Jumbuck DELTA 2 Assembly & Operation Instructions

IMPORTANT! PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE USE!

UNIVERSAL LPG GAS ONLY

ASSEMBLY & OPERATION

INSTRUCTIONS

JUMBUCK DELTA 2

(HS-GG007JB - 3180888)

FOR

OUTDOOR

USE ONLY

FOR YOUR SAFETY

If you smell gas:

1. Shut off gas to the appliance.

2. Extinguish any open flame.

3. If odour continues, immediately call

your gas supplier.

FOR YOUR SAFETY

1. Do not store or use gasoline or other

flammable vapours or liquids in the
vicinity of this or any other appliance.

2. A gas cylinder not connected for use
shall not be stored in the vicinity of
this or any other appliance.

 For outdoor use only.
 Improper installation, adjustment, alteration, service or maintenance can cause

property damage, injury or death.

 Read the installation, operating and maintenance instructions thoroughly before

installing or servicing this equipment.

 Warning: accessible parts may be very hot. Keep young children away.
 Do not move the appliance during use.
 Turn off the gas supply at the gas cylinder after use.
 Any modification of the appliance may be dangerous and will void the warranty.
 Installer to leave instructions with the consumer and consumer to retain them

for future reference.

 Please ensure all packaging and transit protection materials are removed prior to

using the BBQ.

SAFETY INSTRUCTIONS

IMPORTANT: READ THE ASSEMBLY INSTRUCTIONS IN THIS BOOKLET

BEFORE REMOVING THE CONTENTS OF THIS CARTON

IMPORTANT SAFETY INSTRUCTIONS

This appliance must only be used in an above
ground open-air situation with natural ventilation,
without stagnant areas, where gas leakage and
products of combustion are rapidly dispersed by
wind and natural convection

 This BBQ is an outdoor appliance only. Under no

circumstances should it be use indoors.

 READ ALL OPERATING INSTRUCTION BEFORE

LIGHTING

 Do not perform any servicing on the BBQ

yourself. This includes internal adjustment of the
regulator and gas valves. Servicing can only be
carried out by authorized technicians.

 When gas cylinder is replaced or reconnected,

check for leaks.

 Do not store chemicals or flammable materials

near this appliance.

 Unsupervised children should not be near a BBQ

while cooking or during warm up or cool down.

 People with flammable clothing such as nylon

etc. should keep well away from the BBQ when it
is operating.

 Do not leave food unattended on the BBQ.
 In case of fat fire, turn gas cylinder off.
 Particular care must be taken when removing oil

cup or drip tray. Hot oil can cause serious injury.

 This BBQ should not be located under

overhead combustible construction and
proper clearances must be maintained at all
times from combustible construction and/or
materials, with MINIMUM clearances as

follow:
From Sides 450mm
From Back 450mm
High 1000mm

 Turn all gas valves off including gas cylinder

after use.

 Never leave burners on high for more than 10

minutes unless actually cooking. If the burner

makes hissing sound when lit, it may be

burning inside. Turn burner off, allow it to

cool and try again.

 Do not allow build up of unburned gas.
 Oil cup needs to be cleaned regularly to

prevent excessive fat or grease build up that

might contribute to a fire.

DO NOT OPERATE THIS APPLIANCE BEFORE READING THE INSTRUCTION BOOKLET
DO NOT PLACE ARTICLES ON OR AGAINST THIS APPLIANCE
DO NOT STORE CHEMICALS OR FLAMMABLE MATERIALS OR SPRAY AEROSOLS
NEAR THIS APPLIANCE
DO NOT OPERATE THIS APPLIANCE INDOORS
DO NOT ENCLOSE THIS APPLIANCE
DO NOT LIGHT OR OPERATE WITH THE COVER ON(COVER NOT INCLUDED)

.

WARNING

A strong gas smell or the hissing sound of gas
indicates a serious problem with your gas BBQ or
the gas cylinder. Failure to immediately follow the
steps listed below could cause serious bodily
injury, death, or property damage.

 Shut off gas supply to the gas BBQ.
 Turn the control knobs to OFF position.
 Put out any flame with a class B fire

extinguisher.

 Get away from the gas cylinder.
 Do not try to fix the problem yourself.

If odour continues or you have a fire you cannot
extinguish, call your fire department. Do not call
near the gas cylinder because your telephone is an
electrical device and could create a spark resulting
in fire and/or explosion.

NOTE: The normal flow of gas through the
regulator and hose assembly can create a
humming sound. A low volume of sound is
perfectly normal and will not interfere with
operation of the BBQ. If humming sound is loud
and excessive you may need to purge air from the
gas line or reset the regulator excess gas flow
device. This purging procedure should be done
every time a new gas cylinder is connected to your
BBQ.

OTHER CONSIDERATIONS

 Strong winds and low temperatures can

affect the heating and performance of your
gas BBQ so factor in these elements when
positioning your BBQ outdoors for cooking.

 Never use your gas BBQ in a garage, porch,

shed, breezeway or any other enclosed area.

 Your gas BBQ is to be used outdoors only, at

least 45cm from the back and side of any
combustible surface. Your BBQ should not be
placed under any surface that will burn.

 Do not obstruct the flow of ventilation air

around the gas BBQ housing. This gas BBQ is
not intended to be installed in or on
recreational vehicles and/or boats.

INSTALLATION COMPLIANCE

This appliance must be installed in accordance to
the installation instructions provided by the
manufacturer, local gas fitting regulations,
municipal building codes, AS5601 / AG 601 gas
installation codes and any other relevant statutory
regulations

PLACEMENT OF BBQ

PLACEMENT OF BBQ

 This product is meant for outdoor use only! Do not

store petrol or any inflammable liquids near this
product.

 Always place the gas cylinder beside the BBQ when

not in use. Some models have room for a gas bottle
underneath the burners – this is only to be used
when the BBQ is cold!

NOTE:
Wrongful installation, adjustments and changes, or
lack of service and maintenance could cause damage to
individuals or materials. It is therefore important to
carefully read the instructions on how to install, use
and maintain the product before assembling the item.
The BBQ must be installed according to national/local
regulations. Make sure that the gas hose is not
clenched, and never in contact with hot surfaces, and
that the BBQ is installed in exact accordance with these
instructions. For service, please contact authorized
personnel. Always ensure that the BBQ is placed away
from inflammable material when being used. When
lighted, the BBQ must be kept under surveillance at all
times. Keep children at a safe distance from the BBQ;
touching hot surfaces could cause burns. The BBQ must
be kept clean to avoid flare-ups caused by remnants of
fat. Fires resulting from ignition of grease will void the
warranty. Ensure that the gas cylinder is suitable for
your product.

ANY ENCLOSURE IN WHICH THE APPLIANCE IS USED
MUST COMPLY WITH ONE OF THE FOLLWING:
An enclosure with walls on all sides, but at least one
permanent opening at ground level and no overhead
cover. Within a partial enclosure that includes an
overhead cover and no more than two walls. Within a
partial enclosure that includes an overhead cover and
more than two walls, the following shall apply-

i. at least 25% of the total wall area is completely

open; and

ii. at least 30 %of the remaining wall area is open and

unrestricted.

In the case of balconies, at least 20% of the total of the
side, back and front wall areas shall be and remain
open and unrestricted.

GAS CYLINDER SAFETY INFORMATION

GAS TYPE
Note the labeling of appropriate gases listed on
your BBQ and ascertain that the gas you have is
suitable for your BBQ. Be aware that several
different valves for gas cylinders exist, and that the
regulator must connect appropriately to your gas
cylinder.

GAS CONNECTION

 Never try forcing the gas cylinder valve to fit

the gas regulator.

 Never make adjustments to low-pressure

regulator and hose coupling.

 The gas hose must be inspected for signs of

damage/leakage prior to being used. If any of
these parts are being replaced, use only parts
specified by the manufacturer.

 The regulator and gas hose should be secured

by using hose clamps, which are tightened
with the use of a screw driver.

 Do not secure any attachments with tape, or

similar materials not meant for gas
applications.

 When the gas cylinder is not in use, it must be

turned off and disconnecting the regulator is
advisable.

HOSE AND REGULATOR REPLACEMENT
In the case of a problem arising with the hose and
regulator please contact your BBQ supplier for a list
of approved replacement parts. The hose and
regulator assembly parts must comply to Australian
gas standards.

GAS CYLINDER STORAGE
Gas cylinder not in use are to be stored outdoors in
a well ventilated place, out of reach from children.
Make sure that the gas cylinder is placed in an
upright position and on an evenly surfaced ground.
Additional gas cylinder are not to be stored
underneath or in proximity to the BBQ.

SAFETY WHEN LEAKAGE OF GAS IS SUSPECTED

 Turn off the BBQ's gas supply and disconnect the

regulator from the gas cylinder.

 Wipe out any open flames and remove possible

ignition sources. If the smell of gas is sustained,
please contact your gas supplier or the fire
department immediately.

 If the gas cylinder appears to be the source of

smell/leakage, place this outdoor with good
ventilation and away from possible ignition
sources

WARNING

STORE GAS CYLINDER IN A WELL VENTILATED AREA

OUT OF REACH OF CHILDREN

2. Turn off
gas valves

3. Turn gas cylinder
on

4. Spray or apply
soapy water on
gas connections

5. If leak is
present, bubbles
will appear

LEAK TESTING

Please check for gas leakage the first time you are
connecting the BBQ to the gas cylinder, and also
each time you are replacing the gas cylinder or
disconnecting/reconnecting any fittings. Inspect
the hose before each use.

To check for gas leakage, turn on the gas supply at
the gas cylinder, but do not switch on the burners
inside the BBQ. The gas hose will now be filled with
gas. Then pour water with soap over all
connections. Any gas leakage should result in
bubbles within 20 seconds. If a gas leakage is
detected, tighten the connection. If the gas leakage
persist, contact your supplier or place of purchase.
As an alternative, you may use a gas leak detector,

following the manufacturer‟s instructions, available

at all major BBQ retailers. This provides an easier
way to check for gas leaks

DO NOT USE NAKED FLAME FOR LOCATING GAS
LEAKS. IF A LEAK PERSISTS, CALL AN
AUTHORISED PERSON

1. Add soap and water to spray bottle or
soapy water with brush
