JTL ZXA10 F660 Maintenance Management Manual

OpticalNetworkTerminal

MaintenanceManagementManual

ZXA10F660

V1.0

-DPLL7HOHFRPPXQLFDWLRQV/LPLWHG

KWWSMDPLLFRNH
(PDLOMWOVXSSRUW#MWOFRNH
TelSLORW:

6aISLORW:

LEGALINFORMATION

Copyright©2010ZTECORPORATION.

Thecontentsofthisdocumentareprotectedbycopyrightlawsandinternationaltreaties.Anyreproductionor

distributionofthisdocumentoranyportionofthisdocument,inanyformbyanymeans,withoutthepriorwritten

consentof-7/CORPORATIONisprohibited.Additionally,thecontentsofthisdocumentareprotectedby

contractualcondentialityobligations.

Allcompany,brandandproductnamesaretradeorservicemarks,orregisteredtradeorservicemarks,of-7/

CORPORATIONoroftheirrespectiveowners.

Thisdocumentisprovided“asis”,andallexpress,implied,orstatutorywarranties,representationsorconditions

aredisclaimed,includingwithoutlimitationanyimpliedwarrantyofmerchantability ,tnessforaparticularpurpose,

titleornon-infringement.-7/CORPORA TIONanditslicensorsshallnotbeliablefordamagesresultingfromthe

useoforrelianceontheinformationcontainedherein.

-7/CORPORATIONoritslicensorsmayhavecurrentorpendingintellectualpropertyrightsorapplications

coveringthesubjectmatterofthisdocument.Exceptasexpresslyprovidedinanywrittenlicensebetween-7/

CORPORATIONanditslicensee,theuserofthisdocumentshallnotacquireanylicensetothesubjectmatter

herein.

Theultimaterighttointerpretthisproductresidesin-7/CORPORATION.



RevisionHistory

RevisionNo.RevisionDateRevisionReason

1.02011–05–17FirstEdition

SerialNumber:SJ-20110517135211-002

PublishingDate:2011-05-17(R1.0)

Contents

Chapter1Overview....................................................................................1-1

1.1SafetyPrecautions.............................................................................................1-1

1.2PackingList.......................................................................................................1-2

1.3FeaturesandSpecications................................................................................1-3

1.4ProductAppearance...........................................................................................1-4

1.5SystemRequirements........................................................................................1-6

1.6SystemApplicationEnvironment.........................................................................1-7

Chapter2CongurationPreparation.......................................................2-1

2.1PreliminarySetup...............................................................................................2-1

2.2ConguringTCP/IP............................................................................................2-1

2.3LoggingIntotheDevice.....................................................................................2-6

Chapter3DeviceStatus............................................................................3-1

3.1DeviceInformation.............................................................................................3-1

3.2NetworkConnectionInformation..........................................................................3-2

3.3UserInterfaceInformation...................................................................................3-3

3.3.1WLANInterfaceInformation......................................................................3-3

3.3.2EthernetInterfaceInformation...................................................................3-4

3.3.3VoIPStatusInformation............................................................................3-5

Chapter4NetworkConguration.............................................................4-1

4.1ConguringWANConnection..............................................................................4-1

4.2WLANConguration...........................................................................................4-5

4.2.1ConguringBasicWLANParameters........................................................4-5

4.2.2ConguringMulti-SSIDParameters...........................................................4-7

4.2.3ConguringSecurityProperties.................................................................4-8

4.2.4ViewingAssociatedDevices...................................................................4-12

4.3AddressManagementConguration..................................................................4-13

4.3.1ConguringDHCPServer.......................................................................4-13

4.3.2ConguringDHCPBinding......................................................................4-14

4.3.3ConguringSpecicAddressRange........................................................4-15

4.4RouteManagementConguration.....................................................................4-16

4.4.1ConguringDefaultGateway...................................................................4-17

I

4.4.2ConguringStaticRouting......................................................................4-18

Chapter5SecurityConguration.............................................................5-1

5.1ConguringFirewall............................................................................................5-1

5.2ConguringIPFilter............................................................................................5-2

5.3ConguringURLFilter........................................................................................5-5

5.4ConguringDMZHost........................................................................................5-7

5.5ConguringPortForwarding...............................................................................5-8

Chapter6ServiceConguration...............................................................6-1

6.1SIPVoIPServiceConguration...........................................................................6-1

6.1.1ConguringVoIPWANConnection............................................................6-1

6.1.2ConguringSIP........................................................................................6-2

6.1.3ConguringSIPAccounts.........................................................................6-4

6.1.4ConguringVoIPAdvancedParameters....................................................6-5

6.1.5ConguringVoIPMediaParameters..........................................................6-7

6.1.6ConguringFax........................................................................................6-8

6.2ConguringDDNS..............................................................................................6-9

6.3ConguringUPnP.............................................................................................6-11

6.4DNSConguration...........................................................................................6-13

6.4.1ConguringDomainName......................................................................6-13

6.4.2ConguringHostName..........................................................................6-14

6.5QoSConguration............................................................................................6-15

6.5.1ConguringBasicQoSParameters.........................................................6-16

6.5.2ConguringQoSRule.............................................................................6-18

6.5.3ConguringQoSRuleType.....................................................................6-19

6.5.4ConguringQoSLocalApplication..........................................................6-21

6.5.5ConguringQoSQueueManagement.....................................................6-22

6.5.6ConguringQoSIngressRateLimit.........................................................6-23

6.6ConguringSNTPClient...................................................................................6-25

6.7IGMPConguration..........................................................................................6-27

6.7.1ConguringBasicIGMPParameters.......................................................6-27

6.7.2ConguringMulticastVLAN....................................................................6-29

6.7.3ConguringMulticastMACLimit..............................................................6-31

6.7.4ConguringMVLANTagStrip..................................................................6-33

6.8ConguringFTPApplication..............................................................................6-34

Chapter7DeviceManagement.................................................................7-1

7.1TR-069Conguration.........................................................................................7-1

7.1.1ConguringBasicTR-069Parameters.......................................................7-1

II

7.1.2ImportingTR-069Certicate.....................................................................7-3

7.2UserManagement..............................................................................................7-4

7.3DeviceManagement...........................................................................................7-5

7.3.1SystemManagement................................................................................7-5

7.3.2SoftwareUpgrade....................................................................................7-6

7.3.3CongurationManagement.......................................................................7-8

7.4LogManagement...............................................................................................7-9

7.5PingDiagnosis.................................................................................................7-10

AppendixAFAQ.......................................................................................A-1

A.1FAQ................................................................................................................A-1

Index................................................................................................................I

Glossary........................................................................................................III

III

IV

Chapter1

Overview

TableofContents

SafetyPrecautions.....................................................................................................1-1

PackingList................................................................................................................1-2

FeaturesandSpecications.......................................................................................1-3

ProductAppearance...................................................................................................1-4

SystemRequirements................................................................................................1-6

SystemApplicationEnvironment................................................................................1-7

1.1SafetyPrecautions

UsageCautions

lReadallthesafetycautionscarefullybeforeusingthedevice.
lOnlyusetheaccessoriesincludedinthepackage,suchaspowersupplyadapter

andbattery.

lThepowersupplyvoltagemustmeettherequirementsofthedeviceinputvoltage

(Thevoltageuctuationrangeislessthan10%).

lKeepthepowerplugcleananddrytopreventanyriskofelectronicshockorother

danger.

lMakesuretodisconnectallthecablesduringalightningstormtopreventthedevice

fromdamage.

lPoweroffandunplugthepowerplugwhenthedeviceisnotinuseforalogtime.
lDonotattempttoopenthecoversofthedevice.Itisdangeroustodosowhenthe

deviceispoweredON.

lDonotdirectlystareattheopticalinterfacetopreventtheeyesfrombeinghurt.
lPoweroffandstopusingthedeviceunderthefollowingconditions:abnormal

sound,smoke,andstrangesmell.Contacttheserviceproviderformaintenanceif
thedeviceisfaulty .

Note

Theusersshouldreadtheusagecautionsabovecarefullyandwillberesponsibleforany
incidentresultedfromtheviolationofthecautionsabove.

1-1

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

EnvironmentRequirements

lEnsuretheproperventilationtothedevice.Placethedeviceoutofthedirectsunlight.
lKeepthedeviceventilatedanddry.Neverspillanyliquidonthedevice.
lDonotplaceanyobjectonthedevice,incaseitgetsdeformedanddamaged.
lDonotplacethedevicenearanysourceofheatorwater.
lKeepthedeviceawayfromanyhouseholdapplianceswithstrongmagneticor

electricelds,suchasmicrowaveovenandrefrigerator.

CleaningRequirements

lBeforethecleaning,poweroffthedevice,andunplugallthecablesconnectedtothe

device,suchaspowercable,opticalber,andEthernetcable.

lDonotuseanyliquidorspraytocleanthedevice.Usethesoftdrycloth.

EnvironmentProtection

lDonotdisposethedeviceorbatteryimproperly.
lObservethelocalregulationsabouttheequipmentdisposalortreatment.

1.2PackingList

AfteropeningtheZXA10F660packingbox,makesurethatitcontainsthefollowing
components,aslistedinTable1.

Table1PackingList

ComponentNameCountImage

ZXA10F660host1

Poweradapter1

Powercable1

1-2

SJ-20110517135211-002JTLProprietaryandConfidential

1.3FeaturesandSpecifications

Chapter1Overview

ComponentNameCountImage

RJ-45networkcable1

RJ-11telephonecable2

OneZXA10F660(V1.0)OpticalNetworkTerminalUserManualisdeliveredwiththe
product.

Ifanyofthecomponentsareincorrect,lost,ordamaged,contacttheproductagency.If
youwanttochangetheproduct,keepthepackingboxandcomponents.

SystemFeatures

TheZXA10F660hasthefollowingfeatures:

lMACcache:4K
lMulticastservices:1024multicastgroups
lVLANrange:1–4095
lGEMports:32
lT-CONT s:8

InterfaceFeatures

Theinterfacefeaturesareasfollows:

lGPONinterface:incompliancewiththePONstandard,SC/APC,andITU

G.984.1–G.984.5standards

lEthernetinterface:10/100/1000MbpsGEinterfaces(RJ-45),incompliancewith

IEEE802.3standards

lPOTSinterface:RJ-11
lWLANinterface:incompliancewiththeIEEE802.11nstandardwithbuilt-inantenna

TechnicalFeatures

TheZXA10F660implementsthefollowingfunctions:

lFordataaccess,theZXA10F660implementsL2dataswitchingandforwarding.

ByworkingwithrelevantnetworkdevicesthroughsignalingprotocolssuchasH.248
andSIP,theZXA10F660implementstheIPvoicefunction.

1-3

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

lTheZXA10F660providesthesecurity ,QoS,andnetworkmanagementfunctions,

suchasmulti-levelauthenticationbasedondevices,users,andservices.

Itsupportsdatachannelencryption,implementationofQoSrequirementsmatching
thelocaldevicesandnetworkaccordingtoserviceswithdifferentrequirements,and
networkmanagementbasedinvariousmanagementmodes.

ProductSpecications

TheZXA10F660specicationsareasfollows:

lRatedcurrent:1.3A
lRatedvoltage:12VDC
lOperatingtemperature:–5℃to50℃
lOperatinghumidity:5%–95%
lDimensions:260mm×50mm×185mm(Width×Height×Depth)

1.4ProductAppearance

FrontPanel

Figure1showsthefrontpaneloftheZXA10F660.

Figure1FrontPanel

Table2listsLEDsonthefrontpanel.

Table2FrontPanelLEDs

LEDStatusDescription

PON

SolidgreenTheONTGPONisregisteredandthelinkis

OFFTheONTisnotdiscoveredandregistered.

FlashingTheONTistryingtoberegisteredorsetupthe

activated.

connection.

LOS

SJ-20110517135211-002JTLProprietaryandConfidential

SolidredTheONUreceivestheopticalpowerabnormally.

OFFTheONUreceivestheopticalpowernormally .

FlashingTheWANconnectionisabnormal.TheONU

failstoacquiretheIPaddress.

1-4

LEDStatusDescription

Chapter1Overview

WLAN

USB

POTS1–POTS2

LAN1–LAN4

SolidgreenTheWLANfunctionisenabled.

OFFThedeviceisnotpoweredONorthewireless

interfaceisdisabled.

FlashingDataisbeingtransmitted.

SolidgreenTheUSBinterfaceisconnectedbutnodatais

goingthrough.

OFFTheUSBinterfaceisnotconnectedtoastorage

device.

FlashingThereisdatagoingthroughtheUSBinterface.

SolidgreenThedeviceisregisteredontheSS,butnodata

isbeingtransmitted.

OFFThedeviceisnotpoweredONorfailstobe

registeredontheSS.

FlashingDataisbeingtransmitted.

SolidgreenThenetworkinterfaceisconnected,butnodata

isbeingtransmitted.

OFFThedeviceisnotpoweredONorthenetwork

interfaceisnotconnectedwithanetwork

device.

FlashingDataisbeingtransmitted.

SolidblueThedeviceispoweredONnormally. Powerindicator

OFFThedeviceisnotpoweredON.

BackPanel

Figure2showsthebackpaneloftheZXA10F660.

Figure2BackPanel

Table3liststheinterfacesandbuttonsonthebackpanel.

1-5

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

Table3InterfacesandButtonsontheBackPanel

Interface/ButtonDescription

LAN1–LAN4RJ-45LANinterface,connectingtothelocalnetworkthroughtheRJ-45

networkcable

POTS1–POTS2RJ-11telephoneinterface,connectingtothetelephonethroughtheRJ-11

telephonecable

USBUSBinterface,connectingtoastoragedevicethathasaUSBinterface

UPSSecondarypowermonitoringinterface

POWERPowersocket,connectingtothepoweradapter,12VDC

WLANWLANbutton,toenableordisableWLAN

RESETWhenthedeviceispoweredON,pressthebuttonformorethanfiveseconds

torestorethefactorydefaultsettings.

SidePanel

ThesidepanelhasanSC/APCsingle-modeberinterface,implementingtheservices
providedbytheISPinPONaccessmode.ItconnectstotheGPONinterfaceoftheZXA10
F660throughanSC/APCsingle-modeber.Figure3showsthesidepanel.

Figure3SidePanel

1.5SystemRequirements

TheZXA10F660systemrequirementsareasfollows:

lAnISPisneededsothatthedevicecanaccesstheservicesprovidedbytheISP

inPONaccessmode.

lAcomputerthatisinstalledwitha10Mbps/100Mbps/1000MbpsEthernetcardis

needed.

1-6

SJ-20110517135211-002JTLProprietaryandConfidential

lIfnecessary,createamediumandsmallLANbyaddingEthernethubsandcables.
lTousewirelessaccess,an802.11g/bwirelessnetworkcardorabuilt-in802.11g/b

wirelessnetworkcardisrequired.

lThecomputerthataccessesthenetworkshouldbeinstalledwithWindows

98/Me/2000/NT/XP/Vista/7orLinux,networkcarddriverprogram,andTCP/IP
protocol,anditsnetworksettingsshouldbecorrect.

lAcomputerintheLANisinstalledwithaWebbrowser,suchasMicrosoftInternet

Explorer6.0orlaterversion,NetscapeCommunicator4.0orlaterversion.

1.6SystemApplicationEnvironment

TheZXA10F660isanindoordeviceofZTEseriesopticalnetworkterminalequipment.It
workswiththePONdevicetoimplementtheFTTHapplication.

Withtheuseofmultipleuserinterfaces,hub,orEthernetswitch,theZXA10F660can
implementtheFTTO/Bapplication.

Figure4showstheZXA10F660applicationenvironment.

Chapter1Overview

Figure4SystemApplicationEnvironment

Asanindoordevice,theZXA10F660canbeputonthedeskwiththebaseorhungonthe
wallwithoutthebase.

Figure5showstheZXA10F660onawall.

1-7

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

Figure5Wall-Mount

1-8

SJ-20110517135211-002JTLProprietaryandConfidential

Chapter2

ConfigurationPreparation

TableofContents

PreliminarySetup.......................................................................................................2-1

ConguringTCP/IP....................................................................................................2-1

LoggingIntotheDevice.............................................................................................2-6

2.1PreliminarySetup

Generally,theISPhasalreadyconguredthedevice.Theusercandirectlyuseitafter
hardwareconnection.However,theusermayneedtocongurethedeviceinsomespecial
situations.Theusermustconrmthefollowingpreliminarysetups:

lUseonecrossoverorstraight-throughEthernetcabletoconnectacomputerto

thedevice.

lChecktheTCP/IPsettingsofthecomputer.
lDisableanyrunningrewallorsecuritysoftware.
lDisabletheproxyserveroftheInternetExplorer.
lConsulttheISPifsomedatafromtheISPisneeded.

2.2ConfiguringTCP/IP

ShortDescription

PerformthisproceduretocongureTCP/IPofacomputerconnectedtotheZXA10F660.

Context

ThisinstancetakesWindowsXPasanexample.

ThedefaultnetworksettingsfortheZXA10F660areasfollows:

lIPaddress:192.168.1.1
lSubnetmask:255.255.255.0
lDefaultgateway:192.168.1.1

TocongureTCP/IP,performthefollowingsteps:

2-1

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

Steps

1.ChooseStart>Settings>NetworkConnectionstoopentheNetworkConnections
window.

2.Double-clickLocalAreaConnectiontoopentheLocalAreaConnectionStatus
dialogbox,asshowninFigure6.

Figure6LocalAreaConnectionStatus

3.ClickPropertiesintheGeneraltabtoopentheLocalAreaConnectionProperties
dialogbox.

4.SelectInternetProtocol(TCP/IP),asshowninFigure7.

2-2

SJ-20110517135211-002JTLProprietaryandConfidential

Figure7LocalAreaConnectionProperties

Chapter2ConfigurationPreparation

5.ClickPropertiestoopentheInternetProtocol(TCP/IP)Propertiesdialogbox.
SelectUsethefollowingIPaddressandspecifytheIPaddress,Subnetmask,
andDefaultgateway.Forexample,youcansettheIPaddressto192.168.1.7,
Subnetmaskto255.255.255.0,andDefaultgatewayto192.168.1.1,as
showninFigure8.

2-3

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

Figure8SpecifyingtheIPaddressintheInternetProtocol(TCP/IP)Properties

Note

TheIPaddressshallbeinthesamenetworksegmentasLANportaddressofthe
device,whichmeanstheIPaddressyoutypeinshouldbe“192.168.1.x”(xcanbeany
valuefrom2to254).

6.ClickOKtosaveyoursettings.

Note

IfyouareaccessingtheWEBpageofthedeviceforthersttime,pleasecongure
thedeviceasyouaretold.

–EndofSteps–

Follow-UpAction

1.ChooseStart>RuntoopentheRundialogbox.

2-4

SJ-20110517135211-002JTLProprietaryandConfidential

Chapter2ConfigurationPreparation

2.TypeCMDintheOpentextbox,andclickOK.

3.Typeping192.168.1.1inthepop-upwindowandpressEntertocarryouttheping
command.
lIfthecommandwindowdisplaysthemessages,asshowninFigure9,itindicates

thatthecommunicationbetweenyourPCandthedeviceisnormalandyouare
abletoaccesstheInternetnow.

Figure9SuccessfulPingMessage

lIfthecommandwindowdisplaysthemessages,asshowninFigure10,itindicates

thatthecommunicationbetweenyourPCandthedevicefails.

Figure10FailedPingMessage

IfthecommunicationbetweenyourPCandthedevicefails,ensurethefollowingitems:

lTheEthernetcablebetweenthedeviceandyourPChasbeenconnectedproperly.
lThedriverofyournetworkadapterhasbeeninstalledproperly.

2-5

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

lTheTCP/IPsettinghasbeenconguredcorrectlyonyourPC.

IftheZXA10F660IPaddressis192.168.1.1,theIPaddressofthecomputermust
befrom192.168.1.2to192.168.1.254.Thesubnetmaskmustbe255.255.255.0
andthedefaultgatewaymustbe192.168.1.1.

2.3LoggingIntotheDevice

ShortDescription

Performthisproceduretologintothedevice.

Pre-requisites

Thedeviceisproperlyconnectedandthecomputeriscorrectlycongured.

Context

Tologintothedevice,performthefollowingsteps:

Steps

1.OpentheInternetExplorer.Enterhttp://192.168.1.1(defaultIPaddressofthe
device)ontheaddressbarandpressEnter.Thelogindialogboxisdisplayed,as
showninFigure11.

Figure11Login

2.EntertheUsernameandPassword(bydefault,bothareadmin).ClickLogin.

–EndofSteps–

Result

Loggingintothedeviceissuccessful.

2-6

SJ-20110517135211-002JTLProprietaryandConfidential

Chapter3

DeviceStatus

TableofContents

DeviceInformation.....................................................................................................3-1

NetworkConnectionInformation.................................................................................3-2

UserInterfaceInformation..........................................................................................3-3

3.1DeviceInformation

OntheWebinterfaceofthedevice,clicktheStatustab.Bydefault,theDevice
Informationisselected.Therightpanedisplaysthedevicetype,serialnumber,and

versioninformation,andregistrationpassword,asshowninFigure12.

Figure12DeviceInformation

Table4liststheparametersforthedeviceinformation.

Table4DeviceInformationParameters

ParameterDescription

ModelDevicetype

SerialNumberDeviceserialnumber

HardwareVersionHardwareversionnumber

SoftwareVersionSoftwareversionnumber

3-1

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

ParameterDescription

BootLoaderVersionBootversionnumber

PONSerialNumberPONserialnumber

PasswordPasswordusedbytheONUregistrationonthe

3.2NetworkConnectionInformation

OntheStatustab,selectNetworkInterface.Bydefault,theWANConnectionsub-node
isselected.TherightpanedisplaystheWANconnectioninformation,asshowninFigure

13.

ClickRefreshtoviewthelatestinformation.

Figure13WANConnection

OLT

Table5liststheparametersforthenetworkconnectioninformation.

Table5ParametersfortheNetworkConnectionInformation

ParameterDescription

omci1WANconnectiontype

VLANIDVLANIDusedbytheWANinterfacetosendandreceivedata

NATWhethertoenabletheNATfunction

IPIPaddressusedbyZXA10F660

DNSDNSusedbyZXA10F660

DefaultGatewayGatewayusedbyZXA10F660

ConnectionStatusWANconnectionstatus

3-2

SJ-20110517135211-002JTLProprietaryandConfidential

OMCI1istheWANconnectionname,whichiscreatedbytheOMCIinterfaceremotely.

3.3UserInterfaceInformation

Thistopicincludesthefollowing:

lWLANInterfaceInformation
lEthernetInterfaceInformation
lVoIPStatusInformation

3.3.1WLANInterfaceInformation

OntheStatustab,selectUserInterface.Bydefault,WLANisselected.Therightpane
displaystheWLANswitchinformation,packetreceivingandsendinginformation,and
authenticationinformation,asshowninFigure14.

Chapter3DeviceStatus

Note

ClickRefreshtoviewthelatestinformation.

Figure14WLANInterfaceInformation

Table6liststheparametersfortheWLANinterfaceinformation.

3-3

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

Table6ParametersfortheWLANInterfaceInformation

ParameterDescription

EnableWirelessRFWhethertoenablethewirelessRF

ChannelChannel

SSID1EnableWhethertoenablethewirelessnetworkSSID1

SSID1NameSSID1name,whichidentifiesthewirelessnetwork

AuthenticationTypeAuthenticationmode

EncryptionTypeEncryptionmode

MACAddressMACaddress

PacketsReceived/BytesReceivedNumberofreceivedpacketsorbytes

PacketsSent/BytesSentNumberofsentpacketsorbytes

ErrorPacketsReceivedErrorpacketsreceived

ErrorPacketsSentErrorpacketssent

servicearea

DiscardedReceivingPacketsDiscardedreceivingpackets

DiscardedSendingPacketsDiscardedsendingpackets

3.3.2EthernetInterfaceInformation

OntheStatustab,selectUserInterface.SelectEthernet.Therightpanedisplaysthe
packetreceivingandsendinginformationontheEthernetinterface,asshowninFigure15.

ClickRefreshtoviewthelatestinformation.

3-4

SJ-20110517135211-002JTLProprietaryandConfidential

Figure15EthernetInterfaceInformation

Chapter3DeviceStatus

3.3.3VoIPStatusInformation

Table7liststheparametersfortheEthernetinterfaceinformation.

Table7ParametersfortheEthernetInterfaceInformation

ParameterDescription

EthernetPortPortname

PacketsReceived/BytesReceivedNumberofreceivedpacketsorbytes

PacketsSent/BytesSentNumberofsentpacketsorbytes

ErrorFramesEtherneterrorframes

OntheStatustab,selectUserInterface.SelectVoIPStatus.Therightpanedisplays
theVoIPstatusinformation,asshowninFigure16.

ClickRefreshtoviewthelatestinformation.

3-5

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

Figure16VoIPStatusInformation

Table8liststheparametersfortheVoIPstatusinformation.

Table8ParametersfortheVoIPStatusInformation

ParameterDescription

SIPAccountUsernameTelephonenumber

SIPRegisterStatusRegistrationstatusofthevoiceservice

3-6

SJ-20110517135211-002JTLProprietaryandConfidential

Chapter4

NetworkConfiguration

TableofContents

ConguringWANConnection.....................................................................................4-1

WLANConguration...................................................................................................4-5

AddressManagementConguration........................................................................4-13

RouteManagementConguration............................................................................4-16

4.1ConfiguringWANConnection

ShortDescription

PerformthisproceduretoconguretheWANconnection.

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

Context

ToconguretheWANconnection,performthefollowingsteps:

Steps

1.OntheWebinterfaceofthedevice,clicktheNetworktab.Bydefault,WAN
Connectionisselected,asshowninFigure17.

4-1

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

Figure17WANConnection

2.TheconnectiontypecanbePPPoE,Static,orDHCP.

a.CongurethePPPoEmode.

SelectPPPoEforType,asshowninFigure18.

Figure18PPPoEModeConguration

Table9liststheparametersforthePPPoEmodeconguration.

Table9ParametersforPPPoEModeConguration

ParameterDescription

TypeConnectionmode

ConnectionNamePPPoEconnectionname,automaticallygenerated

bythesystem

EnableNATWhethertoenabletheNATfunction

4-2

SJ-20110517135211-002JTLProprietaryandConfidential

Chapter4NetworkConfiguration

ParameterDescription

ServiceListServicemodessupportedbythesystem:

lTr-069servicemode

Remotemaintenanceandmanagementmode

lInternetservicemode

BroadbandandIPTVservicemode

lVoIPservicemode

Voiceservicemode

VLANIDVLANID

UsernameUsername,usedbythedeviceauthenticationon

interworking

PasswordPassword,usedbythedeviceauthenticationon

interworking

AuthenticationTypeAuthenticationtype,thesameastheauthentication

typefortheuppper-layerdevice

ConnectionTriggerDial-upconnectionmode:

lAlwaysOn

lOnDemand

lManual

IdleTimeoutIdletimebeforethedial-upautodisconnection,

availableonlyinOnDemandmode

b.Congurethestaticmode.

SelectStaticforType,asshowninFigure19.

Figure19StaticModeConguration

Table10liststheparametersforthestaticmodeconguration.

4-3

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

Table10StaticModeConguration

ParameterDescription

TypeConnectionmode

ConnectionNameStaticconnectionname,automaticallygenerated

EnableNATWhethertoenabletheNATfunction

ServiceListServicemodessupportedbythesystem:

VLANIDVLANID

IPAddressIPaddressusedbyZXA10F660

bythesystem

lTr-069servicemode

Remotemaintenanceandmanagementmode

lInternetservicemode

BroadbandandIPTVservicemode

lVoIPservicemode

Voiceservicemode

SubnetMaskSubnetmaskusedbyZXA10F660

DefaultGatewayGatewayusedbyZXA10F660

DNSServer1IPAddressIPaddressofDNS1usedbyZXA10F660

DNSServer2IPAddressIPaddressofDNS2usedbyZXA10F660

DNSServer3IPAddressIPaddressofDNS3usedbyZXA10F660

c.ConguretheDHCPmode.

SelectDHCPforType,asshowninFigure20.

Figure20DHCPModeConguration

Table1 1liststheparametersfortheDHCPmodeconguration.

4-4

SJ-20110517135211-002JTLProprietaryandConfidential

Chapter4NetworkConfiguration

Table11DHCPModeConguration

ParameterDescription

TypeConnectionmode

ConnectionNameDHCPconnectionname,automaticallygenerated

bythesystem

EnableNATWhethertoenabletheNATfunction

ServiceListServicemodessupportedbythesystem:

lTr-069servicemode

Remotemaintenanceandmanagementmode

lInternetservicemode

BroadbandandIPTVservicemode

lVoIPservicemode

Voiceservicemode

VLANIDVLANID

3.ClickCreatetonishtheconguration.ClickCanceltocanceltheconguration.

–EndofSteps–

Result

WANconnectioncongurationiscomplete.

4.2WLANConfiguration

Thistopicincludesthefollowing:

lConguringBasicWLANParameters
lConguringMulti-SSIDParameters
lConguringSecurityProperties
lViewingAssociatedDevices

4.2.1ConfiguringBasicWLANParameters

ShortDescription

PerformthisproceduretocongurethebasicWLANparameters.

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

Context

TocongurethebasicWLANparameters,performthefollowingsteps:

4-5

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

Steps

1.OntheNetworktab,selectWLANontheleftpane.Bydefault,theBasicsub-node
isselected,asshowninFigure21.

Figure21BasicWLANConguration

2.CongurethebasicWLANparameters,aslistedinT able12.

Table12BasicWLANParameters

ParameterDescription

EnableWirelessRFWhethertoenablewirelessRF

ModeWirelesscommunicationmode

Country/RegionCountryorregionname

ChannelWirelesschannelnumber

Selectaproperchannelaccordingtothecountrycode

BeaconIntervalBeaconinterval

TxRateDatatransmissionrate

Alowdatatransmissionratecanenlargethewirelesscommunica-

tionarea.

TransmittingPowerTransmissionpower

QoSTypeQoSprioritytype

RTSThresholdRTSthreshold

DTIMIntervalDTIMinterval

FragmentThresholdFragmentthreshold

Ifapacketsizeexceedsthisthreshold,thepacketisdividedinto

severalfragmentsfortransmission.

4-6

SJ-20110517135211-002JTLProprietaryandConfidential

3.ClickSubmittonishtheconguration.ClickCanceltocanceltheconguration.

–EndofSteps–

Result

ThebasicWLANparametersarecongured.

4.2.2ConfiguringMulti-SSIDParameters

ShortDescription

Performthisproceduretoconguremulti-SSIDparameters.

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

Context

Toconguremulti-SSIDparameters,performthefollowingsteps:

Chapter4NetworkConfiguration

Steps

1.OntheNetworktab,clickWLANontheleftpane.SelectMulti-SSIDSettings,as
showninFigure22.

Figure22Multi-SSIDSettings

2.Congurethemulti-SSIDparametersasshowninTable13.

Table13Multi-SSIDParameters

ParameterDescription

ChooseSSIDChoosetheSSIDthatneedstobeconfigured.

HideSSIDDisableorenableSSIDbroadcast.

EnableSSIDEnabletheSSID.

4-7

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

ParameterDescription

SSIDNameSSIDname.Itcannotexceed32charactersandiscasesensitive.Itis

usedtocontroltheWLANaccess.TheSSIDnamemustmatchallthe

SSIDsoftherelatedaccessnodes;otherwise,thedevicecannotbe

accessed.UptofourWLANsub-portsaresupported.

3.ClickSubmittonishtheconguration.ClickCanceltocanceltheconguration.

–EndofSteps–

Result

Themulti-SSIDparametersarecongured.

4.2.3ConfiguringSecurityProperties

ShortDescription

Performthisproceduretocongurethesecurityproperties.

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

Context

Tocongurethesecurityproperties,performthefollowingsteps:

Steps

1.OntheNetworktab,selectWLAN,andthenselectSecurity,asshowninFigure23.

Figure23SecurityProperties

SSIDsupportsfourauthenticationmodes:OpenSystem,SharedKey,WPA-PSK,
andWPA2-PSK.

2.FromtheChooseSSIDdrop-downlist,selectanSSID.

4-8

SJ-20110517135211-002JTLProprietaryandConfidential

Chapter4NetworkConfiguration

a.InAuthenticationType,selectOpenSystem,andthenenableWEPEncryption

(bydefault,itisdisabled).TheOpenSystemcongurationinformationis
displayed,asshowninFigure24.

Figure24OpenSystemConguration

Table14liststheparametersfortheOpenSystemauthenticationmode.

Table14ParametersforOpenSystemAuthenticationMode

ParameterDescription

ChooseSSIDCurrentSSID

AuthenticationTypeCurrentSSIDauthenticationmode

WEPEncryptionToenableordisableWEPencryption

WEPEncryption

Level

WEPKeyIndexCurrentencryptionvalue

WEPKey1WEPencryptionvalue

WEPencryptionlength

lThe128–bitencryptioncanbea13–bitASCIIcodesora26–bit

hexadecimalnumber.

lThe64–bitencryptioncanbea5–bitASCIIcodeora10–bit

hexadecimalnumber.

Generally,the64–bitencryptioncanmeettheuserrequirements.T o

enhancesecurity,usethe128–bitencryption.

Range:5–bitASCIIcodeor10–bithexadecimalnumber

WEPKey2WEPencryptionvalue

Range:5–bitASCIIcodeor10–bithexadecimalnumber

WEPKey3WEPencryptionvalue

Range:5–bitASCIIcodeor10–bithexadecimalnumber

4-9

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

ParameterDescription

WEPKey4WEPencryptionvalue

Range:5–bitASCIIcodeor10–bithexadecimalnumber

b.InAuthenticationType,selectSharedKey.Bydefault,WEPEncryptionis

enabled.TheSharedKeycongurationinformationisdisplayed,asshownin

Figure25.

Figure25SharedKeyConguration

Table15liststheparametersfortheSharedKeyauthenticationmode.

Table15ParametersforSharedKeyAuthenticationMode

ParameterDescription

ChooseSSIDCurrentSSID

AuthenticationTypeCurrentSSIDauthenticationmode

WEPEncryptionToenableordisableWEPencryption

WEPEncryption

Level

WEPKeyIndexCurrentencryptionvalue

WEPKey1WEPencryptionvalue

WEPencryptionlength

lThe128–bitencryptioncanbea13–bitASCIIcodesora26–bit

hexadecimalnumber.

lThe64–bitencryptioncanbea5–bitASCIIcodeora10–bit

hexadecimalnumber.

Generally,the64–bitencryptioncanmeettheuserrequirements.T o

enhancesecurity,usethe128–bitencryption.

Range:5–bitASCIIcodeor10–bithexadecimalnumber

4-10

SJ-20110517135211-002JTLProprietaryandConfidential

Chapter4NetworkConfiguration

ParameterDescription

WEPKey2WEPencryptionvalue

Range:5–bitASCIIcodeor10–bithexadecimalnumber

WEPKey3WEPencryptionvalue

Range:5–bitASCIIcodeor10–bithexadecimalnumber

WEPKey4WEPencryptionvalue

Range:5–bitASCIIcodeor10–bithexadecimalnumber

c.InAuthenticationType,selectWPA-PSK.TheWP A-PSKconguration

informationisdisplayed,asshowninFigure26.

Figure26WPA-PSKConguration

Table16liststheparametersfortheWP A-PSKauthenticationmode.

Table16ParametersforWPA-PSKAuthenticationMode

ParameterDescription

ChooseSSIDCurrentSSID

AuthenticationTypeCurrentSSIDauthenticationmode

WPAPassphraseWPApre-sharedkey

Range:8–63characters

WPAGroupKeyUpdateIntervalUpdateintervaloftheWPAgroupkey

WPAEncryptionAlgorithmWPAencryptionalgorithm

Note

ThecongurationmethodfortheWPA2-PSKauthenticationmodeisthesameas
thatfortheWPA-PSKauthenticationmode.

4-11

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

3.ClickSubmittonishtheconguration.ClickCanceltocanceltheconguration.

–EndofSteps–

Result

Thesecuritypropertiesarecongured.

4.2.4ViewingAssociatedDevices

ShortDescription

Performthisproceduretoviewtheassociateddevices.

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

Context

Toviewtheassociateddevices,performthefollowingsteps:

Steps

1.OntheNetworktab,selectWLAN,andthenselectAssociatedDevice,asshownin

Figure27.

Figure27AssociatedDevice

2.SelectSSID,andthenclickRefreshtoviewtheMACaddressesoftheassociated
devices.

–EndofSteps–

Result

Theassociateddevicesarelisted.

4-12

SJ-20110517135211-002JTLProprietaryandConfidential

4.3AddressManagementConfiguration

Thistopicincludesthefollowing:

lConguringDHCPServer
lConguringDHCPBinding
lConguringSpecicAddressRange

4.3.1ConfiguringDHCPServer

ShortDescription

PerformthisproceduretoconguretheDHCPserver.

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

Context

ToconguretheDHCPserver,performthefollowingsteps:

Chapter4NetworkConfiguration

Steps

1.OntheNetworktab,selectAddressManagement.Bydefault,DHCPServeris
selected,asshowninFigure28.

Figure28DHCPServer

2.OntheDHCPServertab,conguretheparameters,aslistedinT able17.

4-13

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

Table17ParametersforDHCPServerConguration

ParameterDescription

LANIPAddressIPaddressoftheLANgroup(interfacesubnet)

SubnetMaskSubnetmaskoftheLANgroup

EnableDHCPServerToenableordisabletheDHCPserver

DHCPStartIPAddressStartingIPaddressallocatedbytheDHCPserver

DHCPEndIPAddressEndingIPaddressallocatedbytheDHCPserver

DNSServer1IPAddressIPaddressoftheDNSserver

DNSServer2IPAddressIPaddressoftheDNSserver

DNSServer3IPAddressIPaddressoftheDNSserver

DefaultGatewayIPaddressofthedefaultgateway

LeaseTimeLeasetimeoftheIPaddressbytheDHCPserver

3.ClickSubmittonishtheconguration.ClickCanceltocanceltheconguration.

–EndofSteps–

Result

TheDHCPserveriscongured.

4.3.2ConfiguringDHCPBinding

ShortDescription

PerformthisproceduretoconguretheDHCPbinding.

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

Context

ToconguretheDHCPbinding,performthefollowingsteps:

Steps

1.OntheNetworktab,selectAddressManagement,andthenselectDHCPBinding,
asshowninFigure29.

4-14

SJ-20110517135211-002JTLProprietaryandConfidential

Chapter4NetworkConfiguration

Figure29DHCPBinding

2.CongurebindingbetweentheMACaddressandIPaddress.CreateaDHCPbinding
tabletomaptheclientMACaddresstotheIPaddress.

TheDHCPserverallocatesIPaddressesaccordingtothebindingrelations,andthe
bindingrelationsdonotexpire.

Forexample,iftheMACaddressissetto00-0a-e2-c6-48-baandtheIPaddress
issetto192.168.1.113,itindicatesthattheDHCPserverallocatestheIPaddress

192.168.1.113tothehostwhichtheMACaddresscorrespondsto.

Note

TheIPaddressbelongstotheaddresspoolthatisprovidedbytheDHCPserverin
theLANgroup.

3.ClickAddtonishtheconguration.ClickModifytomodifytheconguration.Click

Deletetodeletetheconguration.

–EndofSteps–

Result

DHCPbindingiscongured.

4.3.3ConfiguringSpecificAddressRange

ShortDescription

Performthisproceduretocongurethespecicaddressrange.

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

Context

Tocongurethespecialaddressrange,performthefollowingsteps:

4-15

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

Steps

1.OntheNetworktab,selectAddressManagement,andthenselectSpecicAddress
Range,asshowninFigure30.

Figure30SpecicAddressRange

2.ClickModifytomodifytheparameters,asshowninFigure31.

Figure31SpecicAddressRangeConguration

3.InStartIPAddressandEndIPAddress,entertheIPaddresses,andthenclick

Modify.

–EndofSteps–

Result

Thespecicaddressrangeiscongured.

4.4RouteManagementConfiguration

Thistopicincludesthefollowing:

4-16

SJ-20110517135211-002JTLProprietaryandConfidential

lConguringDefaultGateway
lConguringStaticRouting

4.4.1ConfiguringDefaultGateway

ShortDescription

Performthisproceduretocongurethedefaultgateway .

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

Context

Tocongurethedefaultgateway,performthefollowingsteps:

Steps

1.OntheNetworktab,selectRoutingManagement.Bydefault,DefaultGatewayis
selected,asshowninFigure32.

Chapter4NetworkConfiguration

Figure32DefaultGateway

2.FromWANConnection,selecttheconnectioninterfaceattheWANside.

Note

ThisinterfaceisavailablewhenconguredonWANConnection.

3.ClickSubmittonishtheconguration.ClickCanceltocanceltheconguration.

–EndofSteps–

Result

Thedefaultgatewayiscongured.

4-17

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

4.4.2ConfiguringStaticRouting

ShortDescription

Performthisproceduretocongurethestaticrouting.

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

Context

Tocongurethestaticrouting,performthefollowingsteps:

Steps

1.OntheNetworktab,selectRoutingManagement,andthenselectStaticRouting,
asshowninFigure33.

Figure33StaticRouting

Table18liststheparametersforstaticroutingconguration.

Table18ParametersforStaticRoutingConguration

ParameterDescription

WANConnectionNetwork-sideinterfacetype

NetworkAddressNetworkaddress

SubnetMaskSubnetmask

DefaultGatewayGateway

2.FromtheWANConnectiondrop-downlist,selectthenetwork-sideinterface.

3.CongureNetworkAddress,SubnetMask,andDefaultGateway,asshownin

Figure34.

4-18

SJ-20110517135211-002JTLProprietaryandConfidential

Chapter4NetworkConfiguration

Figure34StaticRoutingConguration

4.ClickAddtonishtheconguration,asshowninFigure35.ClickModifytomodify
theconguration.ClickDeletetodeletetheconguration.

Figure35StaticRoutingCongurationCompleted

–EndofSteps–

Result

Thestaticroutingiscongured.

4-19

SJ-20110517135211-002JTLProprietaryandConfidential

4-20

SJ-20110517135211-002JTLProprietaryandConfidential

Chapter5

SecurityConfiguration

TableofContents

ConguringFirewall....................................................................................................5-1

ConguringIPFilter....................................................................................................5-2

ConguringURLFilter................................................................................................5-5

ConguringDMZHost................................................................................................5-7

ConguringPortForwarding.......................................................................................5-8

5.1ConfiguringFirewall

ShortDescription

Performthisproceduretoconguretherewall.

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

Context

Toconguretherewall,performthefollowingsteps:

Steps

1.OntheWebinterface,clicktheSecuritytab.Bydefault,Firewallisselected,as
showninFigure36.

Figure36FirewallConguration

5-1

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

2.Settherewallparameters,aslistedinTable19.

Table19FirewallParameters

ParameterDescription

EnableAnti-HackingProtectionToenableordisableanti-hackingprotection

FirewallLevelFirewalllevel

3.ClickSubmittonishtheconguration.ClickCanceltocanceltheconguration.

–EndofSteps–

Result

Therewalliscongured.

lHigh:AllowlegalWAN-sideaccessbut

prohibitWAN-sideping.

lLow:AllowlegalWAN-sideaccessand

WAN-sideping.

5.2ConfiguringIPFilter

ShortDescription

PerformthisproceduretocongureIPlter.

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

Context

TocongureIPlter,performthefollowingsteps:

Steps

1.OntheSecuritytab,selectIPFilter,asshowninFigure37.

5-2

SJ-20110517135211-002JTLProprietaryandConfidential

Figure37IPFilter

Chapter5SecurityConfiguration

Table20liststheparametersforIPlterconguration.

Table20ParametersforIPFilterConguration

ParameterDescription

EnableToenabletheIPfilterfunction

ProtocolProtocol

NameName

StartSourceIPAddressStartingsourceIPaddress

EndSourceIPAddressEndingsourceIPaddress

StartDestinationIPAddressStartingdestinationIPaddress

EndDestinationIPAddressEndingdestinationIPaddress

StartSourcePortStartingsourceportnumber

EndSourcePortEndingsourceportnumber

StartDestinationPortStartingdestinationportnumber

EndDestinationPortEndingdestinationportnumber

IngressIngressinterface

EgressEgressinterface

ModeDiscardPermitMode,includingdiscardandpermit

5-3

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

2.OntheIPFiltertab,setthelterparameters,asshowninFigure38.

Figure38IPFilterConguration

3.ClickAddtonishtheconguration,asshowninFigure39.ClickModifytomodify
theconguration.ClickDeletetodeletetheconguration.

5-4

SJ-20110517135211-002JTLProprietaryandConfidential

Figure39IPFilterCongurationCompleted

Chapter5SecurityConfiguration

–EndofSteps–

Result

IPlteriscongured.

5.3ConfiguringURLFilter

ShortDescription

PerformthisproceduretoconguretheURLlter.

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

Context

ToconguretheURLlter,performthefollowingsteps:

Steps

1.OntheSecuritytab,selectURLFilter,asshowninFigure40.

5-5

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

Figure40URLFilter

Table21liststheparametersforURLlterconguration.

Table21ParametersforURLFilterConguration

ParameterDescription

EnableToenabletheURLfilterfunction

ModeMode,includingdiscardandpermit

URLAddressURLaddress

2.OntheURLFiltertab,setthelterparameters,asshowninFigure41.

Figure41URLFilterConguration

3.ClickAddtonishtheconguration,asshowninFigure42.ClickDeletetodeletethe
conguration.

5-6

SJ-20110517135211-002JTLProprietaryandConfidential

Figure42URLFilterCongurationCompleted

–EndofSteps–

Result

URLlteriscongured.

Chapter5SecurityConfiguration

5.4ConfiguringDMZHost

ShortDescription

PerformthisproceduretoconguretheDMZhost.

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

Context

ToconguretheDMZhost,performthefollowingsteps:

Steps

1.OntheSecuritytab,selectDMZHost,asshowninFigure43.

Figure43DMZHost

5-7

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

2.ConguretheDMZhostparameters,asshowninFigure44.

Figure44DMZHostConguration

Table22liststheparametersforDMZhostconguration.

Table22ParametersforDMZHostConguration

ParameterDescription

AftertheDMZfullportmappingfunctionisenabled,alltheportsareenabledbydefault.
TheLAN-sidehostprovidesservicesthroughDNAT.

3.ClickSubmittonishtheconguration.ClickCanceltocanceltheconguration.

–EndofSteps–

Result

TheDMZhostiscongured.

5.5ConfiguringPortForwarding

EnableToenabletheDMZhost

WANConnectionWAN-sideconnectioninterface

DMZHostIPAddressIPaddressoftheDMZhost

Note

ShortDescription

Performthisproceduretocongureportforwarding.

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

5-8

SJ-20110517135211-002JTLProprietaryandConfidential

Chapter5SecurityConfiguration

Context

Tocongureportforwarding,performthefollowingsteps:

Steps

1.OntheSecuritytab,selectPortForwarding,asshowninFigure45.

Figure45PortForwarding

2.Conguretheportforwardingparameters,asshowninFigure46.

Figure46PortForwardingConguration

Table23liststheparametersforportforwardingconguration.

5-9

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

Table23ParametersforPortForwardingConguration

ParameterDescription

EnableToenabletheportforwardingfunction

NameHostname

ProtocolProtocolname,includingTCP,UDP,aswellasTCP

andUDPprotocols

WANHostIPAddressStartingIPaddressoftheWAN-sidehost

WANConnectionWANconnection

WANStartPortStartingportnumberoftheWAN-sidehost

WANEndPortEndingportnumberoftheWAN-sidehost

LANHostIPAddressIPaddressoftheLAN-sidehost

LANHostPortPortnumberoftheLAN-sidehost

Note

IfaredirectionpolicyofportaccesswiththesourceaddressoftheWAN-sideIP
addressandthedestinationaddressoftheLAN-sideIPaddressiscongured,itis
usedinthescenariowheretheWAN-sideclientaccessestheLAN-sideserver.

3.ClickAddtonishtheconguration,asshowninFigure47.ClickModifytomodify
theconguration.ClickDeletetodeletetheconguration.

5-10

SJ-20110517135211-002JTLProprietaryandConfidential

Figure47PortForwardingCongurationCompleted

Chapter5SecurityConfiguration

–EndofSteps–

Result

Portforwardingiscongured.

5-11

SJ-20110517135211-002JTLProprietaryandConfidential

5-12

SJ-20110517135211-002JTLProprietaryandConfidential

Chapter6

ServiceConfiguration

TableofContents

SIPVoIPServiceConguration..................................................................................6-1

ConguringDDNS......................................................................................................6-9

ConguringUPnP....................................................................................................6-11

DNSConguration...................................................................................................6-13

QoSConguration....................................................................................................6-15

ConguringSNTPClient..........................................................................................6-25

IGMPConguration..................................................................................................6-27

ConguringFTPApplication.....................................................................................6-34

6.1SIPVoIPServiceConfiguration

Thistopicincludesthefollowing:

lConguringVoIPWANConnection
lConguringSIP
lConguringSIPAccounts
lConguringVoIPAdvancedParameters
lConguringVoIPMediaParameters
lConguringFax

6.1.1ConfiguringVoIPWANConnection

ShortDescription

PerformthisproceduretoconguretheVoIPWANconnection.

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

Context

ToconguretheVoIPWANconnection,performthefollowingsteps:

6-1

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

Steps

1.OntheWebinterface,clicktheApplicationtab.SelectVoIP.Bydefault,WAN
Connectionisselected,asshowninFigure48.

Figure48WANConnection

2.SelectaconnectioninterfacefromWANConnection.

3.ClickSubmittonishtheconguration.ClickCanceltocanceltheconguration.

–EndofSteps–

Result

TheVoIPWANconnectioniscongured.

6.1.2ConfiguringSIP

ShortDescription

PerformthisproceduretocongureSIP .

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

Context

TocongureSIP,performthefollowingsteps:

6-2

SJ-20110517135211-002JTLProprietaryandConfidential

Chapter6ServiceConfiguration

Steps

1.OntheApplicationtab,selectVoIP,andthenselectSIPProtocol,asshowninFigure

49.

Figure49SIPProtocol

2.ConguretheSIPprotocolparameters,aslistedinT able24.

Table24ParametersforSIPProtocolConguration

ParameterDescription

LocalPortLocalportnumberusedbytheVoIPprotocol

PrimaryProxyServerIPaddressoftheprimaryproxyserver

PrimaryOutboundProxyServerIPaddressoftheprimaryoutboundproxyserver

PrimaryProxyPortPortnumberoftheprimaryproxyserver

SecondaryProxyServerIPaddressofthesecondaryproxyserver

SecondaryOutboundProxyServerIPaddressofthesecondaryoutboundproxyserver

SecondaryProxyPortPortnumberofthesecondaryproxyserver

RegisterExpiresRegistrationexpirationtime

Unit:second

3.ClickSubmittonishtheconguration.ClickCanceltocanceltheconguration.

–EndofSteps–

Result

SIPiscongured.

6-3

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

6.1.3ConfiguringSIPAccounts

ShortDescription

PerformthisproceduretocongureSIPaccounts.

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

Context

TocongureSIPaccounts,performthefollowingsteps:

Steps

1.OntheApplicationtab,selectVoIP,andthenselectSIPAccounts,asshownin

Figure50.

Figure50SIPAccounts

2.ClickModifytomodifytheaccountparameters,asshowninFigure51.

6-4

SJ-20110517135211-002JTLProprietaryandConfidential

Figure51SIPAccountConguration

Chapter6ServiceConfiguration

Table25liststheparametersforSIPaccountconguration.

Table25ParametersforSIPAccountConguration

ParameterDescription

UsernameNameoftheSIPauthenticationuser

PasswordPasswordoftheSIPauthenticationuser

URIUserregistrationidentification,thatis,theuserSIP

3.ClickModify.

–EndofSteps–

Result

TheSIPaccountsarecongured.

6.1.4ConfiguringVoIPAdvancedParameters

callnumber

ShortDescription

PerformthisproceduretoconguretheVoIPadvancedparameters.

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

6-5

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

Context

ToconguretheVoIPadvancedparameters,performthefollowingsteps:

Steps

1.OntheApplicationtab,selectVoIP,andthenselectAdvanced,asshowninFigure

52.

Figure52AdvancedParameters

2.Conguretheadvancedparameters,asshowninTable26.

Table26AdvancedParameters

ParameterDescription

EchoCancellationToenableordisableechocancellation

VAD&CNGToenableordisableVADandCNG

DTMFDTMFmode,includingRFC2833,RFC2198,andDTMFin

Voice

JitterBufferJitterbuffer,includingfixedandadaptive

MinValueMinimumjitterbuffervalue

Unit:ms

MaxValueMaximumjitterbuffervalue

Unit:ms

3.ClickSubmittonishtheconguration.ClickCanceltocanceltheconguration.

–EndofSteps–

6-6

SJ-20110517135211-002JTLProprietaryandConfidential

Result

TheVoIPadvancedparametersarecongured.

6.1.5ConfiguringVoIPMediaParameters

ShortDescription

PerformthisproceduretoconguretheVoIPmediaparameters.

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

Context

TocongureVoIPmediaparameters,performthefollowingsteps:

Steps

1.OntheApplicationtab,selectVoIP,andthenselectMedia,asshowninFigure53.

Chapter6ServiceConfiguration

Figure53MediaParameters

2.Congurethemediaparameters,asshowninFigure54.

6-7

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

Figure54MediaParameterConguration

Table27liststhemediaparameters.

Table27MediaParameters

ParameterDescription

CodecSelectionCodetype

CodecPriorityCodepriority

3.ClickSubmittonishtheconguration.ClickCanceltocanceltheconguration.

–EndofSteps–

Result

TheVoIPmediaparametersarecongured.

6.1.6ConfiguringFax

ShortDescription

Performthisproceduretocongurefax.

Thesmallerthevalueis,thehigherthepriorityis.

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

Context

Tocongurefax,performthefollowingsteps:

6-8

SJ-20110517135211-002JTLProprietaryandConfidential

Chapter6ServiceConfiguration

Steps

1.OntheApplicationtab,selectVoIP,andthenselectFax,asshowninFigure55.

Figure55FaxConguration

2.SelectEnableT38.

TodisableT38faxmode,clearthecheckbox.

3.ClickSubmittonishtheconguration.ClickCanceltocanceltheconguration.

–EndofSteps–

Result

Faxiscongured.

6.2ConfiguringDDNS

ShortDescription

PerformthisproceduretocongureDDNS.

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

Note

6-9

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

Context

AfterDDNSisapplied,thehostthathasthedynamicIPaddresscanalsoprovidethe
domainnameservice.Forexample,whenthehostobtainsanIPaddressthroughxDSL
dial-uporDHCPserverdynamicallocation,andthehostprovidesthedomainname
service,byusingDDNS,theeffectonthedomainnameaccesswhentheIPaddress
changesiseliminated.

TocongureDDNS,performthefollowingsteps:

Steps

1.OntheApplicationtab,selectDDNS,asshowninFigure56.

Figure56DDNS

2.ConguretheDDNSparameters,asshowninFigure57.

Figure57DDNSConguration

Table28liststheparametersforDDNSconguration.

6-10

SJ-20110517135211-002JTLProprietaryandConfidential

Chapter6ServiceConfiguration

Table28ParametersforDDNSConguration

ParameterDescription

EnableToenabletheDDNSfunction

ServerServeraddress

IftheGNUDIPHTTPprotocolisused,theseveraddressisa

URLaddress.Bydefault,itishttp://ns.eagleeyes.com.cn/cgi-

bin/gdipupdt.cgi.

UsernameDDNSserverusername

PasswordDDNSserverpassword

DomainDomainnamecorrespondingtotheuser,validonlywhenthe

GNUDIPprotocolisused

WANConnectionWAN-sideconnectioninterface

3.ClickSubmittonishtheconguration.ClickCanceltocanceltheconguration.

–EndofSteps–

Result

DDNSiscongured.

6.3ConfiguringUPnP

ShortDescription

PerformthisproceduretocongureUPnP .

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

Context

TheUPnPfunctionsupportszerocongurationanddeviceauto-discovery.Afterthis
functioniscongured,thedevicecanbedynamicallyaddedtoanetworktoobtaintheIP
address,announcethefunction,andknowthefunctionsofotherdevices.

TocongureUPnP,performthefollowingsteps:

Steps

1.OntheApplicationtab,selectUPnP,asshowninFigure58.

6-11

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

Figure58UPnP

2.ConguretheUPnPparameters,asshowninFigure59.

Figure59UPnPConguration

Table29liststheUPnPparameters.

Table29UPnPParameters

ParameterDescription

EnableToenableUPnP

WANConnectionomci1WAN-sideconnectioninterface

3.ClickSubmittonishtheconguration.ClickCanceltocanceltheconguration.

–EndofSteps–

Result

UPnPiscongured.

6-12

SJ-20110517135211-002JTLProprietaryandConfidential

6.4DNSConfiguration

Thistopicincludesthefollowing:

lConguringDomainName
lConguringHostName

6.4.1ConfiguringDomainName

ShortDescription

Performthisproceduretocongurethedomainname.

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

Context

Tocongurethedomainname,performthefollowingsteps:

Chapter6ServiceConfiguration

Steps

1.OntheApplicationtab,selectDNSService.Bydefault,DomainNameisselected,
asshowninFigure60.

Figure60DomainName

2.SetDomainName.

3.ClickSubmittonishtheconguration.ClickCanceltocanceltheconguration.

–EndofSteps–

Result

Thedomainnameiscongured.

6-13

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

6.4.2ConfiguringHostName

ShortDescription

Performthisproceduretocongurethehostname.

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

Context

Tocongurethehostname,performthefollowingsteps:

Steps

1.OntheApplicationtab,selectDNSService,andthenselectHosts,asshownin

Figure61.

Figure61HostName

2.SetHostNameandIPAddress,asshowninFigure62.

6-14

SJ-20110517135211-002JTLProprietaryandConfidential

Chapter6ServiceConfiguration

Figure62HostNameConguration

3.ClickAddtonishtheconguration,asshowninFigure63.ClickModifytomodify
theconguration.ClickDeletetodeletetheconguration.

Figure63HostNameCongurationCompleted

–EndofSteps–

Result

Thehostnameiscongured.

6.5QoSConfiguration

Thistopicincludesthefollowing:

lConguringBasicQoSParameters
lConguringQoSRule
lConguringQoSRuleType
lConguringQoSLocalApplication
lConguringQoSQueueManagement

6-15

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

lConguringQoSIngressRateLimit

6.5.1ConfiguringBasicQoSParameters

ShortDescription

PerformthisproceduretocongurethebasicQoSparameters.

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

Context

TocongurethebasicQoSparameters,performthefollowingsteps:

Steps

1.OntheApplicationtab,selectQoS.Bydefault,Basicisselected,asshowninFigure

64.

Figure64BasicQoSParameters

Note

Thetemplateindexisenabledimmediatelyafterchanged.

2.CongurethebasicQoSparameters,asshowninFigure65.

6-16

SJ-20110517135211-002JTLProprietaryandConfidential

Figure65BasicQoSParameterConguration

Table30liststhebasicQoSparameters.

Chapter6ServiceConfiguration

Table30BasicQoSParameters

ParameterDescription

TemplateIndexTemplateindex

EnableQoSToenableordisabletheQoSfunction

TheTotalUpstreamBandwidthUpstreambandwidththroughtheWANport

Range:8000–104857600bps

QueueSchedulingAlgorithmQueueschedulingalgorithm

Range:SPandDWRR

DWRRbandwidthlockedTolockDWRRbandwidth(whenthequeuescheduling

algorithmisDWRR)

EnableDSCPRe-markingToenableordisableDSCPremarking

802.1PRe-markModelToenableordisablethe802.1premarkingmode

Range:disable,transparenttransmission,andenable

3.ClickSubmittonishtheconguration.ClickCanceltocanceltheconguration.

–EndofSteps–

Result

ThebasicQoSparametersarecongured.

6-17

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

6.5.2ConfiguringQoSRule

ShortDescription

PerformthisproceduretoconguretheQoSrule.

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

Context

ToconguretheQoSrule,performthefollowingsteps:

Steps

1.OntheApplicationtab,selectQoS,andthenselectRule,asshowninFigure66.

Figure66QoSRule

2.ConguretheQoSruleparameters,asshowninFigure67.

6-18

SJ-20110517135211-002JTLProprietaryandConfidential

Figure67QoSRuleConguration

Table31liststheparametersforQoSruleconguration.

Chapter6ServiceConfiguration

Table31ParametersforQoSRuleConguration

ParameterDescription

802.1pRe-marking802.1Premarking

DSCPRe-markingDSCPremarking

CAR(CommittedAccessRate)Ingressratelimitrule

QueueCongestionmanagementqueue

3.ClickSubmittonishtheconguration.ClickCanceltocanceltheconguration.

–EndofSteps–

Result

TheQoSruleiscongured.

6.5.3ConfiguringQoSRuleType

ShortDescription

PerformthisproceduretoconguretheQoSruletype.

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

Context

ToconguretheQoSruletype,performthefollowingsteps:

6-19

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

Steps

1.OntheApplicationtab,selectQoS,andthenselectRuleType,asshowninFigure

68.

Figure68RuleType

2.ConguretheQoSruletypeparameters,asshowninFigure69.

Figure69RuleTypeConguration

Table32liststheparametersforQoSruletypeConguration

Table32ParametersforQoSRuleTypeConguration

ParameterDescription

ClassificationRulesClassificationrules

6-20

SJ-20110517135211-002JTLProprietaryandConfidential

Chapter6ServiceConfiguration

ParameterDescription

ProtocolProtocol

Range:TCP,UDP,ICMP,andRTP

TypeType

MinimumMinimumvalue

MaximumMaximumvalue

3.ClickAddtonishtheconguration,asshowninFigure70.

Figure70RuleTypeCongurationCompleted

4.ClickModifytomodifytheconguration.ClickDeletetodeletetheconguration.

–EndofSteps–

Result

TheQoSruletypeiscongured.

6.5.4ConfiguringQoSLocalApplication

ShortDescription

PerformthisproceduretoconguretheQoSlocalapplication.

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

Context

ToconguretheQoSlocalapplication,performthefollowingsteps:

6-21

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

Steps

1.OntheApplicationtab,selectQoS,andthenselectLocalApplication,asshownin

Figure71.

Figure71LocalApplication

2.IntheQueuedrop-downlist,selectaqueuenumber.

Note

Atpresent,onlytheTr-069servicemodeissupported.

3.ClickSubmittonishtheconguration.ClickCanceltocanceltheconguration.

–EndofSteps–

Result

TheQoSlocalapplicationiscongured.

6.5.5ConfiguringQoSQueueManagement

ShortDescription

PerformthisproceduretocongureQoSqueuemanagement.

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

Context

TocongureQoSqueuemanagement,performthefollowingsteps:

6-22

SJ-20110517135211-002JTLProprietaryandConfidential

Chapter6ServiceConfiguration

Steps

1.OntheApplicationtab,selectQoS,andthenselectQueueManagement,asshown
inFigure72.

Figure72QueueManagement

2.ClicktheModifyiconsinthetabletomodifythequeuemanagementfunctions.

3.SelectorclearEnabletoenableordisablethequeuemanagementfunction.

4.ClickModifytonishtheconguration.

Note

1indicatesenabledand0indicatesdisabled.

WhenthecongestionmanagementalgorithmisDWRR,thequeueweightneedstobe
congured.

Weightreferstotheratioofthedataowpassingthroughthequeuestothetotaldata
ow.

–EndofSteps–

Result

QoSqueuemanagementiscongured.

6.5.6ConfiguringQoSIngressRateLimit

ShortDescription

PerformthisproceduretoconguretheQoSingressratelimit.

6-23

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

Context

ToconguretheQoSingressratelimit,performthefollowingsteps:

Steps

1.OntheApplicationtab,selectQoS,andthenselectIngressRateLimit,asshown
inFigure73.

Figure73IngressRateLimit

2.ConguretheparametersforQoSingressratelimit,asshowninFigure74.

Figure74IngressRateLimitConguration

6-24

SJ-20110517135211-002JTLProprietaryandConfidential

Chapter6ServiceConfiguration

Table33liststheparametersforingressratelimitconguration.

Table33ParametersforIngressRateLimitConguration

ParameterDescription

VisitingInterfaceUserinterfacefortheratelimitrule

EnableToenabletheingressratelimitfunction

RateLimitrate

8000bps–104857600bps

3.ClickAddtonishtheconguration.ClickModifytomodifytheconguration.Click

Deletetodeletetheconguration.

–EndofSteps–

Result

TheQoSingressratelimitiscongured.

6.6ConfiguringSNTPClient

ShortDescription

PerformthisproceduretoconguretheSNTPclient.

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

Context

ToconguretheSNTPclient,performthefollowingsteps:

Steps

1.OntheApplicationtab,selectSNTP,asshowninFigure75.

6-25

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

Figure75SNTP

2.ConguretheSNTPparameters,asshowninFigure75.

Figure76SNTPConguration

Table34liststheSNTPparameters.

Table34SNTPParameters

ParameterDescription

TimeZoneTimezonewherethesubscriberislocated

PrimaryNTPServer

Address

SecondaryNTPServer

Address

PollIntervalIntervalforserversynchronization

IPaddressoftheprimaryNTPserver

IPaddressofthesecondaryNTPserver

Unit:second

3.ClickSubmittonishtheconguration.ClickCanceltocanceltheconguration.

–EndofSteps–

6-26

SJ-20110517135211-002JTLProprietaryandConfidential

Result

TheSNTPclientiscongured.

6.7IGMPConfiguration

Thistopicincludesthefollowing:

lConguringBasicIGMPParameters
lConguringMulticastVLAN
lConguringMulticastMACLimit
lConguringMVLANTagStrip

6.7.1ConfiguringBasicIGMPParameters

ShortDescription

PerformthisproceduretocongurethebasicIGMPparameters.

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

Chapter6ServiceConfiguration

Context

TocongurethebasicIGMPparameters,performthefollowingsteps:

Steps

1.OntheApplicationtab,selectIGMP.Bydefault,Basicisselected,asshowninFigure

77.

Figure77BasicIGMPConguration

2.IGMPModeincludesIGMPSnooping,IGMPProxy,andDisabled.Disabled
indicatestodisabletheIGMPmodeconguration.

6-27

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

lCongureIGMPSnooping.

FromtheIGMPModedrop-downlist,selectIGMPSnooping,asshowninFigure

78.

Figure78IGMPSnoopingConguration

Table35liststheparametersforIGMPsnoopingconguration.

Table35ParametersforIGMPSnoopingConguration

ParameterDescription

IGMPModeIGMPmode

MulticastMACAgingTimeAgingtimeofthemulticastaddress

Non-Fast-LeaveToenabletheNon-Fast-Leavemode

lCongureIGMPProxy.

FromtheIGMPModedrop-downlist,selectIGMPProxy,asshowninFigure79.

6-28

SJ-20110517135211-002JTLProprietaryandConfidential

Figure79IGMPProxyConguration

Table36liststheparametersforIGMPproxyconguration.

Table36ParametersforIGMPProxyConguration

Chapter6ServiceConfiguration

ParameterDescription

IGMPModeIGMPmode

MulticastMACAgingTimeAgingtimeofthemulticastaddress

ReportTimePeriodicalreporttimeofmulticastmessages

Note

ZXA10F660periodicallyreportstheIGMPmemberreportmessagestothe
upper-layermulticastrouteraccordingtotheReportTime.

3.ClickSubmittonishtheconguration.ClickCanceltocanceltheconguration.

–EndofSteps–

Result

ThebasicIGMPparametersarecongured.

6.7.2ConfiguringMulticastVLAN

ShortDescription

PerformthisproceduretocongurethemulticastVLAN.

6-29

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

Context

TocongurethemulticastVLAN,performthefollowingsteps:

Steps

1.OntheApplicationtab,selectIGMP,andthenselectMulticastVLAN,asshownin

Figure80.

Figure80MulticastVLAN

2.CongurethemulticastVLANparameters,asshowninFigure81.

Figure81MulticastVLANConguration

Table37liststheparametersforthemulticastVLANconguration.

6-30

SJ-20110517135211-002JTLProprietaryandConfidential

Table37ParametersforMulticastVLANConguration

ParameterDescription

IGMPModeIGMPmode,configuredontheBasictab

EnableMulticastVLANToenablethemulticastVLANfunction

EnableTranslationToenablemulticastVLANtranslation

MulticastVLANTocreateamulticastVLAN

NewVLANMulticastVLANID

InterfaceNameLANinterfacetobeaddedtothemulticastVLAN

3.ClickSubmittonishtheconguration.ClickCanceltocanceltheconguration.

–EndofSteps–

Result

ThemulticastVLANiscongured.

Chapter6ServiceConfiguration

6.7.3ConfiguringMulticastMACLimit

ShortDescription

PerformthisproceduretoconguremulticastMAClimit.

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

Context

ThemulticastMAClimitfunctioncanbeconguredonlywhentheIGMPmodeisIGMP
Snooping.IGMPProxydoesnotsupportthisfunction.

ToconguremulticastMAClimit,performthefollowingsteps:

Steps

1.OntheApplicationtab,selectIGMP,andthenselectMulticastMACLimit,asshown
inFigure82.

6-31

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

Figure82MulticastMACLimit

2.ClicktheModifyicontocongurethemulticastMAClimit,asshowninFigure83.

Figure83MulticastMACLimitConguration

Table38liststheparametersforthemulticastMAClimitconguration.

Table38ParametersforMulticastMACLimitConguration

ParameterDescription

MulticastMACAddressLimitMaximummulticastaddressesforeachLANport

Range:0–256

3.ClickModify.

–EndofSteps–

Result

MulticastMAClimitiscongured.

6-32

SJ-20110517135211-002JTLProprietaryandConfidential

6.7.4ConfiguringMVLANTagStrip

ShortDescription

PerformthisproceduretocongureMVLANtagstrip.

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

Context

TheMVLANtagstripfunctioncanbeconguredonlywhentheIGMPmodeisIGMP
Snooping.IGMPProxydoesnotsupportthisfunction.

TocongureMVLANtagstrip,performthefollowingsteps:

Steps

1.OntheApplicationtab,selectIGMP,andthenselectTagStripe,asshowninFigure

84.

Chapter6ServiceConfiguration

Figure84MVLANTagStrip

2.ClicktheModifyicontocongureMVLANtagstrip,asshowninFigure85.

6-33

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

Figure85MVLANT agStripConguration

Table39liststheparametersforMVLANtagstripconguration.

Table39ParametersforMVLANT agStripConguration

3.ClickModify.

–EndofSteps–

Result

MVLANtagstripiscongured.

6.8ConfiguringFTPApplication

ShortDescription

PerformthisproceduretocongureFTPapplication.

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

Context

TocongureFTPapplication,performthefollowingsteps:

ParameterDescription

EnableTagStripeToenabletheMVLANtagstripfunction

Steps

1.OntheApplicationtab,selectFTPApplication,asshowninFigure86.

6-34

SJ-20110517135211-002JTLProprietaryandConfidential

Chapter6ServiceConfiguration

Figure86FTPServer

2.ConguretheFTPserverparameters,asshowninFigure87.

Figure87FTPServerConguration

Table40liststheFTPserverparameters.

Table40FTPServerParameters

ParameterDescription

EnableFTPServerToenabletheFTPserver

FTPUsernameFTPloginusername

FTPPasswordFTPloginpassword

3.ClickSubmittonishtheconguration.ClickCanceltocanceltheconguration.

–EndofSteps–

Result

FTPapplicationiscongured.

6-35

SJ-20110517135211-002JTLProprietaryandConfidential

6-36

SJ-20110517135211-002JTLProprietaryandConfidential

Chapter7

DeviceManagement

TableofContents

TR-069Conguration.................................................................................................7-1

UserManagement......................................................................................................7-4

DeviceManagement..................................................................................................7-5

LogManagement.......................................................................................................7-9

PingDiagnosis.........................................................................................................7-10

7.1TR-069Configuration

Thistopicincludesthefollowing:

lConguringBasicTR-069Parameters
lImportingTR-069Certicate

7.1.1ConfiguringBasicTR-069Parameters

ShortDescription

PerformthisproceduretocongurethebasicTR-069parameters.

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

Context

TocongurethebasicTR-069parameters,performthefollowingsteps:

Steps

1.OntheAdministrationtab,selectTR-069.Bydefault,Basicisselected,asshown
inFigure88.

7-1

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

Figure88BasicTR-069Parameters

2.CongurethebasicTR-069parameters,asshowninFigure89.

Figure89BasicTR-069ParameterConguration

Table41liststhebasicTR-069parameters.

Table41BasicTR-069Parameters

ParameterDescription

WANConnectionWAN-sideconnectioninterface

ACSURLNetworkserverURL

UsernameUsername

PasswordPassword

ConnectionRequestURLConnectionrequestURL

ConnectionRequestUsernameConnectionrequestusername

7-2

SJ-20110517135211-002JTLProprietaryandConfidential

ParameterDescription

ConnectionRequestPasswordConnectionrequestpassword

EnablePeriodicInformToenableperiodicreport

PeriodicInformIntervalPeriodicreportinterval

EnableCertificateToenablecertificate

3.ClickSubmittonishtheconguration.ClickCanceltocanceltheconguration.

–EndofSteps–

Result

ThebasicTR-069parametersarecongured.

7.1.2ImportingTR-069Certificate

ShortDescription

PerformthisproceduretoimporttheTR-069certicate.

Chapter7DeviceManagement

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

Context

ToimporttheTR-069certicate,performthefollowingsteps:

Steps

1.OntheAdministrationtab,selectTR-069,andthenselectCerticate,asshownin

Figure90.

Figure90TR-069Certicate

2.ClickBrowsetoselectthecerticatele.

3.ClickImportCerticatetoimportthele.

–EndofSteps–

7-3

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

Result

TheTR-069certicateisimported.

7.2UserManagement

ShortDescription

Performthisproceduretomanageusers.

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

Context

Tomanageusers,performthefollowingsteps:

Steps

1.OntheAdministrationtab,selectUserManagement,asshowninFigure91.

Figure91UserManagement

2.Conguretheusermanagementparameters.

Note

UserRightincludesAdministratorandUser.

3.ClickSubmittonishtheconguration.ClickCanceltocanceltheconguration.

–EndofSteps–

Result

Usermanagementiscomplete.

7-4

SJ-20110517135211-002JTLProprietaryandConfidential

7.3DeviceManagement

7.3.1SystemManagement

Chapter7DeviceManagement

Thistopicincludesthefollowing:

lSystemManagement
lSoftwareUpgrade
lCongurationManagement

ShortDescription

Performthisproceduretomanagethesystem.

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

Context

Tomanagethesystem,performthefollowingsteps:

Steps

1.OntheAdministrationtab,selectSystemManagement,asshowninFigure92.

Figure92SystemManagement

2.ClickReboottorebootthedevice.

3.ClickRestoreDefaulttorestorethesystemtothefactorydefaultsettings.

–EndofSteps–

Result

Systemmanagementiscomplete.

7-5

SJ-20110517135211-002JTLProprietaryandConfidential

ZXA10F660OpticalNetworkTerminalMaintenanceManagementManual

7.3.2SoftwareUpgrade

ShortDescription

Performthisproceduretoupgradethesoftware.

Pre-requisites

TheuserhasloggedintotheWebinterfaceofthedevice.

Context

Caution

Generally,thesoftwareisupgradedbytheZTECORPORA TIONengineers.Iftheuser
wantstoupgradethesoftware,contactthelocalofceofZTECORPORA TIONtoobtain
thelatestsoftwareversion.

Toupgradethesoftware,performthefollowingsteps:

Steps

1.OntheAdministrationtab,selectSystemManagement,andthenselectSoftware
Upgrade,asshowninFigure93.

Figure93SoftwareUpgrade

2.ClickBrowsetoselectthesoftwareversion.

3.ClickUpgradetoupgradethesoftware,asshowninFigure94.

7-6

SJ-20110517135211-002JTLProprietaryandConfidential
