GML Series Gooseneck Microphone GML Series Gooseneck Microphone
GML Series Gooseneck Microphone
GML Series Gooseneck Microphone
GML-5218
GML-5212
GML-O
omni-direction
GML-5206
GML-5206/5212/5218
GML-C
cardioid
GML-S
supercardioid
59512-055
Specification
■ Type Back: Electret Condenser
■ Frequency Response: 80 to 18,000Hz
■ Polar Pattern:Cardioid,Supercardioid,Omnidirectional
■ Output Level(at 1,000Hz): Open circuit voltage:
-56±3 dB* (1.58mV)*0dB=1V /μbar
■ Impedance: Rated impedance is 220Ω
■ MAX. SPL for 1% THD: 125dB
■ Output Connector: XLR(M) type (power module)
■ Power Supply: 9-52 VDC Phantom power(LED standard
operation voltage 48V) or battery power 3V(1.5V * 2)
■ Gooseneck Length: GML-5206 6"(152mm)
GML-5212 12"(305mm)
GML-5218 18"(457mm)
Features
● The GML series are wide-range condenser
microphones with three kinds polar patterns, cardioid,
supercardioid, and omnidirectional, that meet various
applications and demands in sound pick-up situation.
● Bundled with interchangeable microphone heads
provide great convenience in replacing and repairing.
● GML series feature a 3P XLR connector insert,
allowing it to be plugged directly into a mating panel
jack or cable connector.
● -10dB Pad and Low-Cut switches are provided for
easy installation.
● Mic-On LED indicated the working status.
● The small diameter gooseneck permits high flexibility
in proper position and multiple gooseneck length is
able to match different requirements.
Accessories
■ Windscreen
1
1
2
3
2
3
■ Interchangeable capsules
( Supercardioid, Omnidirection )
