch Configurations, and EX9214 Switch Configurations. You can add

a second RE module to the configuration for redundancy.

NOTE: We recommend that you install two RE modules in EX9204, EX9208, and EX9214

switches for redundancy.

The RE module performs the following functions:

Provides switching functionality to the switch through the switching plane

•

Powers the line cards on and off

•

Controls system resets and the boot sequence for the switch

•

Monitors and controls the fan speed, power status for various chassis components, and craft interface

•

LEDs

The switch ships with the RE modules preinstalled. There are two copies of the software:

One copy on the solid-state drive (SSD) in the RE module.

•

One copy on a USB flash drive that can be inserted into the slot on the RE module faceplate.

•

The RE module boots from the storage media in the following order: the USB device (if present), then the SSD, and finally the LAN.

NOTE: Starting with Junos OS Release 17.1R1, EX9200 switches support the EX9200-RE2

g022003

USB port

Reset button

Online LED

Master LED

OK/Fail LED

Storage LED

Extractor clip

Console port

Auxiliary port

Ethernet port

SSD slot 2

SSD slot 1

module. The EX9200-RE2 module supports virtual machine (VM) architecture in an EX9200 switch. Only the EX9200-SF2 module supports the EX9200-RE2 module. Starting with Junos OS Release 17.1R1, you cannot form a Virtual Chassis using an EX9200 switch.

CAUTION: The EX9200-RE module and the EX9200-RE2 module are not interoperable.

Do not install both the RE modules in the same switch chassis.

NOTE: Starting with Junos OS Release 16.1, you can use EX9200 switches as an aggregation

device in Junos Fusion Enterprise. Starting with Junos OS Release 17.4, you can use EX9200 switches with EX9200-RE2 module installed in it as an aggregation device in Junos Fusion Enterprise. See Understanding Junos Fusion Enterprise Software and Hardware Requirements for the list of line cards that support this configuration.

Figure 18 on page 68 shows the EX9200-RE module in an EX9200 switch.

Figure 18: EX9200-RE Module in an EX9200 Switch

Each EX9200-RE module consists of the following components:

Extractor clips—Control the locking system to securely install and remove the EX9200-RE module.

•

AUX port—Connects the EX9200-RE module to a modem or other auxiliary device.

•

CONSOLE port—Connects the EX9200-RE module to a system console through a cable with an RJ-45

•

connector. See “Connecting an EX9200 Switch to a Management Console or an Auxiliary Device” on

page 179.

ETHERNET port—Connects the EX9200-RE module through an Ethernet connection to a management

•

LAN (or any other device that plugs into an Ethernet connection) for out-of-band management. See

“Connecting an EX9200 Switch to a Network for Out-of-Band Management” on page 178.

USB port—Hosts a removable media interface through which you can install the Junos OS manually. See

•

“USB Port Specifications for an EX Series Switch” on page 139.

SATA SSD 1 and SATA SSD 2 slots—Host primary storage for software images, configuration files, and

•

microcode. Also provide secondary storage for log files and memory dump files.

RESET button—Reboots the EX9200-RE module when pressed.

•

ONLINE/OFFLINE button—Turns the EX9200-RE module online or offline when pressed.

•

Status LEDs—Indicate the status of the EX9200-RE module. Each EX9200-RE module has four LEDs

•

labeled MASTER, STORAGE, ONLINE, and OK/FAIL on the faceplate.

Captive screws—Secure the EX9200-RE module in place.

•

Figure 19 on page 69 shows the EX9200-RE2 module in an EX9200 switch.

Figure 19: EX9200-RE2 Module in an EX9200 Switch

6—1— ONLINE/OFFLINE buttonExtractor clips

7—2— SSD LEDs—DISK1 and DISK2Auxiliary port (AUX)

8—3— USB ports—USB1 and USB2Console port (CONSOLE)

9—4— RESET buttonManagement port (MGMT)

10—5— SSD slots—SSD 1 and SSD 2LEDs—ONLINE, OK/FAIL, and MASTER

Each EX9200-RE2 module consists of the following components:

Extractor clips—Control the locking system to securely install and remove the EX9200-RE2 module.

•

AUX port—Connects the EX9200-RE2 module to a modem or other auxiliary device.

•

CONSOLE port—Connects the EX9200-RE2 module to a system console through a cable with an RJ-45

•

connector. See “Connecting an EX9200 Switch to a Management Console or an Auxiliary Device” on

page 179.

MGMT port—Connects the EX9200-RE2 module through an Ethernet connection to a management

•

LAN (or any other device that plugs into an Ethernet connection) for out-of-band management. See

“Connecting an EX9200 Switch to a Network for Out-of-Band Management” on page 178.

Status LEDs—Indicate the status of the EX9200-RE2 module. Each EX9200-RE2 module has five LEDs

•

labeled MASTER, ONLINE, OK/FAIL, DISK1, and DISK2 on the faceplate.

ONLINE/OFFLINE button—Turns the EX9200-RE2 module online or offline when pressed.

•

USB1 and USB2 ports—Host a removable media interface using which you can install the Junos OS

•

manually. See “USB Port Specifications for an EX Series Switch” on page 139.

SSD 1 and SSD 2 slots—Host primary storage for software images, configuration files, and microcode.

•

Also provide secondary storage for log files and memory dump files.

RESET button—Reboots the EX9200-RE2 module when pressed.

•

Captive screws—Secure the EX9200-RE2 module in place.

•

For the specifications of the Routing Engine modules, see Table 25 on page 70.

Table 25: Routing Engine Module Specifications

Connection to Packet Forwarding EnginesMemoryProcessorRE Module

First Junos OS ReleaseMediaDisk

EX9200-RE

EX9200-RE2

(4 cores, 1.73 GHz)

(6 cores, 2 GHz)

16 GBRE-S-EX9200-1800X4

64 GBRE-S-EX9200-2X00x6

Gigabit Ethernet

32- GB hard disk

50- GB SSD X 2

CompactFlash card

memory

12.3R24- GB

17.1R1No flash

Routing Engine Module LEDs in an EX9200 Switch

Each Routing Engine module (RE module) has LEDs on the module faceplate. Table 26 on page 70 describes the functions of these LEDs on the EX9200-RE and Table 27 on page 71 describes the functions of these LEDs on the EX9200-RE2.

Table 26: LEDs on the EX9200-RE Routing Engine Module

State and DescriptionStatusLED Label

RE module is functioning as the primary.BlueMASTER

Unlit

RE module is either functioning as the backup or not installed.

Table 26: LEDs on the EX9200-RE Routing Engine Module (continued)

State and DescriptionStatusLED Label

Blinking—Indicates activity on the SSD.GreenSTORAGE

GreenONLINE

On steadily—RE module is operating normally.

•

Blinking—RE module is coming online or going offline.

•

RE module has failed.RedOK/FAIL

Table 27: LEDs on the EX9200-RE2 Routing Engine Module

State and DescriptionStatusLED Label

RE module is functioning as the primary.BlueMASTER

Unlit

Green

RE module is either functioning as the backup or not installed.

The RE is powered offUnlitONLINE

When the RE module is powering on:

Blinking slowly (LED is lit for a period of

•

time and is unlit for thrice that period of time that follows, and this pattern is repeated)—RE module is coming online.

Blinking fast (LED is lit for a period of time

•

and is unlit for the subsequent same period of time, and this pattern is repeated)—Linux is booted.

On steadily (LED glows steadily)—Junos

•

OS is booted.

When the RE module is powering off:

Blinking fast (LED is lit for a period of time

•

and is unlit for the subsequent same period of time, and this pattern is repeated)—Junos OS is powering off.

Blinking slowly (LED is lit for a period of

•

time and is unlit for thrice that period of time that follows, and this pattern is repeated)—Linux is powering off.

Unlit—RE module is powered off.

•

Table 27: LEDs on the EX9200-RE2 Routing Engine Module (continued)

State and DescriptionStatusLED Label

RE module has failed.RedOK/FAIL

Blinking—Indicates activity on the SSD.GreenDISK1

Blinking—Indicates activity on the SSD.GreenDISK2

SEE ALSO

Installing an RE Module in an EX9200 Switch | 211 Removing an RE Module from an EX9200 Switch | 209

Switch Fabric Module in an EX9200 Switch

The Switch Fabric serves as the central nonblocking matrix through which all network data passes.

Switch Fabric modules (SF modules) are installed horizontally on the front panel of the switch chassis. You can install either one or two SF modules in an EX9204 or EX9208 switch and two or three SF modules in an EX9214 switch. A base-configuration EX9204 or EX9208 switch has only one SF module, and a base-configuration EX9214 switch has two SF modules. See “EX9204 Switch Configurations” on page 27, EX9208 Switch Configurations, or EX9214 Switch Configurations.

In EX9204 and EX9208 switches, you can add a second SF module to the configuration for host subsystem redundancy. In EX9214 switches, you can add a third SF module to the configuration for host subsystem redundancy. If two SF modules are installed, one SF module functions as the primary and the other functions as the backup. If the primary SF module or its components fails or is removed, the backup module takes the role of primary.

The Routing Engine module (RE module) installs directly into a slot on the SF module. The Switch Fabric contains logic that determines which Routing Engine is the primary. The primary Routing Engine controls many internal functions of the SF module.

The backup SF module is hot-insertable and hot-removable, but the primary SF module is only hot-insertable.

The key functions of the Switch Fabric are:

Monitor and control system functions

•

Interconnection of all line cards

•

Clocking, system resets, and booting control

g022002

•

Routing Engine carrier

•

Figure 20 on page 73 shows the original SF module, EX9200-SF.

Figure 20: SF Module EX9200-SF

Starting with Junos OS Release 14.1, a high-speed SF module, EX9200-SF2, is available. Compared to the original SF module, EX9200-SF, the EX9200-SF2 offers increased bandwidth, providing higher-capacity traffic support in settings that require greater interface density (slot and capacity scale).

The EX9200-SF2 supports all EX9200 line cards.

NOTE: When you upgrade from an EX9200-SF module to an EX9200-SF2 module in an EX9200

switch, the SF module types can coexist in the switch during the upgrade. However, you must replace that EX9200-SF module with another EX9200-SF2 module for normal switch operation. See “Upgrading an EX9200-SF to an EX9200-SF2” on page 214.

Figure 21 on page 74 shows the high-speed SF module, EX9200-SF2.

Figure 21: SF Module EX9200-SF2

EX9200-SF2

LINK

BITS

GPS

UTI

EX9200-SF2

The SF modules install horizontally into the front of the chassis. If any slots are empty, you must install a cover panel.

The SF module has the following components:

Chassis management Ethernet switch

•

I2C bus logic, used for low-level communication with each component

•

Component redundancy circuitry

•

Control Board/Routing Engine primary-role mechanism

•

Gigabit Ethernet switch that is connected to the embedded CPU complex on all components

•

Control field-programmable gate array (FPGA)—Provides the Peripheral Component Interconnect (PCI)

•

interface to the Routing Engine

1000Base-T Ethernet controller—Provides a 1-Gbps Ethernet link between the Routing Engines

•

Ethernet switch—Provides 1-Gbps link speeds between the Routing Engine and the line cards

•

External clock interface—Allows BITS or GPS clock source input to the centralized timing circuit, or

•

allows centralized timing to be output to BITS or GPS

Circuits for chassis management and control

•

Power circuits for the Routing Engine and the Switch Fabric

•

SF module LEDs—Indicate system status. (See “Switch Fabric Module LEDs in an EX9200 Switch” on

•

page 75).

Ejector levers—Used for installing and removing the SF module

•

Captive screws—Secure the SF module in place

•

SEE ALSO

Installing an SF Module in an EX9200 Switch | 223

Removing an SF Module from an EX9200 Switch | 221 Taking the Host Subsystem Offline in an EX9200 Switch | 209

Switch Fabric Module LEDs in an EX9200 Switch

The Switch Fabric module (SF module) has three LEDs on the module faceplate. Table 28 on page 75 describes the functions of these LEDs. For information about the LEDs on the EX9200-SF3, see

Table 29 on page 78.

Table 28: SF Module LEDs of an EX9200 Switch

DescriptionStatusLED

Switch Fabric is in active mode.GreenFABRIC ACTIVE

Switch Fabric is offline.Unlit

On steadily—Switch Fabric is operating in fabric-only mode.GreenFABRIC ONLY

Switch Fabric is not operating in fabric-only mode.Unlit

Switch Fabric is online.GreenOK/FAIL

Switch Fabric has failed.Red

Switch Fabric is offline.Unlit

The BITS, GPS, and UTI LEDs, located next to the EXT CLK port, indicate the status of the respective clocking interface. These LEDs are not supported.

EX9200-SF3 Module in an EX9200 Switch

g100547

EX9200-SF3

Starting in Junos OS Release 20.3R1, the EX9200-SF3 Swith Fabric module is available. The EX9200-SF3 provides improved fabric performance and bandwidth capabilities for high-capacity line cards. In a redundant configuration, the EX9200-SF3 provides fabric bandwidth of up to 1 Tbps per slot. In a nonredundant configuration the EX9200-SF3 provides fabric bandwidth of up to 1 Tbps per slot (four fabric planes) and

1.5 Tbps per slot fabric bandwidth when all six fabric planes are used (with EX9200-15C line cards).

Figure 22 on page 76 shows the SF module, EX9200-SF3.

Figure 22: EX9200-SF3

The EX9200-SF3

Software release

Junos OS Release 20.3R1 and later

Name in CLI: EX9200-SF3

EX9200-SF3 Components and Features

DescriptionComponent/Feature

XGE ports

GPS port

External clock interface

Centralized Stratum3E clock module

In-system removable Routing Engine

Two Ethernet ports provide 10GbE and 1GbE SFP+ interfaces. These ports also are connected to the Ethernet control switch, which limits the traffic for the 10GbE port and provides security to prevent unwanted access to the control plane through the external ports.

One RJ-45 GPS external clock interface port receives GPS and PPS timing from the GPS external interface. A red LED indicates there is no clock present or the clock is not OK. A green LED indicates the clock interface is active and OK. If the LED is off, the clock interface is not enabled.

The external clock interface is on the EX9200-SF3 front panel. The clock source interface receives GPS and PPS timing from the GPS external interface.

The clock module performs clock monitoring, filtering, and holdover on the centralized fabric card. This centralized clocking architecture also provides clock cleanup and distribution.

The in-system Routing Engine can support any new Routing Engine that conforms to the standard modular Routing Engine I/O interface and form factor.

NOTE: When a Routing Engine is not installed in the EX9200-SF3, you need to cover

the empty slot with a blank panel.

Hot-swappable

Redundancy

The EX9200-SF3 and associated Routing Engine assembly are hot-swappable. The system software provides a mechanism to shut down the Routing Engine/EX9200-SF3. The system software also provides a method to reset or reboot the Routing Engine/EX9200-SF3. This support is provided through CLI commands and various hardware support circuits.

NOTE: Before removing the module, you must bring the Routing Engine offline to avoid

corrupting the hard drive.

See “Upgrading to an EX9200-SF3” on page 217 for details.System upgrade capabilities

With three EX9200-SF3 Switch Fabric modules installed, the EX9214 provides 2 + 1 redundancy. With two EX9200-SF3s installed, the EX9204 and EX9208 provide 1 + 1 redundancy.

Supports dynamic multicast replication (DMR).DMR

Supports graceful Routing Engine switchover (GRES).GRES

DescriptionComponent/Feature

Hitless operation

module

Allows you to upgrade programmable parts and reboot with “hitless” operation if the redundant EX9200-SF3s are inserted in the system and are operational.

You can remove the Routing Engine module FRU in the existing form factor.Removable Routing Engine

EX9200-SF3 LEDs

Table 29 on page 78 describes the functions of the EX9200-SF3 LEDs.

Table 29: EX9200-SF3 Module LEDs

DescriptionStatusLED

Switch Fabric is online.GreenOK/FAIL

Switch Fabric has failed.Red

Switch Fabric is offline.Unlit

Switch Fabric is in active mode.GreenFABRIC ACTIVE

Switch Fabric is offline.Unlit

On steadily—Switch Fabric is operating in fabric-only mode.GreenFABRIC ONLY

Switch Fabric is not operating in fabric-only mode.Unlit

Port is enabled and a link is established.GreenXGE Port LINK

Port is disabled or no link is established.Unlit

A link is established.GreenGPS EXT CLK

There is activity on the clocking interface.Amber (blinking)

EX9200-SF3 Fabric Bandwidth Performance and Redundancy

EX9214 Switches:

The EX9214 system can contain up to three EX9200-SF3s to provide a total of six switch fabric planes

•

for packet forwarding among the MPCs. Two fabric planes per EX9200-SF3s are required. To achieve full fabric bandwidth performance, three EX9200-SF3s must be installed in the EX9214 chassis.

Two chassis slots are provided in the center of the EX9214 chassis in slots 6 and 7 (also designated as

•

slot SF0 and slot SF1) for two EX9200-SF3s, each equipped with a Routing Engine.

To provide 2 + 1 fabric redundancy for an EX9214, a third EX9200-SF3 must be installed in slot 8 (also

•

designated as slot SF2).

Slot 8 in the EX9214 chassis is a dual-purpose slot, and supports either an EX9200-SF3 or a line card.

•

When the EX9200-SF3/Routing Engine are plugged into slot 8, the Routing Engine is powered down and does not provide any control functionality for the board or the EX9214. The fabric-only LED on the card faceplate will be lit when an EX9200-SF3/Routing Engine assembly is plugged into slot 8.

Once redundancy is configured, the primary EX9200-SF3 controls the chassis.

•

Graceful upgrades can be achieved on a non-primary redundant EX9200-SF3.

•

In a redundant configuration, the non-primary redundant Routing Engine can be removed or installed

•

without affecting the switching plane functionality on the EX9200-SF3 in which it resides.

In a nonredundant configuration, all six fabric planes will be in active mode for increased fabric bandwidth.

•

There is one physical switch fabric per EX9200-SF3 and it acts as two virtual planes in the EX9214.

•

EX9204 and EX9208 Switches:

You can install either one or two EX9200-SF3s in the EX9204 and EX9208 chassis in the slots labeled

•

0 and 1.

The EX9200-SF3 in slot 0 (SF0) provides two fabric planes; the EX9200-SF3 in slot 1 (SF1) provides four

•

fabric planes. A total of six fabric planes are available in the EX9204 and EX9208.

In a redundant configuration, two fabric planes on the first EX9200-SF3 and two fabric planes on the

•

other EX9200-SF3 will be in active mode.

There is one physical switch fabric per EX9200-SF3, and it acts as four virtual planes in the EX9204 and

•

EX9208.

Two EX9200-SF3 modules installed in the EX9204 and EX9208 are required for 1 + 1 redundancy. To provide 1 + 1 fabric redundancy, there must be an EX9200-SF3 installed in slot 1.

NOTE:

If SF0 fails, SF1 will be automatically configured with four fabric planes active. In this failover

•

scenario, the EX9200-SF3 will support full line rate 100 percent redundancy.

If SF1 fails, SF0 has only two available fabric planes; therefore, in this failover mode, the line

•

rate will drop to 50 percent.

EX9200-SF3 Maximum Power Consumption per Ambient Temperature and CB Slot

NOTE: These power consumption values are for the EX9200-SF3 only. They do not include

reallocated power.

Maximum Power ConsumptionAmbient TemperatureEX Series Model

Slot

EX9214

EX9208

EX9204

131° F (55° C)

104° F (40° C)

77° F (25° C)

131° F (55° C)

104° F (40° C)

77° F (25° C)

131° F (55° C)

104° F (40° C)

77° F (25° C)

131° F (55° C)

104° F (40° C)

77° F (25° C)

SF0, SF1, SF2425 W

400 W

385 W

SF0 (primary)295 W

280 W

265 W

SF1 (backup)295 W

280 W

265 W

SF0 (primary)275 W

260 W

245 W

EX9204

131° F (55° C)

104° F (40° C)

77° F (25° C)

SF1 (backup)295 W

280 W

265 W

Interoperability with Existing Hardware

Table 30: EX9200-SF3 Interoperabilitiy with Line Cards and Routing Engines

EX9200-SF3 Operating Mode

Ethernet mode only

SupportedEX9204/EX9208/EX9214

NoEX9200-2C-8XSEnhanced IP/enhanced

NoEX9200-4QS

NoEX9200-6QS

YesEX9200-MPC

YesEX9200-12QS

YesEX9200-32XS

NoEX9200-40T

NoEX9200-40F

NoEX9200-40F-M

YesEX9200-40XS

Supported Routing Engines

EX9200-RE

EX9200-RE2

yes

NOTE: Hyper-mode is the default forwarding mode on the EX9200-SF3. If your deployment

does not need hyper-mode, disable hyper-mode using the set forwarding-options no-hyper-mode CLI command before installing the Routing Engine into the EX9200-SF3.

NOTE: Enhanced IP is the default network service on the EX9200-SF3.

EX9200-SF3 Unsupported Functions and Capabilities from Legacy Swith Fabric Modules

The EX9200-SF3 does not support the external UTI/DTI interface (front panel LED and daughter card

•

interface).

The EX9200-SF3 does not interoperate with any previous generation SF modules (EX9200-SF and

•

EX9200-SF2). Smooth upgrade is not supported.

The EX9200-SF3 does not support BITS.

•

The EX9200-SF3 does not support DPCs.

•

The EX9200-SF3 does not support mixed mode (DPC + MPC).

•

The EX9200-SF3 does not support the JAM release.

•

SEE ALSO

Upgrading to an EX9200-SF3 | 217

Installing an SF Module in an EX9200 Switch | 223

Removing an SF Module from an EX9200 Switch | 221 Taking the Host Subsystem Offline in an EX9200 Switch | 209

EX9200 Line Cards

IN THIS SECTION

Line Card Model and Version Compatibility in an EX9200 Switch | 83

EX9200-2C-8XS Line Card | 86

EX9200-4QS Line Card | 88

EX9200-6QS Line Card | 89

EX9200-MPC Line Card | 92

EX9200-12QS Line Card | 95

EX9200-15C Line Card | 98

EX9200-32XS Line Card | 102

EX9200-40T Line Card | 103

EX9200-40F Line Card | 105

EX9200-40F-M Line Card | 106

EX9200-40XS Line Card | 108

Line Card LED in an EX9200 Switch | 110

Network Port LEDs on Line Cards in an EX9200 Switch | 110

Modular Interface Card LED in an EX9200 Switch | 111

Configuring Rate Selectability on an EX9200-12QS Line Card to Enable Different Port Speeds | 112

Line Card Model and Version Compatibility in an EX9200 Switch

NOTE: If you are installing line cards released after Junos OS Release 14.1, ensure that the

Switch Fabric module (SF module) EX9200-SF2 is installed in the switch chassis.

Table 31 on page 83 shows the model numbers, description of the line card, the Junos OS release in which

the line card was first supported and the Switch Fabric module (SF module) that must be installed in the switch to support each line card.

Table 31: Line Card Models for EX9200 Switches

First Junos OS

SF Module Required

EX9200-SF or EX9200-SF2

EX9200-2C-8XS

EX9200-4QS

ReleaseDescriptionModel number

13.2R1A line card with two 100-Gigabit Ethernet ports and eight 10-Gigabit Ethernet ports

See “EX9200-2C-8XS Line Card” on

page 86

12.3R2A line card with four 40-Gigabit Ethernet ports

See “EX9200-4QS Line Card” on

page 88

Table 31: Line Card Models for EX9200 Switches (continued)

First Junos OS ReleaseDescriptionModel number

SF Module Required

EX9200-6QS

EX9200-MPC

A line card with six 40-Gigabit Ethernet ports and 24 10-Gigabit Ethernet ports

See “EX9200-6QS Line Card” on

page 89

of the following MICs:

EX9200-10XS-MIC

•

EX9200-20F-MIC

•

EX9200-40T-MIC

•

14.2R1

CAUTION: Junos OS

Release 14.2R1 supports the EX9200-6QS line card except for one specific configuration. See the Junos OS

14.2R2 Release Notes

for Known Issue PR1068396 to determine whether that configuration applies to your switch and which release to use if the configuration applies.

15.1R3A modular line card that accepts any

EX9200-SF or EX9200-SF2

EX9200-SF, EX9200-SF2, or EX9200-SF3

EX9200-12QS

EX9200-15C

See “EX9200-MPC Line Card” on

page 92

Ethernet rate-selectable ports, each of which can house transceivers

See “EX9200-12QS Line Card” on

page 95

ports. All ports can operate at 10-Gbps, 25-Gbps, 40-Gbps, or 100-Gbps speeds

See “EX9200-15C Line Card” on

page 98

16.1R1A line card with 12 40-Gigabit

EX9200-SF2 or EX9200-SF3

EX9200-SF320.3R1A line card with 15 rate-selectable

Table 31: Line Card Models for EX9200 Switches (continued)

First Junos OS ReleaseDescriptionModel number

SF Module Required

EX9200-32XS

EX9200-40T

EX9200-40F

EX9200-40F-M

Ethernet ports

See “EX9200-32XS Line Card” on

page 102

10/100/1000BASE-T ports that support RJ-45 connectors

See “EX9200-40T Line Card” on

page 103

ports

See “EX9200-40F Line Card” on

page 105

ports with Media Access Control Security (MACsec) capability

12.3R2A line card with 32 10-Gigabit

12.3R2A line card with 40

12.3R2A line card with 40 1-Gigabit Ethernet

14.2R1A line card with 40 1-Gigabit Ethernet

EX9200-SF, EX9200-SF2, or EX9200-SF3

EX9200-SF or EX9200-SF2

See “EX9200-40F-M Line Card” on

page 106

EX9200-40XS

16.1R1A line card with 40 10-Gigabit Ethernet ports with Media Access Control Security (MACsec) capability, each of which can house 10-gigabit small form-factor pluggable plus (SFP+) transceivers

See “EX9200-40XS Line Card” on

page 108

EX9200-SF2 or EX9200-SF3

Ensure that all of the line cards in a switch are supported in the Junos OS release that you want to use.

EX9200-2C-8XS Line Card

IN THIS SECTION

Line Card Models | 86

Line Card Components | 87

The line cards in EX9200 switches combine a Packet Forwarding Engine and Ethernet interfaces in a single assembly. Line cards are field-replaceable units (FRUs) that you can install in the line card slots on the front of the switch chassis. Line cards are hot-insertable and hot-removable: You can remove and replace them without powering off the switch or disrupting switch functions.

Line Card Models

Table 32 on page 86 shows the model number, description of the line card model, and the Junos OS release

in which the line card was first supported.

Table 32: EX9200-2C-8XS Line Card

Junos OS Release RequiredDescriptionModel

EX9200-2C-8XS

can house 100-gigabit C form-factor pluggable (CFP) transceivers; and eight 10-Gigabit Ethernet ports, each of which can house 10-gigabit small form-factor pluggable plus (SFP+) transceivers

13.2R1 or laterA line card with two 100-Gigabit Ethernet ports, each of which

See Figure 23 on page 87

Figure 23: EX9200-2C-8XS Line Card

4—1— 100-Gigabit Ethernet portsEjector levers

5—2— LEDs for the 100-Gigabit Ethernet portsLine card LED

6—3— 10-Gigabit Ethernet portsLEDs for the 10-Gigabit Ethernet ports

You can use the show version command to see the version of Junos OS for EX Series switches loaded on the switch.

Line Card Components

The EX9200-2C-8XS line card has:

Two 100-Gigabit Ethernet ports, each of which can house CFP transceivers. These ports support

•

100GBASE-LR4 and 100GBASE-SR10 transceivers.

Eight 10-Gigabit Ethernet ports, each of which can house SFP+ transceivers. These ports support

•

10GBASE-SR, 10GBASE-LR, 10GBASE-ER, and 10GBASE-ZR transceivers.

Two dust covers for the two 100-Gigabit Ethernet ports and eight dust covers for the eight 10-Gigabit

•

Ethernet ports

Line card LED—An LED labeled OK/FAIL, which indicates the status of the line card. See “Line Card LED

•

in an EX9200 Switch” on page 110.

LEDs for the ports—One LED on each port, the Link/Activity LED, which indicates the link status and

•

activity on the port. See “Network Port LEDs on Line Cards in an EX9200 Switch” on page 110.

The ports are divided into two port groups. The four 10-Gigabit Ethernet ports labeled 0/0 through 0/3 and the 100-Gigabit Ethernet port labeled 1/0 form one port group. The four 10-Gigabit Ethernet ports labeled 2/0 through 2/3 and the 100-Gigabit Ethernet port labeled 3/0 form the other port group. The ports in each group share 130 gigabits of bandwidth. Thus, you can transmit up to 130 gigabits of traffic through a port group, without packet drop.

EX9200-4QS Line Card

IN THIS SECTION

Line Card Models | 88

Line Card Components | 89

The line cards in EX9200 switches combine a Packet Forwarding Engine and Ethernet interfaces on a single assembly. They are field-replaceable units (FRUs) that you can install in the line card slots on the front of the switch chassis. Line cards are hot-insertable and hot-removable: You can remove and replace them without powering off the switch or disrupting switch functions.

Line Card Models

Table 33 on page 88 shows the model number, description of the line card model, and the Junos OS release

in which the line card was first supported.

Table 33: EX9200-4QS Line Card

Junos OS Release RequiredDescriptionModel

EX9200-4QS

which can house 40-gigabit quad small form-factor pluggable plus (QSFP+) transceivers

12.3R2 or laterA line card with four 40-Gigabit Ethernet ports, each of

See Figure 24 on page 88.

Figure 24: EX9200-4QS Line Card

3—MIC LED

4—1— LEDs for the portsEjector lever

5—2— 40-Gigabit Ethernet portsLine card LED

You can use the show version command to see the version of Junos OS for EX Series switches loaded on the switch.

Line Card Components

The EX9200-4QS line card has:

Four 40-Gigabit Ethernet ports, each of which can house QSFP+ transceivers.

•

Four dust covers preinstalled in the ports.

•

Line card LED—An LED labeled OK/FAIL, which indicates the status of the line card. See “Line Card LED

•

in an EX9200 Switch” on page 110.

MIC LED—An LED labeled OK/FAIL on each MIC, which indicates the status of the MIC. See “Modular

•

Interface Card LED in an EX9200 Switch” on page 111.

LEDs for the ports—One LED on each port, the Link/Activity LED, which indicates the link status and

•

activity on the port. See “Network Port LEDs on Line Cards in an EX9200 Switch” on page 110.

EX9200-6QS Line Card

IN THIS SECTION

Line Card Models | 89

Line Card Components | 90

Line Card Models

Table 34 on page 90 shows the model number, description of the line card model, and the Junos OS release

in which the line card was first supported.

Table 34: EX9200-6QS Line Card

Junos OS Release RequiredDescriptionModel

EX9200-6QS

A line card with six 40-Gigabit Ethernet ports, each of which can house 40-gigabit quad small form-factor pluggable plus (QSFP+) transceivers; and 24 10-Gigabit Ethernet ports, each of which can house 10-gigabit small form-factor pluggable (SFP+) transceivers

See Figure 25 on page 90.

Figure 25: EX9200-6QS Line Card

14.2R1 or later

CAUTION: Junos OS Release 14.2R1 supports the

EX9200-6QS line card except for one specific configuration. See the Junos OS 14.2R2 Release

Notes for Known Issue PR1068396 to determine

whether that configuration applies to your switch and which release to use if the configuration does apply.

4—1— 10-Gigabit Ethernet portsEjector lever

5—2— LEDs for the 40-Gigabit Ethernet portsLine card LED

6—3— 40-Gigabit Ethernet portsLEDs for the 10-Gigabit Ethernet ports

You can use the show version command to see the version of Junos OS for EX Series switches loaded on the switch.

Line Card Components

The EX9200-6QS line card has:

Six 40-Gigabit Ethernet ports, each of which can house QSFP+ transceivers. These ports support

•

40GBASE-LR4 and 40GBASE-SR4 transceivers. Starting with Junos OS for EX Series switches, Release 15.1 R3, these ports support the JNP-QSFP-40G-LX4 transceiver.

24 10-Gigabit Ethernet ports, each of which can house SFP+ transceivers. These ports support

•

10GBASE-SR, 10GBASE-LR, 10GBASE-ER, and 10GBASE-ZR transceivers.

Line card LED—An LED labeled OK/FAIL, which indicates the status of the line card. See “Line Card LED

•

in an EX9200 Switch” on page 110.

Network port LED—One LED on each network port, the Link/Activity LED, which indicates the link

•

status and activity on the port. See “Network Port LEDs on Line Cards in an EX9200 Switch” on page 110.

You can install SFP+ and QSFP+ transceivers in any combination in the ports on the line card. The ports are divided into two port groups. The twelve 10-Gigabit Ethernet ports labeled 0/0 through 0/11 form PIC 0 and twelve 10-Gigabit Ethernet ports labeled 1/0 through 1/11 form PIC 1; PIC 0 and PIC 1 form one port group. The three 40-Gigabit Ethernet ports labeled 2/0 through 2/2 form PIC 2 and three 40-Gigabit Ethernet ports labeled 3/0 through 3/2 form PIC 3; PIC 2 and PIC 3 form the other port group. The ports in each port group share 240 gigabits of bandwidth. Thus, you can transmit up to 240 gigabits of traffic through a port group, without packet drop.

PIC 0 and PIC 1 are activated by default. If you deactivate both PIC 0 and PIC 1, PIC 2 and PIC 3 are automatically activated. Similarly, if you deactivate both PIC 2 and PIC 3, PIC 0 and PIC 1 are automatically activated. You can choose to activate only one of the PICs and keep the other inactive. To deactivate an active PIC, use the power command.

The line card supports the following combinations of active PICs:

Any one PIC

•

PIC 0 and PIC 1

•

PIC 0 and PIC 3

•

PIC 1 and PIC 2

•

PIC 2 and PIC 3

•

NOTE:

The line card does not support the following combinations of active PICs:

PIC 0 and PIC 2

•

PIC 1 and PIC 3

•

EX9200-MPC Line Card

IN THIS SECTION

Line Card Models | 92

Line Card Components | 93

Line Card Models

Table 35 on page 92 shows the model number, description of the line card model, and the Junos OS release

in which the line card was first supported.

Table 35: EX9200-MPC

EX9200-MPC

(MICs):

EX9200-10XS-MIC

•

EX9200-20F-MIC

•

EX9200-40T-MIC

•

The MICs are separately orderable.

The EX9200-MPC line card has two slots on the faceplate in which you can install the MICs. You can install the MICs in the following configurations:

One EX9200-10XS-MIC

•

One EX9200-20F-MIC

•

One EX9200-10XS-MIC and one EX9200-20F-MIC

•

Two EX9200-10XS-MICs

•

Two EX9200-20F-MICs

•

One EX9200-40T-MIC

•

Junos OS Release RequiredDescriptionModel

15.1R3A modular line card that accepts any of the following Modular Interface Cards

You can transmit up to 130 gigabits of traffic through the line card without packet drop.

See Figure 26 on page 93.

Figure 26: EX9200-MPC Line Card

3—1— MIC slots covered by cover panelsEjector lever

2—Line card LED

You can use the show version command to see the version of Junos OS for EX Series switches loaded on the switch.

Line Card Components

The EX9200-MPC line card has:

Two slots that can accept any of the following MICs:

•

EX9200-10XS-MIC, which has ten 10-Gigabit Ethernet ports, each of which can house small form-factor

•

pluggable plus (SFP+) transceivers. The ports form one port group. The ports support 10GBASE-SR, 10GBASE-LR, 10GBASE-ER, and 10GBASE-ZR transceivers. An LED labeled OK/FAIL on the MIC indicates the status of the MIC. See “Modular Interface Card LED in an EX9200 Switch” on page 111. The MIC is shipped with 10 dust covers for the 10 ports. See Figure 27 on page 93.

Figure 27: EX9200-10XS-MIC

3—1— MIC power buttonLEDs for the ports

4—2— MIC LED10-Gigabit Ethernet ports

EX9200-20F-MIC, which has twenty 1-Gigabit Ethernet ports with Media Access Control Security

•

(MACsec) capability, each of which can house 1-gigabit small form-factor pluggable (SFP) transceivers. The EX9200-20F-MIC in EX9200-MPC line card supports 802.1AE IEEE MAC Security standard (also

known as MACsec) with AES-128 bit encryption, providing support for link-layer data confidentiality, data integrity, and data origin authentication. You must apply a single license—EX9200-SFL—to enable MACsec. The ports are divided into two port groups of ten ports each. The ports labeled [0/2]/0 through [0/2]/8 and [1/3]/0 through [1/3]/8 form one port group and the ports labeled [0/2]/1 through [0/2]/9 and [1/3]/1 through [1/3]/9 form another port group. These ports support 1000BASE-T, 1000BASE-SX, 100BASE-FX, 1000BASE-LX, 1000BASE-BX-U, 1000BASE-BX-D, 100BASE-BX-U, 100BASE-BX-D, and 1000BASE-LH transceivers. An LED labeled OK/FAIL on the MIC indicates the status of the MIC. See “Modular Interface Card LED in an EX9200 Switch” on

page 111. The MIC is shipped with 20 dust covers for the 20 ports. See Figure 28 on page 94.

Figure 28: EX9200-20F-MIC

3—1— MIC LEDLEDs for the ports

4—2— MIC power button1-Gigabit Ethernet ports

EX9200-40T-MIC, which has 40 RJ-45 ports, which can accept RJ-45 connectors. The ports are divided

•

into three port groups. The ports labeled 0/1 through 1/5 and 0/0 through 1/4 form port group pic0, the ports labeled 1/7 through 2/3 and 1/6 through 2/2 form port group pic1, and the ports labeled 2/5 through 3/9 and 2/4 through 3/8 form port group pic2. An LED labeled OK/FAIL on the MIC indicates the status of the MIC. See “Modular Interface Card LED in an EX9200 Switch” on page 111. See Figure 29 on page 95.

Figure 29: EX9200-40T-MIC

4—1— MIC power buttonLink/Activity LED for the ports

5—2— MIC LEDStatus LED the ports

3—RJ-45 ports

Cover panels—Two cover panels that cover the MIC slots.

•

Line card LED—An LED labeled OK/FAIL, which indicates the status of the line card. See “Line Card LED

•

in an EX9200 Switch” on page 110.

Network port LEDs—Each port on the EX9200-10XS-MIC and each port on the EX9200-20F-MIC has

•

an LED, the Link/Activity LED, which indicates the link status and activity on the port. Each port on the EX9200-40T-MIC has another LED, the Status LED, which indicates the status of the port parameters. See “Network Port LEDs on Line Cards in an EX9200 Switch” on page 110.

EX9200-12QS Line Card

IN THIS SECTION

Line Card Models | 96

Line Card Components | 97

Line Card Models

g0 0 9 282

0/3

0/ 0

0/4

0/5

0/3

0/4

0/5

100G

0 1 2 3

0/ 1

0/2

0/0

0/ 1

0/ 2

1/0

1/1

1/2

1/0

1/1

1/2

100G

2 3

1/3

1/4

1/5

1/3

1/4

1/5

100G

2 3

1 2 3 3 3 34 4 4 4 1

EX9 200 -12QS

Table 36 on page 96 shows the model number, description of the line card model, and the Junos OS release

in which the line card was first supported.

Table 36: EX9200-12QS Line Card

Junos OS Release RequiredDescriptionModel

EX9200-12QS

16.1R1 or laterA line card with 12 rate-selectable ports, each of which can house transceivers. All ports can operate at 10-Gbps and 40-Gbps speeds. The ports are configured to operate at 10-Gbps speed by default. The ports labeled 0/2, 0/5, 1/2, and 1/5 (see Figure 30 on page 96) can operate at 100-Gbps speed also. The line card supports maximum transmission units (MTUs) from 256 bytes through 9192 bytes.

NOTE: For the EX9200-12QS line card to be operational, you must install the EX9200-SF2 Switch Fabric module

(SF module) in the switch. See “Switch Fabric Module in an EX9200 Switch” on page 72 and “Installing an SF Module

in an EX9200 Switch” on page 223.

Figure 30 on page 96 shows the components of an EX9200-12QS line card.

Figure 30: EX9200-12QS Line Card

3—1— 10G/40G/100G Ethernet portsEjector lever

Line card LEDs

4—2— Link/Activity LEDs for the 10G/40G/100G Ethernet

ports

You can use the show version command to see the version of Junos OS for EX Series switches loaded on the switch.

Line Card Components

The EX9200-12QS line card has:

Twelve rate-selectable Gigabit Ethernet ports. All ports can operate at 10-Gbps and 40-Gbps speeds.

•

The ports are configured to operate at 10-Gbps speed by default. The ports labeled 0/2, 0/5, 1/2, and 1/5 (see Figure 30 on page 96) can operate at 100-Gbps speed also. You can configure the port speed

by using the following command:

user@host# set chassis fpc fpc-slot pic pic-number pic-mode pic-speed number of ports

number-of-active-physical-ports

You can configure a port to operate at 10-Gbps speed. If you configure the ports to operate at 10-Gbps

•

speed, each port operates as four 10-Gbps interfaces.

You can configure a port to operate at 40-Gbps speed and install a 40-gigabit QSFP+ transceiver in

•

the port.

You can configure the ports labeled 0/2, 0/5, 1/2, and 1/5 (see Figure 30 on page 96) to operate at

•

100-Gbps speed and install 100-gigabit QSFP+ transceivers in these ports.

Twelve dust covers for the ports

•

Line card LED—An LED labeled OK/FAIL, which indicates the status of the line card. See “Line Card LED

•

in an EX9200 Switch” on page 110.

Network port LED—Four LEDs for each network port, the Link/Activity LED, which indicates the link

•

status and activity on the port. See “Network Port LEDs on Line Cards in an EX9200 Switch” on page 110.

There are four LEDs labeled 0, 1, 2, and 3 for each port (see Figure 30 on page 96). If a port is configured to operate at 10-Gbps speed, four 10-Gbps interfaces are created and the LEDs labeled 0, 1, 2, and 3 for that port becomes operational. Each of these LEDs indicates the link/activity on each interface on the corresponding port. If a port is configured to operate at 40-Gbps speed, the LED labeled 0 for that port becomes operational. If the ports labeled 0/2, 0/5, 1/2, and 1/5 are configured to operate at 100-Gbps speed, the LED labeled 3 for each of these ports becomes operational.

You can find the list of transceivers supported on the EX9200-12QS line card at the Hardware Compatibility

Tool page for the EX9200-12QS line card.

The ports are divided into two port groups. The six ports labeled 0/0 through 0/5 form one port group, PIC 0. The six ports labeled 1/0 through 1/5 form the other port group, PIC 1. The ports in each group share 240 gigabits of bandwidth. Thus, you can transmit up to 240 gigabits of traffic through a port group without packet drop.

EX9200-15C Line Card

IN THIS SECTION

Line Card Models | 98

Line Card Components | 100

EX9200-15C Power Requirements | 100

EX9200-15C LEDs | 101

Cables and Connectors | 101

Line Card Models

Table 37 on page 99 shows the model number, description of the line card model, and the Junos OS release

in which the line card was first supported.

Table 37: EX9200-15C Line Card

EX9200-15C

Fixed-configuation line card with 15 rate-selectable

•

ports. All ports can operate at 10-Gbps, 25-Gbps, 40-Gbps, or 100-Gbps speeds. The ports are configured to operate at 100-Gbps speed by default.

Line-rate throughput of up to 1.5 Tbps when

•

installed with an enhanced midplane.

NOTE: In the CLI, when you run the show chassis

hardware command, the midplane description will

say <platform>-BP3 for an enhanced midplane. The EX9214 only uses enhanced midplanes.

Line-rate throughput of up to 800 Gbps when

•

installed with a standard midplane.

NOTE: In the CLI, when you run the show chassis

hardware command, the midplane description will

say <platform>-BP for a standard midplane.

Junos OS Release RequiredDescriptionModel

Name In the CLI

EX9200-15C20.3R1 or later

Supports maximum transmission units (MTUs) from

•

256 bytes through 16,000 bytes for transit traffic, and from 256 bytes through 9500 bytes for host-bound packets.

NOTE:

For the EX9200-15C line card to be operational, you must install the EX9200-SF3 Switch

•

Fabric module (SF module) in the switch. See “EX9200-SF3 Module in an EX9200 Switch” on

page 76.

To achieve maximum line-rate performance, the line card’s fabric redundancy mode must be

•

configured in increased bandwidth mode.

To achieve maximum performance, the following number of EX9200-SF3 SF modules must

•

be installed in the system:

EX9214—Three EX9200-SF3 SF modules

•

EX9204 and EX9208—Two EX9200-SF3 SF modules

•

Figure 31 on page 100 shows the components of an EX9200-15C line card.

Figure 31: EX9200-15C Line Card

g100548

EX9200-15C

4—1— Physical Presence buttonOK/FAIL LED

5—2— Port LEDsLane LEDs

3—Network ports

You can use the show version command to see the version of Junos OS for EX Series switches loaded on the switch.

Line Card Components

100

The EX9200-15C line card has:

Fifteen network ports that can be configured for 10-Gbps, 25-Gbps, 40-Gbps, or 100-Gbps (breakout

•

cables are used for 10-Gbps and 25-Gbps speeds).

The Switch Processor Mezzanine Board (SPMB) consists of a 1.6-GHz Intel Broadwell 8-core CPU,

•

100-GB SATA SSD, and two 16-GB ECC DDR4 DRAM modules.

Three Packet Forwarding Engines, each providing a maximum bandwidth of 500 Gbps.

•

Juniper Penta silicon for increased scaling for bandwidth, subscribers, and services.

•

NOTE: On EX9214 switches, the EX9200-15C is not supported in the line-card slots numbered

0, 1, and 11.

EX9200-15C Power Requirements

The power numbers are measured using the following configuration:

IPv4 forwarding with 200-bytes packet size

•

Line-rate traffic on all ports for 1.5-Tbps aggregate bandwidth

•

All 15 ports are configured for 100GbE, with QSFP28 LR4 transceivers installed on all ports

•

At different temperatures:

Juniper EX9204 Hardware Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Table of Contents

About the Documentation

Documentation and Release Notes

Using the Examples in This Manual

Merging a Full Example

Merging a Snippet

Documentation Conventions
