Code No. LIT-1900624
TEC Wireless Thermostat Controllers and TEC20 Coordinator
with Direct-Mount Antenna and Remote Mount Antenna
Issued July 13, 2010
TEC20xx-4 and TEC20xx-4+PIR Series
Wireless Thermostat Controller System for Fan Coil and Zoning
Equipment
Description
The TEC20xx-4 and TEC20xx-4+PIR Series Wireless Thermostat
Controller System provides wireless networked control of Heating,
Ventilating, and Air Conditioning (HVAC) equipment on a Building
Automation System (BAS) that enables remote monitoring and
programming. This system integrates into a supervisory controller that
uses BACnet® Internet Protocol (IP) or BACnet Master-Slave/
Token-Passing (MS/TP) communications.
The TEC20xx-4+PIR Series Wireless Thermostat Controllers have
occupancy sensing capability built into the device. These devices
provide energy savings in high-energy usage light commercial
buildings such as schools and hotels. The devices maximize these
energy savings by using additional setpoint strategies during occupied
times.
TEC20 Coordinators allow the supervisory controller to communicate
with multiple TEC20xx-4 and TEC20xx-4+PIR Series Wireless
Thermostat Controllers:
• TEC2045-4 Wireless Thermostat Controllers control two-pipe fan
coils, cabinet unit heaters, or other equipment using a proportional
0 to 10 VDC control input and one-speed fan control.
• TEC20x6(H)-4 and TEC20x6H-4+PIR Series Wireless
Thermostat Controllers control two- or four-pipe fan coils, cabinet
unit heaters, or other equipment using on/off, floating, or
proportional 0 to 10 VDC control input, three speeds of fan control,
dehumidification capability, and occupancy sensing capability.
• TEC20x7-4 Series Wireless Thermostat Controllers control local
hydronic reheat valves, pressure dependent Variable Air Volume
(VAV) equipment with or without local reheat, or other zoning
equipment using an on/off, floating, or proportional 0 to 10 VDC
control input.
The wireless mesh network uses ZigBee™ technology to enable
remote monitoring and programming and to enhance reliability by
providing redundant transmission paths through other TEC20xx-4 and
TEC20xx-4+PIR Series Wireless Thermostat Controllers, creating a
resilient, self-healing mesh network.
Refer to TEC20xx-4 and TEC20xx-4+PIR Series Wireless Thermostat
Controller System for Fan Coil and Zoning Equipment Product Bulletin
(LIT-12011593) for important product application information.
Features
• wireless communication — allows BAS communications capability
in applications where field bus wiring within the building is prohibitive
• onboard occupancy sensor (Passive Infrared [PIR] Models) —
provides energy savings without additional installation time and cost
• password protection option — protects against unwanted
thermostat controller tampering
• integral humidity sensing capability (dehumidification models) —
increases occupancy comfort by providing dehumidification
• on/off, floating, or proportional 0 to 10 VDC control — offers
additional application flexibility by providing more advanced control
signals
• three speeds of fan control (model dependent) — provide easy FAN
speed selection via the interface key, to meet the application
requirements
• integral wireless signal strength testing built into wireless thermostat
controllers and coordinators — provides quick, easy, visual
indication of the wireless Radio Frequency (RF) signal strength
between a sensor and associated receiver, helps locate optimum
device positions during installation, and aids troubleshooting your
applications
• single/dual setpoint adjustment — enables user setpoint options to
accommodate application
• backlit Liquid Crystal Display (LCD) — offers real-time control status
of the environment in easy-to-read, English text messages with
constant backlight that brightens during user interaction
• two configurable binary inputs — provide additional inputs for
advanced functions such as remote night setback, service or filter
alarms, motion detector, and window status
• over 20 configurable parameters — enable the TEC20xx-4 or
TEC20xx-4+PIR Series Wireless Thermostat Controller to adapt to
any application, allowing installer parameter access without opening
the cover
• optional discharge air sensor — monitors unit efficiency
Applications
The TEC20xx-4 and TEC20xx-4+PIR Series Wireless Thermostat
Controller System is ideal for any location where it is cost-prohibitive,
difficult, or aesthetically unappealing to hardwire between BACnet
devices, including supervisory controllers (such as NCE25 or
NAE35/45/55 engines) and thermostat controllers. Examples of these
locations include the following:
• commercial structures with brick or solid concrete walls and/or
ceilings that impede hard-wired TEC20xx-4 and TEC20xx-4+PIR
Series Thermostat Controller applications
• office buildings, retail stores, and other commercial real estate
where tenant turnover is frequent
• museums, historical buildings, atriums, and other sites where
building aesthetics and historical preservation are important
• buildings with marble, granite, glass, mirrored, wood veneer, or
other decorative surfaces that present challenges to hard-wired
applications
• buildings with asbestos or other hazardous materials that must not
be penetrated or disturbed
• buildings with occupants sensitive to disruptions to business
Locations or applications that prohibit cellular telephones or Wireless
Fidelity (WiFi) systems are unsuitable for the TEC20xx-4 and
TEC20xx-4+PIR Series Wireless Thermostat Controller System:
• operating rooms or radiation therapy rooms
• validated environments
• UL864 applications
Repair Information
If a TEC20xx-4 or TEC20xx-4+PIR Series Wireless Thermostat
Controller System fails to operate within its specifications, replace the
unit. For a replacement, contact the nearest Johnson Controls®
representative.
The performance specifications are nomina l and conf orm to accep table industr y standar ds. For ap plications a t condition s beyond th ese specification s, consult the local Johnson Controls o ffice.
Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. © 2012 Johnson Controls, Inc.
www.johnsoncontrols.com
1 of 4
TEC20xx-4 and TEC20xx-4+PIR Series Wireless Thermostat Controller System for Fan
Coil and Zoning Equipment (Continued)
Selection Charts
TEC20xx-4 and TEC20xx-4+PIR Thermostat Controller Models
Code Number Control Outputs Speeds of Fan
Control
TEC2016-4 Two On/Off 3 No Commercial 1
TEC2016H-4 Two On/Off 3 No Hospitality 1
TEC2016H-4+PIR
TEC2026-4 Two On/Off or Floating 3 No Commercial 1
TEC2026H-4 Two On/Off or Floating 3 No Hospitality 1
TEC2026H-4+PIR
TEC2027-4 Two On/Off or Floating 0 No Commercial 2
TEC2036-4 Two On/Off or Floating 3 Yes Commercial 1
TEC2036H-4 Two On/Off or Floating 3 Yes Hospitality 1
TEC2036H-4+PIR
TEC2045-4 One Proportional 0 to 10 VDC 1 No Commercial 3
TEC2046-4 Two Proportional 0 to 10 VDC 3 No Commercial 1
TEC2046H-4 Two Proportional 0 to 10 VDC 3 No Hospitality 1
TEC2046H-4+PIR
TEC2047-4 Two Proportional 0 to 10 VDC 0 No Commercial 2
TEC2056-4 Two Proportional 0 to 10 VDC 3 Yes Commercial 1
TEC2056H-4 Two Proportional 0 to 10 VDC 3 Yes Hospitality 1
TEC2056H-4+PIR
Application Categories
1. Two- or four-pipe fan coils, cabinet unit heaters, or other equipment using on/off, floating, or proporti onal 0 to 10 VDC control input, and three speeds of fan
control.
2. Local hydronic reheat valves, pressure dependent Variable Air Volume(VAV) equipment with or without loca l r eheat, or other zoning equipment using an
on/off, floating, or proportional 0to 10VDC control input.
3. Two-pipe fan coils, cabinet unit heaters, or other equipment using a proportional 0 to 10 VDC control input and one-speed fan control.
1. Includes onboard occupancy sensor.
1
1
1
1
1
Two On/Off 3 No Hospitality 1
Two On/Off or Floating 3 No Hospitality 1
Two On/Off or Floating 3 Yes Hospitality 1
Two Proportional 0 to 10 VDC 3 No Hospitality 1
Two Proportional 0 to 10 VDC 3 Yes Hospitality 1
TEC20 Coordinator Ordering Information
Code Number Description
TEC20-3C-2 BACnet IP Wireless Coordinator; Requires 15 VDC Power Supply
TEC20-6C-2 BACnet MS/TP Wireless Coordinator; Requires 15 VDC Power Supply
TEC Wireless Accessories (Order Separately)
Code Number Description
SEN-600-1 Remote Indoor Air Temperature Sensor
SEN-600-4 Remote Indoor Air Temperature Sensor with Occupancy Override and LED
TE-636S-1 Strap-Mount Temperature Sensor
TE-6361M-1
TEC20-A-1 Replacement antenna for TEC20 Coordinator
TEC20-RA-1 Remote antenna for TEC20 Coordinator when it is installed inside a metal cabinet or when remote ant enna mounting is required by
NPB-PWR
TEC20-8X-1 120 VAC to 15 VDC Power Supply for TEC20 Coordinator
TEC20-9B-1 Replacement Battery Pack for TEC20 Coordinator
TEC-6-PIR
TEC-6H-PIR
TEC-7-PIR
1. Additional TE-636xx-x Series 10k ohm Johnson Controls Type II Thermistor Sensors are available; refer to the TE-6300 Series Temperature Sensors Product
2. DIN Rail: Type NS35/7.5 (35 x 7.5 mm) and DIN rail end clips. Length of DIN rail depends on the number of DIN rail mounted options.
3. The TEC-6-PIR Accessory Cover can be used to replace the existing cover on a non-PIR TEC20x6-4 Series Wireless Thermostat Controller to provide
4. The TEC-6H-PIR Accessory Cover can be used to replace the existing cover on a non-PIR TEC20x6H-4 Series Wireless Thermostat Controller to provide
5. The TEC-7-PIR Accessory Cover can be used to replace the existing cover on a non-PIR TEC20x7-4 Series Wireless Thermostat Controller to provide
1
2
3
4
5
Bulletin (LIT-216320) for more details.
occupancy sensing capability.
occupancy sensing capability.
occupancy sensing capability.
Duct Mount Air Temperature Sensor
physical installation
DIN Rail Mount 24 VAC/DC Power Module for TEC20 Coordinator
Commercial Fan Coil Cover with Occupancy Sensor
Hospitality Fan Coil Controller Cover with Occupancy Sensor
Zone Controller Cover with Occupancy Sensor
Dehumidification
Capability
Market Application
Category
The performance specifications are nomina l and conf orm to accep table industr y standar ds. For ap plications a t condition s beyond th ese specification s, consult the local Johnson Controls o ffice.
Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. © 2012 Johnson Controls, Inc.
www.johnsoncontrols.com
2 of 4
TEC20xx-4 and TEC20xx-4+PIR Series Wireless Thermostat Controller System for Fan
Coil and Zoning Equipment (Continued)
Technical Specifications
TEC20 Wireless Coordinator
Product Code Numbers TEC20-3C-2: BACnet IP version
Power Requirements 15 VDC, 6 W maximum
Platform IBM
Operating System Niagra
Communications Ethernet: Two 10/100 Mbps Ports (RJ-45 Connection)
Transmission Range Through Walls: 10 m (30 ft)
RF Band Direct-Sequence Spread-Spectrum Transmission; 2.4 Ghz unlicensed band
Transmission Power 10 mW Maximum
Wire Size 18 AWG Maximum, 22 AWG Recommended
Ambient Conditions Op erati ng: 0 to 50°C (32 to 122°F); 95% RH Maximum, Noncondensing
Compliance United States:
Dimensions (H x W x D) 122.4 x 160.4 x 61.9 mm (4.820 x 6.313 x 2.438 in.)
Shipping Weight 0.499 kg (1.1 lb)
TEC20xx-4 and TEC20xx-4+PIR Wireless Thermostat Controllers for Fan Coil and Zoning Equipment Control (Part 1 of 2)
Power Requirements 19 to 30 VAC, 50/60 Hz, 2 VA (Terminals 4 and 5) at 24 VAC Nominal, Class 2 or Safety Extra-Low Voltage (SELV)
Analog Output Rating Proportional Control (TEC204x-4 and TEC205x-4) Models
Fan Relay Output Rating TEC2045-4, TEC20x6(H)-4, TEC20x6H-4+PIR Models: 19 to 30 VAC, 1.0 A Maximum, 15 mA Minimum,
Relay/Triac Contact Rating On/Off and Floating Control
Auxiliary Output Rating Triac Output: 19 to 30 VAC, 1.0 A Maximum, 15 mA Minimum, 3.0 A In-Rush
Binary Inputs Voltage-Free Contacts across Terminal Scom to Terminals BI1, BI2, or UI3
Transmission Range Through Walls: 10 m (30 ft)
RF Band Direct-Sequence Spread-Spectrum Transmission; 2.4 Ghz unlicensed band
Transmission Power 10 mW Maximum
Wire Size 18 AWG Maximum, 22 AWG Recommended
Temperature Sensor Type Local 10k ohm Negative Temperature Coefficient (NTC) Thermistor
Resolution ±0.1C°/±0.2F°
Accuracy Temperature: ±0.5C°/±0.9F° at 21.0°C/70.0°F Ty pical Calibrated
Temperature Range Backlit Display: -40.0°C/-40.0°F to 5 0.0°C/122.0°F
Minimum Deadband 1C°/2F° between Heating and Cooling
Ambient Conditions Operating: 0 to 50°C (32 to 122°F); 95% RH Maximum, Noncondensing
TEC20-6C-2: BACnet MS/TP version
® PowerPC 405EP 250 MHz Processor
64 MB SDRAM and 64 MB Serial Flash
Battery Backup - shutdown begins within 10 seconds
Real-time clock - 3 month backup maximum with battery
AX
RS-232: 9-Pin D-Shell Connection
RS-485: 3-Pin Non-Isolated Port
Line-of-Sight (Open Space): 30 m (100 ft)
Storage: -20 to 60°C (-4 to 140°F); 95% RH Maximum, Noncondensing
UL Listed, File E27734, CCN XAPX, Under UL 873, Temperature Indicating and Regulating Equipment
FCC Compliant to CFR 47, Part 15, Subpart B and Part 15 Class A
(Other compliance information pending)
Canada:
C-UL Listed, File E207782, CCN XAPX7, UnderCAN/CSA C22.2No. 24,Temperature Indicating and
Regulating Equipment, and C22.2 No. 205-M1983 Signal Equipment
Industry Canada, ICES-003
(Other compliance information pending)
0 to 10 VDC into 2k ohm Resistance (Minimum)
3.0 A In-Rush
(TEC201x[H]-4, TEC201xH-4+PIR, TEC202x[H]-4, TEC202xH-4+PIR, TEC203x[H]-4, TEC203xH-4+PIR
Models): 19 to 30 VAC, 1.0 A Maximu m, 15 mA Minimum,
3.0 A In-Rush, Class 2 or SELV
Line-of-Sight (Open Space): 30 m (100 ft)
Humidity (TEC2036[H]-2 or TEC2056[H]-2Models): ±5% RH from 20 to 80% RH at 10 to 32°C (50 to 90°F)
Heating Control: 40.0°F/4.5°C to 32.0°C/ 90.0°F in 0.5° Increments
Cooling Control: 54.0°F/12.0°C to 38.0°C/100.0°F in 0.5° Increments
Storage: -30 to 50°C (-22 to 122°F); 95% RH Maximum, Noncondensing
The performance specifications are nomina l and conf orm to accep table industr y standar ds. For ap plications a t condition s beyond th ese specification s, consult the local Johnson Controls o ffice.
Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. © 2012 Johnson Controls, Inc.
www.johnsoncontrols.com
3 of 4
TEC20xx-4 and TEC20xx-4+PIR Series Wireless Thermostat Controller System for Fan
Coil and Zoning Equipment (Continued)
TEC20xx-4 and TEC20xx-4+PIR Wireless Thermostat Controllers for Fan Coil and Zoning Equipment Control (Part 2 of 2)
Compliance (Pending) United States:
Dimensions (H x W x D) TEC20xx(H)-4 Models: 125 x 86 x 29 mm (4-15/16 x 3-3/8 x 1-1/8 in.)
Shipping Weight TEC20xx(H)-4 Models: 0.75 lb (0.34 kg)
UL Listed, File E27734, CCN XAPX, Under UL 873, Temperature Indicating and Regulating Equipment
FCC Compliant to Part 15.247 Regulations for Low Power Unlicensed Transmitters
(Other compliance information pending)
Canada:
UL Listed, File E27734, CCN XAPX7, Under CSA C22.2 No.24, Temperature Indicating and Regulating Equipment
Industry Canada, ICES-003
(Other compliance information pending)
TEC20xx-4+PIR Models: 125 x 86 x 36 mm (4-15/16 x 3-3/8 x 1-3/8 in.)
TEC20xx-4+PIR Models: 0.77 lb (0.35 kg)
The performance specifications are nomina l and conf orm to accep table industr y standar ds. For ap plications a t condition s beyond th ese specification s, consult the local Johnson Controls o ffice.
Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. © 2012 Johnson Controls, Inc.
www.johnsoncontrols.com
4 of 4
Loading...
