JOY-IT POSTEP60-256 User guide
Version: 25/6/2016
User manual
PoStep60 user manual
2
www.poscope.com
Please read the following notes
1. All information included in this document is current as of the date this document is issued. Such information, however,
is subject to change without any prior notice.
2. PoLabs does not assume any liability for infringement of patents, copyrights, or other intellectual property rights of
third parties by or arising from the use of PoLabs products or technical information described in this document. No
license, express, implied or otherwise, is granted hereby under any patents, copyrights or other intellectual property
rights of PoLabs or others. PoLabs claims the copyright of, and retains the rights to, all material (software, documents,
etc.) contained in this release. You may copy and distribute the entire release in its original state, but must not copy
individual items within the release other than for backup purposes.
3. Descriptions of circuits, software and other related information in this document are provided only to illustrate the
operation of the products and application examples. You are fully responsible for the incorporation of these circuits,
software, and information in the design of your equipment. PoLabs assumes no responsibility for any losses incurred by
you or third parties arising from the use of these circuits, software, or information.
4. PoLabs has used reasonable care in preparing the information included in this document, but PoLabs does not warrant
that such information is error free. PoLabs assumes no liability whatsoever for any damages incurred by you resulting
from errors in or omissions from the information included herein.
5. PoLabs devices may be used in equipment that does not impose a threat to human life in case of the malfunctioning,
such as: computer interfaces, office equipment, communications equipment, test and measurement equipment, audio
and visual equipment, home electronic appliances, machine tools, personal electronic equipment, and industrial robots.
6. Measures such as fail-safe function and redundant design should be taken to ensure reliability and safety when PoLabs
devices are used for or in connection with equipment that requires higher reliability, for example: traffic control
systems, anti-disaster systems, anticrime systems, safety equipment, medical equipment not specifically designed for
life support, and other similar applications.
7. PoLabs devices shall not be used for or in connection with equipment that requires an extremely high level of reliability
and safety, as for example: aircraft systems, aerospace equipment, nuclear reactor control systems, medical equipment
or systems for life support (e.g. artificial life support devices or systems), and any other applications or purposes that
pose a direct threat to human life.
8. You should use the PoLabs products described in this document within the range specified by PoLabs, especially with
respect to the maximum rating, operating supply voltage range and other product characteristics. PoLabs shall have no
liability for malfunctions or damages arising out of the use of PoLabs products beyond such specified ranges.
9. Although PoLabs endeavors to improve the quality and reliability of its products, semiconductor products have specific
characteristics such as the occurrence of failure at a certain rate and malfunctions under certain use conditions.
Further, PoLabs products are not subject to radiation resistance design. Please be sure to implement safety measures
to guard them against the possibility of physical injury, and injury or damage caused by fire in the event of the failure of
a PoLabs product, such as safety design for hardware and software including but not limited to redundancy, fire control
and malfunction prevention, appropriate treatment for aging degradation or any other appropriate measures.
10. Usage: the software in this release is for use only with PoLabs products or with data collected using PoLabs products.
11. Fitness for purpose: no two applications are the same, so PoLabs cannot guarantee that its equipment or software is
suitable for a given application. It is therefore the user's responsibility to ensure that the product is suitable for the
user's application.
12. Viruses: this software was continuously monitored for viruses during production, however the user is responsible for
virus checking the software once it is installed.
13. Upgrades: we provide upgrades, free of charge, from our web site at www.poscope.com. We reserve the right to charge
for updates or replacements sent out on physical media.
14. Please contact a PoLabs support for details as to environmental matters such as the environmental compatibility of
each PoLabs product. Please use PoLabs products in compliance with all applicable laws and regulations that regulate
the inclusion or use of controlled substances, including without limitation, the EU RoHS Directive. PoLabs assumes no
liability for damages or losses occurring as a result of your noncompliance with applicable laws and regulations.
15. Please contact a PoLabs support at support@poscope.com if you have any questions regarding the information
contained in this document or PoLabs products, or if you have any other inquiries.
16. The licensee agrees to allow access to this software only to persons who have been informed of and agree to abide by
these conditions.
17. Trademarks: Windows is a registered trademark of Microsoft Corporation. PoKeys, PoKeys55, PoKeys56U, PoKeys56E,
PoScope, PoLabs and others are internationally registered trademarks.
PoStep60 user manual
3
www.poscope.com
Contents
1 Introduction ..................................................................................................................................... 6
1.1 General symbols for this instructions ...................................................................................... 6
2 Description ...................................................................................................................................... 6
3 PoStep60 features ........................................................................................................................... 6
4 Connection diagram ........................................................................................................................ 7
4.1 Board use requirements .......................................................................................................... 7
4.2 Connection and setting ........................................................................................................... 7
4.3 PoStep pinout .......................................................................................................................... 8
4.4 Stepper motor connection ...................................................................................................... 8
4.4.1 10 pin IDC connector pinout............................................................................................ 8
4.4.2 Stepper motor connections ............................................................................................. 9
4.5 DC motor connection ............................................................................................................ 11
4.5.1 6 pin PWM connector pinout ........................................................................................ 11
4.5.2 DC motor connection .................................................................................................... 11
4.6 PoStep LEDs ........................................................................................................................... 12
4.6.1 Status LED ...................................................................................................................... 12
4.7 Requirements ........................................................................................................................ 12
5 Installation ..................................................................................................................................... 13
6 Technical specifications ................................................................................................................. 13
6.1 Electrical specification – limiting values ................................................................................ 13
6.2 Electrical specification – static characteristic ........................................................................ 13
7 User application............................................................................................................................. 14
7.1 PoStep60 main application GUI ............................................................................................. 14
7.1.1 PoStep driver status ...................................................................................................... 15
7.2 Basic user control of the PoStep driver ................................................................................. 16
7.3 Advanced settings ................................................................................................................. 18
7.4 Step control ........................................................................................................................... 19
7.5 Auto control ........................................................................................................................... 19
7.5.1 Position control mode ................................................................................................... 19
7.5.2 BINx Up/down mode ..................................................................................................... 21
7.5.3 Speed / Auto run mode ................................................................................................. 21
7.6 DC motor control ................................................................................................................... 22
7.7 Log charts .............................................................................................................................. 23
7.8 Firmware update ................................................................................................................... 24
7.9 Major changes in application version 0.61 ............................................................................ 24
7.9.1 Major changes from 0.57 to 0.58: ................................................................................. 24
7.9.2 Major changes from 0.53 to 0.57: ................................................................................. 24
8 PoStep60 I2C protocol specification ............................................................................................. 25
PoStep60 user manual
4
www.poscope.com
8.1 I2C address ............................................................................................................................ 25
8.2 PoStep60 I2C protocol ........................................................................................................... 25
8.2.1 Master write .................................................................................................................. 25
8.2.2 Master read ................................................................................................................... 26
8.3 PoStep60 I2C commands ....................................................................................................... 26
8.3.1 0x01 - Loopback read .................................................................................................... 26
8.3.2 0x03 – Set Run/Sleep mode .......................................................................................... 26
8.3.3 0x0A – Read HW/FW info .............................................................................................. 27
8.3.4 0x10 – Read voltage ...................................................................................................... 27
8.3.5 0x11 – Read temperature .............................................................................................. 27
8.3.6 0x12 – Read pin statuses ............................................................................................... 27
8.3.7 0x13 – Read driver status .............................................................................................. 27
8.3.8 0x14 – Read driver mode .............................................................................................. 28
8.3.9 0x20 – Read full scale current ....................................................................................... 28
8.3.10 0x21 – Read idle current ................................................................................................ 28
8.3.11 0x22 – Read overheat current ....................................................................................... 28
8.3.12 0x23 – Read step mode ................................................................................................. 28
8.3.13 0x24 – Read temperature limit ..................................................................................... 29
8.3.14 0x25 – Read faults ......................................................................................................... 29
8.3.15 0x30 – Set full scale current .......................................................................................... 29
8.3.16 0x31 – Set idle current ................................................................................................... 29
8.3.17 0x32 – Set overheat current .......................................................................................... 30
8.3.18 0x33 – Set step mode .................................................................................................... 30
8.3.19 0x34 – Set temperature limit ........................................................................................ 30
8.3.20 0x35 – Reset faults ........................................................................................................ 30
8.3.21 0x3F – Write settings to EEPROM ................................................................................. 30
8.3.22 0x40 – Read position ..................................................................................................... 30
8.3.23 0x41 – Read maximal speed .......................................................................................... 30
8.3.24 0x42 – Read acceleration .............................................................................................. 30
8.3.25 0x43 – Read deceleration .............................................................................................. 31
8.3.26 0x50 – Set position ........................................................................................................ 31
8.3.27 0x51 – Set maximal speed ............................................................................................. 31
8.3.28 0x52 – Set acceleration ................................................................................................. 31
8.3.29 0x53 – Set deceleration ................................................................................................. 31
8.3.30 0x5E – Set zero .............................................................................................................. 32
8.3.31 0x5F – Stop .................................................................................................................... 32
9 Errata information ......................................................................................................................... 33
10 User manual changes ................................................................................................................ 33
11 Grant of license ......................................................................................................................... 34
11.1.1 Access ............................................................................................................................ 34
11.1.2 Usage ............................................................................................................................. 34
11.1.3 Copyright ....................................................................................................................... 34
PoStep60 user manual
5
www.poscope.com
11.1.4 Liability .......................................................................................................................... 34
11.1.5 Fitness for purpose ........................................................................................................ 34
11.1.6 Mission Critical applications .......................................................................................... 34
11.1.7 Viruses ........................................................................................................................... 34
11.1.8 Support .......................................................................................................................... 34
11.1.9 Upgrades ....................................................................................................................... 34
11.1.10 Trademarks ................................................................................................................ 34
PoStep60 user manual
6
www.poscope.com
NOTE!
Tells you other important information.
CAUTION!
Tells you something that could be considered to reduce a risk of failure or
malfunction.
WARNING!
Tells you something that could cause damage to a property.
1 Introduction
This manual contains information required to configure over an USB and run the PoStep60 driver.
Please read the manual carefully to avoid damage to the driver. This section covers the instrument
general description, instrument specifications and characteristics.
1.1 General symbols for this instructions
A few symbols are used throughout this manual that you should be aware of in order to complete
certain tasks safely and completely. These symbols have different degrees of importance as
described below:
2 Description
The PoStep60 driver incorporate advanced stepper motor controller and external N-channel
MOSFETs to drive a bipolar stepper motor or two brushed DC motors. A micro-stepping indexer is
integrated, which is capable of step modes from full step to 1/256-step. An ultra-smooth motion
profile can be achieved using adaptive blanking time and various current decay modes, including an
auto-mixed decay mode. A simple step/direction or PWM interface allows easy interfacing to
controller circuits. An I2C serial interface can further be used to control all the driver functions
including position control on board. All running parameters (output current (torque), micro stepping,
step mode, decay mode...) can be set over USB and stored on board for standalone operation.
Internal shutdown functions are provided for over current protection, short circuit protection, under
voltage lockout and over temperature. Fault conditions are indicated via a FAULT LED, and each fault
condition can be read in configuration software.
3 PoStep60 features
up to 6,0 Amps Phase Current
advanced settings available through USB connection
compatible with 4, 6, and 8 wire stepper motors of any voltage
+10 VDC to +50 VDC Power Supply
up to 256 Micro-steps per Step
various modes of decay mode for smoother moving of motors
3,3V and 5V logic compatible inputs
250 kHz Max Step Rate
Advanced “Auto-run” modes
0 °C To 85 °C Operating Temperature
LED Power and Status Indicator
Small Size: 54 mm X 75 mm
PoStep60 user manual
7
www.poscope.com
CAUTION!
Please make sure bipolar stepper motor is connected before applying power.
WARNING!
Please make sure power input polarity is correct. Double check before powering up
the driver. Reverse power input polarity results in permanent device failure.
7: Status LEDs
1: USB connector
2. 10 pin IDC connector
3: PoExtension connector
4: Power input
6: PWM inputs
5: Motor outputs
4 Connection diagram
4.1 Board use requirements
To properly operate the PoStep60 driver using external controller following connections need to be
setup: step, direction and enable inputs; 10-50 VDC power supply, connected bipolar stepper motor
before applying power.
4.2 Connection and setting
1. Mount PoStep60 driver firmly to a stable surface. If PoStep60 is mounted to a conductive
(metal) surface, please make sure the driver is properly isolated.
2. Connect USB cable (1) to your PC and run PoStep user application
3. Please setup running parameters (output current (torque), micro stepping, step mode, decay
mode...) using PoStep user application.
4. Connect step, direction, enable and GND from PoStep60 (2) to controller or BOB
5. Connect steeper motor (5) using one of wiring options bellow(
6. Connect power supply (4)
Figure 1: PoStep connections
PoStep60 user manual
8
www.poscope.com
Pin
Function
1
Enable (inverted, 0=enable, 1=disable)
3
Direction
5
Step
7
Fault feedback (OC, 1=driver OK, 0=fault
detected)*
9
+5V external supply voltage
2, 4, 6, 8, 10
GND
NOTE!
Please note some of the drivers are showing failed Under Voltage Lockout (UVLO)
fault status when disabled and supply voltage within required limits. The fault is
removed after driver is enabled and supply voltage within limits.
4.3 PoStep pinout
4.4 Stepper motor connection
4.4.1 10 pin IDC connector pinout
*Fault feedback signal is an open-colector signal. External pull-up resistor is needed to function
properly (please see Figure 2). For input and open-collector output limiting values please refer to
Section 6 - Technical specifications.
Figure 2: Fault feedback pin connection diagram
PoStep60 user manual
9
www.poscope.com
CAUTION!
To avoid malfunctions please make sure the phase winds are connected correctly.
Resistance between leads of different phases is usually > 100kΩ. Resistance between
leads of the same phase is usually < 100Ω.
NOTE!
Simple method of finding correct pairs of each winding wires is as follows (before
proceeding none of the motor wires should be connected): take two random wires
and short circuit them. Try rotating the stepper axis. If the pair is matching the
resistance while trying to rotate the motor is much higher comparing to when none
of the wires is short circuited.
NOTE!
On the motor connector on the PoStep board there is a shield pin available (in the
middle). Please use proper shielding techniques for best performance.
type A
type B
type C
type D
type E
4.4.2 Stepper motor connections
The drive will work with 4-wire, 6-wire or 8-wire stepper motors.
Figure 3: Stepper motor wiring options
4.4.2.1 4-wire motors (type A)
are truly bipolar, and can only be run as such.
4.4.2.2 6-wire motors
can be wired two ways to work with the bipolar drive.
The first is half-winding (type B): In this method, one end wire, and the center-tap wire of the phase
is used. The other end is insulated and left unused. This method uses unipolar nameplate current
specifications, and will produce nameplate torque.
The second is series winding (type C): In this configuration, the center-tap is insulated, and unused.
This method uses all of the wiring per phase, but has double the number of wire turns as halfwinding
or unipolar mode. Because of this, the amperage requirement becomes half the nameplate rating.
Because the wire in the coil can handle more current than ‘half’, motor manufacturers will often
“boost” the torque rating by specifying currents up to 71% of unipolar rated current while running in
series mode. This is fine for FULL step motor drives, but not necessarily so good for microstepping
drives. Using this much can smear microstepping smoothness and accuracy. Any extra torque
achieved by this method will generally be lost to machine vibrations due to loss of microstepping
smoothness. The best performance will be somewhere between the 50% and 71% current rating.
PoStep60 user manual
10
www.poscope.com
The advantage of using series winding is that lower power drives may be used. For example a
unipolar motor rated for 4.0A/phase running in series requires only 2.0A/phase to achieve the same
torque. The disadvantage of this method is that it raises motor inductance, which in turn, slows
motor coil charging time. Since proper torque is reached only when the coil has charged to the
required level, the longer it takes to charge, the longer until full torque is achieved. This leads to
slower full torque stepping rates. Conversely, a half-winding configuration requires full nameplate
rated current, but if the drive is capable of this, the advantage is that rated torque can be achieved
twice as fast as series winding (using the same voltage, when comparing half-winding and series).
4.4.2.3 8-wire motors
can be run in paralell (type E) or serial (type D) mode. Parallel mode needs higher current, has lower
inductance and better torque, Serial mode needs lower current and has lower torque. Please read
also 6-wire motors.
PoStep60 user manual
11
www.poscope.com
Pin
Function
1
End Switch
2
PWM BIN2
3
PWM BIN1
4
PWM AIN2 (inverted)
5
PWM AIN1 (inverted)
6
GND
NOTE!
PWM AIN1 and PWM AIN2 inputs are inverted.
CAUTION!
Please make sure driver is configured to support DC motor drive. If not the DC motor
can randomly rotate in speed and direction due to active micro stepping indexer.
NOTE!
Full-scale current value still applys when in DC drive mode. Idle current is not
applicable and is not being used.
2 4 6
1 3 5
4.5 DC motor connection
4.5.1 6 pin PWM connector pinout
All PWM connector input pins has on board pull-up resistors. The pins can be either open-collector
toward GND or push-pull driven. For input limiting values please refer to Section 6 - Technical
specifications.
4.5.2 DC motor connection
The PoStep driver can be configured to enable direct control the state of the output drivers. This
allows for driving up to two brushed DC motors. First DC motor is connected to terminals A1 and A2
and second DC motor to terminals B1 and B2. Speed and direction of DC motor rotation is controlled
by PWM AINx and PWM BINx for first and second motor respectively. Driver allows connection of
only one DC motor on A or B terminals as well as two DC motors.
Figure 4: Connection of up to 2 DC motors
