JUMO Wtrans Transmitter
RTD Temperature Probe with Wireless
Data Transmission
k For operating temperatures between -30 to +260 °C or -200 to +600 °C
k For mobile or stationary temperature measurement
k Open air range 300 m with interference-resistant transmission
k No wiring work due to state-of-the-art wireless technology
k Approval according to EC directive 94/9/EC (ATEX)
The Wtrans transmitter is used in connection with a Wtrans receiver for stationary or mobile detection of temperatures
within the operating range of -30 to +260 °C or -200 to +600 °C. This measured temperature value is transmitted wirelessly to the receiver of the Wtrans measuring system, where it is displayed and available digitally at the RS485 interface as well as an analog output. One receiver variant can signal various alarms on two relay outputs.
The electronic transmission components of the RTD temperature probe are fitted in a vibration-proof design in the oilresistant and acid-proof case, the ambient temperature of which may either be from -30 to +85 °C or from
-25 to +125 °C. The protection type is IP67. Only a durable lithium battery 3.6 V is used for voltage supply.
The radio frequencies of the Wtrans measuring system (868.4 MHz or 915 MHz) are largely impervious to external interferences and allow transmission even in a rough industrial environment. When using the antenna wall holder with
the 3 m long antenna cable for the receiver, the open air range is 300 m.
The stainless steel protection tube with the Pt1000 temperature sensing element according to DIN EN 60751, class A
in a 3-wire circuit is available with a flat, oblique, or centered probe tip. The insertion length is between
30 to 10000 mm. The variants are available with an extension tube or an M12 × 1 plug connection as an option to connect Pt1000 RTD temperature probes.
The Wtrans transmitter is also available as a version with ATEX approval (basic types 902930/15, .../17, .../55). These
devices can be installed directly in explosive areas up to zone 0. The receiver is installed outside the Ex zone. The
radio data transmission from the Ex area avoids costly installations with cable and protection barrier or supply isolators.
The design of the JUMO RTD temperature probes is to be agreed upon in the order. The Ex variant with M12 connector
is always delivered with an approved JUMO RTD temperature probe with PTFE connection cable. Devices with process connections can be ordered in versions with Ex zone separation.
A setup program is available as an accessory for easy configuration and parameterization of the Wtrans measuring
system on the PC. The OnlineChart function can be used optionally to record the measured values on the PC.
Data sheet 902930
Page 1/25
Block diagram
Approvals/approval marks (see "Technical Data")
Basic type 902930/10
Suitable
Wtrans receivers
k Max. 16 Wtrans transmitters
per Wtrans receiver
k Little wiring work required due to
modern wireless technology
k Radio frequency 868.4 MHz or 915 MHz;
in the 915 MHz frequency band,
ten frequencies can be configured
k Interface RS485 with Modbus protocol
k Four analog outputs
0(4) to 20 mA / 0 to 10 V
or
two analog outputs
(0)4 to 20 mA / 0 to 10 V
and two relay outputs AC 230 V
k For fitting on a DIN rail
35 mm × 7.5 mm
according to DIN EN 60715
For further information refer to data sheet
902931
Basic type 902930/10, 902930/12, 902930/20, 902930/22, 902930/50, and 902930/60
Analog input
Measuring inputPt1000 according to DIN EN 60751, in 3-wire circuit
Operating temperature range-30 to +260 °C for basic type 902930/10 and 902930/20;
-50 to +600 °C for basic type 902930/12 and 902930/22;
-200 to +600 °C for basic type 902930/50 and 902930/60;
Observe the admissible ambient temperature range for the case.
Accuracy of the temperature sensing element Class A ±(0.15 K + 0.002 × ItI) ItI = measured temperature in °C without prefix
Sensor lead resistance≤ 11 ohm per lead with 3-wire circuit
Probe current≤ 500 µA
Measuring circuit monitoringDetection of probe break and probe short circuit.
Output (radio transmission)
Transmitter detection (transmitter ID)Max. 5-digit ID, factory-set, can be configured customer-specific
Transmission intervalAdjustable from 1 to 3600 s:
Radio frequency868.4 MHz (Europe);
Tra n s m i s s ion power< +10 dBm
Open air range300 m for 868.4 MHz, 100 m for 915 MHz
Output signal882.2 to 1977.1 ohm Ⳏ -30 to +260 °C; 185.2 to 3137.1 ohm Ⳏ -200 to +600 °C;
Response time of the complete probeIn water 0.4 m/s / in air 3.0 m/s
Calibration accuracy of the electronic
components
ConfigurationWith setup program
Configurable parametersTransmitter detection (max. 5-digit ID), transmission interval, radio frequency (only at 915 MHz)
Operating lifeApprox. 1 year with the factory-set values and at room temperature
Battery changeOnly use the preconfigured lithium battery that is available in the accessories
Environmental influences
Ambient temperature range of the case-30 to +85 °C (case including electronic components)
Storage temperature range-40 to +85 °C (case including electronic components)
Temperature influence≤ ±0.0025 %
Resistance to climatic conditionsRel. humidity ≤ 95 % w/o condensation according to IEC 68-2-30
Vibration resistanceMax. 2 g at 10 to 2000 Hz (relating to the case including electronic components)
Admissible mechanical shock resistance25 g/6 ms (relating to the case including electronic components)
for basic type 902930/10, 902930/12, and 902930/50 (factory setting = 10 s);
Adjustable from 5 to 3600 s:
for basic type 902930/20, 902930/22, and 902930/60 (factory setting = 15 s)
915 MHz (America, Australia, Canada, and New Zealand);
Ten frequencies can be set in the 915 MHz frequency band.
and when using the antenna wall holder for the receiver and the 3 m long antenna cable. When
installing the antenna directly on the receiver, a reduced range of approx. 40 % must be taken
into account.
Ø 4.0 mm: water t
Ø 6.0 mm: water t
≤ ±0.05 %
1
approx. 3 s, t
0.5
approx. 4 s, t
0.5
approx. 7 s / air t
0.9
approx. 10 s / air t
0.9
approx. 25 s, t
0.5
approx. 32 s, t
0.5
approx. 80 s
0.9
approx. 98 s
0.9
for basic type 902930/10, 902930/12, and 902930/50;
Voltage: 3.6 V, rated capacity: 1.7 Ah
for basic type 902930/20, 902930/22, and 902930/60
(a fast transmission interval and a high or low ambient temperature
will reduce the operating life of the lithium battery)
for basic type 902930/10, 902930/12, and 902930/50;
-25 to +125 °C (case including electronic components)
for basic type 902930/20, 902930/22, and 902930/60
for basic type 902930/10, 902930/12, and 902930/50;
-40 to +125 °C (case including electronic components)
for basic type 902930/20, 902930/22, and 902930/60
1
/K; per K deviation from the reference temperature 22 °C (±3 K) (case)
according to DIN IEC 60068-2-6
according to DIN IEC 68-2.29 per 1000 cycles
1
All accuracy specifications in % relating to the measuring range of 290 K or 800 K.
DIN EN 61326-1
Class B
Industrial requirements
ETSI EN 300 220-1 and ETSI EN 300 220-2
Case
MaterialPEI (polyetherimide), color: black or gray
Flammability classUL 94 HB
DimensionsDiameter approx. 32 mm, length approx. 126 mm;
for insertion lengths refer to order details
Protection typeIP67 according to DIN EN 60529
for basic type 902930/10, 902930/12, 902930/20, and 902930/22;
for basic type 902930/50 and 902930/60 only with the machine connector M12 x 1 connected
Installation positionAny
WeightApprox. 120 g (without protection fitting)
Approvals/approval marks
Approval marks Testing agencyCertificates/certification
numbers
c UL usUnderwriters LaboratoriesE201387UL 61010-1
ICIndustry Canada7472A-WTRANST01
7472A-WTRANST0102
FCCFederal Communications
VT4-WTRANST01
Commission
VT4-WTRANST01-02
Inspection basisValid for
CAN/CSA-C22.2 No. 61010-1
RSS-210 Issue 7
RSS-210 Issue 8
RSS-GEN Issue 3
RSS-102 Issue 4
FCC Rule Part 15C
FCC Rule Part 15C
3.6 V,
Basic type 902930/10
Basic type 902930/12
Basic type 902930/20
Basic type 902930/22
Basic type 902930/50
Basic type 902930/60
915 MHz,
Basic type 902930/10
915 MHz,
Basic type 902930/10
Basic type 902930/12
Basic type 902930/20
Basic type 902930/22
Basic type 902930/50
Basic type 902930/60
915 MHz,
Basic type 902930/10
915 MHz,
Basic type 902930/10
Basic type 902930/12
Basic type 902930/20
Basic type 902930/22
Basic type 902930/50
Basic type 902930/60
Measuring inputPt1000 according to DIN EN 60751, in 3-wire circuit
Operating temperature range-30 to +260 °C
Accuracy of the temperature sensing element Class A ±(0.15 K + 0.002 × ItI) ItI = measured temperature in °C without prefix
Sensor lead resistance≤ 11 ohm per lead with 3-wire circuit
Sensor current≤ 500 µA
Measuring circuit monitoringDetection of probe break and probe short-circuit
Output (radio transmission)
Transmitter detection (transmitter ID)Max. 5-digit ID, factory-set, cannot be configured
Transmission intervalAdjustable via DIP switch to 5 s, 10 s, 20 s, or 45 s (factory-setting = 20 s)
Radio frequency868.4 MHz
Tra n s m i s s ion power< +10 dBm
Open air range300 m when using the antenna wall holder for the receiver and the 3 m long antenna cable.
Output signal882.2 to 1977.1 ohm Ⳏ -30 to +260 °C
Response time of the complete probeIn water 0.4 m/s / in air 3.0 m/s
Calibration accuracy of the electronic
components
Voltage supply
Lithium batteryVoltage: 3.6 V, rated capacity: 2.2 Ah
Operating lifeApprox. 1 year with the factory-set values and at room temperature
Battery changeOnly use the preconfigured lithium battery that is available in the accessories
Environmental influences
Ambient temperature range of the case-30 to +85 °C (case including electronic components)
Storage temperature range-40 to +85 °C (case including electronic components)
Temperature influence≤ ±0.0025 %
Resistance to climatic conditionsRel. humidity ≤ 95 % w/o condensation according to IEC 68-2-30
Vibration resistanceMax. 2 g at 10 to 2000 Hz (relating to the case including electronic components)
Admissible mechanical shock resistance25 g/6 ms (relating to the case including electronic components)
EMC
- Interference emission
- Interference immunity
- Radio frequency spectrum
Case
MaterialPA6 (polyamide), color: blue
Flammability classUL 94 HB
DimensionsDiameter approx. 32 mm, length approx. 126 mm;
Protection typeIP67 according to DIN EN 60529
Installation positionAny
WeightApprox. 120 g (without protection fitting)
When installing the antenna directly on the receiver, a reduced range of approx. 40 % must be
taken into account.
Ø 4.0 mm: water t
Ø 6.0 mm: water t
≤ ±0.05 %
1
approx. 3 s, t
0.5
approx. 4 s, t
0.5
approx. 7 s / air t
0.9
approx. 10 s / air t
0.9
approx. 25 s, t
0.5
approx. 32 s, t
0.5
approx. 80 s
0.9
approx. 98 s
0.9
(a fast transmission interval and a high or low ambient temperature
will reduce the operating life of the lithium battery)
(Part no. 00525539)
If the operating temperature exceeds the max. ambient temperature, take into account the heat
input of the protection fitting into the case. For detailed information, please refer to operating
manual B902930.0.1 in the chapter "Heat input by protection tube/protection fitting“.
1
/K; per K deviation from the reference temperature 22 °C (±3 K) (case)
according to DIN IEC 60068-2-6
according to DIN IEC 68-2.29 per 1000 cycles
DIN EN 61326-1
Class B
Industrial requirements
ETSI EN 300 220-1 and ETSI EN 300 220-2
For insertion length refer to order details
for basic type 902930/15 and 902930/17;
for basic type 902930/55 only with the M12 × 1 machine connector connected
1
All accuracy specifications in % relating to the measuring range of 290 K.
Basic type 902930/10
Basic type 902930/12
Basic type 902930/20
Basic type 902930/22
Basic type 902930/10
with process connection
Basic type 902930/12
with process connection
Basic type 902930/20
with process connection
Basic type 902930/22
with process connection
Basic type 902930/50
with M12 x 1 plug connection
Basic type 902930/60
with M12 x 1 plug connection
Basic type 902930/15
Basic type 902930/17
2012-03-02/00473251
Basic type 902930/15
with process connection
Basic type 902930/17
with process connection
Basic type 902930/55
with M12 × 1 plug connection,
PTFE connection cable
and process connection
Machine connector M12 x 1, 4-pin
according to IEC 60947-5-2
Setup program
The setup program allows the configuration of
transmitters without ATEX approval and receivers through a PC. The configuration data
can be archived on data carriers and printed.
Configurable parameters are:
- Transmitter detection (transmitter ID)
- Transmission interval
- Radio frequency (for 915 MHz only)
The factory settings are:
The setup program can be used to overwrite
changed parameters with the factory settings
at any time.
The connection between transmitter and PC
is es-tablished via a PC interface (USB/TTL or
TTL/RS232 converter).
Data sheet 902930
Page 7/25
Electrical connectionTerminal
assignment
Basic type 902930/50 and 902930/60
RTD temperature probe
in 3-wire circuit (input)
For a safe, interference-free device operation only connect shielded measuring inserts with
shielded cables and connected shielding on both sides (shielding connected to protection tube
and to M12 x 1 machine connector).
For transmitters with ATEX approval, the user
can only set the transmission interval via the
DIP switch. All other parameters are factoryset and cannot be adjusted.
