JoyLite
JoyLite
Manual for App
JoyLite
Overview
JoyLite is a app that remotely controls the smart camera
via a mobile phone. It can be remotely view the camera
live screen, video screenshots, two-way talk, video
playback, infrared night vision and other functions. It
supports for motion detection, SD card playback,you
can also share your wonderful moments to your friends
and family.
JoyLite
108mm
114mm
JoyLite
Parameter
Model
QC21
Lens
355°
Video Compression
H2.64@20fps
Resolution
2.0MP
Video Format
FHD:1920 x1080
HD :1080 x720
Night Vision
10M
Wireless
IEEE802.11b/g/n
Wi-Fi Connect
RJ-45 & WIFI
Electrical Ratings
5V/2A
Temperature Ratings
-10℃~50℃
Storage Humidity
80%RH
Alarm
Support phone push
Extensible Space
Micro SD card ,up to 64G
JoyLite
Installation
Before using app to add your camera ,please
connect your camera’s hardware .
1、Connect the power adaptor to your camera and plug it
into the power outlet.
2、Connect your camera to your router’s Ethernet LAN
port using an Ethernet cable or using Wi - Fi .
3、Please let the phone and the camera connected to the
same wifi during the bind process.（5Ghz currently not
supported）.
JoyLite
Download
Scan QR Code and download JoyLite .
IOS : Search‘JoyLite’ in app store and download it.
Android: Search‘JoyLite’in Google Play and download it.
JoyLite
Indicator introduction
(1) The yellow light always on means the power
connection；
(2) The yellow light blinking means that it’s in
configuration state;
(3) The blue light always on means that it's in normal
operating state.
(4) The blue light blinking means that someone is
viewing live.
JoyLite
Bind
Open JoyLite, click the "+" button in the top right
corner of the home page,and add the camera according
to the page and voice prompts.
Click the home page message
reminder then you can receive
the mobile alert
notification。
Share
Video
playback
JoyLite
Tips
1、If the scan-box shows black when scanning QR code
at the bottom of the camera , please go to the phone
settings and open ‘access to camera’ permission.
2 、 After sending sound waves, if you hear 'tok
tok’prompt tone means connection to Wi-Fi is
successful, the yellow light blinking turn to a blue light,
then click next. You can also add a camera by QR code
JoyLite
Functions
1、The phone can be bundled with multiple cameras for
remote control.
2、Open Camera APP ,you can Screenshots, switching
clarity, full-screen viewing ，infrared night vision,
leave-home alert mode, on /off, PTZ control。
3、PTZ control
The Pan/Tilt control area allows you to control the
cruise of the Pan/Tilt of your ip camera through
directional arrow button .
4、SD card video playback is presented in timeline, if
there is no file playback, please check whether to insert
the specified SD card. （Format your SD card and insert
FAT32 format SD card into SD card slot. ）
5、You can store videos and screenshots in local records.
6、App and firmware versions will continue to update, to
provide customers with quality experience.
JoyLite
Help
Click Settings—Help,and check the FQA。
JoyLite
Camera installation
Install on wall
Install on ceiling
JoyLite
Cautions
1
Please turn off this product in a place that
explicitly prohibits the use of electronic devices,to
avoid electromagnetic interference, including but
not limited to airplane,hospital.
2
Do not use the product in the wet, dusty, high
temperature, thunderstorm or near fire , magnetic
field environment , to avoid causing product
failure, fire or explosion.
3
Do not put camera and accessories in places where
children can touch them to avoid danger.
JoyLite
Warranty Policy
1 Within 7 days of purchase，you can refund
according to the invoice price or replace the same
product if the product quality problems；
2
Within 15 days of purchase, you can replace the
same product if the product quality problems；
3
Within 12 months of purchase，we will provide
you with warranty service if the product quality
problems
JoyLite
Non-Warranty Policy
1 Out of warranty expires；
2
The breakdown caused by the usage , maintain or
the customer inappropriate preservation that hasn’t
follow the requests of the Manual，the damage
caused by the dismantle movement of a
non-our-company authorized maintainer;
3 Damage caused by force majeure；
4
The normal decoloring and wear of the product are
not covered by the warranty.
RF Exposure: A distance of 20 cm shall be maintained
between the antenna and users, and the transmitter
may not be co-located with any other transmitter or
antenna.
