E Series™ Broadband
Services Routers
E Series™ End-of-Life Module Guide
Published: 2010-10-06
Copyright © 2010, Juniper Networks, Inc.
Page 2
E Series End-of-Life Module Guide
This guide provides an overview and description of E Series modules that are end-of-life
(EOL) and can no longer be ordered for the following routers:
•
•
•
•
•
Depending on the EOL schedule of a module, new software releases might not support
the module.
Table 1 on page 3 lists EOL modules alphabetically. It lists EOL modules for ERX routers
first and then for E120 and E320 routers.
ERX7xx models
ERX14xx models
ERX310 router
E120 router
E320 router
NOTE: Any future JunosE release number provided in the Actual or Predicted
Last JunosE Support field of Table 1 on page 3 is based on the current JunosE
release schedule. If the release schedule changes in the future, Juniper
Networks will update the associated Product Support Notification (PSN)
Technical Bulletin for any affected EOL modules.
For more information about E Series routers and modules, refer to the following guides:
•
ERX module installation and maintenance—ERX Hardware Guide
•
E120 and E320 module installation and maintenance—E120 and E320 Hardware Guide
•
Managing E Series routers—JunosE System Basics Configuration Guide
•
Configuring E Series modules—JunosE Link Layer Configuration Guide
To obtain the most current list of EOL modules, see the End-of-Life Products page on
the Juniper Networks Web site at http://www.juniper.net/support/eol.
Copyright © 2010, Juniper Networks, Inc.2
Page 3
Table 1: End-of-Life Modules
Line Module
LabelCombination Name
ERX ROUTER MODULES
CE1
Channelized OC3/STM1
cOCx/STMxF0cOC3/STM1 multimode
I/O Module
Label
I/O
MULTIMODE
First
JunosE
Support
Actual or
Predicted
Last
JunosE
Support
Page
87.3.x1.1.0CE1 FULL I/OCE1CE1
915.0.x2.2.0cOC3 STM1 F0
intermediate reach
long reach
Channelized OC12/STM4
without APS/MSP
redundancy
single-mode
intermediate reach
without APS/MSP
redundancy
single-mode
intermediate reach with
APS/MSP redundancy
cOCx/STMxF0cOC3/STM1single-mode
I/O
SINGLE MODE
cOCx/STMxF0cOC3/STM1single-mode
I/O
LONG HAUL
cOCx/STMxF0cOC12/STM4multimode
I/O
MULTI MODE
cOCx/STMxF0cOC12/STM4
I/O
SINGLE MODE
cOCx/STMxF0cOC12/STM4
COC12 F0 APS
SINGLE MODE
7.0.2,
7.2.0
1115.0.x2.2.0cOC3 STM1 F0
1315.0.x2.2.0cOC3 STM1 F0
1515.0.x2.2.0cOC12 STM4 F0
1715.0.x2.2.0cOC12 STM4 F0
1915.0.x6.1.3,
single-mode long reach
Channelized T1
Channelized T3
cOCx/STMxF0cOC12/STM4
LONG HAUL
2115.0.x2.2.0cOC12 STM4
237.3.x1.1.0CT1 FULL I/OCT1CT1
3Copyright © 2010, Juniper Networks, Inc.
Page 4
E Series End-of-Life Module Guide
Table 1: End-of-Life Modules (continued)
Line Module
LabelCombination Name
E3
I/O Module
Label
First
JunosE
Support
Actual or
Predicted
Last
JunosE
Support
Page
247.0.x1.0.0CT3/T3 I/OCT3CT3 (3 ports)
2514.0.x3.2.0CT3/T3 12 I/OCT3/T3-F0CT3/T3 12 (12 ports)
267.1.x1.1.0E3 I/OE3 ATME3 ATM
277.0.x1.1.0E3 I/OE3 FRAMEE3 Frame (3 ports)
Fast Ethernet
Only line module is EOL.
Gigabit Ethernet (1–port)
(128 MB)
Only line module is EOL.
(128 MB)
Only line module is EOL.
(128 MB)
Only line module is EOL.
COCX-F3E3 Frame (12 ports)
FRAME I/O
2814.0.x4.0.2E3-12
297.0.x1.3.0FE-2 I/OFE-2FE-2 (2 ports)
305.2.x2.0.0FE-8 I/OGE/FEFE-8 (8 ports) (128 MB)
315.2.x2.0.0GE I/O SFPGE/FEGE 1000Base-LH
335.2.x2.0.0GE I/O SFPGE/FEGE 1000Base-SX
355.2.x2.0.0GE I/O SFPGE/FEGE 1000Base-ZX
HSSI
IPSec Service
IPSec Service
OC3/STM1
377.3.x3.1.0HSSI-3 I/OHSSI-3FHSSI
3814.0.x4.0.2No I/O moduleIPSEC
SERVICE
Copyright © 2010, Juniper Networks, Inc.4
Page 5
Table 1: End-of-Life Modules (continued)
Line Module
LabelCombination Name
I/O Module
Label
First
JunosE
Support
Actual or
Predicted
Last
JunosE
Support
Page
multimode
single-mode
OC3/STM1 ATM
OC3/STM1 ATM
multimode without
APS/MSP redundancy
(128 MB)
Only line module is EOL.
OC3/STM1 ATM
single-mode
intermediate reach
without APS/MSP
redundancy (128 MB)
Only line module is EOL.
OC3/STM1 ATM
single-mode long reach
without APS/MSP
redundancy (128 MB)
OC3OC3 (dual-port)
OC3OC3 (dual-port)
OCx/STMx
ATM or
OCx/STMx
/DS3-ATM
OCx/STMx
ATM or
OCx/STMx
/DS3-ATM
OCx/STMx
ATM or
OCx/STMx
/DS3-ATM
394.1.x1.0.0OC3 I/O
MULTI MODE
404.1.x1.0.0OC3 I/O
SINGLE MODE
415.2.x2.0.0OC3-4 I/O
MULTI MODE
435.2.x2.0.0OC3-4 I/O
SINGLE MODE
455.2.x2.0.0OC3-4 I/O
LONG HAUL
Only line module is EOL.
OC12/STM4 ATM
OC12/STM4 ATM
multimode without
APS/MSP redundancy
(128 MB)
Only line module is EOL.
OC12/STM4 ATM
single-mode
intermediate reach
without APS/MSP
redundancy (128 MB)
Only line module is EOL.
OCx/STMx
ATM or
OCx/STMx
/DS3-ATM
OCx/STMx
ATM or
OCx/STMx
/DS3-ATM
475.2.x2.0.0OC12 STM4 I/O
MULTI MODE
495.2.x2.0.0OC12 STM4 I/O
SINGLE MODE
5Copyright © 2010, Juniper Networks, Inc.
Page 6
E Series End-of-Life Module Guide
Table 1: End-of-Life Modules (continued)
Line Module
LabelCombination Name
I/O Module
Label
First
JunosE
Support
Actual or
Predicted
Last
JunosE
Support
Page
OC12/STM4 ATM
single-mode long reach
without APS/MSP
redundancy (128 MB)
Only line module is EOL.
SRPs
memory)
OCx/STMx
ATM or
OCx/STMx
/DS3-ATM
LONG HAUL
SRP I/OSRP-5G+SRP-5G+ (2-GB
SRP I/OSRP-10GSRP-10G(1-GB memory)
515.2.x2.0.0OC12 STM4 I/O
535.2.x1.0.0SRP I/OSRP-5GSRP-5G (512 MB)
548.0.x3.0.2SRP I/OSRP-5G+SRP-5G+ (512 MB)
5514.0.x4.1.3,
5.0.4,
5.1.2,
5.2.0
565.2.x1.1.0SRP I/OSRP-10GSRP-10G (512 MB)
578.0.x4.1.3,
5.0.4,
5.1.2,
5.2.0
587.1.x5.1.0SRP-SE I/OSRP-SE10GSRP-SE10G (512 MB)
SRP-40G PLUS (1 GB)
PLUS
T3
T3 ATM (4 ports)
(128 MB)
Only line module is EOL.
ATM or
OCx/STMx
/DS3-ATM
Tunnel Service Module (TSM)
595.2.x3.4.1SRP I/OSRP-40GSRP-40G (512 MB)
607.1.x4.0.0SRP I/OSRP-40G
617.0.x1.1.0CT3/T3 I/OT3 ATMT3 ATM (3 ports)
625.2.x4.1.04xDS3 ATM I/OOCx/STMx
637.0.x1.1.0CT3/T3 I/OT3 FRAMET3 Frame (3 ports)
6414.0.x4.0.2CT3/T3 12 I/OCOCX-F3T3 Frame (12 ports)
Copyright © 2010, Juniper Networks, Inc.6
Page 7
Table 1: End-of-Life Modules (continued)
Line Module
LabelCombination Name
I/O Module
Label
First
JunosE
Support
Actual or
Predicted
Last
JunosE
Support
Page
TSM
SERVICE
X.21/V.35
E120 and E320 ROUTER MODULES
Gigabit Ethernet IOA
10GE IOA
ES2-S1
10GE
IOA
X.21/V.35 I/OX.21/V.35X.21/V.35
10GE
IOA
658.0.x3.0.2No I/O moduleTUNNEL
667.3.x2.10.1,
3.3.2
6814.0.x7.0.1ES2-S1
7Copyright © 2010, Juniper Networks, Inc.
Page 8
E Series End-of-Life Module Guide
CE1 Module Combination
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
Software features
Model compatibility
SRP module compatibility
CE1
CE1 FULL I/O
•
20
•
First supported: 1.1.0
•
Final supported: 7.3.x
•
40 W
•
Channelized E1
•
Non-ASIC
•
E1
•
HDLC framing
•
See ERX Module Guide, Appendix A, Module Protocol Support for information
about the layer 2 and layer 3 protocols and applications that this module
combination supports.
•
ERX7xx models
•
ERX1410 router
•
SRP-5G
•
SRP-5G+
•
SRP-10G
Module redundancy support
Cables and connectors
LEDs
Alarms, errors, and events
•
1:N redundancy
•
RJ-48C,120 ohm
•
BNC, 75-ohm via a balun panel that connects to the I/O module
•
Use shielded cables to maintain EMC compliance.
•
The transmitted signal complies with ITUT G.703, Physical/electrical
characteristics of hierarchical digital interfaces (November 2001) for cable
lengths up to 450 m (492 yards).
•
See ERX Hardware Guide, Chapter 5, Cabling ERX Routers for more information.
•
See ERX Module Guide, Appendix B, Module LEDs.
•
See Monitoring Interfaces in the Configuring Channelized T1 and Channelized E1
Interfaces chapter of the JunosE Physical Layer Configuration Guide for Release
8.0.x and earlier.
Copyright © 2010, Juniper Networks, Inc.8
Page 9
cOC3/STM1 Multimode Module Combination
cOC3/STM1 Multimode Module Combination
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
Software features
cOCx/STMx F0
cOC3 STM1 F0 I/O
MULTI MODE
•
4
•
First supported: 2.2.0
•
Final supported: 15.0.x
•
130 W
•
OC3/STM1 channelized to DS3, DS1, E1, and DS0
•
Supports either E1 or T1 operation, but not E1 and T1 operation simultaneously
•
EFA ASIC
•
OC3/STM1
•
DS3
•
T1, E1
•
DS0
•
HDLC framing
•
See ERX Module Guide, Appendix A, Module Protocol Support for information about
the layer 2 and layer 3 protocols and applications that this module combination
supports.
Model compatibility
SRP module compatibility
Module redundancy support
•
ERX7xx models
•
ERX14xx models
•
ERX310 router
•
SRP-5G+
•
SRP-10G
•
SRP-40G
•
SRP-40G PLUS
•
SRP-SE10G
•
1:N redundancy
•
NOTE: Line module redundancy is not supported on the ERX310 router.
9Copyright © 2010, Juniper Networks, Inc.
Page 10
E Series End-of-Life Module Guide
Cables and connectors
LEDs
Alarms, errors, and events
•
Up to four SC full duplex connectors
•
Tx power:
•
min: –19 dBm
•
max: –14 dBm
•
Center wavelength: 1310 nm
•
Rx input power:
•
min: –30 dBm
•
max: –14 dBm
•
Rated for 2 km (1.2 miles) over 62.5-micron core cable with an optical loss of
0–9 dB or 50-micron core cable with an optical loss of 7 dB
•
See ERX Hardware Guide, Chapter 5, Cabling ERX Routers for more information.
•
See ERX Module Guide, Appendix B, Module LEDs.
•
See Monitoring Interfaces in JunosE Physical Layer Configuration Guide, Chapter 4,
Configuring Channelized OCx/STMx Interfaces.
Copyright © 2010, Juniper Networks, Inc.10
Page 11
cOC3/STM1 Single-Mode Intermediate Reach Module Combination
cOC3/STM1 Single-Mode Intermediate Reach Module Combination
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
Software features
cOCx/STMx F0
cOC3 STM1 F0 I/O
SINGLE MODE
•
4
•
First supported: 2.2.0
•
Final supported: 15.0.x
•
130 W
•
OC3/STM1 channelized to DS3, DS1, E1, and DS0
•
EFA ASIC
•
OC3/STM1
•
DS3, DS1
•
T1, E1
•
DS0
•
HDLC framing
•
See ERX Module Guide, Appendix A, Module Protocol Support for information
about the layer 2 and layer 3 protocols and applications that this module
combination supports.
Model compatibility
SRP module compatibility
Module redundancy support
•
ERX7xx models
•
ERX14xx models
•
ERX310 router
•
SRP-5G+
•
SRP-10G
•
SRP-40G
•
SRP-40G PLUS
•
SRP-SE10G
•
1:N redundancy
•
NOTE: Line module redundancy is not supported on the ERX310 router.
11Copyright © 2010, Juniper Networks, Inc.
Page 12
E Series End-of-Life Module Guide
Cables and connectors
LEDs
Alarms, errors, and events
•
Up to four SC full duplex connectors
•
Tx power:
•
min: –15 dBm
•
max: –8 dBm
•
Center wavelength: 1310 nm
•
Rx input power:
•
min: –31 dBm
•
max: –8 dBm
•
Rated for 15 km (9.3 miles) of 9-micron core cable
•
See ERX Hardware Guide, Chapter 5, Cabling ERX Routers for more information.
•
See ERX Module Guide, Appendix B, Module LEDs.
•
See Monitoring Interfaces in JunosE Physical Layer ConfigurationGuide, Chapter 4,
Configuring Channelized OCx/STMx Interfaces.
Copyright © 2010, Juniper Networks, Inc.12
Page 13
cOC3/STM1 Single-Mode Long Reach Module Combination
cOC3/STM1 Single-Mode Long Reach Module Combination
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
Software features
cOCx/STMx F0
cOC3 STM1 F0 I/O
LONG HAUL
•
4
•
First supported: 2.2.0
•
Final supported: 15.0.x
•
130 W
•
OC3/STM1 channelized to DS3, DS1, E1, and DS0
•
EFA ASIC
•
OC3/STM1
•
DS3, DS1
•
T1, E1
•
DS0
•
HDLC framing
•
See ERX Module Guide, Appendix A, Module Protocol Support for information
about the layer 2 and layer 3 protocols and applications that this module
combination supports.
Model compatibility
SRP module compatibility
Module redundancy support
•
ERX7xx models
•
ERX14xx models
•
ERX310 router
•
SRP-5G+
•
SRP-10G
•
SRP-40G
•
SRP-40G PLUS
•
SRP-SE10G
•
1:N redundancy
•
NOTE: Line module redundancy is not supported on the ERX310 router.
13Copyright © 2010, Juniper Networks, Inc.
Page 14
E Series End-of-Life Module Guide
Cables and connectors
LEDs
Alarms, errors, and events
•
Up to four SC full duplex connectors
•
Tx power:
•
min: –5.0 dBm
•
max: 0 dBm
•
Center wavelength: 1310 nm
•
Rx input power:
•
min: –34 dBm
•
max: –7 dBm
•
Fiber type: 9-micron core
•
Rated for 40 km (24.8 miles) of 9-micron core cable
•
See ERX Hardware Guide, Chapter 5, Cabling ERX Routers for more information.
•
See ERX Module Guide, Appendix B, Module LEDs.
•
See Monitoring Interfaces in JunosE Physical Layer Configuration Guide, Chapter 4,
Configuring Channelized OCx/STMx Interfaces.
Copyright © 2010, Juniper Networks, Inc.14
Page 15
cOC12/STM4 Multimode Without APS/MSP Redundancy Module Combination
cOC12/STM4 Multimode Without APS/MSP Redundancy Module Combination
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
Software features
cOCx/STMx F0
cOC12 STM4 F0 I/O
MULTI MODE
•
1
•
First supported: 2.2.0
•
Final supported: 15.0.x
•
130 W
•
OC12/STM4 channelized to DS3, DS1, E1, and DS0
•
EFA ASIC
•
OC12/STM4
•
OC3/STM1
•
DS3, DS1
•
T1, E1
•
DS0
•
HDLC framing
•
See ERX Module Guide, Appendix A, Module ProtocolSupport for information about
the layer 2 and layer 3 protocols and applications that this module combination
supports.
Model compatibility
SRP module compatibility
Module redundancy support
•
ERX7xx models
•
ERX14xx models
•
ERX310 router
•
SRP-5G+
•
SRP-10G
•
SRP-40G
•
SRP-40G PLUS
•
SRP-SE10G
•
1:N redundancy
•
NOTE: Line module redundancy is not supported on the ERX310 router.
15Copyright © 2010, Juniper Networks, Inc.
Page 16
E Series End-of-Life Module Guide
Cables and connectors
LEDs
Alarms, errors, and events
•
SC full duplex connector
•
Tx power:
•
min: –19 dBm
•
max: –14 dBm
•
Center wavelength: 1310 nm
•
Rx input power:
•
min: –30 dBm
•
max: –14 dBm
•
Rated for 2 km (1.2 miles) over 62.5-micron core cable with an optical loss of 0–9
dB or 50-micron core cable with an optical loss of 7 dB
•
See ERX Hardware Guide, Chapter 5, Cabling ERX Routers for more information.
•
See ERX Module Guide, Appendix B, Module LEDs.
•
See Monitoring Interfaces in JunosE Physical Layer Configuration Guide, Chapter 4,
Configuring Channelized OCx/STMx Interfaces.
Copyright © 2010, Juniper Networks, Inc.16
Page 17
cOC12/STM4 Single-Mode Intermediate Reach Without APS/MSP Redundancy Module Combination
cOC12/STM4Single-Mode IntermediateReach WithoutAPS/MSP Redundancy Module
Combination
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
Software features
cOCx/STMx F0
cOC12 STM4 F0 I/O
SINGLE MODE
•
1
•
First supported: 2.2.0
•
Final supported: Not applicable
•
130 W
•
OC12/STM4 channelized to DS3, DS1, E1, and DS0
•
EFA ASIC
•
OC12/STM4
•
OC3/STM1
•
DS3, DS1
•
T1, E1
•
DS0
•
HDLC framing
•
See ERX Module Guide, Appendix A, Module Protocol Support for information
about the layer 2 and layer 3 protocols and applications that this module
combination supports.
Model compatibility
SRP module compatibility
Module redundancy support
•
ERX7xx models
•
ERX14xx models
•
ERX310 router
•
SRP-5G+
•
SRP-10G
•
SRP-40G
•
SRP-40G PLUS
•
SRP-SE10G
•
1:N redundancy
•
NOTE: Line module redundancy is not supported on the ERX310 router.
17Copyright © 2010, Juniper Networks, Inc.
Page 18
E Series End-of-Life Module Guide
Cables and connectors
LEDs
Alarms, errors, and events
•
SC full duplex connector
•
Tx power:
•
min: –15 dBm
•
max: –8 dBm
•
Center wavelength: 1310 nm
•
Rx input power:
•
min: –31 dBm
•
max: –8 dBm
•
Rated for 15 km (9.3 miles) of 9-micron core cable
•
See ERX Hardware Guide, Chapter 5, Cabling ERX Routers for more information.
•
See ERX Module Guide, Appendix B, Module LEDs.
•
See Monitoring Interfaces in JunosE Physical Layer Configuration Guide, Chapter 4,
Configuring Channelized OCx/STMx Interfaces.
Copyright © 2010, Juniper Networks, Inc.18
Page 19
cOC12/STM4 Single-Mode Intermediate Reach With APS/MSP Redundancy Module Combination
cOC12/STM4 Single-Mode Intermediate Reach With APS/MSP Redundancy Module
Combination
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
cOCx/STMx F0
COC12 F0 APS
SINGLE MODE
•
2
•
1 active, 1 redundant
•
First supported: 6.1.3 or later 6.1.x release, 7.0.2 or later 7.0.x release, 7.2.0 and
higher-numbered release
•
Final supported: 15.0.x
•
130 W
•
OC12/STM4 channelized to DS3, DS1, E1, and DS0
•
EFA ASIC
•
OC12/STM4
•
OC3/STM1
•
DS3, DS1
•
T1, E1
•
DS0
•
HDLC framing
Software features
Model compatibility
SRP module compatibility
Module redundancy support
•
See ERX Module Guide, Appendix A, Module ProtocolSupport for information about
the layer 2 and layer 3 protocols and applications that this module combination
supports.
•
ERX7xx models
•
ERX14xx models
•
ERX310 router
•
SRP-5G+
•
SRP-10G
•
SRP-40G
•
SRP-40G PLUS
•
SRP-SE10G
•
1:N redundancy
•
NOTE: Line module redundancy is not supported on the ERX310 router.
19Copyright © 2010, Juniper Networks, Inc.
Page 20
E Series End-of-Life Module Guide
Cables and connectors
LEDs
Alarms, errors, and events
•
SC full duplex connector
•
Tx power:
•
min: –15 dBm
•
max: –8 dBm
•
Center wavelength: 1310 nm
•
Rx input power:
•
min: –31 dBm
•
max: –7 dBm
•
Rated for 15 km (9.3 miles) of 9-micron core cable
•
See ERX Hardware Guide, Chapter 5, Cabling ERX Routers for more information.
•
See ERX Module Guide, Appendix B, Module LEDs.
•
See Monitoring Interfaces in JunosE Physical Layer Configuration Guide, Chapter 4,
Configuring Channelized OCx/STMx Interfaces.
Copyright © 2010, Juniper Networks, Inc.20
Page 21
cOC12/STM4 Single-Mode Long Reach Module Combination
cOC12/STM4 Single-Mode Long Reach Module Combination
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
Software features
cOCx/STMx F0
cOC12 STM4
LONG HAUL
•
1 active, 1 redundant
•
First supported: 2.2.0
•
Final supported: 15.0.x
•
130 W
•
OC12/STM4 channelized to DS3, DS1, E1, and DS0
•
EFA ASIC
•
OC12/STM4
•
OC3/STM1
•
DS3, DS1
•
T1, E1
•
DS0
•
HDLC framing
•
See ERX Module Guide, Appendix A, Module Protocol Support for information
about the layer 2 and layer 3 protocols and applications that this module
combination supports.
Model compatibility
SRP module compatibility
Module redundancy support
•
ERX7xx models
•
ERX14xx models
•
ERX310 router
•
SRP-5G+
•
SRP-10G
•
SRP-40G
•
SRP-40G PLUS
•
SRP-SE10G
•
1:N redundancy
•
NOTE: Line module redundancy is not supported on the ERX310 router.
21Copyright © 2010, Juniper Networks, Inc.
Page 22
E Series End-of-Life Module Guide
Cables and connectors
LEDs
Alarms, errors, and events
•
SC full duplex connector
•
Tx power:
•
min: –5.0 dBm
•
max: 0 dBm
•
Center wavelength: 1310 nm
•
Rx input power:
•
min: –34 dBm
•
max: –7 dBm
•
Fiber type: 9-micron core
•
Rated for 40 km (24.8 miles) of 9-micron core cable
•
See ERX Hardware Guide, Chapter 5, Cabling ERX Routers for more information.
•
See ERX Module Guide, Appendix B, Module LEDs.
•
See Monitoring Interfaces in JunosE Physical Layer Configuration Guide, Chapter 4,
Configuring Channelized OCx/STMx Interfaces.
Copyright © 2010, Juniper Networks, Inc.22
Page 23
CT1 Module Combination
CT1 Module Combination
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
Software features
Model compatibility
SRP module compatibility
CT1
CT1 FULL I/O
•
24
•
First supported: 1.1.0
•
Final supported: 7.3.x
•
40 W
•
Channelized T1
•
Non-ASIC
•
DS1, DS0
•
HDLC Framing
•
See ERX Module Guide, Appendix A, Module Protocol Support for information
about the layer 2 and layer 3 protocols and applications that this module
combination supports.
•
ERX7xx models
•
ERX1410 router
•
SRP-5G
•
SRP-5G+
•
SRP-10G
Module redundancy support
Cables and connectors
LEDs
Alarms, errors, and events
•
1:N redundancy
•
RJ-48C 100–ohm connector
•
Use shielded cables to maintain EMC compliance.
•
The line interface unit supports multiple line buildouts.
•
Signal strength is software controlled.
•
The transmitted signal complies with ANSI T1.102-1993 Digital Hierarchy Electrical Interfaces (1999) for cable lengths up to 201 m (660 feet).
•
See ERX Hardware Guide, Chapter 5, Cabling ERX Routers for more information.
•
See ERX Module Guide, Appendix B, Module LEDs.
•
See Monitoring Interfaces in the Configuring Channelized T1 and Channelized E1
Interfaces chapter of the JunosE Physical Layer Configuration Guide for Release
8.0.x and earlier.
23Copyright © 2010, Juniper Networks, Inc.
Page 24
E Series End-of-Life Module Guide
CT3 Module Combination (3 Ports)
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
Software features
Model compatibility
SRP module compatibility
CT3
CT3/T3 I/O
•
3
•
First supported: 1.0.0
•
Final supported: 7.0.x
•
60 W
•
Channelized T3
•
Non-ASIC
•
DS3, DS1, DS0
•
HDLC framing
•
See ERX Module Guide, Appendix A, Module Protocol Support for information
about the layer 2 and layer 3 protocols and applications that this module
combination supports.
•
ERX7xx models
•
ERX1410 router
•
SRP-5G
•
SRP-5G+
•
SRP-10G
Module redundancy support
Cables and connectors
LEDs
Alarms, errors, and events
•
1:N redundancy
•
BNC 75-ohm connector
•
The line interface unit supports two line buildouts:
•
0–68.5 m (0–225 feet)
•
69–137 m (226–450 feet)
•
Signal strength is software controlled.
•
The transmitted signal complies with ANSI T1.102-1993 Digital Hierarchy Electrical Interfaces (1999) for cable lengths up to 201 m (660 feet).
•
See ERX Hardware Guide, Chapter 5, Cabling ERX Routers for more information.
•
See ERX Module Guide, Appendix B, Module LEDs.
•
See Monitoring Interfaces in the Configuring Channelized T3 Interfaces chapter
of the JunosE Physical Layer Configuration Guide for Release 8.0.x and earlier.
Copyright © 2010, Juniper Networks, Inc.24
Page 25
CT3/T3 12 Module Combination (12 Ports)
CT3/T3 12 Module Combination (12 Ports)
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
Software features
Model compatibility
CT3/T3-F0
CT3/T3 12 I/O
•
12
•
First supported: 3.2.0
•
Final supported: 14.0.x
•
130 W
•
Channelized and unchannelized T3
•
EFA ASIC
•
DS3, DS1, DS0
•
HDLC framing
•
See ERX Module Guide, Appendix A, Module ProtocolSupport for information about
the layer 2 and layer 3 protocols and applications that this module combination
supports.
•
ERX7xx models
•
ERX14xx models
•
ERX310 router
SRP module compatibility
Module redundancy support
Cables and connectors
LEDs
Alarms, errors, and events
•
SRP-5G+
•
SRP-10G
•
SRP-40G
•
SRP-40G PLUS
•
SRP-SE10G
•
1:N redundancy
•
NOTE: Line module redundancy is not supported on the ERX310 router.
•
BT43 SMB connector
•
Cable that adapts to 75-ohm BNC is available.
•
The line interface unit supports two line buildouts:
•
0–68.5 m (0–225 feet)
•
69–137 m (226–450 feet)
•
Signal strength is software controlled.
•
The transmitted signal complies with ANSI T1.102-1993 Digital Hierarchy - Electrical
Interfaces (1999) for cable lengths up to 201 m (660 feet).
•
See ERX Hardware Guide, Chapter 5, Cabling ERX Routers for more information.
•
See ERX Module Guide, Appendix B, Module LEDs.
•
See Monitoring Interfaces in JunosE Physical Layer Configuration Guide, Chapter 1,
Configuring Channelized T3 Interfaces.
25Copyright © 2010, Juniper Networks, Inc.
Page 26
E Series End-of-Life Module Guide
E3 ATM Module Combination
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
Software features
Model compatibility
SRP module compatibility
E3 ATM
E3 I/O
•
3
•
First supported: 1.1.0
•
Final supported: 7.1.x
•
60 W
•
Unchannelized E3 for ATM
•
Non-ASIC
•
ATM/AAL5
•
See ERX Module Guide, Appendix A, Module Protocol Support for information
about the layer 2 and layer 3 protocols and applications that this module
combination supports.
•
ERX7xx models
•
ERX1410 router
•
SRP-5G
•
SRP-5G+
•
SRP-10G
Module redundancy support
Cables and connectors
LEDs
Alarms, errors, and events
•
1:N redundancy
•
BNC 75-ohm connector
•
The transmitted signal complies with ITUT G.703, Physical/electrical
characteristics of hierarchical digital interfaces (November 2001) for cable
lengths from 0–137 m (0–450 feet).
•
See ERX Hardware Guide, Chapter 5, Cabling ERX Routers for more information.
•
See ERX Module Guide, Appendix B, Module LEDs.
•
See Monitoring Interfaces in the Configuring T3 and E3 Interfaces chapter of
the JunosE Physical Layer Configuration Guide for Release 8.0.x and earlier.
Copyright © 2010, Juniper Networks, Inc.26
Page 27
E3 Frame Module Combination (3 Ports)
E3 Frame Module Combination (3 Ports)
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
Software features
Model compatibility
SRP module compatibility
E3 FRAME
E3 I/O
•
3
•
First supported: 1.1.0
•
Final supported: 7.0.x
•
60 W
•
Unchannelized E3 for Frame
•
Non-ASIC
•
E3
•
HDLC framing
•
See ERX Module Guide, Appendix A, Module Protocol Support for information
about the layer 2 and layer 3 protocols and applications that this module
combination supports.
•
ERX7xx models
•
ERX1410 router
•
SRP-5G
•
SRP-5G+
•
SRP-10G
Module redundancy support
Cables and connectors
LEDs
Alarms, errors, and events
•
1:N redundancy
•
BNC 75-ohm connector
•
The transmitted signal complies with ITUT G.703, Physical/electrical
characteristics of hierarchical digital interfaces (November 2001) for cable
lengths from 0–137 m (0–450 feet).
•
See ERX Hardware Guide, Chapter 5, Cabling ERX Routers for more information.
•
See ERX Module Guide, Appendix B, Module LEDs.
•
See Monitoring Interfaces in the Configuring T3 and E3 Interfaces chapter of
the JunosE Physical Layer Configuration Guide for Release 8.0.x and earlier.
27Copyright © 2010, Juniper Networks, Inc.
Page 28
E Series End-of-Life Module Guide
E3 Frame Module Combination (12 Ports)
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
Software features
Model compatibility
COCX-F3
E3-12
FRAME I/O
•
12
•
First supported: 4.0.2
•
Final supported: 14.0.x
•
135 W
•
Unchannelized E3 for Frame
•
EFA ASIC
•
E3
•
HDLC framing
•
See ERX Module Guide, Appendix A, Module Protocol Support for information
about the layer 2 and layer 3 protocols and applications that this module
combination supports.
•
ERX7xx models
•
ERX14xx models
•
ERX310 router
SRP module compatibility
Module redundancy support
Cables and connectors
LEDs
Alarms, errors, and events
•
SRP-5G+
•
SRP-10G
•
SRP-40G
•
SRP-40G PLUS
•
SRP-SE10G
•
1:N redundancy
•
NOTE: Line module redundancy is not supported on the ERX310 router.
•
BT43 SMB connector
•
Cable that adapts to 75-ohm BNC is available.
•
The transmitted signal complies with ITUT G.703, Physical/electrical
characteristics of hierarchical digital interfaces (November 2001) for cable
lengths from 0–137 m (0–450 feet).
•
See ERX Hardware Guide, Chapter 5, Cabling ERX Routers for more information.
•
See ERX Module Guide, Appendix B, Module LEDs.
•
See Monitoring Interfaces in JunosE PhysicalLayer Configuration Guide, Chapter 2,
Configuring T3 and E3 Interfaces.
Copyright © 2010, Juniper Networks, Inc.28
Page 29
FE-2 Module Combination (2 Ports)
FE-2 Module Combination (2 Ports)
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
Software features
Model compatibility
SRP module compatibility
FE-2
FE-2 I/O
•
2
•
First supported: 1.3.0
•
Last supported: 7.0.x
•
60 W
•
Fast Ethernet
•
Non-ASIC
•
IEEE 802.3 standards compliance
•
10/100Base-T
•
See ERX Module Guide, Appendix A, Module Protocol Support for information
about the layer 2 and layer 3 protocols and applications that this module
combination supports.
•
ERX7xx models
•
ERX1410 router
•
SRP-5G
•
SRP-5G+
•
SRP-10G
Module redundancy support
Cables and connectors
LEDs
Alarms, errors, and events
•
Not applicable
•
Accepts up to two RJ-45 connectors.
•
For 10-Mbps operation, use CAT 3, 4, or 5 UTP cable.
•
For 100-Mbps operation, use only CAT 5 UTP cable.
•
The transmitted signal complies with IEEE 802.3/802.3u for cable lengths up
to 100 m (328 feet).
•
See ERX Hardware Guide, Chapter 5, Cabling ERX Routers for more information.
•
See ERX Module Guide, Appendix B, Module LEDs.
•
See Monitoring Ethernet Interfaces in the Configuring Ethernet Interfaces chapter
of the JunosE Physical Layer Configuration Guide for Release 8.0.x and earlier.
29Copyright © 2010, Juniper Networks, Inc.
Page 30
E Series End-of-Life Module Guide
FE-8 Module Combination (8 Ports) (128 MB)
This module combination is no longer supported because the line module has reached end-of-life. However, the
I/O module is still supported.
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
Software features
Model compatibility
GE/FE
FE-8 I/O
•
8
•
First supported: 2.0.0
•
Final supported: 5.2.x
•
130 W
•
Fast Ethernet
•
ASIC
•
IEEE 802.3 standards compliance
•
10/100Base-T
•
See ERX Module Guide, Appendix A, Module Protocol Support for information
about the layer 2 and layer 3 protocols and applications that this module
combination supports.
•
ERX7xx models
•
ERX14xx models
•
ERX310 router
SRP module compatibility
Module redundancy support
Cables and connectors
LEDs
Alarms, errors, and events
•
SRP-5G+
•
SRP-10G
•
SRP-40G
•
SRP-40G PLUS
•
SRP-SE10G
•
Not applicable
•
RJ-45 connectors
•
For 10-Mbps operation, use CAT 3, 4, or 5 UTP cable.
•
For 100-Mbps operation, use only CAT 5 UTP cable.
•
The transmitted signal complies with IEEE 802.3/802.3u for cable lengths up
to 100 m (328 feet).
•
See ERX Hardware Guide, Chapter 5, Cabling ERX Routers for more information.
•
See ERX Module Guide, Appendix B, Module LEDs.
•
See Monitoring Ethernet Interfaces in the Configuring Ethernet Interfaces chapter
of the JunosE Physical Layer Configuration Guide for Release 8.0.x and earlier.
Copyright © 2010, Juniper Networks, Inc.30
Page 31
GE 1000Base-LH Module Combination (1 Port) (128 MB)
GE 1000Base-LH Module Combination (1 Port) (128 MB)
This module combination is no longer supported because the line module has reached end-of-life. However, the
I/O module is still supported.
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
Software features
Model compatibility
GE/FE
GE I/O SFP
•
1 active, 1 redundant
•
First supported: 2.0.0
•
Final supported: 5.2.x
•
130 W
•
Gigabit Ethernet
•
The GE SFP I/O module uses a range of small form-factor pluggable (SFP)
transceivers to support different modes and cable lengths.
•
The transceivers on this GE I/O module are 1000Base-LX/LH compliant.
•
ASIC
•
Ethernet (IEEE 802.3z)
•
1000Base-LH
•
See ERX Module Guide, Appendix A, Module ProtocolSupport for information about
the layer 2 and layer 3 protocols and applications that this module combination
supports.
•
ERX7xx models
•
ERX14xx models
•
ERX310 router
SRP module compatibility
Module redundancy support
•
SRP-5G+
•
SRP-10G
•
SRP-40G
•
SRP-40G PLUS
•
SRP-SE10G
•
Not applicable
31Copyright © 2010, Juniper Networks, Inc.
Page 32
E Series End-of-Life Module Guide
Cables and connectors
LEDs
Alarms, errors, and events
•
LC full duplex
•
Tx power:
•
min: –9.5 dBm
•
max: –3 dBm
•
Center wavelength: 1300 nm
•
Rx input power:
•
min: –20 dBm
•
max: –3 dBm
•
Rated for 10 km (6.2 miles) over 10-micron core cable
•
See ERX Hardware Guide, Chapter 5, Cabling ERX Routers for more information.
•
See ERX Module Guide, Appendix B, Module LEDs.
•
See Monitoring Ethernet Interfaces in the Configuring Ethernet Interfaces chapter
of the JunosE Physical Layer Configuration Guide for Release 8.0.x and earlier.
Copyright © 2010, Juniper Networks, Inc.32
Page 33
GE 1000Base-SX Module Combination (1 Port) (128 MB)
GE 1000Base-SX Module Combination (1 Port) (128 MB)
This module combination is no longer supported because the line module has reached end-of-life. However, the
I/O module is still supported.
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
Software features
Model compatibility
GE/FE
GE I/O SFP
•
1 active, 1 redundant
•
First supported: 2.0.0
•
Final supported: 5.2.x
•
130 W
•
Gigabit Ethernet
•
The GE SFP I/O module uses a range of small form-factor pluggable (SFP)
transceivers to support different modes and cable lengths.
•
The transceivers on this GE I/O module are 1000Base-SX compliant.
•
ASIC
•
Ethernet (IEEE 802.3z)
•
1000Base-SX
•
See ERX Module Guide, Appendix A, Module ProtocolSupport for information about
the layer 2 and layer 3 protocols and applications that this module combination
supports.
•
ERX7xx models
•
ERX14xx models
•
ERX310 router
SRP module compatibility
Module redundancy support
•
SRP-5G+
•
SRP-10G
•
SRP-40G
•
SRP-40G PLUS
•
SRP-SE10G
•
Not applicable
33Copyright © 2010, Juniper Networks, Inc.
Page 34
E Series End-of-Life Module Guide
Cables and connectors
LEDs
Alarms, errors, and events
•
LC full duplex
•
Tx power:
•
min: –9.5 dBm
•
max: –4 dBm
•
Center wavelength: 850 nm
•
Rx input power:
•
min: –17 dBm
•
max: –3 dBm
•
Rated for 275 m (300 yards) over 62.5-micron core cable
•
Rated for 550 m (601 yards) over 50-micron core cable
•
See ERX Hardware Guide, Chapter 5, Cabling ERX Routers for more information.
•
See ERX Module Guide, Appendix B, Module LEDs.
•
See Monitoring Ethernet Interfaces in the Configuring Ethernet Interfaces chapter
of the JunosE Physical Layer Configuration Guide for Release 8.0.x and earlier.
Copyright © 2010, Juniper Networks, Inc.34
Page 35
GE 1000Base-ZX Module Combination (1 Port) (128 MB)
GE 1000Base-ZX Module Combination (1 Port) (128 MB)
This module combination is no longer supported because the line module has reached end-of-life. However, the
I/O module is still supported.
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
Software features
Model compatibility
GE/FE
GE I/O SFP
•
1 active, 1 redundant
•
First supported: 2.0.0
•
Final supported: 5.2.x
•
130 W
•
Gigabit Ethernet
•
The GE SFP I/O module uses a range of small form-factor pluggable (SFP)
transceivers to support different modes and cable lengths.
•
The transceivers on this GE I/O module are 1000Base-ZX compliant.
•
ASIC
•
Ethernet (IEEE 802.3z)
•
1000Base-ZX
•
See ERX Module Guide, Appendix A, Module ProtocolSupport for information about
the layer 2 and layer 3 protocols and applications that this module combination
supports.
•
ERX7xx models
•
ERX14xx models
•
ERX310 router
SRP module compatibility
Module redundancy support
•
SRP-5G+
•
SRP-10G
•
SRP-40G
•
SRP-40G PLUS
•
SRP-SE10G
•
Not applicable
35Copyright © 2010, Juniper Networks, Inc.
Page 36
E Series End-of-Life Module Guide
Cables and connectors
LEDs
Alarms, errors, and events
•
LC full duplex
•
Tx power:
•
min: –3 dBm
•
max: 2 dBm
•
Center wavelength: 1550 nm
•
Rx input power:
•
min: –23 dBm
•
max: –3 dBm
•
Rated for 70 km (43.4 miles) over 10-micron core cable
•
See ERX Hardware Guide, Chapter 5, Cabling ERX Routers for more information.
•
See ERX Module Guide, Appendix B, Module LEDs.
•
See Monitoring Ethernet Interfaces in the Configuring Ethernet Interfaces chapter
of the JunosE Physical Layer Configuration Guide for Release 8.0.x and earlier.
Copyright © 2010, Juniper Networks, Inc.36
Page 37
HSSI Module Combination
HSSI Module Combination
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
Software features
Model compatibility
SRP module compatibility
HSSI-3F
HSSI-3 I/O
•
3
•
First supported: 3.1.0
•
Final supported: 7.3.x
•
60 W
•
High-speed serial interface
•
Non-ASIC
•
Up to 44.736 MHz data rate
•
HDLC Framing
•
See ERX Module Guide, Appendix A, Module Protocol Support for information
about the layer 2 and layer 3 protocols and applications that this module
combination supports.
•
ERX7xx models
•
ERX1410 router
•
SRP-5G
•
SRP-5G+
•
SRP-10G
Module redundancy support
Cables and connectors
LEDs
Alarms, errors, and events
•
Not applicable
•
Standard HSSI connector: 2-row, 50-pin, receptacle header with rails and
latch blocks
•
50 feet (15.24 m) maximum cable length
•
See ERX Hardware Guide, Chapter 5, Cabling ERX Routers for more
information.
•
See ERX Module Guide, Appendix B, Module LEDs.
•
See Monitoring Interfaces in the Configuring HSSIs chapter of the JunosE
Physical Layer Configuration Guide for Release 8.0.x and earlier.
37Copyright © 2010, Juniper Networks, Inc.
Page 38
E Series End-of-Life Module Guide
IPSec Service Module Combination
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
Software features
Model compatibility
SRP module compatibility
IPSEC SERVICE
No I/O module
•
Not applicable
•
First supported: 4.0.2
•
Final supported: 14.0.x
•
130 W
•
IPSec Tunnel Service
•
EFA ASIC
•
IPSec tunnels
•
See ERX Module Guide, Appendix A, Module Protocol Support for information
about the layer 2 and layer 3 protocols and applications that this module
combination supports.
•
ERX7xx models
•
ERX14xx models
•
ERX310 router
•
SRP-5G+
•
SRP-10G
•
SRP-40G
•
SRP-40G PLUS
•
SRP-SE10G
Module redundancy support
Cables and connectors
LEDs
Alarms, errors, and events
•
Multiple IPSec Service modules provide redundancy.
•
Not applicable
•
See ERX Module Guide, Appendix B, Module LEDs.
•
See Monitoring Tunnel-Service Interfaces in JunosE Physical Layer
ConfigurationGuide, Chapter 6, Managing Tunnel-Serviceand IPSec-Service
Interfaces.
Copyright © 2010, Juniper Networks, Inc.38
Page 39
OC3 (Dual-Port) Multimode Module Combination
OC3 (Dual-Port) Multimode Module Combination
Line module label
I/O module label
Software release
Description
OC3
OC3 I/O
MULTI MODE
•
First supported: 1.0.0
•
Final supported: 4.1.x
•
Obsolete, no longer supported
39Copyright © 2010, Juniper Networks, Inc.
Page 40
E Series End-of-Life Module Guide
OC3 (Dual-Port) Single-Mode Module Combination
Line module label
I/O module label
Software release
Description
OC3
OC3 I/O
SINGLE MODE
•
First supported: 1.0.0
•
Final supported: 4.1.x
•
Obsolete, no longer supported
Copyright © 2010, Juniper Networks, Inc.40
Page 41
OC3/STM1 ATM Multimode Without APS/MSP Redundancy Module Combination (128 MB)
OC3/STM1ATM MultimodeWithout APS/MSP Redundancy Module Combination(128
MB)
This module combination is no longer supported because the line module has reached end-of-life. However, the
I/O module is still supported.
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
Software features
Model compatibility
OCx/STMx ATM or OCx/STMx /DS3-ATM
OC3-4 I/O
MULTI MODE
•
4
•
First supported: 2.0.0
•
Final supported: 5.2.x
•
130 W
•
Unchannelized, concatenated OC3/STM1 for ATM
•
ASIC
•
OC3/STM1
•
ATM:AAL5
•
See ERX Module Guide, Appendix A, Module Protocol Support for information about
the layer 2 and layer 3 protocols and applications that this module combination
supports.
•
ERX7xx models
•
ERX14xx models
•
ERX310 router
SRP module compatibility
Module redundancy support
•
SRP-5G+
•
SRP-10G
•
SRP-40G
•
SRP-40G PLUS
•
SRP-SE10G
•
1:N redundancy
•
NOTE: Line module redundancy is not supported on the ERX310 router.
41Copyright © 2010, Juniper Networks, Inc.
Page 42
E Series End-of-Life Module Guide
Cables and connectors
LEDs
Alarms, errors, and events
•
SC full duplex connector
•
Tx power:
•
min: –19 dBm
•
max: –14 dBm
•
Center wavelength: 1310 nm
•
Rx input power:
•
min: –30 dBm
•
max: –14 dBm
•
Rated for 2 km (1.2 miles) over 62.5-micron core cable with an optical loss of 0–9
dB or 50-micron core cable with an optical loss of 7 dB
•
See ERX Hardware Guide, Chapter 5, Cabling ERX Routers for more information.
•
See ERX Module Guide, Appendix B, Module LEDs.
•
See Monitoring SONET/SDH Interfaces in the Configuring Unchannelized OCx/STMx
Interfaces chapter of the JunosE Physical Layer Configuration Guide for Release
8.0.x and earlier.
Copyright © 2010, Juniper Networks, Inc.42
Page 43
OC3/STM1 ATM Single-Mode Intermediate Reach Without APS/MSP Redundancy Module Combination (128 MB)
OC3/STM1 ATM Single-Mode Intermediate Reach Without APS/MSP Redundancy
Module Combination (128 MB)
This module combination is no longer supported because the line module has reached end-of-life. However, the
I/O module is still supported.
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
Software features
Model compatibility
OCx/STMx ATM or OCx/STMx /DS3-ATM
OC3-4 I/O
SINGLE MODE
•
4
•
First supported: 2.0.0
•
Final supported: 5.2.x
•
130 W
•
Unchannelized, concatenated OC3/STM1 for ATM
•
ASIC
•
OC3/STM1
•
ATM/AAL5
•
See ERX Module Guide, Appendix A, Module Protocol Support for information
about the layer 2 and layer 3 protocols and applications that this module
combination supports.
•
ERX7xx models
•
ERX14xx models
•
ERX310 router
SRP module compatibility
Module redundancy support
•
SRP-5G+
•
SRP-10G
•
SRP-40G
•
SRP-40G PLUS
•
SRP-SE10G
•
1:N redundancy
•
NOTE: Line module redundancy is not supported on the ERX310 router.
43Copyright © 2010, Juniper Networks, Inc.
Page 44
E Series End-of-Life Module Guide
Cables and connectors
LEDs
Alarms, errors, and events
•
SC full duplex
•
Tx power:
•
min: –15 dBm
•
max: –8 dBm
•
Center wavelength: 1310 nm
•
Rx input power:
•
min: –31 dBm
•
max: –8 dBm
•
Rated for 15 km (9.3 miles) of 9-micron core cable
•
See ERX Hardware Guide, Chapter 5, Cabling ERX Routers for more information.
•
See ERX Module Guide, Appendix B, Module LEDs.
•
See Monitoring SONET/SDH Interfacesin the Configuring Unchannelized OCx/STMx
Interfaces chapter of the JunosE Physical Layer Configuration Guide for Release
8.0.x and earlier.
Copyright © 2010, Juniper Networks, Inc.44
Page 45
OC3/STM1 ATM Single-Mode Long Reach Without APS/MSP Redundancy Module Combination (128 MB)
OC3/STM1 ATM Single-Mode Long Reach Without APS/MSP Redundancy Module
Combination (128 MB)
This module combination is no longer supported because the line module has reached end-of-life. However, the
I/O module is still supported.
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
Software features
Model compatibility
OCx/STMx ATM or OCx/STMx /DS3-ATM
OC3-4 I/O
LONG HAUL
•
4
•
First supported: 2.0.0
•
Final supported: 5.2.x
•
130 W
•
Unchannelized, concatenated OC3/STM1 for ATM
•
ASIC
•
OC3/STM1
•
ATM/AAL5
•
See ERX Module Guide, Appendix A, Module Protocol Support for information
about the layer 2 and layer 3 protocols and applications that this module
combination supports.
•
ERX7xx models
•
ERX14xx models
•
ERX310 router
SRP module compatibility
Module redundancy support
•
SRP-5G+
•
SRP-10G
•
SRP-40G
•
SRP-40G PLUS
•
SRP-SE10G
•
1:N redundancy
•
NOTE: Line module redundancy is not supported on the ERX310 router.
45Copyright © 2010, Juniper Networks, Inc.
Page 46
E Series End-of-Life Module Guide
Cables and connectors
LEDs
Alarms, errors, and events
•
SC full duplex
•
Tx power:
•
min: –5.0 dBm
•
max: 0 dBm
•
Center wavelength: 1310 nm
•
Rx input power:
•
min: –34 dBm
•
max: –7 dBm
•
Rated for 40 km (24.8 miles) of 9-micron core cable
•
See ERX Hardware Guide, Chapter 5, Cabling ERX Routers for more information.
•
See ERX Module Guide, Appendix B, Module LEDs.
•
See Monitoring SONET/SDH Interfacesin the Configuring Unchannelized OCx/STMx
Interfaces chapter of the JunosE Physical Layer Configuration Guide for Release
8.0.x and earlier.
Copyright © 2010, Juniper Networks, Inc.46
Page 47
OC12/STM4 ATM Multimode Without APS/MSP Redundancy Module Combination (128 MB)
OC12/STM4 ATM Multimode Without APS/MSP Redundancy Module Combination
(128 MB)
This module combination is no longer supported because the line module has reached end-of-life. However, the
I/O module is still supported.
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
Software features
Model compatibility
OCx/STMx ATM or OCx/STMx /DS3-ATM
OC12 STM4 I/O
MULTI MODE
•
1
•
First supported: 2.0.0
•
Final supported: 5.2.x
•
130 W
•
Unchannelized, concatenated OC12/STM4 for ATM
•
ASIC
•
OC12/STM4
•
ATM/AAL5
•
See ERX Module Guide, Appendix A, Module Protocol Support for information about
the layer 2 and layer 3 protocols and applications that this module combination
supports.
•
ERX7xx models
•
ERX14xx models
•
ERX310 router
SRP module compatibility
Module redundancy support
•
SRP-5G+
•
SRP-10G
•
SRP-40G
•
SRP-40G PLUS
•
SRP-SE10G
•
1:N redundancy
•
NOTE: Line module redundancy is not supported on the ERX310 router.
47Copyright © 2010, Juniper Networks, Inc.
Page 48
E Series End-of-Life Module Guide
Cables and connectors
LEDs
Alarms, errors, and events
•
SC full duplex
•
Tx power:
•
min: –19 dBm
•
max: –14 dBm
•
Center wavelength: 1310 nm
•
Rx input power:
•
min: –30 dBm
•
max: –14 dBm
•
Rated for 2 km (1.2 miles) over 62.5-micron core cable with an optical loss of 0–9
dB or 50-micron core cable with an optical loss of 7 dB
•
See ERX Hardware Guide, Chapter 5, Cabling ERX Routers for more information.
•
See ERX Module Guide, Appendix B, Module LEDs.
•
See Monitoring SONET/SDH Interfaces in the Configuring Unchannelized OCx/STMx
Interfaces chapter of the JunosE Physical Layer Configuration Guide for Release
8.0.x and earlier.
Copyright © 2010, Juniper Networks, Inc.48
Page 49
OC12/STM4 ATM Single-Mode Intermediate Reach Without APS/MSP Redundancy Module Combination (128 MB)
OC12/STM4 ATM Single-Mode Intermediate Reach Without APS/MSP Redundancy
Module Combination (128 MB)
This module combination is no longer supported because the line module has reached end-of-life. However, the
I/O module is still supported.
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
Software features
Model compatibility
OCx/STMx ATM or OCx/STMx /DS3-ATM
OC12 STM4 I/O
SINGLE MODE
•
1
•
First supported: 2.0.0
•
Final supported: 5.2.x
•
130 W
•
Unchannelized, concatenated OC12/STM4 for ATM
•
ASIC
•
OC12/STM4
•
ATM/AAL5
•
See ERX Module Guide, Appendix A, Module Protocol Support for information
about the layer 2 and layer 3 protocols and applications that this module
combination supports.
•
ERX7xx models
•
ERX14xx models
•
ERX310 router
SRP module compatibility
Module redundancy support
•
SRP-5G+
•
SRP-10G
•
SRP-40G
•
SRP-40G PLUS
•
SRP-SE10G
•
1:N redundancy
•
NOTE: Line module redundancy is not supported on the ERX310 router.
49Copyright © 2010, Juniper Networks, Inc.
Page 50
E Series End-of-Life Module Guide
Cables and connectors
LEDs
Alarms, errors, and events
•
SC full duplex
•
Tx power:
•
min: –15 dBm
•
max: –8 dBm
•
Center wavelength: 1310 nm
•
Rx input power:
•
min: –31 dBm
•
max: –8 dBm
•
Rated for 15 km (9.3 miles) of 9-micron core cable
•
See ERX Hardware Guide, Chapter 5, Cabling ERX Routers for more information.
•
See ERX Module Guide, Appendix B, Module LEDs.
•
See Monitoring SONET/SDH Interfacesin the Configuring Unchannelized OCx/STMx
Interfaces chapter of the JunosE Physical Layer Configuration Guide for Release
8.0.x and earlier.
Copyright © 2010, Juniper Networks, Inc.50
Page 51
OC12/STM4 ATM Single-Mode Long Reach Without APS/MSP Redundancy Module Combination (128 MB)
OC12/STM4 ATM Single-Mode Long Reach Without APS/MSP Redundancy Module
Combination (128 MB)
This module combination is no longer supported because the line module has reached end-of-life. However, the
I/O module is still supported.
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
Software features
Model compatibility
OCx/STMx ATM or OCx/STMx /DS3-ATM
OC12 STM4 I/O
LONG HAUL
•
1
•
First supported: 2.0.0
•
Final supported: 5.2.x
•
130 W
•
Unchannelized, concatenated OC12/STM4 for ATM
•
ASIC
•
OC12/STM4
•
ATM/AAL5
•
See ERX Module Guide, Appendix A, Module Protocol Support for information
about the layer 2 and layer 3 protocols and applications that this module
combination supports.
•
ERX7xx models
•
ERX14xx models
•
ERX310 router
SRP module compatibility
Module redundancy support
•
SRP-5G+
•
SRP-10G
•
SRP-40G
•
SRP-40G PLUS
•
SRP-SE10G
•
1:N redundancy
•
NOTE: Line module redundancy is not supported on the ERX310 router.
51Copyright © 2010, Juniper Networks, Inc.
Page 52
E Series End-of-Life Module Guide
Cables and connectors
LEDs
Alarms, errors, and events
•
SC full duplex
•
Tx power:
•
min: –5.0 dBm
•
max: 0 dBm
•
Center wavelength: 1310 nm
•
Rx input power:
•
min: –34 dBm
•
max: –7 dBm
•
Fiber type: 9-micron core
•
Rated for 40 km (24.8 miles) of 9-micron core cable
•
See ERX Hardware Guide, Chapter 5, Cabling ERX Routers for more information.
•
See ERX Module Guide, Appendix B, Module LEDs.
•
See Monitoring SONET/SDH Interfacesin the Configuring Unchannelized OCx/STMx
Interfaces chapter of the JunosE Physical Layer Configuration Guide for Release
8.0.x and earlier.
Copyright © 2010, Juniper Networks, Inc.52
Page 53
SRP-5G Module Combination (512 GB)
SRP-5G Module Combination (512 GB)
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
Software features
Model compatibility
SRP module compatibility
Module redundancy support
SRP-5G
SRP I/O
•
7
•
First supported: 1.0.0
•
Final supported: 5.2.x
•
100 W
•
Switch route processor (5 Gbps)
•
Not applicable
•
Ethernet (IEEE 802.3)
•
10/100Base-T
•
RS-232
•
Not applicable
•
ERX705 router
•
SRP-5G
•
1:1 redundancy
Cables and connectors
LEDs
Alarms, errors, and events
•
Terminal blocks
•
BNC, 75–ohm
•
Wire wrap posts
•
RJ-45
•
RS-232 (DB-9)
•
See ERX Hardware Guide, Chapter 5, Cabling ERX Routers for more
information.
•
See ERX Module Guide, Appendix B, Module LEDs.
•
See Monitoring Modules in JunosE System Basics Configuration Guide,
Chapter 6, Managing Modules.
53Copyright © 2010, Juniper Networks, Inc.
Page 54
E Series End-of-Life Module Guide
SRP-5G+ Module Combination (512 MB)
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
Software features
Model compatibility
SRP module compatibility
Module redundancy support
SRP-5G+
SRP I/O
•
7
•
First supported: 3.0.2
•
Final supported: 8.0.x
•
125 W
•
Switch route processor (5 Gbps)
•
Not applicable
•
Ethernet (IEEE 802.3)
•
10/100Base-T
•
RS-232
•
Not applicable
•
ERX705 router
•
SRP-5G+
•
1:1 redundancy
Cables and connectors
LEDs
Alarms, errors, and events
•
Terminal blocks
•
BNC, 75–ohm
•
Wire wrap posts
•
RJ-45
•
RS-232 (DB-9)
•
See ERX Hardware Guide, Chapter 5, Cabling ERX Routers for more
information.
•
See ERX Module Guide, Appendix B, Module LEDs.
•
See Monitoring Modules in JunosE System Basics Configuration Guide,
Chapter 6, Managing Modules.
Copyright © 2010, Juniper Networks, Inc.54
Page 55
SRP-5G+ Module Combination (2-GB Memory)
SRP-5G+ Module Combination (2-GB Memory)
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
Software features
Model compatibility
SRP-5G+
SRP I/O
•
7
•
First supported: 4.1.3 or later 4.1.x release, 5.0.4 or later 5.0.x release, 5.1.2
or higher-numbered release, 5.2.0
•
Final supported: 14.0.x
•
125 W
•
Switch route processor (5 Gbps)
•
Has a minimum of 2 GB of error checking and correction (ECC) memory
with a 1-GB nonvolatile storage (NVS) card.
•
The 512–MB version has reached end-of-life.
•
Not applicable
•
Ethernet (IEEE 802.3)
•
10/100Base-T
•
RS-232
•
Not applicable
•
ERX705 router
SRP module compatibility
Module redundancy support
Cables and connectors
LEDs
Alarms, errors, and events
•
SRP-5G+
•
1:1 redundancy
•
Terminal blocks
•
BNC, 75–ohm
•
Wire wrap posts
•
RJ-45
•
RS-232 (DB-9)
•
See ERX Hardware Guide, Chapter 5, Cabling ERX Routers for more
information.
•
See ERX Module Guide, Appendix B, Module LEDs.
•
See Monitoring Modules in JunosE System Basics Configuration Guide,
Chapter 6, Managing Modules.
55Copyright © 2010, Juniper Networks, Inc.
Page 56
E Series End-of-Life Module Guide
SRP-10G Module Combination (512 MB)
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
Software features
Model compatibility
SRP module compatibility
SRP-10G
SRP I/O
•
7
•
First supported: 1.1.0
•
Final supported: 5.2.x
•
125 W
•
Switch route processor (10 Gbps)
•
Not applicable
•
Ethernet (IEEE 802.3)
•
10/100Base-T
•
RS-232
•
Not applicable
•
ERX710 router
•
ERX1410 router
•
SRP-10G
Module redundancy support
Cables and connectors
LEDs
Alarms, errors, and events
•
1:1 redundancy
•
Terminal blocks
•
BNC, 75–ohm
•
Wire wrap posts
•
RJ-45
•
RS-232 (DB-9)
•
See ERX Hardware Guide, Chapter 5, Cabling ERX Routers for more
information.
•
See ERX Module Guide, Appendix B, Module LEDs.
•
See Monitoring Modules in JunosE System Basics Configuration Guide,
Chapter 6, Managing Modules.
Copyright © 2010, Juniper Networks, Inc.56
Page 57
SRP-10G Module Combination (1-GB Memory)
SRP-10G Module Combination (1-GB Memory)
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
Software features
Model compatibility
SRP-10G
SRP I/O
•
7
•
First supported: 4.1.3 or later 4.1.x release, 5.0.4 or later 5.0.x release, 5.1.2
or higher-numbered release, 5.2.0
•
Final supported: 8.0.x
•
125 W
•
Switch route processor (10 Gbps)
•
Has a minimum of 1 GB of error checking and correction (ECC) memory
with a 1-GB nonvolatile storage (NVS) card.
•
Not applicable
•
Ethernet (IEEE 802.3)
•
10/100Base-T
•
RS-232
•
Not applicable
•
ERX710 router
•
ERX1410 router
SRP module compatibility
Module redundancy support
Cables and connectors
LEDs
Alarms, errors, and events
•
SRP-10G
•
1:1 redundancy
•
Terminal blocks
•
BNC, 75–ohm
•
Wire wrap posts
•
RJ-45
•
RS-232 (DB-9)
•
See ERX Hardware Guide, Chapter 5, Cabling ERX Routers for more
information.
•
See ERX Module Guide, Appendix B, Module LEDs.
•
See Monitoring Modules in JunosE System Basics Configuration Guide,
Chapter 6, Managing Modules.
57Copyright © 2010, Juniper Networks, Inc.
Page 58
E Series End-of-Life Module Guide
SRP-SE10G Module Combination (512 MB)
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
Software features
Model compatibility
SRP module compatibility
SRP-SE10G
SRP-SE I/O
•
2
•
First supported: 5.1.0
•
Final supported: 7.1.x
•
Does not operate with JunosE Release 5.3.0 or higher
•
35 W
•
Switch route processor for ERX310 router only (10 Gbps)
•
Not applicable
•
Ethernet (IEEE 802.3)
•
10/100Base-T
•
RS-232
•
Not applicable
•
ERX310 router
•
SRP-SE10G
Module redundancy support
Cables and connectors
LEDs
Alarms, errors, and events
•
Not applicable
•
RJ-45
•
RS-232 (DB-9)
•
See ERX Hardware Guide, Chapter 5, Cabling ERX Routers for more
information.
•
See ERX Module Guide, Appendix B, Module LEDs.
•
See Monitoring Modules in JunosE System Basics Configuration Guide,
Chapter 6, Managing Modules.
Copyright © 2010, Juniper Networks, Inc.58
Page 59
SRP-40G Module Combination (512 MB)
SRP-40G Module Combination (512 MB)
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
Software features
Model compatibility
SRP module compatibility
SRP-40G
SRP I/O
•
7
•
First supported: 3.4.1
•
Final supported: 5.2.x
•
210 W
•
Switch route processor (40 Gbps)
•
Not applicable
•
Ethernet (IEEE 802.3)
•
10/100Base-T
•
RS-232
•
Not applicable
•
ERX1440 router
•
SRP-40G
•
SRP-40G PLUS
Module redundancy support
Cables and connectors
LEDs
Alarms, errors, and events
•
1:1 redundancy
•
Terminal blocks
•
BNC, 75–ohm
•
Wire wrap posts
•
RJ-45
•
RS-232 (DB-9)
•
See ERX Hardware Guide, Chapter 5, Cabling ERX Routers for more
information.
•
See ERX Module Guide, Appendix B, Module LEDs.
•
See Monitoring Modules in JunosE System Basics Configuration Guide,
Chapter 6, Managing Modules.
59Copyright © 2010, Juniper Networks, Inc.
Page 60
E Series End-of-Life Module Guide
SRP-40G PLUS Module Combination (1 GB)
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
Software features
Model compatibility
SRP module compatibility
SRP-40G PLUS
SRP I/O
•
7
•
First supported: 4.0.0
•
Final supported: 7.1.x
•
Has a minimum of 1 GB of error checking and correction (ECC) memory
with a 1-GB nonvolatile storage (NVS) card.
•
210 W
•
Switch route processor (40 Gbps)
•
Not applicable
•
Ethernet (IEEE 802.3)
•
10/100Base-T
•
RS-232
•
Not applicable
•
ERX1440 router
•
SRP-40G
•
SRP-40G PLUS
Module redundancy support
Cables and connectors
LEDs
Alarms, errors, and events
•
1:1 redundancy
•
Terminal blocks
•
BNC
•
BNC, 75–ohm
•
Wire wrap posts
•
RJ-45
•
RS-232 (DB-9)
•
See ERX Hardware Guide, Chapter 5, Cabling ERX Routers for more
information.
•
See ERX Module Guide, Appendix B, Module LEDs.
•
See Monitoring Modules in JunosE System Basics Configuration Guide,
Chapter 6, Managing Modules.
Copyright © 2010, Juniper Networks, Inc.60
Page 61
T3 ATM Module Combination (3 Ports)
T3 ATM Module Combination (3 Ports)
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
Software features
Model compatibility
SRP module compatibility
T3 ATM
CT3/T3 I/O
•
3
•
First supported: 1.1.0
•
Final supported: 7.0.x
•
60 W
•
Unchannelized T3 for ATM
•
Non-ASIC
•
ATM/AAL5
•
See ERX Module Guide, Appendix A, Module Protocol Support for information
about the layer 2 and layer 3 protocols and applications that this module
combination supports.
•
ERX7xx models
•
ERX1410 router
•
SRP-5G
•
SRP-5G+
•
SRP-10G
Module redundancy support
Cables and connectors
LEDs
Alarms, errors, and events
•
1:N redundancy
•
BNC 75-ohm connector
•
The line interface unit supports two line buildouts:
•
0–68.5 m (0–225 feet)
•
69–137 m (226–450 feet)
•
Signal strength is software controlled.
•
The transmitted signal complies with ANSI T1.102-1993 Digital Hierarchy Electrical Interfaces (1999) for cable lengths up to 201 m (660 feet).
•
See ERX Module Guide, Appendix B, Module LEDs.
•
See Monitoring Interfaces in the Configuring T3 and E3 Interfaces chapter of
the JunosE Physical Layer Configuration Guide for Release 8.0.x and earlier.
61Copyright © 2010, Juniper Networks, Inc.
Page 62
E Series End-of-Life Module Guide
T3 ATM Module Combination (4 Ports) (128 MB)
This module combination is no longer supported because the line module has reached end-of-life. However, the
I/O module is still supported.
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
Software features
Model compatibility
SRP module compatibility
OCx/STMx ATM or OCx/STMx /DS3-ATM
4xDS3 ATM I/O
•
4
•
First supported: 4.1.0
•
Final supported: 5.2.x
•
130 W
•
Unchannelized T3 for ATM
•
ASIC
•
ATM/AAL5
•
See ERX Module Guide, Appendix A, Module Protocol Support for information
about the layer 2 and layer 3 protocols and applications that this module
combination supports.
•
ERX7xx models
•
ERX14xx models
•
ERX310 router
•
SRP-5G+
•
SRP-10G
•
SRP-40G
•
SRP-40G PLUS
•
SRP-SE10G
Module redundancy support
Cables and connectors
LEDs
Alarms, errors, and events
•
1:N redundancy
•
75-ohm connector
•
The line interface unit supports two line buildouts:
•
0–68.5 m (0–225 feet)
•
69–137 m (226–450 feet)
•
Signal strength is software controlled.
•
The transmitted signal complies with ANSI T1.102-1993 Digital Hierarchy Electrical Interfaces (1999) for cable lengths up to 201 m (660 feet).
•
See ERX Module Guide, Appendix B, Module LEDs.
•
See Monitoring Interfaces in the Configuring T3 and E3 Interfaces chapter of the
JunosE Physical Layer Configuration Guide for Release 8.0.x and earlier.
Copyright © 2010, Juniper Networks, Inc.62
Page 63
T3 Frame Module Combination (3 Ports)
T3 Frame Module Combination (3 Ports)
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
Software features
Model compatibility
T3 FRAME
CT3/T3 I/O
•
3
•
First supported: 1.1.0
•
Final supported: 7.0.x
•
60 W
•
Unchannelized T3 for Frame
•
Non-ASIC
•
DS3
•
Subrate DS3
•
HDLC framing
•
See ERX Module Guide, Appendix A, Module Protocol Support for information
about the layer 2 and layer 3 protocols and applications that this module
combination supports.
•
ERX7xx models
•
ERX1410 router
SRP module compatibility
Module redundancy support
Cables and connectors
LEDs
Alarms, errors, and events
•
SRP-5G
•
SRP-5G+
•
SRP-10G
•
1:N redundancy
•
BNC 75-ohm connector
•
The line interface unit supports two line buildouts:
•
0–68.5 m (0–225 feet)
•
69–137 m (226–450 feet)
•
Signal strength is software controlled.
•
The transmitted signal complies with ANSI T1.102-1993 Digital Hierarchy Electrical Interfaces (1999) for cable lengths up to 201 m (660 feet).
•
See ERX Module Guide, Appendix B, Module LEDs.
•
See Monitoring Interfaces in the Configuring T3 and E3 Interfaceschapter of the
JunosE Physical Layer Configuration Guide for Release 8.0.x and earlier.
63Copyright © 2010, Juniper Networks, Inc.
Page 64
E Series End-of-Life Module Guide
T3 Frame Module Combination (12 Ports)
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
Software features
Model compatibility
COCX-F3
CT3/T3 12 I/O
•
12
•
First supported: 4.0.2
•
Final supported: 14.0.x
•
135 W
•
Unchannelized T3 for Frame
•
EFA ASIC
•
DS3
•
Subrate DS3
•
HDLC framing
•
See ERX Module Guide, Appendix A, Module Protocol Support for information
about the layer 2 and layer 3 protocols and applications that this module
combination supports.
•
ERX7xx models
•
ERX14xx models
•
ERX310 router
SRP module compatibility
Module redundancy support
Cables and connectors
LEDs
Alarms, errors, and events
•
SRP-5G+
•
SRP-10G
•
SRP-40G
•
SRP-40G PLUS
•
SRP-SE10G
•
1:N redundancy
•
NOTE: Line module redundancy is not supported on the ERX310 router.
•
BT43 SMB
•
Cable that adapts to 75-ohm BNC is available.
•
The line interface unit supports two line buildouts:
•
0–68.5 m (0–225 feet)
•
69–137 m (226–450 feet)
•
Signal strength is software controlled.
•
The transmitted signal complies with ANSI T1.102-1993 Digital Hierarchy Electrical Interfaces (1999) for cable lengths up to 201 m (660 feet).
•
See ERX Module Guide, Appendix B, Module LEDs.
•
See Monitoring Interfaces in JunosE Physical Layer Configuration Guide, Chapter 2,
Configuring T3 and E3 Interfaces.
Copyright © 2010, Juniper Networks, Inc.64
Page 65
Tunnel Service Module (TSM) Module Combination
Tunnel Service Module (TSM) Module Combination
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
Software features
Model compatibility
TUNNEL SERVICE
No I/O module
•
Not applicable
•
First supported: 3.0.2
•
Final supported: 8.0.x
•
130 W
•
Tunnel Service for IP tunnels and LNS termination
•
ASIC
•
IP tunnels
•
LNS termination
•
Network Address Translation
•
Stateful firewall
•
See ERX Module Guide, Appendix A, Module Protocol Support for information
about the layer 2 and layer 3 protocols and applications that this module
combination supports.
•
ERX7xx models
•
ERX14xx models
•
ERX310 router
SRP module compatibility
Module redundancy support
Cables and connectors
LEDs
Alarms, errors, and events
•
SRP-5G+
•
SRP-10G
•
SRP-40G
•
SRP-40G PLUS
•
SRP-SE10G
•
Multiple TSMs provide redundancy.
•
See the Managing Tunnel-Service and IPSec-Service chapter of the JunosE
Physical Layer Configuration Guide for Release 8.0.x and earlier.
•
Not applicable
•
See ERX Module Guide, Appendix B, Module LEDs.
•
See Monitoring Tunnel-Service Interfaces in the Managing Tunnel-Service and
IPSec-Service Interfaces chapter of the JunosE Physical Layer Configuration
Guide for Release 8.0.x and earlier.
65Copyright © 2010, Juniper Networks, Inc.
Page 66
E Series End-of-Life Module Guide
X.21/V.35 Module Combination
Line module label
I/O module label
Number of I/O ports
Software release
Description
Type
Capability
Software features
Model compatibility
SRP module compatibility
X.21/V.35
X.21/V.35 I/O
•
16
•
First supported: 2.10.1, 3.3.2
•
Final supported: 7.3.x
•
60 W
•
X.21/V.35 synchronous serial interface
•
Non-ASIC
•
HDLC framing
•
See ERX Module Guide, Appendix A, Module Protocol Support for information
about the layer 2 and layer 3 protocols and applications that this module
combination supports.
•
ERX7xx models
•
ERX1410 router
•
SRP-5G
•
SRP-5G+
•
SRP-10G
Module redundancy support
Cables and connectors
Cable Lengths
Transmission Speed (Hz)
•
2400
•
4800
•
9600
•
19200
•
38400
•
56000
•
2048000
LEDs
•
Not applicable
•
200-pin proprietary socket on I/O module
•
DB15 X.21 or DB34 V.35 at remote end
•
Serial signals can travel a limited distance without significant degradation.
Slowerserial signals can travel farther without degradation than fasterserial
signals. See “Cable Lengths” row for the maximum cable lengths you can
use to prevent signal degradation at various transmission speeds.
Cable Length (Meters/Feet)
•
1250/4100
•
625/2050
•
312/1025
•
156/513
•
78/256
•
31/102
•
8/25
•
See ERX Module Guide, Appendix B, Module LEDs.
Copyright © 2010, Juniper Networks, Inc.66
Page 67
Alarms, errors, and events
X.21/V.35 Module Combination
•
See Monitoring Interfaces in the Configuring X.21/V.35 Interfaces chapter of
the JunosE Physical Layer Configuration Guide for Release 8.0.x and earlier.
67Copyright © 2010, Juniper Networks, Inc.
Page 68
E Series End-of-Life Module Guide
10GE IOA
IOA label
Number of IOA ports
Software release
Description
Capability
Software features
Model compatibility
Line module compatibility
ES2-S1 10GE IOA
•
1
•
First supported: 7.0.1
•
Final supported: 14.0.x
•
40 W maximum
•
Full-height module
•
Uses a range of 10-gigabit small form-factor pluggable (XFP) transceivers to support
different modes and cable lengths.
•
Ethernet (IEEE 802.3ae)
•
10Gb Base-SR/LR/ER/ZR
•
Port can operate in full duplex mode with an average data rate of 3.4 Gbps
•
See E120 and E320 Module Guide, Appendix A, Module Protocol Support for
information about the layer 2 and layer 3 protocols and applications that this module
combination supports.
•
E320 router
•
E120 router
•
ES2 4G LM
SRP module compatibility
Line module redundancy
compatibility
Port redundancy support
Cablesand connectors (multimode
[SR])
•
SRP-100
•
SRP-120
•
SRP-320
•
Can be paired with an ES2 4G LM.
•
Must be installed in the same redundancy group as an ES2 4G LM and ES2–S1
REDUND IOA combination.
•
Not applicable
•
One LC full duplex connector
•
Transmit power:
•
min: –7.3 dBm
•
max: –1.0 dBm
•
Receive input power:
•
min: –9.9 dBm
•
max: –1.0 dBm
•
See the following corresponding table (SR Fiber Optic Cabling) for cabling
requirements.
•
See E120 and E320 Hardware Guide, Chapter 5, Cabling the Router for more
information.
Copyright © 2010, Juniper Networks, Inc.68
Page 69
Cables and connectors
(single-mode [LR])
Cables and connectors
(single-mode [ER])
•
One LC full duplex connector
•
Transmit power:
•
min: –8.2 dBm
•
max: 0.5 dBm
•
Receive input power:
•
min: –14.4 dBm
•
max: 0.5 dBm
•
See the following corresponding table (LR Fiber Optic Cabling) for cabling
requirements.
•
See E120 and E320 Hardware Guide, Chapter 5, Cabling the Router for more
information.
•
One LC full duplex connector
•
Transmit power:
•
min: –4.7 dBm
•
max: 4.0 dBm
•
Receive input power:
•
min: –15.8 dBm
•
max: –1.0 dBm
•
See the following corresponding table (ER Fiber Optic Cabling) for cabling
requirements.
•
See E120 and E320 Hardware Guide, Chapter 5, Cabling the Router for more
information.
10GE IOA
Cables and connectors
(single-mode [ZR])
LEDs
Alarms, errors, and events
•
One LC full duplex connector
•
Transmit power:
•
min: 0 dBm
•
max: 4 dBm
•
Receive input power:
•
min: –24.0 dBm
•
max: –7.0 dBm
•
See the following corresponding table (ZR Fiber Optic Cabling) for cabling
requirements.
•
See E120 and E320 Hardware Guide, Chapter 5, Cabling the Router for more
information.
Board-level LEDs:
•
OK (green)—Physical link is connected properly and is functioning properly
•
FAIL (red)—Failure detected
Port LEDs:
•
LK (green)—Ethernet link is up
•
ACT (green)—Blinks when there is Ethernet traffic being received
•
See Monitoring Ethernet Interfaces in JunosE Physical Layer Configuration Guide,
Chapter 5, Configuring Ethernet Interfaces.
69Copyright © 2010, Juniper Networks, Inc.
Page 70
E Series End-of-Life Module Guide
Table 2: SR Fiber Optic Cabling
Minimal Modal Bandwidth at 850 nm
(MHz*km)Fiber Type
Table 3: LR Fiber Optic Cabling
Maximum Operating Range (meters)
26 (85.3 ft)16062.5 microns
33 (108.27 ft)200
66 (216.54 ft)40050 microns
82 (269.03 ft)500
300 (984.25 ft)2000
Maximum Operating Range (kilometers)Nominal Wavelength (nm)Fiber Type
10 (6.2 miles)13109 microns
Table 4: ER Fiber Optic Cabling
Table 5: ZR Fiber Optic Cabling
Maximum Operating Range (kilometers)Nominal Wavelength (nm)Fiber Type
40 (24.85 miles)15509 microns
Maximum Operating Range (kilometers)Nominal Wavelength (nm)Fiber Type
80 (49.6 miles)15509 microns
Copyright © 2010, Juniper Networks, Inc.70
Page 71
