Power Plus
Compact Juicer with
Citrus Attachment
JM850
Instruction Booklet
Thank you
for your purchase!
Share your pictures &
stories with us online
Register online at :
www.prodprotect.com/applica
Rate & Review your product
www.juiceman.com
Should you have any questions or concerns with
your new product, please call our Customer
Service Line at 1-800-231-9786 (US and Canada).
Please do not return to the store.
2
Please Read and Save this Use and Care Book.
IMPORTANT SAFEGUARDS
All Juiceman® products are designed with your safety in mind. When
using electrical appliances, basic safety precautions should always
be adhered to, including the following:
•
Read all instructions and save
for future reference:
•
Remove any stickers before using the juicer.
•
To protect against risk of electrical shock, do not
put cord, plugs or appliance in water or other
liquid.
•
Fully unwind the power cord before use.
•
Always make sure the juicer is properly assembled
before plugging in and using.
•
Close supervision is necessary when any
appliance is used by or near children.
•
Unplug from outlet when not in use, before putting
on or taking off parts, or before cleaning.
•
Avoid contacting moving parts.
•
Do not operate any appliance with a damaged
cord or plug or after the appliance malfunctions, or
is dropped or damaged in any manner. Contact the
consumer service number listed in this manual.
•
The use of attachments not recommended by
Juiceman may cause fire, electric shock or injury.
•
Do not use outdoors.
•
Do not let cord hang over edge of table or
counter.
•
Do not let cord touch hot surfaces or become
knotted.
•
Always make sure juicer cover is clamped
securely in place before motor is turned on. Do
not unfasten clamps while juicer is in operation.
Be sure to turn switch to OFF position after each
use. Make sure the motor stops completely before
disassembling.
•
Do not leave the appliance unattended when in use.
•
Use caution when operating the appliance – do
not place hands or fingers near moving or rotating
parts.
•
Do not put your fingers or other objects into the
juicer opening while it is in operation. If food
becomes lodged in opening, use food pusher
or another piece of fruit or vegetable to push it
down. When this method is not possible, turn the
motor off, unplug the appliance and disassemble
juicer to remove remaining food.
•
Do not use the appliance if the rotating sieve is
damaged.
•
Do not use this appliance for other than intended use.
•
Keep the appliance clean; refer to care and
cleaning section of this manual.
•
This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience
and knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by a person responsible for their safety.
•
Children should be supervised to ensure that they
do not play with the appliance.
SAVE THESE INSTRUCTIONS
Safety Features
POLARIZED PLUG (120V models only)
This appliance has a polarized plug (one
blade is wider than the other). To reduce
the risk of electric shock, this plug is
intended to fit into a polarized outlet only
one way. If the plug does not fit fully into
the outlet, reverse the plug. If it still does
not fit, contact a qualified electrician. Do
not attempt to modify the plug in any way.
TAMPER-RESISTANT SCREW
Warning: This appliance is equipped
with a tamper-resistant screw to prevent
removal of the outer cover. To reduce
the risk of fire or electric shock, do not
attempt to remove the outer cover. There
are no user-serviceable parts inside.
Repair should be done only by authorized
service personnel.
This product is for household use only.
ELECTRICAL CORD
1)
A short power-supply cord is provided to
reduce the risk resulting from becoming
entangled in or tripping over a longer cord.
2) If a long detachable power-supply cord
or extension cord is used,
a) The marked electrical rating of the
extension cord should be at least as
great as the electrical rating of the
appliance,
b) If the appliance is of the grounded
type, the extension cord should be a
grounding-type 3-wire cord, and
c) The longer cord should be arranged
so that it will not drape over the
countertop or tabletop where it can be
pulled on by children or tripped over
unintentionally.
Note: If the power cord is damaged,
please contact the warranty department
listed in these instructions.
3
Meet
your
Product may vary slightly from what is illustrated.
Power Plus
Compact Juicer with
Citrus Attachment
Make deliciously simple
citrus juices or extract
a fruit and vegetable
blend with this easy to use
and easy to clean multifunctional juicer.
1. Small food pusher (Pa rt# 770278)
2. Large food pusher (Pa rt# 770280)
(also used as small feed chute)
3. Feed chute
4. Lid
(Part# 770279)
5. Stainless steel filter basket
(Part# 770271)
6. Integrated pulp container
(3.5 cups) (Par t# 770290)
7. Locking latches (both sides)
(Part# 081243MZ169)
8. Speed control dial
9. Base
10. Cord wrap (under base)
11. Anti-drip removable spout
(Pa rt# 0813 51MZ181)
12. Juice pitcher (4 cups)
(Part# 081244PZ11)
5
12
4
11
13. Citrus juicer drive shaft
(Part# 770282)
14. Citrus juicer attachment
(Part# 081249-1MZ169)
15. Small juicing cone (Pa rt# 04178MZ169)
16. Large juicing cone (Part# 04177MZ169)
17. Cleaning brush (Part# 04186 B)
18. Non-skid suction feet (Part# 09183-1)
1
2
3
7
146
13
8
9
18
4
16
15
17
Perfect For:
Small and large
variety of fruits and
greens and berries.
citrus fruits, a
vegetables, leafy
HOW TO JUICE
This product is for household use only.
GETTING STARTED
• Remove all packing material, any stickers, and the plastic band around
the power plug.
• Go to www.prodprotect.com/applica to register your product and visit
www.juiceman.com for more recipes, tips and tricks.
• Wash all removable parts as instructed in CARE AND CLEANING.
Important: Do not rinse or immerse base in water or any other liquid.
• Place base on a dry, level counter, assemble, and get ready to juice.
PREPARATION
Juicing is one of the easiest ways for your body to get
nutrients it needs. Follow these tips to ensure the juice
you’re fueling yourself with is as fresh as it can be!
PURCHASING AND STORING INGREDIENTS:
- Always use fresh, fully ripened fruits and vegetables.
- Select fruits and vegetables that are in season for freshness and
flavor.
- Choose fruits that are plump, tender and have a bright color. Fruits
should be heavy for their size without bruises, cuts or blemishes.
- To ripen fruit, place in a small clean paper bag. Close the bag loosely
and let stand at room temperatures. To speed ripening, add a ripe
apple or banana to the bag. Once ripened, store in the refrigerator
for a day or two until ready to use.
- Store perishable vegetables in the refrigerator until ready to use.
5
PREPARING FRUITS AND VEGETABLES FOR JUICING
h
i
•
2
h
i
•
2
l
o
w
•
1
h
i
•
2
l
o
w
•
1
o
f
f
•
0
h
i
•
2
l
o
w
•
1
o
f
f
•
0
h
i
•
2
l
o
w
•
1
o
f
f
•
0
h
i
•
2
l
o
w
•
1
o
f
f
•
0
h
i
•
2
l
o
w
•
1
o
f
f
•
0
Wash fruits and vegetables thoroughly before juicing.
Tip:
Use a natural bristle brush and biodegradable cleaner
to help remove pesticide residue.
Trim any bruised or discolored sections of fruits and
vegetables.
If desired, remove the skin. The skin may be left on all
produce with the exception of citrus fruits, including oranges,
grapefruit, lemons, limes and tangerines. This is because the
skin contains oil that tastes bitter and is difficult to digest.
Tip:
Although the skin may be left on melons and pineapple,
you may choose to remove them to maximize the fruit
flavor in the finished drink.
Remove pits and large seeds from fruits, including apricots,
cherries, nectarines, mangoes, peaches, plums and melons.
Pack leafy greens, parsley, wheat grass and sprouts into
small, tight bunches.
The large feed chute is designed to fit larger produce such
as whole apples, beets, and oranges. If necessary, cut into
pieces to fit in the feed chute.
Remove and discard outer leaves.
Be sure all parts of the juice extractor are clean and dry.
See the CARE AND CLEANING section of this manual.
6
JUICE
EXTRACTOR
7
ASSEMBLING YOUR JUICE EXTRACTOR
Step 1: Place pulp container on the base with spout
facing left.
Step 2: Place juice spout cover onto juice spout.
Step 3: Insert the stainless steel filter basket in the
center of the pulp container and press down until it
snaps into place.
Note: Cutting teeth are very sharp, handle carefully.
Step 4: Place the lid on top of the pulp container with
tabs on lid facing the sides.
Step 5: Lock the latches by holding down the cover fitting
the top of the latches into the tabs on each side of
the lid. Press the bottom of each latch inward until they
click into place.
Note: The appliance will not operate until the locking latches
are locked.
Step 6: Insert the large food pusher into the feed chute,
matching the indentations on the food pusher to
the projections on the feed chute.
MAKING JUICE IN YOUR JUICE EXTRACTOR:
Step 1: Prepare fruits and vegetables for juicing. Turn
the spout counterclockwise to open and turn the
dial to speed 1 or 2.
