FEC16 Extended Temperature Field Equipment Controller

Installation Instructions

MS-FEC1611-0ET, MS-FEC1611-1ET

Applications

The FEC16 extended temperature field controller is
part of the Metasys® system Field Equipment
Controller (FEC) family. The FEC16 controller runs
pre-engineered and user-programmed applications
and provides the inputs and output s required to monitor
and control a wide variety of Heating, Ventilating, and
Air Conditioning (HVAC) equipment.

FEC extended temperature controllers operate on an
RS-485 BACnet® Master-Slave/Token-Passing (MS/
TP) Bus as BACnet Application Specific Controllers (B­ASC) and integrate into the Web-based Metasys
system.

IMPORTANT: In Metasys system smoke control
applications, use only the MS-FEU1610-0U model
that is UL/cUL Listed, UUKL 864 Listed, 9th Edition
Smoke Control Equipment. For Metasys system
smoke control applications, you must refer to the

Metasys® System UL 864 9th Edition UUKL/ORD­C100-13 UUKLC Smoke Control System Technical
Bulletin (LIT-12011252) for detailed requirements

and procedures for installing and operating UUKL
864 Listed Metasys system devices. Failure to meet
the requirements or follow the procedures in the

Metasys® System UL 864 9th Edition UUKL/ORD­C100-13 UUKLC Smoke Control System Technical
Bulletin (LIT-12011252) can void the UUKL 864

listing for Smoke Control Equipment.

Part No. 24-10143-306, Rev. C

Issued May 16, 2014

Supersedes November 13, 2013

North American Emissions Compliance

Canada

This Class (A) digital apparatus meets all the
requirements of the Canadian Interference-Causing
Equipment Regulations.

Cet appareil numérique de la Classe (A) respecte
toutes les exigences du Règlement sur le matériel
brouilleur du Canada.

United States

This equipment has been tested and found to
comply with the limits for a Class A digital device
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference when this equipment is
operated in a commercial environment. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instruction manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential area
may cause harmful interference, in which cas e th e
users will be required to correct the interference at
their own expense.

Installation

Observe these guidelines when installing an FEC
extended temperature controller:

• Transport the FEC in the original container to
minimize vibration and shock damage.

• Verify that all parts shipped with the FEC.

• Do not drop the FEC or subject it to physical shock.

FEC16 Extended Temperature Field Equipment Controller Installation Instructions 1

Parts Included

Figure 1: Controller Mounting Positions

Figure 2: Back of FEC16 Controller Showing

Extended Mounting Clips, DIN Rail Channel, and

• one FEC16 controller with removable terminal
blocks

• one installation instructions sheet

Materials and Special Tools Needed

• three fasteners appropriate for the mounting
surface (M4 screws or #8 screws)

• one 20 cm (8 in.) or longer piece of 35 mm DIN ra il
and appropriate hardware for DIN rail mount (only)

• small straight blade screwdriver for securing wires
in the terminal blocks

Mounting

Observe these guidelines when mounting an FEC
extended temperature controller:

• Ensure the mounting surface can support the FEC,
DIN rail, and any user-supplied enclosure.

• Mount the FEC on 35 mm DIN rail whenever
possible.

• Mount the FEC in the proper mounting position
(Figure 1).

On panel or enclosure mount applications, observe
these additional guidelines:

• Do not install the FEC in an airtight enclosure.

• Mount the FEC so that the enclosure walls do not
obstruct cover removal or ventilation through the
controller.

• Mount the FEC so that the power transform e r an d
other devices do not radiate excessive heat to the

controller.

• Mount the FEC on a hard, even surface whenever
possible in wall-mount applications.

• Use shims or washers to mount the FEC securely
and evenly on the mounting surface.

• Mount the FEC in an area free of corrosive vapors
and observe the Ambient Conditions in the

Technical Specifications

• Provide for sufficient space around the FEC for
cable and wire connections, easy cover removal,
and good ventilation through the controller (50 mm
[2 in.] minimum on the top, bottom, and front of the
controllers).

• Do not mount the FEC on surfaces prone to
vibration, such as duct work, or in areas where
electromagnetic emissions from other devices or
wiring can interfere with controller communication.

section.

FEC16 Extended Temperature Field Equipment Controller Installation Instructions2

DIN Rail Mount Applications

DIN rail mounting is the preferred mounting method.
To mount an FEC on 35 mm DIN rail:

Wall Mount Applications

To mount an FEC directly on a wall (or other flat vertical
surface):

1. Securely mount a 20 cm (8 in.) or longer section of
35 mm DIN rail horizontal and centered in the
desired space so that the controller mounts in the
horizontal position shown in Figure 1.

2. Pull the two bottom mounting clips outward to the
extended position (Figure 2).

3. Hang the controller on the DIN rail by the hooks at
the top of the (DIN rail) channel on the back of the
controller (Figure 2), and position the controller
snugly against the DIN rail.

4. Push the bottom mounting clips inward to secure
the controller on the DIN rail.

To remove the FEC from the DIN rail, pull the bottom
mounting clips out to the extended position and
carefully lift the controller off the DIN rail.

1. Pull the two bottom mounting clips outward and
ensure they are locked in the extended positions
as shown in Figure 2.

2. Mark the three mounting hole locations on the wall
using the dimensions in Figure 2 and one of the
mount positions shown in Figure 1 (or hold the
controller up to the wall/surface in a proper mount
position and mark the hole locations through the
mounting clips.)

3. Drill holes in the wall at the locations marked in
Step 2, and insert appropriate wall anchors in all
three holes (if necessary).

4. Hold the FEC in place, and insert the screws
through the mounting clips and into the holes.
Carefully tighten all of the screws.

IMPORTANT: Do not overtighten the mounting
screws. Overtightening the screws may damage the
mounting clips.

FEC16 Extended Temperature Field Equipment Controller Installation Instructions 3

Figure 3: FEC161 1 Controller Physical Features and Wiring Terminals

POWER

SA BUS

FC BUS

EOL

FAULT

BINARY

OUT1

OCOM1

OUT3

OCOM3

OCOM2

OUT2

SOURCE 24VAC

FEC1611

+15V

IN1

ICOM1

IN2

ICOM2

IN3

ICOM3

UNIVERSAL BINARY

CONFIGURABLE

ADDRESS

OUT4

OCOM4

OUT6

OCOM6

OUT7

OCOM7

OCOM5

OUT5

COM

HOT

24V~

COM

SHD

SENSO

R

POWER

COM

SA BUSFC

BUS

L

E

D

S

t

a

t

u

s

I

n

d

i

c

a

t

o

r

s

F

C

B

u

s

P

o

r

t

R

J

-

1

2

6

-

P

i

n

M

o

d

u

l

a

r

J

a

c

k

FC BUS

C

o

n

f

i

g

u

r

a

b

l

e

O

u

t

p

u

t

s

c

a

n

b

e

d

e

f

i

n

e

d

a

s

:

V

o

l

t

a

g

e

A

n

a

l

o

g

O

u

t

p

u

t

(

0

-

1

0

V

D

C

)

B

i

n

a

r

y

O

u

t

p

u

t

(

2

4

V

A

C

T

r

i

a

c

)

2

4

VA

C,

C

l

a

s

s

2Su

p

p

ly

P

o

w

erTermi

n

a

lBl

o

ck

D

e

v

i

c

e

A

d

d

r

e

s

s

D

I

P

S

w

i

t

c

h

B

l

o

c

k

B

i

n

a

r

y

O

u

t

p

u

t

s

2

4

V

A

C

T

r

i

a

c

s

(Live 24 VAC

on Exposed Jumper Pins.)

B

i

n

a

r

y

I

n

p

u

t

s

c

a

n

b

e

d

e

f

i

n

e

d

a

s

:

D

r

y

C

o

n

t

a

c

t

M

a

i

n

t

a

i

n

e

d

P

u

l

s

e

C

o

u

n

t

e

r

M

o

d

e

(

5

0

H

z

a

t

5

0

%

d

u

t

y

c

y

c

l

e

)

S

e

n

s

o

r

P

o

r

t

(

S

A

B

u

s

)

R

J

-

1

2

6

-

P

i

n

M

o

d

u

l

a

r

J

a

c

k

F

C

B

u

s

T

e

r

m

i

n

a

l

B

l

o

c

k

S

A

B

u

s

T

e

r

m

i

n

a

l

B

l

o

c

k

U

n

i

v

e

r

s

a

l

I

n

p

u

t

s

t

c

a

n

b

e

d

e

f

i

n

e

d

a

s

:

V

o

l

t

a

g

e

A

n

a

l

o

g

I

n

p

u

t

(

0

-

1

0

V

D

C

)

C

u

r

r

e

n

t

A

n

a

l

o

g

I

n

p

u

t

(

4

-

2

0

m

A

)

R

e

s

i

s

t

i

v

e

A

n

a

l

o

g

I

n

p

u

t

s

(

0

-

6

0

0

k

o

h

m

)

:

0

-

2

k

p

o

t

e

n

t

i

o

m

e

t

e

r

R

T

D

:

1

k

N

i

c

k

e

l

,

1

k

P

l

a

t

i

n

u

m

,

o

r

A

9

9

B

S

I

N

T

C

:

1

0

k

T

y

p

e

L

,

1

0

k

J

C

I

T

y

p

e

I

I

,

o

r

2

.

2

5

2

k

T

y

p

e

I

I

D

r

y

C

o

n

t

a

c

t

B

i

n

a

r

y

I

n

p

u

Display

N

a

v

iga

t

i

o

n

Buttons(

N

o

t

av

ailable

o

n

a

l

l FEC

m

odels)

L

C

DDispla

y

Are

a(Not

a

v

a

i

lable

on al

l FEC

mod

els.)

Mounting Cli

p

s

(Two of Three

)

Cover Lift

Tab

Cover Lift

Tab

FIG:fec16_phys_feas

Binary Output Source Power

Selection Jump ers

FEC16 Extended Temperature Field Equipment Controller Installation Instructions4

Wiring

!

!

Figure 4: FC Bus Terminal Block Wiring

Figure 5: SA Bus Terminal Block Wiring

CAUTION: Risk of Electric Shock.

Disconnect the power supply before
making electrical connections to avoid
electric shock.

Mise En Garde: Risque de décharge
électrique: Débrancher l'alimentation

avant de réaliser tout raccordement
électrique afin d'éviter tout risque de
décharge électrique.

CAUTION: Risk of Electric Shock.

Disconnect the power supply before
making electrical connections to avoid
electric shock.

Mise En Garde: Risque de décharge
électrique: Débrancher l'alimentation

avant de réaliser tout raccordement
électrique afin d'éviter tout risque de
décharge électrique.

IMPORTANT: Do not exceed the controller
electrical ratings. Exceeding controller electrical
ratings can result in permanent damage to the
controller and void any warranty.

FC Bus Terminal Block

The FC Bus terminal block is a blue, removable,
4-terminal plug that fits into a board-mounted jack.

Wire the removable FC Bus terminal block plugs on the
FEC, and other field controllers in a daisy-chain
configuration using 3-wire twisted, shielded cable as
shown in Figure 4. See Table 3 for more information.

Note: The Shield terminal (SHLD) on the FC Bus
terminal block is isolated and can be used to connect
the cable shields on the bus (Figure 4).

IMPORTANT: Use copper conductors only. Make
all wiring in accordance with local, national, and
regional regulations.

IMPORTANT: Electrostatic discharge can damage
controller components. Use proper electrostatic
discharge precautions during installation, setup, and
servicing to avoid damaging the controller.

For detailed information on configuring and wiring an
MS/TP Bus, Field Controller (FC) Bus, and Sensor
Actuator (SA) Bus, refer to the MS/TP Communications
Bus Technical Bulletin (LIT-12011034).

FEC Terminal Blocks and Bus Ports

See Figure 3 for terminal block and bus port locations
on the FEC16 controller . Observe the following
guidelines when wiring an FEC controller.

Input and Output Terminal Blocks

All of the fixed input terminal blocks are mounted on
the bottom of the FEC. The output terminal blocks are
mounted on the top of the controller. See Table 1 for
more information.

SA Bus Terminal Block

The SA Bus terminal block is a brown, removable,
4-terminal plug that fits into a board-mounted jack.

Wire the removable SA Bus terminal block plugs on the
FEC and other SA Bus devices in a daisy-chain
configuration using 4-wire twisted, shielded cable as
shown in Figure 5. See Table 3 for more information.

FEC16 Extended Temperature Field Equipment Controller Installation Instructions 5

FC Bus Port

Figure 6: Pin Number Assignments for

Sensor, SA Bus, and FC Bus Ports on

FEC, IOM, and VMA16

Figure 7: 24 VAC Supply Power

Terminal Block Wiring

The FC Bus port on the front of the FEC is an RJ-12,
6-position modular jack that provides a conn ec tio n for
the Wireless Commissioning Converter or ZFR1811
Wireless Field Bus Router.

The FC Bus port is connected internally to the FC Bus
terminal block. See Table 3 for more information. The
FC Bus Port pin assignment is shown in Figure 6.

Sensor Port

The Sensor (SA Bus) port on the bottom of the FEC
(Figure 3) is an RJ-12, 6-position modular jack that
provides a connection for the Wireless Commissioning
Converter, the VAV Balancing Tool, specified network
sensors, or other SA Bus devices with RJ-12 plugs.

A DIS1710 Local Controller Display also can be
connected to the SA Bus port (but only on FEC models
without integral display and push buttons).

The Sensor port is connected internally to the SA Bus
terminal block. See Table 3 for more information.The
Sensor Port pin assignment is shown in Figure 6.

Supply Power Terminal Block

The 24 VAC supply power terminal block is a gray,
removable, 3-terminal plug that fits into a board­mounted jack on the top right of the FEC.

Wire the 24 VAC supply power wires from the
transformer to the HOT and COM terminals on the
terminal plug as shown in Figure 7. The middle
terminal on the supply power terminal block is not
used. See Table 3 for more information.

The supply power wire colors may be different on
transformers from other manufact ur er s. Re fe r to th e
transformer manufacturer’s instructions and the project
installation drawings for wiring details.

IMPORTANT: Connect 24 V AC supply power to the
FEC and all other network devices so that
transformer phasing is uniform ac ro ss th e ne two rk
devices. Powering network devices with uniform
24 VAC supply power phasing reduces noise,
interference, and ground loop problems. The FEC
does not require an earth ground connection.

Wireless Network Applications

The FEC also can be installed in a wireless application.
To configure a controller for use with the ZFR1800
Series Wireless Field Bus system:

1. Wire the input/output terminals and SA Bus.
Note: In wireless network applications, do not

connect any wires to the FC Bus terminal block.

2. Connect the ZFR181 1 Wireless Field Bus Router to
the FC Bus port (RJ-12 modular jack) on the front
of the FEC.

3. Ensure that the FEC device address DIP switches
are set to the correct device address. See Setting
the Device Address.

4. Position DIP switch 128 to ON to enable wireless
operation on the FEC.

For more information on installing an FEC in a wireless
configuration, refer to the ZFR1811 Wireless Field Bus
Router Installation Instructions (Part No. 24-10325-1).

FEC16 Extended Temperature Field Equipment Controller Installation Instructions6

FEC Terminal Functions, Ratings, Requirements, and Wiring Guidelines

Input and Output Wiring Guidelines

Table 1 provides information and guidelines about the
functions, ratings, and requirements for the FEC input
and output terminals; and references guidelines for
determining proper wire sizes and cable lengths.

In addition to the wiring guidelines in Table 1, observe
these guidelines when wiring FEC inputs and outputs:

•Run all low-voltage wiring and cables separate
from high-voltage wiring.

• All input and output cables, regardless of wire size
or number of wires, should consist of stranded,
insulated, and twisted copper wires.

• Shielded cable is not required for input or output
cables.

• Shielded cable is recommended for input and
output cables that are exposed to high
electromagnetic or radio frequency noise.

• Inputs/outputs with cables less than 30 m (100 ft)
typically do not require an offset in the software
setup. Cable runs over 30 m (100 ft) may require
an offset in the input/output software setup.

Table 1: I/O Terminal Blocks, Functions, Ratings, Requirements, and Cables (Part 1 of 2)

T e rminal Block
Label

UNIVERSAL

(Inputs)

BINARY

(Inputs)

Terminal

Function, Ratings, and Requirements Determine Wire Size and

Labels

+15 V 15 VDC Power Source for active (3-wire) input devices

INn Analog Input - Voltage Mode (0-10 VDC)

ICOMn Universal Input Common for all Universal IN terminals

INn Binary Input - Dry Contact Maintained Mode

ICOMn Binary Input Common for all Binary Input (IN) terminals

connected to the Universal INn terminals.
Provides 100 mA total current.

10 VDC maximum input voltage
Internal 75k ohm Pulldown

Analog Input - Current Mode (4-20 mA)

Internal 100 ohm load Impedance
A current loop fail-safe jumper can be positioned to
maintain a closed 4-20 mA current loop even when power
to the controller is interrupted or off. See Universal Input
Current Loop Jumpers.

Analog Input - Resistive Mode (0-600k ohm)

Internal 12 V, 15k ohm pull up
Qualified Sensors: 0-2k potentiometer,
RTD (1k Nickel [Johnson Controls® sensor],
1k Platinum, and A99B Silicon Temperature Sensor)
Negative Temperature Coefficient (NTC) Sensor
(10k Type L, 10k JCI Type II, 2.252k Type II)

Binary Input - Dry Contact Maintained Mode

1 second minimum pulse width
Internal 12 V, 15k ohm pull up

Note: All Universal ICOMn terminals share a common,
which is isolated from all other commons.

0.01 second min. pulse width
Internal 18 V, 3k ohm pull up

Binary Input - Pulse Counter/Accumulator Mode

0.01 second minimum pulse width
(50 Hz at 50% duty cycle)
Internal 18 V, 3k ohm pull up

Note: All Binary ICOMn terminals share a common,
which is isolated from all other commons, except the
Configurable Output (CO) common (OCOMn) when the
CO is defined as an Analog Output.

Maximum Cable Length

Same as (Universal) INn.
Note: Use 3-wire cable for

devices that source power
from the +15 V terminal.

See Guideline A in Table 2.

See Guideline B in Table 2.

See Guideline A in Table 2.

See Guideline A in Table 2.

Same as (Universal) INn.

See Guideline A in Table 2.

1

FEC16 Extended Temperature Field Equipment Controller Installation Instructions 7

Table 1: I/O Terminal Blocks, Functions, Ratings, Requirements, and Cables (Part 2 of 2)

T e rminal Block
Label

BINARY

(Outputs)
Power Selection
Jumper positioned
to External (EXT)

BINARY

(Outputs)
Power Selection
Jumper positioned
to Internal (INT)

CONFIGURABLE

(Outputs)

Terminal

Function, Ratings, and Requirements Determine Wire Size and

Labels

OUTn Binary Output - 24 VAC Triac (External Power)

Connects OUTn to OCOMn when activated.
External Power Source:
30 VAC maximum output voltage

0.5 A maximum output current

1.3 A at 25% duty cycle
Maximum 6 cycles/hour with M9220-BGx-3
40 mA minimum load current

OCOMn Binary Output Common (for OUTn terminal)

Note: Each Binary Output common terminal (OCOMn) is

isolated from all other commons, including other Binary
Output commons.

OUTn Binary Output - 24 VAC Triac (Internal Power)

Model FEC1611-0ET: Sources internal 24 VAC power

(24~COM).
Model FEC1611-1ET: Sources internal 24 VAC power

(24~HOT).

OCOMn Binary Output - 24 VAC Triac (Internal Power)

Model FEC1611-0ET: Connects OCOMn to 24~ HOT

when activated.
Model FEC1611-1ET: Connects OCOMn to 24~ COM

when activated.
Internal Power Source:
30 VAC maximum voltage to load

0.5 A maximum output current

1.3 A at 25% duty cycle
Maximum 6 cycles/hour with M9220-BGx-3
40 mA minimum load current

OUTn Analog Output - Voltage Mode (0-10 VDC)

10 VDC maximum output voltage
10 mA maximum output current
Requires an external load of 1,000 ohm or more

Binary Output 24 VAC Triac

Connects OUT to OCOM when activated.
External Power Source:
30 VAC maximum voltage to load

0.5 A maximum output current

1.3 A at 25% duty cycle
Maximum 6 cycles/hour with M9220-BGx-3
40 mA minimum load current

OCOMn Analog Output Signal Common: All Configurable

Outputs defined as Analog Outputs share a common,
which is isolated from all other commons except the
Binary Input common.

Binary Output Signal Common: All Configurable
Outputs (COs) defined as Binary Outputs are isolated
from all other commons, including other CO commons.

Maximum Cable Length

See Guideline C in Table 2.

See Guideline C in Table 2.

See Guideline A in Table 2.

See Guideline C in Table 2.

Same as (Configurable)

OUTn.

1

1. See Table 2 to determine wire size and cable lengths for cables other than the recommended cables.

FEC16 Extended Temperature Field Equipment Controller Installation Instructions8

Table 2 defines cable length guidelines for the various

Figure 8: Maximum Wire Length by Current and Wire Size

wire sizes that may be used for input and output wiring.

Table 2: Cable Length Guidelines for Recommended Wire Sizes

Guideline Wire Size/Gauge and Type Maximum Cable Length

and Type

A

B

C See Figure 8 to select wire size/gauge.

2

1.5 mm

0.8 mm

0.6 mm
N/A (24 AWG) stranded copper 107 m (350 ft) twisted wire

1.5 mm2 (18 AWG) stranded copper

0.8 mm

0.6 mm
N/A

Use stranded copper wire.

(18 AWG) stranded copper
(20 AWG) stranded copper
(22 AWG) stranded copper

(20 AWG) stranded copper
(22 AWG) stranded copper

(24 AWG) stranded copper

457 m (1,500 ft) twisted wire 100 mV maximum voltage drop
297 m (975 ft) twisted wire
183 m (600 ft) twisted wire

229 m (750 ft) twisted wire 100 mV maximum voltage drop
137 m (450 ft) twisted wire
91 m (300 ft) twisted wire
61 m (200 ft) twisted wire
See Figure 8 to determine

cable length. Use twisted
wire cable.

Maximum Cable Length versus Load Current

Use Figure 8 to estimate the maximum ca ble length
relative to the wire size and the load current (in mA)
when wiring inputs and outputs.

Assumptions

Depending on the cable length and
the connected input or output device,
you may have to define an offset in
the setup software for the input or
output point.

Depending on the cable length and
the connected input or output device,
you may have to define an offset in
the setup software for the input or
output point.

N/A

FEC16 Extended Temperature Field Equipment Controller Installation Instructions 9

FC and SA Bus and Supply Power Wiring Guidelines

Table 3 provides information about the functions,
ratings, and requirements for the FEC communication

•Run all low-voltage wiring and cables separate
from high-voltage wiring.

• All FC and SA Bus cables, regardless of wire size,
should be twisted, insulated, stranded copper wire.

bus and supply power terminals; and provide s
guidelines for wire sizes, cable types, and cable
lengths when wiring the FEC communication buses
and supply power.

In addition to the guidelines in Table 3, observe these
guidelines when wiring the SA/FC Buses and supply
power:

• Shielded cable is strongly recommended for all FC
and SA Bus cables.

• Refer to the MS/TP Communications Bus
Technical Bulletin (LIT-12011034) for detailed
information regarding wire size and cable length
requirements for the FC and SA buses.

T able 3: Communication Bus and Supply Power Terminal Blocks, Funct ions, Rat ings, Re quirements, and

Cables

Terminal
Block/Port

Terminal
Labels

Function, Electrical Ratings/Requirements

Recommended Cable Type

1

Label

FC BUS

FC BUS

(Port)

SA BUS

SENSOR

(SA Bus Port)

24~ HOT 24 VAC Power Supply - Hot

2

2

2

+

­COM Signal Reference (Common) for bus communications
SHLD Isolated terminal (optional shield drain connection)

+

­COM SA Bus Signal Reference and 15 VDC Common
SA PWR 15 VDC Supply Power for Devices on the SA Bus

2

COM 24 VAC Power Supply Common (Isolated from a ll ot her

FC Bus Communications 0.6 mm (22 AWG) stranded, 3-wire

RJ-12 6-Position Modular Connector provides:
FC Bus Communications
FC Bus Signal Reference and 15 VDC Common
15 VDC Power for Wireless Commissioning
Converter or ZFR1811 Wireless Router .

SA Bus Communications 0.6 mm (22 AWG) stranded, 4-wire

(Maximum total current draw for SA Bus is 240 mA.)

RJ-12 6-Position Modular Connector provides:
SA Bus Communications
SA Bus Signal Reference and 15 VDC Common
15 VDC Power for devices on the SA Bus and
Wireless Commissioning Converter.

Supplies 20-30 VAC (Nominal 24 VAC)

Common terminals on controller)

twisted, shielded cable
recommended

Wireless Commissioning
Converter retractable cable or

24 AWG 3-pair CAT 3 Cable
<30.5 m (100 ft)

(2 twisted-pairs), shielded cable
recommended

Note: The + and - wires are one
twisted pair and the COM and
SA PWR are the second twisted
pair of wires.

24 AWG 3-pair CAT 3 Cable
<30.5 m (100 ft)

0.8 mm to 1.5 mm
(20 to 16 AWG) 2-wire

2

1. See Table 2 to determine wire size and cable lengths for cables other than the recommended cables.

2. The SA Bus and FC Bus wiring recommendations in this table are for MS/TP bus communications at 38.4k baud. For more
information, refer to the MS/TP Communications Bus Technical Bulletin (LIT-12011034).

FEC16 Extended Temperature Field Equipment Controller Installation Instructions10

Setup and Adjustments

Figure 9: Device Address Switches Set to 21

Setting the Device Address

Metasys field controllers are master devices on
BACnet MS/TP (SA or FC) buses. Before operating
field controllers on a bus, you must set a valid and
unique device address for each controller on the bus.

Y ou set a field controller's device address by setting the
positions of the switches on the Device Address DIP
switch block at the top of the controller (Figure 3).
Device addresses 4 through 127 are the valid
addresses for these controllers.

The DIP switch block (Figure 9) has eight switches
numbered 128, 64, 32, 16, 8, 4, 2, and 1. Switches 64
through 1 are device address switches. Switch 128 is a
mode switch that enables a field controller to operate
on a ZFR1800 Series Wireless Field Bus. Switch 128
must be set to off for all hard-wired SA and FC Bus
applications. Set switch 128 to ON for wireless FC Bus
applications only.

Set the highest number switch that is less than or
equal to the intended device address to ON. Then
continue setting lower numbered switches until the
total equals the intended address. For example, if
the intended device address is 21, set switch 16 to
ON first, then set switch 4 ON, followed by switch 1
(16+4+1= 21). See Figure 9.

3. Set switch 128 to ON only for controllers on a
ZFR1800 Series Wireless Field Bus application.
For all hard-wired SA and FC Bus applications,
ensure that switch 128 is set to off.

Note: Do not connect a field controller with switch
128 set to ON to an active (hard-wired) SA or FC
Bus. When a controller with switch 128 set to ON
and a device address from 4 to 127 is connected to
a wired field bus, the entire field bus is rendered
inoperable until the controller is disconnected or
switch 128 is set to off.

Refer to the ZFR1800 Series Wireless Field Bus
System Technical Bulletin (LIT -12011295) for more
information on device addresses in wireless
applications.

4. Set a unique and sequential device address for
each of the field controllers connected on the SA or
FC Bus starting with device address 4.

Note: Metasys field controllers ship with switch 128
ON and the remaining address switches off rendering
the controllers wired slave devices, which do not
operate on MS/TP buses, but do not interfere with bus
operation. Set a valid and unique device address on
the field controller before applying power to the
controller on the bus.

To set the device addresses on Metasys field
controllers:

1. Set all of the switches on the field controller’s
device address DIP switch block (128 through 1) to
off.

2. Set one or more of the seven address switches (64
through 1) to ON, so that the sum of the switch
numbers set to ON equals the intended device
address. See Table 4 for valid field controller
addresses.

To ensure the best bus perfor ma n ce , s et
sequential device addresses with no gaps in the
device address range (4, 5, 6, 7, 8, 9, and so on).
The field controllers do not need to be physically
connected on the bus in their numerical device
address order.

5. Write each field controller's device address on the
white label below the DIP switch block on the
controller's cover.

Refer to the MS/TP Communications Bus Technical
Bulletin (LIT-12011034) for more information on field
controller device addresses and how to set them on
MS/TP buses.

Table 4 shows and describes the valid FC Bus and
SA Bus devices addresses for Johnso n Controls®
MS/TP communications bus applications.

FEC16 Extended Temperature Field Equipment Controller Installation Instructions 11

Table 4: SA/FC Bus Device Address Descriptions

Figure 10: FEC16 with Cover Removed

Showing Jumper and EOL Switch Positions

Figure 11: EOL Switch Positions

Device

Address Description

Address

0

(Switch
128 Off)

1 to 3

(Switch
128 Off)

4 to 127

(Switch
128 Off)

0 to 3

(Switch
128 ON)

4 to 127

(Switch
128 ON)

Reserved for FC Bus Supervisory Controller
(not valid for field controllers).

Reserved for peripheral devices (not valid for
field controllers).

Valid for MS/TP Master field controllers on a
hard-wired SA Bus or FC Bus.

Reserved addresses for wired slave devices
(not valid for field controllers).

Note: Metasys controllers ship with 128 ON
and the remaining address switches off,
rendering the controllers wired slave devices,
which do not operate on Metasys field buses.

Valid for MS/TP Master field controllers on

wireless FC Buses only.
Note: Do not connect a Metasys controller

with these device addresses to an active
wired SA or FC Bus. When a controller with
one of these device address is connected to
a wired field bus, the field bus is rendered
inoperable until the controller is disconnected
or switch 128 is set to off.

Replace the cover by placing it squarely over the base,
and then gently and evenly push the cover on to the
latches until they snap into the latched position.

Setting the EOL Switch

Each field controller has an End-of-Line (EOL) switch,
which, when set to ON/up, sets the field controller as a
terminating device on the bus. See Figure 3 or
Figure 10 for the EOL switch location on the field
controller. The default EOL switch position is off/down.

Removing the FEC Housing Cover

IMPORTANT: Disconnect all power sources to the
controller before removing cover and changing the
position of any jumper or the EOL switch on the
controller. Failu re to disconnect power before
changing a jumper or EOL switch position can result
in damage to the controller and void any warranties.

IMPORTANT: Electrostatic discharge can damage
controller components. Use proper electrostatic
discharge precautions during installation, setup, and
servicing to avoid damaging the controller.

The controller cover is held in place by four plastic
latches that extend from the base and snap into slots
on the inside of the housing cover. To remove the
controller cover:

1. Place your fingernails under the two cover lift tabs
on the sides of the housing cover (Figure 3) and
gently pry the top of the cover away from the base
to release the cover from the two upper latches.

2. Pivot the top of the cover further to release it from
the lower two latches.

To set the EOL switch on a field controller:

1. Determine the physical location of the field
controller on the SA or FC Bus.

2. Determine if the field controller must be set as a
terminating device on the bus.

Note: The EOL termination rules for SA Buses
and FC Buses are different. Refer to the

MS/TP Communications Bus Technical Bulletin,
(LIT-12011034) for detailed information regarding

EOL termination rules and EOL switch settings on
SA and FC Buses.

3. If the field controller is a terminating device on the
SA Bus or FC Bus, set the EOL switch to ON. If the
field controller is not a terminating device on the
bus, set the EOL switch to off.

When a field controller is connected to power with its
EOL switch set to ON, the amber EOL Light-Emitting
Diode (LED) on the controller cover is lit.

FEC16 Extended Temperature Field Equipment Controller Installation Instructions12

Setting the Input and Output Jumpers

!

Figure 12: Example Binary Outputs and the

Associated Source Power Jumper Positions

Figure 13: Current Loop Jumper Positions

Binary Output Source Power Selection Jumpers

CAUTION: Risk of Electric Shock.

Disconnect supply power to the FEC16
controller before attempting to adjust the
Binary Output Source Power Selection
Jumpers. Failure to disconnect the
supply power may result in electric shock.

Mise En Garde: Risque de décharge
électrique: Débrancher l'alimentation de

l'controller avant tout réglage du Binary
Output Source Power Selection Jumpers.
Le non-respect de cette précaution
risque de provoquer une décharge
électrique.

IMPORTANT: Do not connect an external power
source to a Binary Output (BO) when the BO power
source jumper is in the internal power (INT) position.
Connecting external power to a BO that sources
internal power can damage the controller and void
any warranties.

Universal Input Current Loop Jumpers

The Universal Input (UI) current loop fail-safe jumpers
are on the circuit board under the housing cover near
the UI terminals (Figure 10). When a UI is defined (in
the system software) as a 4-20 mA analog input and
the UI’s current loop jumper is in the (default) Disabled
position (Figure 13), the 4-20 mA current loop circuit
opens whenever power to the FEC is interrupted or off.

Setting the current loop jumper to the Enabled position
(Figure 13) connects an internal 100 ohm resis to r
across the UI terminals, which maintains the 4-20 mA
current loop circuit even when power to the FEC is
interrupted or off.

IMPORTANT: Current Loop jumpers must be in the
(default) Disabled position for all UIs that are not set
up to operate as 4-20 mA analog inputs.

The BO source power selection jumpers determine
whether a BO provides internal power (sourced from
the FEC) to the output load (INT position) or requires
an external power source (EXT position) for the output
load. Figure 12 shows an example of an FEC16
controller BOs and the associated power selection
jumpers to the right of the BOs terminal block.

Table 5 identifies the current loop jumpers associated
with each UI on the FEC16 controller.

Table 5: FEC16 UI Inputs and Jumper Labels

Universal Input
Label

IN1 J74
IN2 J73

Jumper Label on Circuit
Board

Commissioning

Commission the FEC with the Metasys Controller Tool
(software), either via the Bluetooth® Wireless
Commissioning Converter, ZigBee® wireless dongle,
or in passthrough mode when connected to an NAE or
NCE. Refer to Controller Tool Help (LIT-12011147).

Refer to the DIS1710 Local Controller Display
Technical Bulletin (LIT-12011270) for information on
connecting a DIS1710 display.

FEC16 Extended Temperature Field Equipment Controller Installation Instructions 13

Troubleshooting

Observe the LEDs on the front of the controller and see
Table 6 to troubleshoot the controller.

To troubleshoot the integral FEC display, refer to the

DIS1710 Local Controller Display Technical Bulletin
(LIT-12011270).

Table 6: Status LEDs and Description of LED States

LED Label LED

Color

POWER Green On Steady Off Steady = No Supply Power or the controller’s polyswitch/resettable fuse is

FAULT Red Off Steady Off Steady = No Faults

SA BUS Green Blink - 2 Hz Blink - 2 Hz = Data Transmission (normal communication)

FC BUS Green Blink - 2 Hz Blink - 2 Hz = Data Transmission (normal communication)

EOL Amber Off

Normal
State

(Except on
terminating
devices)

Descriptions of LED States

open. Check Output wiring for short circuits and cycle power to controller.
On Steady = Power Connected

On Steady = Device Fault; no application loaded; Main Code download
required, if controller is in Boot mode, or a firmware mismatch exists between
the FEC and the ZFR1811 Wireless Field Bus Router.

Blink - 2 Hz = Download or Startup in progress, not ready for normal operation
Blink Rapidly - 5 Hz = One or more defined SA Bus device is offline. Check

SA Bus devices for problems, including low batteries on wireless sensor.

Off Steady = No Data Transmission (N/A - auto baud not supported)
On Steady = Communication lost, waiting to join communication ring

Off Steady = No Data Transmission (auto baud in progress)
On Steady = Communication lost, waiting to join communication ring

On Steady = EOL switch in ON position
Off Steady = EOL switch in Off positio n

FEC16 Extended Temperature Field Equipment Controller Installation Instructions14

Repair Information

If the FEC16 controller fails to operate within its

Accessories

See Table 7 to order accessories.
specifications, replace the unit. For a replacement
controller, contact the nearest Johnson Controls
representative.

Table 7: FEC16 Controller Accessories Ordering Information

Product Code Number Description

MS-BTCVT-1 Wireless Commissioning Converter, with Bluetooth® Technology
MS-DIS1710-0 Local Controller Display (for use with MS-FEC1611 model only)
MS-ZFR1811-0 Wireless Field Bus Router for wireless FEC applications
TP-2420 Transformer, 120 VAC Primary to 24 VAC secondary, 20 VA, Wall Plug

Y65T31-0

AS-XFR050
AP-TBK4SA-0 Replacement MS/TP SA Bus Terminal, 4-Position, Brown, Bulk Pack
AP-TBK4FC-0 Re placement MS/TP FC Bus Terminal, 4-Position, Blue, Bulk Pack
AP-TBK3PW-0 Replacement Power Terminal, 3-Position Connector, Gray, Bulk Pack

1. Additional Y60 Series transformers are also available.

1

-0

Transformer , 120/208/240 V AC Primary to 24 VAC Secondary, 40 V A, Foot Mount, 8 in. Primary
Leads and Secondary Screw Terminals, Class 2

Power transformer (Class 2, 24 VAC, 50 VA maximum output), no enclosure

Technical Specifications

FEC16 Extended Temperature Controller (Part 1 of 2)

Product Code Numbers MS-FEC1611-0ET Field Equipment Controller

Supply Voltage 24 VAC (nominal, 20 VAC minimum/30 VAC maximum), 50/60 Hz, power supply Class 2

Ambient Conditions Operating: -40 to 70°C (-40 to 158°F); 10 to 90% RH noncondensing

Controller Addressing DIP switch set; valid field controller device addresses 4–127

Communications Bus BACnet® MS/TP, RS-485:

Processor H8SX/166xR Renesas® 32-bit microcontroller
Memory 1 MB Flash Memory and 512 KB Random Access Memory (RAM)
Input and Output

Capabilities

Analog Input/Analog Output
Resolution and Accuracy

Terminations Input/Output: Fixed Screw Terminal Blocks

Mounting Horizontal on single 35 mm DIN rail mount (preferred), or screw mount on flat surface with

Housing Enclosure material: ABS and polycarbonate UL94 5VB; Self-extinguishing, Plenum Rated

MS-FEC1611-1ET Field Equipment Controller

(North America), Safety Extra-Low Voltage (SELV) (Europe)

Storage: -40 to 80°C (-40 to 176°F); 5 to 95% RH noncondensing

(Device addresses 0–3 and 128–255 are reserved and not valid field controller addresses.)

3-wire FC Bus between the supervisory controller and field controllers
4-wire SA Bus between field controller, network sensors and other sensor/actuator devices,
includes a lead to source 15 VDC supply power (from field controller) to bus devices.

2 - Universal Inputs: Defined as 0-10 VDC, 4-20 mA, 0-600k ohm, or Binary Dry Contact
1 - Binary Inputs: Defined as Dry Contact Maintained or Pulse Counter/Accumulator Mode
3 - Binary Outputs: Defined as 24 VAC Triac (selectable internal or external source power)
4 - Configurable Outputs: Defined as 0-10 VDC or 24 VAC Triac BO

Input: 16-bit resolution
Output: 16-bit resolution, ±200 mV accuracy in 0-10 VDC applications

FC Bus, SA Bus, and Supply Power: 3-Wire and 4-Wire Pluggable Screw Terminal Blocks
FC Bus and SA Bus: RJ-12 6-Pin Modular Jacks

three integral mounting clips on controller

Protection Class: IP20 (IEC529)

FEC16 Extended Temperature Field Equipment Controller Installation Instructions 15

Metasys® and Johnson Controls® are registered trademarks of Johnson Controls, Inc.

All other marks herein are the marks of their respective owners. © 2014 Johnson Controls, Inc.

Building Efficiency

507 E. Michigan Street, Milwaukee, WI 53202

FEC16 Extended Temperature Controller (Part 2 of 2)

Dimensions
(Height x Width x Depth)

Weight 0.4 kg (0.9 lb)
Compliance United States: UL Listed, File E107041, CCN PAZX, UL 916, Energy Management

The performance specifications are nominal and conform to acceptable industry standard. For application at conditions beyond these
specifications, consult the local Johnson Controls® office. Johnson Controls, Inc. shall not be liable for damages resulting from misapplication
or misuse of its products.

150 x 164 x 53 mm (5-7/8 x 6-7/16 x 2-1/8 in.) including terminals and mounting clips
Note: Mounting space requires an additional 50 mm (2 in.) space on top, bottom and front

face of controller for easy cover removal, ventilation and wire terminations.

Equipment
FCC Compliant to CFR47, Part 15, Subpart B, Class A

Canada: UL Listed, File E107041, CCN PAZX7, CAN/CSA C22.2 No. 205, Signal
Equipment Industry Canada Compliant, ICES-003

Europe: CE Mark – Johnson Controls, Inc. declares that this product is in compliance with
the essential requirements and other relevant provisions of the
EMC Directive 2004/108/EC.

Australia and New Zealand: C-Tick Mark, Australia/NZ Emissions Compliant
BACnet International: BACnet Testing Laboratories™ (BTL) 135-2004 Listed BACnet

Application Specific Controller (B-ASC)

FEC16 Extended Temperature Field Equipment Controller Installation Instructions16

Published in U.S.A. www.johnsoncontrols.com
