ITEM #: QTY:
MODEL #:
PROJECT NAME:
010118
3601 S. Banker St. Effingham, IL 62401 • P.O. BOX 609 • Ph: (888) 431-2667 • Fax: (800) 433-2667
"JNS" MAPLE TOP WORK TABLES
1-1/2" THICK HARD ROCK MAPLE FLAT TOP W/
GALVANIZED BASE & ADJUSTABLE UNDERSHELF
FEATURES:
• 1-1/2" THICK HARD MAPLE TOP, STYLE "SCT" FLAT TOP
• MAPLE TOP W/ OIL FINISH W/ OPTIONAL VARNIQUE FINISH
• GALVANIZED STEEL BASE AND ADJUSTABLE UNDERSHELF
• ADJUSTABLE BULLET FEET
• SHIPPED KNOCKED-DOWN, EASY-TO-ASSEMBLE
• ALL MODELS ARE APPROVED BY THE NSF
MATERIAL:
• TOP: NORTHERN HARD ROCK MAPLE
• SHELF: 18 GAUGE GALVANIZED STEEL,
(*6FT TABLE ONLY, 16 GAUGE)
• LEGS: 16 GAUGE GALVANIZED STEEL
• GUSSETS: GALVANIZED STEEL
• FEET: 1" ADJUSTABLE GALVANIZED STEEL
OPTIONAL ACCESSORIES
DESCRIPTION MODEL QTY
DRAWER
DRAWER LOCK
CASTERS
ADJ. SHELF
OVERSHELVES
POT RACK
MAPLE TOP WORK TABLES
24” WIDE QTY 30" WIDE QTY 36" WIDE QTY
JNS01 JNS08 JNS15
JNS02 JNS09 JNS16
JNS03 JNS10 J N S17
JNS04 J N S11 JNS18
JNS05 JN S12 JNS19
JNS06 JN S13 JNS20
JNS06A JNS13A JNS20A
JNS07 JN S14 J NS21
392
Page 2
DETAILED SPECIFICATIONS
L
CLEARANCE =
L - 9 .625"
÷
2"
DETAILED SPECIFICATIONS
L
W
DETAILED SPECIFICATIONS
L W
35"
12"
L
CLEARANCE =
L-8"
CLEARANCE =
L - 9 .625"
÷
2"
L
W
1 1/2"
DETAILED SPECIFICATIONS
35"
L
CLEARANCE =
L - 9 .625"
÷
2"
W
1 1/2"
• UNITS 7 FT. AND LARGER ARE FURNISHED WITH SIX LEGS.
• FINISHED SIZE OF UNDERSHELF.
SHELF LENGTH = LENGTH MINUS 4.875”
SHELF WIDTH = WIDTH MINUS 4.25”
MAPLE TOP WORK TABLES
LENGTH 24” WIDE WT. ( LBS) 30" WIDE W T. (L B S) 36" WIDE W T. (LB S)
36 JNS01 68 JNS08 82 JNS15 92
48 JNS02 86 JNS09 104 JNS16 117
60 JNS03 104 JNS10 126 JNS17 142
72 JNS04 128 JN S011 151 JNS18 171
84 JNS05 14 4 JN S112 181 JNS19 204
96 JNS06 165 JNS13 200 J NS20 226
108 JNS06A 176 JNS13A 215 JNS20A 250
120 JNS07 19 3 J NS14 237 J NS21 270
SOME UNITS SHIP UNASSEM BLED FOR RED UCED SHI PPING COST. ALL DIMENSIO NS ARE T YPICA L. TOLER ANCE +/- . 500"
John Boos & Co. is constantly engaged in a program of improving products and therefore reserves the right to change specications without prior notice.
3601 S. Banker St. • Effingham, IL 62401 • PO BOX 609 • [email protected]
www.johnboos.com
010118
