JUMO AQUIS 500 AS Operating Manual

JUMO AQUIS 500 AS

Indicator/Controller for Standard Signals

Type 202568

Operating Manual

20256800T90Z002K000

V2.00/EN/00528531

WARNING:

PGM

PGM

PGM

A sudden malfunction of the device, or one of the sensors connected to it, could
potentially result in dangerous, imprecise dosing! Suitable preventive measures to
stop this happening must be in place.

Note:

Please read these operating instructions before commissioning the device. Keep
the manual in a place which is accessible to all users at all times.

Resetting the brightness of the LC display:

If the brightness/contrast setting has been adjusted so that the display text is no
longer legible, the basic setting can be restored as follows:

✱ Switch off the supply voltage.
✱ Switch on the supply voltage and immediately press and hold the and

keys simultaneously.

Reset the language to "English":

If the language has been adjusted so that the display text is no longer
comprehensible, use the Administrator password, 7485, to reset the language to
"English":

✱ Press the key for longer than 3 seconds.
✱ Press the key once.
✱ Briefly press the key.
✱ Enter 7485.
✱ Briefly press the key.

The required language can then be set in
ADMINISTR. LEVEL / PASSWORD / PARAMETER LEVEL / DISPLAY /
LANGUAGE.

Contents

1 Typographical conventions ...................................................... 6

1.1 Warning signs ..............................................................................................6

1.2 Reference signs ...........................................................................................6

2 Description ................................................................................ 7

3 Identifying the device version .................................................. 9

3.1 Nameplate ....................................................................................................9

3.2 Order details ...............................................................................................10

3.3 Accessories (included in delivery) ..............................................................11

3.4 Accessories (optional) ................................................................................11

4 Mounting .................................................................................. 12

4.1 General .......................................................................................................12

4.2 Surface mounting .......................................................................................12

4.3 Pipe installation set / weather protection roof ...........................................13

4.4 DIN rail installation set ...............................................................................13

4.5 Mounting in a panel ....................................................................................14

5 Electrical connection .............................................................. 16

5.1 Installation instructions ..............................................................................16

5.2 Electrical isolation ......................................................................................17

5.3 Opening and closing the device ................................................................18

5.4 Connecting the cables ...............................................................................19

5.5 Terminal assignment ..................................................................................20

5.6 Pin configuration ........................................................................................21

6 Operation ................................................................................. 23

6.1 Controls ......................................................................................................23

6.2 Display .......................................................................................................24

6.3 Principle of operation .................................................................................25

6.4 Parameter overview ...................................................................................26

6.5 Measuring mode ........................................................................................28

6.6 Input/output information ............................................................................28

6.7 MANUAL mode / simulation mode ............................................................30

6.8 HOLD mode ...............................................................................................34

6.9 Operator level .............................................................................................35

6.10 Administrator level .....................................................................................35

Contents

6.11 Device info .................................................................................................41

6.12 Controller functions ....................................................................................42

6.13 Manual mode .............................................................................................43

6.14 Hold mode .................................................................................................43

7 Commissioning ....................................................................... 44

7.1 Getting started ...........................................................................................44

7.2 Setting examples .......................................................................................45

8 Calibrating a sensor with a standard signal ......................... 75

8.1 Notes ..........................................................................................................75

8.2 General .......................................................................................................75

8.3 One-point offset calibration (zero point calibration) ...................................76

8.4 Two-point calibration .................................................................................78

8.5 Final value calibration ................................................................................80

9 Calibrating a pH combination electrode ............................... 83

9.1 Notes ..........................................................................................................83

9.2 General .......................................................................................................83

9.3 One-point offset calibration (zero point calibration) ...................................84

9.4 Two-point calibration .................................................................................86

10 Calibrating a redox combination electrode .......................... 89

10.1 Notes ..........................................................................................................89

10.2 General .......................................................................................................89

10.3 One-point offset calibration (zero point calibration) ...................................90

10.4 Two-point calibration .................................................................................92

11 Calibrating conductive conductivity cells ............................ 95

11.1 Notes ..........................................................................................................95

11.2 General .......................................................................................................95

11.3 Calibrating the relative cell constant ..........................................................96

11.4 Calibrating the temperature coefficient of the measurement solution .......98

12 Setup program ...................................................................... 104

12.1 Function ...................................................................................................104

Contents

13 Eliminating errors and faults ................................................ 105

14 Technical data ....................................................................... 107

14.1 Analog inputs ...........................................................................................107

14.2 Temperature compensation .....................................................................107

14.3 Measuring circuit monitoring ...................................................................107

14.4 Binary input ..............................................................................................107

14.5 Controller .................................................................................................107

14.6 Analog outputs (max. 2) ...........................................................................107

14.7 Switching outputs (max. two (SPDT) changeovers) .................................107

14.8 Supply voltage for sensors ......................................................................108

14.9 Setup interface .........................................................................................108

14.10 Electrical data ..........................................................................................108

14.11 Display .....................................................................................................108

14.12 Housing ....................................................................................................108

14.13 Standard accessories ..............................................................................108

14.14 Approvals/marks of conformity ................................................................108

15 Appendix ................................................................................ 109

15.1 Operator level parameters .......................................................................109

15.2 Parameter explanations ...........................................................................117

15.3 Glossary ...................................................................................................121

15.4 Panel cut-out ............................................................................................128

16 China RoHS ........................................................................... 129

17 Index ....................................................................................... 131

1.1 Warning signs

Danger

This symbol is used when there may be danger to personnel if the
instructions are ignored or not followed correctly!

Caution

This symbol is used when there may be damage to equipment or data if the
instructions are ignored or not followed correctly!

1.2 Reference signs

Note
This symbol is used to draw your special attention to a remark.

1 Typographical conventions

1

abc

✱ Action instruction

Footnote

Footnotes are remarks that refer to specific points in the text. Footnotes
consist of two parts:

A marker in the text and the footnote text.
The markers in the text are arranged as consecutive superscript numbers.

This symbol indicates that an action to be performed is described.
The individual steps are marked by this asterisk.
Example:
✱ Loosen Phillips-head screws.

6

2 Description

General The device has two analog inputs and one binary input. The first analog input

is suitable for connecting standard signals (0 - 10 V or 0(4) - 20 mA), which can
be prepared by any transmitter or sensor (such as a 2-wire transmitter). Pt100,
Pt1000 or NTC/PTC resistance thermometers (up to 4 k ohms) can be
connected to the second analog input. The power supply for a 2-wire
transmitter is integrated in the device.

Input signals can be shown as numbers or as a bar graph on the graphic
display. Parameters are displayed in plain text for easily comprehensible and
secure operation.

With two optional relay switching contacts, it is possible to implement both
simple switching or alarm functions and demanding control tasks with P, PI,
PD and PID action. If required, the device can also be provided with two freely
configurable and scalable analog outputs (0 - 10 V or 0(4) - 20 mA).

The device is suitable, for example, for displaying, measuring and controlling:

• Free chlorine, chlorine dioxide, ozone, hydrogen peroxide and peracetic
acid, in combination with sensors as per data sheet 20.2630.

• The pH value or redox potential with 2-wire transmitters as per data sheet

20.2701.

• (Hydrostatic) liquid levels with 2-wire transmitters (level probes) as per data
sheet 40.2090 or data sheet 40.4390.

• Flow rate in conjunction with transmitters as per data sheet 40.6010.

• Two temperature measuring points.

• Most sensors and transmitters that output standard signals (0 - 10 V or
0(4) - 20 mA).

Because temperature measurement is integrated, temperature compensation
takes place quickly and precisely, which is particularly important for many
analytical measurements.

Key features • Display: pH, mS/cm, µS/cm, ppm, %, mV, etc.

Special visualizations can also be configured with the setup program.

• Large, backlit LC graphic display.

• A choice of display visualizations: large numbers, bar graph or trend
display.

• Integrated calibration routines.

• Calibration logbook.

• IP67 enclosure protection for surface mounting
IP65 enclosure protection for switch cabinet mounting

• Selectable languages: German, English, French; additional languages can
be loaded later through the setup program.

• Through the setup program: user-friendly configuration, system
documentation, subsequent loading of additional languages.

7

2 Description

Indicator/controller

2 Analog inputs

Input 1:
Standard signal
0(4) - 20 mA or 0 - 10 V

1 Binary input

Floating

contact

Functions:

- keypad

locking

- alarm stop

- HOLD

Supply voltage

Analog outputs

Outputs 1 + 2:
0(4) - 20 mA or 0 - 10 V

Option

Setup interface

Switching outputs

Outputs 3 + 4:

- relay, changeover (SPDT)

User-friendly configuration
Subsequent language loading
System documentation

Configurable

- analog actual value output

- continuous controller output
(PID action)

Configurable

- limit controller

- pulse width output (PID)

- pulse frequency output (PID)

- modulating controller (PID)

- calibration timer run down

Standard

Input 2:
Temperature
manual input or automatic
Pt100 / Pt1000 / PTC / NTC

Supply voltage outputs

- 24 V DC +15/-25%
max. 30 mA (short-circuit proof)
for a 2-wire transmitter

110 - 240 V AC
12 - 24 V DC
20 - 30 V AC/DC

- 12 V DC (10 - 20 V), max. 10 mA
e.g. for an inductive proximity
switch

Block diagram

8

3 Identifying the device version

Typ: 2025 / 0- - - - 2 /00068 1 888 888 888 310-310- 3

TN: 00528743

JUMO AQUIS 500 AS

Fulda, Ger many
www.ju mo.net

AC 110..240V -15/+10% 48..63Hz

≤ 14VA

F-Nr.: 0168122901018050001

3.1 Nameplate

on the
transmitter

The date of manufacture is encoded in "F-Nr." (serial number):
1805 means year of manufacture 2018 / calendar week 05

9

3 Identifying the device version

3.2 Order details

(1) Basic type

202568 JUMO AQUIS 500 AS

Indicator/controller for standard signals

(2) Basic type extensions

10 for panel mounting
20 in surface-mounted housing

(3) Input (freely configurable)

888 0(4) - 20 mA and 0 - 10 V

(4) Output 1 (for main value or continuous controller)

000 no output
888 analog output 0(4) - 20 mA and 0 - 10 V

(5) Output 2 (for temperature or continuous controller)

000 no output
888 analog output 0(4) - 20 mA and 0 - 10 V

(6) Output 3

000 no output
310 relay with changeover contact

(7) Output 4

000 no output
310 relay with changeover contact

(8) Supply voltage

23 110 - 240 V AC, +10% / -15%, 48 - 63 Hz
25 20 - 30 V AC/DC, 48 - 63 Hz
30 12 - 24 V DC, ± 15%

(9) Extra codes

000 none

(1) (2) (3) (4) (5) (6) (7) (8) (9)

Order code /- -----/,...
Sample order 202568 / 20 - 888 - 888 - 000 - 310 - 000 - 23 / 000

1

List extra codes in sequence, separated by commas.

1

10

3 Identifying the device version

3.3 Accessories (included in delivery)

4 x pluggable screw terminals
1 x small plug-in link
1 x large plug-in link
1 x mounting clip for cable diameters > 5 mm
2 x mounting clips for cable diameters < 5 mm
1 x mounting clip for cable diameters < 3 mm
2 x pan head screws, 3.5x6.5
4 x spacing rollers for panel mounting
4 x hexagonal nuts for panel mounting
4 x countersunk screws, M6x10
4 x fixings
1 x cable gland, M12x1.5
1 x sealing ring for M12x1.5 cable gland
1 x reducing washer, M12x1.5
2 x cable glands, M16x1.5
2 x sealing rings for M16x1.5 cable gland
1 x multi-sealing insert for M16x1.5 cable gland
1 x PVC-insulated flexible cord

3.4 Accessories (optional)

Type Part no.

Protective cover for JUMO AQUIS 500 00398161
Pipe installation set for JUMO AQUIS 500
DIN rail installation set for JUMO AQUIS 500
Support pillar with base clamp, arm and chain 00398163
Holder for suspension fitting 00453191
Back panel set 202560/65 00506351
PC setup software 00483602
PC interface cable including USB/TTL converter and two

adapters (USB connecting cable)

1

2

00483664
00477842

00456352

1

With the pipe installation set, the JUMO AQUIS 500 can be attached to
a pipe (e. g. a support pillar or a railing).

2

With the DIN rail installation set, the JUMO AQUIS 500 can be attached
to a 35 mm x 7.5 mm DIN rail as per EN 60715 A.1.

11

4.1 General

30

60

149

134

120

161

140

77

94

94

23

(1)

4 Mounting

Mounting
location

Find a location that ensures easy accessibility for the later calibration.
The fastening must be secure and must ensure low vibration for the device.
Avoid direct sunlight!
Permissible ambient temperature at the installation location: -10 to 55°C with

max. 95% rel. humidity, no condensation.

Installation

The device can be mounted in any position.

position

4.2 Surface mounting

n

Fixing brackets (1) are included with delivery.

✱ Screw four fixing brackets (1) onto the enclosure.

The fixing brackets can be turned in increments of 90°.

✱ Fasten the enclosure onto the fixing brackets (with screws, plugs, etc.) on a

surface or plate.

12

4 Mounting

ø30-50

(2)

(1)

(1)

4.3 Pipe installation set / weather protection roof

The pipe installation set for JUMO AQUIS 500 (item no.: 00483664) can be
used to fasten the device (and optionally the protective roof for JUMO AQUIS
500, item no.: 00398161) onto pipes or railings with a diameter from 30 to 50
mm.

Screws (1) M5 x 30 for pipe diameters from 30 to 40 mm.
Screws (2) M5 x 40 for pipe diameters from 40 to 50 mm.
The pipe installation set is also suitable for horizontal pipes.

4.4 DIN rail installation set

The DIN rail installation set for JUMO AQUIS 500 (item no.:00477842) can be
used to attach the device to a 35 mm x 7.5 mm DIN rail as defined in DIN EN
60715 A.1.

13

4 Mounting

(1)

(2)

(4)

(5)

(3)

4.5 Mounting in a panel

Drilling template See section 15.4 "Panel cut-out", page 128.
The panel must be sufficiently thick to achieve the specified IP65 enclosure

protection!

✱ Prepare the panel cut-out and holes based on the drill template.
✱ Place the control panel (1) with gasket (2) in the panel cut-out and fasten it

with screws (2) spacing rollers (4) and nuts (5).

To ensure electrical safety, the cable cover must be mounted,
see next page!

14

4 Mounting

(1)

(2)

(3)

44

Depth behind
panel

✱ Make the electrical connection.
✱ Break off the required flap(s) (3) from the cable cover (2) so that the cable

can be laid in the cable path.

✱ Attach the cable cover (2) onto the control panel (1).

15

5.1 Installation instructions

The electrical connection must only be performed by
qualified personnel!

The choice of cable, the installation and the electrical connection must
conform to the requirements of VDE 0100 “Regulations on the Installation of
Power Circuits with Nominal Voltages below 1000 V” or the appropriate local
regulations. Only flexible cables and wires shall be used!

If contact with live parts is possible while working on the device, it must be
completely disconnected from the electrical supply.

Load circuits must be fused for the maximum relay current in each case, in
order to prevent welding of the relay contacts in the event of a short circuit.

The electromagnetic compatibility conforms to EN 61326.
Run input, output and supply cables separately and not parallel to one

another.
Use shielded sensor cables with twisted conductors. Do not run these cables

close to current-carrying components or cables. Ground shielding at one end.
Sensor leads should be implemented as uninterrupted cables (not routed via

terminal blocks etc.).
Do not connect any additional loads to the supply terminals of the device.
The device is not suitable for use in areas with an explosion hazard (Ex areas).
Apart from faulty installation, incorrect settings on the device may also affect

the proper functioning of the subsequent process or lead to damage. Safety
devices independent of the device should therefore always be provided and
should only be capable of adjustment by specialist personnel.

5 Electrical connection

Conductor
cross-sections
and ferrules

Mounting information

Minimum
cross-section

Without ferrule 0.34mm

Ferrule without collar 0.25mm
Ferrule with collar, up to 1.5 mm
Ferrule with collar, from 1.5mm
Twin ferrule with collar 0.25mm

2

2

0.25mm

1.5mm

2

2

2

2

2

Maximum
cross-section

2

2.5mm

2

2.5mm

2

1.5mm

2

2.5mm

2

1.5mm

Minimum
ferrule length

10mm
(stripped)

10mm
10mm
12mm
12mm

The enclosure protection specified for the device (IP67) is only achievable if not
more than one cable runs into the device through each cable gland.

16

5.2 Electrical isolation

3,700 V AC

1

Setup interface

Supply voltage

30 V AC
50 V DC

Supply voltage
for a 2-wire transmitter

3,700 V AC

Relay contacts

Binary input

Supply voltage
for an inductive proximity switch

30 V AC
50 V DC

Analog output 1

Secondary input (Pt100/Pt1000)

30 V AC
50 V DC

Analog output 2

Main input standard signal
0(4) ... 20 mA or 0 - 10 V

5 Electrical connection

1

Not for SELV/PELV of 30 (12 - 24 V DC) supply voltage!

17

5 Electrical connection

(1)

(2)

5.3 Opening and closing the device

Opening the
device

Closing the
device

✱ Prior to opening, loosen all cable fittings (2) so that the cables are

moveable.

✱ Push connection cable a little into the case so that enough cable reserve is

available for opening.

✱ Loosen the 4 front-panel screws (1) of the case lid and pull them out as

much as possible.

✱ Pull the lid to the front and then fold to the front. The user needs to be able

to easily open the lid. Do not use force while opening!

✱ When closing the device, pull the connecting cables to the outside while

the cable fittings are in a released state and make sure that the lines in the
inside of the device run properly. Pay attention to the corresponding
sheathing measurement to ensure strain relief and protection type (IP67) of
the cable fitting.

✱ The user must be able to close the lid with the 4 screws without a high

degree of pressure.

✱ Tighten cable fittings.

18

5.4 Connecting the cables

(1)

The electrical connection for the surface-mountable housing is easily
accessible when the device is folded out.

5 Electrical connection

The device contains a guide plate that ensures an optimum cable path. After
laying the cables, the cable cover (1) must be attached until it clicks, like
shown above. This is important to ensure the electrical safety!

To connect the individual core wires, remove pluggable screw terminals from
the control panel.

Run the connecting cables through the cable glands.

19

5 Electrical connection

987654103

NL1

(L-) (L+)

11 12 13 14 15

13 14 15 16

9876541032

1

11 12

(3)

(1)

(2)

figure without cable cover
and without sensor cable

987654103

11 12 13 14 15

9876541032

1

(L-)

NL1

(L+)

13 14 15 16

11 12

Row 1

Row 2

Interior view

✱ Lead the connecting cables in through the cable fittings.
✱ Use the cable clip (3) to clamp the signal cable to the shielding.

The clip (3) must only be attached by a 3.5 x 6.5 pan head screw! If the screw
is any longer, dangerous voltage could be directed to the cable shielding!

✱ Break off the required flap(s) from the cable cover so that the cable can be

laid in the cable path. Attach the cable cover.

✱ Connect the cores as assigned below, and as seen in section 5.6 "Pin

configuration", page 21.

✱ Push the plug-in terminals for row 1 (1) and row 2 (2) into the sockets in the

device.

5.5 Terminal assignment

20

5 Electrical connection

ϑ

9

8

10

ϑ

9

8

10

11

12

5.6 Pin configuration

Connection Terminal Row
Power supply voltage for transmitter/controller

Supply voltage (23):
110 — 240 V AC -15/+10%, 48 — 63 Hz

Supply voltage (25):
20—30V AC/DC, 48—63Hz

Supply voltage (30):
12 — 24 V DC +/-15% (permissible only for
connection to SELV/PELV circuits)

NC 3

Power supply voltage for proximity switch

12 V DC (10 - 20 V) 11 L+

Power supply voltage for transmitter

24 V DC (-15 / +20 %) 14 L+

Inputs

NC 1

Standard signal input
0(4) - 20 mA

or
0 - 10 V and 10 - 0 V

Resistance thermometer in 2-wire circuit 8

1 N (L-)

2 L1 (L+)

12 ⊥

15 L-

2
3
6
7

4 -

5 +

9

10

1

1

1

2

Inputs

Resistance thermometer in 3-wire circuit 9

8

10

Binary input 11

2

12

Outputs

21

5 Electrical connection

+

-

+

-

6

4

5

10

8

9

Connection Terminal Row

Analog output 1
0 - 20 mA and 20 - 0 mA or 4 - 20 mA and

20 - 4 mA
or
0 - 10 V and 10 - 0 V

(electrically isolated)
Analog output 2

0 - 20 mA and 20 - 0 mA or 4 - 20 mA and
20 - 4 mA
or
0 - 10 V and 10 - 0 V

(electrically isolated)
Switching output K1

(floating)

Switching output K2
(floating)

+ 13

- 14

2

+ 15

- 16

4 pole
5 NC
6 NO

1NC 7

8 pole
9 NC
10 NO

22

6 Operation

(2)

(1)

(4)

(6)

(5)

(3)

CAL

EXIT

PGM

device operation via the optional set-up program, See section 12 "Setup
program", page 104.

Operation via the device keypad is described
below.

6.1 Controls

(1) Display backlit (during operation)

(2) key Start calibration

(3) key Cancel entry / Exit level

(4) key Change level

Forward selection
Confirm selection

(5) key Reduce numerical value

Forward selection

(6) key Increase numerical value

Forward selection

23

6 Operation

(1) (2) (3) (5)(4) (6)

(7)

(8)(9)

(10)

(11)

EXIT

6.2 Display

6.2.1 Measuring mode (normal display)

Example

Relay K1 is active

(1)

Relay K2 is active

(2)

Binary input 1 is

(3)

triggered
Keypad is locked

(4)

device status (notes)

(5)

- Alarm (e.g. overrange)

- Calib flashes (calibration timer
expired)

- Calib (customer calibration
active)

Output mode

(6)

- Man (manual mode)

- Hold (hold mode)

To return to measuring mode (MEASURING):
press the key or wait for a "timeout".

Measurement value

(7)

Measurement unit

(8)

Temperature of measuring

(9)

material

(10)

device status e.g.

- Measuring (normal)

- Calibration status

(11)

AL R1 = Alarm, controller 1
AL R2 = Alarm, controller 2
AL R12 = Alarm, controllers 1
and 2

24

6.3 Principle of operation

EXIT

or

timeout

(appr. 60 s)

PGM

Normal display

> 2 s

Measurement mode

Operator level
Administrator level
Calibration level
Calibration logbook
Device info

Main menu

Standard signal
Temperature input
Binary input
Controller channel 1

Switch output

Analog 1

2

Display

Controller channel 2
Controller spec. funct.

1

Switch output 2

output

Analog output

Operator level

Password

Parameter level
Enable

Calibration enable

freigabe

Delete logbook

level

Basic settings

Calibration

Administrator level

Zero point
Final value
2-Point calibration

Calibration level

Calibration data

Calibration logbook

Input
Signal type
Operating mode
Unit
Decimal point
Scaling start
Scaling end

Device info

EXIT EXIT EXIT

EXIT

EXIT

or

timeout

(appr. 60 s)

or

timeout

(appr. 60 s)

or

timeout

(appr. 60 s)

or

timeout

(appr. 60 s)

or

timeout

(appr. 60 s)

6.3.1 Operation in levels

6 Operation

25

6 Operation

6.4 Parameter overview

Measuring mode (normal display); See section 6.5 "Measuring mode", page 28

OPERATOR LEVEL, See section 6.9 "Operator level", page 35

STANDARD SIGNAL
TEMPERATURE INPUT
BINARY INPUT
CONTROLLER CHANNEL 1
CONTROLLER CHANNEL 2
CONTROLLER SPEC. FUNCT.
SWITCH OUTPUT 1
SWITCH OUTPUT 2
ANALOG OUTPUT 1
ANALOG OUTPUT 2
DISPLAY

CTRl. Setpoints

MIN/MAX values
See section 6.6.1 "Min/Max
values", page 28

Output level display
See section 6.6.2 "Output
level limit", page 29

Manual mode overview
See section 6.7.4 "MANUAL/
Simulation overview", page
33

ADMINISTR. LEVEL, See section 6.10 "Administrator level", page 35

Password

PAR AMETER LE VEL

STANDARD SIGNAL
TEMPERATURE INPUT
BINARY INPUT
CONTROLLER CHANNEL 1
CONTROLLER CHANNEL 2
CONTROLLER SPEC. FUNCT.
SWITCH OUTPUT 1
SWITCH OUTPUT 2
ANALOG OUTPUT 1
ANALOG OUTPUT 2
DISPLAY

ENABLE LEVEL

STANDARD SIGNAL
TEMPERATURE INPUT
BINARY INPUT
CONTROLLER CHANNEL 1
CONTROLLER CHANNEL 2
CONTROLLER SPEC. FUNCT.
SWITCH OUTPUT 1
SWITCH OUTPUT 2
ANALOG OUTPUT 1
ANALOG OUTPUT 2
DISPLAY

,

See section 6.10.2 "Parameter level", page 37

, See section 6.10.3 "Enable level", page 37

26

Measuring mode ADMINISTRATOR LEVEL

BASIC SETTINGS,

INPUT
SIGNAL TYPE
OPERATING MODE
UNIT
DECIMAL POINT
SCALING START
SCALING END
NEW DEVICE INITIALIZE

See section 6.10.4 "Basic settings", page 39

6 Operation

CALIBRATION LEVEL

ZERO POINT
FINAL VALUE
2-POINT CALIBRATION

CALIBRATION LOGBOOK

DEVICE INFO

CALIBRATION LEVEL
40

ZERO POINT
FINAL VALUE
2-POINT CALIBRATION

CALIBRATION ENABLE

ZERO POINT
FINAL VALUE
2-POINT CALIBRATION

DELETE LOGBOOK

,

See section 6.10.6 "Calibration level", page

27

6 Operation

(3)

(1)

(2)

PGM

6.5 Measuring mode

6.5.1 Normal display

Visualization The following are displayed in measuring mode:

- the analog input signal

- the unit: (configurable as pH, mS/cm, µS/cm, ppm, %, mV, etc.)

- the temperature of the measuring material

(1) MEASURING -> measuring mode
(2) 23.7°C -> the temperature of the measuring material
(3) 1.58 ppm -> the measurement value calculated from the standard

signal at the input

The "trend display" or "bar graph" display types can also be selected in
measuring mode, see "MEAS. DISPLAY TYPE" page 118.

6.6 Input/output information

6.6.1 Min/Max values

Activating the
display of min/
max values

The device is in measuring mode (normal display)
✱ Press the key for less than 2 seconds.

The minimum and maximum values of the main variable (ppm, pH,
conductivity, etc.), and the temperature are displayed.

28

The extreme values of the main measurement variable and the temperature are
not mutually assigned (e. g. not 1.16 ppm at 15.3°C).

To return to measuring mode:

EXIT

PGM

PGM

EXIT

PGM

press the key or wait for a "timeout".
Measurements with "out of range" are ignored.
Press the key again briefly to go to "Output level limit" mode.
The min/max value memory can be reset:

Operator level/ Display / Min/Max reset.
If the basic setting is changed or there is a loss of power,

the min and max values are deleted.

6.6.2 Output level limit

6 Operation

The device is in measuring mode (normal display)
✱ Press the key twice for less than 2 seconds.

The output level of both controller contacts will be displayed (if available).

The output level of an output can only be displayed if the output concerned
has been configured:
e.g. Administr. level/ Parameter level/ Ctr. chan.1 or 2.

To return to the normal display:
Press the key or wait for a "time out".
Press the key again to go to "Manual mode overview" mode.

29

6 Operation

Simulation modeMANUAL mode

"Higher order"

controller

Switching output

K1 / K1

Analog output

A1 / A1

6.7 MANUAL mode / simulation mode

These functions can be used to set the switching outputs and analog outputs
of the device manually to a defined state. This facilitates dry startup,
troubleshooting and customer service.

Simulation mode directly accesses switching outputs K1/2 or analog outputs
1/2. When simulation mode has been selected, MANUAL mode is not
possible!

In MANUAL mode the settings for "higher order controllers" are taken into
consideration.

6.7.1 MANUAL mode via "higher order control functions"

Higher order
switching
functions

Select manual
mode

The JUMO AQUIS 500 is configured for higher order control functions when
the following setting is made:

User level / controller channel 1 or 2 / control type Limit value or pulse length

or pulse frequency or modulating or continuous controller.

When the configuration is set to continuous controller, analog outputs 1 and/or
2 are activated. In other configurations switching outputs K1 or K2 are
switched.

In the factory setting of the device the MANUAL mode parameter is disabled
and can only be activated by the administrator!
This parameter must first be enabled for other users.

30

✱ Set to Administrator level / Password / Parameter level / Special controller

functions / Manual mode locked, Momentary action or Switching.

6 Operation

EXIT

EXIT

EXIT

EXIT

PGM

PGM

Locked = No manual mode, control via JUMO AQUIS 500.
Momentary =the outputs are active as long as the or key is pressed.

action
Switching = the outputs are active if the or key is pressed. If the

corresponding key is pressed again, the output becomes inactive
again.

Activate
manual mode

The device is in display mode
✱ Press the and keys for less than 2 seconds.

The word MANUAL appears in the status line of the display.

If the and keys are pressed for longer than 3 seconds, the device goes
into HOLD mode.

Then the outputs of the device respond according to the default settings.
To exit HOLD mode, press the and keys for longer than 3 seconds.

Control is no longer through the JUMO AQUIS 500. The output level of the
controller channels is 0%.

Controller channel 1 is activated by the key. In this case the output level of
controller channel 1 is 100%.

Controller channel 2 is activated by the key. In this case the output level of
controller channel 2 is 100%.

Deactivation ✱ Press the key.

Control is once again through the outputs of the device.
The word MANUAL appears in the status line of the display.

Overview of
MANUAL/
Simulation
mode

You can display which outputs and/or controllers are in MANUAL mode.
The device is in "normal display" mode.

Press the key several times for less than 2 seconds (the number of times
varies depending on the equipment and configuration of the device).

Output level of
controller
channels

The device is in "normal display" mode
Press the key several times for less than 2 seconds (the number of times

varies depending on the equipment and configuration of the device).

31

6 Operation

EXIT

The display changes when the key or the key is pressed.

To return to measuring mode:
press the key or wait for a "timeout".

6.7.2 Simulation of switching outputs

Simple witching
functions

Activate
simulation

Deactivate
manual mode

The switching outputs are configured when the following setting is made:
Operator level / Controller channels 1 and/or 2 / Controller type Off

and

Switching output 1 or 2 / function or or or .

In the factory setting of the device the MANUAL mode parameter is set to "No
simulation" and can only be activated by the administrator!
This parameter must first be enabled for other users.

✱ Set Administrator level / Password / Parameter level / Switching output 1 or

2 / Manual mode no simulation, Inactive or Active.

No simulation = No manual mode, control is via the JUMO AQUIS 500.
Inactive = Relay K1 or K2 is de-energized.
Active = Relay K1 or K2 is energized.

No simulation = No manual mode, control via JUMO AQUIS 500.

32

6.7.3 Simulation of analog outputs via MANUAL mode

PGM

EXIT

6 Operation

Enabling and
activation

Deactivation ✱

✱ Select activation of simulation of the actual value output:

Administrator level / Password / Parameter level / Analog output 1 or 2
Simulation / Off or On.

With "On" the output takes on the value of the "Simulation value" parameter.
When the JUMO AQUIS is in display mode, the word MANUAL appears in the

status line of the display.

Administrator level / Password / Parameter level / Analog output 1 or 2
Simulation / Off.

The corresponding output of the JUMO AQUIS 500 works again.
When the JUMO AQUIS is in display mode, the word MANUAL disappears

from the status line of the display.

6.7.4 MANUAL/Simulation overview

You can display which outputs and/or controllers are in MANUAL mode.
The device is in "normal display" mode

Press the key several times for less than 2 seconds (the number of times
varies depending on the equipment and configuration of the device).

/

/

.

To return to measuring mode:
press the key or wait for a "timeout".

33

6 Operation

EXIT

EXIT

EXIT

EXIT

EXIT

6.8 HOLD mode

In HOLD status the outputs take on the states programmed in the relevant
parameter (controller channel, switching output or analog output).

This function can be used to "freeze" switching outputs and the analog
outputs of the device. This means the current status of the output will be
retained even when the measured value changes. Control is not via the device.

If MANUAL mode is activated while HOLD mode is activated, MANUAL mode
takes precedence and MANUAL then appears in the status line of the display!
MANUAL mode can be terminated by pressing the key.
If HOLD mode is still activated (by the binary input or by keyboard), the device
then returns to HOLD mode!

HOLD mode can be activated by pressing the key or by the binary input.

Activation by
pressing key

Pressing a key
to deactivate
HOLD mode

✱ Press and hold the and keys longer than 3 seconds.

Then the outputs of the device respond according to the default settings.
The word HOLD appears in the status line of the display.

If the and keys are pressed for less than 3 seconds, the device goes
into manual mode.

Then the outputs of the device respond according to the default settings.

✱ Press the and keys for longer than 3 seconds.

If the and keys are pressed for less than 3 seconds, the device goes
into Manual mode.

Then the outputs of the device respond according to the default settings.

Control is through the outputs of the device again. The word MANUAL
disappears from the status line of the display.

34

6.9 Operator level

PGM

PGM

PGM

All the parameters that the Administrator (See section 6.10 "Administrator
level", page 35) has enabled can be edited at this level. All the other

parameters (marked by a key ) are read only.

✱ Press the key for longer than 2 seconds.
✱ Select "OPERATOR LEVEL".

6.10 Administrator level

6 Operation

- All the parameters can be edited at this level.

- At this level, it is also possible to define which parameters can be edited by
a "normal" operator and which calibrations can be performed.

To get to the Administrator level, proceed as follows:

✱ Press the key for longer than 2 seconds.
✱ Use the or keys to select "ADMINISTR. LEVEL".
✱ Use the or keys to enter the password 300.
✱ Confirm the key.

35

EXIT

PGM

BASIC

SETTINGS

PARAMETER

LEVEL

ADMIN. LEVEL

or

timeout

(adjustable)

CALIBRATION

LEVEL

EXIT

or

timeout

EXIT

PASSWORD

0

300

or

timeout

CALIB.

ENABLE

EXIT

or

timeout

DELETE

LOGBOOK

EXIT

or

timeout

ENABLE

LEVEL

EXIT

or

timeout

6 Operation

6.10.1 Administrator levels

36

6.10.2 Parameter level

The settings that can be made here are the same as those at operator level,
See section 6.9 "Operator level", page 35.
As the operator has administrator rights here, the parameters that are locked
at operator level can now also be modified.

6.10.3 Enable level

All parameters can be enabled (modification possible) or locked (no
modification possible) for editing at operator level.

The enable level is reached via ADMINISTR. LEVEL / PASSWORD / ENABLE
LEVEL.

STANDARD SIGNAL

Signal type
Scaling start
Scaling end
Relative cell constant
Zero point
Slope
Compensation type
Temperature coefficient
Reference temperature
Filter time const.
Calibration interval

6 Operation

TEMPERATURE INPUT

Sensor type
Unit
Filter time const.
Offset

BINARY INPUT

Function

- No function

- Key lock

- Hold mode

- Hold inverse

CTRL. CHAN. 1 and CTRL. CHAN. 2

Controller type
Setpoint
Setpoint 2
Min/Max contact
Proportional band
Reset time
Derivate time
Pulse period
Actr. stroke time
Hysteresis
Min. on time

37

6 Operation

Max. pulse freq.
Output level limit
Pull-in delay
Drop-out delay
Controller alarm
Alarm tolerance
Alarmdelay
In hold mode
Hold output level
On error
Max. setpoint
Min. setpoint

Ctrl.Spec.Funct. (Controller special functions)

I switch-off
Separate controller
Manual mode

Switching output 1 and Switching output 2

Function
Switching point
USP pre-alarm
Spacing
Hysteresis
Switch-on delay
Switch-off delay
Pulse time
During calibration
On error
In hold mode
Manual mode
No simulation
Break/make contact

ANALOG OUTPUT 1 and ANALOG OUTPUT 2

Signal selector
Signal type
Scaling start
Scaling end
During calibration
On error
In hold mode
Save value
Simulation
Simulation value

DISPLAY

Language
Lighting
LCD inverse
Meas. display type
Upper display
Lower display

38

Bargr. scale start
Bargr. scale end
Min/max reset
Op. timeout
Contrast

6.10.4 Basic settings

The JUMO AQUIS 500 AS has a basic settings wizard, to make it easier for the
user to configure the extensive setting options of the device and to avoid
configuration conflicts.
The basic settings are reached via: ADMINISTR. LEVEL / PASSWORD / BASIC
SETTINGS.

Here all the important settings are systematically queried. At the end, once a
request for conformation has been acknowledged, the device is initialized with
the new settings. Dependent parameters are checked and adjusted.

6 Operation

39

6 Operation

Operating maode

Confirmation request

Reinitialize device?

yes

no

All dependent

parameters initialized

Parameters are

not modified

Concentration

Compensation type

NaOH
HNO3

H2SO4

HCL

Conductivity

Unit

µS/cm

mS/cm

Decimal point

XXXX / XXX.x /

XX.xx / X.xxx

Temperature

coefficient

0.0 ... 5.5%/K

Custom table

Basic settings

Signal type

0...20 mA

4...20 mA

0...10 V

pH linear

Scaling start

Scaling end

Compensation type

Natural water

Linear

TE.Coef.Curve

Unit

%

customized

Scaling start

Scaling end

Decimal point

XXXX / XXX.x /

XX.xx / X.xxx

Scaling start

Scaling end

Unit

% / customized /

mV / pH / ppm /
µS/cm / mS/cm

Decimal point

XXXX / XXX.x /

XX.xx / X.xxx

Scaling start

Scaling end

6.10.5 Basic settings wizard

The basic settings of the device are specified here.

6.10.6 Calibration level

Depending on which operating mode has been configured (in the Basic
Settings menu), one or more of the following calibration options will be
available:

-Zero point

-Final value

- 2-Point calibration

- Temperature coefficient linear

- Temperature coefficient curve

- Relative cell constant

40

The calibration level is reached via: ADMINISTR. LEVEL / PASSWORD /
CALIB. LEVEL.

6.10.7 Calibration enable

The setting made here determines which calibration procedure may or may
not be run via the "CAL" key after starting calibration at the operator level.

Calibration enable is reached via: ADMINISTR. LEVEL / PASSWORD / CALIB.
ENABLE.

The following can be locked or enabled:

-Zero point

-Final value

- 2-Point calibration

- Temperature coefficient linear

- Temperature coefficient curve

- Relative cell constant

6.10.8 Delete logbook

6 Operation

The last five calibration processes are archived in the calibration logbook.
If required, the logbook can be deleted once a request for confirmation has

been acknowledged.

6.11 Device info

Here is a list of the current configuration of all the important parameters (from
the Basic Settings menu).

Example SIGNAL TYPE -> 4...20 mA

OPERATING MODE -> LINEAR
UNIT -> e.g. ppm, pH or customized unit
DECIMAL POINT -> XX.xx
SCALING START -> 0.00 ppm
SCALING END -> 2.00 ppm

41

6 Operation

6.12 Controller functions

Simple
switching
functions

Higher-order
control
functions

Typical operator
level
parameters

In the JUMO AQUIS 500, simple switching functions such as alarm contact,
limit value monitoring or calibration timer signaling are configured at parameter
level via the parameters of "Switching output 1 and 2".

In this case, the parameters of controller channel 1 and 2 must be set to "Off".
Higher-order control functions are configured at parameter level via the

parameters of "Controller channel 1 and 2".
In this case, the parameters of the switching outputs must be set to

"Controller 1 and Controller 2".

Switching output 1 / 2 Explanation

None
Controller 1 device control should be of a "higher order"

Controller 2 device control should be of a "higher order"
Controller alarm 1 / 2

Controller alarm

Main variable

Main variable

Main variable

No switching function and
no control function required

"Simple" switching functions

AF1 main variable

AF2 main variable

AF7 main variable

Main variable

Tem p.

Tem p.

Tem p.

Tem p.
Sensor error
Calibration timer

Controller channel 1 / 2

Limit value
Pulse width
Pulse frequency
Steady
Modulating

Off

AF8 main variable

AF1 temperature

AF2 temperature

AF7 temperature

AF8 temperature

"Higher order" control functions

Must be selected if "simple" switching functions
are required.

42

6.13 Manual mode

EXIT

EXIT

EXIT

EXIT

EXIT

In manual mode, controller outputs can be activated manually.
The keys assigned to the outputs can have a "pulsed" or "switched"

action.

- Pulsed: the assigned output is only activated while the key is being
pressed.

- Switched: the assigned output is activated by pressing the key and the key
must be pressed again to deactivate it.

Activating manual mode:
✱ Press the and keys for less than 1 second.

Deactivating manual mode:
✱ Press the key briefly - the device returns to normal mode

(automatic mode).

Key assignment:
The key switches output K1
The key switches output K2

6 Operation

6.14 Hold mode

When Hold mode is activated, the outputs adopt their configured states.
Activating Hold mode:
✱ Press the and keys for longer than 2 seconds.

Deactivating Hold mode:
✱ Press the and keys once again for longer than 2 seconds - the

device returns to normal mode (automatic mode).

43

7.1 Getting started

Below is a suggestion for configuring the device reliably in little time.
By checking the setting options of this list before starting the configuration,

you can avoid timeouts during the configuration.

✱ Mount the device, See section 4 "Mounting", page 12.
✱ Install the device, See section 5 "Electrical connection", page 16 ff.
✱ Call up Administrator level (ADMINISTR. LEVEL).
✱ Enter password 300.
✱ Call PARAMETER LEVEL / DISPLAY / OP. TIMEOUT.
✱ Set OP. TIMEOUT to 0 minutes (no timeout).
✱ Exit the parameter level.
✱ Call up Administrator level (ADMINISTR. LEVEL).
✱ Enter password 300.

7 Commissioning

✱ Select BASIC SETTINGS and work through all the menu items
✱ Answer "YES" to the "Reinitialize device" query
✱ Configure the required parameters.
✱ Calibrate the device to the sensor and the measuring material.

44

7 Commissioning

?

Power supply

uncalibrated sensor

Pt100 / Pt1000
temperature signal

Option:

1 or 2 relays

Option:

Calibrated analog output for
pH value
0(4) - 20 mA or 0 -10 V
electrically isolated

Option:

Output for temperature
0(4) - 20 mA or 0 -10 V
electrically isolated

(1)

(2)

(3)

(4)

signal (current 4 - 20 mA)

7.2 Setting examples

7.2.1 Measuring the pH value with a pH combination electrode and a 2-wire transmitter

For pH electrodes, see data sheets 201005, 201020 and 201030.
For 2-wire transmitter, see data sheet 202701.
For compensation thermometer, see data sheet 201085.

Ta sk Measuring range: 2 - 12 pH

Output signal: 4 - 20 mA
Temperature measurement Pt100
Control function: Pulse width controller
Setpoint 1: pH 6.5
Setpoint 2: pH 8.5

Measuring
setup

(1) JUMO AQUIS 500 AS
(2) 2-wire transmitter, type 202701
(3) pH combination electrode
(4) Compensation thermometer, type 201085/16-89-1003-22-120

45

7 Commissioning

?

+-

(3)

(4)

(5)

(6) (7)

(1)

(2)

(3)

Electrical Connection

(1) Terminal block1
(2) Terminal block 2
(3) SC = shield
(4) Coaxial cable as per data sheet 202990
(5) 2-wire shielded cable as per data sheet 202990
(6) pH combination electrode with mounted 2-wire transmitter
(7) Compensation thermometer

46

Calling up Administrator level

Administrator

level

Operator

level

Meas. mode

Calibration

level

EXIT

Calibration

logbook

Device info

PGM

OUTPUT LEVEL

Controller 1

2Controller

MIN/MAX VALUES

> 3 s

EXIT

or timeout (adjustable)

PGM

< 2 sec

PGM

< 2 sec

EXIT

o)r timeout (adjustable

EXIT

o)r timeout (adjustable

EXIT

o)r timeout (adjustable

EXIT

o)r timeout (adjustable

EXIT

CTRL. SETPOINTS

SETPOINT 1

2SETPOINT

or timeout
(adjustable)

EXIT

MANUAL MODE

OVERVIEW

PGM

< 2 sec

PGM

< 3 sec

or

✔

✔

✔

continue on

next page

PGM

7 Commissioning

47

7 Commissioning

EXIT

PGM

BASIC

SETTINGS

PARAMETER

LEVEL

ADMIN. LEVEL

or

timeout

(adjustable)

CALIBRATION

LEVEL

EXIT

or

timeout

EXIT

PASSWORD

0

300

or

timeout

CALIB.

ENABLE

EXIT

or

timeout

DELETE

LOGBOOK

EXIT

or

timeout

ENABLE

LEVEL

EXIT

or

timeout

✔

continue on

next page

PGM

✔

✔

✔

Calling up the basic settings

48

Make the basic settings for the main input

✔

✔

✔

✔

✔

✔

Operating maode

Confirmation request

Reinitialize device?

yes

no

All dependent

parameters initialized

Parameters are

not modified

Concentration

Compensation type

NaOH
HNO3

H2SO4

HCL

Conductivity

Unit

µS/cm

mS/cm

Decimal point

XXXX / XXX.x /

XX.xx / X.xxx

Temperature

coefficient

0.0 ... 5.5%/K

Custom table

Basic settings

Signal type

0...20 mA

4...20 mA

0...10 V

pH linear

Scaling start

Scaling end

Compensation type

Natural water

Linear

TE.Coef.Curve

Unit

%

customized

Scaling start

Scaling end

Decimal point

XXXX / XXX.x /

XX.xx / X.xxx

Scaling start

1

Scaling end

1

Unit

% / customized /

mV / pH / ppm /

µS/cm / mS/cm

Decimal point

XXXX / XXX.x /

XX.xx / X.xxx

Scaling start

Scaling end

7 Commissioning

1

Value relevant to the 2-wire transmitter.

49

7 Commissioning

EXIT

PGM

BASIC

SETTINGS

PARAMETER

LEVEL

ADMIN. LEVEL

or

timeout

(adjustable)

CALIBRATION

LEVEL

EXIT

or

timeout

EXIT

PASSWORD

0

300

or

timeout

CALIB.

ENABLE

EXIT

or

timeout

DELETE

LOGBOOK

EXIT

or

timeout

ENABLE

LEVEL

EXIT

or

timeout

✔

continue on

next page

PGM

✔

✔

Calling up Parameter level

50

Concluding device settings / checks

7 Commissioning

Input for
temperature

Controller
channel 1

Sensor type: Pt100/Pt1000
Unit: °C
Filter time constant: 2 s
Offset: 0.0°C

Controller type: Pulse width controller
Setpoint: pH 6.5
Min./Max. contact: Min. contact
Proportional band: As required
Reset time: As required
Derivative time: As required
Pulse period: As required
Minimum ON time: As required
Output level limit: As required
Controller alarm: As required
Alarm tolerance: As required
Alarm delay: As required
In Hold mode: As required
Hold output level: As required
On error: As required

Controller
channel 2

Max. setpoint: As required
Min. setpoint: As required

Controller type: Pulse width controller
Setpoint: pH 8.5
Min./Max. contact: Max. contact
Proportional band: As required
Reset time: As required
Derivative time: As required
Pulse period: As required
Minimum ON time: As required
Output level limit: As required
Controller alarm: As required
Alarm tolerance: As required
Alarm delay: As required
In Hold mode: As required
Hold output level: As required
On error: As required
Max. setpoint: As required
Min. setpoint: As required

51

7 Commissioning

Controller
special
functions

Switching
output 1

Switching
output 2

Analog output 1 Signal selector: Main variable

I switch-off: As required
Manual mode: As required
Separate controllers: As required

Function: Controller 1
Manual mode: As required
Break/make contact: As required

Function: Controller 2
Manual mode: As required
Break/make contact: As required

Signal type: 4 - 20 mA
Scaling start: 2.00 pH
Scaling end: 12.00 pH
During calibration: As required
On error: As required
In Hold mode: As required
Safe value: As required
Simulation: As required
Simulation value: As required

Display Language: As required

Lighting: As required
Inverse LCD: As required
Meas. display type: As required
Lower display: As required
Upper display: As required
Max./Min. reset: As required
Op. timeout: As required
Contrast: As required

52

7 Commissioning

Supply

uncalibrated

Option:

1 or 2 relays

Option:

Calibrated analog output for
pH value
0(4) - 20 mA or 0 -10 V
electrically isolated

Option:

Output for temperature
0(4) - 20 mA or 0 -10 V
electrically isolated

(1)

(2)

(3)

voltage

sensor signal
(current 4 - 20 mA)

7.2.2 Measuring the concentration of free chlorine

For sensor for chlorine, see data sheet 202630.
For optional flow monitor, see data sheet 202811

Ta sk Measuring range: 0 - 2 ppm

Output signal: 0 - 20 mA
Control function: off

Measuring
setup

(1) JUMO AQUIS 500 AS
(2) Sensor for free chlorine, type 202630
(3) Flow monitor, type 202811/20...

53

7 Commissioning

+

-

(1)

(2)

(3)

(4)

Terminal assignment of flow monitor

Wire color Function Connection

Brown +12 V Row 1, terminal 11
Black Contact

(NPN N/O
contact)

Row 2, terminal 12

Blue GND Row 1, terminal 12

Electrical connection

(1) Terminal block 1
(2) Terminal block 2
(3) Sensor for free chlorine), type 202630/40 or /43...
(4) Flow monitor, type 202811/20...

54

Calling up Administrator level

Administrator

level

Operator

level

Meas. mode

Calibration

level

EXIT

Calibration

logbook

Device info

PGM

OUTPUT LEVEL

Controller 1

2Controller

MIN/MAX VALUES

> 3 s

EXIT

or timeout (adjustable)

PGM

< 2 sec

PGM

< 2 sec

EXIT

o)r timeout (adjustable

EXIT

o)r timeout (adjustable

EXIT

o)r timeout (adjustable

EXIT

o)r timeout (adjustable

EXIT

CTRL. SETPOINTS

SETPOINT 1

2SETPOINT

or timeout
(adjustable)

EXIT

MANUAL MODE

OVERVIEW

PGM

< 2 sec

PGM

< 3 sec

or

✔

✔

✔

continue on

next page

PGM

7 Commissioning

55

7 Commissioning

EXIT

PGM

BASIC

SETTINGS

PARAMETER

LEVEL

ADMIN. LEVEL

or

timeout

(adjustable)

CALIBRATION

LEVEL

EXIT

or

timeout

EXIT

PASSWORD

0

300

or

timeout

CALIB.

ENABLE

EXIT

or

timeout

DELETE

LOGBOOK

EXIT

or

timeout

ENABLE

LEVEL

EXIT

or

timeout

✔

continue on

next page

PGM

✔

✔

✔

Calling up the basic settings

56

Make the basic settings for the main input

✔

✔

✔

✔

✔

✔

Operating maode

Confirmation request

Reinitialize device?

yes

no

All dependent

parameters initialized

Parameters are

not modified

Concentration

Compensation type

NaOH
HNO3

H2SO4

HCL

Conductivity

Unit

µS/cm

mS/cm

Decimal point

XXXX / XXX.x /

XX.xx / X.xxx

Temperature

coefficient

0.0 ... 5.5%/K

Custom table

Basic settings

Signal type

0...20 mA

4...20 mA

0...10 V

pH linear

Scaling start

Scaling end

Compensation type

Natural water

Linear

TE.Coef.Curve

Unit

%

customized

Scaling start

Scaling end

Decimal point

XXXX / XXX.x /

XX.xx / X.xxx

Scaling start

Scaling end

Unit

ppm

Scaling start

1

Scaling end

1

Decimal point

XX.xx

✔

✔

7 Commissioning

1

Value relevant to the 2-wire transmitter.

57

7 Commissioning

EXIT

PGM

BASIC

SETTINGS

PARAMETER

LEVEL

ADMIN. LEVEL

or

timeout

(adjustable)

CALIBRATION

LEVEL

EXIT

or

timeout

EXIT

PASSWORD

0

300

or

timeout

CALIB.

ENABLE

EXIT

or

timeout

DELETE

LOGBOOK

EXIT

or

timeout

ENABLE

LEVEL

EXIT

or

timeout

✔

continue on

next page

PGM

✔

✔

Calling up Parameter level

58

Concluding device settings / checks

7 Commissioning

Input for
temperature

Binary input Function: Hold mode
Analog output 1 Signal type: 0 - 20 mA

Display Language: As required

Sensor type: No sensor
Unit: °C
Filter time constant: 2 s
Manual temperature: As required

Scaling start: 0.00 ppm
Scaling end: 2.00 ppm
During calibration: As required
On error: As required
In Hold mode: As required
Safe value: As required
Simulation: As required

Lighting: As required
LCD inverse: As required
Meas. display type: As required
Lower display: None
Upper display: Main variable
Max./Min. reset: As required
Op. timeout: As required
Contrast: As required

59

7 Commissioning

Supply voltage

Sensor signal
(current 4 - 20 mA)

Option:

1 or 2 relays

Option:

Calibrated analog output for
level
0(4) - 20 mA or 0 -10 V
electrically isolated

Option:

Output for temperature
0(4) - 20 mA or 0 -10 V
electrically isolated

(1)

(2)

7.2.3 Liquid level or level measurement or pressure measurement

For level measurement probes, see data sheets 402090, 404390, 404391 and

404753.
Pressure transmitter, see data sheet 401010 e.g.

Ta sk Measuring range: 0 - 100%

Output signal: 4 - 20 mA
Control function: Limit controller
Limit value 1: 10%
Limit value 2: 80%

Measuring
setup

(1) JUMO AQUIS 500 AS
(2) Level probe, type 402090 or type 403490 or type 404391 or pressure transmitter type

60

401010 e.g.

Electrical connection

+

-

(1)

(2)

(3)

(4)

(5)

7 Commissioning

(1) Terminal block 1
(2) Terminal block 2
(3) Temperature signal connection
(4) Level signal connection
(5) Level probe or pressure transmitter

61

7 Commissioning

Administrator

level

Operator

level

Meas. mode

Calibration

level

EXIT

Calibration

logbook

Device info

PGM

OUTPUT LEVEL

Controller 1

2Controller

MIN/MAX VALUES

> 3 s

EXIT

or timeout (adjustable)

PGM

< 2 sec

PGM

< 2 sec

EXIT

o)r timeout (adjustable

EXIT

o)r timeout (adjustable

EXIT

o)r timeout (adjustable

EXIT

o)r timeout (adjustable

EXIT

CTRL. SETPOINTS

SETPOINT 1

2SETPOINT

or timeout
(adjustable)

EXIT

MANUAL MODE

OVERVIEW

PGM

< 2 sec

PGM

< 3 sec

or

✔

✔

✔

continue on

next page

PGM

Calling up Administrator level

62

Calling up the basic settings

EXIT

PGM

BASIC

SETTINGS

PARAMETER

LEVEL

ADMIN. LEVEL

or

timeout

(adjustable)

CALIBRATION

LEVEL

EXIT

or

timeout

EXIT

PASSWORD

0

300

or

timeout

CALIB.

ENABLE

EXIT

or

timeout

DELETE

LOGBOOK

EXIT

or

timeout

ENABLE

LEVEL

EXIT

or

timeout

✔

continue on

next page

PGM

✔

✔

✔

7 Commissioning

63

7 Commissioning

✔

✔

✔

✔

✔

✔

Operating maode

Confirmation request

Reinitialize device?

yes

no

All dependent

parameters initialized

Parameters are

not modified

Concentration

Compensation type

NaOH
HNO3

H2SO4

HCL

Conductivity

Unit

µS/cm

mS/cm

Decimal point

XXXX / XXX.x /

XX.xx / X.xxx

Temperatur e

coefficient

0.0 ... 5.5%/K

Custom table

Basic settings

Signal type

0...20 mA

4...20 mA

0...10 V

pH linear

Scaling start

Scaling end

Compensation type

Natural water

Linear

TE.Coef.Curve

Unit

%

customized

Scaling start

Scaling end

Decimal point

XXXX / XXX.x /

XX.xx / X.xxx

Scaling start

1

Scaling end

1

Unit

%

customized

Decimal point

XXX.x

Scaling start

Scaling end

✔

✔

Make the basic settings for the main input

1

Value relevant to level measurement probe or pressure transmitter.

64

Calling up Parameter level

EXIT

PGM

BASIC

SETTINGS

PARAMETER

LEVEL

ADMIN. LEVEL

or

timeout

(adjustable)

CALIBRATION

LEVEL

EXIT

or

timeout

EXIT

PASSWORD

0

300

or

timeout

CALIB.

ENABLE

EXIT

or

timeout

DELETE

LOGBOOK

EXIT

or

timeout

ENABLE

LEVEL

EXIT

or

timeout

✔

continue on

next page

PGM

✔

✔

7 Commissioning

65

7 Commissioning

Concluding device settings / checks
Input for

temperature

Controller
channel 1

Sensor type: Pt100/Pt1000
Unit: °C
Filter time constant: 2 s
Manual temperature: As required

Controller type: Limit controller
Setpoint: 10%
Min./Max. contact: Min. contact
Hysteresis: As required
Pull-in delay: As required
Drop-out delay: As required
Controller alarm: As required
Alarm tolerance: As required
Alarm delay: As required
In Hold mode: As required
On error: As required
Max. setpoint: As required
Min. setpoint: As required

Controller
channel 2

Switching
output 1

Switching
output 2

Display Language: As required

Controller type: Limit controller
Setpoint: 80%
Min./Max. contact: Max. contact
Hysteresis: As required
Pull-in delay: As required
Drop-out delay: As required
Controller alarm: As required
Alarm tolerance: As required

Function: Controller 1
Manual mode: As required

Function: Controller 2
Manual mode: As required

Lighting: As required
LCD inverse: As required
Meas. display type: As required
Lower display: Temperature
Upper display: Compensated

66

Max./Min. reset: As required
Op. timeout: As required
Contrast: As required

7.2.4 Measuring two temperatures

??

Supply voltage
Sensor signal

(current 4 - 20 mA)

Option:

1 or 2 relays

Option:

Output for temperature 1
(4) - 20 mA or 0 -10 V
electrically isolated

Option:

Output for temperature 2
0(4) - 20 mA or 0 -10 V
electrically isolated

(1)

(2)

Pt100 / Pt1000

Temperature signal

(3)

(4)

For temperature sensors, see data sheets 707010, 707030 and 909722.

Ta sk Measuring range 1: 0 - 100°C

Output signal: 0 - 20 mA
Temperature measurement: With Pt100
Control function: Input 1: PID controller

Input 2: Simple limit switch
Limit value 1: 80°C
Limit value 2: 50°C

Measuring
setup

7 Commissioning

(1) JUMO AQUIS 500 AS
(2) 2-wire transmitter for temperature
(3) Fitting for temperature sensor and 2-wire transmitter
(4) Compensation thermometer

Input 1 can only be changed from °C to °F (customized unit) by means of the
setup program!
Input 2 can be changed directly on the device in the "Temperature input / Unit"
menu.

67

7 Commissioning

?

+-

(1)

(2)

(3)

(5)

(6)

(4)

(7)

Electrical connection

(1) Terminal block 1
(2) Terminal block 2
(3) Temperature signal 2 connection
(4) Temperature signal 1 connection
(5) 2-wire transmitter for temperature
(6) Fitting for temperature sensor and 2-wire transmitter
(7) Compensation thermometer

68

Calling up Administrator level

Administrator

level

Operator

level

Meas. mode

Calibration

level

EXIT

Calibration

logbook

Device info

PGM

OUTPUT LEVEL

Controller 1

2Controller

MIN/MAX VALUES

> 3 s

EXIT

or timeout (adjustable)

PGM

< 2 sec

PGM

< 2 sec

EXIT

o)r timeout (adjustable

EXIT

o)r timeout (adjustable

EXIT

o)r timeout (adjustable

EXIT

o)r timeout (adjustable

EXIT

CTRL. SETPOINTS

SETPOINT 1

2SETPOINT

or timeout
(adjustable)

EXIT

MANUAL MODE

OVERVIEW

PGM

< 2 sec

PGM

< 3 sec

or

✔

✔

✔

continue on

next page

PGM

7 Commissioning

69

7 Commissioning

EXIT

PGM

BASIC

SETTINGS

PARAMETER

LEVEL

ADMIN. LEVEL

or

timeout

(adjustable)

CALIBRATION

LEVEL

EXIT

or

timeout

EXIT

PASSWORD

0

300

or

timeout

CALIB.

ENABLE

EXIT

or

timeout

DELETE

LOGBOOK

EXIT

or

timeout

ENABLE

LEVEL

EXIT

or

timeout

✔

continue on

next page

PGM

✔

✔

✔

Calling up the basic settings

70

Make the basic settings for the main input

✔

✔

Operating maode

Confirmation request

Reinitialize device?

yes

no

All dependent

parameters initialized

Parameters are

not modified

Concentration

Compensation type

NaOH
HNO3

H2SO4

HCL

Conductivity

Unit

µS/cm

mS/cm

Decimal point

XXXX / XXX.x /

XX.xx / X.xxx

Temperature

coefficient

0.0 ... 5.5%/K

Custom table

Basic settings

Signal type

0...20 mA

4...20 mA

0...10 V

pH linear

Scaling start

Scaling end

Compensation type

Natural water

Linear

TE.Coef.Curve

Unit

%

customized

Scaling start

Scaling end

Decimal point

XXXX / XXX.x /

XX.xx / X.xxx

Scaling start

Scaling end

Unit

customized

1

Decimal point

XXX.x

Scaling start

2

Scaling end

2

✔

✔

✔✔✔

✔

7 Commissioning

1

2

It is essential to have the setup program to set the customized unit of measurement!
Value relevant to the 2-wire transmitter of temperature sensor 1.

71

7 Commissioning

EXIT

PGM

BASIC

SETTINGS

PARAMETER

LEVEL

ADMIN. LEVEL

or

timeout

(adjustable)

CALIBRATION

LEVEL

EXIT

or

timeout

EXIT

PASSWORD

0

300

or

timeout

CALIB.

ENABLE

EXIT

or

timeout

DELETE

LOGBOOK

EXIT

or

timeout

ENABLE

LEVEL

EXIT

or

timeout

✔

continue on

next page

PGM

✔

✔

Calling up Parameter level

72

Concluding device settings / checks

7 Commissioning

Input for
temperature

Controller
channel 1

2

1

Sensor type: Pt100/Pt1000
Unit: °C
Filter time constant: 2 s
Offset: 0.0°C

Controller type: Pulse width controller
Setpoint: 80.0°C
Min./Max. contact: Max. contact
Proportional band: As required
Reset time: As required
Derivative time: As required
Pulse period: As required
Minimum ON time: As required
Output level limit: As required
Controller alarm: As required
Alarm tolerance: As required
Alarm delay: As required
In Hold mode: As required
Hold output level: As required
On error: As required
Max. setpoint: As required
Min. setpoint: As required

Controller

Controller type: Off

channel 2
Switching

output 1

2

Switching
output 2

1

Function: Controller 1

Function: Temperature
Switching point: 50.0°C
Hysteresis: As required
Switch-on delay: As required
Switch-off delay: As required
Pulse time: As required
During calibration: As required
On error: As required
In Hold mode: As required
Manual mode: As required

Analog output 1 Signal selector: Main variable

Signal type: 0 - 20 mA
Scaling start: 0.0°C

73

7 Commissioning

Scaling end: 100.0°C
During calibration: As required
On error: As required
In Hold mode: As required
Safe value: As required
Simulation: As required
Simulation value: As required

Display Language: As required

Lighting: As required
Inverse LCD: As required
Meas. display type: As required
Lower display: Temperature
Upper display: Compensated
Max./Min. reset: As required
Op. timeout: As required
Contrast: As required

1

The sensor of "Temperature 2" is configured here.

2

The sensor of "Temperature 1" is configured here.

74

8 Calibrating a sensor with a standard signal

CAL

8.1 Notes

During calibration, relays and analog output signals adopt their configured
states!

The sensors connected to the device should be cleaned and the device itself
calibrated, at regular intervals (subject to the measuring material).

8.2 General

The device provides three calibration options for adapting the JUMO AQUIS
500 AS to a sensor with a standard signal (e.g. a sensor for free chlorine):

- With one-point offset calibration, the zero point of the sensor is

calibrated, see section 8.3 "One-point offset calibration (zero point
calibration)", page 76.

- With two-point calibration, the zero point and slope of the sensor are

calibrated, see section 8.4 "Two-point calibration", page 78. This is the
recommended calibration for most sensors.

- With one-point final value calibration, the slope of the sensor is

calibrated, see section 8.5 "Final value calibration", page 80. This is the
recommended calibration for chlorine sensors, for example.

Start
calibration

Calibration can be started as follows:

- By pressing the key,

if this has been enabled in ADMINISTR. LEVEL / PASSWORD / CALIB.
ENABLE.

- Via ADMINISTR. LEVEL / PASSWORD / CALIB. LEVEL

- Via CALIB. LEVEL in the main menu,

if this has been enabled in ADMINISTR. LEVEL / PASSWORD / CALIB.
ENABLE.

The way in which the outputs respond depends on their configuration.

1

Relevant to the connected 2-wire transmitter.

75

8 Calibrating a sensor with a standard signal

CAL

PGM

8.3 One-point offset calibration (zero point calibration)

Requirement - The JUMO AQUIS 500 AS must be supplied with voltage.

see section 5 "Electrical connection", page 16 ff.

- A sensor must be connected.

- The configuration of the basic settings must be as follows:

SIGNAL TYPE relevant to the connected 2-wire
transmitter
OPERATING MODE "LINEAR"
UNIT "% or Customized"
DECIMAL POINT as required
SCALING START
SCALING END
.

- Calibration must be enabled,

see section 6.10 "Administrator level", page 35.

- The transmitter is in "measuring mode".

1

1

✱ Now bring the system to a defined state (e.g. when measuring liquid level:

empty the container).

The way in which the outputs respond depends on their configuration.

✱ Start calibration (by pressing the key or via Administrator level).

✱ Start the zero point calibration with the key.

1

Relevant to the connected 2-wire transmitter.

76

8 Calibrating a sensor with a standard signal

PGM

PGM

PGM

EXIT

Wait until the display value has stabilized; then press to continue.

✱ Set the displayed value to the required value (usually 0%) with

keys or ; then press to continue.

The zero point determined by the device is displayed.
✱ Use the key to accept the value or

the key to reject it.

The device returns to measuring mode.

77

8 Calibrating a sensor with a standard signal

display =

input value

slope

+ zero point

CAL

8.4 Two-point calibration

The values determined during calibration (zero point and slope) work out as
follows:

Requirement - The device must be supplied with voltage.

see section 5 "Electrical connection", page 16 ff.

- A sensor must be connected.

- The configuration of the basic settings must be as follows:

INPUT "STANDARD SIGNAL"
SIGNAL TYPE relevant to the connected 2-wire
transmitter
OPERATING MODE "LINEAR"
UNIT "% or customized"
DECIMAL POINT as required
SCALING START
SCALING END

- Calibration must be enabled,

see section 6.10 "Administrator level", page 35.

- The transmitter is in "measuring mode".

1

1

✱ Now bring the system to a defined state (e.g. when measuring liquid level:

empty the container).

The way in which the outputs respond depends on their configuration.

✱ Start calibration (by pressing the key or via Administrator level).

1

Relevant to the connected 2-wire transmitter.

78

8 Calibrating a sensor with a standard signal

PGM

PGM

PGM

PGM

PGM

✱ Start the 2-point calibration with the key.

✱ Wait until the display value has stabilized; then press

to continue.

✱ Set the displayed value to the required value (usually 0) with

keys or ; then press to continue.

✱ Now bring the system to a second defined state

(e.g. when measuring liquid level: container full).

✱ Wait until the display value has stabilized; then press

to continue.

✱ Set the displayed value to "Maximum" (usually 100%) with

keys or ; then press to continue.

79

8 Calibrating a sensor with a standard signal

PGM

EXIT

The zero point and slope determined by the device are displayed.
✱ Use the key to accept the calibrated values or

reject them with the key.

The device returns to measuring mode.

8.5 Final value calibration

Requirement - The JUMO AQUIS 500 AS must be supplied with voltage.

see section 5 "Electrical connection", page 16 ff.

- A sensor must be connected.

- The configuration of the basic settings must be as follows:

INPUT "STANDARD SIGNAL"
SIGNAL TYPE relevant to the connected 2-wire transmitter
OPERATING MODE "LINEAR"
UNIT "ppm or customized"
DECIMAL POINT as required
SCALING START
SCALING END
.

- Calibration must be enabled, see section 6.10 "Administrator level", page

35.

- The transmitter is in "measuring mode".

For a configuration example see section 7.2.2 "Measuring the concentration of
free chlorine", page 53.

1

1

1

Relevant to the connected 2-wire transmitter.

80

8 Calibrating a sensor with a standard signal

CAL

PGM

PGM

PGM

-

✱ The process must now be brought to the state that is as relevant as

possible to the final value (e.g. when measuring chlorine, the required
concentration).

The way in which the outputs respond depends on their configuration.

✱ Start calibration (by pressing the key or via Administrator level).

✱ Start the zero point calibration with the key.

Wait until the display value has stabilized; then press to continue.

✱ Set the displayed value to the required final value with keys or ;

then press to continue.

81

8 Calibrating a sensor with a standard signal

PGM

EXIT

The slope determined by the device is displayed.
✱ Use the key to accept the value or

the key to reject it.

The device returns to measuring mode.

82

9 Calibrating a pH combination electrode

CAL

9.1 Notes

During calibration, relays and analog output signals adopt their configured
states!

The sensors connected to the device should be cleaned and the device itself
calibrated, at regular intervals (subject to the measuring material).

9.2 General

The device provides two calibration options for adapting the JUMO AQUIS
500 AS to a pH combination electrode:

- With one-point offset calibration, the zero point of the pH

combination electrode is calculated, See section 9.3 "One-point offset
calibration (zero point calibration)", page 84.
Recommended only for special applications, such as ultra-pure water.

- With two-point calibration, the zero point and slope of the combination

electrode are calibrated, See section 9.4 "Two-point calibration", page 86.
This is the recommended calibration for most sensors.

Start
calibration

The device must be configured for pH measurement!
For a configuration example See section 7.2.1 "Measuring the pH value with a

pH combination electrode and a 2-wire transmitter", page 45.

Calibration can be started as follows:

- By pressing the key,

if this has been enabled in ADMINISTR. LEVEL / PASSWORD / CALIB.
ENABLE.

- Via ADMINISTR. LEVEL / PASSWORD / CALIB. LEVEL.

- Via CALIB. LEVEL

if this has been enabled in ADMINISTR. LEVEL / PASSWORD / CALIB.
ENABLE.

The way in which the outputs respond depends on their configuration.

83

9 Calibrating a pH combination electrode

CAL

PGM

9.3 One-point offset calibration (zero point calibration)

Requirement - The JUMO AQUIS 500 AS must be supplied with voltage.

See section 5 "Electrical connection", page 16 ff.

- A combination electrode with a 2-wire transmitter must be

connected.

- The configuration of the basic settings must be as follows:

SIGNAL TYPE
OPERATING MODE "pH"
SCALING START
SCALING END
.

- Calibration must be enabled,

See section 6.10 "Administrator level", page 35.

- The transmitter is in "measuring mode".

1

1

1

The buffer solution must maintain a constant temperature during calibration!

✱ Start calibration (by pressing the key or via Administrator level).

✱

✱ Start the zero point calibration with the key.
✱ Immerse the combination electrode in a buffer solution with a known

pH value (usually around pH 7).

1

Relevant to the connected 2-wire transmitter.

84

9 Calibrating a pH combination electrode

PGM

PGM

PGM

PGM

EXIT

✱ With manual temperature entry, use the or keys to set the

calibration solution temperature and confirm your entry with the key.

✱

✱ Wait until the display value has stabilized; then press

to continue.

Calibration is
complete

✱ Set the displayed value to the buffer solution value with the

or keys; then press to continue.

✱ Use the key to accept the zero point or

the key to reject it.

The device returns to measuring mode.
After rinsing, the combination electrode can again be used to take

measurements.

85

9 Calibrating a pH combination electrode

CAL

PGM

9.4 Two-point calibration

The buffer solutions (reference solutions) used for calibration must differ by at
least 2 pH!
During the calibration, the temperature of the two buffer solutions must be
identical and remain constant!

Requirement - The JUMO AQUIS 500 AS must be supplied with voltage.

See section 5 "Electrical connection", page 16 ff.

- A combination electrode with a 2-wire transmitter must be

connected.

- The configuration of the basic settings must be as follows:

SIGNAL TYPE
OPERATING MODE "pH"
SCALING START
SCALING END
.

- Calibration must be enabled,

See section 6.10 "Administrator level", page 35.

- The transmitter is in "measuring mode".

1

1

1

✱ Start calibration (by pressing the key order or via Administrator level).

✱ Start the 2-point calibration with the key.

✱ Immerse the combination electrode in the first buffer solution with the

known pH value.

86

9 Calibrating a pH combination electrode

PGM

PGM

PGM

PGM

PGM

✱ With manual temperature entry, use the or keys to set the buffer

solution temperature and confirm your entry with the key.

✱ Wait until the display value has stabilized; then press

to continue.

✱ Set the displayed value to the value of the first buffer solution with

the or keys; then press to continue.

✱ Rinse the pH combination electrode.
✱ Immerse the pH combination electrode in the second buffer solution.
✱ Wait until the display value has stabilized; then press

to continue.

✱ Set the displayed value to the value of the second buffer solution with the

or keys; then press to continue.

The zero point and slope determined by the device are displayed.

87

9 Calibrating a pH combination electrode

PGM

EXIT

✱ Use the key to accept the calibrated values or

reject them with the key.

The device returns to measuring mode.

Calibration is
complete

After rinsing, the combination electrode can again be used to take
measurements.

88

10 Calibrating a redox combination electrode

CAL

10.1 Notes

During calibration, relays and analog output signals adopt their configured
states!

The sensors connected to the device should be cleaned and the device itself
calibrated, at regular intervals (subject to the measuring material).

10.2 General

The device provides two calibration options for adapting the JUMO AQUIS
500 AS to a redox combination electrode:

- With one-point offset calibration, the zero point of the combination

electrode is calibrated, See section 10.3 "One-point offset calibration (zero
point calibration)", page 90. This is the recommended method if "mV" has
been configured as the UNIT.

- With two-point calibration, the zero point and slope of the combination

electrode are calibrated, See section 10.4 "Two-point calibration", page 92.
This is the recommended method if "%" or "CUSTOMIZED" has been
configured as the UNIT.

- With one-point final value calibration, the slope of the combination

electrode is calibrated. This calibration is not recommended for redox
measurements!

Start
calibration

Calibration can be started as follows:

- By pressing the key,

if this has been enabled in ADMINISTR. LEVEL / PASSWORD / CALIB.
ENABLE.

- Via ADMINISTR. LEVEL / PASSWORD / CALIB. LEVEL

- Via CALIB. LEVEL

if this has been enabled in ADMINISTR. LEVEL / PASSWORD / CALIB.
ENABLE.

The way in which the outputs respond depends on their configuration.

89

10 Calibrating a redox combination electrode

CAL

PGM

10.3 One-point offset calibration (zero point calibration)

Requirement - The JUMO AQUIS 500 AS must be supplied with voltage.

See section 5 "Electrical connection", page 16 ff.

- A combination electrode with a 2-wire transmitter must be connected.

- The configuration of the basic settings must be as follows:

SIGNAL TYPE relevant to the connected 2-wire transmitter
OPERATING MODE "LINEAR"
UNIT "mV"
DECIMAL POINT as required
SCALING START
SCALING END
.Calibration must be enabled,
See section 6.10 "Administrator level", page 35.

- The transmitter is in "measuring mode".

1

1

The redox voltage of a measurement solution is not temperature-dependent!

✱ Start calibration (by pressing the key or via Administrator level).

✱ Immerse the combination electrode in a buffer solution with a known redox

potential.

✱ Start the zero point calibration with the key.

1

Relevant to the connected 2-wire transmitter.

90

10 Calibrating a redox combination electrode

PGM

PGM

PGM

EXIT

Wait until the display value has stabilized; then press to continue.

✱ Set the displayed value to the buffer solution value with the or keys;

then press to continue.

Calibration is
complete

The zero point determined by the device is displayed.
✱ Use the key to accept the value or

the key to reject it.

The device returns to measuring mode.
After rinsing, the combination electrode can again be used to take

measurements.

91

10 Calibrating a redox combination electrode

CAL

PGM

10.4 Two-point calibration

Requirement - The device must be supplied with voltage.

See section 5 "Electrical connection", page 16 ff.

- A combination electrode must be connected to the transmitter.

- The configuration of the basic settings must be as follows:

SIGNAL TYPE relevant to the connected 2-wire
transmitter
OPERATING MODE "LINEAR"
UNIT "%"
DECIMAL POINT as required
SCALING START
SCALING END1.

- Calibration must be enabled,

See section 6.10 "Administrator level", page 35.

- The transmitter is in "measuring mode".

1

The redox potential of a measurement solution is not temperature-dependent!

✱ Start calibration (by pressing the key or via Administrator level).

✱ Start the 2-point calibration with the key.
✱ Immerse the combination electrode in a solution with a known redox

potential.

1

Relevant to the connected 2-wire transmitter.

92

10 Calibrating a redox combination electrode

PGM

PGM

PGM

PGM

✱ Wait until the display value has stabilized; then press

to continue.

✱ Set the displayed value to the required value of the first solution with the

or keys; then press to continue.

✱ Rinse the redox combination electrode.
✱ Immerse the redox combination electrode in the second solution.

✱ Wait until the display value has stabilized; then press

to continue.

✱ Set the displayed value to the value of the second buffer solution with the

or keys; then press to continue.

93

10 Calibrating a redox combination electrode

PGM

EXIT

The zero point and slope determined by the device are displayed.
✱ Use the key to accept the calibrated values or

reject them with the key.

The device returns to measuring mode.

Calibration is
complete

After rinsing, the combination electrode can again be used to take
measurements.

94

11 Calibrating conductive conductivity cells

CAL

11.1 Notes

During calibration, relays and analog output signals adopt their configured
states!

The sensors connected to the device should be cleaned and the device itself
calibrated, at regular intervals (subject to the measuring material).

11.2 General

Requirement A conductive conductivity cell delivers a standard signal to the JUMO AQUIS

500 AS either via an external transmitter provided by the customer or via a
transmitter integrated in the measuring cell.
If the signal is not yet temperature compensated, or if there are measurement
errors because of cell constant deviations, the JUMO AQUIS 500 can take on
the task of temperature compensation and/or cell calibration.

The device provides two calibration options for adapting the JUMO AQUIS
500 AS to conductive conductivity cells:

- Calibration of the relative cell constants; this is a one-point

calibration, see section 11.3 "Calibrating the relative cell constant", page

96.

- Calibration of a linear temperature coefficient; this is a two-point calibration,

see section 11.4 "Calibrating the temperature coefficient of the
measurement solution", page 98.

Start
calibration

- Calibration of a non-linear temperature coefficient. Here the temperature

coefficient is calibrated at six points, see section 11.4 "Calibrating the
temperature coefficient of the measurement solution", page 98.

Calibration can be started as follows:

- By pressing the key,

if this has been enabled in ADMINISTR. LEVEL / PASSWORD / CALIB.
ENABLE.

- Via ADMINISTR. LEVEL / PASSWORD / CALIB. LEVEL

- Via CALIB. LEVEL

if this has been enabled in ADMINISTR. LEVEL / PASSWORD / CALIB.
ENABLE.

The way in which the outputs respond depends on their configuration.

95

11 Calibrating conductive conductivity cells

CAL

11.3 Calibrating the relative cell constant

When there is an increased demand for accuracy, the cell constant first has to
be calibrated.

Requirement - The JUMO AQUIS 500 AS must be supplied with voltage.

see section 5 "Electrical connection", page 16 ff.

- A sensor must be connected.

- The configuration of the basic settings must be as follows:

SIGNAL TYPE relevant to the connected transmitter
OPERATING MODE "CONDUCTIVITY"
UNIT mS/cm or µS/cm
DECIMAL POINT as required
SCALING START
SCALING END
.

- Calibration must be enabled,

see section 6.10 "Administrator level", page 35.

- The transmitter is in "measuring mode".

1

1

The measurement solution must maintain a constant temperature during
calibration!

✱ Press the key or

select the calibration level (CALIBR. LEVEL) or
at Administrator level (password required), select the calibration level.

✱ Immerse the conductivity sensor in a reference solution with a known

conductivity.

1

Relevant to the connected transmitter.

96

11 Calibrating conductive conductivity cells

PGM

PGM

PGM

PGM

EXIT

✱ Select REL. CELL CONSTANT;
✱ Press the key.

✱

✱ When the measurement value is steady, press the key;

the displayed conductivity measurement flashes.

✱ Use the or keys to set the value to the actual conductivity.
✱ Press the key; the relative cell constant determined by the device is

displayed (as a %).

✱ Use the key to accept the temperature coefficient or

the key to reject it.

The current measurement value and the temperature are displayed.

97

11 Calibrating conductive conductivity cells

CAL

11.4 Calibrating the temperature coefficient of the measurement solution

11.4.1 Linear Temperature coefficient

The conductivity of each measurement solution changes in accordance with
its specific temperature coefficient.
We therefore recommend that you run a temperature coefficient calibration.

Requirement - The JUMO AQUIS 500 AS must be supplied with voltage.

see section 5 "Electrical connection", page 16 ff.

- A conductivity transmitter must be connected.

- A temperature sensor must be connected.

- The configuration of the basic settings must be as follows:
SIGNAL TYPE relevant to the connected transmitter
OPERATING MODE "CONDUCTIVITY"
UNIT mS/cm or µS/cm
DECIMAL POINT as required
SCALING START
SCALING END
.

- Calibration must be enabled,
see section 6.10 "Administrator level", page 35.

- The transmitter is in "measuring mode".

1

1

✱ Immerse the conductivity sensor in a sample of the measurement solution.
✱ Press the key or

select the calibration level (CALIBR. LEVEL) or
at Administrator level (password required), select the calibration level.

✱ Select "LINEAR TEMP. CO.".

1

Relevant to the connected 2-wire transmitter.

98

11 Calibrating conductive conductivity cells

(1)

(2)

PGM

PGM

The displayed current sensor temperature flashes (1).
✱ Enter the required working temperature and confirm your entry.

The working temperature must be at least 5°C above or below the reference
temperature (25.0°C).

The LC display now shows the chosen working temperature (flashing) (2).
✱ Press the key.

The conductivity (399 µS/cm) at the current temperature (24.3°C) now appears
on the right of the LC display.
The temperatures T1 (25°C) and T2 (70.0°C) that have yet to be
triggered are shown on the left.

✱ Press the key.
✱ Heat the measuring material until the working temperature is reached.

During calibration, the rate of temperature change in the measurement
solution must not exceed 10 °C/min.

Calibration is also possible in the cooling process (with a falling temperature).
It starts above the working temperature and ends below the working
temperature.

As soon as the temperature of the measuring material exceeds T1 (25°C), this
is hidden on the display. The uncompensated conductivity at the current
temperature is displayed on the right.

99

11 Calibrating conductive conductivity cells

PGM

EXIT

If the temperature of the medium exceeded T2 (73.0°C), the device determines
the temperature coefficient.

The LC display now shows the determined temperature coefficient as %/°C.

✱ Use the key to accept the temperature coefficient or

the key to reject it.

The transmitter is in "measuring mode" and displays the compensated
conductivity of the solution.

100
