P1000 Series Pressure-Independent
Valve Assembly
P1000 Series Pressure-Independent Valves
Description
P1000 Series Pressure-Independent Valves
are designed to regulate the flow of hot or
chilled water and 60% glycol solutions in
response to the demand of a controller in
HVAC systems. The pressure-independent
valves eliminate the need for separate
balancing valves. These valves are available
in sizes 1/2 through 2 in. (DN15 through
DN50) with factory-mounted
Johnson Controls® VA2104 and
VA2120 Series Non-Spring-Return and
M2204 and M2215 Series Spring-Return
Electric Actuators for floating or proportional
control.
Refer to the P1000 Series
Pressure-Independent Valves Product
Bulletin (LIT-12011272) for important product
application information.
Features
• No Cv Calculation — simplifies valve
selection.
• Automatic System Balancing — prevents
overflow or underflow to maximize system
performance.
• Combined Control and Balancing Valve —
reduces installation time and cost.
Selection Charts
Two-Way Non-Spring Return (Part 1 of 2)
Valve Code
Valves
Number
Actuators
Pressure-Independent
Threaded Ball Valves and
P1241A00 1/2 0.5 200 P1241A00+21LAGA P1241A00+21LHGA
P1241A01 1 P1241A01+21LAGA P1241A01+21LHGA
P1241A02 2 P1241A02+21LAGA P1241A02+21LHGA
P1241A03 3 P1241A03+21LAGA P1241A03+21LHGA
P1241A04 4 P1241A04+21LAGA P1241A04+21LHGA
P1241A05 5 P1241A05+21LAGA P1241A05+21LHGA
P1241B06 3/4 6 200 P1241B06+21LAGA P1241B06+21LHGA
P1241B07 7 P1241B07+21LAGA P1241B07+21LHGA
P1241B08 8 P1241B08+21LAGA P1241B08+21LHGA
P1241B09 9 P1241B09+21LAGA P1241B09+21LHGA
P1241B10 10 P1241B10+21LAGA P1241B10+21LHGA
Pressure-Independent Valves
• 600 psi Static Pressure Rating for 1/2
through 1 in. Valves and 400 psi Static
Pressure Rating for 1-1/4 through 2 in.
Valves — allow use of valve in a wide
range of systems.
• 200 psi Closeoff Pressure Rating —
provides tight shutoff in high-pressure
systems.
• 5 to 50 psi Operating Differential Pressure
Rating — allows use of valve in a wide
range of systems.
• Availability of Factory-Mounted VA2104,
VA2120, VA2202, M2204, or
M2215 Series Electric Actuators —
reduces installation time, thus reducing
overall installation cost.
• Maintenance-Free Design — eliminates
need for periodic rebuilding and
rebalancing of the system, with no
packings to adjust.
• American National Standards Institute
(ANSI) Class IV Leakage and ±5% Flow
Accuracy — reduces energy costs and
provides superior room comfort.
Size, in. Flow Rate, gpm Closeoff psig 24 VAC Supply
Floating DC 0 to 10 V Proportional
VA2104-AGA-2 VA2104-HGA-2
1.5 P1241A01521LAGA P1241A01521LHGA
2.5 P1241A02521LAGA P1241A02521LHGA
3.5 P1241A03521LAGA P1241A03521LHGA
4.5 P1241A04521LAGA P1241A04521LHGA
5.5 P1241A05521LAGA P1241A05521LHGA
6.5 P1241B06521LAGA P1241B06521LHGA
7.5 P1241B07521LAGA P1241B07521LHGA
8.5 P1241B08521LAGA P1241B08521LHGA
9.5 P1241B09521LAGA P1241B09521LHGA
Code No. LIT-1900445
Repair Information
If the P1000 Series Pressure-Independent
Valve fails to operate within its specifications,
replace the valve body, actuator, or entire
assembly. For replacement parts, contact the
nearest Johnson Controls representative.
The performance specifications are nomina l and con form to accep table ind ustry stand ards. For applicati ons at con ditions be yond these specification s, consult th
Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. © 2014 Johnson Controls, Inc.
V–302
Pressure-Independent Valves
P1000 Series Pressure-Independent Valves (Continued)
Two-Way Non-Spring Return (Part 2 of 2)
Valve Code
Number
P1241C11 1 11 200 P1241C11+21LAGA P1241C11+21LHGA
P1241C12 12 P1241C12+21LAGA P1241C12+21LHGA
P1241C13 13 P1241C13+21LAGA P1241C13+21LHGA
P1241C14 14 P1241C14+21LAGA P1241C14+21LHGA
P1241C15 15 P1241C15+21LAGA P1241C15+21LHGA
P1241C16 16 P1241C16+21LAGA P1241C16+21LHGA
P1241C17 17 P1241C17+21LAGA P1241C17+21LHGA
P1241C18 18 P1241C18+21LAGA P1241C18+21LHGA
P1241C19 19 P1241C19+21LAGA P1241C19+21LHGA
P1241D18 1-1/4 18 200 P1241D18+21AHGA
P1241D19 19 P1241D19+21AHGA
P1241D20 20 P1241D20+21AHGA
P1241D21 21 P1241D21+21AHGA
P1241D22 22 P1241D22+21AHGA
P1241D23 23 P1241D23+21AHGA
P1241D24 24 P1241D24+21AHGA
P1241D25 25 P1241D25+21AHGA
P1241D26 26 P1241D26+21AHGA
P1241E26 1-1/2 26 200 P1241E26+21AHGA
P1241E27 27 P1241E27+21AHGA
P1241E28 28 P1241E28+21AHGA
P1241E29 29 P1241E29+21AHGA
P1241E30 30 P1241E30+21AHGA
P1241E31 31 P1241E31+21AHGA
P1241E32 32 P1241E32+21AHGA
P1241E33 33 P1241E33+21AHGA
P1241F33 2 33 200 P1241F33+21AHGA
P1241F34 34 P1241F34+21AHGA
P1241F35 35 P1241F35+21AHGA
P1241F36 36 P1241F36+21AHGA
P1241F37 37 P1241F37+21AHGA
P1241F38 38 P1241F38+21AHGA
P1241F39 39 P1241F39+21AHGA
P1241F40 40 P1241F40+21AHGA
P1241F44 44 P1241F44+21AHGA
P1241F48 48 P1241F48+21AHGA
P1241F52 52 P1241F52+21AHGA
P1241F56 56 P1241F56+21AHGA
P1241F60 60 P1241F60+21AHGA
P1241F65 65 P1241F65+21AHGA
P1241F70 70 P1241F70+21AHGA
P1241F75 75 P1241F75+21AHGA
P1241F80 80 P1241F80+21AHGA
P1241F90 90 P1241F90+21AHGA
P1241F100 100 P1241F10021AHGA
Size, in. Flow Rate, gpm Closeoff psig 24 VAC Supply
Floating DC 0 to 10 V Proportional
VA2104-AGA-2 VA2104-HGA-2
Valves
Valves
Actuators
Actuators
Pressure-Independent
Pressure-Independent
Threaded Ball Valves and
Threaded Ball Valves and
The performance specifications are no minal and co nform t o acceptab le ind ustry standar ds. For appl ications at condition s beyond these specifica tions, consult th
Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. © 2014 Johnson Controls, Inc.
V–303
P1000 Series Pressure-Independent Valves (Continued)
Two-Way Spring Return (Part 1 of 2)
Valve Code
Number
Assemblies with VA2202-HGA-2P Spring-Return Actuator
P1241A00 1/2 0.5 200 P1241A00+22THGA P1241A00+24THGA
P1241A01 1 P1241A01+22THGA P1241A01+24THGA
P1241A02 2 P1241A02+22THGA P1241A02+24THGA
P1241A03 3 P1241A03+22THGA P1241A03+24THGA
P1241A04 4 P1241A04+22THGA P1241A04+24THGA
P1241A05 5 P1241A05+22THGA P1241A05+24THGA
Assemblies with M2204-HGA-2 Spring-Return Actuator
P1241A00 1/2 0.5 200 P1241A00+22LHGA P1241A00+24LHGA
P1241A01 1 P1241A01+22LHGA P1241A01+24LHGA
P1241A02 2 P1241A02+22LHGA P1241A02+24LHGA
P1241A03 3 P1241A03+22LHGA P1241A03+24LHGA
P1241A04 4 P1241A04+22LHGA P1241A04+24LHGA
P1241A05 5 P1241A05+22LHGA P1241A05+24LHGA
P1241B06 3/4 6 200 P1241B06+22LHGA P1241B06+24LHGA
Valves
Actuators
P1241B07 7 P1241B07+22LHGA P1241B07+24LHGA
Pressure-Independent
Threaded Ball Valves and
P1241B08 8 P1241B08+22LHGA P1241B08+24LHGA
P1241B09 9 P1241B09+22LHGA P1241B09+24LHGA
P1241B10 10 P1241B10+22LHGA P1241B10+24LHGA
P1241C11 1 11 200 P1241C11+22LHGA P1241C11+24LHGA
P1241C12 12 P1241C12+22LHGA P1241C12+24LHGA
P1241C13 13 P1241C13+22LHGA P1241C13+24LHGA
P1241C14 14 P1241C14+22LHGA P1241C14+24LHGA
P1241C15 15 P1241C15+22LHGA P1241C15+24LHGA
P1241C16 16 P1241C16+22LHGA P1241C16+24LHGA
P1241C17 17 P1241C17+22LHGA P1241C17+24LHGA
P1241C18 18 P1241C18+22LHGA P1241C18+24LHGA
P1241C19 19 P1241C19+22LHGA P1241C19+24LHGA
Pressure-Independent Valves
1
Size, in. Flow Rate, gpm Closeoff psig 24 VAC Supply
DC 0 to 10 V Proportional
Spring Return Open Spring Return Closed
1.5 P1241A01522THGA P1241A01524THGA
2.5 P1241A02522THGA P1241A02524THGA
3.5 P1241A03522THGA P1241A03524THGA
4.5 P1241A04522THGA P1241A04524THGA
5.5 P1241A05522THGA P1241A05524THGA
1.5 P1241A01522LHGA P1241A01524LHGA
2.5 P1241A02522LHGA P1241A02524LHGA
3.5 P1241A03522LHGA P1241A03524LHGA
4.5 P1241A04522LHGA P1241A04524LHGA
5.5 P1241A05522LHGA P1241A05524LHGA
6.5 P1241B06522LHGA P1241B06524LHGA
7.5 P1241B07522LHGA P1241B07524LHGA
8.5 P1241B08522LHGA P1241B08524LHGA
9.5 P1241B09522LHGA P1241B09524LHGA
The performance specifications are no minal and co nform t o acceptab le ind ustry standar ds. For appl ications at condition s beyond these specifica tions, consult th
Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. © 2014 Johnson Controls, Inc.
V–304
Pressure-Independent Valves
P1000 Series Pressure-Independent Valves (Continued)
Two-Way Spring Return (Part 2 of 2)
Valve Code
Size, in. Flow Rate, gpm Closeoff psig 24 VAC Supply
Number
Assemblies with M2215-HGA-2 Spring-Return Actuator
P1241D18 1-1/4 18 200 P1241D18+22AHGA P1241D18+24AHGA
P1241D19 19 P1241D19+22AHGA P1241D19+24AHGA
P1241D20 20 P1241D20+22AHGA P1241D20+24AHGA
P1241D21 21 P1241D21+22AHGA P1241D21+24AHGA
P1241D22 22 P1241D22+22AHGA P1241D22+24AHGA
P1241D23 23 P1241D23+22AHGA P1241D23+24AHGA
P1241D24 24 P1241D24+22AHGA P1241D24+24AHGA
P1241D25 25 P1241D25+22AHGA P1241D25+24AHGA
P1241D26 26 P1241D26+22AHGA P1241D26+24AHGA
P1241E26 1-1/2 26 200 P1241E26+22AHGA P1241E26+24AHGA
P1241E27 27 P1241E27+22AHGA P1241E27+24AHGA
P1241E28 28 P1241E28+22AHGA P1241E28+24AHGA
P1241E29 29 P1241E29+22AHGA P1241E29+24AHGA
P1241E30 30 P1241E30+22AHGA P1241E30+24AHGA
P1241E31 31 P1241E31+22AHGA P1241E31+24AHGA
P1241E32 32 P1241E32+22AHGA P1241E32+24AHGA
P1241E33 33 P1241E33+22AHGA P1241E33+24AHGA
P1241F33 2 33 200 P1241F33+22AHGA P1241F33+24AHGA
P1241F34 34 P1241F34+22AHGA P1241F34+24AHGA
P1241F35 35 P1241F35+22AHGA P1241F35+24AHGA
P1241F36 36 P1241F36+22AHGA P1241F36+24AHGA
P1241F37 37 P1241F37+22AHGA P1241F37+24AHGA
P1241F38 38 P1241F38+22AHGA P1241F38+24AHGA
P1241F39 39 P1241F39+22AHGA P1241F39+24AHGA
P1241F40 40 P1241F40+22AHGA P1241F40+24AHGA
P1241F44 44 P1241F44+22AHGA P1241F44+24AHGA
P1241F48 48 P1241F48+22AHGA P1241F48+24AHGA
P1241F52 52 P1241F52+22AHGA P1241F52+24AHGA
P1241F56 56 P1241F56+22AHGA P1241F56+24AHGA
P1241F60 60 P1241F60+22AHGA P1241F60+24AHGA
P1241F65 65 P1241F65+22AHGA P1241F65+24AHGA
P1241F70 70 P1241F70+22AHGA P1241F70+24AHGA
P1241F75 75 P1241F75+22AHGA P1241F75+24AHGA
P1241F80 80 P1241F80+22AHGA P1241F80+24AHGA
P1241F90 90 P1241F90+22AHGA P1241F90+24AHGA
P1241F100 100 P1241F10022AHGA P1241F10024AHGA
1. All valves with proportional control actuators are shipped from the factory programmed with the valve fully closed at a 0 VDC input signal.
1
DC 0 to 10 V Proportional
Spring Return Open Spring Return Closed
Valves
Valves
Actuators
Actuators
Pressure-Independent
Pressure-Independent
Threaded Ball Valves and
Threaded Ball Valves and
The performance specifications are no minal and co nform t o acceptab le ind ustry standar ds. For appl ications at condition s beyond these specifica tions, consult th
Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. © 2014 Johnson Controls, Inc.
V–305
P1000 Series Pressure-Independent Valves (Continued)
Field Adjustable Flow Ranges and Runtime Data (Part 1 of 2)
Size, in. Valve Code Number Factory Flow Rate,
Without Pressure
Taps
1/2 P1241A00 0.5 0.5 to 1.0 36 100
P1241A01 1 0.5 to 1.0 60
P1241A015 1.5 0.5 to 5.5 47
P1241A02 2 0.5 to 5.5 51
P1241A025 2.5 0.5 to 5.5 53
P1241A03 3 0.5 to 5.5 56
P1241A035 3.5 0.5 to 5.5 58
P1241A04 4 0.5 to 5.5 63
P1241A045 4.5 0.5 to 5.5 66
P1241A05 5 0.5 to 5.5 68
P1241A055 5.5 0.5 to 5.5 73
3/4 P1241B06 6 2 to 10 61 100
P1241B065 6.5 2 to 10 62
P1241B07 7 2 to 10 64
P1241B075 7.5 2 to 10 66
P1241B08 8 2 to 10 67
P1241B085 8.5 2 to 10 68
P1241B09 9 2 to 10 69
P1241B095 9.5 2 to 10 71
P1241B10 10 2 to 10 76
1 P1241C11 11 2 to 16 60 100
P1241C12 12 2 to 16 62
Valves
Actuators
Pressure-Independent
Threaded Ball Valves and
1-1/4 P1241D18 18 100
1-1/2 P1241E26 26 100
P1241C13 13 2 to 16 64
P1241C14 14 2 to 16 67
P1241C15 15 2 to 16 69
P1241C16 16 2 to 16 86
P1241C17 17 6 to 19 65
P1241C18 18 6 to 19 67
P1241C19 19 6 to 19 78
P1241D19 19
P1241D20 20
P1241D21 21
P1241D22 22
P1241D23 23
P1241D24 24
P1241D25 25
P1241D26 26
P1241E27 27
P1241E28 28
P1241E29 29
P1241E30 30
P1241E31 31
P1241E32 32
P1241E33 33
gpm
Pressure-Independent Valves
Field Adjustable Flow
Range Using
FlowSetR
™
Base,
gpm
Running Time (Seconds)
VA2104-AGA-2 VA2104-HGA-2
VA2120-HGA-2
VA2202-HGA-2P
M2204-HGA-2
M2215-HGA-2
The performance specifications are no minal and co nform t o acceptab le ind ustry standar ds. For appl ications at condition s beyond these specifica tions, consult th
Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. © 2014 Johnson Controls, Inc.
V–306
Pressure-Independent Valves
P1000 Series Pressure-Independent Valves (Continued)
Field Adjustable Flow Ranges and Runtime Data (Part 2 of 2)
Size, in. Valve Code Number Factory Flow Rate,
Without Pressure
gpm
Taps
2 P1241F33 33 100
P1241F34 34
P1241F35 35
P1241F36 36
P1241F37 37
P1241F38 38
P1241F39 39
P1241F40 40
P1241F44 44
P1241F48 48
P1241F52 52
P1241F56 56
P1241F60 60
P1241F65 65
P1241F70 70
P1241F75 75
P1241F80 80
P1241F90 90
P1241F100 100
Field Adjustable Flow
Range Using
FlowSetR
™
Base,
gpm
Running Time (Seconds)
VA2104-AGA-2 VA2104-HGA-2
VA2120-HGA-2
VA2202-HGA-2P
M2204-HGA-2
M2215-HGA-2
Technical Specifications
P1000 Series Pressure-Independent Valves (Part 1 of 2)
1
Service
Valve Fluid Temperature Limits 0 to 212°F (-18 to 100°C)
Valve Body Pressure/Temperature Rating 600 psig (4,134 kPa) - Sizes 1/2, 3/4, and 1 in.
Maximum Closeoff Pressure 200 psi (1,378 kPa)
Recommended Minimum Differential Operating Pressure 5 psi (34 kPa)
Maximum Recommended Operating Pressure Drop 50 psi Maximum Differential Pressure
Flow Characteristics Equal Percentage
Flow Accuracy ±10% Combination of Manufacturing Tolerances and Pressure Variations
Valve Body Size/Flow Rate See Field Adjustable Flow Ranges and Runtime Data
Leakage 0.01% of Maximum Flow per ANSI/FCI 70-2, Class 4
End Connections National Pipe Thread (NPT)
Material Body Forged Brass, Nickel Plated
Ball Chrome-Plated Brass
Stem Chrome-Plated Brass
Seats Fiberglass Reinforced Teflon® Polytetrafluoroethylene (PTFE)
Characterizing Disk Tefzel®
Packing Two Ethylene Propylene Diene Monomer (EPDM) O-Rings
Diaphragm Polyester Reinforced Silicone
Regulator Stainless Steel/Brass/Delrin
Spring Stainless Steel
Power Requirements VA2104-AGA-2 AC 24 V ±20%, 50/60 Hz, DC 24 V ±10%, 3 VA Supply Class 2
VA2104-HGA-2 AC 24 V ±20%, 50/60 Hz, DC 24 V ±10%, 4 VA Supply Class 2
VA2120-HGA-2 AC 24 V ±20%, 50/60 Hz, DC 24 V ±10%, 5 VA Supply Class 2
VA2202-HGA-2P AC 24 V ±20%, 50/60 Hz, DC 24 V ±10%, 4 VA Supply Class 2
M2204-HGA-2 AC 24 V ±20%, 50/60 Hz, DC 24 V ±10%, 5 VA Supply Class 2
M2215-HGA-2 AC 24 V ±20%, 50/60 Hz, DC 24 V ±10%, 10 VA Supply Class 2
Hot or Chilled Water, and 60% Glycol Solutions for HVAC Systems
400 psig (2,756 kPa) - Sizes 1-1/4, 1-1/2, and 2 in.
.
Valves
Valves
Actuators
Actuators
Pressure-Independent
Pressure-Independent
Threaded Ball Valves and
Threaded Ball Valves and
The performance specifications are no minal and co nform t o acceptab le ind ustry standar ds. For appl ications at condition s beyond these specifica tions, consult th
Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. © 2014 Johnson Controls, Inc.
V–307
P1000 Series Pressure-Independent Valves (Continued)
Input Signal Floating AC 24 V ±20%, 50/60 Hz, DC 24 V ±10%
Input Impedance Floating 600 Ohms
Feedback Proportional Only DC 0 to 10 V, 0.5 mA Maximum
Electric Connection VA2104, VA2120 36 in. (0.91 m) 18 AWG Plenum Rated Cable, 1/2 in. Conduit
Runtime See Field Adjustable Flow Ranges and Runtime Data
Audible Noise Rating VA2104 < 35 dB (A)
Manual Override VA2104 External Push Button and Handle
Actuator Ambient Conditions Operating -22 to 122°F (-30 to 50°C), 5 to 95% RH Noncondensing (EN 60730-1)
Housing VA2104
Housing Material VA2104
Valves
Actuators
Compliance (North America) VA2104
Pressure-Independent
Threaded Ball Valves and
1. Proper water treatment is recommended; refer to the VDI 2035 Guideline.
Pressure-Independent Valves
P1000 Series Pressure-Independent Valves (Part 2 of 2)
Proportional DC 0 to 10 V, 4 to 20 mA with Field Furnished 500 Ohm Resist or
Proportional 10 0,000 Ohms for DC 0 to 10 V
VA2202
M2204
M2215 36 in. (0.91 m) 18 AWG Appliance Cable, 1/2 in. Conduit
M2204 < 30 dB (A) Operating, < 62 dB (A) Spring Return
VA2202 < 35 dB (A) Operating, < 65 dB (A) Spring Return
VA2120, M2215 < 45 dB (A)
VA2120
VA2202 None
M2204
M2215 Hex Crank
Storage -40 to 176°F (-40 to 80°C), 5 to 95% RH Noncondensing (EN 60730-1)
VA2120
M2204
M2215
VA2202 NEMA 2 (IP42)
VA2120
VA2202
M2204
M2215
VA2120
M2204
M2215
VA2202 UL Listed According to UL 60730-1, UL 60730-2-14 (XAPX)
36 in. (0.91 m) 18 AWG Plenum Rated Cable, 1/2 in. Conduit
.
NEMA 2 (IP54)
Thermoplastic Material, UL 94-5V
Zinc-Coated Metal
UL Listed, File E22734, CCN XAPX (United States) and XAPX7 (Canada)
cUL Listed According to CAN/CSA C22.2 No. 24 (XAPX7)
The performance specifications are no minal and co nform t o acceptab le ind ustry standar ds. For appl ications at condition s beyond these specifica tions, consult th
Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. © 2014 Johnson Controls, Inc.
V–308
Loading...
