Johnson Controls TEC210x-4 Series, TEC210x-4+PIR Series Catalog Page

TEC210x-4 and TEC210x-4+PIR Series

TEC210x-4+PIR Series Networked

Thermostat Controller

N2 Networked Thermostat Controllers

Code No. LIT-1900626 Issued February 8, 2010

Description

The TEC210x-4 and TEC210x-4+PIR Series Thermostat Controllers are N2 networked devices that provide control of rooftop units (with and without economizers), heat pumps, and single- and multi-stage heating/cooling equipment. The TEC210x-4+PIR Series Thermostat Controllers have occupancy sensing capability built into the device. These devices provide energy savings in high-energy usage light commercial buildings such as schools and hotels. The devices maximize these energy savings by using additional setpoint strategies during occupied times.

The TEC210x-4 and TEC210x-4+PIR Series Thermostat Controllers feature Building Automation System (BAS) N2 Bus communication capability that enables remote monitoring and programming for efficient space temperature control.

The TEC210x-4 and TEC210x-4+PIR Thermostat Controllers use an intuitive, plain text, menu-driven, backlit display that makes setup and operation quick and easy.

The TEC210x-4(+PIR) Series includes four models, each include the option of a PIR occupancy sensing cover:

• Single-stage (TEC2101-4 and TEC2101-4+PIR)

• Heat Pump (TEC2102-4 and TEC2102-4+PIR)

• Multi-stage (TEC2103-4 and TEC2103-4+PIR)

• Economizer (TEC2104-4 and TEC2104-4+PIR).

All thermostat controllers use a unique Proportional-Integral (PI) time-proportioning control algorithm that virtually eliminates temperature offset associated with traditional differential-based thermostat controllers.

Refer to the TEC210x-4 and TEC210x-4+PIR

Series N2 Networked Thermostat Controllers Product Bulletin (LIT-12011600) for important

product application information.

Features

• BAS N2 open communication — provides compatibility with a proven communication network; N2 Bus is widely accepted by Heating, Ventilating, and Air Conditioning (HVAC) control suppliers.

• onboard occupancy sensor (Passive Infrared [PIR] models) — provides energy savings without additional installation time and cost

• password protection option — protects against unwanted thermostat controller tampering

• backlit Liquid Crystal Display (LCD) — offers real-time control status of the environment in easy-to-read, English text messages with constant backlight that brightens during user interaction

• simplified setpoint adjustment — enables the user to change the setpoint by simply pressing the UP/DOWN arrow keys

• five easy-to-use interface keys — allow for easy commissioning of the thermostat, and eliminate the need for DIP switches

• two configurable digital inputs — provide additional inputs for advanced functions such as remote night setback, occupancy override, and service or filter alarms

• over 20 configurable parameters — enable the thermostat to adapt to any application, allowing installer parameter access without opening the thermostat cover

• optional discharge air sensor — monitors unit efficiency

• economizer output (TEC2104-4 and TEC2104-4+PIR models) — provides control of economizer operation for singleand multi-stage unitary rooftop equipment

• configurable auxiliary output — provides 24 VAC control for lighting, exhaust fans, and other auxiliary functions

Repair Information

If a TEC210x-4 or TEC210x-4+PIR Series Thermostat Controller fails to operate within its specifications, replace the unit. For a replacement thermostat controller, contact the nearest Johnson Controls® representative.

Selection Charts

N2 Networked Thermostat Controller Models

Code Number Description Applications

TEC2101-4 Single-Stage Unit Heaters and Single-Stage Packaged Heating/Cooling Equipment TEC2101-4+PIR Single-Stage with Onboard Occupancy Sensor TEC2102-4 Heat Pump Heat Pumps with up to 3 Heating/2 Cooling Stages TEC2102-4+PIR Heat Pump with Onboard Occupancy Sensor TEC2103-4 Multi-Stage Multi-Staged Packaged Heating/Cooling Equipment TEC2103-4+PIR Multi-Stage with Onboard Occupancy Sensor TEC2104-4 Multi-Stage, Economizer Economizer Operation for Single- and Multi-Stage Unitary Rooftop Equipment TEC2104-4+PIR Multi-Stage, Economizer with Onboard

The performance specifications are nomina l and conf orm to accep table industr y standar ds. For ap plications a t condition s beyond th ese specification s, consult the local Johnson Controls o ffice. Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. © 2012 Johnson Controls, Inc.

Occupancy Sensor

www.johnsoncontrols.com

1 of 3

TEC210x-4 and TEC210x-4+PIR Series N2 Networked Thermostat Controllers

4-15/16

(125)

3-3/8

(86)

1-1/8

(29)

(125)

(86)

(36)

70.0ºF

Room Temp

Dimensions, in. (mm) (TEC210x-4 and TEC210x-4+PIR Models Shown)

(Continued)

Accessories

Code Number Description

SEN-600-1 Remote Indoor Temperature Sensor SEN-600-4 Remote Indoor Temperature Sensor with Occupancy Override Button and LED

TE-6361M-1 TE-636S-1 TE-6363P-1 TEC-3-PIR

1. Additional TE-636xx-x Series 10k ohm Johnson Controls® Type II Thermistor Sensors are available; refer to the TE-6300 Series Temperature Sensors Product

2. The TEC-3-PIR Accessory Cover can replace the existing cover on a non-PIR TEC210x-4 Series Thermostat Controller to provide occupancy sensing.

Bulletin (LIT-216320) for more details.

Duct Mount Air Temperature Sensor Strap-Mount Temperature Sensor Outdoor Air Temperature Sensor Cover with Occupancy Sensor

4-15/16

70.0ºF

3-3/8

1-3/8

FIG:dmnsns_tec210x

Technical Specifications

TEC210x-4 and TEC210x-4+PIR Series N2 Networked Thermostat Controllers (Part 1 of 2)

Power Requirements 19 to 30 VAC, 50/60 Hz, 2 VA (Terminals RC and C) at 24 VAC nominal, Class 2 or Safety Ext ra-

Relay Contact Rating 19 to 30 VAC, 1.0 A Maximum, 15 mA Minimum, 3.0 A In-Rush, Class 2 or SELV Analog Inputs Resistive Inputs (RS and UI3) for 10k ohm Johnson Controls Type II Negative Temperature

Digital Inputs Voltage-Free Contacts across Terminal C to Terminals DI1 and DI2 Economizer Output Rating (TEC2104-4

and TEC2104-4+PIR Models) Wire Size 18 AWG (1.0 mm Diameter) Maximum, 22 AWG (0.6 mm Diameter) Recommended

Temperature Sensor Type Local 10k ohm Type II Negative Temperature Coefficient (NTC) Thermistor Temperature Range Backlit Display -40.0°F/-40.0°C to 122.0°F/50.0°C in 0.5° Increments

Accuracy Temperature ±0.9F°/±0.5C° at 70.0°F/21.0°C Typical Calibrated Minimum Deadband 2F°/1C° between Heating and Cooling Ambient Conditions Operating 32 to 122°F (0 to 50°C); 95% RH Maximum, Noncondensing

Rating 0 to 10 VDC into 2k ohm resistance minimum Accuracy ±3%

Heating Control 40.0°F/4.5°C to 90.0°F/32.0°C Cooling Control 54.0°F/12.0°C to 100.0°F/38.0°C

Storage -22 to 122°F (-30 to 50°C); 95% RH Maximum, Noncondensing

Low Voltage (SELV)

Coefficient (NTC) Thermistor Sensors

2 of 3

www.johnsoncontrols.com
