NSVS1154 Nov. 2004
JRC SAW FILTER
NSVS1154
Application
315MHz R.K.E.
Electrical Specification: (Table 1)
The device characteristics are measured in the circuit shown in Fig.1.
Table 1. Electrical Specifications
Item |
|
Spec. |
Typ. |
|
Input and Output Impedance |
|
50Ω |
- |
|
Nominal Center Frequency (f0) |
315MHz |
- |
||
Insertion Loss |
|
314.5~315.5MHz |
3.0dB max. |
2.0dB |
Response Variation |
|
314.5~315.5MHz |
1.5dB max. |
0.8dB |
Input and Output VSWR |
|
314.5~315.5MHz |
2.5 max. |
1.8 |
Out of Band Rejection |
|
293.6 MHz |
50dB min. |
60dB |
(Relative to Through Level) |
|
336.4 MHz |
40dB min. |
45dB |
(Operating Temperature Range: -40~+85ºC)
Maximum Rating: (Table 2)
Table 2. Maximum Ratings
Item |
Rating |
Maximum Input Power |
+20dBm |
Maximum DC Voltage |
7.5V |
Operating Temperature Range |
-40~+85ºC |
Storage Temperature |
-45~+90ºC |
Mechanical Specifications: (Fig.2)
Package is designed as small as 3.0x3.0x1.15[mm3] for SMD (Surface Mount Device) type.
Notice:
This part is electrostatic discharge sensitive and may be damaged by improper handling.
Communications Equipment Division
Communications Equipment Marketing Department
10-1, Nishi-Shinjuku 6-chome, Shinjuku-ku,
Tokyo, 160-8328 Japan
Tel. +81 3-3348-3845
Fax. +81 3-3348-3935 http://www.jrc.co.jp/jp/product/device/saw/index.html (Japanese) http://www.jrc.co.jp/eng/product/saw/index.html(English)
NSVS1154 Nov. 2004
|
IN |
1 |
6 |
OUT |
|
50Ω |
50Ω |
||
|
2 SAW5 |
|||
|
|
|
||
|
|
3 |
4 |
|
|
|
Fig.1 Measuring circuit |
|
|
(a) |
|
3. 0±0. 15 |
( b) |
|
1 5 |
420 |
|
|
|
0.± |
|
|
|
( c) |
3. 0 |
WN (1) |
|||
|
( 2) |
|
|
|
1. 1 5 ± 0. 1 5 |
|
|
|
|
|
( 0. 6) |
5) |
|
|
|
|
( 0. 2 |
|
|
3 |
|
|
4 |
|
|
|
|
( 0. 6) |
[ 2 x] |
2 |
|
|
5 |
|
|
( 1. 80) |
|
|
|
1 |
|
|
6 |
|
|
( 0. 45) |
( 0. 75) |
5 3) |
4 x] |
|
|
[4x] |
||
|
|
0. |
[ |
|
|
|
|
||
|
|
|
( |
|
Fig.2 Package dimensions (in mm)
3.8
|
0.93 |
|
|
2.2 |
1.15 |
3.8 |
0.6 |
|
|
1.15 |
|
|
0.93 |
|
Fig.3 Desirable land area (in mm)
Marking
(1)Lot Number
(a)Year
(b)Month
|
|
*Oct.--- |
X |
|
|
Nov.--- |
Y |
|
|
Dec.--- |
Z |
|
(c) Date |
|
|
|
1-9--- |
0 |
|
|
10-19--- |
1 |
|
|
20-31--- |
2 |
|
(2) Part Number Mark |
|
||
|
|
|
|
Pin no. |
|
Connection |
|
1 |
|
GND |
|
2 |
|
IN/OUT |
|
3 |
|
GND |
|
4 |
|
GND |
|
5 |
|
OUT/IN |
|
6 |
|
GND |
|
