Mobile Phone
innos Model：innos i5
User Manual
1. Safety and Precautions
1.1 Safety Alert and Cautions
Before using the phone, please read these cautions
carefully to make sure you use the phone correctly.
IMPORT ANT!
Please read these instructions carefully and follow them
implicitly in case of any dangerous or illicit situations.
Note driving safety
It is strongly recommended that you do
not use a mobile phone when driving.
Please use the personal hand free package
when a call is inevitable.
Please put y our mob ile phon e in the mo bile
phone holder safely, and don’t put it at a
passenger’s seat or any other place that
may risk a drop of your mobile phone in
the case of collision or emergency brake.
Switch off your mobile phone on the
airplane
Interference caused by mobile phones
affects aviation safety, and thus it is illegal
to use it on the airplane. Please make
sure your mobile phone is switched off
when you are on a plane.
Switch off your mobile phone in blasting
operation area
You should strictly obey relevant laws and
2
regulations and switch off your mobile
phone in or near blasting operation area.
Switch off your mobile phone near
dangerous area
Your ce ll p ho ne is n o t all o we d to sw itc h o n
when the refueling and chemical
substance area is nearby.
In a hospital
When using it in a hospital, you should be
subject to the relevant rules specified by
the hospital. Make sure your mobile
phone is switched off when medical
equipment is nearby. Any wireless
transmission equipment, mobile phones
included, will affect its performance.
Other electronic equipment may be
affected as well. If you have any question
in this regard, please consult relevant
doctor or equipment supplier directly.
Interference
Any interference caused by wireless
equipment can do damage to its
performance.
Qualified services
Only qualified services are allowed to
install or re pair mobile phones. If you
install or repair it by yourself, you may
break the guarantee rules.
Accessories and batteries
Only manufacturer recognized accessories
and batteries can be used.
1.2 Protecting Your Battery
The guidelines listed below help you get the most out of
3
your battery’s performance.
z In order to avoid damage, charge the battery only in
temperatures that ranges from 32° F to 113° F (0° C to 45° C).
z Don’t use the battery charger in sunlight or in high humidity
areas directly, such as the bathroom.
z Never dispose of the battery by incineration.
z Keep the metal contacts on top of the battery clean.
z Don’t attempt to disassemble or short-circuit the battery.
z The battery may need recharging if it has not been used
for a long period of time.
z It’s best to replace the battery when it no longer provides
acceptable performance.
z It can be recharged hundreds of times before it needs
replacing.
z Don’t store the battery in high temperature areas for long
periods of time.
Disposal of Lithium Ion (Li-Ion) Batteries
z Do not handle a damaged or leaking Li-Ion battery as you
can be burned.
z For safe disposal options of your Li-Ion batteries, contact
your nearest innos authorized service center.
Note: Be sure to dispose of your battery properly. In some
areas, the disposal of batteries in household or business trash
may be prohibited.
1.3 Cleaning and Maintenance
z Please don’t leave the phone, the battery and the charger
in the bathroom or other high humidity places, and prevent
them from rain.
z Please clean the phone, the battery and the charger using
soft and dry cloth.
z Please don’t wipe the phone using alcohol, thinner or
benzene and other chemical reagents.
z The socket with dirt may cause poor contact or power-off.
4
Please clean it regularly.
5
2. Getting Started
2.1 Phone Overview
2.2 Open the battery door
Push the battery cover upwards.
6
2.3 Insert SIM/USIM card
Open the back cover and take off the battery, then
insert the SIM/USIM, mircro sim, SD card into the sim
slot as shown in picture below:
Note: If the memory card is failed, please check
whether it is correctly placed at good contact of metal
point.
2.5 Power on/off
z Power On: in power off status, long press the
power key on top for about 2 seconds, the phone
will vibrate to indicate the power on and the power
on animation will play.
z Power Off: in power on status, long press power
key until an option small windows shows on screen,
7
select the Power Off option.
2.6Battery Charging
You can charge the battery by connecting the phone
either to a pc USB port or to the provided standard
adopter via the provided standard usb cable.
Note: In order to ensure normal operation of the phone,
please use the innos verified accessories.
2.7 Security
A series of passwords have been set in your mobile
phone and SIM card, for they can prevent any
unauthorized use of your mobile phone and SIM card.
Mobile phone password:
The mobile phone password is the same as the mobile
phone lock password, its preset code by the
manufacturer is 1122.
Note: The mobile phone password may include 4~8
digits. Please change the password in time, and
remember what you have set. The password used by
the theft proof trace function is the mobile phone
password.
PIN code:
The PIN code (personal identification number, 4~8
digits) is used to prevent unauthorized use of your SIM
card. If the PIN verification function is activated, the
PIN code will be required to start the mobile phone each
time. If you have entered the PIN code incorrectly for
three times, the SIM card will be locked. The following
instructions indicate you how to unlock the card:
1> Enter the correct PUK code in line with the prompt on
the screen to unlock the SIM card.
2> Then enter a new PIN code and press the OK soft
key.
3> When you are prompted to reenter the new PIN code,
8
reenter the new PIN code and press the OK key.
4> If the PUK code is correct, the SIM card will be
unlocked, and the PIN code is reset.
Warning: If you have entered the PIN code incorrectly
for three times, the SIM card will be locked
automatically, in that case you need to use the PUK
code to unlock the card. The PUK code is generally
kept by the network operator.
PUK code:
The PUK code (the PIN unlocking password, 8 digits) is
used to unlock the locked PIN code. The PUK code is
provided by the manufacturer together with the SIM
card. If you have entered the PUK code incorrectly for
ten times, the SIM card will be invalidated. You need to
ask your network supplier for a new card.
PIN2 code:
The PIN2 code (4~8 digits) is provided together with the
SIM card, which is used to set the fixed dial and other
functions. Please contact your network operator to
check if your SIM card supports such functions. If you
have entered the PIN2 code incorrectly for three times,
the PIN2 code will be locked. The PIN2 code will be
unlocked only by entering the correct PUK2 code. The
operations are as follows:
1> Enter the correct PUK2 code in line with the prompt
on the screen to unlock the PIN2 code.
2> Then enter a new PIN2 code and press the OK soft
key.
3> When you are prompted to reenter the new PIN2
code, reenter the new PIN2 code and press the OK soft
key.
PUK2 code:
The PUK2 code (the PIN2 unlocking password, 8 digits)
is used to unloc k the lock ed PIN2 co de. The PUK2 code
9
is provided by the manufacturer together with the SIM
card. If the PUK2 code has not been provided, please
contact your network operator. If you have entered
the PUK2 code incorrectly for ten times, you will be
unable to use the functions of the PUK2 code. If you
want to use these functions, please contact your
network operator to change a new card.
3. Basic operation & knowledge
3.1 Using Touch Screen
Tap To act on items on the screen, such as application,
settings icons and options, to type letters and symbols
using the onscreen keyboard, or to press onscreen
buttons, you simply touch down your finger on them
and then lift your finger without change the touch down
position in a short time.
Tap & hold Touch down your finger on the screen
without lifting up or moving for about 2 seconds. This
action will pop-up an special options list or active some
special actions.
Drag Touch down your finger on screen and move
without lifting up to scroll options, switch screens and
other contents displayed on screen.
Flick Drag quickly and release, To scroll through a list
or move quickly, flick across the touch screen, When
you flick a long list, tap the screen to stop it from
scrolling.
Pinch In some applications (such as Maps, Browser,
and Gallery), you can zoom in and out by placing two
fingers on the screen at once and pinching them
together (to zoom out) or spreading them apart (to
zoom in).
10
Using Keys
Power key: Press and hold Power key to open the
power key menu, where you can turn off the phone
(Power off), or turn Flight mode or Silent mode on or off.
Volume key: Press the volume keys to change the
ring volume (on the home screen) or the earpiece
volume (during a call.
Menu key
the current screen or application. When you want to quit
from an applic atio n or do other opera tions , if the re is no
option button displayed on screen, try this menu key.
Home key
app and return to the home screen. On the home screen,
press and hold Home to show the latest apps you used,
then tap an app to open it.
Back key
working in. If the onscreen keyboard is open, closes the
keyboard.
3.2 Home & Main menu screen
When you sign in, the Home screen opens. It is your
starting point to access all the features on your phone，
it displays application icons, widgets, shortcuts, and
other features. You can customize the Home screen with
different wallpaper.
: Opens a menu with items that affect
: Press Home to close any menu or
: Opens the previous screen you were
11
In Home screen, tap the menu icon
menu screen where displays all the apps have been
installed in your phone, tap on one app’s icon to execute
the app.
to enter the Main
12
Screen Lock & Display off
You can customize the phone’s display off time in menu
Settings -> Display -> Screen timeout, without any
operation to the phone in the set time, the LCD display
will go off, short press any of Power key, Menu key,
Home key or Back key will wake up the display from
display off mode.
If you wake up the display in more than 5 seconds after
the LCD auto go off, it will be in the screen lock screen,
there are 4 different ways to unlock the screen
according to your settings under menu Settings ->
Location & security settings -> Set up screen l ock,
Using the on Screen Keyboard
You enter text using the onscreen keyboard. Some
applications open the keyboard automatically. In others,
you touch a text field where you want to enter text to
open the keyboard.
If you have installed the 3
application, before you apply this input method, you
should firstly enable it under menu Settings ->
Language & keyboard. When you need to input text,
rd
party input method
13
tap & hold in the text input filed, an option list will
pop-up for you selection.
Status bar
The Status bar appears at the top of every screen. It
displays icons indicating that you’ve received
notifications (on the left), icons indicating the phone’s
status (on the right), and programs run in background,
along with the current time.
Notification icons
Received notification icons
14
The applications you installed in your phone may use
their own notification icons while running in
background.
To open the Notifications panel:
z Drag the Status bar down from the top of the
screen.
z OR press menu key on Home screen.
Using sensors
Proximity Sensor detects how close an object is to the
surface of the screen. This is typically used to detect
when your face is pressed up against the screen, such
as during a phone call. (While talking on the phone, the
sensor detects talk activity and locks the keypad to
prevent accidental key presses).
Light Sensor lets you use the ambient light level to
adjust the screen brightness/contrast.
15
z In a bright light condition (outdoors), the sensors
cause the device to increase the brightness and
contrast for better viewing.
z In dim light conditions, the device increases the
screen brightness to compensate.
3D accelerometer detects your phone’s acceleration
direction and takes responding actions according to the
running application.
z Rotate the screen display when you rotate the
device while using some features. To set the
interface to keep the orientation when you rotate
the device, select Settings -> Display ->
Auto-rotate screen.
z Take actions according to the gravity’s real time
orientation angle, typically used in games.
z Responding to your actions such swing the device in
some applications.
Compass Sensor always knows where is North, in
some applications such as map, it always points to the
North direction.
Connectivity
PC connections:
z You can connect your device to a PC via USB data
cable. When you connect the device to a PC, you
can synchronize data with an Android
synchronization tool from 3
which you can download from Android market, and
transfer data to and from your device directly.
z You can connect your phone to a computer with a
USB cable, to transfer music, pictures, and other
files between your phone’s SD card and the
computer. To u se this fe ature, yo u should f ollow th e
4 steps below:
1. Use the USB cable that came with your phone to
rd
part running at PC side,
16
connect the phone to a USB port on your computer
(you will receive a notification that the USB is
connected).
2. Open the Notifications panel and tap USB
connected.
3. Tap Turn on USB storage in the scree n tha t ope ns to
confirm that you want to transfer files.
Bluetooth:
Bluetooth technology allows you to connect your
phone, using radio waves, to a compatible
Bluetooth device within 10 meters (32 feet). With
this feature on your device you can:
z Transfer files to or from other Bluetooth available
devices.
z Share multimedia files with other Bluetooth
available devices.
z Remote control another Bluetooth available
devices.
z Connect to computers and access the Internet.
Before using the Bluetooth, you should first turn it on by
selecting Settings -> Wireless & networks ->
Bluetooth, and You may also have to pair your phone
with other Bluetooth devices by steps Settings ->
Wireless & networks -> Bluetooth settings ->
Scan for devices, and then select the device you want
to connect to.
Wi-Fi:
Using Wi-Fi™ you can access the Internet wirelessly
with your phone. You can browse the Internet at home
(personal networks) or in public access zones (hot
spots):
z Personal networks – usually protected. A pass
phrase or a key is required from the owner.
z Hot spots – usually non-protected but often
17
requires you to log on to the operator’s service
before you get Internet access.
Follow the following steps to use your Wi-Fi:
1. Select Settings -> Wireless & networks ->
Wi-Fi to turn it on. (The phone scans for available
Wi-Fi networks and displays the names of those it
finds. Secured networks are indicated with a Lock
icon.If the phone finds a network that you
connected to previously, it connects to it.)
2. If you want to connect to a newly found Wi-Fi
network, tap on the network name under Settings
-> Wireless & networks -> Wi-Fi settings.
You can set your preferred network mode while surf on
internet by selecting options under menu Settings ->
Wireless & networks -> Mobile networks settings
-> Network Mode.
Storage
There are 2 kinds of user storage memory with your
phone, internal storage built in phone and external
storage applies to SD card.
The phone built-in storage is mainly used for installing
application space (see install applications section) and
other information data, user can not directly access data
stored in it.
Application programs and other data you downloaded
from internet or transferred from other devices, camera
captured photos, recorded videos or audios are all
stored in SD card memory, some files to be accessed by
applications such as music, images, videos etc. must be
stored in SD card, you can also make your application
installed in SD card (see install applications section).
Contact
Contact gives you quick and easy access to the people
you want to reach. When you first turn on your phone
18
and sign into your Google Account, any existing Google
contacts would be downloaded to your phone. After
that, your contacts are synchronized: any changes you
make to your contacts on the phone or the web are
made in both places, the next time you sync. Contacts
from Exchange ActiveSync accounts are also synced in
this way.
Information about your contacts is shared with other
applications, such as Gmail, Google Talk , Messaging,
Gallery (for sharing photos and videos), and so on.
If you have more than one account with contact
information, Contacts joins duplicates into a single entry.
You can also manage that process manually
Call
This phone has dual sim dual stand by function, that is
to say you can install 2 sim cards to your phone and to
make a call through either card, also you can receive
any incoming call to either card installed in your phone.
Make a call:
z Tap on dial button
menu screen to enter dial board screen, enter the
phone number and tap either call out button (call
out button 1 or call out button 2) to make a call.
z In contact list, tap & hold on a contact and select
Call contact option, or tap either call out button
(call out button 1 or call out button 2) after entering
another screen.
z In other applications such as message, call log,
there are also options for make a call.
Answer/Reject a call:
on Home screen or on
19
When a call incomes in, drag on the left to the
right until it reaches the green dot to answer a call, drag
on the right to the left until it reaches the red dot
to reject a incoming call.
During a call conversation, press the side volume key to
adjust volume, drag Dialpad
dial pad, press menu key to adopt other options.
Messaging
You can use Messaging to exchange text messages
(SMS) and multimedia messages (MMS) with your
friends on t heir mobile phones.
You can send text (SMS) messages of up to 160
characters to another mobile phone. If you keep typing
after the limit, your message is delivered as a series of
messages.
Multimedia (MMS) messages can contain text and a
picture, a recorded voice, an audio file, a video, or a
picture slideshow.
Messaging automatically converts a message into a
multimedia message if you send it to an em ail address
instead of a phone number, add a subject, or attach a
media file.
Press
on Home screen or Main menu screen to
access message.
When new message received, the message notification
icon
will be shown on the notification bar, drag
at bottom up to open
20
down the bar and tap on the message to read.
Multimedia
Camera is a combination camera and camcorder that
you use to shoot and share pictures and videos. Pictures
and videos are stored on the phone’s SD card, so you
must install one to use Camera.
Gallery is used to view pictures and play videos that
you’ve taken with Camera, downloaded, or copied onto
your SD card. You can perform basic editing tasks on
pictures and set them as your wallpaper or contact
picture.
Music collects all audio files from your SD card to play.
Videos collects all video files from your SD card to play.
Applications
Based on the Android platform, your device’s
functionality can be extended by installing additional
applications, These applications can be downloaded
from internet such as Android Market.
Three ways to install applications in your phone:
z Directly down load from internet, when the
downloading task is completed, select Install option
in your download list to install.
Note: How to install may depend on the browser you use,
before download, make sure an available SD card has
been inserted.
z Download appl ications to your PC local disk, and
install from PC by running innos phone suite.
z If have a file manager installed in you phone, you
21
can transfer or download applications to your SD
card, find out the application you want to install
under path ./mnt/sdcard/.. and tap on it.
Note: To install applications downloaded from websites
other than Android Market, you must select Settings
->Applications-> Unknown sources.
Warning: Applications downloaded from internet can be
from unknown sources. To protect your phone and
personal data, download applications only from trusted
sources such as Android Market.
To manage applications:
Enter Settings -> Applications -> Manage
applications, you can access all the applications.
Tap on an application under each tag list, it will enter the
Application info screen, along with manage buttons.
Force stop to close a running application, it is stopped
without confirmation.
Uninstall to uninstall appl ications tha t you don’t want
to use any more, and free the storage space it occupies.
Clear data to delete user data about an application
such as accounts, databases, settings and so on.
Move to SD card/phone to move applications
installed in phone/SD car d to SD card/phone memory.
Clear cache to delete temporary data for this
application stored in phone.
GPS
With the global positioning system (GPS) receiver in
your phone, you can find your location with in a
accuracy about 50 meters in global range when you are
outdoor.
To use this facility, you should install applications to
support, such as google map, or use the pre-installed
Amap app.
22
Federal Communication Commission Interference
Statement
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception,
which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the
23
interference by one of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment
and receiver.
Connect the equipment into an outlet on a circuit
different from that to which the receiver is connecte d .
Consult the dealer or an experienced radio/TV
technician for help.
FCC Caution: Any changes or modifications not expressly
approved by the party responsible for compliance could
void the user's authority to operate this equipment.
24
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired
operation.
IMPORTANT NOTE:
Federal Communication Commission (FCC) Radiation
Exposure Statement
This EUT is compliance with SAR for general
population/uncontrolled exposure limits in ANSI/IEEE
C95.1-1999 and had been tested in accordance with the
measurement methods and procedures specified in OET
Bulletin 65 Supplement C. This equipment should be
25
installed and operated with minimum distance 1.5cm
between the radiator & your body.
This device was tested for typical body-worn operations.
To comply with RF exposure requirements, a minimum
separation distance of 1.5 cm must be maintained between
the user’s body and the handset, including the antenna.
Third-party belt-clips, holsters, and similar accessories
used by this device should not contain any metallic
components. Body-worn accessories that do not meet
these requirements may not comply with RF exposure
requirements and should be avoided. Use only the
supplied or an approved antenna.
26
Loading...
