Joy-it RB-LCD20x4 User guide
3
LCD Display 20x4 with Buttons
Ausgabe 10.11.2017 Copyright by Joy-IT 1
3
Index
1. Connecng the Display
2. Installing the System
3. Usage & Example-Code
4. Support
LCD Display 20x4 with Buttons
Ausgabe 10.11.2017 Copyright by Joy-IT 2
LCD Display 20x4 with Buttons
3
Dear customer
thank you for purchasing our product.
Please nd our instrucons below.
1. Connecting the Display
Plug the display onto the pin header of your Raspberry Pi so that the display is placed over your
Raspberry Pi.
As soon as you power your Raspberry Pi, the displays backlight should start to light.
Ausgabe 10.11.2017 Copyright by Joy-IT 3
