Juiceman JM1000M User Manual

Juiceman® Express Jr. Juice Extractor & Food Processor

For online customer service

Customer Care Line:

and to register your product, go to

www.prodprotect.com/applica

MODEL/MODELO

❍

JM1000M

Please Read and Save this Use and Care Book

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be followed including the following:

❍

Read all instructions.

❍

To protect against risk of electrical shock do not put cord, plugs or appliance in water or other liquid.

❍

Close supervision is necessary when any appliance is used by or near children.

❍

Unplug from outlet when not in use, before putting on or taking off parts, or before cleaning.

❍

Avoid contacting moving parts.

❍

Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions, or is dropped or damaged in any manner. Return appliance to the nearest authorized service facility for examination, repair or electrical or mechanical adjustment. Or, call the appropriate toll-free number on the cover of this manual.

❍

The use of attachments not recommended or sold by the manufacturer may cause fire, electric shock or injury.

❍

Do not use outdoors.

❍

Do not let cord hang over edge of table or counter, or touch hot surfaces.

❍

Always make sure juicer cover is clamped securely in place before motor is turned on. Do not unfasten clamps while juicer is in operation.

❍

Be sure to turn switch to OFF position after each use of your juicer. Make sure the motor stops completely before disassembling.

❍

Do not put your fingers or other objects into the juicer opening while it is in operation. If food becomes lodged in opening, use food pusher or another piece of fruit or vegetable to push it down. When this method is not possible, turn the motor off and disassemble juicer to remove remaining food.

❍

Do not use the appliance if the rotating sieve is damaged.

❍

Do not operate without the pulp container in place.

❍

Keep hands and utensils away from moving blades or discs while processing food to reduce the risk of severe injury to persons or damage to the food processor. A scraper may be used, but must be used only when the food processor is not running.

❍

Blades are sharp. Handle carefully.

❍

Do not place on or near a hot gas or electric burner, or in a heated oven.

❍

To reduce the risk of injury, never place cutting blade or discs on base without first putting bowl properly in place.

❍

Be certain cover is securely locked in place before operating appliance.

❍

Never feed food by hand. Always use food pusher.

❍

Do not attempt to defeat the cover interlock mechanism.

SAVE THESE INSTRUCTIONS

This product is for household use only.

POLARIZED PLUG (120V Models Only)

This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this plug is intended to ﬁt into a polarized outlet only one way. If the plug does not ﬁt fully into the outlet, reverse the plug. If it still does not ﬁt, contact a qualiﬁed electrician. Do not attempt to modify the plug in any way.

TAMPER-RESISTANT SCREW Warning: This appliance is equipped with a tamper-resistant screw to

prevent removal of the outer cover. To reduce the risk of ﬁre or electric shock, do not attempt to remove the outer cover. There are no userserviceable parts inside. Repair should be done only by authorized service personnel.

ELECTRICAL CORD

a) A short power-supply cord is to be provided to reduce the risk resulting

from becoming entangled in or tripping over a longer cord.

b) Extension cords are available and may be used if care is exercised in

their use.

c) If an extension cord is used,

1) The marked electrical rating of the extension cord should be at least as great as the electrical rating of the appliance,

2) The longer cord should be arranged so that it will not drape over the countertop or tabletop where it can be pulled on by children or tripped over.

Note: If the power supply cord is damaged, it should be replaced by qualiﬁed personnel or in Latin America by an authorized service center.

ENGLISH

GETTING TO KNOW YOUR JUICEMAN® EXPRESS JR.

Product may vary slightly from what is illustrated.

How to Use

This product is for household use only.

GETTING STARTED

• Remove all packing material, and any stickers from the product; remove and save literature.

• Please go to www.prodprotect.com/applica to register your warranty; for additional information about your Juiceman® Express Jr. go to www.juiceman.com.

• Your appliance is partially assembled in the box. Take the appliance apart and wash all removable parts as instructed in CARE AND CLEANING section of this manual. This will remove any traces of dust or residue left from manufacturing and shipping.

Note: The blades are covered by 2 plastic sleeves. Do not discard; instead, save them to store the blade safely and help to retain its sharpness.

Important: Handle the blades very carefully. They are very sharp. We suggest handling the blades by the center post.

• Select a level dry countertop where the appliance is to be used, allowing air space on all sides to provide proper ventilation for the motor.

Important: Do not rinse or immerse motor base in water or any other liquid.

BASE

1. Motor base

2. Off / Perfect Prep™ button

3. High button

4. Low button

5. Skid-resistant feet

6. Spatula/cleaning brush (not shown) Note: For part assemblies, please refer to the specific section for the attachment you

wish to use.

GETTING TO KNOW YOUR JUICE EXTRACTOR

How to Use

CONTROL BUTTONS FOR THE JUICE EXTRACTOR

The control buttons are located on the front of the base. Press Low or High to

select your desired speed. Refer to the SPEED CHART to help select the right speed for your produce.

Note: The Perfect Prep™ button is not recommended for use with the juice extractor.

JUICE EXTRACTOR

† 1. Food pusher (Part # JM2000S-01)

2. Feed chute † 3. Juice extractor lid (Part # JM2000S-02) † 4. Stainless steel mesh filter (not shown) (Part # JM2000S-03)

5. Safety lock latch † 6. Juice extractor base (Part # JM2000S-15)

7. Juice spout † 8. Pulp container (Part # JM2000S-04)

9. Pulp spout Note: † indicates consumer replaceable/removable parts

Low Use Low speed for softer produce like berries, citrus fruits, leafy vegetables and soft-skinned produce such as peaches, plums and cucumbers.

High

Use High speed for harder produce like rind-on melons and pineapple, beets and ginger.

Off

The juice extractor will run continuously until the Off button is pressed. The appliance should be stored in Off position and unplugged when not in use.

IMPORTANT: Always press the OFF button before plugging in the appliance. PURCHASING AND STORING INGREDIENTS

• Always use fresh fully ripened fruits and vegetables.

• When purchasing, consider selecting fruits and vegetables in season for best freshness and ﬂavor.

• Choose fruits that are plump, tender and have bright color. Fruits should be heavy for their size without bruises, cuts or blemishes.

• To ripen fruit, place in a small clean paper bag. Close the bag loosely and let stand at room temperature. (To speed ripening, add a ripe apple or banana to the bag.) Once ripened, store in the refrigerator for a day or two until ready to use.

• Store perishable vegetables in the refrigerator until ready to use.

PREPARING FRUITS AND VEGETABLES

• Wash fruits and vegetables thoroughly just before using in the juice extractor, using a natural bristle brush. We suggest using a biodegradable cleaner, such as Fit® Fruit and Vegetable Wash to help remove pesticide residue.

• If desired, remove the skin. The skin can be left on all produce with the exception of:

o All citrus fruits, including

• Oranges

• Grapefruit

• Lemons

• Limes

• Tangerines

Note: The oil in the skin of these fruits tastes bitter and is difﬁcult to digest. Hint: Although the skin may be left on melons and pineapple, you may choose to

remove them to maximize the fruit ﬂavor in the ﬁnished drink.

• All pits and large seeds should be removed, including:

o Apricots o Cherries o Nectarines o Mangoes o Peaches o Plums o Melons

• Remove and discard outer leaves of non-organic produce. Peel away any wax coatings.

• Trim any bruised or discolored sections of fruits and vegetables

• The design of the feed chute accommodates larger produce. It will easily accommodate most whole fruits and vegetables, such as apples, beets and carrots. If necessary, cut into large pieces before inserting into feed tube.

• Be sure all parts of the juice extractor are clean and dry. See CLEANING instructions on page 13.

ASSEMBLING THE JUICE EXTRACTOR

1. Place the juice extractor base over the motor base with the arrow on the juice extractor base directly above the unlock

symbol on the motor base.

Turn the juice extractor base counterclockwise until it locks into position (A). The arrow will now be above the lock symbol on the motor base.

2. With both hands, hold the stainless steel mesh ﬁlter by the rim and center it over the drive shaft. Lower the ﬁlter into the juice extractor base, rotating it clockwise until it drops into place. You will hear it snap when it is engaged

(B).

Important: The cutting blades at the bottom of the ﬁlter are very sharp. Always handle the ﬁlter by the rim.

Note: When properly assembled, the ﬁlter will spin

freely inside the juice extractor base. This can be checked by spinning the ﬁlter by the rim.

3. Place the lid on the juice extractor base so that the safety lock tab is to the right of the safety lock latch. Rotate the lid counterclockwise until the bar snaps into the latch (C).

Important: Always press the OFF button to make sure the appliance is off before securing the lid.

4. Tilt the pulp container slightly and place it directly under the pulp spout. Push the bottom of the pulp container so it rests against the side of the motor base (D).

Hint: To make cleanup more convenient, line the pulp container with a small plastic bag to collect the pulp.

5. Place a glass or a measuring cup under the juice spout to collect the juice (E).

6. Place the food pusher into the feed chute.

Important: For your protection, this appliance has an interlock system. The juice extractor will not operate unless the lid is properly locked in place.

HOW TO USE JUICE EXTRACTOR

1. Follow the instructions on pages 8 and 9 to assemble the juice extractor.

2. Assemble the prepared fruits and/or vegetables to be used on the counter or in a bowl next to the juice extractor.

3. Place a clean glass for your juice under the juice

spout (F).

4. Be sure the pulp container is in place.

5. Plug appliance into standard electrical outlet.

6. Turn the power to the Low setting and allow to run 10 seconds before placing any food into the feed chute.

7. To use High, allow the appliance to run 10 seconds on Low, then select High and place the food in the

Note: Use the RECOMMENDED SPEEDS guide to help determine your speed

setting.

10. Unplug the appliance when not in use.

Important: Never place ﬁngers or hands into the feed chute.

feed chute.

8. Use the food pusher as a guide to gently direct the produce through the feed chute. To get the most juice from the fruits and vegetables, do not rush the food through the appliance (G).

Note: When using the appliance, do not allow the pulp container to overﬁll. This may cause the appliance to stall.

9. To empty the pulp container or the juice glass during use, simply turn the appliance Off. Allow the motor to come to a complete stop and for all juices to ﬁnish dripping from the spout before emptying. Be sure to replace pulp container and juice glass before resuming extraction.

RECOMMENDED SPEEDS FOR JUICE EXTRACTION

FRUITS RECOMMENDED SPEED

Apricots Low Blueberries Low Blackberries Low Cherries Low Citrus Fruits Low

Grapes Low Kiwi Low Mangoes Low Melons (skin removed) Low Peaches Low Plums Low Raspberries Low Strawberries Low Apples High Cranberries High Melons (skin on) High Pineapple (skin on) High Papaya (skin on) High

VEGETABLES RECOMMENDED SPEED

Cucumber Low Kale Low Parsley Low Spinach Low Tomatoes Low Asparagus High Beets High Broccoli High Cabbage High Carrots High Celery High Fennel High Ginger High Potatoes High Sweet Potatoes High

HINTS AND TIPS FOR YOUR JUICE EXTRACTOR

• Do not put food into the juice extractor before turning the appliance on.

• Let the appliance run for at least 10 seconds before placing any food into the feed chute.

• Do not let the pulp container or juice glass overﬁll while using the machine. Turn the appliance off, wait for the motor to stop running and any juice to stop ﬂowing. Empty the juice glass and/or pulp container. Be sure they are properly replaced before resuming operation of the extractor.

• When processing different fruits and vegetables, process the soft foods on Low speed ﬁrst; follow with the fruits and vegetables that use the High speed.

• When processing leafy vegetables, such as parsley and herbs, add the herbs between the harder foods.

• For easy clean up, place a plastic bag inside the pulp container before using the appliance.

• When processing small fruits, like grapes, add them in handfuls.

• Beets and pomegranates stain easily; process them last and wash all parts before making another juice drink.

• Do not process bananas, avocados or coconut. They have no juice and will clog the appliance.

• Be sure to remove all pits and large seeds from fruits.

• To make delicious citrus juice, peel the fruit, removing all the white pith. Refrigerate till cold and process the fruit through the extractor for a great drink.

• For maximum nutritional beneﬁts drink your processed juice right away.

Tip for optimum juicing: Avoid excessive build up of pulp on the underside of the lid.

USES FOR THE PULP Tip: The pulp from the fruits and vegetables is high in nutritional value.

• Use it to add ﬁber and ﬂavor to mufﬁns and quick breads.

• Use it to thicken soups, casseroles and sauces.

• Use fruit pulp to add nutrition and ﬂavor to desserts, such as, puddings and cakes.

• Be sure to use it the same day you extract the juice.

• Pulp is also food for your garden. Use it for compost.

Care and Cleaning

This product contains no user serviceable parts. Refer service to qualiﬁed service personnel.

Important: Always unplug your appliance from the outlet before cleaning. CLEANING

1. Unplug your Juiceman® Express Jr. and disassemble.

2. Using a sponge or damp cloth, clean the base, rubber feet and underside of the motor base. If necessary, you may use a damp toothbrush or cloth to clean juice from the inside of the drive shaft (on top of motor base).

Important: Do not immerse the base in water or spray with water. Clean only by wiping with a damp sponge, cloth or paper towel.

3. All parts – except the base – are dishwasher-safe (top-rack only) or you may wash in warm, soapy water, using any mild liquid dishwashing detergent. Do not use any products containing ammonia or scouring powders, as these can dull, scratch or mar the surface. Use the cleaning brush provided to remove pulp left on any of the removable parts. Do not use metal brushes or pads.

4. To clean the ﬁlter, use cleaning brush provided to make sure the tiny holes in the mesh ﬁlter are not clogged. This can be accomplished by holding ﬁlter under a running faucet while brushing the mesh screen from both the inside and outside of the ﬁlter.

Tip: Pulp from pulp container can be used in many different ways: making breads, mufﬁns, cakes, soup stocks, compressed facial packs and garden compost material.

REMOVING TOUGH STAINS

1. Due to powerful staining properties of carotenoids found in many vegetables, particularly carrots, we suggest soaking any stained parts overnight in one of the following solutions:

• Biodegradable soap in enough warm water to cover juice extractor

parts

• ¼ cup bleach added to a sink full of warm water

• 1 part warm water to 1 part cider vinegar

• ½ small box of baking soda in enough warm water to cover juicer parts.

Important: Never use ammonia or abrasive cleansers!

2. After soaking overnight, lightly scrub with soft bristle brush and liquid detergent.

STORAGE

Store your appliance in a clean, dry place. Never wrap cord tightly around the appliance. Do not put any stress on cord where it enters the motor base, as this could cause cord to fray and break.

TROUBLESHOOTING FOR THE JUICE EXTRACTOR

PROBLEM POSSIBLE CAUSE SOLUTION

NOTES

Juice extractor will not start when speed button is depressed.

The motor of the juice extractor seems to be struggling.

The juice extractor has stopped producing juice.

The juice extractor is not producing as much juice as expected.

Appliance stops running.

The juice extractor portion of the appliance may not be assembled correctly.

• Pulp container may be full.

• Pulp may have collected under the lid.

• The speed selected may not be correct

The filter basket may be blocked.

High fiber fruits and vegetables may be clogging the filter.

Motor may be overheating.

Check the ASSEMBLY instructions found on pages 8 and 9.

• Turn off the appliance. Empty the pulp container. Do not allow the pulp container to get too full.

• Turn off and unplug the appliance. Disassemble the appliance and take off the lid. Wash thoroughly and return to appliance following the assembly instructions.

• Check the RECOMMENDED SPEED guide on pages 10 and 11.

Turn off and unplug the appliance. Disassemble the appliance and take off the lid. Wash thoroughly and return to appliance following the assembly instructions.

Unplug appliance and allow it to cool approximately 5 minutes before continuing use.

OVERHEAT PROTECTION SYSTEM Important: This appliance contains a PTC overheat protection system. When the appliance is being operated for too long or with too much load, the PTC protector will shut down the power of the appliance to protect the unit. If the power shuts down, unplug for 20 minutes and plug in for normal operation.

GETTING TO KNOW YOUR JUICEMAN® EXPRESS JR. WORKBOWL

How to Use

CONTROL BUTTONS FOR THE WORKBOWL

The control buttons are located on the front of the base. Press Low or High to select a speed.

WORKBOWL

† 1. Workbowl feed chute cap (Part # JM2000S-11)

2. Workbowl feed chute † 3. Workbowl lid (Part # JM2000S-12)

4. Safety lock latch

5. Workbowl handle † 6. 9-cup workbowl (Part # JM2000S-13) † 7. Flat blade (Part # JM2000S-15) † 8. S-blade (Part # JM2000S-14) Note: † indicates consumer replaceable/removable parts

Off/Perfect Prep™ button

The appliance should be stored in Off position and unplugged when not in use. The Perfect Prep™ function works like a pulse function and is perfect for short

and precise tasks. It lets you control the size and uniformity of the foods being chopped.

• The Perfect Prep™ button must be pressed and held for the appliance to operate. When released, the appliance will stop. Do not use the Perfect Prep™ button longer than 2 minutes continuously.

• The motor runs as long as this button is held down. Press the button down and then release; allow the blades to stop running and the food to fall to the bottom of the workbowl before pressing again.

• This function gives better control when chopping, mincing, mixing and blending foods. You can control the size of the foods from coarse to ﬁne.

High/Low Speed Control

• When either speed is selected, the processor will run continuously until the Off button is pressed.

• These speeds are used for chopping, blending, dressings, sauces and making batters.

IMPORTANT: Always press the OFF button before plugging in the appliance. CUTTING BLADES

The workbowl comes with two blades (see callouts 7 and 8 on page 16):

• The “S” blade can be used for chopping vegetables and fruits, mincing cooked meats, grinding coffee beans and nuts and making cookie and bread crumbs.

+ 18 hidden pages
