Johnson Amplification JM60 User Manual

User’s Guide

please visit Johnson Amplification on the World Wide Web at http//www.johnson-amp.com

The symbols shown above are internationally accepted symbols that warn of potential
hazards with electrical products.The lightning flash with arrowpoint in an equilateral
triangle means that there are dangerous voltages present within the unit.The exclama­tion point in an equilateral triangle indicates that it is necessary for the user to refer
to the owner’s manual.

These symbols warn that there are no user serviceable parts inside the unit.Do not
open the unit.Do not attempt to service the unit yourself.Refer all servicing to quali­fied personnel.Opening the chassis for any reason will void the manufacturer’s warran­ty.Do not get the unit wet.If liquid is spilled on the unit,shut it off immediately and
take it to a dealer for service. Disconnect the unit during storms to prevent damage.

WARNING

FOR YOUR PR OTECTION, PLEASE READ THE FOLLO WING:

WATER AND MOISTURE: Appliance should not be used near water (e.g.near a bathtub,

washbowl,kitchen sink,laundry tub,in a wet basement,or near a swimming pool,etc). Care
should be taken so that objects do not fall and liquids are not spilled into the enclosure
through openings.

POWERSOURCES: The appliance should be connected to a power supply only of the
type described in the operating instructions or as marked on the appliance.

GROUNDINGORPOLARIZATION: Precautions should be taken so that the grounding
or polarization means of an appliance is not defeated.

POWERCORDPR OTECTION: Power supply cords should be routed so that they are
not likely to be walked on or pinched by items placed upon or against them,paying particular
attention to cords at plugs,convenience receptacles,and the point where they exit from the
appliance.

SERVICING: To reduce the risk of fire or electric shock,the user should not attempt to
service the appliance beyond that described in the operating instructions. All other servicing
should be referred to qualified service personnel.

FOR UNITS EQUIPPED WITH EXTERNALL YACCESSIBLE FUSE RECEPT A­CLE: Replace fuse with same type and rating only.

U.K. MAINS PLUG WARNING

A molded mains plug that has been cut off from the cord is unsafe. Discard the mains
plug at a suitable disposal facility. NEVER UNDER ANY CIRCUMSTANCES

SHOULD YOU INSER T A DAMAGED OR CUT MAINS PLUG INT O A 13
AMP POWER SOCKET . Do not use the mains plug without the fuse cover in place.

Replacement fuse covers can be obtained from your local retailer. Replacement fuses
are 13 amps and MUST be ASTA approved to BS1362.

SAFETY INSTR UCTIONS

NOTICE FOR CUSTOMERS IF YOUR UNIT IS EQUIPPED WITH A
POWER CORD .

WARNING: THISAPPLIANCEMUSTBEEARTHED .

The cores in the mains lead are coloured in accordance with the following code:

GREEN and YELLOW - Earth BLUE - Neutral BROWN - Live

As colours of the cores in the mains lead of this appliance may not correspond with
the coloured markings identifying the terminals in your plug,proceed as follows:

•The core which is coloured green and yellow must be connected to the termi­nal in the plug marked with the letter E,or with the earth symbol,or coloured
green,or green and yellow.

•The core which is coloured blue must be connected to the terminal marked N
or coloured black.

• The core which is coloured brown must be connected to the terminal marked
L or coloured red.

This equipment may require the use of a different line cord,attachment plug,or both,
depending on the available power source at installation. If the attachment plug needs
to be changed, refer servicing to qualified service personnel who should refer to the
table below. The green/yellow wire shall be connected directly to the unit's chassis.

ELECTR OMA GNETIC COMP ATIBILITY

This unit conforms to the Product Specifications noted on the Declaration of
Conformity . Operation is subject to the following two conditions:

• this device may not cause harmful interference,and

• this device must accept any interference received,including interference that
may cause undesired operation. Operation of this unit within significant elec­tromagnetic fields should be avoided.

• use only shielded interconnecting cables.

LITHIUM BA TTER Y WARNING

CAUTION!

This product may contain a lithium battery.There is danger of explosion if the battery is
incorrectly replaced.Replace only with an Eveready CR 2032 or equivalent.Make sure
the battery is installed with the correct polarity. Discard used batteries according to
manufacturer’s instructions.

ADVARSEL!

Lithiumbatteri - Eksplosjonsfare.Ved utskifting benyttes kun batteri som anbefalt av
apparatfabrikanten. Brukt batteri returneres apparatleverandøren.

ADVARSEL!

Lithiumbatteri - Eksplosionsfare ved fejlagtig håndtering. Udskiftning må kun ske med
batteri av samme fabrikat og type.Levér det brugte batteri tilbage til leverandøren.

VAROITUS!

Paristo voi räjähtää,jos se on virheellisesti asennettu.Vaihda paristo ainoastaan laite­valmistajan suosittelemaan tyyppin.Hävitä käytetty paristo valmistajan ohjeiden
mukaisesti.

VARNING!

Explosionsfara vid felaktigt batteribyte.Använd samma batterityp eller en ekvivalent typ
som rekommenderas av apparattillverkaren.Kassera använt batteri enligt fabrikantens
instruktion.

WARNING: If the ground is defeated,certain fault conditions in the unit or in the
system to which it is connected can result in full line voltage between chassis and
earth ground.Severe injury or death can then result if the chassis and earth ground are
touched simultaneously.

DECLARATION OF CONFORMITY

Manufacturers Name: Johnson Amplification
Manufacturers Address: 8760 S. Sandy Parkway

Sandy, Utah 84070, USA

declares that the product:

Product Name: Johnson Marquis JM60/JM120
Product Options: All

conforms to the following Product Specifications:

Safety: EN 60065 (1993)

E 65-94
IEC 65 (1985) with Amendments 1, & 2 (JM60)
IEC 65 (1985) with Amendments 1, 2, & 3 (JM120)

EMC: EN 55013 (1990)

EN 55020 (1991)

Supplementary Information:

The product herewith complies with the requirements of the Low Voltage
Directive 89/336/EEC as amended by Directive 93/68/EEC.

Johnson Amplification

President of Johnson Amplification
8760 S. Sandy Parkway
Sandy, Utah 84070, USA
Tel: [phone]
Fax: [phone]

Effective November 16, 1998
European Contact: Your local Johnson Amplification Sales and Service Office or
International Sales Office

8760 S. Sandy Parkway
Sandy, Utah 84070, USA
Tel: [phone]
Fax: [phone]

We at Johnson Amplification are very proud of our products and back-up each one we sell with the following

Warranty:

1. The warranty registration card must be mailed within ten days after purchase date to validate this warranty .

2. Johnson Amplification warrants this product, when used solely within the U.S., to be free from defects in materials and

workmanship under normal use and service.

3. Johnson Amplification liability under this warranty is limited to repairing or replacing defective materials that show
evidence of defect, provided the product is returned to Johnson Amplification WITH RETURN AUTHORIZATION, where all
parts and labor will be covered up to a period of one year. A Return Authorization number may be obtained from Johnson
Amplification by telephone. The company shall not be liable for any consequential damage as a result of the products use
in any circuit or assembly .

4. Proof-of-purchase is considered to be the burden of the consumer .

5. Johnson Amplification reserves the right to make changes in design, or make additions to, or improvements upon this

product without incurring any obligation to install the same on products previously manufactured.

6. The consumer forfeits the benefits of this warranty if the product’s main assembly is opened and tampered with by
anyone other than a certified Johnson Amplification technician, or if the product is used with AC voltages outside of the
range suggested by the manufacturer .

7. The foregoing is in lieu of all other warranties, expressed or implied, and Johnson Amplification neither assumes nor
authorizes any person to assume any obligation or liability in connection with the sale of this product. In no event shall
Johnson Amplification or its dealers be liable for special consequential damages or from any delay in the performance of
this warranty due to causes beyond their control.

Johnson Amplification is a registered trademark of the Harman Music Group Incorporated

Note: The information contained in this manual is subject to change at any time without notification. Some information
contained in this manual may also be inaccurate due to undocumented changes in the product or operating system since this
version of the manual was completed. The information contained in this version of the owner’s manual supersedes all previous
versions.

Table of Contents

Safety information.....................................................I

Declaration of Conformity.........................................II

Warranty...................................................................III

Table of Contents......................................................IV

Section 1 - Introduction

Congratulations.........................................................1

Included Items..........................................................1

Product Features.......................................................1

Quick Start................................................................2

Hidden Button Accessible Parameters.......................2

A Guided Tour of the JM60/JM120............................3

The Front Panel ........................................................3

The Rear Panel.........................................................5

About the JM60/JM120.............................................6

Amp Section..............................................................6

Effects Section...........................................................6

Performance Mode...................................................6

Section 2 - Using the JM60/JM120

Getting Started ..........................................................7

Making Connections.................................................7

Plug and Play.............................................................7

Stereo Operation.......................................................7

Direct Output............................................................8

Footswitch Connections.............................................8

Powering ..................................................................9

Selecting a Preset......................................................9

Editing a Preset.........................................................9

Selecting an Amp Model............................................9

Amp Models..............................................................9

Editing an Amp Model ..............................................10

Amp Controls............................................................10

Noise Gate.................................................................10

Editing Effects...........................................................11

Selecting Effects........................................................11

JM60 Mod/Pitch Effects ............................................11

JM120 Mod/Pitch Effects ..........................................13

Delay Effects Group ..................................................14

Reverb Effects Group ................................................15

Storing Copying a Preset...........................................16

Section 3 - Guided Example

Creating a Preset ......................................................17

Section 4 - Other Functions

Manual Mode...........................................................19

Foot Controller Options............................................20

J3 .............................................................................20

J8 .............................................................................20

J8 Expression Pedal Calibration ...............................20

External Speaker......................................................21

Headphones .............................................................21

Direct Outputs..........................................................21

Speaker On/Off.........................................................22

Effects Loop..............................................................22

Resetting the JM60/JM120........................................23

Appendix

Preset List.................................................................23

Specifications ...........................................................24

Section-1 Introduction

1

Section 1 - Introduction

Congratulations

on your purchase of the Johnson Marquis JM60/JM120! Thank you for choosing Johnson Amplification.

The Johnson Marquis JM60 and JM120 are two of the most flexible amplifiers in the world. With 18 high quality amp models, a host of
modulation, pitch shifting, delay, and reverb effects all at your command, the JM60/JM120 are truly in a class by themselves. This user’s
guide is your key to understanding how to get the most out of the JM60/JM120. Please read it carefully and familiarize yourself with the
controls on your amp. You’re sure to have endless hours of audio satisfaction by doing so.

Your Marquis was carefully assembled and packaged at the factory. Before you proceed any further, make sure the following items are
included:

• (1) User’s Guide

• (1) Johnson Marquis JM60/JM120 Amplifier

• (1) Johnson Amplification Warranty Card

• (1) Detachable Power Cord

Please take a moment to fill out the warranty registration card, and be sure to save all packing materials. The warranty is your safeguard in
the unlikely event that the unit requires servicing, and the packing materials should be used to return the unit.

Once again, thank you for your purchase, and we are sure you will enjoy your JM60/JM120.

Marquis JM60/JM120 Features:

• 120 Watt Stereo Power Amp

• 100 Watt, 12” Johnson Speaker(s)

• Real 12AX7 Tube Preamp

• Exclusive Johnson Amplification Integrated Amp Modeling

• 18 Different Amp Models

• 3 Effects at Once

• 20 Bit A/D/A

• 24 Bit DSP

• Headphone/Speaker Compensated Direct Outs

• Instant Module Access

• Optional J3 or J8 Foot controller

• Simple User Interface

Quick Start

The JM60/JM120 come with 27 pre-programmed factory presets, and 27 user presets. From the factory, the user presets are
exact duplicates of the factory presets. This allows you to experiment without running the risk of losing any of the original
sounds contained in the JM60/JM120.

For those of you who prefer to burn now and read later, we’ve included this Quick Start section to get you up and running.

Making Connections:

Connect your instrument to the input jack on the front panel. If an extension cabinet is to be used (JM60 only), connect an
unshielded speaker cable from the Extension Speaker Output jack on the rear panel to a satellite speaker cabinet (such as the
J112) with a minimum 8 ohm load.

Optional Foot Controller Connections:

Connect the optional J3 footswitch or J8 foot controller to their designated jacks on the rear panel.

Caution: Do not connect anything but the J3 or J8 foot controllers to the JM60/JM120. Doing so may damage the
device.

Apply Power:

Turn the Master Volume on the JM60/JM120 all the way down. Turn the power switch to the on position. Gradually increase the
master volume control to achieve the desired volume.

Select Preset:

Use the Select knob to scroll through the different presets. Once you have found some presets that suit your taste, you can alter
the sounds to your specific needs.

Each of the various effects will have dedicated knobs which will vary the amount of their associated parameters. The Amp section
has a Gain, Treble, Mid, Bass, Presence (JM120 only), and a preset Level knob. The Mod/Pitch effects section has a Speed and
Depth knob (the JM120 includes a Level knob for the Mod/Pitch effects). The Delay section has a Delay Level, and Feedback
knob. The Reverb section has a Level knob. You can adjust any of these parameters to your liking, and remember that you are
not at risk of losing any sounds so, don’t be afraid to experiment.

Hidden Button Accessible Parameters

There are hidden parameters that can be accessed by holding buttons and turning the Select knob. Here is the list of these
programmable parameters:

Noise Gate Threshold - Press and hold current Model button until display flashes “ ” and a number value. This is the gate

threshold and can be adjusted from Off,1-30, A1-A6. Press any button to exit.

Mod/Pitch Effect Level (JM60 only)- Press and hold Mod/Pitch Select Button. While still holding the button, turn the Select

knob. The current effect level is now displayed and can be adjusted. Press any button
to exit.

Delay Time Fine Adjust - Press and hold TapIt button until display starts flashing “ ” and a number value. This is the

delay time. Use the Select knob to adjust the delay time in 10ms increments. Press any button to
exit.

Section 1 - Introduction

A Guided Tour of the Marquis JM60/JM120

3

Section 1 - Introduction

The Front Panel

1. Input - This 1/4” jack is where you connect your instrument to the JM60/JM120.

2. Master Volume - This knob is used to control the overall output volume on the JM60/JM120.

3. Amp Models - These buttons will instantly select one of the 18 different amplifier models that the JM60/JM120 has available. Each press

of one of these buttons will access a different type of amp model. The LED corresponding to the currently selected amp
model will light as these buttons are used.

3a. American - This button will call up one of the 6 different American Amplifier models. The American Amp models include:

Black Face, Tweed, Rectified, Blues Combo, Boutique, and High Gain.

3b. British - This button will call up one of the 6 different British Amplifier models. The British Amp models

include: Class A Clean, Class A Dirty, High Wattage, Master Volume, Modern Gain, and Hot Rod.

3c. Johnson - This button will select one of the 6 Johnson Amplifier models. The Johnson Amp models include: Clean

Tube (a clean combo setting), Crunch Tube (a smoothly overdriven combo), Saturated Tube (an extra gain and
sustain combo), Fuzz (a high gain fuzz distortion), Overdrive (a smooth crunch distortion), and Metal (a high gain
solid state distortion).

4. Amp Controls - These knobs control all of the amplifiers equalization and levels for each preset.
4a. Gain - This knob controls the amount of distortion gain (drive) for each preset.

4b. Treble - This knob is used to increase or decrease the amount of treble enhancement in each preset.
4c. Mid - This knob is used to increase or decrease the amount of mid-range enhancement in each preset.
4d. Bass - This knob is used to increase or decrease the amount of bass enhancement in each preset.

4e. Presence (JM120 only) - This knob is used to adjust the definition or edge for each preset.
4f. Level - This knob is used to adjust the volume level of each preset.

5) Mod/Pitch Select- This button is used to select one of the 6 different types of modulation or pitch shifting effects (9 on the JM120).

Each press of this button will select a different type of effect. The Mod/Pitch effects in the JM60 include Chorus,
Flanger, Phaser, Tremolo, Vibrato and Pitch Shift. The Mod/Pitch effects in the JM120 include Chorus, Flanger,
Phaser, TremoPan, VibroPan, Ring Modulator, Dual Pitch, Dual Detune, and Rotary Speaker Simulator. The LED next
to the currently selected Mod/Pitch effect will light as this button is pressed. Pressing and holding this button will

bypass the effect. If no LED is lit, the effect is bypassed. To access the Mod/Pitch Level on the JM60, press and hold
the Select button. While still holding the button, begin turning the Select knob. Release the Select button and now
you can adjust the currently selected Mod/Pitch effect level to your liking. Press any button to exit.

6) Delay Select- This button will select the type of delay module being used. Each press of this button will select a new type of

delay module. The delay types include Analog, Delay, and Ping Pong. The LED next to the currently selected
delay type will light as this button is used. Pressing and holding this button will bypass the Delay effect. If no LED is lit, the

effect is bypassed

7) Tap It - This button is used to set the delay time of the delay effect. Tapping this button in tempo with the music will synchronize the

delay repeats with the tempo of the song. Pressing and holding this button will access the Delay Time fine adjust parameter.
Using the Select knob, you can adjust the Delay time in 10ms increments (100 ms when the delay time exceeds 1 second).
Press any button to exit.

8) Reverb Select- This button is used to select one of the 3 different types of reverb. Each press of this button will select a next type of

reverb module. The reverb types include Hall, Plate, and Spring. The LED next to the currently selected reverb type will
light as this button is used. Pressing and holding this button will bypass the effect. If no LED is lit, the effect is bypassed.

9) Numeric Display - This two digit display indicates the currently active Bank and Preset. There are 27 user presets and 27 factory

presets in the JM60/JM120 arranged in 9 banks with 3 different presets in each bank. The first digit in the display
will show the bank number and the second digit shows whether channel 1, 2, or 3 is selected. A decimal point in
the lower right hand corner of the display indicates a factory preset is active.

10) Manual - This button is used to activate the current position of all knobs on the front panel. In other words, the front panel

knob positions will not necessarily reflect the sound of a preset until the Manual button has been pressed. Once
the Manual button is pressed, the sound will correspond to the value of the knobs.

11) Store - This button is used to store your custom settings to one of the user preset locations. The store button will light when changes

have been made to a preset indicating that changes will be lost if they are not stored.

12) Speed - In general, this knob will adjust the speed of the modulation effect. However, it is also used to adjust other parameters

depending on the type of effect that has been chosen. See pages 12-14 for a complete list of the parameters controlled for
each type of effect.

13) Depth - In general, this knob will adjust the depth, or intensity of the modulation effect. However, it is also used to adjust other

parameters depending on the type of effect that has been chosen. See pages 12-14 for a complete list of the parameters
controlled for each type of effect.

14) Level (JM120 only) - This knob adjusts the volume level of the modulation and pitch shift effect.

15) Delay Level - This knob adjusts the volume level of the delay effect.

16) Feedback - This knob will adjust the number of delay repeats.

17) Reverb - This knob adjusts the volume level of the reverb effect.

18) Select - This knob is used to change from one preset to another. It will scroll through all available presets in both the user

and factory banks. Once you have scrolled through the user presets it will shift to the factory presets. If you
continue to turn the knob, it will “wrap around” to the user presets again.

19) Power Switch (JM120 only) - Engages or disengages power.

Section 1 - Introduction

The Rear Panel

5

Section 1 - Introduction

1) Power Switch (JM60 only) - Engages or disengages power.

2) Power Receptacle - Connect the detachable power cord to this jack. The rectangular drawer under the receptacle is the

fuse holder. Use only the fuse size and rating as specified on the back of your amp. A spare fuse is located in a
second pocket of this drawer

3) J8 Foot Controller Jack - This 5 pin din jack is for connecting the optional Johnson J8 foot controller only. THIS IS NOT A

MIDI CONNECTION . Connecting a MIDI device to this jack could damage the device.

4) J3 Footswitch Jack - This jack is for connecting the optional Johnson J3 footswitch. The J3 must use a TRS stereo cable for

connection.

5) External Speaker Jack (JM60 only) - This is a powered output for connecting the J112 external speaker cabinet. Connecting an

extra speaker cabinet must be done in order to utilize the JM60’s stereo capabilities. A
minimum speaker load of 8 Ωs is required.

6) Headphone Jack - This stereo TRS jack is used to connect a pair of stereo headphones. It can also be used as a speaker

compensated direct out for direct to mixing console connections.

7) Speaker On/Off Switch - This switch enables or disables the internal speaker on the JM60/JM120 for those times when

you do not want the speaker active such as during direct recording.

8) Loop Return - This stereo TRS jack is used to connect from the outputs of an external effect device to the JM60/JM120. It is a

stereo input to the stereo power amp within the Marquis. Connecting a mono cable will provide just a mono
return, and effects in the loop will only be heard from the internal speaker.

9) Loop Send - This stereo TRS jack is used to connect from the JM60/JM120 to the inputs of an external effect device. It is a post

preamp, post effects stereo output. *

* Note: The effect loop of the Marquis JM60/JM120 is designed for use with rack mount effects only. The output level may
not be suitable for pedal type effects and may overdrive their input stage.
