JRC NSVA528 User Manual

NSVA528 Nov. 2004
JRC SAW FILTER
NSVA528
Application
Cordless telephone
Electrical Specification: (Table 1) The device characteristics are measured in the circuit shown in Fig.1.
Table 1. Electrical Specifications Item Spec. Typ. Spec. Typ. Input and Output Impedance 50 Nominal Center Frequency (f0) Insertion Loss f0±1.2MHz Response Variation f0±1.2MHz Input and Output VSWR f0±1.2MHz Out of Band Rejection
(Relative to Through Level)
0.3~860.1MHz 927MHz
970~1500MHz
0.3~884.1MHz 903MHz
990~1500MHz
903MHz - 927MHz -
3.5dB max. 2.4dB 3.5dB max. 2.1dB
1.5dB max. 0.5dB 1.5dB max. 0.2dB
2.5 max. 2.2 2.5dB max. 1.9 40dB min. 48dB 35dB min. 36dB 40dB min. 43dB
- -
- -
- -
-
50
- -
- -
- -
40dB min. 48dB 35dB min. 49dB 40dB min. 45dB
-
(Operating Temperature Range: -10~+60ºC)
Maximum Rating: (Table 2)
Table 2. Maximum Ratings Item Rating Maximum Input Power +20dBm Maximum DC Voltage 7.5V Operating Temperature Range -10~+60ºC Storage Temperature -20~+70ºC
3
] for SMD (Surface Mount Device) type.
Notice: This part is electrostatic discharge sensitive and may be damaged by improper handling.
Communications Equipment Marketing Department
http://www.jrc.co.jp/jp/product/device/saw/index.html (Japanese)
http://www.jrc.co.jp/eng/product/saw/index .html (English)
Communications Equipment Division
10-1,Nishi-Shinjuku 6-chome,Shinjuku-ku,
Tokyo. 160-8328 Japan
Tel. +81 3-3348-3845
Fax. +81 3-3348-3935
NSVA528 Nov. 2004
IN 50
IN 50
8
1 2
SAW
3
7 6
5
4
OUT 50
OUT 50
(a)
(1)
Fig.1 Measuring circuit
3.5±0.2
3.5±0.2
J17
(b)
(2)
RT
(3)
(2.54)
1.0±0.2
3
2
(0.95)
(0.6)
4
(0.8)
[5x]
5
6
(1.27)
1
[2x ]
(1.0)
Fig.2 Package dimensions (in mm)
1.3 [6x]
8
4.3
0.8
7
Marking (1) Manufacture’s Mark (2) Lot Number (a) Year (b) Month *Oct.--- X Nov.--- Y
[8x ]
Dec.--- Z
(0.6)
(3) Part number Mark
Pin no. Connection
1 IN1(903MHz) 2 GND 3 IN2(927MHz) 4 GND 5 OUT2(927MHz) 6 GND 7 OUT1(903MHz) 8 GND
0.8
[6x]
1.27
4.3
Via-Hole(Φ0.3)
1.27
Fig.3 Desirable land area (in mm)
