JumpPod® (JP1514)

Trampoline Section Instructions

These instructions will detail how to assemble one (1) of the ve (5) sections that make up the frame of the JumpPod® Trampoline.

Once you have assembled one section of the frame, you can simply repeat this process to complete additional sections.

When all ve sections are complete, connect them together to complete the trampoline.

These instructions may differ from the instruction book, but this method tends to allow for easier assembly.

Additionally, this method makes it easier for one person to put together the trampoline by themselves.

We recommend to have an additional person to help with assembly.

Version 05282008

The easiest to put the trampoline together is in ve individual sections.

Assuming the Pod Connector (Key #4) isn’t already attached to Key #1, set down the Pod connector.

Next is key #1, the top rail with six holes. The pod connector slides onto the end of this top rail.

“Top of Tube”

Key #1

4 Spring holes on top
2 Spring holes on the bottom
(6 Spring holes total)

“Underside”

2

Next you can slide key #2, the Socket connector with ve spring holes, onto the end of key #1.

“Underside”“Top of Tube”

Key #2

3 Spring holes on top
2 Spring holes on the bottom
(5 Spring holes total)

Note, the support sleeve end of key number two goes onto the open end of key #1,
