TEC226x-4(+PIR) and TEC220x-4(+PIR) Series
TEC22xx-4+PIR Series
L
ONWORKS Network
Staged Thermostat Controller
Code No. LIT-1900631
Issued February 8, 2010
LONW
ORKS
® Network Staged Thermostat Controllers
Description
The TEC226x-4(+PIR) Series Programmable
and TEC220x-4(+PIR) Series
Non-Programmable L
Configurable Staged Thermostat Controllers
provide control of rooftop units (with and
without economizers), heat pumps, and
single- and multi-stage heating/cooling
equipment. The TEC226x-4+PIR and
TEC220x-4+PIR Series Thermostat
Controllers have occupancy sensing capability
built into the device. These devices provide
energy savings in high-energy usage light
commercial buildings such as schools and
hotels. The devices maximize these energy
savings by using additional setpoint strategies
during occupied times.
The technologically advanced
TEC226x-4(+PIR) and TEC220x-4(+PIR)
Series Thermostat Controllers feature a
Building Automation System (BAS)
ONWORKS Network communication capability
L
that enables remote monitoring and
programming for efficient space temperature
control.
The TEC226x-4(+PIR) and TEC220x-4(+PIR)
Series Thermostat Controllers use an intuitive,
plain text, menu-driven, backlit display that
makes setup and operation quick and easy.
The TEC220x-4+PIR and TEC226x-4+PIR
Series includes four models, each include the
option of a PIR occupancy sensing cover:
• Single-stage (TEC22x1-4 and
TEC22x1-4+PIR)
• Heat Pump (TEC22x2-4 and
TEC22x2-4+PIR)
• Multi-stage (TEC22x3-4 and
TEC22x3-4+PIR)
• Economizer (TEC22x4-4 and
TEC22x4-4+PIR)
All thermostat controllers use a unique,
Proportional-Integral (PI) time-proportioning
control algorithm that virtually eliminates
temperature offset associated with traditional
differential-based thermostat controllers
ONWORKS® Network
Refer to the TEC226x-4(+PIR) and
TEC220x-4(+PIR) Series L
Thermostat Controllers Product Bulletin
(LIT-12011606) for important product
application information.
ONWORKS Network
Features
•LONWORKS network communication —
provides compatibility with a proven
communication network; L
Network is widely accepted by Heating,
Ventilating, and Air Conditioning (HVAC)
control suppliers
• onboard occupancy sensor (Passive
Infrared [PIR] models) — provides energy
savings without additional installation time
and cost
• password protection option — protects
against unwanted thermostat controller
tampering
• backlit Liquid Crystal Display (LCD) —
offers real-time control status of the
environment in easy-to-read, English text
messages with constant backlight that
brightens during user interaction
• simplified setpoint adjustment — enables
the user to change the setpoint by simply
pressing the UP/DOWN arrow keys
• five easy-to-use interface keys — allow for
easy commissioning of the thermostat, and
eliminate the need for DIP switches
• two configurable digital inputs — provide
additional inputs for advanced functions
such as remote night setback, occupancy
override, and service or filter alarms
• over 20 configurable parameters — enable
the thermostat to adapt to any application,
allowing installer parameter access without
opening the thermostat cover
• optional discharge air sensor — monitors
unit efficiency
• economizer output (TEC22x4-4 and
TEC22x4-4+PIR models) — provides
control of economizer operation for singleand multi-stage unitary rooftop equipment
ONWORKS
• configurable auxiliary output — provides
24 VAC control for lighting, exhaust fans,
and other auxiliary functions
Repair Information
If a TEC226x-4(+PIR) or TEC220x-4(+PIR)
Series Thermostat Controller fails to operate
within its specifications, replace the unit. For a
replacement thermostat controller, contact the
nearest Johnson Controls® representative.
Selection Chart
LONWORKS Network Configurable Staged Thermostat Controller Models (Part 1 of 2)
Code Number Description Programmable Applications
TEC2261-4 Single-Stage Yes Unit Heaters and Single-Stage Packaged Heating/Cooling
TEC2201-4 No
TEC2261-4+PIR Single-Stage with Onboard Occupancy
TEC2201-4+PIR No
TEC2262-4 Heat Pump Yes Heat Pumps with up to 3 Heating/2 Cooling Stages
TEC2202-4 No
TEC2262-4+PIR Heat Pump with Onboard Occupancy Sensor Yes
TEC2202-4+PIR No
The performance specifications are nomina l and conf orm to accep table industr y standar ds. For ap plications a t condition s beyond th ese specification s, consult the local Johnson Controls o ffice.
Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. © 2012 Johnson Controls, Inc.
Equipment
Yes
Sensor
www.johnsoncontrols.com
1 of 3
TEC226x-4(+PIR) and TEC220x-4(+PIR) Series LONWORKS® Network Staged Thermostat
Dimensions, in. (mm) (TEC22xx-4 and TEC22xx-4+PIR Model Shown)
4-15/16
(125)
3-3/8
(86)
1-1/8
(29)
(125)
(86)
(36)
70.0ºF
Room Temp
Room Temp
Controllers (Continued)
LONWORKS Network Configurable Staged Thermostat Controller Models (Part 2 of 2)
Code Number Description Programmable Applications
TEC2263-4 Multi-Stage Yes Multi-Staged Packaged Heating/Cooling Equipment
TEC2203-4 No
TEC2263-4+PIR Multi-Stage with Onboard Occupancy Sensor Yes
TEC2203-4+PIR No
TEC2264-4 Multi-Stage, Economizer Yes Economizer Operation for Single- and Multi-Stage Unitary
TEC2204-4 No
TEC2264-4+PIR Multi-Stage, Economizer with Onboard
TEC2204-4+PIR No
Occupancy Sensor
Yes
Accessories
Code Number Description
SEN-600-1 Remote Indoor Air Temperature Sensor
SEN-600-4 Remote Indoor Air Temperature Sensor with Occupancy Override and LED
TE-6361M-1
TE-636S-1
TE-6363P-1
TEC-3-PIR
1. Additional TE-636xx-x Series 10k Type II Thermistor Sensors are available; refer to the TE-6300 Series Temperature Sensors Product Bulletin (LIT-216320) for
2. The TEC-3-PIR Accessory Cover can be used to replace the existing cover on a non-PIR TEC22xx-4 Staged Thermostat Controller to provide occupancy
1
1
1
2
more details.
sensing capability.
Duct Mount Air Temperature Sensor
Strap-Mount Temperatu re Sensor
Outdoor Air Temperature Sensor
Cover with Occupancy Sensor
Rooftop Equipment
4-15/16
70.0ºF
3-3/8
1-3/8
FIG:dmnsns_tec22xx
The performance specifications are nomina l and conf orm to accep table industr y standar ds. For ap plications a t condition s beyond th ese specification s, consult the local Johnson Controls o ffice.
Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. © 2012 Johnson Controls, Inc.
2 of 3
www.johnsoncontrols.com
TEC226x-4(+PIR) and TEC220x-4(+PIR) Series LONWORKS® Network Staged Thermostat
Controllers (Continued)
Technical Specifications
TEC226x-4(+PIR) and TEC220x-4(+PIR) Series LONWORKS Network Staged Thermostat Controllers
Power Requirements 19 to 30 VAC, 50/60 Hz, 2 VA (Terminals RC and C) at 24 VAC nominal, Class 2 or Saf ety Extra -Low Voltage
Relay Contact Rating 19 to 30 VAC, 1.0 A Maximum, 15 mA Minimum, 3. 0 A In-Rush, Class 2 or SELV
Analog Inputs Resistive Inputs (RS and UI3) for 10k ohm Johnson Controls Type II Negative Temperatu re Coefficien t (NTC)
Digital Inputs Voltage-Free Cont acts across Terminal C to Terminals DI1 and DI2
Economizer Output
(TEC22x4-4 and
TEC22x4-4+PIR
Models)
Wire Size Unshielded Twisted Pair - 22 AWG (0.6 mm Diameter) Minimum, 18 AWG (1.0 mm Diameter) Recommended
Temperature Sensor Type Local 10k ohm Type II NTC Thermistor
ONWORKS Network Standard 64 Devices Maximum without repeater, 128 Devices Maximum with repeater; 6,250 ft (1,905 m) Maximum
L
Temperature Range Backlit Display -40.0°F/-40.0°C to 122.0°F/50.0°C in 0.5° Increments
Accuracy Temperature ±0.9F°/±0.5C° at 70.0°F/21.0°C Ty pical Calibrated
Minimum Deadband 2F°/1C° between Heating and Cooling
Ambient Conditions Operating 32 to 122°F (0 to 50°C); 95% RH Maximum, Noncondensing
Compliance United States UL Listed, File E27734, CCN XAPX,
Shipping Weight TEC226x-4 and TEC220x-4 Models: 0.75 lb (0.34 kg)
Rating 0 to 10 VDC into 2k ohm resistance minimum
Accuracy ±3%
Heating Control 40.0°F/4.5°C to 90.0°F/32.0°C
Cooling Control 54.0°F/12.0°C to 100.0°F/38.0°C
Storage -22 to 122°F (-30 to 50°C); 95% RH Maximum, Noncondensing
Canada UL Listed, File E27734, CCN XAPX7,
Europe CE Mark, EMC Directive 2004/108/EC
Australia and New
Zealand
(SELV)
Thermistor Sensors
Length (Bus Topology)
Under UL 873, Temperature Indicating and Regulating Equipment
FCC Compliant to CFR 47, Part 15, Subpart B, Class A
ONMARK® Certification 3.4
L
Under CAN/CSA C22.2 No. 24, Temperature Indicating and Regulating Equipment
Industry Canada, ICES-003
EN 61000-6-1 and EN 61000-6-3
C-Tick Mark, Australia/NZ Emissions Compliant
TEC226x-4+PIR and TEC220x-4+PIR Models: 0.77 lb (0.35 kg)
The performance specifications are nomina l and conf orm to accep table industr y standar ds. For ap plications a t condition s beyond th ese specification s, consult the local Johnson Controls o ffice.
Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. © 2012 Johnson Controls, Inc.
www.johnsoncontrols.com
3 of 3
