Juniper EX3300-24P operation manual

EX3300 Switch Hardware Guide

Modified: 2017-07-05

Juniper Networks, Inc. 1133 Innovation Way Sunnyvale, California 94089 USA 408-745-2000 www.juniper.net

Juniper Networks, Junos, Steel-Belted Radius, NetScreen, and ScreenOS are registered trademarks of Juniper Networks, Inc. in the United States and other countries. The Juniper Networks Logo, the Junos logo, and JunosE are trademarks of Juniper Networks, Inc. All other trademarks, service marks, registered trademarks, or registered service marks are the property of their respective owners.

Juniper Networks assumes no responsibility for any inaccuracies in this document. Juniper Networks reserves the right to change, modify, transfer, or otherwise revise this publication without notice.

EX3300 Switch Hardware Guide

The information in this document is current as of the date on the title page.

YEAR 2000 NOTICE

Juniper Networks hardware and software products are Year 2000 compliant. Junos OS has no known time-related limitationsthrough the year 2038. However, the NTP application is known to have some difficulty in the year 2036.

END USER LICENSE AGREEMENT

The Juniper Networks product that is the subject of this technical documentation consists of (or is intended for use with) Juniper Networks software. Use of such software is subject tothe terms and conditions of the End User License Agreement (“EULA”) posted at

http://www.juniper.net/support/eula.html. By downloading, installing or using such software, you agree to the terms and conditions of

that EULA.

About the Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xvii

Documentation and Release Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xvii

Supported Platforms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xvii

Documentation Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xvii

Documentation Feedback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xix

Requesting Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xx

Self-Help Online Tools and Resources . . . . . . . . . . . . . . . . . . . . . . . . . . . xx

Opening a Case with JTAC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xx

Part 1 Overview

Chapter 1 System Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

EX3300 Switches Hardware Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

EX3300 Switches First View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Uplink Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Power over Ethernet Plus Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

EX3300 Switch Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

EX3300 Switch Hardware and CLI Terminology Mapping . . . . . . . . . . . . . . . . . . . . 5

Chapter 2 Chassis Components and Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Chassis Physical Specifications for EX3300 Switches . . . . . . . . . . . . . . . . . . . . . . . 9

Front Panel of an EX3300 Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Rear Panel of an EX3300 Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

LCD Panel in EX3300 Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

LCD Panel Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

LCD Panel Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Chassis Status LEDs in EX3300 Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Management Port LEDs in EX3300 Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Network Port and Uplink Port LEDs in EX3300 Switches . . . . . . . . . . . . . . . . . . . . 19

Chapter 3 Cooling System and Airflow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Cooling System and Airflow in an EX3300 Switch . . . . . . . . . . . . . . . . . . . . . . . . . 23

Airflow Direction in EX3300 Switch Models . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Front-to-Back Airflow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Back-to-Front Airflow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Chapter 4 Power Supplies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Power Supply in EX3300 Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

EX3300 Switch Hardware Guide

Chapter 5 Viewing System Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Part 2 Site Planning, Preparation, and Specifications

Chapter 6 Preparation Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Chapter 7 Power Specifications and Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Chapter 8 Transceiver and Cable Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Chapter 9 Pinout Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

Dashboard for EX Series Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Graphical Chassis Viewer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

System Information Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Health Status Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Capacity Utilization Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Alarms Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

File System Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Chassis Viewer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Site Preparation Checklist for EX3300 Switches . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Environmental Requirements and Specifications for EX Series Switches . . . . . . . 52

General Site Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Site Electrical Wiring Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Chassis Physical Specifications for EX3300 Switches . . . . . . . . . . . . . . . . . . . . . . 58

Rack Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Cabinet Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Requirements for Mounting an EX3300 Switch on a Desktop or Wall . . . . . . . . . 60

Clearance Requirements for Airflow and Hardware Maintenance for EX3300

Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Power Specifications for EX3300 Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

AC Power Cord Specifications for EX3300 Switches . . . . . . . . . . . . . . . . . . . . . . . 66

Calculating the EX Series Switch Fiber-Optic Cable Power Budget . . . . . . . . . . . . 67

Calculating the EX Series Switch Fiber-Optic Cable Power Margin . . . . . . . . . . . . 68

Pluggable Transceivers Supported on EX3300 Switches . . . . . . . . . . . . . . . . . . . . 71

Pluggable Transceivers Supported on EX Series Switches . . . . . . . . . . . . . . . . . . . 72

SFP+ Direct Attach Copper Cables for EX Series Switches . . . . . . . . . . . . . . . . . . 73

Cable Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Standards Supported by These Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Management Cable Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Understanding EX Series Switches Fiber-Optic Cable Signal Loss, Attenuation,

and Dispersion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Signal Loss in Multimode and Single-Mode Fiber-Optic Cable . . . . . . . . . . . 80

Attenuation and Dispersion in Fiber-Optic Cable . . . . . . . . . . . . . . . . . . . . . . . 81

Console Port Connector Pinout Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

USB Port Specifications for an EX Series Switch . . . . . . . . . . . . . . . . . . . . . . . . . . 84

RJ-45 Management Port Connector Pinout Information . . . . . . . . . . . . . . . . . . . . 85

RJ-45 Port, QSFP+ Port, SFP+ Port, and SFP Port Connector Pinout

Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

RJ-45 to DB-9 Serial Port Adapter Pinout Information . . . . . . . . . . . . . . . . . . . . . 90

Table of Contents

Chapter 10 Planning the Virtual Chassis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Planning EX3300 Virtual Chassis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Understanding EX3300 Virtual Chassis Hardware Configuration . . . . . . . . . . . . . 92

Virtual Chassis Cabling Configuration Examples for EX3300 Switches . . . . . . . . 92

Part 3 Initial Installation and Configuration

Chapter 11 Unpacking the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

Unpacking an EX3300 Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

Parts Inventory (Packing List) for an EX3300 Switch . . . . . . . . . . . . . . . . . . . . . . 98

Registering Products—Mandatory for Validating SLAs . . . . . . . . . . . . . . . . . . . . . 99

Chapter 12 Installing the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

Installing and Connecting an EX3300 Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

Mounting an EX3300 Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102

Mounting an EX3300 Switch on a Desk or Other Level Surface . . . . . . . . . . . . . . 103

Mounting an EX3300 Switch on Two Posts in a Rack or Cabinet . . . . . . . . . . . . 104

Mounting an EX3300 Switch on Four Posts in a Rack or Cabinet . . . . . . . . . . . . 107

Mounting an EX3300 Switch in a Recessed Position in a Rack or Cabinet . . . . . . 110

Mounting an EX3300 Switch on a Wall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110

Chapter 13 Connecting the Switch to Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115

Connecting Earth Ground to an EX Series Switch . . . . . . . . . . . . . . . . . . . . . . . . . 115

Parts and Tools Required for Connecting an EX Series Switch to Earth

Ground . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115

Special Instructions to Follow Before Connecting Earth Ground to a

Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118

Connecting Earth Ground to an EX Series Switch . . . . . . . . . . . . . . . . . . . . . 120

Connecting AC Power to an EX3300 Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

Connecting DC Power to an EX3300 Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123

Chapter 14 Connecting the Switch to the Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127

Connecting a Device to a Network for Out-of-Band Management . . . . . . . . . . . . 127

Connecting a Device to a Management Console by Using an RJ-45

Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128

Connecting a Fiber-Optic Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129

Chapter 15 Performing Initial Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131

EX3300 Switch Default Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131

Connecting and Configuring an EX Series Switch (CLI Procedure) . . . . . . . . . . . 135

Connecting and Configuring an EX Series Switch (J-Web Procedure) . . . . . . . . . 139

Configuring the LCD Panel on EX Series Switches (CLI Procedure) . . . . . . . . . . . 143

Disabling or Enabling Menus and Menu Options on the LCD Panel . . . . . . . 143

Configuring a Custom Display Message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144

Part 4 Installing, Maintaining, and Replacing Components

Chapter 16 Replacing Transceiver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149

Installing a Transceiver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149

Removing a Transceiver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151

EX3300 Switch Hardware Guide

Chapter 17 Maintaining and Replacing Fiber-Optic Cable . . . . . . . . . . . . . . . . . . . . . . . . 155

Chapter 18 Contacting Customer Support and Returning the Chassis or

Part 5 Troubleshooting

Chapter 19 Alarms and Syslog Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167

Connecting a Fiber-Optic Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155

Disconnecting a Fiber-Optic Cable from a Device . . . . . . . . . . . . . . . . . . . . . . . . . 156

Maintaining Fiber-Optic Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157

Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159

Returning an EX3300 Switch or Component for Repair or Replacement . . . . . . 159

Locating the Serial Number on an EX3300 Switch or Component . . . . . . . . . . . 160

Listing the Switch and Components Details with the CLI . . . . . . . . . . . . . . . 160

Locating the Chassis Serial Number ID Label on an EX3300 Switch . . . . . . . 161

Contacting Customer Support to Obtain Return Material Authorization . . . . . . . 161

Packing an EX3300 Switch or Component for Shipping . . . . . . . . . . . . . . . . . . . 162

Packing a Switch for Shipping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 162

Packing Switch Components for Shipping . . . . . . . . . . . . . . . . . . . . . . . . . . . 163

Understanding Alarm Types and Severity Levels on EX Series Switches . . . . . . . 167

Chassis Component Alarm Conditions on EX3300 Switches . . . . . . . . . . . . . . . 168

Checking Active Alarms with the J-Web Interface . . . . . . . . . . . . . . . . . . . . . . . . . 175

Monitoring System Log Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 176

Part 6 Safety and Compliance Information

Chapter 20 General Safety Guidelines and Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 183

General Safety Guidelines and Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 183

Definitions of Safety Warning Levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 184

Qualified Personnel Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 186

Warning Statement for Norway and Sweden . . . . . . . . . . . . . . . . . . . . . . . . . . . . 187

Chapter 21 Fire Safety Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 189

Fire Safety Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 189

Chapter 22 Installation Safety Guidelines and Warnings . . . . . . . . . . . . . . . . . . . . . . . . . 191

Installation Instructions Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 191

Chassis Lifting Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 192

Restricted Access Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 192

Ramp Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 194

Rack-Mounting and Cabinet-Mounting Warnings . . . . . . . . . . . . . . . . . . . . . . . . 194

Wall-Mounting Warning for EX3300 Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . 198

Grounded Equipment Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 198

Chapter 23 Radiation and Laser Safety Guidelines and Warnings . . . . . . . . . . . . . . . . . 201

Laser and LED Safety Guidelines and Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . 201

General Laser Safety Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201

Class 1 Laser Product Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 202

Class 1 LED Product Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 202

Laser Beam Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 202

Radiation from Open Port Apertures Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . 203

Table of Contents

Chapter 24 Maintenance and Operational Safety Warnings . . . . . . . . . . . . . . . . . . . . . . 205

Maintenance and Operational Safety Guidelines and Warnings . . . . . . . . . . . . . 205

Battery Handling Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 205

Jewelry Removal Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 206

Lightning Activity Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 207

Operating Temperature Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 208

Product Disposal Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 209

Chapter 25 Electrical Safety Guidelines and Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . 211

General Electrical Safety Guidelines and Warnings . . . . . . . . . . . . . . . . . . . . . . . . 211

Action to Take After an Electrical Accident . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 212

Prevention of Electrostatic Discharge Damage . . . . . . . . . . . . . . . . . . . . . . . . . . . 213

AC Power Electrical Safety Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 214

AC Power Disconnection Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 215

DC Power Electrical Safety Guidelines for Switches . . . . . . . . . . . . . . . . . . . . . . . 216

DC Power Disconnection Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 219

DC Power Grounding Requirements and Warning . . . . . . . . . . . . . . . . . . . . . . . . 220

DC Power Wiring Sequence Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 221

DC Power Wiring Terminations Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 223

Multiple Power Supplies Disconnection Warning . . . . . . . . . . . . . . . . . . . . . . . . . 224

TN Power Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 224

Chapter 26 Agency Approvals and Compliance Statements . . . . . . . . . . . . . . . . . . . . . . 227

Agency Approvals for EX Series Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 227

Compliance Statements for EMC Requirements for EX Series Switches . . . . . . 228

Canada . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 228

European Community . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 229

Israel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 229

Japan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 229

Korea . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 230

United States . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 230

FCC Part 15 Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 230

Nonregulatory Environmental Standards . . . . . . . . . . . . . . . . . . . . . . . . . . . . 231

Compliance Statements for Acoustic Noise for EX Series Switches . . . . . . . . . . 232

EX3300 Switch Hardware Guide

List of Figures

Part 1 Overview

Chapter 2 Chassis Components and Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Figure 1: Front Panel of an EX3300 Switch with 48 Gigabit Ethernet Ports . . . . . . 10

Figure 2: Front Panel of an EX3300 Switch with 24 Gigabit Ethernet Ports . . . . . . 11

Figure 3: Rear Panel of an EX3300 Switch with an AC Power Supply . . . . . . . . . . 12

Figure 4: Rear Panel of an EX3300 Switch with a DC Power Supply . . . . . . . . . . . 12

Figure 5: LCD Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Figure 6: Chassis Status LEDs in an EX3300 Switch . . . . . . . . . . . . . . . . . . . . . . . . 17

Figure 7: LEDs on the Management Port on an EX3300 Switch . . . . . . . . . . . . . . . 18

Figure 8: LEDs on the Network Ports on the Front Panel . . . . . . . . . . . . . . . . . . . . 19

Figure 9: LEDs on the Uplink Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Chapter 3 Cooling System and Airflow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Figure 10: Front-to-Back Airflow Through the EX3300 Switch Chassis . . . . . . . . . 24

Figure 11: Back-to-Front Airflow Through the EX3300 Switch Chassis . . . . . . . . . 25

Part 2 Site Planning, Preparation, and Specifications

Chapter 6 Preparation Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Figure 12: Clearance Requirements for Airflow and Hardware Maintenance for

EX3300 Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Figure 13: Front-to-Back Airflow Through the EX3300 Switch Chassis . . . . . . . . . 62

Figure 14: Back-to-Front Airflow Through the EX3300 Switch Chassis . . . . . . . . . 62

Chapter 7 Power Specifications and Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Figure 15: AC Plug Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Chapter 8 Transceiver and Cable Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Figure 16: SFP+ Direct Attach Copper Cables for EX Series Switches . . . . . . . . . . 73

Chapter 10 Planning the Virtual Chassis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Figure 17: EX3300 Switches Mounted on a Single Rack and Connected in a Ring

Topology: Option 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

Figure 18: EX3300 Switches Mounted on a Single Rack and Connected in a Ring

Topology: Option 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

Figure 19: EX3300 Switches Mounted on a Single Rack and Connectedin a Ring:

Option 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94

Figure 20: EX3300 Switches Mounted on Adjacent Racks and Connected in a

Ring Topology Using Medium and Long Cables: Option 1 . . . . . . . . . . . . . . . . 94

Figure 21: EX3300 Switches Mounted on Adjacent Racks and Connected in a

Ring Topology Using Medium and Long Cables: Option 2 . . . . . . . . . . . . . . . 94

EX3300 Switch Hardware Guide

Part 3 Initial Installation and Configuration

Chapter 12 Installing the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

Chapter 13 Connecting the Switch to Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115

Chapter 14 Connecting the Switch to the Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127

Chapter 15 Performing Initial Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131

Figure 22: Attaching Rubber Feet to a Switch Chassis . . . . . . . . . . . . . . . . . . . . . 104

Figure 23: Attaching the Mounting Bracket Along the Front of the Switch . . . . . 105

Figure 24: Mounting the Switch on Two Posts in a Rack . . . . . . . . . . . . . . . . . . . . 106

Figure 25: Attaching the Front-Mounting Bracket to the Side Mounting-Rail . . . 108

Figure 26: Attaching the Side Mounting-Rail to the Switch Chassis . . . . . . . . . . 108

Figure 27: Mounting the Switch to the Front Posts in a Rack . . . . . . . . . . . . . . . . 109

Figure 28: Sliding the Rear Mounting-Blade into the Side Mounting-Rail . . . . . . 109

Figure 29: Attaching Wall-Mount Brackets to a Switch Chassis . . . . . . . . . . . . . . . 111

Figure 30: Measurements for Installing Mounting Screws . . . . . . . . . . . . . . . . . . . 113

Figure 31: Mounting the Switch on a Wall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113

Figure 32: Connecting the Grounding Lug to a Switch Mounted on Four Posts of

a Rack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119

Figure 33: Connecting a Grounding Cable to an EX Series Switch . . . . . . . . . . . . 120

Figure 34: Connecting an AC Power Cord Retainer Clip to the AC Power Cord

Inlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123

Figure 35: Connecting an AC Power Cord to the AC Power Cord Inlet . . . . . . . . . . 123

Figure 36: Securing Ring Lugs to the Terminals on the DC Power Supply . . . . . . 125

Figure 37: RJ-45 Connector on an Ethernet Cable . . . . . . . . . . . . . . . . . . . . . . . . . 127

Figure 38: Connecting a Device to a Network for Out-of-Band Management . . . 128

Figure 39: RJ-45 Connector on an Ethernet Cable . . . . . . . . . . . . . . . . . . . . . . . . 128

Figure 40: Connecting a Device to a Management Console Through a Console

Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129

Figure 41: Connecting a Device Directly to a Management Console . . . . . . . . . . . 129

Figure 42: Connecting a Fiber-Optic Cable to an Optical Transceiver Installed in

a Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130

Figure 43: LCD Panel in an EX3200, EX4200, EX4500, EX4550, or EX8200

Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140

Figure 44: LCD Panel in an EX4300 Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140

Part 4 Installing, Maintaining, and Replacing Components

Chapter 16 Replacing Transceiver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149

Figure 45: Installing a Transceiver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151

Figure 46: Removing an SFP, SFP+, XFP, or a QSFP+ Transceiver . . . . . . . . . . . . 153

Chapter 17 Maintaining and Replacing Fiber-Optic Cable . . . . . . . . . . . . . . . . . . . . . . . . 155

Figure 47: Connecting a Fiber-Optic Cable to an Optical Transceiver Installed in

a Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156

Chapter 18 Contacting Customer Support and Returning the Chassis or

Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159

Figure 48: Location of the Serial Number ID Label on EX3300 Switches . . . . . . . 161

List of Figures

Part 6 Safety and Compliance Information

Chapter 25 Electrical Safety Guidelines and Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . 211

Figure 49: Placing a Component into an Antistatic Bag . . . . . . . . . . . . . . . . . . . . 214

EX3300 Switch Hardware Guide

List of Tables

About the Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xvii

Table 1: Notice Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xviii

Table 2: Text and Syntax Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xviii

Part 1 Overview

Chapter 1 System Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Table 3: EX3300 Switch Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Table 4: CLI Equivalents of Terms Used in Documentation for EX3300

Chapter 2 Chassis Components and Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Table 5: Physical Specifications of the EX3300 Switch Chassis . . . . . . . . . . . . . . . 9

Table 6: LCD Panel Menu Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Table 7: Chassis Status LEDs in an EX3300 Switch . . . . . . . . . . . . . . . . . . . . . . . . . 17

Table 8: Link/Activity LED on the Management Port on an EX3300 Switch . . . . . 19

Table 9: Status LED on the Management Port on an EX3300 Switch . . . . . . . . . . 19

Table 10: Link/Activity LED on the Network Ports and Uplink Ports in EX3300

Table 11: Status LED on the Network Ports in EX3300 Switches . . . . . . . . . . . . . . . 21

Table 12: Status LED on the Uplink Ports in EX3300 Switches . . . . . . . . . . . . . . . . 22

Chapter 3 Cooling System and Airflow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Table 13: Airflow Direction in EX3300 Switch Models . . . . . . . . . . . . . . . . . . . . . . . 23

Chapter 4 Power Supplies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Table 14: Power Consumed by EX3300 Switches . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Chapter 5 Viewing System Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Table 15: Details of a Virtual Chassis Member Switch . . . . . . . . . . . . . . . . . . . . . . 30

Table 16: Status of a Member Switch in a Virtual Chassis . . . . . . . . . . . . . . . . . . . . 31

Table 17: System Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Table 18: Health Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Table 19: Capacity Utilization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Table 20: Chassis Viewer for EX2200 Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Table 21: Chassis Viewer for EX2200-C Switches . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Table 22: Chassis Viewer for EX3200, EX3300, and EX4200 Switches . . . . . . . . . 37

Table 23: Chassis Viewer for EX4300 Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Table 24: Chassis Viewer for EX4500 Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Table 25: Chassis Viewer for EX4550 Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Table 26: Chassis Viewer for EX4600 Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Table 27: Chassis Viewer for EX6210 Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

EX3300 Switch Hardware Guide

Part 2 Site Planning, Preparation, and Specifications

Chapter 6 Preparation Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Chapter 7 Power Specifications and Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Chapter 8 Transceiver and Cable Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Chapter 9 Pinout Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

Table 28: Chassis Viewer for EX8208 Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Table 29: Chassis Viewer for EX8216 Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Table 30: Chassis Viewer for XRE200 External Routing Engines . . . . . . . . . . . . . . 46

Table 31: Site Preparation Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Table 32: EX Series Switch Environmental Tolerances . . . . . . . . . . . . . . . . . . . . . . 53

Table 33: Site Electrical Wiring Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Table 34: Physical Specifications of the EX3300 Switch Chassis . . . . . . . . . . . . . 58

Table 35: Rack Requirements and Specifications . . . . . . . . . . . . . . . . . . . . . . . . . 59

Table 36: Cabinet Requirements and Specifications . . . . . . . . . . . . . . . . . . . . . . . 59

Table 37: AC Power Supply Electrical Specifications for EX3300 Switches . . . . . 65

Table 38: DC Power Supply Electrical Specifications for EX3300 Switches . . . . . 65

Table 39: AC Power Cord Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Table 40: Estimated Values for Factors Causing Link Loss . . . . . . . . . . . . . . . . . 69

Table 41: Software Support for SFP+ Passive Direct Attach Copper Cables for

EX Series Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Table 42: SFP+ Direct Attach Copper Cable Specifications . . . . . . . . . . . . . . . . . . 76

Table 43: Specifications of Cables to Connect to Management Devices . . . . . . . 80

Table 44: Console Port Connector Pinout Information . . . . . . . . . . . . . . . . . . . . . . 83

Table 45: RJ-45 Management Port Connector Pinout Information . . . . . . . . . . . . 85

Table 46: 10/100/1000BASE-T Ethernet Network Port Connector Pinout

Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

Table 47: SFP Network Port Connector Pinout Information . . . . . . . . . . . . . . . . . . 86

Table 48: SFP+ Network Port Connector Pinout Information . . . . . . . . . . . . . . . . 87

Table 49: QSFP+ Network Port Connector Pinout Information . . . . . . . . . . . . . . . 88

Table 50: RJ-45 to DB-9 Serial Port Adapter Pinout Information . . . . . . . . . . . . . 90

Part 3 Initial Installation and Configuration

Chapter 11 Unpacking the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

Table 51: Parts List for an EX3300 Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Chapter 13 Connecting the Switch to Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115

Table 52: Parts and Tools Required for Connecting an EX Series Switch to Earth

Ground . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116

Table 53: Special Instructions to Follow Before Connecting Earth Ground to a

Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118

Part 5 Troubleshooting

Chapter 19 Alarms and Syslog Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167

Table 54: Alarm Terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167

List of Tables

Table 55: Chassis Component Alarm Conditions on EX3300 Switches . . . . . . . 169

Table 56: Summary of Key Alarm Output Fields . . . . . . . . . . . . . . . . . . . . . . . . . . 176

Table 57: Filtering System Log Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177

Table 58: Viewing System Log Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179

EX3300 Switch Hardware Guide

About the Documentation

•

Documentation and Release Notes on page xvii

•

Supported Platforms on page xvii

•

Documentation Conventions on page xvii

•

Documentation Feedback on page xix

•

Requesting Technical Support on page xx

Documentation and Release Notes

To obtain the most current version of all Juniper Networks®technical documentation, see the product documentation page on the Juniper Networks website at

http://www.juniper.net/techpubs/.

If the information in the latest release notes differs from the information in the documentation, follow the product Release Notes.

Juniper Networks Books publishes books by Juniper Networks engineers and subject matter experts. These books go beyond the technical documentation to explore the nuances of network architecture, deployment, and administration. The current list can be viewed at http://www.juniper.net/books.

Supported Platforms

For the features described in this document, the following platforms are supported:

•

EX3300

Documentation Conventions

Table 1 on page xviii defines notice icons used in this guide.

EX3300 Switch Hardware Guide

Table 1: Notice Icons

DescriptionMeaningIcon

Indicates important features or instructions.Informational note

Indicates a situation that might result in loss of data or hardware damage.Caution

Alerts you to the risk of personal injury or death.Warning

Alerts you to the risk of personal injury from a laser.Laser warning

Indicates helpful information.Tip

Table 2 on page xviii defines the text and syntax conventions used in this guide.

Table 2: Text and Syntax Conventions

Represents text that you type.Bold text like this

Fixed-width text like this

Italic text like this

Represents output that appears on the terminal screen.

•

Introduces or emphasizes important new terms.

•

Identifies guide names.

•

Identifies RFC and Internet draft titles.

Represents variables (options for which you substitute a value) in commands or configuration statements.

Alerts you to a recommended use or implementation.Best practice

ExamplesDescriptionConvention

To enter configuration mode, type the configure command:

user@host> configure

user@host> show chassis alarms

No alarms currently active

•

A policy term is a named structure that defines match conditions and actions.

•

Junos OS CLI User Guide

•

RFC 1997, BGP Communities Attribute

Configure the machine’s domain name:

[edit] root@# set system domain-name

domain-name

Table 2: Text and Syntax Conventions (continued)

Text like this

Represents names of configuration statements, commands, files, and directories;configurationhierarchy levels; or labels on routing platform components.

About the Documentation

ExamplesDescriptionConvention

•

To configure a stub area, include the

stub statement at the [edit protocols ospf area area-id] hierarchy level.

•

The console port is labeledCONSOLE.

stub <default-metric metric>;Encloses optional keywords or variables.< > (angle brackets)

| (pipe symbol)

# (pound sign)

[ ] (square brackets)

Indention and braces ( { } )

; (semicolon)

GUI Conventions

Bold text like this

Indicatesa choice between the mutually exclusivekeywords or variables on either side of the symbol. The set of choices is often enclosedin parentheses for clarity.

same line as the configurationstatement to which it applies.

Encloses a variable for which you can substitute one or more values.

Identifies a level in the configuration hierarchy.

Identifies a leaf statement at a configuration hierarchy level.

Representsgraphicaluser interface(GUI) items you click or select.

broadcast | multicast

(string1 | string2 | string3)

rsvp { # Required for dynamic MPLS onlyIndicates a comment specified on the

community name members [ community-ids ]

[edit] routing-options {

static {

route default {

nexthop address; retain;

}

•

In the Logical Interfaces box, select

All Interfaces.

•

To cancel the configuration, click

Cancel.

> (bold right angle bracket)

Documentation Feedback

We encourage you to provide feedback, comments, and suggestions so that we can improve the documentation. You can provide feedback by using either of the following methods:

•

Online feedback rating system—On any page of the Juniper Networks TechLibrary site at http://www.juniper.net/techpubs/index.html, simply click the starsto ratethe content, and use the pop-up form to provide us with information about your experience. Alternately, you can use the online feedback form at

http://www.juniper.net/techpubs/feedback/.

Separates levels in a hierarchy of menu selections.

In the configuration editor hierarchy, select Protocols>Ospf.

EX3300 Switch Hardware Guide

•

E-mail—Sendyour comments to techpubs-comments@juniper.net.Include the document or topic name, URL or page number, and software version (if applicable).

Requesting Technical Support

Technicalproduct support is available through the Juniper NetworksTechnicalAssistance Center (JTAC). If you are a customer with an active J-Care or Partner Support Service support contract, or are covered under warranty, and need post-sales technical support, you can access our tools and resources online or open a case with JTAC.

•

JTAC policies—For a complete understanding of our JTAC procedures and policies, review the JTAC User Guide located at

http://www.juniper.net/us/en/local/pdf/resource-guides/7100059-en.pdf.

•

Product warranties—For product warranty information, visit

http://www.juniper.net/support/warranty/.

•

JTAC hours of operation—The JTAC centers have resources available 24 hours a day, 7 days a week, 365 days a year.

Self-Help Online Tools and Resources

For quick and easy problem resolution, Juniper Networks has designed an online self-service portal calledthe Customer Support Center (CSC) that provides you with the following features:

•

Find CSC offerings: http://www.juniper.net/customers/support/

•

Search for known bugs: http://www2.juniper.net/kb/

•

Find product documentation: http://www.juniper.net/techpubs/

•

Find solutions and answer questions using our Knowledge Base: http://kb.juniper.net/

•

Download the latest versions of software and review release notes:

http://www.juniper.net/customers/csc/software/

•

Search technical bulletins for relevant hardware and software notifications:

http://kb.juniper.net/InfoCenter/

•

Join and participate in the Juniper Networks Community Forum:

http://www.juniper.net/company/communities/

•

Open a case online in the CSC Case Management tool: http://www.juniper.net/cm/

Toverify serviceentitlement byproduct serial number, use our Serial Number Entitlement (SNE) Tool: https://tools.juniper.net/SerialNumberEntitlementSearch/

Opening a Case with JTAC

You can open a case with JTAC on the Web or by telephone.

•

Use the Case Management tool in the CSC at http://www.juniper.net/cm/.

•

Call 1-888-314-JTAC (1-888-314-5822 toll-free in the USA, Canada, and Mexico).

About the Documentation

For international or direct-dial options in countries without toll-free numbers, see

http://www.juniper.net/support/requesting-support.html.

EX3300 Switch Hardware Guide

PART 1

Overview

•

System Overview on page 3

•

Chassis Components and Descriptions on page 9

•

Cooling System and Airflow on page 23

•

Power Supplies on page 27

•

Viewing System Information on page 29

EX3300 Switch Hardware Guide

CHAPTER 1

System Overview

•

EX3300 Switches Hardware Overview on page 3

•

EX3300 Switch Models on page 4

•

EX3300 Switch Hardware and CLI Terminology Mapping on page 5

EX3300 Switches Hardware Overview

Juniper Networks EX Series Ethernet Switches provide scalable connectivity for the enterprise market, including branch offices, campus locations, and data centers. The switches run the Juniper Networks Junos operating system (Junos OS), which provides Layer 2 and Layer 3 switching, routing, and security services. The same Junos OS code base that runs on EX Series switches also runs on all Juniper Networks M Series, MX Series, and T Series routers and SRX Series services gateways.

Juniper Networks EX3300 Ethernet Switches provide connectivity for low-density environments.

This topic describes:

•

EX3300 Switches First View on page 3

•

Uplink Ports on page 4

•

Power over Ethernet Plus Ports on page 4

EX3300 Switches First View

EX3300 switches provide:

•

Either 24 or 48 built-in network ports with 10/100/1000BASE-T Gigabit Ethernet connectors (ports labeled 0 through 23 or 0 through 47)

•

Four uplink ports (ports labeled 0 through 3)

•

Virtual Chassis capability—You can connect up to ten EX3300 switches together to form one unit that you manage as a single chassis, called a Virtual Chassis.

•

Power over Ethernet Plus (PoE+) on all network ports (in PoE+-capable models only)

EX3300 Switch Hardware Guide

Uplink Ports

Each EX3300 switch has four autosensing uplink ports. You can use the uplink ports on the switch to:

•

Connect an access switch to a distribution switch

•

Interconnect member switches of a Virtual Chassis

The uplink ports labeled 0 and 1 (interfaces ge-0/1/0 and ge-0/1/1 or xe-0/1/0 and

xe-0/1/1) are configured by default as network ports. To use uplink ports 0 and 1 to

interconnectVirtual Chassis members, you must configure them as Virtual Chassis ports (VCPs).

The uplink ports labeled 2 and 3 (interfaces ge-0/1/2 and ge-0/1/3 or xe-0/1/2 and

xe-0/1/3) are configured by default as VCPs. You can use these uplink ports to

interconnect Virtual Chassis members. To use uplink ports 2 and 3 as network ports, you must configure them as network ports.

The uplink ports support SFP and SFP+ transceivers. For a list of supported transceivers, see “Pluggable Transceivers Supported on EX3300 Switches” on page 71.

Power over Ethernet Plus Ports

EX3300 switches are available in models with or without PoE+ capability. Models that support PoE+ provide that support on all network ports.

PoE+ ports provide electrical current to devices—such as IP phones, wireless access points, and security cameras—through network cables, thus eliminating the need for separate power cords for those devices.

Documentation

EX3300 Switch Models on page 4•

• Site Preparation Checklist for EX3300 Switches on page 51

EX3300 Switch Models

The EX3300 switch models are available:

•

With 24 or 48 network ports

•

With or without PoE+ capability

NOTE: IEEE 802.3af and IEEE 802.3at powered devices require category 5

or higher Ethernet cables.

•

With front-to-back or back-to-front airflow

•

With AC or DC power supplies

Table 3 on page 5 lists the EX3300 switch models.

Table 3: EX3300 Switch Models

Ports in Which PoE+ Is AvailableAccess PortsModel

Maximum System Power Available for PoE

Direction of Airflow

Chapter 1: System Overview

First Junos OS Release

11.3R1Front-to-back––24 Gigabit EthernetEX3300-24T

11.3R1Front-to-back405 WAll 24 ports24 Gigabit EthernetEX3300-24P

11.3R1Front-to-back––24 Gigabit EthernetEX3300-24T-DC

11.3R1Front-to-back––48 Gigabit EthernetEX3300-48T

11.3R1Back-to-front––48 Gigabit EthernetEX3300-48T-BF

11.3R1Front-to-back740 WAll 48 ports48 Gigabit EthernetEX3300-48P

NOTE: In rare cases, EX3300 switches running a Junos OS release prior to

Release 11.3R4 or Release 11.4R2 might experience some traffic loss or a link failure as a result of non-user-configurable settings that are not optimized. To resolve this issue, upgrade to one of the following Junos OS releases:

•

Junos OS Release 11.3—R4 and later

•

Junos OS Release 11.4—R2 and later

•

Junos OS Release 12.1—R1 and later

Documentation

Front Panel of an EX3300 Switch on page 10•

• EX3300 Switches Hardware Overview on page 3

EX3300 Switch Hardware and CLI Terminology Mapping

This topic describes the hardware terms used in EX3300 switch documentation and the corresponding terms used in the Junos OS command line interface (CLI). See

Table 4 on page 6.

EX3300 Switch Hardware Guide

Table 4: CLI Equivalents of Terms Used in Documentation for EX3300 Switches

HardwareItem (Field as Displayed in CLI)

Chassis

FPC (n)

Description (Field as Displayed in CLI)

•

EX3300-24T

•

EX3300-24P

•

EX3300-24T-DC

•

EX3300-48T

•

EX3300-48T-BF

•

EX3300-48P

switches:

Abbreviated name of the Flexible PIC Concentrator (FPC)

One of the following:

•

EX3300-24T

•

EX3300-24P

•

EX3300-24T-DC

•

EX3300-48T

•

EX3300-48T-BF

•

EX3300-48P

Value (Field as Displayed in CLI)

Value of n is always 0.On EX3300 standalone

Item in Documentation

Switch chassis–One of the following:

The switch does not have actual FPCs. In this case, FPC refers to the switch itself.

Additional Information

“Chassis Physical Specifications for EX3300 Switches” on page 9

Understanding Interface Naming Conventions on EX Series Switches

PIC (n)

On EX3300 Virtual Chassis:

•

Member ID of the switch within the Virtual Chassis

Abbreviated name of the Physical Interface Card (PIC)

•

24x 10/100/1000 BASE-T

•

48x 10/100/1000 BASE-T

n is a value in the range of 0-9.

n is a value in the range of 0–1.

PIC 0One of the following:

PIC 14x GE/XE SFP+

In this case, the FPC number refers to the member ID assignedto the switch.

The switch does not have actual PIC devices; see entries for PIC 0 through PIC 1 for the equivalent item on the switch.

Built-in network ports on the front panel of the switch

Built-in uplink ports on the front panel of the switch

Understanding EX Series Virtual Chassis Components

Understanding Interface Naming Conventions on EX Series Switches

“Front Panel of an EX3300 Switch” on page 10

Chapter 1: System Overview

Table 4: CLI Equivalents of Terms Used in Documentation for EX3300 Switches (continued)

HardwareItem (Field as Displayed in CLI)

Xcvr (n)

Documentation

Description (Field as Displayed in CLI)

Abbreviated name of the transceiver

• EX3300 Switches Hardware Overview on page 3

Value (Field as Displayed in CLI)

to the number of the port in which the transceiver is installed.

Item in Documentation

Optical transceiversn is a value equivalent

Power supplyValue of n is always 0.Built-in power supplyPower Supply (n)

Fan tray–Built-in fan trayFan Tray

Additional Information

“Pluggable Transceivers Supported on EX3300 Switches” on page 71

“Power Supply in EX3300 Switches” on page 27

“Cooling System and Airflow in an EX3300 Switch” on page 23

EX3300 Switch Hardware Guide

CHAPTER 2

Chassis Components and Descriptions

•

Chassis Physical Specifications for EX3300 Switches on page 9

•

Front Panel of an EX3300 Switch on page 10

•

Rear Panel of an EX3300 Switch on page 11

•

LCD Panel in EX3300 Switches on page 12

•

Chassis Status LEDs in EX3300 Switches on page 17

•

Management Port LEDs in EX3300 Switches on page 18

•

Network Port and Uplink Port LEDs in EX3300 Switches on page 19

Chassis Physical Specifications for EX3300 Switches

The EX3300 switch chassis is a rigid sheet-metal structure that houses the hardware components. Table 5 on page 9 summarizes the physical specifications of the EX3300 switch chassis.

Table 5: Physical Specifications of the EX3300 Switch Chassis

Chassis width

Weight

Documentation

ValueDescription

1.75 in. (4.45 cm)Chassis height

•

17.5 in. (44.5 cm)

•

19 in. (48.2 cm) with mounting brackets attached

12 in. (30.5 cm)Chassis depth

•

EX3300-24T: 10 lb (4.6 kg)

•

EX3300-24P: 11.6 lb (5.3 kg)

•

EX3300-24T-DC: 9.8 lb (4.5 kg)

•

EX3300-48T: 10.8 lb (4.9 kg)

•

EX3300-48T-BF: 10.8 lb (4.9 kg)

•

EX3300-48P: 12.8 lb (5.8 kg)

Rack Requirements on page 58•

• Cabinet Requirements on page 59

g021216

0 1 2 3

ALM

EX3300 PoE+

SYS

MST

LCD panel

Network ports

Chassis status LEDs

Enter buttonSFP+ uplink ports

Menu button

EX3300 Switch Hardware Guide

• Mounting an EX3300 Switch on page 102

• Installing and Connecting an EX3300 Switch on page 101

Front Panel of an EX3300 Switch

The front panel of an EX3300 switch consists of the following components:

•

Network ports:

•

Depending on the switch model, 24 or 48 10/100/1000BASE-T Gigabit Ethernet ports (ports labeled 0 through 23 or 0 through 47)

•

Power over Ethernet Plus (PoE+) available in all network ports in EX3300-24P and EX3300-48P models

•

Power over Ethernet Plus (PoE+) not available in any network port in EX3300-24T, EX3300-24T-DC, EX3300-48T, and EX3300-48T-BF models

•

Four built-in uplink ports:

•

The uplink ports support 1-gigabit small form-factor pluggable (SFP) transceivers, 10-gigabit small form-factor pluggable (SFP+) transceivers, or a combination of these transceivers.

•

Ports labeled 0 and 1 are, by default, configured as network ports. You can configure these ports as Virtual Chassis ports (VCPs).

•

Ports labeled 2 and 3 are, by default, configured as VCPs. You can configure these ports as network ports.

•

Network port and uplink port LEDs

•

Three chassis status LEDs

•

LCD panel and the LCD navigation buttons

•

Air intake or air exhaust, depending on the switch model—The intake or exhaust is located immediately below the top edge of the front panel.

Figure 1 on page 10 shows the front panel of an EX3300 switch with 48 Gigabit Ethernet

ports. Figure 2 on page 11 shows the front panel of an EX3300 switch with 24 Gigabit Ethernet ports.

Figure 1: Front Panel of an EX3300 Switch with 48 Gigabit Ethernet Ports

g021217

0 1 2 3

ALM

EX3300

SYS

MST

LCD panel

Network ports

Chassis status LEDs

Enter buttonSFP+ uplink ports

Menu button

Chapter 2: Chassis Components and Descriptions

Figure 2: Front Panel of an EX3300 Switch with 24 Gigabit Ethernet Ports

Documentation

Chassis Status LEDs in EX3300 Switches on page 17•

• Network Port and Uplink Port LEDs in EX3300 Switches on page 19

• RJ-45 Port, QSFP+ Port, SFP+ Port, and SFP Port Connector Pinout Information on

page 85

• Rear Panel of an EX3300 Switch on page 11

• EX Series Virtual Chassis Overview

• Installing a Transceiver on page 149

• Removing a Transceiver on page 151

• Installing and Connecting an EX3300 Switch on page 101

Rear Panel of an EX3300 Switch

The rear panel of the EX3300 switch consists of the following components:

•

Management Ethernet port

•

USB port

•

Console port

•

Protective earthing terminal

•

Redundant power system (RPS) port

•

ESD point

•

Air intake or air exhaust, depending on the switch model

•

Serial number ID label

•

AC power cord inlet or DC power terminal block

Figure 3 on page 12 shows the rear panel of an EX3300 switch with AC power supply.

The power cord retainer extends out of the chassis by 3 in. (7.62 cm).

AC power cord inlet

Air exhaust with fan

Serial number ID label

USB port

Management Ethernet por t

Console RPS

port

Protective earthing terminal

ESD point

g021202

g021203

DC power terminals

Air exhaust with fan

Serial number ID label

USB port

Management Ethernet por t

Console RPS

port

Protective earthing terminal

ESD point

EX3300 Switch Hardware Guide

Figure 3: Rear Panel of an EX3300 Switch with an AC Power Supply

Figure 4 on page 12 shows the rear panel of an EX3300 switch with DC power supply.

Figure 4: Rear Panel of an EX3300 Switch with a DC Power Supply

Documentation

Front Panel of an EX3300 Switch on page 10•

• USB Port Specifications for an EX Series Switch on page 84

• Cooling System and Airflow in an EX3300 Switch on page 23

• Power Supply in EX3300 Switches on page 27

• Prevention of Electrostatic Discharge Damage on page 213

• Connecting Earth Ground to an EX Series Switch on page 115

• Installing and Connecting an EX3300 Switch on page 101

LCD Panel in EX3300 Switches

The LCD panel on the front panel of the switch shows two lines of text, each of which can contain a maximum of 16 characters. The LCD panel displays a variety of information about the switch and also provides a menu to perform basic operations such as initial setup and reboot.

There are two navigation buttons—Menu and Enter—to the right of the LCD panel.

See Figure 5 on page 13.

Chapter 2: Chassis Components and Descriptions

Figure 5: LCD Panel

You can configure the second line of the LCD panel to display a custom message. If the LCD panel is configured to display a custom message, the Menu button and the Enter button are disabled. See “Configuring the LCD Panel on EX Series Switches (CLI

Procedure)” on page 143.

The LCDpanel has a backlight. If the LCD panel is idle for 60 seconds, the backlight turns off. You can turn on the backlight by pressingthe Menu or Enter button once. After turning on the backlight, you can toggle between the LCD panel menus by pressing the Menu button and navigate through the menu options by pressing the Enter button.

This topic describes:

LCD Panel Modes

•

LCD Panel Modes on page 13

•

LCD Panel Menus on page 14

The LCD panel operates in four modes: boot, idle, status, and maintenance.

The LCD panel operates in boot mode during switch reboot. The boot mode displays the key milestones in the switch boot process. The boot mode does not have any menu options. After the boot process is complete, the LCD panel automatically reverts to the Idle menu.

In an EX3300 switch that is not a member of a Virtual Chassis, the first line of the LCD panel displays:

•

The slot number—For a standalone EX3300 switch, the slot number is always 00.

•

The role of the switch—For a standalone EX3300 switch, the role is always RE (for master).

•

Hostname

In an EX3300 switch that is a member of a Virtual Chassis, the first line of the LCD panel displays:

•

The slot number (the member ID for the Virtual Chassis member)

•

Roleof the switch in a Virtual Chassis(RE for master,BK for backup, and LC for linecard member)

•

Hostname

In the idle mode, the second line displays the mode of the network ports’ StatusLED and the number of chassis alarms. The number of alarms is updated every second.

EX3300 Switch Hardware Guide

In the status mode, the second line displays:

•

Virtual Chassis port (VCP) status (for an EX3300 switch that is a member of a Virtual Chassis)

•

Status of the power supply

•

Status of the fan and temperature

•

Version of Junos OS for EX Series switches loaded on the switch

In the maintenance mode, the second line displays one of the following options that you can use to configure and troubleshoot the switch:

•

System halt

•

System reboot

•

Load rescue

•

Request VC port (for an EX3300 switch that is a member of a Virtual Chassis)

•

Factory default

•

System EZSetup

LCD Panel Menus

The LCD panel has three menus: Idle, Status, and Maintenance. Toggle between the LCD panel menus by pressing the Menu button. Navigate throughthe menu options by pressing the Enter button.

Table 6 on page 14 describes the LCD panel menu options.

Table 6: LCD Panel Menu Options

DescriptionMenu

IDLE

In the Idle menu:

•

Press Enter to cycle through the Status LED modes:

•

SPD (speed)

•

ADM (administrative status)

•

DPX (duplex)

•

POE (Power over Ethernet)

See “Network Port and Uplink Port LEDs in EX3300 Switches” on page 19 for information on the Status LED modes.

•

Press Menu to exit the Idle menu and go to the Status menu.

Table 6: LCD Panel Menu Options (continued)

DescriptionMenu

Chapter 2: Chassis Components and Descriptions

STATUS

The Status menu has the following options:

•

Show VCP status—Choose one of the following:

•

Press the Enter button to display the Virtual Chassis port (VCP) status: Up, Down, Disabled.

NOTE: This option is available only for an EX3300 switch that is a member of a Virtual Chassis

configuration.

•

Press the Menu button to go to the next option in the Status menu.

•

Show PSU status—Choose one of the following:

•

Press the Enter button to display the status of the power supply: OK, Failed, Absent.

•

Press the Menu button to go to the next option in the Status menu.

•

Show Environment status—Choose one of the following:

•

Press the Enter button to display the status of the fan and temperature:

•

Fan status: OK, Failed, Absent

•

Temp status: OK, High, Shutdown

•

Press the Menu button to go to the next option in the Status menu.

•

Show Junos version—Choose one of the following:

•

Press the Enter button to display the version of Junos OS for EX Series switches loaded on the switch.

•

Press the Menu button to go to the next option in the Status menu.

•

EXIT STAT MENU?—Choose one of the following:

•

Press the Enter button to exit the Status menu. Then press the Menu button to go to the Maintenance menu.

•

On an EX3300 switch thatis a member of a Virtual Chassis configuration,press the Menu button to return to the Show VCP status option.

NOTE: This option is available only for an EX3300 switch that is a member of a Virtual Chassis

configuration.

If you do not want users to use Status menu options, disable the entire menu or individual menu options. See

“Configuring the LCD Panel on EX Series Switches (CLI Procedure)” on page 143.

EX3300 Switch Hardware Guide

Table 6: LCD Panel Menu Options (continued)

DescriptionMenu

MAINT (Maintenance Menu)

The Maintenance menu has the following options to configure and troubleshoot the switch:

•

SYSTEM HALT?—Choose one of the following:

•

Press the Enter button to halt the switch. Press the Enter button again to confirm the halt.

•

Press the Menu button to go to the next option in the Maintenance menu.

•

SYSTEM REBOOT?—Choose one of the following:

•

Press the Enter button to reboot the switch. Press the Enter button again to confirm the reboot.

•

Press the Menu button to go to the next option in the Maintenance menu.

•

LOAD RESCUE?—Choose one of the following:

•

Press the Enter button to roll back the switch to the rescue configuration. Press the Enter button again to confirm the rollback.

•

Press the Menu button to go to the next option in the Maintenance menu.

•

REQUEST VC PORT?—Choose one of the following:

•

Press the Enter button to configure an uplink port in an EX3300 switch or to delete a VCP from the switch configuration.

NOTE: This option is available only for an EX3300 switch that is a member of a Virtual Chassis

configuration.

•

Press the Menu button to go to the next option in the Maintenance menu.

•

FACTORY DEFAULT?—Choose one of the following:

•

Press the Enter button to restore the switch to the factory default configuration. Press the Enter button again to confirm the restoration.

•

Press the Menu button to go to the next option in the Maintenance menu.

•

ENTER EZSETUP?—Choose one of the following:

•

Press the Enter button to launch EZSetup. Press the Enter button again to confirm the launch.

NOTE: You can use the ENTER EZSETUP option only if the switch is in the factory default configuration.

For information about EZSetup,see “Connecting andConfiguring an EX Series Switch(J-WebProcedure)”

on page 139.

•

Press the Menu button to go to the next option in the Maintenance menu.

•

EXIT MAINT MENU?—Choose one of the following:

•

Press the Enter button to exit the Maintenance menu. Then press the Menu button to go to the Idle menu.

•

Press the Menu button to go to the System Halt option.

If you do not want users to use Maintenance menu options, disable the entire menu or individual menu options. See “Configuring the LCD Panel on EX Series Switches (CLI Procedure)” on page 143.

Documentation

Front Panel of an EX3300 Switch on page 10•

• Connecting and Configuring an EX Series Switch (CLI Procedure) on page 135

Chassis Status LEDs in EX3300 Switches

The front panel of an EX3300 switch has three chassis status LEDs labeled ALM, SYS, and MSTon the far right side of the panel, abovethe uplink ports (see Figure 6 on page17).

You can view the colors of the LEDs remotely through the CLI by issuing the operational mode command show chassis lcd.

Figure 6: Chassis Status LEDs in an EX3300 Switch

Table 7 on page 17 describes the chassis status LEDs in an EX3300 switch, their colors

and states, and the status they indicate.

Chapter 2: Chassis Components and Descriptions

Table 7: Chassis Status LEDs in an EX3300 Switch

State and DescriptionColorLED Label

There is no alarm or the switch is halted.UnlitALM (Alarm)

Red

Amber

There is a major alarm.

NOTE: When you connect power to the switch, the Alarm

(ALM) LED lights red. This behavior is normal. Plugging an active Ethernet cable into the management (MGMT) port on the switch completes the network link and turns off the ALM LED. (See “Connecting a Device to a Network for Out-of-Band

Management” on page 127.)

Connecting the switch to a dedicated management console instead of a network does not affect the ALM LED. The LED remains red until the switch is connected to a network.

There is a minor alarm.

NOTE: The Alarm (ALM) LED lights amber if you commit a

configuration to make it active on the switch and do not also create a rescue configuration to back it up. To save the most recentlycommitted configuration as the rescue configuration, enter the operational mode command request system configuration rescue save.

•

GreenSYS (System)

On steadily—Junos OS for EX Series switches has been loaded on the switch.

•

Blinking—The switch is booting.

•

Off—The switch is powered off or is halted.

g027006

Link/Activity

LED

Status LED

EX3300 Switch Hardware Guide

Table 7: Chassis Status LEDs in an EX3300 Switch (continued)

State and DescriptionColorLED Label

Documentation

GreenMST (Master)

In a standalone EX3300 switch:

•

On steadily—The switch is functioning normally.

•

Off—The switch is powered off or is halted.

In a Virtual chassis configuration:

•

On steadily—The switch is the master in the Virtual Chassis configuration.

•

Blinking—The switch is the backup in the Virtual Chassis configuration.

•

Off—The switch is a linecard member in the Virtual Chassis configuration or is halted.

A major alarm (red) indicates a critical error condition that requires immediate action.

A minor alarm (amber) indicates a noncritical condition that requires monitoring or maintenance. A minor alarm that is left unchecked might cause interruption in service or performance degradation.

All three LEDs can be lit simultaneously.

Front Panel of an EX3300 Switch on page 10•

• Chassis Component Alarm Conditions on EX3300 Switches on page 168

• Checking Active Alarms with the J-Web Interface on page 175

• Understanding Alarm Types and Severity Levels on EX Series Switches on page 167

Management Port LEDs in EX3300 Switches

The managementport on the rear panel of an EX3300 switch has two LEDs that indicate link/activity and port status (see Figure 7 on page 18).

Figure 7: LEDs on the Management Port on an EX3300 Switch

Table 8 on page 19 describes the Link/Activity LED.

012345678910111213141516171819202122

g027005

Link/Activity LED Status LED

Chapter 2: Chassis Components and Descriptions

Table 8: Link/Activity LED on the Management Port on an EX3300 Switch

State and DescriptionColorLED

•

GreenLink/Activity

Blinking—The port and the link are active, and there is link activity.

•

On steadily—The port and the link are active, but there is no link activity.

•

Off—The port is not active.

Table 9 on page 19 describes the Status LED.

Table 9: Status LED on the Management Port on an EX3300 Switch

State and DescriptionLCD IndicatorLED

Indicates the speed. The speed indicators are:

•

One blink per second—10 Mbps

•

Two blinks per second—100 Mbps

•

Three blinks per second—1000 Mbps

SPDStatus

Connecting a Device to a Network for Out-of-Band Management on page 127•

Documentation

Network Port and Uplink Port LEDs in EX3300 Switches

Each network port and uplink port on the front panel of an EX3300 switch has two LEDs that indicate link/activityand port status. SeeFigure 8 on page19 and Figure 9 on page 20.

Figure 8: LEDs on the Network Ports on the Front Panel

g021204

Link/Activity LED

Status LED

Port 0

Port 2

Port 3

Port 1

0 1 2 3

ALM

EX3300 PoE+

SYS

MST

EX3300 Switch Hardware Guide

Figure 9: LEDs on the Uplink Ports

Table 10 on page 20 describes the Link/Activity LED.

Table 10: Link/Activity LED on the Network Ports and Uplink Ports in EX3300 Switches

State and DescriptionColorLED

•

GreenLink/Activity

Blinking—The port and the link are active, and there is link activity.

•

On steadily—The port and the link are active, but there is no link activity.

•

Off—The port is not active.

The LEDs labeled Status LED in Figure 8 on page 19 and Figure 9 on page 20 indicate the status of one of the four port parameters—speed, administrative status, duplex mode, and Power over Ethernet Plus (PoE+) status. From the Idle menu of the LCD, use the

Enter button on the LCDpanel to toggle betweenthe SPD, ADM, DPX, and POE,indicators.

Table 12 on page 22 describes the Status LED on the network ports and table describes

the Status LED on the uplink ports.

Chapter 2: Chassis Components and Descriptions

Table 11: Status LED on the Network Ports in EX3300 Switches

State and DescriptionLCD IndicatorLED

LED: SPDStatus

LED: ADM

LED: DPX

LED: POE

Indicates the speed.

The status indicators are:

•

Unlit—10 Mbps

•

Blinking—100 Mbps

•

On steadily—1000 Mbps

Indicates the administrative status. The status indicators are:

•

On steadily—Port is administratively enabled.

•

Off—Port is administratively disabled.

Indicates the duplex mode.

The status indicators are:

•

Green—Port is set to full-duplex mode.

•

Unlit—Port is set to half-duplex mode.

Indicates the PoE status.

The status indicators are:

•

On steadily—PoE is available on the port.

•

Blinking—PoEis availableon the port, but no poweris drawn from the port because of one of the following:

•

No device that draws power from the port is connected to the port.

•

A device that draws power from the port is connected to the port, but the device is not drawing any power from the port.

•

Unlit—PoE is not enabled on the port.

EX3300 Switch Hardware Guide

Table 12: Status LED on the Uplink Ports in EX3300 Switches

State and DescriptionLCD IndicatorLED

Documentation

LED: SPDStatus

Indicates the speed.

The status indicators are:

•

Unlit—10/100 Mbps

•

Blinking—1000 Mbps

•

On steadily—10 Gbps

LED: ADM

LED: DPX

Indicates the administrative status. The status indicators are:

•

On steadily—Port is administratively enabled.

•

Off—Port is administratively disabled.

Indicates the duplex mode.

The uplink ports are always set to full-duplex; therefore, the LED for uplink ports is always green.

LED: POE

Indicates the PoE status.

PoEis not enabled onuplink ports; therefore, the LED for uplink ports is always unlit.

• Front Panel of an EX3300 Switch on page 10

• Configuring Gigabit Ethernet Interfaces (CLI Procedure)

• Configuring Gigabit Ethernet Interfaces (J-Web Procedure)

CHAPTER 3

Cooling System and Airflow

•

Cooling System and Airflow in an EX3300 Switch on page 23

Cooling System and Airflow in an EX3300 Switch

The cooling system in an EX3300 switch consists of two fans: one along the rear of the chassis and another along the left side of the chassis. The fans provide front-to-back or back-to-front chassis cooling depending on the switch model.

This topic describes:

•

Airflow Direction in EX3300 Switch Models on page 23

•

Front-to-Back Airflow on page 24

•

Back-to-Front Airflow on page 24

Airflow Direction in EX3300 Switch Models

Table 13 on page 23 shows the different EX3300 switch models and their direction of

airflow.

Table 13: Airflow Direction in EX3300 Switch Models

Direction of AirflowModel

Front-to-backEX3300-24T

Front-to-backEX3300-24P

Front-to-backEX3300-24T-DC

Front-to-backEX3300-48T

Back-to-frontEX3300-48T-BF

Front-to-backEX3300-48P

g021205

Chassis rear

Chassis front

Fan

Air intake

Fan air exhaust

Air intake

Air exhaust

EX3300 Switch Hardware Guide

Front-to-Back Airflow

In front-to-back airflow models, the air intake is located on the front of the chassis. Cool air is pulled into the chassis and pushed toward the rear of the chassis. Hot air exhausts from the rear of the chassis. See Figure 10 on page 24.

Figure 10: Front-to-Back Airflow Through the EX3300 Switch Chassis

Back-to-Front Airflow

In back-to-front airflow models, the air intake is located on the rear of the chassis. Cool air is pulled into the chassis and pushed toward the front of the chassis. Hot air exhausts from the front of the chassis. See Figure 11 on page 25.

g021247

Chassis rear

Chassis front

Fan

Air exhaust

Fan air

intake

Air exhaust

Air intake

Chapter 3: Cooling System and Airflow

Figure 11: Back-to-Front Airflow Through the EX3300 Switch Chassis

Documentation

Under normal operating conditions, the fans operate at moderate speeds for minimal noise. Temperature sensors in the chassis monitor the temperature within the chassis. If any fan fails or if the temperature inside the chassis rises above the threshold, the switch raises an alarm and all functioning fans operate at a higher speed than normal. If the temperature inside the chassis rises above the threshold, the switch shuts down automatically.

• Rear Panel of an EX3300 Switch on page 11

• Chassis Status LEDs in EX3300 Switches on page 17

• Understanding Alarm Types and Severity Levels on EX Series Switches on page 167

• Prevention of Electrostatic Discharge Damage on page 213

EX3300 Switch Hardware Guide

CHAPTER 4

Power Supplies

•

Power Supply in EX3300 Switches on page 27

Power Supply in EX3300 Switches

The power supply in EX3300 switches is built in along the rear panel of the chassis, with an AC power cord inlet or DC power terminal block on the rear panel to connect power to the switch.

NOTE: After powering on the switch, wait for at least 60 seconds before

powering it off. After powering off the switch, wait for at least 60 seconds before powering it back on.

Afterthe switch has beenpowered on, it cantake up to 60 secondsfor status indicators—suchasshow chassis command outputand messageson the LCD panel—toindicate that the power supplyis functioning normally. Ignore error indicators that appear during the first 60 seconds.

Table 14 on page 27 lists the power consumed by each EX3300 switch model. The

maximum power available on a PoE+ port is 15.4 W.

Table 14: Power Consumed by EX3300 Switches

Number of PoE-Enabled PortsModel Number

24EX3300-24P

Maximum Power Consumed by the Switch

drawn)

Maximum System Power Available for PoE

–50 W–EX3300-24T

405 W60 W (when no PoE power is

–50 W–EX3300-24T-DC

–76 W–EX3300-48T

–76 W–EX3300-48T-BF

EX3300 Switch Hardware Guide

Table 14: Power Consumed by EX3300 Switches (continued)

Documentation

Number of PoE-Enabled PortsModel Number

48EX3300-48P

Maximum Power Consumed by the Switch

Maximum System Power Available for PoE

740 W91 W (when no PoE power is

drawn)

• AC Power Cord Specifications for EX3300 Switches on page 66

• Rear Panel of an EX3300 Switch on page 11

• Power Specifications for EX3300 Switches on page 65

• Connecting AC Power to an EX3300 Switch on page 121

• Connecting DC Power to an EX3300 Switch on page 123

• Connecting Earth Ground to an EX Series Switch on page 115

CHAPTER 5

Viewing System Information

•

Dashboard for EX Series Switches on page 29

Dashboard for EX Series Switches

NOTE: This topic applies only to the J-Web Application package.

When you log in to the J-Web user interface, the dashboard for the Juniper Networks EX Series Ethernet Switches appears. Use the dashboard to view system information.

The Update Available windowappears if there is a latestupdate of the J-Web Application package available on the Juniper Networks server. This window is enabled by the auto update feature of J-Web.

NOTE:

•

The Update Available window will not appear when you log in, if you have not selected the Check for updatesautomaticallyon every login in the Update Preference section in the Maintain > Update J-Web side pane. By default, the Check for update automatically on every login is selected.

•

If you choose Update Later, you can updateto the latest J-Web Application package by clicking the orange icon next to Update Available on the top pane of the J-Web interface or through Maintain > Update J-Web.

The dashboard comprises a graphical chassis viewer and four panels.

This topic describes:

•

Graphical Chassis Viewer on page 30

•

System Information Panel on page 31

•

Health Status Panel on page 33

•

Capacity Utilization Panel on page 35

•

Alarms Panel on page 35

EX3300 Switch Hardware Guide

•

File System Usage on page 36

•

Chassis Viewer on page 36

Graphical Chassis Viewer

The Dashboard panel displays a graphical view of the chassis of a switch. In a Virtual Chassis, it displays a graphical view of each member switch.

In a Virtual Chassis, the default valuesare shown on the Dashboardpanel when no chassis image is clicked. The panel displays the value for a switch if you click its image.

NOTE: If the member switch is not present, inactive, or not provisioned, you

cannot expand the member switch image.

In J-Web Application package Release 14.1X53-A2, you can form a Virtual Chassisusing EX4600 andEX4300 switches.When in a mixed VirtualChassis consisting of EX4600 switches and EX4300switches, the EX4600 switches can be the master, backup,or in the linecard role, whilethe EX4300 switches must be in the linecard role.

Table 15 on page 30 lists the details that are displayed on each member switch.

Table 15: Details of a Virtual Chassis Member Switch

ExampleDetails

EX3300Model number of the member switch

Assigned ID that applies to the entire Virtual Chassis configuration

Role of the member switch

Status of the member switch

The status of the member switch is displayed on the image of the switch. If the member switchappears dimmed, it means the switchis not present, is inactive, or is not provisioned in theVirtual Chassis.If the member switchdoes not appear dimmed, itmeans the switch is present and is active.

ID 2

NOTE: If the member switch is not provisioned, the serial number

of the switch is displayed instead of its ID.

Master

Possible roles are: Master, Backup, or Linecard

Prsnt

Possible statuses are: Prsnt, NotPrsnt, Inactive, or Unprvsnd

Table 16 on page 31 describes the possible status of a member switch.

Table 16: Status of a Member Switch in a Virtual Chassis

It means the member switchIt appears asIf the member switch is

Chapter 5: Viewing System Information

Not present

Inactive

Not provisioned

PrsntPresent

NotPrsnt

dimmed and

Inactive

dimmed and

Unprvsnd

Has established physical and logical connections with Virtual Chassis member switches.

Has been disconnected from the existing Virtual Chassis.dimmed and

Has established physicalconnections, but is unableto establish logical connections.

Cannot synchronize with the existing preprovisioned Virtual Chassis.

Click Rear View for a graphical view of the rear panel of the switch.

Click Preferences to choose which panels must be displayed and set the refresh interval forchassis viewer information. Click OK to saveyour changesand return tothe dashboard or click Cancel to return to the dashboard without saving changes.

NOTE: You can drag the various panels to different locations in the J-Web

window.

System Information Panel

Table 17: System Information

System name

Device model

DescriptionField

Indicates the local name of the EX Series switch. The local name of the EX Series switches changes when an individual image is clicked.

Indicatesthe model of the EX Series switch.In a Virtual Chassis configuration,to indicate the model of aswitch, click the image of that switch.

NOTE: In a Virtual Chassis setup for an EX6210, EX8208, or

EX8216 switch, the Device model field displays details of the master Routing Engine. To view details of a member, select it.

EX3300 Switch Hardware Guide

Table 17: System Information (continued)

DescriptionField

Inventory details

Indicates the following:

•

For EX3200 switches; and forEX2200, EX2200-C, EX3300, EX4200, EX4300, EX4500, EX4550, and EX4600 switches that are not configured as Virtual Chassis, the value displayed in Inventory details field is always 1 FPC. FPC is a legacy term for a slot in a large Juniper Networks chassis; which simply refers to the standalone switch.

•

For EX2200 and EX2200-C switches configured asa Virtual Chassis, the value displayed in the Inventory details field is 1–4 FPC, with the number corresponding to the number of member switches.

•

For EX3300 switches configured as a Virtual Chassis, the value displayed in the Inventory details field is 1–6 FPC, with the number corresponding to the number of member switches.

NOTE: For Junos OSRelease14.1X53-D10and later,EX3300

switches configured as a Virtual Chassis display the value 1–10 FPC in the Inventory details field.

•

For EX4200, EX4500, EX4550, and EX4600 switches configured as a Virtual Chassis, the value displayed in the Inventory details field is 1–10 FPC, with the number corresponding to the number of member switches.

•

For EX6210 switches, the values displayed in the Inventory details field are 1–2 CB and 1–9 FPC. CB, or Control Board, refers to the SRE module. FPC refers to line cards and the FPC within the CB.

•

For an EX8208 switch, the values displayed in Inventory details field are 1–3 CB and 0–8 FPC. CB, or Control Board, refers to SRE and SF modules. FPC refers to line cards.

•

For EX8216 switches, the values displayed in Inventory details field are 1–2 CB and 0–16 FPC. CB, or Control Board, refers to RE modules and FPC refers to line cards.

•

For an XRE200 ExternalRoutingEngine in an EX8200 Virtual Chassis, the value displayed in Inventory details is 1 XRE. XRE refers to RE modules. For XRE200 External Routing Engines configured asa Virtual Chassis, the values displayed in Inventory details are 1–2 XRE and 0–4 LCC, where LCC refers to the EX8200 line card chassis.

Junos image

Boot image

Indicatesthe versionof the Junos OS image. In a Virtual Chassis configuration, the Junos OS image of the master switch is displayed by default. To display the Junos OS image of a specific switch, click the image of that switch.

Indicatesthe versionof the boot image that is used. In a Virtual Chassis configuration, the boot image of the master switch is displayed by default. To display the boot image of a specific switch, click the image of that switch.

Table 17: System Information (continued)

Chapter 5: Viewing System Information

DescriptionField

Device uptime

Indicates the time since the last reboot. In a Virtual Chassis configuration,to displaythe uptime of the specificswitch, click the image of that switch.

Indicates the time when the switch was last configured.Last configured time

Health Status Panel

Table 18: Health Status

DescriptionField

EX2200, EX2200-C, EX3200, EX3300, EX4200, and EX4300 Switches

Memory util.

Flash

Indicates the memory used in the Routing Engine. In a Virtual Chassis configuration, the memory utilization value of the master Routing Engine is displayed.

NOTE: In EX4300 and EX4600 Virtual Chassis, to display the Routing Engine memory utilization of

the master or backup, click the respective image. J-Web is supported on EX4600 switches only in J-Web Application package Release 14.1X53-A2.

Indicates the usage and capacity of internal flash memory and any external USB flash drive.

NOTE: In EX4300 Virtual Chassis, the flash memory utilization of the master switch is displayed by

default. To display the flash memory utilization along with the internal and external flash memory utilization details for each switch or line card, mouse over individual switch or line card images.

In EX4600 Virtual Chassis,to displaythe flash memory utilization along with the internaland external flash memory utilization details of each switch or line card mouse over the green-colored indicator.

Temp.

CPU load

Indicates the chassis temperature status. Temperatures are listed in Celsius and the corresponding Fahrenheit values.

NOTE: The Temp field is unavailable for a standalone EX2200-C switch.

The Temp field is dynamically available for an EX2200 Virtual Chassis switch based on the model of the member clicked.

NOTE: In EX4300 Virtual Chassis, the temperature of the master Routing Engine is displayed by

default. To display the temperature of the Routing Engine of any switch, click the image of that switch.

In EX4600 Virtual Chassis, to display the temperature of the Routing Engine of each switch, mouse over the green-colored indicator.

Indicates the average CPU usage over 15 minutes. In a Virtual Chassis configuration, on loading the master or backup switch, the CPU load for that switch's Routing Engine is displayed by default. To display the CPU load for a specific switch's Routing Engine, click the image of that switch.

EX3300 Switch Hardware Guide

Table 18: Health Status (continued)

DescriptionField

Fan status

Indicates the status of the fans in the fan tray. The possible values are OK, Failed, and Absent. In a Virtual Chassis configuration, the fan status of the master switch is displayed by default. To display the fan status for any switch , click the image of that switch.

NOTE: The Fan status field is unavailable for a standalone EX2200-C switch.

The Fan status field is dynamically available for an EX2200 Virtual Chassis switch based on the model of the member clicked.

In EX4600 Virtual Chassis, mouse over the fan icon to display the fan status of all the switches.

EX4500 and EX4550 Switches

Memory util.

Temp.

Fan status

Indicates the memory used in the Routing Engine. In a Virtual Chassis configuration, the memory utilization value of the master Routing Engine is displayed.

Indicates the usage and capacity of internal flash memory and any external USB flash drive.Flash

Indicates the chassis temperature status. Temperatures in the dashboard are listed in Celsius and the corresponding Fahrenheit values.

NOTE: The Temp field is unavailable for an EX4500 switch.

Indicates the average CPU usage over 15 minutes.CPU load

Indicates the status of the fans in the fan tray. The possible values are OK, Failed, and Absent. This field also indicates the direction of airflow of the fan tray. The possible values are Front to back and

Back to front.

EX6210 Switches

Memory util.

EX8208 Switches

Memory util.

EX8216 Switches

Indicates the memory used in the master Routing Engine. Click the backup Routing Engine to view the memory used in the backup Routing Engine.

Indicates the average CPU usage over 15 minutes.CPU load

Indicates the usage and capacity of internal flash memory and any external USB flash drive.Flash

Indicates the status of the fans in the fan tray. The possible values are OK, Failed, and Absent.Fan status

Indicatesthe memory used in the externalRoutingEngine. In an EX8200 Virtual Chassis,the memory utilization value of the XRE200 External Routing Engine in the master role is displayed. Click the

XRE200 External Routing Engine in the backup role to view the memory used in the backup external

Routing Engine.

Indicates the average CPU usage over 15 minutes.CPU load

Indicates the usage and capacity of internal flash memory and any external USB flash drive.Flash

Table 18: Health Status (continued)

DescriptionField

Chapter 5: Viewing System Information

Memory util.

Indicatesthe memory used in the externalRoutingEngine. In an EX8200 Virtual Chassis,the memory utilization value of the XRE200 External Routing Engine in the master role is displayed. Click the XRE200 External Routing Engine in the backup roleto view the memory used in the backup external Routing Engine.

Indicates the average CPU usage over 15 minutes.CPU load

Indicates the usage and capacity of internal flash memory and any external USB flash drive.Flash

XRE200 External Routing Engines

Memory util.

Indicatesthe memory used in the externalRoutingEngine. In an EX8200 Virtual Chassis,the memory utilization value of the XRE200 External Routing Engine in the master role is displayed. Click the backup XRE200 ExternalRouting Engine to viewthe memory used in backup externalRouting Engine.

Indicates the average CPU usage over 15 minutes.CPU load

Indicates the usage and capacity of internal flash memory and any external USB flash drive.Flash

Indicates the status of the fans in the fan tray. The possible values are OK, Failed, and Absent.Fan Status

Capacity Utilization Panel

Table 19: Capacity Utilization

DescriptionField

Number of active ports

Total number of ports

Number of VLANs configured

Alarms Panel

Indicates the number of active ports in the switch. Configured Virtual Chassis ports (VCPs) are considered as active ports.

Indicates the number of ports in the switch.

NOTE: In EX3300 and EX4600 Virtual Chassis, the total

number of ports of all of the switches is displayed.

Indicates the number of MAC table entries.Used-up MAC-Table entries

Indicatesthe maximum number of MAC table entriespermitted.Supported MAC-Table entries

Indicates the number of VLANs configured.

NOTE: Only tagged VLANs are counted.

Indicates the maximum number of VLANs supported.Number of VLANs supported

Displaysinformation about the last five alarms raisedin the system. For example, if there are 5 major alarms, then details of all 5 major alarms are displayed. If there are 4 major

EX3300 Switch Hardware Guide

File System Usage

Chassis Viewer

alarms and 3 minor alarms, then details of the 4 major alarms and 1 minor alarm are displayed. Major alarms are displayed in red and minor alarms are displayed in yellow.

In an EX8200 Virtual Chassis, the top 5 alarms for the master external Routing Engine are displayed by default. If you select an EX8200 member switch of the Virtual Chassis, the top 5 alarms for that member switch are displayed.

To display the file system storage details of a switch in the backup or linecard role, click the image of that switch.

Click the Rear View button to see the back of the chassis image. Click the Front View button to see the front of the chassis image. In a Virtual Chassis configuration, the Rear

View button is disabled if the switch is not selected.

•

Table 20 on page 36—Describes the chassis viewer for EX2200 switches.

•

Table 21 on page 37—Describes the chassis viewer for EX2200-C switches.

•

Table 22 on page 37—Describes the chassis viewer for EX3200, EX3300, and EX4200

switches.

•

Table 23 on page 39—Describes the chassis viewer for EX4300 switches.

•

Table 24 on page 40—Describes the chassis viewer for EX4500 switches.

•

Table 25 on page 41—Describes the chassis viewer for EX4550 switches.

•

Table 26 on page 43—Describes the chassis viewer for EX4600 switches.

•

Table 27 on page 43—Describes the chassis viewer for EX6210 switches.

•

Table 28 on page 44—Describes the chassis viewer for EX8208 switches.

•

Table 29 on page 46—Describes the chassis viewer for EX8216 switches.

•

Table 30 on page 46—Describes the chassis viewer for the XRE200 External Routing

Engines.

Table 20: Chassis Viewer for EX2200 Switches

DescriptionField

Front View

Interface status

In the image, the following colors denote the interface status:

•

Green—Interface is up and operational.

•

Yellow—Interface is up but is nonoperational.

•

Gray—Interface is down and nonoperational.

Mouse over the interface (port) to view more information.

Rear View

Table 20: Chassis Viewer for EX2200 Switches (continued)

DescriptionField

Chapter 5: Viewing System Information

Management (me0) port

Console port

USB port

The management port is used to connect the switchto a management devicefor out-of-band management.

The console port is used to connect the switch to a management console or to a console server. (You might do this for initial switch configuration.)

Indicates the USB port for the switch.

NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for

your EX Series switch.

Mouse over the fan tray icon to display name, status, and description information.Fan tray

Mouse over the power outlet icon to display name, status, and description information.Power supply

Table 21: Chassis Viewer for EX2200-C Switches

DescriptionField

Front View

Interface status

In the image, the following colors denote the interface status:

•

Green—Interface is up and operational.

•

Yellow—Interface is up but is nonoperational.

•

Gray—Interface is down and nonoperational.

Mouse over the interface (port) to view more information.

Management (me0) port

Console port

USB port

The management port is used toconnect the switch to a managementdevice for out-of-band management.

The console port is used to connect the switch to a management console or to a console server. (You might do this for initial switch configuration.)

Indicates the USB port for the switch.

NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for

your EX Series switch.

Rear View

Mouse over the power outlet icon to display name, status, and description information.Power supply

Table 22: Chassis Viewer for EX3200, EX3300, and EX4200 Switches

DescriptionField

Front View

EX3300 Switch Hardware Guide

Table 22: Chassis Viewer for EX3200, EX3300, and EX4200 Switches (continued)

DescriptionField

Interface status

In the image, the following colors denote the interface status:

•

Green—Interface is up and operational.

•

Yellow—Interface is up but is nonoperational.

•

Gray—Interface is down and nonoperational.

Mouse over the interface (port) to view more information.

For a Virtual Chassis configuration, select the switch to view the interface status.

If an SFP+ uplink module is installed in the switch, mouse over the port icon to display whether the module is configured to operate in 1-gigabit mode or in 10-gigabit mode. If the module is configured to operate in 1-gigabit mode, the tool tip information is displayed for all 4 ports. If the module is configured to operate in 10-gigabit mode, the tool tip information is displayed only for 2 ports.

On an EX3300 switch with the 4x GE/XE SFP+ module, mouse over the port icon to display whether the module is configured to operate in 1-gigabit mode or 10-gigabit mode.

For SFP, SFP+, and XFP ports, the interfaces appear dimmed if no transceiver is inserted. The chassis viewer displays Transceiver not plugged-in when you mouse over the port icon.

LCD panel

LCD panel configured for the LEDs on the ports. Mouse over the icon to view the current character display.

Rear View of the EX3200 Switch

Management (me0) port

The management port is used to connect the switch to a management device for out-of-band management.

Console port

The console port is used to connect the switch to a management console or to a console server. (You might do this for initial switch configuration.)

USB port

Indicates the USB port for the switch.

NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your

EX Series switch.

Mouse over the fan tray icon to display name, status, and description information.Fan tray

Mouse over the power supply icon to display name, status, and description information.Power supply

Rear View of the EX3300 and EX4200 Switch

Fan tray

Mouse over the fan tray icon to display name, status, and description information. For a Virtual Chassis, the status of the fans of the selected member switch is displayed.

Virtual Chassis port

Displayed only when EX4200 switches are configured as a Virtual Chassis. The following colors denote the Virtual Chassis port (VCP) status:

•

Green—VCP is up and operational.

•

Yellow—VCP is up but is nonoperational.

•

Gray—VCP is down and nonoperational.

Chapter 5: Viewing System Information

Table 22: Chassis Viewer for EX3200, EX3300, and EX4200 Switches (continued)

DescriptionField

USB port

Indicates the USB port for the switch.

NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your

EX Series switch.

Management (me0) port

The management port is used to connect the switch to a management device for out-of-band management.

Console port

The console port is used to connect the switch to a management console or to a console server. (You might do this for initial switch configuration.)

Mouse over the power supply icons to display name, status, and description information.Power supplies

Table 23: Chassis Viewer for EX4300 Switches

DescriptionField

Front View

Interface status

In the image, the colors listed below denote the interface status for both copper and fiber media type of ports:

•

Green—Interface is up and operational.

•

Yellow—Interface is up but is nonoperational.

•

Gray—Interface is down and nonoperational.

Mouse over the interface (port) to view more information.

LCD panel

LCD panel configured for the LEDs on the ports. Mouse over the icon to view the current character display.

The mini console port is used to connect the switch to the management console.Mini USB console

PIC 2 slot

You can install an uplink module in the PIC 2 slot. Mouse over the ports in the module to view the details of the ports in module.

24-port and 48-port EX4300 switches support the4-port 10-Gigabit SFP+ uplink module.

EX4300-32F switches support the 2-port40-Gigabit QSFP+uplink moduleand the 8-port 10-Gigabit SFP+ uplink module.

When you install a transceiver in the port, the following colors denote the interface status:

•

Green—Interface is up and operational.

•

Yellow—Interface is up but is not operational.

•

Gray—Interface is down and not operational.

NOTE: In EX4300 switches the LEDs are seen in the front panel, these are not active.

Rear View of the EX4300 Switch

Management port

The management port is used to connect the switch to a management device for out-of-band management.

EX3300 Switch Hardware Guide

Table 23: Chassis Viewer for EX4300 Switches (continued)

DescriptionField

Console port

USB port

PIC 1 slot

The Console port (RJ-45) is used to connect the switch to a management console or to a console server.

Indicates the USB port for the switch.

NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your

EX Series switch.

Mouse over the fan tray icons to display name, status, and description information.Fan tray

Mouse over the power supply icons to display name, status, and description information.Power supplies

The rear panel of a 24-port and a 48-port EX4300 switch has four (built-in) 40-Gigabit QSFP+ ports, and the rear panel of an EX4300-32F switch has two (built-in) 40-Gigabit QSFP+ ports, in which you can install QSFP+ transceivers. Mouse over the ports to view the details of the ports.

After you install a transceiver in the port, the following colors denote the interface status:

•

Green—Interface is up and operational.

•

Yellow—Interface is up but is not operational.

•

Gray—Interface is down and not operational.

For QSFP+ ports, the interfaces appear dimmed if no transceiver is inserted. The chassis viewer displays Transceiver not plugged in when you mouse over the port.

When a QSFP+ port is configured as a Virtual Chassis Port (VCP), the following colors denote the VCP status:

•

Green—VCP is up and operational.

•

Yellow—VCP is up but is not operational.

•

Gray—VCP is down and not operational.

Table 24: Chassis Viewer for EX4500 Switches

DescriptionField

Front View

Interface status

In the image, the colors listed below denote the interface status:

•

Green—Interface is up and operational.

•

Yellow—Interface is up but is nonoperational.

•

Gray—Interface is down and nonoperational.

Mouse over the interface (port) to view more information.

For a Virtual Chassis configuration, select the switch to view the interface status.

If an SFP+ uplink module is installed in the switch, mouse over the interface (ports) on the module for more information.

For SFP and SFP+ ports, the interfaces appear dimmed if no transceiver is inserted. The chassis viewer displays Transceiver not plugged-in when you mouse over the port icon.

Table 24: Chassis Viewer for EX4500 Switches (continued)

DescriptionField

Chapter 5: Viewing System Information

LCD panel

Management (me0) port

USB port

LCDpanel configuredfor the LEDs on the ports. Mouse over the icon to view the current character display.

The console port is used to connect the switch to a management console or to a console server.Console port

The management port is used to connect the switch to a management device for out-of-band management. Use this port for initial switch configuration.

Indicates the USB port for the switch.

NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for

your EX Series switch.

Rear View of the EX4500 Switch

Fan tray

Virtual Chassis port

Mouse over the fan tray icon to display status of the fans and airflow direction information. For a Virtual Chassis, the status of the fans of the selected member switch is displayed.

Displayedonly when switches are configured as a Virtual Chassis. The colors listed belowdenote the Virtual Chassis port (VCP) status:

•

Green—VCP is up and operational.

•

Yellow—VCP is up but is nonoperational.

•

Gray—VCP is down and nonoperational.

Mouse over the power supply icons to display name, status, and description information.Power supplies

Intraconnect module

Mouse over the module to display details of the intraconnect module. The intraconnect module helps the switch achieve line rate on all its ports.

Mouse over to display details of the switches in the Virtual Chassis configuration.Virtual Chassis module

Table 25: Chassis Viewer for EX4550 Switches

DescriptionField

Front View

EX3300 Switch Hardware Guide

Table 25: Chassis Viewer for EX4550 Switches (continued)

DescriptionField

Interface status

LCD panel

Management (me0) port

PIC1 slot

In the image, the colors listed below denote the interface status:

•

Green—Interface is up and operational.

•

Yellow—Interface is up but is nonoperational.

•

Gray—Interface is down and nonoperational.

Mouse over the interface (port) to view more information.

For a Virtual Chassis configuration, select the switch to view the interface status.

If an expansion module or a Virtual Chassis module is installed in the switch, mouse over the interface (ports) on the module for more information.

On an EX4550-32F switch,for SFP and SFP+ ports, the interfaces appear dimmed if no transceiver is inserted. The chassis viewer displays Transceiver (1G/10G) not plugged in when you mouse over the port icon.

LCD panel configured for the LEDs on the ports. Mouse over the icon to view the current character display.

The console port is used to connect the switch to a management console or to a console server.Console port

The mini console port is used to connect the switch to the management console.Mini Console port

The management port is used to connect the switch to a management device for out-of-band management. Use this port for initial switch configuration.

You can insert an uplink module or a Virtual Chassis module in the PIC1 slot. Mouse over to display the details of the module inserted (uplink or Virtual Chassis).

USB port

Indicates the USB port for the switch.

NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your

EX Series switch.

Rear View of the EX4550 Switch

Fan tray

Mouse over the fan tray icon to display the status of the fans and airflow direction information. For a Virtual Chassis, the status of the fans of the selected member switch is displayed.

Virtual Chassis port

Displayed only when switches are configured as a Virtual Chassis. In the image, the colors listed below denote the Virtual Chassis port (VCP) status:

•

Green—VCP is up and operational.

•

Yellow—VCP is up but is nonoperational.

•

Gray—VCP is down and nonoperational.

Mouse over the power supply icons to display name, status, and description information.Power supplies

PIC2 slot

You can insert an uplink module or a Virtual Chassis module into the PIC2 slot. Mouse over to display the details of the module inserted (uplink or Virtual Chassis).

Chapter 5: Viewing System Information

Table 26: Chassis Viewer for EX4600 Switches

DescriptionField

Front View

NOTE: J-Web is supported on EX4600 switches only in J-Web Application package Release 14.1X53-A2.

Interface status

In the image,the colors listed below denote the interface status for both copper and fiber

media type of ports:

•

Green—Interface is up and operational.

•

Yellow—Interface is up but is nonoperational.

•

Gray—Interface is down and nonoperational.

Mouse over the interface (port) to view more information.

PIC 1 and PIC 2 slots

You can install an expansion module in the PIC 1 and PIC 2 slots. If you have installed an

expansion module, mouse over the ports in the module to view the details of the ports

in module.

When you install a transceiver in the port, the following colors denote the interface status:

•

Green—Interface is up and operational.

•

Yellow—Interface is up but is not operational.

•

Gray—Interface is down and not operational.

NOTE:

•

In EX4600 switches the LEDs are seen in the front panel; these are not active.

•

In EX4600 switches there is no LCD panel.

Rear View of the EX4600 Switch

Management port

The management ports (RJ-45 and SFP) is used to connect the switch to a management

device for out-of-band management.

Console port

The Console port (RJ-45) is used to connect the switch to a management console or to

a console server.

USB port

Indicates the USB port for the switch.

NOTE: We recommend that you use USB flash drives purchased from Juniper Networks

for your EX Series switch.

Mouse over the fan tray icons to display name, status, and description information.Fan tray

Mouse over the power supply icons to display name, status, and description information.Power supplies

Table 27: Chassis Viewer for EX6210 Switches

DescriptionField

Front View

Mouse over the temperature icon to display the temperature of the CB or line card.Temperature

EX3300 Switch Hardware Guide

Table 27: Chassis Viewer for EX6210 Switches (continued)

DescriptionField

Interface status

Select the CB or line card.

In the image, the colors listed below denote the interface status:

•

Green—Interface is up and operational.

•

Yellow—Interface is up but is nonoperational.

•

Gray—Interface is down and nonoperational.

Mouse over the interface (port) to view more information.

You can view status for the following ports on the SRE module:

•

USB port—Indicates the USB port for the switch.

NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your

EX Series switch.

•

Management (me0) port—The management port is used to connect the switch to a management device for out-of-band management. There are 2 management ports: fiber and copper. The same status is displayed for both the me0 ports.

•

Console port—The console port is used to connect the switch to a management console or to a console server. (You might do this for initial switch configuration.)

CBs support 4 SFP+ uplink ports. Mouse over the interface on the CB for more information.

For SFP and SFP+ ports, the interfaces appear dimmed if no transceiver is inserted. The chassis viewer displays Transceiver not plugged-in when you mouse over the port icon.

Mouse over the power supply icons to display name, status, and description information.Power supplies

LCD panel

LCD panel configured for the LEDs on the ports. Mouse over the icon to view the current character displayof themaster Routing Engine.The EX6210 switch has 2LCD panels, one for eachRouting Engine. The backup Routing Engine LCD displays Backup.

Rear View of the EX6210 Switch

Mouse over the fan tray icon to display information regarding the cooling fans.Fan tray

Table 28: Chassis Viewer for EX8208 Switches

DescriptionField

Front View

Table 28: Chassis Viewer for EX8208 Switches (continued)

DescriptionField

Chapter 5: Viewing System Information

Interface status

Slot numbers

In the image, click any line card, SRE module, or SF module to view the front view of the selected component. In the image, the colors listed below denote the interface status:

•

Green—Interface is up and operational.

•

Yellow—Interface is up but is nonoperational.

•

Gray—Interface is down and nonoperational.

Mouse over the interface (port) to view more information.

You can view status for the following ports on the SRE module:

•

USB port—Indicates the USB port for the switch.

NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your

EX Series switch.

•

Auxiliary port—This port is unavailable.

•

Management (me0) port—The management port is used to connect the switch to a management device for out-of-band management.

•

Console port—The console port is used to connect the switch to a management console or to a console server. (You might do this for initial switch configuration.)

Because the SF module has no ports, no status information is displayed.

Slots on the switch are labeled, from the top of the switch down:

•

0–3 (line cards)

•

SRE0, SF, SRE1 (SRE and SF modules)

•

4–7 (line cards)

Temperature

LCD panel

Rear View

The active slots contain a gray temperature icon. Mouse over the icon to display temperature information for the slot.

Mouse over the fan tray icon to display name, status, and description information.Fan status

Mouse over the power supply icons to display name, status, and description information.Power supplies

LCD panel configured for the LEDs on the ports. Mouse over the icon to view the current character display.

The EX8208 switch does not have any components on the rear of the chassis.

EX3300 Switch Hardware Guide

Table 29: Chassis Viewer for EX8216 Switches

DescriptionField

Front View

Interface status

In the image, click any line card or RE module to display the front view of the selected component. In the image, the colors listed below denote the interface status:

•

Green—Interface is up and operational.

•

Yellow—Interface is up but is nonoperational.

•

Gray—Interface is down and nonoperational.

Mouse over the interface (port) to view more information.

You can view status for the following ports on the RE module:

•

USB port—Indicates the USB port for the switch.

NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your

EX Series switch.

•

Auxiliary port—This port is unavailable.

•

Management(me0) port—The management port is used to connect the switchto a management device for out-of-band management.

•

Console port—The console port is used to connect the switch to a management console or to a console server. (You might do this for initial switch configuration.)

Slot numbers

Temperature

Slots on the switch are labeled, from the top of the switch down:

•

RE0 (RE module)

•

RE1 (RE module)

•

0–15 (line cards)

The active slots contain a gray temperature icon. Mouse over the icon to display temperature information for the slot.

Mouse over the fan tray icon to display consolidated information about the fans.Fan status

Mouse over the power supply icons to display name, status, and description information.Power supplies

LCD panel

LCD panel configured for the LEDs on the ports. Mouse over the icon to view the current character display.

Rear View

SF modules

Mouse over the SF module icons in their respective slots to display information.Slots are numbered SF7–SF0, from left to right.

Table 30: Chassis Viewer for XRE200 External Routing Engines

DescriptionField

Front View

Chapter 5: Viewing System Information

Table 30: Chassis Viewer for XRE200 External Routing Engines (continued)

DescriptionField

Interface status

Management (me0) port

Virtual Chassis port

LCD panel

Temperature

In the image, the colors listed below denote the interface status:

•

Green—Interface is up and operational.

•

Yellow—Interface is up but is nonoperational.

•

Gray—Interface is down and nonoperational.

Mouse over the interface (port) to view more information.

For a Virtual Chassis configuration, select the switch to view the interface status.

The console port is used to connect the switch to a management consoleor to a console server.Console port

The management port is used to connect the switch to a management device for out-of-band management. Use this port for initial switch configuration.

In the image, the colors listed below denote the Virtual Chassis port (VCP) status:

•

Green—VCP is up and operational.

•

Yellow—VCP is up but is nonoperational.

•

Gray—VCP is down and nonoperational.

Mouse over the interface (port) to view more information.

LCDpanel configuredfor the LEDs on the ports. Mouse over the icon toview thecurrent character display.

The active slots contain a gray temperature icon. Mouse over the icon to display temperature information for the slot.

USB port

Indicates the USB port for the switch.

NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for

your EX Series switch.

PIC1 slot

You can install a Virtual Chassis module in the PIC1 slot. Mouse over the Virtual Chassis ports to display the port status details.

PIC2 slot

You can install a Virtual Chassis module in the PIC2 slot. Mouse over the Virtual Chassis ports to display the port status details.

Rear View of the XRE200 External Routing Engine

Fan modules

Mouse over the fan modules to display status of the fans and airflow direction information. For a Virtual Chassis, the status of the fans of the selected member switch is displayed.

Mouse over the power supply icons to display name, status, and description information.Power supplies

EX3300 Switch Hardware Guide

Release History Table DescriptionRelease

Documentation

14.1X53-D10

For Junos OS Release14.1X53-D10 and later, EX3300 switches configured as a Virtual Chassis display the value 1–10 FPC in the Inventory details field.

14.1X53-A2

In J-Web ApplicationpackageRelease14.1X53-A2,you canform a Virtual Chassis using EX4600 and EX4300 switches.

14.1X53-A2

J-Web is supported on EX4600 switches only in J-Web Application package Release 14.1X53-A2.

• J-Web User Interface for EX Series Switches Overview

• EX2200 Switches Hardware Overview

• EX2300 Switches Hardware Overview

• EX3200 Switches Hardware Overview

• EX3300 Switches Hardware Overview on page 3

• EX4200 Switches Hardware Overview

• EX4300 Switches Hardware Overview

• EX4500 Switches Hardware Overview

• EX6210 Switch Hardware Overview

• EX8208 Switch Hardware Overview

• EX8216 Switch Hardware Overview

• Checking Active Alarms with the J-Web Interface on page 175

• XRE200 External Routing Engine Hardware Guide
