Juniper EX4500-40F-FB, EX4500-40F-DC-C, EX4500-40F-VC1-FB, EX4500-40F-VC1-BF, EX4500-40F-VC1-DC Complete Hardware Manual

...

Complete Hardware Guide for EX4500 Ethernet Switches

Modified: 2015-06-23 Revision 13

Juniper Networks, Inc. 1133 Innovation Way Sunnyvale, California 94089 USA 408-745-2000 www.juniper.net

Juniper Networks, Junos, Steel-Belted Radius, NetScreen, and ScreenOS are registered trademarks of Juniper Networks, Inc. in the United States and other countries. The Juniper Networks Logo, the Junos logo, and JunosE are trademarks of Juniper Networks, Inc. All other trademarks, service marks, registered trademarks, or registered service marks are the property of their respective owners.

Juniper Networks assumes no responsibility for any inaccuracies in this document. Juniper Networks reserves the right to change, modify, transfer, or otherwise revise this publication without notice.

Complete Hardware Guide for EX4500 Ethernet Switches

Revision History July 2014—Revision 13 March 2014—Revision 12 January 2013—Revision 11 September 2012—Revision 10 September 2012—Revision 9 March 2012—Revision 8 November 2011—Revision 7 September 2011—Revision 6 July 2011—Revision 5 March 2011—Revision 4 December 2010—Revision 3 August 2010—Revision 2 May 2010—Revision 1

The information in this document is current as of the date on the title page.

YEAR 2000 NOTICE

Juniper Networks hardware and software products are Year 2000 compliant. Junos OS has no known time-related limitations through the year 2038. However, the NTP application is known to have some difficulty in the year 2036.

SOFTWARE LICENSE

The terms and conditions for using this software aredescribed in the software license contained in the acknowledgment to your purchase order or, to the extent applicable, to any reseller agreement or end-user purchase agreement executed between you and Juniper Networks. By using this software, you indicate that you understand and agree to be bound by those terms and conditions.

Generally speaking, the software license restricts the manner in which you are permitted to use the software and may contain prohibitions against certain uses. The software license may state conditions under which the license is automatically terminated. You should consult the license for further details.

For complete product documentation, please see the Juniper NetworksWeb site at www.juniper.net/techpubs.

END USER LICENSE AGREEMENT

The Juniper Networks product that is the subject of this technical documentation consists of (or is intended for use with) Juniper Networks software. Use of such software is subject tothe terms and conditions of the End User License Agreement (“EULA”) posted at

http://www.juniper.net/support/eula.html. By downloading, installing or using such software, you agree to the terms and conditions of

that EULA.

About the Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xv

Junos OS Documentation and Release Notes . . . . . . . . . . . . . . . . . . . . . . . . . xv

Documentation Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xv

Documentation Feedback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xvii

Requesting Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xvii

Self-Help Online Tools and Resources . . . . . . . . . . . . . . . . . . . . . . . . . . xviii

Opening a Case with JTAC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xviii

Part 1 Switch and Components Overview and Specifications

Chapter 1 EX4500 Switch Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

EX4500 Switches Hardware Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

EX4500 Switches First View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Intraconnect Module and Virtual Chassis Module . . . . . . . . . . . . . . . . . . . . . . . 5

Virtual Chassis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Uplink Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Power Supplies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

EX4500 Switch Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Identifying EX4500 Switch Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Chassis Physical Specifications for EX4500 Switches . . . . . . . . . . . . . . . . . . . . . . 11

Front Panel of an EX4500 Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Rear Panel of an EX4500 Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

EX4500 Switch Hardware and CLI Terminology Mapping . . . . . . . . . . . . . . . . . . . 15

Chapter 2 Component Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

LCD Panel in EX4500 Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

LCD Panel Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

LCD Panel Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Chassis Status LEDs in EX4500 Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Field-Replaceable Units in EX4500 Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Network Port and Uplink Module Port LEDs in EX4500 Switches . . . . . . . . . . . . . 24

Management Port LEDs in EX4500 Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

AC Power Supply in EX4500 Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

AC Power Supply LEDs in EX4500 Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

DC Power Supply in EX4500 Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

DC Power Supply LEDs in EX4500 Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Cooling System and Airflow in an EX4500 Switch . . . . . . . . . . . . . . . . . . . . . . . . . 32

Fan Tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Airfow Direction in EX4500 Switch Models . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Front-to-Back Airflow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Complete Hardware Guide for EX4500 Ethernet Switches

Back-to-Front Airflow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Uplink Modules in EX4500 Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Intraconnect Module in EX4500 Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Virtual Chassis Module in EX4500 Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Chapter 3 Component Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

USB Port Specifications for an EX Series Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Console Port Connector Pinout Information for an EX Series Switch . . . . . . . . . . 42

RJ-45 to DB-9 Serial Port Adapter Pinout Information for a Switch . . . . . . . . . . . 43

Management Port Connector Pinout Information for an EX4500 Switch . . . . . . . 44

NetworkPort and Uplink ModulePort ConnectorPinout Information for EX4500

Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Virtual Chassis Ports Connector Pinout Information for EX4500 Switches . . . . . 46

Pluggable Transceivers Supported on EX4500 Switches . . . . . . . . . . . . . . . . . . . 49

SFP+ Direct Attach Cables for EX Series Switches . . . . . . . . . . . . . . . . . . . . . . . . . 67

Cable Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Standards Supported by These Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Grounding Cable and Lug Specifications for EX4500 Switches . . . . . . . . . . . . . . . 72

Part 2 Planning for Switch Installation

Chapter 4 Site Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Site Preparation Checklist for EX4500 Switches . . . . . . . . . . . . . . . . . . . . . . . . . . 77

General Site Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Site Electrical Wiring Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Environmental Requirements and Specifications for EX Series Switches . . . . . . . 81

Chapter 5 Rack and Cabinet Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

Rack Requirements for EX4500 Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

Cabinet Requirements for EX4500 Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

Clearance Requirements for Airflow and Hardware Maintenance for EX4500

Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Chapter 6 Cable Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Network Cable Specifications for EX4500 Switches . . . . . . . . . . . . . . . . . . . . . . . 91

Understanding EX Series Switches Fiber-Optic Cable Signal Loss, Attenuation,

and Dispersion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Signal Loss in Multimode and Single-Mode Fiber-Optic Cable . . . . . . . . . . . 92

Attenuation and Dispersion in Fiber-Optic Cable . . . . . . . . . . . . . . . . . . . . . . 92

Chapter 7 Planning Power Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

AC Power Supply Specifications for EX4500 Switches . . . . . . . . . . . . . . . . . . . . . 95

DC Power Specifications for EX4500 Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

AC Power Cord Specifications for an EX4500 Switch . . . . . . . . . . . . . . . . . . . . . . 96

Calculating the EX Series Switch Fiber-Optic Cable Power Budget . . . . . . . . . . 100

Calculating the EX Series Switch Fiber-Optic Cable Power Margin . . . . . . . . . . . 100

Table of Contents

Chapter 8 Planning the Virtual Chassis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

Understanding EX4200, EX4500, and EX4550 Virtual Chassis Hardware

Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

Ports Used to Interconnect Virtual Chassis Members . . . . . . . . . . . . . . . . . . 103

Number of Switches, Required Software Releases, and Member RolesThat

You Configure in the Virtual Chassis . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104

Virtual Chassis Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105

Switch Role and Member ID on the LCD Panel . . . . . . . . . . . . . . . . . . . . . . . 106

Planning EX4200, EX4500, and EX4550 Virtual Chassis . . . . . . . . . . . . . . . . . . 106

Part 3 Installing and Connecting the Switch and Switch Components

Chapter 9 Installing the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

Installing and Connecting an EX4500 Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

Unpacking an EX4500 Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112

Parts Inventory (Packing List) for an EX4500 Switch . . . . . . . . . . . . . . . . . . . . . . 112

Mounting an EX4500 Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114

Mounting an EX4500 Switch on Two Posts in a Rack or Cabinet . . . . . . . . . . . . . 114

Mounting an EX4500 Switch on Four Posts in a Rack or Cabinet . . . . . . . . . . . . . 116

Mounting an EX4500 Switch in a Recessed Position in a Rack or Cabinet . . . . . 120

Chapter 10 Installing Switch Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

Installing and Removing EX4500 Switch Hardware Components . . . . . . . . . . . . 121

Installing an AC Power Supply in an EX4500 Switch . . . . . . . . . . . . . . . . . . . . . . 122

Installing a DC Power Supply in an EX4500 Switch . . . . . . . . . . . . . . . . . . . . . . . 124

Installing a Fan Tray in an EX4500 Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125

Installing an Uplink Module in an EX4500 Switch . . . . . . . . . . . . . . . . . . . . . . . . . 127

Installing an Intraconnect Module in an EX4500 Switch . . . . . . . . . . . . . . . . . . . 129

Installing a Virtual Chassis Module in an EX4500 Switch . . . . . . . . . . . . . . . . . . . 131

Connecting a Virtual Chassis Cable to an EX4500 Switch . . . . . . . . . . . . . . . . . . 133

Installing a Transceiver in an EX Series Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . 134

Chapter 11 Connecting the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137

Connecting Earth Ground to an EX Series Switch . . . . . . . . . . . . . . . . . . . . . . . . . 137

Parts and Tools Required for Connecting an EX Series Switch to Earth

Ground . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138

Special Instructions to Follow Before Connecting Earth Ground to a

Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140

Connecting Earth Ground to an EX Series Switch . . . . . . . . . . . . . . . . . . . . . 142

Connecting AC Power to an EX4500 Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143

Connecting DC Power to an EX4500 Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145

Connecting a Switch to a Network for Out-of-Band Management . . . . . . . . . . . 149

Connecting a Switch to a Management Console . . . . . . . . . . . . . . . . . . . . . . . . . 150

Connecting a Fiber-Optic Cable to a Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152

Chapter 12 Performing Initial Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155

EX4500 Default Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155

Connecting and Configuring an EX Series Switch (CLI Procedure) . . . . . . . . . . . . 161

Connecting and Configuring an EX Series Switch (J-Web Procedure) . . . . . . . . . 164

Complete Hardware Guide for EX4500 Ethernet Switches

Part 4 Removing the Switch and Switch Components

Chapter 13 Removing the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171

Powering Off an EX4500 Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171

Removing an EX4500 Switch from a Rack or Cabinet . . . . . . . . . . . . . . . . . . . . . 173

Chapter 14 Removing Switch Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175

Installing and Removing EX4500 Switch Hardware Components . . . . . . . . . . . . 175

Removing an AC Power Supply from an EX4500 Switch . . . . . . . . . . . . . . . . . . . 176

Replacing Redundant AC Power Supplies in an EX4500 Switch Without

Disrupting Switch Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178

Replacing the Power Supply in the Top Slot . . . . . . . . . . . . . . . . . . . . . . . . . 180

Replacing the Power Supply in the Bottom Slot . . . . . . . . . . . . . . . . . . . . . . 182

Removing a DC Power Supply from an EX4500 Switch . . . . . . . . . . . . . . . . . . . . 183

Removing a Fan Tray from an EX4500 Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . 184

Removing an Uplink Module from an EX4500 Switch . . . . . . . . . . . . . . . . . . . . . 186

Removing an Intraconnect Module from an EX4500 Switch . . . . . . . . . . . . . . . . 188

Removing a Virtual Chassis Module from an EX4500 Switch . . . . . . . . . . . . . . . 190

Disconnecting a Virtual Chassis Cable from an EX4500 Switch . . . . . . . . . . . . . 192

Disconnecting a Fiber-Optic Cable from a Switch . . . . . . . . . . . . . . . . . . . . . . . . 194

Removing a Transceiver from a Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 195

Part 5 Switch and Component Maintenance

Chapter 15 Routine Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201

Maintaining Fiber-Optic Cables in Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201

Part 6 Troubleshooting Switch Issues

Chapter 16 Troubleshooting Switch Issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 205

Troubleshooting the Boot Process on EX4500 Switches . . . . . . . . . . . . . . . . . . 205

Part 7 Returning Hardware

Chapter 17 Returning the Switch or Switch Components . . . . . . . . . . . . . . . . . . . . . . . . 209

Returning an EX4500 Switch or Component for Repair or Replacement . . . . . . 209

Locating the Serial Number on an EX4500 Switch or Component . . . . . . . . . . . 210

Listing the Switch and Components Details with the CLI . . . . . . . . . . . . . . . 210

Locating the Chassis Serial Number ID Label on an EX4500 Switch . . . . . . . 211

Locating the Serial Number ID Labels on FRUs in an EX4500 Switch . . . . . . 211

Contacting Customer Support to Obtain Return Materials Authorization for

Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 213

Packing an EX4500 Switch or Component for Shipping . . . . . . . . . . . . . . . . . . . 215

Packing an EX4500 Switch for Shipping . . . . . . . . . . . . . . . . . . . . . . . . . . . . 216

Packing EX4500 Switch Components for Shipping . . . . . . . . . . . . . . . . . . . . 217

Part 8 Safety Information

Chapter 18 General Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 221

General Safety Guidelines and Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 221

Definitions of Safety Warning Levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 222

Table of Contents

Fire Safety Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 224

Qualified Personnel Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 225

Warning Statement for Norway and Sweden . . . . . . . . . . . . . . . . . . . . . . . . . . . . 226

Chapter 19 Radiation and Laser Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 227

Laser and LED Safety Guidelines and Warnings for Switches . . . . . . . . . . . . . . . 227

General Laser Safety Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 227

Class 1 Laser Product Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 228

Class 1 LED Product Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 228

Laser Beam Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 229

Radiation from Open Port Apertures Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . 230

Chapter 20 Installation and Maintenance Safety Information . . . . . . . . . . . . . . . . . . . . 233

Installation Instructions Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 233

Chassis Lifting Guidelines for EX4500 Switches . . . . . . . . . . . . . . . . . . . . . . . . . 235

Ramp Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 236

Rack-Mounting and Cabinet-Mounting Warnings . . . . . . . . . . . . . . . . . . . . . . . . 236

Grounded Equipment Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 241

Maintenance and Operational Safety Guidelines and Warnings . . . . . . . . . . . . . 242

Battery Handling Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 242

Jewelry Removal Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 243

Lightning Activity Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 244

Operating Temperature Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 245

Product Disposal Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 246

Chapter 21 Power and Electrical Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . 249

General Electrical Safety Guidelines and Warnings . . . . . . . . . . . . . . . . . . . . . . . 249

Prevention of Electrostatic Discharge Damage . . . . . . . . . . . . . . . . . . . . . . . . . . 250

AC Power Electrical Safety Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 252

AC Power Disconnection Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 254

DC Power Electrical Safety Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 255

DC Power Disconnection Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 257

DC Power Grounding Requirements and Warning . . . . . . . . . . . . . . . . . . . . . . . . 259

DC Power Wiring Sequence Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 260

DC Power Wiring Terminations Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 262

Multiple Power Supplies Disconnection Warning . . . . . . . . . . . . . . . . . . . . . . . . . 263

TN Power Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 264

Action to Take After an Electrical Accident . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 264

Part 9 Compliance Information

Chapter 22 Compliance Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 269

Agency Approvals for EX Series Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 269

Compliance Statements for EMC Requirements for EX Series Switches . . . . . . 270

Canada . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 270

European Community . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 271

Israel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 271

Japan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 271

Korea . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 272

United States . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 272

Complete Hardware Guide for EX4500 Ethernet Switches

FCC Part 15 Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 272

Nonregulatory Environmental Standards . . . . . . . . . . . . . . . . . . . . . . . . . . . . 273

Compliance Statements for Acoustic Noise for EX Series Switches . . . . . . . . . . 274

Declaration of Conformity for EX4500 Switches . . . . . . . . . . . . . . . . . . . . . . . . . 274

List of Figures

Part 1 Switch and Components Overview and Specifications

Chapter 1 EX4500 Switch Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Figure 1: EX4500 Switch Front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Figure 2: EX4500 Switch Rear with Intraconnect Module Installed . . . . . . . . . . . . . 4

Figure 3: EX4500 Switch Rear with Virtual Chassis Module Installed . . . . . . . . . . . 5

Figure 4: EX4500 Switch Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Figure 5: Label Identifying EX4500 Switches that Support DCB . . . . . . . . . . . . . . 13

Figure 6: EX4500 Switch Rear Panel with an Intraconnect Module Installed . . . . 14

Figure 7: EX4500 Switch Rear Panel with a Virtual Chassis Module Installed . . . . 14

Chapter 2 Component Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Figure 8: LCD Panel in EX4500 Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Figure 9: Chassis Status LEDs in an EX4500 Switch . . . . . . . . . . . . . . . . . . . . . . . 22

Figure 10: Network Port LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Figure 11: Uplink Module Port LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Figure 12: LEDs on the Management Port on an EX4500 Switch . . . . . . . . . . . . . . 26

Figure 13: AC Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Figure 14: Power Cord Retainer for an AC Power Supply . . . . . . . . . . . . . . . . . . . . 28

Figure 15: AC Power Supply LEDs in EX4500 Switches . . . . . . . . . . . . . . . . . . . . . 29

Figure 16: DC Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Figure 17: DC Power Supply LED in EX4500 Switches . . . . . . . . . . . . . . . . . . . . . . 32

Figure 18: Fan Tray Used in an EX4500 Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Figure 19: Front-to-Back Airflow Through the EX4500 Switch Chassis . . . . . . . . 34

Figure 20: Back-to-Front Airflow Through the EX4500 Switch Chassis . . . . . . . . 35

Figure 21: Uplink Module Slots in an EX4500 Switch . . . . . . . . . . . . . . . . . . . . . . . 36

Figure 22: SFP+ Uplink Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Figure 23: Intraconnect Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Figure 24: Virtual Chassis Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Figure 25: Virtual Chassis Module LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Chapter 3 Component Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Figure 26: SFP+ Direct Attach Cables for EX Series Switches . . . . . . . . . . . . . . . . 68

Part 2 Planning for Switch Installation

Chapter 5 Rack and Cabinet Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

Figure 27: Front-to-Back Airflow Through the EX4500-40F-FB Switch

Chassis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Figure 28: Back-to-Front Airflow Through the EX4500-40F-BF Switch

Chassis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Complete Hardware Guide for EX4500 Ethernet Switches

Figure 29: Clearance Requirements for Airflow and Hardware Maintenance for

an EX4500 Switch Chassis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Part 3 Installing and Connecting the Switch and Switch Components

Chapter 9 Installing the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

Figure 30: Attaching the Mounting Bracket Along the Front of the Switch . . . . . . 115

Figure 31: Mounting the Switch on Two Posts in a Rack . . . . . . . . . . . . . . . . . . . . . 116

Figure 32: Attaching the Front-Mounting Bracket to the Switch Chassis . . . . . . . 118

Figure 33: Mounting the Switch on the Front Posts in a Rack . . . . . . . . . . . . . . . . 119

Figure 34: Sliding the Rear Mounting-Blades to the Rear of a Four-Post Rack . . . 119

Chapter 10 Installing Switch Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

Figure 35: Installing a Power Supply in an EX4500 Switch . . . . . . . . . . . . . . . . . . 123

Figure 36: Installing a DC Power Supply in an EX4500 Switch . . . . . . . . . . . . . . . 125

Figure 37: Installing a Fan Tray in an EX4500 Switch . . . . . . . . . . . . . . . . . . . . . . 126

Figure 38: Uplink Module Slots in an EX4500 Switch . . . . . . . . . . . . . . . . . . . . . . 127

Figure 39: Installing an Uplink Module in an EX4500 Switch . . . . . . . . . . . . . . . . 128

Figure 40: Installing an Intraconnect Module in an EX4500 Switch . . . . . . . . . . . 131

Figure 41: Installing the Virtual Chassis Module in an EX4500 Switch . . . . . . . . . 133

Figure 42: Connecting a Virtual Chassis Cable to a Dedicated VCP on a Virtual

Chassis Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134

Figure 43: Installing a Transceiver in an EX Series Switch . . . . . . . . . . . . . . . . . . . 136

Chapter 11 Connecting the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137

Figure 44: Connecting the Grounding Lug to a Switch Mounted on Four Posts of

a Rack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141

Figure 45: Connecting a Grounding Cable to an EX Series Switch . . . . . . . . . . . . 142

Figure 46: Power Cord Retainer in an AC Power Supply . . . . . . . . . . . . . . . . . . . . 144

Figure 47: Connecting the Power Supply Cord to an EX4500 Switch . . . . . . . . . 145

Figure 48: Remove Plastic Cover from Terminal Block . . . . . . . . . . . . . . . . . . . . . 147

Figure 49: Connecting the Power Supply Cables to an EX4500 Switch . . . . . . . 148

Figure 50: Install Plastic Cover on Terminal Block . . . . . . . . . . . . . . . . . . . . . . . . . 148

Figure 51: Ethernet Cable Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149

Figure 52: Connecting a Switch to a Network for Out-of-Band Management . . . 150

Figure 53: Ethernet Cable Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151

Figure 54: Connecting a Switch to a Management Console Through a Console

Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152

Figure 55: Connecting a Switch Directly to a Management Console . . . . . . . . . . 152

Figure 56: Connecting a Fiber-Optic Cable to an Optical Transceiver Installed in

a Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153

Chapter 12 Performing Initial Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155

Figure 57: LCD Panel in an EX3200, EX4200, EX4500, EX4550, or EX8200

Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165

Figure 58: LCD Panel in an EX4300 Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165

Part 4 Removing the Switch and Switch Components

Chapter 14 Removing Switch Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175

Figure 59: Removing a Power Supply from an EX4500 Switch . . . . . . . . . . . . . . 178

List of Figures

Figure 60: Verify Green Power Supply LEDs for Normal Operation . . . . . . . . . . . 180

Figure 61: Removing an AC Power Supply from an EX4500 Switch . . . . . . . . . . . 181

Figure 62: Sliding a Replacement Power Supply into the EX4500 Switch . . . . . . 181

Figure 63: Connecting the Replacement Power Supply Cord . . . . . . . . . . . . . . . . 182

Figure 64: Removing a DC Power Supply from an EX4500 Switch . . . . . . . . . . . 184

Figure 65: Removing a Fan Tray from an EX4500 Switch . . . . . . . . . . . . . . . . . . 186

Figure 66: Removing an Uplink Module from an EX4500 Switch . . . . . . . . . . . . . 187

Figure 67: Removing an Intraconnect Module from an EX4500 Switch . . . . . . . 189

Figure 68: Removing the Virtual Chassis Module from an EX4500 Switch . . . . . 192

Figure 69: Disconnecting a Virtual Chassis Cable from a Dedicated VCP on a

Virtual Chassis Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193

Figure 70: Removing a Transceiver from a Switch . . . . . . . . . . . . . . . . . . . . . . . . . 196

Part 7 Returning Hardware

Chapter 17 Returning the Switch or Switch Components . . . . . . . . . . . . . . . . . . . . . . . . 209

Figure 71: Location of the Serial Number ID Label on an EX4500 Switch . . . . . . . 211

Figure 72: Location of the Serial Number ID Label on an AC Power Supply Used

in an EX4500 Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 212

Figure 73: Location of the Serial Number ID Label on the Fan Tray Used in an

EX4500 Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 212

Figure 74: Location of the Serial Number ID Label on the Virtual Chassis Module

Used in an EX4500 Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 213

Part 8 Safety Information

Chapter 21 Power and Electrical Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . 249

Figure 75: Placing a Component into an Antistatic Bag . . . . . . . . . . . . . . . . . . . . 251

Part 9 Compliance Information

Chapter 22 Compliance Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 269

Figure 76: Declaration of Conformity for the EU . . . . . . . . . . . . . . . . . . . . . . . . . . 275

Figure 77: Suppliers Declaration of Conformity for Australia and New

Zealand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 276

Complete Hardware Guide for EX4500 Ethernet Switches

List of Tables

About the Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xv

Table 1: Notice Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xvi

Table 2: Text and Syntax Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xvi

Part 1 Switch and Components Overview and Specifications

Chapter 1 EX4500 Switch Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Table 3: EX4500 Switch Models, Components, and Supported Junos OS

Table 4: Physical Specifications of the EX4500 Switch Chassis . . . . . . . . . . . . . . . 11

Table 5: CLI Equivalents of Terms Used in Documentation for EX4500

Chapter 2 Component Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Table 6: LCD Panel Menu Options in EX4500 Switches . . . . . . . . . . . . . . . . . . . . . 19

Table 7: Chassis Status LEDs in an EX4500 Switch . . . . . . . . . . . . . . . . . . . . . . . . 22

Table 8: Link/ActivityLED on Network Ports and Uplink Module Ports in EX4500

Table 9: Status LED on Network Ports and Uplink Module Ports in EX4500

Table 10: Link/Activity LED on the Management Port on an EX4500 Switch . . . . 27

Table 11: Status LED on the Management Port on an EX4500 Switch . . . . . . . . . . 27

Table 12: Power Supply LED on EX4500 Switches . . . . . . . . . . . . . . . . . . . . . . . . . 30

Table 13: DC Power Supply LED on EX4500 Switches . . . . . . . . . . . . . . . . . . . . . . 32

Table 14: Airflow Direction in EX4500 Switch Models . . . . . . . . . . . . . . . . . . . . . . 33

Table 15: Uplink Module Status LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Table 16: Intraconnect Module Status LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Table 17: Virtual Chassis Module LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Chapter 3 Component Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Table 18: EX Series Switches Console Port Connector Pinout Information . . . . . . 42

Table 19: RJ-45 to DB-9 Serial Port Adapter Pinout Information . . . . . . . . . . . . . . 44

Table 20: Management Port Connector Pinout Information for EX4500

Table 21: Network Port and Uplink Module Port Connector Pinout Information

Table 22: Virtual Chassis Ports (VCPs) Connector Pinout Information . . . . . . . . . 46

Table 23: Optical interface Support and Copper Interface Support for Gigabit

Table 24: Optical interface Support for Gigabit Ethernet SFP+ Transceivers in

Release . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

for EX4500 Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Ethernet SFP Transceivers in EX4500 Switches . . . . . . . . . . . . . . . . . . . . . . . 51

EX4500 Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Complete Hardware Guide for EX4500 Ethernet Switches

Table 25: Software Support for SFP+ Passive Direct Attach Cables for EX Series

Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Table 26: SFP+ Direct Attach Cable Specifications . . . . . . . . . . . . . . . . . . . . . . . . 70

Part 2 Planning for Switch Installation

Chapter 4 Site Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Table 27: Site Preparation Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Table 28: Site Electrical Wiring Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Table 29: EX Series Switch Environmental Tolerances . . . . . . . . . . . . . . . . . . . . . . 82

Chapter 5 Rack and Cabinet Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

Table 30: Rack Requirements and Specifications for the Switch . . . . . . . . . . . . . 85

Table 31: Cabinet Requirements and Specifications for the Switch . . . . . . . . . . . . 87

Chapter 7 Planning Power Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

Table 32: AC Power Supply Specifications for an EX4500 Switch . . . . . . . . . . . . 95

Table 33: Power Specifications for the DC Power Supply Used in an EX4500

Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

Table 34: AC Power Cord Specifications for an EX4500 Switch . . . . . . . . . . . . . . 97

Table 35: Estimated Values for Factors Causing Link Loss . . . . . . . . . . . . . . . . . . 101

Chapter 8 Planning the Virtual Chassis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

Table 36: Number of Switches and Switch Roles for an EX4200 Virtual Chassis,

per Junos OS Release . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104

Table 37: Number of Switches and Switch Roles for an EX4500 Virtual Chassis,

per Junos OS Release . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105

Table 38: Number of Switches and Switch Roles for an EX4550 Virtual Chassis,

per Junos OS Release . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105

Table 39: Number of Switches and Switch Roles for a Mixed EX4200, EX4500,

and EX4550 Virtual Chassis, per Junos OS Release . . . . . . . . . . . . . . . . . . . 105

Table 40: Virtual Chassis Components to Consider When Planning an EX4200,

EX4500, and EX4550 Virtual Chassis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106

Table 41: Cabling Requirements for a Virtual Chassis . . . . . . . . . . . . . . . . . . . . . . 107

Part 3 Installing and Connecting the Switch and Switch Components

Chapter 9 Installing the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

Table 42: Inventory of Components Provided with an EX4500 Switch . . . . . . . . . 113

Chapter 11 Connecting the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137

Table 43: Parts and Tools Required for Connecting an EX Series Switch to Earth

Ground . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138

Table 44: Special Instructions to Follow Before Connecting Earth Ground to a

Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140

About the Documentation

•

Junos OS Documentation and Release Notes on page xv

•

Documentation Conventions on page xv

•

Documentation Feedback on page xvii

•

Requesting Technical Support on page xvii

Junos OS Documentation and Release Notes

For a list of related Junos OS documentation, see

http://www.juniper.net/techpubs/software/junos/.

If the information in the latest release notes differs from the information in the documentation, follow the Junos OS Release Notes.

To obtain the most current version of all Juniper Networks®technical documentation, see the product documentation page on the Juniper Networks website at

http://www.juniper.net/techpubs/.

Documentation Conventions

Table 1 on page xvi defines the notice icons used in this guide.

Complete Hardware Guide for EX4500 Ethernet Switches

Table 1: Notice Icons

DescriptionMeaningIcon

Indicates important features or instructions.Informational note

Indicates a situation that might result in loss of data or hardware damage.Caution

Alerts you to the risk of personal injury or death.Warning

Alerts you to the risk of personal injury from a laser.Laser warning

Indicates helpful information.Tip

Table 2 on page xvi defines the text and syntax conventions used in this guide.

Table 2: Text and Syntax Conventions

Represents text that you type.Bold text like this

Fixed-width text like this

Italic text like this

Represents output that appears on the terminal screen.

•

Introduces or emphasizes important new terms.

•

Identifies guide names.

•

Identifies RFC and Internet draft titles.

Represents variables (options for which you substitute a value) in commands or configuration statements.

Alerts you to a recommended use or implementation.Best practice

ExamplesDescriptionConvention

To enter configuration mode, type the configure command:

user@host> configure

user@host> show chassis alarms

No alarms currently active

•

A policy term is a named structure that defines match conditions and actions.

•

Junos OS CLI User Guide

•

RFC 1997,BGP Communities Attribute

Configure the machine’s domain name:

[edit] root@# set system domain-name

domain-name

Table 2: Text and Syntax Conventions (continued)

Text like this

Represents names of configuration statements, commands, files, and directories;configurationhierarchy levels; or labels on routing platform components.

About the Documentation

ExamplesDescriptionConvention

•

To configure a stub area, include the

stub statement at the [edit protocols ospf area area-id] hierarchy level.

•

The console port is labeledCONSOLE.

stub <default-metric metric>;Encloses optional keywords or variables.< > (angle brackets)

| (pipe symbol)

# (pound sign)

[ ] (square brackets)

Indention and braces ( { } )

; (semicolon)

GUI Conventions

Bold text like this

Indicatesa choice between the mutually exclusivekeywordsor variables on either side of the symbol. The set of choices is often enclosed in parentheses for clarity.

same line as the configuration statement to which it applies.

Encloses a variable for which you can substitute one or more values.

Identifies a level in the configuration hierarchy.

Identifies a leaf statement at a configuration hierarchy level.

Representsgraphicaluser interface(GUI) items you click or select.

broadcast | multicast

(string1 | string2 | string3)

rsvp { # Required for dynamic MPLS onlyIndicates a comment specified on the

community name members [ community-ids ]

[edit] routing-options {

static {

route default {

nexthop address; retain;

}

•

In the Logical Interfaces box, select

All Interfaces.

•

To cancel the configuration, click

Cancel.

> (bold right angle bracket)

Documentation Feedback

We encourage you to provide feedback, comments, and suggestions so that we can improve the documentation. You can provide feedback by using either of the following methods:

Requesting Technical Support

Technicalproduct support is availablethrough the Juniper NetworksTechnical Assistance Center (JTAC). If you are a customer with an active J-Care or Partner Support Service

Separates levels in a hierarchy of menu selections.

In the configuration editor hierarchy, select Protocols>Ospf.

Complete Hardware Guide for EX4500 Ethernet Switches

support contract, or are covered under warranty, and need post-sales technical support, you can access our tools and resources online or open a case with JTAC.

•

JTAC policies—For a complete understanding of our JTAC procedures and policies, review the JTAC User Guide located at

http://www.juniper.net/us/en/local/pdf/resource-guides/7100059-en.pdf.

•

Product warranties—For product warranty information, visit

http://www.juniper.net/support/warranty/.

•

JTAC hours of operation—The JTAC centers have resources available 24 hours a day, 7 days a week, 365 days a year.

Self-Help Online Tools and Resources

For quick and easy problem resolution, Juniper Networks has designed an online self-service portal called the Customer Support Center (CSC) that provides you with the following features:

•

Find CSC offerings: http://www.juniper.net/customers/support/

•

Search for known bugs: http://www2.juniper.net/kb/

•

Find product documentation: http://www.juniper.net/techpubs/

•

Find solutions and answer questions using our Knowledge Base: http://kb.juniper.net/

•

Download the latest versions of software and review release notes:

http://www.juniper.net/customers/csc/software/

•

Search technical bulletins for relevant hardware and software notifications:

http://kb.juniper.net/InfoCenter/

•

Join and participate in the Juniper Networks Community Forum:

http://www.juniper.net/company/communities/

•

Open a case online in the CSC Case Management tool: http://www.juniper.net/cm/

To verify serviceentitlement by product serial number,use our Serial Number Entitlement (SNE) Tool: https://tools.juniper.net/SerialNumberEntitlementSearch/

Opening a Case with JTAC

You can open a case with JTAC on the Web or by telephone.

•

Use the Case Management tool in the CSC at http://www.juniper.net/cm/.

•

Call 1-888-314-JTAC (1-888-314-5822 toll-free in the USA, Canada, and Mexico).

For international or direct-dial options in countries without toll-free numbers, see

http://www.juniper.net/support/requesting-support.html.

PART 1

Switch and Components Overview and Specifications

•

EX4500 Switch Overview on page 3

•

Component Descriptions on page 17

•

Component Specifications on page 41

Complete Hardware Guide for EX4500 Ethernet Switches

CHAPTER 1

EX4500 Switch Overview

•

EX4500 Switches Hardware Overview on page 3

•

EX4500 Switch Models on page 7

•

Identifying EX4500 Switch Models on page 10

•

Chassis Physical Specifications for EX4500 Switches on page 11

•

Front Panel of an EX4500 Switch on page 12

•

Rear Panel of an EX4500 Switch on page 13

•

EX4500 Switch Hardware and CLI Terminology Mapping on page 15

EX4500 Switches Hardware Overview

Juniper Networks EX4500 Ethernet Switches provide high-density 10-gigabit ports for aggregation layerand data center top-of-rack deployments,and provideoptions for data center optimized airflow (hot aisle/cold aisle). You can configure EX4500 switches in a Virtual Chassis, or in a mixed Virtual Chassis with EX4200 switches or EX4550 switches or both, in a total of up to 10 members.

Software

You can manage EX4500 switches using the same interfaces that you use for managing other devices running Juniper Networks Junos operating system (Junos OS)—the command-line interface (CLI) and the J-Web graphical interface.

•

Software on page 3

•

EX4500 Switches First View on page 4

•

Intraconnect Module and Virtual Chassis Module on page 5

•

Virtual Chassis on page 6

•

Uplink Modules on page 6

•

Power Supplies on page 6

Juniper Networks EX Series Ethernet Switches run Junos OS, which provides Layer 2 and Layer 3 switching, routing, and security services. The same Junos OS code base that runs on EX Series switches also runs on all Juniper Networks M Series, MX Series, and T Series routers, and SRX Series Services Gateways. For information about installing software on your switch, see Software Installation on EX Series Switches.

g020845

g020846

EX4500-LB

Fan tray

AC power supply

Intraconnect module

Fan tray handle

Complete Hardware Guide for EX4500 Ethernet Switches

EX4500 Switches First View

EX4500 switches provide connectivity for high-density 10-Gigabit Ethernet data center top-of-rack and aggregation deployments. Typically, EX4500 switches are used in data centers where they can be positioned as the top device in a rack to provide connectivity for all devices in the rack.

The EX4500 switch is 2 rack units (2 U) in size. Each EX4500 switch is designed to optimize rack space utilization and cabling. See Figure 1 on page 4, Figure 2 on page 4, and Figure 3 on page 5.

NOTE: The side of the switch where the networkports are locatedis the front

of the switch.

Figure 1: EX4500 Switch Front

Figure 2: EX4500 Switch Rear with Intraconnect Module Installed

Chapter 1: EX4500 Switch Overview

Figure 3: EX4500 Switch Rear with Virtual Chassis Module Installed

EX4500 switches are availablein models with either front-toback airflowor back-to-front airflow and hardware that either supports or does not support Data Center Bridging (DCB), also known as Converged Enhanced Ethernet (CEE). See “EX4500 Switch Models”

on page 7. All eight models provide40 wire-speed10-gigabit small form-factorpluggable

(SFP+) network ports that can house either 1-Gigabit Ethernet transceivers or 10-Gigabit Ethernet transceivers. All models support two optional high-speed uplink modules.

To provide carrier-class reliability, EX4500 switches include:

•

Dual redundant, load-sharingpower supplies that are hot-insertableand hot-removable field-replaceable units.

•

An FRU fan tray with five fans. The switch remains operational if a single fan fails.

•

RedundantRouting Engines in a Virtual Chassis configuration. This redundancy enables graceful Routing Engine switchover (GRES).

•

Junos OS with its modular design that enables failed system processes to gracefully restart.

Intraconnect Module and Virtual Chassis Module

EX4500 switches ship with either the intraconnect module or the Virtual Chassis module preinstalled in the switch. Only one of the modules can be installed on the rear side of the switch chassis at a time. Both modules are offline FRUs.

•

Intraconnect module—The intraconnect module helps the switch achieve line rate on all its ports. See “Intraconnect Module in EX4500 Switches” on page 38.

•

Virtual Chassis module—The Virtual Chassis module has two dedicated Virtual Chassis ports (VCPs) that can be used to interconnect the EX4500 switch with EX4200 switches,EX4500 switches, or EX4550 switches to form a Virtual Chassis. See “Virtual

Chassis Module in EX4500 Switches” on page 39.

Complete Hardware Guide for EX4500 Ethernet Switches

NOTE: Operating an EX4500 switch without the intraconnect module or the

Virtual Chassis module is not supported. EX4500 switches running Junos OS Release 10.4R2 or later 10.4 releases will not boot if you do not install the intraconnect module in the switch. EX4500 switches running Junos OS Release 11.1R1 or later releases will not boot if you install neither the intraconnect module nor the Virtual Chassis module in the switch.

NOTE: The VirtualChassis module is supported on EX4500switches in Junos

OS Releases 11.1 and later.

Virtual Chassis

The number of EX4500 switches that can be interconnected into a Virtual Chassis composed exclusively of EX4500 switches depends on the Junos OS release running on the switches. See “Understanding EX4200, EX4500, and EX4550 Virtual Chassis

Hardware Configurations” on page 103.

Uplink Modules

EX4200,EX4500, and EX4550 switches can be connected together into the same Virtual Chassis to form a mixed Virtual Chassis. The number of EX4200, EX4500, and EX4550 switches that can be interconnected into a mixed Virtual Chassis depends on the Junos OS release running on the switches. See “Understanding EX4200, EX4500, and EX4550

Virtual Chassis Hardware Configurations” on page 103.

You can use the following ports to configure an EX4500 switch in a Virtual Chassis composed exclusively of EX4500 switches or in a mixed Virtual Chassis:

•

Dedicated VCPs on the Virtual Chassis module installed in the switch

•

SFP+ uplink module ports configured as VCPs

•

SFP+ fixed network ports configured as VCPs

For information about understanding and configuring VirtualChassis, see EX2200, EX3300, EX4200, EX4500 and EX4550 Virtual Chassis.

Optional uplink modules are available for EX4500 switches. You can install up to two uplink modules in an EX4500 switch. Each uplink module provides four SFP+ ports for connecting to core devices in a data center. You can install SFP or SFP+ transceivers in these ports. You can also configure the uplink module ports as VCPs to form a Virtual Chassis. For more information, see “Uplink Modules in EX4500 Switches” on page 36.

Power Supplies

EX4500 switches support both AC and DC power supplies. Each AC power supply is available in two different airflow models, front-to-back and back-to-front. DC power supplies are available only in the front-to-back airflow model.

Chapter 1: EX4500 Switch Overview

EX4500 switches ship with one AC or DC power supply installed. Youcan install a second AC or DC power supply in your EX4500 switch. See “AC Power Supply in EX4500

Switches” on page 27 and “DC Power Supply in EX4500 Switches” on page 30.

CAUTION: Mixing different types (AC and DC) of power supplies or power

supplies with front-to-back and back-to-front airflow in the same chassis is not supported.

Documentation

EX4500 Switch Models on page 7•

• Field-Replaceable Units in EX4500 Switches on page 23

• EX Series Virtual Chassis Overview

EX4500 Switch Models

The EX4500 switch is available in eight models. Table 3 on page 7 lists the models for an EX4500 switch and their port configurations, the airflow direction in each model, the components included in each model, and the Junos OS release in which the models were introduced.

NOTE: The side of the switch where the networkports are locatedis the front

of the switch.

Table 3: EX4500 Switch Models, Components, and Supported Junos OS Release

Port ConfigurationModel

•

EX4500-40F-FB

Front-to-back40-port GbE/10GbE SFP/SFP+

Chassis

•

One fan tray (with green exhaust label visible)

•

One AC power supply (with green ejector lever)

•

One power cord

•

One power supply cover panel

•

Two uplink module cover panels

•

One intraconnect module

First Junos OS ReleaseSwitch ComponentsDirection of Airflow

10.2R1

Complete Hardware Guide for EX4500 Ethernet Switches

Table 3: EX4500 Switch Models, Components, and Supported Junos OS Release (continued)

EX4500-40F-BF

EX4500-40F-FB-C (supports Data Center Bridging (DCB), also known as Converged Enhanced Ethernet (CEE))

Port ConfigurationModel

GbE/10GbE SFP/SFP+

First Junos OS ReleaseSwitch ComponentsDirection of Airflow

•

Back-to-front40-port

Chassis

•

One fan tray (with orange

10.2R1

intake label visible)

•

One AC power supply (with orange ejector lever)

•

One power cord

•

One power supply cover panel

•

Two uplink module cover panels

•

One intraconnect module

•

Front-to-back40-port

Chassis

•

One fan tray (with green

10.3R1

exhaust label visible)

•

One AC power supply (with green ejector lever)

•

One power cord

•

One power supply cover panel

•

Two uplink module cover panels

•

One intraconnect module

EX4500-40F-BF-C (supports DCB)

EX4500-40F-DC-C (supports DCB)

GbE/10GbE SFP/SFP+

•

Back-to-front40-port

Chassis

•

One fan tray (with orange

10.3R1

intake label visible)

•

One AC power supply (with orange ejector lever)

•

One power cord

•

One power supply cover panel

•

Two uplink module cover panels

•

One intraconnect module

•

Front-to-back40-port

Chassis

•

One fan tray (with green

10.3R2

exhaust label visible)

•

One DC power supply (with green ejector lever)

•

One power supply cover panel

•

Two uplink module cover panels

•

One intraconnect module

Chapter 1: EX4500 Switch Overview

Table 3: EX4500 Switch Models, Components, and Supported Junos OS Release (continued)

EX4500-40F-VC1-FB (supports DCB)

EX4500-40F-VC1-BF (supports DCB)

Port ConfigurationModel

GbE/10GbE SFP/SFP+

First Junos OS ReleaseSwitch ComponentsDirection of Airflow

•

Front-to-back40-port

Chassis

•

One fan tray (with green

11.1R1

exhaust label visible)

•

One AC power supply (with green ejector lever)

•

One power cord

•

One power supply cover panel

•

Two uplink module cover panels

•

One Virtual Chassis module

•

Back-to-front40-port

Chassis

•

One fan tray (with orange

11.1R1

intake label visible)

•

One AC power supply (with orange ejector lever)

•

One power cord

•

One power supply cover panel

•

Two uplink module cover panels

•

One Virtual Chassis module

EX4500-40F-VC1-DC (supports DCB)

GbE/10GbE SFP/SFP+

•

Front-to-back40-port

Chassis

•

One fan tray (with green

11.1R1

exhaust label visible)

•

One DC power supply (with green ejector lever)

•

One power supply cover panel

•

Two uplink module cover panels

•

One Virtual Chassis module

NOTE: EX4500 switches that have the label VIRTUAL CHASSIS on the front

panel support DCB (also known as CEE).

NOTE: Uplink modules, transceivers, Virtual Chassis cables, and Virtual

Chassis cable connector retainers are not part of the EX4500 switch’s shipping configuration. If you want to purchase any of these, or additional power supplies for your switch, you must order them separately.

Complete Hardware Guide for EX4500 Ethernet Switches

CAUTION: Mixing different types (AC and DC) of power supplies or power

supplies with front-to-back and back-to-front airflow in the same chassis is not supported.

Documentation

Chassis Physical Specifications for EX4500 Switches on page 11•

• Front Panel of an EX4500 Switch on page 12

• Rear Panel of an EX4500 Switch on page 13

• EX4500 Switches Hardware Overview on page 3

Identifying EX4500 Switch Models

Purpose Identify the model number of your EX4500 switch.

Action Check the value of the Routing Engine (FRU Model Number) field in the output of the

show chassis hardware extensive CLI command.

user@switch> show chassis hardware extensive

....

Routing Engine 0 REV 00D 750-026816 DE0210022651 EX4500-40F Jedec Code: 0x7fb0 EEPROM Version: 0x02 P/N: 750-026816 S/N: DE0210022651 Assembly ID: 0x095a Assembly Version: 05.00 Date: 01-21-2010 Assembly Flags: 0x00 Version: REV 00D CLEI Code: COMUX00CRA ID: EX4500-40F FRU Model Number: EX4500-40F-FB

....

The model number of your switch is one of the following:

Meaning The FB or the BF in the model number indicates the direction of airflow in the chassis:•

• EX4500-40F-FB

• EX4500-40F-BF

• EX4500-40F-FB-C

• EX4500-40F-BF-C

• EX4500-40F-DC-C

• EX4500-40F-VC1-FB

• EX4500-40F-VC1-BF

• EX4500-40F-VC1-DC

• FB—Front-to-back airflow

Chapter 1: EX4500 Switch Overview

• BF—Back-to-front airflow

• The C in the model number indicates that the switch supports Data Center Bridging

(DCB), also known as Converged Enhanced Ethernet (CEE). The absence of C in the model number of switches thatdo not support Virtual Chassis indicates that the switch does not support DCB.

NOTE: All models of EX4500 switches that support Virtual Chassis

(switchesthat have the label VIRTUALCHASSIS on the front panel) support DCB even though their model numbers do not have a C appended.

• The DC in the model number indicates that the switch model supports DC power

supply.

• The VC in the model number indicates that the switch model can be used in a Virtual

Chassis configuration.

NOTE: All EX4500 switch models can be used in a Virtual Chassis

configuration if you have installed the Virtual Chassis module.

EX4500 Switch Models on page 7•

Documentation

Chassis Physical Specifications for EX4500 Switches

The EX4500 switch chassis is a rigid sheet-metal structure that houses the other switch components. Table 4 on page 11 summarizes the physical specifications of the EX4500 switch chassis.

Table 4: Physical Specifications of the EX4500 Switch Chassis

ValueDescription

3.5 in. (8.9 cm)Chassis height

•

Chassis width

17.25 in. (43.82 cm)

•

The outer edges of the front-mounting brackets extend the width to 19 in. (48.3 cm).

•

21.1 in. (53.6 cm)Chassis depth

Weight

•

EX4500 switch with 1 AC power supply: 37 lb (17 kg)

•

AC power supply: 3 lb (1.3 kg)

•

DC power supply: 3 lb (1.3 kg)

g020800

0 2

1 3

0 1 2 3

ST ST

0 1 2 3

4 6

5 7

8 10

9 11

12 14

13 15

16 18

17 19

20 22

21 23

24 26

25 27

28 30

29 31

32 34

33 35

36 38

CON

MGMT

37 39

Network ports Management port

Enter button

Console port

USB port

ESD point

LCD panel

Chassis status LEDs

Menu button

0 2

1 3

Upper port numbers

Lower port numbers

0, 2, 4, 6.... 38

1, 3, 5, 7.... 39

Complete Hardware Guide for EX4500 Ethernet Switches

You can mount an EX4500 switch on a standard 19-in. two-post rack. You can also mount an EX4500 switch on a standard 19-in. four-post rack or in a standard 19-in. enclosed cabinet.

Documentation

Rack Requirements for EX4500 Switches on page 85•

• Cabinet Requirements for EX4500 Switches on page 86

• Mounting an EX4500 Switch on page 114

• Installing and Connecting an EX4500 Switch on page 111

• Installing and Removing EX4500 Switch Hardware Components on page 121

Front Panel of an EX4500 Switch

The front panel of an EX4500 switch consists of the following components:

•

40 SFP+ network ports

•

Network port LEDs

•

Two slots for installing uplink modules—Installing uplink modules is optional.

•

LCD panel and the LCD navigation buttons

•

Chassis status LEDs

•

Console port

•

Management port

•

Management port LEDs

•

USB port

•

ESD point

Figure 4 on page 12 shows the front panel of an EX4500 switch.

Figure 4: EX4500 Switch Front Panel

g020857

0 2

1 3

0 1 2 3

ST ST

0 1 2 3

4 6

5 7

8 10

9 11

12 14

13 15

16 18

17 19

20 22

21 23

24 26

25 27

28 30

29 31

32 34

33 35

36 38

CON

MGMT

37 39

Chapter 1: EX4500 Switch Overview

EX4500 switches that have the label VIRTUAL CHASSIS on the front panel support Data Center Bridging (DCB), also known as Converged Enhanced Ethernet (CEE). See

Figure 5 on page 13.

Figure 5: Label Identifying EX4500 Switches that Support DCB

Documentation

Rear Panel of an EX4500 Switch on page 13•

• LCD Panel in EX4500 Switches on page 17

• Chassis Status LEDs in EX4500 Switches on page 22

• Network Port and Uplink Module Port LEDs in EX4500 Switches on page 24

• Uplink Modules in EX4500 Switches on page 36

• Pluggable Transceivers Supported on EX4500 Switches on page 49

• Installing and Removing EX4500 Switch Hardware Components on page 121

Rear Panel of an EX4500 Switch

The rear panel of the EX4500 switch consists of the following components:

•

Power supply or power supplies

•

One of the following:

•

AC appliance inlet and AC power supply LED

•

DC terminal block and DC power supply LED

•

Fan tray

•

One of the following:

•

Intraconnect module

•

Virtual Chassis module

g020801

EX4500-LB

Fan tray

AC power supply LEDs

Fan tray handles

AC appliance

inlets

AC power supplies

Intraconnect module

Complete Hardware Guide for EX4500 Ethernet Switches

NOTE: Operating an EX4500 switchwithout the Intraconnect module or the

Virtual Chassis module installed is not supported. EX4500 switches running Junos OS Release 10.4R2 or later will not boot if either the Intraconnect or the Virtual Chassis module is not installed in the switch chassis.

NOTE: The protective earthing terminal is located on the left side of the

chassis. See “Connecting Earth Ground to an EX Series Switch” on page 137.

Figure 6 on page 14 shows the rear panel of an EX4500 switch with AC power supplies

and Intraconnect module installed.

Figure 6: EX4500 SwitchRear Panel with an Intraconnect Module Installed

Documentation

Figure 7 on page 14 shows the rear panel of an EX4500 switch with AC power supplies

and a Virtual Chassis module installed.

Figure 7: EX4500 Switch Rear Panel with a Virtual Chassis Module Installed

Front Panel of an EX4500 Switch on page 12•

• Cooling System and Airflow in an EX4500 Switch on page 32

Chapter 1: EX4500 Switch Overview

• AC Power Supply in EX4500 Switches on page 27

• DC Power Supply in EX4500 Switches on page 30

• Intraconnect Module in EX4500 Switches on page 38

• Virtual Chassis Module in EX4500 Switches on page 39

• Installing and Removing EX4500 Switch Hardware Components on page 121

EX4500 Switch Hardware and CLI Terminology Mapping

This topic describes the hardware terms used in EX4500 switch documentation and the corresponding terms used in the Junos OS command line interface (CLI). See

Table 5 on page 15.

Table 5: CLI Equivalents of Terms Used in Documentation for EX4500 Switches

Hardware Item (CLI)

PIC (n)

Description (CLI)

Abbreviated name of the Physical Interface Card (PIC)

module (EX4500 LB)

n is a value in the range of 0–3.

PIC 040x 1/10GE

PIC 14x XE SFP+

PIC 24x XE SFP+

Switch chassis–EX4500-40FChassis

The switch does not have actual PIC devices; see entries for PIC 0 through PIC 3 for the equivalent item on the switch.

Built-in network ports on the front panel of the switch

Uplink module installed in the left slot on the front panel of the switch

Uplink module installed in the right slot on the front panel of the switch

Intraconnect modulePIC 3Intraconnect

Additional InformationItem In DocumentationValue (CLI)

“Chassis Physical Specifications for EX4500 Switches” on page 11

Understanding Interface Naming Conventions on EX Series Switches

“Front Panel of an EX4500 Switch” on page 12

“Uplink Modules in EX4500 Switches” on page 36

“Intraconnect Module in EX4500 Switches” on page 38

module

Virtual Chassis modulePIC 3Virtual Chassis

“Virtual Chassis Module in EX4500 Switches” on page 39

Complete Hardware Guide for EX4500 Ethernet Switches

Table 5: CLI Equivalents of Terms Used in Documentation for EX4500 Switches (continued)

Hardware Item (CLI)

Xcvr (n)

Power supply (n)

Fan tray

Description (CLI)

Abbreviated name of the transceiver

One of the following:

•

PS 1000W /1200W AC Front-to-back airflow

•

PS 1000W /1200W AC Back-to-front airflow

•

PS 1000W /1200W DC Front-to-back airflow

following:

•

Fan tray, front-to-back airflow

•

Fan tray, back-to-front airflow

number of the port in which the transceiver is installed.

n is a value in the range of 0–1. The value corresponds to the power supply slot number.

NOTE: Mixing differenttypes

(AC and DC) of power supplies or power supplies with front-to-back and back-to-front airflow in the same chassis is not supported.

Optical transceiversn is a value equivalent to the

AC power supply or DC power supply

Fan tray–One of the

Additional InformationItem In DocumentationValue (CLI)

“Pluggable Transceivers Supported on EX4500 Switches” on page 49

•

AC Power Supply in EX4500 Switches on page 27

•

DC Power Supply in EX4500 Switches on page 30

“Cooling Systemand Airflow in an EX4500 Switch” on page 32

Documentation

• EX Series Switches Hardware and CLI Terminology Mapping

• EX4500 Switches Hardware Overview on page 3

CHAPTER 2

Component Descriptions

•

LCD Panel in EX4500 Switches on page 17

•

Chassis Status LEDs in EX4500 Switches on page 22

•

Field-Replaceable Units in EX4500 Switches on page 23

•

Network Port and Uplink Module Port LEDs in EX4500 Switches on page 24

•

Management Port LEDs in EX4500 Switches on page 26

•

AC Power Supply in EX4500 Switches on page 27

•

AC Power Supply LEDs in EX4500 Switches on page 29

•

DC Power Supply in EX4500 Switches on page 30

•

DC Power Supply LEDs in EX4500 Switches on page 32

•

Cooling System and Airflow in an EX4500 Switch on page 32

•

Uplink Modules in EX4500 Switches on page 36

•

Intraconnect Module in EX4500 Switches on page 38

•

Virtual Chassis Module in EX4500 Switches on page 39

LCD Panel in EX4500 Switches

The LCD panel on the front panel of EX4500 switch shows two lines of text, each that can contain a maximum of 16 characters. The LCD panel displays a variety of information about the switch and also provides a menu to perform basic operations such as initial setup and reboot.

There are two navigation buttons—Menu and Enter—to the right of the LCD panel.

See Figure 8 on page 17.

Figure 8: LCD Panel in EX4500 Switches

Complete Hardware Guide for EX4500 Ethernet Switches

You can configure the second line of the LCD panel to display a custom message. If the LCD panel is configured to display a custom message, the Menu button and the Enter button are disabled.See Configuring the LCD Panel on EX Series Switches (CLI Procedure).

The LCD panel has a backlight. If the LCD panel remains idle for 60 seconds, the backlight turns off. You can turn on the backlight by pressing the Menu or Enter button once. After turning on the backlight, you can toggle between the LCD panel menus by pressing the Menu button and navigate through the menu options by pressing the Enter button.

NOTE: The chassis viewer in the J-Web interface also displaysthe LCDpanel.

From the J-Web interface, you can view real-time status information in the LCD panel. See Dashboard for EX Series Switches.

This topic describes:

•

LCD Panel Modes on page 18

•

LCD Panel Menus on page 19

LCD Panel Modes

The LCD panel operates in four modes: boot, idle, status, and maintenance.

The LCD panel operates in boot mode during switch reboot. The boot mode displays the key milestones in the switch boot process. The boot mode does not have any menu options. After the boot process is complete, the LCD panel automatically reverts to the Idle menu.

The first line of text on the LCD panel displays the slot number, the role of the switch, and hostname. For a standalone EX4500 switch, the slot number is always 00, and the role is always RE.

In an EX4500 switch that is a member of a Virtual Chassis, the first line of the LCD panel displays:

•

The slot number (the member ID for the Virtual Chassis member)

•

Roleof the switch in a Virtual Chassis (RE for master, BK for backup, and LCfor linecard member)

•

Hostname

In the idle mode, the second line of text on the LCD panel displays the mode of the network ports’ Status LED and the number of chassis alarms. The number of alarms is updated every second.

In the status mode, the second line displays:

•

Virtual Chassis port (VCP) status (supported only on EX4500 switches in a Virtual Chassis configuration running Junos OS Release11.1 or later.This option is not supported on standalone EX4500 switches.)

•

Status of the power supplies

LCD Panel Menus

Chapter 2: Component Descriptions

•

Status of the fans in the fan tray and the chassis temperature

•

Version of Junos OS for EX Series switches loaded on the switch

In the maintenance mode, the second line displays one of the following options that you can use to configure and troubleshoot the switch:

•

System halt

•

System reboot

•

Load rescue

•

RequestVC port (supported only on EX4500 switches in a Virtual Chassis configuration running Junos OS Release 11.1 or later. This option is not supported on standalone EX4500 switches.)

•

Factory default

•

EZSetup

The LCD panel has three menus: Idle, Status, and Maintenance. You can toggle between the LCD panel menus by pressing the Menu button and navigate through the menu options by pressing the Enter button.

Table 6 on page 19 describes the LCD panel menu options.

Table 6: LCD Panel Menu Options in EX4500 Switches

DescriptionMenu

IDLE

In the Idle menu:

•

Press Enter to cycle through the Status LED modes, which are port status indicators:

•

ADM (administrative status)

•

DPX (duplex)

•

SPD (speed)

See “Network Port and Uplink Module Port LEDs in EX4500 Switches”on page 24 for information on the Status LED modes.

•

Press Menu to exit the Idle menu and go to the Status menu.

Complete Hardware Guide for EX4500 Ethernet Switches

Table 6: LCD Panel Menu Options in EX4500 Switches (continued)

DescriptionMenu

STATUS

The Status menu has the following options:

•

Show VCP status—Choose one of the following:

•

Press the Enter button to display the Virtual Chassis port (VCP) status: Up,

Down.

NOTE: This option is supported only on EX4500 switches in a Virtual Chassis

configuration running Junos OS Release 11.1 or later.

This option is not supported on standalone EX4500 switches.

•

Press the Menu button to go to the next option in the Status menu.

•

Show PSU Status—Choose one of the following:

•

Press Enter to display the status of power supplies: OK, Fld (Failed), ABS

(Absent).

•

Press Menu to go to the next option in the Status menu.

•

Show Environment Status—Choose one of the following:

•

Press Enter to display the status of the fan tray and the chassis temperature:

•

Fan tray status: OK, Fld, ABS

•

Chassis temperature status: OK, High, Shutdown

•

Press Menu to go to the next option in the Status menu.

•

Show Junos Version Status—Choose one of the following: .

•

Press Enter to display the version of Junos OS for EX Series switches loaded

on the switch.

•

Press Menu to go to the next option in the Status menu.

•

EXIT STAT MENU?—Choose one of the following:

•

Press Enter to exit the Status menu.

•

Press Menu to return to the Show VCP Status option.

You can disable the Status menu or the options in the Status menu in the LCD panel. See Configuring the LCD Panel on EX Series Switches (CLI Procedure).

Table 6: LCD Panel Menu Options in EX4500 Switches (continued)

DescriptionMenu

Chapter 2: Component Descriptions

MAINT (Maintenance Menu)

The Maintenance menu has the following options to configure and troubleshoot the switch:

•

SYSTEM HALT?—Choose one of the following:

•

Press Enter to halt the switch. Press Enter again to confirm the halt.

•

Press Menu to go to the next option in the Maintenance menu.

•

SYSTEM REBOOT?—Choose one of the following:

•

Press Enter to reboot the switch. Press Enter again to confirm the reboot.

•

Press Menu to go to the next option in the Maintenance menu.

•

LOAD RESCUE?—Choose one of the following:

•

Press Enter to roll back the switch to the previous valid configuration. Press

Enter again to confirm the rollback.

•

Press Menu to go to the next option in the Maintenance menu.

•

REQUEST VC PORT?—Choose one of the following:

•

Press the Enter button to configure an uplink module port or a network port

to be a Virtual Chassis port (VCP) or to delete a VCP from the switch

configuration (when you delete the VCP, the port is reset to an uplink module

port or network port).

NOTE: This option is supported only on EX4500 switches in a Virtual Chassis

configuration running Junos OS Release 11.1 or later.

This option is not supported on standalone EX4500 switches.

•

Press the Menu button to go to the next option in the Maintenance menu.

•

FACTORY DEFAULT?—Choose one of the following:

•

Press Enter to restore the switch to the factory default configuration. Press

Enter again to confirm the restoration. The LCD panel flashes a success or

failure message and returns to the Idle menu.

•

Press Menu to go to the next option in the Maintenance menu.

•

ENTER EZSETUP?—Choose one of the following:

•

Press Enter to launch EZSetup. Press Enter again to confirm the launch.

EZSetupconfiguresDHCP and enables the J-Web user interfaceon the switch.

The LCD panel flashes a success or failure message for approximately 10

seconds and returns to the Idle menu.

NOTE: You can use EZSetup only on a standalone switch that is in the factory

default configuration.

For information about EZSetup, see “Connectingand Configuring an EX Series

Switch (J-Web Procedure)” on page 164.

•

Press Menu to go to the next option in the Maintenance menu.

•

EXIT MAINT MENU?—Choose one of the following:

•

Press Enter to exit the Maintenance menu.

•

Press Menu to return to the SYSTEM HALT option.

You can disable the Maintenance menu or the options in the Maintenance menu in the LCD panel. See Configuring the LCD Panel on EX Series Switches (CLI Procedure).

Complete Hardware Guide for EX4500 Ethernet Switches

Documentation

Front Panel of an EX4500 Switch on page 12•

• Field-Replaceable Units in EX4500 Switches on page 23

• Connecting and Configuring an EX Series Switch (CLI Procedure) on page 161

• Connecting and Configuring an EX Series Switch (J-Web Procedure) on page 164

Chassis Status LEDs in EX4500 Switches

The front panel of an EX4500 switch has three chassis status LEDs (labeled ALM, SYS, and MST) on the far right side of the panel, next to the Menu and Enter buttons (see

Figure 9 on page 22).

Figure 9: Chassis Status LEDs in an EX4500 Switch

Table 7 on page 22 describes the chassis status LEDs in an EX4500 switch, their colors

and states, and the status they indicate. You can view the colors of the three LEDs remotely through the CLI by issuing the operational mode command show chassis led.

Table 7: Chassis Status LEDs in an EX4500 Switch

State and DescriptionColorLED Label

There is no alarm or the switch is halted.UnlitALM (Alarm)

There is a major alarm.Red

There is a minor alarm.Amber

GreenSYS (System)

GreenMST (Master)

•

In a standalone EX4500 switch:

•

In a Virtual chassis configuration:

•

On steadily—Junos OS for EX Series switches has been loaded on the switch.

Blinking—The switch is booting. Off—The switch is powered off or is halted.

On steadily—The switch is functioning normally. Off—The switch is powered off or is halted.

On steadily—The switch is the master in the Virtual Chassis configuration.

Blinking—The switch is the backup in the Virtual Chassis configuration.

Off—The switch is a linecard member in the Virtual Chassis configuration or is halted.

Chapter 2: Component Descriptions

A major alarm (red) indicates a critical error condition that requires immediate action.

A minor alarm (amber) indicates a noncritical condition that requires monitoring or maintenance. A minor alarm that is left unchecked might cause interruption in service or performance degradation.

All three LEDs can be lit simultaneously.

Documentation

Front Panel of an EX4500 Switch on page 12•

• Checking Active Alarms with the J-Web Interface

• Understanding Alarm Types and Severity Levels on EX Series Switches

Field-Replaceable Units in EX4500 Switches

Field-replaceable units (FRUs) are components that you can replace at your site. The FRUs in EX4500 switches are:

•

Power supplies

•

Fan tray

•

Uplink module(s)

•

Intraconnect module

•

Virtual Chassis module

•

SFP+ transceivers

•

SFP transceivers

NOTE: Uplink modules, transceivers, Virtual Chassis cables, and Virtual

Chassis cable connector retainers are not part of the standard package and must be ordered separately.

The power supplies, fan tray, uplink module(s), and transceivers are hot-removable and hot-insertable: You can remove and replace them without powering off the switch or disrupting switch functions.

The Intraconnect module and Virtual Chassis module are offline field-replaceable: You can remove and replace these components, but the switch must be powered off to replace the component.

g020802

0 2

1 3

0 21 3 ST 0 21 3 ST

4 6

5 7

8 10

9 11

12 14

13 15

16 18

17 19

20 22

21 23

24 26

25 27

28 30

29 31

32 34

33 35

36 38

CON

MGMT

37 39

Status lower port

Status upper port

Link/Activity lower port

Link/Activity upper port

Complete Hardware Guide for EX4500 Ethernet Switches

NOTE: If you have a Juniper J-Care service contract, register any addition,

change, or upgrade of hardware components at

https://www.juniper.net/customers/csc/management/updateinstallbase.jsp .

Failureto do so can resultin significant delays if you need replacement parts. This note applies if you change the type of power supply or add a new type of uplink module. It does not apply if you replace these components with the same type of component.

Installing and Removing EX4500 Switch Hardware Components on page 121•

Documentation

Network Port and Uplink Module Port LEDs in EX4500 Switches

Each network port and uplink module port on an EX4500 switch has two LEDs that indicatelink/activity and status. The figures in this topic show the location of these LEDs:

•

Figure 10 on page 24 shows the location of the LEDs on the network ports on the front

panel of an EX4500 switch. The LEDs point toward the port to which the LEDs belong.

•

Figure 11 on page 25 shows the location of the LEDs on the uplink module ports on the

SFP+ uplink module.

Figure 10: Network Port LEDs

g020803

Link/Activity

LED

Status LED

Chapter 2: Component Descriptions

Figure 11: Uplink Module Port LEDs

The LEDs labeled Link/Activity LED in Figure 10 on page 24 and Figure 11 on page 25 indicate link activity.

Table 8 on page 25 describes the Link/Activity LED.

Table 8: Link/Activity LED on Network Ports and Uplink Module Ports in EX4500 Switches

State and DescriptionColorLED

•

GreenLink/Activity

The Status LED in Figure 10 on page 24 and Figure 11 on page 25 indicate the status of one of the three port parameters. The port parameters are administrative status, duplex mode, and speed.

Table 9 on page 26 describes the Status LED on network ports and uplink module ports

in EX4500 switches. From the Idle menu of the LCD, use the Enter button on the LCD panel to toggle between the ADM, DPX, and SPD indicators.

Blinking—The port and the link are active, and there is link activity.

•

On steadily—The port and the link are active, but there is no link activity.

•

Off—The port is not active.

g020805

36 38

CON

MGMT

37 39

Management

port

Link/Activity

LED

Status

LED

MGMT

Complete Hardware Guide for EX4500 Ethernet Switches

Table 9: Status LED on Network Ports and Uplink Module Ports in EX4500 Switches

State and DescriptionLCD IndicatorLED

Documentation

LED: ADMStatus

Indicates the administrative status (enabled or disabled).

The status indicators are:

•

Green—Port is administratively enabled.

•

Unlit—Port is administratively disabled.

LED: DPX

Indicates the duplex mode.

The status indicators for network ports on the front panel are:

•

Green—Port is set to full-duplex mode.

•

Unlit—Port is set to half-duplex mode.

The uplink module ports are always set to full-duplex mode; therefore, the LED is always green.

LED: SPD

Indicates the speed.

The speed indicators are:

•

Blinking green—1 Gbps

•

Steadily green—10 Gbps

Front Panel of an EX4500 Switch on page 12•

• Uplink Modules in EX4500 Switches on page 36

Management Port LEDs in EX4500 Switches

The management port on the front panel of an EX4500 switch has two LEDs that indicate link/activity and port status (see Figure 12 on page 26).

Figure 12: LEDs on the Management Port on an EX4500 Switch

Table 10 on page 27 describes the Link/Activity LED.

Chapter 2: Component Descriptions

Table 10: Link/Activity LED on the Management Port on an EX4500 Switch

State and DescriptionColorLED

•

GreenLink/Activity

Blinking—The port and the link are active, and there is link activity.

•

On steadily—The port and the link are active, but there is no link activity.

•

Off—The port is not active.

Table 11 on page 27 describes the Status LED.

Table 11: Status LED on the Management Port on an EX4500 Switch

State and DescriptionColorLED

GreenStatus

Documentation

Front Panel of an EX4500 Switch on page 12•

• Connecting a Switch to a Network for Out-of-Band Management on page 149

AC Power Supply in EX4500 Switches

The AC power supply in EX4500 switches is a hot-insertable and hot-removable field-replaceable unit (FRU): You can install it without powering off the switch or disrupting the switching function.

EX4500 switches ship with an AC power supply that gives an output of 1000 W at low-voltage line (100–120 VAC) and 1200 W at high-voltage line (200–240 VAC). You can install a second power supply in the switch too.

Powersupplies are installed at the rear of the chassis in slots labeled 1 and 0. Both power supplies are accessible from the rear of the chassis.

Indicates the speed. The speed indicators are:

•

One blink per second—10 Mbps

•

Two blinks per second—100 Mbps

•

Three blinks per second—1000 Mbps

WARNING: The switch is pluggable type A equipment installed in a

restricted-access location. It has a separate protective earthing terminal provided on the chassis in addition to the grounding pin of the power supply cord. This separate protective earthing terminal must be permanently connected to earth ground. See “Connecting Earth Ground to an EX Series

Switch” on page 137

Each AC power supply weighs approximately 3 lb (1.3 kg) and has an independent 12 A ratedAC appliance inlet on its front. Each inlet requires a dedicated AC power feed. Each

g020808

Ejector lever

Power supply LED

Power supply handle

AC appliance inlet

g020852

Retainer clip

Adjustment nut

Complete Hardware Guide for EX4500 Ethernet Switches

AC power supply has a fan, a bicolor LED on the faceplate that indicates the status of the power supply, and a colored ejector lever. See Figure 13 on page 28.

Figure 13: AC Power Supply

Each AC power supply has an ejector lever that holds the power supply in place. The ejector lever locks into the corresponding hole in the chassis on the left side of the AC appliance inlet. For instructions for installing the power supply, see “Installing an AC

Power Supply in an EX4500 Switch” on page 122.

Each AC power supply comes with a power cord retainer that holds the power cord in place. See Figure 14 on page 28. The power cord retainer has a clip and an adjustment nut. The L-shaped ends of the retainer clip hook into the bracket holes on each side of the AC appliance inlet. The adjustment nut holds the power cord in the correct position. For instructions for installing the power cord retainer, see “Installing an AC Power Supply

in an EX4500 Switch” on page 122.

Figure 14: Power Cord Retainer for an AC Power Supply

Each power supply has its own fan and is cooled by its own internal cooling system. The airflow for a power supply is either from the front of the power supply to the back or from the back of the power supply to the front depending on the switch model you purchase.

The color of the ejector lever on the power supply indicates the direction of airflow of the power supply.

•

Green—Front-to-back airflow

•

Orange—Back-to-front airflow

g020809

AC power supply LEDs

Chapter 2: Component Descriptions

The color of the power supply's ejector lever must match the color of the intake or exhaust label visible through the vents of the installed fan tray. The color match indicates that the direction of airflow through the fan tray matches the direction of airflow through the power supply.

CAUTION: Verify that the direction of airflow through the power supply

matches the direction of airflow through the fan tray to prevent overheating of the chassis.

Each AC power supply provides power to all components in the switch. The two power supplies provide full power redundancy to the switch. If one power supply fails or is removed, the second power supply balances the electrical load without interruption. The switch reassesses the power required to support the switch configuration and issues error messages if the available power is insufficient.

Documentation

Installing an AC Power Supply in an EX4500 Switch on page 122•

• AC Power Supply Specifications for EX4500 Switches on page 95

• AC Power Supply LEDs in EX4500 Switches on page 29

AC Power Supply LEDs in EX4500 Switches

An AC power supply has one bicolor LED on its faceplate. This LED displays information about the status of the power supply. See Figure 15 on page 29.

Figure 15: AC Power Supply LEDs in EX4500 Switches

Table 12 on page 30 describes the LED on an AC power supply in an EX4500 switch.

Complete Hardware Guide for EX4500 Ethernet Switches

Table 12: Power Supply LED on EX4500 Switches

DescriptionLED State

Unlit

Green

Amber

Documentation

AC Power Supply Specifications for EX4500 Switches on page 95•

• AC Power Cord Specifications for an EX4500 Switch on page 96

• Connecting AC Power to an EX4500 Switch on page 143

Indicates one of the following:

•

Power supply is disconnected from AC power feed.

•

AC power input voltage is not within normal operating range.

•

No AC power input.

•

On steadily—Power supply is functioning normally.

•

Blinking—Power supply has failed.

•

On steadily—Power supply has failed.

•

Blinking—Power supply has failed.

DC Power Supply in EX4500 Switches

The DC power supply in EX4500 switches is a hot-insertable and hot-removable field-replaceable unit (FRU).

EX4500 switches are shipped with one power supply. A cover panel is installed in the second power supply slot. You can add a second power supply to the switch.

Powersupplies are installed at the rear of the chassis in slots labeled 1 and 0. Both power supplies are accessible from the rear of the chassis.

WARNING: The switch is pluggable type A equipment installed in a

Switch” on page 137.

Each DC power supply weighs approximately 3 lb (1.3 kg) and has a pair of DC input lugs (–48 VDC and RTN) on the front of the power supply. Each DC power supply also has a fan, a bicolor LED on the faceplate that indicates the status of the power supply, and a colored ejector lever. See Figure 16 on page 31.

Figure 16: DC Power Supply

g020858

Ejector lever

Power supply LED

Power supply handle

DC terminal block

NOTE: A 1200 W DC power supply requires a dedicated 30 A circuit breaker

for the input DC feed.

Chapter 2: Component Descriptions

Each DC power supply has an ejector lever that holds the power supply in place. The ejectorleverlocks into the correspondinghole in the chassis. For instructions for installing the power supply, see “Installing a DC Power Supply in an EX4500 Switch” on page 124.

Each power supply has its own fan and is cooled by its own internal cooling system. The airflow for a power supply is from the front of the power supply to the back.

The color of the ejector lever on the power supply indicates the direction of airflow of the power supply.

•

Green—Front-to-back airflow

The color of the power supply's ejector lever must match the color of the exhaust label visible through the vents of the installed fan tray. The color match indicates that the direction of airflow through the fan tray matches the direction of airflow through the power supply.

CAUTION: Verify that the direction of airflow through the power supply

matches the direction of airflow through the fan tray to prevent overheating of the chassis.

Each DC power supply provides power to all components in the switch. Two power supplies provide full power redundancy to the switch. If one power supply fails or is removed, the second power supply balances the electrical load without interruption. The switch reassesses the power required to support the switch configuration and issues error messages if the available power is insufficient.

The output for the DC power supply is 12 VDC. The output power is 1200 W.

g020859

DC power supply LED

Complete Hardware Guide for EX4500 Ethernet Switches

Documentation

Installing a DC Power Supply in an EX4500 Switch on page 124•

• DC Power Specifications for EX4500 Switches on page 96

• DC Power Supply LEDs in EX4500 Switches on page 32

DC Power Supply LEDs in EX4500 Switches

A DC power supply has one bicolor LED (labeled POK) on its faceplate.This LED displays information about the status of the power supply. See Figure 17 on page 32.

Figure 17: DC Power Supply LED in EX4500 Switches

Table 13 on page 32 describes the LED on a DC power supply in an EX4500 switch.

Table 13: DC Power Supply LED on EX4500 Switches

DescriptionLED StateLED

Indicates one of the following:

•

Power supply is disconnected from DC power feed.

•

DC power input voltage is not within normal operating range (–42 VDC through –60 VDC).

•

No DC power input.

•

On steadily—Power supply is functioning normally.

•

Blinking—Power supply has failed.

•

On steadily—Power supply has failed.

•

Blinking—Power supply has failed.

Documentation

UnlitP OK

Green

Amber

DC Power Specifications for EX4500 Switches on page 96•

• Connecting DC Power to an EX4500 Switch on page 145

Cooling System and Airflow in an EX4500 Switch

The cooling system in an EX4500 switch consists of a single fan tray.

Fan Tray

g020812

Fan tray handles

Chapter 2: Component Descriptions

This topic describes:

•

Fan Tray on page 33

•

Airfow Direction in EX4500 Switch Models on page 33

•

Front-to-Back Airflow on page 34

•

Back-to-Front Airflow on page 34

The fan tray is a hot-insertable and hot-removable field-replaceableunit (FRU). The fan tray contains five fans (see Figure 18 on page 33).

Figure 18: Fan Tray Used in an EX4500 Switch

The fan tray installs horizontally in the rear of the chassis. The fan tray has two handles, one on each side that facilitate handling of the fan tray.

You remove and replace the fan tray from the rear of the chassis. The switch continues to operate for a limited time (30 seconds) during the replacementof the fan tray without thermal shutdown.

The fan tray provides front-to-back or back-to-front airflow depending on the switch model you purchase.

NOTE: The side of the switch where the networkports are locatedis the front

of the switch.

Airfow Direction in EX4500 Switch Models

Table 14 on page 33 shows the different EX4500 switch models and their direction of

airflow.

Table 14: Airflow Direction in EX4500 Switch Models

Direction of AirflowModel

Front-to-backEX4500-40F-FB

Back-to-frontEX4500-40F-BF

Front-to-backEX4500-40F-FB- C

Front

Rear

Fans (5)

g020813

Complete Hardware Guide for EX4500 Ethernet Switches

Table 14: Airflow Direction in EX4500 Switch Models (continued)

Direction of AirflowModel

Back-to-frontEX4500-40F-BF-C

Front-to-backEX4500-40F-DC-C

Front-to-backEX4500-40F-VC1-FB

Back-to-frontEX4500-40F-VC1-BF

Front-to-backEX4500-40F-VC1-DC

Front-to-Back Airflow

In the EX4500 switch models that have front-to-back airflow, the air intake to cool the chassis is located on the front of the chassis. Air is pulled into the chassis and pushed towardthe fan tray. Hot air exhausts from the rear of the chassis. See Figure 19 on page 34.

Figure 19: Front-to-Back Airflow Through the EX4500 Switch Chassis

Back-to-Front Airflow

In the EX4500 switch models that have back-to-front airflow, the air intake to cool the chassis is located on the rear of the chassis. Air is pulled into the chassis and pushed away from the fan tray. Hot air exhausts from the front of the chassis. See

Figure 20 on page 35.

Front

Rear

Fans (5)

g020816

Chapter 2: Component Descriptions

Figure 20: Back-to-Front Airflow Through the EX4500 Switch Chassis

Each fan tray has colored intake or exhaust labels that are visible through the fan tray vents. The INTAKE label is orange. The EXHAUST label is green.

NOTE: Only one of the labels, INTAKE or EXHAUST, is visible through the

vents of the installed fan tray.

The color of the label visible through the vents of the installed fan tray must match the color of the ejector lever on the installed power supply. The color match indicates that the powersupply has the correct airflow for this model. See “ACPowerSupply in EX4500

Switches” on page 27.

CAUTION: To prevent overheating of the chassis, verify that the color of the

label visible through the vents of the installed fan tray matches the color of the ejector lever of the installed power supply. A color match indicates that the direction of airflow through the fan tray matches the direction of airflow of the power supply.

Temperature sensors in the chassis monitor the temperature within the chassis. The fan tray used in the switch comes with load-sharing redundancy that can tolerate a single fan failure at room temperature (below 113° F/45° C) to still provide sufficient cooling.

Under normal operating conditions, the fans in the fan tray run at less than full speed. If a fan fails or the ambient temperature rises above the threshold 113° F (45° C), the speed of the remaining fans is automatically adjusted to keep the temperature within the acceptable range, 32° F (0° C) through 113° F (45° C).

The system raises an alarm if the fan fails or if the ambient temperatureinside the chassis rises above the acceptable range. If the temperature inside the chassis rises above the threshold temperature, the system shuts down automatically.

g020856

0 2

1 3

0 1 2 3

ST ST

0 1 2 3

4 6

5 7

8 10

9 11

12 14

13 15

16 18

17 19

20 22

21 23

24 26

25 27

28 30

29 31

32 34

33 35

36 38

CON

MGMT

37 39

Uplink Module (PIC 1)

Uplink Module (PIC 2)

Complete Hardware Guide for EX4500 Ethernet Switches

You can check the status of fans and the chassis temperature from the Environment Statusoption in the Status menu on the LCD panel. See “LCD Panel in EX4500 Switches”

on page 17.

You cannot replace a single fan. If one or more fans fail, you must replace the entire fan tray.

Documentation

Installing a Fan Tray in an EX4500 Switch on page 125•

• Removing a Fan Tray from an EX4500 Switch on page 184

• Field-Replaceable Units in EX4500 Switches on page 23

• Rear Panel of an EX4500 Switch on page 13

• Prevention of Electrostatic Discharge Damage on page 250

Uplink Modules in EX4500 Switches

EX4500 switches support SFP+ uplink modules. The SFP+ uplink module is a hot-insertable and hot-removable field replaceable unit (FRU).

NOTE: Uplink modules and transceivers are not part of the EX4500 switch’s

shipping configuration. You must order them separately.

You can install up to two SFP+ uplink modulesin an EX4500 switch. Both uplink modules install horizontally on the front of the chassis. The uplink module slot on the left is PIC 1. The uplink module slot on the right is PIC 2. See Figure 21 on page 36.

Figure 21: Uplink Module Slots in an EX4500 Switch

Each SFP+ uplink module provides four ports. Each module can house four 10-gigabit small form-factor pluggable (SFP+) transceivers or four 1-gigabit small form-factor pluggable (SFP) transceivers.

NOTE: When a new uplink module is installed in the switch or an existing

uplink module is replaced with another uplink module, the switch detects the newlyinstalled uplink module. The switch creates the required interfaces when new transceivers are installed in those ports.

g020806

Link/Activity

LED

Status LED

Chapter 2: Component Descriptions

Theoperatingmode foran SFP+ uplink moduleis shownin the output of the show chassis

pic fpc-slot slot number pic-slot 1 command.

You can use the uplink module ports to connect an access switch to a distribution switch.

Figure 22 on page 37 shows the SFP+ uplink module.

Figure 22: SFP+ Uplink Module

The SFP+ uplink module has an LED on the faceplate (labeled ST) that indicates the status of the uplink module. See Figure 22 on page 37.

Table 15 on page 37 describes the LED on the uplink module in an EX4500 switch.

Table 15: Uplink Module Status LED

UnlitST

Each uplink module port has a pair of LEDs that indicate the link/activity and status of the port. See “NetworkPort and Uplink Module Port LEDs in EX4500 Switches”on page 24 for details about the uplink module port LEDs.

The SFP+ uplink modules are shipped with dust covers preinstalled in the ports.

The SFP+ uplink modules require Junos OS for EX Series switches, Release 9.4 or later.

Documentation

Network Port and Uplink Module Port LEDs in EX4500 Switches on page 24•

• Network Port and Uplink Module Port Connector Pinout Information for EX4500

Switches on page 45

• Pluggable Transceivers Supported on EX4500 Switches on page 49

• SFP+ Direct Attach Cables for EX Series Switches on page 67

DescriptionStateLED

•

The uplink module is offline.

•

The chassis is powered off.

•

The uplink module is online and functioning normally.Green

• EX Series Switches Interfaces Overview

• Installing an Uplink Module in an EX4500 Switch on page 127

• Removing an Uplink Module from an EX4500 Switch on page 186

g020853

Status LED

Captive screws

Complete Hardware Guide for EX4500 Ethernet Switches

Intraconnect Module in EX4500 Switches

The intraconnect module is installed horizontallyon the rear of an EX4500 switch chassis. The intraconnect module helps the switch achieve line rate on all its ports. The module is an offline field-replaceable unit (FRU).

The intraconnectmodule comes preinstalledin the switch chassis in the EX4500-40F-FB, EX4500-40F-BF, EX4500-40F-FB-C,EX4500-40F-BF-C, and EX4500-40F-DC-C switch models. You must order it separately for all other switch models. See “EX4500 Switch

Models” on page 7.

CAUTION: Operating an EX4500 switch without the intraconnect module

or the Virtual Chassis module is not supported. EX4500 switches running Junos OS Release 10.4R2 or later 10.4 releases will not boot if you do not install the intraconnect module in the switch. EX4500 switches running Junos OS Release 11.1R1 or later releases will not boot if you install neither the intraconnect module nor the Virtual Chassis module in the switch.

Figure 23 on page 38 shows the intraconnect module.

Figure 23: Intraconnect Module

The intraconnect module has an LED (labeled ST) on the faceplate that indicates the status of the intraconnect module.

Table 16 on page 38 describes the LED on the intraconnect module in an EX4500 switch.

Table 16: Intraconnect Module Status LED

GreenST

Unlit

DescriptionStateLED

The intraconnect module is functioning normally.

•

The intraconnect module is not functioning normally.

•

The switch has been powered off.

The intraconnect module has two captive screwson the faceplate that secure the module in the chassis. To remove or replace the intraconnect module, follow the instructions in

“Removing an Intraconnect Module from an EX4500 Switch” on page 188.

g021032

Chapter 2: Component Descriptions

Documentation

Rear Panel of an EX4500 Switch on page 13•

• Field-Replaceable Units in EX4500 Switches on page 23

• Installing an Intraconnect Module in an EX4500 Switch on page 129

Virtual Chassis Module in EX4500 Switches

The Virtual Chassis module is installed horizontallyon the rear panel of an EX4500 switch chassis. The Virtual Chassis module has two dedicated Virtual Chassis ports (VCPs) that can be used to interconnect the EX4500 switch with an EX4200 switch or an EX4500 switch in a Virtual Chassis configuration. The module is an offline field-replaceable unit (FRU).

NOTE: The VirtualChassis module is supported on EX4500switches in Junos

OS Releases 11.1 and later.

The Virtual Chassis module comes preinstalled in the switch chassis in the EX4500-40F-VC1-FB, EX4500-40F-VC1-BF, and EX4500-40F-VC1-DC switch models. You must order it separately for all other switch models. See “EX4500 Switch Models”

on page 7.

NOTE: Virtual Chassis cables and Virtual Chassis cable connector retainers

are not part of the EX4500 switch’s shipping configuration. If you want to purchase these, you must order them separately.

CAUTION: Operating an EX4500 switch without the intraconnect module

Figure 24 on page 39 shows the Virtual Chassis module.

Figure 24: Virtual Chassis Module

g021033

Status LED

Virtual chassis mode LED

Complete Hardware Guide for EX4500 Ethernet Switches

The Virtual Chassis module has two LEDs (labeled ST and VC MODE ) on the left side of its faceplate that indicate the status and the operating mode of the Virtual Chassis module. See Figure 25 on page 40.

Figure 25: Virtual Chassis Module LEDs

Table 17 on page 40 describes the LEDs on the Virtual Chassis module in an EX4500

switch.

Table 17: Virtual Chassis Module LEDs

Documentation

DescriptionStateLED

GreenST

Unlit

GreenVC Mode

Unlit

The Virtual Chassis module is functioning normally.

One of the following:

•

The Virtual Chassis module is not functioning normally.

•

The switch has been powered off.

The Virtual Chassis module and VCPs are active.

The Virtual Chassis module is operating in Intraconnectmode. The VCPs are not active.

The Virtual Chassis module has two captive screws on the faceplate that secure the module to the switch chassis. To remove or replace the Virtual Chassis module, follow the instructions in “Removing a Virtual Chassis Module from an EX4500 Switch” on

page 190.

• Rear Panel of an EX4500 Switch on page 13

• Field-Replaceable Units in EX4500 Switches on page 23

• Installing a Virtual Chassis Module in an EX4500 Switch on page 131

CHAPTER 3

Component Specifications

•

USB Port Specifications for an EX Series Switch on page 41

•

Console Port Connector Pinout Information for an EX Series Switch on page 42

•

RJ-45 to DB-9 Serial Port Adapter Pinout Information for a Switch on page 43

•

Management Port Connector Pinout Information for an EX4500 Switch on page 44

•

Network Port and Uplink Module Port Connector Pinout Information for EX4500 Switches on page 45

•

Virtual Chassis Ports Connector Pinout Information for EX4500 Switches on page 46

•

Pluggable Transceivers Supported on EX4500 Switches on page 49

•

SFP+ Direct Attach Cables for EX Series Switches on page 67

•

Grounding Cable and Lug Specifications for EX4500 Switches on page 72

USB Port Specifications for an EX Series Switch

The following Juniper Networks USB flash drives have been tested and are officially supported for the USB port on all EX Series switches:

•

RE-USB-1G-S

•

RE-USB-2G-S

•

RE-USB-4G-S

CAUTION: Any USB memory product not listed as supported for EX Series

switches has not been tested by Juniper Networks. The use of any unsupported USB memory product could expose your EX Series switch to unpredictablebehavior. Juniper Networks Technical AssistanceCenter (JTAC) can provide only limited support for issues related to unsupported hardware. We strongly recommend that you use only supported USB flash drives.

All USB flash drives used on EX Series switches must have the following features:

•

USB 2.0 or later.

•

Formatted with a FAT or MS-DOS file system.

Complete Hardware Guide for EX4500 Ethernet Switches

•

If the switch is running Junos OS Release 9.5 or earlier, the formatting method must use a master boot record. Microsoft Windows formatting, by default, does not use a master boot record. See the documentation for your USB flash drive for information about how your USB flash drive is formatted.

Documentation

EX2200 Switches Hardware Overview•

• Rear Panel of an EX3200 Switch

• Rear Panel of an EX3300 Switch

• Rear Panel of an EX4200 Switch

• EX4300 Switches Hardware Overview

• Front Panel of an EX4500 Switch on page 12

• Management Panel of an EX4600 Switch

• EX4550 Switches Hardware Overview

• Switch Fabric and Routing Engine (SRE) Module in an EX6200 Switch

• Switch Fabric and Routing Engine (SRE) Module in an EX8208 Switch

• Routing Engine (RE) Module in an EX8216 Switch

• Routing Engine Module in an EX9200 Switch

• Booting an EX Series Switch Using a Software Package Stored on a USB Flash Drive

Console Port Connector Pinout Information for an EX Series Switch

The console port on an EX Series switch is an RS-232 serial interface that uses an RJ-45 connector to connect to a console management device. The default baud rate for the console port is 9600 baud.

Table 18 on page 42 provides the pinout information for the RJ-45 console connector.

An RJ-45 cable and an RJ-45 to DB-9 serial port adapter are supplied with the switch.

NOTE: If your laptop or PC does not have a DB-9 male connector pin and you

want to connect your laptop or PC directly to an EX Series switch, use a combination of the RJ-45 to DB-9 female adapter supplied with the switch and a USB to DB-9 male adapter. You must provide the USB to DB-9 male adapter.

Table 18: EX Series Switches Console Port Connector Pinout Information

DescriptionSignalPin

Request to sendRTS Output1

Data terminal readyDTR Output2

Chapter 3: Component Specifications

Table 18: EX Series Switches Console Port Connector Pinout Information (continued)

DescriptionSignalPin

Transmit dataTxD Output3

Signal groundSignal Ground4

Signal groundSignal Ground5

Receive dataRxD Input6

Data carrier detectCD Input7

Clear to sendCTS Input8

Documentation

EX2200 Switches Hardware Overview•

• Rear Panel of an EX3200 Switch

• Rear Panel of an EX3300 Switch

• Rear Panel of an EX4200 Switch

• EX4300 Switches Hardware Overview

• Front Panel of an EX4500 Switch on page 12

• EX4550 Switches Hardware Overview

• Management Panel of an EX4600 Switch

• Switch Fabric and Routing Engine (SRE) Module in an EX6200 Switch

• Switch Fabric and Routing Engine (SRE) Module in an EX8208 Switch

• Routing Engine (RE) Module in an EX8216 Switch

• Connecting a Switch to a Management Console on page 150

• Configuring the Console Port Type (CLI Procedure)

RJ-45 to DB-9 Serial Port Adapter Pinout Information for a Switch

The console port is an RS-232 serial interface that uses an RJ-45 connector to connect to a management device such as a PC or a laptop. If your laptop or PC does not have a DB-9 male connector pin and you want to connect your laptop or PC to the switch, use a combination of the RJ-45 to DB-9 female adapter supplied with the switch along with a USB to DB-9 male adapter.

Table 19 on page 44 provides the pinout information for the RJ-45 to DB-9 serial port

adapter.

Complete Hardware Guide for EX4500 Ethernet Switches

Table 19: RJ-45 to DB-9 Serial Port Adapter Pinout Information

SignalDB-9 PinSignalRJ-45 Pin

CTS8RTS1

DSR6DTR2

RXD2TXD3

GND5GND4

TXD3RXD6

DTR4DSR7

RTS7CTS8

Documentation

Connecting a Switch to a Management Console on page 150•

• Connecting and Configuring an EX Series Switch (CLI Procedure) on page 161

• Connecting an EX9200 Switch to a Management Console or an Auxiliary Device

• Connecting and Configuring an EX9200 Switch (CLI Procedure)

• Connecting and Configuring an OCX1100 Switch (CLI Procedure)

Management Port Connector Pinout Information for an EX4500 Switch

The management port on an EX4500 switch uses an RJ-45 connector to connect to a management device for out-of-band management.

The port uses an autosensing RJ-45 connector to support a 10/100/1000Base-T connection.TwoLEDs on the port indicate link/activityon the port and the administrative status of the port. See “Management Port LEDs in EX4500 Switches” on page 26.

Table 20 on page 44 provides the pinout information for the RJ-45 connector for the

managementport. An RJ-45 cable, with a connectorattached,is supplied with the switch.

Table 20: Management Port Connector Pinout Information for EX4500 Switches

DescriptionSignalPin

Transmit/receive data pair 1TRP1+1

Transmit/receive data pair 1TRP1-2

Transmit/receive data pair 2TRP2+3

Transmit/receive data pair 3TRP3+4

Chapter 3: Component Specifications

Table 20: Management Port Connector Pinout Information for EX4500 Switches (continued)

DescriptionSignalPin

Transmit/receive data pair 3TRP3-5

Transmit/receive data pair 2TRP2-6

Transmit/receive data pair 4TRP4+7

Transmit/receive data pair 4TRP4-8

Documentation

See Front Panel of an EX4500 Switch on page 12 for port location.•

• Connecting a Switch to a Network for Out-of-Band Management on page 149

Network Port and Uplink Module Port Connector Pinout Information for EX4500 Switches

The network ports and uplink module ports on an EX4500 switch havetwo LEDs on each port that indicate link/activity on the port and the port status. See “Network Port and

Uplink Module Port LEDs in EX4500 Switches” on page 24.

Table 21 on page 45 provides the pinout information for the network port and uplink

module port connector pinout.

Table 21: Network Port and Uplink Module Port Connector Pinout Information for EX4500 Switches

DescriptionSignalPin

Module transmitter groundVeeT1

Module transmitter faultTX_Fault2

Transmitter disableTX_Disable3

2-wire serial interface data lineSDA4

2-wire serial interface clockSCL-5

Module absentMOD_ABS6

Rate select 0, optionally controls SFP+ module receiver.RS07

Receiver loss of signal indicationRX_LOS8

Rate select 1, optionally controls SFP+ transmitter.RS19

Module receiver groundVeeR10

Complete Hardware Guide for EX4500 Ethernet Switches

Table 21: Network Port and Uplink Module Port Connector Pinout Information for EX4500 Switches (continued)

DescriptionSignalPin

Module receiver groundVeeR11

Receiver inverted data outputRD-12

Receiver non inverted data outputRD+13

Module receiver groundVeeR14

Module receiver 3.3 V supplyVccR15

Module transmitter 3.3 V supplyVccT16

Module transmitter groundVeeT17

Transmitter non inverted data inputTD+18

Transmitter inverted data inputTD-19

Module transmitter groundVeeT20

Documentation

Front Panel of an EX4500 Switch on page 12•

• Uplink Modules in EX4500 Switches on page 36

Virtual Chassis Ports Connector Pinout Information for EX4500 Switches

EX4500 switches use a 68-pin connectorcable to interconnect switches to forma Virtual Chassis. Table 22 on page 46 provides the Virtual Chassis ports (VCPs) connector pinout information.

Table 22: Virtual Chassis Ports (VCPs) Connector Pinout Information

Pin NamePin Number

GNDA1

P1TXP0A2

P1TXN0A3

GNDA4

P1TXP1A5

P1TXN1A6

Chapter 3: Component Specifications

Table 22: Virtual Chassis Ports (VCPs) Connector Pinout Information (continued)

Pin NamePin Number

GNDA7

P1TXP2A8

P1TXN2A9

GNDA10

P1TXP3A11

P1TXN3A12

GNDA13

NCA14

NCA15

GNDA16

NCA17

NCA18

NCA19

NCA20

NCA21

GNDA22

P2TXP0A23

P2TXN0A24

GNDA25

P2TXP1A26

P2TXN1A27

GNDA28

P2TXP2A29

P2TXN2A30

Complete Hardware Guide for EX4500 Ethernet Switches

Table 22: Virtual Chassis Ports (VCPs) Connector Pinout Information (continued)

Pin NamePin Number

GNDA31

P2TXP3A32

P2TXN3A33

GNDA34

GNDB1

P1RXP0B2

P1RXN0B3

GNDB4

P1RXP1B5

P1RXN1B6

GNDB7

P1RXP2B8

P1RXN2B9

GNDB10

P1RXP3B11

P1RXN3B12

GNDB13

NCB14

NCB15

NCB16

NCB17

NCB18

NCB19

NCB20

Chapter 3: Component Specifications

Table 22: Virtual Chassis Ports (VCPs) Connector Pinout Information (continued)

Pin NamePin Number

NCB21

GNDB22

P2RXP0B23

P2RXN0B24

GNDB25

P2RXP1B26

P2RXN1B27

GNDB28

P2RXP2B29

P2RXN2B30

GNDB31

P2RXP3B32

P2RXN3B33

GNDB34

Documentation

Planning EX4200, EX4500, and EX4550 Virtual Chassis on page 106•

• Understanding EX Series Virtual Chassis Components

• Understanding EX4200, EX4500,and EX4550 Virtual Chassis Hardware Configurations

on page 103

• Connecting a Virtual Chassis Cable to an EX4500 Switch on page 133

Pluggable Transceivers Supported on EX4500 Switches

Uplink module ports on EX4500 switches support SFP and SFP+ transceivers. This topic describes the optical interfaces supported for those transceivers. It also lists the copper interface supported for the SFP transceivers.

Complete Hardware Guide for EX4500 Ethernet Switches

NOTE: We recommend that you use only optical transceivers and optical

connectors purchased from Juniper Networks with your Juniper Networks device.

CAUTION: If you are having a problem running a Juniper Networks device

that is using a third-party optic or cable, the Juniper Networks Technical Assistance Center (JTAC) can help you diagnose the source of the problem. Your JTAC engineer might recommend that you check the third-party optic or cable and potentially replace it with an equivalent Juniper Networks optic or cable that is qualified for the device.

The Gigabit Ethernet SFP and SFP+ transceivers installed in EX4500 switches support digital optical monitoring (DOM): Youcan view the diagnostic details for these transceivers by issuing the operational mode CLI command show interfaces diagnostics optics.

NOTE: The transceivers support DOM even if they are installed in uplink

module ports configured as Virtual Chassis ports.

The tables in this topic describe the optical interfacesupport over single-mode fiber-optic (SMF) and multimode fiber-optic (MMF) cables for SFP and SFP+ transceiversand over the copper interface for SFP transceivers:

•

Table23 on page51—Optical interfacesupport and copper interfacesupport for Gigabit

Ethernet SFP transceivers.

•

Table24 on page 62—Optical interface support for Gigabit Ethernet SFP+ transceivers.

Chapter 3: Component Specifications

Table 23: Optical interface Support and Copper Interface Support for Gigabit Ethernet SFP Transceivers in EX4500 Switches

ValueSpecificationEthernet Standard

EX-SFP-1GE-TModel number1000BASE-T

1000 MbpsRate

RJ-45Connector type

CopperFiber count

–Transmitter wavelength

–Minimum launch power

–Maximum launch power

configuration

–Minimum receiver sensitivity

–Maximum input power

CopperFiber type

–Core/Cladding size

–Modal bandwidth

100 m (328 ft)Distance

Not availableDOM support

Junos OS for EX Series switches, Release 10.2 or laterSoftware required

NoSupport for Virtual Chassis

Complete Hardware Guide for EX4500 Ethernet Switches

Table 23: Optical interface Support and Copper Interface Support for Gigabit Ethernet SFP Transceivers in EX4500 Switches (continued)

ValueSpecificationEthernet Standard

EX-SFP-1GE-SXModel number1000BASE-SX

1000 MbpsRate

LCConnector type

850 nmTransmitter wavelength

–9.5 dBmMinimum launch power

–3 dBmMaximum launch power

–21 dBmMinimum receiver sensitivity

configuration

0 dBmMaximum input power

MMFFiber type

50 µm50 µm62.5 µm62.5 µmCore size

500 MHz/km400 MHz/km200 MHz/km160 MHz/kmModal bandwidth

220 m (721 ft)Distance

AvailableDOM support

Junos OS for EX Series switches, Release 10.3 or laterSoftware required

YesSupport for Virtual Chassis

275 m (902 ft)

500 m (1640 ft)

550 m (1804 ft)

Chapter 3: Component Specifications

Table 23: Optical interface Support and Copper Interface Support for Gigabit Ethernet SFP Transceivers in EX4500 Switches (continued)

ValueSpecificationEthernet Standard

EX-SFP-1GE-LXModel number1000BASE-LX

1000 MbpsRate

LCConnector type

DualFiber count

1310 nmTransmitter wavelength

–9.5 dBmMinimum launch power

–3 dBmMaximum launch power

configuration

–25 dBmMinimum receiver sensitivity

–3 dBmMaximum input power

SMFFiber type

9/125 µmCore/Cladding size

–Modal bandwidth

10 km (6.2 miles)Distance

AvailableDOM support

Junos OS for EX Series switches, Release 10.2 or laterSoftware required

YesSupport for Virtual Chassis

Complete Hardware Guide for EX4500 Ethernet Switches

Table 23: Optical interface Support and Copper Interface Support for Gigabit Ethernet SFP Transceivers in EX4500 Switches (continued)

ValueSpecificationEthernet Standard

EX-SFP-GE10KT13R14Model number1000BASE-BX-U

1000 MbpsRate

LCConnector type

SingleFiber count

1310 nmTransmitter wavelength

1490 nmReceiver wavelength

–9 dBmMinimum launch power

configuration

–3 dBmMaximum launch power

–30 dBmMinimum receiver sensitivity

–3 dBmMaximum input power

SMFFiber type

9/125 µmCore/Cladding size

–Modal bandwidth

10 km (6.2 miles)Distance

AvailableDOM support

Junos OS for EX Series switches, Release 11.2 or laterSoftware required

YesSupport for Virtual Chassis

Chapter 3: Component Specifications

Table 23: Optical interface Support and Copper Interface Support for Gigabit Ethernet SFP Transceivers in EX4500 Switches (continued)

ValueSpecificationEthernet Standard

EX-SFP-GE10KT14R13Model number1000BASE-BX-D

1000 MbpsRate

LCConnector type

SingleFiber count

1490 nmTransmitter wavelength

1310 nmReceiver wavelength

–9 dBmMinimum launch power

configuration

–3 dBmMaximum launch power

–30 dBmMinimum receiver sensitivity

–3 dBmMaximum input power

SMFFiber type

9/125 µmCore/Cladding size

–Modal bandwidth

10 km (6.2 miles)Distance

AvailableDOM support

Junos OS for EX Series switches, Release 11.2 or laterSoftware required

YesSupport for Virtual Chassis

Complete Hardware Guide for EX4500 Ethernet Switches

Table 23: Optical interface Support and Copper Interface Support for Gigabit Ethernet SFP Transceivers in EX4500 Switches (continued)

ValueSpecificationEthernet Standard

EX-SFP-GE10KT13R15Model number1000BASE-BX-U

1000 MbpsRate

LCConnector type

SingleFiber count

1310 nmTransmitter wavelength

1550 nmReceiver wavelength

–9 dBmMinimum launch power

configuration

–3 dBmMaximum launch power

–21 dBmMinimum receiver sensitivity

–3 dBmMaximum input power

SMFFiber type

9/125 µmCore/Cladding size

–Modal bandwidth

10 km (6.2 miles)Distance

AvailableDOM support

Junos OS for EX Series switches, Release 11.2 or laterSoftware required

YesSupport for Virtual Chassis

Chapter 3: Component Specifications

Table 23: Optical interface Support and Copper Interface Support for Gigabit Ethernet SFP Transceivers in EX4500 Switches (continued)

ValueSpecificationEthernet Standard

EX-SFP-GE10KT15R13Model number1000BASE-BX-D

1000 MbpsRate

LCConnector type

SingleFiber count

1550 nmTransmitter wavelength

1310 nmReceiver wavelength

–9 dBmMinimum launch power

configuration

–3 dBmMaximum launch power

–21 dBmMinimum receiver sensitivity

–3 dBmMaximum input power

SMFFiber type

9/125 µmCore/Cladding size

–Modal bandwidth

10 km (6.2 miles)Distance

AvailableDOM support

Junos OS for EX Series switches, Release 11.2 or laterSoftware required

YesSupport for Virtual Chassis

Complete Hardware Guide for EX4500 Ethernet Switches

Table 23: Optical interface Support and Copper Interface Support for Gigabit Ethernet SFP Transceivers in EX4500 Switches (continued)

ValueSpecificationEthernet Standard

EX-SFP-GE40KT13R15Model number1000BASE-BX-U

1000 MbpsRate

LCConnector type

SingleFiber count

1310 nmTransmitter wavelength

1550 nmReceiver wavelength

–6.5 dBmMinimum launch power

configuration

2 dBmMaximum launch power

–23 dBmMinimum receiver sensitivity

–3 dBmMaximum input power

SMFFiber type

9/125 µmCore/Cladding size

–Modal bandwidth

40 km (24.8 miles)Distance

AvailableDOM support

Junos OS for EX Series switches, Release 11.2 or laterSoftware required

YesSupport for Virtual Chassis

Chapter 3: Component Specifications

Table 23: Optical interface Support and Copper Interface Support for Gigabit Ethernet SFP Transceivers in EX4500 Switches (continued)

ValueSpecificationEthernet Standard

EX-SFP-GE40KT15R13Model number1000BASE-BX-D

1000 MbpsRate

LCConnector type

SingleFiber count

1550 nmTransmitter wavelength

1310 nmReceiver wavelength

–6.5 dBmMinimum launch power

configuration

–23 dBmMinimum receiver sensitivity

–3 dBmMaximum input power

SMFFiber type

9/125 µmCore/Cladding size

–Modal bandwidth

40 km (24.8 miles)Distance

AvailableDOM support

Junos OS for EX Series switches, Release 11.2 or laterSoftware required

YesSupport for Virtual Chassis

Complete Hardware Guide for EX4500 Ethernet Switches

Table 23: Optical interface Support and Copper Interface Support for Gigabit Ethernet SFP Transceivers in EX4500 Switches (continued)

ValueSpecificationEthernet Standard

EX-SFP-1GE-LX40KModel number1000BASE-LX

1000 MbpsRate

LCConnector type

DoubleFiber count

1310 nmTransmitter wavelength

–14 dBmMinimum launch power

–8 dBmMaximum launch power

configuration

–45 dBmMinimum receiver sensitivity

–3 dBmMaximum input power

SMFFiber type

9/125 µmCore/Cladding size

–Modal bandwidth

40 km (24.8 miles)Distance

AvailableDOM support

Junos OS for EX Series switches, Release 11.2 or laterSoftware required

YesSupport for Virtual Chassis

Chapter 3: Component Specifications

Table 23: Optical interface Support and Copper Interface Support for Gigabit Ethernet SFP Transceivers in EX4500 Switches (continued)

ValueSpecificationEthernet Standard

EX-SFP-1GE-LHModel number1000BASE-LH (or

1000BASE-ZX)

1000 MbpsRate

LCConnector type

DualFiber count

1550 nmTransmitter wavelength

–2 dBmMinimum launch power

5 dBmMaximum launch power

configuration

–25 dBmMinimum receiver sensitivity

–3 dBmMaximum input power

SMFFiber type

9/125 µmCore/Cladding size

–Modal bandwidth

70 km (43.5 miles)Distance

AvailableDOM support

Junos OS for EX Series switches, Release 11.2 or laterSoftware required

YesSupport for Virtual Chassis

Complete Hardware Guide for EX4500 Ethernet Switches

Table24: Optical interface Support for Gigabit Ethernet SFP+ Transceiversin EX4500 Switches

ValueSpecificationEthernet Standard

EX-SFP-10GE-USRModel number10GBASE-USR

10 GbpsRate

LCConnector type

DualFiber count

850 nmTransmitter wavelength

–7.3 dBmMinimum launch power

–1.3 dBmMaximum launch power

–11.1 dBmMinimum receiver sensitivity

Modal bandwidth

Distance

configuration

–1.0 dBmMaximum input power

MMFFiber type

200 MHz/km

10 m (32.8 ft)

AvailableDOM support

Junos OS for EX Series switches, Release 10.2 or laterSoftware required

YesSupport for Virtual Chassis

500 MHz/km

30 m (98.4 ft)

50/125 µm50/125 µm62.5/125 µmCore/Cladding size

OM3OM3OM1Fiber grade

1500 MHz/km

100 m (328 ft)

Chapter 3: Component Specifications

Table 24: Optical interface Support for Gigabit Ethernet SFP+ Transceivers in EX4500 Switches (continued)

ValueSpecificationEthernet Standard

EX-SFP-10GE-SRModel number10GBASE-SR

10 GbpsRate

LCConnector type

DualFiber count

850 nmTransmitter wavelength

–7.3 dBmMinimum launch power

–1 dBmMaximum launch power

Modal bandwidth

Distance

configuration

–9.9 dBmMinimum receiver sensitivity

–1 dBmMaximum input power

MMFFiber type

160 MHz/km

26 m (85 ft)

AvailableDOM support

Junos OS for EX Series switches, Release 10.2 or laterSoftware required

YesSupport for Virtual Chassis

200 MHz/km

33 m (108 ft)

400 MHz/km

66 m (216 ft)

500 MHz/km

82 m (269 ft)

50/125 µm50/125 µm50/125 µm62.5/125 µm62.5/125µmCore/Cladding size

OM3OM2–OM1FDDIFiber grade

1500 MHz/km

300 m (984 ft)

Complete Hardware Guide for EX4500 Ethernet Switches

Table 24: Optical interface Support for Gigabit Ethernet SFP+ Transceivers in EX4500 Switches (continued)

ValueSpecificationEthernet Standard

EX-SFP-10GE-LRMModel number10GBASE-LRM

10 GbpsRate

LCConnector type

DualFiber count

1310 nmTransmitter wavelength

–6.5 dBmMinimum launch power

0.5 dBmMaximum launch power

Modal bandwidth

Distance

configuration

–21 dBmMinimum receiver sensitivity

0.5 dBmMaximum input power

MMFFiber type

500 MHz/km

220 m (722 ft)

AvailableDOM support

Junos OS for EX Series switches, Release 10.3R2 or laterSoftware required

YesSupport for Virtual Chassis

500 MHz/km

220 m (722 ft)

50/125 µm50/125 µm62.5/125 µmCore/Cladding size

OM3OM2FDDI/OM1Fiber grade

500 MHz/km

220 m (722 ft)

Chapter 3: Component Specifications

Table 24: Optical interface Support for Gigabit Ethernet SFP+ Transceivers in EX4500 Switches (continued)

ValueSpecificationEthernet Standard

EX-SFP-10GE-LRModel number10GBASE-LR

10 GbpsRate

LCConnector type

DualFiber count

1310 nmTransmitter wavelength

–8.2 dBmMinimum launch power

0.5 dBmMaximum launch power

configuration

–18 dBmMinimum receiver sensitivity

0.5 dBmMaximum input power

SMFFiber type

9/125 µmCore/Cladding size

–Modal bandwidth

10 km (6.2 miles)Distance

AvailableDOM support

Junos OS for EX Series switches, Release 10.2 or laterSoftware required

YesSupport for Virtual Chassis

Complete Hardware Guide for EX4500 Ethernet Switches

Table 24: Optical interface Support for Gigabit Ethernet SFP+ Transceivers in EX4500 Switches (continued)

ValueSpecificationEthernet Standard

EX-SFP-10GE-ERModel number10GBASE-ER

10 GbpsRate

LCConnector type

DualFiber count

1550 nmTransmitter wavelength

–4.7 dBmMinimum launch power

4 dBmMaximum launch power

configuration

–11.3 dBmMinimum receiver sensitivity

–1 dBmMaximum input power

SMFFiber type

9/125 µmCore/Cladding size

–Modal bandwidth

40 km (24.8 miles)Distance

AvailableDOM support

Junos OS for EX Series switches, Release 11.1 or laterSoftware required

YesSupport for Virtual Chassis

Chapter 3: Component Specifications

Table 24: Optical interface Support for Gigabit Ethernet SFP+ Transceivers in EX4500 Switches (continued)

ValueSpecificationEthernet Standard

EX-SFP-10GE-ZRModel number10GBASE-ZR

10 GbpsRate

LCConnector type

DualFiber count

1550 nmTransmitter wavelength

0 dBmMinimum launch power

5 dBmMaximum launch power

Documentation

–20 dBmMinimum receiver sensitivity

–8 dBmMaximum input power

SMFFiber type

9/125 µmCore/Cladding size

–Modal bandwidth

80 km (49.7 miles)Distance

AvailableDOM support

Junos OS for EX Series switches, Release 11.4R5 or laterSoftware required

YesSupport for Virtual Chassis

configuration

Front Panel of an EX4500 Switch on page 12•

• Installing a Transceiver in an EX Series Switch on page 134

• Removing a Transceiver from a Switch on page 195

SFP+ Direct Attach Cables for EX Series Switches

Small form-factor pluggable plus transceiver (SFP+) direct attach copper cables, also known as Twinax cables, are suitable for in-rack connections between servers and switches. They are suitable for short distances of up to 7 m (23 ft), making them ideal

Complete Hardware Guide for EX4500 Ethernet Switches

for highly cost-effective networking connectivity within a rack and between adjacent racks. See Figure 26 on page 68.

Figure 26: SFP+ Direct Attach Cables for EX Series Switches

This topic describes:

•

Cable Specifications on page 68

•

Standards Supported by These Cables on page 72

Cable Specifications

EX Series switches support SFP+ passive direct attach cables. The passive Twinax cable is a straight cable with no active electronic components. EX Series switches support 1 m, 3 m, 5 m, and 7 m long SFP+ passive direct attach cables.

Table 25 on page 68 describes the support for SFP+ passive direct attach cable lengths

on EX Series switches for Junos OS releases.

Table 25: Software Support for SFP+ Passive Direct Attach Cables for EX Series Switches

Cable LengthSoftware Support AddedSwitch

Junos OS Release 10.3EX3200 switches

Junos OS Release 10.3EX4200-24T, EX4200-24T-DC, EX4200-24P, EX4200-24PX,EX4200-24F,EX4200-24F-DC, EX4200-48T, EX4200-48T-DC, EX4200-48P, and EX4200-48PX switches

Junos OS Release 12.3R4EX4200-24F-S and EX4200-48T-S switches

Junos OS Release 11.3EX3300 switches

Junos OS Release 13.2X50-D10EX4300-24T, EX4300-24P, EX4300-48T, EX4300-48T-AFI, EX4300-48P, EX4300-48T-DC, and EX4300-48T-DC-AFI switches

1 m (3 ft), 3 m (10 ft), 5 m (16 ft), and 7 m (23 ft)

1 m (3 ft) and 3 m (10 ft)Junos OS Release 13.2X51-D15EX4300-32F switches

EX4300-48T-S,and EX4300-48P-S switches

Junos OS Release 13.2X51-D26EX4300-24T-S, EX4300-24P-S,

1 m (3 ft), 3 m (10 ft), 5 m (16 ft), and 7 m (23 ft)

1 m (3 ft) and 3 m (10 ft)Junos OS Release 13.2X51-D26EX4300-32F-S switches

Chapter 3: Component Specifications

Table 25: Software Support for SFP+ Passive Direct Attach Cables for EX Series Switches (continued)

Cable LengthSoftware Support AddedSwitch

1 m (3 ft), 3 m (10 ft), and 7 m (23 ft)Junos OS Release 10.2EX4500 switches

5 m (16 ft)Junos OS Release 11.2

EX4550-32T-DC-AFI, EX4550-32T-DC-AFO, EX4550-32F-AFI, EX4550-32F-AFO, EX4550-32F-DC-AFI, and EX4550-32F-DC-AFO switches

(EX8200-40XS)

NOTE: Werecommend that you use only SFP+ direct attachcablespurchased

from Juniper Networks with your Juniper Networks device.

CAUTION: If you are having a problem running a Juniper Networks device

Junos OS Release 12.2EX4550-32T-AFI, EX4550-32T-AFO,

Junos OS Release 12.3R5EX4550-32F-S switches

1 m (3 ft), 3 m (10 ft), 5 m (16 ft), and 7 m (23 ft)

1 m (3 ft), 3 m (10 ft), and 7 m (23 ft)Junos OS Release 10.0EX82008-port SFP+ line cards(EX8200-8XS)

5 m (16 ft)Junos OS Release 10.3

1 m (3 ft), 3 m (10 ft), and 7 m (23 ft)Junos OS Release 10.3EX8200 40-port SFP+ line cards

5 m (16 ft)Junos OS Release 11.1

The cables are hot-removable and hot-insertable: You can remove and replace them without powering off the switch or disrupting switch functions. A cable comprises a low-voltage cable assembly that connects directly into two SFP+ ports, one at each end of the cable. The cables use high-performance integrated duplex serial data links for bidirectional communication and are designed for data rates of up to 10 Gbps.

Table 26 on page 70 describes the cable specifications.

Complete Hardware Guide for EX4500 Ethernet Switches

Table 26: SFP+ Direct Attach Cable Specifications

ValueSpecificationModel Number

10-Gbps full-duplex serial transmissionRateEX-SFP-10GE-DAC-1M

SFP+ passive Twinax cable assemblyConnector type

3.3 VSupply voltage

0.57 WPower consumption (per end)

–40°C through 85°CStorage temperature

TwinaxCable type

30 AWGWire AWG

1 in. (2.54 cm)Minimum cable bend radius

100 ohmsCable characteristic impedance

2% maximumCrosstalk between pairs

1.31 nsec/ftTime delay

3.3 ft (1 m)Length

10-Gbps full-duplex serial transmissionRateEX-SFP-10GE-DAC-3M

SFP+ passive Twinax cable assemblyConnector type

3.3 VSupply voltage

0.57 WPower consumption (per end)

–40°C through 85°CStorage temperature

TwinaxCable type

30 AWGWire AWG

1 in. (2.54 cm)Minimum cable bend radius

100 ohmsCable characteristic impedance

2% maximumCrosstalk between pairs

1.31 nsec/ftTime delay

9.9 ft (3 m)Length

Table 26: SFP+ Direct Attach Cable Specifications (continued)

Chapter 3: Component Specifications

ValueSpecificationModel Number

10-Gbps full-duplex serial transmissionRateEX-SFP-10GE-DAC-5M

SFP+ passive Twinax cable assemblyConnector type

3.3 VSupply voltage

0.57 WPower consumption (per end)

–40°C through 85°CStorage temperature

TwinaxCable type

24 AWGWire AWG

1 in. (2.54 cm)Minimum cable bend radius

100 ohmsCable characteristic impedance

2% maximumCrosstalk between pairs

1.31 nsec/ftTime delay

16.4 ft (5 m)Length

10-Gbps full-duplex serial transmissionRateEX-SFP-10GE-DAC-7M

SFP+ passive Twinax cable assemblyConnector type

3.3 VSupply voltage

0.57 WPower consumption (per end)

–40°C through 85°CStorage temperature

TwinaxCable type

24 AWGWire AWG

1 in. (2.54 cm)Minimum cable bend radius

100 ohmsCable characteristic impedance

2% maximumCrosstalk between pairs

1.31 nsec/ftTime delay

23 ft (7 m)Length

Complete Hardware Guide for EX4500 Ethernet Switches

Standards Supported by These Cables

The cables comply with the following standards:

•

SFP mechanical standard SFF-843—see ftp://ftp.seagate.com/sff/SFF-8431.PDF .

•

Electrical interface standard SFF-8432—see ftp://ftp.seagate.com/sff/SFF-8432.PDF .

•

SFP+ Multi-Source Alliance (MSA) standards.

Documentation

Pluggable Transceivers Supported on EX Series Switches•

• Installing a Transceiver in an EX Series Switch on page 134

• Removing a Transceiver from a Switch on page 195

Grounding Cable and Lug Specifications for EX4500 Switches

For installations that require a separate grounding conductor to the chassis, the switch must be adequately grounded before power is connected to ensure proper operation and to meet safety and electromagnetic interference (EMI) requirements. To ground an EX4500 switch, connect a grounding cable to earth ground and then attach it to the chassis grounding points.

CAUTION: For installations that require a separate grounding conductor to

the chassis, use the protective earthing terminal on the switch chassis to connect to earth ground. Before switch installation begins, a licensed electrician must attach a cable lug to the grounding cables that you supply. See “Connecting Earth Ground to an EX Series Switch” on page 137. A cable with an incorrectly attached lug can damage the switch.

A pair of threaded inserts (PEM nuts) is provided on the left side towards the rear corner of the chassis for connecting the switch to earth ground. The grounding points fit UNC 10-32 screws. The grounding points are spaced at 0.625 in. (15.86 mm).

The grounding cable that you provide for an EX4500 switch must be 14 AWG (2 mm2), minimum 90°C wire, or as permitted by the local code.

NOTE: Grounding is provided to an AC-powered switch when you plug its

power supplies into grounded AC power receptacles.

WARNING: The switch is pluggable type A equipment installed in a

Chapter 3: Component Specifications

connectedto earth ground for installationsthat require a separategrounding conductor to the chassis.

Documentation

AC Power Supply in EX4500 Switches on page 27•

• Installing an AC Power Supply in an EX4500 Switch on page 122

Complete Hardware Guide for EX4500 Ethernet Switches

PART 2

Planning for Switch Installation

•

Site Preparation on page 77

•

Rack and Cabinet Requirements on page 85

•

Cable Requirements on page 91

•

Planning Power Requirements on page 95

•

Planning the Virtual Chassis on page 103

Complete Hardware Guide for EX4500 Ethernet Switches

CHAPTER 4

Site Preparation

•

Site Preparation Checklist for EX4500 Switches on page 77

•

General Site Guidelines on page 78

•

Site Electrical Wiring Guidelines on page 79

•

Environmental Requirements and Specifications for EX Series Switches on page 81

Site Preparation Checklist for EX4500 Switches

The checklist in Table 27 on page 77 summarizes the tasks you need to perform when preparing a site for EX4500 switch installation.

Table 27: Site Preparation Checklist

Environment

Verify that environmental factors such as temperatureand humidity do not exceed switch tolerances.

“Environmental Requirements and Specifications for EX Series Switches” on page 81

DatePerformed byFor More InformationItem or Task

Power

Measure distance between external power sources and switch installation site.

Locate sites for connection of system grounding.

Calculate the power consumption and requirements.

Hardware Configuration

Choose the number and types of switches you want to install.

Rack or Cabinet

“AC PowerSupply Specifications for EX4500 Switches” on page 95

“EX4500 Switches Hardware Overview” on page 3

Complete Hardware Guide for EX4500 Ethernet Switches

Table 27: Site Preparation Checklist (continued)

DatePerformed byFor More InformationItem or Task

Verify that your rack or cabinet meets the minimum requirements for the installation of the switch.

Plan rack or cabinet location, including required space clearances.

Secure the rack or cabinet to the floor and building structure.

Cables

Acquire cables and connectors:

•

Determine the number of cables needed based on your planned configuration.

•

Review the maximum distance allowed for each cable. Choose the length of cablebased on the distance between the hardware components being connected.

Plan the cable routing and management.

Documentation

General Safety Guidelines and Warnings on page 221•

• General Site Guidelines on page 78

“Rack Requirements for EX4500 Switches” on page 85

“Cabinet Requirements for EX4500 Switches” on page 86

“ClearanceRequirements for Airflow and Hardware Maintenance for EX4500 Switches” on page 87

• Installing and Connecting an EX4500 Switch on page 111

• Mounting an EX4500 Switch on page 114

General Site Guidelines

This topic applies to hardware devices in the EX Series product family, which includes EX Series switches, the EX Series Redundant Power System (RPS), and the XRE200 External Routing Engine.

This topic also applies to hardware devices in the QFX Series and to OCX1100 switches.

Chapter 4: Site Preparation

Efficient device operation requires proper site planning and maintenance and proper layout of the equipment, rack or cabinet (if used), and wiring closet.

To plan and create an acceptable operating environment for your device and prevent environmentally caused equipment failures:

•

Keep the area around the chassis free from dust and conductive material, such as metal flakes.

•

Followprescribed airflow guidelines to ensure that the cooling systemfunctions properly and that exhaust from other equipment does not blow into the intake vents of the device.

•

Follow the prescribed electrostatic discharge (ESD) prevention procedures to prevent damaging the equipment. Static discharge can cause components to fail completely or intermittently over time.

•

Install the device in a secure area, so that only authorized personnel can access the device.

Documentation

Prevention of Electrostatic Discharge Damage on page 250•

• Environmental Requirements and Specifications for EX Series Switches on page 81

• Environmental Requirements and Specifications for OCX1100 Switches

• Environmental Requirements and Specifications for a QFX3100 Director Device

• Environmental Requirements and Specifications for a QFX3008-I Interconnect Device

• Environmental Requirements and Specifications for a QFX3500 Device

• Environmental Requirements and Specifications for QFX3600 and QFX3600-I Devices

• Environmental Requirements and Specifications for a QFX5100 Device

Site Electrical Wiring Guidelines

This topic applies to hardware devices in the EX Series product family, which includes EX Series switches, the EX Series Redundant Power System (RPS), and the XRE200 External Routing Engine.

This topic also applies to hardware devices in the QFX Series and to OCX1100 switches.

Table28 on page 80 describes the factors you must consider whileplanning the electrical

wiring at your site.

WARNING: It is particularly important to provide a properly grounded and

shielded environment and to use electrical surge-suppression devices.

Complete Hardware Guide for EX4500 Ethernet Switches

Table 28: Site Electrical Wiring Guidelines

GuidelinesSite Wiring Factor

Signaling limitations

Radio frequency interference

Electromagnetic compatibility

If your site experiences any of the following problems, consult experts in electrical surge suppression and shielding:

•

Improperly installed wires cause radio frequency interference (RFI).

•

Damagefrom lightning strikesoccurswhen wires exceedrecommended distances or pass between buildings.

•

Electromagneticpulses (EMPs) caused by lightning damage unshielded conductors and electronic devices.

To reduce or eliminate RFI from your site wiring, do the following:

•

Use a twisted-pair cable with a good distribution of grounding conductors.

•

If you must exceed the recommended distances, use a high-quality twisted-paircablewith one ground conductor for each data signal when applicable.

If your site is susceptible to problems with electromagnetic compatibility (EMC), particularly from lightning or radio transmitters, seek expert advice.

Some of the problems caused by strong sources of electromagnetic interference (EMI) are:

•

Destruction of the signal drivers and receivers in the switch

•

Electrical hazards as a result of power surges conducted over the lines into the equipment

Documentation

General Safety Guidelines and Warnings on page 221•

• General Electrical Safety Guidelines and Warnings on page 249

• Prevention of Electrostatic Discharge Damage on page 250

• Power Supply in EX2200 Switches

• Power Supply in EX3200 Switches

• Power Supply in EX3300 Switches

• Power Supply in EX4200 Switches

• AC Power Supply in EX4300 Switches

• DC Power Supply in EX4300 Switches

• AC Power Supply in EX4500 Switches on page 27

• DC Power Supply in EX4500 Switches on page 30

• AC Power Supply in EX4550 Switches

• DC Power Supply in EX4550 Switches

• AC Power Supply in an EX4600 Switch

• DC Power Supply in an EX4600 Switch

• AC Power Supplies in an EX6200 Switch

• DC Power Supply in an EX6200 Switch

• AC Power Supply in an EX8200 Switch

• DC Power Supply in an EX8200 Switch

• AC Power Supply in an EX9204 Switch

• DC Power Supply in an EX9204 Switch

• AC Power Supply in an EX9208 Switch

• DC Power Supply in an EX9208 Switch

• AC Power Supply in an EX9214 Switch

• DC Power Supply in an EX9214 Switch

• Power Supply in an EX Series Redundant Power System

• AC Power Supply in OCX1100 Switches

Chapter 4: Site Preparation

• DC Power Supply in OCX1100 Switches

• AC Power Supply in a QFX3100 Director Device

• AC Power Supply in a QFX3008-I Interconnect Device

• Wiring Tray in a QFX3008-I Interconnect Device

• AC Power Supply for a QFX3500, QFX3600, or QFX3600-I Device

• DC Power Supply for a QFX3500, QFX3600, or QFX3600-I Device

• AC Power Supply for a QFX5100 Device

• DC Power Supply in a QFX5100 Device

Environmental Requirements and Specifications for EX Series Switches

The switch must be installed in a rack or cabinet housed in a dry, clean, well-ventilated, and temperature-controlled environment.

Ensure that these environmental guidelines are followed:

•

The site must be as dust-free as possible, because dust can clog air intake vents and filters, reducing the efficiency of the switch cooling system.

•

Maintain ambient airflow for normal switch operation. If the airflow is blocked or restricted, or if the intake air is too warm, the switch might overheat, leading to the switch temperature monitor shutting down the switch to protect the hardware components.

Table 29 on page 82 provides the required environmental conditions for normal switch

operation.

Complete Hardware Guide for EX4500 Ethernet Switches

Table 29: EX Series Switch Environmental Tolerances

Environment Tolerance

Switch or device SeismicTemperatureRelative HumidityAltitude

EX2200-C

EX2200 (except EX2200-C switches)

EX3200

EX3300

EX4200

No performance degradation up to 5,000 feet (1524 meters)

No performance degradation up to 10,000 feet (3048 meters)

Normal operation ensured in relative humidity range of 10% through 85% (noncondensing)

Normal operation ensured in the temperaturerange 32° F through 104° F (0° C through 40° C) at altitudes up to 5,000 ft (1,524 m).

For information about extended temperatureSFPs, see Pluggable

Transceivers Supported on EX2200 Switches.

Normal operation ensured in the temperaturerange 32° F through 113° F (0° C through 45° C)

Complies with Zone 4 earthquake requirements as per GR-63, Issue 4.

EX4300

EX4500

EX4550

No performance degradation up to 10,000 feet (3048 meters)

Normal operation ensured in relative humidity range of 10% through 85% (noncondensing)

Normal operation ensured in the temperaturerange 32° F through 113° F (0° C through 45° C)

•

EX4550-32F switches—Normal operation ensured in the temperature range 32° F through 113° F (0° C through 45° C)

•

EX4550-32T switches—Normal operation is ensured in the temperature range 32° F through 104° F (0° C through 40° C)

Complies with Zone 4 earthquake requirements as per GR-63, Issue 4.

Juniper EX4500-40F-FB, EX4500-40F-DC-C, EX4500-40F-VC1-FB, EX4500-40F-VC1-BF, EX4500-40F-VC1-DC Complete Hardware Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Table of Contents

List of Figures

List of Tables

About the Documentation

Junos OS Documentation and Release Notes

Documentation Conventions

Documentation Feedback

Requesting Technical Support

Self-Help Online Tools and Resources

Opening a Case with JTAC

EX4500 Switches Hardware Overview

Software

EX4500 Switches First View

Intraconnect Module and Virtual Chassis Module

Virtual Chassis

Uplink Modules

Power Supplies

EX4500 Switch Models

Identifying EX4500 Switch Models

Chassis Physical Specifications for EX4500 Switches

Front Panel of an EX4500 Switch

Rear Panel of an EX4500 Switch

EX4500 Switch Hardware and CLI Terminology Mapping

LCD Panel in EX4500 Switches

LCD Panel Modes

LCD Panel Menus

Chassis Status LEDs in EX4500 Switches

Field-Replaceable Units in EX4500 Switches

Network Port and Uplink Module Port LEDs in EX4500 Switches

Management Port LEDs in EX4500 Switches

AC Power Supply in EX4500 Switches

AC Power Supply LEDs in EX4500 Switches

DC Power Supply in EX4500 Switches

DC Power Supply LEDs in EX4500 Switches

Cooling System and Airflow in an EX4500 Switch

Fan Tray

Airfow Direction in EX4500 Switch Models

Front-to-Back Airflow

Back-to-Front Airflow

Uplink Modules in EX4500 Switches

Intraconnect Module in EX4500 Switches

Virtual Chassis Module in EX4500 Switches

USB Port Specifications for an EX Series Switch

Console Port Connector Pinout Information for an EX Series Switch

RJ-45 to DB-9 Serial Port Adapter Pinout Information for a Switch

Management Port Connector Pinout Information for an EX4500 Switch

Network Port and Uplink Module Port Connector Pinout Information for EX4500 Switches

Virtual Chassis Ports Connector Pinout Information for EX4500 Switches

Pluggable Transceivers Supported on EX4500 Switches

SFP+ Direct Attach Cables for EX Series Switches

Cable Specifications

Standards Supported by These Cables

Grounding Cable and Lug Specifications for EX4500 Switches

Site Preparation Checklist for EX4500 Switches

General Site Guidelines

Site Electrical Wiring Guidelines

Environmental Requirements and Specifications for EX Series Switches
