FX-DIS Local Controller Display
Technical Bulletin
FX-DIS1710-0
Document Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Related Documentation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Local Controller Display on the Sensor Actuator (SA) Bus. . . . . . . . . . . . . . . . . . . . 5
Local Controller Display Keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Local Controller Display Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Local Controller Display Operation Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Local Controller Display Menu Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Description of Local Controller Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Local Controller Display Pages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Diagnostic Pages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Code No. LIT-12011666
Issued March 22, 2019
Supersedes April 12, 2011
Controller Information Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Idle/Favorites Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Password Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Change Password Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Data Refresh Rate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Detailed Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Entering a Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Changing the Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Displaying Configured Input and Output Points. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Commanding Configured Input and Output Points . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Displaying Configured Parameters and Setpoints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Commanding Configured Parameters and Setpoints . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Displaying Overridden Points. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Viewing and Setting Display Information Preferences. . . . . . . . . . . . . . . . . . . . . . . . . . 21
Setting the Backlight Intensity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
1FX-DIS Local Controller Display Technical Bulletin
Setting the Backlight Timeout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Selecting a Date Format Preference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Selecting the Display Precision Style. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Setting the Display Contrast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Setting the Idle Timeout Value. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Selecting the Time Format Preference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Displaying Controller Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Logging Off the Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
FX-DIS Local Controller Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
FX-DIS Local Controller Display Technical Bulletin2
Document Introduction
This document describes how to operate and troubleshoot the Facility Explorer
Local Controller Display (FX-DIS1710-0). The display module is a local user
interface for the Facility Explorer Programmable Variable Air Volume (VAV) Box
Controllers (FX-PCVs) and Facility Explorer General Purpose Programmable
Controllers (FX-PCGs) that do not have an integral display. For some FX-PCGs,
the display is a built-in component. Use this document for both the stand-alone and
the built-in display models.
This document does not describe how to commission the display with the
Controller Configuration Tool (CCT). For details, refer to
Controller Tool Help (LIT-12011147).
See Related Documentation for additional information related to applying the
Local Controller Display to your FX-PC Series Controller.
FX-DIS Local Controller Display Technical Bulletin 3
Related Documentation
Table 1 lists documentation related to the Facility Explorer Local Controller
Display (FX-DIS1710).
Table 1: Facility Explorer Local Controller Display (FX-DIS1710) Related
Documentation
For Information On See Document LIT or Part Number
Features, Benefits, and
Applications of the FX-DIS1710
Installation and Specifications
of the FX-DIS1710-0
Commissioning, Uploading, and
Downloading the FX-DIS1710
Specifications of the Facility
Explorer Programmable
Controllers
Installation Instructions and
Specifications for the FX-PCG16
and FX-PCG26
Installation Instructions and
Specifications for the
PCV1617 and PCV1632
Installing the FX-ZFR1800
Series Wireless Field Bus
System (Facility Explorer
network only)
Specifications of the Wireless
Commissioning Converter and
Setting up a Bluetooth®
Wireless Adapter
Integrating the MS/TP
Communication Bus into the
Metasys System
CCT Software Controller Tool Help
FX-DIS Local Controller Display
Product Bulletin
FX-DIS Local Controller Display
Installation Instructions
Controller Tool Help
FX-PC Series Programmable
Controllers and Related Products
Product Bulletin
FX-PCG16 General Purpose
Programmable Controller
Installation Instructions
FX-PCG26 General Purpose
Programmable Controller
Installation Instructions
FX-PCG16 General Purpose
Programmable Controller
Installation Instructions
FX-ZFR Series Wireless Field Bus
System Technical Bulletin
FX-BTCVT Bluetooth®
Commissioning Converter
Installation Instructions
FX-BTCVT Bluetooth®
Commissioning Converter
Commissioning Guide
BACnet® Controller Integration
with NAE/NCE Technical Bulletin
LIT-12011667
Part No. 24-10240-17
LIT-12011147
LIT-12011657
Part No. 24-10143-52
Part No. 24-10143-160
Part No. 24-10143-489
LIT-12011660
Part No. 24-10108-10
LIT-12011665
LIT-1201531
LIT-12011147
1
1
1. This LIT number represents a printer friendly version of the Help.
FX-DIS Local Controller Display Technical Bulletin4
Local Controller Display on the Sensor Actuator (SA) Bus
Figure 1: FX-PC Controllers on the FC Bus
F
X_FIG:DIS
_
N
twr
k
FX-PCG
without Display
FX-PCG
with Integral Display
* Typically, a local display is mounted to the door of an enclosure that contains the controller.
FX-DIS**
FC Bus FC Bus
FX-PCG with
Local Display*
SA Bus
FC Bus
** Note:
Do not connect the local display to an FX-PCG that has an integral display.
PCG
PCG
FX-PCV-1610-0
PCG
The Local Controller Display is an optional accessory to an FX-PCG and FX-PCV
that provides a user interface to the device. The display installs on the front door of
the panel that houses the controller and is connected to the SA Bus. Figure 1 shows
an example network of FX-PC controllers with Local Controller Displays.
FX-DIS Local Controller Display Technical Bulletin 5
Figure 2 shows the dimensions, and Figure 3 shows the physical features of the
Figure 2: Local Controller Display Dimensions, mm/in.
Removable
O-Ring
Front View
Back View
F
X_FIG:DIS_Dim
s_5.0
DIS
Removable
Back Plate
SA Bus
Access Hole
86
3-3/8
231
9-1/16
238
9-3/8
Depth
26
1.0
64
2-1/2
Figure 3: Local Controller Display Physical Features
** RJ-12 6-pin modular jack. To use port, remove cap plug. When done, replace cap plug.
FX_FIG:DIS_LEDs_5.0
Display
Screen
Keypad
Red Alarm
LED*
Removable
Back Plate
* Alarm Light Emitting Di ode (LED) not used.
Local Controller Display. The same general design features also to apply FX
controller models that have a built-in display.
Table 2 describes the purpose of each component on the Local Controller Display.
Table 2: Local Controller Display Components
Component Description
Display Screen Displays the controller’s user interface.
FC/SA Bus Port Allows for Bluetooth RJ-12 6-pin device connection for
commissioning purposes.
Keypad Used for interacting with the display.
Red Alarm LED Not used.
Removable Back Plate Used to hold the display onto the door of the enclosure.
Removable O-Ring Fits inside gland around housing perimeter.
SA Bus Access Hole Cutout section on the removable back plate through which the
SA Bus connector cable can pass for connection to the display.
FX-DIS Local Controller Display Technical Bulletin6
Local Controller Display Keypad
Figure 4: Local Controller Display Keypad
Up/Down
Arrows
Escape
Left/Right
Arrows
Enter
FIG:navb utns
esc
esc
The Local Controller Display has six keys that are used to navigate the menu
structure (Figure 4):
• Up/Down Arrows () move the highlighted field up or down on the
current display, or within a menu. These arrows also allow for incrementing
and decrementing a number or digit within a number, and move between fields
on pages that contain multiple fields.
• Left/Right Arrows () move the highlighted field to the right or left on the
current display. These arrows also allow for selecting a digit within a number
for modification purposes, and scroll the Idle page four items at a time.
• Escape ( ) button cancels the current data value or selection. This button
also returns the display to the previous page.
• Enter ( ) button performs the action of the highlighted field on the display.
This button also accesses the next menu level.
• Pressing Escape + Enter simultaneously logs off the user. The display then
returns to the Idle/Favorites page.
All keys on the Local Controller Display have a repeat function in where key
action is repeated when the key is held down for more than 1 second. For example,
if you hold down the up key, the highlighted field moves up one selection each
second. The repeat rate is the same for all the keys.
FX-DIS Local Controller Display Technical Bulletin 7
Local Controller Display Configuration
FX-PC controllers with a local display, or controllers with the remote stand-alone
display, are configured with CCT. The CCT provides a Configure Display menu
option that allows you to:
• define which points appear on the display pages (Input/Output View,
Parameter/Setpoint View, and Idle View) and in which order
• define which points are read-only (cannot be commanded using the display)
• specify point names and descriptions
• set display attributes including contrast and backlight intensity
• select timeout settings
• select authorization, including password definition
These options are available in CCT through the Configure Display option found in
the Tools menu while in Configuration mode. For details, refer to
Controller Tool Help (LIT-12011147).
Local Controller Display Operation Overview
The Local Controller Display uses a fixed set of display pages to organize the
objects and data defined in the controller. Use the keypad to log on to the device
and navigate between and within each page. See Local Controller Display Keypad
for navigation information. You cannot change the order of the pages, but you can
change the contents of the pages when you configure the display with CCT.
FX-DIS Local Controller Display Technical Bulletin8
Local Controller Display Menu Structure
Figure 5: Local Controller Display Menu Structure
Controller
Startup
Diagnostic
Pages
Controller
Information
Page
Idle
Page
Password
Entry Page
Enter
Password
Main Menu
Page
Input/Output
Page
Parameter/
Setpoint Page
Override
Page
Display
Information
Page
Controller
Information
Page
Change
Password
Page
Logoff
Focus
Page
Command
Select
Page
Adjust
Page
State n
Page
Override
Page
Release
Page
Release All
Page
In Context
Page
Out of Context
Page
FIG:MnuFlwAll
Password
disabled or
user logged on.
Esc
Enter/
Esc
Accept
Enter/Esc
Enter/Esc
Accept/Esc
Accept/Esc
Figure 5 is a flowchart of the menu structure for the Local Controller Display. The
menu selections are described in the sections that follow.
FX-DIS Local Controller Display Technical Bulletin 9
Description of Local Controller Display
Figure 6: Common Areas of the Local Controller Display
Input/Output
! SAD-O
55.3
ZN-T
SF-C
F
I
G
:
S
c
r
n
E
x
75.4
On
Item Value
Item Status
The pages that you access from the display’s Main Menu share a common layout
and theme. For example, all pages have a page title and a scroll bar used to
navigate the page. In addition, all pages support four lines of text. The common
areas of the screens are shown in Figure 6.
Page Title
Scroll Bar
Item Label
If a text field shown on the Local Controller Display exceeds 20 characters, the
text scrolls across the screen once and then remains left justified with trailing
ellipses to indicate the entire text is not showing. For example, Floor1 Zone
Temperature may be shortened as Floor1 Zone Temper…. Text characters not
supported by any available character are displayed as asterisks.
Text is also shortened if the data field for the object exceeds the total allocated
width. For example, if the value of an object is 12345.67, the displayed value may
be shortened to 12345 (depending on its initial length).
Pages on the Local Controller Display:
• share a common method of row selection
• use a common method of entering data within an editable field
• show a scroll bar to indicate the scrolling feature is enabled
• support scrolling of rows and data that span multiple screens
• share a common method of wrapping row selection when the endpoints of the
rows in a list have been reached
• update their values every 5 seconds (Present Value and Reliability attributes) or
120 seconds (all other attributes)
You can select objects shown on the Local Controller Display when you configure
the display with CCT. For details, refer to Controller Tool Help
(LIT-12011147).
FX-DIS Local Controller Display Technical Bulletin10
Local Controller Display Pages
Figure 7: Diagnostic Pages That Appear During Startup
Startup...
Operational
FIG:StrtUp
When the controller is powered on, the screen displays a series of pages that
sequence automatically to indicate the status of the controller. These pages
include:
• Diagnostic Pages which provide status information during powerup. These
pages also present four screens that feature the Johnson Controls® logo
(Figure 7).
• Controller Information Page which displays information about the controller
(Figure 8).
• Idle/Favorites Page which displays important values and frequently referenced
input and output points (Figure 9).
Diagnostic Pages
When the controller is powered on, the screen sequences through four pages, as
shown in Figure 7. If a problem is detected during startup, the screen indicates the
error condition. If the controller is missing an application, the Johnson Controls
screen remains showing with the message Application Download Required. If an
application is present, the startup sequence completes and the Controller
Information page appears (Figure 8).
Display is Offline
Reading Controller Information
FX-DIS Local Controller Display Technical Bulletin 11
Controller Information Page
Figure 8: Controller Information Page - FX Example
FX-PCG2610-0
Operational
5.3
10
Default Fan Coil
CTRL 6 UI,2BI,3BO,2AO,4CO
Model Name
Application Name
Firmware Version
Controller Status
Controller Description
Device Address
Figure 9: Idle/Favorites Page
OCC_MODE
SAD-O
OCCUPIED
55.3
?ZN-T
*ZN-SP
Point Name
FIG:IdlScrn
75.4
76.0
Point Status
The Controller Information page displays general information about the controller,
such as the device name and firmware version (Figure 8). This page appears for
about 8 seconds, then the Idle/Favorites Page appears (Figure 9). If the controller
has not yet been commissioned by CCT, the display remains on the Controller
Information page.
You can also access the information shown in Figure 8 in attribute view format by
selecting Controller Information from the Main Menu. The information shown on
the Controller Information page cannot be customized.
Idle/Favorites Page
The Idle/Favorites page is the default view for the controller. It shows a
user-defined, ordered list of data points selected from within the application
running in the controller (Figure 9). Use CCT to specify which objects appear on
this page.
Val ue
Scroll Bar
FX-DIS Local Controller Display Technical Bulletin12
When more than four points are configured for the Idle page, the points list scrolls
Figure 10: Password Page
Password
Accept
Cancel
ABCDEFGHI
FIG:EntrPwd
Asterisks appear
in place of typed
characters.
JKLMNOPQRS
0123456789
Backspace
***
vertically down the page one line at a time. You can scroll the page one item at a
time by using the up and down arrow keys or scroll the page four items at a time by
using the left and right arrow keys. Each point appears in a single row and contains
its name, value, and status. The point’s status is indicated by a symbol to the left of
its name (Table 3). Point values are updated every 5 seconds.
Table 3: Icons Used for Displaying Point Status
Symbol Description of Point Status
<none> Normal Operation - Point Status is in a normal state.
? Offline – Point Status is offline or unreliable; actual value is unknown.
* Overridden – Point Status is in an overridden state.
¤ Out Of Service – Point Status is currently out of service.
The Idle/Favorites page reappears whenever you log off the display or the idle
timeout period expires. Pressing the Esc key when the Idle/Favorites page is
displayed allows you to log on, or if already logged on, to access the Main Menu.
Password Page
A Password page is used when password access is enabled for the display.
Passwords protect the display from unauthorized users. The display permits only
one password for all users, and this password applies only to a single controller.
For simplicity, you may want to use the same password for all controllers with
displays. See Change Password Page for password character limits.
The Password page is presented when you press the Esc key (Figure 10). From this
page, you individually select each character of your password. An asterisk masks
each selected character. When you select Accept, the password is authenticated
and the Main Menu page appears. If the password entered is not valid, the
controller displays Authorization Failed. Message password access to the display
is granted, you remain logged on to the controller until you log off manually, or
until no keypad activity occurs during the idle timeout period. The timeout period
is set by the user.
Note: Password support is enabled and defined with CCT under the Display
Configuration option. CCT is also used to disable the password if the
password requirement is no longer desired. Password access cannot be
disabled from the Local Controller Display.
TUVWXYZ
FX-DIS Local Controller Display Technical Bulletin 13
Change Password Page
Change Password
Accept
New
FIG:ChngPwd
Confirm
Enter a new password
Confirm the password
Figure 11: Change Password Page
Once logged on, you can change your password by accessing the Change
Password page. The process involves entering, confirming, then saving the new
password. The password can be from one to 32 characters in length, all uppercase
alphanumeric characters. If the new and confirmed password entries do not match,
the message Passwords do not match appears. If the new password is accepted,
the Main Menu page appears.
Cancel
Data Refresh Rate
Data shown on the Local Controller Display is periodically refreshed depending on
controller activity and is not set by the user. For monitored points, Present Value
and Reliability attributes update every 5 seconds. For all other attributes, values
are updated within 120 seconds. After 10 minutes with no keypad activity
(including being logged off), the refresh rate of all attributes, including Present
Value and Reliability, reverts to 120 seconds.
FX-DIS Local Controller Display Technical Bulletin14
Detailed Procedures
Figure 12: Password Entry Page
Password
Accept
Cancel
ABCDEFGHI
FIG:EntrPwd
Asterisks appear
in place of typed
characters.
JKLMNOPQRS
0123456789
Backspace
***
Change Password
Accept
New
FIG:ChngPwd
Confirm
Enter a new password
Confirm the password
Figure 13: Change Password Page
Entering a Password
To enter a password:
Note: The password entry page is available only if a password was enabled when
the Display Configuration was set with CCT. Otherwise, the display menus
are accessible without a password entry.
1. Press the Escape or Enter key. The Password page appears (Figure 12).
TUVWXYZ
2. Use the arrow keys to select each character of your password, and press Enter
to submit each character. Your entries appear in the upper right corner as
asterisks. To correct an entry, use Backspace to erase one entry at a time, or
press Esc to clear the entire password and start over.
3. When you have entered the entire password, select Accept and press Enter. The
password is verified and the Main Menu appears.
Changing the Password
To change the password:
1. Go to the Main Menu by using the keypad. See Local Controller Display
Keypad.
2. Scroll down and select the Change Password option.
3. Press Enter. The Change Password page appears (Figure 13).
Cancel
FX-DIS Local Controller Display Technical Bulletin 15
4. Select the Enter a new password option. The New password entry page
Figure 14: New Password Page
New
Accept
Cancel
ABCDEFGHI
FIG:NwPwd
characters.
JKLMNOPQRS
0123456789
Backspace
***
Figure 15: Change Password Page
Change Password
Accept
Cancel
New
FIG:ChngPwdCnfrm
Confirm
***
Confirm the password
characters.
Figure 16: Confirm Password Page
Confirm
Accept
Cancel
ABCDEFGHI
FIG:CnfrmP wd
characters.
JKLMNOPQRS
0123456789
Backspace
***
Change Password
Accept
New
FIG:ChngPwdCnfrm2
Confirm
***
***
Figure 17: Change Password Page
appears (Figure 14).
Asterisks appear
in place of typed
TUVWXYZ
5. Use the arrow keys to select each character of your new password, and press
Enter to submit each character. Your entries appear in the upper right corner as
asterisks. To correct an entry, use Backspace to erase one character at a time, or
press Esc to clear the entire password and start over.
6. When you have entered the entire password, select Accept and press Enter. The
Change Password confirmation page appears (Figure 15).
Asterisks appear
in place of typed
7. Press Enter to confirm the new password. The Confirm password page appears
(Figure 16).
Asterisks appear
in place of typed
TUVWXYZ
8. Reenter your new password, select Accept, and press Enter. The Change
Password confirmation page reappears (Figure 17).
Cancel
9. Select Accept and press Enter. The new password is confirmed and, if
accepted, the Main Menu appears. If the new and confirmed password entries
do not match, the message Passwords do not match appears.
FX-DIS Local Controller Display Technical Bulletin16
Note: You can also change your password using CCT. The new password is
Input/Output
SAD-O
55.3
?ZN-T
*ZN-SP
FIG:InOut Scrn
75.4
76.0
Figure 18: Input/Output Page
Cancel
Command
Zone Setpoint
FIG:CmdSel
Reliability
72.5
Comm OK
Figure 19: Example of Zone Setpoint Page
effective after you download the application to the controller using
CCT.
Displaying Configured Input and Output Points
To display configured input and output points:
1. Go to the Main Menu.
2. Select the Input/Output option. A list of all configured input and output points
appears (Figure 18).
3. Use the up/down arrow keys to scroll through the list of points and their current
values.
4. For details on a particular point, select the point and press Enter. The Focus
page for the point appears. Figure 19 is an example of a zone setpoint.
ZN-SP
5. Use the up/down arrow keys to navigate through point details.
6. Press Esc to return to the Main Menu.
Commanding Configured Input and Output Points
To command configured input and output points:
1. Go to the Main Menu.
2. Select the Input/Output option. A list of all configured input and output points
appears.
3. Select the point that you want to command.
4. Press Enter. The Command option for the point is highlighted.
FX-DIS Local Controller Display Technical Bulletin 17
5. Press Enter to display the commands available for this point. Figure 20 shows
Command
Release
Adjust
Override
FIG:CmdSel
Figure 20: Command Page
Figure 21: Adjust Page
Adjust
Accept
Cancel
ZN-SP
Selections
FIG:CmdAna
72.0
+ 72.0
Current Setting
OCC-SCHEDULE Occupied
FLUSHPOS
HIGH-EN
FIG:ParmS etScrn
100
Tru e
Figure 22: Parameter/Setpoint Page
an example for an analog point.
6. Select a Command and press Enter. The Adjust page appears (Figure 21). For
analog points, use the left and right arrow keys to position the cursor to a
desired digit location. Then, use the up and down arrow keys to increment and
decrement a value. For binary points, use the up and down arrow keys to scroll
through the available selections. Figure 21 shows an example for adjusting an
analog setpoint.
7. Press Enter to select Accept.
8. Press Enter again to verify the selection and send the command.
9. Press Esc to return to the Main Menu.
Displaying Configured Parameters and Setpoints
To display configured parameters and setpoints:
1. Go to the Main Menu.
2. Select the Parameter/Setpoints option. A list of all configured parameters and
setpoints appears.
Parameter/Setpoint
3. Use the up/down arrow keys to scroll through the list with the current values.
FX-DIS Local Controller Display Technical Bulletin18
4. For more details on a particular item, select the item and press Enter. The
OCC-SCHEDULE
Cancel
Command
Reliability
FIG:OccSch
Out of Service
Occupied
False
Reliable
Figure 23: Occupancy Schedule Page
Command
Release
Adjust
Override
FIG:CmdSel
Figure 24: Command Page
Focus page for the item appears. Figure 23 is an example for the Occupancy
Schedule.
5. Use the up/down arrow keys to navigate through the information.
6. Press Esc to return to the Main Menu.
Commanding Configured Parameters and Setpoints
To command configured parameters and setpoints:
1. Go to the Main Menu.
2. Select the Parameter/Setpoints option. A list of all configured parameters and
setpoints appears.
3. Use the up/down arrow keys to select the parameter or setpoint (for example,
analog or binary) that you want to command.
4. Press Enter. The Focus page for the item appears with the Command option
selected.
5. Press Enter to display the commands available to this parameter or setpoint.
Figure 24 shows an example for the Command Pages.
FX-DIS Local Controller Display Technical Bulletin 19
6. Select a Command and press Enter. The Adjust page appears (Figure 25). For
Figure 25: Adjust Page
Adjust
Accept
Cancel
OCC-SCHEDULE
Selections
FIG:CmdOccSch
Occupied
Current Setting
Occupied
Figure 26: Overrides Page
Overrides
*ZN-SP
*CLG-EN
FIG:OvrLst
75.0
False
analog points, use the left and right arrow keys to position the cursor to a
desired digit location. Then, use the up/down arrow keys to increment and
decrement a value. For binary points, use the up/down arrow keys to scroll
through the available selections. Figure 25 shows an example for the Adjust
Pages.
7. Press Enter to select Accept.
8. Press Enter again to verify the selection and send the command.
9. Press Esc to return to the Main Menu.
Displaying Overridden Points
To display overridden points:
1. Go to the Main Menu.
2. Select the Overrides option. A list of all points that are currently overriden
appears (Figure 26). If no points are overriden, the user message Status: No
objects are overridden appears.
3. Use the up/down arrow keys to scroll through the list of points and their current
values.
FX-DIS Local Controller Display Technical Bulletin20
4. To display the Focus page for a particular point, select the point and press
Cancel
Command
Zone Setpoint
FIG:OvrZne St
Reliability
75.0
Comm OK
*ZN-SP
Figure 27: Zone Setpoint Page
Enter. The Focus page for the point appears, which also allows you to
command the point (for example, release the override). (See Figure 20 for the
available commands.) Figure 27 is an example for a zone setpoint in override.
5. Use the up/down arrow keys to navigate through the information.
6. Press Esc to return to the Main Menu.
Viewing and Setting Display Information Preferences
The Display Information option shows how the Local Controller Display is
configured. Table 4 summarizes these settings, including those that you can
customize.
Table 4: Display Information Preferences (Part 1 of 2)
Parameter Description Selections
Backlight
Intensity
Backlight
Timeout
Date Format
Preference
Display
Precision
Style
Display
Contrast
Firmware
Version
1
1
Controls the brightness of
the Local Controller
Display.
Defines how long the
display remains backlit
when no user activity is
present before going dim.
Sets how dates are
presented on the display.
Sets which style is used to
segment a number.
Sets the amount of
contrast the screen uses.
Displays the firmware
version of the display.
Bright, Medium, Dim, Off (no backlighting)
1 minute, 5 minutes, 1 hour, 8 hours
MM DD YY (01 15 07)
MM DD YYYY (01 15 2007)
DD JAN YYYY (15 January 2007)
DD JAN YY (15 January 07)
DD MM YY (15 01 07)
DD MM YYYY (15 01 2007)
Dot (72.8)
Comma (72,8)
10%, 25%, 50%, 75%, 90%
(10% for high contrast; 90% for low contrast)
(Not configurable)
Example: 4.0.0.0102
FX-DIS Local Controller Display Technical Bulletin 21
Table 4: Display Information Preferences (Part 2 of 2)
Parameter Description Selections
Idle Page
Timeout
Language Displays the configured
MAC Address Displays the controller’s
MS/TP Baud
Rate
Time Format
Preference
1. Backlight intensity and display contrast both affect the readability of the display. Best visibility is
backlight intensity is Bright and display contrast is 10%. Worst visibility is backlight intensity is
off and display contrast is 90%.
Defines how long the
display waits between
keyboard interactions
before logging off the user.
language.
configured Media Access
Control (MAC) address.
Displays the configured
Master-Slave/TokenPassing (MS/TP) baud
rate.
Sets how time of day
appears on the display.
1 minute, 5 minutes, 15 minutes,
30 minutes, 1 hour, No Timeout
(Not configurable)
Default: English (United States)
(Not configurable)
Example: 22
(Not configurable)
Example: 38,400
12 MM (4:30)
12 MM SS (4:30:30)
12 MM AM/PM (4:30 PM)
12 MM SS AM/PM (4:30:30 PM)
24 MM (16:30)
24 MM SS (16:30:30)
FX-DIS Local Controller Display Technical Bulletin22
Setting the Backlight Intensity
Figure 28: Modify Backlight Intensity Page
Modify
Accept
Cancel
Selections
FIG:Baklitintscrn
Medium
Bright
Figure 29: Modify Backlight Timeout Page
Modify
Accept
Cancel
Backlight Timeout
Selections
5 Min.
1 Min.
To set the backlight intensity:
1. Go to the Main Menu.
2. Scroll down to select the Display Information option and press Enter.
3. Scroll down to select the Backlight Intensity parameter and press Enter. The
Modify page appears.
4. On the Modify page, use the up/down arrow keys to select a backlight intensity
(Figure 28). The screen changes as you select an intensity level.
Current Setting
Backlight Intensity
5. Press Enter to select Accept.
6. Press Enter again to save the setting and return to the Information page.
7. Press Esc to return to the Main Menu.
Setting the Backlight Timeout
To set the backlight timeout:
1. Go to the Main Menu.
2. Scroll down to select the Display Information option and press Enter.
3. Scroll down to select the Backlight Timeout parameter and press Enter. The
Modify page appears.
4. On the Modify page, use the up/down arrow keys to select a backlight timeout
(Figure 29).
Current Setting
5. Press Enter to select Accept.
6. Press Enter again to save the setting and return to the Information page.
7. Press Esc to return to the Main Menu.
FX-DIS Local Controller Display Technical Bulletin 23
Selecting a Date Format Preference
Figure 30: Modify Date Format Preferences Page
Modify
Accept
Cancel
Date Format Pref.
Selections
FIG:DteFrm Pref
MM DD YY
MM DD YYYY
Figure 31: Modify Display Precision Style Page
Modify
Accept
Cancel
Selections
FIG:Dsply Prec
Dot
Comma
Current Setting
To select a date format preference:
1. Go to the Main Menu.
2. Scroll down to select the Display Information option and press Enter.
3. Scroll down to select the Date Format Pref. parameter and press Enter. The
Modify page appears.
4. On the Modify page, use the up/down arrow keys to find the format you want
to use for displaying dates (Figure 30).
Current Setting
5. Press Enter to select Accept.
6. Press Enter again to save the setting and return to the Information page.
7. Press Esc to return to the Main Menu.
Selecting the Display Precision Style
To select the display precision style:
1. Go to the Main Menu.
2. Scroll down to select the Display Information option and press Enter.
3. Scroll down to select the Disp (Display) Precision Style parameter and press
Enter. The Modify page appears.
4. On the Modify page, use the up/down arrow keys to select the style to use as
the separator in a number (Figure 31).
Display Precision Style
5. Press Enter to select Accept.
6. Press Enter again to save the setting and return to the Information page.
7. Press Esc to return to the Main Menu.
FX-DIS Local Controller Display Technical Bulletin24
Setting the Display Contrast
Figure 32: Modify Display Contrast Page
Modify
Accept
Cancel
Display Contrast
Selections
FIG:Dsply Cntr
10%
50%
Modify
Accept
Cancel
Idle Page Timeout
Selections
F
I
G
:
I
d
l
t
m
e
o
u
t
5 min
1 Min.
Current Setting
Figure 33: Modify Idle Page Timeout Page
To set the display contrast:
1. Go to the Main Menu.
2. Scroll down to select the Controller Information option and press Enter.
3. Scroll down to select the Display Contrast parameter and press Enter. The
Modify page appears.
4. On the Modify page, use the up/down arrow keys to select a percentage for the
display contrast (Figure 32). The screen changes as you select a percentage.
Current Setting
5. Press Enter to select Accept.
6. Press Enter again to save the setting and return to the Information page.
7. Press Esc to return to the Main Menu.
Setting the Idle Timeout Value
To set the auto-logoff timeout value:
1. Go to the Main Menu.
2. Scroll down to select the Display Information option and press Enter.
3. Scroll down to select the Idle Page Timeout parameter and press Enter. The
Modify page appears.
4. On the Modify page, use the up/down arrow keys to select a new idle timeout
value (Figure 33).
5. Press Enter to select Accept.
6. Press Enter again to save the setting and return to the Information page.
7. Press Esc to return to the Main Menu.
FX-DIS Local Controller Display Technical Bulletin 25
Selecting the Time Format Preference
Figure 34: Modify Time Format Preference Page
Modify
Accept
Cancel
Time Format Preference
Selections
F
I
G
:
T
m
F
r
m
P
r
e
f
12 MM
24 MM SS
Current Setting
To select a time format preference:
1. Go to the Main Menu.
2. Scroll down to select the Display Information option and press Enter.
3. Scroll down to select the Time Format Preference parameter and press Enter.
The Modify page appears.
4. On the Modify page, use the up/down arrow keys to find the format you want
to use for displaying times (Figure 34).
5. Press Enter to select Accept.
6. Press Enter again to save the setting and return to the Information page.
7. Press Esc to return to the Main Menu.
FX-DIS Local Controller Display Technical Bulletin26
Displaying Controller Information
To display controller information:
1. Go to the Main Menu.
2. Scroll down and select the Controller Information option.
3. Scroll down to view each line of controller information. Table 5 lists the type
of information available. None of these attributes can be modified from the
display, but some are defined when the application is configured using
CCT. See Table 5.
Table 5: Controller Display Attributes
Attribute Description Example
1
Status
CTRL List of the controller’s point capacities 6 UI, 2 BI, 3 BO, 2 AO,
Model Name Model name of the controller FX-PCG2611-0
Object Name
System Name
Local Site Director Not applicable ****
Firmware Version Version of the firmware stored in the controller 5.3
CPU Usage Number representing the current Central
FCB Mac Address Number representing the MAC address
FCB Baud Rate Baud rate configured for communication on the
2
2
Current status of the controller Operational
4 CO
Object name of the controller FC-22
Name of the system application in the controller FCapp
6
Processing Unit (CPU) usage in percent
10
assigned to the controller
Auto
MS/TP Bus
1. No attribute label named Status is shown; only the current status of the controller is indicated.
2. This attribute is defined when the application is configured using CCT.
Logging Off the Display
To log off the display:
1. Go to the Main Menu.
2. Scroll down and select the Log Off option.
3. Press Enter. You are logged off and the Idle/Favorites page appears.
Note: You may also log off by pressing the Esc and Enter keys at the same
time.
Troubleshooting
Table 6: Troubleshooting the FX-DIS1710 Local Controller Display
Problem Solution
The error message
Warning: Keypad Error
appears
The Display Screen is not
Displaying Settings
User is holding down a key on the keypad while the unit is starting
up. Release the key and press Escape to clear the error.
Display settings need to be adjusted. See Table 4 for setting
options.
FX-DIS Local Controller Display Technical Bulletin 27
Building Efficiency
507 E. Michigan Street, Milwaukee, WI 53202
Technical Specifications
FX-DIS Local Controller Display
Product Code Number FX-DIS1710-0 Local Controller Display
Power Requirement Nominal 15 V Provided by Controller Over SA Bus
Power Consumption 2 VA Maximum
Ambient Operating Temperature 0C to 50C (32F to 122F)
Ambient Operating Conditions 10% to 90% RH, 30C (86F) Maximum Dew Point
Ambient Storage Temperature -40C to 70C (-40F to 158F)
Ambient Storage Conditions 5 to 95% RH, 30C (86F) Maximum Dew Point
Terminations RJ-12 6-Pin Jack at Service Port (Covered by Removable
Processor Renesas® H8S-2398 32-bit Microprocessor
Memory 256 KB Flash Memory
Operating System RTOS-H8S
Network and Serial Interfaces Communication to FX-PC Controller Over SA Bus
Graphic Display Resolution 240 pixels x 64 pixels with White LED Backlighting
Dimensions (Height x Width x Depth) 85.9 mm x 238 mm x 25.8 mm (3-3/8 in. x 9-3/8 in. x 1.0
Housing Plastic Housing Material: ABS + Polycarbonate
Mounting (Height x Width) Mount to the Outside of the Enclosure
Compliance United States UL Listed, File E107041, CCN PAZX, UL 916, Energy
Canada UL Listed, File E107041, CCN PAZX7, CAN/CSA C22.2
Australia and
New Zealand
Shipping Weight 0.14 kg (0.3 lb)
Cap-Plug)
SA Bus Connection on Back of Unit
8 KB Random Access Memory (RAM)
(Adjustable)
in.)
Protection: IP20 (IEC60529)
70.5 mm x 216.5 mm (2-13/16 in. x 8-9/16 in.)
Management Equipment
FCC Compliant to CFR47, Part 15, Subpart B, Class A
No. 205, Signal Equipment; Industry Canada Compliant,
ICES-003
C-Tick Mark, Australia/NZ Emissions Compliant
Metasys® and Johnson Controls® are registered trademarks of Johnson Controls.
All other marks herein are the marks of their respective owners. © 2019 Johnson Controls.
FX-DIS Local Controller Display Technical Bulletin28
Published in U.S.A. www.johnsoncontrols.com
Loading...
