Page 1
INSTRUCTION MANUAL
11’X13’ Joyside Gazebo with Netting
Series E02
IF YOU PURCHASED THE GAZEBO ONLINE AND HAVE ANY
QUESTIONS OR CONCERNS
PLEASE CONTACT US WITH EMAIL
Page 2
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble or install the product.
When installing and assembling the item, it is recommended two or more adults are involved.
This product is intended for outdoor use only and should be placed on flat, horizontal ground.
Do not use the unit during an electrical storm, as there is a remote chance of getting struck by lightning.
Do not climb on top of the item. Falling off it can result in serious injury, possibly even death.
Do not use open-flame appliances or accessories near the gazebo
This package contains small items and plastic bags that should be kept away from children
Ensure all connectors and poles are firmly secured in position. It is important to do so before
use to avoid collapsing or damage to the item, which could result in injury
Center hook’s maximum weight capacity is 26 lbs
WARNING
Keep all flame and heat sources away from the tent fabric. This tent is made with fabric that meets CPAI-84
specifications for flame resistance. It is not fireproof. The fabric will burn if left in continuous contact with any
flame source. The application of any foreign substance to the tent fabric may render the flame-resistant
properties ineffective. Remove the roof canopy during severe weather conditions such as sustained strong winds,
hurricanes, tropical downpours and snow. The manufacturer or retailer is not liable for any loss of the product or
other items due to the failure to take down the item during any inclement weather. It is critical to secure
assembled gazebo to the ground with provided stakes or bolt it down to the patio/deck with 16 appropriate
bolts/screws (not included). Make sure you have required hardware prior the assembly.
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list
and hardware contents list. If any part is missing or damaged, do not attempt to assemble the product. Please,
write down the list of damaged/missing part names. If you purchased the item online, you have 30 days to
communicate any issue to the seller. Make sure you contact seller directly not the marketplace. Replacement
parts will be provided free of cost. If you discovered an issue past 30 days of delivery or purchased an item at a
brick and mortar store, please contact us with email [email protected].
TOOLS NEEDED (NOT INCLUDED)
Page 3
EXPLODED DRAWING
A1
A2
E
B1
B2
C1
C2
D1
D2
D3
F
H
H1
L
M
N
O
No.
DESCRIPTION
Draft
QTY
EXTRA
AA
M6x20 Bolt
32
2
BB
Washer
60
3
CC
M6x30 Bolt
12
1
DD
Nut
8
1
EE
M6x35 Bolt
8
1
Z
Wrench
2
0
FF
Stake
16
0
GG
Plastic Ring
48
3
HARDWARE CONTENTS
Page 4
PACKAGE CONTENTS
No.
DESCRIPTION
Draft
QTY
A1
Small corner panel
4
A2
big corner panel
4
B1
Long side long beam
2
B2
Long side short beam
2
C1
Short side long beam
2
C2
Short side short beam
2
D1
short center beam
2
D2
long middle beam upper tube
2
D3
long middle beam under tube
2
E
corner Connector
4
F
regulating tube
4
H
Oblique Beam upper tube
4
H1
Oblique Beam under tube
4
K
Big Roof Connector
1
L
Hook
1
M
Big Canopy
1
N
Small Canopy
1
O
Mosquito netting
1
Page 5
CCX12
BBX20
AAX8
EX4
AA
BB
E
X4
CC
BB
A1
A2
A2X4
A1X4
Page 6
B2
B1
X2
C2
C1
X2
X4
B1
C1
B2
C2
AA
BB
BBX8
AAX8
B1X2 B2X2
C1X2 C2X2
Page 7
4x
2x
AA
BB
2x
BBX16
AAX16
B1
B2
C1
C2
A1
A2
A2
A1
B1
B2
C1
C2
Page 8
EEX4
BBX8
KX1
HX4
H1X4
DDX4
DD
BB
EE
BB
X4
K
H1
H
X4
H
H1
Page 9
BBX8
DDX4
D1X2
D3X2
MX1
AA
BB
BB
DD
D1
3
D3
D1
D3
D2
D3
D2
1
L
D1
2
D2
M
LX1
D2X2
EEX4
Page 10
FX4 NX1
N
H
F
X4
Page 11
M
OX1
O
GGx48
GG
M
O
Page 12
FF
X4
OX 1
FFX16
