Johnson Controls Direct Mount Actuator Accessories Catalog

Electric Damper Actuators

Direct Mount Actuator Accessories

Direct Mount Actuator Accessories (Part 1 of 3)

Code
Number

Electric Damper Actuators

Electric Damper ActuatorsElectric Damper Actuators

CBL-2000-1 20 in. wire harness, actuator/transmitter to controller 1 ■
CBL-2000-2 20 in. cable, actuator/transmitter to controller, plenum rated 1 ■
CBL-2000-3 72 in. cable, actuator/transmitter To controller, plenum rated 1 ■

VAV

DPT-2015-0 Differential pressure transmitter, 0 to 1-1/2 in. W.C.

Accessories

M9000-606 Position indicators, M9203 and M9208 Series 5 ■
M9000-611 Position indicators, M9220 Series 5 ■
M9000-154 Jackshaft coupler kit, M9108 (16) (24) (32) Series (Ø 1 in.) 1 ■ ■ ■ ■
M9203-601 Standard coupler kit, M9203 Series (Ø 1/4 to 1/2 in.)

M9203-602 Retainer for M9203 coupler 5 ■
M9208-601 Standard coupler kit, M9208 Series (Ø 5/16 to 5/8 in.)

M9208-600 Large coupler kit, M9208 Series (Ø 1/2 to 3/4 in.)

M9220-601 Standard coupler kit M9220 Series (1/2 to 3/4 in.)

M9220-600 Jackshaft coupler kit, M9220 Series (3/4 to 1-1/16 in.)

S9208-608 8 mm square shaft adapter 5 ■
S9208-610 10 mm square shaft adapter 5
M9220-610 10 mm square shaft adapter with retainer 1

Shaft Couplers / Position Indicators

M9220-612 12 mm square shaft adapter with retainer 1 ■
M9220-614 14 mm square shaft adapter with retainer 1 ■
M9208-602 Retainer for M9208 coupler 5 ■
M9220-602 Retainer for M9220 coupler 5 ■
M9000-152 Reinforcement plate for mounting to thin sheet metal 1 ■ ■ ■ ■ ■
M9000-158 Tandem mounting bracket 1 ■ ■ ■ ■ ■
M9000-160 Anti-rotation bracket, M9106 (9) and M9108 (16) (24)

Brackets

Mounting

M9000-604 Anti-rotation bracket, M(S)9208 and M(S)9210 (20) Series 1 ■■ ■
M9000-153 Crankarm kit 1 ■ ■ ■ ■ ■
M9208-150 Crankarm kit 1 ■
M9000-150 Damper mount linkage kit for D1300 dampers 1 ■ ■ ■ ■
DMPR-KC254 Damper mount linkage kit for D1300 dampers 1 ■ ■ ■ ■
DMPR-KC260 Damper mount linkage kit for D1300 dampers 1 ■
DMPR-KC054 Damper blade ar m for D1300 dampers 1 ■ ■ ■ ■ ■■
DMPR-KC100 Damper blade linkage for D1300 dampers 1 ■ ■ ■ ■ ■■
DMPR-KC102 Damper push rod, Ø 5/16 x 48 in. length 1 ■ ■ ■ ■ ■■
M9000-151 Remote mounting kit with crankarm and damper linkage 1 ■ ■ ■
M9203-100 Remote mounting kit with crankarm 1 ■
M9203-110 Universal mounting kit 1 ■
M9203-115 Universal mounting kit with crankarm 1 ■

Damper Linkages / Accessories

M9203-150 Crankarm kit 1 ■
M9203-250 Remote mounting kit with crankarm and damper linkage for

Description

(0 to 374 Pa.)

(□ 1/4 to 5/16 in.)

(□ 1/4 to 1/2 in.)

(□ 3/8 to 9/16 in.)

(□ 3/8 to 1/2 in.)

(□ 5/8 to 3/4 in.)

(32) Series

D1300 dampers

1

Electric Damper Actuators

Qty Non-Spring Return Spring Return

1 ■

1

1

1

1

1

1

1

Code No. LIT-1900167

General Purpose General Purpose Safety

VAV

M9104(6)-AGx-2Nxx

M9102(4)-xGA-xS

M9106(9)-xGx-2

M9108

M9116

M9124

M9132

M9203

M9208

M9220

■

■

■

■

■

■

■ ■ ■ ■ ■

■

S9208

■

The performance specifications are nomina l and con form to accep table ind ustry stand ards. For applicati ons at con ditions be yond these specification s, consult th
Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. © 2014 Johnson Controls, Inc.

V–54

Electric Damper Actuators

Direct Mount Actuator Accessories (Continued)

Direct Mount Actuator Accessories (Part 2 of 3)

Code
Number

M9208-100 Remote mounting kit with crankarm 1 ■
M9208-250 Remote mounting kit with crankarm and damper linkage for

M9000-170 Remote mounting kit (horizontal) with crankarm 1 ■
M9000-270 Remote mounting kit (horizontal) with crankarm and damper

M9000-171 Remote mounting kit (vertical) with crankarm 1 ■
M9000-271 Remote mounting kit (vertical) with crankarm and damper

DMPR-KC300 Ball joint for Ø 5/16 in. rod, 1/4-20 x 9/16 in. thread mount 10 ■ ■ ■ ■ ■

(Cont.)

M9000-400 Jackshaft mounting kit, Ø 1/2 to 1.05 in. 1 ■ ■ ■ ■ ■■
M9000-402 Replacement hardware for M9000-400 jackshaft mounting kit 1 ■ ■ ■ ■ ■■
M9000-605 Ball joint for Ø 1/4 or 5/16 in. rods, 5/16-24 x 33/64 in. thread

Damper Linkages / Accessories

M9220-605 Ball joint for M8x1.25 threaded rod, M8x1.25 x 16.5 mm thread

DMPR-KC003 Blade pin extension (Ø 1/2 x 7 in.) for D1300 dampers 5 ■ ■ ■ ■ ■■ ■■
M9000-155 Manual handle 1 ■ ■ ■ ■
M9000-607 Position indicators, VA9203 and VA9208 Series
M9000-516 Ball valve linkage for non-spring return, 1/2 to 2 in. VG1000

M9000-518 Ball valve linkage for non-spring return, 2-1/2 to 4 in. VG1000

M9000-519 Ball valve linkage for spring return, 2-1/2 to 4 in. VG1000

M9000-551 Ball valve linkage, 1/2 to 1 in. hot/chilled water applications 1 ■
M9000-560 Ball valve linkage, 1/2 to 2 in. hot/chilled water applications 1 ■ ■
M9000-561 Thermal barrier for M9000-551 and M9000-560 ball valve

M9000-520 Ball valve linkage, special and larger valve applications 1 ■
M9000-530 Linkage for 2-1/2 in. flanged iron globe valves for single actuato r

M9000-531 Linkage for 3 in. flanged iron globe valves for single actuator

Valve Linkages

M9000-532 Linkage for 3 in. flanged iron globe valves for tandem actuator

M9000-533 Linkage for 5 in. flanged iron globe valves for single actuator

M9000-534 Linkage for 5 in. flanged iron globe valves for tandem actuator

M9000-535 Linkage for 6 in. flanged iron globe valves for single actuator

M9000-536 Linkage for 6 in. flanged iron globe valves for tandem actuator

M9000-537 Linkage for 4 in. flanged iron globe valves for tandem actuator

M9000-610 T andem a ctuator ada pter kit for VG2000 Seri es iron globe valve

Description

D1300 dampers

linkage for D1300 dampers

linkage for D1300 dampers

mount

mount

valves with 9 mm square stem

flanged valves with 11 mm square stem

flanged valves with 11 mm square stem

linkages permits use of M(VA)9xxx actuators on VG1000 valves
with low-pressure steam

mounting

mounting
Linkage for 4 in. flanged iron globe valves for single actuator

mounting

mounting
Linkage for 4 in. flanged iron globe valves for tandem actuator

mounting

mounting

mounting

mounting

mounting

mounting

linkages

1

Qty Non-Spring Return Spring Return

General Purpose General Purpose Safety

VAV

M9104(6)-AGx-2Nxx

M9102(4)-xGA-xS

M9106(9)-xGx-2

M9108

M9116

M9124

M9132

M9203

1

1

1

5

5

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

■ ■ ■

■ ■

■

■ ■ ■

■ ■ ■

■ ■

■ ■ ■

■ ■

■ ■

■ ■

■ ■

■ ■

■ ■

■ ■

■ ■■

M9208

■

M9220

■

■

■

■

Electric Damper ActuatorsElectric Damper ActuatorsElectric Damper ActuatorsElectric Damper Actuators

S9208

The performance specifications are no minal and co nform t o acceptab le ind ustry standar ds. For appl ications at condition s beyond these specifica tions, consult th
Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. © 2014 Johnson Controls, Inc.

V–55

Electric Damper Actuators

Direct Mount Actuator Accessories (Continued)

Direct Mount Actuator Accessories (Part 3 of 3)

Code
Number

Electric Damper Actuators

Electric Damper ActuatorsElectric Damper Actuators

M9000-310 Weather shield NEMA 3R, control dampers and VG2000Series

M9000-320 Weather shield NEMA 3R, control dampers and VG2000Series

M9000-330 Weather shield NEMA 3R, VG1000 Series ball valves with

M9000-340 Weather shield NEMA 3R, VG1000 Series ball valves with

M9000-321 Weather shield, NEMA 4X (IP66), control dampers 1 ■ ■

Weather Shields

M9000-341 Weather shield, NEMA 4X (IP66), 1/2 to 2 in. VG1000 Series

M9203-603 Adjustable stop kit 1 ■
M9208-603 Adjustable stop kit 1 ■
M9220-603 Adjustable stop kit

Adj. Stops

M9000-105 Pluggable 3-terminal block 1 ■ ■ ■ ■ ■
M9000-106 Pluggable 4-terminal block 1 ■
M9104-100 Conduit adapter for 3/8 in. flexible metal conduit 10 ■

Wiring

M9200-100 Threaded conduit adapters for 1/2 in. electrician’s fittings

Accessories

M9208-604 Manual crank, long, crank radius 2-13/16 in. (75 mm) 5 ■ ■
M9208-605 Manual crank, short, crank radius 1-13/16 in. (46.5 mm) 5

Tools

M9220-604 Manual crank 5
M9000-103 Transformer, 14 VA Class 2, 120 to 24 VAC 60 Hz 1 ■ ■ ■ ■
M9000-104 Transformer, 14 VA Class 2, 230 to 24 VAC 60 Hz 1 ■ ■ ■ ■
Y65G13-0 Transformer, 40 VA Class 2, 24 to 24 VAC 60 Hz isolation, foot

Y65A13-0 Transformer, 40 VA Class 2, 120 to 24 VAC 60 Hz, foot

Y65A21-0 Transformer, 40 VA Class 2, 120 to 24 VAC 60 Hz, box

Y65S13-0 Transformer, 40 VA Class 2, 208/240 to 24 VAC 60 Hz, foot

Y63T22-0 Transformer, 50 VA Class 2, 120/208/240 to 24 VAC 60 Hz, box

Y63T31-0 Transformer, 50 VA Class 2, 120/208/240 to 24 VAC 60 Hz,

Y66T12-0 Transformer, 75 VA Class 2, 120/208/240 t o 24 VAC 60 Hz, foot

Miscellaneous

Y66T13-0 Transformer, 75 VA Class 2, 120/208/240 t o 24 VAC 60 Hz, foot

Y64T15-0 Transformer, 92 VA Class 2, 120/208/240 t o 24 VAC 60 Hz, foot

Y64T21-0 Transformer, 92 VA Class 2, 120/208/240 to 24 VAC 60 Hz, box

Y64T22-0 Transformer, 92 VA Class 2, 120/208/240 to 24 VAC 60 Hz, box

M9000-200 Commissioning tool, for all 24V M(S)9xxx and M2202 Series

ST1.72E Duct thermal fuse, 162°F (72°C) 1

1. Ø means round shaft size (diameter); □ means square shaft size (each side)

Electric Damper Actuators

Description

iron globe valve linkages, non-spring return

iron globe valve linkages, spring return

M9000-516 or M9000-518 linkage, non-spring return

M9000-517 or M9000-519 linkage, spring return

ball valves (requires M9000-551 or M9000-560 ball valve
linkage kit)

mounting

mounting

mounting

mounting

mounting

foot/box mounting

mounting

mounting

mounting

mounting

mounting

actuators

1

Qty Non-Spring Return Spring Return

General Purpose General Purpose Safety

VAV

M9104(6)-AGx-2Nxx

M9102(4)-xGA-xS

M9106(9)-xGx-2

M9108

M9116

M9124

M9132

M9203

M9208

1

1

1

1

1

1

5

1 ■

1 ■

1 ■

1 ■

1 ■

1 ■

1 ■

1 ■

1 ■

1 ■

1 ■

1 ■

■ ■ ■ ■ ■

■ ■ ■

■ ■

■■■ ■ ■ ■ ■■

■■■ ■ ■ ■ ■■

■■■ ■ ■ ■ ■■

■■■ ■ ■ ■ ■■

■■■ ■ ■ ■ ■■

■■■ ■ ■ ■ ■■

■■■ ■ ■ ■ ■■

■■■ ■ ■ ■ ■■

■■■ ■ ■ ■ ■■

■■■ ■ ■ ■ ■■

■■■ ■ ■ ■ ■■

■■■ ■ ■ ■ ■■ ■

M9220

■

■

■

■ ■

■

S9208

■

The performance specifications are no minal and co nform t o acceptab le ind ustry standar ds. For appl ications at condition s beyond these specifica tions, consult th
Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. © 2014 Johnson Controls, Inc.

V–56

M9106-AGA-2N

M9106-AGS-2N

Electric Damper Actuators

Direct Mount Actuator Accessories (Continued)

M9104-AGx-2Nxx and M9106-AGx-2Nxx Series Actuator Accessories

Electric Damper ActuatorsElectric Damper ActuatorsElectric Damper ActuatorsElectric Damper Actuators

M9104-AGx-2Nxx and M9106-AGx-2Nxx Series Actuator Accessories

Code Number Description Qty

Variable Air Volume (VAV) System Accessories

CBL-2000-1 20 in. (0.5 m) plenum rated wiring harness 1

(CBL-2000-1.tif)

CBL-2000-2 20 in. (0.5 m) plenum rated wiring harness 1

(CBL-2000-2.tif)

CBL-2000-3 72 in. (1.8 m) plenum rated wiring harness 1

(CBL-2000-3.tif)

DPT-2015-0 0 to 1.5 in W.C. (0 to 375 Pa) differential pressure transmitter 1

(DPT-2015-0.tif)

The performance specifications are no minal and co nform t o acceptab le ind ustry standar ds. For appl ications at condition s beyond these specifica tions, consult th
Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. © 2014 Johnson Controls, Inc.

V–57

M9102/9104-xGA-2S

(M9102-AGA-2S.tif)

M9102/9104-xGA-3S

(M9102-IGA-3S.tif)

Electric Damper Actuators

Direct Mount Actuator Accessories (Continued)

M9102-xGA-xS and M9104-xGA-xS Series Actuator Accessories

Electric Damper Actuators

Electric Damper ActuatorsElectric Damper Actuators

M9102-xGA-xS and M9104-xGA-xS Series Actuator Accessories

Valve Linkages

Electric Damper Actuators

Code Number Description Qty

M9000-551 VG1000 ball valve linkage

(for use with M9104 Series actuators only)

1

(M9000-550 ii01.cdr)
from 34-636-1816

(M9000_561.jpg)

Weather Shields

(M9000_341.jpg)

Wiring Accessories

(M9000-550.tif)

M9000-561 Thermal barrier for M9000-560 and M9000-551 ball valve linkages.

Permits use of M(VA)9xxx actuators on VG1000 Series ball valves
with low-pressure steam

M9000-341 Weather shield NEMA4x (IP66), 1/2 to 2 in. for VG1000 Series ball

valves

M9104-100 3/8 in. (10 mm) flexible metal conduit adapter kit

(for use with M9102-xxx-2S or M9104-xxx-2S actuators with
integrated wiring harness only)

1

1

10

(M9104-100.tif)

The performance specifications are no minal and co nform t o acceptab le ind ustry standar ds. For appl ications at condition s beyond these specifica tions, consult th
Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. © 2014 Johnson Controls, Inc.

V–58

M9106-GGA-2

(M9106-GGA-2.tif)

Electric Damper Actuators

Direct Mount Actuator Accessories (Continued)

M9106-xGx-2 and M9109-xGx-2 Serie s Act u at o r Acce ss o rie s

Electric Damper ActuatorsElectric Damper ActuatorsElectric Damper ActuatorsElectric Damper Actuators

M9106-xGx-2 and M9109-xGx-2 Series Actuator Accessories

Code Number

Mounting Brackets

M9000-160 Anti-rotation bracket for M9106(9) and M9108(16)(24)(32) Series

(M9000-160.tif)

Damper Linkages / Accessories

DMPR-KC003 Blade pin extension (Ø 1/2 x 7 in.)

(DMPR-KC003.tif)

Valve Linkages

M9000-520 VG1000 ball valve linkage

(M9000-520.tif)

(from 14-1297-5)

Weather Shields

M9000-310 NEMA 3R weather shield for control dampers 1

Description

1

actuators

(for use with D1300 dampers only)

(for special and larger valve applications)

Qty

1

5

1

(M9000-310.tif)

Wiring Accessories

M9000-105 Pluggable 3-terminal block 1

(M9000-105.tif)

M9000-106 Pluggable 4-terminal block 1

(M9000-106.tif)

1. Ø means round shaft size (diameter); □ means square shaft size (each side)

The performance specifications are no minal and co nform t o acceptab le ind ustry standar ds. For appl ications at condition s beyond these specifica tions, consult th
Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. © 2014 Johnson Controls, Inc.

V–59

M9108-AGA-2

(M9108-AGA-2.tif)

Electric Damper Actuators

Direct Mount Actuator Accessories (Continued)

M9108, M9116, M9124, and M9132 Series Actuator Accessories

Electric Damper Actuators

Electric Damper ActuatorsElectric Damper Actuators

M9108, M9116, M9124, and M9132 Series Actuator Accessories (Part 1 of 4)

Shaft Couplers / Position Indicators

Electric Damper Actuators

Code Number

Description

M9000-154 Jackshaft coupler kit for

M9108 (16) (24) (32) Series actuators, (Ø 1 in.)

1

Qty

1

(M9000-154.tif)

(from LIT-1900167)

Mounting Brackets

(M9000-152.tif)

(M9000-158.tif)

(M9000-160.tif)

Damper Linkages / Accessories

(DMPR-KC003.tif)

M9000-152 Reinforcing plate for mounting to thin sheet metal 1

M9000-158 Tandem mounting bracket 1

M9000-160 Anti-rotation bracket 1

DMPR-KC003 Blade pin extension (Ø 1/2 x 7 in.)

DMPR-KC054 Blade pin extension (Ø 1/2 x 7 in.)

(for use with D1300 dampers only)

(for use with D1300 dampers only)

5

1

(DMPR-KC054.tif)

The performance specifications are no minal and co nform t o acceptab le ind ustry standar ds. For appl ications at condition s beyond these specifica tions, consult th
Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. © 2014 Johnson Controls, Inc.

V–60

Electric Damper Actuators

Direct Mount Actuator Accessories (Continued)

M9108, M9116, M9124, and M9132 Series Actuator Accessories (Part 2 of 4)

Code Number

Description

DMPR-KC100 Damper blade linkage (for use with D1300 dampers only) 1

1

Qty

(DMPR-KC100.tif)

(DMPR-KC102.tif)

(DMPR-KC260.tif)

(DMPR-KC300)

(M9000-150.tif)

(from LIT-1900167)

(M9000-151.tif)

DMPR-KC102 Damper push rod, Ø 5/16 x 48 in. 1

DMPR-KC254 Damper mount linkage kit (for use with D1300 dampers only) 1

DMPR-KC300 Ball joint for Ø 5/16 in. rod, 1/4-20 x 9/16 in. thread mount 10

M9000-150 Damper mounting kit for remote, inside-duct mounting an M9108

(16) (24) Series actuator to a three-blade or larger damper

M9000-151 Remote mounting kit, with crankarm and damper linkage for M9108

M9000-153 Crankarm kit

(16) (24) Series actuators
Use the M9000-151 linkage only on three-blade or larger dampers

(not for use with M9132 Series actuators or tandem applications)

(not for use with M9132 Series actuators or tandem applications)

Electric Damper ActuatorsElectric Damper ActuatorsElectric Damper ActuatorsElectric Damper Actuators

1

1

1

(M9000-153.tif)

M9000-400 Jackshaft mounting kit, Ø 0.5 to 1.05 in. 1

(M9000_400.jpg)

M9000-402 Replacement hardware for M9000-400 jackshaft mounting kit 1

(M9000_402.jpg)

The performance specifications are no minal and co nform t o acceptab le ind ustry standar ds. For appl ications at condition s beyond these specifica tions, consult th
Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. © 2014 Johnson Controls, Inc.

V–61

Electric Damper Actuators

Direct Mount Actuator Accessories (Continued)

M9108, M9116, M9124, and M9132 Series Actuator Accessories (Part 3 of 4)

Valve Linkages

Electric Damper Actuators

Electric Damper ActuatorsElectric Damper Actuators

(M9000-155.tif)

(M9000-516.tif)

(M9000-518.tif)

Electric Damper Actuators

Code Number

M9000-155 Manual handle 1

M9000-516 Ball valve linkage f or non-spring return,

M9000-518 Ball valve linkage for non-spring return, 2-1/2 to 4 in. VG1000

M9000-530 VG200 0 linkage kit for single M9116 (24) Series electric actuator and

M9000-531 VG200 0 linkage kit for a single M9116 (24) Series electric actuator

M9000-533 VG200 0 linkage kit for a single M9124 Series electric actuator and

M9000-535 VG200 0 linkage kit for a single M9124 Series electric actuator and

Description

1/2 to 2 in. VG1000 valves with 9 mm square stem

flanged valves with 11 mm square stem

Johnson Controls
3/8 in. stems

and Johnson Controls 3 to 4 in. cast iron globe valves with
3/8 in. stems

Johnson Controls 5 in. cast iron globe valves with 1/2 in. stems

Johnson Controls 6 in. cast iron globe valves with 1/2 in. stems

1

® 2-1/2 in. cast iron globe valves with

Qty

1

1

1

1

1

1

(M9000-531.tif)

(M9000-534.tif)

(M9000-610.tif)

M9000-532 VG200 0 linkage kit for tandem M9124 Series electric actuators and

M9000-534 VG200 0 linkage kit for tandem M9124 Series electric actuators and

M9000-536 VG200 0 linkage kit for tandem M9124 Series electric actuators and

M9000-537 VG200 0 linkage kit for tandem M9124 Series electric actuators and

M9000-610 Tandem actuator adapter kit for VG2000 Series iron globe valve

Johnson Controls 3 to 4 in. cast iron globe valves with 3/8 in. stems

Johnson Controls 5 in. cast iron globe valves with 1/2 in. stems

Johnson Controls 6 in. cast iron globe valves with 1/2 in. stems

Johnson Controls 3 to 4 in. cast iron globe valves with 1/2 in. stems

linkages (not for use with the M9000-530 linkage)

1

1

1

1

1

The performance specifications are no minal and co nform t o acceptab le ind ustry standar ds. For appl ications at condition s beyond these specifica tions, consult th
Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. © 2014 Johnson Controls, Inc.

V–62

Electric Damper Actuators

Direct Mount Actuator Accessories (Continued)

M9108, M9116, M9124, and M9132 Series Actuator Accessories (Part 4 of 4)

Code Number

Weather Shields

M9000-310 NEMA 3R weather shield for control dampers or M9000-53x linkage

Description

kits on VG2000 Series cast iron flanged globe valves

1

Qty

1

Electric Damper ActuatorsElectric Damper ActuatorsElectric Damper ActuatorsElectric Damper Actuators

(M9000-310.tif)

M9000-330 NEMA 3R weather shield for VG1000 Series

(M9000-330.tif)

Wiring Accessories

M9000-105 Pluggable 3-terminal block

(M9000-105.tif)

Miscellaneous (Unique to M9108[16][24][32] Series Actuators)

M9000-103 Transformer, Class 2, 120/24 VAC 1

(M9000-103.tif)

M9000-104 Transformer, Class 2, 230/24 VAC 1

(M9000-104.tif)

1. Ø means round shaft size (diamete r); □ means square shaft size (each side)

non-spring-return ball valves with M9000-516 or M9000-518 linkage

1

The performance specifications are no minal and co nform t o acceptab le ind ustry standar ds. For appl ications at condition s beyond these specifica tions, consult th
Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. © 2014 Johnson Controls, Inc.

V–63

M9203-GGB-2

(M9203.jpg)

Electric Damper Actuators

Direct Mount Actuator Accessories (Continued)

M9203 Series Actuator Accessories

Electric Damper Actuators

Electric Damper ActuatorsElectric Damper Actuators

M9203 Series Actuator Accessories (Part 1 of 4)

Shaft Couplers / Position Indicators

Electric Damper Actuators

Code Number

M9000-606 Position indicators, M9203 and M9208 Series 1

Description

1

Qty

(M9000_606.jpg)

(M9203_601.jpg)

(M9203_602.jpg)

Mounting Brackets

(M9000_604.jpg)

M9203-601 Standard coupler kit, M9203 Series

M9203-602 Retainer for M9203 coupler 5

M9000-604 Anti-rotation bracket 1

(Ø 1/4 to 1/2 in.) (□ 1.4 to 5/16 in.)

1

The performance specifications are no minal and co nform t o acceptab le ind ustry standar ds. For appl ications at condition s beyond these specifica tions, consult th
Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. © 2014 Johnson Controls, Inc.

V–64

Electric Damper Actuators

Direct Mount Actuator Accessories (Continued)

M9203 Series Actuator Accessories (Part 2 of 4)

Weather Shields

(M9000_321.jpg)

(M9000_341.jpg)

Damper Linkages / Accessories

(DMPR-KC003.tif)

Code Number

Description

1

M9000-321 Weather shield NEMA 4x (IP66), control dampers 1

M9000-341 Weather shield NEMA 4x (IP66), 1/2 to 2 in. VG1000 Series ball

DMPR-KC003 Blade pin extension (Ø 1/2 x 7 in.)

valves

(for use with D1300 dampers only)

DMPR-KC054 Damper blade arm (for use with D1300 dampers only) 1

Qty

Electric Damper ActuatorsElectric Damper ActuatorsElectric Damper ActuatorsElectric Damper Actuators

1

1

(DMPR-KC054.tif)

(DMPR-KC100.tif)

(DMPR-KC102.tif)

(M9203_100.jpg)

DMPR-KC100 Damper blade linkage (for use with D1300 dampers only) 1

DMPR-KC102 Blade pin extension (Ø 1/2 x 7 in.)

(for use with D1300 dampers only)

M9203-100 Remote mounting kit with crankarm 1

1

The performance specifications are no minal and co nform t o acceptab le ind ustry standar ds. For appl ications at condition s beyond these specifica tions, consult th
Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. © 2014 Johnson Controls, Inc.

V–65

Electric Damper Actuators

Direct Mount Actuator Accessories (Continued)

M9203 Series Actuator Accessories (Part 3 of 4)

Electric Damper Actuators

Electric Damper ActuatorsElectric Damper Actuators

(M9203_110.jpg)

(M9203_115.jpg)

Electric Damper Actuators

Code Number

M9203-110 Universal mounting kit 1

M9203-115 Universal mounting kit with crankarm 1

M9203-150 Crankarm kit 1

Description

1

Qty

(M9203_150.jpg)



Adjustable Stops

(M9203_603.jpg)

M9203-250 Remote mounting kit with crankarm and damper linkage for

M9000-605 Ball joint for Ø 1/4 and Ø 5/16 in. rods, 5/16-24 x 33/64 in. thread

M9203-603 Adjustable stop kit 1

D1300 dampers

mount

1

5

The performance specifications are no minal and co nform t o acceptab le ind ustry standar ds. For appl ications at condition s beyond these specifica tions, consult th
Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. © 2014 Johnson Controls, Inc.

V–66

Electric Damper Actuators

Direct Mount Actuator Accessories (Continued)

M9203 Series Actuator Accessories (Part 4 of 4)

Valve Linkages

(M9000_607.jpg)

(M9000-560.jpg)

Code Number

M9000-607 Position indicators, VA9203 and VA9208 Series 1

M9000-560 Ball valve linkage for spring return,

M9000-561 Thermal barrier for M9000-560 and M9000-551 ball valve linkages.

Description

1/2 to 2 in. hot and chilled water applications

Permits use of M(V A)9xxx actuators on VG1000 valves with
low-pressure steam

1

Qty

Electric Damper ActuatorsElectric Damper ActuatorsElectric Damper ActuatorsElectric Damper Actuators

1

1


1. Ø means round shaft size (diamete r); □ means square shaft size (each side)

The performance specifications are no minal and co nform t o acceptab le ind ustry standar ds. For appl ications at condition s beyond these specifica tions, consult th
Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. © 2014 Johnson Controls, Inc.

V–67

M9208-BAC-3

(M9208-BAC-3.tif)

Electric Damper Actuators

Direct Mount Actuator Accessories (Continued)

M9208 Series Actuator Accessories

Electric Damper Actuators

Electric Damper ActuatorsElectric Damper Actuators

M9208 Series Actuator Accessories (Part 1 of 3)

Shaft Couplers / Position Indicators

Electric Damper Actuators

Code Number

M9208-600 Large coupler kit for use with M9208 Series actuators

Description

(Ø 1/2 to 3/4 in. and □ 3/8 to 9/16 in.)

1

Qty

1

(M9000-600.tif)

(M9000-601.tif)

(M9208-602.tif)

Mounting Brackets

(M9000-604.tif)

Tools

(M9208-604.tif)

(M9208-605.tif)

M9208-601 Standard coupler kit for use with M9208 Series actuators

(Ø 5/16 to 5/8 in. and □ 1/4 to 1/2 in.)

M9208-602 Retainer for M9208 coupler 5

M9000-604 Anti-rotation bracket 1

M9208-604 Long manual crank, 2-13/16 in. (72 mm) crank radius 5

M9208-605 Short manual crank, 1-13/16 in. (47 mm) crank radius 5

M9000-321 Weather shield NEMA 4X(IP66), control dampers 1

1

(M9000_321.jpg)

The performance specifications are no minal and co nform t o acceptab le ind ustry standar ds. For appl ications at condition s beyond these specifica tions, consult th
Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. © 2014 Johnson Controls, Inc.

V–68

Electric Damper Actuators

Direct Mount Actuator Accessories (Continued)

M9208 Series Actuator Accessories (Part 2 of 3)

Weather Shields

(M9000_341.jpg)

Damper Linkages / Accessories

(DMPR-KC003.tif)

Code Number

M9000-341 Weather shield NEMA 4X(IP66),

Description

1/2 to 2 in. VG1000 Series ball valves

DMPR-KC003 Blade pin extension (Ø 1/2 x 7 in.)

(for use with D1300 dampers only)

DMPR-KC054 Damper blade arm (for use with D1300 dampers only) 1

1

Qty

1

Electric Damper ActuatorsElectric Damper ActuatorsElectric Damper ActuatorsElectric Damper Actuators

5

(DMPR-KC054.tif)

(DMPR-KC100.tif)

(DMPR-KC102.tif)

(M9000_400.jpg)

(M9000_402.jpg)

DMPR-KC100 Damper blade linkage (for use with D1300 dampers only) 1

DMPR-KC102 Damper push rod , Ø 5/ 16 x 48 in. 1

M9000-400 Jackshaft mounting kit, Ø 0.5 to 1.05 in.

M9000-402 Replacement hardware for M9000-400 jackshaft mounting kit

M9000-605 Ball joint for Ø 1/4 and Ø 5/16 in. rods,

5/16-24 x 33/64 in. thread mount

5


M9208-100 Remote mounting kit with crankarm 1

(M9208-100.tif)

The performance specifications are no minal and co nform t o acceptab le ind ustry standar ds. For appl ications at condition s beyond these specifica tions, consult th
Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. © 2014 Johnson Controls, Inc.

V–69

Electric Damper Actuators

Direct Mount Actuator Accessories (Continued)

M9208 Series Actuator Accessories (Part 3 of 3)

Damper Linkages / Accessories

Electric Damper Actuators

Electric Damper ActuatorsElectric Damper Actuators

(M9208-150.tif)

(M9208-250.tif)

Adjustable Stops

(M9208-603.tif)

Wiring Accessories

Electric Damper Actuators

Code Number

M9208-150 Crankarm kit 1

M9208-250 Remote mounting kit with crankarm and damper linkage

M9208-603 Adjustable stop kit 1

M9200-100 Threaded conduit adapters for 1/2 in. electrician’s fittings 1

Description

(for use with D1300 dampers only)

1

Qty

1

(M9200_100.jpg)

1. Ø means round shaft size (diamete r); □ means square shaft size (each side)

The performance specifications are no minal and co nform t o acceptab le ind ustry standar ds. For appl ications at condition s beyond these specifica tions, consult th
Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. © 2014 Johnson Controls, Inc.

V–70

M9220-BAC-3

(M9220-BAC-3.tif)

Electric Damper Actuators

Direct Mount Actuator Accessories (Continued)

M9220 Series Actuator Accessories

M9220 Series Actuator Accessories (Part 1 of 4)

Shaft Couplers / Position Indicators

Code Number

Description

M9000-611 Position indicators for use with M9220 Series actuators 5

Electric Damper ActuatorsElectric Damper ActuatorsElectric Damper ActuatorsElectric Damper Actuators

1

Qty

(M9000-611.tif)

(M9220-600A.tif)

(M9220-601.tif)

(M9220-602.tif)

(M9220-610.tif)

Mounting Brackets

(M9000-152.tif)

(M9220-602.tif)

M9220-600 Jackshaft coupler kit for use with M9220 Series actuators

Ø 3/4 in. to 1-1/16 in. (19 to 27 mm) round shafts;
or 5/8 and 3/4 in. (16, 18 and 19 mm) square shafts

M9220-601 Standard coupler kit for use with M9220 Series actuators

Ø 1/2 to 3/4 in. (12 to 19 mm) round shafts;
or 3/8 and 1/2 in. (10, 12 and 14 mm) square shafts

M9220-602 Retainer for M9220 coupler 5

M9220-610 10 mm square shaft adapter with retainer 1

M9220-612 12 mm square shaft adapter with retainer 1

M9220-614 14 mm square shaft adapter with retainer 1

M9000-152 Reinforcing plate for mounting to thin sheet metal 1

M9000-158 Tandem mounting bracket 1

1

1

(M9000-158.tif)

The performance specifications are no minal and co nform t o acceptab le ind ustry standar ds. For appl ications at condition s beyond these specifica tions, consult th
Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. © 2014 Johnson Controls, Inc.

V–71

Electric Damper Actuators

Direct Mount Actuator Accessories (Continued)

M9220 Series Actuator Accessories (Part 2 of 4)

(M9000-604.tif)

Electric Damper Actuators

Electric Damper ActuatorsElectric Damper Actuators

Damper Linkages / Accessories

(DMPR-KC003.tif)

(DMPR-KC054.tif)

(DMPR-KC100.tif)

Electric Damper Actuators

Code Number

Description

M9000-604 Anti -rotation bracket 1

DMPR-KC003 Blade pin extension (Ø 1/2 x 7 in.)

(for use with D1300 dampers only)

DMPR-KC054 Damper blade arm (for use with D1300 dampers only) 1

DMPR-KC100 Damper blade linkage (for use with D1300 dampers only) 1

DMPR-KC102 Damper push rod, Ø 5/16 x 48 in. 1

1

Qty

5

(DMPR-KC102.tif)

(DMPR-KC260.tif)

(M9000-153.tif)

(M9000-170.tif)

(M9000-171.tif)

DMPR-KC260 Damper mount linkage kit (for use with D1300 dampers only) 1

M9000-153 Crankarm kit

(not for use with M9132 series actuators or tandem applications)

M9000-170 Remote mounting kit (horizontal) with crankarm and ball joint 1

M9000-171 Remote mounting kit (vertical) with crankarm and ball joint 1

M9000-270 Remote mounting kit (horizontal) with crankarm and damper

linkage (for use with D1300 dampers only)

1

1

(M-9000-270.tif)

The performance specifications are no minal and co nform t o acceptab le ind ustry standar ds. For appl ications at condition s beyond these specifica tions, consult th
Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. © 2014 Johnson Controls, Inc.

V–72

Electric Damper Actuators

Direct Mount Actuator Accessories (Continued)

M9220 Series Actuator Accessories (Part 3 of 4)

(M9000-271.tif)

(M9000_400.jpg)

(M9000_402.jpg)

Code Number

Description

1

M9000-271 Remote mounting kit (vertical) with crankarm and damper linkage

(for use with D1300 dampers only)

M9000-400 Jackshaft mounting kit, Ø 0.5 to 1.05 in. 1

M9000-402 Replacement hardware for M9000-400 jackshaft mounting kit 1

M9000-605 Ball joint for Ø 1/4 and Ø 5/16 in. rods,

5/16-24 x 33/64 in. thread mount

Qty

1

Electric Damper ActuatorsElectric Damper ActuatorsElectric Damper ActuatorsElectric Damper Actuators

5

(M9000_605.jpg)

(M9220-605.tif)

Valve Linkages

(M9000-518.tif)

(M9000-531.tif)

M9220-605 Ball joint for M8x1.25 threaded rod, M8x1.25 x 16.5 mm thread

mount

M9000-519 Ball valve linkage for spring return, 2-1/2 to 4 in. VG1000 flanged

valves with 11 mm square stem

M9000-530 VG2000 linkage kit for M9220 Series electric actuator and

Johnson Controls 2-1/2 in. cast iron globe valves with
3/8 in. stems

M9000-531 VG2000 linkage kit for a single M9220 Series electric actuator and

Johnson Controls 3 in. and 4 in. cast iron globe valves with 3/8 in.
stems

M9000-533 VG2000 linkage kit for a single M9220 Series electric actuator and

M9000-535 VG2000 linkage kit for a single M9220 Series electric actuator and

Johnson Controls 5 in. cast iron globe valves with 1/2 in. stems

Johnson Controls 6 in. cast iron globe valves with 1/2 in. stems

5

1

1

1

1

1

The performance specifications are no minal and co nform t o acceptab le ind ustry standar ds. For appl ications at condition s beyond these specifica tions, consult th
Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. © 2014 Johnson Controls, Inc.

V–73

Electric Damper Actuators

Direct Mount Actuator Accessories (Continued)

M9220 Series Actuator Accessories (Part 4 of 4)

Electric Damper Actuators

Electric Damper ActuatorsElectric Damper Actuators

(M9000-535.tif)

(M9000-610.tif)

Weather Shields

Electric Damper Actuators

Code Number

Description

M9000-532 VG2000 linkage kit for tandem M9220 Series electric actuators and

Johnson Controls 3 in. and 4 in. cast iron globe valves with 3/8 in.
stems

M9000-534 VG2000 linkage kit for tandem M9220 Series electric actuators and

Johnson Controls 5 in. cast iron globe valves with 1/2 in. stems

M9000-536 VG2000 linkage kit for tandem M9220 Series electric actuators and

M9000-537 VG2000 linkage kit for tandem M9220 Series electric actuators and

Johnson Controls 6 in. cast iron globe valves with 1/2 in. stems

Johnson Controls 3 in. and 4 in. cast iron globe valves with 1/2 in.
stems

M9000-610 Tandem actuator adapter kit for VG2000 Series iron globe valve

linkages (not for use with the M9000-530 linkage)

M9000-320 NEMA 3R weather shield for control dampers or M9000-53x Series

linkage kits on VG2000 Series cast iron flanged globe valves

1

Qty

1

1

1

1

1

1

(M9000-320.tif)

M9000-340 NEMA 3R weather shield for VG1000 Series ball valves with

(M9000-340.tif)

Adjustable Stops

M9220-603 Adjustable stop kit 1

(M9220-603.tif)

Wiring Accessories

M9200-100 Threaded conduit adapters for 1/2 in. electrician’s fittings

(M9200_100.jpg)

Tools

M9220-604 Manual crank 5

(M9220-604.tif)

1. Ø means round shaft size (diamete r); □ means square shaft size (each side)

M9000-517 or M9000-519 linkage, spring return

1

The performance specifications are no minal and co nform t o acceptab le ind ustry standar ds. For appl ications at condition s beyond these specifica tions, consult th
Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. © 2014 Johnson Controls, Inc.

V–74

S9208-BDC-33C

(S9208BDC33C.tif)

Electric Damper Actuators

Direct Mount Actuator Accessories (Continued)

S9208 Series Actuator Accessories

S9208 Series Actuator Accessories

Code Number Description Qty

Shaft Couplers / Position Indicators

S9208-608 8 mm square shaft adapter 5

Electric Damper ActuatorsElectric Damper ActuatorsElectric Damper ActuatorsElectric Damper Actuators

(S9208-608.tif)

(S9208-610.tif)

Mounting Brackets

(M9000-604.tif)

Tools

(M9208-604.tif)

(M9208-605.tif)

Miscellaneous

(ST1.tif)

S9208-610 10 mm square shaft adapter 5

M9000-604 Anti-rotation bracket 5

M9208-604 Long manual crank, 2-13/16 in. (72 mm) crank radius 5

M9208-605 Short manual crank, 1-13/16 in. (47 mm) crank radius 5

ST1.72E Duct thermal fuse, 162°F (72°C) 1

The performance specifications are no minal and co nform t o acceptab le ind ustry standar ds. For appl ications at condition s beyond these specifica tions, consult th
Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. © 2014 Johnson Controls, Inc.

V–75

Electric Damper Actuators

Direct Mount Actuator Accessories (Continued)

Miscellaneous Accessories

Miscellaneous Accessories

Transformers

Electric Damper Actuators

Electric Damper ActuatorsElectric Damper Actuators

(Y63T22.tif)

(Y63T31.tif)

(Y64T15.tif)

(Y64T21.tif)

Electric Damper Actuators

Code Number Description Qty

Y63T22-0 Transformer, 50 VA Class 2, 120/208/240 to 24 VAC 60 Hz, box

Y63T31-0 Transformer, 50 VA Class 2, 120/208/240 to 24 VAC 60 Hz,

Y64T15-0 Transformer, 92 VA Class 2, 120/208/240 to 24 VAC 60 Hz, foot

Y64T21-0 Transformer, 92 VA Class 2, 120/208/240 to 24 VAC 60 Hz, box

Y64T22-0 Transformer, 92 VA Class 2, 120/208/240 to 24 VAC 60 Hz, box

mounting

foot/box mounting

mounting

mounting

mounting

1

1

1

1

1

(Y64T22.tif)

(Y65A13.tif)

(Y65A21.tif)

(Y65G13.tif)

(Y65S13.tif)

(Y65T12.tif)

(Y66T13.tif)

Commissioning Tool

Y65A13-0 Transformer, 40 VA Class 2, 120 to 24 VAC 60 Hz, foot mounting 1

Y65A21-0 Transformer, 40 VA Class 2, 120 to 24 VAC 60 Hz, box mounting 1

Y65G13-0 Transformer, 40 VA Class 2, 24 to 24 VAC 60 Hz isolation, foot

mounting

Y65S13-0 Transformer, 40 VA Class 2, 208/240 to 24 VAC 60 Hz, foot

mounting

Y66T12-0 Transformer, 75 VA Class 2, 120/208/240 to 24 VAC 60 Hz, foot

mounting

Y66T13-0 Transformer, 75 VA Class 2, 120/208/240 to 24 VAC 60 Hz, foot

mounting

M9000-200 Commissioning tool for all 24V M(S)9xxx and M2202 Series

actuators

1

1

1

1

1

(M9000_200.jpg)

The performance specifications are no minal and co nform t o acceptab le ind ustry standar ds. For appl ications at condition s beyond these specifica tions, consult th
Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. © 2014 Johnson Controls, Inc.

V–76
